Partner BV24 User Guide

BV24

INSTRUCTION MANUAL

IMPORT ANT INFORMATION

GB

sure you understand them before using this unit. Retain these instructions for future
reference.

: Please read these instructions carefully and make

MANUEL D’INSTRUCTIONS

RENSEIGNEMENTS IMPORTANTS:

FR

atentivement les instructions et assurez--vous de les avoir comprises. Conservez
les instructions pour référence ultérieure.

Avant d’utiliser cet appareil, veuillez lire

BETRIEBSANWEISUNG

WICHTIGE INFORMATION:

DE

Geräts aufmerksam durch. Verwenden Sie es erst, wenn Sie sicher sind, daß Sie
alle Anweisungen verstanden haben und gut aufbewahren.

Lesen Sie diese Hinweise zur Handhabung des

MANUAL DE INSTRUCCIONES

INFORMACIÓN IMPORTANTE:

ES

asegúrese de entenderlas antes de utilizar esta aparato. Conserve las instruc­ciones para la referencia en el futuro.

Lea atentamente las instrucciones y

LIBRETTO D’ISTRUZIONI

INFORMAZIONI IMPORTANTI

IT

istruzioni e prendere dimestichezza con il prodotto prima di usario. Mantenga
queste istruzioni per riferimento futuro.

: Siete pregati di leggere attentamente questo

HANDLEIDING

BELANGRIJKE IMPORTANTS:

NL

zeker van dat uze begrijpt alvorens de blower te gebrulken en bewaar ze voor
toekomstige raadpleging.

Lees deze instructies zorgvuldig en wees er

530163813 1/29/03

KEY TO SYMBOLS

WARNING!

can be dangerous! Care­less or improper use can
cause serious or even fa­tal injury.

Read and understand the
instruction manual before
using the blower.

WARNING!

bottom cover is secured
or the vacuum tube is
properly installed. Avoid
the impeller blade with
your hand or any foreign
object.

Instructions on how to
open vacuum inlet cover.

This blower

Be sure the

SAFETY RULES

WARNING:

Safety Rules and Precautions can result in
serious injury.

KNOW YOUR UNIT

Read your instruction manual carefully until

S

you completely understand and can follow all
warnings and safety rules before operating
the unit.
Restrictunittousers who understandandwill

D

follow all warnings and safety rules in this
manual.

WARNING:

ing unit. Remove all debris and hard objects
such as rocks, glass, wire, etc. that can rico­chet, be thrown, or otherwise cause injury or
damage during operation.
Use your unit as a blower for:

Sweeping debris or grass clippings from

D

driveways, sidewalks, patios, etc.
Blowing grass clippings, straw, or leaves into

D

piles, around joints, or between bricks.

Use your unit as a vacuum for:

Pickingupdrymaterialsuch asleaves,grass,

D

small twigs, and bits of paper.
For best results during vacuum use, operate

D

your unit at high speed.
Move slowly back and forth over the material

D

as you vacuum. Avoid forcing the unit into a
pile of debris as this can clog the unit.
Keep the vacuum tube about an inch above

D

the ground for best results.

Failure to follow all

Inspect area before start-

-- 2 --

Use unleaded or quality
leaded petrol and two
stroke oil.

Always wear eye and ear
protection.

Fast throttle

Slow idle

PLAN AHEAD

Always wear eye and ear protection when

D

operating, servicing, or performing
maintenance on unit. Wearing eye protection
will help to prevent rocks or debris from being
blownor ricocheting into eyes and face which
can result in blindness and/or serious injury .
Eye protection should be marked Z87.
Always wear foot protection. Do not go

D

barefoot or wear sandals.
Always wear respirator or face mask when

D

working with unit in dusty environments.
Securehair above shoulder length. Secure or

D

remove jewelry, loose clothing, or clothing
with loosely hanging straps, ties, tassels, etc.
They can be caught in moving parts.
Do not operate unit when you are tired, ill,

D

upset, or if you are under the influence of
alcohol, drugs, or medication.
Keep children, bystanders,and animalsaway

D

fromwork area a minimum of 10 meterswhen
starting or operating unit. Do not point blower
nozzle in the direction of people or pets.

