ADDENDUM

Addendum No. C2499M-A

Date November 17, 2005

Manuals Affected Spectra III

™

SE Series Dome Drive Manuals: C2443M-C, C2444M-C, and C2445M-D

Manual Update The following are manual changes for Spectra III SE software Version 1.28 and greater and instructions for accessing a

Spectra III EVS dome system.

Presets

Spectra III SE system presets have been upgraded from 80 to 150. Each of the user-deﬁnable presets can be programmed to use pan, tilt, camera settings, and motion detection. The programmable presets are numbered 1-32, 35-82, and 100-150.

The following presets are predeﬁned for speciﬁc functions:

33 “Flip” command 95 Select main programming menu

34 “Pan zero” command 96 Stop a scan

88 IR ﬁlter IN (color) 97 Random scanning

89 IR ﬁlter OUT (black-white) 98 Frame scanning

90-91 Manual limit stops 99 Start auto scanning

92-93 Scan limit stops

Title Text

Title Text has been added to the Dome Settings menu. The title text is the label used to identify the camera when it is viewed on the monitor. Up to 20 characters can be used for a title.

To edit the title text label, do the following:

1. Use the joystick to position the cursor beside EDIT TITLE TEXT.

DOME SETTINGS

BACK EXIT

TITLE TEXT

ENABLE TITLE TEXT <EDIT TITLE TEXT>

BACK EXIT

2. Press Iris Open.

3. Use the joystick to position the cursor beside a character. Press Iris Open to select the character. To clear a character, position the cursor beside BACKSPACE and then press Iris Open.

4. When the title is completed, move the cursor to OK. Press Iris Open to return to the Title Text menu.

5. Enable the title text label by doing the following:

a. Move the cursor beside ENABLE TITLE TEXT.

b. Press Iris Open. The cursor moves to the right.

c. Move the joystick up or down to view the selections. Select ON and then press Iris Open to enable the title text.

LABEL FOR PRESET PRESET NUMBER 1234567890 OK ABCDEFGHIJ CANCEL KLMNOPQRST UVWXYZ.,-/ SPACE abcdefghij BACKSPACE klmnopqrst uvwxyz*;:

------

(Continued on next page

Label Position

The Title Text label can be positioned anywhere on the monitor. This feature allows you to customize the appearance of your monitor screen.

To move the Title Text label, do the following:

1. Use the joystick to position the cursor beside a label.

2. Press Iris Open.

3. Use the joystick to move the label up, down, left, and/or right.

4. Press Iris Open.

PRESET LABEL 2 (SECS) ZONE LABEL 2 (SECS) ZOOM 2 (SECS) AZIMUTH/ELEVATION 2 (SECS) DIRECTION OFF ALARM MESSAGE 2 (SECS)

<LABEL POSITIONS> RESTORE FACTORY DEFAULTS

BACK EXIT

5. Repeat steps 1 through 4 to position other labels.

6. Position the cursor next to Save and Exit. Press Iris Open to save the settings and exit the menu.

Spectra III EVS

If your dome drive is used in a Spectra III EVS Series (Endura from an Endura WS5050 Workstation or VCD5000 video console display.

To access the main programming menu from a WS5050:

1. Right-click in the video pane of the Spectra dome system.

2. Click Preset and then click Select Preset.

3. Enter 95 and then click OK.

To access the main programming menu from a VCD5000:

1. Enter 95 for the preset action. The shortcuts menu appears.

2. Press the Preset button on the KBD5000.

™

) dome system, the following instructions tell you how to access the main programming menu

DISPLAY SETUP

LABEL POSITION

[ZONE LABEL-------] [PRESET LABEL-------] [ALARM 1-------] [ALERT MESSAGE-------] [TITLE TEXT-------]

SAVE AND EXIT CANCEL AND EXIT HELP

XXX

o/-XXXo

NE XXX.XX

Worldwide Headquarters • 3500 Pelco Way • Clovis, California 93612 USA • www.pelco.com

USA & Canada • Tel: 800/289-9100 • Fax: 800/289-9150

International • Tel: 1-559/292-1981 • Fax: 1-559/348-1120

OPERATION/PROGRAMMING

Spectra III™ SE Series

Models DD53C22 & DD53C22-X

C2444M-C (1/04)

OPERATION/PROGRAMMING MANUAL

MODELS DD53C22 & DD53C22-X

22X LowLight™ COLOR TECHNOLOGY

WELCOME ................................................................................................................................................................................................ 5

GETTING STARTED .......................................................................................................................................................................... 5

HOW TO OPERATE YOUR DOME SYSTEM .............................................................................................................................................. 6

ACCESSING MAIN MENU (PRESET 95) .......................................................................................................................................... 7

CM6700/CM6800 ................................................................................................................................................................... 7

KBD200A/KBD300A (DIRECT MODE ONLY) ........................................................................................................................... 7

CM9500 .................................................................................................................................................................................. 7

CM9740/CM9760 ................................................................................................................................................................... 7

KBD4000/KBD4002 (GENEX MULTIPLEXER) .......................................................................................................................... 8

MPT9500 ................................................................................................................................................................................ 8

PELCONET ............................................................................................................................................................................... 8

LANGUAGE .............................................................................................................................................................................................. 11

SYSTEM INFORMATION.......................................................................................................................................................................... 12

DISPLAY SETUP ....................................................................................................................................................................................... 13

<LABEL POSITION> ......................................................................................................................................................................... 14

DOME SETTINGS ..................................................................................................................................................................................... 15

<CAMERA> ..................................................................................................................................................................................... 15

TYPE OF LIGHTING ................................................................................................................................................................ 15

AUTO FOCUS ......................................................................................................................................................................... 15

ZOOM LIMIT .......................................................................................................................................................................... 16

ZOOM SPEED ......................................................................................................................................................................... 16

LOW LIGHT LIMIT .................................................................................................................................................................. 16

<ADVANCED CAMERA SETTINGS> ............................................................................................................................................... 17

SHUTTER SPEED .................................................................................................................................................................... 17

AGC LIMIT ............................................................................................................................................................................. 17

AUTO IRIS .............................................................................................................................................................................. 18

AUTO SHARPNESS ................................................................................................................................................................ 19

AUTO WHITE BALANCE ........................................................................................................................................................ 19

BACKLIGHT COMPENSATION (BLC) ...................................................................................................................................... 20

VIDEO LEVEL .......................................................................................................................................................................... 20

<MOTION SETTINGS> .................................................................................................................................................................... 21

AUTO FLIP .............................................................................................................................................................................. 21

PROPORTIONAL PAN ............................................................................................................................................................. 21

PARK TIME ............................................................................................................................................................................ 22

SCAN SPEED ......................................................................................................................................................................... 23

PRESET FREEZE FRAME ........................................................................................................................................................ 23

LIMIT STOPS .......................................................................................................................................................................... 24

AZIMUTH ZERO ..................................................................................................................................................................... 25

<POWER UP> .................................................................................................................................................................................. 26

POWER UP ACTION ............................................................................................................................................................... 26

<LINE SYNC> .................................................................................................................................................................................. 27

<PRESETS> ..................................................................................................................................................................................... 28

<PATTERNS>................................................................................................................................................................................... 30

<ZONES> ........................................................................................................................................................................................ 31

2 C2444M-C (1/04)

<WINDOW BLANKING> ................................................................................................................................................................. 32

REVERSE ................................................................................................................................................................................ 34

BLANK ALL ABOVE/BLANK ALL BELOW ............................................................................................................................... 34

<ALARMS> ..................................................................................................................................................................................... 35

<AUX> ............................................................................................................................................................................................. 38

<ALERT> ......................................................................................................................................................................................... 39

REPEAT ................................................................................................................................................................................... 39

ACK ACTION .......................................................................................................................................................................... 40

ACTIVATE AUX ....................................................................................................................................................................... 40

CURRENT READING .............................................................................................................................................................. 40

ALERT RESET ......................................................................................................................................................................... 40

<CLEAR> ......................................................................................................................................................................................... 41

<PASSWORD> ................................................................................................................................................................................ 42

RESET, CYCLE, POWER, REBOOT ............................................................................................................................................................ 43

RESET CAMERA .................................................................................................................................................................... 43

CYCLE CAMERA POWER ....................................................................................................................................................... 43

REBOOT SYSTEM .................................................................................................................................................................. 43

SOFTWARE/LANGUAGE FILE UPLOAD ................................................................................................................................................... 44

UPLOAD ICON ................................................................................................................................................................................. 44

SPECIFICATIONS...................................................................................................................................................................................... 45

REGULATORY NOTICES ........................................................................................................................................................................... 46

C2444M-C (1/04) 3

WELCOME

Thank you for purchasing Pelco’s premier integrated dome system, Spectra III SE. Your new system features a high resolution, color camera/optics package with LowLight™ technology and programmable dome drive software.

