LT/ST Power Amplifier
Owner’s Manual
1
Save the carton and packing materials!
Should you ever need to ship the unit,
use only the original factory packing.
For replacement packaging, call Crest Audio’s
Customer Service Depar tment directly.
2
Read all documentation before
operating your equipment.
Retain all
documentation for future reference.
3
Follow all instructions printed on
unit chassis for proper operation.
4
Never hold a power switch or circuit breaker in the on-position, if
it won’t stay there by itself!
5
Do not use the unit if the electrical
power cord is frayed or broken.
The power supply cords should be
routed so that they are not likely to be
walked on or pinched by items placed
upon or against them.
6
Always operate the unit with the
AC ground wire connected to the
electrical system ground.
Precautions
should be taken so that the means of
grounding of a piece of equipment is not
defeated.
7
Damage caused by connection to
improper AC voltage is not covered
by any warranty.
Mains voltage must be
correct and the same as that printed on
the rear of the unit.
8
Do not ground any hot (red) terminal.
Never connect a hot
(red) output to
ground or to another hot (red) output!
9
Power down and disconnect units
from mains voltage before making
connections.
0
Do not drive the inputs with a signal level greater than that
required to enable equipment to
reach full output.
¡
Do not run the output of any amplifier channel back into another
channel’s input.
Do not parallel- or series-connect
an amplifier output with any
other amplifier output.
Crest Audio is not responsible for damage
to loudspeakers for any reason.
Ô
Do not connect the inputs or outputs of amplifiers to any other
voltage source:
such as a battery,
mains source, or power supply, regardless of whether the amplifier is turned
on or off.
£
Connecting amplifier outputs to
oscilloscopes or other test equipment while the amplifier is in bridged
mono mode may damage both the
amplifier and test equipment!
¢
Do not spill water or other liquids
into or on the unit, or operate the
unit while standing in liquid.
ˆ
Do not block fan intake or
exhaust ports.
Do not operate equipment on a
surface or in an environment
which may impede the normal
flow of air around the unit:
such as
a bed, rug, weathersheet, carpet, or
completely enclosed rack.
§
If the unit is used in an extremely
dusty or smoky environment:
the
unit should be periodically blown free of
foreign matter.
¶
Do not use the unit near stoves,
heat registers, radiators, or other
heat producing devices.
ƒ
The power cord of equipment
should be unplugged from the outlet when left unused for a long period of time.
Service Information
Do not remove the cover!
Removing the cover will expose you to
potentially dangerous voltages.There are
no user serviceable par ts inside.
Equipment should be serviced by
qualified service personnel when:
A. The power supply cord or the plug has
been damaged.
B. The equipment has been exposed to rain.
C. The equipment does not appear to oper-
ate normally, or exhibits a marked change in
performance.
D. The equipment has been dropped, or the
enclosure damaged.
To obtain service:
contact your nearest Crest Audio
Service Center, Distributor, Dealer,
or Crest Audio at 201.909.8700
USA
or visit www.crestaudio.com for additional information.
email techserve
@crestaudio.com
This equipment conforms to EN55022 Class A. In a
domestic environment this product may cause radio
interference in which case the user may be required to
take adequate measures.
This equipment has been tested and found to comply
with the limits for a Class B digital device pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
*Reorient or relocate the receiving antenna.
*Increase the separation between the equipment and
the receiver.
*Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
*Consult the dealer or an experienced radio/TV techni-
cian for help.
This symbol is used to alert
the operator to follow important
procedures and precautions
detailed in documentation.
