Paradox Magellan MG5000, Spectra SP4000, Spectra SP5500, Spectra SP6000, Spectra SP65 User Manual

...
MG5000 MG5050
SP65 SP4000 SP5500 SP6000 SP7000
Always Armed, Never Disarmed
User Guide
Warranty
Limitations of Alarm Systems
We strongly advise that you review and take into consideration the “Limitations of Alarm Systems” document available on our website at http://paradox.com/Terms/
.
Warning for Connections to Non-Traditional Telephony (e.g. VoIP)
Paradox alarm equipment was designed to work effectively around traditional telephone systems. For those customers who are using a Paradox alarm panel connected to a non-traditional telephone system, such as "Voice Over Internet Protocol" (VoIP) that converts the voice signal from your telephone to a digital signal travel­ing over the Internet, you should be aware that your alarm system may not function as effectively as with tradi­tional telephone systems.
For example, if your VoIP equipment has no battery back-up, during a power failure your system's ability to transmit signals to the central station may be compromised. Or, if your VoIP connection becomes disabled, your telephone line monitoring feature may also be compromised. Other concerns would include, without limitation, Internet connection failures which may be more frequent than regular telephone line outages.
We therefore strongly recommend that you discuss these and other limitations involved with operating an alarm system on a VoIP or other non-tra ditional telephone system with your inst allation company. They should be able to offer or recommend measures to reduce the risks involved and give you a better understanding.
WARNINGS: Information to User
This equipment has been tested and found to comply with the limits for Class B digital devices, pursuant to Part 15 of FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy, and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communica­tions. However, there is no guarantee that interfere nce will not occur in a particu lar installation. If this equipment does cause harmful interference to equipment intermittently, the user is encouraged to try to correct the interfer­ence by one or more of the following measures: (1) re orient or relocate the receiving antenna; (2) increase the separation between the equipment and receiver; (3) connect the equipment to an outlet on a circuit other than the one to which the receiver is connected, or (4) consult the dealer or an experienced radio/tv technician for assistance. CAUTION: The user is cautioned that any changes or modifications not expressly approved by Par­adox Security Systems could void the user’s authority to operate/use the equipment.
Patents
One or more of the following US patents may apply: 7046142, 6215399, 6111256, 5920259, 5886632, and RE39406. Canadian and international patents may also apply.
© 2014 Paradox Security Systems Ltd. All rights reserved. Specifications may change without prior notice. Par­adox, StayD, Magellan and Spectra are trademarks or registered trademarks of Paradox Security Systems (Bahamas) Ltd. or its affiliates in Canada, the United States and/or other countries.
Table of Contents
Warranty .................................................................... 0
Limitations of Alarm Systems..................................... 0
Warning for Connections to Non-Traditional
Telephony (e.g. VoIP)......................................... 0
WARNINGS: Information to User............................... 0
Patents....................................................................... 0
User Settings .................................................................. 2
Zone Settings.................................................................. 3
User Codes...................................................................... 4
Adding / Modifying a User.......................................... 4
Deleting a User .......................................................... 4
Setting the Time & Date ................................................. 5
Setting Chime Zones...................................................... 5
Trouble Display............................................................... 6
Keypads........................................................................... 7
Auditory Feedback..................................................... 7
Visual Feedback . ... .... ... ... ... ... .... ... ... ... .... ................... 7
Keypad Muting........................................................... 7
Keypad Backlight ....................................................... 8
Power Save Mode (K32RF / K37 only)... ... ... ... .......... 8
Keypad Overviews..................................................... 9
Remote Controls........................................................... 12
Remote Control Feedback (REM2).......................... 12
Arming & Disarming with StayD ................... ... ... .... ... . 12
To Turn On/Off StayD Mode.................................... 12
To Change Arm Mode.............................................. 13
Advanced StayD Settings ....................................... . 13
Arming & Disarming..................................................... 14
Regular Arming........................................................ 14
Sleep Arming ........................................................... 14
Stay Arming ...................... ... .... ... ... ... ... .... ... ... ... .... ... 14
