DD5L Series
Dome Drive
Installation/
Operation Manual
C1471M (10/98)
Pelco • 3500 Pelco Way, Clovis • CA 93612-5699 USA • www.pelco.com
In North America and Canada: Tel (800) 289-9100 or FAX (800) 289-9150
International Customers: Tel (1-209) 292-1981 or FAX (1-209) 348-1120
CONTENTS
Section Page
1.0 GENERAL .................................................................................................. 3
1.1 IMPORTANT SAFEGUARDS AND WARNINGS ............................... 3
1.2 UNPACKING INSTRUCTIONS ..........................................................4
2.0 DESCRIPTION .......................................................................................... 5
2.1 MODELS ............................................................................................5
3.0 INSTALLATION .......................................................................................... 6
4.0 OPERATION .............................................................................................13
4.1 POWER-UP DISPLAY ...................................................................... 13
4.2 PAN AND TILT FUNCTIONS ............................................................ 13
4.2.1 Auto Flip ................................................................................ 13
4.2.2 Scan Speed .......................................................................... 13
4.3 ZOOM ............................................................................................... 14
4.4 PRESET FUNCTIONS ...................................................................... 14
4.5 RANDOM, FRAME, AND AUTO SCANNING ................................... 14
4.6 PARK ................................................................................................ 15
4.7 PROGRAMMING THE SPECTRA® LITE .......................................... 15
4.7.1 Main Menu Access................................................................ 15
4.7.2 Backlight Compensation .......................................................16
4.7.3 Reset Camera ....................................................................... 16
4.7.4 Gain/AGC ............................................................................. 17
4.7.4.1 AGC Mode ........................................................... 17
4.7.4.2 Gain .....................................................................17
4.7.5 Shutter Speed ....................................................................... 18
4.7.6 Sharpness ............................................................................. 18
4.7.7 White Balance ....................................................................... 18
4.7.8 Line Synchronization ............................................................ 19
4.7.9 Power Up Mode ....................................................................19
4.7.10 Auto Flip ................................................................................ 20
4.7.11 Limit Stops ............................................................................20
4.7.11.1 Turning Limit Stops On or Off ..............................20
4.7.11.2 Programming Limit Stops .................................... 20
4.7.12 Park Time Minutes ................................................................21
5.0 TROUBLESHOOTING ..............................................................................22
6.0 MAINTENANCE ........................................................................................22
7.0 SPECIFICATIONS ....................................................................................23
8.0 WARRANTY AND RETURN INFORMATION ........................................... 24
4.7.13 Scan Speed .......................................................................... 21
6.1 DOME CLEANING ............................................................................ 22
6.2 SERVICE MANUAL .......................................................................... 22
LIST OF ILLUSTRATIONS
Figure Page
1 System Components (In-Ceiling Model Shown) ................................ 4
2 Backlight ........................................................................................... 16
LIST OF TABLES
Table Page
A Switch Settings for SW1 .................................................................... 6
B Switch Settings for SW2 – P-Type Control ........................................ 7
C Switch Settings for SW2 – D-Type Control ........................................8
REVISION HISTORY
Manual # Date Comments
C1471CM 10/98 Original version.
2 Pelco Manual C1471M (10/98)
1.0 GENERAL
1.1 IMPORTANT SAFEGUARDS AND WARNINGS
Observe the following WARNINGS before installing and using this product.
1. Installation and servicing should only be done by qualified service personnel
and conform to all local codes.
2. Unless the unit is specifically marked as a NEMA Type 3, 3R, 3S, 4, 4X, 6, or
6P enclosure, it is designed for indoor use only and it must not be installed
where exposed to rain and moisture.
3. Only use replacement parts Pelco recommends.
4. After replacing or repairing this unit’s electrical components, measure the resistance between the line and exposed parts to verify the exposed parts have
not been connected to line circuitry.
5. The installation method and materials should be capable of supporting four
times the weight of the enclosure, pan and tilt, camera and lens combination.
The product and/or manual may bear the following marks:
This symbol indicates that dangerous voltage constituting a
risk of electric shock is present within this unit.
This symbol indicates that there are important operating and
maintenance instructions in the literature accompanying this
unit.
CAUTION:
RISK OF
ELECTRIC SHOCK.
DO NOT OPEN.
TO REDUCE THE RISK OF ELECTRICAL SHOCK,
DO NOT REMOVE COVER. NO USER-
SERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
CAUTION:
Please thoroughly familiarize yourself with the information
in this manual prior to installation and operation.
Pelco Manual C1471M (10/98) 3
1.2 UNPACKING INSTRUCTIONS
This box contains one dome drive and one Installation/Operation manual (C1471M).
Inspect all parts carefully. Save the shipping carton, boxes, and inserts. If an item
appears damaged, replace it in its box and contact the factory at 1-800-289-9100
or 1-209-292-1981 for replacement. (International customers fax 1-209-348-1120
for authorization and instructions.) To return an item to the factory for repair, refer to
Section 8.0, WARRANTY AND RETURN, for instructions.
BACK
BOX
DOME
DRIVE
LOWER
DOME
Figure 1. System Components (In-Ceiling Model Shown)
4 Pelco Manual C1471M (10/98)
Spectra® Lite domes can do the following:
• 360° pan rotation
• preset positioning
• +2 to -92° tilt
• variable speed
All Spectra
capability to focus when going to a preset position. An integral receiver has a switch
to select the type of control. The receiver supports Coaxitron
types. The dome operates on 24 VAC. The dome drive is quickly installed and
removed from the back box without tools.
2.1 MODELS
DD5L-C Dome drive with color camera and lens, NTSC standard
2.0 DESCRIPTION
®
Lite models include a color CCD camera with a 12X zoom lens and
®
and RS-422 control
Pelco Manual C1471M (10/98) 5
3.0 INSTALLATION
NOTE:
For Coaxitron® control,
SW2 is not used and all switches
must
be OFF.
CAUTION:
Make
sure the dome drive
locks into place. Pull
down on the dome
drive with moderate
pressure to ensure
that it stays in place.
Control Type Switch Setting
Coaxitron
P-Type Control ON OFF OFF OFF OFF OFF OFF OFF**
D-Type Control OFF ON OFF OFF OFF OFF OFF* OFF**
NOTES: Switches SW1-3 through SW1-6 MUST be OFF.
®
D-type control is RS-422 that is compatible with Pelco‘s CM6700, MPT9500 and CM8500
controllers or with American Dynamics control systems using the AD2083 Translator.
P-type control is RS-422 that is compatible with Pelco's CM6700/CM9750/CM9760 control systems.
* OFF- Use with controllers that have more than 32 presets.
ON- Use with American Dynamics controllers (32 presets).
