DD14 Series

Intercept

Fixed Mount

Installation/

Operation Manual

C291M-B (1/98)

Pelco • 3500 Pelco Way, Clovis • CA 93612-5699 USA • www.pelco.com

In North America and Canada: Tel (800) 289-9100 or FAX (800) 289-9150

International Customers: Tel (1-559) 292-1981 or FAX (1-559) 348-1120

CONTENTS

Section Page

1.0 GENERAL..................................................................................................5

1.1 IMPORTANT SAFEGUARDS AND WARNINGS ...............................5

1.2 UNPACKING INSTRUCTIONS ..........................................................6

2.0 DESCRIPTION ..........................................................................................7

2.1 MODELS............................................................................................7

3.0 INSTALLATION ..........................................................................................8

3.1 FIXED MOUNT INSTALLATION ........................................................8

3.2 LENS WIRING ..................................................................................10

3.3 CAMERA/LENS INSTALLATION ...................................................... 10

3.4 ADJUSTMENTS ...............................................................................10

4.0 MAINTENANCE........................................................................................11

4.1 FIXED MOUNT REMOVAL ............................................................... 11

5.0 EXPLODED ASSEMBLY DIAGRAM.........................................................12

6.0 SPECIFICATIONS ....................................................................................14

7.0 WARRANTY AND RETURN INFORMATION ...........................................16

2 Pelco Manual C291M-B (1/98)

LIST OF ILLUSTRATIONS

Figure Page

1 Back Box and Fixed Mount Components...........................................9

2 DD14 Fixed Mount Exploded Assembly Diagram............................. 12

LIST OF TABLES

Table Page

A DD14 Fixed Mount Parts List ............................................................13

REVISION HISTORY

Manual # Date Comments

C291M — Original version. C291M-A 6/95 Rev A. Update manual to show new rocker style power

C291M-B 1/98 Rev B. Changed manual to new format and manual

switch.

pagination. Revised installation instructions. Reduced number of models.

Pelco Manual C291M-B (1/98) 3

(This page intentionally left blank.)

4 Pelco Manual C291M-B (1/98)

1.0 GENERAL

1.1 IMPORTANT SAFEGUARDS AND WARNINGS

Prior to installation and use of this product, the following WARNINGS should be observed.

1. Installation and servicing should only be done by Qualified Service Personnel and conform to all Local codes.

2. Unless the unit is specifically marked as a NEMA Type 3, 3R, 3S, 4, 4X, 6, or 6P enclosure, it is designed for indoor use only and it must not be installed where exposed to rain and moisture.

3. Only use replacement parts recommended by Pelco.

4. After replacement/repair of this unit’s electrical components, conduct a resistance measurement between line and exposed parts to verify the exposed parts have not been connected to line circuitry.

5. The installation method and materials should be capable of supporting four (4) times the weight of the enclosure, pan/tilt, camera and lens combination.

The product and/or manual may bear the following marks:

This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this unit.

This symbol indicates that there are important operating and maintenance instructions in the literature accompanying this unit.

CAUTION:

RISK OF

ELECTRIC SHOCK.

DO NOT OPEN.

TO REDUCE THE RISK OF ELECTRICAL SHOCK,

DO NOT REMOVE COVER. NO USER-

SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

CAUTION:

Please thoroughly familiarize yourself with the information

in this manual prior to installation and operation.

Pelco Manual C291M-B (1/98) 5

1.2 UNPACKING INSTRUCTIONS

Unpack and inspect all parts carefully. Be sure to save the shipping carton and any inserts. They are the saf est material in

which to make future shipments. The following items are supplied:

1 Fixed mount 1 Dome liner 1 1/4-20 x 1/2" bolt 1 1/4" flat washer 1 1/4" split lock washer 1 Installation/Operation Manual (C291M-B)

If an item appears to have been damaged in shipment, replace it properly in its carton and contact the factory at 1-800-289-9100 or 1-209-292-1981 for a replacement. (International customers fax 1-209-348-1120 for authorization and instr uctions.)

