Peavey IMPULSE-1015-II Data Sheet
Impulse® 1015
Product
Specications
www.peavey.com
Specications - Peavey® Impulse® 1015
Frequency Response: 68 Hz to 18 kHz, 1 meter on axis, swept sine in anechoic environment
Usable Low Frequency limit (-10 dB point anechoic): 59 Hz
Nominal sensitivity (1W @1M, swept sine input in anechoic environment): 97 dB (average)
Maximum Sound Pressure Level (1 meter):
124 dB continuous
130 dB SPL peak with music
Radiation Angle measured at -6 dB point of polar response:
Nominal: 110 degrees horizontal X 80 degrees vertical
(Axis of the vertical main polar lobe is angled down 10 degrees, resulting in the angular pattern with respect to
straight ahead being +30, -50 degrees)
Transducer Complement:
Low Frequency Section:
1 X 15” woofer, vented
Black Widow® 1508-8 BWX WR SS SF (03617980)
High Frequency Section:
1 X 1.0” exit, 50 mm voice coil
RX™22N Neodymium compression driver on asymmetrical Quadratic roat CD Horn
Box Tuning Frequency: 45 Hz
Electro-acoustic crossover frequency: 1.9 kHz
Crossover type:
Internal passive two-way crossover with driver EQ, and driver level matching incorporated.
Crossover Slopes:
12 dB/octave (2nd order) each driver, both with staggered poles and driver EQ.
Impedance (Z) in ohms (Ω):
Nominal: 8.0 Ω
Minimum: 5.3 Ω
Input Connections:
Two NL-4 twist-lock jacks in parallel with a 4 position screw terminal barrier strip.
Enclosure Materials & Finish:
Black polypropylene plastic with textured surface, black powder-coated perforated full-coverage grille.
Mounting provisions:
Four rubber feet provide vibration free oor or stage use, and a molded-in stand mounting cup is on the bottom
for use with 1 3/8” stand poles. Unit has two four insert mounting groups (8 inserts total) of M6 metric inserts,
for use with the Peavey VM 70 mounting bracket, one on the le side, and one on top.
Overall Dimensions ( H x W x D )
28.3”H x 16.75”W x 15.00”D
719 mm x 426 mm x 381 mm
Net Weight: 48 lbs. (21.8 kg)
Features
• 2-way full range sound reinforcement system
• Black Widow® 15” 1508-8 BWX WR SS SF long-throw woofer
• RX™22N Neodymium compression driver
• Power Handling: 2000 watts peak, 1000 watts Program
• HF Driver protected by Sound Guard™ III
• Patented Quadratic roat Waveguide™ technology, 110 by 80 degree coverage
• Rugged plastic injection-molded trapezoidal enclosure
• Cabinet has dual rear corner angled sides for oor monitor use.
• Full-coverage perforated steel grille, with powder coat nish
• Pole mount molded-in for 1 3/8” diameter poles
• M6 metric y points for VM-70, top and le side of cabinet
• Weather-resistant for sheltered outdoor use.
• Overall system weatherization rating of IP44
DO NOT remove the protective metal grilles.
WARNING! e Impulse®1015 is very ecient and powerful! is sound system can permanently damage hearing! Use extreme care setting the overall maximum loudness!
e apparent sound level of the Impulse®1015 can be deceiving due to its clear, clean sound output. e lack of
distortion or obvious distress can make the sound level seem much lower than it actually is. is system is capable of SPL in excess of 130 dB at 1 M from the speaker!
