Pantech C120 Cingular User Manual
3
5U010125000 REV03
MANUAL DEL USUARIO
USER MANUAL
USERS MANUAL
5U010125000 REV03
1
USER’S MANUAL
C120
Thank you for choosing the Pantech C120, our latest triband GSM mobile phone.
The C120 has many features that will enhance your mobile
experience. From its light weight and reliability, to the builtin camera, we know you will enjoy all the features the C120
has to offer.
The C120 user guide contains important information about
using your handset. Please read the manual thoroughly,
pay attention to the warranty on the back page and be alert
to the exclusions and limitations of your warranty, related to
the use of unauthorized components.
NOTE
Some information in this User Manual may differ from
your phone, depending on your software version and network
provider.
Design
Single Candy-bar
Displays
• 1.5” LCD
• Supports up to 65,536 colors within 128 x 128 pixels
• 6 lines for text in basic mode with 16-pixel font
• Two Soft keys ([[] and []]), and 5-way joystick
• List and grid menu
Melodies
Yamaha 40 poly(SMF)/16poly (SMAF) sound
Camera
VGA CMOS built-in Camera.
•Resolution up to 640 x 480 (307,200 pixels)
•Self-timer function (5 seconds or 10 seconds)
•Photo album
Dimensions & Weight
•Weight: 75 g
•Dimensions: 103 mm x 42.5 mm x 13.5 mm
Power Management (Performance)
Operating Frequency
• GSM 850, DCS 1800, and PCS 1900 networks in North
America, South America, Europe, Africa, and Asia-Pacific
where these networks are supported.
• Automatic band switching.
Phone specifications
2
Standard
Lithium-Ion
(Li-ion)
Up to
800 mAh
Up to
250 Hours
3 Hours
Battery Type Capacity Standby Time Talk Time
3
Cancel/Back/Text
Clear/Edit Exit Key
Power On/Off
DiaI key
Call Accept
Alphanumeric Key
Vibrate Mode
Joy Stick 4-way Menu
Navigation (Message
Write New, IM, Address
Book List, My Stuff)
Push in on joystick
(Menu confirm)
Volume up/down
Right Soft key(Camera)
Left Soft key(Menu)
Voicemail
View
Camera
Earpiece
Headset jack
Quick & Easy
4
[n]
o
c
s
e
1
Keys Functions
Perform the functions shown at the bottom line of the display by using these Soft keys.
In standby mode, enter the Menu using the left selection (“Soft”) key and enter the Camera preview
mode using the right selection (“Soft”) key.
Scroll through the menu options in Menu mode.
In standby mode,
Push to Left: My Stuff
Up: Message Write New
Right: IM
Down: Address Book list
In Standby mode, press to launch the MEdia Net directly.
Select a menu function or store user-input information, such as names. Also use this key for confirmation
(as the [OK] key).
Delete characters from the display, or returns to the previous menu.
If pressed briefly in Standby mode, open Calendar view.
Make or receive a call. If pressed in Standby mode, display the Recent calls list.
If pressed and held in Standby mode, redial the last number called.
End the current call. If pressed and held in Menu mode, cancel user input and return to Standby mode.
If pressed and held, in standby mode, switch your phone on/off.
If pressed and held in Standby mode, connect to the voicemail server automatically.
5
Quick & Easy
0~9
*
0
zx
Keys Functions
Enter numbers, letters or special characters. If pressed in Standby mode, display the dialing screen.
If pressed and held in Standby mode, enter or exit from Vibrate mode.
If pressed and held in Text input mode, display the Symbol input screen.
If pressed in Predictive text input mode, switch to Word search mode.
Enter an international dialing prefix(011, +).
In Text input mode, enter the space character.
Adjust the earpiece volume level which you want during a call, and move the cursor upwards or downwards in the menu mode.
Control the ringtone volume in standby mode.
k
Enter a camera menu if pressed in standby mode.
Enter a camera preview mode if pressed and held in standby mode.
Set the Auto Answer only when a headset is connected to your phone’s headset jack.
