Pantech C300 User Guide
5U010367000 REV00
USER MANUAL
MANUAL DEL USUARIO
USERS MANUAL
5U010367000 REV00
1
USER’S MANUAL
C300
Thank you for choosing the Pantech C300, our latest triband GSM mobile phone.
The C300 has many features that will enhance your mobile
experience. From its light weight and reliability, to the builtin camera with flash, we know you will enjoy all the features
the C300 has to offer.
The C300 user guide contains important information about
using your handset. Please read the manual thoroughly,
pay attention to the warranty on the back page and be alert
to the exclusions and limitations of your warranty, related to
the use of unauthorized components.
NOTE
Some information in this User Manual may differ from
your phone, depending on your software version and network
provider.
Design
Clamshell phone with internal and external TFT displays.
Displays
• 1.52” internal LCD
• 1.0” external LCD
• True TFT color display
• Supports up to 262K colors within 128 x 128 pixels
• 6 lines for text in basic mode with 16-pixel font
• Two programmable (“Soft”) selection keys [[] and []];
four-way scroll/selection ([o]) key
• List and grid menu
Melodies
Yamaha 64 poly sound.
MP3 ringtones
Camera
VGA CMOS built-in Camera.
•Resolution up to 640 x 480 (307,200 pixels)
•Self-timer function (5 seconds or 10 seconds)
•Internal and external displays function as viewfinders
•Flash LED (Light)
•Photo album
Dimensions & Weight
•Weight: 70.9 g
•Dimensions: 69 mm x 43 mm x 19.2 mm
Power Management (Performance)
Operating frequency
• GSM 850, DCS 1800, and PCS 1900 networks in North
America, South America, Europe, Africa, and Asia-Pacific
where these networks are supported.
• Automatic band switching.
Phone specifications
2
Battery Type Capacity Standby Time Talk Time
Standard
Lithium-Ion
(Li-ion)
Up to
850 mAh
Up to
250 hours
3 hours
Using a mobile phone while driving may be
prohibited.
Please check local laws and regulations with regard to the
prohibition of mobile phone use while driving, and comply
with them.
Use of your phone while you are driving may disturb your
concentration and so cause an accident. Always switch your
phone off as soon as possible.
Should you use your phone in an emergency, either use a
hands free device built into your car, or pull over in a safe
place first.
Switch off in restricted areas
Always switch your phone off in areas where mobile phone
use is restricted.
Switch off in explosive or dangerous areas
Always switch your phone off in areas with explosive or
dangerous materials (such as fuels, fuel stations or areas
containing chemical goods) and obey any instructions or
signals. Do not remove your mobile phone’s battery in such
areas
Switch off in aircraft
Always switch your phone off or select Flight Mode On
(press the [Menu] Soft key, select 9.Settings, select
4.Phone, and then select 3.Flight Mode) when you are in
an aircraft. The electromagnetic waves emitted by your
phone may affect the electronic navigation equipment in
the aircraft.
Switch off in hospitals and near medical equipment
Always switch your phone off in hospitals, and obey the
regulations or rules of the hospital.
Switch your phone off when using medical equipment
for private purposes, if possible. Always consult with the
medical equipment’s manufacturer or an expert regarding
phone use near the medical equipment.
Installing a hands free device in your vehicle
Install vehicle hands free devices away from the steering
wheel and airbag expansion area, otherwise injury may
result.
3
Safety precautions
Mobile phones and other electronic devices
Mobile phones emit electromagnetic waves that may affect
nearby electronic devices. When it is switched on, do not
place your phone close to delicate electronic equipment.
Safety precautions
4
5
Earpiece
Internal display
Right Soft key
External display
Camera Flash (LCD
mode)/Flashlight
Camera
Headset jack
Volume up (camera)/
down(flashlight/backlight)
Menu Scroll
Left Soft key
Cancel/back/text Clear/
edit exit key
Calendar
Power on/off
DiaI key
Call accept
Voicemail
Alphanumeric keys
Vibrate mode
Microphone
OK key (Menu confirm
key)
Four-way menu navigation/
special menu shortcut key
(write new message, Address
Book list, Photo Album,
Media Gallery)
Pantech C300 at a glance
Quick & easy
6
[ ]
o
c
s
e
1
Keys Functions
Left Right
Perform the functions shown at the bottom line of the display by using these Soft keys.
Scroll through the menu options in Menu mode.
