Pantech C180 DUO User Manual

Thank you for choosing the AT&T Smart Device Pantech duo™, which has adopted the Microsoft Windows Mobile™ 6

Standard in a dual slider design to give you the convenience of Windows and the comfort of a familiar shape. Using ActiveSync

, you can keep your PC and Pantech duo™ synchronized at all times. The Pantech duo™ offers the various features listed below which are designed to enhance your mobile experience.

Key Features of the Pantech duo™

 Microsoft Windows Mobile™ 6 for Smartphone OS

 Full graphic TFT 262K Color LCD (240x320 pixel)

 Full QWERTY keyboard

 CMOS Camera (1.3 mega-pixels)

 Built-in Bluetooth Technology

 Advanced Voice Command Technology

 2-Way Text Messaging

 Multimedia Messaging Service

 E-mail Messaging Service

 microSD Card for External Memory (SDIO Support)

 Voice Memo

 Easy text entry using the XT9 text input mode

 Internet Access

IMPORTANT INFORMATION

This Pantech duo™ user guide contains very important information about how to handle and use the product.

Please read this manual thoroughly, pay attention to the warranty on the back page and be warned of the exclusions and limitations of your warranty, which is, for example, to prohibit using the unauthorized accessories or components.

WELCOME

MENU TREE

Using Shortcuts

Numbered menu items, such as menus, sub-menus, and options can be quickly accessed by using their shortcut numbers. In Start window, Main Menus can be accessed by pressing the number keys (1 to 0) corresponding to their location on the screen.

Example: Accessing the Shop Multimedia menu.

1. Press the [Start] soft key.

2. Press the [8] for AT&T Mall

3. Press the [1] for Shop Tones

4. Press the [1] for

Shop Games.

5. Press the scroll key to display the list of available games.

Menu Outline

The following list shows the menu structure and indicates the number assigned to each option.

1 Messaging

1.1 Messages

1.2

New E-mail Account

2 Calendar

3 Contacts

4 ActiveSync

5 AT&T Music

5.1 Windows Media Player

5.2 Shop Music

5.3 MusicID

5.4 XM Radio Mobile

5.5 Music Videos

5.6 The Buzz

5.7 Community

6 Cellular Video

7 MEdia Net

8 AT&T Mall

8.1 Shop Tones

8.2 Shop Games

3 Shop Graphics

4 Shop Multimedia

5 Shop Applications

6 MEdia Net Home

9 My Stuff

10 IM & E-mail

10.1 IM

11 MobiTV

12 Call History

13 Organizer

13.1 Alarm

13.2 Voice Note

13.3 Notepad

13.4 Calculator

13.5 World Time

13.6 Tasks

14 Office Mobile

14.1 Excel Mobile

14.2 Powerpoint Mobile

14.3 Word Mobile

15 Games

16 Internet Explorer

17 Applications

17.1 Camera

17.

2 Download Agent

17.

3 File Explorer

17.

4 Java

17.

5 Speed Dial

17.

6 Voice Command

17.

7 Task Manager

17.

8 ClearVue PDF

17.

9 Get TaleNav

17.10

My-Cast Weather

17.11

Myspace Mobile

18 Settings

18.1 Phone

18.

2 Sounds

18.

3 Profiles

18.

4 Home Screen

18.

5 Clock

18.

6 Connections

18.

7 Security

18.

8 Remove Programs

18.

9 Power Management

More...

1 IPM Power Mode

2 Accessibility

3 Text Input Mode

4 Regional Settings

5 Owner Information

6 About

7 Error Reporting

8 Windows Update

MENU TREE

CHAPTER 1

BEFORE USING YOUR PHONE ................................................................15

INSIDE THE PACKAGE .................................................................................. 16

HANDSET DESCRIPTION .............................................................................

ACTIVATING YOUR PHONE ..........................................................................

HOME SCREEN .............................................................................................

HOME SCREEN CUSTOMIZATION ..................................................................... 20

HOME SCREEN ICONS .......................................................................................

BATTERY USAGE ......................................................................................... 24

BATTERY INSTALLATION .................................................................................... 24

BATTERY REMOVAL ............................................................................................

BATTERY CHARGING ..........................................................................................

BATTERY STATUS CHECK LED ..........................................................................

BATTERY HANDLING INFORMATION ...............................................................

CHAPTER 2

BASIC OPERATION .................................................................................... 29

TURNING THE PHONE ON/OFF ................................................................... 30

TURNING THE PHONE ON ................................................................................ 30

TURNING THE PHONE OFF ................................................................................

USING THE QUICK LIST ............................................................................... 31

CALL FUNCTIONS ......................................................................................... 32

MAKE A CALL BY ENTERING A CONTACT NAME ......................................... 32

MAKE A CALL BY ENTERING A PHONE NUMBER .........................................

MAKE A CALL FROM AN OPEN CONTACT .....................................................

MAKE A CALL FROM THE CALL HISTORY

LIST .............................................. 33

MAKE A CALL USING A RECENTLY DIALED PHONE NUMBER ...................

MAKE A CALL FROM A HYPERLINK PHONE NUMBER .................................

ANSWER A CALL BY PRESSING ANY KEY .....................................................

ANSWER OR IGNORE A CALL ..........................................................................

ANSWER A SECOND CALL ................................................................................

INSERT A MANUAL PAUSE IN A DIALING SEQUENCE .................................

INSERT A THREE-SECOND PAUSE IN A DIALING SEQUENCE .....................

BASIC FUNCTIONS ....................................................................................... 37

SETTING UP YOUR VOICEMAIL ......................................................................... 37

LOCK THE KEYPAD ..............................................................................................

UNLOCK THE KEYPAD .........................................................................................

AUTO-LOCK THE KEYPAD ...................................................................................

SET THE DATE AND TIME ...................................................................................

SET THE IDLE TIMER ...........................................................................................

CHANGE THE HOME SCREEN APPEARANCE ..................................................

VIEW OPERATING SYSTEM INFORMATION ....................................................

ENTER OWNER INFORMATION .........................................................................

EXPLORE FILES AND FOLDERS .........................................................................

SILENCE THE RING TONE OF AN INCOMING CALL .......................................

MAKING AN EMERGENCY CALL ................................................................ 43

ENTERING TEXT AND NUMBERS ...............................................................

ENTERING TEXT AND NUMBERS ...................................................................... 44

CHANGE BETWEEN UPPERCASE, LOWERCASE, AND CAPS LOCK .............

CHANGE THE MULTIPRESS TIMEOUT ..............................................................

DELETE CHARACTERS ........................................................................................

CONTENTS

ENTER A SPACE ................................................................................................... 45

ENTER A SYMBOL ...............................................................................................

ENTER NUMBERS IN TEXT BOXES ..................................................................

ENTER PUNCTUATION IN MULTIPRESS MODE ..............................................

ENTER PUNCTUATION IN XT9 MODE .............................................................

ENTER TEXT IN XT9 MODE ...............................................................................

START A NEW LINE ............................................................................................

TURN ON CAPS LOCK ........................................................................................

ENTER THE PLUS SIGN FOR INTERNATIONAL CALLS ..................................

CHANGE THE INPUT MODE ...............................................................................

USING QWERTY KEYBOARD ....................................................................... 50

CHAPTER 3

CALENDAR, CONTACTS, CALL HISTORY & MY STUFF .......................53

CALENDAR ..................................................................................................... 54

SCHEDULE AN APPOINTMENT .......................................................................... 54

DELETE AN APPOINTMENT ...............................................................................

UPDATE AN APPOINTMENT ...............................................................................

VIEW AN APPOINTMENT ....................................................................................

VIEW APPOINTMENTS FOR THE WEEK ............................................................

VIEW TODAY’S AGENDA .....................................................................................

VIEW YOUR AGENDA FOR A SPECIFIC DATE ..................................................

VIEW YOUR SCHEDULE FOR THE MONTH ......................................................

MAKE AN APPOINTMENT RECURRING ............................................................

SHOW WEEK NUMBERS ....................................................................................

CHANGE THE WORKWEEK DISPLAY .................................................................

CHANGE THE REMINDER TIME ..........................................................................

CONTACTS .....................................................................................................63

CREATE A NEW CONTACT .................................................................................63

BEAM A CONTACT ..............................................................................................

CALL A CONTACT FROM CONTACT INFORMATION ......................................

CALL A CONTACT FROM THE CONTACT LIST ................................................

CHANGE THE DEFAULT NUMBER FOR A CONTACT ......................................

DUPLICATE A CONTACT .....................................................................................

COPY TO DEVICE / SIM ......................................................................................

COPY ALL TO DEVICE / SIM ...............................................................................

DELETE A CONTACT ...........................................................................................

DELETE ALL DEVICE / SIM .................................................................................

CREATE A CONTACT FOR A CALLER ..............................................................

FILTER THE CONTACT LIST ................................................................................

FIND A CONTACT ................................................................................................

SEND AN E-MAIL TO A CONTACT ....................................................................

SEND A TEXT MESSAGE TO A CONTACT ........................................................

VIEW AND EDIT CONTACT INFORMATION ......................................................

ADD A PICTURE TO A CONTACT .......................................................................

REMOVE A PICTURE FROM A CONTACT .........................................................

ASSIGN A CATEGORY TO A CONTACT ............................................................

ASSIGN A RING TONE TO A CONTACT ............................................................

CREATE A SPEED DIAL .....................................................................................

USING SPEED DIALS ..........................................................................................

VIEW AND EDIT A SPEED DIAL ........................................................................

DELETE A SPEED DIAL .......................................................................................

CALL HISTORY .............................................................................................. 79

VIEW CALL TIMERS ............................................................................................. 79

RESET CALL TIMERS ...........................................................................................

VIEW DETAILS ABOUT A CALL .........................................................................

CREATE A CONTACT FROM CALL HISTORY ...................................................

DELETE AN ITEM FROM CALL HISTORY .........................................................

DIAL THE LAST NUMBER CALLED ....................................................................

FIND A CONTACT FROM CALL HISTORY .........................................................

INSERT AN INTERNATIONAL COUNTRY CODE ..............................................

SEND AN E-MAIL MESSAGE FROM CALL HISTORY ......................................

MY STUFF ...................................................................................................... 84

CHAPTER 4

VOICE MAIL & MESSAGING .................................................................. 85

VOICEMAIL ..................................................................................................... 86

CALL YOUR VOICEMAILBOX ............................................................................... 86

TEXT MESSAGING ....................................................................................... 87

CREATE A TEXT MESSAGE ................................................................................ 87

DELETE ALL MESSAGES ....................................................................................

MULTIMEDIA MESSAGE .............................................................................. 89

CREATE A MULTIMEDIA MESSAGE .................................................................. 89

TEXT BOX .............................................................................................................

MULTIMEDIA MESSAGE MENU OPTIONS ......................................................

VIEW MULTIMEDIA MESSAGE ..........................................................................

SELECT MULTIMEDIA MESSAGE IN THE LIST OF MESSAGE TYPE ............

CHANGE MESSAGING ACCOUNT OPTIONS ...................................................

CHANGE HOW THE MESSAGE LIST DISPLAYS ..............................................

CREATE A MESSAGE FROM A CONTACT CARD ............................................

E-MAIL ............................................................................................................ 96

SYNCHRONIZING E-MAIL MESSAGES ............................................................. 96

DURING SYNCHRONIZATION: ...........................................................................

CONNECTING DIRECTLY TO AN E-MAIL SERVER ...........................................

FOLDER BEHAVIOR WITH A DIRECT CONNECTION TO AN E-MAIL SERVER

... 97

CREATING AN E-MAIL ACCOUNT .....................................................................

