Panasonic TH-47LFP30W Operating Instructions

Operating Instructions

FULL HD LCD Display

Model No.

TH-42LFP30W
TH-47LFP30W

English

h

Please read these instructions before operating your set
and retain them for future reference.

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that you will have many years of
enjoyment from your new LCD Display.
To obtain maximum benefit from your set, please read these Instructions before making
any adjustments, and retain them for future reference.
Retain your purchase receipt also, and note down the model number and serial number of
your set in the space provided on the rear cover of these instructions.
Visit our Panasonic Web Site http://panasonic.net

ii

Precautions for Installation

• Do not install by yourself. Please ask a installation professional or your dealer to install.

• This product complies with IP66 dust and water protection standard. Do not change or damage dust or water
resistance of the product.

• Please note the dust and water resistance of this product does not guarantee damage or fault free.

Using with dust or water resistance degraded causes fire, electric shock, or

CAUTION

This product complies with international standard IP rating (Ingress Protection) dust ingress protection level 6 and
water ingress protection level 6.

product damage.

Precautions for handling pressure-adjusting caps

Do not loosen or remove the pressure-adjusting caps (2) for the terminal cover.
This will damage the cabinet airtightness.

Do not block the ventilation such as covering the pressure-adjusting caps.

• The pressure-adjusting caps are used to adjust the air pressure inside of the product.

Special material is used so that they let air pass but not liquid such as water.

Terminal cover

After connecting cable etc. of the device to the terminals, check if the terminal cover is sealed correctly and closed
fi rmly using all the fi xing screws when attaching the terminal cover.
To seal the terminal cover correctly, be aware of the following points:

Check if the fi xing sealant is fi xed in the correct position in the cover. Fixing sealant is an important part to
seal the cable part.

Terminal part on
main unit rear side

Fixing sealant

Terminal cover rear side

Pressure-adjusting caps

Terminal cover

Fixing sealant

Stick the cable to the shape of the dent on the terminal strip base tightly.

Fixing sealant

●

The structure is to keep the airtightness
by tucking the cable pulled out along the
dent on the terminal strip base with both
fixing sealant of the terminal strip base
and terminal cover.

iii

Precautions for Installation

Power cable

To keep the waterproof property, do not loosen the part fi xing
the power cable to the rear plate.

Do not force to bend the protruding part of the power cable.
This may cause disconnection.

Protective coating

Cabinet aluminum parts and rear plate are protected from corrosion wth coating. Be careful not to damage
the surface. In case the surface is damaged, corrosion may occur from there.

Installation position

Do not install the product to a place where the product is exposed to direct sunlight.

• If the screen is exposed to direct sunlight, the liquid crystal panel may have adverse effect.

• When direct sunlight is on the screen, black shadow may appear. This will disappear when the temperature
drops.

• To avoid direct sunlight, installing a “canopy” above this product is recommended.

• To install the product long term in a special environment such as near a swimming pool, hot spring, or ocean, or in
a factory uses chemicals or gases, please consult your local Panasonic dealer beforehand.

Installation conditions

To use the product in an environment where outdoor air temperature is lower than 39 °F (4 °C), make sure
to set the “Winter Mode” to “On”. The inside temperature is kept constant and the startup can be performed
smoothly. (see page 42)

Do not exhibit or use this product in a condition where water splashes on to it continuously for long time.

To install on a wall etc.

• Consult your dealer about fi ttings etc. beforehand.

• Choose a permanent position where the total weight of the product and fi ttings can be hold permanently. If the
strength of the position is not suffi cient, a serious accident such as fall may be caused.

• Do not install the product where a person can be hang or lean on, or a passer may collide into. Accident may be
caused.

• Take measures for tipping over and fall with an assumption of a fi tting or installation location failure.

• Installation strength may be degraded due to aging depends on the environment. Ask a installation professional to
inspect or repair regularly.

• When an abnormality or fault such as loose screw is detected, ask an installation professional or your dealer
immediately for repair.

• Panasonic will not be responsible for any damages from an accident such as defect of installation, improper use,
modifi cation, or natural disaster.

iv

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING: To reduce the risk of electric shock, do not remove cover or back.
No user-serviceable parts inside. Refer servicing to qualifi ed service personnel.

The lightning flash with
arrow-head within a triangle
is in tend ed to tell the user
that parts inside the product
are a risk of electric shock
to per sons.

The exclamation point within
a triangle is intended to
tell the user that important
operating and servicing
instructions are in the papers
with the ap pli ance.

WARNING : To prevent damage which may result in fi re or shock hazard, do not expose this apparatus to rain

or mois ture.
Do not place containers with water (fl ower vase, cups, cosmetics, etc.) above the set.
(including on shelves above, etc.)