** OFF - Use with all control systems except CM9502 with variable speed keyboards.
ON - Use with CM9502 with variable speed keyboards for smoother joystick control.
SW1-1 SW1-2 SW1-3 SW1-4 SW1-5 SW1-6 SW1-7 SW1-8
OFF OFF OFF OFF OFF OFF OFF OFF**
For CM9502 with fixed speed keyboards, set switch OFF.
1. Turn on power to the back box. The red LED should light to indicate power. If
the LED does not light, correct the trouble before proceeding. (Refer to Section 6.0, TROUBLESHOOTING, in manual C1487M.) If the light operates,
you may either leave power on or turn it off before continuing the installation.
2. Set the switches on the bottom of the dome drive. Refer to Table A for the
settings for SW1, and Table B and Table C for SW2.
3. Install the dome drive in the back box. Line up the green tab and red tab on
the dome drive with the green label and red label on the back box. Raise the
dome drive into the back box and push on the ends of the tabs until they both
click into place on the back box.
4. Turn on power, if it is not on. Listen for the fan operating. If the fan does not
work, the dome will overheat and shut down. If the fan does not work, return
the back box electronic assembly and dome drive to the factory for repair.
Refer to Section 6.1, BACK BOX ELECTRONIC ASSEMBLY REMOVAL, in
manual C1487M.
Table A. Switch Settings for SW1
6 Pelco Manual C1471M (10/98)
Table B. Switch Settings for SW2 – P-Type Control
NOTE:
For Coaxitron® controls, all switches on SW2 MUST be OFF.
For D-type control systems, refer to Table C.
Receiver Address Switch Setting
1 OFF OFF OFF OFF OFF
2ONOFF OFF OFF OFF
3 OFF ON OFF OFF OFF
4ONONOFF OFF OFF
5 OFF OFF ON OFF OFF
6ONOFF ON OFF OFF
7 OFF ON ON OFF OFF
8ONONONOFF OFF
9 OFF OFF OFF ON OFF
10 ON OFF OFF ON OFF
11 OFF ON OFF ON OFF
12 ON ON OFF ON OFF
13 OFF OFF ON ON OFF
14 ON OFF ON ON OFF
15 OFF ON ON ON OFF
16 ON ON ON ON OFF
17 OFF OFF OFF OFF ON
18 ON OFF OFF OFF ON
19 OFF ON OFF OFF ON
20 ON ON OFF OFF ON
21 OFF OFF ON OFF ON
22 ON OFF ON OFF ON
23 OFF ON ON OFF ON
24 ON ON ON OFF ON
25 OFF OFF OFF ON ON
26 ON OFF OFF ON ON
27 OFF ON OFF ON ON
28 ON ON OFF ON ON
29 OFF OFF ON ON ON
30 ON OFF ON ON ON
31 OFF ON ON ON ON
32 ON ON ON ON ON
SW2-1 SW2-2 SW2-3 SW2-4 SW2-5
Baud Rate Switch Setting
2400 OFF OFF OFF
4800 ON OFF OFF
9600 OFF ON OFF
SW2-6 SW2-7 SW2-8
Pelco Manual C1471M (10/98) 7
Table C. Switch Settings for SW2 – D-Type Control
NOTE:
For Coaxitron® controls, all switches on SW2 MUST be OFF.
For P-type control systems, refer to Table B.
Receiver Address Switch Setting
SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8
1ONOFF OFF OFF OFF OFF OFF OFF
2 OFF ON OFF OFF OFF OFF OFF OFF
3ONONOFF OFF OFF OFF OFF OFF
4 OFF OFF ON OFF OFF OFF OFF OFF
5ONOFF ON OFF OFF OFF OFF OFF
6 OFF ON ON OFF OFF OFF OFF OFF
7ONONONOFFOFF OFF OFF OFF
8 OFF OFF OFF ON OFF OFF OFF OFF
9ONOFF OFF ON OFF OFF OFF OFF
10 OFF ON OFF ON OFF OFF OFF OFF
11 ON ON OFF ON OFF OFF OFF OFF
12 OFF OFF ON ON OFF OFF OFF OFF
13 ON OFF ON ON OFF OFF OFF OFF
14 OFF ON ON ON OFF OFF OFF OFF
15 ON ON ON ON OFF OFF OFF OFF
16 OFF OFF OFF OFF ON OFF OFF OFF
17 ON OFF OFF OFF ON OFF OFF OFF
18 OFF ON OFF OFF ON OFF OFF OFF
19 ON ON OFF OFF ON OFF OFF OFF
20 OFF OFF ON OFF ON OFF OFF OFF
21 ON OFF ON OFF ON OFF OFF OFF
22 OFF ON ON OFF ON OFF OFF OFF
23 ON ON ON OFF ON OFF OFF OFF
24 OFF OFF OFF ON ON OFF OFF OFF
25 ON OFF OFF ON ON OFF OFF OFF
26 OFF ON OFF ON ON OFF OFF OFF
27 ON ON OFF ON ON OFF OFF OFF
28 OFF OFF ON ON ON OFF OFF OFF
29 ON OFF ON ON ON OFF OFF OFF
30 OFF ON ON ON ON OFF OFF OFF
31 ON ON ON ON ON OFF OFF OFF
32 OFF OFF OFF OFF OFF ON OFF OFF
33 ON OFF OFF OFF OFF ON OFF OFF
34 OFF ON OFF OFF OFF ON OFF OFF
35 ON ON OFF OFF OFF ON OFF OFF
36 OFF OFF ON OFF OFF ON OFF OFF
37 ON OFF ON OFF OFF ON OFF OFF
38 OFF ON ON OFF OFF ON OFF OFF
39 ON ON ON OFF OFF ON OFF OFF
40 OFF OFF OFF ON OFF ON OFF OFF
41 ON OFF OFF ON OFF ON OFF OFF
42 OFF ON OFF ON OFF ON OFF OFF
43 ON ON OFF ON OFF ON OFF OFF
44 OFF OFF ON ON OFF ON OFF OFF
45 ON OFF ON ON OFF ON OFF OFF
46 OFF ON ON ON OFF ON OFF OFF
47 ON ON ON ON OFF ON OFF OFF
48 OFF OFF OFF OFF ON ON OFF OFF
49 ON OFF OFF OFF ON ON OFF OFF
50 OFF ON OFF OFF ON ON OFF OFF
51 ON ON OFF OFF ON ON OFF OFF
52 OFF OFF ON OFF ON ON OFF OFF
53 ON OFF ON OFF ON ON OFF OFF
54 OFF ON ON OFF ON ON OFF OFF
55 ON ON ON OFF ON ON OFF OFF
56 OFF OFF OFF ON ON ON OFF OFF
Continued on next page
8 Pelco Manual C1471M (10/98)
Table C. Switch Settings for SW2 – D-Type Control (Continued)
NOTE:
For Coaxitron® controls, all switches on SW2 MUST be OFF.