CREATE AN E-MAIL MESSAGE .........................................................................

OVERVIEW OF E-MAIL SECURITY ................................................................... 100

DOWNLOAD A COMPLETE E-MAIL MESSAGE ...............................................101

DOWNLOAD AN ATTACHMENT ........................................................................101

MARK A FOLDER FOR SYNCHRONIZATION .................................................. 102

ADD A PICTURE TO AN E-MAIL MESSAGE ................................................... 103

VERIFY THE DIGITAL SIGNATURE ON A SIGNED MESSAGE YOU RECEIVE

.. 103

SEND AND RECEIVE INTERNET E-MAIL MESSAGES ...................................

104

ADD A VOICE RECORDING TO AN E-MAIL MESSAGE .................................

104

SET UP AN INTERNET E-MAIL ACCOUNT MANUALLY ...............................

105

DELETE A MESSAGE ........................................................................................

107

DELETE AN ACCOUNT ......................................................................................

107

EDIT PREDEFINED TEXT ...................................................................................

108

EMPTY THE DELETED ITEMS FOLDER ...........................................................

109

FORWARD A MESSAGE ....................................................................................

109

INSERT PREDEFINED TEXT INTO A MESSAGE ..............................................

110

MARK A MESSAGE AS READ OR UNREAD ...................................................

110

MOVE A MESSAGE TO A DIFFERENT FOLDER ..............................................

111

OPEN A MESSAGE .............................................................................................

112

CONTENTS

QUICKLY MOVE BETWEEN ACCOUNTS ..........................................................112

SEND A MESSAGE DRAFT ................................................................................

113

REPLY TO A MESSAGE ......................................................................................

113

SAVE A DRAFT OF A MESSAGE ......................................................................

114

SPECIFY THE LANGUAGE FOR READING A MESSAGE ................................

114

STOP ADDING A SIGNATURE TO MESSAGES ...............................................

115

VIEW AN ATTACHMENT ....................................................................................

115

VIEW MESSAGE FOLDER CONTENTS .............................................................

116

VIEW THE INBOX MESSAGE LIST ....................................................................

116

VIEW THE LIST OF ACCOUNTS ........................................................................

117

WHAT IS SSL? ....................................................................................................

117

CHAPTER 5

ORGANIZER ............................................................................................. 119

ALARM ......................................................................................................... 120

USING THE ALARM ........................................................................................... 120

VOICE NOTE ................................................................................................ 121

CREATE A VOICE NOTE ....................................................................................121

LISTEN TO A VOICE NOTE ................................................................................

122

DELETE A VOICE NOTE .....................................................................................

122

RENAME A VOICE NOTE ..................................................................................

123

NOTEPAD ..................................................................................................... 124

TO ACCESS NOTEPAD ...................................................................................... 124

CREATING A MEMO ..........................................................................................

124

VIEWING A MEMO ............................................................................................

124

SENDING A MEMO ...........................................................................................

124

DELETING A MEMO ..........................................................................................

125

CALCULATOR .............................................................................................. 126

USING THE CALCULATOR ................................................................................ 126

WORLD TIME ............................................................................................... 127

USING THE WORLD TIME ................................................................................. 127

TASKS ........................................................................................................... 128

CREATE A TASK ................................................................................................. 128

CHANGE A COMPLETED TASK TO INCOMPLETE ..........................................

128

ASSIGN A CATEGORY TO A TASK ...................................................................

129

DELETE A TASK ..................................................................................................

130

MARK A TASK AS COMPLETE .........................................................................

130

LOCATE A TASK .................................................................................................

131

CHAPTER 6

AT&T MUSIC ............................................................................................ 133

WINDOWS MEDIA PLAYER® .................................................................... 134

COPYING MEDIA FILES .................................................................................... 134

PLAYING MEDIA FILES .....................................................................................

136

SETTING UP A PLAY LIST ................................................................................

138

SHOP MUSIC ............................................................................................ 141

USING ID SONG! .............................................................................................. 142

MUSIC ID .................................................................................................... 142

USING MANAGE ID’S ....................................................................................... 143

GETTING HELP WITH MUSIC ID .....................................................................

144

EXITING FROM THE MUSIC ID APPLICATION ...............................................

144

XM RADIO MOBILE .................................................................................... 146

MUSIC VIDEOS

.......................................................................................... 146

THE BUZZ

................................................................................................... 147

COMMUNITY ............................................................................................ 149

CHAPTER 7

AT&T MALL .............................................................................................. 151

SHOP TONES ............................................................................................... 152

SHOP GAMES .............................................................................................

153

SHOP GRAPHICS ........................................................................................

154

SHOP MULTIMEDIA ....................................................................................

155

SHOP APPLICATIONS .................................................................................

156

MEDIA NET HOME .....................................................................................

157

CHAPTER 8

CELLULAR VIDEO ................................................................................... 159

CELLULAR VIDEO ........................................................................................ 160

MEDIA CLIP OPTIONS ................................................................................

162

LIBRARY .............................................................................................................. 162

PLAY/PAUSE ........................................................................................................

162

STOP ....................................................................................................................

162

SHUFFLE/REPEAT ...............................................................................................

162

FULL SCREEN ....................................................................................................

162

OPTIONS ............................................................................................................. 163

PROPERTIES .......................................................................................................

163

SETTINGS ........................................................................................................... 164

CELLULAR VIDEO SETTINGS ...........................................................................

164

USING THE VIDEO CATEGORIES .............................................................. 165

VIEWING A VIDEO CLIP ....................................................................................165

CUSTOMIZING CELLULAR VIDEO ............................................................. 166

UPDATING THE FAVORITES LIST ..................................................................... 166

ADDING A VIDEO ALERT ..................................................................................

167

MY PURCHASES ......................................................................................... 168

PARENTAL CONTROLS ...............................................................................

169

SETTING UP PARENTAL CONTROL ................................................................ 169

CONFIGURING THE FILTERS ............................................................................

170

CHAPTER 9

IM&EMAIL, MOBITV, MEDIA NET, OFFICE MOBILE ..........................171

IM&EMAIL, MOBITV, MEDIA NET, OFFICE MOBILE ............................... 172

IM&EMAIL ........................................................................................................... 172

MOBITV ............................................................................................................... 172

MEDIA NET .........................................................................................................

173

OFFICE MOBILE ................................................................................................. 173

CHAPTER 10

CAMERA ................................................................................................... 175

CAMERA / CAMCORDER MODE .............................................................. 176

CONTENTS

SELECT VIDEO QUALITY ................................................................................. 176

COPY AN IMAGE TO YOUR PHONE

............................................................... 177

TAKE PICTURES USING A TIMER

..................................................................178

ADJUST PICTURES AND VIDEO FOR LIGHTING CONDITIONS ..................

178

SELECT WHERE PICTURES ARE SAVED .........................................................

179

CREATE A PICTURES FOLDER .........................................................................

179

EDIT A PICTURE ................................................................................................

180 VIEW PICTURES AS A SLIDE SHOW

............................................................. 181

SET A PICTURE AS THE HOME SCREEN

...................................................... 182

SEND A PICTURE VIA MULTIMEDIA MESAGE ..............................................

183

SAVE A COPY OF A PICTURE ..........................................................................

184

VIEW PICTURES ON YOUR PHONE ................................................................

184

CAMERA / CAMCORDER OPERATIONS ................................................. 185

CAMERA ............................................................................................................ 185

VIDEO ................................................................................................................. 185

RECORD A VIDEO .............................................................................................

185

PLAY RECORDED FILE ......................................................................................

186

TAKE A PICTURE ...............................................................................................

186

TAKE A PICTURE (MULTISHOT) .......................................................................

186

SNAPSHOT .........................................................................................................

187

VIEWING SAVED FILE .......................................................................................

187

CAMERA / CAMCORDER CONTROLS ...................................................... 188

CAMERA MENU ............................................................................................... 188

CAMCORDER MENU ........................................................................................

190

GENERAL SETTINGS .........................................................................................

192 CAMERA SETTINGS

........................................................................................ 194

CAMCORDER SETTINGS

................................................................................. 195

OVERVIEW OF THE DEFAULT HARDWARE BUTTON ASSIGNMENTS ........

196

CHAPTER 11

MOBILE INTERNET EXPLORER .............................................................197

USING INTERNET EXPLORER ................................................................... 198

ADD A WEB PAGE TO THE FAVORITES LIST .................................................. 198

CHANGE CONNECTION OPTIONS ..................................................................

199

CHANGE WEB PAGE DISPLAY OPTIONS .......................................................200

CLEAR HISTORY, COOKIES, OR TEMPORARY FILES ..................................... 201

CREATE A NEW FOLDER IN FAVORITES ........................................................ 201

DELETE A FAVORITE .........................................................................................

202

DISCONNECT FROM THE INTERNET ..............................................................

202

EDIT A FAVORITE ...............................................................................................

203

GO TO A LINK ....................................................................................................

203

GO TO A WEB PAGE ..........................................................................................

204

GO TO A WEB PAGE IN THE HISTORY LIST ...................................................

204

OPEN INTERNET EXPLORER ............................................................................

205

REFRESH A WEB PAGE .....................................................................................

205

RETURN TO A WEB PAGE YOU VISITED IN THE SAME SESSION ..............

205

VIEW A FAVORITE .............................................................................................

206

VIEW A LIST OF RECENTLY VISITED WEB PAGES ........................................

206

MOVE A FAVORITE TO A FOLDER ...................................................................

207

CHANGE THE SIZE OF TEXT ON WEB PAGES ..............................................

207

SHOW OR HIDE PICTURES ON WEB PAGES ................................................

208

VIEW A PAGE IN FULL SCREEN MODE .........................................................

208

SEND A LINK VIA E-MAIL ................................................................................ 209

ADJUST THE SCROLLING SPEED ....................................................................

210

CHAPTER 12

CONNECTIVITY, BLUETOOTH AND ACTIVESYNC ............................... 211

ACTIVESYNC ................................................................................................ 212

INSTALL AND SET UP ACTIVESYNC .............................................................. 212

SET UP AN EXCHANGE SERVER CONNECTION ..........................................

213

CHANGE ACTIVESYNC SETTINGS ..................................................................

214

SCHEDULE SYNCHRONIZATION AS ITEMS ARRIVE ....................................

215

CHANGE THE SYNCHRONIZATION SCHEDULE .............................................

216

START AND STOP SYNCHRONIZATION .........................................................

217

VIEW INFORMATION ABOUT SYNC STATUS ................................................

217

CHANGE SETTINGS FOR AN INFORMATION TYPE ......................................

218

CONNECT THE PHONE ......................................................................................

219

DEACTIVATE THE USB MODEM ......................................................................

219

CONNECT TO A PC USING CHARGEABLE USB CABLE ...............................

220

CONNECT TO A PC USING BLUETOOTH .......................................................

220

CHANGE E-MAIL SECURITY OPTIONS ...........................................................

221

EXCLUDE AN E-MAIL ADDRESS FROM REPLY ALL .....................................

222

BLUETOOTH ................................................................................................. 223

ACCEPT A BLUETOOTH PARTNERSHIP .......................................................... 223

CREATE A BLUETOOTH PARTNERSHIP ..........................................................

224

END A BLUETOOTH PARTNERSHIP ................................................................

225

MAKE YOUR DEVICE DISCOVERABLE ............................................................

226

RENAME A BLUETOOTH PARTNERSHIP ........................................................

227

TURN BLUETOOTH ON AND OFF ................................................................... 228

RECEIVE BEAMED INFORMATION ..................................................................

