Panasonic TX-65LZ1000E User guide

Model No.

e

HELP

English

Read first

Before use

• Licence 13

• Note 16

Features

• 4K resolution 17

• Home 18

• Freeview Play EPG 19

• Dual Tuner 20

• Easy Mirroring 21

Home

Home

• Information 22

• How to use 24

• Pin to HOME 26

• Option menu 27

Devices

• How to use 28

• Option menu 29

Apps

• How to use 31

• Option menu 32

Live TV

• How to use 33

• Option menu 34

my Scenery

• How to use 36

Watching

Basic

• Satellite connection 37

• Basic connection 39

- 2 -

• Selecting channel 41

• Information banner 43

• Freeview Play banner (UK) 46

• Satellite banner 48

• AV Options 50

• Subtitle 52

• Last view 53

• Off Timer 54

• Energy saving functions 55

• Adjusting time 59

• Language 60

4K resolution

• 4K-compatible equipment 62

• HDMI Auto Setting 63

• Valid 4K format 64

External equipment

• External connection 65

• Watching external input 69

• Operating with TV’s remote control 71

• HDMI features 73

• HDMI HDR Setting 75

• HDMI Signal Power Link Setting 76

• Valid input signals 77

For best picture

• Viewing Mode 78

• Aspect 81

• Aspect Control Signal 82

• Basic settings 84

• Ambient Sensor Settings 88

• Noise reduction settings 89

• Advanced Settings 90

• Option Settings 97

• Screen Settings 102

• Lock Settings 104

- 3 -

• Copy Adjustment 105

For best audio

• Sound mode 106

• Line Array Speaker Sound Focus settings 108

• Basic settings 109

• Volume settings 113

• Headphone terminal output setting 116

• Voice Guidance Settings 118

• Audio Description 119

• Advanced settings 120

TV Guide

• Freeview Play EPG (UK) 124

• TV Guide 126

• Timer Programming 128

• Guide link programming 129

Teletext

• Digital text service 130

• Viewing Teletext 131

• Teletext mode 133

• Teletext Character Set 134

Tuning and editing channels

• Setting menu 135

• Channel List Editor 136

• Favourites Editor 139

• Auto Setup 141

• Channel Sorting by Region 143

• Manual Tuning 144

• Update Channel List 146

• Signal Condition 147

• Add New Channels 148

• Other settings 149

• Selectable satellites 150

- 4 -

Recording

USB HDD setup

• Preparations 151

• Setting for USB HDD 153

Recording current programme

• One Touch Recording 155

• Rewind LIVE TV 156

Timer Programming

• Setting Timer Programming 158

• Editing Timer Programming 160

• Note 161

Technical information

• USB HDD 162

Media Player

Using Media Player

• Information 163

• Selecting device / mode 165

Easy List View

• Selecting file 166

• Filtering files 168

Mix Folder View

• Selecting file 169

• Filtering files 171

• Sorting files 172

Playback

• Playback 173

• Slideshow Settings 175

• Video Setup 177

• Audio output settings 178

Recorded TV mode

• Selecting content 179

- 5 -

• Watching recorded TV 180

• Grouping content 182

• Deleting content 183

• Chapter List 184

• Audio output settings 185

Connected device

• Device handling caution 186

• USB devices 187

Supported format

• Photo format 188

• Video format 189

• Music format 192

Network

Internet content

• Information 193

• Selecting internet content 194

• Note 195

Home network

• In-House streaming 196

• Preparations 199

Network connections

• Internet connection 200

• Home network connection 201

• Note 204

Network settings

• Network Connection 205

• Custom - Wireless 207

• Custom - Wired 209

• Custom - Wireless Access Point 2 11

• Network Status 212

• TV Name 213

• TV Remote App Settings 214

- 6 -

• Network Link Settings 216

• Smart Speaker Settings 218

• Mirroring Settings 219

• Control4 Settings 220

• VOD Content Refresh 221

• Software Update 222

• New Software Message 223

• IPv6 224

• Terms of Service and Settings 225

• Samba Interactive TV Settings 226

Photos

• Selecting file 227

• Viewing photo 228

• Using Slideshow 229

Videos

• Selecting file 230

• Watching video 231

• Video Setup 233

• Audio output settings 235

Music

• Selecting file 237

• Playing music 238

• Music Setup 239

Supported format

• Photo format 240

• Video format 241

• Music format 244

Functions

Menu

• How to use 245

Voice Control

• Information 246

- 7 -

• How to use 247

• Settings 248

• Note 250

Mirroring

• How to use 251

• Mirroring Settings 252

Multi Window

• Information 253

• Multi Window 254

• Note 256

VIERA Link “HDAVI Control™”

• Summary of VIERA Link 257

• Preparations 262

• Easy playback 263

• Power on Link 264

• Power off Link 265

• Standby Power Save 266

• Intelligent Auto Standby 267

• VIERA Link Control 268

• Speaker Selection 270

• Note 271

Child Lock

• Using Child Lock 272

• PIN number 273

• Parental Rating 274

Power LED Indicator

• Using Power LED Indicator 275

Data Service Application

• Using Data Service Application 276

• Privacy Setting 277

• Note 278

- 8 -

Common Interface

• Caution 279

• Using Common Interface 280

Shipping Condition

• Shipping Condition 281

Updating the TV Software

• Information 282

• Auto update 283

• Manual update 284

Setting characters

• Using Numeric buttons 285

Bluetooth devices

• Bluetooth Setup 286

Keyboard

• Keyboard 289

Settings

Setting main menu

• How to use 290


• Viewing Mode 292

• Basic settings 293

• Ambient Sensor Settings 295

• Noise reduction settings 296

• Advanced Settings 297

• Option Settings 298

• Screen Settings 300

• PICTURE Button Setting 301

• Lock Settings 302

• Copy Adjustment 303

• Reset to Defaults 304

- 9 -

Sound

• Mode 305

• Basic settings 306

• Volume settings 308

• Headphone terminal output setting 309

• Voice Guidance Settings 310

• Audio Description 311

• Advanced settings 312

• Reset to Defaults 314

Network

• Network Connection 315

• Network Status 316

• TV Name 317

• TV Remote App Settings 318

• Network Link Settings 319

• Smart Speaker Settings 320

• Mirroring Settings 321

• Control4 Settings 322

• Other settings 323

Timer

• On Timer 324

• Off Timer 325

• Timer Programming 326

• Time Zone 327

• Auto Standby 328

• No signal Power off 329

Setup

• Voice Control 330

• Eco Navigation 331

• USB Device Setup 332

• Recording Setup 333

• Bluetooth Setup 334

• Child Lock 335

• Tuning Menu 336

- 10 -

• Language 338

• Display Settings 339

• HDMI Auto Setting 341

• HDMI HDR Setting 342

• VIERA Link Settings 343

• Data Service Application 344

• Home Settings 345

• System Menu 346

• Other Settings 347

Support

Help menu

• Using Help menu 348

FAQs

• Picture 349

• Digital TV 351

• Analogue TV 353

• Sound 354

• HDMI 355

• Network 356

• Other 358

• Detailed information 361

Maintenance

• Care and Cleaning 362

- 11 -

How to use

■ Meaning of signs

OK :

Letters enclosed in brackets indicate remote control buttons.

Main Menu :

Letters in cyan indicate on-screen display items.

:

References in this eHELP

You can jump to the page by pressing OK while the cursor is on the
references.

■ Operation guide

= Note =

●

The design and specifications are subject to change without notice.

●

The images shown in this eHELP are for illustrative purposes only.

●

This eHELP covers all models, however, some features may not be
available on certain models.

●

Refer to the paper manual and the actual menu in the TV etc. to confirm
your model’s features.

- 12 -

Read first

Before use

Licence

Even if no special notation has been made of company or product
trademarks, these trademarks have been fully respected.

DVB and the DVB logos are trademarks of the DVB Project.

®

Wi-Fi

is a registered trademark of Wi-Fi Alliance®.

WPA3™, WPA2™, WPA™ are trademarks of Wi-Fi Alliance

®

The Bluetooth
by Bluetooth SIG, Inc. and any use of such marks by Panasonic Holdings
Corporation is under license.

The terms HDMI, HDMI High-Definition Multimedia Interface, and the
HDMI Logo are trademarks or registered trademarks of HDMI Licensing
Administrator, Inc.

x.v.Colour™ is a trademark.

© 2020 Advanced Micro Devices, Inc.

All rights reserved. AMD and FreeSync and combinations thereof are
trademarks of Advanced Micro Devices, Inc.

word mark and logos are registered trademarks owned

®

.

Dolby, Dolby Vision, Dolby Vision IQ, Dolby Atmos, Dolby Audio, and
the double-D symbol are trademarks of Dolby Laboratories Licensing
Corporation.

Manufactured under license from Dolby Laboratories.

Confidential unpublished works.

Copyright © 1992–2021 Dolby Laboratories.

All rights reserved.

- 13 -

Text-to-Speech Powered by Nuance

2002-2022 Nuance Communications, Inc. All rights reserved.

Google is a trademark of Google LLC.

“PlayReady” is a trademark registered by Microsoft. Please be aware of the
following.

(a) This product contains technology subject to certain intellectual property
rights of Microsoft. Use or distribution of this technology outside of this
product is prohibited without the appropriate license(s) from Microsoft.

