User Guide
J-Touch
CDM8999VW
™
CHAPTER 1. BEFORE USING
BEFORE USING ...............................................................................................7
INSIDE THE PACKAGE ..............................................................................................8
REMOVE BATTERY................................................................................................ 15
BATTERY HANDLING INFORMATION ..................................................................17
REMOVING THE MICROSD CARD ........................................................................17
CHAPTER 2. BASIC OPERATION
BASIC OPERATION ........................................................................................21
TURNING THE PHONE ON/OFF ............................................................................ 22
MAKING AN INTERNATIONAL CALL ...................................................................30
3WAY CALLING ...................................................................................................31
CALLING A NUMBER FROM CONTACTS .............................................................. 31
2
VIBRATE MODE..................................................................................................... 32
AVAILABLE OPTIONS DURING A CALL................................................................33
MAKING AN EMERGENCY CALL .......................................................................... 34
CHAPTER 3. MEMORY FUNCTION
MEMORY FUNCTION .....................................................................................35
STORING A PHONE NUMBER ..............................................................................36
EDITING CONTACT ENTRIES................................................................................. 38
ONE, TWO, THREETOUCH DIALING....................................................................46
CHAPTER 4. MENU FUNCTION
MENU FUNCTION..........................................................................................47
BACKUP ASSISTANT.............................................................................................49
RECENT CALLS ......................................................................................................56
3
CHAPTER 5. MEDIA CENTER
MEDIA CENTER .............................................................................................95
SEARCH ................................................................................................................. 96
4
BROWSE & DOWNLOAD .................................................................................... 107
CHAPTER 6. MESSAGING MENU
MESSAGING MENU .....................................................................................109
WHEN A NEW MESSAGE ARRIVES ...................................................................110
CHAPTER 7. SAFETY AND WARRANTY
SAFETY .......................................................................................................126
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ........................126
SAFETY INFORMATION FOR FCC RF EXPOSURE ..............................................130
HEARING AID COMPATIBILITY HAC FOR WIRELESS TELECOMMUNICATIONS
5
NATIONAL INSTITUTE FOR OCCUPATIONAL SAFETY AND HEALTH................ 145
WARRANTY ................................................................................................147
12 MONTH LIMITED WARRANTY ......................................................................147
BEFORE USING
This chapter provides important information about using the
JTOUCH
Handset descriptions
Charging your battery
Battery handling information
Removing the microSD card
1
TM
including:
Inside the package
Key descriptions
Display indicators
Install battery
Remove battery
Touch Interaction
J-TOUCH
6
™
INSIDE THE PACKAGE
PRODUCT SAFETY & WARRANTY GUIDE
This package should include all items pictured below. If any are missing or dierent, immediately contact the retailer where you purchased the phone.
Attention: Ne pas exposer a des tempeŕatures élevées (140℉/60℃). Ne pas démonter. Ne pas laisser des objets métaliques venir en contact avec les bornes de pile ni les court-circuiter. Ne pas incinérer ni faire brûler. Pour mettre au rebut adéquatement (Ex:numéro de recyclage 1-800-822-8837)
Cuidado: No exponga a alta temperatura (140℉
Caution:Do not expose to high temperature
/60℃). No desensamble. No permita que
(140℉/60℃). Do not disassemble.
objetos de metal entren en contacto o hagan
Do not allow metal objects to contact or short
cortocircuito con los terminales de la batería.
circuit the battery terminals. Do not incinerate
No incinere ni exponga al fuego. Para eliminar
or expose to fire. To dispose of properly
en forma adecuada (Por ejemplo:Número de
(Ex:Recycling number 1-800-822-8837)
reciclaje 1-800-822-8837)
Standard Battery
HANDSET DESCRIPTIONS
1
•BEFORE USING
10
911
8
01
02
03
7
04
05
6
06
5
07
4 3
8
Handset
Battery Cover
QRG
Product Safety &
(Quick Reference Guide)
USB AC Adapter USB Cable
Warranty Guide
1. Volume Up/ Down Key
2. Home Key
3. Camera Key
4. AVC Key
5. Power On/O Key
6. MicroSD Slot
2
7. 35mm Earphone Jack
8. Ear piece
9. Fast Forward Key
10. Play/Pause Key
11. Rewind Key
9
KEY DESCRIPTIONS
1. [ / ] Volume Keys:
earpiece volume during a call or volume when playing music.
2. [H] Home Key:
return to the Home screen from anywhere.
3. [Q] Camera/Video Key:
hold to activate the Video Camera.
4. AVC Key:
5. Power On/O Key:
and o.
6. microSD Card Slot:
memory capacity.
7. Earphone Jack:
hands-free conversations or for listening to music.
8. Earpiece:
9. Fast Forward Key
10. Play/Pause Key
11. Rewind Key
10
Press to adjust master volume in idle mode, adjust the
Pressing the Home Key on devices allows the user to
Press to access the built-in camera. Press and
Activate Advanced Voice Commands function.
The Power key allows the user to power the device on
Insert a microSD card (sold separately) here to increase
Allows you to plug in an optional headset for convenient,
Allows you to hear the other caller.
DISPLAY INDICATORS
Icon Icon Descriptions
1X:
Indicates your phone is in the CDMA 1X network. More bars indicate
a stronger signal.
Digital:
Indicates your phone is receiving digital data. More bars indicate
a stronger signal.
Airplane Mode:
Roaming: The phone is outside of the home service area.
SSL (Secured Socket Layer):
between client and server has been established during data communication using encryption.
Voice Privacy:
Data Call:
Dormant:
reverts to Dormant mode when there hasn't been activity on a page for some time - the connection is still active and you can make and receive calls.
No Service:
TTY:
Voice Call: * No icon indicates the phone is in idle mode.
E911:
calls only.
Transmitting and receiving information is restricted.
Indicates that secure communication
Indicates Voice Privacy mode is active.
Indicates a Data Session is in progress.
Indicates phone is in a dormant state during a data call. Phone
Phone cannot receive signal from the system.
TTY mode is active.
A call is in progress.
Global Positioning Service (GPS) for E911 is set to On for emergency
•BEFORE USING
01
02
03
04
05
06
07
11
Icon Icon Descriptions
Location On:
GPS is set to On for Location Service and E911 calls.
Keypad Lock:
Bluetooth:
Bluetooth Active:
Bluetooth Connected:
Playing Music:
Pause Music:
Battery Level:
the charge.
AVR Active:
AVR Listening:
All Sounds O:
Alarm Only:
Vibrate Only:
Speakerphone:
Missed Calls:
Message:
Calendar Appointment:
12
Indicates the keypad and external keys are locked.
Indicates Bluetooth® mode.
Indicates that music is playing.
Indicates that music playback has been paused.
Battery charging level - the more blocks, the stronger
AVR mode is active.
Indicates AVR listening.
All sounds are set to o.
Phone will alert you only with an alarm tone.
Indicates the Ringer Volume is set to Vibrate On.
Speakerphone mode is active.
Indicates you have missed calls.
Indicates you have new messages.
Indicates Bluetooth Active mode.
Indicates a Bluetooth Device is connected.
Event Alarm is active.
•BEFORE USING
Icon Icon Descriptions
Voicemail:
Indicates you have a voice mail message.
Alarm On:
Appears when an alarm is set.
Recent Call Icons
Sent Call Missed Call
Received Call
New Contact Icons
Mobile1 Pic/Video
Mobile2
Home IM Screen Name
Business Fax
Personal Email Speed Dial
Business Email Address
Group
Message Icons
WL Messenger Opened MMS Notication
AIM Corrupt Message
Yahoo! Pending Message Send
Ringtone
01
02
03
04
05
06
07
13
•BEFORE USING
Message Icons
Unread EMS Unread MMS
Read EMS Read MMS
New/Unread Message Sent Message
Opened/Read Message Received Message
Message Delivered Unread WAP Push
Incomplete Delivery Read WAP Push
Sent Message, Delivery Failed
Message Locked Multiple Message Failed
Text Message Draft
Picture Message Draft Multiple Message Pending
Priority Multiple Message Sent
Unopened MMS Notication
Other Icon
DST (Daylight Saving Time)
14
Multiple Message Delivered
Multiple Message Incomplete
INSTALL BATTERY
1. Insert your nger tip into the slot (1), then push down on top of the battery cover and slide it o to remove (2).
2. Slide (1) the battery into the slot by aligning the contacts and press down (2) until you hear the “click”.
Correct Incorrect
3. Align the cover tabs with the slots on the back of the device and slide the battery cover onto the unit until it snaps into place.
If the battery is not correctly placed in the compartment,
the handset will not turn on and/or the battery may detach during use.
REMOVE BATTERY
1. To remove the battery cover, insert your nger tip into the slot (1), then push down on top of the battery cover and slide it o (2).
2. Insert your ngernail into the slot (1) and lift the battery from the compartment (2).
3. Align the cover tabs with the slots on the back of the device and slide the battery cover onto the unit until it snaps into place.
01
02
03
04
05
06
07
15
CHARGING YOUR BATTERY
1. Connect the USB data cable into the cableless wall adapter.
2. Plug the USB data cable into the phone’s Charging/ Data Jack (making sure to align the connector as it appears in the following image) and the wall adapter end into an electrical outlet.
If the battery connector is not properly aligned, damage
could occur to the charging connector and the phone may not charge.
Correct Incorrect
Correct Incorrect
3. To remove the Wall Charger, pull the charger from the device.
• When you charge the battery with the handset powered o you will see a charging status screen. After the charging has completed, the Charge Complete message appears. You cannot operate the phone until it is powered on. To turn your phone on, press and hold the Power Key
P until your display turns on.
•
The battery is not fully charged at the time of purchase.
Fully charge the battery before use.
16
•BEFORE USING
•
It is more ecient to charge the battery with the handset powered o.
•
Battery operating time gradually decreases over time.
•
If the battery fails to perform normally, you may need to replace the battery.
BATTERY HANDLING INFORMATION
DO’S
•
Only use the battery and charger approved for use with the JTOUCHTM. Only use the battery for its original purpose.
• Try to keep batteries in a temperature between 41°F (5°C) and 95°F (35°C). If the battery is stored in
• temperatures above or below the recommended range, give it time to warm up or cool down before using. Store the discharged battery in a cool, dark, and dry place.
• Purchase a new battery when its operating time gradually decreases after fully charging.
• Properly dispose of the battery according to local laws.
•
DON’TS
•
Don’t attempt to disassemble the battery – it is a sealed unit with no serviceable parts. Don’t accidentally short circuit the battery by carrying it in your pocket or purse with other metallic objects
• such as coins, clips and pens. This may critically damage the battery. Don’t leave the battery in extremely hot or cold temperatures. Otherwise, it could signicantly reduce the
• capacity and lifetime of the battery. Don’t dispose of the battery by placing into a re.
•
REMOVING THE MICROSD CARD
This device comes with a 1GB pre-installed microSD Card.
1. Open the microSD Card cover, and use your thumb to press and release the
microSD Card.
2. Press the memory card inward, gently, until it pops out. Remove the microSD
Card.
3. Close the microSD Card cover.
To prevent possible damages, please keep the microSD Card cover closed at all times
regardless of whether the microSD Card is inserted or not.
01
02
03
04
05
06
07
17
TOUCH INTERACTION
Action Symbol Descriptions
A Tap is a gesture, touch that lasts for up to 500ms that requires the user to briefly contact the screen in one location.
Tap
Touch and Hold
Dragging
18
It is used to engage in a function. If a user taps on an inactive area of the screen there shall be no resulting ac tion. Note: when an option exists to launch an ac tion with a Drag or with a Tap gesture, a Tap is preferred
A Touch & Hold gesture, i.e. a touch that lasts for 500ms or longer, is generally used to display an enhanced view, to dis­play additional information or to perform a specific action. It is similar to the Tap with the difference that the user touches the screen leaving the finger motionless until the information is displayed or the action occurs. It is the duration of the touch that triggers a different event from Tap. If an object is not Touch & Hold-enabled there shall be no resulting action. The same object shall not support both Touch & Hold and Drag gestures
A Drag is a gesture that requires the user to touch, hold and move the finger without losing contact with the screen, thereby establishing a path of contact with the screen. The object touched moves in direct response to the motion of the finger. To prevent any action from being performed, the finger is dragged outside of the screen or into an inac tive area and the action is cancelled. If an object is not Drag- enabled, there shall be no resulting action. The same object shall not support both Touch & Hold and Drag gestures. Note: when an option exists to launch an ac tion with a Drag or with a Tap gesture, a Tap is preferred.
•BEFORE USING
Action Symbol Descriptions
A Flick is a unidirectional gesture that requires the user to contact the screen in a quick flicking motion. The screen scrolls in direct response to the flick of the finger in the same
Flicking
Drag and Drop
Free Draw
Circle Draw
direction, with the speed of motion at release determining the speed of screen movement. The screen movement shall continue at constant speed or decelerate over time until the user touches the screen to stop it. If an object is not Flick-enabled, there shall be no resulting action.
A Drag & Drop gesture. It is used to engage in a func tion that File is Selected & Moved
Free Draw Gesture. It is used to engage in a function that User Selected the Touch area
A circle Draw gesture for inside It is used to engage in a function that User Draw the circle inside on Screen
A circle Draw gesture for outside It is used to engage in a function that User Draw the circle outside on Screen
19
Action Symbol Descriptions
Shake Shake for the phone
Turn
Drop
Upset
Tap
Bounce
Tilt
20
Turn off the hand phone
Drop down the phone
opposite for Phone shell
The phone shell tap in side
Bounced the Phone
A slope of Phone shell
BASIC OPERATION
This chapter addresses and explains the basic features for
Turning the phone on/o
Accessing the menu
Menu summary
Making a call
Answering calls
Missed Call noti cation
Wait/Pause feature
Making an international call
3-way calling
Call waiting function
J-TOUCH
Calling a number from contacts
Using auto keypad lock function
Available options during a call
Making an emergency call
™
2
TM
including:
JTOUCH
Adjusting volume Caller ID function
Vibrate mode
Speakerphone mode
Dialing Letters
TURNING THE PHONE ON/OFF
TURNING THE PHONE ON
1. Press and hold the Power Key P on the right side of your phone until the display turns on.
• If “ENTER LOCK CODE” appears on the display, tap to unlock the keypad, enter your 4-digit lock code.
•
The default lock code is the last 4 digits of your phone number.
TURNING THE PHONE OFF
1. Press and hold the Power Key P on the right side of your phone until the display turns o.
• Immediately change or recharge the battery when “BATTERY LOW” appears on the display. Memory may possibly be damaged if the phone turns o due to the battery completely draining.
•
Turn the phone o before removing or replacing the battery. If the phone is on,
unsaved data may be lost.
ACCESSING THE MENU
Your phone can be customized via the menu. Each function can be accessed by touching the menu icon.
1. To access the main menu, slide the phone up to show Home Screen. If the phone is locked, entering PIN Code is required to unlock the phone.
2. To scroll through the menu, ick the screen up or down.
3. To return to the previous page, tap the return to Home Screen, tap the HOME soft key
22
Back
. To exit the current menu and
H
.
•BASIC OPERATION
MENU SUMMARY
Main Menu 2ND DEPTH 3RD DEPTH 4TH DEPTH
My Verizon
Tools Voice Commands Call <Name or # >
Send <MSG Type> Go To <Shortcut> Check <Item> Contact <Name>
Calculator
Tip Calculator
Calendar Monthly View
Search
Weekly View
Daily View
Event Detail View
Add New Event Subject
Location Start Date Start Time End Date End Time Recurrence Alert Tone Vibrate Alert Time Reminder Email Reminder Event Type Attendees Notes
01
02
03
04
05
06
07
23
Main Menu 2ND DEPTH 3RD DEPTH 4TH DEPTH
Setting Airplane Mode (ON/OFF)
24
Alarm clock Alarm 1 Set Time
Alarm 2
Alarm 3
Stop watch
World Clock
Unit Converter
My Locations Geo Info Connect
Geo Picture
Note Pad Note 1
Note 2
USB Mess Storage
Bluetooth (ON/OFF)
Music Only Mode (ON/OFF)
Bluetooth Settings Add New Device
Bluetooth Radio (ON/OFF)
Device Name Connect to Device
Repeat Ringtone
Send Message
Remove Device Rename Device Incoming Security Service Discovery Device Info
•BASIC OPERATION
Main Menu 2ND DEPTH 3RD DEPTH 4TH DEPTH
Sound Settings Ringtones
Display Settings Wallpaper
Touch Settings Touch Vibrate Feedback
Call Settings Auto Answer with Handsfree
Memory Save Options
Settings My Phone Name
Caller ID Readout Emergency Tone Alert Vibrate Alert Reminder Power On/O Sound Open/Close Sound Service Alerts Touch Audio Feedback Digit Dial Readout Device Connect
Banners Main Menu Settings Backlight Timer Backlight Brightness Display Theme Font Type Dial Fonts Menu Font Size Clock Format
Vibrate Level
Side Close to End Call Auto Retry TTY Mode Voice Privacy DTMF Tones Assistant Dialing
Phone Memory Card Memory
Discover Mode (ON/OFF) Auto Pair Handsfree (ON/OFF)
01
02
03
04
05
06
07
25
Main Menu 2ND DEPTH 3RD DEPTH 4TH DEPTH
Media Center Search
26
USB Mode USB Mode set to
Phone Info My Number
Music & Tones V Cast Music/Rhapsody
Picture & Video V CAST Videos
Games Shop Application
Browser
Change to
SW/HW Version Icon Glossary Software Update Operating System
Shop Ringtones Shop applications
My Ringtones Shop applications
My Music Play All Song
My Sounds Record New
Sync Music
Shop Pictures My Pictures My Videos Take Picture Record Video Online Album
All songs Playlists Artists Genres Albums Manage My Music Sync Music
Erase All
•BASIC OPERATION
Main Menu 2ND DEPTH 3RD DEPTH 4TH DEPTH
Browser
Direction VZ Navigator Launch VZ Navigator
Game
Search
V CAST Videos
My Music
Message New Message Text Message
Browse & Download VZ Navigator
Extras Shop Application
Inbox
Sent
Drafts
Voicemail
Visual Voicemail
Mobile IM
Email Mobile Email
Chat
More Erase All Messages
Visual Voice Mail Mobile Email Social Beat
Picture Message Video Message Voice Message
Mobile Web Mail
Quick Text Settings
01
02
03
04
05
06
07
27
Main Menu 2ND DEPTH 3RD DEPTH 4TH DEPTH
Email & IM Mobile Email
Mobile Web Mail
Mobile IM
Voicemail
Recent Calls All Calls
Missed Calls
Received Calls
Dialed Calls
Keypad
Contacts In Case of Emergency Personal Info Undened Note (List View)
28
Contact Detail Picture
Name Mobile Home Business Mobile 2 Fax Personal E-mail Business E-mail IM Send name Card Home Address Business Address Settings-Ringtone Favorites Groups Speed Dials Title Company Birthday Notes
•BASIC OPERATION
MAKING A CALL
1. On Home Screen, tap area code if needed).
• To erase one digit at a time, tap cancel key C.
•
To erase the entire number, touch and hold cancel key C.
•
When you place or receive a call from phone numbers stored in your Contact List with
a contact name, the name will be displayed.
2. Tap
Call
.
3. To end a call, tap
• If you activate the Auto Retry function, the phone will automatically re-dial the number (Refer to page 00).
•
You can also place calls using Voice-Activated Dialing. Please refer to page 00 for
more details.
Keypad (K
End
.
) and enter the phone number (include the
ANSWERING CALLS
1. When your phone rings or vibrates, open slide the phone and tap answer the incoming call.
2. To ignore incoming calls, tap
3. To end a call, tap
If Answer Options is set to “Auto with Handsfree”, calls are answered automatically
after about ve seconds (Refer to page 112).
End
Ignore
.
.
Answer
MISSED CALL NOTIFICATION
When an incoming call is not answered, the Missed Call icon appears on the display.
TO DISPLAY THE MISSED CALL ENTRY FROM THE NOTIFICATION SCREEN:
1. Tap
View Now
2. Tap
.
OPEN
to view the call details.
01
02
03
04
05
06
07
to
29
TO DISPLAY A MISSED CALL ENTRY FROM IDLE MODE:
1. In the Home Screen, tap
2. Tap
Missed Calls
.
Recent Calls
.
3. Highlight the entry you wish to view.
4. To dial the phone number, tap
Call
.
WAIT/PAUSE FEATURE
Pauses are used for automated systems (i.e., voice mail or calling cards). Insert a pause after a phone number and then enter another group of numbers. The second set of numbers is dialed automatically after the pause. This feature is useful for dialing into systems that require a code.
Wait (w)
The phone stops dialing until you tap
Call
to advance to the next number.
2-Sec Pause (p)
The phone waits 2 seconds before sending the next string of digits automatically.
1. In the Home Screen, enter the phone number.
2. Tap
More
.
3. Select
2-Sec Pause
.
4. Enter additional number(s) (pin number or credit card number).
5. Tap
Call
to dial or tap
Save
to save.
MAKING AN INTERNATIONAL CALL
1. In the Home Screen, then tap multitap keypad. The + required for international calls appears.
2. Enter the country code, area code, and phone number, then tap
3. To end the call, tap
30
End
.
