Description

The CCC1390H Series camera is a compact, wide dynamic range (WDR), day/night camera. Its WDR technology provides up to 60 dB of dynamic range and produces superior images over a wide range of lighting conditions, including extreme backlight conditions. The camera also uses a removable infrared (IR) cut ﬁlter to switch between color and black-white (B-W) modes as environmental lighting conditions change. It also provides a dual resolution of 530 TVL (B-W) and 480 TVL (color).

On-screen programmable menus can be accessed locally using the rear panel button or remotely using any Pelco controller with Pelco P or Pelco D protocol. Use these menus to select a speciﬁc proﬁle or to customize and save camera settings for the speciﬁc application.

The CCC1390H Series camera has a standard CS-mount and can be used with ﬁxed, manual, or DC-drive auto iris lenses. The auto iris is controlled through a standard four-pin square connector that is included with all Pelco auto iris lenses.

The CCC1390H Series camera is quick and easy to install and is ideal for Pelco’s DomePak

and ImagePak

ﬁxed camera dome/enclosure

packages.

PRODUCT FEATURES

•

Compact Body Style

•

Wide Dynamic Range (60 dB Maximum); Captures Both High-Luminance and Low-Luminance Objects

•

Day/Night with Automatic or Manual Control; Captures High-Quality Color During the Day and Clear B-W Images at Night

•

Electronic Zoom

•

1/3-Inch Format Sony

SS-2WD CCD Imager

•

Digital Signal Processing

•

530 TV Lines (B-W); 480 TV Lines (Color)

•

On-Screen Menu Conﬁguration

•

Four Preset Application Proﬁles; One User-Deﬁnable Proﬁle

•

Selectable Auto White Balance (AWB), Automatic Gain Control (AGC), and Backlight Compensation (BLC)

•

Electronic Shutter Control (ESC)

•

Digital Slow Shutter (DSS)

•

Flickerless Mode

•

CS Lens Mount (C-Mount Lens Requires Optional Adapter)

•

Autosensing DC-Drive Auto Iris

•

Autosensing 24 VAC/12 VDC with Line Lock or Internal Synchronization

•

Internal Top/Bottom Mount

8 C2924M-A (5/05)

Figure 1. CCC1390H Series Camera

MODELS

CCC1390H-6 1/3-inch high resolution day/night, WDR, CCD camera, 24 VAC or 12 VDC, NTSC format

CCC1390H-6X 1/3-inch high resolution day/night, WDR, CCD camera, 24 VAC or 12 VDC, PAL format

 

 







 Lens Mount: Mount a standard CS-mount lens to the CCC1390H Series camera (refer to Lens Mounting). To use a C-mount lens, install a

 Back Focus Locking Screw: Use a 1.5-mm Allen wrench to adjust the back focus (refer to Lens Focusing).

 Camera Mount and 3a Mount Adapter: Use the top or bottom mount hole. The maximum thread depth (top) is 0.188 inches (4.7 mm); the

 Serial Terminating Switch: Use this switch to terminate the serial signal at the last camera on the serial chain (refer to Connecting

 Auto Iris Lens Connector: Insert the four-pin connector from the DC-drive auto iris lens into this connector (refer to Lens Mounting).

 Video Output Connector: Connect a coaxial video cable to this BNC connector to output the video image (refer to Connecting Video).

 Setup Button: Use this ﬁve-position button to conﬁgure the camera either directly (refer to Quick Setup) or through the setup menus (refer

 Power Terminal Strip: Use this three-pin, push-in type terminal strip to connect either 12 VDC or 24 VAC power (refer to Connecting

 Indicators: Use these indicators to quickly determine camera status (refer to Quick Setup).

 External Control Connector: Use this seven-pin connector to connect the camera to one or more serial devices. Use it also to connect an

C/CS-mount adapter.

adapter extends the thread depth (top) to 0.25 inches (6.4 mm). The maximum thread depth (bottom) is 0.25 inches (6.4 mm). Refer to Camera

Mounting.