Your phone automatically answers calls after 5 seconds.
Contents
6
Getting started
Package Contents ................................................................14
SIM Card ................................................................................ 15
About your SIM card ...............................................................15
Installing/Removing your SIM card .........................................15
Battery ...................................................................................15
Inserting your battery ..............................................................15
Removing your battery ...........................................................15
Charging your battery ............................................................. 15
Display ...................................................................................17
Display ....................................................................................17
Display icons ..........................................................................17
Automatic display off ..............................................................
20
Selecting functions and options ......................................... 20
Selecting functions and options ..............................................20
Keypad Lock .........................................................................21
To lock the keypad ..................................................................
21
To unlock the keypad ..............................................................
21
Basic functions
Switching your phone on or off ..........................................24
To switch your phone on .........................................................
24
To switch your phone off .........................................................
24
Making and ending a call ..................................................... 24
To make a call .........................................................................
24
To end a call ...........................................................................
24
To make a call using Call Logs ...............................................
24
To make a call using Entry ......................................................
25
To make an International call ..................................................
25
To speed-dial from Entry .........................................................
25
To make an emergency call ....................................................
25
Answering a call ...................................................................26
To answer a call ......................................................................
26
To reply to a missed call .........................................................
26
To reject a call .........................................................................
26
To answer a second call .........................................................
26
To switch between two calls ...................................................
26
To end the current call ............................................................
26
Options during a call ............................................................27
To adjust the call volume ........................................................
27
To switch your microphone off (Mute) or on (Speak) ..............
27
•To switch your phone’s microphone off ...............................27
•To switch your phone’s microphone back on ......................27
To put a call on hold, and return to a held call ........................
27
•To put a call on hold ............................................................ 27
•To return to a held call ......................................................... 27
7
Contents
•To make a call while you are on a call ................................27
•To switch between two calls ................................................28
•To end a call ........................................................................28
Transferring a call ...................................................................
28
Multi-party calls ....................................................................... 28
•To make a multi-party call ...................................................28
•To add a new person to a multi-party call ...........................28
•To add a caller to a multi-party call .....................................29
•To view the status of multi-party call participants ................29
•To answer or make a second call duringa multi-party call ..29
•To have a private conversation with one participant ...........29
•To remove one participant from a multi-party-call ............... 29
Searching for a number in Address Book during a call ...........
30
•To search for a name or group in Address Book ................. 30
•To find a name manually in Address Book ..........................30
•To view the highlighted entry in Address Book ....................30
Using DTMF tones .................................................................. 30
Reading or writing a message during a call ............................ 30
Using your headset ..............................................................31
Selecting menu functions ....................................................31
Moving within your phone’s menu and submenu functions ....
31
Using the Shortcut Key in Standby Mode ...............................32
Entering text .......................................................................... 33
Input Mode .............................................................................. 33
ABC mode ..............................................................................33
123 mode ................................................................................ 33
Symbol mode .......................................................................... 33
T9 mode .................................................................................33
My Words ...............................................................................
33
Spell ........................................................................................ 33
To change Text input mode .....................................................
33
To insert a space ....................................................................
34
Scrolling ..................................................................................34
Clearing Letters and Words ....................................................
34
Returning to the Previous Screen ........................................... 34
Using T9 mode .......................................................................
35
Using ABC mode ....................................................................
35
Changing case ........................................................................ 36
Using 123 Mode .....................................................................36
Using Symbol Mode ...............................................................36
Using My Words .....................................................................
36
Applications
IM ............................................................................................ 40
Starting Instant Messenger ..................................................... 40
Viewing the Conversation Log ................................................
40
Messaging ............................................................................. 40
Contents
8
Text Message .........................................................................40
Multimedia Message ............................................................... 40
Receiving a new message ...................................................... 41
Managing memory ..................................................................41
Write New ...............................................................................
42
•Text Message ......................................................................42
•Multimedia Message ........................................................... 43
Inbox .......................................................................................46
Sent ........................................................................................47
Outbox .................................................................................... 48
Draft ........................................................................................48
Browser Msg ........................................................................... 49
Voicemail ................................................................................