WARNING : 1) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to

qualifi ed service personnel.

2) Do not remove the grounding pin on the power plug. This apparatus is equipped with a three pin
grounding-type power plug. This plug will only fi t a grounding-type power outlet. This is a safety fea ture.
If you are unable to insert the plug into the outlet, contact an electrician.

Do not defeat the purpose of the grounding plug.

This ENERGY STAR mark is applicable in USA only.

As an ENERGY STAR® Partner, Panasonic has determined that this product meets the
ENERGY STAR

®

guidelines for energy effi ciency.

v

Important Safety Instructions

1) Read these instructions.

2) Keep these instructions.

3) Heed all warnings.

4) Follow all instructions.

5) Do not use this apparatus near water.

6) Clean only with dry cloth.

7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.

8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifi ers) that produce heat.

9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the provided plug does not fi t into your outlet, consult an
electrician for replacement of the obsolete outlet.

10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.

11) Only use attachments / accessories specifi ed by the manufacturer.

12) Use only with the cart, stand, tripod, bracket, or table specifi ed by the manufacturer, or sold with
the apparatus. When a cart is used, use caution when moving the cart / apparatus combination
to avoid injury from tip-over.

13) Unplug this apparatus during lightning storms or when unused for long periods of time.

14) Refer all servicing to qualifi ed service personnel. Servicing is required when the apparatus has been damaged
in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.

15) To prevent electric shock, ensure the grounding pin on the AC cord power plug is securely connected.

vi

FCC STATEMENT

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced technician for help.

This device complies with Part15 of the FCC Rules. Operation is subject to the following two conditions:(1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.

FCC CAUTION:
To assure continued compliance, follow the attached installation instructions and use only shielded
interface cables when connecting to computer or peripheral devices. Any changes or modifi cations not
expressly approved by Panasonic Corp. of North America could void the user's authority to operate this
device.

FCC Declaration of Conformity

Model No. TH-42LFP30W, TH-47LFP30W

Responsible Party: Panasonic Corporation of North America
Three Panasonic Way 2F-5, Secaucus, NJ 07094
Contact Source: Panasonic Solutions Company
Panasonic Plasma Concierge 1-800-973-4390

CANADIAN NOTICE:

This Class B digital apparatus complies with Canadian ICES-003.

vii

Important Safety Notice

IMPORTANT: THE MOULDED PLUG

WARNING

1) No naked fl ame sources, such as lighted candles, should be placed on / above the set.

2) To prevent electric shock, do not remove cover. No user serviceable parts inside. Refer servicing to qualifi ed
service personnel.

3) Do not remove the earthing pin on the power plug. This apparatus is equipped with a three pin earthing-type
power plug. This plug will only fi t an earthing-type power outlet. This is a safety feature. If you are unable to
insert the plug into the outlet, contact an electrician.

Do not defeat the purpose of the earthing plug.

4) To prevent electric shock, ensure the earthing pin on the AC cord power plug is securely connected.

CAUTION

This appliance is intended for use in environments which are relatively free of electromagnetic fi elds.
Using this appliance near sources of strong electromagnetic fi elds or where electrical noise may overlap with the
input signals could cause the picture and sound to wobble or cause interference such as noise to appear.
To avoid the possibility of harm to this appliance, keep it away from sources of strong electromagnetic fi elds.

FOR YOUR SAFETY, PLEASE READ THE FOLLOWING TEXT CAREFULLY.

This display is supplied with a moulded three pin mains plug for your safety and convenience. A 10 amp fuse is
fi tted in this plug. Shall the fuse need to be replaced, please ensure that the replacement fuse has a rating of 10
amps and that it is approved by ASTA or BSI to BS1362.

Check for the ASTA mark

If the plug contains a removable fuse cover, you must ensure that it is refi tted when the fuse is replaced.
If you lose the fuse cover the plug must not be used until a replacement cover is obtained.
A replacement fuse cover can be purchased from your local Panasonic dealer.

Do not cut off the mains plug.
Do not use any other type of mains lead except the one supplied with this display.
The supplied mains lead and moulded plug are designed to be used with this display to avoid
interference and for your safety.
If the socket outlet in your home is not suitable, get it changed by a qualifi ed electrician.
If the plug or mains lead becomes damaged, purchase a replacement from an authorized dealer.

WARNING : — THIS DISPLAY MUST BE EARTHED.

How to replace the fuse.

IMPORTANT: THE MOULDED PLUG

or the BSI mark on the body of the fuse.