If an item needs to be returned to the factory for repair, consult the WARRANTY AND RETURN section of this manual for instructions.

6 Pelco Manual C291M-B (1/98)

The DD14A0L fixed mount is part of the IDS14 Intercept® Series of domes. The fixed mount requires a back box to make a complete system.

This manual covers the DD14A0L fixed mount only. For installation and operation instructions for the back box, refer to manual C454M-C.

2.1 MODELS

DD14A0L Fixed mount with dome liner (dome is included with back box).

2.0 DESCRIPTION

Pelco Manual C291M-B (1/98) 7

3.0 INSTALLATION

Proceed with the installation of the fixed mount after you have installed the back box.

If a camera/lens package has not been installed on your fixed mount, you can install the camera/lens either before you install the fixed mount in the back box or after you install the fixed mount. If y ou want to install the camera/lens first, proceed to Sections 3.2, LENS WIRING, and 3.3, CAMERA/LENS INSTALLATION, then return to Section 3.1, FIXED MOUNT INSTALLATION.

3.1 FIXED MOUNT INSTALLATION

1. Turn off the power to the back box.

2. Remove the hairpin clips from the two latches inside the back box (refer to Figure 1) and open the latches.

3. Insert the fixed mount into the back box: a. Refer to Figure 1 and line up the upper backet on the dome so that:

The 25-pin connector on the fixed mount will go into its mating connector on the back box.

The latch pins on the side of the upper bracket will go into the latches in the back box.

The two guide pins on the back box will go into the bushings on the upper

bracket of the fixed mount. b. Push the fixed mount into place and close the latches. c. Reinstall the hairpin clips in the latches to prevent the latches from open-

ing.

Proceed to Sections 3.2, LENS WIRING, and 3.3, CAMERA/LENS INSTALLATION, if you have not installed your camera/lens. Otherwise proceed to Section 3.4, ADJUSTMENTS.

8 Pelco Manual C291M-B (1/98)

BACK BOX

HAIRPIN

CLIP

LATCH

GUIDE PIN GUIDE PIN

HAIRPIN

CLIP

FIXED MOUNT UPPER BRACKET

LATCH PIN

BUSHING

25-PIN CONNECTOR

LATCH

25-PIN CONNECTOR

BUSHING

LATCH PIN

Figure 1. Back Box and Fixed Mount Components

Pelco Manual C291M-B (1/98) 9

3.2 LENS WIRING

Refer to the back box manual for wiring pinouts and wire the lens according to the manufacturer’s instructions.

Proceed to Section 3.3, CAMERA/LENS INSTALLATION.

3.3 CAMERA/LENS INSTALLATION

1. Attach the camera/lens to the tilt table using the 1/4-20 x 1/2" bolt, flat washer , and lock washer that are supplied.

2. Connect the camera power spade lugs and coaxial video cable.

Proceed to Section 3.4, ADJUSTMENTS.

3.4 ADJUSTMENTS

1. Loosen the horizontal positioning lock-down knob, rotate the mount the desired position, and re-tighten the knob.

2. Loosen the vertical positioning lock-down knob, adjust the tilt table to the desired position, and re-tighten the knob.

3. Install the dome liner: Push the studs on the liner into the mount bracket. Make sure the window slot is aligned with the lens.

Ensure there is sufficient clearance between the camera/lens and the dome liner. Reposition the camera/lens and wiring as necessary to achieve clearances.

4. Reach into the back box and turn on the power switch (if applicable to your back box.

5. Suspended/Hard Ceiling Models - Attach the trim ring and dome to the back box.

Pendant Models - Align the three bezel pins with the large hole in the back box brackets, push the bezel up and rotate clockwise to latch.

Attach the back box gasket to the rim of the back box to provide an air-tight seal between the back box and the bezel.

The installation is complete.

