PRODUCT SPECIFICATION
Spectra® HD Series Network Dome System
HIGH DEFINITION PAN/TILT/ZOOM HIGH-SPEED DOME
Product Features
• Up to 1280 x 960 Resolution
• 4:3 or 16:9 Aspect Ratio; 960p at 20 Images per Second (ips),
720p at 30 ips
• 1.3 Megapixel (MPx), 18X Optical, Wide Dynamic Range (WDR)
Camera
• Ability to Control and Monitor Video Over IP Networks
• Autotracking and Adaptive Motion Detection
• 2 Simultaneous Video Streams: Dual H.264 and Scalable MJPEG
• 360° Continuous Pan Rotation at 400° per Second
• Supported Protocols: TCP/IP, UDP/IP (Unicast, Multicast IGMP), UPnP,
DNS, DHCP, RTP, NTP, and More
• Power over Ethernet (PoE) IEEE 802.3af
• USB Expansion Slots for Alarms and Audio Accessories
• 16 Preset Tours, 255 Dome Presets, 8 Privacy Zones
camera solutions
Pelco takes its industry-leading Spectra® Series dome into the
world of high definition.
streaming images over the Internet using a standard Web browser
(Microsoft® Internet Explorer® or Mozilla® Firefox®). With four times
the resolution of standard definition domes,
solution to view details such as faces, license plates, tattoos,
playing cards (in casinos), or other specific features.
Spectra HD
improvement in quality over MPEG-4 and 20 times more efficient
than M-JPEG. The dome system features open architecture
connectivity for third-party software recording solutions allowing
integration into virtually any IP-based HD system. It is also
compatible with Digital Sentry
with all Pelco IP camera solutions,
to record, manage, configure, and view multiple live streams. When
connected to an Endura® HD network-based video security system,
the dome system has access to EnduraStor™ and EnduraView™ for
optimized image quality and bandwidth efficiency.
Spectra HD
maintenance that you have come to expect from Spectra. Each
dome system consists of a back box, a dome drive, and a lower
dome.
supports High-Profile H.264 compression, a vast
features the same ease of installation and ease of
Spectra HD
delivers crystal-clear, live
Spectra HD
®
video management systems. As
Spectra HD
is Endura Enabled
is an ideal
Spectra HD
environmental in-ceiling, pendant, and environmental pendant. All
environmental models meet NEMA Type 4X, IP66 when properly
installed.
Spectra HD
that increase performance and make configuration and operation
easy. An internal scheduling clock allows for the scheduling of
presets and patterns. Window blanking enables a user to configure
up to eight, four-sided, user-defined privacy areas. Password
protection prevents unauthorized users from changing the system
settings. Intuitive multilingual on-screen configuration can be
displayed in English, Spanish, Portuguese, Italian, French, German,
Russian, Polish, and Turkish.
™
Spectra HD
range from a smooth, fast pan motion of 400 degrees per second to
a smooth “creep” speed of 0.1 degree per second. The system is
capable of continuous 360 degrees rotation, and it has an “auto flip”
feature that allows the dome to rotate 180 degrees and reposition
itself for uninterrupted viewing of any subject that passes directly
beneath the dome.