Keypad (K
), press and hold the * key in the
Call
•BASIC OPERATION
3WAY CALLING
With 3-Way Calling, you can talk to two people at the same time. When using this feature, normal airtime rates will be applied for each of the two calls.
1. In the Home Screen, tap to call, then tap the
Call
Keypad (K
.
) and enter the phone number you wish
2. Once you have established the connection, enter the second phone number you wish to call and then tap
3. When you’re connected to the second party, tap
Call
.
Call
again to begin your 3-Way
call.
If one of the people you called hangs up during your call, you and the remaining caller
stay connected. If you initiated the call and are the rst to hang up, all three calls will be disconnected.
CALL WAITING FUNCTION
If you are on a call and you receive another incoming call, you will hear a beep and the caller’s phone number will appear on the display. With Call Waiting, you may put the active call on hold while you answer the other incoming call.
1. To answer another call while on the phone, tap hold. To switch back to the rst caller, tap
Call
. This places the rst call on
Call
again.
CALLING A NUMBER FROM CONTACTS
1. In the Home Screen, tap
2. Select the Contact entry and tap
3. Tap
Call
to place the call.
Selecting the Contact entry and then tapping
.
Contact entry automatically.
Contacts
.
VIEW
, then select the desired phone number.
Call
will dial the Default Number of the
31
ADJUSTING VOLUME
TO ADJUST THE MASTER VOLUME:
1. Press the Volume Keys / up or down.
• Press the Volume Keys / up or down to adjust Earpiece volume during a call.
CALLER ID FUNCTION
Caller ID displays the number of the person calling when your phone rings. If the caller’s identity is stored in Contacts, the name appears on the screen. The caller ID is stored in the Recent Calls menu.
VIBRATE MODE
Vibrate Mode mutes key tones and alerts for an incoming call, message, voicemail and missed call. To activate Vibrate Mode:
1. In the
Home Screen
the right of the menu bar.
, tap
Settings, Sound Settings
, tap ON/OFF buttons on
SPEAKERPHONE MODE
The Speakerphone feature lets you hear audio through the speaker and talk without holding the phone.
1. To activate speakerphone in call screen, tap of incoming and outgoing call screen.
Speaker
button in the lower part
USING AUTO LOCK FUNCTION
When slide opened, the device shall automatically enter the Lock mode after a period inactivity
• Auto Lock and LCD backlight timers are combined: device enters Lock Mode and
backlight turns o at the same time.
• Auto Lock timer shall be user settable from
32
Settings
/
Display Settings
•BASIC OPERATION
Backlight Timer
• Auto Lock shall be deactivated when in AVR mode or when watching video. Deactivating Auto Lock for additional applications must be approved by Verizon Wireless.
• When slide is opened and phone is locked, press side key and tap
Unlock”
• When slide is closed and phone is locked, slide open to unlock the phone.
AVAILABLE OPTIONS DURING A CALL
During a phone call, you can access the following features by tapping More:
NEW MESSAGE
To access the Messages Menu during a call:
1. Tap
. The default timer shall be set to 45 seconds.
to unlock the phone.
More
, and
New Message
.
“Touch to
01
02
03
04
05
06
07
CONTACT LIST
To view your Contact List during a call:
1. Tap
More
, and
Contact List
.
RECENT CALLS
To view your Recent Calls list during a call:
1. Tap
More
, and tap
Recent Calls
.
BLUETOOTH
To access the Bluetooth® Menu during a call:
1. Tap
More
, and tap
Bluetooth
If an Audio device is connected, Audio To Phone / Audio To Device is displayed in the
options menu instead of Bluetooth.
.
MAIN MENU
/
To access the Main Menu during a call:
1. Tap
More
, and tap
Main Menu
.
33
NOTEPAD
To compose notes during a call:
1. Tap
More
, and tap
Notepad
.
VOICE PRIVACY
To turn the voice privacy feature On or O :
1. Tap
More
, and tap
Voice Privacy
.
MAKING AN EMERGENCY CALL
The E911 feature automatically places the phone in Emergency Call Mode when you dial the preprogrammed emergency number, out of the service area.
911 IN LOCK MODE
To make an emergency call in Lock Mode:
1. In the Home Screen, tap
2. The call connects.
3. The phone maintains Emergency Mode for 5 minutes. When the call ends, the phone returns to Lock Mode.
911 USING ANY AVAILABLE SYSTEM
To make an Emergency Call using any available system:
1. In the Home Screen, tap
2. The call connects.
3. The phone will stay in Emergency Mode for 5 minutes. While the phone is in the Emergency Mode for 5 minutes, the phone can receive an incoming call from any available system or you can make outgoing calls even in the Emergency Callback Mode.
34 34
Keypad (K
Keypad (K
911
. It also operates in Lock Mode and
) and enter “
911
”, then tap
) and enter “
911
”, then tap
Call
Call
MEMORY FUNCTION
This chapter addresses memory functions including:
Storing a phone number
Editing contact entries
Entering letters, numbers & symbols
One, Two, Three-touch dialing
.
.
J-TOUCH
™
3
Default numbers
STORING A PHONE NUMBER
The Contact List stores up to 1000 entries.
ADDING A NEW CONTACT
1. In the Home Screen, tap
2. Tap
New Contact
3. Tap Name eld and enter contact name.
4. Scroll
up or down and tap the information eld you want to ll in.
Mobile / Home / Business / Mobile 2 / Fax / Personal Email / Business Email
/
IM / Home Address / Business Address / Ringtone / Favorites /
Group
/
Default Number / Speed Dials / Title / Company / Birthday /
Notes
.
To add another phone number to a contact already stored in memory, tap the Contact
list bar and tab Edit.
5. Fill in the phone numbers and name information (up to 32 characters) in each eld.
6. Tap
Save
.
7. “
CONTACT SAVED
Tap
Back
to exit, or tap
OPTIONS TO CUSTOMIZE YOUR CONTACTS
Once the basic phone number and name information is stored in your Contacts, you can edit and/or customize the entries.
1. In the Home Screen, tap
2. Tap
Edit
.
3. Select the information eld you want to customize.
4. Change the data as necessary, then tap
36
Contacts
.
.
” displays, then the phone number reappears on the screen.
Call
to call the number.
Contacts
, and tap contact entry you want to edit.
Save
to update the contact entry.
•memory function
ADDING OR CHANGING GROUPS
To organize your Contacts into groups:
1. In the Home Screen, tap
2. Tap
Edit
.
3. Tap
Group
4. Tap
5. Tap
and select groups you want to change.
Done
to set the group.
Save
to update the contact entry.
Contacts
, and tap contact entry you want to edit.
CHANGING THE CALL RINGTONE
To identify who is calling by setting dierent ringtones for dierent phone numbers in your Contacts:
1. In the Home Screen, tap
2. Tap
Edit
.
3. Scroll to
Ringtone
4. Select Ringtones from
5. Tap Play button
6. Tap
Save
.
7. “
CONTACT SAVED
8. Tap
Done
to change your Rington.
Contacts
, and tap contact entry you want to edit.
eld, and tap the bar.
Chnge To
p
list.
and listen to the ringtone. If you like it, tap the bar.
” is displayed.
ADDING OR CHANGING THE PIC/VIDEO ID
To select a picture or video to assign to a Caller ID:
1. In the Home Screen, tap
2. Tap
Edit
.
3. Tap Picture ID in Name eld. If Picture ID is exist, tap
Contacts
, and tap contact entry you want to edit.
Change
.
4. Scroll to tap a picture/video clip.
5. Flicking the screen left and right to select picture/video, and tap the screen.
6. When completed, tap
Set Picture ID
to change the Picture ID.
01
02
03
04
05
06
07
37
ADDING OR CHANGING AN EMAIL ADDRESS
To enter or add an Email address to a Contact entry:
1. In the Home Screen, tap
Contacts
.
2. Tap contact entry you want to add or change an email address.
3. Tap
Edit
.
4. Tap
Personal Emal
or
Business Email
.
5. Enter an Email address using the Keypad, and tap entry.
Just turning your phone to landscape position, QWERTY Keypad appears for easy
text input.
ADDING A SPEED DIAL ENTRY
To add an entry to Speed Dial:
1. In the Home Screen, tap
Contacts
.
2. Tap contact entry you want to add a speed dial number.
3. Tap
Edit
.
4. Scroll up and down and tap
Speed Dial
eld.
5. Enter number from 2 to 99 using numeric keypad.
6. Tap the Speed Dial bar.
7. Tap
Save
to update the speed dial.
You can search unslide the phone up to tap the corresponding speed dial number to
select the location.
EDITING CONTACT ENTRIES
ADDING A PHONE NUMBER FROM IDLE MODE
1. In the Home Screen, tap save (up to 32 digits).
2. Tap
Save
3. Tap
Update Existing
38
.
Keypad
, and enter the phone number you want to
.
Done
to update the contact
•memory function
4. Tap the existing Contact entry.
5. Tap the following phone number type eld.
Mobile / Home / Business / Mobile 2 / Fax
6. If a phone number is already assigned to the type you selected, select overwrite the existing entry.
7. “
CONTACT UPDATED
screen. Tap
” displays, then the phone number reappears on the
Call
to call the number.
ADDING A PHONE NUMBER FROM THE CONTACT LIST SCREEN
1. In the Home Screen, tap
2. Tap the Contact entry you want to edit, then tap
3. Tap the phone number eld and enter the number, then tap
Contacts
. Your Contacts are displayed alphabetically.
Edit
.
Save
to update
the contact entry.
4. “
CONTACT UPDATED
screen. Tap
” displays, then the phone number reappears on the
Call
to call the number.
EDITING STORED PHONE NUMBERS
1. In the Home Screen, tap
2. Tap the Contact entry you want to edit, then tap
Contacts
. Your Contacts are displayed alphabetically.
Edit
.
3. Select the phone number you want to edit.
4. Edit the phone number as necessary, and then tap
Save
to update the contact
entry.
EDITING STORED NAMES
1. In the Home Screen, then tap
Contacts
. Your Contacts are displayed
alphabetically.
2. Tap the Contact entry you want to edit, then tap
3. Edit the name as necessary, and then tap
Edit
.
Save
to update the contact entry.
Yes
01
to
02
03
04
05
06
07
39
DELETING A PHONE NUMBER FROM A CONTACT
1. In the Home Screen, tap
Contacts
2. Tap contact entry you want to edit.
3. Tap
Edit
.
4. Tap the desired phone number eld to delete.
5. Touch and hold the cancel key
6. Tap
Save
to update the contact entry. A conrmation message appears.
C
to delete the number.
DELETING A CONTACT ENTRY
1. In the Home Screen, tap
Contacts
2. Tap contact entry you want to delete.
3. Tap
Erase
.
4. Tap
Yes
. A conrmation message appears.
DELETING A SPEED DIAL
1. In the Home Screen, tap
Contacts
.
2. Tap contact entry you want to edit.
3. Tap
Edit
.
4. Tap the desired speed dial eld to delete.
5. Tap
Remove
.
6. Select numbers to remove from Speed Dial.
7. Tap
Done
. A conrmation message appears.
8. Tap
Save
to update the contact entry.
40
•memory function
DEFAULT NUMBERS
The phone number saved when a Contact is created is the Default Number. If more than one number is saved in a Contact entry, another number can be set as the Default Number.
The Default Number cannot be deleted. The entire Contact entry can be deleted or
another number can be assigned as the Default Number allowing you to delete the original number and keep the Contact entry.
CHANGING THE DEFAULT NUMBER
1. In the Home Screen, tap
2. Tap contact entry you want to edit.
3. Tap
Edit
.
4. Tap
Default Number
5. Tap the phone number you want to assign as the Default Number.
6. Tap
Save
to update the contact entry.
Contacts
eld.
01
02
03
04
05
06
07
41
ENTERING LETTERS, NUMBERS & SYMBOLS
Your device provides two kinds of entering method, Multi-tap Keypad and QWERTY Keypad, that provides a superior typing experience on a small handheld device for easy and comfortable input.
MULTITAP KEYPAD
You can enter text with multi-tap, predictive, numeric or symbol.
9
1. T9 Word Key ( ) :
2. Mode Change Key:
• When in Numeric entry mode
- Tap
•
When in Text entry mode
- Tap on the same key.
42
1 2
4 635
to change between entering letters that appear on the same key.
to change between entering numbers and symbols that appear
8 7
•memory function
3. More Key:
4. Done Key:
5. Space Key:
6. Cancel Key:
7. Clear Key:
8. Symbol Key ( ):
9. Shift Key ( ):
PREDICTIVE T9 WORD MODE
The predictive mode automatically compares your keystrokes with an internal linguistic dictionary to determine the correct word. It will display the most commonly used word rst. The most commonly used word will appear rst. To change another word listed in phone’s dictionary, tap and then select word you want to enter.
1. Tap
2. Press
ALPHABET INPUT MODE
Tap the key showed with the target letter once for the rst letter and twice for the second letter and so on.
1. Tap
2. Tap the letter key you want to input repeatedly. To write the letter “f”, tap
Go to More function available in text input mode.
Save input text and return to the previous screen.
Tap to accept a word and add a space while entering letters.
Cancel input text and return to previous screen.
When in a text entry eld and in entry mode, tap to delete the character to the left of the cursor. Touch and hold to delete the entire word or character string that was just entered.
Tap Symbol key to change between entering symbols
that appear on the same key.
Tap Shift key to select a letter case for the standard text
input mode.
key in pop-up window
and then the key pad change to T9 mode and display change to .
2
to 9 to input text. For example, to write ‘hello’ press
556
.
to change multi-tap mode.
43
3
3 times.
01
02
03
04
05
06
07
43
NUMERIC MODE
You can input numbers in this mode.
1. Tap
to change the numeric mode.
2. Tap
to and to input numbers.
SYMBOL MODE
You can input symbols.
1. Tap
to view the symbols.
2. Tap
/ to view other symbols
3. Select symbol you want to insert.
QWERTY KEYPAD
1
2
1. Shift Key:
Tap to select a letter case for the standard text [abc] input mode.
2. Done Key:
3. More Key:
Save input text and return to the previous screen.
Go to More function available in text input mode.
4. Mode Change Key:
• When in Numeric entry mode
- Tap
to change between entering letters that appear on the same key.
44
•memory function
•
When in Text entry mode
- Tap
to change between entering numbers and symbols that appear
on the same key.
5. Space Key:
6. Cancel Key:
7. Enter Key:
8. Clear Key:
Tap to accept a word and add a space while entering letters.
Cancel input text and return to previous screen.
Tap to insert a carriage return.
When in a Text entry eld and in entry mode, tap to delete the character to the left of the cursor. Touch and hold to delete the entire word or character string that was just entered.
9. Keypad show/hide key:
Tap to show or hide keypad.
SWITCHING THE KEYPAD
You can change your keypad just by turning your device vertically or horizontally.
9
The on-screen keytop showings may change according to the input mode or the menu it is used.
8
7
6
4
3
5
45
ONE, TWO, THREETOUCH DIALING
Ideal for frequently dialed numbers, this feature allows contact entries to be dialed via the keypad with only one, two, or three key strokes.
ONETOUCH DIALING:
1-9:
In the Home Screen, tap to connect to for more than 1 second. your voicemail box.
TWOTOUCH DIALING:
10-94:
In the Home Screen, tap
second digit of the number to dial.
95, 96, 97, 98 and 99:
THREE  TOUCH DIALING:
100-500:
In the Home Screen, tap the  rst and second digits, then touch and hold
the third digit of the number to dial.
411:
Speed Dial entry 411 (
Keypad
, then touch and hold the number you wish
(Voicemail
) is already assigned to
Keypad
the  rst digit and touch and hold the
Speed Dial entries
97(#BAL), 98(#MIN)
95(#Warranty Center), 96(#DATA)
and
99(#PMT)
to Verizon Wireless Account Information.
Directory Assistance
) is already assigned.
are already assigned
This chapter addresses accessing the menu and using its functions
CONTACTS
New Contact
Contact List
Backup Assistant
Groups
Speed Dials
,
In Case of Emergency
My Name Card
RECENT CALLS
Access and Options
All Calls
Touch Key Settings
and features to customize your JTOUCH
Missed Calls
Received Calls
Dialed Calls
View Timers
SETTINGS
Bluetooth Sounds Settings Display Settings
Phone Settings
Call Settings
USB Mode
Phone Info
Set-up Wizard
Voice Commands
Calculator
Tip Calculator
Calendar Self Icon
Memory
TOOLS
E-Diary
MENU FUNCTION
4
Alarm Clock
Stop Watch
World Clock
Notepad
USB Mass Storage
MY VERIZON
My Verizon
TM
.
J-TOUCH
46
™
NEW CONTACT
To add a new number to your Contact List:
Using this submenu, the number is saved as a new Contact. To save the number into
an existing Contact or edit the Contact entry.
1. In the Home Screen, tap
2. Tap
New Contact
Contacts
.
.
3. Tap Name eld and enter contact name.
To change the input mode, select text input mode ( [T9 Word], [ABC], [Abc], [abc],
[123], [Sym] ).
4. Scroll up or down and tap the information eld you want to ll in. Field includes:
Mobile 1 / Home / Business / Mobile 2 / Fax / Personal Email / Business Email
/
IM / Home Address / Business Address / Ringtone / Favorites /
Groups
/
Default Number / Speed Dials / Title / Company / Birthday /
Notes
5. Tap
Save
to create the contact entry.
CONTACT LIST
You can review all the entries stored in your Contact List by icking the list or quickly nd a list by tapping a rst character on the keypad below. Keypad may be dragged down to show more list.
1. In the Home Screen, tap
The list of names in your contacts is displayed.
2. Select the name or number by scrolling Tray Icon, or tap initial letter to the
alpha numeric keypad.
• Any letter corresponding to the rst letter of a saved contact is touchable. Other letters
are visually distinct and inactive.
48
Contacts
.
•CONTACTS
• Tap More, and you can choose Text, Pix, Video, Voice messages and Send Name Card:
3. To dial the selected number, tap the Call button s or tap contact entry bar to
Call, Send Message
or
Send Name Card
.
BACKUP ASSISTANT
Backup Assistant is a wireless service that stores a copy of your Contact List to a secure web site.
1. In the Home Screen, tap the
Contacts, More
, and
Backup Assistant
.
2. Follow the on-screen prompts.
GROUPS
Groups allow you to classify phone entries into groups with up to 10 members in each group. The default groups include Family and Work and they cannot be erased or renamed.
TO ADD NEW GROUP
1. In the Home Screen, tap
2. Tap
New Group
3. Enter a new group name, tap
All
and tap
Done
TO ASSIGN PHONE NUMBER TO GROUP
1. In the Home Screen, tap
2. Select the group where you want to add the contact, and then tap
3. Tap
Add
.
4. Your contact entries will be displayed in alphabetical order. Mark the contact you want to add or
5. Tap
Done
and “
Contacts, More
, and
.
Next
and tap entries you want to add or
.
Contacts, More
Mark All
, and
.
CONTACT ADDED TO GROUP
Groups
.
Groups
.
” will be displayed.
Mark
Options
.
01
02
03
04
05
06
07
49
TO CHANGE GROUP NAME
1. In the Home Screen, tap
Contacts, More
, and
2. Select the group you want to rename then tap
3. Tap
Rename Contacts
4. Enter the new group name, then tap
.
Done
.
ERASE GROUP
1. In the Home Screen, tap
Contacts, More
, and tap
2. Select the existing group you want to erase, and tap
3. Tap
Erase Group
4. A conrmation message “
5. Tap
Yes
.
to erase the group.
ERASE GROUP?
” appears on the screen.
TO SEND A TEXT MESSAGE TO A GROUP
1. In the Home Screen, tap
Contacts, More
, and tap
2. Select the group you want to send a message to, and tap
3. Tap
Send Message
4. Tap
Add Text
To insert items in your message, tap More and Add Quick Text, Add Graphic, Add
Sound, Add Name Card and Format Text.
5. Tap
Done
, and tap
and write your messages.
and tap
Send
.
Text Message
in select message type window.
TO SEND A PICTURE MESSAGE TO A GROUP
1. In the Home Screen, tap
Contacts, More
, and tap
2. Select the group you want to send a message to, and tap
3. Tap
Send Message, Picture Message
and tap
4. Scroll to tap a picture.
5. Flicking the screen left and right to select picture, and tap
50
Groups
.
More
.
Groups
More
Groups
Groups
Add Picture
. .
.
More
.
.
More
.
.
Add to Message
•CONTACTS
For detailed information on the picture, tap File Info, to show File Name, Date, Time,
Resolution and File Size.
6. Tap
Callback Number
7. Tap
Add Sounds
8. Tap
Add Subject
9. Tap
Add Name Card
desired card.
10. Tap
More
Slide
,
Priority Level or Lock
These options will vary depending on the message contents chosen.
11. To send the Picture Message, tap
TO SEND A VIDEO MESSAGE TO A GROUP
1. In the Home Screen, tap
2. Select the group you want to send a message to, and tap
3. Tap
Send Message
4. Scroll to tap a video clip.
5. You can play the video clip by tapping playbutton on the video screen.
For detailed information on the video, tap File Info, to show File Name, Date, Time,
Duration and File Size.
