Owner’s Manual

Hospitality LCD HDTV

Model No.

TH-32LRU60
TH-39LRU60
TH-42LRU60
TH-50LRU60
TH-65LRU60

English

Thank you for purchasing this Panasonic product.
Please read these instructions before operating your set
and retain them for future reference. The images shown in
this manual are for illustrative purposes only.

TQB2AA0719E1

Experience an amazing level of
multimedia excitement

Enjoy rich multimedia

USB Flash Memory

VCR

Amplifier with

Speaker system

DVD Recorder/

Blu-ray Disc recorder

This product incorporates the following software:

(1) the software developed independently by or for Panasonic Corporation,
(2) the software owned by third party and licensed to Panasonic Corporation,
(3) open sourced software

The software categorized as (3) are distributed in the hope that it will be useful, but WITHOUT ANY WARRANTY, without even
the implied warranty of MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.

DVD Player/

Blu-ray Disc player

Camcorder

Personal computer

Cable box

2

HDMI, the HDMI logo and High­Definition Multimedia Interface are
trademarks or registered trademarks
of HDMI Licensing LLC in the United
States and other countries.

Energy Star is a joint program of
the US Environmental Protection
Agency and the U.S. Department of
Energy. It is administered in Canada
by Natural Resources Canada
(NRC) through the Office of Energy
Efficiency (OEE). This program is
helping to protect the environment
and save money through energy
efficient products and practices.
This product qualifies for ENERGY
STAR in the factory default setting
and this is the setting in which
energy savings will be achieved.
Any modifications to the factory
default setting could result in
greater energy consumption beyond
levels that meet ENERGY STAR
qualifications.

Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.

Pro: Idiom is a trademark of Zenith
Corporation.

Contents

Please read before using the unit

●

Safety Precautions ·········································4

Quick Start Guide

●

Accessories/Optional Accessory ···················· 7

●

Connections ················································· 11

●

Identifying Controls ······································ 15

Enjoy your TV!

Basic Features

●

Watching TV ················································· 16

●

Watching content from external devices ······17

●

Using Media Player ······································ 18

Quick Start

Guide

Viewing Advanced

Advanced Features

●

Guest Menu ················································· 19

Support Information

●

Ratings List for Lock ···································· 20

●

Technical Information ···································21

●

Troubleshooting ···········································25

●

Care and Cleaning ·······································27

●

Specifications ··············································· 28

●

Limited Warranty ··········································30

●

LIMITED WARRANTY STATEMENT ···········31

●

Customer Service ········································ 32

Information

Support

3

Safety Precautions

The lightning flash with arrowhead

CAUTION

RISK OF ELECTRIC SHOCK

WARNING: To reduce the risk of electric shock, do not remove cover or back.
No user-serviceable parts inside. Refer servicing to qualified service personnel.

DO NOT OPEN

Note to CATV System Installer

This reminder is provided to direct the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as
close to the point of cable entry as practical.

Secure Ventilation

Slots and openings in the cabinet and the back or bottom are provided for ventilation, and to ensure reliable operation of the LCD
TV and to protect it from overheating. These openings must not be blocked or covered. There should be at least 4 inches (10 cm)
of space around the TV. The openings should never be blocked by placing the LCD TV on a bed, sofa, rug or other similar surface.
This LCD TV should not be placed in a built-in installation such as a bookcase unless proper ventilation is provided.

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that
produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.

11) Only use attachments / accessories specified by the manufacturer.

12) Use only with the cart, stand, tripod, bracket or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury
from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.

15) Operate only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied
to your home consult your television dealer or local power
company.

16) Follow all warnings and instructions marked on the LCD TV.

17) Never push objects of any kind into this LCD TV through cabinet
slots as they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Never spill liquid
of any kind on the LCD TV.

18) If an outside antenna is connected to the television equipment,
be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges.
In the U.S. Section 810-21 of the National Electrical Code
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.

EXAMPLE OF ANTENNA
GROUNDING AS PER
(NEC) NATIONAL
ELECTRICAL
CODE

GROUND CLAMP

ELECTRIC
SERVICE
EQUIPMENT

POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)

4

within a triangle is intended to tell the
user that parts inside the product are a
risk of electric shock to persons.