229

BEAM AN ITEM .................................................................................................

230

SET UP A BLUETOOTH-ENABLED HEADSET ................................................

231

SET UP A STEREO HEADSET ..........................................................................

232

TURN WIRELESS POWER ON OR OFF ...........................................................

233

CONNECT TO INTRANET URLS .......................................................................

234 USE A SPECIFIC CONNECTION TO CONNECT TO THE INTERNET

............ 235

EDIT A VPN CONNECTION ...............................................................................

236

OVERVIEW OF BLUETOOTH VIRTUAL COM PORTS .............................. 237

OUTGOING COM PORT .................................................................................... 237

SET UP AN OUTGOING BLUETOOTH COM PORT .......................................

237

CREATE A DIAL-UP CONNECTION ..................................................................

239

CREATE A PROXY CONNECTION ....................................................................

240

CREATE A VPN CONNECTION .........................................................................

241

DELETE A DIAL-UP CONNECTION ...................................................................

242

DELETE A PROXY CONNECTION ....................................................................

242

DELETE AN INTRANET URL .............................................................................

243

DELETE A VPN CONNECTION ..........................................................................

244

EDIT A DIAL-UP CONNECTION ........................................................................

244

EDIT A PROXY CONNECTION ..........................................................................

245

EDIT AN INTRANET URL ..................................................................................

246

CONNECTING THE GPS INTERMEDIATE DRIVER TO GPS HARDWARE .....

247

CONTENTS

CHAPTER 13

APPLICATIONS ......................................................................................... 249

DOWNLOAD AGENT ................................................................................... 250

FILE EXPLORER ...........................................................................................

251

JAVA .............................................................................................................

252

SPEED DIAL .................................................................................................

253

VOICE COMMAND .....................................................................................

254

1 - ADJUST THE MICROPHONE ....................................................................... 254

2 - SET THE VOICE COMMAND BUTTON ......................................................

254

3 - TRY OUT VOICE COMMAND ......................................................................

254

TRY OUT MORE COMMANDS .........................................................................

255

TO LEARN MORE .............................................................................................

255

USING THE VOICE COMMAND BUTTON ........................................................

256

MAKING PHONE CALLS ...................................................................................

257

SHOWING CONTACTS ......................................................................................

259

READING APPOINTMENTS ...............................................................................

260

PLAYING MUSIC ................................................................................................

261

STARTING PROGRAMS .....................................................................................

262

GETTING PHONE STATUS ................................................................................

263

GETTING VOICE COMMAND HELP .................................................................

263

PERSONALIZATION ...........................................................................................

264

GENERAL OPTIONS .........................................................................................

264

PHONE OPTIONS .............................................................................................

265

CALENDAR OPTIONS ......................................................................................

265

MEDIA OPTIONS ..............................................................................................

265 GENERAL TIPS

................................................................................................ 266

PHONE AND CONTACT TIPS ............................................................................

267

READING APPOINTMENTS TIPS ......................................................................

268

PLAYING MUSIC TIPS ........................................................................................

268

STARTING PROGRAMS TIPS ............................................................................

269

TROUBLESHOOTING .........................................................................................

270

TASK MANAGER ......................................................................................... 273

CLEARVUE PDF ...........................................................................................

274

GET TELENAV ..............................................................................................

275

MY-CAST WEATHER

– DEMO .................................................................... 276

MYSPACE MOBILE ......................................................................................

277

CHAPTER 14

SETTINGS ................................................................................................. 279

PHONE .......................................................................................................... 280

AUTO ANSWER .................................................................................................. 280

AUTO LOCK ........................................................................................................

280

CALL FORWARDING ..........................................................................................

280

CALL OPTIONS ..................................................................................................

281

TURN CALL WAITING NOTIFICATIONS ON AND OFF ..................................

281

CALLER ID ..........................................................................................................

282

CHANNELS .........................................................................................................282

FIXED DIALING ..................................................................................................

283

SELECT NETWORKS ..........................................................................................

283

ADD A NETWORK ..............................................................................................

284

DISPLAY YOUR PHONE NUMBER ....................................................................

284

CONTENTS

SERVICE DIALING NUMBERS (SDN) .............................................................. 285

SELECT TTY MODE ............................................................................................

285

SOUNDS ...................................................................................................... 286

CHANGE OR TURN SOUNDS ON OR OFF ..................................................... 286

DELETE A SOUND .............................................................................................

287

COPY A SOUND FROM YOUR PC TO YOUR PHONE ....................................

288

PROFILES ..................................................................................................... 289

VIEW THE LIST OF PROFILES .......................................................................... 289

EDIT A PROFILE .................................................................................................

289

CHANGE THE CURRENT PROFILE ...................................................................

290

HOME SCREEN ........................................................................................... 291

CHANGE THE HOME SCREEN APPEARANCE ................................................291

CLOCK .......................................................................................................... 292

SET THE DATE AND TIME ................................................................................. 292

AUTO UPDATE ...................................................................................................

292

CONNECTIONS ............................................................................................ 293

WIRELESS MANAGER ....................................................................................... 293

CREATE A BLUETOOTH PARTNERSHIP ..........................................................

294

CREATE A DIAL-UP CONNECTION ..................................................................

295

CREATE A

GPRS CONNECTION ...................................................................... 296

CREATE A PROXY CONNECTION ....................................................................

297

CREATE A VPN CONNECTION .........................................................................

298

END A BLUETOOTH PARTNERSHIP ................................................................

299

DELETE A DIAL-UP CONNECTION ...................................................................

299

DELETE A

GPRS CONNECTION ....................................................................... 299

DELETE A PROXY CONNECTION ....................................................................

299

CHANGE AN INTRANET URL ........................................................................... 301

MAKE YOUR DEVICE VISIBLE ........................................................................... 301

TURN ON AND OFF BLUETOOTH ................................................................... 302

RECEIVE BEAMED INFORMATION ..................................................................

302

BEAM AN ITEM .................................................................................................

303

SET UP AN OUTGOING BLUETOOTH COM PORT .......................................

304

SET UP A BLUETOOTH-ENABLED HEADSET ................................................

305

SECURITY .................................................................................................... 306

ENABLE THE DEVICE LOCK ..............................................................................306

DISABLE THE DEVICE LOCK .............................................................................

307

VIEW A CERTIFICATE ........................................................................................

308

DELETE A CERTIFICATE ....................................................................................

308

ACTIVATING THE SIM PIN ................................................................................

308

LOCKING THE SIM CARD ................................................................................. 310

CHANGING PIN2 ................................................................................................ 310

ENCRYPTION .......................................................................................................311

MASTER CLEAR

...............................................................................................311

REMOVE A PROGRAM ............................................................................... 312

POWER MANAGEMENT .............................................................................

313

IPM POWER MODE .....................................................................................

314

ACCESSIBILITY ............................................................................................

315

REGIONAL SETTINGS ................................................................................

316

ERROR REPORTING ....................................................................................

317

TURN ERROR REPORTING ON / OFF .............................................................317

CONTENTS

CHAPTER 15

GAMES ..................................................................................................... 319

SOLITAIRE .................................................................................................... 320

START A GAME OF SOLITAIRE .......................................................................320

HOW TO MOVE CARDS ....................................................................................

320

PLAY SOLITAIRE ................................................................................................

321

BUBBLE BREAKER ...................................................................................... 322

OVERVIEW OF BUBBLE BREAKER .................................................................. 322

BREAKER BONUS ..............................................................................................

322

START BUBBLE BREAKER ................................................................................

322

VIEW BUBBLE BREAKER STATISTICS ............................................................

323

MIDNIGHT POOL — DEMO ....................................................................... 324

BRAIN CHALLENGE

— DEMO .................................................................. 325

SCRABBLE BLAST

— DEMO ..................................................................... 326

TIGER WOODS PGA TOUR 07

— DEMO ................................................. 327

JEWEL QUEST 2

— DEMO ....................................................................... 330

CHAPTER 16

SAFETY AND WARRANTY ....................................................................329

SAFETY INFORMATION FOR WIRELESS HANDHELD PHONES ............ 330

EXPOSURE TO RADIO FREQUENCY SIGNALS ..............................................330

ANTENNA CARE ................................................................................................

330

DRIVING SAFETY ...............................................................................................

331

ELECTRONIC DEVICES ......................................................................................

332

PRECAUTIONS ...................................................................................................

334

SAFETY INFORMATION FOR FCC RF EXPOSURE .................................. 335

BODY-WORN OPERATION ................................................................................. 335

SAR INFORMATION .................................................................................... 336

SAFETY INFORMATION FOR BATTERY USAGE ............................................ 337

FCC & INDUSTRY CANADA REGULATORY COMPLIANCE .................... 337

FCC HEARING-AID COMPATIBILITY REGULATIONS FOR WIRELESS DEVICES

.. 340

FDA CONSUMER UPDATE .........................................................................

342

PROTECT YOUR WARRANTY .....................................................................

346

MANUFACTURER’S WARRANTY ...............................................................

347

12 MONTH LIMITED WARRANTY .................................................................... 347

MEMO

Chapter 1

BEFORE USING

YOUR PHONE

 INSIDE THE PACKAGE

 HANDSET DESCRIPTION

 ACTIVATING YOUR PHONE

 HOME SCREEN

 BATTERY USAGE

C H 1

This package should include all items pictured below.

If any are missing or different, you should immediately contact the retailer where you purchased the phone.

AC Travel ChargerHandset

Standard Battery

INSIDE THE PACKAGE

User Manual

The Pantech duo™ weight is 110 g. The dimensions are 102x50 x21.1 mm.

HANDSET DESCRIPTION

Earpiece

Right Soft Key Performs functions in lower right display.

END/Power Key Turns phone on/off, ends calls, exits menus.

Microphone

Navigation Keys Press to enter menu system. Press to scroll through menus and lists.

SEND Key

Home Key

Quick List/Lock

Cancel key

microSD Card I/O Slot

Left Soft Key Performs functions in lower left display.

Selected

Menu Item

Menu features

Messaging Calendar Contacts

ActiveSync AT&T Music Cellular Video

MEdia Net AT&T Mall My Stuff

IM & E-mail MobiTV Call History

Organizer Office Mobile Games

Internet Explorer Applications Settings

C H 1

Camera Lens

Camera Key

Record/ Voice Command Key

HANDSET DESCRIPTION

Mirror

External speaker

QWERTY keypad

LCD horizon View Screen

Left and Right Functional Soft Keys

Volume Key

Holding device at internal antenna area might affect call quality reception.

Internal Antenna

C H 1

ACTIVATING YOUR PHONE

If you have purchased Pantech duo™ from the AT&T Store, it has been activated already and

is ready to use. If you have upgraded your phone or received a new phone by mail, it probably needs to be activated before you can use it.

To activate your phone, follow these steps:

1. Visit an AT&T Store and have your phone activated, and place your

cursor on the MY ACCOUNT tab available on the home page.

2. When the drop-down menu “HOW To

” Wireless Guide displays, select ACTIVATE YOUR NEW PHONE and click GO, to display instructions needed to activate your phone online.

3. After gathering the required materials, select the Activated New Phone link and follow the online directions to complete the activation process.

C H 1

The Home Screen plays an integral part in the navigational mode of your Smartphone. It is the first screen displayed every time the phone is turned on. You can easily return to the Home screen by pressing the HOME key.

