Paradyne CSU, 9126, 9126-II, 9128-II, DSU User Manual

0 (0)

FrameSaver® SLV

9126, 9126-II, and 9128-II CSU/DSU,

and 9126-II Router

User’s Guide

Document No. 9128-A2-GB20-80

September 2002

Copyright © 2002 Paradyne Corporation.

All rights reserved.

Printed in U.S.A.

Notice

This publication is protected by federal copyright law. No part of this publication may be copied or distributed, transmitted, transcribed, stored in a retrieval system, or translated into any human or computer language in any form or by any means, electronic, mechanical, magnetic, manual or otherwise, or disclosed to third parties without the express written permission of Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773.

Paradyne Corporation makes no representation or warranties with respect to the contents hereof and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. Further, Paradyne Corporation reserves the right to revise this publication and to make changes from time to time in the contents hereof without obligation of Paradyne Corporation to notify any person of such revision or changes.

Changes and enhancements to the product and to the information herein will be documented and issued as a new release to this manual.

Warranty, Sales, Service, and Training Information

Contact your local sales representative, service representative, or distributor directly for any help needed. For additional information concerning warranty, sales, service, repair, installation, documentation, training, distributor locations, or Paradyne worldwide office locations, use one of the following methods:

TInternet: Visit the Paradyne World Wide Web site at www.paradyne.com. (Be sure to register your warranty at www.paradyne.com/warranty.)

TTelephone: Call our automated system to receive current information by fax or to speak with a company representative.

Within the U.S.A., call 1-800-870-2221

Outside the U.S.A., call 1-727-530-2340

Document Feedback

We welcome your comments and suggestions about this document. Please mail them to Technical Publications, Paradyne Corporation, 8545 126th Ave. N., Largo, FL 33773, or send e-mail to userdoc@paradyne.com. Include the number and title of this document in your correspondence. Please include your name and phone number if you are willing to provide additional clarification.

Trademarks

ACCULINK, COMSPHERE, FrameSaver, Hotwire, MVL, NextEDGE, OpenLane, and Performance Wizard are registered trademarks of Paradyne Corporation. GranDSLAM, GrandVIEW, ReachDSL, and TruePut are trademarks of Paradyne Corporation. All other products and services mentioned herein are the trademarks, service marks, registered trademarks, or registered service marks of their respective owners.

Patent Notification

FrameSaver products are protected by U.S. Patents: 5,550,700 and 5,654,966. Other patents are pending.

A

September 2002

9128-A2-GB20-80

Contents

About This Guide

T Purpose and Intended Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

T Document Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi

T Product-Related Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii

T Conventions Used . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiv

1 About the FrameSaver SLV

T

System Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1



CSU/DSU-Specific Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-2



Router-Specific Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-2

T FrameSaver Diagnostic and SLM Feature Sets. . . . . . . . . . . . . . . . . .

1-4

T

FrameSaver Diagnostic Feature Set . . . . . . . . . . . . . . . . . . . . . . . . . .

1-5



Additional FrameSaver SLV9126-II and 9128-II Features. . . . . . .

1-9



Additional FrameSaver SLV 9128-II Features . . . . . . . . . . . . . . . .

1-9

T

FrameSaver SLM Feature Set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-10

T

OpenLane SLM System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-11

T NetScout Manager Plus and NetScout Probes . . . . . . . . . . . . . . . . . .

1-12

2 User Interface and Basic Operation

T

Logging On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-2

T

Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-4

T

Screen Work Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-5

T

Navigating the Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-6



Keyboard Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-6



Function Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-7



Selecting from a Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-8



Switching Between Screen Areas . . . . . . . . . . . . . . . . . . . . . . . . .

2-8



Selecting a Field . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-9



Entering Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-9



Screen Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-9

T Navigating the Router’s CLI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-10



CLI Keyboard Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

2-10

9128-A2-GB20-80

September 2002

i

Contents

3 Configuration Procedures



T Basic Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-1

Configuration Option Areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-3

Accessing and Displaying Configuration Options . . . . . . . . . . . . .

3-4

Changing Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . .

3-5

Saving Configuration Options . . . . . . . . . . . . . . . . . . . . . . . . . . . .

3-6

4 Configuration Options

T Using the Easy Install Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-3

T Using RIP with FrameSaver SLV CSU/DSUs . . . . . . . . . . . . . . . . . . .

4-4

T Entering System Information and Setting the System Clock . . . . . . . .

4-5

T Setting Up the Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-6



Setting Up Call Directories for Trap Dial-Out. . . . . . . . . . . . . . . . .

4-6



Setting Up to Use the Modem PassThru Feature . . . . . . . . . . . . .

4-7

T

Setting Up Auto-Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-8



Selecting a Frame Relay Discovery Mode. . . . . . . . . . . . . . . . . . .

4-9



Automatically Removing a Circuit . . . . . . . . . . . . . . . . . . . . . . . . .

4-11

T Setting Up Dial Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-12



Setting Up the DBM Physical Interface . . . . . . . . . . . . . . . . . . . . .

4-12



Setting Up Automatic Backup Configuration . . . . . . . . . . . . . . . . .

4-13



Modifying ISDN Link Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-16



Restricting Automatic Backup and Configuring Backup Timers . .

4-17



Configuring the DBM Interface to Send SNMP Traps . . . . . . . . . .

4-18



Assigning DLCIs to a Backup Group . . . . . . . . . . . . . . . . . . . . . . .

4-18

T PVC Backup Over the Network Interface. . . . . . . . . . . . . . . . . . . . . . .

4-19

T Setting Up Back-to-Back Operation . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-19



Changing Operating Mode. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-19

T

Configuration Option Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-20

T

Configuring the Overall System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-21



Configuring Frame Relay and LMI for the System (CSU/DSUs) . .

4-21



Configuring Class of Service Definitions . . . . . . . . . . . . . . . . . . . .

4-25



Code Point Definitions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-27



Configuring Service Level Verification Options . . . . . . . . . . . . . . .

4-28



Configuring General System Options . . . . . . . . . . . . . . . . . . . . . .

4-31

T

Configuring Physical Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-34



Configuring the Network Interface . . . . . . . . . . . . . . . . . . . . . . . . .

4-34



Configuring a User Data Port (CSU/DSUs) . . . . . . . . . . . . . . . . . .

4-38



Configuring the DSX-1 Interface . . . . . . . . . . . . . . . . . . . . . . . . . .

4-43



Configuring the ISDN DBM Interface. . . . . . . . . . . . . . . . . . . . . . .