49
Templates ...............................................................................
49
Settings ................................................................................... 50
•Common Settings ...............................................................50
•Text Message ......................................................................50
•Multimedia Message ........................................................... 51
•Voice Mail ............................................................................51
•Browser Message ...............................................................51
Memory Info ............................................................................ 52
Recent Calls .......................................................................... 53
Missed Calls ...........................................................................53
Received Calls ........................................................................ 53
Dialed Calls ............................................................................54
Delete Call Logs .....................................................................54
Call Time .................................................................................
54
GPRS Info ..............................................................................55
MEdia Net ..............................................................................55
MEdia Net Home ....................................................................55
OTA Settings Service ..............................................................
55
•WAP/OTA Provisioning .......................................................55
Bookmarks .............................................................................. 56
Go to URL ............................................................................... 56
Profiles .................................................................................... 56
Cache .....................................................................................58
•Cache Mode ........................................................................ 58
•Clear Cache ........................................................................ 58
Security Certifications .............................................................58
Version ....................................................................................
58
Cingular Mall ......................................................................... 59
Shop Tones .............................................................................
59
Shop Games ........................................................................... 59
Shop Graphics ........................................................................59
Shop Multimedia .....................................................................59
Shop Applications ...................................................................
59
9
Contents
MEdia Net Home ....................................................................59
Camera ..................................................................................60
Take a Photo ...........................................................................
60
•Taking photos ......................................................................60
Using your Camera Options ...................................................61
•The Preview mode .............................................................. 61
Photo Album ...........................................................................
62
•Viewing the saved photos ................................................... 62
•Using the Photo Options ..................................................... 62
Settings ................................................................................... 62
My Stuff .................................................................................63
DRM/Forward Lock ................................................................. 63
Games &Apps ........................................................................63
•Shop Games ....................................................................... 63
•Games ................................................................................63
Audio ......................................................................................64
•Shop Tones ......................................................................... 64
•Audio ...................................................................................64
Graphics .................................................................................64
•Shop Graphics ....................................................................64
•Graphics .............................................................................. 65
Photo Album ...........................................................................
65
•Viewing the saved photos ................................................... 65
•Using the Photo Options ..................................................... 66
Tools .......................................................................................
66
•Alarm ................................................................................... 66
Calendar ................................................................................. 67
•Monthly View ....................................................................... 67
•Daily View ...........................................................................68
•Event View &Edit ................................................................68
Memo ...................................................................................... 68
Voice Memo ............................................................................
69
World Time .............................................................................
69
Calculator ...............................................................................70
Converter ................................................................................70
Stopwatch ...............................................................................70
SIM Tool Kit ............................................................................
71
Memory Status .......................................................................71
Address Book .......................................................................71
Name Search .......................................................................... 71
Add Entry ................................................................................72
Speed Dial .............................................................................. 72
•To set Speed Dial ................................................................72
•To add to Speed Dial ........................................................... 72
•To edit Speed Dial ...............................................................73
•To remove from Speed Dial ................................................73
Contents
10
•To set Speed Dial in Name Search ..................................... 73
Groups ....................................................................................73
Memory in Use .......................................................................73
Delete All ................................................................................
74
Copy All ..................................................................................
74
My Phone Number .................................................................. 74
Memory Info ............................................................................ 74
Service Numbers .................................................................... 74
Settings .................................................................................75
Display ....................................................................................75
•Shop Graphics ....................................................................75
•Main Screen ........................................................................75
•Greeting ..............................................................................75
•Contrast ..............................................................................75
•Backlight .............................................................................75
Audio ......................................................................................76
•Shop Tones ......................................................................... 76
•Ringtone .............................................................................. 76
Volume ....................................................................................