(b) Content owners use Microsoft PlayReady™ content access technology to
protect their intellectual property, including copyrighted content. This device
uses PlayReady technology to access PlayReady-protected content and/or
WMDRM-protected content. If the device fails to properly enforce restrictions
on content usage, content owners may require Microsoft to revoke the
device’s ability to consume PlayReady-protected content. Revocation should
not affect unprotected content or content protected by other content access
technologies.

Content owners may require you to upgrade PlayReady to access their
content.

If you decline an upgrade, you will not be able to access content that requires
the upgrade.

This product incorporates the following software:

(1) the software developed independently by or for Panasonic Entertainment
& Communication Co., Ltd.,

(2) the software owned by third party and licensed to Panasonic
Entertainment & Communication Co., Ltd.,

(3) the software licensed under the GNU General Public License, Version 2.0
(GPL V2.0),

(4) the software licensed under the GNU LESSER GENERAL PUBLIC
LICENSE Version 2.1 (LGPL V2.1), and/or,

(5) open sourced software other than the software licensed under the GPL
V2.0 and/or LGPL V2.1.

The software categorized as (3) - (5) are distributed in the hope that it will be
useful, but WITHOUT ANY WARRANTY, without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE. Please
refer to the detailed terms and conditions thereof shown in the “Software
Licence” menu on this product.

- 14 -

At least three (3) years from delivery of this product, Panasonic will give to
any third party who contacts us at the contact information provided below,
for a charge no more than our cost of physically performing source code
distribution, a complete machine-readable copy of the corresponding source
code covered under GPL V2.0, LGPL V2.1 or the other licenses with the
obligation to do so, as well as the respective copyright notice thereof.

Contact Information: [email protected]

The source code and the copyright notice are also available for free in our
website below.

https://panasonic.net/cns/oss/tv/EUIDTV22.html

- 15 -

Note

●

When using your own contents (music, video, picture, etc.) with this unit,
pay attention not to harm the copyright, intellectual property, privacy, etc.
of the subject. Pay attention to the privacy, image rights, etc. of display
images, and use this unit at your own risk.

●

Keep your personal information (password of broadband router, etc.) safe
to prevent such information from being stolen by a third party while you
input or display the information on the TV screen.

- 16 -

Features

4K resolution

You can watch content in 4K format that has twice the horizontal and vertical
resolution of the 1080p signal.

Watching > 4K resolution > 4K-compatible equipment

- 17 -

Home

“Home” is a gateway to the TV programmes, applications and connected
devices.

It provides you an easy way to access all the features.

Home > Home > Information

- 18 -

Freeview Play EPG

Using the Freeview Play EPG enables you to select a programme easily, view
programme information, etc.

Watching > TV Guide > Freeview Play EPG (UK)

- 19 -

Dual Tuner

You can watch or record 2 programmes simultaneously, watch a programme
while recording another programme, etc.

Functions > Multi Window > Multi Window

- 20 -

Easy Mirroring

You can watch and display images of other devices (smartphone, etc.) on the
TV screen using a mirroring function. You can also start the mirroring function
from the other devices without operating the TV.

Functions > Mirroring > How to use

- 21 -

Home

Home

Information

“Home” is a gateway to the TV programmes, applications and connected
devices.

Home is displayed by pressing HOME and it provides you an easy way to
access all the features as shown below (example).

Home

my Scenery

– Displays the photos or videos stored in this TV, connected USB device,

etc.

Home > my Scenery

Live TV

– Gateway to TV programmes

Home > Live TV

Devices

– Gateway to connected devices (HDMI equipment, USB device, network

equipment, etc.)

Home > Devices

- 22 -

Apps

– Gateway to various applications (internet content, etc.)

Home > Apps

= Note =

●

Be sure to update the software when a software update notice is displayed
on the TV screen. If the software is not updated, you may not be able to
use Home. You can update the software later manually.

Network > Network settings > Software Update

- 23 -

How to use

From Home, you can access all the features such as TV programmes,
applications and connected devices.

●

A broadband network environment is required to use internet services.

Network > Network connections > Internet connection

1. Display Home with HOME.
(Example)

2. Select a feature (device / application / TV programme) and press OK to
access.

●

To watch full-screen TV, select Live TV.
(Example)

●

You can also select the content from the relevant programme information,
recommended content, etc. by pressing for each feature.

= Note =

●

The design and specifications are subject to change without notice.

■ Search

You can search for content from various sources.

●

Ireland only

1. Display Home with HOME.

2. Select Search and press OK to access.

●

A search history may be displayed and you can select it for keyword
search.

●

To delete the search history

1) Select Search and press OPTION.

2) Select Delete all histories and press OK.

3. Follow the on-screen instructions.

- 24 -

■ Freeview Play

●

UK only

1. Start Freeview Play with PROVIDER LIST.

2. Follow the on-screen instructions.

●

For Freeview (Channel list is alternatively displayed for the other modes.)

■ Auto Pin

Selects whether to automatically add a shortcut for a feature frequently used
on Home.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > Home Settings > Auto Pin and press OK to access.

3. Select On / Off and press OK to set.

■ Game Control Board

You can set up the picture settings for playing games in HDMI input or check
the setting status.

1. Display Home with HOME.

2. Select Apps and press OK to access.

3. Select Game Control Board and press OK to access.

4. Follow the on-screen instructions.

●

The setting items depend on the input signal or connected device.

- 25 -

Pin to HOME

You can add a shortcut for a frequently used feature on Home.

1. Display Home with HOME.

2. Select Devices / Apps / Live TV and press OK to access.

3. Select a feature (device / application / TV programme).

4. Display the option menu with OPTION.

5. Select Pin to HOME and press OK to set.

6. Select the position to add on Home and press OK to set.

●

To remove a shortcut from Home, set Unpin from HOME.

Home > Home > Option menu

- 26 -

Option menu

You can customise Home.

1. Display the option menu with OPTION.

2. Select one of the following items and press OK to access.

Unpin from HOME / Move / Sorting mode

3. Set the item and press OK to store.

Unpin from HOME

Removes a shortcut from Home.

Move

Arranges the position of the icons.

Sorting mode

Sorts the channels displaying on Home.

- 27 -

Devices

How to use

Connected devices (HDMI equipment, USB device, network equipment, etc.)
can be accessed easily from Devices.

1. Display Home with HOME.

2. Select Devices and press OK to access.
(Example)

●

To exit Devices

EXIT

●

To add a shortcut icon

Home > Home > Pin to HOME

3. Select a device and press OK to access.

●

For external equipment

Watching > External equipment

●

For USB device

Media Player > Using Media Player

●

For network equipment

Network > Home network

●

For mirroring function

Functions > Mirroring

= Note =

●

The design and specifications are subject to change without notice.

- 28 -

Option menu

1. Display the option menu with OPTION.

2. Select one of the following items and press OK to access.

Pin to HOME / Accessibility / Show Info.

3. Set the item and press OK to store.

Pin to HOME

Adds a shortcut for a frequently used feature on Home.

Home > Home > Pin to HOME

Accessibility

Voice Guidance Settings:

Guidance settings for visually impaired users

Watching > For best audio > Voice Guidance Settings

Voice Control:

Selects the voice service for Voice Control function.

Functions > Voice Control > Settings

Audio Description:

Narration settings for visually impaired users

Watching > For best audio > Audio Description

Dialogue Enhancement:

Enhances the intelligibility of dialogue and commentary.

Watching > For best audio > Volume settings

Preferred Subtitle Type:

Selects the preferred subtitle type.

Watching > Basic > Subtitle

Screen Display:

Turns the screen off when you select Off.

Watching > For best picture > Screen Settings

Radio Mode:

Sets the timer for turning off the screen automatically when a radio
channel is selected.

Watching > Basic > Energy saving functions

- 29 -

Show Info.

Displays the information about the selected device.

- 30 -

Apps

How to use

Various applications (internet content, etc.) can be accessed easily from

Apps.

1. Display Home with HOME.

2. Select Apps and press OK to access.
(Example)

●

To exit Apps

EXIT

●

To add a shortcut icon

Home > Home > Pin to HOME

●

You can assign a favourite application to MY APP of the TV’s remote
control.

Home > Apps > Option menu

3. Select an application and press OK to access.

4. Follow the on-screen instructions.

= Note =

●

The design and specifications are subject to change without notice.

●

Internet apps are provided by their service providers, and may be
changed, interrupted, or discontinued at any time.

●

A broadband network environment is required to fully use this function.

- 31 -

Option menu

1. Display the option menu with OPTION.

2. Select one of the following items and press OK to access.

Pin to HOME / Set as My App / Move / Lock / Unlock / Uninstall / Show
Info.

3. Set the item and press OK to store.

Pin to HOME

Adds a shortcut for a frequently used feature on Home.

Home > Home > Pin to HOME

Set as My App

Assigns your favourite application to MY APP of the TV’s remote control.

●

is displayed on the assigned application.

●

To change the assignment, set Set as My App while the cursor is on
another application.

Move

Arranges the position of the applications.

Lock, Unlock

Locks / unlocks a specific application to restrict access (if available).

●

Child Lock PIN number is required to access to locked application.

Functions > Child Lock > PIN number

Uninstall

Deletes an application from Apps (if available).

Show Info.

Displays the information about the selected application.

- 32 -

Live TV

How to use

Live TV is a gateway to the TV programmes.

1. Display Home with HOME.

2. Select Live TV.

3. Press OK to access.
(Example)

●

For details of watching TV

Watching > Basic

●

To add a shortcut icon

Home > Home > Pin to HOME

- 33 -

Option menu

1. Display the option menu with OPTION.

2. Select one of the following items and press OK to access.

Pin to HOME / Accessibility / AV Options / Category

3. Set the item and press OK to store.

Pin to HOME

Adds a shortcut for a frequently used feature on Home.

