CSA Group
4 3/16"
(106 mm)
2 1/2"
(41 mm)
6 11/32"
(161 mm)
6 11/32"
(161 mm)
P188620LF
P188620LF-M
P188620LF-W
P188620LF-ECO-W
LAVATORY FAUCET
1 1/2" (38 mm)
max. deck
thickness
3 15/32"
(88 mm)
1 11/16"
(42 mm)
2x 1 1/8" to
1 1/2" (29 mm
to 38 mm)
hole size
1 5/8" to 2 3/8"
(42 mm to 61 mm)
2 1/8"
(54 mm) dia.
4" (102 mm)
3 7/32"
(82 mm)
6 17/32" (166 mm)
4" (102 mm)
3 5/16"
(84 mm)
1/2"-14
NPSM
1 17/32" to 2 1/8"
(39 mm to 54 mm)
2 1/8" (54 mm) dia.
1 27/32"
(47 mm)
■ Single Handle Centerset Deck Mount
STANDARD SPECIFICATIONS:
• Max flow rate: 1.50 GPM @ 60 PSI,
5.68 L/Min @ 414 kPa
• Max flow rate (ECO models only): 1.20 GPM @ 60 PSI,
4.54 L/Min @ 414 kPa
• Control mechanism is of the rotating ball type with
replaceable non-metallic seats
• Control handle returns to the neutral position when
valve is turned off
• 1/4" O.D. copper supply lines
• Models have drain with pop-up type fitting with
plated flange and stopper
WARRANTY:
• Lifetime limited warranty on parts (other than
electronic parts and batteries) and finishes: or, for
commercial users, for 5 years from date of purchase.
• 5 year limited warranty on electronic parts (other than
batteries); or, for commercial users, for 1 year from the
date of purchase. No warranty is provided on batteries.
Certified by
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
• ASME A112.18.2 / CSA B125.2
Indicates compliance to
ICC/ANSI A117.1
• EPA WaterSense
• Verified compliant with 0.25% weighted average Pb
content regulations
®
5 13/32"
(137 mm)
(35 mm)
▲ Designate proper finish suffix
PSP-L-P188620LF Rev. B
1 3/8"
dia.
1 1/4"
(32 mm) dia.
4 9/16"
(116 mm)
1 3/8"
(35 mm)
dia.
1 1/4"
(32 mm) dia.