ASA

Open the fuse compartment with a screwdriver and replace the fuse.

viii

Table of Contents

Precautions for Installation .................................... iii

Important Safety Instructions ................................. vi

FCC STATEMENT .................................................... vii

Important Safety Notice ........................................ viii

Safety Precautions ................................................... 2

Accessories .............................................................. 5

Accessories Supply ................................................. 5

Remote Control Batteries ........................................ 5

About Power Supply Cord ....................................... 6

Connections .............................................................. 7

AC cord connection ................................................. 7

How to remove terminal cover ................................. 7

Video equipment connection ................................... 8

VIDEO and COMPONENT / RGB IN connection .... 9

HDMI connection ................................................... 10

DVI-D IN connection .............................................. 10

PC Input Terminals connection ...............................11

SERIAL Terminals connection ............................... 12

Power On / Off ......................................................... 13

Selecting the input signal ...................................... 15

Basic Controls ........................................................ 16

ASPECT Controls ................................................... 18

Digital Zoom ............................................................ 19

On-Screen Menu Displays ..................................... 20

Adjusting Pos. /Size ............................................... 22

Picture Adjustments ............................................... 24

Advanced settings ................................................. 25

Sound Adjustment .................................................. 26

PRESENT TIME Setup / Set up TIMER .................. 27

PRESENT TIME Setup .......................................... 27

Set up TIMER ........................................................ 28

Screensaver (For preventing image retention) .... 29

Setup of Screensaver Time ................................... 30

Wobbling ................................................................. 30

Reduces power consumption ............................... 31

Customizing the Input labels ................................. 32

Selecting the On-Screen Menu Language ............ 33

Customizing the On-Screen Menu Display .......... 33

Setup for MULTI DISPLAY ...................................... 34

How to Setup MULTI DISPLAY ............................. 34

Setup for Input Signals .......................................... 36

Component / RGB-in select ................................... 36

Signal menu .......................................................... 37

3D Y/C Filter .......................................................... 37

Colour system ....................................................... 38

Cinema reality ....................................................... 38

XGA Mode ............................................................. 38

Noise reduction ..................................................... 39

Sync ...................................................................... 39

Input signal display ................................................ 40

Options Adjustments ............................................. 41

Troubleshooting ..................................................... 43

Applicable Input Signals ........................................ 44

Shipping condition ................................................. 46

Specifi cations ......................................................... 47

Trademark Credits

• VGA is a trademark of International Business Machines Corporation.

• Macintosh is a registered trademark of Apple Inc., USA.

• SVGA, XGA, SXGA and UXGA are registered trademarks of the Video Electronics Standard Association.
Even if no special notation has been made of company or product trademarks, these trademarks have been fully respected.

• HDMI, the HDMI Logo, and High-Defi nition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other countries.

Note:

Image retention may occur. If you display a still picture for an extended period, the image might remain on the screen.
However, it will disappear after a while.

1

Safety Precautions

WARNING

Setup

Always be sure to ask a qualifi ed technician to carry out set-up.

Small parts can present choking hazard if accidentally swallowed. Keep small parts away from young children. Discard
unneeded small parts and other objects, including packaging materials and plastic bags/sheets to prevent them from
being played with by young children, creating the potential risk of suffocation.

Do not place any objects on top of the Display.

• If any foreign objects get inside the Display, please consult your local Panasonic dealer.

Transport only in upright position!

• Transporting the unit with its display panel facing upright or downward may cause damage to the internal
circuitry.

Releasing heat should not be impeded by covering the surface of this display with items such as newspapers,
table cloths and curtains.

For suffi cient heat release;
Leave a space of 3 15/16” (10 cm) or more at the top, left and right, and 1 31/32” (5 cm) or more at the rear, and
also keep the space between the bottom of the display and the fl oor surface.

• This product has a structure to let the heat out from the cabinet surface.

• Use the product within the operating condition temperature range.

Cautions for Wall Installation

• Wall installation should be performed by an installation professional. Installing the Display incorrectly may lead to
an accident that results in death or serious injury. Furthermore, when installing on a wall, a wall hanging bracket
that conforms to VESA standards (VESA 400 × 400) must be used.

• When installing the Display vertically, turn up the power indicator for the upward direction.

2

Safety Precautions

When using the LCD Display

The Display is designed to operate on 110 - 127 or 220 - 240 V AC, 50/60 Hz.

Attach the terminal cover fi rmly to use.

• Otherwise the dust and water resistance is damaged and may cause fi re, electric shock or product damage.

Do not stick any foreign objects into the Display.

• Do not insert any metal or fl ammable objects into the Display or drop them onto the Display, as doing so can cause
fi re or electric shock.