6. Tap
Callback Number
7. Tap
Add Subject
8. Tap
Add Name Card
desired card.
9. Tap
More
to select from the following options:
Remove Video
.
These options will vary depending on the message contents chosen.
10. To send the Video Message, tap
, enter the phone number to receive reply.
, select the sound you would like to send.
, input a subject.
, select
My Name Card
or
to select from the following options:
.
Send
.
Contacts, More
, and tap
, and tap
Video Message
, enter the phone number to receive reply.
, input a subject.
, select
My Name Card
,
Priority Level or Lock
Send
or
.
.
From Contacts
. Select the
Preview, Save As Draft, Add
Groups
.
More
.
in select video window.
From Contacts
. Select the
Preview, Save As Draft,
01
02
03
04
05
06
07
51
TO SEND A VOICE MESSAGE TO A GROUP
1. In the Home Screen, tap
2. Select the group you want to send a message to, and tap
3. Tap
Send Message
Contacts, More
, and tap
, and
Voice Message
Groups
.
More
in select video window.
4. When message “Press Record to start recording “ appears, tap recording.
5. After recording, you can
6. Tap
Callback Number
7. Tap
Add Subject
8. Tap
Add Name Card
Play, Record Again
or
Add to Message
, enter the phone number to receive reply.
, input a subject.
, select
My Name Card
or
From Contacts
desired card.
9. Tap
More
to select from the following options:
Remove Voice Recording
These options will vary depending on the message contents chosen.
10. To send the Voice Message, tap
,
Priority Level or Lock
Send
Preview, Save As Draft,
.
.
SPEED DIALS
From idle mode, calls can be placed to numbers stored in speed dials by sliding the phone up, and tapping & holding the location number on the keypad.
1. In the Home Screen, tap
2. Scroll to the desired Speed Dial position, or enter the Speed Dial digit, then and tap the desired Contact entry.
4. Highlight the number you wish to set to speed dial.
5. “
SET SPEED DIAL TO CONTACT?
“Unassigned” appears if the location is available.
52
Contacts, More
, and
” appears on the screen. Tap
Speed Dials
.
.
Record
.
. Select the
Yes
.
to start
•CONTACTS
TO ERASE A SAVED SPEED DIAL
1. In the Home Screen, tap
Contacts, More
, and
Speed Dials
.
2. Scroll to select the Speed Dial entry you want to erase.
3. Tap
Remove
Yes
.
REMOVE SPEED DIAL?
” appears on the screen.
.
4. A conrmation message “ Tap
IN CASE OF EMERGENCY
Your phone has a special menu to organize your emergency contacts and personal information.
TO ASSIGN EMERGENCY CONTACTS
Follow the procedures below to register a Contact to be contacted in case of emergency, or to register a medical record number or other personal info. To register up to three dierent Contacts to ICE:
1. In the Home Screen, tap
2. Tap
Personal Info
Back
.
3. Tap
Add Contact
TO REASSIGN EMERGENCY CONTACTS
1. In the Home Screen, tap
2. Tap
More
, then tap
3. Then select a contact from the Contacts List, tap Contact entry.
4. A conrmation message appears.
TO UNASSIGN EMERGENCY CONTACTS
1. In the Home Screen, tap
2. Select the contact you want to unassign, then tap
3. Tap
Unassign
Contacts
, and
In Case of Emergency
.
and enter your personal information on Note1-3 and tap
and select Contact entry.
Contacts, In Case of Emergency
Re-assign
. Select the contact you want to re-assign.
Contacts
, and tap
In Case of Emergency
More
.
.
.
.
01
02
03
04
05
06
07
53
TO CALL AN ASSIGNED EMERGENCY CONTACT
1. In the Home Screen, tap
2. Tap the contact entry you want to call or tap Call button (
Contacts
, and tap
In Case of Emergency
s
TO ADD PERSONAL INFO
To store a Medical Record Number or other information that may be useful in case of an emergency:
1. In the Home Screen, tap
2. Select
Personal Info
3. Select
Note 1, Note 2
4. Enter the information using the Keypad and then tap
5. The entered information now appears, when you tap
Note 3
.
.
or
Contacts
Note 3
, and tap
and then tap
In Case of Emergency
Edit
.
Save
.
Note 1, Note 2
TO EDIT SAVED PERSONAL INFO
1. In the Home Screen, tap
2. Select
Personal Info
.
Contacts
, and tap
In Case of Emergency
3. Select the Note you want to edit.
4. Tap
Edit
, edit the Note with keypad, then tap
Save
.
TO ERASE SAVED PERSONAL INFO
1. In the Home Screen, tap
2. Select
Personal Info
3. Select the Note you want to erase then tap
4. “ERASE?” will be displayed on the screen. Tap
.
Contacts
, and tap
In Case of Emergency
Erase
Yes
.
. A conrmation message
appears.
54
•CONTACTS
MY NAME CARD
.
).
.
or
.
.
A Name Card with the handset’s mobile number automatically appears.
EDIT MY NAME CARD
1. In the Home Screen, tap
2. Tap
Edit
.
3. Edit the My Name Card entry and then tap
Contacts
, and tap
My Name Card
Save
to save your changes.
.
CALL MY NAME CARD
1. In the Home Screen, tap
2. Select
Send via Bluetooth, Send via Text Msg, Send via Picture Msg, Send
via Video Msg
•
Send via Bluetooth:
1. Tap Add New Devices. If the Bluetooth power is switched o, the following message will appear on the screen: “TURN BLUETOOTH POWER ON?”.
2. When “PLACE DEVICE YOU ARE CONNECTING TO IN DISCOVERABLE MODE” appears, to start searching Bluetooth devices.
3. Flick the screen up or down to select a desired device and tap Pair Device. Please refer to
page 92 for more details on Bluetooth.
4. The handset may prompt you for the passkey. Consult the Bluetooth accessory (sold separately) instructions for the appropriate passkey (typically “0000” - 4 zeroes). Enter the passkey.
5. “Before Connecting To [Device Name]” will appear on the screen. Select Always Ask or
Always Connect.
Send via Text Msg:
• attachment.
1. Enter the recipient’s contact information.
2. Enter your message in the Text eld and then tap Call.
Send via Picture Msg:
• attachment.
1. Enter the recipient’s contact information.
2. Save your Voice Message and save to draft or send. Please refer to page 143 for more
details on Picture Message.
Contacts, More
or
Send via Voice Msg
Allows you to send Name Card to another Bluetooth® device.
Allows you to send Text messages with the Name Card as an
Allows you to send picture messages with the Name Card as an
and
Send Name Card
.
.
01
02
03
04
05
06
07
55
•
Send via Video Msg:
attachment.
1. Enter the recipient’s contact information.
2. Save your Voice Message and save to draft or send. Please refer to page 143 for more details on Video Message.
Send via Voice Msg:
• attachment.
1. Tap Record to begin recording a voice memo and tap Stop to nish recording
2. After recording, you can Play, Record Again and Add to Message.
3. Save your Voice Message and save to draft or send. Please refer to page 143 for more
details on Voice Message.
Allows you to send video messages with the Name Card as an
Allows you to send voice messages with the Name Card as an
RECENT CALLS
The Recent Calls menu is a list of the last phone numbers or Contact entries for calls you placed, accepted, missed, or blocked. It is continually updated as new numbers are added to the beginning of the list and the oldest entries are removed from the bottom of the list.
ACCESS AND OPTIONS
1. In the Home Screen, tap
2. Select a submenu.
• All Calls
•
Missed Calls
•
Received Calls
•
Dialed Calls
ALL CALLS
Displays information about the most recently received, dialed and missed calls.
1. In the Home Screen, tap
2. Tap the Send Key ( And do one of the following options:
• Tap
More
.
56
Recent Calls
Recent Calls
s
) in an entry to place a call the the number.
.
, and
All Calls
.
•RECENT CALLS
Sort by:
Sort by the phone number from All calls list.
Select Date and Time, Name or Call Length.
Erase:
Deletes the call from All calls list.
Select the contacts you want to delete, then tap Erase.
Erase All:
Deletes all entries from All calls list.
View Timers:
Displays usage time. Refer to the “View Timers” on page xx.
Blocked Calls:
Locks or unlocks the entry. You will need to enter a lock code.
The default lock code is the last 4 digits of your phone number.
• Tap an entry to view the entry.
Call:
Allows you to call to the number.
Send Message: Save to Contacts:
-
-
Allows you to send message to the contact.
Add New Contact: Update Existing:
After the 270 received, dialed or missed calls, the oldest call will automatically be
Allows you to save to the contacts List.
Allows you to add to the contacts List.
Allows you to update to the existing ontacts List.
erased from the history.
MISSED CALLS
Displays information about the 90 most recently missed calls.
1. In the Home Screen, tap
2. Tap the Send Key ( And do one of the following options:
• Tap
More
.
Sort by:
Sort by the phone number from Missed Calls list.
Select Date and Time, Name or Call Length.
Erase:
Deletes the call from Missed Calls list.
Select the contacts you want to delete, then tap Erase.
Erase All:
Deletes all entries from Missed Calls list.
View Timers:
Displays usage time. Refer to the “View Timers” on page xx.
Blocked Calls:
The default lock code is the last 4 digits of your phone number.
• Tap the Contact Number to view the entry.
Call:
Allows you to call to the number.
Recent Calls
s
) in an entry to place a call the the number.
Locks or unlocks the entry. You will need to enter a lock code.
, and
Missed Calls
.
01
02
03
04
05
06
07
57
Send Message: Save to Contacts:
-
-
Allows you to send message to the contact.
Add New Contact: Update Existing:
After 90 missed calls, the oldest call will automatically be erased from the history.
Allows you to save to the contacts List.
Allows you to add to the contacts List.
Allows you to update to the existing ontacts List.
RECEIVED CALLS
Displays information about the 90 most recently received calls.
1. In the Home Screen, tap
2. Tap the Send Key ( And do one of the following options:
• Tap
More
.
Sort by:
Sort by the phone number from Received Calls list.
Select Date and Time, Name or Call Length.
Erase:
Deletes the call from Received Calls list.
Select the contacts you want to delete, then tap Erase.
Erase All:
Deletes all entries from Received Calls list.
View Timers: Blocked Calls:
The default lock code is the last 4 digits of your phone number.
• Tap the Contact Number to view the entry.
Call:
Allows you to call to the number.
Send Message: Save to Contacts:
Add New Contact:
-
Update Existing:
­ After 90 received calls, the oldest call will automatically be erased from the history.
Recent Calls
s
) in an entry to place a call the the number.
Displays usage time. Refer to the “View Timers” on page xx.
Locks or unlocks the entry. You will need to enter a lock code.
Allows you to send message to the contact.
Allows you to save to the contacts List.
Allows you to add to the contacts List.
Allows you to update to the existing ontacts List.
, and
Received Calls
DIALED CALLS
Displays information about the 90 most recently dialed numbers.
1. In the Home Screen, tap
2. Tap the Send Key (
Recent Calls
s
) in an entry to place a call the the number.
, and
Dialed Calls
And do one of the following options:
58
•RECENT CALLS
• Tap
More
.
Sort by:
Sort by the phone number from Dialed Calls list.
Select Date and Time, Name or Call Length.
Erase:
Deletes the call from Dialed Calls list.
Select the contacts you want to delete, then tap Erase.
Erase All:
Deletes all entries from Dialed Calls list.
View Timers:
Displays usage time. Refer to the “View Timers” on page xx.
Blocked Calls:
Locks or unlocks the entry. You will need to enter a lock code.
.
The default lock code is the last 4 digits of your phone number.
• Tap the Contact Number to view the entry.
Call:
Allows you to call to the number.
Send Message: Save to Contacts:
-
-
Allows you to send message to the contact.
Add New Contact: Update Existing:
After 90 dialed calls, the oldest call will automatically be erased from the history.
Allows you to save to the contacts List.
Allows you to add to the contacts List.
Allows you to update to the existing ontacts List.
01
02
03
04
05
06
07
VIEW TIMERS
Checks the usage time and manages your calls within the limit you set. To view 11 timers (Last Call, All Calls, Received Calls, Dialed Calls, Roaming Calls, Transmit Data, Received Data, Total Data, Last Reset, Lifetime Calls, Lifetime Data Counter):
1. In the Home Screen, tap
2. Tap
More
, then tap
Recent Calls
View Timers
.
.
3. Call list appears. Call timers include:
Last Call / All Calls / Received Calls / Dialed Calls / Roaming Calls / Transmit Data Lifetime Data Counter
• Tap Reset to reset highlighted timer.
.
• Tap Reset All to reset all timers.
/
Received Data / Total Data / Last Reset / Lifetime Calls /
59
AIRPLANE MODE ON/OFF
In Airplane Mode, all menu functions can be accessed except making calls, receiving calls, data connection and Bluetooth®. Activating Airplane Mode will disable all wireless communications. Services that support Location On functions are temporarily disabled. To switch ON and OFF the Airplane Mode:
1. In the Home Screen, tap
2. Tap
ON/OFF
button of
Settings
.
Airplane Mode
.
BLUETOOTH ON/OFF
To switch ON and OFF the Bluetooth.
1. In the Home Screen, tap
2. Tap
ON/OFF
button of
Settings
.
Bluetooth
. Bluetooth status window appears.
MUSIC ONLY MODE ON/OFF
To switch ON and OFF the Music Only Mode:
1. In the Home Screen, tap
2. Tap
ON/OFF
button of
Settings
.
Music Only Mode
.
BLUETOOTH
Bluetooth® technology connectivity enables wireless connections between electronic devices. If connected with a Bluetooth handsfree device, you can use your phone more freely. Since devices with Bluetooth connectivity communicate using radio waves, your phone and the other device do not need to be in direct line-of-sight. The two devices only need to be within 10 meters (30 feet) of each other. The connection can be subject to interference from obstructions such as walls or other electronic devices. This device is compliant with Bluetooth specication 2.1, supporting the following proles: Headset, Handsfree, Stereo, Phonebook Access, Object Push for vCard and File Transfer. To ensure interoperability between other devices supporting Bluetooth technology, use approved enhancements for this model. Check with the manufacturers of other devices to determine their compatibility with this phone. There may be restrictions on using
60
•SETTINGS
Bluetooth technology in some locations. Check with your local authorities or Verizon Wireless. If you want more information on this function, visit the Bluetooth Technology organization Web site: https://www.bluetooth.org/.
Important:
Features using Bluetooth technology, or allowing such features to run in the background while using other features, increase the demand on battery power and reduce the battery life.
ADD NEW DEVICES
Pairing is the process that allows the handset to locate, establish and register a 1-to-1 connection with the target device.
1. In the Home Screen, tap
Devices
.
2. “
Place device you are connecting to in discoverable mode
Settings, Bluetooth Settings
, and
Add New
” appears on the
LCD screen.
3. Tap
Next
. “
Searching for Bluetooth device...
” appears.
4. If the Bluetooth® power is switched o, the following message will appear on the LCD screen: “
5. Devices will be listed on then tap
NO DEVICES FOUND, TRY AGAIN?
Devices found
Pair
.
”. Tap
Yes
.
. Select the device you wish to pair to,
6. The handset may prompt you for the passkey. Consult the Bluetooth accessory (sold separately) instructions for the appropriate passkey (typically “0000”  4 zeroes). Enter the passkey.
You do not need to input the passkey for pairing when the passkey of the Bluetooth
headset or hands-free kit is 0000.
7. The handset will prompt you with the following message on the LCD screen:
Before Connecting To [Device Name]
before connecting to the Bluetooth device, select handset will prompt you with the message “ Select
Yes
. If you do not wish to conrm every time before connecting to the
Bluetooth device, select
Always Connect
. If you would like to always conrm
Always Ask
. Then the
Connect To [Device Name]?
.
”.
01
02
03
04
05
06
07
61
8. Once connected, you will see the device listed in the Bluetooth menu and the Bluetooth device connected icon will appear at the top of the screen when connected to the Bluetooth device.
• In the Bluetooth menu, you can disconnect the connected device with an icon by tapping Drop. Conversely, you can reconnect by pressing the button again.
•
When an audio device is connected, you can select another device and the
connection is automatically transferred from that audio device to the other one. Following options are available: Send Name Card, Get Name Card, Send Picture, Send
Video and File Transfer.
•
If multiple devices are displayed, select the device you want to connect to.
OPTIONS
1. In the Home Screen, tap
Settings
, and
Bluetooth Settings
.
2. Select the paired device.
3. Tap
More
.
4. Select one of the following options.
•
Remove Device: Rename Device:
•
Incoming Security:
•
Service Discovery:
•
Device Info:
•
5. Or, tap to access
Video
are available:
•
Disconnect: Send Name Card:
•
1. Flick the screen up or down to highlight a desired contact or contacts, then tap MARK. If
2. Tap
Get Name Card:
•
Send Picture:
•
1. Flick the screen up, down, left or right to highlight a desired photo or photos, then tap
62
Removes a device from the pairing list. Renames a paired device.
Sets permissions for connecting an incoming device.
Searches for the services that the selected device supports.
Displays device information.
Send Name Card, Get Name Card, Send Picture, Send
or
File Transfer
you want to change your selections, tap UNMARK to deselect your selections.
Done
. Select the desired option and the following options
Disconnects the connected device.
Allows you to send name cards stored in Contacts to a selected device.
. If you want to send all the name cards, tap Send All.
Get name cards from the selected device.
Allows you to send photos to a selected device.
•SETTINGS
MARK. If you want to change your selections, tap UNMARK to deselect your selections.
2. Tap Done. If you want to send all the photos, tap Send All.
Send Video:
Allows you to send videos to a selected device.
•
1. Flick the screen up, down, left or right to highlight a desired video or videos, then tap
MARK. If you want to change your selections, tap UNMARK to deselect your selections.
2. Tap Done. If you want to send all the videos, tap Send All.
File Transfer:
Allows you to get les from the selected device.
•
SETTINGS
MY PHONE NAME
To edit the Bluetooth® name of your phone:
1. In the Home Screen, tap
2. Tap
Settings
3. Tap button on
Settings
.
My Phone Name
, and
Bluetooth Settings
.
.
4. Use the Keypad to enter a new custom name.
5. Tap
Done
to save and exit.
DISCOVERY MODE
To set whether your device is able to be searched for by other Bluetooth devices in the area:
1. In the Home Screen, tap
2. Tap
Settings
3. To turn on
Discovery Mode
If Bluetooth power is not on, it will be turned on automatically.
Settings
, and
Bluetooth Settings
.
.
, tap button switch to ON.
AUTO PAIR HANDSFREE
To set Auto Pair Handsfree On/O:
1. In the Home Screen, tap
2. Tap
Settings
3. To turn on
Auto Pair Handsfree
Settings
, and
Bluetooth Settings
.
.
, tap button switch to ON.
01
02
03
04
05
06
07
63
SUPPORTED PROFILES
To view brief descriptions of the proles supported by the phone:
1. In the Home Screen, tap
2. Tap
Settings
3. Tap
Supported Proles
subject:
Headset
Transfer
.
Settings, Bluetooth Settings
.
and information windows appears on the following
/
Handsfree
/
Dial Up Networking
SOUNDS SETTINGS
RINGTONES
To set ringtones for types of
Missed Call
and
1. In the Home Screen, tap
2.
Sound Setting
3. Scroll to
Ringtone
4. Ringtone selection windows appears. You can select and play
ringtone
or ringtones for the following categories:
Msg
/
Voicemail
To purchase additional Ringtone, tap Shop Ringtone and follow directions on the
screen.
CALLER ID READOUT
1. In the Home Screen, tap
2. Select
Ring Only, Caller ID + Ring or Name Repeat
EMERGENCY TONE
1. In the Home Screen, tap
2. Select from
64
Incoming Call, Txt Msg, Multimedia Msg, Voicemail
:
Settings
, and
Sounds Settings
list menu appears
menu and tap current ringtone button.
Change to
ringtone or
Shop Ringtone
Incoming Call
/
Missed Call
.
Setting, Sound Settings, Caller ID Readout
Settings, Sounds Settings
Alert, Vibrate
or O.
.
/
Object Push
/
.
Current
. You can organize your
/
Txt Msg /
Multimedia
.
.
, and
Emergency Tone
File
•SETTINGS
3. To view the help screen for
Emergency Tone
, tap
Help
.
ALERT VIBRATE
You can turn ON or OFF the Alert Vibrate for Incoming Call, Txt Msg, Multimedia Msg, Voicemail, Missed Call.
1. In the Home Screen, tap
2. Scroll to
Alert Vibrate
/
Txt Msg
/
Multimedia Msg/ Voicemail
Settings, Sounds Settings
and turn ON or
OFF
the Alert Vibrate for
/
Missed Call
.
Incoming Call
.
ALERTS REMINDER
You can change the Alerts Reminder for
,
Missed Call.
1. In the Home Screen, tap
2. Scroll to
Alert Reminder
Msg
/
Multimedia Msg
3. Tap menu bar to select
Txt Msg, Multimedia Msg, Voicemail
Settings, Sounds Settings
.
and select Alert Reminder you want to change:
/
Voicemail
/
Missed Call
.
Once, Every 2 minutes, Every 15 minutes
or
O.
, and
Txt
01
02
03
04
05
06
07
POWER ON/OFF SOUND
To set the phone to sound a tone when the phone is powered on or o.