This symbol is used to warn operators
that uninsulated “dangerous voltages”
are present within the equipment enclosure that may pose a risk of electric
shock.
important precautions
p. 1
table of contents
1
2
3
4
5
6
7
how to use this manual
p.2
introduction
p.3
installation
p.5
unpacking
mounting
cooling and ventilation
powering
maintenance
features overview
p.9
front panel
rear panel
operation modes
p.15
stereo
parallel
bridged
connections
p.17
input
output
safety
p.21
tourclass protection
precautions
user responsibility
service and support
p.25
support
contact us
registration
specifications
p.27
block diagram
p.28
wire gauge charts
p.29
b
c
a
contents
appendices
p. 2
LT / ST owner’s manual
how to use this manual
1
conventions
terms
official Crest Audio features and
each indicator or control on the amplifier will appear as: terms
actions
specific actions or selections the user can execute will appear as: actions
tasks
are broken down into steps 1
2
3
warnings
indicators
tips
see
see—refers to other sections of the manual containing
supplementary information on the current topic or a related issue
note
note—supplementary feature information
Preferred methods.
Helpful hints.
Feature insights.
+
Procedures not to attempt.
Issues or hazards to keep in
mind when operating
the equipment.
a
What to look for on
the equipment display.
Alerts, indicators, or
prompts that may appear.
®
p. 3
introduction
1
welcome
Congratulations on your purchase of a new LT / ST Series professional power amplifier and thank you for your confidence in Crest Audio products. You are among the growing number of audio professionals who have made Crest
Audio one of the world’s leading suppliers of professional and commercial/industrial audio systems.
For your safety, please read the Important Precautions section before installing and operating the amplifier. The Crest
Audio LT and ST Series amplifiers are designed for high operating efficiency and accurate sonic performance across
the full audio bandwidth, even under stressful conditions.
The Crest Audio LT and ST series both utilize Class D amplifier technology which greatly improves the efficiency of
the amplifier and reduces the power demand from the mains supply. The LT amplifier incorporates a linear power
supply whereas the ST uses a resonant switching supply with power delivery characteristics similar to a linear supply but with greatly reduced weight. Both power supply designs are built to the same uncompromising standards.
This, combined with major advances in amplifier technology provides for extreme reliability and sonic accuracy for
which Crest products are renown.
The Crest audio LT series and ST series amplifiers differ in power supply design,electrical efficiency and weight however, their feature sets are identical.For this reason, the majority of this users manual applies to both models.
LT linear-toroid power supply
A traditional linear power supply is used in the LT Series. Because of the amplifier sections efficiency, (approx
93%) the transformer does not need to be as big or as heavy.This gives the LT Series an advantage in delivering more power in a more compact package.
The efficiency of the output stage also gives the power supply the ability to handle heavy-duty cycles without
compromising sonic integrity.
ST resonant-switching power supply
The ST amplifier switching power supply employs a resonant design which utilizes zero-power switching
technology.
Benefits of resonant-switching include:
• reduced power component stress for
better reliability and efficiency
• 20dB lower noise than conventional switching supplies
(and therefore more EMC friendly)
• behaves like a classic linear supply, but with the added
advantages of size and weight reduction
In order to maintain strict quality assurance standards, all Crest Audio power amplifiers are built in our state-of-theart USA manufacturing facility. Internal components are the finest available and key sub-assemblies are pre-tested
before final assembly. Each amplifier is “burned in” and thoroughly tested (using precision audio test equipment)
before shipping. In addition, all LT / ST Series amplifiers incorporate Crest’s exclusive TourClass
®
protection features
to safeguard both internal circuitry and connected loudspeakers.
This proven combination of advanced design,quality construction and comprehensive circuit protection is your guarantee of fail-safe reliability. You can depend on consistent, stable performance even when your LT / ST Series amplifier is subjected to punishing extremes in the most demanding fixed or mobile sound reinforcement applications.
p. 5
installation
2
unpacking
mounting
cooling and
ventilation
powering
maintenance
/
what to do with the shipping carton
/
proper rack-mounting technique
/
keeping the amplifier cooled
/
required AC line voltages
/
routine maintenance practices
LT / ST owner’s manual
p. 6
installation
2
unpacking
Please inspect the amplifier carefully immediately after unpacking. If you find any damage, notify your supplier/dealer immediately. Only the shipper may file a damage claim
with the carrier for damage incurred during shipping. Be sure to save the carton and
all packing materials for the carrier’s inspection.