In Standby mode:
Left key [l]: Access Media Gallery menu
Up key [u]: Access Write New message menu
Right key [r]: Access Address Book list menu
Down key [dD]: Access Photo Album list menu
In Standby mode, press to launch the WAP page directly.
Select a menu function or store user-input information, such as names. Also use this key for confirmation
(as the [OK ] key).
Deletes characters from the display, or returns to the previous menu.
If pressed briefly in Standby mode, opens Calendar view.
Makes or receives a call. If pressed in Standby mode, displays the Recent calls list.
If pressed and held in Standby mode, redials the last number called.
Ends the current call. If pressed and held in Menu mode, cancels user input and returns to Standby
mode. If pressed and held, outside Menu mode, switches your phone on/off.
If pressed and held in Standby mode, connects to the voicemail server automatically.
7
Quick & easy
0~9
*
0
zx
Keys Functions
Enters numbers, letters or special characters. If pressed in Standby mode, displays the dialing screen.
If pressed and held in Standby mode, enters or exits from Vibrate mode.
If pressed and held in Text input mode, displays the Symbol input screen.
If pressed in Predictive text input mode, switches to Word search mode.
Enters an international dialing prefix (+).
In Text input mode, enters the space character.
Adjusts the earpiece volume in calls, and moves the cursor upwards or downwards in menus.
If your phone is opened while in Standby mode, controls the Ring Volume.
In Standby mode, turn Camera preview mode on or off by pressing the side up-volume key. When the flip
is closed, press the side down key to turn the backlight on, and press and hold to turn flashlight on or off.
#
Locks the keypad if pressed and held in standby mode.
Press and hold [#] key to lock the keypad.
Contents
8
Getting started
Package contents .................................................................14
SIM card ................................................................................. 15
About your SIM card ...............................................................15
Installing/Removing your SIM card .........................................15
Battery ...................................................................................15
Inserting your battery ..............................................................15
Removing your battery ...........................................................15
Charging your battery ............................................................. 15
Internal & external displays .................................................17
Internal display .......................................................................17
Internal display icons .............................................................. 17
Automatic display off ..............................................................
20
Selecting functions and options ......................................... 21
Selecting functions and options when your phone is open ..... 21
Selecting functions and options when your phone is closed ..21
Side key special functions ......................................................22
Keypad lock ..........................................................................22
To lock the keypad ..................................................................
22
To unlock the keypad ..............................................................
22
Basic functions
Switching your phone on or off ..........................................24
To switch your phone on .........................................................
24
To switch your phone off .........................................................
24
Making and ending a call ..................................................... 24
To make a call .........................................................................
24
To end a call ...........................................................................
24
To make a call using Call Logs ...............................................
24
To make a call using Entry ......................................................
25
To make an International call ..................................................
25
To speed-dial from Entry .........................................................
25
To make an emergency call ....................................................
25
Answering a call ...................................................................26
To answer a call ......................................................................
26
To reply to a missed call .........................................................
26
To reject a call .........................................................................
26
To answer a second call .........................................................
26
To switch between two calls ...................................................
26
To end the current call ............................................................
27
Options during a call ............................................................27
To adjust the call volume ........................................................
27
To switch your microphone off (Mute) or on (Speak) ..............
27
•To switch your phone’s microphone off ...............................27
•To switch your phone’s microphone back on ......................27
To put a call on hold, and return to a held call ........................
27
•To put a call on hold ............................................................27
9
Contents
•To return to a held call ......................................................... 28
•To make a call while you are on a call ................................28
•To switch between two calls ................................................28
•To end a call ........................................................................28
Transferring a call ...................................................................
28
Multi-party calls ....................................................................... 28
•To make a multi-party call ...................................................28
•To add a new person to a multi-party call ...........................29
•To add a caller to a multi-party call .....................................29
•To view the status of multi-party call participants ................29
•To answer or make a second call during a multi-party call .29
•To have a private conversation with one participant ...........29
•To remove one participant from a multi-party-call ............... 29
Searching for a number in Address Book during a call ...........
30
•To search for a name or group in Address Book ................. 30
•To find a name manually in Address Book ..........................30
•To view the highlighted entry in Address Book ....................30
Using DTMF tones .................................................................. 30
Reading or writing a message during a call ............................ 30
Using your headset ..............................................................31
Selecting menu functions ....................................................32
Moving within your phone’s menu and submenu functions ....