Select and press the OK key to access

your most recently used programs

AT&T Operator Name and date/

time

Appointment List

Your current profile in use Number of unread voicemail messages

Number of unread messages

Soft key commands

HOME SCREEN CUSTOMIZATION

The Home Screen allows you to customize your start page. It can be used to display a variety of information, such as phone-specific status, information from over-the-air services, and information from personal information manager (PIM) applications. You can fully customize the Home Screen by installing new plug-ins and schemes.

HOME SCREEN ICONS

Status icons appear at the top of the screen and on the Home screen. The following table lists common status icons and their meanings.

Indicator Meaning

Multimedia message (MMS) or Text message (SMS)

New voicemail

New e-mail

Voice call

HOME SCREEN

C H 1

HOME SCREEN

Indicator Meaning

Voice call in progress

GPRS / EDGE / 3G Data call in progress

Calls are forwarded

Call on hold

Missed call

Line 1/Line 2

Battery level

Low battery

Battery charging

No battery

Signal strength

No signal

No wireless coverage

ActiveSync/Synchronization error

Phone off

Silent

Multipress text input mode, lowercase

Multipress text input mode, uppercase first character only

Multipress text input mode, uppercase

XT9 text input mode, lowercase

XT9 text input mode, uppercase first character only

C H 1

HOME SCREEN

Indicator Meaning

XT9 text input mode, uppercase

Numeric input mode

GPRS connection available

EDGE connection available

3G connection available

Bluetooth ON

Missing SIM card

Voice Command Enabled

microSD card inserted

Speaker phone on

Keys Functions

[Send] key

Press to make or receive a call. Short press: View Recent Calls. Long press: Make a call to the last number called.

[End ] key

Press to turn the phone on/off, to terminate a call or to return to the Home Screen.

[Lef t] soft key

Press to access the main menu or the Menu functions displayed on the bottom line.

[Right] soft key

Press to access Contacts or Menu function displayed on bottom line.

[Quick List] key

Short press to launch the Quick List. Long press to enter lock mode.

[C/Back] key

Press to clear a digit from the display or to return to the previous page.

C H 1

HOME SCREEN

Keys Functions

Numeric

keypad

* key

A short press changes to capital letters or symbols during text entry mode. A long press shows menu for changing letters or symbols.

Numeric

keypad

0 key

Press and hold to insert a ‘+’ for international call

Numeric

keypad

# key

Press to insert a space and long press to enter choosing symbols during text entry mode.

[Home] key

Press to return to the Home screen.

[Volume ] key

Press to adjust voice volume during a call, and adjust audio volume in standby mode.

[Recording ] key

Activates Voice Command or Voice Notes.

A long

press enters voice command state as default.

[Camera] key

Press to launch the camera application.

Numeric

key pad

1~9 keys

Press from number 1 to number 9 on numeric key pad, it prints numeric number of corresponding alphabet each situation.

Qwerty

: left / right soft keys A ~ Z: alphabet key. FN: function key. Press and hold this key and

press alphabet key at once, it prints blue colored symbols or numbers.

Enter: enter key Back: back key Caps Shift: one time press for first word in

capital, double press for holding in capitals.

C H 1

BATTERY USAGE

The battery is not charged when the phone is first purchased – fully charge the battery before first use. The battery will charge faster if the phone is powered off while charging. Battery operating time gradually decreases over time. If the battery fails to perform normally, you may need to replace it.

BATTERY INSTALLATION

Be sure to use only the batteries that have been provided with the phone. Installation is easier if you have placed the phone on a flat surface.

Place the battery on the back of the handset and slide into place.

Push the battery down until it locks into place.

BATTERY REMOVAL

Again, place the battery on a flat surface and use an even, steady pressure when removing the battery.

Pull the release latch upwards, lift up the battery.

Remove the battery from the handset.

C H 1

BATTERY USAGE

If the battery is not correctly placed in the compartment,

the handset will not turn on and/or the battery may detach during use.

BATTERY CHARGING

Make sure the battery is properly installed in the handset. Use all normal cautions when working with a standard wall outlet.

BATTERY STATUS CHECK LED

LED is located at the left side of earpiece.

LED color &

blinking

Status Action

Orange Static

Phone is being Power

Turn off after 3 seconds.

Red Static

Now Charging

Green Static

Charging Complete

Red Blinking

Charging Error (No Battery, Hot or Cold Battery, Bad Charger, Bad Battery)

Blinking every 1 second.

C H 1

BATTERY USAGE

POWER CONNECTION

Plug the AC Charger into a standard outlet.

Plug the other end of the AC Charger into the bottom of your phone. The battery must be installed in the phone.

POWER-OFF CHARGING

• The

Pantech duo™

will enter ‘power-off charging mode’ automatically

if you try to charge it with the device powered off.

• Charging state will be displayed according to the current state. (complete, 0% ~ 90% and error )

• Backlight will turn on for 5 seconds if you press any key except [END] key.

• Press

[End] key if you want to exit ‘power-off charging mode’ and

turn on.

___________________________

_______________________________

C H 1

BATTERY USAGE

BATTERY USAGE TIMES

The operating time is subject to your handset usage and configuration.

Battery Capacity Talk Time

STD 1320 mAh Up to 180 minutes

BATTERY STANDBY TIMES

The operating time is subject to your handset usage and configuration.

Battery Capacity Standby Time

STD 1320 mAh Up to 250 hours

These times are for a new battery. Usage and Standby times may decrease over time.

• The battery may not be fully charged at the time of purchase.

• Fully charge the battery before use.

• The battery must be connected to the phone in order to charge it.

• Battery operating time gradually decreases over time.

• If the battery fails to perform normally, you may need to

replace the battery.

_____________________________

_________________________________

C H 1

BATTERY USAGE

BATTERY HANDLING INFORMATION

The correct usage and handling of batteries can preserve the lifetime of your phone and ensure proper operation. Operating times are subject to the usage and configuration of your handset; please see the label on your battery for your battery’s capacity. Follow these suggestions carefully.

DOs

• Only use the battery and charger approved by the manufacturer.

• Only use the battery for its original purpose.

• Try to keep

the battery in a temperature range of 41ºF (5ºC) to 95ºF (35ºC). Otherwise, it could significantly reduce the capacity and lifetime of the battery.

• If the battery is stored in temperatures above or below the recommended range, give it time to warm up or cool down before using it.

• Completely drain the battery before recharging. It may take one to four days to completely drain.

• Store the discharged battery in a cool, dark, and dry place.

• Purchase a new battery when its operating time gradually decreases after fully charging.

• Dispose of and recycle used batteries in accordance with local regulations.

DON’Ts

• Don’t use a damaged battery or charger.

• Don’t attempt to disassemble the battery – it is a sealed unit with no serviceable parts.

• Don’t accidentally short circuit the battery by carrying it in your pocket or purse with other metallic objects such as coins, clips and pens. This may critically damage the battery. To prevent injury or burns, ensure that no metal objects come into contact with the + and – terminals of the battery.

• Don’t dispose of batteries by burning; they may explode.

______

____________

BASIC

OPERATION

Chapter 2

This chapter addresses and explains the basic features of your phone including:

 TURNING THE PHONE ON/OFF

 USING THE QUICK LIST



CALL FUNCTIONS



BASIC FUNCTIONS



MAKING AN EMERGENCY CALL

 ENTERING TEXT AND NUMBERS

C H 2

TURNING THE PHONE ON

Press and hold the END key E until your “Power On” logo appears.

• If “Password” appears on the display, enter your 4-digit password to unlock your phone.

• If

the battery does not have enough charge to turn on the phone, the keypad will not light up. You should charge your phone before turning it on.

TURNING THE PHONE OFF

Press and hold the END key E until the “Power Off” logo appears.

Immediately change or recharge the battery when the battery low alert window appears on the display as “Alert

– Main Battery low. To prevent possible data loss, replace or recharge the battery according to the owner’s manual.” The phone’s memory may possibly be damaged if the phone turns off due to the battery completely draining. If the phone turns off, unsaved data may be lost.

TURNING THE PHONE ON/OFF

TIP

USING THE QUICK LIST

The Quick List provides a list of commands that you can use to quickly perform common actions.

Press the Quick List F key.

Use the Navigation Key to select the Quick List command you want.

To Select this command

Turn off the phone.

Power off

Turn on or off any wireless connection, such as a Bluetooth, Cellular phone. (You will not be able to make or receive phone calls.)

Wireless Manager

Lock the keypad so that you cannot make accidental key presses. To unlock the keypad, press Unlock, and then press the * key.

Lock

Make one of these profiles the active profile.

Normal Silent Vibrate Outdoor Automatic

You can turn off wireless connections to preserve battery life when you don’t want to make or receive calls, or in environments where cell phones must be turned off. When wireless connections are off you can still use other phone features.

C H 2

Your Pantech duo™ phone has many options. This section will show you how to use basic functions such as making and receiving calls, locking and unlocking your phone, and managing the appearance and settings on your phone.

MAKE A CALL BY ENTERING A CONTACT NAME

Your phone allows you to call someone from your contact list or address book. The screen will

auto-fill the contact name as you begin

to enter it.

On the Home screen, begin entering the contact name.

When you see the contact name you want to call, select it and press left soft key > [Call].

MAKE A CALL BY ENTERING A PHONE NUMBER

On the Home screen, begin entering the phone number.

Do one of the following:

• If you see the number or contact name to call, select it and

press left soft key > [Call].

• If you do not see the number or contact name, finish entering the number and press

OK or Send key.

CALL FUNCTIONS

TIP

C H 2

MAKE A CALL FROM AN OPEN CONTACT

You can open contacts from the main screen and make a call from that contact.

On the Home screen, press the right soft key > [Contacts].

Select the contact to call and press OK.

Select the phone number to call and press

OK or

left soft key

< [Call] or Send key.

If you have a long list of contacts, you can use a shortcut to find the contact you want. Enter the first few letters of the contact’s name. When you do this, the phone searches through the contact list and displays the name. To call the contact, select the phone number and press

OK or Left Soft Key [Call].

MAKE A CALL FROM THE CALL HISTORY LIST

Call History displays calls you have made, received, and missed.

On the Home screen, press [Start] and select

Call History using the Navigation Key.

Select the name or phone number to call.

Press S.

CALL FUNCTIONS

C H 2

CALL FUNCTIONS

MAKE A CALL USING A RECENTLY DIALED PHONE NUMBER

Your phone will maintain a list of recent calls you have made. These calls are always easily accessible for redialing.

On the Home screen, press SEND to display a list of recent calls.

Select a name or phone number to make a call.

Press S.

MAKE A CALL FROM A HYPERLINK PHONE NUMBER

You can quickly dial a phone number from an e-mail or text message that contains a hyperlink phone number. A hyperlink phone number is underlined in the same manner as a Web site address.

From a message containing a hyperlink phone number, select the phone number and press

OK.

ANSWER A CALL BY PRESSING ANY KEY

You can set your phone to answer by pressing any key.

On the Home screen, press [Start] [Settings] [Phone] [Call Options].

Use the Navigation key to select “Any Key answer” and press

[OK] to check on the item and

press Left Soft Key

[Done] to finish.

C H 2

CALL FUNCTIONS

ANSWER OR IGNORE A CALL

To answer the call, press SEND or press Answer. To reject the call, press

END or press Ignore.

Selecting Ignore will connect the caller to your voicemail if you subscribe to this service.

ANSWER A SECOND CALL

To put the first call on hold and answer the second call, press SEND key or press [Answer]

To switch between calls, press

[Swap].

To end the second call and go back to the first, press

End key.

INSERT A MANUAL PAUSE IN A DIALING SEQUENCE

On the Home screen, press the right function key > [Contacts].