External Control).

to Accessing Setup Menus).

Power).

external day/night ﬁlter switch. Refer to Connecting External Control for more information.

C2924M-A (5/05) 9

PARTS LIST

CCC1390H Series camera

Quick Start Guide

Safety Instructions

External control connector assembly: seven-pin micro (1.25 mm) connector with wires (26 AWG) and connector cover

Camera mount spacer

Four-pin auto iris connector (type DN-152N)

Lens mount cap

Resource CD:

•

Installation/Operation manual: INSTALL.PDF

•

Quick Start Guide: QSG.PDF

•

Important Safety Instructions: SAFETY.PDF

OPTIONAL ACCESSORIES

PCMA40 Lens adapter. Adapts standard C-mount lenses to CS-mount cameras.

REQUIRED TOOLS

Small Phillips screwdriver for connector cover

Small ﬂat tip screwdriver for serial termination

Allen wrench (1.5 mm) for back focus adjustment

Neutral density ﬁlter (ND3) for auto iris adjustment

10 C2924M-A (5/05)

Lens Mounting

The CCC1390H Series camera supports both manual and DC-drive auto iris lenses, either ﬁxed focal length or varifocal. It automatically senses an auto iris lens as soon as you plug in the connector. The camera has a standard CS-mount that can accept a C-mount lens with a PCMA40 lens adapter.

After mounting an auto iris lens, but before using the camera, perform the auto iris automatic adjustment procedure (refer to Auto Iris Lens

Adjustment) . Also perform this procedure each time you change the lens.

NOTE: The CCC1390H Series camera does not support video-drive auto iris lenses.

WIRING AN AUTO IRIS LENS

DC-drive auto iris lenses are controlled through the four-pin drive connector (type D4-152N). Figure 2 identiﬁes the pin connections for the auto iris lens connector on the back of the camera.

Figure 2. DC-Drive Auto Iris Lens Connector

Pin DC-Drive Auto Iris Lens

1 Control coil negative (–)

2 Control coil positive (+)

3 Drive coil positive (+)

4 Drive coil negative (–)

C2924M-A (5/05) 11

MOUNTING THE LENS

To mount the lens onto the camera (refer to Figure 3):

1. Make sure the lens will not touch the camera imager when installed.

2. Use clean, compressed air or a clean, dry lens cloth to make sure there is no dust or other foreign matter between the lens and the camera imager.

3. C-mount lens: Screw the adapter onto the lens.

4. Screw the lens onto the lens mount.

5. DC-drive auto iris lens: Connect the four-pin connector from the lens to the connector on the back of the camera.

Figure 3. Mounting Lens to Camera

CS-MOUNT LENS

C/CS MOUNT ADAPTER (FOR C-MOUNT LENS ONLY)

AUTO IRIS LENS CABLE AND CONNECTOR (OPTIONAL)

12 C2924M-A (5/05)

Camera Mounting

The CCC1390H Series camera can be mounted from either the top or bottom, depending on the type of camera mount used in your installation. Use a standard 1/4-20 screw. The maximum thread depth (top) is 0.188 inches (4.7 mm). To extend the thread depth (top) to 0.25 inches (6.4 mm), use the camera mount spacer (supplied). The maximum thread depth (bottom) is 0.25 inches (6.4 mm).

The CCC1390H Series camera can be ﬁtted with most Pelco lenses and mounted into most Pelco domes and enclosures, resulting in the greatest possible number of combinations. This means you can ﬁnd a solution for nearly any application.

When selecting a lens, dome, or enclosure for this camera, consider how the physical dimensions of each component may affect camera installation and operation. Speciﬁcally, you should address the following three issues.

•

Enclosure size: The camera dimensions are 2.2 (D) x 2.09 (W) x 2.17 (H) inches (5.6 x 5.3 x 5.5 cm). Make sure the enclosure is large

enough for both the camera and the lens.