32
Using the Shortcut Key in Standby Mode ...............................32
Entering text .......................................................................... 33
Input mode .............................................................................. 33
T9 mode .................................................................................33
ABC mode ..............................................................................33
123 mode ................................................................................ 33
Symbol mode .......................................................................... 33
To change Text input mode .....................................................
33
To insert a space ....................................................................
34
Scrolling ..................................................................................34
Clearing letters and words ......................................................34
Returning to the previous screen ............................................ 34
Using T9 mode .......................................................................
35
Using ABC mode ....................................................................
35
Changing case ........................................................................ 36
Using 123 mode .....................................................................36
Using Symbol mode ...............................................................36
Using My Words .....................................................................
36
Applications
Messaging ............................................................................. 40
Text Message .........................................................................
40
Multimedia Message ............................................................... 40
Receiving a new message ...................................................... 40
Contents
10
Managing memory ..................................................................40
Write New ...............................................................................
42
•Text Message ......................................................................42
•Multimedia Message ........................................................... 42
Inbox .......................................................................................45
Sent ........................................................................................47
Outbox .................................................................................... 48
Draft ........................................................................................48
Browser Msg ........................................................................... 48
Voicemail ................................................................................
49
Templates ...............................................................................
49
Settings ................................................................................... 49
•Common Settings ...............................................................49
•Text Message ......................................................................50
•Multimedia Message ........................................................... 50
•Voice Mail ............................................................................50
•Browser Message ..............................................................51
Memory Info ............................................................................ 52
Address Book .......................................................................52
Name Search .......................................................................... 52
Add Entry ................................................................................53
Speed Dial .............................................................................. 53
•To set Speed Dial ................................................................53
•To add to Speed Dial ........................................................... 53
•To edit Speed Dial ...............................................................54
•To remove from Speed Dial ................................................54
•To set Speed Dial in Name Search .....................................54
Group ...................................................................................... 54
Memory in Use .......................................................................54
Delete All ................................................................................
55
Copy All ..................................................................................
55
My Phone Number .................................................................. 55
Memory Info ............................................................................ 55
Service Numbers .................................................................... 55
Recent Calls .......................................................................... 56
Missed Calls ...........................................................................56
Received Calls ........................................................................ 56
Dialed Calls ............................................................................57
Delete Call Logs .....................................................................57
Call Time .................................................................................
57
GPRS Info ..............................................................................58
Media Gallery ........................................................................58
DRM/Forward Lock ................................................................. 58
Audio ......................................................................................58
Graphics .................................................................................59
Photo Album ...........................................................................
59
11
Contents
•Viewing the saved photos ................................................... 60
•Using the Photo Options ..................................................... 60
Memory Status .......................................................................60
Multimedia .............................................................................61
Camera ...................................................................................61
•Take a Photo .......................................................................61
•Using your camera options .................................................61
•Photo Album ........................................................................63
•Settings ............................................................................... 63
Games & Apps ........................................................................
64
•Games ................................................................................64
Settings .................................................................................64
Display ....................................................................................64
•Main Screen ........................................................................64
•Greeting ..............................................................................64
•Contrast ..............................................................................65
•Backlight .............................................................................65
Audio ......................................................................................65
•Ringtone .............................................................................. 65
•Volume ................................................................................66
•Alert Tones ..........................................................................66
•Key Tone .............................................................................66
•Sound Effects ...................................................................... 66
Call .........................................................................................67
•Call Forward ........................................................................ 67
•Answer Type ....................................................................... 68
•Auto Redial .........................................................................68
•Call Waiting .........................................................................69
•Caller ID .............................................................................. 69
Phone .....................................................................................69
•Language ............................................................................ 69
•Time & Date ........................................................................ 69
•Flight Mode .........................................................................69
Security ................................................................................... 70
•PIN1 Check .........................................................................70
•Change PIN1 ......................................................................70
•Phone Lock ......................................................................... 70
•Change Password ............................................................... 70
•Phone Barring ..................................................................... 70
•Fixed Dialing (Fixed Dialing Numbers) ...............................71
•Change PIN2 ......................................................................71
•Network Barring ..................................................................71
•Closed User Group (CUG) ..................................................71
Software Version ....................................................................