Home > Home > Pin to HOME

Accessibility

Voice Guidance Settings:

Guidance settings for visually impaired users

Watching > For best audio > Voice Guidance Settings

Voice Control:

Selects the voice service for Voice Control function.

Functions > Voice Control > Settings

Audio Description:

Narration settings for visually impaired users

Watching > For best audio > Audio Description

Dialogue Enhancement:

Enhances the intelligibility of dialogue and commentary.

Watching > For best audio > Volume settings

Preferred Subtitle Type:

Selects the preferred subtitle type.

Watching > Basic > Subtitle

Screen Display:

Turns the screen off when you select Off.

Watching > For best picture > Screen Settings

Radio Mode:

Sets the timer for turning off the screen automatically when a radio
channel is selected.

Watching > Basic > Energy saving functions

- 34 -

AV Options

Easy optional setting for viewing, sound, etc.

Watching > Basic > AV Options

●

Menu items and selectable options vary depending on the TV mode.

Category

Changes the category of channels for selecting a channel from the channel
list, information banner, etc.

●

Ireland only

- 35 -

my Scenery

How to use

Some features are not available on all models. Available menu items are displayed on your TV screen.

Displays my Scenery from Home.

1. Display Home with HOME.

2. Select my Scenery by pressing

.

3. Press OK.
(Example)

●

Select a scenery and press OK to switch my Scenery.

●

To exit my Scenery

EXIT

= Note =

●

The design and specifications are subject to change without notice.

●

Viewing Mode is fixed to my Scenery when my Scenery is displayed.

●

When no operation is performed for 15 minutes, the luminance level is
automatically adjusted to prevent panel “image retention”.

■ Settings

You can set up the scenery (selecting contents stored in this TV or connected
device, timer function, background music, etc.) and also view the guide
screen.

1. Press OK while my Scenery is displayed.

2. Select the items and press OK to access.

3. Follow the on-screen instructions.

●

Menu items and selectable options vary depending on the scenery.

= Note =

●

A picture may not be displayed depending on its file size.

●

The still pictures / moving pictures stored on the root directory can be
selected and the files in the folders are not selectable.

- 36 -

Watching

Basic

Satellite connection

Please ensure that the unit is disconnected from the mains socket before
attaching or disconnecting any cables.

●

External equipment and cables shown are not supplied with this TV.

●

For Satellite

■ Dual Tuner

Connecting both satellite terminals IN 1 and IN 2 to a satellite dish allows you
to watch or record 2 satellite programmes simultaneously.

Satellite IN 1 / IN 2 terminals

Satellite cables

Satellite dish

- 37 -

■ Single Tuner

Connect the satellite IN 1 terminal to the satellite dish.

●

Watching or recording 2 satellite programmes simultaneously, etc. is not
supported in single tuner mode.

Satellite IN 1 terminal

Satellite cable

Satellite dish

= Note =

●

To ensure your satellite dish is correctly installed, please consult your local
dealer. Also consult the received satellite broadcasting companies for
details.

●

Keep the TV away from electronic equipment (video equipment, etc.) or
equipment with an infrared sensor, otherwise distortion of image / sound
may occur or operation of other equipment may be affected.

●

Check the terminal type and cable plugs are correct for connection.

- 38 -

Basic connection

Some features are not available on all models.

Please ensure that the unit is disconnected from the mains socket before
attaching or disconnecting any cables.

●

External equipment and cables shown are not supplied with this TV.

■ Aerial

Terrestrial terminal

RF cable

Terrestrial aerial

●

For digital, analogue

■ DVD Recorder / Blu-ray Recorder, etc.

Terrestrial terminal

RF cable

DVD Recorder / Blu-ray Recorder, etc.

Terrestrial aerial

HDMI terminal

HDMI cable

- 39 -

■ Cable TV box

HDMI terminal

HDMI cable

Cable TV box

Terrestrial aerial / Cable

= Note =

●

For details of VIERA Link connections

Functions > VIERA Link “HDAVI Control™” > Summary of VIERA Link

●

Please also read the manual of the equipment being connected.

●

Keep the TV away from electronic equipment (video equipment, etc.) or
equipment with an infrared sensor, otherwise distortion of image / sound
may occur or operation of other equipment may be affected.

●

Use a fully wired HDMI compliant cable.

●

Use a high speed HDMI cable for high resolution images.

●

Use a Premium High Speed HDMI cable for HDR images.

●

Use a Ultra High Speed HDMI cable and connect to HDMI1 or HDMI2 for
4K high frame rate (120 Hz) images.

●

Check the terminal type and cable plugs are correct for connection.

- 40 -

Selecting channel

Some features are not available on all models.

1. Select the mode with TV.

Freeview (UK only) / DVB (Ireland only) / Analogue / Satellite

●

Selectable modes vary depending on the channels stored.

2. Select a channel with Channel Up / Down or Numeric buttons.

●

DVB channel position begins from number 1 upward. Analogue channel
position numbers are in the 0 - 99 range.

■ To select a channel using information banner

1. Display information banner with if it is not displayed.

2. Select a channel and press OK to watch while the banner is displayed.

Watching > Basic > Information banner

Watching > Basic > Freeview Play banner (UK)

■ To select a channel using TV Guide

1. Display TV Guide with GUIDE.

2. Select the current programme and press OK to access.

– The current programme is displayed on the top left of the screen.

3. Select Watch Now or View and press OK to watch.

●

For Ireland

Watching > TV Guide > TV Guide

●

For details of Freeview Play EPG

Watching > TV Guide > Freeview Play EPG (UK)

●

Not valid in Analogue

■ To display Discover more (UK and Freeview only)

1. Display Discover more with Freeview Play.

2. Select the application and press OK to access.

●

For the applications, follow the on-screen instructions.

- 41 -

■ To select the type of channel list

●

For DVB (Ireland only), Satellite

Automatically selects all channels or favourites list in the information banner
when the TV is turned on.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > Other Settings > Power on Channel List and press OK to
access.

3. Select All Channel List / Last and press OK to set.

■ To watch pay-TV

●

For details of the encrypted channels

Functions > Common Interface > Using Common Interface

●

Consult the operator / broadcaster or CI module manufacturer for more
information and conditions of the services.

- 42 -

Information banner

Some features are not available on all models.

Display information banner with .

●

Also appears when changing a channel.

●

The detailed information of the input signal (connected device information,
or signal information such as resolution, HDR type, and ALLM information)
is displayed when you press and hold for 3 seconds in the external
input mode (HDMI). Press it again to hide the information.

●

For Satellite, Analogue, DVB (Ireland only)

(Example)

Channel position and name

Channel type (Radio, HDTV, etc.) / Encrypted channel ( ) / TV mode ( ,

, )

Programme

Start time / End time (except Analogue)

Channel position, etc. (Analogue)

Progress time indicator of the selected programme (except Analogue)

Category

●

To change the category (DVB)

Home > Live TV > Option menu

Date and time

Features available / message meanings

Bad signal:

Poor quality TV signal

DD, DD+, DAC4, HE-AAC:

Dolby Audio (Dolby Digital, Dolby Digital Plus, Dolby AC-4), Dolby
Atmos or HE-AAC audio track

- 43 -

AD:

Audio Description service available

●

This function can aid visually-impaired viewers by providing an
additional audio track to describe events on screen.

Watching > For best audio > Audio Description

Also in :

Same programme available as HD broadcast (UK only)

●

To display the extra information for details

STTL:

Subtitle service available

TEXT:

Text service available

Multi Audio:

Multiple audio available

Stereo, Mono, NICAM:

Audio mode

1 – 90:

Off Timer remaining time

Watching > Basic > Off Timer

●

To confirm another tuned channel

/

●

To watch the channel listed in the banner

OK

●

Information on the next programme (DVB)

●

Extra information (DVB)

– Press again to hide the banner.

●

To hide the banner

EXIT

- 44 -

●

To adjust banner timeout, set Banner Display Timeout.

1) Display the menu with MENU, select Main Menu and press OK to

access.

2) Select Setup > Display Settings > Banner Display Timeout and press

OK to access.

3) Set the item and press OK to store.

●

AD, STTL, TEXT, Multi Audio indications are displayed as available

on particular programmes, but may not be available for all individual
programmes being broadcast. Display the extra information to confirm
availability of these functions.

- 45 -

Freeview Play banner (UK)

Display information banner with .

●

Also appears when changing a channel.

●

The detailed information of the input signal (connected device information,
or signal information such as resolution, HDR type, and ALLM information)
is displayed when you press and hold
input mode (HDMI). Press it again to hide the information.

●

For Freeview

(Example)

for 3 seconds in the external

Channel position and name

Programme

Date / Start time / End time

Current date and time

Event image (when available)

Features available / message meanings

AD:

Audio Description service available

●

This function can aid visually-impaired viewers by providing an
additional audio track to describe events on screen.

Watching > For best audio > Audio Description

SD:

SD broadcasts available

SD>HD:

Same programme available as HD broadcast

SL:

Sign language available

S:

Subtitle service available

- 46 -

●

To confirm another tuned channel

/

●

To watch the channel listed in the banner

OK

●

Information on the next programme

●

Extra information

– Press again to hide the banner.

●

To hide the banner

EXIT

●

To adjust banner timeout, set Banner Display Timeout.

1) Display the menu with MENU, select Main Menu and press OK to

access.

