PCD TXT8030 Movilnet User Guide

User Guide
TXT8030
1. BEFORE USING
BEFORE USING .........................................................................................................9
INSIDE THE PACKAGE ........................................................................................... 10
HANDSET DESCRIPTIONS ..................................................................................... 11
KEY DESCRIPTIONS .............................................................................................. 13
DISPLAY INDICATORS ........................................................................................... 16
INSTALL BATTERY ................................................................................................ 20
REMOVE BATTERY ...............................................................................................20
CHARGING YOUR BATTERY ...................................................................................21
SWIVELING THE KEYPAD ......................................................................................23
2. BASIC OPERATION
BASIC OPERATION ..................................................................................................25
TURNING THE PHONE ON/OFF ..............................................................................26
ACCESSING THE MENU .........................................................................................26
USING THE TASK BAR ...........................................................................................27
MENU SUMMARY ................................................................................................28
MAKING A CALL .................................................................................................. 32
ANSWERING CALLS ............................................................................................. 32
MISSED CALL NOTIFICATION .................................................................................33
WAIT/PAUSE FEATURE .........................................................................................33
ANSWERING A CALL ............................................................................................ 34
MAKING AN INTERNATIONAL CALL .......................................................................34
3-WAY CALLING ..................................................................................................35
2
CALL WAITING FUNCTION .................................................................................... 35
CALLING A NUMBER FROM CONTACTS ................................................................... 35
ADJUSTING VOLUME ............................................................................................ 36
CALLER ID FUNCTION .......................................................................................... 36
VIBRATE ON/OFF MODE .......................................................................................37
SPEAKERPHONE MODE ....................................................................................... 37
USING AUTO KEYPAD LOCK FUNCTION................................................................... 37
AVAILABLE OPTIONS DURING A CALL .................................................................... 38
MAKING AN EMERGENCY CALL .............................................................................39
3. MEMORY FUNCTION
MEMORY FUNCTION ............................................................................................... 43
STORING A PHONE NUMBER ................................................................................ 44
ENTERING LETTERS, NUMBERS & SYMBOLS .......................................................... 51
ONE, TWO, THREE-TOUCH DIALING .......................................................................53
4. MENU FUNCTION
CALLS .................................................................................................................... 56
CALLS ................................................................................................................. 56
MISSED CALLS .................................................................................................... 56
RECEIVED CALLS ................................................................................................. 57
DIALED CALLS .....................................................................................................58
ALL CALLS .......................................................................................................... 58
VIEW TIMERS ......................................................................................................59
CONTACTS ..............................................................................................................60
NEW ENTRY ........................................................................................................60
3
LIST ENTRIES ......................................................................................................60
MESSAGE GROUPS .............................................................................................61
SPEED DIALS ....................................................................................................... 65
MY NAME CARD .................................................................................................. 66
CONFIGURATION ...................................................................................................67
SOUNDS SETTINGS .............................................................................................. 67
DISPLAY SETTINGS ..............................................................................................72
PHONE SETTINGS ................................................................................................74
CALL SETTINGS ................................................................................................... 78
MEMORY ............................................................................................................ 80
BLUETOOTH ........................................................................................................84
USB MODE .......................................................................................................... 89
PHONE INFO .......................................................................................................90
TOOLS .................................................................................................................... 91
VOICE COMMANDS ..............................................................................................91
CALCULATOR ....................................................................................................... 97