72
Reset ......................................................................................72
TTY .........................................................................................72
Contents
12
Network ..................................................................................72
Organizer ...............................................................................73
Alarm ......................................................................................73
•To set an alarm ...................................................................73
•To manage existing alarms .................................................73
Calendar ................................................................................. 73
Memo ...................................................................................... 75
Voice Memo ............................................................................
75
•To record a voice memo ...................................................... 75
•To manage voice memos ....................................................75
•To play a voice memo .........................................................76
WAP .......................................................................................
76
Home ...................................................................................... 76
OTA Settings Service ..............................................................
76
•WAP/ OTA Provisioning ......................................................76
Bookmarks .............................................................................. 77
Go to URL ............................................................................... 77
Profiles .................................................................................... 77
Cache .....................................................................................78
•Cache Mode ........................................................................ 79
•WClear Cache ..................................................................... 79
Security Certifications .............................................................79
Version ....................................................................................
79
Tools ......................................................................................
79
World Time .............................................................................
79
Calculator ...............................................................................79
Converter ................................................................................80
Stopwatch ...............................................................................80
SIM Tool Kit ............................................................................
80
Appendix
Menu tree ............................................................................... 84
Access codes ........................................................................ 86
Troubleshooting checklist ...................................................
87
Performance and safety .......................................................88
Glossary ................................................................................89
FCC & Industry Canada Regulatory Compliance ..............91
Warranty ................................................................................
93
1
Getting started
1. Package Contents
2. SIM Card
3. Battery
4. Internal & External Displays
5. Selecting Functions and Options
6. Keypad Lock
Package contents
14
* The actual contents may vary depending on your region.
Battery Travel charger User’s Manual
Phone
About your SIM card
When you subscribe to your network operator, you receive
a SIM (Subscriber Identity Module) card containing your
registration information, PIN code, etc.
Like a credit card, it should be kept secure and handled
carefully.
Do not bend, scratch or expose it to moisture.
Avoid static electricity.
To avoid corrupting your SIM card’s memory, always switch
off your phone before removing or inserting your SIM card.
Installing/Removing your SIM card
❶ Remove the battery from your
phone by pushing and lifting it as
shown below.
❷ If the SIM slot is empty, insert the
SIM card into the slot.
❸ To remove your SIM card, push the
SIM card in the arrow direction as
shown below.
Inserting your battery
Put the contacts of the battery into the
hole located at the bottom of the unit,
as shown in the following picture.
Press the upper side of the battery until
you hear the “click”.
Removing your battery
Push the battery-lock key up and
remove the battery.
Charging your battery
Your phone uses a Li-Ion battery. Make sure
to use an authorized battery and charger
only. For more details, please inquire at your
nearest dealer.
You can use your phone when the battery is
being recharged.
When the battery is inserted in your phone,
open the protective cover located on the
bottom of your phone and connect the
charger adapter, as shown below. A suitable
adapter is supplied with your phone.
15
SIM card & Battery
When your battery is fully charged,
remove the adapter connection from
the outlet, then disconnect the adapter
from your phone by pressing the
adapter’s side buttons and pulling the
adapter away from your phone, as
shown below.
•Do not use a damaged battery or charger.
•Use your battery for the specified purpose only.
• The closer you are to your network’s base station, the
longer your phone usage time because less battery
power is consumed for the connection.
• The battery recharging time varies depending on the
remaining battery capacity and the battery and charger
type you use.
• Battery life inevitably shortens over time.
• Use an authorized battery and charger only.
• Since overcharging may shorten battery life, remove the
phone from its charger once it is fully charged. Unplug the
charger, once charging is complete. Leaving the battery
in hot or cold places, especially inside a car in summer
or winter, may reduce the capacity and life of the battery.
Always keep the battery within normal temperatures.
• Do not put your battery into contact with conductive
objects.
• Dispose of and recycle used batteries in accordance with
local regulations. Do not dispose of batteries by burning;
they may explode.
• Do not use an unauthorized charger.
• To prevent injury or burns, ensure that no metal objects
come into contact with the + and – terminals of the
battery.
Battery
16
Tip
Your phone is powered by a Lithium Ion (Li-Ion) battery.
This means that, unlike other forms of battery technology, you can
recharge your battery while some charge remains without reducing
your phone’s autonomy due to the “battery memory effect” inherent
in those technologies.
17
Internal & External Displays
Your phone has two displays (internal and external). Icons
at the top of the internal display indicate your phone’s
status.
Internal display
Internal display icons
Depending on your phone’s status, the following icons may
appear at the top of the internal display.