If the packing materials are in good condition, please save them.
If you ever need to ship the unit anywhere without mounting it in a rack, you should
take advantage of the original factory packing materials in order to avoid unnecessary
damage.
mounting
All LT / ST Series amplifiers mount in standard 19-inch racks and occupy two rack
spaces. Four front-panel mounting holes are provided on each amplifier. Rear mounting ears give additional support and use of rear supports is highly recommended in all
mobile and touring sound systems. Handles are fitted standard.
front width 19"/483mm
LT shown. ST has the same dimensions
For replacement
packaging, call Crest
Audio’s
Customer Service
Department directly.
see—service and support
+
LT / ST shown
rear width 17"/432mm
front
height
3.47"/
88 mm
front
height
3.47"/
88mm
depth14"/356mm
2
p. 7
installation
Make certain that there
is enough space around
the front and rear of the
amplifier to allow the
heated air to escape.
When mounting in a rack,
try to avoid using doors
or covers on the front
and rear of the enclosure;
the exhaust air must not
be impeded
suggestion
In racks with closed backs
allow at least
one stan-
dard-rack-space opening
for every four amps.
a
cooling and ventilation
LT / ST amplifiers use a forced air cooling system to maintain a low,even operating temperature.
Air is drawn in by a DC fan on the rear panel, flows through the cooling fins and then
exhausts through the front panel vent.
Heat sink temperature is monitored and controls the variable speed fan. Fan speed
increases only as required, keeping fan noise to a minimum.
If the heat sink surpasses its maximum allowed temperature, the thermal protection
circuit will activate and open the output relays allowing the amplifier to cool to a safe
temperature. To continue using the amp, it must be reset by turning the power off and
then turning it back on again.
Thermal protect activation only occurs under extreme thermal conditions and is not
part of normal operation.
powering
Unless otherwise specified when ordered, LT / ST amplifiers are supplied factory set
to following voltage options :
Option 1 US domestic nominal 120Vac 60Hz for rated power output
(safe operating range 100 - 132Vac )
Option 2 export models nominal 230Vac 50Hz for rated power output
(safe operating range 200 - 264Vac )
note
Due to the nature of the switching power supply in the ST, 50 - 60Hz operation is acceptable for both
options.
maintenance
LT / ST amplifiers require no routine maintenance.
If the amplifier is used in an extremely dusty or smoky environment , the unit should
be periodically blown free ( using compressed air ) of any foreign matter that may have
built up inside the unit.
Users will not need to make any adjustments to the amplifier during its lifetime.There
are no user-serviceable parts or adjustments that require opening the amplifier.
p. 9
features overview
3
front panel
rear panel
/
location of connectors and controls
/
legend of panel symbols
p. 10
LT / ST owner’s manual
features overview
3
LT / ST shown
1
2
3 4
7
5
6
9
1 2 3 4
7
5
6
9
8
8
p. 11
features overview
3
front panel
1
Rack Mounting Ears
Two front-panel mounting holes are provided on each mounting ear.
2
Channel Level attenuators
Two input attenuators adjust level for their respective amplifier
channels. In Bridged Mono and Parallel modes, the channel A
attenuator controls overall signal level (see rear panel mode switch
description).
3
Protect
This Red LED indicates that the amp channel is in Protect mode.
During Power up, the amp briefly goes into protect mode in order
to prevent any loud spikes from being fed the speakers. After a few
seconds the amp comes out of protect mode and is ready for
normal operation. If the amp stays in Protect mode, this indicates
that there may be a problem internal to the amp. If the amp goes
into Protect mode during operation this indicates that either a
problem has developed internal to the amp or the amp is being
over-stressed and needs to cool down. After a Protect condition, the
amp must be reset by cycling the power off and then on again in order
to continue using it.