This manual is designed to be a reference tool for the operation and programming of your system. Inside you will find information about Spectra III SE’s features and commands, as well as a detailed menu tree.

Getting Started

You will need to install your dome system before using this manual. Refer to the installation packet supplied with the back box for installation instructions.

Once installed apply power to the Spectra III SE dome system. The system will start a configuration sequence. When configuration is done, the following information is displayed:

Pelco Spectra III SE *Version X.XX D Address: 1 P Address: 2 Comm 2400, N, 8, 1

CONFIGURE DONE

This information will remain on the monitor until dome operation begins.

Refer to the following pages to learn how to operate and program your dome system.

* Pressurized Spectra III SE dome systems require software version 1.25 or higher to monitor

temperature, pressure, and dew point.

C2444M-C (1/04) 5

HOW TO OPERATE YOUR DOME SYSTEM

Operation How to Control

Pan and Tilt Move joystick or press the direction keys left/right and up/down.

Zoom Far To zoom far, do the following:

1. Press the Zoom Tele button or turn the joystick clockwise until zoom stops at the 32X zoom limit.

2. Release the button or joystick for one second.

3. To continue zooming (digitally), press the button or turn the joystick clockwise again until you have the

picture you want or reach the digital zoom1 limit.

Zoom Wide Press the Zoom Wide button or turn the joystick counterclockwise.

Scanning

Stop Scan Preset 96 Random Scan Preset 97 Frame Scan Preset 98 Auto Scan Preset 99

Presets Refer to the documentation supplied with the control system.

Patterns

Refer to the documentation supplied with the control system.

Zones Refer to the

Alarms Refer to the

Auto Flip Tu rn on or off in the programming menu. Refer to the

Digital zoom magnifies the image electronically and the picture may appear pixilated. The larger the digital zoom limit the

Zones

section and to the documentation supplied with the control system.

Alarms

section in this manual.

Auto Flip

section in this manual.

greater the reduction in resolution.

The dome cannot do electronic zoom in a pattern. Optical zoom will operate in a pattern.

6 C2444M-C (1/04)

Accessing Main Menu (Preset 95)

You can call up the main menu on your monitor by programming (setting or creating) preset 95 (preset 28 if in AD32-preset mode).

Programming preset 95 for Pelco’s controllers varies according to the type of controller you are using. Instructions for programming preset 95 are given below for various Pelco controllers.

CM6700/CM6800

1. Enter the number of the Spectra dome system and press the CAM key.

2. Enter 95 and hold the PRESET key for two seconds.

3. In the Edit Preset menu, arrow to SET and press the ACK key. The main menu appears.

KBD200A/KBD300A (DIRECT MODE ONLY)

1. Enter 95.

2. Hold the PRESET key (approximately five seconds) until the main menu appears on the screen.

CM9500

1. Enter the number of the Spectra dome system and press the CAM key. The Main menu appears.

2. Highlight SETUP in the Main menu and press the SELECT key.

3. Highlight CAM in the Setup menu and press the SELECT key.

4. Highlight PRESET in the Camera menu and press the SELECT key.

5. Enter 95 and press the F1 key. The main menu appears.

CM9740/CM9760

1. Press the ESCAPE key to open the Main menu. Select DEF. The Define Submenu appears.

2. Enter your four-digit PIN

3. Enter 95 and select PRST. The main menu appears on the monitor.

4. Select the Quit icon to return to the default menu.

C2444M-C (1/04) 7

if this is your first time entering this mode.

(Continued on next page)

KBD4000/KBD4002 (GENEX® MULTIPLEXER)

1. Press the SPOT MONITOR key.

2. Enter 95, then hold the PRESET key (approximately five seconds) until the main menu appears on the screen.

MPT9500

Standard Coaxitron Mode

1. Enter 95 and press the PRESET SET key.

2. Position the asterisk in the YES row and press the F1 key. The main menu appears.

Extended Coaxitron or RS-485 Mode

1. Enter 95 and press the PRESET SET key.

2. Press the F2 key. The main menu appears.

PelcoNet

™

1. Check the Set box.

2. Click the preset 95 button. The main menu appears.

8 C2444M-C (1/04)

Presets

The following presets are reserved for special functions.

Preset Function

33 Flip command 90-91 Manual limit stops 92-93 Scan limit stops 95 Select main programming menu 96 Stop a scan 97 Random scanning 98 Frame scanning 99 Start auto scanning

NOTE: For American Dynamics controllers with only 32 presets, switch SW3-1 on the dome drive to the ON position. When SW3-1 is ON, preset

99 becomes 32 92 becomes 25 98 becomes 31 91 becomes 24 97 becomes 30 90 becomes 23 96 becomes 29 89 becomes 22 95 becomes 28 88 becomes 21

93 becomes 26 If the limit stops are turned off, presets 23-26 can be used as regular presets.

DOME SETTINGS

BACK EXIT

SPECTRA III

LANGUAGE ENGLISH

<SYSTEM INFORMATION> <DISPLAY SETUP> <DOME SETTINGS> ACK ALERT**

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DISPLAY SETUP

PRESET LABEL (2 SECS) ZONE LABEL (2 SECS) ZOOM (2 SECS) AZIMUTH/ELEVATION (2 SECS) DIRECTION OFF ALARM MESSAGE (2 SECS)

<LABEL POSTIONS> RESTORE FACTORY DEFAULTS

BACK EXIT

LABEL POSITION

[ZONE LABEL-------] [PRESET LABEL-------] [ALARM 1-------] [ALERT MESSAGE-------]**

SAVE AND EXIT CANCEL AND EXIT HELP

/-XXX

XXX NE XXX.XX

SYSTEM INFORMATION

DOME DRIVE MODEL BACK BOX MEMORY SOFTWARE VERSION BIOS VERSION FONT VERSION

COMM D ADDRESS P ADDRESS CM9500 MODE 32 PRESETS PROTOCOL

PRESSURIZED**

<ADDITIONAL> BACK EXIT

ADDITIONAL

FREE MEMORY LAST RESET AZIMUTH ZERO OFFSET MOTOR ACTIVE CAMERA ACTIVE FPGA VERSION X VIDEO LEVEL NORMAL CAMERA XXXX-XXXX

LANGUAGE 1

LANGUAGE 6 BACK

EXIT

AVAILABLE

2400, N, 8, 1

POWER ON

ENGLISH X.XX

ITALIANO X.XX

DD53C22

XX.X XX.X XX.X

OFF OFF

X.XX

18304

YES YES

QUICK START GUIDE – SYSTEM SETUP

Quick Programming Guide

Access main menu (preset 95). See the

(Preset 95)

section.

Use the joystick* to position the cursor beside menu selection.

1 2

Press Iris Open, the submenu/cursor moves to the right.

Move the joystick up or down to view selections.

Press Iris Open to make selection.

Press Iris Close to cancel selection.

Accessing Main Menu

CAMERA

TYPE OF LIGHTING AUTO FOCUS ZOOM LIMIT ZOOM SPEED LOW LIGHT LIMIT

BACK EXIT

ADVANCED SETTINGS

SHUTTER SPEED AGC LIMIT

AUTO IRIS AUTO IRIS LEVEL AUTO IRIS PEAK

AUTO SHARPNESS SHARPNESS LEVEL AUTO WHITE BALANCE R GAIN B GAIN

BACKLIGHT COMP

VIDEO LEVEL

BACK

EXIT

OUTDOOR

X176

MEDIUM

AUTO

OFF

HIGH

AUTO FLIP PROPORTIONAL PAN

PARK TIME (MINUTES) PARK ACTION SCAN SPEED DEG/S

PRESET FREEZE FRAME LIMIT STOPS

BACK EXIT

ON 482 678

MOTION

PRESETS

NONE

AUTO

ON ON

POWER UP ACTION

BACK EXIT

POWER UP

LINE SYNC ON

AUTO

LINE SYNC PHASE 0

BACK EXIT

LINE SYNC

PRESET NUMBER 1 * * * PRESET NOT DEFINED * * *

BACK EXIT

REFERENCE INFORMATION AZIMUTH ELEVATION ZOOM CUSTOM CAMERA SETTINGS

* If your controller does not have a joystick, use the up or down key.

** This setting only applies to Pressurized Spectra III SE dome systems with software

version 1.25 or higher. Spectra III systems that are not pressurized or pressurized systems that do not have dome drive software version 1.25 or higher will not display this menu item.

Software version 1.25 or higher includes the software to monitor temperature, pressure, and dew point for Pressurized Spectra III SE systems.