Press the contact in whose phone number you want to insert a pause.

Select the phone number and press [Menu] [Edit].

Place the cursor where you want to insert the pause.

C H 2

Press [Menu] [Insert Wait]. The letter w appears where the manual pause will occur in the dialing sequence.

Press [Done].

To resume dialing after reaching a manual pause, press OK.

INSERT A THREE-SECOND PAUSE IN A DIALING SEQUENCE

There may be occasions when you wish to pause dialing after you’ve selected a contact to call. You can insert a three

-second pause

between selecting a contact to call and when the phone actually dials.

On the Home screen, press the right function key > [Contacts].

Press the contact in whose phone number you want to insert a pause.

Select the phone number and press [Menu]

[Edit].

Place the cursor where you want to insert the pause.

Press [Menu] [Insert Pause]. The letter p appears after three-second pause will occur in the dialing sequence.

Press [Done].

CALL FUNCTIONS

C H 2

SETTING UP YOUR VOICEMAIL

SET UP VOICEMAIL

All unanswered calls to your AT&T Pantech duo™ are sent to voicemail, even if your phone is turned off. You’ll want to set up your voicemail and personal greeting as soon as you activate your Pantech duo

™. Your service provider has assigned your voicemail

number to the 1 key.

CHECK VOICEMAIL

When checking your voicemail, all unanswered calls will be played back in the order they were received. After you have entered your voicemail

you will hear options, to save, delete, replay, or skip each message.

Press and hold 1 key to call your voicemailbox.

Follow the instructions to retrieve it.

BASIC FUNCTIONS

_____________________

TIP

C H 2

BASIC FUNCTIONS

LOCK THE KEYPAD

Locking the keypad turns off keypad functionality. This is a helpful feature if, for example, the phone is turned on and in your pocket, and you want to prevent accidental key presses.

Display the Quick List by pressing

Select [Lock] and press OK or press and hold key until it enters in the lock mode directly.

Once the keypad is locked, the left soft key label changes to Unlock.

You can still receive calls and make emergency calls when the keypad is locked.

You can use a shortcut to quickly lock your phone by using one simple button. Press key F and hold until displaying [Unlock] on the soft menu

UNLOCK THE KEYPAD

On the Home screen, press Unlock and press the * key.

C H 2

BASIC FUNCTIONS

AUTO-LOCK THE KEYPAD

When deactivating the locked key, you have to enter * key additionally. However, with Auto-Lock, you can deactivate the lock function automatically. Activate Auto-Lock as follows before using it.

Select [Start] [Settings] [Phone] [Auto Lock] on the Home screen.

Change the status of Auto-Lock to ‘On’.

Select [Done].

Once Auto-Lock is activated, the keypad will become locked when the slide is lowered and the screen is turned off. You can unlock the setting in this condition by pressing the key for one second or simply open the slide.

SET THE DATE AND TIME

Your phone is not preset with current date and time. You will need to select the time zone and the date and time.

On the Home screen, press [Start], select Settings with the Navigation Key, or select Settings from the menu bar on top of the Home

screen.

Select Clock, press OK, then Date and Time.

In Time Zone, select your time zone using the left and right Navigation Keys.

In Date, edit the month, day, or year.

In Time, edit the hour, minute, and second.

Press [Done].

C H 2

BASIC FUNCTIONS

SET THE IDLE TIMER

Your Pantech duo™ will automatically return to the Home screen after a period of inactivity. You can adjust the amount of time before the Pantech duo™ defaults to the Home screen.

On the Home screen, press [Start], select Settings with the Navigation Key, or select Settings from the menu bar on top of the Home screen and press OK.

Select Home Screen.

Select Time out, use left and right Navigation Keys to set the amount of time for the phone to be idle before the Home screen automatically appears.

Press [Done].

CHANGE THE HOME SCREEN APPEARANCE

The Pantech duo™ allows you to choose from many color schemes and layouts and allows you to use a background image for the main screen.

On the Home screen, press [Start], select Settings with the Navigation Key, or select Settings from the menu bar on top of the Home screen and press OK.

Select Home Screen.

Under the Home Screen Layout, select a

Color

scheme, and Background image

Press [Done].

C H 2

BASIC FUNCTIONS

VIEW OPERATING SYSTEM INFORMATION

There may be instances when you wish to see the basic information about your phone’s operating system. This option allows you to see summaries of all the settings on your phone.

On the Home screen, press [Start], select Settings with the Navigation Key, or select Settings from the menu bar on top of the Home screen and press OK.

Press More..., then select About.

To see About and more settings, press More....

ENTER OWNER INFORMATION

Entering and displaying owner information allow someone to return the phone to you in case it is lost.

On the Home screen, press [Start] [Settings] [More...] [Owner Information]

Complete the following:

• In Name, enter your name.

• In Telephone number, enter a number where you can be reached.

• In E-mail address, enter your e-mail address.

• In Notes, enter any other information you want to include.

Press [Done].

To see Owner Information and more settings, press More....

C H 2

EXPLORE FILES AND FOLDERS

File Explorer lets you browse the contents of folders on your phone. The root folder on the phone is named My Device. My Device is similar to My Computer on a PC and contains the My Documents, Program Files, Temp, Storage Card, and Windows folders among others.

On the Home screen, press [Start], then select Applications and then select File Explorer or

select My Stuff. The My Documents folder and its subfolders are listed.

To find the folder you want, do the following.

•

Select one of the folders listed in the main window.

• Press [Menu], and navigate through the folders listed there.

•

Select the item you want to open.

SILENCE THE RING TONE OF AN INCOMING CALL

Press Volume down button until the ring is silenced. You may still answer the call if you want to.

BASIC FUNCTIONS

C H 2

Emergency calls do not depend on the availability of the 911 (or 112) network in your area. The emergency number will work independently of the network area you are in, with or without a SIM card inserted.

Dial 911 (or 112) and press OK.

You can make calls to emergency service numbers under any circumstances, even if you have locked the phone.

MAKING AN EMERGENCY CALL

TIP

C H 2

ENTERING TEXT AND NUMBERS

You can enter text, numbers and symbols by using the keypad. The phone supports four input modes for entering text, numbers and symbols: Multipress,

XT9, Numeric and symbols. Multipress and XT9 modes are used for entering text, Numeric mode is used for entering numbers, and Symbols mode is used for entering symbols like “@”, “/”, “$” and punctuation marks.

When you select a field that requires text or numbers, the phone automatically selects the appropriate input mode. The status indicator on the top right side of the display screen shows the input mode that you are currently using.

CHANGE BETWEEN UPPERCASE, LOWERCASE, AND CAPS LOCK

Press the * key to change between uppercase, lowercase, and caps lock within a text input mode.

In both Multipress and XT9 modes, the first letter of a sentence is automatically capitalized.

CHANGE THE MULTIPRESS TIMEOUT

The Multipress timeout setting controls the amount of time you have to press a single key to get to the next letter on that key. If the time expires, the phone moves the cursor to the next letter in a word or sentence.

On the Home screen, press [Start].

Select Settings, then press More... to select Accessibility.

In Multipress timeout, select the length of the pause between key presses using left and right Navigation Keys.

C H 2

DELETE CHARACTERS

You can only delete characters when you are in input mode, either for numbers, names, or text. The Clear key operates similarly to a “backspace” key on a computer.

To backspace and delete a single character in any input mode, press

Clear C key.

To backspace and delete an entire text or numeric field in any input mode, press and hold the Clear C key.

ENTER A SPACE

Either with Multipress or XT9 mode, press the # key.

ENTER A SYMBOL

There may be times when you need to use a symbol that is not displayed on the keypad. Additional symbols are available by accessing a separate page.

Press and hold the * key.

In the menu that appears, press Symbols to display the Symbols page.

Select the symbol you want.

Press OK.

ENTERING TEXT AND NUMBERS

TIP

C H 2

ENTER NUMBERS IN TEXT BOXES

To enter numbers, use Numeric mode. If you need to enter a number within a line of text, change to Numeric mode to enter the number, and then change back to Multipress or

XT9 mode to finish entering the text.

Change to Numeric mode by pressing and holding the * key.

Enter the number or numbers using the keypad.

Change back to Multipress or XT9 input mode by briefly pressing the

* key, then finish entering

your text.

If a field permits a numeric entry only, such as a phone number, the input mode automatically defaults to Numeric mode.

ENTER PUNCTUATION IN MULTIPRESS MODE

Press 1 until you see the punctuation mark.

To see all of the available symbols, press and hold the

# key.

ENTER PUNCTUATION IN XT9 MODE

In a text box when in XT9 text entry mode, do the following:

Press 1, and select from a list of common punctuation.

ENTERING TEXT AND NUMBERS

C H 2

ENTER TEXT IN XT9 MODE

To form a word in XT9 mode, press the number keys that contain the letters you want. As you enter letters, XT9 analyzes your key presses and attempts to complete the word. For example, to enter the word shoe, press

7, 4, 6, 3.

Press and hold the * key.

On the popup menu, select

XT9 and press OK

key.

The XT9 indicator appears at the top of the screen.

Enter letters by pressing the keys on which the letters appear. Press a key only once for each letter. If there is more than one choice in the

XT9 dictionary for your entry, a list of available words is displayed.

Press the # key to enter a space after the word

is entered, or press one of the available

words and the space is added automatically.

If you do not see the desired word, press Add Word? from the list, and then enter the word

using Multipress.

ENTERING TEXT AND NUMBERS

C H 2

START A NEW LINE

When you are entering information in a text box, if you want to add a line break, use the OK key.

In a multi-line text box such as the Notes area of a contact or a calendar appointment, do the following:

In any input mode, press

OK key.

TURN ON CAPS LOCK

You can toggle back and forth between having the cap lock on and off, the status indicator will tell you which mode you are in.

In Multipress or XT9 mode, press the * key until the status indicator for the text input mode appears in all capitals.

Press the * key to cycle back to lowercase.

ENTER THE PLUS SIGN FOR INTERNATIONAL CALLS

Before dialing an international call you must insert the plus sign in the number. The “

0” functions as the plus sign.

In a numeric entry field, press and hold

ENTERING TEXT AND NUMBERS

C H 2

CHANGE THE INPUT MODE

There are several input modes available on your phone depending on whether you are entering contact information, phone numbers, symbols or text. Be sure you are in the input mode you desire.

In text input mode, press and hold the

* key.

A popup menu appears; select

the input mode

you want and press

OK.

The status indicator for the selected input mode appears at the top right of the screen.

ENTERING TEXT AND NUMBERS

C H 2

USING QWERTY KEYBOARD

Your phone, with a specifically designed QWERTY keyboard, that provides a superior typing experience on a small handheld for easy and comfortable text writing. You can use all of the phone functions with the keyboard either closed or open. When you open the keyboard you have the extra benefit of a full messaging keyboard. The handheld includes a fully-functional QWERTY keyboard you can use to compose text for

mail messages, notes, and so on.

KEY FUNCTION

Left soft key

Press to access the main menu or the Menu functions displayed on the left at the bottom.

Right soft key

Press to access Contacts or Menu function displayed on the right at the bottom.

Shift

To type upper-case letters, hold down the Shift key and then press one or more letter keys.

To type upper-case letters continuously, use the CAPS-LOCK mode. To change to the CAPS-LOCK mode, double-tap the Shift key. Once the CAPSLOCK mode is set, you can type

upper-case letters

only. To deactivate, double-tap the Shift key again.

To type an upper-case letter for the first letter of a word only, simply press the Shift key once. Then, the first letter you type will be

upper case while the rest

will be lower-case.