Do not remove the cover or modify it in any way.

• High voltages which can cause severe electric shocks are present inside the Display. For any inspection, adjustment
and repair work, please contact your local Panasonic dealer.

Ensure that the mains plug is easily accessible.

An apparatus with CLASS I construction shall be connected to a mains socket outlet with a protective earthing connection.

Do not use any power supply cord other than that provided with this unit.

• Doing so may cause fi re or electric shocks.

Securely insert the power supply plug as far as it will go.

• If the plug is not fully inserted, heat may be generated which could cause fi re. If the plug is damaged or the wall
socket is loose, they shall not be used.

Do not handle the power supply plug with wet hands.

• Doing so may cause electric shocks.

Do not do anything that may damage the power cable. When disconnecting the power cable, pull on the plug body, not the cable.

• Do not damage the cable, make any modifi cations to it, place heavy objects on top of it, heat it, place it near any
hot objects, twist it, bend it excessively or pull it. To do so may cause fi re and electric shock. If the power cable is
damaged, have it repaired at your local Panasonic dealer.

If the Display is not going to be used for any prolonged length of time, unplug the power supply plug from
the wall outlet.

To prevent the spread of fi re, keep candles or other open fl ames away from this product at all times.

If problems occur during use

If a problem occurs (such as no picture or no sound), or if smoke or an abnormal odour starts to come out
from the Display, immediately unplug the power supply plug from the wall outlet.

• If you continue to use the Display in this condition, fi re or electric shock could result. After checking that the smoke
has stopped, contact your local Panasonic dealer so that the necessary repairs can be made. Repairing the Display
yourself is extremely dangerous, and shall never be done.

If foreign objects get inside the Display, if the Display is dropped, or if the cabinet becomes damages, disconnect
the power supply plug immediately.

•

A short circuit may occur, which could cause fi re. Contact your local Panasonic dealer for any repairs that need to be made.

3

Safety Precautions

CAUTION

When using the LCD Display

Be sure to disconnect all cables before moving the Display.

• If the Display is moved while some of the cables are still connected, the cables may become damaged, and fi re or
electric shock could result.

Disconnect the power supply plug from the wall socket as a safety precaution before carrying out any
cleaning.

• Electric shocks can result if this is not done.

Clean the power cable regularly to prevent it becoming dusty.

• If dust built up on the power cord plug, the resultant humidity can damage the insulation, which could result in fi re.
Pull the power cord plug out from the wall outlet and wipe the mains lead with a dry cloth.

Do not burn or breakup batteries.

• Batteries must not be exposed to excessive heat such as sunshine, fi re or the like.

Power supply

• Install the product near an electrical outlet so that the plug can be unplugged immediately when an abnormality
occurs.

• For a wall installation, used a power outlet which can be unplugged immediately when an abnormality occurs.

• This product is energized when the power plug is inserted to a socket. To cut off the power completely, the power
plug must be unplugged from the socket.

Cabinet

• Corner part of the metal cabinet is a potential injury hazard.

• To lift the product, hold the handles for the precaution of fall. Injury or damage may be caused.

Cleaning and maintenance

The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning
cloth or a soft, lint-free cloth.

• If the surface is particularly dirty, wipe with a soft, lint-free cloth which has been soaked in pure water or water in
which neutral detergent has been diluted 100 times, and then wipe it evenly with a dry cloth of the same type until
the surface is dry.

• Do not scratch or hit the surface of the panel with fi ngernails or other hard objects, otherwise the surface may
become damaged. Furthermore, avoid contact with volatile substances such as insect sprays, solvents and thinner,
otherwise the quality of the surface may be adversely affected.

If the cabinet becomes dirty, wipe it with a soft, dry cloth.

• If the cabinet is particularly dirty, soak the cloth in water to which a small amount of neutral detergent has been
added and then wring the cloth dry. Use this cloth to wipe the cabinet, and then wipe it dry with a dry cloth.

• Do not allow any detergent to come into direct contact with the surface of the Display. If water droplets get inside
the unit, operating problems may result.

• Avoid contact with volatile substances such as insect sprays, solvents and thinner, otherwise the quality of the
cabinet surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods
in contact with articles made from rubber or PVC.

4

Accessories

Accessories Supply

Check that you have the accessories and items shown

Operating Instruction book

Power supply cord

Main plug types vary between countries. Make sure to use the power supply cord
with the voltage and shape appropriate to your country and region. (see page 6)

CD-ROM
(Operating
instructions)

Remote Control
Transmitter
N2QAYB000535

Note:

Remote Control Transmitter is not water
protection type.

