Peerless-AV SF632-AW Sell Sheet

SF660(P)

SF660-AB/AW

Universal Flat Wall Mount

for 39" to 80" Displays

The new SF660 delivers enhanced display compatibility, accommodating large displays,

®

including those with VESA

for enhanced electrical access and cable management, as well as display placement

exibility to achieve the perfect installation. This ultra-slim mount is the ultimate in low-prole

applications for 39” to 80” displays.

800 x 400mm hole pattern. Its open wall plate architecture allows

FEATURES

 Universal mount ts displays

with mounting patterns up to
825 x 433mm (32.48" W x 17.05" H)

 Increased display compatibility

includes VESA

®

800 x 400mm

mounting hole patterns

 Open wall plate architecture

allows for total wall access,
increasing electrical access and
cable management options

 Low-prole design holds display

only 1.25" (32mm) from the wall

for a low-prole application

 Includes deep display adaptors

to hold display 1.7" (43mm)
from wall for easier cable
management access

 Horizontal display adjustment

of up to 8" (203mm) (depending

on display model) for perfect
display placement

 Universal brackets easily hook

onto wall plate for fast installation

VIEWING FLEXIBILITY

Horizontal display adjustment
up to 8" (203mm) for perfect
display positioning

Dispay size: 39"-80" Max load: 200lb (90kg)

EASY INSTALLATION

Simple hook-on design

makes installation safe,
quick and easy

 Mounts to wood studs, concrete,

cinder block or metal studs
(metal stud accessory required)

 Comes with fastener pack with

all necessary display attachment
hardware

 Integrated security options

available

 UL listed

®

 Agion

antimicrobial* nish

assists in controlling the spread

of infections with SF660-AB/AW

models

SF660-AB/AW:

Nature’s antimicrobial

OPEN ARCHITECTURE

Open wall plate

architecture for exible

cable management and
wall placement

Low-prole design holds display only

Patented. Utility Patent No. 7,823,850; 8,517,322.

* Antimicrobial protection is limited to the treated article and does not protect a user against disease

causing bacteria. Always clean products thoroughly after each use. Visit agion-tech.com for more details.

CLICK: peerless-av.com CALL: 800.865.2112 FAX: [phone]

1.25" (32mm) from the wall

Model Numbers

WARRANTY: Limited 5-year

SF660P SmartMount® Universal Flat Wall Mount for 39” to 80” Displays - standard models
SF660(-AB/AW) SmartMount

®

Universal Flat Wall Mount for 39" to 80" Displays - security models

Product Specifications

DImENSIONS (W x H x D) PRODUCT WEIGHT LOAD CAPACITy FINISH AVAILABLE COLORS

SF660(-AB/AW)(P)

* Antimicrobial protection is limited to the treated article and does not protect a user against disease causing bacteria.

Always clean products thoroughly after each use. Visit www.agion-tech.com for more details.

34.12" x 18.00" x 1.25"
(867 x 457 x 32mm)

6.76lb (3kg) 200lb (90kg) Matte

Package Specifications

PACKAGE SIZE (W x H x D) PACKAGE SHIP WEIGHT PACKAGE UPC CODE PACKAGE CONTENTS UNITS IN PACKAGE

SF660:

735029235590
735029235620
735029283706
735029283713

SF660(-AB/AW)(P)

35.25" x 10.06" x 3.50"
(895 x 256 x 89mm)

9.4lb (4.26kg)

SF660P:

SF660-AB:

SF660-AW:

Accessories

ACC415: 4-pack Metal Stud Fastener Kit
ACC309: Video Conference Shelf

SF660(P)

SF660-AB

SF660-AW

Wall plate, universal

brackets, mounting and

display attachment

hardware

Black

Antimicrobial* black
Antimicrobial* white

1

All dimensions = inch (mm)

A R C H I T E C T S S P E C I F I C A T I O N S

The Smartmount® Universal Flat Wall Mount shall be a Peerless-AV model SF660(-AB/AW)(P) and shall be located where indicated on the plans.

Peerless Industries, Inc.  2300 White Oak Circle  Aurora, IL 60502  [phone]  [phone]  Fax: [phone]  peerless-av.com

Visit peerless-av.com to see the complete line of AV solutions from Peerless-AV, including at panel mounts, projector mounts, carts/stands, furniture, cables, display cleaners and a full assortment of accessories.

© 2014 Peerless Industries, Inc. Peerless-AV
Agion is a registered trademark of Sciessent.

Assembly and installation shall be done according to instructions provided by the manufacturer.

®

and SmartMount® are registered trademarks of Peerless Industries, Inc. All rights reserved.

LIT-0595 rev.2