76
•Alert Tones .......................................................................... 76
•Key Tone ............................................................................. 77
•Sound Effects ...................................................................... 77
Call .........................................................................................77
•Call Forward ........................................................................ 77
•Answer Type ....................................................................... 79
•Auto Redial .........................................................................79
•Call Waiting .........................................................................79
•Caller ID .............................................................................. 79
Phone .....................................................................................80
•Language ............................................................................ 80
•Time & Date ........................................................................ 80
•Flight Mode .........................................................................80
Security ................................................................................... 80
•PIN1 Check .........................................................................81
•Change PIN1 ......................................................................81
•Phone Lock ......................................................................... 81
•Change Password ............................................................... 81
•Phone Barring ..................................................................... 81
•Fixed Dialing (Fixed Dialing Numbers) ...............................81
•Change PIN2 ......................................................................82
•Network Barring ..................................................................82
•Closed User Group (CUG) .................................................. 82
Software Version ....................................................................
82
Reset ......................................................................................83
TTY .........................................................................................83
11
Contents
Appendix
Menu tree ............................................................................... 86
Access codes ........................................................................ 88
Troubleshooting checklist ...................................................
89
Performance and safety .......................................................90
Glossary ................................................................................91
FCC & Industry Canada Regulatory Compliance ..............93
Safety precautions ...............................................................96
12
1
Getting started
1. Package Contents
2. SIM Card
3. Battery
4. Display
5. Selecting functions and options
6. Keypad Lock
Package Contents
14
Battery Travel charger User’s manualPhone
About your SIM card
When you subscribe to Cingular, you receive a SIM
(Subscriber Identity Module) card containing your
registration information, PIN code, etc.
Like a credit card, it should be kept secure and handled
carefully.
Do not bend, scratch or expose it to moisture.
Avoid static electricity.
To avoid corrupting your SIM card’s memory, always switch
off your phone before removing or inserting your SIM card.
Installing/Removing your SIM card
❶ Remove the battery from your
phone by pushing and lifting it as
shown.
❷ If the SIM slot is empty, insert the
SIM card into the slot.
❸ To remove your SIM card, push
the SIM card in the arrow direction
as shown.
Inserting your battery
Insert the locators of the battery into the
hole located in the upper of the unit and
press the bottom of the battery. Push the
case of the battery until the sound of a
‘click’ is heard.
Removing your battery
Push the battery toward upside and
remove the battery.
Charging your battery
Your phone uses a Li-Ion battery. Make sure
to use an authorized battery and charger
only. For more details, please inquire at your
nearest dealer.
You can use your phone when the battery is
being recharged.
When the battery is inserted in your phone,
open the protective cover located on the
bottom of your phone and connect the
charger adapter, as shown. A suitable
adapter is supplied with your phone.
15
SIM Card & Battery
When your battery is fully charged,
remove the adapter connection from
the outlet, then disconnect the adapter
from your phone by pressing the
adapter’s side buttons and pulling the
adapter away from your phone, as
shown.
•Do not use a damaged battery or charger.
•Use your battery for the specified purpose only.
• The closer you are to your network’s base station, the
longer your phone usage time because less battery
power is consumed for the connection.
• The battery recharging time varies depending on the
remaining battery capacity and the battery and charger
type you use.
• Battery life inevitably shortens over time.
• Use an authorized battery and charger only.
• Since overcharging may shorten battery life, remove the
phone from its charger once it is fully charged. Unplug the
charger, once charging is complete. Leaving the battery
in hot or cold places, especially inside a car in summer
or winter, may reduce the capacity and life of the battery.
Always keep the battery within normal temperatures.
• Do not put your battery into contact with conductive
objects.
• Dispose of and recycle used batteries in accordance with
local regulations. Do not dispose of batteries by burning;
they may explode.
• Do not use an unauthorized charger.
• To prevent injury or burns, ensure that no metal objects
come into contact with the + and – terminals of the
battery.
Battery
16
Tip
Your phone is powered by a Lithium Ion (Li-Ion) battery.
This means that, unlike other forms of battery technology, you can
recharge your battery while some charge remains without reducing
your phone’s autonomy due to the “battery memory effect” inherent
in those technologies.
17
Display
Display Display icons
Depending on your phone’s status, the following icons may
appear at the top of the display.