4
ACL / IGM
This Red LED illuminates when either the ACL or IGM protection
circuitry is engaged. See Section 6,Tourclass Protection for more
information on these Crest-exclusive features.
5
-24, -18, -6, 0dB
The first three LEDs (-24, -18, -6,) are Green and the last led, 0dB is
yellow. These LEDs respond to the incoming program material as peak
meters. Under normal operating conditions the Green LEDs illuminate
with the dynamics of the program material and the Yellow LED flashes
during the loudest peaks.
6
Signal
Green LED varies in intensity in response to signals below -24 dB.
7
Active
Green LED illuminates when the amp is on to show that the channel
is active.
8
Fan Outlet Grill
LT & ST Series amplifiers are cooled by a single rear-mounted fan.
Cool air flows over the heat sink and exhausts through the front grill.
Make sure this outlet remains clear to allow unrestricted airflow.
9 Power switch
This switch turns the amp on and off. If the amp doesn’t turn on when
the switch is in the
ON position, check the circuit breaker on the rear
panel.
p. 12
rear panel
1
IEC power connector
Accepts a standard IEC terminated power cable
2
Breaker
Resettable circuit breaker - no fuses are used. Breaker can trip due to
a power surge or over-voltage condition. If it trips once, reset it. If it
continues to trip, the amplifier may need servicing.
3
Fan
The fan operates continuously while the amp is on. An internal
temperature sensor increases the speed of the fan during high
temperature conditions. Air enters through the rear of the
amp and exits through the front grill. Be sure to allow adequate air
flow from the rear of the rack the amp is mounted in.
rear panel legend
input connection
XLR connector polarity
TRS connector polarity
bridged mono mode
parallel mode
stereo mode
chassis ground lifted-position
chassis ground grounded-position
output connection
speakon output
channel A stereo/parallel
channel B stereo/parallel
bridged mono
five-way binding post
channel A stereo/parallel
bridged mono
channel B stereo/parallel
1
4
5
6
LT / ST shown
3
7
2
p. 13
features overview
3
rear panel
4
Output connections
Speakers can be connected via the high current binding posts and
the industry-standard Speakon (NL-4) connectors.
Binding posts: One pair (Red- hot, Black- ground) per channel.
Speakons - One connector for each channel. In Bridged Mono
mode, the Speakon connector for Channel A is used exclusively
(see Operation Modes).
5
Ground lift switch
The recessed two-position ground lift switch is used to isolate the
amp’s signal ground from the chassis/AC ground.The factory default
setting is to the right, Grounded.To lift, or disconnect the signal
ground from the chassis/AC ground, slide the switch to the left.
In situations where chassis ground must be lifted, use this switch never lift the ground prong on the AC connector.
6
Input connections
Input signals can be connected to the amp via the Phoenix connectors, the 1/4” TRS connectors and the Female XLR (pin 2 hot) connectors. Input sensitivity is
.775v (0 dBv) for full rated output
power. See Connections
7
Mode selector switch
This recessed, three position switch configures the amplifier for
Stereo, Parallel or Bridged Mono operation. The default factory
setting is Stereo. See - operation modes.
Never connect a hot
(red) output to ground
or to another
hot (red)
output!
a
Do not adjust the mode
selection switch while
the amplifier is turned-on.
a
In situations where an UNBALANCED signal is fed to the amp, it’s
important to ground the unused
input. If the inverting (-) input of an
amp channel is left floating, the channels gain will drop by 6 dB. In effect,
the amp will not be as loud. For more
information about this, ask your dealer
or contact Crest Audio Technical
Support directly.
a
p. 15
operation modes
4
stereo
parallel
bridged
/
choosing the appropriate mode
/
switching between operation modes
/
special considerations when using bridged mode
p. 16
mode selection
The three-position, recessed Mode Select switch (located on the rear panel)
configures the amplifier for Stereo, Parallel or Bridged mode. Amplifiers are
factory-configured for Stereo mode. Shut the amp off before changing
modes.