For P-type control systems, refer to Table B.
Receiver Address Switch Setting
SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8
57 ON OFF OFF ON ON ON OFF OFF
58 OFF ON OFF ON ON ON OFF OFF
59 ON ON OFF ON ON ON OFF OFF
60 OFF OFF ON ON ON ON OFF OFF
61 ON OFF ON ON ON ON OFF OFF
62 OFF ON ON ON ON ON OFF OFF
63 ON ON ON ON ON ON OFF OFF
64 OFF OFF OFF OFF OFF OFF ON OFF
65 ON OFF OFF OFF OFF OFF ON OFF
66 OFF ON OFF OFF OFF OFF ON OFF
67 ON ON OFF OFF OFF OFF ON OFF
68 OFF OFF ON OFF OFF OFF ON OFF
69 ON OFF ON OFF OFF OFF ON OFF
70 OFF ON ON OFF OFF OFF ON OFF
71 ON ON ON OFF OFF OFF ON OFF
72 OFF OFF OFF ON OFF OFF ON OFF
73 ON OFF OFF ON OFF OFF ON OFF
74 OFF ON OFF ON OFF OFF ON OFF
75 ON ON OFF ON OFF OFF ON OFF
76 OFF OFF ON ON OFF OFF ON OFF
77 ON OFF ON ON OFF OFF ON OFF
78 OFF ON ON ON OFF OFF ON OFF
79 ON ON ON ON OFF OFF ON OFF
80 OFF OFF OFF OFF ON OFF ON OFF
81 ON OFF OFF OFF ON OFF ON OFF
82 OFF ON OFF OFF ON OFF ON OFF
83 ON ON OFF OFF ON OFF ON OFF
84 OFF OFF ON OFF ON OFF ON OFF
85 ON OFF ON OFF ON OFF ON OFF
86 OFF ON ON OFF ON OFF ON OFF
87 ON ON ON OFF ON OFF ON OFF
88 OFF OFF OFF ON ON OFF ON OFF
89 ON OFF OFF ON ON OFF ON OFF
90 OFF ON OFF ON ON OFF ON OFF
91 ON ON OFF ON ON OFF ON OFF
92 OFF OFF ON ON ON OFF ON OFF
93 ON OFF ON ON ON OFF ON OFF
94 OFF ON ON ON ON OFF ON OFF
95 ON ON ON ON ON OFF ON OFF
96 OFF OFF OFF OFF OFF ON ON OFF
97 ON OFF OFF OFF OFF ON ON OFF
98 OFF ON OFF OFF OFF ON ON OFF
99 ON ON OFF OFF OFF ON ON OFF
100 OFF OFF ON OFF OFF ON ON OFF
101 ON OFF ON OFF OFF ON ON OFF
102 OFF ON ON OFF OFF ON ON OFF
103 ON ON ON OFF OFF ON ON OFF
104 OFF OFF OFF ON OFF ON ON OFF
105 ON OFF OFF ON OFF ON ON OFF
106 OFF ON OFF ON OFF ON ON OFF
107 ON ON OFF ON OFF ON ON OFF
108 OFF OFF ON ON OFF ON ON OFF
109 ON OFF ON ON OFF ON ON OFF
110 OFF ON ON ON OFF ON ON OFF
111 ON ON ON ON OFF ON ON OFF
112 OFF OFF OFF OFF ON ON ON OFF
Continued on next page
Pelco Manual C1471M (10/98) 9
Table C. Switch Settings for SW2 – D-Type Control (Continued)
NOTE:
For Coaxitron® controls, all switches on SW2 MUST be OFF.
For P-type control systems, refer to Table B.
Receiver Address Switch Setting
SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8
113 ON OFF OFF OFF ON ON ON OFF
114 OFF ON OFF OFF ON ON ON OFF
115 ON O N OFF OFF ON ON ON OFF
116 OFF OFF ON OFF ON ON ON OFF
117 ON OFF ON OFF ON ON ON OFF
118 OFF ON ON OFF ON ON ON OFF
119 ON O NONOFFONON ON OFF
120 OFF OFF OFF ON ON ON ON OFF
121 ON OFF OFF ON ON ON ON OFF
122 OFF ON OFF ON ON ON ON OFF
123 ON ON OFF ON ON ON ON OFF
124 OFF OFF ON ON ON ON ON OFF
125 ON OFF ON ON ON ON ON OFF
126 OFF ON ON ON ON ON ON OFF
127 ON ON ON ON ON ON ON OFF
128 OFF OFF OFF OFF OFF OFF OFF ON
129 ON OFF OFF OFF OFF OFF OFF ON
130 OFF ON OFF OFF OFF OFF OFF ON
131 ON ON OFF OFF OFF OFF OFF ON
132 OFF OFF ON OFF OFF OFF OFF ON
133 ON OFF ON OFF OFF OFF OFF ON
134 OFF ON ON OFF OFF OFF OFF ON
135 ON ON ON OFF OFF OFF OFF ON
136 OFF OFF OFF ON OFF OFF OFF ON
137 ON OFF OFF ON OFF OFF OFF ON
138 OFF ON OFF ON OFF OFF OFF ON
139 ON ON OFF ON OFF OFF OFF ON
140 OFF OFF ON ON OFF OFF OFF ON
141 ON OFF ON ON OFF OFF OFF ON
142 OFF ON ON ON OFF OFF OFF ON
143 ON ON ON ON OFF OFF OFF ON
144 OFF OFF OFF OFF ON OFF OFF ON
145 ON OFF OFF OFF ON OFF OFF ON
146 OFF ON OFF OFF ON OFF OFF ON
147 ON ON OFF OFF ON OFF OFF ON
148 OFF OFF ON OFF ON OFF OFF ON
149 ON OFF ON OFF ON OFF OFF ON
150 OFF ON ON OFF ON OFF OFF ON
151 ON ON ON OFF ON OFF OFF ON
152 OFF OFF OFF ON ON OFF OFF ON
153 ON OFF OFF ON ON OFF OFF ON
154 OFF ON OFF ON ON OFF OFF ON
155 ON ON OFF ON ON OFF OFF ON
156 OFF OFF ON ON ON OFF OFF ON
157 ON OFF ON ON ON OFF OFF ON
158 OFF ON ON ON ON OFF OFF ON
159 ON ON ON ON ON OFF OFF ON
160 OFF OFF OFF OFF OFF ON OFF ON
161 ON OFF OFF OFF OFF ON OFF ON
162 OFF ON OFF OFF OFF ON OFF ON
163 ON ON OFF OFF OFF ON OFF ON
164 OFF OFF ON OFF OFF ON OFF ON
165 ON OFF ON OFF OFF ON OFF ON
166 OFF ON ON OFF OFF ON OFF ON
167 ON ON ON OFF OFF ON OFF ON
168 OFF OFF OFF ON OFF ON OFF ON
Continued on next page
10 Pelco Manual C1471M (10/98)
Table C. Switch Settings for SW2 – D-Type Control (Continued)
NOTE:
For Coaxitron® controls, all switches on SW2 MUST be OFF.