2) Select Setup > Display Settings > Banner Display Timeout and press

OK to access.

3) Set the item and press OK to store.

= Note =

●

In Satellite, the information banner will appear when pressing .

Watching > Basic > Satellite banner

- 47 -

Satellite banner

Only for the model supporting the satellite reception

Display information banner with .

●

Also appears when changing a channel.

●

The detailed information of the input signal (connected device information,
or signal information such as resolution, HDR type, and ALLM information)
is displayed when you press and hold for 3 seconds in the external
input mode (HDMI). Press it again to hide the information.

●

For Satellite

(Example)

Channel position and name

Programme

Start time / End time

Progress time indicator of the selected programme

Category

Current time

Features available / message meanings

AD:

Audio Description service available

●

This function can aid visually-impaired viewers by providing an
additional audio track to describe events on screen.

Watching > For best audio > Audio Description

SD:

SD broadcasts available

SD>HD:

Same programme available as HD broadcast

SL:

Sign language available

S:

Subtitle service available

- 48 -

●

To confirm another tuned channel

/

●

To watch the channel listed in the banner

OK

●

Information on the next programme

●

Extra information

– Press again to hide the banner.

●

To hide the banner

EXIT

●

To adjust banner timeout, set Banner Display Timeout.

1) Display the menu with MENU, select Main Menu and press OK to

access.

2) Select Setup > Display Settings > Banner Display Timeout and press

OK to access.

3) Set the item and press OK to store.

- 49 -

AV Options

Confirm or change the current status.

●

Display the image full-screen to use this function.

1. Display the option menu with OPTION.

2. Select AV Options and press OK to access.

3. Select one of the following items and press OK to access.

Audio Type / Multi Audio / Monaural Audio / Sub Channel / Subtitle
Language / Teletext Character Set / Teletext Language / NICAM / Volume
Correction

●

The function items vary depending on the TV mode and country you
select.

4. Set the item and press OK to store.

Audio Type

Set to Audio Description if the programme has Audio Description service,
then you will hear an additional audio track to describe events on screen (if
available).

●

For digital

●

To adjust the volume for Audio Description

Watching > For best audio > Audio Description

●

Not valid in multi window mode

Multi Audio

Selects between alternative language or Audio Description for sound tracks (if
available).

●

This setting is not stored and it returns to the default setting once you exit
the current programme.

●

For digital

●

Multi Audio / AD is displayed instead of Multi Audio. (Ireland only)

Monaural Audio

Selects stereo / monaural (if available).

●

This setting is not stored and it returns to the default setting once you exit
the current programme.

●

Not valid in Analogue

- 50 -

Sub Channel

Selects the multifeed programme - sub channel (if available).

●

For Satellite

Subtitle Language

Selects the language in which subtitles should appear (if available).

●

This setting is not stored and it returns to the default setting once you exit
the current programme.

●

Not valid in Analogue

●

Not valid on the sub screen in multi window mode

Teletext Character Set

Sets the teletext language font.

Watching > Teletext > Teletext Character Set

●

Ireland only

Teletext Language

Selects between alternative languages for teletext (if available).

●

For digital, Satellite

NICAM

Switches NICAM sound (if available).

Watching > For best audio > Advanced settings

●

For Analogue

Volume Correction

Adjusts the volume of each individual channel or input mode.

- 51 -

Subtitle

Some features are not available on all models.

■ Freeview, DVB, Satellite

Display / hide subtitles (if available) with STTL.

●

You can also display / hide subtitles from Subtitle in the menu.

1) Display the menu with MENU.

2) Select Subtitle, press OK and follow the on-screen instructions.

●

To select the preferred subtitle type

1) Display the menu with MENU, select Main Menu and press OK to

access.

2) Select Setup > Display Settings > Preferred Subtitle Type and press

OK to access.

3) Select Standard / Hard of Hearing and press OK to set.

– Hard of Hearing provides aids in understanding and enjoyment with

digital channel subtitles (depending on the broadcaster).

– Ireland only

●

Preferred Subtitles 1 / 2 in Language are given priority.

Watching > Basic > Language

– Ireland only

■ Analogue

Display subtitles with STTL.

●

Hide subtitles with EXIT.

= Note =

●

If you press STTL in Analogue, the TV switches to teletext service and
calls up a favourite page. Press EXIT to return to TV mode.

●

This is the same as switching to analogue teletext service and selecting
“P888” (subtitle service).

Watching > Teletext > Viewing Teletext

●

Not valid on the sub screen in multi window mode

- 52 -

Last view

Switch to a previously viewed channel or input mode easily with last view
button.

(LAST VIEW)

●

Press again to return to the current view.

= Note =

●

Switching channel may not be available depending on the condition.

●

Watching less than 10 seconds is not reflected in the previously viewed
channel or input mode.

- 53 -

Off Timer

Switch to TV Standby mode automatically after a fixed period.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Timer > Off Timer and press OK to access.

3. Select the time in 15-minute increments and press OK to set.

90 / 75 / 60 / 45 / 30 / 15 / Off (minutes)

●

To cancel, set to Off or turn the TV off.

●

The remaining time is displayed on the bottom right of the screen.

●

The remaining time will flash on the screen when less than 3 minutes.

- 54 -

Energy saving functions

The TV can be eco-friendly using energy-saving functions.

The TV goes into Standby mode in the following conditions:

●

Eco Navigation is set to Set to Eco.

●

Off Timer is active.

Watching > Basic > Off Timer

●

No operation is performed for 4 hours while Auto Standby is set to On.

●

No signal is received and no operation is performed for 10 minutes while

No signal Power off is set to On.

= Note =

●

This function does not affect the recording.

■ On Timer

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Timer > On Timer and press OK to access.

3. Set On Timer to Off to continue the settings.

4. Set the item and press OK to store.

On Timer

Automatically turns the TV on at the set time with the preset channel, volume,
etc.

Set to Off to edit the timer details or disable this function.

●

LED lights orange in Standby mode when On Timer is set to On.

Repeat

Selects the day to repeat the set timer function.

●

To cancel the repeat, disable all days.

Time

Sets the time to turn the TV on.

Time Voice Guidance

Sets the voice guidance of timer function.

- 55 -

Volume

Sets the volume when the TV is turned on by the set timer function.

my Scenery/TV/Input

Selects TV mode when the TV is turned on by the set timer function.

Channel

Selects a channel when the TV is turned on by the set timer function.

= Note =

●

TV turns on at the set time and turns off automatically after 60 minutes by
off timer function. Set Off Timer to Off to keep watching the TV.

●

The timer function is activated every day of the week which is set in

Repeat. When Repeat is not set, On Timer switches to Off after TV is

turned on automatically.

●

This function is not available when the TV is turned off with Mains Power
On / Off switch.

■ Auto Standby

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Timer > Auto Standby and press OK to access.

3. Select On / Off and press OK to set.

Auto Standby

(On / Off)

Automatically turns the TV to Standby mode for energy saving when no
operation is performed for 4 hours.

●

Automatic input switching with the connected equipment affects this
function and time-count resets.

●

A notification message will appear 3 minutes before going into Standby
mode.

●

Changing the default configuration may result in higher energy
consumption of the product.

- 56 -

■ No signal Power off

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Timer > No signal Power off and press OK to access.

3. Select On / Off and press OK to set.

No signal Power off

(On / Off)

Automatically turns the TV to Standby mode to prevent unnecessary power
consumption when no signal is received and no operation is performed for
10 minutes.

●

A notification message will appear 3 minutes before going into Standby
mode.

■ Eco Navigation

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > Eco Navigation and press OK to access.

3. Select Set to Eco and press OK to set.

Eco Navigation

Automatically sets the TV to the most suitable energy-saving mode.

The concerned items and their current settings are displayed. Select Set to

Eco to set them to the energy-saving settings at once.

●

Auto Standby and No signal Power off are active when Eco Navigation is

set to Set to Eco.

- 57 -

■ Radio Mode

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > Display Settings > Radio Mode and press OK to access.

3. Select the time and press OK to set.

Radio Mode

Sets the timer for turning off the screen automatically when a radio channel is
selected.

(20 / 15 / 10 / 5 / Off (seconds))

●

Sound is active even if the screen is turned off. This function is effective in
reducing power consumption when listening to a radio channel.

●

Press any buttons except Standby On / Off switch, Volume Up / Down or

MUTE to turn the screen on.

●

Not valid in Analogue

- 58 -

Adjusting time

Adjusts the time data.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Timer > Time Zone and press OK to access.

3. Set the item and press OK to store.

●

The time data are corrected based on GMT.

●

Ireland only

- 59 -

Language

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > Language and press OK to access.

3. Select one of the following items and press OK to access.

Preferred Multi Audio / Preferred Audio 1 / 2 / Preferred Subtitles 1 / 2 /
Preferred Subtitles / Preferred Teletext

4. Set the item and press OK to store.

Preferred Multi Audio

Selects the preferred language for digital channel multi audio (depending on
the broadcaster).

●

UK only

Preferred Audio 1 / 2

Selects the first and second preferred language for digital channel multi audio
(depending on the broadcaster).

●

Ireland only

Preferred Subtitles 1 / 2

Selects the first and second preferred language for digital channel subtitles
(depending on the broadcaster).

●

To display subtitles

Watching > Basic > Subtitle

●

Ireland only

Preferred Subtitles

Selects the preferred language for digital channel subtitles (depending on the
broadcaster).

●

To display subtitles

Watching > Basic > Subtitle

●

provides aids in understanding and enjoyment with subtitles (depending

on the broadcaster).