4-45



Setting Up ISDN Link Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-49

ii

September 2002

9128-A2-GB20-80

Contents

T Assigning Time Slots/Cross Connections . . . . . . . . . . . . . . . . . . . . . .

4-51

Assigning Frame Relay Time Slots to the Network Interface . . . .

4-52

Assigning DSX-1 Time Slots to the Network Interface . . . . . . . . .

4-53

Assigning a Synchronous Data Port to Network or DSX-1



Time Slots . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-59

Clearing Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-60

T Configuring Frame Relay for an Interface . . . . . . . . . . . . . . . . . . . . . .

4-61

T Manually Configuring DLCI Records . . . . . . . . . . . . . . . . . . . . . . . . . .

4-64

T Configuring PVC Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-68

T Configuring the IP Path List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-72

T Setting Up Management and Communication Options . . . . . . . . . . . .

4-73

Configuring Node IP Information . . . . . . . . . . . . . . . . . . . . . . . . . .

4-74

Configuring Management PVCs . . . . . . . . . . . . . . . . . . . . . . . . . .

4-77

Configuring General SNMP Management . . . . . . . . . . . . . . . . . . .

4-83

Configuring Telnet and/or FTP Session Support . . . . . . . . . . . . . .

4-84

Configuring SNMP NMS Security . . . . . . . . . . . . . . . . . . . . . . . . .

4-87

Configuring SNMP Traps and Trap Dial-Out . . . . . . . . . . . . . . . . .

4-88

Configuring Ethernet Management . . . . . . . . . . . . . . . . . . . . . . . .

4-94

Configuring the Communication Port. . . . . . . . . . . . . . . . . . . . . . .

4-96

Configuring the Modem Port . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

4-100

T Configuring the Criteria for Automatic Backup . . . . . . . . . . . . . . . . . . .

4-104

5 Configuring the FrameSaver SLV Router

T

FrameSaver SLV Router Overview . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-2

T

IP Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-3

T

Address Resolution Protocol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-3

T

Proxy ARP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-3

T

Interface Configuration. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-4

T

Network Address Translation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-5



IP Options Processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-5



Applications Supported by NAT. . . . . . . . . . . . . . . . . . . . . . . . . . .

5-5



NAT Configuration Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-6

T Network Address Port Translation . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-8



NAPT Configuration Example . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-8



NAT and NAPT Configuration Example. . . . . . . . . . . . . . . . . . . . .

5-10

T Dynamic Host Configuration Protocol Server. . . . . . . . . . . . . . . . . . . .

5-11



DHCP Server with NAT Configuration Example . . . . . . . . . . . . . .

5-12



DHCP Server at Remote Site Configuration Example. . . . . . . . . .

5-13

T

DHCP Relay Agent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-13

9128-A2-GB20-80

September 2002

iii

Contents



T

Router Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-14





IP Router Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-14





Bridge Filtering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-14





IP Filtering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-15





Land Bug Prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-15





Smurf Attack Prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-15



T Provisioning the Router Interface. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

5-15



T Configuring the Router Using Terminal Emulation. . . . . . . . . . . . . . . .

5-16





Uploading and Downloading the Router Configuration Via the CLI

5-16

6

Security and Logins





T

Limiting Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-2



T

Controlling Asynchronous Terminal Access. . . . . . . . . . . . . . . . . . . . .

6-2



T Limiting Dial-In Access via the Modem Port. . . . . . . . . . . . . . . . . . . . .

6-4



T

Controlling ISDN Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-5





ISDN Call Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-5





Disabling ISDN Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-5



T Controlling Telnet or FTP Access . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-6





Limiting Telnet Access. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-6





Limiting FTP Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-7





Limiting Telnet or FTP Access Over the TS Access Management







Link . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-8



T

Controlling SNMP Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-9





Disabling SNMP Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-9





Assigning SNMP Community Names and Access Levels . . . . . . .

6-10





Limiting SNMP Access Through IP Addresses . . . . . . . . . . . . . . .

6-11



T

Creating a Login. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-12



T

Modifying a Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-13



T

Deleting a Login . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-13



T

Controlling Router CLI Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-14





Access Levels (Command Modes) . . . . . . . . . . . . . . . . . . . . . . . .

6-14





Changing Access Levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

6-15

7

Operation and Maintenance





T

Displaying System Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7-3



T Viewing LEDs and Control Leads . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7-4





FrameSaver SLV 9126 LEDs and Control Leads . . . . . . . . . . . . .

7-5





FrameSaver SLV 9128-II LEDs and Control Leads. . . . . . . . . . . .

7-7





LED Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7-8





Control Lead Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7-11



T

Device Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

7-12

iv

September 2002

9128-A2-GB20-80

Contents

T Status Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-18

System and Test Status Messages . . . . . . . . . . . . . . . . . . . . . . . . 7-19

Network LMI-Reported DLCIs Status . . . . . . . . . . . . . . . . . . . . . . 7-29

IP Path Connection Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-31

PVC Connection Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-33

Time Slot Assignment Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-36

DBM Interface Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-38

T IP Routing Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-48

T Performance Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-50 Clearing Performance Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . 7-51 Service Level Verification Performance Statistics . . . . . . . . . . . . . 7-52 DLCI Performance Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-57 Additional Performance Statistics for IP Enabled DLCI . . . . . . . . . 7-59 Frame Relay Performance Statistics . . . . . . . . . . . . . . . . . . . . . . . 7-60 ESF Line Performance Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . 7-64 DBM Call Performance Statistics. . . . . . . . . . . . . . . . . . . . . . . . . . 7-67 Ethernet Performance Statistics . . . . . . . . . . . . . . . . . . . . . . . . . . 7-68

T Trap Event Log. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-69

T Modem Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-70 Activating the Modem PassThru Feature . . . . . . . . . . . . . . . . . . . 7-70 Canceling Modem PassThru Operation. . . . . . . . . . . . . . . . . . . . . 7-70 Manually Disconnecting the Modem . . . . . . . . . . . . . . . . . . . . . . . 7-71 Verifying Modem Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-71

T ISDN DBM Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-72 Forcing Backup (Disruptive) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-72 Placing a Test Call (Nondisruptive) . . . . . . . . . . . . . . . . . . . . . . . . 7-73 Verifying ISDN Lines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-74 Verifying That Backup Can Take Place . . . . . . . . . . . . . . . . . . . . . 7-74

T FTP File Transfers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-75

Upgrading System Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-77

Upgrading ISDN BRI DBM Software . . . . . . . . . . . . . . . . . . . . . . . 7-78