The operator of the
machine must insure
that no one comes
within a 10 meter ra­dius while working.
When several opera­tors are working within
the same area, a safe­ty distance of at least
10 meters must be ob­served.

WARNING!

The blower can throw
objects violently.

--You can be blinded
or injured.

--Always wear eye
protection.

Thrown
objects

HANDLE FUEL WITH CAUTION

Eliminate all sources of sparks or flame

D

(including smoking, open flames, or work that
can cause sparks) in the areas where fuel is
mixed, poured, or stored.
Mix and pour fuel in an outdoor area; store

D

fuel in acool, dry,wellventilated place; usean
approved, marked container for all fuel
purposes.
Do not smoke while handling fuel or while

D

operating the unit.
Makesure the unit is properly assembled and

D

in good operating condition.
Do not fill fuel tank while engine is hot or

D

running.
Avoid spilling fuel or oil. Wipe up fuel spills

D

before starting engine.
Move at least 3 meters away from fuel and

D

fueling site before starting engine.
Always store petrol in a container approved

D

for flammable liquids.

OPERATE YOUR UNIT SAFELY

WARNING:

opening the vacuum inlet door. The engine
must be stopped and the impeller blades no
longer turning to avoid serious injury from the
rotating blades.

Inspect unit before each use for worn, loose,

D

missing, or damaged parts. Do not use until
unit is in proper working order.
Keep outside surfaces free of oil and fuel.

D

Never start or run engine inside a closed

D

room or building. Breathing exhaust fumes
can kill.
To avoid static electricity shock, do not wear

D

rubber gloves or any other insulated gloves
while operating unit.
Donot set unit on any surface except aclean,

D

hard area while engine is running. Debris
such as gravel, sand, dust, grass, etc. could
be picked up by the air intake and thrown out
through discharge opening, damaging unit,
property , or causing serious injury to
bystanders or operator.
Avoiddangerousenvironments.Donot use in

D

unventilated areas or whereexplosive vapors
or carbon monoxide build up could be
present.
Do not overreach or use from unstable

D

surfaces such as ladders, trees, steep
slopes, rooftops, etc. Keep firm footing and
balance at all times.
Never place objects inside the blower tubes;

D

always direct the blowing debris away from
people, animals, glass, andsolid objectssuch

Stop the engine before

as trees, automobiles, walls, etc. The forceof
air can cause rocks, dirt, or sticks to be
thrownorto ricochet whichcan hurt people or
animals, breakglass, or cause otherdamage.
Never run unit without the proper equipment

D

attached. When using your unit as a blower,
always install blower tubes. When using your
unit as a vacuum, always install vacuum
tubes and vacuum bag assembly. Make sure
vacuum bag assembly is completely zipped.
Check air intake opening, blower tubes,

D

vacuum tubes, and elbow tube frequently,
always with engine stopped and spark plug
disconnected. Keep vents and discharge
tubes free of debris which can accumulate
and restrict proper air flow.
Never place any object in the air intake

D

opening as this could restrict proper air flow
and cause damage to the unit.
Neveruse for spreading chemicals, fertilizers,

D

or other substances which may contain toxic
materials.
Toavoid spreadingfire, do not usenear leaf or

D

brush fires, fireplaces, barbecue pits,
ashtrays, etc.
Use only for jobs explained in this manual.

D

MAINTAIN YOUR UNIT PROPERLY

Have all maintenance other than the

D

recommended procedures described in the
instruction manual performed by an
authorized service dealer.
Disconnect spark plug before performing

D

maintenance except for carburetor
adjustments.
Use only recommended Partner

D

replacement parts; use of any other parts
mayvoid your warranty and cause damage to
your unit.
Empty fuel tank before storing the unit. Use

D

upfuelleft in carburetor by starting engineand
letting it run until it stops.
Do not use any accessory or attachment

D

other than those recommended by
manufacturer for use with your unit.
Do not store the unit or fuel in a closed area

D

where fuel vapors can reach sparks or an
open flame from hot water heaters, electric
motors or switches, furnaces, etc.
Store in a dry area out of reach of children.