CALENDAR .......................................................................................................... 97
ALARM CLOCK ................................................................................................... 100
STOP WATCH .....................................................................................................102
WORLD CLOCK .................................................................................................. 103
NOTEPAD ..........................................................................................................104
VOICE MEMO..................................................................................................... 106
USB MASS STORAGE .......................................................................................... 107
4
5. MULTIMEDIA
microSD .............................................................................................................. 110
USING THE microSD CARD .................................................................................. 110
MULTIMEDIA........................................................................................................112
SOUND BOX ......................................................................................................112
MP3 BOX ..........................................................................................................113
PICTURE BOX ....................................................................................................115
NEO APPLICATIONS ...........................................................................................118
NEO NAVIGATION .............................................................................................. 118
6. MESSAGES MENU
MESSAGES........................................................................................................... 122
WHEN A NEW MESSAGE ARRIVES .......................................................................122
NEW MESSAGE .................................................................................................. 122
VOICEMAIL ...................................................................................................... 124
INBOX .............................................................................................................. 125
SENT ................................................................................................................ 125
DRAFTS ............................................................................................................ 126
SETTINGS ......................................................................................................... 127
ERASE .............................................................................................................. 129
5
7. SAFETY AND WARRANTY
SAFETY ................................................................................................................ 131
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES .................................. 132
SAFETY INFORMATION FOR FCC RF EXPOSURE ..................................................... 136
SAR INFORMATION ............................................................................................ 137
HEARING AID COMPATIBILITY (HAC) FOR WIRELESS
TELECOMMUNICATIONS DEVICES ........................................................................ 139
FDA CONSUMER UPDATE .................................................................................... 141
AVOID POTENTIAL HEARING LOSS. ...................................................................... 147
FCC COMPLIANCE INFORMATION ........................................................................150
WARRANTY .......................................................................................................... 151
12 MONTH LIMITED WARRANTY ......................................................................... 151
6
7
Before Using
This chapter provides important information about using the
Handset descriptions
Charging your battery
Battery handling information
Swiveling the keypad
Removing the microSD card
1
TXT8030 including:
Inside the package
Key descriptions
Display indicators
Install battery
Remove battery
TXT8030
INSIDE THE PACKAGE
This package should include all items pictured below. If any are missing or different, immediately contact the retailer where you purchased the phone.
%75% 9P$K:K/LLRQ%DWWHU\ %DWWHU\0DQXIDFWXUHGE\3DQWHFK&XULWHO &HOO0DQXIDFWXUHGLQ.RUHD %DWWHU\0DQXIDFWXUHGLQ.RUHD
Standard Battery
WARRANTY CARD
Warranty Card
Pre-installed
microSD Card
Battery Cover
Handset
User Guide
10
Wall Charger
HANDSET DESCRIPTIONS
1
2
3 4 5
6
01
02
03
16 15
14 13
12 11
10
9 8 7
17
18
19
04
05
06
07
1. Left Soft Key
2. Speakerphone Key
3. SEND Key
4. Rewind Key
5. External Speaker
6. Music Keypad
7. Music Key
8. Fast-forward Key
9. Play/Pause Key
10. END Key
11. CLR/AVC Key
12. Right Soft Key
13. Directional Key
14. OK Key
15. Display Screen
16. Earpiece
17. Wrist Strap Eyelet
18. Camera Key
19. Task Bar/Lock Key
11
28
27
20 21
22
26
25
24 23
29
30
31
20. Shift Key
21. International Dial Key
22. Vibration Key
23. TXT Composer Key
24. Quick Note Key
25. QWERTY Keypad
12
26. Camera Lens
27. Self-Portrait Mirror
28. Headset Jack
29. Charging/Data Jack
30. Volume Keys
31. microSD Card Slot
KEY DESCRIPTIONS
The following list correlates to the previous page’s phone illustration.
1. [ ] Left Soft Key: From idle mode, press to display the main Menu or
] Speakerphone Key: Press to turn Speakerphone On or Off.
2. [
] SEND Key: Press to make or receive a call. From idle mode, press to
3. [
] Rewind Key: From the music player or while music is playing in the
4. [
5. External Speaker: Music, Ringtones and Sounds are played through the
6. Music Keypad: Press to activate the music player or play, pause, fast forward,
] Music Key: Press to activate the music player or switch between the
7. [
] Fast-forward Key: From the music player or while music is playing
8. [
] Play/Pause Key: From the music player or while music is playing in
9. [
] END Key: Press and hold to turn the phone on/off or press to end a
10. [
access the function listed above the key.
access the ALL CALLS list.
background, press to skip back one complete song or press and hold to rewind a song.
speaker.
rewind, and skip music.
music player and MP3 Box.
in the background, press to skip forward one complete song or press and hold to fast forward through a song.
the background, press to play or pause a song.
call or browser session, and/or return to idle mode.
01
02
03
04
05
06
07
13
11. [ ] CLR/AVC Key: Press to clear a character from the display. Press and
hold to clear all characters. Within a menu, press to return to the previous menu. From idle mode, press and hold to access the VOICE COMMANDS menu.