PATTERN NUMBER 1 <PROGRAM PATTERN> <CLEAR PATTERN>

BACK EXIT

REFERENCE INFORMATION PATTERN USAGE 0% REMAINING 100%

PATTERNS ZONES

ZONE NUMBER 1 * * * ZONE NOT DEFINED * * *

<EDIT ZONE> ZONE ENABLED ZONE BLANKING

BACK EXIT

OFF

WINDOW BLANKING

STYLE GRAY

BLANK ALL ABOVE OFF BLANK ALL BELOW OFF

BACK EXIT

SET WINDOWS

WINDOW NUMBER

ENABLE WINDOW REVERSE CLEAR WINDOW

BACK EXIT

RESUME OFF SEQUENCE (SECS) 5 RESET DELAY (SECS) 0

BACK EXIT

ALARMS

ALARM SETTINGS

ALARM NUMBER

ALARM PRIORITY ALARM ACTION ACTIVATE AUX ALARM CONTACT

BACK EXIT

LOW

NONE

N/O

AUX 1 MODE DWELL TIME (SECS)

AUX 2 MODE DWELL TIME (SECS)

BACK EXIT

AUX

TOGGLE

REPEAT ACK ACTION

ACTIVATE AUX <CURRENT READING> RESET ALERT

BACK EXIT

TEMPERATURE

DEWPOINT

PRESSURE

REFRESH

BACK EXIT

ALERT** CLEAR PASSWORD

CONSTANT

ALWAYS ON

CURRENT READING**

CLEAR ALL ZONES CLEAR ALL PRESETS CLEAR ALL PATTERNS

CLEAR ALL WINDOW BLANKING

RESTORE FACTORY DEFAULTS

BACK EXIT

0°C 0°F 0°C 0°F

0.0 PSIG

0.0 BAR

ENABLE PASSWORD OFF <EDIT PASSWORD>

BACK EXIT

EDIT THE PASSWORD

---------1234567890

ABCDEFGHIJ KLMNOPQRST UVWXYZ.,-/ abcdefghij klmnopqrst uvwxyz*;:

CANCEL

SPACE

BACKSPACE

C2444M-C (1/04) 9

LANGUAGE

SPECTRA III

LANGUAGE ENGLISH

<SYSTEM INFORMATION> <DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

The language for the on-screen menus is selectable. Available languages include English, Spanish, French, German, Italian, and Portuguese. The factory default language is English.

To change the display language:

1. Use the joystick to position the cursor beside LANGUAGE.

2. Press Iris Open. The cursor moves to the right, beside the current, selected language.

3. Move the joystick up or down to view selections. Press Iris Open to enter selection. All on-screen menus are changed to the selected language.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 11

SYSTEM INFORMATION

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

SYSTEM INFORMATION

DOME DRIVE MODEL DD53M22 BACK BOX MEMORY AVAILABLE SOFTWARE VERSION XX.X BIOS VERSION XX.X FONT VERSION XX.X

COMM 2400, N, 8, 1 D ADDRESS 1 P ADDRESS 2 CM9500 MODE OFF 32 PRESETS OFF PROTOCOL C

PRESSURIZED* X.XX <ADDITIONAL> BACK

EXIT

The system Information screen displays dome drive model, software version, available memory, and other diagnostic information.

System settings cannot be changed using this screen. This screen is for reference only.

Use the following steps to display the System Information screen:

1. Use the joystick to position the cursor beside SYSTEM INFORMATION.

2. Press Iris Open. The SYSTEM INFORMATION window opens.

FREE MEMORY 18304 LAST RESET POWER ON AZIMUTH ZERO OFFSET 0 MOTOR ACTIVE YES CAMERA ACTIVE YES FPGA VERSION X VIDEO LEVEL NORMAL CAMERA XXXX-XXXX

LANGUAGE 1 ENGLISH X.XX LANGUAGE 2 ESPANOL X.XX LANGUAGE 3 PORTUGUES X.XX LANGUAGE 4 DEUTSCH X.XX LANGUAGE 5 FRANCAIS X.XX LANGUAGE 6 ITALIANO X.XX

BACK EXIT

ADDITIONAL

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

12 C2444M-C (1/04)

DISPLAY SETUP

SPECTRA III

LANGUAGE ENGLISH

<SYSTEM INFORMATION> <DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DISPLAY SETUP

PRESET LABEL 2 (SECS) ZONE LABEL 2 (SECS) ZOOM 2 (SECS) AZIMUTH/ELEVATION 2 (SECS) DIRECTION OFF ALARM MESSAGE 2 (SECS)

<LABEL POSITIONS> RESTORE FACTORY DEFAULTS

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

Display setup allows you to program how labels are displayed on the monitor. The following labels are available:

PRESET LABEL - Identifies preset. ZONE LABEL - Identifies zone. ZOOM RATIO - Identifies the amount of magnification. AZIMUTH

/ELEVATION2 - Amount of pan from 0° and the amount of tilt from 0° horizontal. DIRECTION - Displays compass direction. ALARM MESSAGE - Displays activated alarm.

A preset label is displayed when a preset is called. A zone label is displayed when the system moves into a zone. The zoom ratio label is displayed when zoom is activated. Azimuth/elevation and direction labels are displayed when pan/tilt is activated. An alarm message appears on the monitor when an alarm occurs.

The following settings are available for each label:

OFF - Label is not displayed when activated. CONSTANT - The label is continually displayed when activated. 2 SECONDS - The label is displayed for 2 seconds after activation. 5 SECONDS - The label is displayed for 5 seconds after activation. 10 SECONDS - The label is displayed for 10 seconds after activation.

Azimuth is the pan angle from 0° to 359°.

Elevation is the tilt position from 0° (horizon) to -90°.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 13

<Label Position>

SPECTRA III

LANGUAGE ENGLISH

<SYSTEM INFORMATION> <DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DISPLAY SETUP

PRESET LABEL 2 (SECS) ZONE LABEL 2 (SECS) ZOOM 2 (SECS) AZIMUTH/ELEVATION 2 (SECS) DIRECTION OFF ALARM MESSAGE 2 (SECS)

<LABEL POSITIONS> RESTORE FACTORY DEFAULTS

BACK EXIT

LABEL POSITION

[ZONE LABEL-------] [PRESET LABEL-------] [ALARM 1-------] [ALERT MESSAGE-------]*

SAVE AND EXIT CANCEL AND EXIT HELP

/-XXX

XXX NE XXX.XX

Labels can be placed anywhere on the monitor. This feature allows you to customize the appearance of your monitor screen.

The following labels are not set at fixed positions:

PRESET LABEL ZONE LABEL ALARM 1 ZOOM RATIO - XXX.XX AZIMUTH

/ELEVATION2 - XXX°/-XX° DIRECTION - NE ALERT MESSAGE3*

To set a label position:

1. Use the joystick to position the cursor beside a label.

2. Press Iris Open.

3. Use the joystick to move the label up, down, left, and/or right.

4. Press Iris Open.

5. Repeat steps 1 through 4 to position other labels.

6. Position the cursor next to Save and Exit. Press Iris Open to save settings and exit

menu.

Azimuth is the pan angle from 0° to 359°.

Elevation is the tilt position from 0° (horizon) to -90°.

The alert message is the warning displayed on the monitor if pressure, temperature, or dew point inside the dome reach unacceptable levels.

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

14 C2444M-C (1/04)

DOME SETTINGS

<Camera>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

<CAMERA> <MOTION> <POWER UP> <LINE SYNC> <PRESETS> <PATTERNS> <ZONES> <WINDOW BLANKING> <ALARMS> <AUX> <ALERT>* <CLEAR> <PASSWORD> BACK EXIT

CAMERA

TYPE OF LIGHTING OUTDOOR AUTO FOCUS ON ZOOM LIMIT X176 ZOOM SPEED MEDIUM LOW LIGHT LIMIT 2

TYPE OF LIGHTING

Pelco has calibrated settings that optimize the white balance, and the picture, for indoor and outdoor lighting conditions. There are two settings:

OUTDOOR (default) INDOOR

AUTO FOCUS

Auto focus allows the lens to remain in focus during zoom-in, zoom-out, and motion functions.

There are two auto focus settings:

ON (default) - If auto focus mode is set to ON, the camera will focus automatically when

using pan, tilt, and zoom functions.

OFF - Focus is operated manually. To focus, press the Focus Far or Focus Near button on the

controller.

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 15

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

ZOOM LIMIT

Zoom limit allows the user to define a limitation on the amount of telephoto zoom. The default setting is 176X.

Cameras with 264X zoom (22X optical zoom and 12X electronic zoom) can be set for 22X, 32X, 88X, 176X, 220X, or 264X.

ZOOM SPEED

Zoom Speed allows the user to define how fast the dome will go from full wide zoom to the 22X optical zoom. The default setting is MEDIUM.

DOME SETTINGS

<PASSWORD> BACK EXIT

CAMERA

TYPE OF LIGHTING OUTDOOR

AUTO FOCUS ON

ZOOM LIMIT X176

ZOOM SPEED MEDIUM

LOW LIGHT LIMIT 2

BACK

EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

Available settings for zoom speed include the following: HIGH – 2.4 seconds MEDIUM (default) – 3.9 seconds LOW – 6.3 seconds

NOTE: When using the HIGH setting, the image may be out of focus until zooming stops.