Your phone has a display. Icons at the top of the display indicate your phone’s status.
Icon area
Text and graphic area
Displays the following information in Standby
mode:
Textural and graphical information showing
Network Name, Time and Date, or a Greeting
put in by the user.
Soft keys
Icon(s) Description
Received signal strength. The greater the number of bars, the stronger the signal.
A call is being made.
Your phone is outside the network coverage area; you cannot make or receive calls.
You have received one or more voice messages.
WAP is connected.
Display
18
Icon(s) Description
You have received one or more text, multimedia or e-mail messages.
is displayed if the text message memory is full.
A GPRS signal is available.
is displayed when there is an active GPRS session.
Call-forwarding feature is activated.
Flight mode is activated.
Alarm is set.
You have set the alert type for incoming call to ring only.
You have set the alert type for incoming call to ring ascent (volume increases over the duration of
the ring).
You have set the alert type for incoming call to ring and vibrate.
You have received one or more WAP push messages.
You have set the alert type for incoming call to vibrate then ring.
19
Display
Icon(s) Description
You have set the alert type for incoming call to silent.
You have set the alert type for incoming call to vibrate only. (Blue)
You have set the alert type for all tones to be quiet and for all rings to vibrate only. (Red)
Headset is connected.
Battery level. The bar indicates the available battery charge. If your battery charge is low, is
displayed.
A message is being received.
A message is being sent.
Speakerphone mode is activated.
Available, Away, Invisible Status of AIM
Online, Away, Busy, Offline Status of MSN
Available, Busy, Invisible Status of YAHOO
You have received one or more IM messages
Display & Selecting functions and options
20
Automatic display off
If you do not press any key for ten seconds (dependent on
the user setting) while the display is dimmed, the display
turns off automatically to save power. To restore the display,
press any key.
Selecting functions and options
Your phone offers several convenient ways for you to select
the phone function you want. You can access all of your
phone’s functions.
Selecting functions and options
Your phone offers many phone operating and customization
functions arranged in menus and sub-menus.
Each menu and sub-menu allows you to view and change
the settings of the particular function.
You access these functions using the left and right selection
(“Soft”) keys.
Soft key functions change depending on the current
context. The label or icon in the bottom line of the display,
above the Soft keys, shows each key’s current function.
To display the functions and options available, or
select the one required:
❶ Press the [[] or []] Soft key as appropriate.
❷ To select the function that is displayed or option that
is highlighted, press the Soft key [[] or push in on
joystick.
NOTE
In some functions, you may be asked to enter a password
or PIN.
Enter the required code then push in on joystick.
21
Selecting functions and options & Keypad Lock
❸ To highlight the next option on a list, push the joystick Up
[u] or Down [d].
❹ To move back to the previous function or option on a list,
press the [c] key.
❺ To return to the Standby mode, press the [e] key.
Keypad Lock
To lock the keypad
Keypad lock prevents accidental pressing of the keys.
Press the [Menu] Soft key then select the [
*] key within 3
seconds.
To unlock the keypad
Press the [Unlock] Soft key then select [*] key within 5
seconds to unlock the keypad.
2
Basic functions
1. Switching your phone on or off
2. Making and ending a call
3. Answering a call
4. Options during a call
5. Using your headset
6. Selecting menu functions
7. Entering text
To switch your phone on
❶ Press the [e] key until your phone switches on.
❷ If you are asked to input your PIN1 (Personal
Identification Number), enter your SIM card’s PIN1 and
push in on joystick. (For further details, see Security on
page 80.)
Your phone starts to search for an available network and
the current date and time is shown on the display. Once
connected to the network, you can make and receive calls.
To switch your phone off
Press and hold the [e] key until the power-off animation is
displayed.
Making and ending a call
To make a call
Enter the area code and phone number from Standby
mode, then press the [s] key.
To clear the last digit displayed, press the [
c] key.
To clear all the digits displayed, press and hold the [
c]
key.
To end a call
Press the [e] key in the normal way. To terminate all active
calls at the same time while you are in multi-party call,
select [Options] and then select [End All Calls].