includes a choice of four back box models: in-ceiling,
dome system includes many software enhancements
features include variable speed capabilities, which
International Standards
Organization Registered Firm;
ISO 9001 Quality System
C3470 / NEW 9-3-10
TECHNICAL SPECIFICATIONS
SOFTWARE FEATURES
• 255 Presets
• 16 Tours
• ±0.1° Preset Accuracy
• Multilingual Menus (English, Spanish, Portuguese, Italian, German, French, Russian, Polish, and Turkish)
• Password Protection
• 400°/sec Pan Preset Speed and 200°/sec Tilt Preset Speed
• Rotating Discreet Liner with Sealed Fixed Bubble
• 8 Privacy Zones, Configurable in Size
• “Auto Flip” Feature Rotates Dome 180° at Bottom of Tilt Travel
• Configurable Park with Actions
• Proportional Pan/Tilt Continually Decreases Pan/Tilt Speeds in Proportion to Depth of Zoom
BACK BOX FEATURES
7.5 (19.0)
In-Ceiling (Indoor)
5.2
(13.2)
3.5
(8.8)
5.9 (15.0)
8.2 (20.8)
• Single Back Box for Suspended or Hard Ceiling Applications
• Requires 5.25-Inch Space Above Ceiling and 3.25 Inches Below
• Minimum Ceiling Thickness 0.5-Inch; Maximum 1.75 Inches
• Quick Disconnect to Dome Drive
• Aluminum Construction
• Suitable for Use in Environmental Air Handling Spaces
10.6
(26.9)
(ENVIRONMENTAL DOME
WITH SUN SHROUD SHOWN)
4.4
(11.0)
4.3
(10.9)
NOTE: VALUES IN PARENTHESES ARE CENTIMETERS; ALL OTHERS ARE INCHES.
5.9 (15.0)
8.6 (21.8)
9.9 (25.2)
5.9 (15.0)
8.6 (21.8)
Standard and Environmental Pendant
• Standard and Environmental Models
• Standard Pendant Available in Black or Gray Finish; Environmental
Pendant Available in Gray Finish Only
• Quick Disconnect to Dome Drive
• Aluminum Construction
• Environmental Model Includes Sun Shield, Fan, and Heater
Environmental In-Ceiling
• Single Back Box for Hard Ceiling Applications
• Requires 4.4-Inch Space Above Ceiling and 4.3 Inches Below
• Includes Heater and Fan
• Minimum Ceiling Thickness 0.5-Inch; Maximum 1.75 Inches
• Quick Disconnect to Dome Drive
• Aluminum Construction
TECHNICAL SPECIFICATIONS
CAMERA
Sensor Type 1/3-inch CCD
Optical Zoom 18X
Maximum Resolution 1280 x 960
Lens f/1.6 (focal length, 4.7 ~ 84.6 mm optical)
Aspect Ratios 4:3 or 16:9
Light Sensitivity f/1.6; 2,850°K; SNR >24dB
Color (33 ms) 0.70 lux
Color (250 ms) 0.07 lux
Mono (33 ms) 0.25 lux
Mono (250 ms) 0.02 lux
Day/Night Capabilities Yes
IR Cut Filter Yes
IR Trace Curves 850 nm and 950 nm
Wide Dynamic Range 60 dB
Iris Control Auto iris with manual override
Backlight Compensation Yes
VIDEO
Video Encoding H.264 high, main, or base profile and MJPEG
Video Streams Up to 2 simultaneous streams; the second stream is variable based on the setup of the primary stream
Frame Rate Up to 30, 25, 24, 15, 12.5, 12, 10, 8, 7. 5, 6, 5, 4, 3, 2.5, 2, 1 (dependent upon coding, resolution, and stream configuration)
H.264 High Profile
Available Resolutions
MPx Width Height
1.30 1280 960 4:3 20 12.00 20 3.00
0.92 1280 720 16:9 30 12.00 30 2.90
0.49 800 608 4:3 20 5.15 20 1.75
0.31 640 480 4:3 20 3.25 20 1.20
0.23 640 352 16:9 30 3.60 30 1.15
0.18 480 368 4:3 20 1.85 20 0.75
0.13 480 272 16:9 30 2.05 30 0.75
0.08 320 240 4:3 20 0.80 20 0.40
0.06 320 176 16:9 30 0.90 30 0.35
Supported Protocols TCP/IP, UDP/IP (Unicast, Multicast IGMP), UPnP, DNS, DHCP, RTP, RTSP, NTP, IPv4, SNMP v2c/v3, QoS, HTTP, HTTPS, LDAP (client), SSH,
Users
Unicast Up to 20 simultaneous users depending on resolution settings (2 guaranteed streams)
Multicast Unlimited users H.264
Security Access Password protected
Software Interface Web browser view and setup, up to 16 cameras
Pelco System Integration Endura 2.0 (or later)
Open IP Integration Pelco IP camera API
Minimum System Requirements
Processor Intel® Core™ 2 Duo microprocessor, 2.6 GHz
Operating System Windows® XP, Windows Vista®, or Mac® OS X 10.4 (or later)
Memory 2 GB RAM
Network Interface Card 100 megabits (or greater)
Monitor Minimum of 1024 x 768 resolution, 16- or 32-bit pixel color resolution
Web Browser* Internet Explorer 7.0 (or later) or Firefox 3.5 (or later); Internet Explorer 8.0 (or later) is recommended for configuring analytics
Media Player† Pelco Media Player‡ or QuickTime® 7.6.5 for Windows XP, Windows Vista, or QuickTime 7.6.4 for Mac OS X 10.4
*Internet Explorer is not supported by Mac OS X 10.4.