1. In the Home screen, tap
2. Scroll to
Power On/O Sound
O
.
Settings, Sound Settings
and tap
ON/OFF
button for
.
Power On
or
Power
OPEN/CLOSE SOUND
To set the phone to sound a tone when opening or closing slide.
1. In the Home screen, tap
2. Scroll to
Open/Close Sound
Close
.
.
3. Select and tap sound listings under
Before selection, you can play the sound by tapping play button p.
Settings, Sound Settings
and tap selection button on
Change to
.
.
Slide Open
or
Slide
65
SERVICE ALERTS
To set any of the three Alert options to either On or O.
1. In the Home screen, tap
2. Scroll to
Service Alerts
ERI
: The Enhanced Roaming Indicator (ERI) feature displays a text banner on
Settings, Sound Settings
and tap
ON/OFF
button of the following options:
.
the display screen informing the handset user of which systems the wireless device is using as compared to the service plan they purchased. The ERI Banner text changes to tell a customer if they are using the Verizon Wireless Network, Extended Network or Roaming.
Minute Beep Call Connect Software Update
: Alerts you every minute during a call.
: Alerts you when the call is connected.
: Alerts you when updating software.
TOUCH AUDIO FEEDBACK
To set the phone to sound a tone when touching the screen.
1. In the Home screen, tap
2. Scroll to
Touch Audio Feedback
Settings, Sound Settings
and tap ON/
OFF
button.
DIGIT DIAL READOUT
The Digit Dial Readout setting controls if digits are read out when you enter a phone number with the keypad.
1. In the Home screen, tap
2. Scroll to
Digit Dial Readout
Settings, Sound Settings
and tap ON/
OFF
button.
.
DEVICE CONNECT
Allows you to turn the Device Connect On or O.
1. In the Home screen, tap
2. Scroll to
66
Device Connect
Settings, Sound Settings
and tap ON/
OFF
button.
.
•SETTINGS
DISPLAY SETTINGS
WALLPAPER
To choose the background wallpaper to be displayed on the Home Screen:
1. In the Home Screen, tap
2. Tap picture icon under
3. In
Select Picture
• To take a picture for Wallpaper, tap Take Picture, shot a new picture and Set As
Wallpaper.
•
To purchase additional wallpaper image, tap Shop Pictures and follow directions on
the screen.
4. Larger picture appears on screen with left and right navigator button. Tap the button to search more pictures or tap
To preview more full-screen picture, touch the picture.
BANNER
To set your Personal or ERI banner:
PERSONAL BANNER
The Personal Banner can be up to 16 characters and is displayed on your phone’s display screen from idle mode.
1. In the Home Screen, tap
2. Scroll to
Banner
2. Enter or edit the banner text (up to 16 characters) and tap
ERI BANNER
If you use ERI Service, ERI Text is shown on the sub banner.
1. In the Home Screen, tap
2. Scroll to
Banner
Settings
, and
Wallpaper
Display Settings
.
.
window, scroll and tap a thumbnail picture.
Settings, Display Settings
, and tap button in
Settings, Display Settings
, and tap ON/
OFF
Set As Wallpaper
Personal
button of
ERI
.
.
.
.
.
Save
.
01
02
03
04
05
06
07
67
MAIN MENU SETTINGS
To change Main Menu layout and type:
1. In the Home screen, tap
2. Scroll to
Main Menu Settings
Settings, Display Settings
and select
POSITION MENU ITEMS
Allows you to move the position of the Main Menu to a dierent position.
1. Drag the item you want to move to new position.
2. Tap
Save
to return to Menu Settings.
REPLACE MENU ITEMS
Allows you to replace Main Menu with desired menus.
1. Touch the item you want to replace.
2. Select an item in the list to replace it.
3. Tap
Save
to save and return to Menu Settings.
CHANGE MENU LAYOUT
Allows you to change Menu Layout with desired menus.
1. To change the layout displayed in under the
2. You can select
Change to
Shotcuts
listings.
or
Grid
Current Menu Layout
.
CHANGE MENU PROFILE
Allows you to change Menu Prole with desired menus.
1. To change the menu prole displayed in bar under
Change to
Tap Help to view the help screen for the Menu Prole
2. You may select from
or
Communicator
.
3. 'SET MENU PROFILE ?' appears. Tap
68
.
Multimedia, Personalize, Messaging, Productivity
Current Menu Layout
Yes
to change.
.
.
, tap menubar
, tap menu
•SETTINGS
RESET MENU SETTINGS
Allows you to reset Main Menu Settings.
1. Select
Menu Layout, Menu Items, Item Positions
2. Tap
Done
to return to Menu Settings, or tap
Menu Settings.
-
Menu Items and positions:
content of the Main Menu.
Menu Layout:
-
Menu Prole
-
All
: Reset all Main Menu Settings to the initial Main Menu Settings.
- Tap
Help
to view the help for the Menu Prole.
Reset Menu Items and positions to the initial order and
Reset Menu Layout to the initial Menu Layout.
: Reset Menu Prole to the initial Menu Prole.
BACKLIGHT TIMER
To set the duration for backlight illumination of the Main Screen:
1. In the Home screen, tap
2. Scroll to
Backlight Timer
3. Select
30 Seconds, 45 Seconds, 1 Minute, 1 1/2 Minute, 2 Minute
Always On
.
Even if Always On is selected for the Backlight Timer setting, the backlight will turn o
when the phone is powered o.
Setting, Display Settings
and tap button.
or
All
Help
.
to view the help for Reset
.
01
02
03
04
05
06
07
or
BACKLIGHT BRIGHTNESS
To set the brightness for backlight illumination of the Main Screen:
1. In the Home screen, tap
2. Switch
ON
Done
the
.
3. Tap
DISPLAY THEME
To choose the background screen:
1. In the Home screen, tap
Setting, Display Settings, Backlight Brightness
Auto Brightness
or tap Brightness level control bar manually.
Settings, Display Settings
.
69
2. Scroll to
Display Theme
3. Tap
Pastel White
Tap Help to view the help for the Display Theme.
or
Misty Black
.
, and tap
FONT TYPE
To set the font type:
1. In the Home screen, tap
2. Scroll to
Font Type
3. Select from
Font
.
Settings, Display Settings
.
VZW Font, Modern Font, Dandy Font, Classic Font
DIAL FONTS
To set the dial font size:
1. In the Home screen, tap
2. Scroll to
Dial Fonts
3. Select
Normal
Settings, Display Settings
.
or
Large Only
.
MENU FONT SIZE
To set the menu font size:
1. In the Home screen, tap
2. Scroll to
Menu Font Size
3. Select
Normal, Large
Settings, Display Settings
.
or
Small
.
CLOCK FORMAT
To choose the kind of clock to be displayed on the LCD screen:
1. In the Home screen, tap
Setting, Display Settings, Clock Format
2. Scroll the screen left or right to select from
Large Digital 12, Digital 24, Large Digital 24
'Large Digital 12' is the default setting for this device.
70
Set As Display Theme
.
.
or
Episode
.
.
Analog, Large Analog, Digital 12
, O and tap
Set Clock Format
•SETTINGS
TOUCH SETTINGS
TOUCH VIBRATE FEEDBACK
To choose the background wallpaper to be displayed on the Home Screen:
1. In the Home screen, tap
2. Switch
ON
or
If ON is selected, Vibrate Level menu is displayed.
Settings, Touch Settings, Touch Vibrate
OFF
for the
Touch Vibrate Feedback
.
.
VIBRATE LEVEL
1. In the Home screen, tap
2. Select
Low, Medium
Settings, Touch Settings, Touch Vibrate
or
High
.
.
PHONE SETTINGS
VOICE COMMANDS SETTINGS
LANGUAGE
To set the bilingual feature to either English or Espanol:
1. In the Home screen, tap
2. Select either
LOCATION
1. In the Home screen, tap
2. Select one of the following settings.
•
Full Detection: E911 Only:
Your location will be hidden from the network and applications, except for 911.
•
,
.
When Lock Setting is set for Location Setting under Restrictions on the Security menu,
you will need to enter a lock code. The default lock code is the last 4 digits of your phone number.
Settings, Phone Settings, Language
English
or
Espanol
.
Setting, Phone Settings, Location
Your location is now available to the network.
.
.
01
02
03
04
05
06
07
71
CURRENT COUNTRY
Allows you to set the country of your current location so that your phone works properly while you travel.
1. In the Home screen, tap
Setting, Phone Settings, Current Country
2. Select the desired country.
Tap Help to view the help for the Current Country.
SECURITY
The Security menu allows you to electronically secure the phone.
The default lock code is the last 4 digits of your phone number.
EDIT CODES
To set a new lock code:
1. In the Home screen, tap
Settings, Phone Settings, Security
2. Enter the four-digit lock code.
3. Tap
Edit Codes
.
4. Select one of the following settings.
•
Phone Only:
Allows you to edit the lock code for Security. (The default lock code is the
last 4 digits of your phone number.)
Calls & Services:
• is the last 4 digits of your phone number.)
5. If
Phone Only Security Code New Code
6. If
Calls & Services & Services Cod & Services Code New Code
72
Allows you to edit the lock code for Restrictions. (The default lock code
is selected, enter the new four-digit code in the
eld. Enter the new four-digit code again in the
eld to conrm your input.
is selected, enter the current lock code in the
e eld. Enter the new four-digit code in the
eld. Enter the new four-digit code again in the
eld.
.
.
Enter New
Re-enter
Enter Calls
Enter New Calls
Re-enter
•SETTINGS
RESTRICTIONS
Use the following procedure to congure Location Setting, Calls and Messages restrictions.
1. In the Home screen, tap
Settings, Phone Settings, Security
.
2. Enter the four-digit lock code. The default lock code is the last 4 digits of your phone number.
3. Tap
Restrictions
.
4. Select one of the following settings:
•
Location Setting: Calls:
• For Incoming Calls, select Allow All, Contacts Only or Block All. For Outgoing Calls, select Allow All, Contacts Only or Block All.
Messages:
• For Incoming Messages, select Allow All or Block All. For Outgoing Messages, select Allow All or Block All.
Dial-Up Modem:
•
Unlock Setting/Lock Setting.
Incoming Calls/Outgoing Calls.
Incoming Messages/Outgoing Messages.
Allow/Block.
PHONE LOCK SETTING
This setting species whether the phone should be locked whenever it is turned on. Lock Mode prevents the unauthorized use of your phone. Once the phone is locked, it is in restricted mode until the lock code is entered. You can still make emergency calls.
1. In the Home screen, tap
Settings, Phone Settings, Security
.
2. Enter the four-digit lock code. The default lock code is the last 4 digits of your phone number.
3. Tap
Phone Lock Setting
.
4. Select one of the following settings.
•
Unlocked:
Phone is unlocked.
On Power Up:
•
Phone will lock when it is turned on.
01
02
03
04
05
06
07
73
LOCK PHONE NOW
Lock the phone now.
1. In the Home screen, tap
Settings, Phone Settings, Security
2. Enter the four-digit lock code. The default lock code is the last 4 digits of your phone number.
3. Tap Lock Phone Now.
RESTORE PHONE
To delete all User Data and restore all settings to their initial defaults:
1. In the Home screen, tap
Settings, Phone Settings, Security
2. Enter the four-digit lock code. The default lock code is the last 4 digits of your phone number.
3. Tap
Restore Phone.
4. A conrmation message appears in the display, select
5. After reading the message that appears, tap
Next
Yes
.
6. Enter the four-digit lock code. The phone will turn o and then back on again automatically.
CALL SETTINGS
AUTO ANSWER WITH HANDSFREE
To determine how to answer an incoming call:
1. In the Home Screen, tap
handsfree
2. Select
ON/OFF
SLIDE CLOSE TO END CALL
1. In the Home Screen, tap
2. Select
ON/OFF
74
.
Settings, Call Settings
.
Settings, Call Settings
.
, and
Auto Answer with
, and
Slide close to end call
, and.
•SETTINGS
AUTO RETRY
To set a period of time the phone waits before automatically redialing when an
.
.
attempted call fails:
1. In the Home Screen, tap
2. Select
O, 10 Seconds, 30 Seconds or 60 Seconds
Settings, Call Settings
, and
.
Auto Retry
.
TTY MODE
You can attach a TTY device to your phone enabling you to communicate with parties also using a TTY device. A phone with TTY support is able to translate typed characters to voice. Voice can also be translated into characters and then displayed on the TTY.
1. In the Home Screen, tap
2. Select
TTY Full, TTY + Talk, TTY + Hear or TTY O
Settings, Call Settings
, and
TTY Mode
.
.
VOICE PRIVACY
Voice Privacy provides advanced voice encryption to prevent eavesdropping. To turn the voice privacy feature On or O:
1. In the Home Screen, tap
2. Select
ON/OFF
.
Settings, Call Settings
, and
Voice Privacy
.
01
02
03
04
05
06
07
DTMF TONES
To set the Key Tone length and touch tone playback speed:
1. In the Home Screen, tap
2. Select
Normal or Long
•
Normal:
Sends out a tone for a xed period of time even if you continue to tap the key.
Long:
Sends out a continuous tone for the duration the key is taped and held.
•
Settings, Call Settings
.
, and
DTMF Tones
.
ASSISTED DIALING
To set the Assisted Dialing feature On or O:
.
1. In the Home Screen, tap
2. Select
ON/OFF in the Assisted Dialing
Settings, Call Settings
.
, and
Assisted Dialing
.
75
MEMORY
SAVE OPTIONS
To select whether to save to Phone Memory or to Card Memory when saving les:
1. In the Home Screen, tap
2. Select
Pictures, Videos or Sounds
3. Select
Phone Memory or Card Memory in the Pictures, Videos or Sounds
menu.
PHONE MEMORY
Allows you to manage the memory usage for pictures, videos, ringtones, music, sounds and contacts on your Phone Memory.
PHONE MEMORY USAGE
To check the available Phone Memory capacity, used capacity and total capacity:
1. In the Home Screen, tap
2. Tap
Phone Memory Usage
3. Tap
Back
to return to the previous screen.
DELETING AND MOVING FILES
To delete les stored in Phone Memory or to move les from Phone Memory to Card Memory:
1. In the Home Screen, tap
2. Select
My Pictures, My Videos, My Ringtones, My Music, My Sounds or
My Contacts
3. Tap
More
4. Select
Erase
If you have selected My Contacts, you can select Move to Card, Copy to Card or Erase
after tapping More. If you want to copy the contacts, tap Copy to Card.
5. Select a le, or tap
76
.
.
to delete a le or
Mark All
Settings, Memory
.
Settings, Memory
.
Settings, Memory
Move to Card
, then tap
Move
, and
Save Options
, and
Phone Memory
, and
Phone Memory
to move a le to Card Memory.
.
•SETTINGS
MOVE ALL TO CARD
To move all les saved in Phone Memory to Card Memory(memory card sold separately).
.
1. In the Home Screen, tap
2. Select
Move All To Card
3. Select
Yes
.
Do not remove the memory card from the phone while a le or les are being moved
to Card Memory.
CARD MEMORY
Allows you to manage the memory usage for pictures, videos, music, sounds and contacts on your Card Memory. The memory card(sold separately) must be inserted into the phone to perform these functions.
.
CARD MEMORY USAGE
To check the available Card Memory capacity, used capacity and total capacity:
1. In the Home Screen, tap
2. Tap
Card Memory Usage
3. Tap
Back
to return to the previous screen.
Settings, Memory
.
Settings, Memory
.
, and
Phone Memory
, and
Card Memory
.
01
02
03
04
05
06
07
.
FORMAT CARD
.
To format the card inserted:
1. In the Home Screen, tap
2. Tap
Card Memory Usage
3. Tap
4. Tap
Format Card Yes
, enter your 4-digit lock code.
.
Settings, Memory
, then tap
More
, and
.
Card Memory
.
DELETING AND MOVING FILES
To delete les stored in Card Memory or to move les from Card Memory to Phone Memory:
1. In the Home Screen, tap
Settings, Memory
, and
Card Memory
.
77
2. Select
My Pictures, My Videos, My Music, My Sounds or My Contacts
3. Tap
More
.
4. Select
Erase
to delete a le or
If you have selected My Contacts, you can select Move to Phone, Copy to Phone or Erase
after tapping More. If you want to copy the contacts, tap Copy to Phone.
5. Select a le, or tap
Mark All
Move
to move a le to Phone Memory.
, then tap
Move
.
MOVE ALL TO PHONE
To move all les saved in Card Memory to Phone Memory:
1. In the Home Screen, tap
2. Select
Move All To Phone
3. Select
Yes
.
Do not remove the memory card from the phone while a le or les are being moved
to Card Memory.
Settings, Memory
.
, and
Card Memory
USB MODE
You can use a USB data cable to transfer data between the device and a compatible PC.
Important:
To activate your device for data transfer, select USB Mode before
connecting the USB data cable.
1. In the Home Screen, tap
2. Select
Modem Mode, Media Sync Mode or Ask On Plug
•
Modem Mode:
connecting with a USB data cable.
Media Sync Mode:
•
Player via USB data cable.
Ask On Plug:
Allows you to select USB Mode whenever the USB data cable is connected
•
from your computer to your phone.
• Even if Ask On Plug is set for USB Mode, you may not be asked to select USB Mode while receiving/making a call, using Bluetooth®, transferring data, etc.
•
To use End User Upgrade Tool, select Modem Mode for USB Mode.
78
Settings
, and
USB Mode
.
Allows you to use your phone as a modem for your computer when
Allows you to sync your phone music les with PC’s Windows Media
.
•SETTINGS
.
PHONE INFO
MY NUMBER
To view your phone number:
1. In the Home Screen, tap
Settings, Phone Info
, and
My Number
.
2. The following information appears:
Mobile Device Number (MDN) / Mobile Identication Number (MIN)
/
Other device information
.
3. Tap
Back
to return to the previous screen.
SW/HW VERSION
To view your device HW/SW information:
1. In the Home Screen, tap
Settings, Phone Info
, and
SW/HW Version
.
01
02
03
04
05
06
07
2. The following information appears:
Software Version / PRL Version / ERI Version / Browser Version / Media Center Version
/
Touch UI Version / Hardware Version / MEID
/
Software Update Client
3. Tap
Back
to return to the previous screen.
ICON GLOSSARY
To view all the icons and their meanings:
1. In the Home Screen, tap
2. Tap
Back
to return to the previous screen.
Please refer to Display Indicators on page xx for more details about the icons.
Settings, Phone Info
, and
Icon Glossary
.
SOFTWARE UPDATE
The Software Update option allows you to download and update the software in your phone automatically. Only the internal software is updated; Contacts entries or other information saved to your phone will NOT be deleted.
79
STATUS
Check the latest Software Download/Update status.
1. In the Home Screen, tap
2. Tap
Status
.
Settings, Phone Info
CHECK NEW
To check Download Server for new Software updates:
1. In the Home Screen, tap
2. Tap
Check New
Settings, Phone Info
.
OPERATING SYSTEM
1. In the Home Screen, tap
2. Tap
Back
to return to the previous screen.
Settings, Phone Info
EASY SETUP
SOUNDS
The Easy Set-up menu allows you to set ve stages for operation.
1. In the Home Screen, tap
2. Tap
Sounds
3. Select option for the followings.
•
CALL SOUNDS:
save the setting or tap Skip to go to the next setting.
TEXT MESSAGE ALERT:
• tap Exit to save the setting or tap Skip to go to the next setting.
PIC/VIDEO/VOICE MSG ALERT:
• then tap Exit to save the setting or tap Skip to go to the next setting.
VOICEMAIL MSG ALERT:
• tap Exit to save the setting or tap Skip to complete set-up.
80
Settings
and
.
Select Ring Only, Vibrate Only, Ring and Vibrate or Be Silent then tap Exit to
Select Ring Only, Vibrate Only, Ring and Vibrate or Be Silent then
Select Ring Only, Vibrate Only, Ring and Vibrate or Be Silent
Select Ring Only, Vibrate Only, Ring and Vibrate or Be Silent then
, and
Easy Set-up
, and
Software Update
, and
Software Update
Operating System
Sounds settings
.
.
with simple
•SETTINGS
DISPLAY
Easy Set-up menu allows you to set nine stages for
.
.
operation.
1. In the Home Screen, tap
2. Tap
Display
3. Select option for the followings.
.
•
PERSONAL BANNER:
main screen, then tap Done or tap Skip to go to the next setting.
WALLPAPER:
Select a desired screen, then tap Set As Wallpaper or tap Skip to go to the
• next setting.
DISPLAY THEMES:
• next setting.
MENU LAYOUT:
•
MENU TYPE:
Select Multimedia, Personalize, Messaging, Productivity or Communicator,
• then tap Exit. or tap Skip to go to the next setting.
DIAL FONT SIZE:
• setting.
CLOCK FORMAT:
•
Digital 24 or O, then tap Exit or tap Skip to complete set-up.
This guide gives navigation instructions according to the defaults, Menu Layout is set
to Grid, and Display Themes is set to Misty Black. If other settings are set, navigating the phone’s menus may be dierent.
Settings
Enter the banner text (up to 16 characters) to be displayed on the
Select Misty Black or Pastel White, then tap Exit or tap Skip to go to the
Select Grid or Shortcuts, then tap Exit or tap Skip to go to the next setting.