Icon area
Text and graphic area
Displays the following information in Standby
mode:
Textural and graphical information showing
Network Name, Time and Date, or a Greeting
put in by the user.
Soft keys
Icon(s) Description
Received signal strength.The greater the number of bars,the stronger the signal.
A call is being made.
Your phone is outside the network coverage area;you cannot make or receive calls.
Internal External Displays
18
Icon(s) Description
WAP is connected.
You have received one or more text,multimedia or e-mail messages.
is displayed if the text message memory is full.
A GPRS signal is available.
is displayed when there is an active GPRS session.
Call-forwarding feature is activated.
Flight mode is activated.
Alarm is set.
You have set the alert type for incoming call to ring only.
You have received one or more voice messages.
You have received one or more WAP push messages.
19
Internal External Displays
You have set the alert type for incoming call to ring ascent (volume increases over the duration of
the ring).
You have set the alert type for incoming call to ring and vibrate.
Icon(s) Description
You have set the alert type for incoming call to vibrate then ring.
You have set the alert type for incoming call to silent.
You have set the alert type for incoming call to vibrate only. (Blue)
Headset is connected.
Battery level.The bar indicates the available battery charge.If your battery charge is low, is
displayed.
A message is being received.
You have set the alert type for all tones to be quiet and for all rings to vibrate only. (Red)
Internal External Displays
20
Automatic display off
If you do not press any key for ten seconds (dependent on the user setting) while the internal and external displays are
dimmed, the internal display turns off automatically to save power. To restore the display, press any key.
Icon(s) Description
A message is being sent.
Speakerphone mode is activated.
21
Selecting functions and options
Your phone offers several convenient ways for you to select
the phone function you want. You can access all of your
phone’s functions when it is open.
Selecting functions and options
when your phone is open
Your phone offers many phone operating and customization
functions arranged in menus and sub-menus. Each menu
and sub-menu allows you to view and change the settings
of the particular function. You access these functions using
the left and right selection (“Soft”) keys when your phone is
open. Soft key functions change depending on the current
context. The label or icon in the bottom line of the display,
above the Soft keys, shows each key’s current function.
To display the functions and options available, or
select the one required:
❶ Press the left or right Soft key as appropriate.
❷ To select the function that is displayed or option that is
highlighted, press the Soft key [[] or the [o] key.
❸ To highlight the next option on a list, press the [u/D]
key.
❹ To move back to the previous function or option on a list,
press the [c] key.
❺ To return to the Standby mode, press the [e] key.
Selecting functions and options
when your phone is closed
You can use some functions even though the phone is
closed. Here are functions of the side keys when the phone
flip is closed:
- Press to adjust the earpiece volume up.
- Press once to turn the ring off for an incoming call.
- Press and hold to reject an incoming call.
- Press and hold to turn the camera on/ off, while the flip is
closed. Press once to take a picture.
Side Up
z
•Adjusts the earpiece volume.
• Turns the melody off if pressed when you
receive an incoming call and the flip is closed.
• Rejects the incoming call if pressed and held
when you receive an incoming call and the
flip is closed.
• Turns the camera capture mode on/off, if
pressed and held.
NOTE
In some functions, you may be asked to enter a password
or PIN. Enter the required code then press the [
o] key.
Selecting functions and options & Keypad Lock
22
Side key special functions
Snap Shot: To initiate the camera function when the folder
is closed, press and hold the side [z] key. Press the side [z]
key again to take a photo. The image is saved in the album.
This function makes it easy to take a self portrait.
Flash Light: To turn ON the flash light, press and hold the
Side DOWN [
x] key. Press once to turn it OFF.
x
Side Down
•Press to adjust the earpiece volume down.
• Press once to turn off the ring for an incoming
call.
•Press and hold to reject an incoming call.
• Press once to turn the backlight on, while the
flip is closed.
•Press and hold to turn on the flash light.
•Press once to turn it off.
Keypad lock
To lock the keypad
Keypad lock prevents accidental pressing of the keys.
Press the [Menu] Soft key then select [
*] key within 3
seconds.
Press and hold [
#
] key to lock the keypad.
To unlock the keypad
Press the [Unlock] Soft key then select [*] key within 5
seconds to unlock the keypad.
2
Basic functions
1. Switching your phone on or off
2. Making and ending a call
3. Answering a call
4. Options during a call
5. Using your headset
6. Selecting menu functions
7. Entering text
To switch your phone on
❶ Open the phone.