C H 2

KEY FUNCTION

To type a special character or numbers, press the applicable key while holding down the FN key.

To type special characters or numbers consecutively, use the FN-LOCK mode. To change to the FN-LOCK mode, double-tap the FN key. You can type special characters or numbers only in this mode. To deactivate, double-tap the FN key again.

To type a special character or number for the first letter of a word only, simply press the FN key once. Then, the first letter you type will be a special character or number while the rest will be normal letters.

To type a special character that is not placed on the keyboard, press FN + Space.

Space key

Press the Space key to type a blank space.

Enter key

Press the Enter key to insert a

line break.

Del key

Press the Delete key to delete a character to the left of the text cursor.

USING QWERTY KEYBOARD

C H 2

MEMO

C H 3

CALENDAR, CONTACTS,

CALL HISTORY

& MY STUFF

Chapter 3

This chapter discusses using calendar and contacts menu on your phone.

 CALENDAR

 CONTACTS

 CALL HISTORY



MY STUFF

C H 3

CALENDAR

SCHEDULE AN APPOINTMENT

Your calendar allows you to schedule appointments and reminders by day, by time, or by event.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Press [Menu] and select New Appointment.

Enter information about the appointment.

To schedule an all-day event, under

End time,

select All day event.

Press [Done].

All-day events do not occupy blocks of time in the Calendar; instead, they appear in banners at the top of the calendar.

See also ‘Change the remainder time’.

TIP

C H 3

DELETE AN APPOINTMENT

To delete an existing appointment, you will have the option of deleting just one appointment or the entire series if it is a recurring appointment.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

In Agenda view, select the appointment to delete.

Press [Menu], then Delete Appointment.

Press One to delete only the current appointment.

When you delete an appointment in Calendar on your phone, it is also deleted on your PC the next time you synchronize. If the appointment has not been synchronized with a PC, it will be deleted only from the phone. Calendar items can be deleted only from Agenda view or from an open calendar appointment. To delete from other views, open the appointment, and Press [Menu] [Delete].

To cancel a deletion, press

Cancel key.

CALENDAR

C H 3

UPDATE AN APPOINTMENT

When your schedule or appointment information changes, you can easily edit the appointment with new information.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Select the appointment and press OK key and press right soft key

> [Menu] and select Edit

and press OK key.

Press All to edit the series.

Make your changes and press

[Done].

VIEW AN APPOINTMENT

Your appointments should be easily viewable from the main calendar menu. The Calendar menu is accessible with the Start soft key from the Home screen.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Select the appointment to view and press OK.

CALENDAR

TIP

C H 3

CALENDAR

VIEW APPOINTMENTS FOR THE WEEK

Each week’s appointments are clearly displayed in the calendar, when you’ve selected Week view.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Press [Menu] and select Week View.

See also ‘Change the display of the workweek’.

VIEW TODAY’S AGENDA

For a single day’s schedule, select that day from one of the views in the calendar and select Agenda view.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Press [Menu] select Go to Today and press OK.

From Week or Month view in

Calendar, press

soft key [Menu]

and select Agenda View.

To view previous or approaching dates, scroll left or right, or press [Menu] [Go to Date]. To quickly view today’s agenda,

on the Home screen, press an

upcoming appointment (if one is present).

C H 3

VIEW YOUR AGENDA FOR A SPECIFIC DATE

You can also select a specific date to check that day’s schedule.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Press [Menu] select Go to Date and press OK.

Enter the date to view, and press

[Done].

VIEW YOUR SCHEDULE FOR THE MONTH

The calendar function has week views and month views, for a higher level view of a schedule.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Press [Menu] select Month View and press OK.

CALENDAR

C H 3

CALENDAR

MAKE AN APPOINTMENT RECURRING

If you’ve already entered a single appointment in your calendar and would like to change it to a recurring appointment, use the Occurs selection after selecting the appointment.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Select an appointment and press soft key

[Menu]

[Edit].

Scroll to Occurs and use left/right navigation key to select one of the recurrence options.

Press [Done].

C H 3

SHOW WEEK NUMBERS

In many cases the weeks of the year are referred to by number – the calendar function allows you the option of displaying the number of the week, between 1 and 52.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Press the right soft key [Menu]

and select

Tools

, and press OK key or right navigation key,

it shows options menu, then press

OK key.

Scroll to Month view and click OK.

Select Show week numbers.

Press [Done].

In Week view, the week number appears at the top of the screen. In Month view, the week numbers appear along the left side of the screen.

CALENDAR

C H 3

CALENDAR

CHANGE THE WORK WEEK DISPLAY

Depending on your schedule, you may want to change the default work week displayed. You can choose any day of the week to start and/or finish.

From the Home screen, press the left soft key

< [Start].

Select Calendar and press OK.

Press the right soft key [Menu]

and select Tools,

press OK key or right navigation key, and press

Options.

Do one of the following:

• To specify the first day of the week, in First day of week, press Sunday or Monday.

• To specify the number of days you want to appear in a week, in Week view

, press 5-day week, 6-day week, or

7-day week

Press [Done].

C H 3

CHANGE THE REMINDER TIME

By default, the reminder time is set 15 minutes prior to an appointment.

In Calendar, press the right soft key [Menu]

and select Tools, press OK key or right navigation key, and press

Options.

Scroll to Set reminders and press OK.

Change the time.

Press [Done].

CALENDAR

TIP

C H 3

CONTACTS

Using the Contacts feature of your Pantech duo™, you can manage all the phone information you need. There are many options for adding contacts, retrieving contacts, and managing the information for each contact.

CREATE A NEW CONTACT

To enter a new contact manually, without having the caller on the phone, you will use the Contacts selection from the

Home screen.

On the Home screen, press [Start].

Select Contacts using the Navigation key and press OK.

Press the left soft key

< [New].

Enter information for the new contact.

Press [Done].

If someone who isn’t in your list of contacts calls you or sends you a message, you can create a contact from Call History or from the message by pressing [Menu] [Save to Contacts]

C H 3

CONTACTS

BEAM A CONTACT

It is possible to use your phone to send a contact to another device such as Bluetooth radio. This is called “beaming” your contact. A list of devices will appear when you’ve selected Beam.

On the Home screen, press the left soft key <

[Start]

Select Contacts.

Select the contact to beam.

Press the right soft key

> [Menu].

Select Send Contact then select Beam and press OK.

On the list that appears, scroll to the name of the device you want to beam the contact.

To beam using

Bluetooth, ensure that both Bluetooth radios are turned on and that Bluetooth is discoverable on the receiving device.

Press Beam.

Status information displays, indicating the name of the device to which the phone is beaming, and whether the beaming process is pending, finished, or was unsuccessful.

C H 3

CONTACTS

If you want to receive a contact by beam, you have to follow these steps.

On the Home screen, press left soft key <

[Start]

Select Settings and press OK.

Select Connections and press OK.

Select Beam and press OK.

Check

Receive incoming beams.

More information about Bluetooth, see Chapter 12. Bluetooth section.

CALL A CONTACT FROM CONTACT INFORMATION

You can call a contact directly by selecting them from the Contacts page off the Home screen.

On the Home screen, press the left soft key < [Start] and then jump to 3 or directly press right soft key

[Contacts].

Select the contact to call and press OK.

Scroll to the phone number to dial.

Press OK or SEND.

TIP

C H 3

CALL A CONTACT FROM THE CONTACT LIST

If you do not select one of the contacts phone numbers, but you press

Send, your phone will dial the default number for that contact.

On the Home screen, press the left soft key <

[Start]

and then jump to 3 or directly press

right soft key

[Contacts].

Select the contact to call.

Press SEND. The contact’s default phone number is dialed.

To call a phone number other than the default, press the contact, press OK and scroll to the number you want to dial, then press SEND.

CHANGE THE DEFAULT NUMBER FOR A CONTACT

The default number for the contact will be the first number displayed. If you need to change the default number, you will use the Navigation key to set the default.

On the Home screen, press the left soft key <

[Start]

Select Contacts and press OK.

Select the contact whose default number you want to change.

CONTACTS

C H 3

CONTACTS

Press the Navigation Key left or right

to select the number or other contact method that you want to set as the default. For example, (m)obile, (h)ome or (w)ork.

DUPLICATE A CONTACT

This feature allows you to copy contacts in Device or SIM to the same area. (Device

➞ Device, SIM ➞ SIM)

On the Home screen, press the left soft key

[Start]

Select Contacts and press OK.

Scroll to the contact to duplicate.

Press the right soft key

> [Menu].

Select Duplicate Contact from the popup menu and press OK.

COPY TO DEVICE / SIM

This feature allows you to copy selected contacts in Device or SIM to other areas. (Device

➞ SIM, SIM ➞ Device)

On the Home screen, press the left soft key

[Start].

Select Contacts and press OK.

Scroll to the contact to copy.

C H 3

Press the right soft key

> [Menu].

When selecting SIM Contact, select Copy to Device from the popup menu and press

OK.

When selecting Device Contact, s

elect Copy to

SIM from the popup menu and press OK.

COPY ALL TO DEVICE / SIM

This feature allows you to copy all contacts in Device or SIM to other areas. (Device

➞ SIM, SIM ➞ Device)

On the Home screen, press the left soft key

[Start].

Select Contacts and press OK.

Press the right soft key

> [Menu].

When selecting SIM Contact, select Copy All to Device from the popup menu and press

OK.

When selecting Device Contact, s

elect Copy All

to SIM from the popup menu and press OK.

CONTACTS

C H 3

DELETE A CONTACT

Deleting a contact is very simple, just use the Menu key once you have selected the contact.

On the Home screen, press the left soft key <

[Start]

Select Contacts and press OK.

Scroll to the contact to delete.

Press the right soft key > [Menu].

Select Delete Contact from the popup menu and press OK.

DELETE ALL DEVICE / SIM

This feature allows you to delete all contacts in Device or SIM.

On the Home screen, press the left soft key

[Start]

Select Contacts and press OK.

Press the right soft key

> [Menu].

When selecting SIM Contact, select Delete All SIM from the popup menu and press OK.

When selecting Device Contact, select Delete

All Device from the popup menu and press

OK.

CONTACTS

C H 3

CONTACTS

CREATE A CONTACT FOR A CALLER

Creating a contact for a caller makes their information easier to retrieve when the call is done. The contact can be added to the Contact list during the call.

During a call, press the right soft key

[Menu]

Select Save to Contacts and press OK.

Select <New Contact>.

Enter information about the contact.

Press [Done]. The contact is added to your Contact list.

FILTER THE CONTACT LIST

Contacts that have categories assigned are displayed in a list when filtered by category.

On the Home screen, press the left soft key

< [Start].

Select Contacts and press OK.

Press the right soft key

> [Menu].

Select Filter from the popup menu and press OK.

Select a category to filter.

C H 3

CONTACTS

FIND A CONTACT

The contact section of your phone has an auto-fill feature that will allow you to find contacts more quickly. While entering the number or name of the contact, the phone will auto-fill the rest of the information as you press the keys, until you find the right contact.

On the Home screen, press the left soft key

< [Start].

Select Contacts and press OK.

Begin entering the name or phone number of the contact you want to find until the contact is displayed. For example, to find “Sandra,”

2, 6, 3, 7, 2 because these

numbers correspond to the letters for that name.

SEND AN E-MAIL TO A CONTACT

If a contact’s e-mail address is entered into their information, you can send an e-mail from within the contact list after selecting the contact.

On the Home screen, press the left soft key

< [Start].

Select Contacts and press OK.

Select a contact and press OK.