†
This product is not compatible with QuickTime version 7.6.4 for Windows XP or Windows Vista. If you have this version installed on your PC, you will need to upgrade
to QuickTime version 7.6.5.
‡
Pelco Media Player is recommended for control, smoothness, and reduced latency as compared to QuickTime.
SSL, SMTP, FTP, mDNS (Bonjour
Digital Sentry 4.2 (or later)
Resolution MJPEG
Aspect
Maximum
Ratio
®
), and 802.1x (EAP)
IPS
Recommended
bitrate (Mbps)
(IP GOP structure)
Maximum
IPS
Recommended
bitrate (Mbps)
TECHNICAL SPECIFICATIONS
GENERAL
Construction
Back Box Aluminum
Dome Drive Aluminum, thermo plastic
Lower Dome Acrylic
Light Attenuation
Smoked f/0.5 light loss
Clear Zero light loss
Cable Entry (back box)
In-Ceiling 0.75-inch conduit fitting
Pendant Through 1.5-inch NPT pendant mount
Weight (approximate) Unit Shipping
In-Ceiling 5.2 lb (2.4 kg) 8 lb (3.6 kg)
Environmental In-Ceiling 6.2 lb (2.8 kg) 10 lb (4.5 kg)
Standard Pendant 6.5 lb (3.0 kg) 11 lb (5.0 kg)
Environmental Pendant 7.6 lb (3.5 kg) 12 lb (5.4 kg)
Environment
In-Ceiling Indoor
Environmental In-Ceiling Outdoor
Pendant, Standard, and
Environmental Indoor/outdoor
Operating Temperature
In-Ceiling 32° to 122°F (0° to 50°C)
Standard Pendant (Assumes no wind chill factor)
Maximum 113°F (45°C) absolute maximum; 95°F (35°C)
sustained maximum
Minimum 25°F (–4°C) sustained minimum
Environmental In-Ceiling,
Environmental Pendant (Assumes no wind chill factor)
Maximum 140°F (60°C) absolute maximum;
122°F (50°C) sustained maximum
Minimum –60°F (–51°C) absolute minimum; prevents
icing at sustained minimum of –22°F (–30°C);
de-ices 0.1 inch (2.5 mm) within 3 hours after
power-up at –22°F (–30°C)
Effective Projected Area (EPA) 20.5 square inches (without mount),
47 square inches (with IWM Series mount)
ELECTRICAL
Ports RJ-45 connector for 100Base-TX
Auto MDI/MDI-X
Autonegotiate/Manual setting
Cabling Type Cat5 or better for 100Base-TX
Input Voltage 18 to 32 VAC; 24 VAC nominal
22 to 27 VDC; 24 VDC nominal
Input Power
24 VAC 23 VA nominal (without heater);
73 VA nominal (with heater)
24 VDC 0.7 A nominal (without heater);
3 A nominal (with heater)
PoE IEEE802.3af (without heater)
Fuse 1.25 A
MECHANICAL
(Dome Drive Only)
Variable Speed 0.1° to 400°
Preset Accuracy ±0.1°
Pan Movement 360° continuous pan rotation
Vertical Tilt +0° to –90°
Manual Pan/Tilt Speeds
Pan 0.1° to 80°/sec manual operation,
Tilt 0.1° to 40°/sec manual operation
Preset Speeds
Pan 400°/sec
Tilt 160°/sec
150°/sec Turbo
MODEL NUMBERS
SYSTEM MODEL NUMBERS
HD, 1.3 MPx,
Type Back Box Color Lower Dome
In-ceiling, indoor
In-ceiling,