❷ Press and hold the power on/off key until your phone
switches on.
❸ If you are asked to input your PIN (Personal Identification
Number), enter your SIM card’s PIN and press the [o]
key. (For further details, see Security on page 70.)
Your phone starts to search for an available network and
the current date and time is shown on the internal and
external displays. Once connected to the network, you can
make and receive calls.
To switch your phone off
Press and hold the [e] key until the power-off animation is
displayed.
Making and ending a call
To make a call
Enter the area code and phone number from Standby
mode, then press the [s] key.
To clear the last digit displayed, press the [
c] key.
To clear the all digits displayed, press and hold the [
c]
key.
To end a call
Press the [e] key in the normal way. To terminate all active
calls at the same time while you are in multi-party call,
select [Options] and then select [End All Calls].
Once the call is completed, a call summary (displaying
the recipient’s name or number, and the call length) is
displayed.
To make a call using Call Logs
Your phone logs up to 30 dialed, received and missed call
numbers. The last call number is saved in the first position.
Switching your phone on or off & Making and ending a call
24
NOTE
If a malfunction occurs while you use your phone or it is
not turned on, remove the battery then insert it again after 5 to 10
seconds.
NOTE
To change the language if you are switching on your
phone for the first time, select the Language menu option. (For
further details, see Language on page 69.)
NOTE
If you have turned the [Auto Redial] option on (For further
details, see Auto Redial on page 68), your phone will attempt to
make a call automatically for up to 10 times if it is not answered.
If you dial the same number more than once, only the latest
occurrence is saved.
❶ Press the [s] key to display the Call Logs list of dialed,
received or missed call numbers in reverse chronological
order.
❷ Press the [z/x] key or the [u/D] key to select a
number.
❸ Press the [s] key to dial the selected number.
(For further details, see 3. Recent Calls on page 56.)
To make a call using Entry
You can store frequently used names and phone numbers,
called Entry, in your SIM card or your phone’s memory.
Therefore; you do not have to remember all your phone
numbers; simply select the name to recall the associated
number.
❶ Press the [D] key to see the Name Search list.
❷ Select a number from Name Search.
❸ Press the [s] key to dial. (For further details, see 2.
Address Book on page 54)
To make an International call
❶ Press and hold the [0] key for the international prefix
until the ‘+’ character appears on the display, or type the
outgoing national code.
❷ Type the country code, area code, and phone number
that you want to call.
❸ Press the [s] key.
To speed‐dial from Entry
Press and hold the Speed Dial number to make a call using
the number you have saved. For example, press and hold
the [5] key to dial a number which you have saved as “5”
in your Speed Dial list.
(For further details, see Speed Dial on page 53.)
To make an emergency call
You can make emergency calls even if your phone does not
have a SIM card.
❶ Select Emergency Number, or press the [SOS] Soft key
if your phone does not have a SIM card.
❷ Press the [s] key.
25
Making and ending a call
NOTE
To redial the last number in the Call Logs list, press and
hold the [
s] key.
To answer a call
When you receive a call, your phone rings (or vibrates).
If the caller can be identified, the caller’s phone number is
displayed (or the caller’s name, if it is stored in your entry).
❶ To answer a call, open your phone.
❷ If your phone is already open, press the [s] key.
To reply to a missed call
If the incoming call could not be answered, a missed call
message is shown on your phone’s display to remind you of
the call you have missed.
To reply to a missed call, do the following.
Keep your phone open.
❶ Press the [View] Soft key to display the list of missed
calls.
❷ If necessary, scroll to highlight the number you want by
pressing the [u/D] l key.
❸ Press the [s] key to call.
Press the [
c] key or [e] key to close the ‘missed call’
notification message.
To reject a call
• Press the [e] key or the [Reject] Soft key. If the [Reject]
Soft key is pressed, the caller will hear Voice mail.
To answer a second call
You can answer an incoming call while you have a call in
progress, if your network service provider supports this
service and you have activated the Call Waiting option.
(For further details, see Call Waiting on page 69.)
You will be notified of an incoming call by a ‘call waiting’
tone.
Press the [
s] key. The first call is automatically put on hold.
To switch between two calls
Press the [Swap] Soft key.