●

UK only

- 60 -

Preferred Teletext

Selects the preferred language for digital channel teletext service (depending
on the broadcaster).

●

Ireland only

- 61 -

4K resolution

4K-compatible equipment

You can watch content in 4K format that has twice the horizontal and vertical
resolution of the 1080p signal.

●

For details of valid 4K format

Watching > 4K resolution > Valid 4K format

●

Connect the 4K-compatible equipment to HDMI terminal using a
4K-compatible cable and you can watch content in 4K format.

■ 4K-compatible equipment

HDMI terminal

HDMI cable

4K-compatible equipment

●

Check the terminal type and cable plugs are correct for connection.

●

Use a fully wired HDMI compliant cable.

●

Use a high speed HDMI cable for high resolution images.

●

Use a Premium High Speed HDMI cable for HDR images.

●

Use a Ultra High Speed HDMI cable and connect to HDMI1 or HDMI2 for
4K high frame rate (120 Hz) images.

- 62 -

HDMI Auto Setting

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > HDMI Auto Setting and press OK to access.

3. Set the item and press OK to store.

HDMI Auto Setting

(Mode1 / Mode2 / Mode3)

Reproduces the image more precisely with the expanded colour gamut and
more smoothly with the high frame rate when connecting the 4K-compatible
equipment. Mode2 is a mode that supports higher definition signals than

Mode1. Mode3 is a mode that supports higher frame rate signals than Mode2.

Set to Mode1 when the image or sound in HDMI input is not played properly.

Mode1:

For high compatibility. Set to Mode1 when the image or sound in HDMI
input is not played properly.

Mode2:

For the 4K-compatible equipment that has the function to output the
image precisely with the expanded colour gamut

Mode3:

For the 4K 120 Hz-compatible equipment that has the function to output
the high frame rate image (This mode is available for HDMI1 / HDMI2.)

●

Not valid when NVIDIA Auto Game Mode is set to On and some of NVIDIA
PC graphics cards supporting HDMI 2.1 VRR are detected (HDMI Auto

Setting is fixed to Mode3.)

●

The setting can be stored for each HDMI input.

●

Valid format (4K)

– Mode1: 4:4:4 / 4:2:2 (30p, 25p, 24p), 4:2:0 (60p, 50p)

– Mode2: 4:4:4 / 4:2:2 (30p, 25p, 24p), 4:4:4 / 4:2:2 / 4:2:0 (60p, 50p)

– Mode3: 4:4:4 / 4:2:2 (30p, 25p, 24p), 4:4:4 / 4:2:2 / 4:2:0 (120p, 100p,

60p, 50p)

- 63 -

Valid 4K format

■ Valid 4K format (HDMI)

4K UHD

●

3 840 × 2 160 (120p, 100p, 60p, 50p, 30p, 25p, 24p)

– Aspect is fixed to 16:9.

= Note =

●

The above signals are reformatted for optimal viewing on your display.

●

Use HDMI1 / HDMI2 for the following 4K format.

– 4K UHD 50 Hz / 60 Hz 4:4:4 (10 bit / 12 bit)

– 4K UHD 100 Hz / 120 Hz

●

For details of aspect

Watching > For best picture > Aspect

- 64 -

External equipment

External connection

Some features are not available on all models.

These diagrams show our recommendations for connection of your TV to
various pieces of equipment. For other connections, consult the instructions
for each piece of equipment.

●

For details of basic connection

Watching > Basic > Basic connection

●

To use the specific devices supporting Bluetooth wireless technology

Functions > Bluetooth devices

●

Check the terminal type and cable plugs are correct for connection.

●

External equipment and cables shown are not supplied with this TV.

■ HDMI equipment

HDMI terminal

HDMI cable

Recorder / Player / Cable TV box / Camcorder / Amplifier with speaker

system / Game

- 65 -

= Note =

●

Use a fully wired HDMI compliant cable.

●

Use a high speed HDMI cable for high resolution images.

●

Use a Premium High Speed HDMI cable for HDR images.

●

Use a Ultra High Speed HDMI cable and connect to HDMI1 or HDMI2 for
4K high frame rate (120 Hz) images.

●

For details of VIERA Link connections

Functions > VIERA Link “HDAVI Control™” > Summary of VIERA Link

●

Use HDMI2 to connect the TV to an amplifier which has eARC (Enhanced
Audio Return Channel) / ARC (Audio Return Channel) function.

●

Use HDMI1 / HDMI2 to connect the device that supports 4K high frame
rate (120 Hz), VRR (Variable Refresh Rate), AMD FreeSync Premium
function.

■ AV devices connecting to TV with AV (VIDEO) adaptor (not

supplied)

AV IN (VIDEO) terminals

AV (VIDEO) adaptor (Shielded / not supplied)

1: L

2: Video

3: Ground

4: R

(3.5 mm mini plug)

Composite cable (Shielded)

●

Use shielded composite cable.

Audio cables (Shielded)

●

Use shielded audio cables.

Camcorder / Game equipment

- 66 -

■ USB devices

USB port

USB cable

USB HDD, etc.

= Note =

●

It is recommended to connect the device to the TV’s USB port directly.

●

You cannot use two or more of the same kind of USB devices
simultaneously except USB Flash Memory or USB HDD.

●

Use USB 1 port for connecting the USB HDD.

●

Some USB devices or USB HUB may not be used with this TV.

●

You cannot connect any devices by using USB card reader.

■ Listening with external speakers

DIGITAL AUDIO

Optical digital audio cable

Amplifier with speaker system

●

To enjoy multi-channel sound from external equipment (e.g. Dolby
Audio (Dolby Digital) 5.1ch), connect the equipment to the amplifier. For
information about the connections, read the manuals of the equipment and
amplifier.

●

To select the sound output to adjust the volume, set TV Speaker Setting.

Watching > For best audio > Volume settings

- 67 -

■ Headphones

Headphone / Subwoofer jack

3.5 mm stereo mini plug

Headphones

●

To use headphones, set Headphone Terminal Output to Headphone.

Watching > For best audio > Headphone terminal output setting

●

Do not connect a sub woofer while Headphone Terminal Output is set to

Headphone.

●

To adjust the volume, set Headphone Volume.

Watching > For best audio > Headphone terminal output setting

●

To select the sound output to adjust the volume, set TV Speaker Setting.

Watching > For best audio > Volume settings

■ Sub woofer

Headphone / Subwoofer jack

Audio cable (3.5 mm stereo mini plug - audio pin plug)

Sub woofer

●

To use a sub woofer, set Headphone Terminal Output to Sub Woofer.

Watching > For best audio > Headphone terminal output setting

●

Do not connect headphones while Headphone Terminal Output is set to

Sub Woofer.

●

To adjust the volume, set Sub Woofer Adjustment.

Watching > For best audio > Headphone terminal output setting

●

The volume of the sub woofer can be also controlled when adjusting the
volume of this unit with this TV’s remote control.

●

If the sub woofer unit has volume control, check the level as well.

- 68 -

Watching external input

Connect the external equipment (VCR, DVD, etc.) and you can watch through
the input.

1. Display the input selection menu with AV.

2. Select the input mode connected to the equipment and press OK to watch.
(The selected mode is displayed on the top left of the screen.)

●

You can also select the input pressing AV. Press repeatedly until the
desired input is selected.

●

You can label or skip each input mode. Skipped inputs will not be
displayed when AV is pressed. (Input Labels)

●

The remote control is capable of operating the content or external
equipment.

Watching > External equipment > Operating with TV’s remote control

●

To return to TV mode

TV

= Note =

●

If the external equipment has an aspect adjustment function, set it to 16:9.

●

For details, read the manual of the equipment or ask your local dealer.

■ Input Labels

Accessing the input labels list allows you to change the input name or skip
the input if unconnected, improving identification and selection in the Input

Selection banner.

Watching > Basic > Information banner

Watching > Basic > Freeview Play banner (UK)

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > Display Settings > Input Labels and press OK to access.

3. Set the item and press OK to store.

●

To name each input mode freely, select User input and set characters
(maximum 10 characters).

●

To skip the input mode, select Skip.

- 69 -

■ Playing Time Display

Set to On to display a time period of continuous use in Game Mode on the top
right of the screen every 30 minutes.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > Display Settings > Playing Time Display and press OK to
access.

3. Select On / Off and press OK to set.

●

This function is available when Input Lag is set to Fast.

- 70 -

Operating with TV’s remote control

You can operate the content in Media Player / media server, recording
functions or the connected equipment with the following buttons of this TV’s
remote control.

:

Playback (VCR / DVD / video content)

:

Stop the operations

:

Rewind, view the picture rapidly in reverse (VCR)

Skip to the previous track, title or chapter (DVD / video content)

Press and hold to search backward (DVD / video content)

:

Fast-forward, view the picture rapidly forward (VCR)

Skip to the next track, title or chapter (DVD / video content)

Press and hold to search forward (DVD / video content)

:

Pause / Resume

Press and hold to play at slow speed (DVD)

:

One Touch Recording

Recording > Recording current programme > One Touch Recording

- 71 -

■ How to change the code

Each Panasonic product has its own remote control code. Change the code
according to the product for operation.

1. Press and hold Standby On / Off switch during the following operations.

2. Enter the appropriate code as follows with Numeric buttons.

●

Codes for each product and features

70: DVD Recorder, DVD Player, Blu-ray Disc Player

71: Player theatre, Blu-ray Disc theatre

72: VCR

73 (default):

Using in USB HDD recording, Media Player, in-house streaming or
VIERA Link

3. Press

to change.