For P-type control systems, refer to Table B.
Receiver Address Switch Setting
SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8
169 ON OFF OFF ON OFF ON OFF ON
170 OFF ON OFF ON OFF ON OFF ON
171 ON ON OFF ON OFF ON OFF ON
172 OFF OFF ON ON OFF ON OFF ON
173 ON OFF ON ON OFF ON OFF ON
174 OFF ON ON ON OFF ON OFF ON
175 ON ON ON ON OFF ON OFF ON
176 OFF OFF OFF OFF ON ON OFF ON
177 ON OFF OFF OFF ON ON OFF ON
178 OFF ON OFF OFF ON ON OFF ON
179 ON ON OFF OFF ON ON OFF ON
180 OFF OFF ON OFF ON ON OFF ON
181 ON OFF ON OFF ON ON OFF ON
182 OFF ON ON OFF ON ON OFF ON
183 ON ON ON OFF ON ON OFF ON
184 OFF OFF OFF ON ON ON OFF ON
185 ON OFF OFF ON ON ON OFF ON
186 OFF ON OFF ON ON ON OFF ON
187 ON ON OFF ON ON ON OFF ON
188 OFF OFF ON ON ON ON OFF ON
189 ON OFF ON ON ON ON OFF ON
190 OFF ON ON ON ON ON OFF ON
191 ON ON ON ON ON ON OFF ON
192 OFF OFF OFF OFF OFF OFF ON ON
193 ON OFF OFF OFF OFF OFF ON ON
194 OFF ON OFF OFF OFF OFF ON ON
195 ON ON OFF OFF OFF OFF ON ON
196 OFF OFF ON OFF OFF OFF ON ON
197 ON OFF ON OFF OFF OFF ON ON
198 OFF ON ON OFF OFF OFF ON ON
199 ON ON ON OFF OFF OFF ON ON
200 OFF OFF OFF ON OFF OFF ON ON
201 ON OFF OFF ON OFF OFF ON ON
202 OFF ON OFF ON OFF OFF ON ON
203 ON ON OFF ON OFF OFF ON ON
204 OFF OFF ON ON OFF OFF ON ON
205 ON OFF ON ON OFF OFF ON ON
206 OFF ON ON ON OFF OFF ON ON
207 ON ON ON ON OFF OFF ON ON
208 OFF OFF OFF OFF ON OFF ON ON
209 ON OFF OFF OFF ON OFF ON ON
210 OFF ON OFF OFF ON OFF ON ON
211 ON ON OFF OFF ON OFF ON ON
212 OFF OFF ON OFF ON OFF ON ON
213 ON OFF ON OFF ON OFF ON ON
214 OFF ON ON OFF ON OFF ON ON
215 ON ON ON OFF ON OFF ON ON
216 OFF OFF OFF ON ON OFF ON ON
217 ON OFF OFF ON ON OFF ON ON
218 OFF ON OFF ON ON OFF ON ON
219 ON ON OFF ON ON OFF ON ON
220 OFF OFF ON ON ON OFF ON ON
221 ON OFF ON ON ON OFF ON ON
222 OFF ON ON ON ON OFF ON ON
223 ON ON ON ON ON OFF ON ON
224 OFF OFF OFF OFF OFF ON ON ON
Continued on next page
Pelco Manual C1471M (10/98) 11
Table C. Switch Settings for SW2 – D-Type Control (Continued)
NOTE:
For Coaxitron® controls, all switches on SW2 MUST be OFF.
For P-type control systems, refer to Table B.
Receiver Address Switch Setting
SW2-1 SW2-2 SW2-3 SW2-4 SW2-5 SW2-6 SW2-7 SW2-8
225 ON OFF OFF OFF OFF ON ON ON
226 OFF ON OFF OFF OFF ON ON ON
227 ON ON OFF OFF OFF ON ON ON
228 OFF OFF ON OFF OFF ON ON ON
229 ON OFF ON OFF OFF ON ON ON
230 OFF ON ON OFF OFF ON ON ON
231 ON ON ON OFF OFF ON ON ON
232 OFF OFF OFF ON OFF ON ON ON
233 ON OFF OFF ON OFF ON ON ON
234 OFF ON OFF ON OFF ON ON ON
235 ON ON OFF ON OFF ON ON ON
236 OFF OFF ON ON OFF ON ON ON
237 ON OFF ON ON OFF ON ON ON
238 OFF ON ON ON OFF ON ON ON
239 ON ON ON ON OFF ON ON ON
240 OFF OFF OFF OFF ON ON ON ON
241 ON OFF OFF OFF ON ON ON ON
242 OFF ON OFF OFF ON ON ON ON
243 ON ON OFF OFF ON ON ON ON
244 OFF OFF ON OFF ON ON ON ON
245 ON OFF ON OFF ON ON ON ON
246 OFF ON ON OFF ON ON ON ON
247 ON ON ON OFF ON ON ON ON
248 OFF OFF OFF ON ON ON ON ON
249 ON OFF OFF ON ON ON ON ON
250 OFF ON OFF ON ON ON ON ON
251 ON ON OFF ON ON ON ON ON
252 OFF OFF ON ON ON ON ON ON
253 ON OFF ON ON ON ON ON ON
254 OFF ON ON ON ON ON ON ON
12 Pelco Manual C1471M (10/98)
The red LED in the back box interconnect door lights when power is turned on and
the fan exhausts heat from inside the back box. If you have an outdoor pendant
model with a heater, heater elements in the back box turn on at 70°F (21°C) and off
at 85°F (29°C). The heater element in the lower dome turns on at 40°F (4°C) and
off at 60°F (16°C). The interconnect door fan and heater fans in the outdoor back
box operate continuously.
4.1 POWER-UP DISPLAY
4.0 OPERATION
NOTE:
The dome will stop operating if voltage at the dome drops
below 18 VAC. It will turn back on
and go through its start-up routine
when the voltage exceeds 18 VAC.
When the dome is powered up or reset, the monitor displays the selected protocol,
revision number, and other information, which remains until the dome moves. The
information displayed depends on the selected protocol and the choice made on
the menu for selectable power-up mode. As a default, the dome goes to a random
position.
The control system protocol (C, D, or P) appears. C is for Pelco’s Coaxitron® control system. D-type control is RS-422 compatible with Pelco’s CM6700, MPT9500,
and CM8500 controllers or with American Dynamics control systems using the
AD2083 Translator. P-type control is RS-422 compatible with Pelco’s CM6700 and
CM9750/CM9760 control systems.