Once the call is completed, a call summary (displaying
the recipient’s name or number, and the call duration) is
displayed.
To make a call using Call Logs
Your phone logs up to 30 dialed, received and missed call
Switching your phone on or off & Making and ending a call
24
NOTE
If a malfunction occurs while you use your phone or it is
not turned on, remove the battery then insert it again after 5 to 10
seconds.
NOTE
To change the language if you are switching on your
phone for the first time, select the Language menu option. (For
further details, see Language on page 80.)
NOTE
If you have turned the [Auto Redial] option on (For further
details, see Auto Redial on page 79), your phone will attempt
to make a call automatically for up to 10 times if a call is not
connected.
numbers. The last call number is saved in the first position.
If you dial the same number more than once, only the latest
occurrence is saved.
❶ Press the [s] key to display the Call Logs list of dialed,
received or missed call numbers in reverse chronological
order.
❷ Press the [z/x] key or push the joystick Up [u] or Down
[d] to select a number.
❸ Press the [s] key to dial the selected number.
(For further details, see 3.Recent Calls on page 53.)
To make a call using Entry
You can store frequently used names and phone numbers,
called Entry, in your SIM card or your phone’s memory.
Therefore; you do not have to remember all your phone
numbers; simply select the name to recall the associated
number.
❶ Push the joystick Down [d] to see the Name Search list.
❷ Select a number from Name Search.
❸ Press the [s] key to dial. (For further details, see
8.Address Book on page 71)
To make an International call
❶ Press and hold the [0] key for the international prefix
until the ‘+’ character appears on the display, or type the
outgoing national code that follows 011 (if the network
supports it).
❷ Type the country code, area code, and phone number
that you want to call.
❸ Press the [s] key.
To speed‐dial from Entry
Press and hold the Speed Dial number to make a call using
the number you have saved. For example, press and hold
the [5] key to dial a number which you have saved as “5”
in your Speed Dial list.
(For further details, see Speed Dial on page 72.)
To make an emergency call
You can make emergency calls even if your phone does not
have a SIM card.
❶ Select Emergency Number, or press the [SOS] Soft key
if your phone does not have a SIM card.
❷ Press the [s] key.
25
Making and ending a call
NOTE
To redial the last number in the Call Logs list, press and
hold the [
s] key.
To answer a call
When you receive a call, your phone rings (and/or vibrates).
If the caller can be identified, the caller’s phone number is
displayed (or the caller’s name, if it is stored in your entry).
❶ Press the [s] key.
To reply to a missed call
If the incoming call could not be answered, a missed call
message is shown on your phone’s display to remind you of
the call you have missed.
To reply to a missed call, do the following.
❶ Press the [View] Soft key to display the list of missed
calls.
❷ If necessary, scroll to highlight the number you want by
pushing the joystick Up [u] or Down [d].
❸ Press the [s] key to call the ‘missed call’s number.
Press the [
c] key or [e] key to close the ‘missed call’
notification message.
To reject a call
• Press the [e] key or the [Reject] Soft key. If the [Reject]
Soft key is pressed, the caller will hear Voice mail.
To answer a second call
You can answer an incoming call while you have a call in
progress, if your network service provider supports this
service and you have activated the Call Waiting option. (For
further details, see Call Waiting on page 79.)
You will be notified of an incoming call by a ‘call waiting’
tone. Press any keys except the [
e]key or [Reject] Soft
key. The first call is automatically put on hold.
To switch between two calls
Press the [Swap] Soft key.
To end the current call
Press the [s] key. The call on hold is automatically
reconnected to you.
Answering a call
26
If your answer type is set to [Any Key], you can answer
calls by pressing any key except the [
e] key regardless of the
answer type.
NOTE
NOTE
This function is network and subscription dependent, and
may not be available in all areas.
NOTE
This function is network and subscription dependent, and
may not be available in all areas.
To adjust the call volume
To adjust the earpiece volume during a call, do one of the
following.
• To increase the call volume during a call, press the [
z]
volume key on the left side of your phone.