Determining Whether a Download Is Completed. . . . . . . . . . . . . . 7-79

Changing Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-79

Transferring Collected Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-80

T Turning Off the System Alarm Relay . . . . . . . . . . . . . . . . . . . . . . . . . . 7-81

8 Troubleshooting

T Problem Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-2

T Resetting the Unit and Restoring Communication . . . . . . . . . . . . . . . . 8-3

Resetting the Unit from the Control Menu . . . . . . . . . . . . . . . . . . . 8-3

Resetting the Unit By Cycling the Power . . . . . . . . . . . . . . . . . . . . 8-3

Restoring Communication with an Improperly Configured Unit . . . 8-4

9128-A2-GB20-80

September 2002

v

Contents

T Troubleshooting Management Link Feature . . . . . . . . . . . . . . . . . . . . 8-5

T LMI Packet Capture Utility Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-5 Viewing Captured Packets from the Menu-Driven User Interface . 8-6

T Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-7

T Viewing the Trap Event Log . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14

T Troubleshooting Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14

Device Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-14

Frame Relay PVC Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-16

ISDN DBM Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-17

T Tests Available. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-18

Test Timeout Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-19

DBM Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-19

T Starting and Stopping a Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-20 Aborting All Tests. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-21

T PVC Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-22

PVC Loopback. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-23

Send Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-24

Monitor Pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-24

Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-25

Test Call. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-25

T Physical Tests . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-26 Line Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-27 Payload Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-28 Repeater Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-29 DTE Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-30 Send Line Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-31 Data Channel Loopbacks on a Frame Relay Link . . . . . . . . . . . . . 8-32 Send Remote Line Loopback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-33 Send and Monitor Pattern Tests . . . . . . . . . . . . . . . . . . . . . . . . . . 8-34

T IP Ping Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-35 IP Ping Test – Procedure 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-39 IP Ping Test – Procedure 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-40

T Lamp Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8-40

9Setting Up OpenLane for FrameSaver Devices and Activating SLM Features

T OpenLane Support of FrameSaver Devices . . . . . . . . . . . . . . . . . . . . 9-2

T Setting Up the OpenLane SLM System . . . . . . . . . . . . . . . . . . . . . . . . 9-2

T Setting Up FrameSaver Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-3

T Ordering SLM Feature Set Activations. . . . . . . . . . . . . . . . . . . . . . . . . 9-4 To Find Your License Key Number . . . . . . . . . . . . . . . . . . . . . . . . 9-4 The Activation Certificate. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-5

vi

September 2002

9128-A2-GB20-80

Contents

T Administering and Managing SLM Activations . . . . . . . . . . . . . . . . . . .

9-6

Entering an Activation Certificate. . . . . . . . . . . . . . . . . . . . . . . . . .

9-7

Checking Activation Certificate Status. . . . . . . . . . . . . . . . . . . . . .

9-7

Scheduling Activations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

9-8

Checking the Status of Scheduled Activations . . . . . . . . . . . . . . .

9-9

Canceling Scheduled Activations . . . . . . . . . . . . . . . . . . . . . . . . .

9-9

Accessing and Printing the Certificate Summary Report. . . . . . . .

9-9

10 Setting Up NetScout Manager Plus for FrameSaver Devices

T

Preparation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-2

T Configuring NetScout Manager Plus . . . . . . . . . . . . . . . . . . . . . . . . . .

10-3



Adding FrameSaver SLV Units to the NetScout Manager Plus





Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-4



Verifying Domains and Groups . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-5



Correcting Domains and Groups . . . . . . . . . . . . . . . . . . . . . . . . . .

10-6



Adding SLV Alarms Using a Template . . . . . . . . . . . . . . . . . . . . .

10-8



Editing Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-9



Adding SLV Alarms Manually . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-11



Creating History Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-13



Installing the User-Defined History Files . . . . . . . . . . . . . . . . . . . .

10-15

T Monitoring a DLCI’s History Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-16

T Monitoring the Agent Using NetScout Manager Plus . . . . . . . . . . . . . .

10-18

T

Statistical Windows Supported. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

10-20

11 Setting Up Network Health for FrameSaver Devices

T Installation and Setup of Network Health . . . . . . . . . . . . . . . . . . . . . . .

11-2

T

Discovering FrameSaver Elements . . . . . . . . . . . . . . . . . . . . . . . . . . .

11-3

T Configuring the Discovered Elements . . . . . . . . . . . . . . . . . . . . . . . . .

11-4

T

Grouping Elements for Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11-5

T Generating Reports for a Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11-6



About Service Level Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11-6



About At-a-Glance Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11-6



About Trend Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11-7



Printed Reports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

11-7

T Reports Applicable to SLV Devices . . . . . . . . . . . . . . . . . . . . . . . . . . .

11-7

A Menu Hierarchy

T Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A-1

9128-A2-GB20-80

September 2002

vii

Contents

B SNMP MIBs and Traps, and RMON Alarm Defaults

T

MIB Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-2

T Downloading MIBs and SNMP Traps. . . . . . . . . . . . . . . . . . . . . . . . . .

B-2

T

System Group (mib-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-3



FrameSaver Unit’s sysDescr (system 1) . . . . . . . . . . . . . . . . . . . .

B-3



FrameSaver Unit’s sysObjectID (system 2). . . . . . . . . . . . . . . . . .

B-3

T

Interfaces Group (mib-2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-3



Paradyne Indexes to the Interface Table (ifTable). . . . . . . . . . . . .

B-3



NetScout Indexes to the Interface Table (ifTable) . . . . . . . . . . . . .

B-6

T Standards Compliance for SNMP Traps . . . . . . . . . . . . . . . . . . . . . . .

B-8



Trap: warmStart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-9



Trap: authenticationFailure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-9



Traps: linkUp and linkDown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-10



Traps: enterprise-Specific . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-13



Traps: RMON-Specific . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-16



Trap: dialControl . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-17

T RMON Alarm and Event Defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . .

B-18



Physical Interface Alarm Defaults . . . . . . . . . . . . . . . . . . . . . . . . .

B-19



Frame Relay Link Alarm Defaults . . . . . . . . . . . . . . . . . . . . . . . . .

B-20



DLCI Alarm Defaults – Paradyne Area . . . . . . . . . . . . . . . . . . . . .

B-22



DLCI Alarm Defaults – NetScout Area. . . . . . . . . . . . . . . . . . . . . .

B-23

T Object ID Cross-References (Numeric Order) . . . . . . . . . . . . . . . . . . .