LOW LIGHT LIMIT

Low light limit is the maximum duration, in fractions of a second, that the electronic shutter will remain open in low light conditions. The default setting is 2.

Settings include the following:

2 =1/2 second 8 = 1/8 second 30 =1/30 second 4 = 1/4 second 15 =1/15 second 60 =1/60 second

16 C2444M-C (1/04)

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

<Advanced Camera Settings>

SHUTTER SPEED

Shutter speed is the duration of the electronic shutter. Program shutter speed to operate automatically (Auto) or manually (Numeric Value).

AUTO (default) - The electronic shutter speed is set automatically by the amount of light

sensed by the camera.

NUMERIC VALUE - Spectra III SE dome system has several numerical shutter speed

settings. The higher the number, the faster the electronic shutter.

DOME SETTINGS

<CAMERA> <MOTION> <POWER UP> <LINE SYNC> <PRESETS> <PATTERNS> <ZONES> <WINDOW BLANKING> <ALARMS> <AUX> <ALERT>* <CLEAR> <PASSWORD> BACK EXIT

NOTE: Set the shutter speed to 100 if you are using an NTSC camera in a 50 Hz environment. This will eliminate any flicker that may occur in the picture.

AGC LIMIT

The slowest shutter speed setting is 2 = 1/2 second The fastest setting is 30,000 = 1/30,000 second

Increasing the shutter speed lowers the light sensitivity and reduces the streaking of fast moving objects.

The AGC (automatic gain control) Limit adjusts the brightness of the picture. Settings range from 0 to 40. The brightness increases as the number gets higher.

CAMERA

TYPE OF LIGHTING OUTDOOR AUTO FOCUS ON ZOOM LIMIT X176 ZOOM SPEED MEDIUM LOW LIGHT LIMIT 2

BACK EXIT

ADVANCED SETTINGS

SHUTTER SPEED AUTO

AGC LIMIT 27

AUTO IRIS AUTO AUTO IRIS LEVEL 66 AUTO IRIS PEAK 8

AUTO SHARPNESS ON SHARPNESS LEVEL 26

AUTO WHITE BALANCE ON R GAIN 482 B GAIN 678

BACKLIGHT COMP OFF VIDEO LEVEL HIGH

BACK EXIT

Quick Programming Guide

* This setting only applies to Pressurized

Spectra III SE dome systems with software version 1.25 or higher.

C2444M-C (1/04) 17

(See page 9)

SPECTRA III

LANGUAGE ENGLISH

ACK ALERT*

RESET CAMERA

CYCLE CAMERA POWER

REBOOT SYSTEM

EXIT

DOME SETTINGS

<ZONES>

<AUX>

<ALERT>*

<CLEAR>

<PASSWORD> BACK EXIT

CAMERA

TYPE OF LIGHTING OUTDOOR AUTO FOCUS ON ZOOM LIMIT X176 ZOOM SPEED MEDIUM LOW LIGHT LIMIT 2

AUTO IRIS

Auto iris is the lens function that automatically opens and closes the iris in response to changing light conditions.

Program the auto iris to operate automatically or at a user-defined level.

OFF - Auto iris is disabled, and control is always manual. AUTO (default) - The iris is adjusted automatically to produce a constant video output as

determined by the Auto Iris Level setting.

NOTE: If auto iris is in the auto mode, it will remain that way until the iris is manually opened or closed. The dome will return to auto mode when it is panned or tilted more than 15 degrees.

Auto Iris Level

Auto Iris Level is the numeric value the auto iris uses to maintain the brightness level of the camera. Increase the value to brighten the scene. Decrease the level to darken the scene. This setting can be adjusted if the video level in the auto iris mode is too bright or too dark.

NOTE: If backlight compensation is ON, decrease the Auto Iris Level setting.

Auto Iris Peak

Increasing the peak value will cause the auto iris circuit to react more to highlights or “peaks” in the picture. Decreasing this value will cause it to use the average video level to adjust the iris.

BACK EXIT

ADVANCED SETTINGS

SHUTTER SPEED AUTO

AGC LIMIT 27

AUTO IRIS AUTO

AUTO IRIS LEVEL 66

AUTO IRIS PEAK 8

AUTO SHARPNESS ON

SHARPNESS LEVEL 26

AUTO WHITE BALANCE ON

R GAIN 482

B GAIN 678

BACKLIGHT COMP OFF

VIDEO LEVEL HIGH

BACK

EXIT

* This setting only applies to Pressurized

Spectra III SE dome systems with software version 1.25 or higher.

18 C2444M-C (1/04)

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

<PASSWORD> BACK EXIT

CAMERA

TYPE OF LIGHTING OUTDOOR AUTO FOCUS ON ZOOM LIMIT X176 ZOOM SPEED MEDIUM LOW LIGHT LIMIT 2

AUTO SHARPNESS

Auto sharpness enhances picture detail by increasing the aperture gain of the camera and sharpening the edges in the picture.

There are two settings:

ON (default) - The camera automatically maintains a normal sharpness mode. OFF - The sharpness of the picture is set manually by programming the SHARPNESS LEVEL.

Sharpness level settings range from 0-31.

AUTO WHITE BALANCE

This feature automatically processes the viewed image to retain color balance over a color temperature range. The default setting for auto white balance is ON.

R GAIN - Adjusts the picture output in the red range. As you change the value, you will

see the color change on your monitor.

B GAIN - Adjusts the picture output in the blue range. As you change the value, you will

see the color change on your monitor.

BACK EXIT

ADVANCED SETTINGS

SHUTTER SPEED AUTO

AGC LIMIT 27

AUTO IRIS AUTO AUTO IRIS LEVEL 66 AUTO IRIS PEAK 8

AUTO SHARPNESS ON SHARPNESS LEVEL 26

AUTO WHITE BALANCE ON R GAIN 482 B GAIN 678

BACKLIGHT COMP OFF VIDEO LEVEL HIGH

BACK

EXIT

Quick Programming Guide

* This setting only applies to Pressurized

Spectra III SE dome systems with software version 1.25 or higher.

C2444M-C (1/04) 19

(See page 9)

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

BACKLIGHT COMPENSATION (BLC)

If a bright backlight is present, the subjects in the picture may appear dark or as a silhouette. Backlight compensation enhances objects in the center of the picture. The dome uses the center of the picture to adjust the iris. If there is a bright light source outside of this area, it will wash out to white. The camera will adjust the iris so that the object in the sensitive area is properly exposed.

There are two backlight compensation settings:

ON - Backlight compensation is activated. OFF (default) - Backlight compensation is not activated.

DOME SETTINGS

<PASSWORD> BACK EXIT

CAMERA

TYPE OF LIGHTING OUTDOOR AUTO FOCUS ON ZOOM LIMIT X176 ZOOM SPEED MEDIUM LOW LIGHT LIMIT 2

BACK EXIT

NOTE: If backlight compensation is ON, decrease the Auto Iris setting. Refer to the section.

VIDEO LEVEL

Set the video output to one of the following:

NORMAL - 1.0 volt peak-to-peak HIGH (default setting) - 1.2 volt peak-to-peak to compensate for losses in video cable.

Auto Iris

ADVANCED SETTINGS

SHUTTER SPEED AUTO

AGC LIMIT 27

AUTO IRIS AUTO AUTO IRIS LEVEL 66 AUTO IRIS PEAK 8

AUTO SHARPNESS ON SHARPNESS LEVEL 26

AUTO WHITE BALANCE ON R GAIN 482 B GAIN 678

BACKLIGHT COMP OFF VIDEO LEVEL HIGH

BACK EXIT

* This setting only applies to Pressurized

Spectra III SE dome systems with software version 1.25 or higher.

20 C2444M-C (1/04)

<Motion Settings>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

MOTION

AUTO FLIP ON PROPORTIONAL PAN ON PARK TIME (MINUTES) 0 PARK ACTION NONE SCAN SPEED (DEG/S) 25 PRESET FREEZE FRAME AUTO

LIMIT STOPS ON <SET MANUAL STOPS> <CLEAR MANUAL STOPS> <SET SCAN STOPS> <CLEAR SCAN STOPS>

BACK EXIT

REFERENCE INFORMATION MANUAL LIMITS SET NO SCAN LIMITS SET NO

AUTO FLIP

When the camera tilts downward and goes just beyond the vertical position, the dome rotates 180 degrees. When the dome rotates (flips), the camera starts moving upward as long as you continue to hold the joystick in the down position. Once you let go of the joystick after the dome rotates, joystick control returns to normal operation. The auto-flip feature is useful for following a person who passes directly beneath the dome.

There are two auto flip modes:

ON (default) - Auto flip mode is enabled. OFF - Auto flip mode is disabled.