stereo
In Stereo mode, both channels operate independently,with their input attenuators controlling their respective levels.Signal at Channel A’s input produces
output at Channel A’s output,while signal at Channel B’s input produces out-
put at Channel B’s output. Recommended minimum nominal load impedance
for stereo operation is 2 Ohms per channel.
parallel
When set to Parallel mode, program material applied to Channel A’s input
will appear at both Channel A and B outputs.The attenuator for Channel A
controls the level for both A and B outputs.
bridged
Bridged mode straps both amplifier channels together to make a singlechannel monaural amplifier. One channel
pushes and the other pulls equally,
increasing the power output over that of either channel alone
(see Specifications). Signal is applied to the Channel A input only. Channel
A’s attenuator is used to control signal level.
Use extreme caution when operating the amplifier in Bridged mode. Never
ground either side of the speaker cable when the amplifier is in Bridged
mode; both sides are “hot.”
If an output patch panel is used, all connections must be isolated from each
other and from the panel.The recommended minimum nominal load impedance in the Bridged mode is 4 ohms, which is the equivalent to driving both
channels separately at 2 ohms.
see—connections for examples of mode-specific wirings
Connecting amplifier
outputs to oscilloscopes
or other test equipment
while the amplifier is
in
bridged mode may
damage both the amplifier
and test equipment!
a
LT / ST owner’s manual
operation modes
4
p. 17
connections
5
input
XLR 1/4” TRS
output
Phoenix 3 pin
/
proper wiring schemes for connectors:
speakon
binding post
/
correct signal paths: stereo, parallel and bridged
p. 18
LT / ST owner’s manual
connections
5
inputs
LT / ST amplifiers are configured standard with pin 2 hot on XLR inputs.
outputs
Speakers are connected using the high-current five-way binding posts
or speakon connectors, or both.
see—operation modes
Very high current is
available at the outputs.
Please connect your
output cable to the + and
- terminals of each section precisely as shown.
a
stereo/parallel
female
XLR
bridged mono
TRS pinouts 3-pin Phoenix (view of connector on rear of amp)
Speaker + to PIN 1+
Speaker - to PIN 1-
Speaker + to PIN 1+
Speaker - to PIN 2+
Com In + In -
p. 19
connections
5
stereo mode
five-way binding post connectors
parallel mode
five-way binding post connectors
bridged mono mode
five-way binding post connectors
p. 20
stereo mode
speakon output connectors
parallel mode
speakon output connectors
bridged mono mode
speakon output connectors
Speaker + to PIN 1+
Speaker - to PIN 2+
LT / ST owner’s manual
connections
5
p. 21
safety
6
user
responsibility
speaker
protection
TourClass
/
the owner’s role in amplifier safety
/
protecting your speakers
/
description of TourClass protection features
p. 22
LT / ST owner’s manual
safety
6
speaker protection
All loudspeakers have electrical, thermal and physical limits which must be observed to prevent damage or failure.Cone or compression drivers can be damaged (sometimes to the point
of failure) from excessive power, low frequencies applied to high frequency drivers, severely
clipped wave forms, and DC voltage. All LT / ST Series amplifiers automatically protect speakers from DC voltages and subsonic signals.
see—TourClass protection
Mid- and high-frequency transducers—compression drivers in particular—are highly susceptible to damage from overpowering,clipped wave forms,or frequencies below their rated pass
band.When using an electronic crossover, make absolutely certain that the low and mid bands
are connected to the correct amplifiers and drivers—and not accidentally connected to those
for a higher or lower frequency band.
The amplifier’s clipping point is its maximum peak output power. At maximum peak output
power, Crest Audio LT / ST Series amplifiers will deliver more power than many speakers can
safely handle. Be sure the peak power capability of the amplifier is not excessive for your
speaker system.To ensure that the speakers never receive excessive power, and to prevent
amplifier clipping,use a properly adjusted external limiter (or a compressor with a ratio of 10:1
or higher) to control power output. Use one compressor/limiter for each frequency band in
systems with active electronic crossovers.
