PARA Dox CR-R880-BL Installation Manual

CR-R880-BL:

Indoor/Outdoor Proximity Reader

with 10cm (4in) read range

Installation Manual

CR-R880-BL 1

Table of Contents

Basic Operation ...............................................2

CR-R880-BL Block Diagram ...................................2

Technical Spec ific a tions .................................3

Features ............................................................ 4

Tricolour LED Display .............................................4

Face Light ...............................................................4

Audible Tone ..........................................................5

Weather Resistant ..................................................5

SwiftRead ...............................................................5

Diagnostic Test .......................................................5

Installation ........................................................ 5

Important Notes on Selecting an Installation Site ...5

Mounting .................................................................6

Mounting on Metal ..................................................7

Wiring .....................................................................7

Card Presentation Test ...........................................8

Wiegand Output Wiring Diagram ..........................10

ABA Output Wiring Diagram .................................11

Dimensions ....................................................12

Regular Mounting Plate ........................................12

Gang Box Mounting Plate .....................................13

2 Installation Manual

Basic Operation

When power is supplied to the reader, the antenna in the
reader will emit a continuous low-frequency RF field.
When a card is placed within this field, the antenna inside
the card will gather the energy present in the field to
power the internal circuitry of the card. The card will then
transmit its unique identification (ID) number to the
Indoor/Outdoor Proximity Reader with 10cm (4in) read
range (CR-R880-BL). After receiving the signal, the
reader verifies the validity of the signal. If the signal is
valid, it will be decoded by the reader and sent in the
appropriate output format to the host controller through
data cables. The controller then determines what action
to take in response to the information received from the
reader.

Figure 1: CR-R880-BL Block Diagram

CR-R880-BL 3

Technical Specifications

Input Voltage: Typical 13.8Vdc

Minimum 11.0Vdc
Maximum 14.5Vdc

Input Current: Typical 65mA @ 12.5Vdc

With card present 105mA @

12.5Vdc

Power Consumption: Typical 812mW @ 12.5Vdc

With card present 1.31W @

12.5Vdc

Read Range*: CR-R702-A Clam Shell Card

CR-R704-B Blue Proximity Key Tag

Frequency: Exciter field 125 KHz Pulse

Modulated
Receive Low Frequency 12.500

KHz
Receive High Frequency 15.625

KHz

Operating Temperature: Minimum -35°C (-31°F)

Maximum +65°C (149°F)

Output Formats: 26-Bit Wiegand, 37-Bit Wiegand,

ABA & Custom

Cable Distance: 152.4m (500 feet)
Recommended Cables: 22AWG (.8mm Dia.), Multi-

Conductor, Alpha 5196, 5198
18AWG (1 .2mm Dia.), Multi-

Conductor, Alpha 5386, 5388
Belden 9553 (18A WG, 6 conductor ,

stranded with overall shield)

Led Indicator: Tricolour LED Display
Face Light: Blue
Audio Indicator: Beeper
Colour: Black
Weight: 9.8 oz. (280g)
Material: UV resistant, ABS plastic

4 Installation Manual

*The specified read range assumes no electrical
interference and that the card is presented parallel to
the reader , with the reader installed and operated as
outlined in this manual. The read range will vary
depending on the type of card used. The larger the
card, the greater the read range. The read range may
decrease if reader is mounted on metal.

All specifications are subject to change without
notice.

Features

Tricolour LED Display

The CR-R880-BL reader includes a tricolour LED display
(red, green and amber) used to indicate the reader's
status. When the orange wire is pulled low, the red LED
will illuminate. When the yellow wire is pulled low, the
green LED will illuminate. When the yellow and orange
wires are pulled low (oscillation at 1KHz is required), both
LEDs will illuminate producing an amber colour.

Face Light

The CR-R880-BL’s elegant blue face light remains
illuminated at all times so that it can be easily located in
the dark.

Dimensions: 5.75" H x 2" W x 1" T
Gang Box Mounting Plate: Single (available as an option)
Approvals:

Compliant to all EU and EFTA
countries except Greece according
to RTT&E directives.