Select Normal or Large Only, then tap Exit. or tap Skip to go to the next
Select Analog, Large Analog, Digital 12, Large Digital 12, Digital 24, Large
and
Display settings
Easy Set-up
with simple
.
01
02
03
04
05
06
07
SETUP WIZARD
The Set-up Wizard menu allows you to set the following four menus with simple operation.
1. In the Home Screen, tap
2. Tap
Set-up Wizard
3. Select option for the followings.
•
CALL SOUNDS:
save the setting or tap Skip to go to the next setting.
DISPLAY THEMES:
•
Settings
and
Easy Set-up
.
.
Select Ring Only, Vibrate Only, Ring and Vibrate or Be Silent then tap Exit to
Select Misty Black or Pastel White, then tap Exit or tap Skip to go to the
81
next setting.
MENU LAYOUT:
•
•
•
Select Grid or Shortcuts, then tap Exit or tap Skip to go to the next setting.
MENU TYPE:
Select Multimedia, Personalize, Messaging, Productivity or Communicator,
then tap Exit. or tap Skip to go to the next setting.
CLOCK FORMAT:
Digital 24 or O, then tap Exit or tap Skip to complete set-up.
Select Analog, Large Analog, Digital 12, Large Digital 12, Digital 24, Large
TOOLS
VOICE COMMANDS
Your phone is equipped with an Advanced Voice Commands (AVC) feature. This feature allows you to make calls or use the phone’s functions by simply using your voice. All you have to do is talk into the phone and then the phone will recognize your voice and complete tasks by itself.
1. To access Voice Commands from idle mode, slide the phone up, tap
Voice Commands
2. The phone displays the Voice Commands menu and prompts you to say the name of the command you want to use. To complete your task, simply follow the voice prompts. You can speak the name of the command after you hear a beep.
3. Select one of the following options.
Call <Name or #> / Send <MSG Type> / Go To <Shortcut> / Check <Item> Verizon
To view information about each option, tap Info. Tap Settings to access Voice
Commands Settings. Please refer to page xx for more details on Voice Commands
Settings.
4. When it recognizes one of these commands, the phone launches the associated application. If the phone does not hear a command within approximately eight seconds, AVC mode will turn itself o.
82
.
/
Contact <Name> / Search / Redial / Play <Playlist> / My
/
Help
Tools
, and
•TOOLS
CALL <NAME OR #>
Use the Call command to voice dial a name from your Contact List or a phone number. When dialing a number, pronounce each digit, but do not pause noticeably between the digits.
1. You will hear
Please say a command
and the Voice Commands menu will be
displayed.
2. If calling a contact from your Contact List, say Call <Name>. Your phone will ask you to conrm the name you said. Say “
Yes
“ if it was repeated correctly. That phone number will be dialed. If there is more than one number saved for that contact, you will be asked to conrm which number to dial. Examples: Call John Work
CALL <MSG TYPE>
Use the Send command to send a text or other type of message to a specied name or number.
1. You will hear
Please say a command
and the Voice Commands menu will be
displayed.
2. Say “
Send
“ followed immediately by Text, Picture, Video or Voice Message.
Examples: Send text message to Bob
GO TO <SHORTCUT>
Use the Go To command to open an application on your phone. You can say “ by itself and be prompted to say the application name, or you can skip the prompt by
Go To
” followed by the application name.
saying ”
1. You will hear
Please say a command
and the Voice Commands menu will be
Go To
”
displayed.
2. To access a menu within the phone, say “
Go To
” followed by the menu. Examples: “Go To Calendar”. If no menu option is stated, a list of options will be provided.
01
02
03
04
05
06
07
83
CHECK <ITEM>
The Check command lets you check status information for your phone. You can say
Check
” or “
Check Status
“
1. You will hear
” to see and hear all status information.
Please say a command
and the Voice Commands menu will be
displayed.
2. Say “
Check
” followed immediately by one of the following items:
Status / Voicemail / Messages / Missed Calls / Time / Signal Strength / Battery Level
/
Volume / Balance / Minutes / Payment / My Number
CONTACT <NAME>
Use the Contact command to retrieve and display information for any name stored in your Contact List.
1. You will hear
Please say a command
and the Voice Commands menu will be
displayed.
2. Say “
Contact <Name>
” to retrieve and display the contact information.
Examples: Contact Bob Smith and follow the voice prompts.
Call / Readout / Create New / Modify / Erase
SEARCH
Use the Search command to search for information over the Internet.
1. You will hear
Please say a command
and the Voice Commands menu will be
displayed.
2. Say “
Search
”.
3. Your phone will make a web connection.
REDIAL
Use the Redial command to make a call to the last number you dialed.
1. You will hear
Please say a command
and the Voice Commands menu will be
displayed.
2. Say “
Redial
”.
84
•TOOLS
3. Your phone will make a call to the last number you dialed.
PLAY <PLAYLIST>
Say “
Play
” followed by a playlist title and then your phone will play back the recognized
playlist for you.
1. You will hear
Please say a command
and the Voice Commands menu will be
displayed.
2. Say “
Play <Playlist>
” to play back individual playlist or say “
Play All Songs
to play back all songs saved in your phone.
MY VERIZON
Use the My Verizon command to access information about your Verizon account.
1. You will hear
Please say a command
and the Voice Commands menu will be
displayed.
2. Say “
My Verizon
”.
3. Your phone will make a web connection.
HELP
Use the Help command to view how to use the Voice Commands.
1. You will hear
Please say a command
and the Voice Commands menu will be
displayed.
2. Say “
Help
”.
3. The Help guide will be displayed on your phone.
VOICE COMMANDS SETTINGS
CONFIRM CHOICES
When the phone does not recognize your voice command, it will ask you to repeat your voice command. If it does not recognize the name or number, it will display a list of up to three choices and speak each one in turn. You can control how often the phone asks you to conrm the recognized name or number.
01
02
03
”
04
05
06
07
85
1. In the Home Screen, tap
To view information about each option, tap Info.
2. Tap
Settings
You can also access Voice Commands Settings, tapping Settings & Tools, Phone
Settings, Voice Commands Settings, and Conrm Choices in the Home Menu.
3. Select
Automatic, Always Conrm
and then tap
Tools
, and
Voice Commands
Conrm Choices
or
.
Never Conrm
.
.
SENSITIVITY
The Sensitivity setting allows you to adjust the sensitivity monitoring of voice tones. If you frequently experience the messages “
NOT RECOGNIZED Tr y again?
frequently experience false activations (when the phone recognizes a name you didn’t say), adjust the sensitivity toward
1. In the Home Screen, tap
2. Tap
Settings
3. Select
and then tap
More Sensitive, Automatic
Please try again
”, adjust the sensitivity toward
More Sensitive
Tools
, and
Voice Commands
Sensitivity
.
or
Less Sensitive
” or “
Less Sensitive
.
.
.
ADAPT VOICE
Voice Commands are speaker independent, which means that no training or adaptation is required. Some users with heavy accents or unusual voice characteristics may nd diculty in achieving high accuracy with speaker independent Voice Commands, so the Adapt Voice feature allows users to dramatically improve the recognition accuracy after adapting their voices. Users who get acceptable recognition accuracy will nd no additional benet to performing the Adapt Voice feature.
1. In the Home Screen, tap
2. Tap
Settings
3. Tap
Train Voice
•
Train Voice:
Requires that you make recordings of your voice to customize the voice
recognition system. It will take a few minutes.
86
and then tap
or
Reset Voice
Tools
, and
Adapt Voice
.
Voice Commands
.
.
COMMAND
. If you
•TOOLS
Reset Voice:
Once you nish the adaptation process, you can reset the adaptation to
• the factory default. The reset Voice option only appears after you nish the Train Voice process.
4. “Adaptation will take a couple of minutes to complete. Adapt in a
quiet room. Select OK to begin.” will appear on the screen. Wait for the
beep, and then repeat the sentences using a normal tone of voice.
5. When you are nished with a full session, you will reach a screen that reads “
Adaptation Complete
”.
PROMPTS
Allows you to select voice command system characteristics.
1. In the Home Screen, tap
2. Tap
Settings
3. Select
Mode, Audio Playback
•
Mode:
Select the voice command system mode from the following:
- Prompts: For handset to prompt for required information.
- Tones Only: For handset to provide beeps only for audio guidance.
Audio playback:
• Select Speakerphone or Earpiece.
Timeout:
Select a period of time either 5 seconds or 10 seconds which the system
• listens for a command before timing out.
Tools
, and
and then tap
Prompts
.
or
Timeout
Allows audio playback to play through the speakerphone or earpiece.
Voice Commands
.
.
4. Tap an option you want.
ABOUT
1. In the Home Screen, tap
2. Tap
Settings
and then tap
Tools
About
, and
Voice Commands
.
.
3. The Nuance version appears.
4. To return to the previous screen, tap
Back
.
01
02
03
04
05
06
07
87
CALCULATOR
The Calculator allows you to perform simple mathematical calculations. To access the calculator:
1. In the Home Screen, tap
2. Add, subtract, multiply, and divide, as with a standard calculator.
3. To reset, tap
You can reset calculator by shaking the phone.
Clear All
Tools
, and
Calculator
.
.
TIP CALCULATOR
Allows you to calculate the tip and determine how much each person should pay for the bill.
1. In the Home Screen, tap
2. Input the amount in the
3. Select the percentage of tip in the The amount of a tip will be displayed in the
4. Input the number of persons by ick the screen up or down. The total cost and cost per person is shown.
5. Tap
Reset
to clear the elds. Tap
Tools
, and
Total Bill
Tip Calculator
eld.
% Tip
Back
.
eld by ick the screen up or down.
Tip ($)
eld.
to return to the previous menu.
CALENDAR
The Calendar tool provides easy and convenient access to your schedule. Simply store your appointments and your phone will alert you.
1. In the Home Screen, tap
2. Highlight the scheduled day.
3. Tap
Add
.
4. The Subject eld is highlighted. Enter the name of the event using the Keypad. Flick the screen down to set the other elds for the event:
88
Tools
, and
Calendar
.
•TOOLS
START DATE
Use the keypad to change or enter the start date.
START TIME
Use the keypad to set a start time and select am/pm.
END DATE
Use the keypad to change or enter the end date.
END TIME
Use the keypad to set an end time and select am/pm.
RECURRENCE
Flick the screen left or right to set the recurrence of the event from the following:
Once / Daily / Weekly / Monthly / Yearly
ALERT TONE
Tap
Set
to select a new ringtone. Highlight a desired ringtone. Tap
a ringtone.
Play
VIBRATE
Tap the ON/
OFF
switch.
REMINDER
Flick the screen left or right to select a reminder before the event from the following:
Once / Every 2 Minutes / Every 15 Minutes / O
to play
01
02
03
04
05
06
07
89
ALERT TIME
Flick the screen left or right to select the alert time before the event takes place from the following:
On time / 15 minutes before / 30 minutes before / 45 minutes before / 1 hour before
/
3 hours before / 5 hours before / 1 day Before
5. Tap the date of the calendar.
6. Tap
Save
to save it. The date of the event will be marked on your calendar.
VIEW SAVED EVENT
1. In the Home Screen,
2. Choose the event then tap
Tools
, and
VIEW
Calendar
.
.
ERASE SAVED EVENT
1. In the Home Screen, tap
2. Choose the event then tap
3. Tap
Erase
, select
Yes
Tools
, and
Calendar
VIEW
.
.
.
ERASE ALL PAST EVENTS
Allows you to delete past events from today.
1. In the Home Screen, tap
2. Choose the event then tap
3. Tap
Options
4. Select
Yes
.
, select
Tools
, and
VIEW
Erase Passed
Calendar
.
.
.
ALARM CLOCK
The Alarm Clock tool allows you to set up to three alarms. When you set an alarm, the current time is displayed at the top of the screen. When the alarm goes o, Alarm 1 (2 or 3, as applicable) will be displayed on the LCD screen and the alarm will sound.
1. In the Home Screen, tap
90
Tools
, and
Alarm Clock
.
Shortcut:
From idle mode, scroll left to access the MY SHORTCUTS and tap Alarm
Clock.
2. Highlight an
Alarm
(1, 2 or 3).
3. Flick the screen down to set the elds for the alarm:
ALARM
Flick the screen left or right to select On or O.
TIME
Use the keypad to set a time for the alarm and set am or pm.
FREQUENCY
Flick the screen left or right to select a setting from the following:
Once / Daily / Weekdays / Weekends
RINGTONE
Tap
Set
then tap
Tap
4. Tap
Play
SAVE
Shop Applications
to play a ringtone. Tap
to set the alarm.
or select the alert tone you wish to set.
SET
to make your selection.
TURN ON/OFF THE ALARM SETTING
1. In the Home Screen, tap
2. Highlight an
3. Select
Turn On
Alarm
(1, 2 or 3), then tap
or
Turn O
Tools
.
, and
Alarm Clock
Options
. .
RESET THE ALARM SETTING
1. In the Home Screen, tap
2. Highlight an
3. Tap
Reset Alarm
4. “
RESET ALARM (1, 2 or 3)?
Alarm
(1, 2 or 3), then tap
.
Tools, Alarm Clock
.
Options
.
” will appear on the screen. Tap
•TOOLS
Yes
.
01
02
03
04
05
06
07
91
RESET ALL ALARM SETTINGS
1. In the Home Screen, tap
2. Highlight an
3. Tap
Reset All
4. “
RESET ALL ALARMS?
Tools
Alarm
.
, and
(1, 2 or 3), then tap
” will appear on the screen. Tap
Alarm Clock
Options
. .
Yes
.
STOP WATCH
Simultaneously times up to twenty dierent events. To operate the stop watch:
1. In the Home Screen, tap
2. To start the stop watch, tap
3. To pause it, tap
4. To resume it, tap
5. To reset it, tap
Stop
Resume
Reset
Tools
, and
Stop Watch
Start
.
.
.
.
.
TO TIME UP TO TWENTY EVENTS AT ONCE
1. To start the stop watch, tap
2. To stop a time period and continue measuring another one, tap
3. To stop the second and continue measuring a third one, tap
4. To measure up to twenty time periods, repeat the above steps.
5. To stop the stop watch, tap
6. To reset it, tap to the previous menu.
Reset
, then tap
Start
.
Stop
.
Back
to nish using the stop watch and return
WORLD CLOCK
To display the time and date in pre-programmed cities:
1. In the Home Screen, tap
2. Tap
Cities
to access the CITIES LIST. Select the desired city. Or, ick the screen left or right to select the desired continent. Flick the screen left or right to select your city.
92
Tools
, and
World Clock
.
Lap
Lap
.
•TOOLS
3. The world map appears with the city, its date and time.
4. Tap
Back
to return to the previous menu.
DAYLIGHT SAVING TIME DST SETTING
1. In the Home Screen, tap
2. Select the desired continent.
3. Tap
DST
to set Daylight Saving Time, the DST icon appears.
4. To turn o DST, tap
DST option will adjust clocks forward one hour.
5. Tap
Back
to return to the previous menu.
DST
Tools
again.
, and
World Clock
.
UNIT CONVERTER
The Unit Converter allows you to convert unit of measurement from one into another.
1. In the Home Screen, tap
2. Enter gure and ick the categories.
.
3. Flick up and down to select source unit and target unit.
4. Converted gure is displayed in the window.
For temperature conversion, you may switch to minus number by tapping +/– .
Tools
, and
Unit Converter
.
01
02
03
04
05
06
07
NOTEPAD
Your phone includes an internal notepad that can be used to compose and store reminders and notes. To create a note:
1. In the Home Screen, tap
2. Tap
New
to enter a new note.
3. For text entry, you may use vertical multi-tap keypad or horizontal QWERTY Keypad.
4. To save a note, tap
Please refer to page XXX for more details on sending messages.
Done
Tools
.
, and
Notepad
.
93
VIEW SAVED MEMO
To view a saved memo:
1. In the Home Screen, tap
2. Tap a note in the , then tap
ERASE SAVED MEMO
To erase a saved memo:
1. In the Home Screen, tap
2. Select a note, tap
3. “
ERASE?
” will appear on the screen.
4. Tap
Yes
.
ERASE ALL SAVED MEMOS
To erase all saved memos:
1. In the Home Screen, tap
2. Tap
Erase All
3. “
ERASE ALL?
4. Tap
Yes
.
Tools
, and
Notepad
VIEW
.
Tools
, and
.
Tools
, and
Notepad
Notepad
Erase
. ” will appear on the screen.
.
.
.
USB MASS STORAGE
USB Mass Storage allows you to transfer  les to or from your PC. In order to use this option, you must insert a microSD memory card (sold separately) and connect your device to a PC with the USB cable.
1. In the Home Screen, tap
Tools
, and
USB Mass Storage
.
MY VERIZON
To access your Verizon account information:
1. In the Home Screen, tap
94
My Verizon
.
Your phone provides a unique feature - Media Center - that enables
MEDIA CENTER
you to download ringtones, wallpapers, games and more from your
network to your phone. Please contact your service provider for the
J-TOUCH
availability of these services.
™
5
Using a microSD Card
Browse & Download
Search
Music & Tones
Picture & Video
Games
Mobile Web
Extras
Media Center Info
95
SEARCH
1. In the Home Screen, tap
Media Center
, and
Search
.
USING A MICROSD CARD
A microSDSM Card (sold separately) stores sounds, videos, images, photos, music and other les.
INSTALLING A MICROSD CARD
To install your microSD Card:
1. Open the microSD Card cover, and insert the microSD Card into the slot with the gold contacts facing down.
2. Press the microSD Card into the slot until you hear the ‘click’, then close the microSD Card cover.
3. Then, “
SET MEMORY CARD AS DEFAULT STORAGE LOCATION?
the display.
4. Select
Yes
or No.
To prevent possible damages, please keep the microSD Card slot closed at all times
regardless of whether a microSD Card is inserted or not.
REMOVING A MICROSD CARD
To remove the microSD Card:
1. Open the microSD Card cover, and use your thumb to press and release the microSD Card. Press the memory card inward, gently, until it pops out.
2. Remove the microSD Card and close the microSD Card cover.
• Do not remove the microSD Card while reading or writing les. Otherwise it could be damaged.
•
To ensure the proper function of removable memory, please use a microSD Card
(sold separately).
96
” will appear on
•MEDIA CENTER
MUSIC & TONES
The Music & Tones menu allows you to mange ringtones, music and sounds les. It also allows you to get new ringtones.
V CAST MUSIC/RHAPSODY
V CAST Music with Rhapsody is an integrated service between Verizon Wireless and Rhapsody America. Rhapsody lets you pick up your duplicate tracks, manage all the music on your Verizon Wireless phone, and shop for MP3s.
• Additional charges for music may apply. V CAST Music service is not available in all areas. Check www.verizonwireless.com/music website for details.
SHOP RINGTONES
To connect to Media Center and download new ringtones:
1. In the Home Screen, tap
2. If you have not downloaded any ringtones or ringtone applications previously, tap
Get New Applications
MY RINGTONES
TO PLAY DOWNLOADED TUNES OR TONES:
1. In the Home Screen, tap
2. Select the tune or tone you want to play, then tap Play button
3. To stop, tap Stop button
TO ERASE DOWNLOADED TUNES OR TONES:
1. In the
Home
Ringtones
2. Tap
More
to access the following options:
Erase All:
Deletes all downloaded ringtones from your phone.
Media Center, Music & Tones
and follow the prompts.
Media Center, Music & Tones
o
Screen, tap
Media Center, Music & Tones
.
, and Shop
Ringtones
, and
My Ringtones
p
.
.
, and
My
01
02
03
04
05
06
.
07
.
97
97
TO ASSIGN DOWNLOADED TUNES OR TONES:
1. In the Home Screen, tap
2. By tapping the name of the ringtone in the following options.
•
1. Set as Ringtone:
2. Set as Contact ID:
• the ringtone to.
3. Set as Alert Sounds:
• the following:
4. Tap
More
to access the following options:
•
Shop Ringtone: Erase All:
Deletes all the ringtones from your phone.
•
Media Center, Music & Tones
Change to
Set as a ringtone.
The setting screen appears. Select the Contact you want to assign
Tap the corresponding number key to set the ringtone for one of
All Messages / TXT Message / Multimedia Messages / Voicemail
You can shop ringtones via network.
, and
list, you can select one of
MY MUSIC
My Music menu allows you to playback and manage music les stored in your phone’s memory and on a memory card (sold separately).
1. In the Home Screen, tap
2. Select one of the following options.
•
Now Playing: All Song:
Allows you to view or play all songs.
•
Playlists:
Allows you to create or view playlists. Once you have created playlists, you can
• play songs by playlists.
Artists:
Allows you to view or play your songs by artists.
•
Genres:
Allows you to view or play your songs by genres.
•
Albums:
Allows you to view or play your songs by albums.
•
Manage My Music:
•
Move To Card / Move To Phone / Erase
•
Sync Music:
Allows you to synchronize your music les from PC to your phone.
Music Alerts:
•
Sound Eect:
• button.
98
Media Center, Music & Tones
Move to Music Player presently being played.
Allows you to manage your music les with following options:
V CAST Music Set Alert.