D

SAFETY NOTICE:

through prolonged use of gasoline powered
hand tools could cause blood vessel or nerve
damage in the fingers, hands, and joints of peo­ple prone to circulation disorders or abnormal
swelling. Prolonged use in cold weather has
been linked to blood vessel damage in other­wisehealthy people. If symptomsoccur suchas
numbness,pain,lossof strength, changein skin
color or texture, or loss of feeling in the fingers,
hands, or joints, discontinue the use of this tool
and seek medical attention. An antivibration
system does not guarantee the avoidance of
theseproblems.Userswhooperate powertools
on a continual and regular basis must monitor
closely their physical conditionand the condition
of this tool.

Exposure to vibrations

!

-- 3 --

10

WHAT IS WHAT?

12

11

2

3

1

9

8

WHAT IS WHAT?

1. Throttle Lever 8. Blower tube

2. Primer button 9. Elbow tube

3. Choke lever 10. Vacuum bag

4. Fuel cap 11. Lower vacuum tube

5. Starter rope 12. Upper vacuum tube

6. Rear handle 13. Instruction manual

7. Spark plug

7

ASSEMBLY

A standard screwdriver is required for as-

CARTON CONTENTS

Check carton contents against the following
list.

Blower

S

Blower tube

S

Upper vacuum tube

S

Lower vacuum tube

S

Elbow tube

S

Vacuum bag

S

NOTE:

in the empty fuel tank.

It is normal for the fuel filter to rattle

ASSEMBLY

WARNING:

the impeller blades have stopped turning be­fore opening the vacuum inlet door or at­tempting to insert or remove the vacuum or
blower tubes. The rotating blades can cause
serious injury. Always disconnect the spark
plug before performing maintenance or ac­cessing movable parts.

WARNING:

repeat all steps to ensure your unit isproperly
assembled and all fasteners are secure. Fol­lowallsafety information in the manual and on
the unit.

Stop engine and be sure

If received assembled,

D

sembly.

BLOWER TUBE ASSEMBLY

1. Align the rib on the blower tube with the

NOTE:

blower tube to be inserted in blower outlet.
Loosen knob by turning counterclockwise.

2. Secure the tube by turning the knob clock-

3. Toremove the tube, turn the knob counter-

VACUUM BAG ASSEMBLY

1. Open the zipper on the vacuum bag and

2. Push the small end of the elbow tube

-- 4 --

4

5

6

13

groove in the blower outlet; slide the tube
into place.

Knob must be loose enough to allow

Blower
Outlet

Groove

wise.
clockwise to loosen the tube; remove the

tube.

insert the elbow tube.
through the small opening in the bag.

Blower
Tube

Rib

Elbow
Tube

Small
Opening

4. Hold the vacuum inlet cover open until up­per vacuum tube is installed.

Vacuum Inlet

Zipper
Opening

NOTE:

ing is flush against the flared area of the el­bow tube, and the rib on the elbow tube is
on the bottom.

3. Close the zipper on the bag. Make sure the

4. Remove blower tube from engine.

5. Insert the elbow tube intothe blower outlet.

6. Turn knob clockwise to secure elbow tube.

Make sure edge of the small open-

zipper is closed completely.

Groove

Make sure elbow tube rib is aligned with
the blower outlet groove.

Rib

Rib

VACUUM TUBE ASSEMBLY

1. Align the lower vacuum tube as shown.
Push lower vacuum tube into upper vacu­um tube.

Upper Vacuum
Tube

Retaining P ost

Vacuum

Inlet

5. Place the hooks of the upper vacuum tube

6. Pivot the tube until it is secured to the

PIVOT

Cover

on the retaining posts of the unit.
blower unit by the vacuum inlet latch.

Inlet Cover

Latch

Hook

Retaining
Post

HOW TO CONVERT UNIT FROM
VACUUM USE TO BLOWER USE

1. Remove the vacuum tubes by inserting
the tip of a screwdriver into the latch area
of the vacuum inlet.

2. Gently tilt handle of screwdriver toward
the back of the unit to release the latch
while pulling up on the upper vacuum tube
with your other hand.

Lower Vacuum Tube

2. Insert the tip of a screwdriver into the latch
area of the vacuum inlet.

Latch

Area

3. Gently tilt the handle of the screwdriver to­ward the back of the unit to release the
latch while pulling up on the v acuum inlet
cover with your other hand.