The ACL clip limiting circuit will automatically limit the duration of squared-off, continuous
wave forms applied to the speakers.The amplifier will,however, allow normal musical transient
bursts to pass. Of course, when the amplifier does clip, it is operating at its maximum output
power. Note that some speaker systems are packaged with proprietary “processors” that have
power limiting circuits and therefore should not require additional limiting. Do not drive any
low-frequency speaker enclosure with frequencies lower than its own tuned frequency; the
reduced acoustical damping could cause a ported speaker to bottom out even at moderate
power. Consult the speaker system specifications to determine its frequency limits, and employ
a roll-off filter if necessary.
recommended speaker cabling
The wire gauge charts will assist you in determining the optimum copper wire gauge for your
speaker cables.Remember that the speaker cable resistance robs amplifier power in two ways:
through power lost directly to resistance (often referred to as I
2
R loss), and through increased
total load resistance, which decreases the amount of power available from the amplifier.
Appendix C gives cable length figures in feet/AWG wire gauges and in metric values.
see—wire gauge
user responsibility
Your LT / ST Series amplifier is very powerful and can be potentially dangerous to loudspeakers and operators alike. It is your responsibility to read
important precautions
(see the inside-front cover) and make sure that the amplifier is installed, wired, and
operated properly as instructed in this manual.
Many loudspeakers can be easily damaged or destroyed by overpowering, especially
with the high power available from a bridged amplifier. Always be aware of the speaker’s continuous and peak power capabilities. Crest Audio is not responsible for damage
to loudspeakers for any reason.
see—speaker protection
p. 23
safety
6
TourClass®protection
Just like Crest Audio’s highly acclaimed Pro series amps, LT and ST amps incorporate
TourClass protection features. Derived from Crest Audio’s extensive experience with the
world’s largest sound rental companies, the TourClass group of circuits sets the industry
standard for assured protection of internal amplifier circuits and all connected loads.
ACL ACTIVE CLIP LIMITING
At the amplifier’s full power limit, or clipping point, ACL will be activated.This is indicated
by illumination of the
ACL / IGM LED.The channel gain is automatically reduced, protecting
the loudspeakers from potential damage from the high power, continuous square waves that
would otherwise be produced.
ACL may be activated by uncontrolled feedback, oscillations,
improper equipment gain settings, or an equipment malfunction upstream from the amplifier. Only steady or excessive clipping
(not normal program transients) will trigger ACL. The
circuit is virtually transparent in operation and full signal bandwidth is maintained.
IGM INSTANTANEOUS GAIN MODULATION
IGM is an innovative circuit that allows the amplifier to operate safely into loads as low as 2
ohms.When the amplifier sees a load that overstresses the output stage, the
IGM circuit adjusts
the channel gain to a safe level. This gain control circuit is inaudible in normal use. In addition,
if extreme and sustained low impedance is encountered,the amplifier’s output relay will open.
AutoRamp
Auto Ramp operates every time the amplifier is turned on or is reactivated after a protect
condition is corrected.This exclusive Crest Audio feature gradually increases gain to the attenuator setting avoiding unnecessary stress on the loudspeakers.
Thermal Protect
Abnormally high heat sink temperatures will engage the Protect circuit and disconnects the
output relays.During this time the Prot LEDs will light red.The cooling fan will continue running at high speed. Normal operation resumes once the amplifier cools to a safe level.
Short Circuit
If an output is shorted (i.e. defective speakers or crossed speaker wires) the channel will shutdown and can be re-set by turning the amplifier off, then on.
DC Voltage
If an amplifier channel detects DC voltage at its output terminals, the output relay will immediately
open to prevent loudspeaker damage. The protect LEDs illuminate.