Allows you to choose from Normal, CS HP or SRS WOW HD by tapping
, and
My Music
My Ringtones
.
•MEDIA CENTER
Airplane Mode:
•
Music Only Mode:
.
•
3. Tap
•
Shop Ringtone:
NATIVE MUSIC PLAYER
Allows you to ON/OFF Airplane Mode.
Allows you to ON/OFF Music Only Mode.
More
to access the following options:
You can shop ringtones via network.
01
02
03
04
05
06
Skin & File info
Progress Bar
Elapsed time
Repeat
Total Time Shuffle
07
99
Icon Name Descriptions
Volume
Previous / Next
Pause/Play Indicates player’s status
Repeat
Shuffle
Indicates current music volume level on screen when you increase or decrease volume level with side volume key
Tap: Previous, Next Touch and hold: Rewind, Fast Forward
Repeat All Repeat One Off
On Off
/
PLAYING MUSIC
1. In the Home Screen, tap
2. Tap
All Songs
Media Center, Music & Tones
, then select the desired song and tap
tap again.
4. Tap
Mute
to mute or tap
•
Exit Player:
Exits the music player and returns to previous screen.
Music Only Mode:
•
Song Info:
Displays the music le information.
•
Home Screen:
•
Repeat:
Select
•
Shue:
Select On or
•
Sound Eects:
•
More
to select from the following options:
Sets Music Only Mode On to disable all wireless communications.
Returns to home screen without exiting the music player.
Repeat All, Repeat One
O
Select
Normal, Rock, Jazz, Classic, Pop
or O for the player’s repeat mode.
for the player’s shue mode.
or
Bass
5. During music playback, ick the screen left to start the song over again or
ick the screen
right to advance to the next song if there are other songs to
be played. If you ick the screen left, the song rewinds or if you drag right, the song will fast forward.
100
, and
My Music
Play
. To pause the song,
for sound eect settings.
You can control music player with Music Keys on top of your phone.
MY SOUNDS
To select a desired sound:
1. In the Home Screen, tap
2. Tap Play button
Media Center, Music & Tones
p
to hear the sound. Tap Stop button o to stop playing the
, and
My Sounds
sound.
3. Tap
Options
to access the following options:
•
Send:
Allows you to send the sound with a picture message.
To Online Album:
•
Rename:
• List out the options for preloaded sounds, as they can’t be renamed and cannot be
Move to Phone/Card:
•
phone. This option only appears if a memory card is inserted.
Lock/Unlock:
.
•
Erase:
•
File Info:
•
Allows you to upload the selected tone to the online server.
Renames the sound.
erased.
Deletes the sound.
Allows you to move the selected sound to the memory card or the
Locks or unlocks the selected sound in your phone.
Displays information about the selected sound.
01
.
02
03
04
05
06
07
RECORDING NEW SOUNDS
1. In the Home Screen, tap
2. Tap
More
and tap
3. Tap
Record
to begin recording. When done, tap
Media Center, Music & Tones
Record New
.
, and
Stop
to nish recording.
My Sounds
.
The recording is automatically saved to your My Sounds list in a le named with a number.
4. By tapping the lename, you can
to Phone
,
Erase
the sound.
Send, To Online Album, Rename, Move
101
SYNC MUSIC
SYNC YOUR MUSIC FROM YOUR PC TO YOUR V CAST MUSIC WITH RHAPSODY® CAPABLE PHONE
This option allows you to transfer music les from your PC. In order to use this option, you must install V CAST Music with Rhapsody on your PC.
1. Open V CAST Music with Rhapsody software. Don’t have V CAST MUSIC with Rhapsody software? Download it for free at www.verizonwireless.com/music.
2. Plug in the USB cable (included inbox) to your phone and connect it to a USB port on your PC.
3. From the main screen on your phone, the SYNC MUSIC V CAST MOBILE PHONE display appears. Your phone should display the message: Connected
4. Drag and drop the song(s) you want to sync from My Library, to your V CAST Music with Rhapsody mobile phone, listed under the Sources tab. Once synchronization is complete, press the END/CLR key and disconnect the USB cable (included inbox).
5. Under the Music & Tones menu, open My Music to view and play your music.
• A compatible USB cable is required for synchronizing.
•
V CAST Over The Air Music downloads are not available. Music can be purchased
and downloaded via V CAST Music with Rhapsody through your PC. V CAST Music with Rhapsody will work with Windows Vista, XP, or 2000 (Only 32-bit versions of Windows are supported.). Not available for Mac or Linux.
PICTURE & VIDEO
V CAST VIDEOS
V CAST brings the world to your mobile phone with full-motion video and sound. Catch up with what’s happening with video clips from Music, Showcase, Comedy, News, Sports, Net’s Best, TV & Film, Latino, Kids and Lifestyle (Must be in V CAST coverage area. Additional fees may apply).
102
1. In the Home Screen, tap
Media Center, Picture & Video
, and
V CAST Videos
2. Touch video clip categories to view.
SHOP PICTURES
To connect to Media Center and download a variety of Pictures (images):
1. In the Home Screen, tap
2. Tap
Shop Pictures
The downloaded application will be included in the list when you access: Shop
Pictures.
Media Center
, and
Picture & Video
, and follow the on-screen prompts.
.
MY PICTURES
The My Pictures menu allows you to view all the pictures you have taken, store selected images in your phone, send pictures to the Online Album, delete images and access additional picture options.
1. In the Home Screen, tap
2. Select the desired picture, then tap the
3. Select one of the following options:
•
Send:
Send a picture message.
Set As:
Assigns the selected picture to display for specic tasks (
•
3. Tap
More
to access the following options.
•
Move to Card: Lock:
Lock the selected picture.
•
Erase:
Erase the selected picture. When
• picture.
Camera:
Take a new picture.
•
Shop Picture:
•
File Info:
Displays the following information about the selected picture:
•
File Name / Date / Time / Resolution / File Size
Media Center, Picture & Video
More
Move the piccture to external memory
ERASE?
appear on screen, tap
Download various pictures.
.
, and
My Pictures
Wallpaper / Picture ID
Yes
to erase the
.
).
MY VIDEOS
The My Videos menu allows you to view all the videos you have recorded, store selected videos in your phone, send videos to the Online Album, delete videos and access
.
01
02
03
04
05
06
07
103
additional video options.
1. In the Home Screen, tap
Media Center, Picture & Video
, and
2. Select the desired video, you can play the video by tapping the Play button on the video screen.
3. You can tap two options on the screen:
•
Send:
Allows you to send a picture with following options:
Video Message / To Online Album / Via Bluetooth
•
Set as:
Allows you to use the video clip for
4. By tapping
More
•
Move to Phone/Card: Erase:
•
Camera:
•
Set As Video ID:
•
File Info:
•
File Name / Date / Time / Duration / File Size
, you can access following options:
Erase the selected video clip.
Move video clip to External memory or to phone.
Record a new video.
Set the selected video as a contact ID.
Displays the following information about the selected video:
Wall paper
.
RECORD VIDEO
1. To access the video camera, press and hold the Camera Key Q.
If the keypad is locked, open slide to unlock the keypad. Press and hold the Camera
Q to access the video camera viewnder. To exit from the video camera, press
Key
H
the Home Key
.
2. Tap camera mode icon in top left of the screen
3. Point the camera lens at your subject. You can check the video framing through the display screen.
4. Tap the video screen, zoom control bar and brightness control bar appears. Tap zoom buttons ( (
, ) to adjust the brightness.
• Tap Setting icon on the right bottom of the screen, and choose from the following:
Display Mode: White Balance:
Darkness)
104
, ) to zoom in or out. Tap brightness control button
To select display mode (Auto / Landscape / Portrait)
To select white balance (Auto / Sunny / Cloudy / Tungsten / Fluorescent /
My Videos
Video Quality:
.
p
Recording Time: Color Eects: Save Options: Shutter Sound: Video Resolution: Restore Factory Settings:
5. Press camera key Q to record a video. To stop recording, tap the camera key
Q
6. After recording the video, tap Play button on the screen to preview the recorded video, tap saving the video you just recorded, tap tap
DELETING A VIDEO
1. In the Home Screen, tap
2. Select the video you want to erase, then tap
3. “
4. Select
To select video quality (High / Medium / Low)
Limit the recording time to 15 Seconds (For Send) or 1 Hour (For Save).
(Normal / Antique / Black & White / Negative)
(Phone Memory / Card Memory)
To select shutter sound from (Shutter / Silent)
To select video resolution (176x144 / 640x480 / 320x240)
Yes / No
again.
Save
Set As Wallpaper
to save the video. To record another video without
. To send the video to someone, tap
Erase
. To attached picture as Wallpaper,
Media Center, Picture & Video
Erase
ERASE VIDEO FROM MY VIDEOS?
Yes
. A conrmation message appears.
” will appear on your display.
01
02
03
04
05
Send
.
06
07
, and
My Videos
.
.
TAKE PICTURE
1. To access the camera, press the Camera Key Q.
If the keypad is locked, open slide to unlock the keypad. Press and hold the Camera Key
Q to access the camera viewnder.
2. Point the camera lens at your subject. You can check the picture framing through the display screen.
3. Tap the camera screen, zoom control bar and brightness control bar appears. Tap zoom buttons ( 2048x1536). Tap brightness control button (
• Tap Setting icon on the right bottom of the screen, and choose from the following:
Capture Mode:
, ) to zoom in or out (except when resolution is set to
, ) to adjust the brightness.
To select capture mode (Auto / Landscape / Portrait)
105
White Balance:
Darkness
Self Timer: Multi-shot: Shutter Sound:
Silent / Say Cheeze / Ready!123)
Picture Resolution: [
160x120, [Portrait] 1536x2048, 1200x1600, 960x1280, 480x640, 240x320, 120x160
Color Eects: Save Options: Smile Shot: Face Tag: Face Filter:
Snow / Fisheye / Concave / Beauty Blur)
Restore Factory Settings:
Tap to select from Auto / Sunny / Cloudy / Tungsten / Fluorescent /
O / 3 Seconds / 5 Seconds/ 10 Seconds
0 / 3 / 6 / 9
Allows you to select the shutter sound from the following: (Shutter /
Landscape] 2048x1536,1600x1200,1280x960,640x480, 320x240,
(Normal / Antique / Black & White / Negative)
(Phone Memory / Card Memory)
To toggle smile shot (ON / OFF)
To toggle face tag (ON / OFF)
To select face lter (None / Big Head / Facial Color / Out Focusing / Mosaic /
Yes / No
4. Press the Camera Key Q to take the picture.
5. After taking the picture, it will be displayed. To save the picture, tap take another picture without saving the picture you just took, tap send the picture to someone, tap
Call
.
ONLINE ALBUM
To access Online Album:
1. In the Home Screen, tap
Media Center, Picture & Video
2. Follow the on-screen prompts.
GAMES
DOWNLOADING NEW GAMES
To download games and applications:
1. In the Home Screen, tap
2. Select
Get New Applications
3. Follow the on-screen prompts.
106
Media Center
.
, and
Games
.
, and
Online Album
Save
Erase
. To
. To
PLAYING DOWNLOADED GAMES
1. To play the game you downloaded, from the and tap
PLAY
to run the application.
DELETING A DOWNLOADED GAME
1. In the Home Screen, tap
Media Center
2. Follow the on-screen prompts.
BROWSER
Now you can access news, sports, weather and Email from your phone. Mobile Web keeps you updated by providing access to up-to-date information when you subscribe to Internet service with your service provider. Please contact your service provider for a list of available websites and service details.
1. In the Home Screen, tap
Media Center
, and
, and
Games
menu, select the game
Games
.
Browser
.
01
02
03
04
05
06
07
2. Follow the on-screen prompts.
BROWSE & DOWNLOAD
DOWNLOADING NEW APPLICATIONS
To download tools that can help you navigate to entertainment spots, restaurants, and
.
provide you with up-to-date weather information:
1. In the Home Screen, tap
2. Select
Backup Assistant, Mobile Email
Media Center
, and
or
Browse & Download
VZ Navigator
. Follow the on-
.
screen prompts.
EXTRAS
DOWNLOADING NEW APPLICATIONS
To download Applications:
1. In the Home Screen, tap
2. Select
Get New Applications
Media Center
.
, and
Extras
.
107
3. Follow the on-screen prompts.
MEDIA CENTER INFO
To view Application Memory, Phone Memory, View Log and Help information:
1. In the Home Screen, tap
2. Select one of the following options.
App. Memory / Phone Memory / View Log / Help
Media Center
, and tap
Info
.
MESSAGING MENU
This chapter addresses Voicemail, TXT, Picture, Video, Voice
When a new message arrives
New Message
Messages
Voicemail
Visual Voicemail
Messaging functions including:
Inbox
Sent
Drafts
Erase All Messages
6
Mobile IM
Email
Chat
Quick Text
Settings
108
J-TOUCH
™
WHEN A NEW MESSAGE ARRIVES
1. The following display appears when a new message arrives.
2. To view the message now, select
3. To view the message later, select
View Now View Later
NEW MESSAGE
TXT MESSAGE
1. In the Home Screen, tap
2. Tap
Text Message
3. Tap
Add Recipient
From Contacts: From Favorites: From Recent Calls: Enter Address: Groups:
4. Tap the
• By tapping
Add Quick Text: Add Graphic: Add Sound: Add Name Card: Format Text:
Color.
Language:
5. Tap
More
Save As Draft: Priority Level: Lock:
Lock the text message.
6. When completed, tap
110
Search for a group stored in the Groups menu.
Add Text
More
Inserts Sound in the text message.
Allows you to edit Alignment, Font Size, Font Style, Font Color or Background
Changes to English or Espanol.
, you can choose from the followings:
Message
, then select
.
, you can choose from the following:
Search for a phone number which is stored in the Contact List.
Search for a phone number which is stored in the Favorites List.
Search for a phone number which is stored in the Recent Calls menu.
Input the phone number or email adress of the recipient .
button, input your message.
, you can choose from the followings:
Inserts predened sentences in the text message.
Inserts Graphics in the text message.
Inserts Name Card in the text message.
Save the text message to Drafts.
Select High or Normal.
Send
to send the text message.
.
.
New Message
.
New Txt Message
View Now
View Later
•MEssaging menu
PICTURE MESSAGE
1. In the Home Screen, tap
2. Tap
Picture Message
3. Tap
Add Recipient
From Contacts: From Favorites: From Recent Calls: Enter Address: Groups:
Search for a group stored in the Groups menu.
Send to Online Album:
4. Tap
Add Picture
Message
, then select
New Message
.
.
, you can choose from the following:
Search for a phone number which is stored in the Contact List.
Search for a phone number which is stored in the Favorites List.
Search for a phone number which is stored in the Recent Calls menu.
Input the phone number or email adress of the recipient .
Send to Online Album.
button.
5. Flicking the screen to select a photo, and tap photo you want.
6. The preview screen appears, ick to left or right to search other photos.
Tap Shop Picture to purchase photo images.
7. Tap
Add Callback Number
6. Tap
Add Sound
7. Tap
Add Subject
• Tap
More
, to choose from the followings:
Add Quick Text: Language:
8. Tap Select
9. Tap
Preview:
Save As Draft: Add Slide: Remove Picture: Priority Level: Lock:
Inserts predened sentences in the picture message.
Changes to English or Espanol.
Add Name Card
My Name Card
More
, you can choose from the followings:
Shows the picture message before it is sent.
Save the picture message to Drafts.
Allows you to insert multiple picture messages.
Select High or Normal.
Lock the picture message.
10. When completed, tap
button to enter phone number to receive reply.
button. Listen and select Sound you want.
button to input the photo title.
button. Select Name Card you want.
or
From Contacts
Removes an inserted picture from the Picture eld.
Send
.
to send the picture message.
01
02
03
04
05
06
07
111
VIDEO MESSAGE
1. In the Home Screen, tap
2. Tap
Video Message
3. Tap
Add Recipient
From Contacts: From Favorites: From Recent Calls: Enter Address: Groups:
Search for a group stored in the Groups menu.
Send to Online Album:
4. Tap
Add Video
Message
, then select
New Message
.
, you can choose from the following:
Search for a phone number which is stored in the Contact List.
Search for a phone number which is stored in the Favorites List.
Search for a phone number which is stored in the Recent Calls menu.
Input the phone number or email adress of the recipient .
Send to Online Album.
button.
5. Flicking the screen to select video clip, and select and tap video clips you want.
6. To preview the clip tap the Play button on the screen.
To record new video tap Record New.
7. Tap
Add Subject
8. Tap Text area, input your message.
• By tapping
Add Quick Text: Language:
9. Tap
Add Subject
• By tapping
Add Quick Text: Language:
10. Tap Select
11. Tap
Preview:
Save As Draft: Remove Video: Priority Level: Lock:
112
112
.
More
, you can choose from the followings:
Inserts predened sentences in the vodeo message.
Changes to English or Espanol.
box. Input your subject.
More
, you can choose from the followings:
Inserts predened sentences in the video message.
Changes to English or Espanol.
Add Name Card
My Name Card
More
Shows the video message before it is sent.
Lock the video message.
box. Select Name Card you want.
or
From Contacts
, you can choose from the followings:
Save the video message to Drafts.
Removes an inserted video from the Video eld.
Select High or Normal.
.
•MEssaging menu
.
VOICE MESSAGE
1. In the Home Screen, tap
2. Tap
Voice Message
3. Tap
Record
and choose from the followings.
Play:
Play the recorded voice memo.
Record Again: Add to Message:
4. Tap
Add Recipient
From Contacts: From Favorites: From Recent Calls: Enter Address: Groups:
Search for a group stored in the Groups menu.
Send to Online Album:
5. Tap
Text
box, input your message.
• By tapping
More Add Quick Text: Language:
12. When completed, tap
6. Tap
7. Tap
8. Tap
Changes to English or Espanol.
Add Subject
• By tapping
More Add Quick Text: Language:
Changes to English or Espanol.
Add Name Card
Select
My Name Card
More
, you can choose from the followings:
Preview:
Shows the voice message before it is sent.
Save As Draft: Remove Voice Recording: Priority Level:
Send
to send the video message.
Message
, then select
New Message
.
.
to start recording a voice memo, then tap
Record new voice memo again.
Insert the voice memo into the voice message.
, you can choose from the following:
Search for a phone number which is stored in the Contact List.
Search for a phone number which is stored in the Favorites List.
Search for a phone number which is stored in the Recent Calls menu.
Input the phone number or email adress of the recipient .
Send to Online Album.
, you can choose from the followings:
Inserts predened sentences in the voice message.
box. Input your subject.
, you can choose from the followings:
Inserts predened sentences in the voice message.
STOP
to nish recording
box. Select Name Card you want.
or
From Contacts
Save the voice message to Drafts.
Removes an inserted voice memo from the Video eld.
Select High or Normal.
.
01
02
03
04
05
06
07
113
113
Lock:
Lock the video message.
9. When completed, tap
Send
to send the voice message.
MESSAGES
The
Messages
default setting. All received and sent messages are stored under the
menu is displayed when
by contact name.
If current mode is not
Message, More, Settings
1. In the Home Screen, tap
2. Select a message and view the message.
3. To reply to the sender, tap Reply key
Message
mode.
If you tap
More
Video Message
, you can select
or
Reply with Voice Message
4. In the text entry eld, enter the message and tap
5. While viewing the message with full screen, tap message. To erase the message, tap
6. When navigating through the following available options. Options are dependent on the message type and may be dierent from each eld.
•
114
•
•
•
•
•
Erase Sent / Received: Erase Drafts: Erase All Messages: Erase:
Deletes the message.
Add To Contacts: Manage Messages:
Erase: Deletes the messages.
-
Lock: Locks the messages.
-
Unlock: Unlocks the messages.
-
Allows you to delete unlocked sent and received messages.
Allows you to delete unlocked messages stored in Drafts.
Allows you to delete unlocked messages stored in your phone.
Saves the phone number to the Contact List.
Allows you to manage messages with following options:
Inbox View
is set to
Contacts
mode, you can change the mode by tap
and select
Contacts
r
or tap
in the
Reply
, and you can input
Message
.
Reply with Picture Message, Reply with
mode.
Reply
Reply
Erase
, and then select
Message
menu, tap
More
Contacts
which is the
Messages
menu
Inbox View
menu.
to reply to the sender.
to reply or send the
Yes
.
to display the
TXT
•MEssaging menu
Mark as Read / Mark as Unread: Marks the messages as read or unread.
-
Sort Alphabetically / Sort By Time:
•
Messaging Menu:
•
Quick Text:
•
Draft:
•
Add:
•
Format Text:
•
Color.
Add Recipient:
•
Priority Level:
•
Cancel Message:
•
Play Again:
•
Forward:
•
Reply w. copy:
•
Save Picture:
•
Save Graphic:
•
Save Sound:
•
Save Video:
•
Save as Ringtone:
•
View Name Card:
•
Save Name Card:
•
Set As:
• sound as Ringtone, Contact ID or Alert Sounds.
Save As Quick Text:
•
Lock / Unlock:
•
Extract Addresses:
• them to the Contact List, make a call or send the message.
Message Info:
•
Reply to All:
•
Resend:
•
Returns to the previous Messaging screen.
Inserts predened sentences in the message.
Save the message to Drafts.