The exclamation point within a
triangle is intended to tell the
user that important operating and
servicing instructions are in the
papers with the appliance.

ANTENNA
LEAD-IN WIRE

ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)

GROUNDING
CONDUCTORS
(NEC SECTION 810-21)

GROUND CLAMPS

19) An outside antenna system should not be located in the vicinity of overhead power lines, other electric light, power circuits,
or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits as contact with them might be fatal.

20) Unplug this LCD TV from the wall outlet and refer servicing to qualified service personnel under the following conditions:

a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the LCD TV.
c. If the LCD TV has been exposed to rain or water.
d. If the LCD TV does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as improper adjustment of other

e. If the LCD TV has been dropped or the cabinet has been damaged.
f. When the LCD TV exhibits a distinct change in performance - this indicates a need for service.

21) When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer
that have the same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock, or other
hazards.

22) WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN,

23) WARNING: SMALL PARTS CAN PRESENT CHOKING HAZARD IF ACCIDENTALLY SWALLOWED. KEEP SMALL

24) WARNING: To prevent the spread of fire, keep candles or other open flames away from this product at all

25) WARNING: Do not place this TV in any medical institutions or locations with medical devices.

26) WARNING: Do not use this TV near any automatic control devices such as automatic doors or fire alarms.

27) WARNING: Keep this TV away at least 9 inches (22 cm) from the location where a cardiac pacemaker is implanted.

28) CAUTION: The Power switch on this unit will not completely shut off all power from AC outlet. Since the power cord serves

29) CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS PLUG WITH A RECEPTACLE OR OTHER OUTLET

30) CAUTION: USE WITH OTHER STAND MAY RESULT IN INSTABILITY POSSIBLY CAUSING INJURY.

31) CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME

controls may result in damage and will often require extensive work by a qualified technician to restore the
LCD TV to normal operation.

MOISTURE, DRIPPING OR SPLASHING.
DO NOT PLACE LIQUID CONTAINERS (FLOWER VASES, CUPS, COSMETICS, ETC.) ABOVE THE SET
(INCLUDING ON SHELVES ABOVE, ETC.).

PARTS AWAY FROM YOUNG CHILDREN.
DISCARD UNNEEDED SMALL PARTS AND OTHER OBJECTS, INCLUDING PACKAGING MATERIALS
AND PLASTIC BAGS/SHEETS TO PREVENT THEM FROM BEING PLAYED WITH BY YOUNG CHILDREN,
CREATING THE POTENTIAL RISK OF SUFFOCATION.

times.

Radio waves from this TV may interfere with the medical devices and cause accidents due to the
malfunction.

Radio waves from this TV may interfere with the automatic control devices and cause accidents due to the
malfunction.

Radio waves from this TV may interfere with the operation of the pacemaker.

as the main disconnect device for the unit, you will need to unplug it from the AC outlet to shut down all power.
Therefore, make sure the unit has been installed so that the power cord can be easily unplugged from AC outlet
in case of an accident. To avoid fire hazard, the power cord should also be unplugged from the AC outlet when
left unused for a long period of time (for example, when on vacation).

UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

OR EQUIVALENT TYPE.

NOTE: This equipment is designed to operate in North America and other countries where the broadcasting system and AC

house current are exactly the same as in North America.

5

Safety Precautions (Continued)

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause
harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

FCC Caution:
To assure continued compliance, follow the attached installation instructions and use only shielded interface cables
when connecting to computer or peripheral devices. Any changes or modifications not expressly approved by
Panasonic Corp. of North America could void the user’s authority to operate this device.

Model No. TH-32LRU60, TH-39LRU60, TH-42LRU60, TH-50LRU60, TH-65LRU60

Responsible Party: Panasonic Corporation of North America

Contact Source: Panasonic System Communications Company of North America

FCC Declaration of Conformity

Two Riverfront Plaza, Newark, NJ 07102-5490

1-800-973-4390

CEA CHILD SAFETY NOTICES: Flat panel displays are not always supported on the proper stands or
installed according to the manufacturer’s recommendations. Flat panel displays that are inappropriately
situated on dressers, bookcases, shelves, desks, speakers, chests or carts may fall over and may cause
personal injury or even death.