Blower
Outlet

Latch Area

Vacuum
Inlet Cover

-- 5 --

Latch Area

3. Remove the vacuum bag.

4. Close the vacuum inlet cover and make
sure it is latched closed.

5. Reinstall the blower tube (see BLOWER
TUBE ASSEMBLY).

SHOULDER STRAP ADJUSTMENT
(for vacuum use only)

1. Hold the unit as shown with the muffler
side facing away from your body and clo­thes.

2. Pass the shoulder strap over your head
and onto your right shoulder.

3. Extend your left arm toward the rear of the
vacuum bag.

4. Adjust shoulder strap until the vacuum
bag/shoulder strap seam lies between
your thumb and index finger.

5. Make sure air flows freely from the elbow
tube into bag. If bag is kinked, theunit will not
operate properly.

OPERATION

OPERATING POSITION

Hearing
Protection

Eye
Protection

Blower

OPERATING TIPS

While vacuuming or blowing debris, hold

S

the unit with the muffler s ide facing away
from your body and clothes (see OPERAT­ING POSITION).
To reduce the risk of hearing loss

S

associated with sound level(s), hearing
protection is required.
To reduce the risk of injury associated with

S

contacting rotating parts, stop the engine be­fore installing or removing attachmen ts. Do
not operate without guard(s) in place.
Operate power equipment only at reasonable

S

hours--not early in the morning or late at night
whenpeople might be disturbed. Comply with
times listedin local ordinances. Usual recom­mendations are 9:00 a.m. to 5:00 p.m.,
Monday though Saturday.
To reduce noise levels, limit the number of

S

pieces of equipment used at any one time.
To reduce noise levels, operate power

S

blowers at the lowest possible throttle
speed to do the job.
Use rakes and brooms to loosen debris be-

S

fore blowing.
In dusty conditions, slightly dampen sur-

S

faces or use a mister attachment when wa­ter is available.
Conserve water by using power blowers

S

instead of hoses for many lawn and garden
applications, including areas such as gutters,
screens, patios, grills, porches, and gardens.

Hearing
Protection

Vacuum

-- 6 --

Watchout for children, pets, open windows,

S

or freshly washed cars. Blow debris away
safely.
Use the full blower nozzle extension so the

S

air stream can work close to the ground.
After using blowers and other equipment,

S

CLEAN UP! Dispose of debris in trash re­ceptacles.

BEFORE STARTING ENGINE

WARNING:

information in the safety rules before you
begin. If you do not understand the safety
rules, do not attempt to fuel yourunit. Contact
an authorized service dealer.

Be sure to read the fuel

FUELING ENGINE

WARNING:

when refueling.
This engine is certified to operate on
unleaded petrol. Before operation, petrol
must be mixed with a good quality 2-cycle
air-cooled engine oil. We recommend
Partner!brand oil mixed at a ratio of 40:1
(2.5%). A 40:1 ratio is obtained by mixing 5
liters of unleaded petrol with 0,125 liter of oil.
When mixing fuel, follow the instructions
printed on the container. Always read and
follow the safety rules before fueling your unit.

Remove fuel cap slowly

IMPORTANT

Experience indicates that alcohol blended
fuels (called gasohol or using ethanol or
methanol) can attract moisture which leads to
separation and formation of acids during stor­age. Acidic gas can damage the fuel system
of an engine while in storage. Toavoid engine
problems, empty the fuel system before stor­age for 30 days or longer. Drain the gas tank,
start the engine and let it run until the fuel lines
and carburetor are empty. Use fresh fuel next
season. Never use engine or carburetor
cleaner products in the fuel tank or permanent
damage may occur.

STOPPING YOUR ENGINE

To stop the engine, move the throttle lever

D

to the STOP position.

BEFORE STARTING THE ENGINE

WARNING:

tubes are secure before using the unit.

Fuel engine. Move at least 3 meters away

D

from the fueling site.
Hold the unit in the starting position as

D

shown. Make sure the blower end is di­rected away from people, animals, glass,
and solid objects.

Blower

WARNING:

hold the unit as illustrated. Do not set unit on
any surface except a clean, hard area when
starting engine or while engine is running. De­bris such as gravel, sand, dust, grass, etc.
could be picked up by the air intake and
thrown out through the discharge opening,
damaging theunit or property, or causing seri­ous injury to bystanders or the operator.