Bypassing a Zone.................................................... 15
One-Touch Arming................... ... ... ... ... .... ... ... ... .... ... 15
Auto-Arming............................................................. 16
Display Mode........................................................... 16
Alarms ........................................................................... 17
Alarm Display........................................................... 17
Disarming & Deactivating an Alarm ......................... 17
Panic Alarms............................................................ 17
Fire Alarms............................................................... 17
Testing & Maintenance............................................ 18
Communicating Through the Internet (IP100) ........... 18
Communicating Using Text Messages (PCS100)...... 18
Communicating by Phone........................................... 20
(Voice-Guided VDMP3) ................................ ... ... ... .... ... 20
VDMP3 Instructions Diagram................................... 21
Advanced System Features ........................................ 22
Programmable Outputs (PGMs) .............................. 22
Partitioning............................................................... 22
Quick Function Keys................................................ 22
System Notes............... .... ... ... ... .... ... ... ... ... .... ... ... .......... 22
Quick Programming..................................................... 24
Master Quick Menus................................................ 24
Index.............................................................................. 26
Magellan / Spectra SP 1
User Settings
For security reasons, write only the user’s name and not their user code. 4-Digit Codes l 6-Digit Codes l
User # and Name
01: Master Mas- 02: Master 1 Mas- 03: Master 2 Mas- 04:________________________________________ 05:________________________________________ 06:________________________________________ 07:________________________________________ 08:________________________________________ 09:________________________________________ 10:________________________________________ 11:________________________________________ 12:________________________________________ 13:________________________________________ 14:________________________________________ 15:________________________________________ 16:________________________________________ 17:________________________________________ 18:________________________________________ 19:________________________________________ 20:________________________________________ 21:________________________________________ 22:________________________________________ 23:________________________________________ 24:________________________________________ 25:________________________________________ 26:________________________________________ 27:________________________________________ 28:________________________________________ 29:________________________________________ 30:________________________________________ 31:________________________________________ 32:________________________________________
*Programmed by your installer.
Partition 1Partition
2
Byp* Stay* Force*
Arm*
only
PGM*
only
Duress*
l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l l l lllll l l l l l l l l l
2 User Guide
Zone Settings
Write the device type (motion detector, door contact etc.) and location.
Zone Number and Description
001:______________________________ _____ 002:______________________________ _____ 003:______________________________ _____ 004:______________________________ _____ 005:______________________________ _____ 006:______________________________ _____ 007:______________________________ _____ 008:______________________________ _____ 009:______________________________ _____ 010:______________________________ _____ 011:______________________________ _____ 012:______________________________ _____ 013:______________________________ _____ 014:______________________________ _____ 015:______________________________ _____
Partition
1 or 2
Byp Stay Sleep Force 24Hr
Entry delay
Fire
zone
Fire
Delay
llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll
016:______________________________ _____ 017:______________________________ _____ 018:______________________________ _____ 019:______________________________ _____ 020:______________________________ _____ 021:______________________________ _____ 022:______________________________ _____ 023:______________________________ _____ 024:______________________________ _____ 025:______________________________ _____ 026:______________________________ _____ 027:______________________________ _____ 028:______________________________ _____ 029:______________________________ _____ 030:______________________________ _____ 031:______________________________ _____ 032:______________________________ _____
l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l llllllll l l l l l l l l
Magellan / Spectra SP 3
User Codes
User codes are personal identification numbers for each user that allow you to enter certain programming modes, arm or disarm your system, as well as activate or deactivate PGMs. The system supports the following:
1 System Master Code
2 Master Codes
29 User Codes
System Master Code (Default: 123456)
The System Master Code can arm or disarm any partition, and can create, modify or delete any user code.