PROPORTIONAL PAN

Proportional pan automatically reduces or increases the pan and tilt speeds in proportion to the amount of zoom. At telephoto zoom settings, the pan and tilt speeds will be slower for a given amount of joystick deflection than at wide zoom settings. This keeps the image from moving too fast on the monitor when there is a large amount of zoom.

There are two proportional pan modes:

ON (default) - Enables the proportional pan mode. OFF - Disables proportional pan mode. The pan speed will not depend on the amount of zoom.

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 21

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

<ZONES>

<AUX>

<ALERT>*

<CLEAR>

BACK EXIT

MOTION

AUTO FLIP ON PROPORTIONAL PAN ON PARK TIME (MINUTES) 0 PARK ACTION NONE SCAN SPEED (DEG/S) 25 PRESET FREEZE FRAME AUTO

LIMIT STOPS ON <SET MANUAL STOPS> <CLEAR MANUAL STOPS> <SET SCAN STOPS> <CLEAR SCAN STOPS>

BACK EXIT

REFERENCE INFORMATION MANUAL LIMITS SET NO SCAN LIMITS SET NO

PARK TIME

This feature allows the dome to begin a specified operation (scan, preset, or pattern) after a programmed time of inactivity.

Park time can be programmed from 1 minute to 720 minutes (12 hours), or set to zero, which disables this feature. The default setting is zero.

Park Action

This feature will define the activity when the dome parks. The following settings are available:

NONE (default) - No action. AUTO SCAN - Dome starts auto scan operation. RANDOM SCAN - Dome starts random scan operation. FRAME SCAN - Dome starts frame scan operation. PRESET 1 - Dome goes to preset 1. PRESET 8 - Dome goes to preset 8. PATTERN 1 - Dome runs pattern 1. PATTERN 2 - Dome runs pattern 2. PATTERN 3 - Dome runs pattern 3. PATTERN 4 - Dome runs pattern 4.

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

22 C2444M-C (1/04)

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

SCAN SPEED

Scan speed is the degrees per second that the dome will pan when in a scan mode. Scan speed is adjustable from 1 to 40 degrees per second through the programming menu. The default setting is 25 degrees per second.

PRESET FREEZE FRAME

This feature freezes the scene on the monitor when going to a preset. This allows for smooth transition from one preset scene to another. Preset freeze frame also reduces bandwidth when used with digital network systems such as PelcoNet™ and guarantees that blanked areas will not be revealed when going to a preset.

DOME SETTINGS

BACK EXIT

MOTION

AUTO FLIP ON PROPORTIONAL PAN ON PARK TIME (MINUTES) 0 PARK ACTION NONE SCAN SPEED (DEG/S) 25 PRESET FREEZE FRAME AUTO

LIMIT STOPS ON <SET MANUAL STOPS> <CLEAR MANUAL STOPS> <SET SCAN STOPS> <CLEAR SCAN STOPS>

BACK EXIT

REFERENCE INFORMATION MANUAL LIMITS SET NO SCAN LIMITS SET NO

There are three preset freeze frame settings:

ON - The image on the screen freezes when a preset is called. When the dome reaches the

preset, the image is unfrozen and the preset scene is displayed. OFF - The image is never frozen. AUTO (default) - Freeze frame is turned on automatically if window blanking is ON. If

window blanking is OFF, freeze frame is off.

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 23

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

MOTION

AUTO FLIP ON PROPORTIONAL PAN ON PARK TIME (MINUTES) 0 PARK ACTION NONE SCAN SPEED (DEG/S) 25 PRESET FREEZE FRAME AUTO

LIMIT STOPS ON <SET MANUAL STOPS> <CLEAR MANUAL STOPS> <SET SCAN STOPS> <CLEAR SCAN STOPS>

BACK EXIT

REFERENCE INFORMATION MANUAL LIMITS SET NO SCAN LIMITS SET NO

LIMIT STOPS

Limit stops are programmable stops that limit the pan range of the dome. There must be two limits, a left and a right, to define an area.

There are two types of limit stops:

MANUAL - A manual (joystick) pan operation stops when a limit stop is reached. SCAN - The dome reverses direction during random, frame, or auto scanning when a limit

stop is reached.

To set manual or scan stops:

1. Use the joystick to position the cursor beside SET MANUAL STOPS or SET SCAN STOPS.

2. Press Iris Open.

3. Follow the directions displayed on the monitor.

NOTE: In order for the manual or scan stops to work, the LIMIT STOPS setting must be ON.

To clear manual or scan stops:

1. Use the joystick to position the cursor beside CLEAR MANUAL STOPS or CLEAR SCAN STOPS.

2. Press Iris Open.

3. Follow the directions displayed on the monitor.

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

24 C2444M-C (1/04)

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

MOTION

AUTO FLIP ON PROPORTIONAL PAN ON PARK TIME (MINUTES) 0 PARK ACTION NONE SCAN SPEED (DEG/S) 25 PRESET FREEZE FRAME AUTO

LIMIT STOPS ON <SET MANUAL STOPS> <CLEAR MANUAL STOPS> <SET SCAN STOPS> <CLEAR SCAN STOPS>

BACK EXIT

REFERENCE INFORMATION MANUAL LIMITS SET NO SCAN LIMITS SET NO

AZIMUTH ZERO

Azimuth is the pan angle from 0° to 359°. Azimuth zero is the pan position you specify to be the 0° point. Azimuth zero is normally set to magnetic north. Once set, azimuth and compass readings are based on the set Azimuth Zero point.

To program azimuth zero:

1. Use the joystick to position the cursor beside SET AZIMUTH ZERO.

2. Press Iris Open.

3. Follow the directions displayed on the monitor.

To clear azimuth zero:

1. Use the joystick to position the cursor beside CLEAR AZIMUTH ZERO.

2. Press Iris Open.

3. Follow the directions displayed on the monitor.

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 25

<Power Up>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

POWER UP ACTION

This setting defines a specific activity (scan, preset, pattern) to be performed in the event the power to the dome is cycled.

The following settings are available:

NONE - No action. AUTO (default) - The dome resumes its prior activity or direction before the power outage. AUTO SCAN - Dome starts auto scan operation. RANDOM SCAN - Dome starts random scan operation. FRAME SCAN - Dome starts frame scan operation. PRESET 1 - Dome goes to preset 1. PRESET 8 - Dome goes to preset 8. PATTERN 1 - Dome runs pattern 1. PATTERN 2 - Dome runs pattern 2. PATTERN 3 - Dome runs pattern 3. PATTERN 4 - Dome runs pattern 4.

POWER UP

POWER UP ACTION AUTO

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

26 C2444M-C (1/04)

<Line Sync>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

LINE SYNC

LINE SYNC ON LINE SYNC PHASE 0

Line sync refers to a programmable function that allows you to synchronize all cameras within a matrix system.

NOTE: Spectra III SE automatically senses V-sync input. No line sync setup is required for Pelco control systems that provide a V-sync signal.

For matrix systems that do not output V-sync, there are two settings for line synchronization:

ON (default) - Adjusts the phase of the line sync to synchronize input power. LINE SYNC

PHASE settings range from 0-359 degrees.

OFF - The dome synchronizes to an internal clock.

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 27

<Presets>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

The Spectra III SE dome system has 80 programmable preset positions. Each preset can be programmed to use pan, tilt, and all programmable camera settings.

The presets are numbered 1-32 and 35-82. Presets 33 and 34 are fixed commands that cannot be programmed. Preset 33 is the “flip” command, which will pan the dome drive 180 degrees. Preset 34 is the “pan zero” command, which will direct the dome drive to the factory-determined zero reference point.

Use the following steps to program a preset.

1. Select the preset number: a. Use the joystick to position the cursor beside PRESET NUMBER. Press Iris Open.

The cursor moves to the right.

b. Move the joystick up or down to view selections. Press Iris Open to enter selection.

2. Edit the preset label: a. Use the joystick to position the cursor beside EDIT PRESET LABEL. b. Press Iris Open. The following appears on the monitor:

LABEL FOR PRESET PRESET NUMBER 1234567890 OK ABCDEFGHIJ CANCEL KLMNOPQRST UVWXYZ.,-/ SPACE abcdefghij BACKSPACE klmnopqrst uvwxyz*;:

------

PRESETS

PRESET NUMBER 1 * * * PRESET NOT DEFINED * * *

BACK EXIT

REFERENCE INFORMATION AZIMUTH ELEVATION ZOOM RATIO CUSTOM CAMERA SETTINGS -

c. Use the joystick to position the cursor beside a character. Press Iris Open to enter

selection. To clear a character, position the cursor beside BACKSPACE, and then press Iris Open.

d. When label is completed, move the cursor to OK. Press Iris Open to return to the

Preset menu.