Answering a call
26
If your answer type is set to [Any Key], you can answer
calls by pressing any key except the [
e] key. While the flip is
closed, you can press any side key to stop the ring, or press and
hold any side key to reject the call.
NOTE
NOTE
This function is network and subscription dependent, and
may not be available in all areas.
NOTE
This function is network and subscription dependent, and
may not be available in all areas.
To end the current call
Press the [s] key. The call on hold is automatically
reconnected to you.
Options during a call
To adjust the call volume
To adjust the earpiece volume during a call, do one of the
following.
• To increase the call volume during a call, press the [
z]
volume key on the left side of your phone.
• To decrease the call volume during a call, press the [
x]
volume key on the left side of your phone.
• In Standby mode with the folder open, adjust the ringtone
volume by using the [
z/x] keys.
To switch your microphone off
(Mute) or on (Speak)
You can temporarily switch your phone’s microphone off so
that the person you talk to on your phone cannot hear you.
For example, you may wish to say something to another
person in the room but do not want the person calling to
hear you.
To switch your phone’s microphone off
Press the [Mute] Soft key, or press [Options] then select
[Mute].
To switch your phone’s microphone
back on
Press the [Unmute] Soft key, or press [Options] then select
[Unmute].
To put a call on hold, and return to
a held call
You can put a call on hold whenever you want.
You can make another call while you have a call in progress
if your network service provider supports this service.
One call is active, while the other is on hold. You can also
switch between the calls.
To put a call on hold
Press the [Options] Soft key then select [Hold], or press the
[s] key.
The callers name and icon are grayed while the call is on
hold.
27
Answering a call & Options during a call
To return to a held call
Press the [Options] Soft key then select [Resume], or press
the [s] key again.
To make a call while you are on a call
❶ Enter the phone number that you want to dial or look it
up in Address Book entry.
❷ Press the [s] key to dial the second call. The first call is
automatically put on hold.
To switch between two calls
Press the [Swap] Soft key.
The current call is put on hold and the held call is
reactivated so that you can continue your conversation with
the caller.
To end a call
Press the [e] key in the normal way. To terminate all active
calls at the same time while you are in multi-party call,
select [Options] and then select [End All Calls].
Transferring a call
You can transfer or connect the current call to the held call if
your network service provider supports this service, so that
callers can talk to each other.
You will be disconnected from both of them.
❶ During a call, make or answer a call in the normal way
then press the [Options] Soft key.
❷ Press the [u/D] key to highlight the [Transfer] option
then press the [Select] Soft key or [o] key.
The two callers will be connected to each other.
Multi‐party calls
A multi-party call feature is a network service that allows up
to six people to take part in a multi-party or conference call
simultaneously.
For further details, contact your service provider.
To make a multi‐party call
❶ Call the first participant in the normal way.
❷ Call the second participant in the normal way. The first
call is automatically put on hold.
❸ To join the first participant to a multi-party call, press the
[Options] Soft key then select the [Join All] option.
❹ Press the [o] key
Options during a call
28
To add a new person to a multi‐party
call
❶ Call the person in the normal way.
❷ Press the [Options] Soft key then select the [Join All]
option.
❸ Press the [o] key.
To add a caller to a multi‐party call
Press the [Options] Soft key then select the [Join All] option.
To view the status of multi‐party call
participants
Press the [l/r] key. An icon indicates whether the remote
party is participating in the multi-party call (‘Far Multiparty’)
or on hold (‘Far Hold’.)
To answer or make a second call during
a multi‐party call
❶ Place the multi-party call on hold by pressing the
[Options] Soft key then selecting the [Hold All Calls]
option.
❷ Answer or make a call in the normal way.
❸ To reactivate the multi-party call on hold, press the
[Swap] Soft key.
❹ To end the multi-party call, press the [e] key or close
the flip.
To have a private conversation with one
participant
❶ Press the [Options] Soft key then select the [Private]
option.
❷ Press the [o] key.
❸ Press the [Uu/D] key to highlight the participant you
want then press the [o] key. Now you can talk privately
with that person.
❹ The other participants can continue the conversation
with each other.
❺ To return to the multi-party call, press the [Options] Soft
key then select the [Join All] option.
❻ Press the [o] key.
All of the multi-party call participants can now hear each
other.
To remove one participant from a multi‐
party‐call
❶ Press the [Options] Soft key then select the [Exclude]
option.
❷ Press the [u/D] key to highlight the participant then
29
Options during a call
Loading...