= Note =

●

Confirm if the remote control works correctly after changing the code.

●

The codes may be reset to defaults if batteries are replaced.

●

Some operations may not be available depending on the equipment.

- 72 -

HDMI features

Some features are not available on all models.

HDMI (high-definition multimedia interface) is the world’s first complete digital
consumer AV interface complying with a non-compression standard.

HDMI allows you to enjoy high-definition digital images and high-quality
sound by connecting the TV to external equipment.

HDMI-compatible equipment* with an HDMI or DVI output terminal, such as a
DVD player, a set top box or game equipment, can be connected to the HDMI
terminal using a fully wired HDMI compliant cable.

Watching > External equipment > External connection

* : The HDMI logo is displayed on HDMI-compliant equipment.

■ Applicable HDMI features

●

Input audio signal:

LPCM, Dolby Audio (Dolby Digital, Dolby Digital Plus, Dolby TrueHD),
Dolby Atmos

– Audio settings can be made on HDMI Audio Format in the Sound

Menu.

Watching > For best audio > Advanced settings

●

Input video signal:

Matches the output setting of the digital equipment.

Watching > External equipment > Valid input signals

●

VIERA Link (HDAVI Control 5)

Functions > VIERA Link “HDAVI Control™” > Summary of VIERA Link

●

Content Type

●

Deep Colour

●

eARC (Enhanced Audio Return Channel) / ARC (Audio Return Channel)

– eARC (Enhanced Audio Return Channel) / ARC (Audio Return

Channel) are functions to send digital sound signals via an HDMI cable.

– For HDMI2

●

x.v.Colour™

●

4K

Watching > 4K resolution > Valid 4K format

- 73 -

●

VRR (Variable Refresh Rate) / AMD FreeSync Premium

– VRR (Variable Refresh Rate) / AMD FreeSync Premium provides

smoother gaming experience with low latency and without image
stuttering or tearing.

– For HDMI1 / 2

■ DVI connection

If the external equipment has only a DVI output, connect to the HDMI terminal
via a DVI to HDMI adaptor cable. When using the DVI to HDMI adaptor cable,
connect the audio cable to the audio input terminal.

●

Depending on the model, composite cable (not supplied) may be
necessary to connect to the audio input terminals.

●

Enquire HDMI adaptor cable at your local digital equipment retailer shop.

= Note =

●

Audio settings can be made on HDMI Audio Format / HDMI Input in the
Sound Menu.

Watching > For best audio > Advanced settings

●

If the connected equipment has an aspect adjustment function, set the
aspect ratio to “16:9”.

●

These HDMI connectors are “type A”.

●

These HDMI connectors are compatible with HDCP (High-Bandwidth
Digital Content Protection) copyright protection.

●

Equipment having no digital output terminal may be connected to the
analogue input terminals to receive analogue signals.

●

This TV incorporates HDMI™ technology.

- 74 -

HDMI HDR Setting

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > HDMI HDR Setting and press OK to access.

3. Set the item and press OK to store.

HDR Setting

(Dynamic / Static / Off)

Set to Dynamic or Static when the HDR device is connected to the TV.

●

Please turn Off this function if the image looks unnatural. This may occur
in some cases such as compatibility with the connected device, source
images or with use of multi-window function.

●

Image may disappear for a few seconds when the setting is changed.

●

For HDMI

HDR Dynamic Setting

HDR10+ Functionality

(On / Off)

Enables the HDR10+ function for HDMI input signal.

Dolby Vision

(On / Off)

On:

Allows Dolby Vision processing to occur either on the TV or the source
device mainly.

Off:

Disables Dolby Vision functionality.

= Note =

●

Supporting HDR does not increase the peak brightness capabilities of the
TV panel.

- 75 -

HDMI Signal Power Link Setting

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Setup > Other Settings > HDMI Signal Power Link Setting and
press OK to access.

3. Set the item and press OK to store.

HDMI Signal Power Link Setting

Power on Link

(On / Off)

When the connected equipment is operated, the TV is automatically turned
on. (Only when the TV is in Standby mode.)

Power off Link

(On / Off)

When the TV is set to Standby mode, the connected equipment is also
automatically set to Standby.

Link Terminal

Selects HDMI terminal to use the power link function.

- 76 -

Valid input signals

■ HDMI

Signal name

525 (480) / 60p

625 (576) / 50p

750 (720) / 60p, 50p

1 125 (1 080) / 60i, 50i

1 125 (1 080) / 120p, 100p, 60p, 50p, 24p

3 840 × 2 160 / 120p, 100p, 60p, 50p, 30p, 25p, 24p

= Note =

●

Signals other than those above may not be displayed properly.

●

The above signals are reformatted for optimal viewing on your display.

●

For details of valid 4K format

Watching > 4K resolution > Valid 4K format

- 77 -

For best picture

Viewing Mode

Some features are not available on all models. Available menu items are displayed on your TV screen.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Picture > Viewing Mode and press OK to access.

3. Select the mode and press OK to set.

Viewing Mode

(Dynamic / Auto AI / Normal / Professional Photo / Cinema / Filmmaker /

True Cinema / Custom / Professional1 / Professional2 / Sport / Game / Dolby
Vision Vivid / Dolby Vision IQ / Dolby Vision Bright / Dolby Vision Dark)

Selects your favourite picture mode for each input.

Dynamic:

Improves contrast and sharpness for viewing in a bright room.

Auto AI:

Adjusts the luminance, colour temperature, shades of black, etc. to suit
your watching environment.

●

To adjust the effect level, set Auto AI – Picture Effect Level.

Normal:

Normal use for viewing in a normal lighting condition.

Professional Photo:

Reproduces the original image for photo.

●

For photo content

Cinema:

Improves the performance of contrast, black and colour reproduction
for watching a film in a darkened room.

Filmmaker:

Reproduces the original image quality precisely. Reacts to room
brightness.

True Cinema:

Reproduces the original image quality precisely without any revision.

Custom:

Adjusts each menu item manually to suit your favourite picture quality.

- 78 -

Professional1 / 2:

Allows you to set and lock the professional picture settings.

Watching > For best picture > Advanced Settings

●

If a certified professional dealer sets these modes, Professional1
and Professional2 may be displayed as isf Day and isf Night.

Sport:

Improves picture quality for watching sports, etc.

●

The sound mode is automatically set to Stadium when Viewing

Mode is set to Sport. To cancel the linkage of the sound and viewing

mode, set Sport Link to Off.

Watching > For best audio > Basic settings

Game:

Improves picture quality for playing games, etc.

●

For HDMI, AV

●

Input Lag is automatically set to Fast when Viewing Mode is set to
Game.

Watching > For best picture > Option Settings

Dolby Vision Vivid:

Reproduces Dolby Vision content precisely in a bright room.

Dolby Vision IQ:

Automatically adjusts to reproduce Dolby Vision content according to
the content, lighting condition, etc.

Dolby Vision Dark:

Reproduces Dolby Vision content precisely in a darkened room.

●

The following items can be adjusted and stored for each mode.

Luminance Level / Backlight / Contrast / Brightness / Colour / Tint /
Sharpness / Colour Temperature / Colour Remaster / Rec.2020 Colour
Remaster / Adaptive Backlight Control / Ambient Sensor Settings / Noise
Reduction / MPEG Remaster / Resolution Remaster / Dynamic Range
Remaster / Dark Visibility Enhancer / Intelligent Frame Creation

●

This function can be stored respectively for input or TV mode.

●

Viewing Mode is fixed to my Scenery when my Scenery is displayed.

- 79 -

■ Netflix Calibrated Mode

Reproduces the image quality based on the professional monitor settings
while watching Netflix.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Picture > Netflix Calibrated Mode and press OK to access.

3. Select On / Off and press OK to set.

●

Viewing Mode is fixed to Netflix when Netflix Calibrated Mode is set to On.

●

For Netflix content

■ Auto AI – Picture Effect Level

Adjusts the effect level when Viewing Mode is set to Auto AI. The effect level
is automatically higher when setting high.

●

This function is available when Viewing Mode is set to Auto AI.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Picture > Auto AI – Picture Effect Level and press OK to access.

3. Set the item and press OK to store.

●

Auto AI – Picture Effect Level is not available when 4K 120Hz Bypass
Mode is set to On.

■ To change the viewing mode with PICTURE

You can change the viewing mode easily only by pressing PICTURE.

1. Display Viewing Mode with PICTURE.

2. Select the mode and press OK to set.

●

You can also change the mode by pressing PICTURE.

(Press repeatedly until you reach the desired mode.)

●

To set the viewing mode selection

1) Display the menu with MENU, select Main Menu and press OK to

access.

2) Select Picture > PICTURE Button Setting and press OK to access.

3) Select the viewing mode to set.

- 80 -

Aspect

Some features are not available on all models. Available menu items are displayed on your TV screen.

Changes the aspect ratio (image size).

■ To change the aspect ratio manually

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Picture > Screen Settings and press OK to access.

3. Select Aspect and press OK to access.

4. Set the item and press OK to store.

Auto:

The best ratio is selected automatically according to the “Aspect Control
Signal”.

Watching > For best picture > Aspect Control Signal

16:9:

Directly displays the image at 16:9 without distortion (anamorphic).

4:3:

Displays the image at the standard 4:3 without distortion.

Zoom:

Displays a 16:9 letterbox or 4:3 image without distortion.

4:3 Full:

Displays a 4:3 image enlarged horizontally to fit the screen.