] Right Soft Key: From idle mode, press to display Contacts or to
12. [
access the function listed above the key.
13. Directional Key: Allows you to scroll through phone menu options and
provides a shortcut to phone functions from idle mode.
] OK Key: Allows you to accept choices when navigating through a
14. [
menu.
15. Display Screen: Displays incoming calls, messages, signal, battery strength,
time and date.
16. Earpiece: The earpiece allows you to hear the other caller.
17. Wrist Strap Eyelet: Accessory eyelet (optional straps and lanyards -
purchased separately).
18. Camera Key: Press to access the built-in camera.
] Task Bar/Lock Key: Press to activate the Task Bar menu or press and
19. [
hold to lock/unlock the keypad.
20. Shift Key: In text entry mode, press to change the character input type.
21. International Dial Key: Press to enter an asterisk (*) character for calling
features. Press and hold to display the plus sign (+) for international dialing.
22. Vibration Key: Press and hold to place your device in Vibrate Mode.
23. TXT Composer Key: Press to access the New Text Message menu.
24. Quick Note Key: Press to access the Quick Note menu or to add a space
between characters.
14
25. QWERTY Keypad: Press to enter numbers, letters, and characters using a full
QWERTY keypad interface.
26. Camera Lens: The lens of your built-in camera.
27. Self-Portrait Mirror: Displays your reflection when taking pictures.
28. Headset Jack: Allows you to plug in an optional headset for convenient,
hands-free conversations.
] Charging/Data Jack: Plug in the Wall Charger or USB cable here.
29. [
/ ] Volume Keys: Press to adjust the ringer volume in idle mode,
30. [
adjust the voice volume during a call or adjust music volume when playing music.
] microSD Card Slot: A pre-installed microSD Card is inserted here.
31. [
01
02
03
04
05
06
07
15
DISPLAY INDICATORS
Icon Icon Descriptions
Signal Strength: Indicates Signal Strength.
1X: 1X service is available.
D: CDMA IS 95 service is available.
Airplane Mode: Transmitting and receiving information is restricted.
Roaming: The phone is outside of the home service area.
SSL (Secured Socket Layer): Indicates that secure communication between client and
server has been established during data communication using encryption.
Voice Privacy: Indicates Voice Privacy mode is active.
Data Call: Indicates Data Session in progress.
Dormant: Indicates phone is in a dormant state during a data call. Phone reverts
to Dormant mode when there hasn't been activity on a page for some time — the connection is still active and you can make and receive calls.
No Service: Phone cannot receive signal from the system.
TTY: TTY mode is active.
Location On: Global Positioning Service is set to On for Location Service and 911 calls.
Bluetooth: Indicates Bluetooth mode.
Bluetooth Active: Indicates Bluetooth Active mode.
16
Icon Icon Descriptions
Bluetooth Connected: Indicates Bluetooth Device is connected.
Bluetooth Discovery: Indicates Bluetooth Discovery mode is On.
Playing Music: Indicates that music is playing.
Pause Music: Indicates that music playback has been paused.
Numeric Entry Mode: Enter numbers by pressing the corresponding key on the keypad.
Alphabetical Entry Mode: Enter characters by pressing the key with the desired
characters.
Battery Level: Battery charging level-the more blocks, the stronger the charge.
AVC Active: AVC mode is active.
AVC Listening: Indicates AVC listening.
Silent: Indicates the Ringer Volume is set to Silent.
Vibrate Only: Indicates the Ringer Volume is set to Vibrate On.
Speakerphone: Speakerphone mode is active.
Message: Indicates you have a new message.
Voicemail: Indicates you have a voicemail message.
Alarm On: Appears when an alarm is set.
01
02
03
04
05
06
07
17
Recent Calls Icons
Dialed Call
Received Call
Missed Call
Contact Icons
Mobile1 Group
Mobile2 Picture
Home Ringtone
Work Fax
E-mail 1 Speed Dial
E-mail 2
18
Message Icons
NEW/Unread Message
Opened/Read Message
Message Delivered
Incomplete Delivery Sent Message
Sent Message, Delivery Failed
Message Locked
Text Message Draft
Multimedia Message Draft
Message Priority level
Unread Multimedia Messages Read Multimedia Messages Pending Message Send
Multiple Messages Delivered Multiple Messages Failed Multiple Messages Incomplete Multiple Messages Pending Multiple Messages Sent
01
02
03
04
05
06
07
19
INSTALL BATTERY
. Push down (1) the battery door release latch with
your finger tip and pull off (2) the battery cover.