Remote Control Batteries

Batteries for the Remote
Control Transmitter
(R6 (UM3) Size × 2)

Requires two R6 batteries.

1. Pull and hold the hook, then open
the battery cover.

2. Insert batteries - note correct
polarity ( + and -).

“R6 (UM3)” size

-

+

+

-

3. Replace the cover.

Helpful Hint:

For frequent remote control users, replace old batteries with Alkaline
batteries for longer life.

Precaution on battery use

Incorrect installation can cause battery leakage and corrosion that will damage the remote control transmitter.
Disposal of batteries should be in an environment-friendly manner.

Observe the following precaution:

1. Batteries shall always be replaced as a pair. Always use new batteries when replacing the old set.

2. Do not combine a used battery with a new one.

3. Do not mix battery types (example: “Zinc Carbon” with “Alkaline”).

4. Do not attempt to charge, short-circuit, disassemble, heat or burn used batteries.

5.

Battery replacement is necessary when remote control acts sporadically or stops operating the Display set.

6. Do not burn or breakup batteries.
Batteries must not be exposed to excessive heat such as sunshine, fi re or the like.

5

Accessories

About Power Supply Cord

Main plug types vary between countries. Check the shape of the power plugs to choose the appropriate cable for
you.

Asia

Country Name Appropriate AC Cables

India
Indonesia
Philippine
Malaysia
Singapore
Hong Kong

Middle East

United Arab Emirates
Iraq
Iran
Oman
Syria
Lebanon
Qatar
Kuwait
Saudi Arabia

Africa

Egypt

South Africa

Middle/South America

Uruguay
Ecuador
Colombia
Chili
Panama
Paraguay
Puerto Rico
Venezuela
Peru
Bolivia
Honduras

North America

USA
Canada

Europe

Italy
Austria
Netherlands
Greece
Switzerland
Sweden
Spain
Czech
Denmark
Germany
Norway
Hungary
Finland
France
Bulgaria
Belgium
Portugal
Poland
Monaco
Luxembourg
Russia
Kazakhstan
Ukraine
Belarus
UK Cable C

Oceania

Australia
New Zealand

Cable B or Cable C

Cable C

Cable B or Cable C

Cable C

Cable B or Cable CEthiopia

Cable A or Cable B

Caution:

110-127 V AC: Cable A is adaptable
220-240 V AC: Cable B is adaptable

Cable A (110-127 V AC Compatible)

Cable B

Cable D

Cable A

Plug Type : A

Cable B

Plug Type : SE

D

FI

S

16A 250V~

N

Cable C

Plug Type : BF

Cable D

Plug Type : O

NL

10A 250V~

NL

Insulating sleeve

6

Connections

AC cord connection

Connect the AC cord

Line up and push together connectors A and B
so they are tight and then twist C until A and B
cannot be pulled apart.

A

C

B

Disconnect the AC cord

Unscrew C and pull connector A and B apart.

C

Note:

When disconnecting the AC cord, be
absolutely sure to disconnect the AC
cord plug at the socket outlet first.

A

B

How to remove terminal cover

To remove the terminal cover to connect a cable or other item, remove all 12 screws in bottom, middle, then top order
to prevent the terminal cover dropping off. Opening the terminal cover with some screws left on damages the terminal
cover.

Remove the screws (12) to
take out the terminal cover.

Notes:

• After connection, check the cable is pulled out along the groove without overlapping, then tighten the all 12 screws
to attach the terminal cover correctly. Otherwise water enters inside and causes fi re, electric shock and product
damage.

• Water-proof washer is used for one screw with marked. To attach the terminal cover, let the water-proof washer
through to attach the marked screw.

• Make sure to read the “Terminal cover” (page iii) section for the correct handling of the terminal cover to use the
product properly.

7

Connections

Video equipment connection

COMPONENT/RGB IN

Component/RGB
Video Input Terminal
(see page 9)

PC IN
PC Input Terminal
(see page 11)

DVI-D IN

DVI-D Input Terminal
(see page 10)

AV IN

HDMI1, HDMI2
HDMI Input Terminal
(see page 10)

Remove the terminal
cover

EXT SP

Speaker output terminal

Black

Red

While pressing
the lever, insert
the core wire.

Black

SERIAL

Control the Display by
connecting to PC
(see page 12)

AV IN

VIDEO
Composite Video Input

(see page 9)

Terminal

Red

Return the lever.

8

Connections

VIDEO and COMPONENT / RGB IN connection

Note:

Additional equipment, cables and adapter plugs shown are not supplied with this set.