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

28 C2444M-C (1/04)

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

PRESETS

PRESET NUMBER 1 * * * PRESET NOT DEFINED * * *

BACK EXIT

REFERENCE INFORMATION AZIMUTH ELEVATION ZOOM RATIO CUSTOM CAMERA SETTINGS -

3. Edit the preset scene:

a. Use the joystick to position the cursor beside EDIT PRESET SCENE. b. Press Iris Open. c. Follow the directions displayed on the monitor.

4. Edit preset camera settings:

a. Use the joystick to position the cursor beside EDIT CAMERA SETTINGS. b. Press Iris Open. The EDIT CAMERA SETTINGS window appears on the monitor. Refer

to the

Camera

and

Advanced Camera Settings

sections of this manual to change

preset camera settings.

NOTE: You can copy camera settings from one preset to another preset. To copy camera settings do the following:

1. Use the joystick to position the cursor beside COPY CAMERA SETTINGS.

2. Press Iris Open. The cursor moves to the right.

3. Move the joystick up or down to view selections. Press Iris Open to enter selection.

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 29

<Patterns>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

PATTERNS

PATTERN NUMBER 1 <PROGRAM PATTERN> <CLEAR PATTERN>

BACK EXIT

REFERENCE INFORMATION PATTERN USAGE 0% REMAINING 100%

A pattern is a memorized, repeating, series of pan, tilt, zoom and preset functions that can be recalled with a command from a controller or automatically by a programmed function (alarm, park or power-up).

The Spectra III SE can handle up to four user-defined patterns. Pattern length is based upon memory usage rather than a fixed amount of time. The complexity of a pattern will determine the amount of storage available to program other patterns.

To program a pattern:

1. Use the joystick to position the cursor beside PATTERN NUMBER. Press Iris Open. The

cursor moves to the right.

2. Move the joystick up or down to view selections. Press Iris Open to enter selection.

3. Use the joystick to position the cursor beside PROGRAM PATTERN.

4. Press Iris Open. The Patterns programming window appears on the monitor.

5. Follow the directions displayed on the monitor.

After a pattern is programmed, the remaining storage percentage is displayed on the screen. This is the amount of memory available to program the remaining patterns.

To clear a pattern:

1. Use the joystick to position the cursor beside CLEAR PATTERN.

2. Press Iris Open.

3. Follow the directions displayed on the monitor.

NOTE: When programming one or more presets within a pattern use the normal controller commands to Call a Preset.

NOTE: Not all controllers can start all four patterns. However, any of the four patterns can be automatically started with park, power-up, and alarm functions.

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

30 C2444M-C (1/04)

<Zones>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

ZONES

ZONE NUMBER 1 * * * ZONE NOT DEFINED * * *

<EDIT ZONE> ZONE ENABLED NO ZONE BLANKING OFF

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

A zone is a pan area, defined by a left and right limit, on the 360-degree pan plane. The Spectra dome system is capable of eight zones, each with a 20-character label.

To program a zone:

1. Use the joystick to position the cursor beside ZONE NUMBER. Press Iris Open the cursor moves to the right.

2. Move the joystick up or down to view selections. Press Iris Open to enter selection.

3. Use the joystick to position the cursor beside EDIT ZONE.

4. Press Iris Open. The Zone programming window appears on the monitor.

5. Follow the directions displayed on the monitor. After the left and right limit stops are set, the Zones menu reappears with the ZONE ENABLED option set to YES.

To edit a zone label:

1. Use the joystick to position the cursor beside EDIT ZONE LABEL.

2. Press Iris Open. The following appears on the monitor:

3. Use the joystick to position the cursor beside a character. Press Iris Open to enter selection. To clear a character, position the cursor beside BACKSPACE, and then press Iris Open.

LABEL FOR PRESET PRESET NUMBER 1234567890 OK ABCDEFGHIJ CANCEL KLMNOPQRST UVWXYZ.,-/ SPACE abcdefghij BACKSPACE klmnopqrst uvwxyz*;:

------

4. When the label is completed, move the cursor the OK. Press Iris Open to return to the Zones menu.

To disable a zone (a zone is enabled automatically when it is programmed) or to blank a zone:

1. Move the cursor beside ZONE ENABLED or ZONE BLANKING.

2. Press Iris Open. The cursor moves to the right.

3. Move the joystick up or down to view selections. Press Iris Open to enter selection.

To clear a zone:

1. Use the joystick to position the cursor beside CLEAR ZONE.

2. Press Iris Open. Follow the instructions on the screen.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 31

<Window Blanking>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

WINDOW BLANKING

STYLE GRAY

BLANK ALL ABOVE OFF BLANK ALL BELOW OFF

BACK EXIT

Window blanking allows a user to program up to eight, four-sided, user-defined areas that cannot be viewed by the operator of the dome system. A blanked area will move with pan and tilt functions and automatically adjust in size as the lens zooms telephoto and wide.

Spectra III SE has two style modes for window blanking, GRAY and SMEAR. If style is set to gray, the blanked area is covered with a solid gray window. If smear is selected images behind the window will be noticeable but not distinguishable.

To set a window blanking area:

1. Use the joystick to position the cursor beside WINDOW BLANKING. Press Iris Open. The WINDOW BLANKING menu appears on the screen.

2. Move the joystick to position the cursor beside SET WINDOWS. Press Iris Open to enter.

3. Position the cursor beside WINDOW NUMBER. Press Iris Open. The cursor moves to the right.

4. Move the joystick up or down to view selections. Press Iris Open to enter selection.

5. Use the joystick to position the cursor beside EDIT WINDOW LOCATION. Press Iris Open, and then follow the instructions that appear on the screen.

NOTE: Use the inside corner of the window selection tool as a guide when selecting the upper left, upper right,

INSIDE CORNER

bottom right, and bottom left corners of the window.

NOTE: Set windows are not visible when editing a new window location.

When all four corners are set, the SET WINDOWS menu reappears, the blanked area is displayed, and the ENABLE WINDOW option is set to YES.

SET WINDOWS

WINDOW NUMBER 1

ENABLE WINDOW REVERSE CLEAR WINDOW

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

32 C2444M-C (1/04)

IMPORTANT: Increase the size of the window if any part of the blanked area is revealed during pan, tilt, and zoom operations.

6. The blanked area can be programmed to turn on or off at a specified zoom point. To set the zoom point:

a. Use the joystick to position the cursor beside EDIT WINDOW ZOOM, and then press

Iris Open.

b. Zoom in to the point where you want window blanking to turn on. Press Iris Open to

set the zoom point.

TIP: Since the area is already blanked out, it may be difficult to determine when you want window blanking to turn on. Reverse the window before setting the zoom point. When finished reverse the window again to blank out the area.

Window Blanking Disabled Window Blanking Enabled

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 33

REVERSE

HORIZON

A blanked out area can be reversed to make it visible and the areas on both sides of it not visible. The areas above and below the blanking area remain visible. Reversing the window a second time will return it to its original condition.

CLEAR WINDOW

All areas that have been set for window blanking are cleared.

BLANK ALL ABOVE/BLANK ALL BELOW

Blank All Above and Blank All Below add additional flexibility to setting up privacy areas. These settings are ideal for applications where a complete pan location needs to be blanked.

Blank All Above

Blanks everything above a user-defined tilt angle. A blanked band will appear at the top of the screen. The following settings are available:

OFF (default) - No blanking 0 - Blanks area from horizon to 2° below horizon

-10 - Blanks area from horizon to 10° below horizon

-20 - Blanks area from horizon to 20° below horizon

-30 - Blanks area from horizon to 30° below horizon

-40 - Blanks area from horizon to 40° below horizon

-50 - Blanks area from horizon to 50° below horizon

-60 - Blanks area from horizon to 60° below horizon

-70 - Blanks area from horizon to 70° below horizon

-80 - Blanks area from horizon to 80° below horizon

AMERA

8 0

Blank All Below

Blanks everything below a user-defined tilt angle. A blanked circle will appear below the specified angle. The following settings are available:

OFF (default) - No blanking 0 - Blanks area from 2° to 92° below horizon

-10 - Blanks area from 10° to 92° below horizon

-20 - Blanks area from 20° to 92° below horizon

-30 - Blanks area from 30° to 92° below horizon

-40 - Blanks area from 40° to 92° below horizon

-50 - Blanks area from 50° to 92° below horizon

-60 - Blanks area from 60° to 92° below horizon

-70 - Blanks area from 70° to 92° below horizon

-80 - Blanks area from 80° to 92° below horizon

34 C2444M-C (1/04)

<Alarms>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

ALARMS

RESUME OFF SEQUENCE (SECS) 5 RESET DELAY (SECS) 0

BACK EXIT

The Spectra III SE dome has seven alarm inputs, which can be programmed as high, medium or low priority. When an alarm is received, an input signal to the dome triggers the user-defined action (go to preset, run pattern, etc.) programmed for the alarm.