B-26

C Router CLI Commands, Codes, and Designations

T

CLI Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-1



Pager Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-3



Access Control Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-3



Configuration Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-4



Interface Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-5



IP Routing Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-8



Bridge Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-9



ARP Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-11



NAT Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-12



DHCP Server Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-15



DHCP Relay Agent Commands. . . . . . . . . . . . . . . . . . . . . . . . . . .

C-18



Filter (access-list) Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-19



Diagnostic Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-23



Show Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-25

T

Ethernet Type Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

C-29

viii

September 2002

9128-A2-GB20-80

Contents

T Protocol and Port Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-31

ICMP Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-31

TCP Port Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-33

UDP Port Designations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-34

D Router Command Line Summaries and Shortcuts

T CLI Summaries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1

Show Command Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-2

Access Control and System Level Command Summary . . . . . . . . D-3

CLI Command Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-4

CLI Command Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . D-6

E Connectors, Cables, and Pin Assignments

T Rear Panels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-1

T COM Port Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-4 COM Port for 9126 and 9128-II (25-Position) . . . . . . . . . . . . . . . . E-4 COM Port for 9126-II (9-Position) . . . . . . . . . . . . . . . . . . . . . . . . . E-4 COM Port for 9128-II Carrier Mount . . . . . . . . . . . . . . . . . . . . . . . E-5 COM Port-to-PC Cable (Feature No. 3100-F2-550) . . . . . . . . . . . E-5 COM Port-to-Terminal/Printer Cable (Feature No. 3100-F2-540) . E-6 COM Port-to-Router Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-7 Gender Adapter/Changer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-10 LAN Adapter Converter and Cable . . . . . . . . . . . . . . . . . . . . . . . . E-10

T DTE Port Connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-11

Standard V.35 Straight-through Cable. . . . . . . . . . . . . . . . . . . . . . E-12

Standard V.35 Crossover Cable . . . . . . . . . . . . . . . . . . . . . . . . . . E-12

T DSX-1 Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-13

DSX-1 Port for 9126, 9126-II, and Carrier Mounted 9128-II

(8-Position) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-13 DSX-1 Adapter (Feature No. 9008-F1-560). . . . . . . . . . . . . . . . . . E-13 DSX-1 Port for 1-Slot 9128-II (15-Position) . . . . . . . . . . . . . . . . . . E-14

T T1 Network Cable (Feature No. 3100-F1-500) . . . . . . . . . . . . . . . . . . E-15 T1 Mass Termination Cable (Feature No. 9007-F1-500). . . . . . . . E-15 Canadian T1 Line Interface Cable (Feature No. 3100-F1-510) . . . E-16

T Ethernet Port Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-16

T Modem Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-17

T ISDN DBM Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-17

ISDN Modular Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . E-17

9128-A2-GB20-80

September 2002

ix

Contents

FTechnical Specifications

GEquipment List

T

Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

G-1

T

Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

G-6

Index

x

September 2002

9128-A2-GB20-80

About This Guide

Purpose and Intended Audience

This document contains information needed to properly set up, configure, and verify operation of the FrameSaver SLV (Service Level Verifier) 9126, 9126-II, and 9128-II CSU/DSU, and 9126-II Router running firmware release 2.0.3 or above. It is intended for system designers, engineers, administrators, and operators.

You must be familiar with the functional operation of digital data communications equipment and frame relay networks.

Document Organization

Section

Description





Chapter 1, About the FrameSaver

Identifies how the FrameSaver SLV 9126, 9126-II,

SLV

and 9128-II CSU/DSU, and 9126-II Router, fit into



Paradyne’s Service Level Management (SLM)



solution, and describes their features.





Chapter 2, User Interface and

Shows how to navigate the menu-driven user

Basic Operation

interface.





Chapter 3, Configuration

Shows how to access and save configuration options.

Procedures







Chapter 4, Configuration Options

Provides configuration information for the



FrameSaver SLV 9126, 9126-II, and 9128-II



CSU/DSU, and 9126-II Router.





Chapter 5, Configuring the

Describes the router’s interfaces and features, and

FrameSaver SLV Router

shows typical setups and configurations.





Chapter 6, Security and Logins

Provides procedures for controlling access to the



FrameSaver SLV and setting up logins.





Chapter 7, Operation and

Provides procedures to display unit identification

Maintenance

information and perform file transfers, as well as how



to display and interpret status and statistical



information.





Chapter 8, Troubleshooting

Provides device problem resolution, alarm, and other



information, as well as troubleshooting and test



procedures.





9128-A2-GB20-80

September 2002

xi

About This Guide

Section

Description





Chapter 9, Setting Up OpenLane

Identifies where installation and setup information is

for FrameSaver Devices and

located and how FrameSaver units are supported.

Activating SLM Features







Chapter 10, Setting Up NetScout

Describes setup of the NetScout Manager Plus

Manager Plus for FrameSaver

application so it supports FrameSaver units, and so

Devices

you can change alarm and history file defaults.





Chapter 11, Setting Up Network

Describes setup of Concord’s Network Health

Health for FrameSaver Devices

application so reports can be created for FrameSaver



units, and identifies those reports that apply to



FrameSaver units.





Appendix A, Menu Hierarchy

Contains a graphical representation of how the user



interface screens are organized.





Appendix B, SNMP MIBs and

Identifies the MIBs supported and how they can be

Traps, and RMON Alarm Defaults

downloaded, describes the unit’s compliance with



SNMP format standards and with its special



operational trap features, and describes the



RMON-specific user history groups, and alarm and



event defaults.





Appendix C, Router CLI

Describes the configuration options available for the

Commands, Codes, and

router, and the minimum access level for each

Designations

command.





Appendix D, Router Command

Provides a summary of router CLI commands,

Line Summaries and Shortcuts

showing syntax and defaults.





Appendix E, Connectors, Cables,

Shows the rear panel, tells what cables are needed,

and Pin Assignments

and provides pin assignments for interfaces and



cables.





Appendix F, Technical

Technical Specifications.

Specifications







Appendix G, Equipment List

Equipment List.





Index

Lists key terms, acronyms, concepts, and sections.