VCR

AUDIO OUT

L

DVD Player

VIDEO OUT

R

RCA-BNC
Adapter plug

Notes:

• Change the “Component/RGB-in
select” setting in the “Setup” menu to
“Component” (when Component signal
connection) or “RGB” (when RGB signal
connection). (see page 36)

• Accepts only RGB signals from
COMPONENT/RGB IN terminal with
“Sync on G”.

RCA-BNC
Adapter plug

B PR OUT

Y P

RGB OUT

Computer RGB Camcorder

AUDIO OUT

RL

DVD Player

9

Connections

HDMI connection

[Pin assignments and signal names]

Pin No.

Signal Name

1

T.M.D.S Data2+

T.M.D.S Data2

2

Shield

3

T.M.D.S Data2-

4

T.M.D.S Data1+
T.M.D.S Data1

5

Shield

6

T.M.D.S Data1-

7

T.M.D.S Data0+
T.M.D.S Data0

8

Shield

9

T.M.D.S Data0-

10

T.M.D.S Clock+

Pin No.

11

12

13

14

15
16

17

18
19

T.M.D.S Clock
Shield

T.M.D.S Clock-

CEC

Reserved
(N.C. on device)

SCL
SDA
DDC/CEC

Ground
+5V Power
Hot Plug Detect

Signal Name

DVD player

HDMI

AV OU T

DVD player

HDMI

AV OU T

HDMI cables

2

4

18

3

1

19

Note:

Additional equipment and HDMI cable shown are not supplied with this set.

DVI-D IN connection

PC with DVI-D
video out

DVI-video cable with Ferrite core
(Within 5 m)

Stereo mini plug (M3)

DVI-D Input Connector
Pin Layouts

24

16

8

Connection port view

17

9

1

Pin No.

Signal Name

T.M.D.S. data 2-

1

T.M.D.S. data 2+

2

T.M.D.S. data 2 shield

3
4
5

DDC clock

6

DDC data

7
8

T.M.D.S. data 1-

9

T.M.D.S. data 1+

10

T.M.D.S. data 1 shield

11
12 24

Pin No.

13
14
15
16
17
18
19
20
21
22
23

Signal Name

+5 V DC
Ground
Hot plug detect
T.M.D.S. data 0­T.M.D.S. data 0+
T.M.D.S. data 0 shield

T.M.D.S. clock shield
T.M.D.S. clock+
T.M.D.S. clock-

Notes:

• Additional equipment and cables shown are not supplied with this set.

• Use the DVI-D cable with Ferrite core complying with the DVI standard. Image deterioration may occur depending
on the length or the quality of the cable.

Shared with
PC IN.

10

PC Input Terminals connection

Connections

(Female)

Shared with
DVI-D IN.

COMPUTER

Conversion adapter
(if necessary)

Connect a cable which matches
the audio output terminal on the computer.

Audio

RGB

PC cable with
Ferrite core

Stereo mini plug (M3)

Mini D-sub 15p

(Male)

Notes:

• Computer signals which can be input are those with a horizontal scanning frequency of 30 to 110 kHz and vertical scanning
frequency of 48 to 120 Hz. (However, the image will not be displayed properly if the signals exceed 1,200 lines.)

• The display resolution is a maximum of 1,440 × 1,080 dots when the aspect mode is set to “4:3”, and 1,920 × 1,080
dots when the aspect mode is set to “16:9”. If the display resolution exceeds these maximums, it may not be possible
to show fi ne detail with suffi cient clarity.

• The PC input terminals are DDC2B-compatible. If the computer being connected is not DDC2B-compatible, you will
need to make setting changes to the computer at the time of connection.

• Some PC models cannot be connected to the set.

• There is no need to use an adapter for computers with DOS/V compatible Mini D-sub 15P terminal.

• The computer shown in the illustration is for example purposes only.

• Additional equipment and cables shown are not supplied with this set.

• Panasonic recommends using a PC cable that includes a Ferrite core.

• Do not set the horizontal and vertical scanning frequencies for PC signals which are above or below the specifi ed
frequency range.

• Component Input is possible with the pin 1, 2, 3 of the Mini D-sub 15P Connector.

Signal Names for Mini D-sub 15P Connector

Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name

1514131211

67839

1

2

10

45

Pin Layout for PC Input
Terminal

1

2

3

4

NC (not connected)

5

GND (Ground)

R

G

B

6

7

8

9

10

GND (Ground)

GND (Ground)

GND (Ground)

+5 V DC

GND (Ground)

11

NC (not connected)

12

13

14

15

HD/SYNC

SDA

VD

SCL

11

Connections

SERIAL Terminals connection

The SERIAL terminal is used when the Display is controlled by a computer.

COMPUTER

RS-232C Straight cable

(Female)

D-sub 9p

Notes:

• Use the RS-232C straight cable to connect the computer to the Display.