For D and P protocols, the device address, baud rate, parity (N), number of data
bits (8), and number of stop bits (1) appears. For D protocol, “32 presets” appears
if the 32-preset mode is selected (SW1-7 ON). “CM9500 mode” appears if CM9500
mode is selected (SW1-8 ON).
4.2 PAN AND TILT FUNCTIONS
Use your controller’s joystick to control pan and tilt operation.
• Fixed-Speed Controllers - Pan and tilt operation is at a fixed speed; the
controller determines the speed.
•Variable-Speed Controllers - Depending on the joystick’s position, standard
pan operation ranges from 0.5 to 80 degrees per second (dps); standard tilt
operation ranges from 0.5 to 40 dps. When performing preset operations, pan
speed is 250 dps; tilt speed is 100 dps. In turbo mode, pan speed is 150 dps,
while turbo mode does not affect tilt speed.
4.2.1 Auto Flip
When the camera tilts down and just beyond vertical, the dome rotates 180 degrees. When the dome rotates (flips), the camera starts moving upward while you
continue holding the joystick in the down position. Once you release the joystick
after the dome rotates, joystick control returns to normal operation. Auto-flip is useful for following someone who passes directly beneath the camera. You can disable
this feature in the auto flip programming menu.
4.2.2 Scan Speed
Scan speed is adjustable from 1 to 40 degrees per second through the programming menu.
Pelco Manual C1471M (10/98) 13
4.3 ZOOM
The Spectra® Lite dome can magnify an object up to 12 times (12X of optical
zoom).
Zoom Telephoto - Press and hold down the Zoom Tele button until you have the
picture you want.
Zoom Wide - Press the Zoom Wide button to increase the field of view.
4.4 PRESET FUNCTIONS
NOTE:
For AMERICAN DYNAMICS controllers with only 32 presets, set switch SW1-7 on the
dome drive in the ON position.
When SW1-7 is ON, preset
99 becomes 32
98 becomes 31
97 becomes 30
96 becomes 29
95 becomes 28
94 becomes 27
93 becomes 26
92 becomes 25
91 becomes 24
90 becomes 23
If the limit stops are turned off (refer to Section 4.7.11.1), presets 2326 can be used as regular presets.
NOTE
:
In the following material,
sometimes a number in parentheses follows a preset. This second
number is for 32-preset mode
(conversion that lets Pelco’s presets work with American Dynamics controllers). If you are using an
American Dynamics controller,
use the number in parentheses.
The Spectra® Lite dome can go to 32 preset locations, each with a 20-character
label. Presets are numbered 1-32. Refer to your control system documentation for
programming presets.
When doing a preset operation, the amount of error in moving to the pan and tilt
positions is 1/2 degree. You may get erratic operation if you command the dome to
go to an undefined preset.
Presets 33 and 34 are fixed commands (you cannot program them). Preset 33 is
the “flip” command, which pans the dome drive 180 degrees from its current position. Preset 34 is the “pan zero” command, which directs the dome drive to the
factory-determined zero reference point. The following presets are reserved for
special functions.
Preset Function
1 Park (Section 4.7.12)
33 Flip command (Section 4.4)
34 Pan zero command (Section 4.4)
90-93 Limit stops (Sections 4.5 and 4.7.11)
95 Select camera programming menu (Section 4.7.1)
96 Stop a scan (Section 4.5)
97-99 Activate scanning (Section 4.5)
4.5 RANDOM, FRAME, AND AUTO SCANNING
Program preset 97 (30) to start random scanning. Program preset 98 (31) to activate frame scanning (three seconds of scanning followed by a three-second pause).
Program preset 99 (32) to start auto (continuous) scanning.
Software controls scan limit stops. When the dome reaches one, it immediately
reverses direction. Refer to Section 4.7.11, LIMIT STOPS, to program the scan
limit stops. Program preset 96 (29) to stop a scan. Any pan and tilt or lens command also stops a scan.
14 Pelco Manual C1471M (10/98)
4.6 PARK
If the dome does not receive any commands for a specified period, it goes to preset
1 and parks. The dome will not park if the time specified is zero or preset 1 has not
been programmed. The default is zero minutes.
4.7 PROGRAMMING THE SPECTRA® LITE
The dome can be programmed for the following functions:
AGC (automatic gain control) Gain Sharpness
Auto flip disable Limit stops Shutter speed
Auto park time Power line synchronization White balance
Backlight compensation Power-up mode
Camera reset Scan speed
The main menu contains four secondary menus: Camera, Line Sync, Power Up,
and Other. Each secondary menu has submenus, which are structured as shown
below. Beside the menu items are section numbers in parentheses showing where
the functions are explained.
1. Camera
First Camera Submenu Second Camera Submenu
Backlight comp (4.7.2) Shutter speed (4.7.5)
Reset camera (4.7.3) Sharpness (4.7.6)
Gain/AGC (4.7.4) Auto sharpness
AGC mode Sharpness
Gain White balance (4.7.7)
Next (to second camera Auto white bal
submenu) M-G white bal
Prev (to first camera submenu)
2. Line Sync (4.7.8) 3. Power Up (4.7.9)
Line sync Power up
Line sync phase
4. Other
Auto flip (4.7.10)
Limit stops (4.7.11)
Park time minutes (4.7.12)
Scan speed deg/s (4.7.13)
The following sections explain how to program the Spectra® Lite dome using the
menu choices.
4.7.1 Main Menu Access
You can call up the main menu on your monitor by programming (setting or creating) preset 95 (28). Programming preset 95 varies according to the type of controller you are using. Below are instructions for programming preset 95 for various
controllers.
CM6700
1. Enter the number of the Spectra® Lite camera and press the CAM key.
2. Enter 95 and hold the PRESET key for two seconds.
3. In the Edit Preset menu, arrow to SET and press the ACK key. The main menu
appears.
CM8500
1. Enter the number of the Spectra® Lite camera and press the CAM key.
2. Highlight PRESET in the Camera menu and hold down the joystick button
until the Set Presets prompt appears.
3. Enter 95 and press the PRESET key. The main menu appears.
Pelco Manual C1471M (10/98) 15
CM9500
1. Enter the number of the Spectra® Lite camera and press the CAM key.
2. Press the SELECT key twice.
3. Highlight CAM in the Setup menu and press the SELECT key.
4. Highlight PRESET in the Camera menu and press the SELECT key.
5. Enter 95 and press the F1 key. The main menu appears.
CM9750
1. Turn the KEY SWITCH to the ON position.
2. Press the PROG key. PROGRAM appears on the LCD screen.
3. Press the PRES key. The PRESET prompt appears.
4. Enter 95 and press the ENTER key. The main menu appears.
5. Turn the KEY SWITCH to the OFF position.
CM9760
1. In the default menu, select DEF. The Define Submenu appears.
2. Enter your four-digit PIN.
3. Enter 95 and select PRST. The main menu appears on the monitor.
4. Select the Quit icon to return to the default menu.
Non-Sensitive Area
Sensitive
Area
®
Figure 2. Backlight Compensation
MPT9500
Standard Coaxitron Mode
®
1. Enter 95 and press the PRESET SET key.
2. Position the asterisk in the YES row and press the F1 key. The main menu
appears.