There are three global alarm settings:

RESUME - This mode lets the dome resume its previous activity (scan, pattern, or previous

position) after all alarms are cleared.

SEQUENCE - This is the time the dome will perform an alarm activity when more than one

alarm of the same priority occurs at the same time.

RESET DELAY - This is the amount of time the dome considers the alarm to be active after

it has physically cleared.

Use the following steps to program alarm settings.

1. Use the joystick to position the cursor beside ALARM SETTINGS. Press Iris Open.

2. Select the alarm number: a. Use the joystick to position the cursor beside ALARM NUMBER. b. Press Iris Open. The cursor moves to the right. c. Move the joystick up or down to view selections. Press Iris Open to enter selection.

(Continued on next page)

ALARM SETTINGS

ALARM NUMBER 1

ALARM PRIORITY LOW ALARM ACTION NONE ACTIVATE AUX NO ALARM CONTACT N/O

BACK EXIT

Quick Programming Guide

* This setting only applies to Pressurized

Spectra III SE dome systems with software version 1.25 or higher.

C2444M-C (1/04) 35

(See page 9)

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

ALARMS

RESUME OFF SEQUENCE (SECS) 5 RESET DELAY (SECS) 0

BACK EXIT

3. Select the alarm priority: a. Use the joystick to position the cursor beside ALARM PRIORITY. b. Press Iris Open. The cursor moves to the right. c. Move the joystick up or down to view the available selections. Available settings

include HIGH, MEDIUM, and LOW (default). If multiple alarms with different priorities are active at the same time, the dome will only go to the alarms with the highest priority.

d. Press Iris Open to enter selection.

NOTE: HIGH - Alarm action takes highest priority and will override manual pan, tilt,

and zoom control.

MEDIUM/LOW - Alarm action will not occur if an alarm occurs during manual

pan, tilt, and zoom control.

4. Set the alarm action: a. Use the joystick to position the cursor beside ALARM ACTION. b. Press Iris Open. The cursor moves to the right. c. Move the joystick up or down to view the available selections. The following are the

settings for alarm action:

NONE - No action when alarm is triggered. PRESET - Dome goes to the preset that is the same as the alarm number. Preset

1 will go to Alarm 1. PATTERN 1 - Dome runs pattern 1 when alarm is triggered. PATTERN 2 - Dome runs pattern 2 when alarm is triggered. PATTERN 3 - Dome runs pattern 3 when alarm is triggered. PATTERN 4 - Dome runs pattern 4 when alarm is triggered. AUTO SCAN - Dome starts auto scan operation when alarm is triggered. RANDOM SCAN - Dome starts random scan operation when alarm is triggered. FRAME SCAN - Dome starts frame scan operation when alarm is triggered.

d. Press Iris Open to enter selection.

ALARM SETTINGS

ALARM NUMBER 1

ALARM PRIORITY LOW ALARM ACTION NONE ACTIVATE AUX NO ALARM CONTACT N/O

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

36 C2444M-C (1/04)

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

5. Set the auxiliary to activate: a. Use the joystick to position the cursor beside ACTIVATE AUX. b. Press Iris Open. The cursor moves to the right. c. Move the joystick up or down to view the following available selections.

NO (default) - Not activated. 1 - An alarm action will close AUX 1. 2 - An alarm action will close AUX 2.

d. Press Iris Open to enter selection.

DOME SETTINGS

BACK EXIT

ALARMS

RESUME OFF SEQUENCE (SECS) 5 RESET DELAY (SECS) 0

BACK EXIT

NOTE: The AUX 1/AUX2 will stop when all the alarms assigned to it have cleared. If the AUX1/AUX is set up as momentary, then it will be activated each time a new alarm is activated.

6. Set the alarm contact: a. Use the joystick to position the cursor beside ALARM CONTACT. b. Press Iris Open. The cursor moves to the right. c. Move the joystick up or down to view the following available selections.

N/O (default) - Normally open N/C - Normally closed

d. Press Iris Open to enter selection.

ALARM SETTINGS

ALARM NUMBER 1

ALARM PRIORITY LOW ALARM ACTION NONE ACTIVATE AUX NO ALARM CONTACT N/O

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

Quick Programming Guide

1.25 or higher.

(See page 9)

C2444M-C (1/04) 37

<Aux>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

An auxiliary output is a programmable signal from the dome back box that can trigger another device to operate. An auxiliary output is programmable to trigger from an alarm or from a controller.

An AUX 1 command from the controller will activate the relay in the dome and operate the device that is connected to the relay. The output of AUX 1 can be connected to the alarm input of a system switch to activate automatic monitor switching and recording.

An AUX 2 command from the controller will place a ground at the output of AUX 2 to operate the device that is connected to it.

The following are the available AUX MODE settings:

TOGGLE (default) - Changes the state of the auxiliary output every time an AUX command

is received from the controller.

LATCHING - Must receive an AUX ON/AUX OFF command from the controller to turn the

auxiliary output on/off.

MOMENTARY - An AUX ON command from the controller turns the auxiliary output on for

the programmed DWELL TIME. The auxiliary output will automatically turn off when the dwell time is finished.

AUX

AUX 1 MODE TOGGLE DWELL TIME (SECS) 1 AUX 2 MODE TOGGLE DWELL TIME (SECS) 1

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

38 C2444M-C (1/04)

<Alert>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

ALERT

REPEAT CONSTANT ACK ACTION ALWAYS ON ACTIVATE AUX NO <CURRENT READING> RESET ALERT

BACK EXIT

NOTE: The

Alert

section only applies to Pressurized Spectra III SE dome systems with software version 1.25 or higher. Spectra III SE systems that are not pressurized or pressurized systems that do not have dome drive software version 1.25 or higher will not display this menu item.

Software version 1.25 or higher includes the software to monitor temperature, pressure, and dew point for Pressurized Spectra III SE systems.

Sensors strategically placed inside the pressurized dome system continually monitor pressure, temperature, and dew point. If internal conditions reach unacceptable levels, an alert message appears on the screen describing the alert condition. Example: If pressure drops below 1 psig, “LOW PRESSURE” is displayed on the monitor.

The following system conditions will trigger an alert message:

System Condition Alert Message

Temperature is above 140°F (60°C) HIGH TEMPERATURE Temperature is below -40°F (-40°C). LOW TEMPERATURE Pressure is above 11 PSIG. HIGH PRESSURE Pressure is below 1 PSIG LOW PRESSURE The difference between the temperature and the dew point is DEW POINT (HIGH

less than or equal to 3°C. HUMIDITY)

The alert message will be repeatedly displayed until the system controller acknowledges the alert condition by selecting ACK ALERT in the main menu. Once acknowledged, the alert message changes to the programmed acknowledge action (ACK ACTION). If the alert condition remains active after a period of time, the alert message reappears on the monitor, restarting the alert message cycle. This cycle will continue to repeat until the alert condition is resolved.

REPEAT

This setting programs how often an alert message is repeatedly displayed until the system controller acknowledges the alert condition. The following are the settings for REPEAT:

CONSTANT - The alert message is continuously displayed on the monitor until acknowl-

edged.

15 MIN - The alert message is displayed every 15 minutes for a 15-second duration until

acknowledged.

30 MIN - The alert message is displayed every 30 minutes for a 15-second duration until

acknowledged.

60 MIN - The alert message is displayed every 60 minutes for a 15-second duration until

acknowledged.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 39

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

ACK ACTION

Acknowledge action programs the alert label behavior after the alert condition has been acknowledged. The following settings are available for ACK ACTION:

ALWAYS ON - The alert label is displayed until alert conditions are cleared.

OFF 8 HRS - The alert label is turned off for 8 hours. Label returns after 8 hours if the alert

condition persists.

OFF 24 HRS - The alert label is turned off for 24 hours. Label returns after 24 hours if the

alert condition persists.

DOME SETTINGS

BACK EXIT

ALERT

REPEAT CONSTANT ACK ACTION ALWAYS ON ACTIVATE AUX NO <CURRENT READING> RESET ALERT

BACK EXIT

CURRENT READING

TEMPERATURE 0°C

DEWPOINT 0°C

PRESSURE 0.0 PSIG

REFRESH

BACK EXIT

0.0 BAR

OFF 48 HRS - The alert label is turned off for 48 hours. Label returns after 48 hours if the

alert condition persists.

ACTIVATE AUX

This setting activates an auxiliary when an alert condition exists. ACTIVATE AUX settings include the following:

NO (default) - Not activated. 1 - An alert condition will close AUX 1. 2 - An alert condition will close AUX 2.

CURRENT READING

The Current Reading menu displays the existing status of temperature, pressure, and dew point inside the dome system. An arrow displayed to the left of a menu item denotes that an alert condition exists. An up arrow indicates the reading is over the threshold. A down arrow indicates the reading is below the threshold.