The consumer electronics industry (of which Panasonic is a member) is committed to making home
entertainment enjoyable and safe. To prevent personal injury or death, be sure to follow the following safety
guidelines:

TUNE INTO SAFETY:

• One size does NOT fit all. Follow the
of your flat panel display.

• Carefully read and understand all enclosed instructions for proper use of this product.

• Don’t allow children to climb on or play with furniture and television sets.

• Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.

• Remember that children can become excited while watching a program, especially on “larger than life”

flat panel displays. Care should be taken to install the display where it cannot be pushed, pulled over,
or knocked down.

• Care sh

WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:

• Use a mount that has been recommended by the display manufacturer and/or listed by an independent

• Follow all instructions supplied by the display and wall mount manufacturers.

• If you have any doubts about your ability to safely install your flat panel display, contact your retailer

• Make sure the wall where you are moun

• A minimum of two people are required for installation. Flat panel displays can be heavy.

The American Academy of Pediatrics discourages media viewing for children younger than two
years. For more details, see www.aap.org.

ould be taken to route all cords and cables connected to the flat panel display so that they

cannot be pulled or grabbed by curious children.

laboratory (such as UL, CSA, ETL).

about professional installation.

designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure,
contact a professional installer.

manufacturer’s recommendations for the safe installation and use

ting the display is appropriate. Some wall mounts are not

6

Accessories/Optional Accessory

Accessories

Check you have all the items shown.

Accessories

Remote Control
Transmitter

N2QAYB000820

Optional Accessory

Wall-hanging bracket

Please contact a professional installer to purchase the recommended UL qualified wall-hanging bracket. For
additional details, please refer to the wall-hanging bracket installation manual.

Screw for fixing the TV onto the wall-hanging bracket
(not supplied with the TV)

Depth of screw:
(for 32 ”) M4
Minimum: 0.36 ” (9 mm)
Maximum: 0.66 ” (17 mm)
(for 39 ”) M6
Minimum: 0.40 ” (10 mm)
Maximum: 0.59 ” (15 mm)

(View from the side)

WARNING

Always be sure to ask a qualified technician to carry out set-up.
Do not mount the unit directly below ceiling lights (such as spotlights, floodlights or halogen lights) that typically give off

high heat. Doing so may warp or damage plastic cabinet parts.

Take care when fixing wall brackets to the wall. Always ensure that there are no electrical cables or pipes in the wall

before hanging bracket.
To prevent fall and injury, remove the TV from its fixed wall position when it is no longer in use.
Incorrect wall-hanging bracket or incorrect fitting may cause equipment to fall, resulting in injury and product damage.
Panasonic disclaims liability for any damage or injury arising from incorrect wall-hanging bracket, incorrect fitting or

otherwise failure to follow the above instructions.

Batteries for the
Remote Control
Transmitter (2)

AA Battery

Simple Owner’s Manual

(for 42 ”) M6
Minimum: 1.26 ” (32 mm)
Maximum: 1.53 ” (39 mm)
(for 50 ”) M6
Minimum: 0.44 ” (11 mm)
Maximum: 0.66 ” (17 mm)
(for 65 ”) M6
Minimum: 0.75 ” (19 mm)
Maximum: 0.82 ” (21 mm)

Pedestal
(For details, see
“Installing the TV.”)

(image)

Back of the TV

a

Holes for wall-hanging bracket
installation

b

Power cord

(for 32”)
a: 7.9” (200 mm)
b: 3.9” (100 mm)
(for 39”/42”)
a: 7.9” (200 mm)
b: 7.9” (200 mm)

(for 50”/65”)
a: 15.7” (400 mm)
b: 15.7” (400 mm)

Guide

Quick Start

Accessories/Optional Accessory

Installing the remote’s batteries

Caution

Incorrect installation may cause battery
leakage and corrosion, resulting in
damage to the remote control.

Do not mix old and new batteries.

•

Do not mix different battery types (such

•

as alkaline and manganese batteries).
Do not use rechargeable (Ni-Cd) batteries.

•

Do not burn or break batteries.

Hook

Open

Close

Note the correct polarity (+ or -).

