CK3500
Upgrade procedure for the
Parrot CK3100, CK3300, CK3500
This document will help you in order to upgrade your
Hands-free car kit via Bluetooth. Car kit upgrades are
needed to improve the compatibility of your Parrot device,
by allowing you to use more phones with your kit. It can
also allow you to get new functionalities.
You will find hereunder two different possibilities to upgrade
the Parrot CK3100 via Bluetooth.
Software upgrades remove paired phones, synchronized
contacts and voice tags.
1 Downloading the upgrade files...................................................................................... 1
2 Upgrading the Parrot CK3100....................................................................................... 3
2.1 By serial cable........................................................................................................... 3
2.2 By Bluetooth (Method A) ........................................................................................... 5
2.2.1 Using stack Toshiba......................................................................................... 5
2.2.2 Using stack Broadcom and Microsoft................................................................ 9
2.3 By Bluetooth (Method B).............................................................................................12
1 Downloading the upgrade files
Before you begin:
1. Start the Parrot Software Update Tool program.
► The following dialog box is displayed.
Download and install the
program available on our web site www.parrot.com then
choose SUPPORT and DOWNLOAD.
Parrot Software Update Tool
2. Click Next.
1
► The following dialog box is displayed.
3. Select Car kits and click Next.
► The following dialog box is displayed.
4. Select the Parrot CK3100 in the list and click Next.
► The following dialog box is displayed.
5. Click on Download Latest version.
► The Download Software Update dialog box is displayed.
2
6. Select your language.
7. Click on Download Now and wait until the end of the download
.
► The downloaded files will be stored in C:\Program Files\ Parrot Software Update
Tool\Internet Files.
2 Upgrading the Parrot CK3100
There are three methods to upgrade your Parrot CK3100: one by serial cable (§2.1) and two by
Bluetooth (§2.2 and 2.3)
2.1 By serial cable
Before you begin:
.
• Download the upgrade you wish to install.
• Connect your computer to your carkit via the serial cable.
•
Keep the Parrot CK3100 off.
1. Start the Parrot Software Update Tool and click Next.
2. Choose the Parrot CK3100 and click Next.
3. Get the previously downloaded files by clicking on Browse and click Next.
4. Select Serial connection and click Next.
3
5. Select the COM port on which you have connected the serial cable and click Next.
6. When the Parrot Software Update Tool reaches the “XPRAM downloading” step, plug in
the car kit’s power supply.
7. Wait until the end of the upgrade process and click on Finish.
► You can now disconnect your car kit from the computer.
► Your Parrot CK3100 is now up-to-date.
4