• The computer shown is for example purposes only.

• Additional equipment and cables shown are not supplied with this set.

The SERIAL terminal conforms to the RS-232C interface
specifi cation, so that the Display can be controlled by a
computer which is connected to this terminal.

Signal names for D-sub 9P connector

Pin No. Details

The computer will require software which allows the
sending and receiving of control data which satisfies
the conditions given below. Use a computer application
such as programming language software. Refer to the
documentation for the computer application for details.

Communication parameters

Signal level RS-232C compliant

Synchronization method Asynchronous

Baud rate 9600 bps

Parity None

Character length 8 bits

Stop bit 1 bit

Flow control -

Basic format for control data

These signal names are those of computer specifi cations.

Command

Command Parameter Control details
PON None Power ON
POF None Power OFF
AVL ** Volume 000 - 100

AMT

IMS None

The transmission of control data from the computer
starts with a STX signal, followed by the command, the
parameters, and lastly an ETX signal in that order. If there
are no parameters, then the parameter signal does not
need to be sent.

STX C1 C2 C3 P1 P2 P3 P4: P5 ETX

Colon Parameter(s)
Start
(02h)

3-character
command (3 bytes)

(1 - 5 bytes)

End
(03h)

DAM None

Notes:

• If multiple commands are transmitted, be sure to wait for
the response for the fi rst command to come from this unit

With the power off, this display responds to PON command
only.

before sending the next command.

• If an incorrect command is sent by mistake, this unit will
send an “ER401” command back to the computer.

• Consult an Authorized Service Center for detail instructions
on command usage.

1 3 4 5 2

6 7 8 9

Pin layout for SERIAL Terminal

(Male)

2
3
5

4

6

•
7
8

1

9

•

0 Audio MUTE OFF
1 Audio MUTE ON

AV1
AV2

HM1
HM2
DV1
PC1

ZOOM
FULL
NORM
ZOM2

(Shorted in this set)

Input select (toggle)
VIDEO input (VIDEO)
COMPONENT/RGB IN input
(Component)
HDMI1 input (HDMI1)
HDMI2 input (HDMI2)
DVI-D IN input (DVI)
PC IN input (PC)

Screen mode select (toggle)
Zoom1
16:9
4:3
Zoom2

R X D
T X D

GND

Non use

NC

12

Power On / Off

Connecting the AC cord plug to the Display. (see page 7)

Connecting the plug to the Wall Outlet

Notes:

• Main plug types vary between countries. The power
plug shown at right may, therefore, not be the type
fi tted to your set. (see page 6)

• When disconnecting the AC cord, be absolutely
sure to disconnect the AC cord plug at the socket
outlet fi rst.

Press the Power switch on the Display to turn the
set on: Power-On.

Power Indicator: Green

Press the button on the remote control to turn the Display off.

Power Indicator: Red (standby)

Power switch

Power Indicator

Remote Control
Sensor

Press the button on the remote control to turn the Display on.

Power Indicator: Green

Turn the power to the Display off by pressing the switch on the unit, when
the Display is on or in standby mode.

Note:

During operation of the power management function, the power indicator turns
orange in the power off state.

13

Power On / Off

When fi rst switching on the unit

Following screen will be displayed when the unit is turned on for the fi rst time.
Select the items with the remote control. Unit buttons are invalid.

OSD Language

1

Select the language.

2

Set.

PRESENT TIME Setup

1

Select “DAY” or “PRESENT TIME”.

2

Setup “DAY” or “PRESENT TIME”.

OSD Language

English (UK)

Deutsch

Français

Italiano

Español

ENGLISH (US)

PRESENT TIME Setup

PRESENT TIME MON 99 : 99

Set
DAY
PRESENT TIME

MON

99 : 99

1

Select “Set”.

2

Set.

PRESENT TIME Setup

PRESENT TIME MON 99 : 99

Set
DAY
PRESENT TIME

No activity power off

To enable No activity power off, select “Enable”.

1

2

Set.

No activity power off

Display will be turned off
when there is no activity for 4 hours.

If selecting “Enable”, a

“Select “Yes” or “No”.

1

Set.

2

confi rmation window appears.

No activity power off

Are you sure
you want to enable ’No activity power off’ ?

Notes:

• Once the items are set, the screens won't be displayed when switching on the unit next time.

• After the setting, the items can be changed in the following menus.
OSD Language (see page 33)
PRESENT TIME Setup (see page 27)
No activity power off (see page 31)

TUE

10 : 00

DisableEnable

NoYes

Power ON warning message

The following message may be displayed when turning the unit power ON:

No activity power off Precautions

’No activity power off’ is enabled.