. Slide (1) the battery into the slot by aligning the
contacts and press (2) until you hear the "click".
. Align the cover tabs with the slots on the back of the
device and press the battery cover onto the unit until it snaps into place.
If the batter y is not correctly placed in the compartment, the
handset will not turn on and/or the battery may detach during use.
REMOVE BATTERY
. To remove the battery cover, push down (1) battery
door release latch with your finger tip and pull off (2) the battery cover.
. Push the bottom of the battery upwards while inserting
your finger into the slot (1) and remove (2) the battery.
20
/LLRQ%DWWHU\
LQ.RUHD XIDFWXUHGE\3DQWHFK&XULWHO FWXUHGLQ.RUHD
%75%
DQXIDFWXUHG
9P$K:K
%DWWHU\0DQ
&HOO0DQXID
%DWWHU\0
CHARGING YOUR BATTERY
. To charge, open the Charging/Data Jack cover and connect
the Wall Charger. Make sure you align the connector as it
appears in the image.
If the batter y connector is not properly aligned, damage could occur to
the charging connector and the phone may not charge.
CORRECT INCORRECT
CORRECT INCORRECT
. Plug the other end into a standard outlet.
. To remove the Wall Charger, squeeze the adapter’s side
buttons (1) and pull the charger from the device (2).
• When you charge the battery with the handset powered off you will
see a charging status screen. After the charging has completed, the Charge Complete message appears. You cannot operate the phone until it is powered on.
•
The battery is not fully charged at the time of purchase. Fully charge the battery before use.
•
It is more efficient to charge the battery with the handset powered off.
•
Batter y operating time gradually decreases over time.
•
If the batter y fails to perform normally, you may need to replace the battery.
01
02
03
04
05
06
07
21
BATTERY HANDLING INFORMATION
DO’S
•
Only use the battery and charger approved for use with the TXT8030.
•
Only use the battery for its original purpose.
•
Try to keep batteries in a temperature between 41°F (5°C) and 95°F (35°C). If the battery is stored
in temperatures above or below the recommended range, give it time to warm up or cool down before using.
•
Store the discharged battery in a cool, dark, and dry place.
•
Purchase a new battery when its operating time gradually decreases after fully charging.
•
Properly dispose of the battery according to local laws.
DON’TS
•
Don’t attempt to disassemble the battery – it is a sealed unit with no serviceable parts.
•
Don’t accidentally short circuit the battery by carrying it in your pocket or purse with other
metallic objects such as coins, clips and pens. This may critically damage the battery.
•
Don’t leave the battery in extremely hot or cold temperatures. Otherwise, it could significantly
reduce the capacity and lifetime of the battery.
•
Don’t dispose of the battery by placing into a fire.
22
SWIVELING THE KEYPAD
To avoid breakage, turn the device in the direction indicated.
. Rotate the swivel bottom of the phone to the right, as shown above.
. The swivel bottom must be rotated to the left in order to bring it back to the original
position.
Impor tant: To prevent breakage, do not rotate the swivel bottom 360 degrees.
REMOVING THE microSD CARD
This device comes with a pre-installed microSD Card.
. Open the microSD Card cover, and use your thumb to press and release the microSD
Card.
. Press the memory card inward, gently, until it pops out. Remove the microSD Card.
. Close the microSD Card cover.
To prevent possible damages, please keep the microSD Card cover closed at all times regardless of whether
the microSD Card is inserted or not.
01
02
03
04
05
06
07
23
Basic Operation
This chapter addresses and explains the basic features for
Turning the phone on/off
Accessing the menu
using the task bar
Menu summary
Making a call
Answering calls
Missed call notification
Wait/Pause feature
Answering a call
Making an international call
Call waiting function
Calling a number from contacts
Vibrate on/off mode
Speakerphone mode
Using auto keypad lock function
Available options during a call
Making an emergency call
TXT8030
2
TXT8030 including:
3-way calling
Adjusting volume
Caller ID function
TURNING THE PHONE ON/OFF
TURNING THE PHONE ON
. Press and hold the END Key until your display turns on.