YouMUSTmakesurethe

STARTING POSITION

Vacuum

When starting engine,

ST ARTING A COLD ENGINE (or a
warm engine after running out of fuel)

1. Move throttle lever to the position.

2. Move choke lever to the FULL CHOKE
position.

3. Slowly press the primer bulb 8 times.

Throttle Lever

Primer Button

4. Pull starter rope sharply until engine at­tempts to run, but no morethan 5 pulls (be­low 0_C, 8 pulls).

If engine attempts to start before the

NOTE:

th

5

pull, go to next step immediately.

5. Move the choke lever to the HALF
CHOKE position.

6. Pull the starter rope sharply until the en­gine runs, but no more than 5 pulls (below
0_C, 10 pulls).

7. Run engine for 5 seconds, then move
choke lever to the RUN position.

8. Allow the unit to run for 30 more seconds
at the RUN position before moving the

throttle lever to the

If engine has not started after 5pulls (atHALF
CHOKE), repeat STARTING A COLD EN­GINE procedure. If engine still does not start,
proceed to STARTING A FLOODED EN­GINE.

9. Tostop the engine, move the throttle lever
to the STOP position.

position.

STARTING A WARM ENGINE

1. Move throttle lever to the position.

2. Pull starter rope sharply until engine runs
but no more than 5 pulls.

If engine has not started, pull starter

NOTE:

rope 5 more pulls. If engine still does not run,
it is probably flooded.

3. Tostop the engine, move the throttle lever
to the STOP position.

STARTING A FLOODED ENGINE

Flooded engines can be started by placing
the choke lever in the RUN position. Move

throttle lever to the fast position
pull rope until engine starts. After engine
starts, move the throttle lever tothe slowposi-

tion
Starting could require pulling the starter rope

many times depending on how badly the unit is
flooded.

If unit still doesn’t start, refer to the TROUBLE­SHOOTING TABLE or contact an authorized
service dealer.

to allow engine to idle.

; then,

Choke Lever

-- 7 --

MAINTENANCE

WARNING:

unless engine and muffler are cold. A hot
muffler can cause serious burns.

WARNING:

plug before performing maintenance except
for carburetor adjustments.

CHECK FOR LOOSE
FASTENERS AND PARTS

Spark Plug Boot

S

Air Filter

S

Housing Screws

S

CHECK FOR DAMAGED OR
WORN PARTS

Contact an authorized service dealer for re­placement of damaged or worn parts.

Throttle Lever -- Ensure throttle lever func-

S

tions properly bymoving the throttle leverto
the STOP position. Make sure engine
stops; then restart engine and continue.
Fuel Tank. Discontinue use of unit if fuel

S

tank is damaged or leaks.
Vacuum Bag -- Discontinue use of vacuum

S

bag if it is torn or damaged.

INSPECT AND CLEAN UNIT & LABELS

After each use, inspect complete unit for

S

loose or damaged parts. Clean the unit and
decals using adamp cloth with a mild deter­gent.
Wipe off unit with a clean dry cloth.

S

CLEAN AIR FILTER

Avoid touching muffler

Disconnect the spark

create a fire hazard or produce harmful
evaporative emissions.

3. Wash the filter in soap and water.

4. Allow filter to dry.

5. Apply a few drops of oil to the filter;
squeeze filter to distribute oil.

6. Replace parts.

REPLACE SPARK PLUG

Replace spark plug each year to ensure the
engine starts easier and runs better. Set
spark plug gap at 0.025 inch. Ignition timing is
fixed, nonadjustable.

1. Twist, then pull off spark plug boot.

2. Remove spark plug from cylinder and dis­card.

3. Replace with Champion RCJ-6Y spark
plug and tighten securely with a 19 mm
socket wrench.

4. Reinstall the spark plug boot.

REPLACE FUEL FILTER

To replace fuel filter,drain unitby running it dry of
fuel, then remove fuel cap/retainer assembly
fromtank.Pullfilter fromtank andremoveit from
fuelline. Installnewfuel filter onfuel line; reinstall
parts.

Fuel Line

Air Filter
Cover

Air Filter

Screws

Cleaning the air filter:

A dirty air filter decreases engine perform­ance and increases fuel consumption and
harmful emissions. Always clean after every
5 hours of operation or yearly, whichever
comes first.

