Peerless-AV ESHV10 User Manual

ESHV20

Single AV Wall Shelf with Glass

for AV Components

People gravitate toward at panel displays for their aesthetics but once mounted the question

of where to place the audio visual components becomes troubling. This AV Wall Shelf provides

an elegant solution. The modern, sleek glass shelving blends in with the décor of a room

enhancing the image so carefully cultivated by the consumer. Its ability to organize and

center AV components directly above or below the display transforms any room by creating

a trendy ambiance.

FEATURES

 Strong, tempered glass shelf

can be vertically adjusted
to accommodate AV
components of any height

 Cable management system

helps keep cables concealed
and organized

 Supports up to 30lb

 Bubble level makes for a quick

and easy installation

ADJUSTABLE H EI GH T

Easily adjust the height of the
component shelf after installation
without the use of tools

TEMPERED GLASS SHELF

For up to 30lb of support
with a sleek, modern look

Max load: 30lb (13.6kg)

BUBBLE LEVEL

For a quick and easy
installation without the
use of extra tools

CABLE MANAGEMENT

Keeps component
cables concealed
and organized

CLICK: www.peerless-av.com CALL: 800.865.2112 FAX: [phone]

Side View

Model Numbers

Product Specifications

DImENSIONS (W x H x D) PRODUCT WEIGHT LOAD CAPACITy FINISH AVAILABLE COLORS

WARRANTY: Limited 5-year

ESHV20

15.6" x 13.41" x 13.76"
(396 x 341 x 350mm)

Package Specifications

PACKAGE SIZE (W x H x D) PACKAGE SHIP WEIGHT PACKAGE UPC CODE PACKAGE CONTENTS UNITS IN PACKAGE

ESHV20

12.00"

(305mm)

13.25" x 2.625" x 17.125"
(337 x 67 x 435mm)

3.38"

(86mm)

1.30"

(33mm)

12.46"

(317mm)

4.48lb (2.03kg) 30lb (13.6kg)

5.65lb (2.56kg) 735029276098

Powder

coat

AV Wall Shelf with

Glass, Instructions,

Installation hardware

Gloss Black

1

All dimensions = inch (mm)

15.60"

(396mm)

TOP VIEW

13.76"

(350mm)

ISOMETRIC VIEW

0.24"

10.87"

(276mm)

8.42"

(214mm)

(6mm)

13.41"

(341mm)

1.43"

(36mm)

FRONT VIEW

SIDE VIEW

A R C H I T E C T S S P E C I F I C A T I O N S

Assembly and installation shall be done according to instructions provided by the manufacturer.

Peerless Industries, Inc.  2300 White Oak Circle  Aurora, IL 60502  [phone]  [phone]  Fax: [phone]  www.peerless-av.com

Visit www.peerless-av.com to see the complete line of AV solutions from Peerless-AV, including at panel mounts, projector mounts, carts/stands, furniture, cables, screen cleaners and a full assortment of accessories.

© 2011 Peerless Industries, Inc. All rights reserved.

The Peerless-AV Single AV Wall Shelf with Glass shall be model ESHV20.

LIT-0758