= Note =

●

Display the image full-screen to use this function completely.

●

Aspect mode can be stored separately for SD (Standard definition) and
HD (High definition) signals.

●

Aspect cannot be changed in teletext service.

●

Aspect is fixed to Auto when Viewing Mode is set to Filmmaker.

●

Aspect is fixed to 16:9 in the following conditions:

– Input Lag is set to Fast.

– 4K content

– 1080p Pure Direct is set to On.

– 4K Pure Direct is set to On.

- 81 -

Aspect Control Signal

Some features are not available on all models.

Programmes usually contain an “Aspect Control Signal”. (Widescreen signal,
Control signal through HDMI terminal)

In Auto mode, aspect mode will appear in the top left of the screen if a
Widescreen signal (WSS) or a Control signal through HDMI terminal is found.
The aspect switches to the appropriate ratio.

Watching > For best picture > Aspect

■ Available conditions

Terrestrial terminal (WSS only)

●

Valid input signal format:

DVB

PAL I

Invalid input signal format:

PAL 525/60 6.0 MHz

M.NTSC 6.0 MHz

Satellite terminal (WSS only)

●

Valid input signal format:

Satellite

AV IN (VIDEO) terminals

●

Valid input signal format:

PAL

PAL 525/60*

M.NTSC*

NTSC*
* : Control signal through HDMI terminal only

- 82 -

HDMI terminal

●

Valid input signal format:

525 (480) / 60p

625 (576) / 50p

750 (720) / 60p, 50p

1 125 (1 080) / 60i, 50i

1 125 (1 080) / 120p, 100p, 60p, 50p, 24p

3 840 × 2 160 / 120p, 100p, 60p, 50p, 30p, 25p, 24p

●

HDMI terminal does not receive WSS signal.

= Note =

●

If the screen size looks unusual when a widescreen-recorded programme
is played back on a VCR, adjust the tracking of the VCR. Read the manual
of the VCR.

●

For details of valid 4K format

Watching > 4K resolution > Valid 4K format

- 83 -

Basic settings

Some features are not available on all models. Available menu items are displayed on your TV screen.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Picture and press OK to access.

3. Select one of the following items and press OK to access.

Luminance Level / Backlight / Contrast / Brightness / Colour / Tint /
Sharpness / Colour Temperature / Colour Remaster / Rec.2020 Colour
Remaster / Adaptive Backlight Control / Resolution Remaster / Dynamic
Range Remaster / Dark Visibility Enhancer / Intelligent Frame Creation

4. Set the item and press OK to store.

Luminance Level, Backlight, Contrast, Brightness, Colour, Tint, Sharpness

Adjusts the levels of these options according to your personal preference.

●

Sharpness is not available when Viewing Mode is set to Dolby Vision IQ or
4K 120Hz Bypass Mode is set to On.

Colour Temperature

Sets the overall colour tone of the picture (bluer - redder).

●

Not valid when Viewing Mode is set to Dolby Vision IQ

Colour Remaster

(Max / Min / Off)

Displays the vivid images with the expanded colour gamut.

●

Not valid in the following conditions:

– Viewing Mode is set to the mode of Dolby Vision.

– 4K 120Hz Bypass Mode is set to On.

Rec.2020 Colour Remaster

(On / Off)

Displays the vivid images with the suitable colour gamut.

●

Not valid in the following conditions:

– Viewing Mode is set to the mode of Dolby Vision.

– 4K 120Hz Bypass Mode is set to On.

●

This function is available only for Rec. 2020 and displayed instead of

Colour Remaster.

- 84 -

Adaptive Backlight Control

Automatically controls the level of backlight according to the images.

Not valid when VRR is set to On

Resolution Remaster

(Auto / Max / Mid / Min / Off)

Enhances picture resolution to make the image sharper.

●

Not valid in the following conditions:

– Viewing Mode is set to Dolby Vision IQ.

– 4K 120Hz Bypass Mode is set to On.

Dynamic Range Remaster

(On / Off)

Enhances bright areas of the image closer to the original luminance making
improved picture impact.

●

Not valid in the following conditions:

– Multi window

– HDR video signal

– Viewing Mode is set to Sport or the mode of Dolby Vision.

– 4K 120Hz Bypass Mode is set to On.

Dark Visibility Enhancer

Adjusts the black level or middle luminance level.

●

Not valid when 4K 120Hz Bypass Mode is set to On

- 85 -

Intelligent Frame Creation

(Custom / Max / Mid / Min / Off)

Automatically compensates the picture frame rate and removes juddering
movements to make the images smooth.

●

Depending on the content, images may be noisy. To prevent the noise,
change the setting.

●

Select Custom to set Intelligent Frame Creation manually.

Blur Reduction:

Adjusts the smoothness of camera content to minimise blur.

Film Smooth:

Adjusts the smoothness of film content.

Reset to Defaults:

Resets items for Intelligent Frame Creation.

●

Not valid in the following conditions:

– Input Lag is set to Fast.

– 1080p Pure Direct is set to On.

– 4K Pure Direct is set to On.

– Photo content

– Viewing Mode is set to Dolby Vision IQ.

– 120 Hz video signal from 120 Hz-compatible equipment

Auto AI – Film Interlock:

Reproduces image more precisely for the film content. Set to Off when
the image looks unnatural.

●

Set Viewing Mode to Auto AI to use this function.

●

Not valid in the following conditions:

– Input Lag is set to Fast.

– 1080p Pure Direct is set to On.

– 4K Pure Direct is set to On.

– Photo content

– 120 Hz video signal from 120 Hz-compatible equipment

- 86 -

Accurate IFC:

Reproduces image like the original filming image for the film content.
Set to Off when the image looks unnatural.

●

Set Intelligent Frame Creation to Off to use this function.

●

Not valid in the following conditions:

– Input Lag is set to Fast.

– 1080p Pure Direct is set to On.

– 4K Pure Direct is set to On.

– Photo content

– 120 Hz video signal from 120 Hz-compatible equipment

Black Frame Insertion:

Makes the blurring image clearer for video content, etc.

●

When Input Lag is set to Fast in HDMI input with the equipment
supporting VRR function, the input lag may occur.

●

Not valid in the following conditions:

– Photo content

– VRR is set to On.

– Multi window

– 4K 120Hz Bypass Mode is set to On.

Clear Motion:

Makes the moving pictures clearer.

●

When Input Lag is set to Fast in HDMI input, the input lag may
occur.

- 87 -

Ambient Sensor Settings

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Picture > Ambient Sensor Settings > Auto Brightness / Auto White

Balance and press OK to access.

3. Set the item and press OK to store.

Auto Brightness

(On / Off)

Adjusts brightness automatically depending on ambient lighting conditions.

●

This function may not be available when Viewing Mode is set to the mode
of Dolby Vision.

Auto White Balance

(On / Off)

Adjusts the white balance depending on ambient lighting conditions.

●

This function may not be available when Viewing Mode is set to the mode
of Dolby Vision.

- 88 -

Noise reduction settings

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Picture > Noise Reduction / MPEG Remaster and press OK to
access.

3. Set the item and press OK to store.

Noise Reduction

(Auto / Max / Mid / Min / Off)

Reduces unwanted picture noise.

●

Not valid in the following conditions:

– 1080p Pure Direct is set to On.

– 4K Pure Direct is set to On.

– Viewing Mode is set to Dolby Vision IQ.

– 4K 120Hz Bypass Mode is set to On.

MPEG Remaster

(Auto / Max / Mid / Min / Off)

Reduces flicker noise in contoured parts of a picture and block noise.

●

Not valid in the following conditions:

– 1080p Pure Direct is set to On.

– 4K Pure Direct is set to On.

– Viewing Mode is set to Dolby Vision IQ.

– 4K 120Hz Bypass Mode is set to On.

- 89 -

Advanced Settings

Some features are not available on all models. Available menu items are displayed on your TV screen.

You can adjust and set up the detailed picture settings when Viewing Mode
is set to Professional Photo, Cinema, Filmmaker, True Cinema, Custom,

Professional1 / 2, Game, Dolby Vision IQ, Dolby Vision Bright or Dolby Vision
Dark.

Watching > For best picture > Viewing Mode

1. Select the input mode with AV or TV.

2. Display the menu with MENU, select Main Menu and press OK to access.

3. Select Picture > Viewing Mode and press OK to access.

4. Select the mode and press OK to set.

Professional Photo / Cinema / Filmmaker / True Cinema / Custom /
Professional1 / Professional2 / Game / Dolby Vision IQ / Dolby Vision
Bright / Dolby Vision Dark

■ Adjust the detailed picture settings

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Picture > Advanced Settings and press OK to access.

3. Select one of the following items and press OK to access.

Contrast Control / Colour Gamut / Photo Colour Gamut / White Balance

/ Colour Management / Gamma / Dynamic HDR Effect / HDR Tonemap

clipping / Reset to Defaults

4. Set the item and press OK to store.

- 90 -

■ Contrast Control

Contrast Control

(Custom / Auto / Off)

Automatically adjusts the detailed contrast settings. Select Custom to set

Contrast Control Setting manually.

●

Not valid in the following conditions:

– Viewing Mode is set to Filmmaker.

– Tonemap clipping is set to Clipping.

– 4K 120Hz Bypass Mode is set to On.

Contrast Control Setting

●

Not valid when 4K 120Hz Bypass Mode is set to On

Adaptive Gamma Control:

Adjusts the gamma curve to make the image brighter.

Black Expander:

Gradually adjusts the shades of black.