Installing the TV

WARNING

These instructions are for use by qualified service personnel only. To reduce the risk of electric shock and injury do not
perform any servicing other than that contained in the operating instructions unless you are qualified to do so.
To prevent injury, this device must be properly secured to the furniture, which is installed on the floor or wall, in accordance
with the installation instructions for this device.

7

Accessories

Bracket (1)

TBL5ZA34841 (TH-32LRU60)
TBL5ZA34831 (TH-39LRU60)
TBL5ZA34811 (TH-42LRU60)
TBL5ZA34801 (TH-50LRU60)
TBL5ZA34611 (TH-65LRU60)

Assembly screws

Screws (4) Screws (4)

XYN4+F12FJK

size (M4 × 12)
( TH-32LRU60/

TH-39LRU60/
TH-42LRU60/
TH-50LRU60)

XYN4+F25FNK

size (M4 × 25)
(TH-65LRU60)

XSS5+12FNK

size (M5 × 12)
( TH-32LRU60/

TH-39LRU60/
TH-42LRU60)

XSS5+15FNK

size (M5 × 15)
( TH-50LRU60/

TH-65LRU60)

Base (1)

TBL5ZX07281 (TH-32LRU60)
TBL5ZX07321 ( TH-39LRU60/

TBL5ZX07381 (TH-50LRU60)
TBL5ZX07161 (TH-65LRU60)

TH-42LRU60)

Security screw (1) Security screw (1)

THE2AC004J
size (M4 × 12)
( TH-32LRU60/

TH-39LRU60/
TH-42LRU60/
TH-50LRU60)

Neck cover (1)

TBL2AB30081

( TH-32LRU60/TH-39LRU60/

TH-42LRU60)

THM2AA001N
size (M5 × 12)
(TH-32LRU60)

Screw (1) Screws (2) Screw (1)

THEC1509
size (M3 × 5)
( TH-32LRU60/

TH-39LRU60/
TH-42LRU60)

■

Assembling the pedestal

(1) Install securely with assembly screws . (Total 4 screws)
(2) The rotation angle can be set at 0°, 30°, 60° or 90°. Install

It is not necessary to install

Tighten screws firmly.
For TH-50LRU60/TH-65LRU60, only (1) is needed in “Assembling the pedestal”.

For TH-32LRU60, one of the screws can be
replaced with a security screw if necessary.

B

(3) Install neck cover.
(4) Install securely with an assembly screw .

Tighten screws firmly.

XVE6A10FJK
size (M6 × 10)
( TH-32LRU60/

TH-39LRU60/
TH-42LRU60)

screws if 90° angle rotation is desired.

B

F

XTB3+30AFJK
size (M3 × 30)
( TH-32LRU60/

TH-39LRU60/
TH-42LRU60/
TH-50LRU60)

screws to each angle control position.

Security screw (1)

THT2AA002J
size (M3 × 30)
( TH-32LRU60/

0°

F

30°

60°

E

TH-39LRU60/
TH-42LRU60/
TH-50LRU60)

Wood screws (4)

XTS5+20AFJK
( TH-32LRU60/

TH-39LRU60/
TH-42LRU60/
TH-50LRU60)

8

■

Set-up

Place the TV at a comfortable distance for viewing. Avoid placing it where sunlight or other bright light (including reflections)
will fall on the screen. Use of some types of fluorescent lighting can reduce remote control transmitter range. Adequate
ventilation is essential to prevent an internal component failure. Keep away from areas of excessive heat or moisture.

Install securely with assembly screws .

(Total 4 screws)
Tighten screws firmly.
For TH-65LRU60, only installing screws

is needed in “Set-up”.

Please visit the Panasonic website

about screw location template.

http://panasonic.net
Put the template where the TV is installed.

One of the screws

can be replaced

with a security screw

if necessary.

A

Quick Start

Guide

0.24 ”(6 mm)

Install screws through screw eyelid guide

as indicated on the template. (Total 4 screws)

Install the TV firmly to the desk using the

hole of bottom plate.

Screw location template

A screw can be replaced
with a security screw
necessary.

Install securely with an assembly screw .
Tighten screws firmly.

I

Insert

Slide

Bottom plate
screw hole

if

G

Accessories/Optional Accessory

9