Scroll to the e-mail address and press OK.

Select the e-mail account to use.

Enter a subject, compose your message, and then press Send.

C H 3

SEND A TEXT MESSAGE TO A CONTACT

You can send text message from within the contact list after selecting the contact and pressing the Menu key.

From the Home screen, press the left soft key

< [Start].

Select Contacts and press OK.

Select a contact, and press OK.

Press the right soft key

> [Menu] and select

Send Text Message.

Compose your message, and press the left soft key

< [Send].

VIEW AND EDIT CONTACT INFORMATION

You may want to change or update contact information once it has already been entered. Do this from the Contacts menu of the Home screen.

On the Home screen, press the left soft key

< [Start].

Select Contacts and press OK.

Select a contact, and press OK.

Press the right soft key

> [Menu], select

[Edit] and press OK.

When finished making changes, press

[Done].

CONTACTS

C H 3

ADD A PICTURE TO A CONTACT

You may wish to add a picture to a contact record. You can add an existing picture, or you can put the phone in Camera mode to take the picture and add it to the contact.

On the Home screen, press the left soft key <

[Start]

Select Contacts and press OK.

Select a contact, and press OK.

Press the right soft key

> [Menu], select

[Edit] and press OK.

Using the Navigation Key, scroll down to Picture.

Do one of the following:

• Select the picture you want to add.

• Press

Camera and take a picture.

CONTACTS

C H 3

CONTACTS

REMOVE A PICTURE FROM A CONTACT

Once a picture is attached to a contact, it can easily be removed or changed from the Contacts menu by using the soft key

and editing the

field.

On the Home screen, press the left soft key

< [Start].

Select Contacts and press OK.

Select a contact, and press OK.

Press the right soft key

> [Menu], select

[Edit] and press OK.

Press Remove Picture.

C H 3

CONTACTS

ASSIGN A CATEGORY TO A CONTACT

It may be helpful to group your contacts in categories you define for easier reference. If you know the contact’s category you can easily retrieve the contact.

You can use categories to help you organize and group your contacts.

On the Home screen, press the left soft key

< [Start].

Select a Contact, and press OK.

Select a contact, and press OK.

Press the right soft key

> [Menu], select

[Edit] and press OK.

Using the Navigation Key, scroll down to Categories.

Use the left and right Navigation Keys to select the category you want.

Press [Done].

Categories are shared between your contacts and tasks. A category will remain in the list of shared categories as long as it is assigned to at least one contact or task.

C H 3

ASSIGN A RING TONE TO A CONTACT

To easily identify who is calling you by the ring tone, you can assign a custom ring tone to each contact.

On the Home screen, press the left soft key

< [Start].

Select Contacts and press OK.

Select a contact, and press OK.

Press the right soft key

> [Menu], select

[Edit] and press OK.

Using the Navigation Key, scroll down to

Custom ring tone.

Select the ring tone you want.

Press [Done].

CREATE A SPEED DIAL

You can create a speed dial for a phone number, e-mail address, or Web page address that is stored in Contacts.

On the Home screen, press the left soft key

< [Start].

Select Contacts and press OK.

Select the contact for whom to create a speed dial and press OK.

CONTACTS

C H 3

CONTACTS

Select the phone number, e-mail address, or Web page address for which to create a speed dial.

Press [Menu] and select Add to Speed Dial, then press OK.

In Keypad assignment, select the speed dial number to use.

Press [Done].

The number 1 is reserved for calling your voicemailbox.

USING SPEED DIALS

Set up speed dial codes to allow you to call contacts by pressing only one (or two) buttons from the Home screen.

On the Home screen, press and hold the number on the keypad that you have assigned as a speed dial for the phone number, e-mail address, or Web page.

If the speed dial is two digits, press the first digit, and press and hold the second digit.

The phone dials the phone number, opens a new e-mail message, or goes to the Web page.

C H 3

VIEW AND EDIT A SPEED DIAL

You can view or edit all the contacts you’ve assigned to speed dial by entering the Speed Dial menu from the Start soft key.

On the Home screen, press the left soft key

< [Start].

Select [Applications] [Speed Dial] and press OK.

Select a contact you want to change and press

OK key.

Make any changes and press

[Done].

DELETE A SPEED DIAL

Deleting a Speed Dial can be done at any time by following these instructions.

On the Home screen, press the left soft key

< [Start].

Select [Applications] [Speed Dial] and press OK.

Select the speed dial to delete.

Press [Menu] and select Delete from the popup menu.

CONTACTS

TIP

C H 3

Call history provides details of all calls received, missed and dialed.

From the Home screen, press the left soft key

< [Start].

Select Call History and OK.

To view only missed calls, incoming calls, or outgoing calls, press [Menu] select Filter, and then press the type of calls to view.

Once you have accessed Call History from the main menu, the icon appears on the top of the Home screen Shortcut bar. Select the icon and press OK to go directly to Call History.

VIEW CALL TIMERS

You can time each call that is received or made, and the time and length of each call can be reviewed.

From the Home screen, press the left soft key

< [Start].

Select Call History and press OK.

Press [Menu] and select View Timers from the popup menu.

CALL HISTORY

C H 3

RESET CALL TIMERS

When call information is no longer required, the call timers can be set to zero.

From the Home screen, press the left soft key

< [Start].

Select Call History and press OK.

Press [Menu] and select View Timers from the popup menu and press

OK.

Press [Menu] and select Reset Timers and press OK.

Press Yes. All of the call timers are set to zero (0), except for the Lifetime calls timer.

VIEW DETAILS ABOUT A CALL

To review all the stored information on a call you will access the Call History function.

From the Home screen, press the left soft key

< [Start].

Select Call History and press OK.

Select the call you want to view details for and press OK.

CALL HISTORY

TIP

C H 3

CREATE A CONTACT FROM CALL HISTORY

While you are in the Call History function, you can select any of the calls and automatically add that caller to your contact list.

From the Home screen, press the left soft key

< [Start].

Select Call History and press OK.

Select the phone number for which to create a contact and press [Menu] and scroll to Save to

Contacts in the popup menu and press OK.

Select <New Contact> and press OK.

Enter the remainder of the contact information and press [Done]. The new contact appears in your contact list.

DELETE AN ITEM FROM CALL HISTORY

Any entry in the Call History can be deleted by selecting an entry and then by accessing the menu.

From the Home screen, press the left soft key

< [Start].

Select Call History and press OK.

Select the item to delete.

Press the right soft key

> [Menu], then select

Delete from the popup menu.

To delete all items in Call History, press [Start] [Call History] [Menu]

[Delete List].

CALL HISTORY

C H 3

CALL HISTORY

DIAL THE LAST NUMBER CALLED

If you need to quickly call the last number you have called, this shortcut allows you to do so without using menus.

On the Home screen, press SEND twice.

FIND A CONTACT FROM CALL HISTORY

There is an option in the Call History for finding contacts from your contact list. The

auto-fill feature will help.

From the Home screen, press the left soft key

< [Start].

Select Call History and press OK.

Press [Menu], then select Find Contact from the popup menu.

INSERT AN INTERNATIONAL COUNTRY CODE

To make an international call you must include a country code at the beginning of the dialing sequence for the phone number.

Press and hold 0 until a plus (+) sign appears, enter the country code, and then enter the rest of the phone number.

You can insert a plus (+) sign into a contact’s phone number or dial it directly from the keypad.

C H 3

CALL HISTORY

SEND AN E-MAIL MESSAGE FROM CALL HISTORY

To use this function, the E-mail address of the person you are sending an E-mail to must be included in their contact information card.

From the Home screen, press the left soft key

< [Start].

Select Call History and press OK.

Select the contact you want to send an E-mail message to and press [Menu].

Scroll to E-mail and press OK.

Select an E-mail account.

Compose the message and press Send.

C H 3

The My Stuff displays My Pictures, My Ringtones, My Videos, Notes, and Templates.

My Stuff’s menu is same as File Explorer.

MY STUFF

C H 4

VOICEMAIL &

MESSAGING

Chapter 4

This chapter addresses Voicemail, Text, Multimedia Message, Video and E-mail Messaging functions including:

 VOICEMAIL

 TEXT MESSAGING



MULTIMEDIA MESSAGING



E-MAIL

C H 4

Voicemail is available at all times. When you call your voicemail the messages will be played back in the order they were received. You will have options to save, delete, replay, or skip each message.

CALL YOUR VOICEMAILBOX

Retrieving your voicemail is simple and can be accessed directly from the Home screen.

On the Home screen, press and hold 1 to call your voicemailbox.

Follow the instructions to retrieve it.

VOICEMAIL

C H 4

TIP

TEXT MESSAGING

You can create a text message, delete a text message, or clear all text messages. Contacts from the contact list can be used to send messages just as they can be used to make calls.

CREATE A TEXT MESSAGE

The Pantech duo™ allows you to create text messages quickly. You create a text message by typing in a phone number or by selecting a contact first.

On the Home screen, press the left soft key <

[Start]

select Messaging and press OK.

Select Message and press OK.

Press the right soft key [Menu] [New] [Text Message].

In “To”, enter text message recipient’s phone numbers. Insert a semicolon (;) between multiple text message recipient’s phone numbers.

Press Down navigation key, and compose message you want to send.

Press [Send]. Text messages are sent immediately.

You can quickly enter text message numbers from your contact cards. In To, press [Menu]

and select ‘Add Recipient’ from the list. Then, select the recipient’s phone number. To cancel a message, Press [Menu] [Cancel Message].

C H 4

DELETE ALL MESSAGES

To clear all messages in a folder, you will need to show all the folders and select the folder you want.

On the Home screen, press the left soft key

< [Start] select Messaging and press OK.

Select Messages and press OK.

Press [Menu], then select Folders.

Press [Menu] then select Show all Folders.

Select the folder with the messages you want to delete.

Press [Menu] [Clear Messages].

TEXT MESSAGING

C H 4

MULTIMEDIA MESSAGE

Multimedia Messaging Service allows you to send multimedia messages to others, which can include text, graphics and ring tones in a message.

CREATE A MULTIMEDIA MESSAGE

Creating a Multimedia message is simple and you can add images or attachments to the message.

On the Home screen, press the left soft key <

[Start]

, select Messaging and press OK.

Select Message, press OK, then press [Menu] [New] [Multimedia Message]

Enter an e-mail address or phone number.

Input a subject of this Multimedia message.

Input text message in text box.

To add an image, press [Menu]

[Add Item] and

press OK, then select Image.

Select an image from Picture file browser and the image is added to the Multimedia message.

Press the left soft key [Send] to send message.

TIP

C H 4

MULTIMEDIA MESSAGE

If Multimedia message was sent successfully, a ‘Message sent successfully’ dialog will appear.

You can quickly enter Multimedia message numbers from your contact cards. In To, press [Menu] and select ‘

Add recipient’ from the list. Then, select the recipient’s phone number. To cancel

a Multimedia message, just press [Menu]

[Cancel Composer].

TEXT BOX

Enter the text that you wish to send. English and Spanish languages are supported.

MULTIMEDIA MESSAGE MENU OPTIONS

The Menu supports advanced MMS composer option.

Menu option Description

Preview

Press [Menu] [Preview].

Preview is displayed when Multimedia message has content (image, sound, text or video).

Preview is not displayed when message is empty.

Add Recipient

You can add recipients in various ways to select the recipient address from Contact list or Photo Album

Press [Menu] [Add Recipient] to select the recipient address from Contact list or Photo Album.

Press [Menu] [Add Recipient] [Contacts]: add a contact from Contact list.