10 Pelco Manual C291M-B (1/98)

Clean the acrylic dome as necessary to provide a clear picture. Clean the dome with a nonabrasive cleaning cloth and antistatic cleaner that is safe for use on acrylic plastic.

4.1 FIXED MOUNT REMOVAL

1. Pendant Models Only - Remove the gasket from the rim of the back box.

2. Remove the back box trim ring or bezel. To remove a bezel, turn it about 1/2" (1.27 cm) counterclockwise and pull down.

3. Turn off the power switch.

4. Remove the hairpin clips from the latches.

5. Open one of the latches.

6. Grasp the unit with one hand to prepare for the 10- to 13-pound (4.5-5.9 kg) load.

7. Open the other latch and lower the fixed mount.

4.0 MAINTENANCE

Pelco Manual C291M-B (1/98) 11

5.0 EXPLODED ASSEMBLY DIAGRAM

K L

M E

Figure 2. DD14 Fixed Mount Exploded Assembly Diagr am

12 Pelco Manual C291M-B (1/98)

Table A. DD14 Fixed Mount Parts List

Item Quantity Description Part Number

12Bushing 80010004 22Push nut 80010011 31Upper mount bracket 8004034COMP 41Spindle bracket 8004037COMP 51Frame 8004019COMP 62Dome bracket 8004020COMP 71Tilt table 8004021COMP 82Latch pin 8004145COMP

91ABS dome liner 81410002 10 1 Dome plate, receiver side 8144002COMP 11 1 Dome plate, tilt side 8144003COMP 12 1 Dome brace 8144004COMP 13 4 Ball stud PT180410000 14 2 Gray knob, 1/4-20 tapped CM1610003 15 1 25-position connector receptacle CON10J025Z41T 16 4 Ball stud receiver PT180410001 17 1 Cross bar 8004043COMP 18 6 Crimp pin, loose piece (not shown) CON66107-2

(for use with item #15)

19 1 BNC crimp connector for RG174 Coax (not shown) CONCPM88-174

A2Screw, 1/4-20 x 1" flat head, Phillips ZH1/420X1.00SFS

B1Allen screw, 1/4-20 x 1" ZH1/420X1.00SS

C1Lock nut, 1/4-20, nylon insert ZH1/420NUTCHN

D6Screw, 6-32 x 3/8" pan head, Phillips ZH6-32X.375SPP

E18Internal star washer, #6 ZH6LWSIS

F2Screw, 6-32 x 1/2" pan head, Phillips ZH6-32X.500SPP

G4Screw, 8-32 x 1/2" pan head, Phillips ZH8-32X.500SPP H4Internal star washer, #8 ZH8LWSIS

I8Screw, 6-32 x 3/8" flat head, Phillips, black ZH6-32X.375BPF

J2Spacer, 1/4" hex x 1/2" long, 6-32 tapped SPA8423

K1Fender washer, 1/4" x 1.5" x 14" ga, black ZH255X1.50X62

L1Split lock washer, 1/4" ZH1/4LWSSL

M10Nut, 6-32 ZH6-32NUTSH N4Spacer, 1/4" O.D. x 1/8" long, #6 clear SPA8500 P6Screw, 6-32 x 3/8" pan head, Phillips, black ZH6-32X.375BPP

Pelco Manual C291M-B (1/98) 13

6.0 SPECIFICATIONS

MECHANICAL

Pan: 360° movement in horizontal plane Tilt: -90° movement from horizontal plane Approximate

Camera/Lens Size: Maximum total length of camera/lens 11.5" (29.21 cm) includ-

ing BNC cable connection to camera; max. lens width 4.70" (11.93 cm); max. lens height 3.20" (8.13 cm)

Connectors

Video: BNC Camera Power: Spade lugs

GENERAL

Construction

Fixed Mount: Aluminum with stainless steel hardware Dome Liner: Plastic

Weight: 4.1 lbs (1.85 kg)

(Design and product specifications subject to change without notice.)