Reset to Defaults:

Resets items for Contrast Control Setting.

- 91 -

■ Colour Gamut / Photo Colour Gamut

Colour Gamut

(Native / Rec. 709 / SMPTE-C / EBU / Rec. 2020 / DCI-P3)

Reproduces image colour precisely according to the colour gamut standards.

Native:

Displays deep colours by expanding the colour gamut to its maximum.

Rec. 709:

Standard for HD (High definition)

SMPTE-C:

Standard for NTSC

EBU:

Standard for PAL

Rec. 2020:

Provides the suitable colour gamut for Rec. 2020.

DCI-P3:

Provides the suitable colour gamut for DCI.

●

Set Colour Remaster to Off to use this function.

●

Set Rec.2020 Colour Remaster to Off to use this function for the Rec.
2020 signal.

●

Not valid in the following conditions:

– Viewing Mode is set to the mode of Dolby Vision.

– 4K 120Hz Bypass Mode is set to On.

●

Photo Colour Gamut is displayed for photo content instead of Colour
Gamut.

- 92 -

Photo Colour Gamut

(Auto / sRGB / Adobe / Rec. 2020)

Auto:

Automatically adjusts the colour gamut according to the input signal.

sRGB:

Standard for sRGB

Adobe:

Standard for AdobeRGB

Rec. 2020:

Provides the suitable colour gamut for Rec. 2020.

●

This function is available only for photo content.

●

Not valid in the following conditions:

– Viewing Mode is set to the mode of Dolby Vision.

– 4K 120Hz Bypass Mode is set to On.

■ White Balance

R-Gain / G-Gain / B-Gain

Adjusts the white balance of bright red / green / blue components.

R-Cutoff / G-Cutoff / B-Cutoff

Adjusts the white balance of dark red / green / blue components.

More Detailed Adjustment

Adjusts more detailed items for White Balance.

Input Signal Level:

Adjusts the input signal level.

R-Gain / G-Gain / B-Gain:

Adjusts the detailed white balance of bright red / green / blue
components.

Reset to Defaults:

Resets items for More Detailed Adjustment.

Reset to Defaults

Resets White Balance to the default settings.

- 93 -

■ Colour Management

●

Not valid when 4K 120Hz Bypass Mode is set to On

R-Hue / R-Saturation / R-Luminance

Adjusts the picture hue / saturation / luminance of red areas.

G-Hue / G-Saturation / G-Luminance

Adjusts the picture hue / saturation / luminance of green areas.

B-Hue / B-Saturation / B-Luminance

Adjusts the picture hue / saturation / luminance of blue areas.

More Detailed Adjustment

Adjusts more detailed items for Colour Management.

C-Hue / M-Hue / Y-Hue:

Adjusts the picture hue of cyan / magenta / yellow areas.

C-Saturation / M-Saturation / Y-Saturation:

Adjusts the saturation of cyan / magenta / yellow areas.

C-Luminance / M-Luminance / Y-Luminance:

Adjusts the luminance of cyan / magenta / yellow areas.

Reset to Defaults:

Resets items for More Detailed Adjustment.

Reset to Defaults

Resets Colour Management to the default settings.

- 94 -

■ Gamma

Gamma

Switches the gamma curve.

●

Please note the numerical values are reference for the adjustment.

More Detailed Adjustment

Adjusts more detailed items for Gamma.

Input Signal Level:

Adjusts the input signal level.

Gain:

Adjusts the gain of gamma for selected signal level.

Reset to Defaults:

Resets items for More Detailed Adjustment.

Reset to Defaults

Resets Gamma to the default settings.

■ Dynamic HDR Effect

Dynamic HDR Effect

(On / Off)

Automatically adjusts the luminance according to an HDR video signal.

●

Not valid in the following conditions:

– Viewing Mode is set to the mode of Dolby Vision.

– 4K 120Hz Bypass Mode is set to On.

– Tonemap clipping is set to Clipping.

- 95 -

■ HDR Tonemap clipping

●

Not valid when 4K 120Hz Bypass Mode is set to On

Tonemap clipping

(Normal / Clipping)

Automatically controls tonemap with content meta data.

●

Not valid when Viewing Mode is set to Dolby Vision IQ or Dolby Vision

Dark

Clipping Threshold

Adjust clipping luminance (nit) of tonemap.

Reset to Defaults

Resets HDR Tonemap clipping to the default settings.

■ Reset to Defaults

Reset to Defaults

Resets Advanced Settings to the default settings.

- 96 -

Option Settings

Some features are not available on all models. Available menu items are displayed on your TV screen.

1. Display the menu with MENU, select Main Menu and press OK to access.

2. Select Picture > Option Settings and press OK to access.

3. Select one of the following items and press OK to access.

Input Lag / ALLM / NVIDIA Auto Game Mode / VRR / Film Cadence Mode

/ 1080p Pure Direct / 4K Pure Direct / 4K 120Hz Bypass Mode / 60Hz

Refresh Mode / HDMI Content Type / HDMI EOTF Type / EOTF Type /
HDMI Colorimetry Type / HDMI RGB Range / HDMI YCbCr Range

4. Set the item and press OK to store.

Input Lag

(Auto / Fast / Normal)

Provides suitable images for fast response signals when playing games.

●

To display a continuous record of time spent using Game Mode, set

Playing Time Display.

●

Not valid in the following conditions:

– TV mode

– 1080p Pure Direct is set to On.

– 4K Pure Direct is set to On.

– Viewing Mode is set to Game. (Input Lag is fixed to Fast.)

– Viewing Mode is set to Dolby Vision IQ.

– 4K 120Hz Bypass Mode is set to On.

– VRR is set to On. (Input Lag is fixed to Fast.)

ALLM

(On / Off)

Automatically switches the TV to Game Mode according to the ALLM
information when using this TV in single window mode.

●

For HDMI

●

Not valid in the following conditions:

– Multi window

– HDMI Auto Setting is set to Mode1.

– NVIDIA Auto Game Mode is set to On and some of NVIDIA PC

graphics cards supporting HDMI 2.1 VRR are detected. (ALLM is fixed
to On.)

- 97 -

NVIDIA Auto Game Mode

(On / Off)

Set to On to enable NVIDIA HDMI 2.1 gaming function.

●

For HDMI1 / 2

●

Not valid in multi window mode

VRR

(On / Off)

Provides smoother gaming experience with low latency and without image
stuttering or tearing. Set to On to enable VRR (Variable Refresh Rate) and
AMD FreeSync Premium function when the equipment supporting VRR / AMD
FreeSync Premium function is connected to this TV.

●

For HDMI1 / 2

●

Not valid in the following conditions:

– Multi window

– HDMI Auto Setting is set to Mode1 or Mode2.

– NVIDIA Auto Game Mode is set to On and some of NVIDIA PC

graphics cards supporting HDMI 2.1 VRR are detected. (ALLM is fixed
to On.)

Film Cadence Mode

(Auto / On / Off)

Improves vertical resolution for movie images.

●

This function is available for interlaced signals (except in the mode of multi
window, Network services or when Input Lag is set to Fast).

1080p Pure Direct

(On / Off)

Reproduces the original image quality in detail for 1080p (HDMI) input signal.

●

Not valid in the following conditions:

– Multi window

– Input Lag is set to Fast.

– Viewing Mode is set to the mode of Dolby Vision.

- 98 -

4K Pure Direct

(On / Off)

Reproduces the original image quality in detail for 4K (HDMI) input signal.

●

Not valid in the following conditions:

– Multi window

– Input Lag is set to Fast.

– Viewing Mode is set to the mode of Dolby Vision.

– 4K 120 Hz signal

4K 120Hz Bypass Mode

(On / Off)

Reproduces the original image quality in detail for 4K 120 Hz signal. Some
picture menu items are not available when 4K 120Hz Bypass Mode is set to

On.

●

For 4K 120 Hz signal (HDMI1 / HDMI2)

●

Not valid in the following conditions:

– Multi window

– Viewing Mode is set to the mode of Dolby Vision.

60Hz Refresh Mode

(On / Off)

Reduces the input lag when connecting 60Hz output game equipment.

●

For HDMI, AV

●

Not valid in the following conditions:

– 1080p Pure Direct is set to On.

– 4K Pure Direct is set to On.

– VRR is set to On.

– Multi window

- 99 -

HDMI Content Type

(Graphics / Photos / Auto / Off)

Adjusts the picture settings of each HDMI input according to the selected
content type.

Auto:

Automatically adjusts the picture settings according to the received
HDMI content if the connected equipment supports HDMI Content
Type.

●

To set the availability of each content type for Auto mode, select Auto

Detail Setting.

●

For HDMI

●

Not valid when Viewing Mode is set to Professional Photo or the mode of
Dolby Vision

HDMI EOTF Type

(Auto / Traditional gamma / HLG / PQ)

Selects the EOTF type for each HDMI input. Set to Auto for general use.

●

For HDMI

●

HDR10+ function is available when HDMI EOTF Type is set to Auto.

●

Not valid when Viewing Mode is set to the mode of Dolby Vision

EOTF Type

(Auto / Traditional gamma / HLG / PQ)

Selects the EOTF type of broadcast or video content.

It works correctly only when the signal corresponds to each EOTF type. Set to

Auto for general use.

●

Automatically switches to Auto for broadcast each time another input /
channel is selected.

●

For digital, video content

●

HDR10+ function is available when EOTF Type is set to Auto.

●

Not valid when Viewing Mode is set to the mode of Dolby Vision

- 100 -