1. Clean the cover and the area around it to
keep debris from falling into the carburetor
chamber when the cover is removed.

2. Remove parts as illustrated.

NOTE:

other flammable solvent. Doing so can

Do not clean filter in gasoline or

-- 8 --

Fuel Filter

CHECK MUFFLER MOUNTING
SCREWS

Once each year, ensure muffler mounting
screws are secure and tightened properly to
prevent damage.

Mounting
Screw

Muffler Cover

Screws

1. Loosen and remove the 2 screws from the
muffler cover.

2. Remove the muffler cover.

3. Tighten the 2 muffler mounting screws se­curely.

4. Reinstall muffler cover and 2 screws.
Tighten securely.

Holes

INSPECT MUFFLER AND SPARK
ARRESTING SCREEN

As the unit is used, carbon deposits build up
on the muffler and spark arresting screen,
and must be removed to avoid creating a fire
hazard or affecting engine performance.

VIEW OF MUFFLER

Spark arresting
screen

Exhaust
Diverter

Screws

Replace the spark arresting screen every 25
hours of operation orif any damage or breaks
in the screen are noted.

STORAGE

WARNING:

endof season orif it will not be used for 30 days
or more.

Allow engine to cool, and secure the unit be-

S

fore storing or transporting.
Store unit and fuel in a well ventilated area

S

where fuel vapors cannot reach sparks or
open flames from water heaters, electric mo­tors or switches, furnaces, etc.
Storeunitwithall guardsinplace. Positionunit

S

so that any sharp object cannot accidentally
cause injury.
Store unit and fuel well out of thereach of chil-

S

dren.

EXTERNAL SURFACES

If your unit is to be stored for a period of time,

S

clean it thoroughly before storage. Store in a
clean dry area.
Lightly oil external metal surfaces.

S

Prepare unit for storage at

NOTE:

resting screen.

1. Loosen and remove the 2 screws from the

3. Loosen and remove both screws from the

3. Remove the exhaust diverter and spark

4. Install new spark arresting screen.

5. Reinstall exhaust diverter and both

6. Reinstall muffler cover and 2 screws.

NOTE:

broken or damaged, we recommend that the
muffler be replaced.

Donot attempt to clean the spark ar-

muffler cover. Remove the muffler cover.
exhaust diverter.
arresting screen.

screws. Tighten screws securely.

If any part of the muffler is cracked,

CARBURETOR ADJUSTMENT

There is no screw for idle adjustment on your
blower. The throttle lever is used to control
engine speed. The throttle lever can be
placed in one of four positions: STOP, IDLE

or

, FULL THROTTLE or , and one
intermittent position. Ifyourengine will not run
properly or you require further assistance,
contact an authorized service dealer.

INTERNAL ENGINE

Remove spark plug and pour 1 teaspoon of

S

2-cycle engine oil (air cooled) through the
spark plug opening. Slowly pull the starter
rope 8 to 10 times to distribute oil.
Replace spark plug with new one of recom-

S

mended type and heat range.
Clean air filter.

S

Check entire unit for loose screws, nuts, and

S

bolts. Replace any damaged,broken, orworn
parts.
Start each season using only fresh fuel hav-

S

ing the proper gasoline to oil ratio.

OTHER

Do not store gasoline from one season to

S

another.
Replace your gasoline can if it starts to rust.

S

-- 9 --

TROUBLESHOOTING TABLE

e

WARNING:

recommended remedies below other than remedies that require operation of the unit.

Always stop unit and disconnect spark plug before performing any of th

TROUBLE CAUSE REMEDY

Engine will not
start.

Engine will not
idle properly.

Engine will not
accelerate,
lacks power, or
dies under a
load.

Engine
smokes
excessively.

Engine
runs hot.

1.Engine flooded.

2.Fuel tank empty.

3.Spark plug not firing.

4.Fuel not reaching carburetor.

5.Compression low.

1.Fuel not reaching carburetor.

2.Carburetor requires adjustment.

3.Crankshaft seals worn.

4.Compression low.

1.Air filter dirty.

2.Fuel not reaching carburetor.

3.Spark plug fouled.

4.Spark arresting screen clogged.

5.Carburetor requires adjustment.

6.Carbon build up.

7.Compression low.

1.Choke partially on.

2.Fuel mixture incorrect.