A master glossary of terms and acronyms used in Paradyne documents is available on the World Wide Web at www.paradyne.com. Select Library Technical Manuals Technical Glossary.

xii

September 2002

9128-A2-GB20-80

Paradyne CSU, 9126, 9126-II, 9128-II, DSU User Manual

About This Guide

Product-Related Documents

Document



Number

Document Title

Paradyne FrameSaver Documentation:

9000-A2-GN19 FrameSaver SLV ISDN Installation Instructions

9000-A2-GN1D 9000 Series Access Carrier Installation Instructions

9126-A2-GL10 FrameSaver SLV 9126 and 9126-II Quick Reference

9126-A2-GL12 FrameSaver SLV 9126-II Router Quick Reference

9126-A2-GN10 FrameSaver SLV 9126 1-Slot Unit Installation Instructions

9126-A2-GN11 FrameSaver SLV 9126-II 1-Slot Unit Installation Instructions

9126-A2-GN12 FrameSaver SLV 9126-II Router Installation Instructions

9128-A2-GL10 FrameSaver SLV 9128/9128-II Quick Reference

9128-A2-GN10 FrameSaver SLV 9128 1-Slot Housing-to-9000 Series Access Carrier Upgrade Instructions

9128-A2-GN11 FrameSaver SLV 9128/9128-II Network Access Module (NAM)

Installation Instructions

9128-A2-GN12 FrameSaver SLV 9128/9128-II 1-Slot Unit Installation Instructions

Paradyne OpenLane NMS Documentation:

7800-A2-GB30 OpenLane SLM Reports Reference Guide

7800-A2-GB32 OpenLane SLM Administrator’s Guide

NetScout Documentation:

2930-170

NetScout Probe User Guide





2930-610

NetScout Manager/Plus User Guide





2930-620

NetScout Manager/Plus & NetScout Server Administrator Guide





2930-788

NetScout Manager Plus Set Up & Installation Guide





Concord Communications Documentation:

09-10010-005 Network Health User Guide

09-10020-005 Network Health Installation Guide

09-10050-002

Network Health – Traffic Accountant Reports Guide

09-10070-001 Network Health Reports Guide

Complete Paradyne documentation for this product is available at

www.paradyne.com. Select Library Technical Manuals.

To order a paper copy of this manual:

TWithin the U.S.A., call 1-800-PARADYNE (1-800-727-2396)

TOutside the U.S.A., call 1-727-530-8623

9128-A2-GB20-80

September 2002

xiii

About This Guide

Conventions Used

Convention Used

When Used





Italic

To indicate variable information (for example, DLCI nnnn,



where nnnn denotes a 4-digit number).





Menu sequence:

To provide an abbreviated method for indicating the



selections to be made from a menu or selections from within



a menu before performing a procedural step.



For example,



Main Menu Status System and Test Status indicates



that you should select Status from the Main Menu, then



select System and Test Status.





(Path:)

To provide a check point that coincides with the menu path



shown at the top of the screen. Always shown within



parentheses so you can verify that you are referencing the



correct table (e.g., Path: main/config/alarm).





Brackets [ ]

To indicate multiple selection choices when more than one



selection is available (e.g., Performance



StatisticsStatus[Network/Port-1]).





Text highlighted in blue

To indicate a hyperlink to additional information when viewing



this manual online. Click on the highlighted text.





xiv

September 2002

9128-A2-GB20-80

About the FrameSaver SLV

1

This chapter includes the following:

TSystem Overview, below

TFrameSaver Diagnostic and SLM Feature Sets on page 1-4

TFrameSaver Diagnostic Feature Set on page 1-5

TFrameSaver SLM Feature Set on page 1-10

TOpenLane SLM System on page 1-11

TNetScout Manager Plus and NetScout Probes on page 1-12

System Overview

Our system solution consists of:

TFrameSaver® SLV (Service Level Verifier) units

TOpenLane® SLM (Service Level Management) system

TNetScout Manager Plus application

TStandalone NetScout Probes, if needed

This solution provides increased manageability, monitoring, and diagnostics so customers can identify problems more efficiently, troubleshoot those problems faster, and maximize their network to control costs. It is also compatible with Concord Communication’s Network Health software.

The FrameSaver SLV 9126-II Router and 9126, 9126-II, and 9128-II CSU/DSUs operate with other FrameSaver devices, and when teamed with internationally based FrameSaver devices in multinational applications, provide a complete global frame relay management solution.

9128-A2-GB20-80

September 2002

1-1

1. About the FrameSaver SLV

CSU/DSU-Specific Features

The following features only apply to the FrameSaver SLV 9126, 9126-II, and 9128-II CSU/DSUs:

TTwo Interfaces. Provides two interfaces for traffic:

Synchronous DTE port for user data

Ethernet Interface for management data

TUpstream Pipelining. Provides pipelining capability into the Wide Area Network (WAN) for reduced latency, where groups of bytes are transmitted as soon as they are received, rather than waiting for the entire frame to be collected before sending.

TLMI Protocol Support. Automatically detects and initializes the Local Management Interface (LMI) protocol type on the user data port.

Router-Specific Features

The following features only apply to the FrameSaver SLV 9126-II router:

Device Migration. The FrameSaver SLV 9126-II Router can be converted to a

FrameSaver SLV 9126-II CSU/DSU with a firmware download.

In-Band Router Management. Permits the router to be managed via customer data PVCs and EDLCIs by assigning an IP address for router management that is different from the IP address generally used for the network interface.

Inverse ARP for User Data. Provides Inverse ARP (Address Resolution Protocol) support for user data, as well as management data. The router responds to Inverse ARP requests, and can acquire the IP address of a FrameSaver device at the far end of a customer PVC. ARP information is retained for both customer data and management data.

1-2

September 2002

9128-A2-GB20-80

1. About the FrameSaver SLV

TCLI Access and Configuration. Provides a router Command Line Interface (CLI), along with the menu-driven user interface, for configuring and managing the router. It is accessed from the Main Menu via a direct COM port connection or Telnet.

The following features are configurable using the CLI:

NAT (Network Address Translation) support provides the means to bind IP addresses in a private network to addresses in a public, or global, network for transparent routing between the two domains on all PVCs. Up to 30 NAT pools are supported.

Routing table configuration permits configuration of static routes. Up to 32 entries can be made.

IP forwarding to forward multicast IP packets and customer datagrams.

Filtering on the Ethernet and frame relay interfaces, configurable from the CLI access list, allows the router to filter MAC frames and prevent unwanted inbound connections. Two filter access lists are supported per interface, one for the transmit and one for the receive direction.

The following protocol is supported:

DHCP (Dynamic Host Configuration Protocol) support for dynamic allocation of IP addresses and automatic cleanup when a subinterface is deleted, as well as allowing multiple IP address ranges for DHCP deny capability. The DHCP server and relay cannot be enabled at the same time. Up to 253 DHCP clients can be supported. One DHCP pool of addresses, and one IP address range per pool is supported.