Subsonic Frequencies
Built-in high pass filtering provides subsonic frequency protection for each channel. In addition,
a relay will open if excessive subsonic energy appears
at the output.
p. 25
service and support
7
/
when to get support
/
ways to contact Crest Audio
support
contact us
p. 26
support
In the unlikely event that your amplifier develops a problem, it must be
returned to an authorized distributor, service center or shipped directly to
our factory.
To obtain service, contact your nearest Crest Audio Service Center,
Distributor, Dealer, or any of the worldwide Crest Audio offices. For those
with Internet access, please visit the Crest Audio web site.
contact us
customer service
phone 201.909.8700 USA
fax 201.909.8744 USA
email customerserve@crestaudio.com
technical support
phone 201.909.8700 USA
fax 201.587.0550 USA
email techserve@crestaudio.com
web site
www.crestaudio.com
mail
Crest Audio Inc.
16-00 Pollitt Drive
Fair Lawn, NJ 07410 USA
For replacement
packaging, call Crest
Audio’s Customer Service
+
LT / ST owner’s manual
service and support
7
p. 27
Stereo power 8Ω
4Ω
2Ω
Bridged mono power 8Ω
4Ω
Maximum output voltage rms each channel
Frequency response 1W @ 8Ω
Power bandwidth @ rated power
Damping Factor
Input cmrr
Input sensitivity for full rated output power
Input impedance
Hum and noise
Crosstalk
Class
Circuit breaker rating
120 Vac
Circuit breaker rating 230Vac
Current draw 1/8 power, 4Ω 120 Vac
Current draw 1/3 power, 4Ω 120 Vac
Current draw idle 120Vac
Thermal emissions 1/3 Power, 4Ω, BTU/HR
Cooling
Input connectors,
per channel
Output connectors
Controls
LED indicators
TourClass protection
Construction
Dimensions
Weight
net LT
net ST
1000 1500 2000
LT / ST
1kHZ, 0.5%THD+N
280W 400W 550W
500W 750W 1000W
650W 900W 1200W
1000W 1500W 2000W
1300W 1800W 2400W
53 rms 64 rms 72 rms
20Hz–20kHz, +0 / - 1dB 20Hz–20kHz, +0 / - 1dB 20Hz–20kHz, +0 / - 1dB
20Hz–20kHz, +0 / - 1dB 20Hz–20kHz, +0 / - 1dB 20Hz–20kHz, +0 / - 1dB
400:1 @ 8Ω 400:1 @ 8Ω, 400:1 @ 8Ω,
60dB @ 1 kHz 60dB @ 1 kHz 60dB @ 1 kHz
.775V .775V .775V
20K balanced 10K unbalanced 20K balanced 10K unbalanced 20K balanced 10K unbalanced
-100dB
, A-weighted below rated power -100dB, A-weighted below rated power -100dB, A-weighted below rated power
-55dB @ 1kHz below rated power -55dB @ 1kHz below rated power -55dB @ 1kHz below rated power
DDD
10A 15A 20A
6A 10A 12A
3A 4A 5A
6A 8.5A 10A
0.6A 0.6A 0.6A
1240 1630 1960
Back to front via variable speed fan Back to front via variable speed fan Back to front via variable speed fan
Female XLR pin 2+, stereo 1/4” TRS Female XLR pin 2+, stereo 1/4” TRS Female XLR pin 2+, stereo 1/4” TRS