The high temperature alert occurs if the temperature is above 140°F (60°C). The low temperature alert occurs if the temperature is below -40°F (-40°C). The high pressure alert occurs if the pressure is above 11 PSIG. The low pressure alert occurs if the pressure is below 1 PSIG. The dew point (high humidity) alert occurs if the difference between the temperature and

the dew point is less than or equal to 3°C.

NOTE: The normal operating temperature inside the unit will be greater than the temperature outside the back box due to the heat emitted by the system’s electronics.

0°F

ALERT RESET

Alert reset clears the alert condition and removes the alert label from the monitor. The system automatically checks internal conditions 60 seconds after reset. If conditions are still unacceptable, the alert label reappears on the screen indicating further corrective action is required.

40 C2444M-C (1/04)

<Clear>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

Use this setting to clear user-defined settings or return the dome to factory default settings.

The following are the available CLEAR settings:

ALL ZONES - Clears all zones. To clear a single zone, refer to the ALL PRESETS - Clears all presets. To clear a single preset, refer to the ALL PATTERNS - Clears all patterns. To clear a single patterns, refer to the

Zones

section.

Presets

Patterns

section.

ALL WINDOW BLANKING - Clears all blanked windows. To clear a single blanked window,

refer to the

Window Blanking

section.

RESTORE FACTORY DEFAULTS - Restores all camera settings to factory default settings.

CLEAR

CLEAR ALL ZONES CLEAR ALL PRESETS CLEAR ALL PATTERNS CLEAR ALL WINDOW BLANKING

RESTORE FACTORY DEFAULTS

BACK EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 41

<Password>

SPECTRA III

LANGUAGE ENGLISH <SYSTEM INFORMATION>

<DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

DOME SETTINGS

BACK EXIT

Spectra III SE features password protection to prevent unauthorized changes to the dome settings. An operator can open the System Information and Display Setup Screens, but cannot access any of the Dome Settings menus.

Controller/keyboard commands cannot override password-protected settings. If a keyboard is used to set a preset, pattern, or zone, the Enter Password screen appears on the monitor. The password must be entered before programming can continue.

At least one character must be entered to create a valid password.

PASSWORD

ENABLE PASSWORD OFF <EDIT PASSWORD>

BACK EXIT

EDIT THE PASSWORD

---------1234567890 OK

ABCDEFGHIJ CANCEL KLMNOPQRST UVWXYZ.,-/ SPACE abcdefghij BACKSPACE klmnopqrst uvwxyz*;:

* This setting only applies to Pressurized

Spectra III SE dome systems with software version 1.25 or higher.

42 C2444M-C (1/04)

RESET, CYCLE POWER, REBOOT

SPECTRA III

LANGUAGE ENGLISH

<SYSTEM INFORMATION> <DISPLAY SETUP> <DOME SETTINGS> ACK ALERT*

RESET CAMERA CYCLE CAMERA POWER REBOOT SYSTEM

EXIT

* This setting only applies to

Pressurized Spectra III SE dome systems with software version

1.25 or higher.

RESET CAMERA

Use this function to reset all camera settings to factory default parameters.

CYCLE CAMERA POWER

If the camera is not operating or if you lose camera control, cycle camera power. Cycling camera power resets the camera but does not change any saved camera settings.

REBOOT SYSTEM

Reboot the system if it is not operating or if there is no control. Rebooting the system will cycle dome and camera power without changing programmed dome settings.

Quick Programming Guide

(See page 9)

C2444M-C (1/04) 43

SOFTWARE/LANGUAGE FILE UPLOAD

The RJ-45 data port of the dome drive allows access for on-site setup, testing, and uploading of revised operating software and language files. A Pelco field service tool is required to perform these operations. Field service tools include Pelco’s remote monitor kit (IPS-RMK), remote data port box (IPS-RDPE-2), and remote monitor cable (IPS-CABLE).

For instructions on how to upload revised operating software and language files refer to the Installation/Operation manual supplied with the field service tool.

NOTE: Only perform software uploads when necessary. Software uploads do not need to be performed if the dome system is operating properly.

UPLOAD ICON

During a software/language file upload, an icon will appear on the monitor to indicate data is being transferred to the Spectra dome system (refer to the figure below). The default setting for data transmission is 115.2 KB per second. Noisy and long-run connections will slow the transmission rate.

Upload Icon

44 C2444M-C (1/04)

SPECIFICATIONS

DD53C22

Signal Format NTSC Scanning System 2:1 Interlace Image Sensor 1/4-inch CCD Effective pixels 768 (H) X 494 (V) Horizontal Resolution >470 TV lines Lens F1.6 (f=4~88 mm optical, 22X optical zoom, 12X electronic zoom) Zoom Speed 3.9 seconds Horizontal Angle of view 47° at 4 mm wide zoom; 2.2° at 88 mm telephoto zoom Focus Automatic with manual override Maximum Sensitivity at 35 IRE 0.02 lux at 1/2 sec. shutter speed Sync System Internal/AC line lock, phase adjustable via remote control, V-sync White Balance Automatic with manual override Shutter Speed Automatic (electronic iris)/manual

1/2 ~ 1/30,000 Iris Control Automatic iris control with manual override Gain Control Automatic/off Video Output 1 Vp-p, 75 ohms Video Signal to Noise >50 dB

DD53C22-X

Signal Format PAL Scanning System 2:1 Interlace Image Sensor 1/4-inch CCD Effective pixels 752 (H) X 582 (V) Horizontal Resolution >460 TV lines Lens F1.6 (f=4~88 mm optical, 22X optical zoom, 12X electronic zoom) Zoom Speed 3.9 seconds Horizontal Angle of view 47° at 4 mm wide zoom; 2.2° at 88 mm telephoto zoom Focus Automatic with manual override Maximum Sensitivity at 35 IRE 0.02 lux at 1/1.5 sec. shutter speed Sync System Internal/AC line lock, phase adjustable via remote control, V-sync White Balance Automatic with manual override Shutter Speed Automatic (electronic iris)/manual

1/1.5 ~ 1/30,000 Iris Control Automatic iris control with manual override Gain Control Automatic/off Video Output 1 Vp-p, 75 ohms Video Signal to Noise >50 dB

C2444M-C (1/04) 45

REGULATORY NOTICES

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

RADIO AND TELEVISION INTERFERENCE This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However there is no guarantee that the interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and the receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

You may also find helpful the following booklet, prepared by the FCC: “How to Identify and Resolve Radio-TV Interference Problems.” This booklet is available from the U.S. Government Printing Office, Washington D.C. 20402.

Changes and Modifications not expressly approved by the manufacturer or registrant of this equipment can void your authority to operate this equipment under Federal Communications Commission’s rules.

REVISION HISTORY

Manual # Date Comments

C2444M 2/02 Original version. C2444M-A 11/02 Revised Quick Start Guide. C2444M-B 2/03 Manual revised to include features of software version 1.2. C2444M-C 1/04 Added alert feature. Updated menus and instructions.

46 C2444M-C (1/04)

World Headquarters

3500 Pelco Way

Clovis, California 93612 USA

USA & Canada

Tel: 800/289-9100

Fax: 800/289-9150

International Tel: 1-559/292-1981 Fax: 1-559/348-1120

www.pelco.com

ISO9001

Pelco DD53C22-X User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Presets

Title Text

Label Position

Spectra III EVS

CONTENTS

WELCOME

Getting Started

HOW TO OPERATE YOUR DOME SYSTEM

Accessing Main Menu (Preset 95)

CM6700/CM6800

KBD200A/KBD300A (DIRECT MODE ONLY)

CM9500

CM9740/CM9760

MPT9500

PelcoNet

SYSTEM INFORMATION

<Label Position>

<Camera>

TYPE OF LIGHTING

AUTO FOCUS

ZOOM LIMIT

ZOOM SPEED

LOW LIGHT LIMIT

<Advanced Camera Settings>

SHUTTER SPEED

AGC LIMIT

AUTO IRIS

AUTO SHARPNESS

AUTO WHITE BALANCE

BACKLIGHT COMPENSATION (BLC)

VIDEO LEVEL

<Motion Settings>

AUTO FLIP

PROPORTIONAL PAN

PARK TIME

SCAN SPEED

PRESET FREEZE FRAME

LIMIT STOPS

AZIMUTH ZERO

<Power Up>

POWER UP ACTION

<Line Sync>

<Presets>

<Patterns>

<Zones>

<Window Blanking>

REVERSE

BLANK ALL ABOVE/BLANK ALL BELOW

<Alarms>

<Aux>

<Alert>

REPEAT

ACK ACTION

CURRENT READING

ACTIVATE AUX

ALERT RESET

<Clear>

<Password>

RESET CAMERA

CYCLE CAMERA POWER

REBOOT SYSTEM

UPLOAD ICON

REGULATORY NOTICES