Press [Menu] [Add Recipient] [Multi Contacts]: add multiple contacts from Contact list at once.

Press [Menu] [Add Recipient] [Photo Album]: add Photo Album.

Press [Menu] [Add Recipient] [Bcc]: show Bcc field to add recipients in Bcc field.

Press [Menu] [Add Recipient] [Cc]: show Cc field to add recipients in Cc field.

C H 4

MULTIMEDIA MESSAGE

Menu option Description

Check Name

Press [Munu] [Check Name], convert phone number to corresponding name, if that number

registered in contact list.

Add Item

You can add content such as text, image, sound, video, vCard, vCalendar, and Attachments.

Press [Menu] [Add Item] [Text]: enter a text message in the text box.

Press [Menu] [Add Item] [Image]: select image file from My Pictures.

Press [Menu] [Add Item] [Sound]: select sound file from My Documents.

Press [Menu] [Add Item] [Video]: select video file from My Videos.

Press [Menu] [Add Item] [vCard]: select a vCard.

Press [Menu] [Add Item] [vCalendar]: select a vCalendar.

Press [Menu] [Add Item] [Attachments]: select any file from all of memory.

Create Item

You can add a picture, video or sound from Camera and Voice

Note.

Press [Menu] [Create Item] [Picture]: Take a picture with Camera and add it to Multimedia message.

Press [Menu] [Create Item] [Video]: Record a video with Camcorder and add it to Multimedia message.

Press [Menu] [Create Item] [Sound]: Record a Voice

Note and add to Multimedia message.

Template

You can add current components as a template, or replace with previous saved templates.

Press [Menu] [Template] [Add Template]: Replace current components with previous saved components.

Press [Menu] [Template] [Save as template]: Save current components as a new template.

Remove Item

You can remove content such as image, sound, text and video. Press [Menu] [Remove Item].

C H 4

Menu option Description

My Text

Press [Menu] [My Text]. You can add predefined text messages to text field.

Priority Level

You can set the importance of Multimedia Message.

Press [Menu] [Priority Level] [High]: set Multimedia Message to be important.

Press [Menu] [Priority Level] [Normal]: set Multimedia Message to be normal.

Press [Menu] [Priority Level] [Low]: set Multimedia Message to be low.

Page Layout

You can set the layout of Multimedia Message in preview.

Press [Menu] [Page Layout] [Image Top]: place image on top and text to below in preview.

Press [Menu] [Page Layout] [Text Top]: place text to top and image to below in preview.

Options

You can set the importance of Multimedia Message.

Press [Menu] [Options] [Insert Page]: insert a new page at current page.

Press [Menu] [Options] [Delete Page]: delete current page.

Press [Menu] [Options] [Move Page]: change the order of current page.

Press [Menu] [Options] [Duration]: set durations between pages.

Press [Menu] [Options] [Multimedia Msg. Options]: set properties of Multimedia Message such as profile, default edit mode

, etc.

Press [Menu] [Options] [Per Msg. Setting]: set properties of per message such as delivery report, read report

, etc.

Press [Menu] [Options] [ About]: show information about Multimedia Message

client.

Save

Press [Menu] [Save]: Save Multimedia Message in draft folder. Back to Inbox.

Cancel Composer

Press [Menu] [Cancel Composer]:Cancel Multimedia Message Back to Inbox.

MULTIMEDIA MESSAGE

C H 4

VIEW MULTIMEDIA MESSAGE

To view Multimedia Message, simply select Multimedia Message from the Messaging menu and you will see a list of Inbox messages.

On the Home screen, press the left soft key <

[Start]

, select Messaging and press OK.

Select Multimedia Message which you want to see for list of Inbox messages.

Press OK to play selected message.

SELECT MULTIMEDIA MESSAGE IN THE LIST OF MESSAGE TYPE

After selecting Multimedia Message from the Messaging menu, you will use the Menu button to step through each field that is available when composing a message.

On the Home screen, press the left soft key <

[Start]

, select Messaging and press OK.

Press [Menu] [Reply] to send a reply Multimedia Message to new receiver and

“CC”, “BCC”.

Press [Menu] [Reply all] to send a reply Multimedia Message to all senders.

Open Multimedia Message editor and display “To” field with “RE”: all sender addresses including “CC”, “BCC” sender.

Press [Menu] [Forward] to forward Multimedia Message, Open Multimedia Message editor.

MULTIMEDIA MESSAGE

C H 4

MULTIMEDIA MESSAGE

Press [Menu] [Save] Save to save address to phonebook.

Press [Menu] [Details] to show detailed information about current Multimedia Message, such as message size, sender.

Press [Menu] [Delete] to delete current message in the inbox list.

Press [Menu] [Back] to terminate Multimedia Message viewer and go back to the Inbox message list.

CHANGE MESSAGING ACCOUNT OPTIONS

Multimedia Message, E-mail and text messages can be displayed differently and you can select from many options for each.

On the Home screen, press the left soft key <

[Start]

, select Messaging and press OK.

Select Messages or E-mail account and press

OK.

Press [Menu] [Tools] [Options].

Select the type of options to change.

Press [Done].

TIP

C H 4

MULTIMEDIA MESSAGE

CHANGE HOW THE MESSAGE LIST DISPLAYS

You can change the order in which messages are displayed and show the date and time that messages were received.

On the Home screen, press the left soft key <

[Start]

, select Messaging and press OK.

Press [Menu] [Tools] [Options] [Display].

Change the display options and press

[Done].

CREATE A MESSAGE FROM A CONTACT CARD

Just as you can make phone calls from a contact card, you can select a contact and send a message from the contact card.

On the Home screen, press [Start], select Contacts and press OK.

Select a contact.

Select the messaging address or phone number to use.

Select the account to use and press OK.

Use left soft key that displays corresponding action, or press right soft key [Menu]

and select

the message you want to use. Ex) ‘Send Text

Message’ ‘Send Multimedia Msg.’

A new message opens ready for you to complete and send.

To cancel a message, press [Menu] [Cancel Composer].

C H 4

E-MAIL

The Pantech duo™ allows you to send e-mails with several options. You can copy, blind copy, set priority, and store

e-mails just as you would from a computer. The Pantech duo™ uses Outlook as the default mail program.

You can send and receive e-mail messages in one of these ways:

• Synchronize e-mail messages with Microsoft Exchange or Microsoft

Outlook on your PC.

• Send and receive e-mail messages by connecting directly to an e-mail

server through an Internet Service Provider (ISP) or a network.

SYNCHRONIZING E-MAIL MESSAGES

Use the Outlook E-mail account to send and receive e-mail messages by synchronizing e-mail messages with Microsoft Exchange or Microsoft Outlook on your PC. E-mail messages can be synchronized as part of the general synchronization process. You will need to enable Inbox synchronization in ActiveSync.

DURING SYNCHRONIZATION:

• Messages are copied from the mail folders of Exchange or Outlook on

your PC to the

Outlook E-mail folders on your phone.

• E-mail messages in

Outlook E-mail on your phone are transferred to

Exchange or Outlook, and then sent from those programs.

CONNECTING DIRECTLY TO AN E-MAIL SERVER

You can send and receive e-mail messages by connecting to an e-mail server. You’ll need to set up a remote connection to a network or an ISP, and a connection to your e-mail server. When you connect to the e-mail server, new messages are downloaded to the phone’s Inbox folder. Also messages in the phone’s Outbox folder are sent, and messages that have been deleted on the e-mail server are removed from the phone’s message folders.

C H 4

FOLDER BEHAVIOR WITH A DIRECT CONNECTION TO AN E-MAIL SERVER

The behavior of the folders you create depends on whether you are using POP3 or IMAP4.

• If you use POP3 and you move e-mail messages to a folder you

created, the link is broken between the messages on the phone and their copies on the mail server. The next time you connect, the mail server will see that the messages are missing from the phone and delete them. This prevents you from having duplicate copies of a message, but it also means that you will no longer have access to messages that you move to folders created from anywhere except the phone.

• If you use IMAP4, the folders you created and the e-mail messages

you moved are mirrored on the server. Therefore, messages are available to you anytime you connect to your mail server. This synchronization of folders occurs whenever you connect to your mail server, create new folders or rename/delete folders when connected.

CREATING AN E-MAIL ACCOUNT

You need to create a new account to be used for retrieving and sending e-mail messages.

TO MAKE A NEW ACCOUNT:

From the main Messaging

screen, select New

E-mail Account.

Enter your E-mail address. If you want to set up your

account automatically from the Internet,

select Try to get e-mail settings automatically

from the Internet. And press Next soft key.

If it couldn’t find setting, press the Next soft key.

_________________________________

E-MAIL

C H 4

Select your e-mail provider, one

or both of

Internet e-mail or Exchange server.

Enter your display name and press the Next

soft

key.

Enter your Incoming mail server

and select

Account type and press the Next soft key.

Enter your user information, such as user name, password, and press the Next soft key.

Enter the Outgoing (SMTP) mail server names and press the Next soft key.

Select how often your phone automatically connects to the server and checks for incoming e-mails.

Press the Finish soft key.

TO EDIT AN ACCOUNT:

From the main Messaging

screen, scroll to the

account you want.

Press the Menu soft key and select Settings.

Change the account settings as you would when creating it.

___________________________

E-MAIL

C H 4

TIP

E-MAIL

CREATE AN E-MAIL MESSAGE

You can create an e-mail message from a contact card, or by typing in the address.

On the Home screen, press left soft key <

[Start]

, select Messaging and press OK.

Select the e-mail account with which you want to send.

Press right soft key [Menu] [New]

In To, Cc, and/or Bcc, enter recipient’s

e-mail addresses. Insert a semicolon (; ) between the multiple addresses.

In Subject, enter a subject.

Enter a message.

Press Send. E-mail messages are stored in Outbox and are sent to recipients the next time you synchronize or connect to your e-mail server and send and receive mail.

You can quickly enter e-mail addresses from your contact cards. In To, press

ENTER and select a recipient from the list. Then, select the recipient’s e-mail address. To set the priority, press [Menu

] [Message Options].

To cancel

an E-mail message, press [Menu] [Cancel

Message]

100

C H 4

OVERVIEW OF E-MAIL SECURITY

You can help prevent impersonation, tampering, and eavesdropping when sending e-mail messages from your Outlook e-mail account by using Secure Multipurpose Internet Mail Extensions (S/MIME) digital signatures and encryption.

A signature helps prevent impersonation and tampering. Impersonation occurs when a hacker sends e-mail messages and pretends to be someone else. Tampering occurs when a hacker intercepts your e-mail messages and changes the message without the recipient’s knowledge.

Signing a message applies the sender’s certificate (and public key) to the message. This proves to the recipient that the message is from the sender and not from an imposter.

Encryption helps prevent eavesdropping, which occurs when a hacker intercepts and reads your e-mail messages. Using a cryptographic message format such as S/MIME for encryption helps improve e-mail privacy because it converts plain, readable text of the message into cipher (scrambled) text. The sender’s messaging program uses the recipient’s public key to encrypt (lock) the e-mail message and attachments. Only the recipient who has the private key

that matches the public key you used to encrypt the message can decipher (unscramble) the message.

A certificate is a digital means of proving your identity. When you send a digitally signed message, you are sending your certificate and public key. Certificates can expire or be revoked.

S/MIME encryption and digital signatures for Windows Mobilebased devices are available only with Exchange Server 2003 Service Pack 2 or a later version that supports S/MIME. If you aren’t using one of these products, or have not yet synchronized, these options are unavailable.

E-MAIL

Pantech C180 DUO User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