• To decrease the call volume during a call, press the [
x]
volume key on the left side of your phone.
• In Standby mode, adjust the ringtone volume by using the
[z/x] keys.
To switch your microphone off
(Mute) or on (Speak)
You can temporarily switch your phone’s microphone off so
that the person you talk to on your phone cannot hear you.
For example, you may wish to say something to another
person in the room but do not want the person calling to
hear you.
To switch your phone’s microphone off
Press the [Mute] Soft key, or press [Options] then select
[Mute].
To switch your phone’s microphone
back on
Press the [Unmute] Soft key, or press [Options] then select
[Unmute].
To put a call on hold, and return to
a held call
You can put a call on hold whenever you want.
You can make another call while you have a call in progress
if your network service provider supports this service. One
call is active, while the other is on hold. You can also switch
between the calls.
To put a call on hold
Press the [Options] Soft key then select [Hold], or press the
[s] key. The caller’s name and icon are grayed while the
call is on hold.
To return to a held call
Press the [Options] Soft key then select [Resume], or press
the [s] key again.
To make a call while you are on a call
❶ Enter the phone number that you want to dial or look it
27
Options during a call
up in Address Book entry.
❷ Press the [s] key to dial the second call. The first call is
automatically put on hold.
To switch between two calls
Press the [Swap] Soft key. The current call is put on hold
and the held call is reactivated so that you can continue
your conversation with the caller.
To end a call
Press the [s] key in the normal way. To terminate all active
calls at the same time while you are in multi-party call,
select [Options] and then select [End All Calls].
Transferring a call
You can transfer or connect the current call to the held call
if your network service provider supports this service, so
that callers can talk to each other.
You will be disconnected from both of them.
❶ During a call, make or answer a call in the normal way
then press the [Options] Soft key.
❷ Push the joystick Up [u] or Down [d] to highlight the
[Transfer] option then press the [Select] Soft key or push
in on joystick.
The two callers will be connected to each other.
Multi‐party calls
A multi-party call feature is a network service that allows
up to six people to take part in a multi-party or conference
call simultaneously. For further details, contact your service
provider.
To make a multi‐party call
❶ Call the first participant in the normal way.
❷ Call the second participant in the normal way. The first
call is automatically put on hold.
❸ To join the first participant to a multi-party call, press the
[Options] Soft key then select the [Join All] option.
❹ Push in on joystick.
To add a new person to a multi‐party
call
❶ Call the person in the normal way.
❷ Press the [Options] Soft key then select the [Join All]
option.
❸ Push in on joystick.
Options during a call
28
To add a caller to a multi‐party call
Press the [Options] Soft key then select the [Join All] option.
To view the status of multi‐party call
participants
Push the joystick Left [l] or Right [r]. An icon indicates
whether the remote party is participating in the multi-party
call (‘Far Multiparty’) or on hold (‘Far Hold’.)
To answer or make a second call during
a multi‐party call
❶ Place the multi-party call on hold by pressing the
[Options] Soft key then selecting the [Hold All Calls]
option.
❷ Answer or make a call in the normal way.
❸ To reactivate the multi-party call on hold, press the
[Swap] Soft key.
❹ To end the multi-party call, press the [e] key.
To have a private conversation with one
participant
❶ Press the [Options] Soft key then select the [Private]
option.
❷ Push in on joystick.
❸ Push the joystick Up [u] or Down [d] to highlight the
participant you want then push in on joystick. Now you
can talk privately with that person.
❹ The other participants can continue the conversation with
each other.
❺ To return to the multi-party call, press the [Options] Soft
key then select the [Join All] option.
❻ Push in on joystick.
All of the multi-party call participants can now hear each
other.
To remove one participant from a multi‐
party‐call
❶ Press the [Options] Soft key then select the [Exclude]
option.
❷ Push the joystick Up [u] or Down [d] to highlight the
participant then push in on joystick. The call ends with
that participant, but you can continue to talk with the
other participants.
End the multi-party call by pressing the [
e] key.
29
Options during a call
Loading...