Extended Coaxitron or RS-485 Mode
®
1. Enter 95 and press the PRESET SET key.
2. Press the F2 key. The main menu appears.
4.7.2 Backlight Compensation
The two backlight compensation modes are on and off. Backlight compensation
lets the dome compensate for bright light behind the object you want to view. With
backlight compensation ON, the dome uses only the center 10 percent of the picture for adjusting the iris (refer to Figure 2). A bright light source outside this area
washes out to white. The camera adjusts the iris so the object in the sensitive area
is properly exposed. To change the backlight compensation mode:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Camera.
2. Press the Iris Open button to enter the Camera submenu.
3. Move the joystick up or down to position the cursor beside Backlight Comp.
4. Press the Iris Open button. The cursor moves to the right beside the word On
or Off.
5. Move the joystick up or down to toggle between On and Off.
6. SELECT – Press the Iris Open button to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
4.7.3 Reset Camera
Resetting the camera returns the following settings to their defaults.
Setting: Default:
Gain/AGC
AGC mode Auto
Gain No default setting
Backlight comp Off
Shutter speed Auto
White balance
Auto white balance On
R-B white balance No default setting
M-G white balance No default setting
Sharpness
Auto sharpness On
Sharpness No default setting
16 Pelco Manual C1471M (10/98)
The following settings are not reset when the camera is reset: park time, auto flip
disable, and limit stops.
Turning off power to the dome does not reset the camera. Camera settings are
retained in memory, and when power is restored, the settings are the same as
when the camera was turned off.
To reset the camera:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Camera.
2. Press the Iris Open button to enter the Camera submenu.
3. Move the joystick up or down to position the cursor beside Reset Camera.
4. Press the Iris Open button to reset the camera.
4.7.4 Gain/AGC
4.7.4.1 AGC Mode
The three AGC (Automatic Gain Control) modes are auto, on, and off.
• In auto mode, the dome automatically adjusts the gain–the amount of amplifi-
cation the camera places on its video information to obtain a full 1-volt peak-topeak video signal out. If the iris is manually opened to its wide-open position
and the picture is weak, the AGC can be turned off and the gain increased
manually to improve the picture. When you close the iris, the AGC turns back
on automatically when the lens iris starts closing.
• In on mode, the AGC is on all the time.
• In off mode, the AGC is off.
To change the AGC mode:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Camera.
2. Press the Iris Open button to enter the Camera submenu.
3. Move the joystick up or down to position the cursor beside Gain/AGC.
4. Press the Iris Open button to enter the Gain/AGC submenu.
5. Move the joystick up or down to position the cursor beside AGC mode.
6. Press the Iris Open button. The cursor moves to the right beside the word
Auto, On, or Off.
7. Move the joystick up or down to position the cursor beside Auto, On, or Off.
8. SELECT – Press the Iris Open button to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
4.7.4.2 Gain
Gain adjusts the signal level of the video output. Increasing the gain in low light
conditions increases the noise level in the picture. To change the gain:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Camera.
2. Press the Iris Open button to enter the Camera submenu.
3. Move the joystick up or down to position the cursor beside Gain/AGC.
4. Press the Iris Open button to enter the Gain/AGC submenu.
5. Move the joystick up or down to position the cursor beside Gain.
6. Press the Iris Open button. The cursor moves to the right beside the current
gain setting (a numeric value).
7. Move the joystick up or down to change the gain (making the picture on your
monitor get brighter or darker).
8. SELECT – Press the Iris Open button to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
Pelco Manual C1471M (10/98) 17
4.7.5 Shutter Speed
There are nine electronic shutter speeds:
Auto 1/100 1/120
1/500 1/1,000 1/2,000
1/4,000 1/10,000 1/30,000
In the Auto setting the camera controls the shutter speed automatically. Increasing
the shutter speed lowers the light sensitivity, but rapidly moving objects will be less
blurred as the speed is increased. To change the electronic shutter speed settings:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Camera.
2. Press the Iris Open button to enter the Camera submenu.
3. Move the joystick up or down to position the cursor beside Next.
4. Press the Iris Open button to go to the next camera submenu.
5. Move the joystick up or down to position the cursor beside Shutter Speed.
6. Press the Iris Open button. The cursor moves to the right beside the current
shutter speed.
7. Move the joystick up or down to choose the shutter speed.
8. SELECT – Press the Iris Open button to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
4.7.6 Sharpness
The two modes for adjusting the picture sharpness are automatic and manual. To
change the mode:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Camera.
2. Press the Iris Open button to enter the Camera submenu.
3. Move the joystick up or down to position the cursor beside Next.
4. Press the Iris Open button to go to the next camera submenu.
5. Move the joystick up or down to position the cursor beside Sharpness.
6. Press the Iris Open button. Another menu appears with the auto sharpness
and sharpness selections.
7. Move the joystick up or down to position the cursor beside one of the choices.
Press the Iris Open button.
AUTO SHARPNESS - Move the joystick up or down to toggle between the On and
Off choices. Press the Iris Open button to select one, or press the Iris Close button
if you do not want to change the setting.
SHARPNESS - Move the joystick up or down to a value. As you change the value,
you can see the sharpness change. Press the Iris Open button to select the value,
or press the Iris Close button if you do not want to change the setting. If Auto Sharpness is on, it changes to off when you select a new value.
4.7.7 White Balance
The three white balance settings are auto, red-blue, and magenta-green. To change
the white balance setting:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Camera.
2. Press the Iris Open button to enter the Camera submenu.
3. Move the joystick up or down to position the cursor beside Next.
4. Press the Iris Open button to go to the next camera submenu.
5. Move the joystick up or down to position the cursor beside White Balance.
6. Press the Iris Open button. Another menu appears with the auto, red-blue, and
magenta-green selections.
7. Move the joystick up or down to position the cursor beside one of the choices.
Press the Iris Open button.
AUTO WHITE BALANCE - Move the joystick up or down to toggle between the
Auto and Off choices. Press the Iris Open button to select one, or press the Iris
Close button if you do not want to change the setting.