•

Lens size: Some lenses have minimum and maximum lengths. To focus the scene correctly, you may have to adjust the lens to its maximum

length. This could affect how it ﬁts within the enclosure.

•

Optical alignment: The optical center of this camera may be too low for some enclosures. As a result, the lower portion of the scene may

be obstructed by the enclosure itself. The camera sled in many Pelco enclosures has a low side and a high side. You may be able to raise the optical center by ﬂipping the camera sled to the high side.

NOTE: To simplify lens and enclosure selection, Pelco offers ImagePak options for the CCC1390H Series camera. Select the lens and the dome or

enclosure. Pelco will build and test it for you. Contact Pelco or your dealer for more information.

C2924M-A (5/05) 13

Connecting Power, Video, and Control

The CCC1390H Series camera offers standard power and coax video connectors as well as an external control connector. Before installation, identify how you will connect each power, video, and control lead to the camera.

CONNECTING POWER

The CCC1390H Series camera is designed to operate from either a 12 VDC or a 24 VAC power source. The camera automatically senses power type. Use only a Class 2 isolated power source that can supply 12 VDC ±15% or 24 VAC ±15%, 50/60 Hz. Maximum power consumption is about

3.5 watts.

NOTES:

•

Be sure to use 60 Hz power for NTSC (CCC1390H-6) and 50 Hz power for PAL (CCC1390H-6X).

•

Install the camera near a socket or outlet that is easily accessible.

Use Table A to help you identify the necessary wire gauge and maximum cable distance. This table applies to two-conductor solid copper wire. (Reduce distance by 10% for stranded copper wire.) These maximum distances are based on a maximum allowable voltage drop of 10%.

WARNINGS:

•

Do not connect high voltage power to the camera because you may damage the camera.

•

Do not short circuit the power leads when connecting the power supply to the camera.

•

Do not remove the connector cover during camera operation.

Table A. Recommended Wire Gauge and Maximum Wiring Distances

Wire Gauge

Maximum Distance

12 VDC 24 VAC

24 AWG (0.25 mm

) 80 ft (24 m) 323 ft (98 m)

22 AWG (0.35 mm

) 128 ft (39 m) 513 ft (156 m)

20 AWG (0.5 mm

) 203 ft (61 m) 815 ft (248 m)

18 AWG (1.0 mm

) 323 ft (98 m) 1,295 ft (394 m)

16 AWG (1.5 mm

) 514 ft (156 m) 2,056 ft (626 m)

14 AWG (2.5 mm

) 816 ft (248 m) 3,264 ft (994 m)

12 AWG (4.0 mm

) 1,295 ft (394 m) 5,183 ft (1,579 m)

10 AWG (6.0 mm

) 2,057 ft (626 m) 8,228 ft (2,507 m)

14 C2924M-A (5/05)

CONNECTING AC POWER

The CCC1390H Series camera requires a power supply of 24 VAC ±15% (20.4 to 27.6 VAC), 50/60Hz. Make sure the power supply has a minimum rating of 270 mA.

When connecting more than one camera to the same AC transformer, remember the following:

•

Connect the same side of the transformer to the same terminal on all cameras. Otherwise, the cameras may be out of phase, causing a vertical roll when switching between cameras. Refer to Camera Synchronization for more information.

•

Use a transformer whose rated power supply is greater than 270 mA multiplied by the number of cameras.

To connect AC power:

1. Strip at least 0.4 inches (10 mm) of the insulation from each power wire.

2. Press and hold the button over either hole marked 24 VAC.

3. Insert one wire from the power supply into the hole and release the button.

4. Gently pull the wire to make sure it is secure.

5. Repeat steps 2 through 4 for the second wire from the power supply.

6. If you are using a ground wire, repeat steps 2 through 4, inserting the ground wire into the hole marked GND.

Figure 4. Connecting AC Power

INPUT

POWER SUPPLY

BUTTONS

24 VAC

OUTPUT

+ 30 hidden pages