9128-A2-GB20-80

September 2002

1-3

1. About the FrameSaver SLV

FrameSaver Diagnostic and SLM Feature Sets

Depending upon the model ordered, the FrameSaver unit has the basic FrameSaver frame relay and diagnostic capability, or it is enhanced with additional SLM (Service Level Management) reporting capability. These are referred to as feature sets, which provide different levels of intelligence for monitoring, managing, and reporting performance of the unit.

The two feature sets include:

TBasic Diagnostic Feature Set. Models with this feature set provide basic FrameSaver capabilities, which include:

Leased Line mode for standard DSU installation and operation

Device health and status

Layer 1 (Physical) and Layer 2 (Frame Relay) performance statistics

Basic physical testing and non-disruptive PVC diagnostics

A troubleshooting DLCI (Data Link Connection Identifier) for service provider use and remote management

Limited RMON (Remote Monitoring) functionality

Multiplexed management PVCs

See FrameSaver Diagnostic Feature Set on page 1-5 for other features and additional information.

TAdvanced SLM Feature Set. Models with this feature set provide all the basic diagnostic capability, plus advanced Service Level Management features. When additional SLV data is collected and the unit is accessed from an OpenLane SLM system, Web access to the following information is available:

TruePut™ Technology using Frame and Data Delivery Ratios (FDR and DDR)

Web browser access to all diagnostic and reporting functions

Historical SLA (Service Level Agreement) verification and trend reports

Real-time RMON (remote monitoring) alarms and configurable alarm thresholds

Real-time and historical network performance graphs

Multiplexed customer PVCs

See FrameSaver SLM Feature Set on page 1-10 for more information about the additional SLM capability.

If the unit does not have the SLM feature set, full SLM capability can be activated at any time by ordering a Feature Activation Certificate. The OpenLane SLM system Release 5.3 or above is required to schedule activation of advanced SLM features in units, and to manage activations.

1-4

September 2002

9128-A2-GB20-80

1. About the FrameSaver SLV

To obtain a Feature Activation Certificate, provide the model to be upgraded, your OpenLane system license key number, and the number of FrameSaver units to be upgraded to SLM capability. You can order the certificate for a single unit or for many units. Your Feature Activation Certificate will include an Activation Certificate Number, the Feature Group Number for the additional SLM features, your OpenLane license key number, and the number of device activations ordered.

When the Feature Activation Certificate arrives, add the Activation Certificate Number to your OpenLane SLM application’s database. Activations can occur at any time, for as many units as desired, until no activations remain for the certificate. When ready to activate units, simply select the units to be activated and schedule the activations. The activations occur when scheduled, and OpenLane updates the certificate information. The OpenLane system also provides a Certificate Summary Report to assist you in the management of the certificate.

FrameSaver Diagnostic Feature Set

A FrameSaver SLV unit with the basic diagnostic feature set provides the following:

TEasy Installation. Provides a straightforward installation menu that requires minimal configuration to get the unit up and running quickly, and to set up remote configuration and management via Telnet access from the NOC (Network Operations Center).

TFrame Relay Aware Management. Supports diagnostic and network management features over the frame relay network. The unit’s frame relay capability also supports:

Inband management channels over the frame relay network using dedicated PVCs.

Unique nondisruptive diagnostics.

CIR monitoring on a PVC basis.

Multiple PVCs on an interface.

Multiplexing management PVCs with user data PVCs.

Multiplexing multiple PVCs going to the same location onto a single network PVC.

TRouter Independence. Unique diagnostics, performance monitoring, PVC-based in-band network management, and SNMP connectivity is not dependent upon external routers, cables, or LAN adapters.

TInverse ARP and Standard RIP Support. Provides Inverse ARP (Address Resolution Protocol) support so the frame relay router at one end of a management PVC can acquire the IP address of a FrameSaver unit at the other end of the PVC. Standard RIP (Routing Information Protocol) allows the router to automatically learn the routes to all FrameSaver units connected to that FrameSaver unit.

TSecurity. Provides multiple levels of security to prevent unauthorized access to the unit.

9128-A2-GB20-80

September 2002

1-5

1. About the FrameSaver SLV

TAuto-Configuration. Provides the following automatic configuration features:

Time Slot Discovery – For automatic configuration of all network DS0 assignments.

Frame Relay Discovery – For automatic discovery of network DLCIs and configuration of a user data port DLCI, the PVC connection, and a management PVC, which is multiplexed with user data DLCIs.

LMI Protocol Discovery – For automatic configuration of the protocol being used by the network.

DLCI Deletion – For automatic removal of configuration of unused DLCIs from the unit’s configuration and statistical databases.

CIR Determination – For automatic recalculation of the committed rate measurement interval (Tc) and excess burst size (Be) when a DLCI’s CIR changes.

Excess burst size (Be) and committed burst size (Bc) are recalculated when Committed Burst Size Bc (Bits) is set to CIR. The committed rate measurement interval (Tc) is recalculated when Committed Burst Size Bc (Bits) is set to Other.

TMaximum Number of PVCs and Management PVCs Supported.



FrameSaver

FrameSaver

FrameSaver

FrameSaver



SLV 9126-II

SLV 9126

SLV 9126-II

SLV 9128-II

Feature

Router

CSU/DSU

CSU/DSU

CSU/DSU











Through

8

16

64

120

Connections









(PVCs)



















Dedicated

2

2

2

2

Management









PVCs



















TMultiplexed Management PVCs. Provides a method of multiplexing management data with customer data transparently over a single PVC (Permanent Virtual Circuit) when FrameSaver devices are at each end of the circuit. This feature also makes it possible to run nondisruptive PVC tests.

TExtensive Testing Capability. Provides a variety of tests to identify and diagnose device and network problems, including nondisruptive PVC loopbacks and end-to-end connectivity. Tests can be commanded from the unit’s menu-driven user interface or the OpenLane system.

These tests include V.54 or FT1-ANSI data channel loopback support so the frame relay network service provider can perform a physical loopback from its own switch without having to contact the local service provider for loopback activation.

TLMI Packet Capture. Provides a way of uploading data that has been captured in a trace file so the data can be uploaded and transferred to a Network Associates Sniffer for analysis, or viewed via the menu-driven user interface. When viewed from the menu-driven user interface, the twelve most recent LMI messages are displayed via the LMI Trace Log.

1-6

September 2002

9128-A2-GB20-80

1. About the FrameSaver SLV

TIntegral Modem. Provides an internal 14.4 Kbps modem to support dialing in to the unit for out-of-band management and automatic dialing out of SNMP traps.