3.Air filter dirty.

4.Carburetor requires adjustment.

1.Fuel mixture incorrect.

2.Spark plug incorrect.

3.Carburetor requires adjustment.

4.Carbon build up.

1.See “Starting Instructions.”

2.Fill tank with correct fuel mixture.

3.Install new spark plug.

4.Check for dirty fuel filter; replace.
Check for kinked or split fuel line;
repair or replace.

5.Contact an authorized service dealer.

1.Check for dirty fuel filter; replace.

Check for kinked or split fuel line;
repair or replace.

2.Contact an authorized service dealer.

3.Contact an authorized service dealer.

4.Contact an authorized service dealer.

1.Clean or replace air filter.

2.Check for dirty fuel filter; replace.

Check for kinked or split fuel line;
repair or replace.

3.Clean or replace spark plug; re-gap.

4.Replace screen.

5.Contact an authorized service dealer.

6.Contact an authorized service dealer.

7.Contact an authorized service dealer.

1.Adjust choke.

2.Empty fuel tank and refill with

correct fuel mixture.

3.Clean or replace air filter.

4.Contact an authorized service dealer.

1.See “Fueling Your Unit.”

2.Replace with correct spark plug.

3.Contact an authorized service dealer.

4.Contact an authorized service dealer.

DECLARATION OF CONFORMITY

relating to 2000/14/EC

EU Declaration of Conformity relating to 2000/14/EC

We, Poulan/Weed Eater Division, Electrolux Home Products, Inc., Texarkana, TX,
75501, USA, Tél. : [phone], declare under sole responsibility that the Partner
model BV24 leaf blower was assessed in accordance with Annex V of the DIRECTIVE
and from serial numbers 2002--137N00001 and onwards, conforms to the provisions of the
DIRECTIVE. The nominal air flow is 0,142 m
and the guaranteed sound power is 112 dB.

Texarkana 02--05--17

3

/s. The measured sound power is 107 dB

Michael S. Bounds, Director
Product Safety and Standards

-- 10 --

DECLARATION OF CONFORMITY

relating to 98/37/EC

EU Declaration ofConformity (Directive 98/37/EC, Annex II, A) (Only applies to Europe)
We, Poulan/Weed Eater Division, Electrolux Home Products, Inc, Texarkana, TX,

75501, USA, Tel: [phone], declare under sole responsibility that the Partner
model BV24 leaf blower from serial numbers 2002--137N00001 and onwards, follows the
provisions of the DIRECTIVES: 98/37/EC (machinery) and 89/336/EEC (electromagnetic
compatibility), including amendments and is in conformity with the following standards: EN

292--2 and CISPR 12.
SMP,The Swedish Machinery Testing Institute, Fyrisborgsgatan 3 S--754 50 Uppsala,

Sweden, has carried out voluntary type approval. The certificate(s) are numbered:
SEC/97/475.

Texarkana 02--05--17

Michael S. Bounds, Director
Safety and Standards

TECHNICAL DATA

MODEL: BV24

ENGINE

Engine displacement 25 cm
Maximum Engine Power, according to ISO 8893 0,71 kW
Rotational Speeds
Idle Speed +/-- 400 3700 rpm
Maximum recommended output shaft speed 8400 rpm
Engine speed at maximum recommended output shaft speed 8400 rpm

MASS

BLOWER 4,8 kg
VACUUM 5,5 kg

VOLUME

Fuel tank 360 cm

SOUND PRESSURE LEVEL

According to prEN 31806
BLOWER
Idling: 80,9 dB(A)
Racing 95,2 dB(A)
VACUUM
Idling: 89,6 dB(A)
Racing 100,0 dB(A)

SOUND POWER LEVEL

According to ISO/CD 10884
BLOWER: 106 dB(A)
VACUUM: 107 dB(A)

VIBRATIONS

According to ISO 7916
BLOWER
Idling: Top 12,1 m/s
Racing: Top 16,0 m/s
VACUUM
Idling: Top 10,9 m/s
Racing: Top 16,6 m/s

3

3

2
2

2
2

YEAR OF CONSTRUCTION: 2003
MANUFACTURER’S ADDRESS: Electrolux Home Products, Inc.

250 Bobby Jones Expressway
Augusta, GA 30907

-- 11 --