18 Pelco Manual C1471M (10/98)
R-B WHITE BALANCE - Move the joystick up or down to a value. As you change
the value, you can see the color change on your monitor. Press the Iris Open button
to select the value, or press the Iris Close button if you do not want to change the
setting. If Auto White Balance is on, it changes to off when you select a new value.
M-G WHITE BALANCE - Move the joystick up or down to a value. As you change
the value, you can see the color change on your monitor. Press the Iris Open button
to select the value, or press the Iris Close button if you do not want to change the
setting. If Auto White Balance is on, it changes to off when you select a new value.
4.7.8 Line Synchronization
You can turn line synchronization on or off.
• If it is on, you can adjust the synchronization of the power line voltage so it is
in phase with other cameras. If cameras are out of phase with each other, they
may produce what appears to be vertical roll when switching between cameras.
• If it is off, the dome synchronizes to an internal clock.
To change the line synchronization settings:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Line Sync.
2. Press the Iris Open button. Another menu appears with the Line Sync and
Line Sync Phase selections.
3. Move the joystick up or down to position the cursor beside one of the choices.
LINE SYNC - Move the joystick up or down to toggle between On and Off. Press
the Iris Open button to select the choice. If you changed to Off, the camera may
reset itself as it adjusts to the new synchronization. If the camera resets, it only
affects line synchronization–it will not change any other camera parameters, such
as auto focus or auto iris. Press the Iris Close button if you do not want to change
the setting.
LINE SYNC PHASE - Move the joystick up or down to change the numeric value.
The value represents the phase angle in tenths of a degree between 0 and 359
degrees (for example, 900 is 90 degrees; 2400 is 240). Press the Iris Open button
to select the choice. The Line Sync setting will change to On. The camera may
reset or the picture on your monitor may wiggle when you change the phase angle.
If the camera resets, it only affects synchronization–it will not change any other
camera parameters, such as auto focus or auto iris. Press the Iris Close button if
you do not want to change the setting.
4.7.9 Power Up Mode
This feature lets the dome resume a desired condition following power-up. The
menu includes the following choices:
• Default – On power-up, the dome goes through a configuration cycle and
stops at zero reference, showing “Configuration Done,” and address and mode
settings on the screen.
• Park – The dome moves to preset 1 when the power-up sequence finishes.
The only text on the screen is the preset label (if any).
• Scan Auto – The dome initiates scan mode when the power-up sequence
finishes. Again, there is no text.
• Scan Frame – The dome initiates a frame scan when the power-up sequence
finishes.
• Scan Rand – The dome initiates a random scan when the power-up sequence
finishes.
The default setting is Default. To select the power-up mode:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Power Up Mode.
2. Press the Iris Open button to enter the Power Up Mode submenu.
Pelco Manual C1471M (10/98) 19
3. Move the joystick up or down to cycle through the selections. Stop on the item
you want to select.
4. SELECT – Press the Iris Open button to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
4.7.10 Auto Flip
The two auto flip modes are on (auto flip enabled) or off (feature disabled). To
change the auto flip mode:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Other.
2. Press the Iris Open button to enter the Other submenu.
3. Move the joystick up or down to position the cursor beside Auto Flip.
4. Press the Iris Open button. The cursor moves to the right beside the word On
or Off.
5. Move the joystick up or down to toggle between On and Off.
6. SELECT – Press the Iris Open button to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
4.7.11 Limit Stops
The two types of limit stop are manual and scan. When manual limit stops are set,
a manual (joystick) pan operation stops when a limit is reached. When scan limit
stops are set, the dome reverses direction during random, frame, and auto scanning when a limit stop is reached. Software controls limit stops. To set limit stops:
1. Turn on limit stop mode.
2. Program the limit stops.
NOTE:
Programming preset 90
(23) disables the manual limit stops
until preset 91 (24) is set.
4.7.11.1 Turning Limit Stops On or Off
To change the limit stop mode:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Other.
2. Press the Iris Open button to enter the Other submenu.
3. Move the joystick up or down to position the cursor beside Limit Stops.
4. Press the Iris Open button. The cursor moves to the right beside the word On
or Off.
5. Move the joystick up or down to toggle between On and Off.
6. SELECT – Press the Iris Open button to select your choice.
CANCEL– Press the Iris Close button if you do not want to change the setting.
4.7.11.2 Programming Limit Stops
Manual Limit Stops
Refer to the documentation for your control system for programming presets, then
do the following:
1. Make sure limit stops are turned ON (refer to Section 4.7.11.1), then exit the
menu.
2. Push the joystick left until you reach the limit you want the camera to go to on
the left.
3. Program preset 90 (23).
4. Push the stick right to the limit you want the camera to go to on the right.
5. Program preset 91 (24).
Setting presets 90 (23) and 91 (24) to the same point disables manual limit stops.
20 Pelco Manual C1471M (10/98)
NOTE:
On power-up, the auto
scan tilt angle will be whatever
angle the camera was at when the
right scan limit was set.
Scan Limit Stops
Refer to the documentation for your control system for programming presets, then
do the following:
1. Make sure limit stops are turned ON (refer to Section 4.7.11.1), then exit the
menu.
2. Push the joystick left until you reach the limit you want the camera to go to on
the left.
3. Program preset 92 (25).
4. Push the joystick right to the limit you want the camera to go to on the right.
5. Program preset 93 (26).
Setting presets 92 (25) and 93 (26) to the same point disables scan limit stops.
4.7.12 Park Time Minutes
NOTE
: Preset 1 must be pro-
grammed for the dome to park.
This feature parks the dome at preset 1 after a programmed number of minutes of
control inactivity. You can set the time from 1 to 720 minutes (12 hours). Setting the
time to zero disables this feature. To change the park time:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Other.
2. Press the Iris Open button to enter the Other submenu.
3. Move the joystick up or down to position the cursor beside Park Time Minutes.
4. Press the Iris Open button. The cursor moves to the right beside the current
park time.
5. Move the joystick up or down to change the park time.
6. SELECT – Press the Iris Open button to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
4.7.13 Scan Speed
Scan speed is adjustable from 1-40 degrees per second, and occurs in three scan
modes: auto, random, and frame. To change the scan speed:
1. On the main menu, move the joystick up or down to position the cursor (>)
beside Other.
2. Press the Iris Open button to enter the Other submenu.
3. Move the joystick up or down to position the cursor beside Scan Speed deg/s.
4. Press the Iris Open button. The cursor moves to the right beside the current
number of degrees.
5. Move the joystick up or down to toggle through the number of degrees (1-40)
until you reach the number you want. (If set on a low number, the scan will
appear to barely move but is still functioning.)
6. SELECT – Press the Iris Open button to select your choice.
CANCEL – Press the Iris Close button if you do not want to change the setting.