environmental
Pendant, standard
Pendant,
environmental
Black with
white trim ring
Black with
black trim ring
Gray
Black
Gray
Smoked S5118-FW0
Clear S5118-FW1
Smoked S5118-YB0
Clear S5118-YB1
Smoked S5118-PG0
Clear S5118-PG1
Smoked S5118-PB0
Clear S5118-PB1
Smoked S5118-EG0
Clear S5118-EG1
COMPONENT MODEL NUMBERS
Back Box Lower Dome Dome Drive
B5-F HD, in-ceiling, gray LDHQF-0 High-quality, smoked, in-ceiling D5118 HD, 1.3 Mpx, 18X optical zoom
B5-F-E HD, environmental in-ceiling, gray LDHQF-1 High-quality, clear, in-ceiling
B5-PG HD, pendant, gray LDHQPB-0 High-quality, smoked, pendant
B5-PB HD, pendant, black LDHQPB-1 High-quality, clear, pendant
B5-PG-E HD, environmental pendant, gray
18X Color
CERTIFICATIONS/RATINGS/PATENTS
• CE, Class A*
• FCC, Class A*
• UL /cUL Listed*
• C-Tick*
• U.S. Patents 5,931,432; 6,793,415 B2; 6,802,656 B2; 6,821,222 B2;
7,161,615 B2
• Meets NEMA Type 4X and IP66 standards when installed properly
(B5-F-E and B5-PG-E)*
*As of the date of this publication, these certifications are pending. Please
consult the factory, our Web site at
®
update for the current status of certifications.
B.O.S.S.
www.pelco.com
, or the most recent
MODEL NUMBERS
RECOMMENDED MOUNTS
In-Ceiling Domes
SD5-P 2' x 2' drop ceiling panel, aluminum
SCA1 Support rails for B5-F; for use in ceiling tile
Pendant Domes
BB5-PCA-BK Pendant conduit adapter, black
BB5-PCA-GY Pendant conduit adapter, gray
IWM Series Wall mount, with or without integral 24 VAC,
MRCA Ceiling mount, black
PP4348 Parapet roof mount
PP350/PP351 Parapet wall/roof mount
SWM Series Compact wall mount, black or gray finish; can
RECOMMENDED POWER SUPPLIES
MCS Series Indoor, 24 VAC power supply
WCS Series Outdoor, 24 VAC power supply
Refer to individual power supply specifications for more information.
construction; replaces 2' x 2' ceiling tile
applications
100 VA transformer; black or gray finish; can
be adapted for corner, parapet or pole
application
be adapted for corner or pole applications
Pelco, Inc. Worldwide Headquarters:
3500 Pelco Way, Clovis, California 93612-5699 USA
USA & Canada
International
www.pelco.com
Tel: (800) 289-9100 • FAX: (800) 289-9150
Tel: +1 (559) 292-1981 • FAX: +1 (559) 348-1120
Pelco, the Pelco logo, and other trademarks associated with Pelco products referred
to in this publication are trademarks of Pelco, Inc. or its affiliates. All other
product names and services are the property of their respective companies.
Product specifications and availability are subject to change without notice.
©Copyright 2010, Pelco, Inc. All rights reserved.
Loading...