14 Pelco Manual C291M-B (1/98)

NOTES

Pelco Manual C291M-B (1/98) 15

7.0 WARRANTY AND RETURN INFORMATION

WARRANTY

Pelco will repair or replace, without charge, any merchandise proved defective in material or workmanship for a period of one year after the date of shipment. Exceptions to this warranty are as noted below:

• Five years on FT/FR8000 Series fiber optic products.

• Three years on Genex

• Three years on Camclosure CC3751H-2, CC3651H-2X, MC3651H-2, and CC3651H-2X camera models, which have a five-year warranty.

• Two years on standard motorized or fixed focal length lenses.

• Two years on Legacy fixed dome products.

• Two years on Spectra motion applications.

• Two years on Esprit® and WW5700 Series window wiper (excluding wiper blades).

• Eighteen months on DX Series digital video recorders, NVR300 Series network video recorders, and Endura™ Series distributed network-based video products.months on DX Series digital video recorders, NVR300 Series network video recorders, Endura™ Series distributed network-based video products, and TW3000 Series twisted pair transmission products.

• One year (except video heads) on video cassette recorders (VCRs). Video heads will be covered for a period of six months.

• Six months on all pan and tilts, scanners or preset lenses used in continuous motion applications (that is, preset scan, tour and auto scan modes).

Pelco will warrant all replacement parts and repairs for 90 days from the date of Pelco shipment. All goods requiring warranty repair shall be sent freight prepaid to Pelco, Clovis, California. Repairs made necessary by reason of misuse, alteration, normal wear, or accident are not covered under this warranty.

Pelco assumes no risk and shall be subject to no liability for damages or loss resulting from the specific use or application made of the Products. Pelco’s liability for any claim, whether based on breach of contract, negligence, infringement of any rights of any party or product liability, relating to the Products shall not exceed the price paid by the Dealer to Pelco for such Products. In no event will Pelco be liable for any special, incidental or consequential damages (including loss of use, loss of profit and claims of third parties) however caused, whether by the negligence of Pelco or otherwise.

The above warranty provides the Dealer with specific legal rights. The Dealer may also have additional rights, which are subject to variation from state to state.

Series products (multiplexers, server, and keyboard).

and fixed camera models, except the CC3701H-2, CC3701H-2X,

, CM6700/CM6800/CM9700 Series matrix, and DF5/DF8 Series

, Esprit®, ExSite™, and PS20 Scanners, including when used in continuous

If a warranty repair is required, the Dealer must contact Pelco at (800)289-9100 or (559) 292-1981 to obtain a Repair Authorization number (RA), and provide the following infor mation:

1. Model and serial number

2. Date of shipment, P.O. number, Sales Order number, or Pelco invoice number

3. Details of the defect or problem If there is a dispute regarding the warranty of a product which does not fall under the warranty condi-

tions stated above, please include a written explanation with the product when returned. Method of return shipment shall be the same or equal to the method by which the item was received by

Pelco. RETURNS

In order to expedite parts returned to the factory for repair or credit, please call the factory at (800) 289-9100 or (559) 292-1981 to obtain an authorization number (CA number if returned for credit, and RA number if returned for repair). All merchandise returned for credit may be subject to a 20% restocking and refurbishing charge.

Goods returned for repair or credit should be clearly identified with the assigned CA or RA number and freight should be prepaid. Ship to the appropriate address below. If you are located within the continental U.S., Alaska, Hawaii or Puer to Rico, send goods to:

If you are located outside the continental U.S., Alaska, Hawaii or Puer to Rico and are instructed to return goods to the USA, you may do one of the following: If the goods are to be sent by a COURIER SERVICE, send the goods to:

If the goods are to be sent by a FREIGHT FORWARDER, send the goods to:

Service Department Pelco 3500 Pelco Way Clovis, CA 93612-5699

Pelco 3500 Pelco Way Clovis, CA 93612-5699 USA

Pelco c/o Expeditors 473 Eccles Avenue South San Francisco, CA 94080 USA Phone: 650-737-1700 Fax: 650-737-0933