Master Codes
Master Code 1 is permanently assigned to Partition 1 and can be used to create, modify or delete user codes that are assigned to Partition 1. Master Code 2 is permanently assigned to Partition 2 (exception: when partitio n­ing is disabled, Master Code 2 will be assigned to Partition 1) and can be used to create, modify or delete user codes that are assigned to the same partition.
NOTE:
Code can modify or delete user codes assigned to both partitions.
Duress Code
If you are forced to arm or disarm your system, entering the user code with the duress option enabled will arm or disarm the system and immediately transmit a silent alert (Duress Code) to the monitoring station. The duress code must be enabled by your installer.
Master Codes cannot modify or delete user codes assigned to both partitions. Only the System Master
User Code Length
Your system can be programmed to use either 4- or 6-digit user codes, where each digit can be any value from 0 to 9. Six-digit codes are considered more difficult to “crack” and therefore, more secure. Avoid programming simple or obvious user codes, such as your telephone number, address, or codes such as 1234.
Adding / Modifying a User
How do I add / modify a user? Visual Feedback
1
Press the [] key.
2 Enter your [
3 Select a user by entering a 2-digit user number (01 to 32). “Arm” flashes. 4 Enter a 4- or 6-digit [ 5 Confirm the [ 6 To register a remote, press and hold any remote button for 3
seconds. Release. Press and hold any remote button for 3 seconds. If you do not wish to assign a remote, press
[
ENTER].
7 To program another user, go to step 3.
To exit, press [ For partitioned systems, continue to step 8.
8Press [1] and/or [2] to assign the user to a partition.
Press [
9 To program another user, go to step 3.
To exit, press [
MASTER CODE].
[] and [1] flash. When a number on the
keypad is lit, the user is already programmed.
USER CODE]. “Sleep” flashes.
USER CODE]. “Stay” flashes.
“Off” flashes.
CLEAR].
ENTER].
CLEAR].
Deleting a User
How do I delete a user?
1
Press the [] key. 2 Enter your [ 3 Select a user by entering a 2-digit user number. 4 Press and hold the [
4 User Guide
MASTER CODE].
SLEEP] key until you hear the confirmation beep.
Setting the Time & Date
How do I set the time & date?
1
Press the [] key. 2 Enter your [ 3Press [ 4Press [5]. 5 Enter time* in the [ 6 Select time format. [1] = 24hr; [2] = AM; [3] = PM. 7 Enter the date in the [ *For SP4000 / SP65 systems, time must be entered in 24hr format. Omit step 6 (time format).
MASTER CODE].
TBL].
HH.MM] format. If HH = 13 or more, skip to step 7.
YYYY/MM/DD] format. You have now set the time & date. Press [CLEAR] to exit.
Setting Chime Zones
A chime-enabled zone will advise you every time it is opened by causing your keypad to beep. Each keypad must be chimed separately.
How do I chime zones?
For K32, K32+ and K32RF: Press & hold the [ ] key. The Arm1, Arm2, Stay1, and Stay2 LEDs will flash.
Enter the zone number corresponding to the zones you want to chime. The corresponding LED will light up.
Press the
[ENTER] key to exit.
For K35 and K37: Press & hold the [ ] key (K35) or [ ] key (K37). The word Chime will appear on the
screen. Enter the zone number corresponding to the zones you want to chime. The corresponding LED will
light up. Press the
active.
For K10V, K10H and K636: Press & hold the zone key ([1] to [0(10)]). Accept beep = chime on.
For K32LCD, K32LCD+: Press and hold the [ ] key. Press [1] to select which zone to chime or press [2] to
configure chime period. The chime period allows you to specify the time frame in which the zone will chime.
Enter the zone number corresponding to the zones you want to chime. Press the [
How do I disable chime zones?
• • For K32, K32+,K32RF, K35, K37, K32LCD and K32LCD+: To disable chime zones, repeat this process
and enter the zone number to disable a chime zone, or press [
entering a zone number.
For K10V, K10H and K636: Press & hold the zone key ([1] to [0(10)]). Fail beep = chime off.