Allows you to add a Graphic, Sound or Name Card.
Allows you to edit Alignment, Font Size, Font Style, Font Color or Background
Allows you to add multiple recipients in the To eld.
Select High or Normal.
Cancels the message and select whether to save it in Drafts.
Replays the sound attached to a picture or voice message.
Forwards the message to another recipient.
Allows you to reply to the recipient including the original message.
Allows you to save the attached picture to your phone.
Allows you to save the attached graphic to your phone.
Allows you to save the attached sound to your phone.
Allows you to save the attached video to your phone.
Allows you to save the sound to your phone as a ringtone.
Shows the attached name card.
Allows you to save the attached name card to your phone.
Allows you to set the attached picture as Wallpaper or Picture ID, and attached
Allows you to save the received message as quick text.
Locks or unlocks the message.
Allows you to extract contacts from the message, then you can save
Shows the message information.
Allows you to reply to all senders.
Resends the message.
Sorts the list in alphabetical order or by time.
INBOX
The
Inbox
menu is displayed when
Inbox View
is set to
Time
. The
Inbox
manages
01
02
03
04
05
06
07
115
received text, picture, voice, video and web alert messages.
If current mode is not
More, Settings
1. In the Home Screen, tap
Time
mode, you can change the mode by tap
and select
Time
in the
, and
Inbox View
Inbox
Message
.
2. Select a message to view the message. To delete the message, tap tap
Yes
.
3. To reply to the sender, tap Reply key
Message
mode.
If you tap
More
Video Message
, you can select
or
Reply with Voice Message
4. When navigating through the
r
or tap
Reply
Reply with Picture Message, Reply with
mode.
Inbox
menu, tap
More
available options. Options are dependent on the message type and may be dierent from each eld.
•
Erase Inbox:
Allows you to delete unlocked messages stored in the Inbox.
Erase Sent:
Allows you to delete unlocked messages stored in Sent.
•
Erase Drafts:
Allows you to delete unlocked messages stored in Drafts.
•
Erase All:
Allows you to delete unlocked messages stored in your phone.
•
Reply:
Allows you to reply to the recipient.
•
Reply w. copy:
Allows you to reply to the recipient including the original message.
Forward:
Forwards the message to another recipient.
Add To Contacts: Extract Addresses:
Message Info: Manage Inbox: Erase: Lock: Unlock: Mark as Read: Mark as Unread: Sort By Sender: Sort By Time:
Saves the phone number to the Contact List.
Allows you to extract contacts from the message, then you can save them to the Contact List, make a call or send the message.
Shows the message information.
Allows you to manage messages with following options:
Deletes the messages.
Locks the messages.
Unlocks the messages.
Marks the messages as read.
Marks the messages as unread.
Sorts the list by sender.
Sorts the list by time.
116
•
•
•
•
•
•
•
•
menu.
Message
Erase
, and you can input
to display the following
, and
Text
•MEssaging menu
•
Sort By Size:
Sorts the list by size.
View By Contacts:
,
•
Play Again:
•
Erase:
•
Save Picture:
•
Save Graphic:
•
Save Sound:
•
Save Video:
•
Save as Ringtone:
•
View Name Card:
•
Save Name Card:
•
Set As:
•
Save As Quick Text:
•
Lock / Unlock:
•
Changes the Messages View setting to By Contacts.
Replays the sound attached to a picture or voice message.
Deletes the message.
Allows you to save the attached picture to your phone.
Allow you to save the attached graphic to your phone.
Allows you to save the attached sound to your phone.
Allows you to save the attached video to your phone.
Allows you to save the sound to your phone as ringtone.
Shows the attached name card.
Allows you to save the attached name card to your phone. Allows you to set the attached picture as Wallpaper or Picture ID, and attached sound as Ringtone, Contact ID or Alert Sounds.
Allows you to save the received message as quick text.
Locks or unlocks the message.
01
02
03
04
05
06
07
SENT
The
Sent
menu is displayed when
already sent or waiting to be sent messages.
If current mode is not
More, Settings
1. In the Home Screen, tap
2. Select a message to view the message. To erase the message, tap Erase button
x
or tap
Erase
3. To send the message, tap
4. When navigating through the available options. Options are dependent on the message type and may be dierent from each eld.
•
Reply to All:
Allows you to reply to all senders.
Forward:
Forwards the message to another recipient.
•
Resend:
Resends the message.
•
Lock / Unlock:
•
Locks or unlocks the message.
Inbox View
Time
mode, you can change the mode by tap
and select
Time
in the
Message
, and
, and tap
Yes
.
Resend
.
Sent
menu, tap
is set to
Inbox View
Sent
.
More
Time
. The
Sent
manages
menu.
to display the following
Message
,
117
•
Add To Contacts: Erase Sent:
•
Message Info:
•
Play Again:
•
Erase:
•
Save As Quick Text:
•
View Name Card:
•
Saves the phone number to the Contact List.
Allows you to delete unlocked messages stored in Sent.
Shows the message information.
Replays the sound attached to a picture or voice message.
Deletes the message.
Allows you to save the received message as quick text.
Shows the attached name card.
DRAFTS
The
Drafts
menu is displayed when
Inbox View
is set to
Time
. The manages draft messages. If message composition is interrupted by a voice call or other events, the message being composed is automatically saved in Drafts.
If current mode is not
More, Settings
1. In the Home Screen, tap
Time
mode, you can change the mode by tap
and select
Time
in the
, and
Inbox View
Drafts
Message
menu.
.
2. Select a message to edit the message. To erase the message, tap Erase button
x
, and tap
Yes
3. When navigating through
available options.
•
Send: Lock / Unlock:
•
Add To Contacts:
•
Erase Drafts:
•
.
Drafts
menu, tap
More
Sends the message.
Locks or unlocks the message.
Saves the phone number to the Contact List.
Allows you to delete unlocked messages stored in Drafts.
to display the following
VOICEMAIL
The
Voicemail
menu shows the number of new voicemail message recorded in your voicemail box.
menu is displayed when
If current mode is not
More, Settings
and select
1. In the Home Screen, tap
118
Inbox View
is set to
Time
mode, you can change the mode by tap
Time
in the
Inbox View
Message
, and
Voicemail
menu.
.
Time
. The
Drafts
Voicemail
menu
Message
Message
•MEssaging menu
Clear Count
, and tap
Yes
2. To delete information about new voicemail, tap
.
ACCESSING YOUR VOICEMAIL BOX
1. In the Home Screen, tap
2. Tap
Call Voicemail
3. Follow the prompts to enter your password and retrieve your messages.
Shortcut:
In the Home Screen, tap
VISUAL VOICEMAIL
The
Visual Voicemail
If current mode is not
,
More, Settings
1. In the Home Screen, tap
2. Follow the on-screen prompts.
Message
. Or dial *86 and tap
, and
Call
Voicemail
menu is displayed when
Time
mode, you can change the mode by tap
and select
Time
in the
Message
, and
Voicemail
.
to access your voicemail box.
Inbox View
is set to
Inbox View
menu.
Visual Voicemail
.
Time
.
Message
01
02
03
04
05
,
06
07
MOBILE IM
The
Mobile IM
menu allows you to send and receive instant messages using one of the following
menu is displayed when
messenger services:
If current mode is not
More, Settings
and select
• AIM
• WL Messenger
• Yahoo!®
LAUNCHING MOBILE IM
,
1. In the Home Screen, tap
2. Follow the on-screen prompts.
Inbox View
is set to
Time
mode, you can change the mode by tap
Time
in the
Inbox View
menu.
Message
, and
Mobile IM
.
Time
. The Mobile IM
Message
,
119
EMAIL
The
Email
menu is displayed when
you to send and receive Email using Mobile Web.
If current mode is not
More, Settings
and select
1. In the Home Screen, tap
2. Select
Mobile Email or Mobile Web Mail
•
Mobile Email:
Connects to Mobile Web via Brew Smartlink.
Mobile Web Mail:
•
Connects to Mobile Web via WAP Browser.
3. Follow the on-screen prompts.
CHAT
The
Chat
menu is displayed when
you to chat with Internet Messenger users.
If current mode is not
More, Settings
and select
1. In the Home Screen, tap
2. The Browser launches.
3. Select one of the displayed chat rooms.
4. Follow the on-screen prompts.
ERASE ALL MESSAGES
To erase all messages stored in your phone:
1. In the Home Screen, tap
2. Tap
More
and tap
options. Options are dependent on the
You can change
Contact
• In case of the
120
Erase All Messages
Inbox View
or
Time
in the
Connacts
mode in the
Inbox View
is set to
Time
Time
mode, you can change the mode by tap
Time
in the
Inbox View
Message
, and
Email
menu.
.
.
Inbox View
is set to
Time
Time
mode, you can change the mode by tap
Time
in the
Inbox View
Message
Message
, and
.
Chat
menu.
.
to display the following available
Inbox View
setting by tap
Inbox View
Inbox View
menu.
setting.
Message, More, Settings
menu.
. The
. The
Email
Chat
menu allows
Message
menu allows
Message
and select
•MEssaging menu
All (Read and Unread) Messages Only Read Messages
• In case of the
,
QUICK TEXT
Allows you to create a new Quick Text or edit the predened Quick Text.
1. In the Home Screen, tap
2. Tap
3. To create a new Quick Text, tap
4. To edit the predened Quick Text, select the Text from the list, edit the Text, and
,
5. To erase a saved Quick Text, tap Erase button
Time All Messages including Unread All except Unread Messages
Locked messages cannot be erased.
mode in the
Message
More
and tap
Quick Text
then tap
Save
.
Inbox View
menu.
.
to display the predened Quick Text.
New
. Enter the new text and tap
x
, and tap
Yes
.
Save
01
02
03
04
05
.
06
07
SETTINGS
The
Settings
menu allows you to congure settings for messages sent or received on
your phone. To access message settings:
1. In the Home Screen, tap
2. Tap
More
and tap
3. Select one of the following menus.
INBOX VIEW
1. Select
Time or Contacts
•
Time:
Sorts received and sent messages into Inbox and Sent folders by time.
Contact:
Groups all received and sent messages by each contact.
•
Message
Settings
to display available menus.
.
.
121
LANGUAGE
1. Select
English or Espanol
.
ENTRY MODE
Allows you to set the default Entry Mode for messaging. For example, if abc mode is set to Entry Mode, its icon will appear in the text entry eld as default.
1. Select
T9 Word, abc, ABC or 123
.
AUTO SAVE SENT
1. Select On,
O or Prompt
•
On:
All sent messages are saved in Sent.
O:
All sent messages are not saved in Sent.
•
Prompt:
The Yes or No dialogue box will be displayed after sending a message.
•
.
AUTO ERASE INBOX
Allows you to set whether Inbox messages are deleted automatically when new messages arrive and Inbox is full.
1. Select
On or O
•
On: O:
•
.
The oldest message will be deleted from the Inbox automatically once full. The oldest message will not be deleted automatically from the Inbox once full.
TXT AUTO VIEW
1. Select
On or O
•
On: O:
•
.
TXT messages are displayed automatically when received. TXT messages are displayed by going into the Inbox, or by responding to the message prompt.
MEDIA MESSAGE AUTO RECEIVE
1. Select
On or O
.
Picture, Voice and Video messages are downloaded automatically. Picture, Voice and Video messages must be retrieved from the Inbox or by responding to the message prompt.
122
•
On: O:
•
•MEssaging menu
VOICEMAIL #
1. Enter a new voicemail number or edit the voicemail number.
2. Tap
Insert
, then tap
2-Sec Pause or Wait
. Please refer to
page xx
for more
details on Wait/ Pause Feature.
CALLBACK #
Allows you to use or edit the default callback number so that the recipient can callback or reply.
1. Tap
On or O
2. If
.
On
is selected, enter a new callback number.
SIGNATURE
Allows you to create a signature that can be automatically inserted at the end of each message.
1. To deactivate Signature function, select
2. To insert a Signature, select
OFF
ON
, and enter your signature in the text entry eld.
.
MESSAGING FONT SIZE
Allows you to set the message font size.
1. Select
Normal, Large or Small
.
01
02
03
04
05
06
07
123
MEMO
124
SAFETY AND WARRANTY
This chapter addresses the safety guidelines and precautions to follow
when operating your phone. Before operating your phone, please be
aware of all the safety details. This chapter contains the terms and
conditions of services and the warranty for your phone. Please review
Safety Information for Wireless
Safety Information for FCC RF Exposure
Hearing Aid Compatibility (HAC) for
Wireless Telecommunications Devices
Handheld Phones
SAR Information
J-TOUCH
FDA Consumer Update Avoid Potential Hearing Loss FCC Compliance Information
12 month Limited Warranty
™
7
them thoroughly.
SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES
READ THIS INFORMATION BEFORE USING YOUR HANDHELD PORTABLE CELLULAR TELEPHONE
EXPOSURE TO RADIO FREQUENCY SIGNALS
Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. In August 1996, the Federal Communications Commissions (FCC) adopted RF exposure guidelines with safety levels for handheld wireless phones. Those guidelines are consistent with the safety standards previously set by both U.S. and international standards bodies:
ANSI C95.1 (1992) * NCRP Report 86 (1986) *
ICNIRP (1996) * Those standards were based on comprehensive and periodic evaluations of the relevant scientic literature. For example, over 120 scientists, engineers, and physicians from universities, government health agencies, and industry reviewed the available body of research to develop the ANSI Standard (C951).
The design of your phone complies with the FCC guidelines (and those standards).
1*: American National Standards Institute. 2*: National Council on Radiation Protection and Measurements. 3*: International Commission on Nonionizing Radiation Protection.
ANTENNA SAFETY
Use only the supplied or an approved replacement antenna. Unauthorized antennas, modications, or attachments could impair call quality, damage the phone, or result in violation of FCC regulations. Please contact your local dealer for replacement antenna.
126
•SAFETY
Do not use the phone with a damaged antenna. If a damaged antenna comes into contact with the skin, a minor burn may result. Please contact your local dealer for replacement antenna.
DRIVING SAFETY
Talking on the phone while driving is extremely dangerous and is illegal in some states. Remember, safety comes rst. Check the laws and regulations on the use of phones in the areas where you drive. Always obey them. Also, if using your phone while driving, please:
• Give full attention to driving. Driving safely is your rst responsibility.
• Use hands-free operation, if available.
• Pull o the road and park before making or answering a call, if driving
conditions so require.
If you must use the phone while driving, please use one-touch, speed dialing, and auto answer modes.
An airbag inates with great force. DO NOT place objects, including both installed or portable wireless equipment, in the area over the airbag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inates, serious injury could result.
WARNING:
Failure to follow these instructions may lead to serious personal injury and
possible property damage.
ELECTRONIC DEVICES
Your wireless handheld portable telephone is a low power radio transmitter and receiver. When it is ON, it receives and also sends out radio frequency (RF) signals. Most modern electronic equipment is shielded from RF energy. However, certain electronic equipment may not be shielded against the RF signals from your wireless phone. Therefore, use of your phone must be restricted in certain situations.
01
02
03
04
05
06
07
127
PACEMAKERS
The Health Industry Manufacturers Association recommends that a minimum separation of six (6”) inches be maintained between a handheld wireless phone and a pacemaker to avoid potential interference with the pacemaker. These recommendations are consistent with the independent research by and recommendations of Wireless Technology Research. Persons with pacemakers:
• ALWAYS keep the phone more than six inches from your pacemaker when the phone is turned on.
• Do not carry the phone in a breast pocket.
• Use the ear opposite the pacemaker to minimize the potential for interference.
• If you have any reason to suspect that interference is taking place, turn your phone OFF immediately.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider (or call the customer service line to discuss alternatives).
OTHER MEDICAL DEVICES
If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy.
Your physician may be able to assist you in obtaining this information. Turn your phone OFF in healthcare facilities when any regulations posted in these areas instruct you to do so. Hospitals or healthcare facilities may be using equipment that could be sensitive to external RF energy.
VEHICLES
RF signals may aect improperly installed or inadequately shielded electronic
128
•SAFETY
systems in motor vehicles. Check with the manufacturer or its representative regarding your vehicle. You should also consult the manufacturer of any equipment that has been added to your vehicle.
POSTED FACILITIES
Turn your phone OFF where posted notices so require.
OTHER SAFETY GUIDELINES
AIRCRAFT
FCC regulations prohibit using your phone while in the air. Turn your phone OFF before boarding an aircraft. Always request and obtain prior consent and approval of an authorized airline representative before using your phone aboard an aircraft.
Always follow the instructions of the airline representative whenever using your phone aboard an aircraft, to prevent any possible interference with airborne electronic equipment.
BLASTING AREAS
To avoid interfering with blasting operations, turn your phone OFF when in a “blasting area” or in areas posted: “Turn o two-way radio.” Obey all signs and instructions.
POTENTIALLY EXPLOSIVE ATMOSPHERES
Turn your phone OFF when in any area with a potentially explosive atmosphere and obey all signs and instructions. Sparks in such areas could cause an explosion or re resulting in bodily injury or even death.
Areas with a potentially explosive atmosphere are often, but not always, clearly marked. They include fueling areas such as gas stations; below deck on boats; fuel or chemical transfer or storage facilities; vehicles using liqueed petroleum
01
02
03
04
05
06
07
129
gas (such as propane or butane); areas where the air contains chemicals or particles, such as grain, dust, or metal powders; and any other area where you would normally be advised to turn o your vehicle’s engine.
PRECAUTIONS
Your Handheld Portable Telephone is a high quality piece of equipment. Before operating, read all instructions and cautionary markings on (1) USB AC Adapter (2) Battery and (3) Product Using Battery.
Failure to follow the directions below could result in serious bodily injury and/or property damage due to battery liquid leakage, re or rupture.
•
DO NOT use this equipment in an extreme environment where high temperature
or high humidity exists.
•
DO NOT abuse the equipment. Avoid striking, shaking or shocking. When not
using, lay down the unit to avoid possible damage due to instability.
•
DO NOT expose this equipment to rain or spilled beverages.
•
DO NOT use unauthorized accessories.
•
DO NOT disassemble the phone or its accessories. If service or repair is required,
return unit to an authorized PCD cellular service center. If unit is disassembled, the risk of electric shock or re may result.
•
DO NOT short-circuit the battery terminals with metal items etc.
SAFETY INFORMATION FOR FCC RF EXPOSURE
WARNING! READ THIS INFORMATION BEFORE USING
CAUTIONS
In August 1996 the Federal Communications Commission (FCC) of the United
130
•SAFETY
States with its action in Report and Order FCC 96-326 adopted an updated safety standard for human exposure to radio frequency electromagnetic energy emitted by FCC regulated transmitters. Those guidelines are consistent with the safety standard previously set by both U.S. and international standards bodies. The design of this phone complies with the FCC guidelines and these international standards.
BODYWORN OPERATION
This device was tested for typical body-worn operations with the back of the phone kept 2 cm. from the body. To maintain compliance requirements, use only belt-clips, holsters or similar accessories that maintain a 2 cm separation distance between the user’s Body and the back of the phone, including the antenna.
The use of belt-clips, holsters and similar accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy these requirements may not comply with FCC RF exposure requirements, and should be avoided.
For more information about RF exposure, please visit the FCC website at www.fcc.gov.
SAR INFORMATION
THIS MODEL PHONE MEETS THE GOVERNMENT’S REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It is designed and manufactured not to exceed the emission limits for exposure to radiofrequency (RF) energy set by the Federal Communications Commission of the U.S. Government. These limits are part of comprehensive guidelines and establish permitted levels of RF energy for the general population. The guidelines are based on standards that were developed by independent scientic organizations
01
02
03
04
05
06
07
131
through periodic and thorough evaluation of scientic studies. The standards include a substantial safety margin designed to assure the safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones employs a unit of measurement known as the Specic Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6 W/kg. * Tests for SAR are conducted with the phone transmitting at its highest certied power level in all tested frequency bands. Although the SAR is determined at the highest certied power level, the actual SAR level of the phone while operating can be well below the maximum value. This is because the phone is designed to operate at multiple power levels so as to use only the power required to reach the network. In general, the closer you are to a wireless base station antenna, the lower the power output.
Before a phone model is available for sale to the public, it must be tested and certied to the FCC that it does not exceed the limit established by the government adopted requirement for safe exposure. The tests are performed in positions and locations (e.g., at the ear and worn on the body) as required by the FCC for each model. The highest SAR value for this model phone when tested for use at the ear is 1.25 W/Kg and when worn on the body, as described in this user guide, is 0.610 W/Kg. (Body-worn measurements dier among phone models, depending upon available accessories and FCC requirements). While there may be dierences between the SAR levels of various phones and at various positions, they all meet the government requirement for safe exposure.
The SAR testing for Body-worn operation was performed with a belt clip that provided a 2 cm separation. The User’s Manual indicates that any holsters/clips used with this device should contain no metallic components.
The FCC has granted an Equipment Authorization for this model phone with all reported SAR levels evaluated as in compliance with the FCC RF exposure
132
•SAFETY
guidelines.
SAR information on this model phone is on le with the FCC and can be found under the Display Grant section of on JYCJ-TOUCH.
