P6919LF
p
Mounting without escutcheon plate:
9 3/4"
(248 mm)
8 1/2"
(217 mm)
1 5/16"~1 1/2"
(33~38mm)
Hole Size
26 1/8"
(664 mm)
5 11/16"
(144 mm)
8 3/16"
(208 mm)
1 1/2"
(38 mm)
Max. Deck
Thickness
Min.2 1/2" (64 mm)
Clearance to Back
Splash Recommended
KITCHEN FAUCETS
Single handle
■
pull-out
9/16 - 24 UNEF
Mounting with escutcheon plate:
8 1/2"
(217 mm)
8"
(203 mm)
10 1/8"
(257 mm)
▲ Designate proper nish sufx
PSP-K-P6919LF Rev A
9 7/8"
(251 mm)
5 3/4"
(147 mm)
3 X1 5/16"~1 1/2"
(33~38mm)
Hole Size
8 3/16"
(208 mm)
1 1/2"
(38 mm)
Max. Deck
Thickness
9/16 - 24 UNEF
Min.2 1/2" (64 mm)
Clearance to Back
Splash Recommended
26 1/8"
(664 mm)
STANDARD SPECIFICATIONS:
• Maximum 1.5 gpm @ 60 psi, 5.7 L/min @ 414 kPa
• One, two, three, four hole mount options (escutcheon
and soap dispenser optional, sold separately)
• Two-function wand; aerated stream or spray
• Dual integral check valves in sprayer
• ceramic cartridge
• Spout rotates 120
• Red/Blue indicator markings
• Polymer braided flexible supply hose with 9/16 - 24 UNEF
thread connection - 26 1/8" (664 mm) long
°
WARRANTY
• Lifetime limited warranty on parts (other than electronic
parts and batteries) and inishes; or,for commercial users,
for 5 years from the date of purchase.
• 5 year limited warranty on electronic parts (other than
batteries); or for commercial users, for 1 year from the
date of purchase. No warranty is provided on batteries.
COMPLIES WITH:
•
ASME A112.18.1 / CSA B125.1
Indicates compliance to
ICC/ANSI A117.1
•
Verified compliant with .25% weighted
average Pb content regulations