TModem PassThru. Provides access to another device’s VT100-compatible user interface over a dial connection. When this feature is enabled, a logical connection between the unit’s modem and COM ports is created, allowing access to a collocated device’s serial port via the FrameSaver unit’s internal modem. This feature is sometimes referred to as the Router Assist feature.

TConfigurable FTP Transfer Rate. Allows you to control the transmit rate when downloading firmware into the FrameSaver unit and uploading user history statistics to an NMS (Network Management System) via the COM port connection or a management PVC so the data can be transferred as a background task using the standard File Transfer Protocol (FTP) over extended periods of time using low bandwidth.

TRMON User History Performance Statistics via SNMP Polling. Provides access to the physical interface and basic frame relay performance statistics by polling the FrameSaver unit using SNMP (Simple Network Management Protocol). These statistics are available real-time via the Enterprise MIB and historically as an RMON2 User History object.

TFrame Relay Traffic Policing. Ensures proper alignment and correlation of CIR (Committed Information Rate) values between the FrameSaver unit and the network switch. When this feature is enabled, the unit can enforce CIR and EIR (Excess Information Rate), marking frames that exceed CIR as DE (Discard Eligible) using the same method used by the switch.

TService Provider Support. Provides information and tools useful to network service providers, which includes the following:

IP Routing Table – Shows the IP routing table for the FrameSaver unit, with network as well as host routes, the number of hops to the destination, the method by which the route was added to the table, the interface used to get to the destination, and how long the route has been in existence.

Trap Event Log – Displays the SNMP (Simple Network Management Protocol) trap event log for the FrameSaver unit from the menu-driven user interface, with the most recent events first, keeping a running total for all trap events stored, the amount of time since the event was logged, plus a description of the trap.

Troubleshooting PVC – Provides a dedicated troubleshooting management link that helps service providers isolate problems within their network.

TATM VPI/VCI and DLCI Correlation. For networks with both ATM and frame relay-access endpoints, allows the FrameSaver unit to report the originating Virtual Path and Channel Identifier (VPI/VCI) in the far-end ATM-access endpoint where the local DLCI is mapped so they can be correlated for OpenLane SLV reports.

TDual Flash Memory. Allows software upgrades while the unit is up and running. Two software loads can be stored and implemented at the user’s discretion.

9128-A2-GB20-80

September 2002

1-7

1. About the FrameSaver SLV

TDSX-1 Drop/Insert Port. Allows DTEs/PBXs that support the DS1 signal format to share the T1 network with other high-speed equipment so that voice traffic can share the same local access circuit as the frame relay data.

TBack-to-Back Operation. Allows two FrameSaver devices to be connected via a leased-line network or simulation so a point-to-point configuration can be implemented.

TEnhanced Ping Operation. FrameSaver devices can check connectivity and roundtrip response time to any remote device in either direction, via the FrameSaver internal management network or the data path.

TPayload Management. Any standard, non-management DLCI can be designated as payload managed, providing management directly from a user data PVC, and support for Telnet, ping, SNMP, and FTP.

TOptional ISDN Backup. FrameSaver SLV 9126 and 9126-II CSU/DSUs can be equipped with a BRI DBM, which supports up to two channels. The channels may have different destinations. The DBM may be field-installed in the FrameSaver SLV 9126 CSU/DSU, and must be factory-installed in the 9126-II CSU/DSU.

FrameSaver SLV 9128-II 1-slot units can be equipped with a PRI DBM, which supports up to 23 B-channels, or a BRI DBM. Carrier-mounted FrameSaver SLV 9128-II NAMs support a PRI DBM only.

When an ISDN BRI or PRI DBM (Basic Rate Interface or Primary Rate Interface Dial Backup Module) is installed, the following ISDN backup features are provided:

Provides automatic dial backup through the ISDN for data when primary frame relay network or access line failures occur, then automatically restores data to the primary route when service returns to normal. Backup is supported regardless of whether or not Caller ID is provisioned on the ISDN circuit. A secondary backup phone number is also available to call when a backup link cannot be established with the primary backup site.

Supports simultaneous origination, answering, or origination and answering backup calls, as needed, based upon how the ISDN Link Profile is set up. This feature is also known as peer-to-peer calling.

Provides automatic configuration of an alternate route and DLCI for automatically created PVCs at either the remote site or central site based upon the learned far-end DLCI number. When the automatic backup feature is enabled, backup and restoration occur automatically.

Provides backup timers that can be configured to better control the amount of time required before backup is initiated, when a backup call will be terminated once the failure condition clears, and a delay before normal service is restored. These features are useful during periods of frequent service disruption.

In addition, round trip latency thresholds can be configured that will initiate backup when configured thresholds are exceeded.

Supports backup call groups, where redundant PVCs can be assigned to a specified call group. Using this feature, the unit only goes into backup when all PVCs in the group are down, and it returns to normal service as soon as one PVC in the group is operational again. This feature is useful when multiple PVCs are going to redundant central sites.

1-8

September 2002

9128-A2-GB20-80

1. About the FrameSaver SLV

When the SLV Sample Interval is set to 10 seconds, provides advance detection of network problems before a DLCI Down indication is received, to minimize data loss.

Provides customer premises equipment (CPE) with a Backward Explicit Congestion Notification (BECN) when backup bandwidth is not sufficient for the traffic, allowing the CPE time to slow traffic to the ISDN before the network starts discarding data.

Supports Frame Relay Forum Multilink Frame Relay Implementation Agreement – FRF.15 so backup bandwidth can be increased by aggregating multiple B-channels over the ISDN link.

Supports collection of call and call attempt statistical information that can be viewed from the menu-driven user interface or via SNMP, and supports alarm generation and call security, as well.

Provides test call capability on ISDN backup links so ISDN and DBM function can be verified before there is an actual primary link failure and switched over to the backup link. Periodic tests are recommended, which can be performed from the menu-driven user interface, or through SNMP commands. Multiple Last Cause Values are also provided to assist in troubleshooting ISDN problems.

Additional FrameSaver SLV 9126-II and 9128-II Features

TEthernet Interface. FrameSaver SLV 9126-II Routers and 9126-II and 9128-II CSU/DSUs units have a 10/100 BaseT Ethernet LAN interface for management, with automatic sensing of the operation rate of 10 Mb or

100 Mb, conforming to ANSI/IEEE 802.3.

Additional FrameSaver SLV 9128-II Features

The following features are unique to FrameSaver SLV 9128-II units:

TMultiple Data Ports. Provides two data ports instead of one, which have standard connectors so no special-order cables are required.