jack socket, 3 pin Phoenix Combicon jack socket, 3 pin Phoenix Combicon jack socket, 3 pin Phoenix Combicon
Speakon connectors and 5 way binding post Speakon connectors and 5 way binding post Speakon connectors and 5 way binding post
Front panel: two attenuators power switch. Rear panel: signal g round-lift, mode select t hermal circuit breaker (all models)
ACL, IGM, protection ACL, IGM, protection ACL, IGM, protection
5 segment bargraph VU 5 segment bargraph VU 5 segment bargraph VU
meter, active
AUTORAMP meter, active AUTORAMP meter, active AUTORAMP
ACL, IGM, AUTORAMP. SHORT CIRCUIT ACL, IGM, AUTORAMP. SHORT CIRCUIT AC L, IGM, AUTORAMP. SHORT CIRCUIT
DC VOLTAGE TURN ON
/OFF TRANSIENT DC VOLTAGE TURN ON/OFF TRANSIENT DC VOLTAGE TURN ON/OFF TRANSIENT
CURRENT IN
-RUSH, SUB / ULTRASONIC INPUT CURRENT IN-RUSH, SUB / ULTRASONIC INPUT CURRENT IN-RUSH, SUB / ULTRASONIC INPUT
16 gauge steel chassis 16 gauge steel chassis 16 gauge steel chassis
3.5” x 19” x 15.25” 89mm x 483 x 388mm height x width x depth
30lb 32.5lb 35lb
22.5lb 23lb 23lb
specifications
a
p. 28
LT / ST owner’s manual
block diagram
b
Channel A
Inputs
Phoenix
Combicon
1/4”
TRS
Female
3-Pin XLR
Channel B
Inputs
Phoenix
Combicon
1/4”
TRS
Female
3-Pin XLR
Channel A
Outputs
5-Way
Binding Posts
A
ATTENUATOR
1
3
2
OUTPUT STAGE
OUTPUT RELAY
Neutrik
Speakon
Channel B
Outputs
5-Way
Binding Posts
B
ATTENUATOR
C
B
1
3
2
A
MODE SWITCH
A: STEREO
B: PARALLEL
C: BRIDGE
OUTPUT STAGE
OUTPUT RELAY
SEE SECTION 5 FOR
OUTPUT CONNECTION DETAILS
Neutrik
Speakon
p. 29
stranded cable length
0.3mm
2
0.5
0.75
1.5
2.5
4.0
2.9%
1.74
1.16
0.58
0.35
0.22
5.6%
3.4
2.3
1.16
0.70
0.44
10.8%
6.7
4.5
2.3
1.39
0.87
0.5mm
2
0.75
1.5
2.5
4
6
4.3%
2.9
1.45
0.87
0.55
0.37
8.2%
5.6
2.9
1.74
1.09
0.73
15.5%
10.8
5.6
3.4
2.2
1.45
0.5mm
2
0.75
1.5
2.5
4
6
8.24%
5.6
2.9
1.74
1.09
0.73
5.5%
10.8
5.6
2.9
1.74
1.09
28%
19.9
10.8
6.7
4.3
2.9
0.75mm
2
1.5
2.5
4
6
10
15.5%
8.2
5.1
3.2
2.2
1.31
0.73%
15.5
9.8
6.3
4.3
2.6
45%
28
18.2
12.0
8.2
5.1
2
meters
5
meters
10
meters
30
meters
wire gauge power loss
8 Ω load 4 Ω load 2 Ω load
wire gauge
c
p. 30
stranded cable length
18AWG
16
14
12
10
0.81%
0.51
0.32
0.20
0.128
1.61%
1.02
0.64
0.40
0.25
3.2%
2.0
1.28
0.80
0.51
18AWG
16
14
12
10
1.61%
1.02
0.64
0.40
0.25
3.2%
2.0
1.28
0.80
0.51
6.2%
4.0
2.5
1.60
1.01
18AWG
16
14
12
10
8
6.2%
4.0
2.5
1.60
1.01
0.60
11.9%
7.7
5.0
3.2
2.0
1.20
22%
14.6
9.6
6.2
4.0
2.4
18AWG
16
14
12
10
8
11.9%
7.7
5.0
3.2
2.0
1.20
22%
14.6
9.6
6.2
4.0
2.4
37%
26
17.8
11.8
7.7
4.7
5
feet
10
feet
40
feet
80
feet
wire gauge power loss
8Ω load 4Ω load 2Ω load
LT / ST owner’s manual
wire gauge
c
http://www.crestaudio.com LT/ST Owner's Manual Version 1.3 03/21/02
Loading...