Pelco Manual C1471M (10/98) 21
5.0 TROUBLESHOOTING
NOTE:
The dome drive contains
no user-serviceable parts. If there
is a problem with the dome drive,
return it to Pelco as a complete
unit for servicing. For instructions
on removing the back box assembly, refer to Section 6.1, BACK
BOX ELECTRONIC ASSEMBLY
REMOVAL, in manual C1487M.
6.0 MAINTENANCE
Symptom: Unit or fan does not operate
Refer to Section 6.0, TROUBLESHOOTING, in manual C1487M.
6.1 DOME CLEANING
Do not scratch the dome. Clean dome exterior and interior surfaces (except chrome
or gold) with a nonabrasive liquid or spray cleaner/wax. Never touch the inside
surface of a chrome or gold dome with your fingers. Instead, follow the care instructions in manual C1487M.
6.2 SERVICE MANUAL
Obtain a service manual (C1455SM): at Pelco’s web site ftp://www.pelco.com, or
call Pelco’s Literature Department.
22 Pelco Manual C1471M (10/98)
7.0 SPECIFICATIONS
MECHANICAL
Pan Movement: 360° continuous pan rotation
Vertical Tilt: Unobstructed +2° to -92°
Manual Pan Speed: 0.5°-80°/sec manual operation, 150°/sec turbo
Manual Tilt Speed: 0.5°-40°/sec
Preset Speeds:
Pan: 250°/sec
Tilt: 100°/sec
Fixed-Speed
Controller:
Pan: 30°/sec
Tilt: 12°/sec
CAMERA
Signal Format: NTSC
Scanning System: 2:1 interlace
Image Sensor: 1/4-inch interline transfer
Resolution: 330 TV lines
Lens
Minimum f/stop: F1.6-2.8
Focal Length: 4 mm to 48 mm optical
Zoom Ratio: 12X optical zoom
Horizontal Angle
of View: 47° (at 4 mm wide zoom), 4° (at 48 mm telephoto zoom)
MTBF: >2 million cycles at room temperature (zoom, focus, iris)
Focus: Manual with capability to focus when going to a present position
Sensitivity: 4 lux at f/1.6 at signal level of 40 IRE, gain high
Signal Process: DSP-3R
Sync System: Internal
White Balance: Automatic with manual override*
Shutter Speed: Automatic (electronic iris)/manual: 1/100 – 1/30,000*
Iris Control: Manual
Gain Control: Automatic with manual override*
Video Output: -.714 V ±.07 V (100 IRE ±10 IRE)
Signal to Noise: >46 dB
Effective pixels: 510 (H) x 492 (V)
* Manual control over camera setup functions depends on the head end and is not
available on all control models.
(Design and product specifications subject to change without notice.)
Pelco Manual C1471M (10/98) 23
8.0 WARRANTY AND RETURN INFORMATION
WARRANTY
Pelco will repair or replace, without charge, any merchandise proved defective in material or
workmanship for a period of one year after the date of shipment.
Exceptions to this warranty are as noted below:
Pelco, the Pelco logo, Camclosure, Esprit,
Genex, Legacy, and Spectra are registered
trademarks of Pelco.
Endura and ExSite are trademarks of Pelco.
© Copyright 1998, Pelco. All rights reserved.
• Five years on FT/FR8000 Series fiber optic products.
• Three years on Genex
• Three years on Camclosure
CC3751H-2, CC3651H-2X, MC3651H-2, and MC3651H-2X camera models, which have a fiveyear warranty.
• Two years on standard motorized or fixed focal length lenses.
• Two years on Legacy
dome products.
• Two years on Spectra
continuous motion applications.
• Two years on Esprit
• Eighteen months on DX Series digital video recorders, NVR300 Series network video
recorders, and Endura
• One year (except video heads) on video cassette recorders (VCRs). Video heads will be
covered for a period of six months.
• Six months on all pan and tilts, scanners or preset lenses used in continuous motion applications
(that is, preset scan, tour and auto scan modes).
Pelco will warrant all replacement parts and repairs for 90 days from the date of Pelco shipment.
All goods requiring warranty repair shall be sent freight prepaid to Pelco, Clovis, California. Repairs
made necessary by reason of misuse, alteration, normal wear, or accident are not covered under
this warranty.
Pelco assumes no risk and shall be subject to no liability for damages or loss resulting from the
specific use or application made of the Products. Pelco’s liability for any claim, whether based on
breach of contract, negligence, infringement of any rights of any party or product liability, relating
to the Products shall not exceed the price paid by the Dealer to Pelco for such Products. In no event
will Pelco be liable for any special, incidental or consequential damages (including loss of use, loss
of profit and claims of third parties) however caused, whether by the negligence of Pelco or
otherwise.
The above warranty provides the Dealer with specific legal rights. The Dealer may also have
additional rights, which are subject to variation from state to state.
If a warranty repair is required, the Dealer must contact Pelco at (800) 289-9100 or (559) 292-1981
to obtain a Repair Authorization number (RA), and provide the following information:
1. Model and serial number
2. Date of shipment, P.O. number, Sales Order number, or Pelco invoice number
3. Details of the defect or problem
If there is a dispute regarding the warranty of a product which does not fall under the warranty
conditions stated above, please include a written explanation with the product when returned.
Method of return shipment shall be the same or equal to the method by which the item was received
by Pelco.
RETURNS
In order to expedite parts returned to the factory for repair or credit, please call the factory at (800)
289-9100 or (559) 292-1981 to obtain an authorization number (CA number if returned for credit,
and RA number if returned for repair).
All merchandise returned for credit may be subject to a 20% restocking and refurbishing charge.
Goods returned for repair or credit should be clearly identified with the assigned CA or RA number
and freight should be prepaid. Ship to the appropriate address below.
If you are located within the continental U.S., Alaska, Hawaii or Puerto Rico, send goods to:
If you are located outside the continental U.S., Alaska, Hawaii or Puerto Rico and are instructed
to return goods to the USA, you may do one of the following:
If the goods are to be sent by a COURIER SERVICE, send the goods to:
Service Department
Pelco
3500 Pelco Way
Clovis, CA 93612-5699
Pelco
3500 Pelco Way
Clovis, CA 93612-5699 USA
If the goods are to be sent by a FREIGHT FORWARDER, send the goods to:
Pelco c/o Expeditors
473 Eccles Avenue
South San Francisco, CA 94080 USA
Phone: 650-737-1700
Fax: 650-737-0933
®
Series products (multiplexers, server, and keyboard).
®
and fixed camera models, except the CC3701H-2, CC3701H-2X,
®
, CM6700/CM6800/CM9700 Series matrix, and DF5/DF8 Series fixed
®
, Esprit®, ExSite™, and PS20 scanners, including when used in
®
and WW5700 Series window wiper (excluding wiper blades).
™
Series distributed network-based video products.
24 Pelco Manual C1471M (10/98)
Loading...