TCarrier-Mounted Models. For customers with high-density requirements, FrameSaver SLV 9128s and 9128-IIs can be ordered as multislot units, called Network Access Modules (NAMs), for insertion in the 14-slot 9000 Series Access Carrier.

9128-A2-GB20-80

September 2002

1-9

1. About the FrameSaver SLV

FrameSaver SLM Feature Set

A FrameSaver SLV unit with the advanced SLM feature set provides the following features in addition to those provided with the basic set:

TTruePutTechnology. Using Frame Delivery Ratios (FDR) and Data Delivery Ratios (DDR), throughput (within and above CIR, as well as between CIR and EIR, and above EIR) can be measured precisely, eliminating inaccuracies due to averaging.

TIntelligent Service Level Verification. Provides accurate throughput, latency, and availability measurements to determine network performance and whether service level agreements (SLAs) are being met, along with SLA reporting.

TRMON Alarms and Configurable Alarm Thresholds. Provides the ability to change SLA parameter and RMON alarm thresholds via the OpenLane system to correct them in real-time, before the SLA is violated.

TMultiplexed Customer PVCs. Provides a method of multiplexing customer management data and user data with network management data transparently over a single PVC when FrameSaver devices are at each end of the circuit.

TFTP User History Poller. Provides a bulk collector using FTP through the OpenLane system that generates a file for data at the time that data is uploaded using FTP.

TNetwork User History Synchronization. Allows correlation of RMON2 User History statistics among all SLV devices in a network. Using a central clock, called the network reference time, all SLV device user history statistics are synchronized across the network, further enhancing the accuracy of OpenLane SLV reports.

TRMON-Based User History Statistics Gathering. Provides everything needed to monitor network service levels, plus throughput with accurate data delivery, network latency, and LMI and PVC availability. Continuous roundtrip latency testing and reporting, as well as CIR to transmitted and received data performance statistics, are included.

In addition, port bursting statistics are kept for all frame relay links for accurate calculation of utilization.

1-10

September 2002

9128-A2-GB20-80

1. About the FrameSaver SLV

OpenLane SLM System

Being standards-based, the OpenLane SLM (Service Level Management) system can be used with other management applications like HP OpenView or IBM’s NetView. OpenLane includes HP OpenView adapters for integrating OpenLane features with the OpenView Web interface.

Being Web-based, the OpenLane system provides Web access to the data contained in the database to provide anytime, anywhere access to this information via a Web browser.

Some of the OpenLane system’s features include:

TReal-time performance graphs provide exact performance measurement details (not averages, which can skew performance results) of service level agreement (SLA) parameters.

Port bursting and EIR (Excess Information Rate) performance monitoring graphs are available when the software release for the OpenLane SLM system is Release 5.2, or later.

THistorical SLV graphs provide service level management historical reports so frame relay SLAs can be verified.

TDiagnostic troubleshooting provides an easy-to-use tool for performing tests, which include end-to-end, PVC loopback, connectivity, and physical interface tests.

For units with ISDN backup capability, provides ISDN physical interface and PVC testing when the software release for the OpenLane SLM system is Release 5.2, or later.

TBasic configuration allows you to configure FrameSaver devices. Network DLCI Circuit IDs can also be assigned.

TAutomatic SLV device and PVC discovery allows all SLV devices with their SLV Delivery Ratio configuration option enabled to be discovered automatically, along with their PVCs.

TA FrameSaver unit can be reset from the OpenLane system.

TFirmware downloading provides an easy-to-use tool for downloading to an entire network or a portion of the network.

TOn-demand polling of FrameSaver devices, and SNMP polling and reporting are available.

TThe maintenance scheduling feature allows for the scheduling of multiple periodic maintenance periods, and provides a record of all scheduled maintenance periods – past, present, and future.

9128-A2-GB20-80

September 2002

1-11

1. About the FrameSaver SLV

NetScout Manager Plus and NetScout Probes

Provides complete LAN and WAN traffic analysis and monitoring functions for

FrameSaver devices.

The following features are supported using this application:

TThresholds for RMON 1 (Remote Monitoring, Version 1) alarms and events can be configured.

TPerformance monitoring can be performed using collected RMON 2

(Version 2) data. NetScout Manager Plus’s Protocol Directory and Distribution functionality allows FrameSaver devices to measure up to eleven network-layer protocols and report the amount of traffic generated by each. Its IP Top Talkers and Listeners reporting identifies the devices using network bandwidth for traffic and protocol analysis, identifying the network’s top six users. In addition, it collects performance statistics from FrameSaver devices. Up to 900 samples can be stored in 15-minute buckets, with 96 buckets in a 24-hour period, for up to five days worth of data.

TOptional standalone NetScout Probes can be used with FrameSaver devices at sites where full 7-layer monitoring, an unlimited number of protocols, and advanced frame capture and decode capabilities are desired.

1-12

September 2002

9128-A2-GB20-80

User Interface and Basic Operation

2

This chapter contains information about how to access, use, and navigate the menu-driven user interface and the Router’s Command Line Interface (CLI). It includes the following:

TLogging On on page 2-2

TMain Menu on page 2-4

TScreen Work Areas on page 2-5

TNavigating the Screens on page 2-6

Keyboard Keys

Function Keys

Selecting from a Menu

Switching Between Screen Areas

Selecting a Field

Entering Information

Screen Contents

TNavigating the Router’s CLI on page 2-10

CLI Keyboard Keys

9128-A2-GB20-80

September 2002

2-1

2. User Interface and Basic Operation

Logging On

Start a session using one of the following methods:

TTelnet session via:

An in-band management channel through the frame relay network.

A local in-band management channel configured on the DTE port between the FrameSaver unit and the router.

TDial-in connection using the internal modem.

TDirect terminal connection over the COM port.

When logging on, the User Interface Idle screen appears.

TIf no security was set up or security was disabled, the Main Menu screen appears (see Main Menu on page 2-4). You can begin your session.

TIf security was set up and is enabled, you are prompted for a login. Enter your login ID and password.

When the user interface has been idle, a session is automatically ended and the screen goes blank when the unit times out. Press Enter to reactivate the interface.

Procedure

To log in when security is being enforced:

1.Type your assigned Login ID and press Enter.

2.Type your Password and press Enter.

Valid characters – All printable ASCII characters

Number of characters – Up to 10 characters can be entered in the Login ID and Password fields

Case-sensitive – Yes

An asterisk (*) appears in the password field for each character entered.

2-2

September 2002

9128-A2-GB20-80

Loading...
+ 440 hidden pages