• If “Enter lock code” appears on the display, press the OK Key to unlock the keypad and enter your 4-digit
lock code and press the OK Key.
• The default lock code is "1234".
TURNING THE PHONE OFF
. Press the OK Key to unlock the keypad, then press and hold the END Key until
your display turns off.
• Immediately change or recharge the battery when “Battery low” appears on the display. Memory may
possibly be damaged if the phone turns off due to the battery completely draining.
• Turn the phone off before removing or replacing the battery. If the phone is on, unsaved data may
be lost.
ACCESSING THE MENU
Your phone can be customized via the menu. Each function can be accessed by scrolling with the Directional Key or by pressing the number that corresponds with the menu item.
. To access the main menu from idle mode, press the OK Key to unlock the keypad,
then press the Left Soft Key [Menu].
. To scroll through the menu, press the Directional Key
press the number that corresponds to the desired menu item.
. To return to the previous page, press the CLR Key
return to idle mode, press the END Key .
26
up, down, left or right or
. To exit the current menu and
. From idle mode, press the OK Key to unlock the keypad, then press the Directional
Key down to open the Message menu. Or, press the Right Soft Key [Contacts] to open your LIST ENTRIES.
This manual assumes that Menu Type of Display Setting is set to Grid which is the default setting.
USING THE TASK BAR
The Task Bar is an alternative way to cycle through menus, requiring fewer key presses. Toggle between the following menus:
Dialing, Calls, Messages, MP3 Box, Picture Box, Contacts, Tools
. From idle mode, press the OK Key to unlock the keypad, then press the Task Bar Key
.
. Press the Directional Key . Select the desired task and press the OK Key.
• Task Bar is not available for certain circumstances such as receiving an incoming call or message,
displaying a notification message or displaying the main menu.
• Once a menu is selected, it is dimmed and not selectable from the Task Bar.
left or right to scroll through Task Bar menus.
01
02
03
04
05
06
07
27
MENU SUMMARY
Main Menu 2ND DEPTH 3RD DEPTH
1. Calls 1. Missed Calls
2. Received Calls
3. Dialed Calls
4. All Calls
5. View Timers
2. Contacts 1. New Entry
2. List Entries
3. Message Groups
4. Speed Dials
5. My Name Card
3. Multimedia 1. Sound Box
2. MP3 Box
3. Picture Box
4. Messages 1. New Message
2. Voicemail
3. Inbox
4. Sent
28
1. All Songs
2. Playlists
3. Artists
4. Genres
5. Albums
6. Manage MP3 Box
7. Music Settings
1. Text Message
2. Multimedia Message
Main Menu 2ND DEPTH 3RD DEPTH
4. Messages 5. Drafts
5. Neo Applications 1. Neo Applications
6. Neo Navigation 1. Connect WAP
7. Configuration
6. Settings
7. Erase
1. Sounds Settings 1. Ringer Volume
1. Entry Mode
2. Auto Save
3. Auto Erase
4. Auto Receive
5. Quick Text
6. Callback #
7. Signature
1. Erase Inbox
2. Erase Drafts
3. Erase Sent
4. Erase All
2. Dial Sounds
3. Call Sounds
4. Alert Sounds
5. Service Alerts
6. Device Connect
7. Power On/Off
8. Key Tone
9. Swivel Sounds
01
02
03
04
05
06
07
29
Main Menu 2ND DEPTH 3RD DEPTH
7. Configuration
30
2. Display Settings
3. Phone Settings
4. Call Settings
5. Memory
6. Bluetooth
7. USB Mode
8. Phone Info
1. My Banner
2.Backlight
3.Wallpaper
4. Menu Type
5. Clock Format
1. Airplane Mode
2. Language
3. Menu Readout
4. Message Readout
5. Location
6. Security
7. System Select
1. Answer Options
2. Auto Retry
3. TTY Mode
4. One Touch Dial
5. Voice Privacy
1. Save Options
2. Internal Memory
3. External Memory
1. Add New Device
1. My Number
2. SW / HW Version
Loading...
+ 124 hidden pages
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