Additional information on Specic Absorption Rates (SAR) can be found on the Cellular Telecommunications Industry Association (CTIA) web-site at
http://www.wow-com.com
* In the United States and Canada, the SAR limit for mobile phones used by the
public is 1.6 watts/kg (W/kg) averaged over one gram of tissue. The standard incorporates a substantial margin of safety to give additional protection for the public and to account for any variations in measurements.
http://www.fcc.gov/oet/ea
.
after searching
HEARING AID COMPATIBILITY HAC FOR WIRELESS TELECOMMUNICATIONS DEVICES
PCD’S COMMITMENT
PCD believes that all of our customers should be able to enjoy the benets of digital wireless technologies.
We are committed to providing a selection of compatible devices for our customers who wear hearing aids.
THIS PHONE HAS A HAC RATING OF M4
WHAT IS HEARING AID COMPATIBILITY?
The Federal Communications Commission has implemented rules and a rating system designed to enable people who wear hearing aids to more eectively use these wireless telecommunications devices. The standard for compatibility of digital wireless phones with hearing aids is set forth in American National
01
02
03
04
05
06
07
133
Standard Institute (ANSI) standard C63.19. There are two sets of ANSI standards with ratings from one to four (four being the best rating): an “M” rating for reduced interference making it easier to hear conversations on the phone when using the hearing aid microphone.
HOW WILL I KNOW WHICH WIRELESS PHONES ARE HEARING AID COMPATIBLE?
The Hearing Aid Compatibility rating is displayed on the wireless phone box.
A phone is considered Hearing Aid Compatible for acoustic coupling (microphone mode) if it has an “M3” or “M4” rating.
HOW WILL I KNOW IF MY HEARING AID WILL WORK WITH A PARTICULAR DIGITAL WIRELESS PHONE?
You’ll want to try a number of wireless phones so that you can decide which works the best with your hearing aids. You may also want to talk with your hearing aid professional about the extent to which your hearing aids are immune to interference, if they have wireless phone shielding, and whether your hearing aid has a HAC rating.
134
•SAFETY
FOR MORE INFORMATION ABOUT HEARING AIDS AND DIGITAL WIRELESS PHONE
•
FCC Hearing Aid Compatibility and Volume Control –
http://www.fcc.gov/cgb/dro/hearing.html
•
Hearing Loss Association of America –
http://www.hearingloss.org/learn/cellphonetech.asp
•
CTIA –
http://www.accesswireless.org/hearingaid/
•
Gallaudet University, RERC –
http://tap.gallaudet.edu/voice
01
02
03
04
05
M4
FDA CONSUMER UPDATE
U.S. FOOD AND DRUG ADMINISTRATION  CENTER FOR DEVICES AND RADIOLOGICAL HEALTH
06
07
CONSUMER UPDATE ON WIRELESS PHONES
1. Do wireless phones pose a health hazard?
The available scientic evidence does not show that any health problems are associated with using wireless phones. There is no proof, however, that wireless phones are absolutely safe. Wireless phones emit low levels of radiofrequency energy (RF) in the microwave range while being used. They also emit very low levels of RF when in the idle mode. Whereas high levels of RF can produce health eects (by heating tissue), exposure to low level RF that does not produce heating eects causes no known adverse health eects. Many studies of low level RF exposures have not found any biological eects. Some studies have suggested that some biological eects may occur, but such ndings have not been conrmed by additional research. In some cases, other researchers have had diculty in reproducing those studies, or in determining the reasons for inconsistent results.
135
2. What is FDA’s role concerning the safety of wireless phones?
Under the law, FDA does not review the safety of radiation-emitting consumer products such as wireless phones before they can be sold, as it does with new drugs or medical devices. However, the agency has authority to take action if wireless phones are shown to emit radiofrequency energy (RF) at a level that is hazardous to the user. In such a case, FDA could require the manufacturers of wireless phones to notify users of the health hazard and to repair, replace or recall the phones so that the hazard no longer exists. Although the existing scientic data do not justify FDA regulatory actions, FDA has urged the wireless phone industry to take a number of steps, including the following:
•
Support needed research into possible biological eects of RF of the type
emitted by wireless phones;
•
Design wireless phones in a way that minimizes any RF exposure to the user that
is not necessary for device function;
and
•
Cooperate in providing users of wireless phones with the best possible
information on possible eects of wireless phone use on human health.
FDA belongs to an interagency working group of the federal agencies that have responsibility for dierent aspects of RF safety to ensure coordinated eorts at the federal level. The following agencies belong to this working group:
•
National Institute for Occupational Safety and Health
•
Environmental Protection Agency
•
Federal Communications Commission
•
Occupational Safety and Health Administration
•
National Telecommunications and Information Administration
The National Institutes of Health participates in some inter-agency working group activities, as well. FDA shares regulatory responsibilities for wireless phones with
136
•SAFETY
the Federal Communications Commission (FCC). All phones that are sold in the United States must comply with FCC safety guidelines that limit RF exposure. FCC relies on FDA and other health agencies for safety questions about wireless phones. FCC also regulates the base stations that the wireless phone networks rely upon. While these base stations operate at higher power than do the wireless phones themselves, the RF exposures that people get from these base stations are typically thousands of times lower than those they can get from wireless phones. Base stations are thus not the subject of the safety questions discussed in this document.
3. What kinds of phones are the subject of this update?
The term “wireless phone” refers here to hand-held wireless phones with built-in antennas, often called “cell,” “mobile,” or “PCS” phones. These types of wireless phones can expose the user to measurable radiofrequency energy (RF) because of the short distance between the phone and the user’s head. These RF exposures are limited by Federal Communications Commission safety guidelines that were developed with the advice of FDA and other federal health and safety agencies. When the phone is located at greater distances from the user, the exposure to RF is drastically lower because a person’s RF exposure decreases rapidly with increasing distance from the source. The so-called “cordless phones,” which have a base unit connected to the telephone wiring in a house, typically operate at far lower power levels, and thus produce RF exposures far below the FCC safety limits.
4. What are the results of the research done already?
The research done thus far has produced conicting results, and many studies have suered from aws in their research methods. Animal experiments investigating the eects of radiofrequency energy (RF) exposures characteristic of wireless phones have yielded conicting results that often cannot be repeated in other laboratories. A few animal studies, however, have suggested that low levels
01
02
03
04
05
06
07
137
of RF could accelerate the development of cancer in laboratory animals. However, many of the studies that showed increased tumor development used animals that had been genetically engineered or treated with cancer-causing chemicals so as to be predisposed to develop cancer in the absence of RF exposure. Other studies exposed the animals to RF for up to 22 hours per day. These conditions are not similar to the conditions under which people use wireless phones, so we don’t know with certainty what the results of such studies mean for human health. Three large epidemiology studies have been published since December 2000. Between them, the studies investigated any possible association between the use of wireless phones and primary brain cancer, glioma, meningioma, or acoustic neu-roma, tumors of the brain or salivary gland, leukemia, or other cancers. None of the studies demonstrated the existence of any harmful health eects from wireless phone RF exposures. However, none of the studies can answer questions about long-term exposures, since the average period of phone use in these studies was around three years.
5. What research is needed to decide whether RF exposure from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological studies of people actually using wireless phones would provide some of the data that are needed. Lifetime animal exposure studies could be completed in a few years. However, very large numbers of animals would be needed to provide reliable proof of a cancer promoting eect if one exists. Epidemiological studies can provide data that is directly applicable to human populations, but 10 or more years’ follow-up may be needed to provide answers about some health eects, such as cancer. This is because the interval between the time of exposure to a cancer-causing agent and the time tumors develop - if they do -may be many, many years. The interpretation of epidemiological studies is hampered by diculties in measuring actual RF exposure during day-to-day use of wireless phones. Many factors aect
138
•SAFETY
this measurement, such as the angle at which the phone is held, or which model of phone is used.
6. What is FDA doing to nd out more about the possible health eects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program and with groups of investigators around the world to ensure that high priority animal studies are conducted to address important questions about the eects of exposure to radiofrequency energy (RF). FDA has been a leading participant in the World Health Organization International Electromagnetic Fields (EMF) Project since its inception in 1996. An inuential result of this work has been the development of a detailed agenda of research needs that has driven the establishment of new research programs around the world. The Project has also helped develop a series of public information documents on EMF issues. FDA and the Cellular Telecommunications & Internet Association (CTIA) have a formal Cooperative Research and Development Agreement (CRADA) to do research on wireless phone safety. FDA provides the scientic oversight, obtaining input from experts in government, industry, and academic organizations. CTIA-funded research is conducted through contracts to independent investigators. The initial research will include both laboratory studies and studies of wireless phone users. The CRADA will also include a broad assessment of additional research needs in the context of the latest research developments around the world.
7. How can I nd out how much radiofrequency energy exposure I can get by using my wireless phone?
All phones sold in the United States must comply with Federal Communications Commission (FCC) guidelines that limit radiofrequency energy (RF) exposures. FCC established these guidelines in consultation with FDA and the other federal health and safety agencies. The FCC limit for RF exposure from wireless telephones is set at a Specic Absorption Rate (SAR) of 1.6 watts per kilogram
01
02
03
04
05
06
07
139
(1.6 W/kg). The FCC limit is consistent with the safety standards developed by the Institute of Electrical and Electronic Engineering (IEEE) and the National Council on Radiation Protection and Measurement. The exposure limit takes into consideration the body’s ability to remove heat from the tissues that absorb energy from the wireless phone and is set well below levels known to have eects. Manufacturers of wireless phones must report the RF exposure level for each model of phone to the FCC. The FCC website ( “c” in the subject index, select locating the FCC identication number on your phone so you can nd your phone’s RF exposure level in the online listing.
8. What has FDA done to measure the radiofrequency energy coming from wireless phones ?
The Institute of Electrical and Electronic Engineers (IEEE) is developing a technical standard for measuring the radiofrequency energy (RF) exposure from wireless phones and other wireless handsets with the participation and leadership of FDA scientists and engineers. The standard, “Recommended Practice for Determining the Spatial-Peak Specic Absorption Rate (SAR) in the Human Body Due to Wireless Communications Devices: Experimental Techniques,” sets forth the rst consistent test methodology for measuring the rate at which RF is deposited in the heads of wireless phone users. The test method uses a tissue-simulating model of the human head. Standardized SAR test methodology is expected to greatly improve the consistency of measurements made at dierent laboratories on the same phone. SAR is the measurement of the amount of energy absorbed in tissue, either by the whole body or a small part of the body. It is measured in watts/kg (or milliwatts/g) of matter. This measurement is used to determine whether a wireless phone complies with safety guidelines.
140
Cell Phones > Research
http://www.fda.gov
).) gives directions for
(under
•SAFETY
9. What steps can I take to reduce my exposure to radiofrequency energy from my wireless phone?
If there is a risk from these products—and at this point we do not know that there is—it is probably very small. But if you are concerned about avoiding even potential risks, you can take a few simple steps to minimize your exposure to radiofrequency energy (RF). Since time is a key factor in how much exposure a person receives, reducing the amount of time spent using a wireless phone will reduce RF exposure.
•
If you must conduct extended conversations by wireless phone every day, you
could place more distance between your body and the source of the RF, since the exposure level drops o dramatically with distance.
For example, you could use a headset and carry the wireless phone away from your body or use a wireless phone connected to a remote antenna. Again, the scientic data do not demonstrate that wireless phones are harmful. But if you are concerned about the RF exposure from these products, you can use measures like those described above to reduce your RF exposure from wireless phone use.
10. What about children using wireless phones?
The scientic evidence does not show a danger to users of wireless phones, including children and teenagers. If you want to take steps to lower exposure to radiofrequency energy (RF), the measures described above would apply to children and teenagers using wireless phones. Reducing the time of wireless phone use and increasing the distance between the user and the RF source will reduce RF exposure. Some groups sponsored by other national governments have advised that children be discouraged from using wireless phones at all. For example, the government in the United Kingdom distributed leaets containing such a recommendation in December 2000. They noted that no evidence exists that using a wireless phone causes brain tumors or other ill
01
02
03
04
05
06
07
141
eects. Their recommendation to limit wireless phone use by children was strictly precautionary; it was not based on scientic evidence that any health hazard exists.
11. What about wireless phone interference with medical equipment?
Radiofrequency energy (RF) from wireless phones can interact with some electronic devices. For this reason, FDA helped develop a detailed test method to measure electromagnetic interference (EMI) of implanted cardiac pacemakers and debrillators from wireless telephones. This test method is now part of a standard sponsored by the Association for the Advancement of Medical instrumentation (AAMI). The nal draft, a joint eort by FDA, medical device manufacturers, and many other groups, was completed in late 2000. This standard will allow manufacturers to ensure that cardiac pacemakers and debrillators are safe from wireless phone EMI. FDA has tested hearing aids for interference from handheld wireless phones and helped develop a voluntary standard sponsored by the Institute of Electrical and Electronic Engineers (IEEE). This standard species test methods and performance requirements for hearing aids and wireless phones so that that no interference occurs when a person uses a “compatible” phone and a “compatible” hearing aid at the same time. This standard was approved by the IEEE in 2000. FDA continues to monitor the use of wireless phones for possible interactions with other medical devices. Should harmful interference be found to occur, FDA will conduct testing to assess the interference and work to resolve the problem.
12. Where can I nd additional information?
For additional information, please refer to the following resources:
•
FDA web page on wireless phones (
http://www.fda.gov/Radiation-EmittingProducts/
RadiationEmittingProductsandProcedures/
142
•SAFETY
HomeBusinessandEntertainment/CellPhones/default.htm
•
Federal Communications Commission (FCC) RF Safety Program
(
http://www.fcc.gov/oet/rfsafety
•
International Commission on Non-Ionizing Radiation Protection
(
http://www.icnirp.de
•
World Health Organization (WHO) International EMF Project
(
http://www.who.int/emf
•
National Radiological Protection Board (UK)
(
http://www.hpa.org.uk/radiation/
)
)
)
)
)
AVOID POTENTIAL HEARING LOSS
Prolonged exposure to loud sounds (including music) is the most common cause of preventable hearing loss. Some scientic research suggests that using portable audio devices, such as portable music players and cellular telephones, at high volume settings for long durations may lead to permanent noise-induced hearing loss. This includes the use of headphones (including headsets, earbuds and Bluetooth® or other wireless devices). Exposure to very loud sound has also been associated in some studies with tinnitus (a ringing in the ear), hypersensitivity to sound and distorted hearing. Individual susceptibility to noise-induced hearing loss and other potential hearing problems varies.
The amount of sound produced by a portable audio device varies depending on the nature of the sound, the device, the device settings and the headphones. You should follow some commonsense recommendations when using any portable audio device:
•
Set the volume in a quiet environment and select the lowest volume at which
you can hear adequately.
01
02
03
04
05
06
07
143
•
When using headphones, turn the volume down if you cannot hear the people
speaking near you or if the person sitting next to you can hear what you are listening to.
•
Do not turn the volume up to block out noisy surroundings. If you choose to
listen to your portable device in a noisy environment, use noise-cancelling headphones to block out background environmental noise.
•
Limit the amount of time you listen. As the volume increases, less time is
required before your hearing could be aected.
•
Avoid using headphones after exposure to extremely loud noises, such as
concerts, that might cause temporary hearing loss. Temporary hearing loss might cause unsafe volumes to sound normal.
•
Do not listen at any volume that causes you discomfort. If you experience ringing
in your ears, hear mued speech or experience any temporary hearing diculty after listening to your portable audio device, discontinue use and consult your doctor.
YOU CAN OBTAIN ADDITIONAL INFORMATION ON THIS SUBJECT FROM THE FOLLOWING SOURCES:
AMERICAN ACADEMY OF AUDIOLOGY
11730 Plaza American Drive, Suite 300 Reston, VA 20190 Voice: 800-AAA-2336 Email: infoaud@audiology.org Internet:
www.audiology.org
144
•SAFETY
NATIONAL INSTITUTE ON DEAFNESS AND OTHER COMMUNICATION DISORDERS NATIONAL INSTITUTES OF HEALTH
31 Center Drive, MSC 2320 Bethesda, MD USA 20892-2320 Voice: (301) 496-7243 Email: nidcdinfo@nidcd.nih.gov Internet:
http://www.nidcd.nih.gov/health/hearing
NATIONAL INSTITUTE FOR OCCUPATIONAL SAFETY AND HEALTH
1600 Clifton Rd Atlanta GA 30333. USA Voice: 1-800-CDC-INFO (1-800-232-4636) Internet:
http://www.cdc.gov/niosh/topics/noise/default.html
FCC COMPLIANCE INFORMATION
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received. Including interference that
may cause undesired operation.
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful Interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
01
02
03
04
05
06
07
145
energy and, if Not installed and used in accordance with the instructions, may cause harmful Interference to radio communications. However, there is no guarantee that interference will not occur in a particular Installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet of a circuit dierent from that to which
the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for assistance.
CAUTION:
Changes or modication not expressly approved by the party responsible for Compliance could void the user’s authority to operate the equipment. Connecting of peripherals requires the use of grounded shielded signal cables.
146
•WARRANTY
12 MONTH LIMITED WARRANTY
Personal Communications Devices, LLC. (the “Company”) warrants to the original retail purchaser of this handheld portable cellular telephone, that should this product or any part thereof during normal consumer usage and conditions, be proven defective in material or workmanship that results in product failure within the rst twelve (12) month period from the date of purchase, such defect(s) will be repaired or replaced (with new or rebuilt parts) at the Company’s option, without charge for parts or labor directly related to the defect(s).
The antenna, keypad, display, rechargeable battery and battery charger, if included, are similarly warranted for twelve (12) months from date of purchase.
This Warranty extends only to consumers who purchase the product in the United States or Canada and it is not transferable or assignable.
This Warranty does not apply to:
(a) Product subjected to abnormal use or conditions, accident, mishandling,
neglect, unauthorized alteration, misuse, improper installation or repair or improper storage;
(b) Product whose mechanical serial number or electronic serial number has been
removed, altered or defaced.
(c) Damage from exposure to moisture, humidity, excessive temperatures or
extreme environmental conditions;
(d) Damage resulting from connection to, or use of any accessory or other product
not approved or authorized by the Company;
(e) Defects in appearance, cosmetic, decorative or structural items such as framing
and nonoperative parts;
01
02
03
04
05
06
07
147
(f) Product damaged from external causes such as re, ooding, dirt, sand,
weather conditions, battery leakage, blown fuse, theft or improper usage of any electrical source.
The Company disclaims liability for removal or reinstallation of the product, for geographic coverage, for inadequate signal reception by the antenna or for communications range or operation of the cellular system as a whole.
When sending your wireless device to Personal Communications Devices for repair or service, please note that any personal data or software stored on the device may be inadvertently erased or altered. Therefore, we strongly recommend you make a back up copy of all data and software contained on your device before submitting it for repair or service. This includes all contact lists, downloads (i.e. third-party software applications, ringtones, games and graphics) and any other data added to your device. In addition, if your wireless device utilizes a SIM or Multimedia card, please remove the card before submitting the device and store for later use when your device is returned, Personal Communications Devices is not responsible for and does not guarantee restoration of any third-party software, personal information or memory data contained in, stored on, or integrated with any wireless device, whether under warranty or not, returned to Personal Communications Devices for repair or service.
To obtain repairs or replacement within the terms of this Warranty, the product should be delivered with proof of Warranty coverage (e.g. dated bill of sale), the consumer’s return address, daytime phone number and/or fax number and complete description of the problem, transportation prepaid, to the Company at the address shown below or to the place of purchase for repair or replacement processing. In addition, for reference to an authorized Warranty station in your area, you may telephone in the United States (800) 229-1235, and in Canada (800) 465-9672 (in Ontario call 416-695-3060).
148
•WARRANTY
THE EXTENT OF THE COMPANY’S LIABILITY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT PROVIDED ABOVE AND, IN NO EVENT, SHALL THE COMPANY’S LAIBILITY EXCEED THE PURCHASE PRICE PAID BY PURCHASER FOR THE PRODUCT.
ANY IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL BE LIMITED TO THE DURATION OF THIS WRITTEN WARRANTY. ANY ACTION FOR BREACH OF ANY WARRANTY MUST BE BROUGHT WITHIN A PERIOD OF 18 MONTHS FROM DATE OF ORIGINAL PURCHASE. IN NO CASE SHALL THE COMPANY BE LIABLE FOR AN SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, WHATSOEVER. THE COMPANY SHALL NOT BE LIABLE FOR THE DELAY IN RENDERING SERVICE UNDER THIS WARRANTY OR LOSS OF USE DURING THE TIME THE PRODUCT IS BEING REPAIRED OR REPLACED.
No person or representative is authorized to assume for the Company any liability other than expressed herein in connection with the sale of this product.
Some states or provinces do not allow limitations on how long an implied warranty lasts or the exclusion or limitation of incidental or consequential damage so the above limitation or exclusions may not apply to you. This Warranty gives you specic legal rights, and you may also have other rights, which vary from state to state or province to province.
IN USA:
Personal Communications Devices, LLC. 555 Wireless Blvd. Hauppauge, NY 11788 1-800-229-1235
01
02
03
04
05
06
07
149
IN CANADA:
PCD Communications Canada Ltd. 5535 Eglinton Avenue West, Suite 234 Toronto, Ontario M9C 5K5 1- 800-465-9672
150
151
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