NOTE: For a description of the confirmation and rejection beeps, see Keypad Feedback on page 7.
To identify your keypad, see page 9.
[ENTER] key to exit. Note: K37 will only chime when powered by AC or when the disp lay is
ENTER] key to exit.
SLEEP] to disable all chime zones instead of
Magellan / Spectra SP 5
Trouble Display
Your alarm system continuously monitors several trouble conditions that can be reported directly to your moni­toring station. When a trouble condition occurs, the [ will illuminate a number corresponding to the trouble the system is experiencing. Except for the Timer Loss trou­ble, contact your monitoring station or installer to resolve the trouble condition.
NOTE: If the keypad emits a
TBL] key to stop the “Trouble Beep”.
[
BEEP every 5 seconds whenever a new trouble condition has occurred, press the
Accessing the Trouble Display
TBL] key will illuminate. Press the [TBL] key , and t he keypad
Press
[TBL]
Key / LED
Trouble Type Trouble Details
Lit
[1] Wireless Zone Low Battery The batteries for one of the system’s wireless
devices needs to be replaced.
[2] Power Trouble The control panel is experiencing power trouble. [3] Bell Trouble There is a bell disconnect/overload on the control
panel.
[4] Communication Trouble Your alarm system, if monitored, could not
communicate with the monitoring station.
[5] Tamper/Zone Wiring Failure A wiring problem is occurring on one or more
devices.
[6] Module Tamper Trouble A device’s anti-tamper switch has been triggered. [7] Fire Loop Trouble One of the zones is in fire loop trouble. [8] Timer Loss Your alarm system’s clock must be reprogrammed.
See Setting the Ti me and Date on page 5 to set your system’s time and date.
[9] Wireless Zone Supervision Loss One or more wireless zones are no longer
communicating with the system.
[0 (10)] Module Supervision Loss One or more modules are no longer communicating
with the system.
[16] /
[
SLEEP]
Keypad Fault There is a problem with one of your system’s
keypads
6 User Guide
Keyp ads
Auditory Feedback
When you enter information on the keypad, it will guide you with beep tones that communicate confirmation or rejection of your entries. You should be familiar with these two keypad beep tones:
Confirmation Beep: When an operation (e.g. arming/disarming) is successfully entered on the keypad or when the system switches to a new status/mode, the keypad produces an intermittent beep tone (“
BEEP”).
Rejection Beep: When the system reverts to its previous status or when an operation is incorrectly entered on the keypad, it will emit a continuous beep tone (“
The following are other types of auditory feedback, and will always be accompanied by the flashing of an arm key or LED ([
Continuous beep = Alarm
Variable beep = Fire alarm
Intermittent beep = Beginning of exit delay
Fast Intermittent beep = Last 10 seconds of exit delay
ARM], [STAY], or [SLEEP]):
BEEEEEEEEP”).
Visual Feedback
The keypad includes colored lights which convey the current status of your system. The state of each light rep­resents a specific condition in your system.
NOTE: Many of the features in your system must be enabled by the installer. If the feature is not programmed, the keypad will emit a rejection beep and the action will be canceled. Refer to Zone Settings on page 3 for details.
BEEP-BEEP-BEEP-
Keypad Muting
When muted, the keypad will only emit the confirmation beep and rejection beep, and will beep when a key is pressed. Therefore, when muted, the keypad will not beep during an alarm and will not beep for chime enabled zones. Each keypad must be muted separately.
How do I mute the keypad?
For K32, K32+, K32RF, K35, K37, K636, K10V and K10H: Press & hold the [
enable or disable keypad muting. If the keypad emits a confirmation beep, Keypad Muting is enabled for
that keypad. If the keypad emits a rejection beep, the feature is disabled.
For the K32LCD, K32LCD+: Press and hold the [ ] key for keypad settings. Press [4] for Mute Control.
Press [arm] to enable or disable keypad muting.
CLEAR] key for 6 seconds to
Magellan / Spectra SP 7