If “No activity power off” in Setup menu is set to “Enable”, a warning message is displayed every time
the power is turned ON. (see page 31)
This message display can be set with the following menu: Options menu

Power On Message (see page 42)

14

Selecting the input signal

Press to select the input signal to be played back from the equipment which has
been connected to the Display.

Input signals will change as follows:

PC HDMI1 HDMI2 Component*VIDEODVI

PC: PC input terminal in PC IN.
DVI: DVI input terminal in DVI-D IN.
HDMI1: HDMI input terminal in AV IN (HDMI1).
HDMI2: HDMI input terminal in AV IN (HDMI2).
VIDEO: Video input terminal in AV IN (VIDEO/S-VIDEO).
Component*: Component or RGB input terminal in COMPONENT/RGB IN.
* “Component” may be displayed as “RGB” depending on the setting of

“Component/RGB-in select”. (see page 36)

Notes:

• Selecting is also possible by pressing the INPUT button on the
unit.

• Select to match the signals from the source connected to the
component/RGB input terminals. (see page 36)

15

Basic Controls

Main Unit

Remote control
sensor

Brightness Sensor

Detects the brightness in the viewing
environment.

Power Indicator

The Power Indicator will light.

• Power-OFF .... Indicator not illuminated (The unit

will still consume some power
as long as the power cord is still
inserted into the wall outlet.)

• Standby ........ Red

• Power-ON ...... Green

• Power management (DPMS)

.......................Orange (PC IN or DVI-D IN

signal. See page 31)

Enter / Aspect button

(see page 18, 20)

Volume Adjustment

Volume Up “+” Down “–”
When the menu screen is displayed:
“+” : press to move the cursor up
“–” :

press to move the cursor down

(see page 20)

16

Main Power On / Off Switch

INPUT button
(INPUT signal selection)

(see page 15)

MENU Screen ON / OFF

Each time the MENU button is pressed, the menu screen
will switch. (see page 20)

Normal Viewing Picture

Sound Pos. /Size Setup

Basic Controls

Remote Control Transmitter

ACTION button

Press to make selections.

ASPECT button

Press to adjust the aspect.
(see page 18)

Standby (ON / OFF) button

The Display must fi rst be plugged into
the wall outlet and turned on at the
power switch (see page 13).
Press this button to turn the Display On,
from Standby mode. Press it again to
turn the Display Off to Standby mode.

POS. /SIZE button

(see page 22)

PICTURE button
(see page 24)

Sound mute On / Off
Press this button to mute the
sound.
Press again to reactivate sound.
Sound is also reactivated when
power is turned off or volume level
is changed.

OFF TIMER button

The Display can be preset to switch to stand-by
after a fi xed period. The setting changes to 30
minutes, 60 minutes, 90 minutes and 0 minutes
(off timer cancelled) each time the button is
pressed.

30 min 60 min

90 min

0 min

When three minutes remain, “Off timer 3 min”
will fl ash.
The off timer is cancelled if a power interruption
occurs.

AUTO SETUP button

Automatically adjusts the position/
size of the screen. (see page 22)

SET UP button (see page 20)

SOUND button (see page 26)

Volume Adjustment

Press the Volume Up “+” or Down “–”
button to increase or decrease the
sound volume level.

R button (see page 20)
Press the R button to return to
previous menu screen.

N button
(see page 23, 24, 25, 26)

POSITION buttons

INPUT button

Press to select Input signal
sequentially. (see page 15)

RECALL button

Press the “RECALL” button to display
the current system status.

Input label

1

Aspect mode (see page 18)

2

Off timer

3

The off timer indicator is

displayed only when the off
timer has been set.

Clock display (see page 42)

4

PC
4:3

10:00

4

Off timer

90min

1
2

3

Digital Zoom (see page 19)

17

ASPECT Controls

The Display will allow you to enjoy viewing the picture at its maximum size, including wide screen cinema format
picture.

Note:

Be aware that if you put the display in a public place for commercial purposes or a public showing
and then use the aspect mode select function to shrink or expand the picture, you may be violating
the copyright under copyright law. It is prohibited to show or alter the copyrighted materials of other
people for commercial purposes without the prior permission of the copyright holder.

Press repeatedly to move through the aspect options:

4:3 Zoom1 16:9Zoom2

[from the unit]

The aspect mode changes each time the
ENTER button is pressed.

Note:

The aspect mode is memorized separately for each input terminal.

Aspect mode

16:9

4:3

Zoom1

Zoom2

Picture Enlarged screen

Description

The display of the pictures fi lls the screen.
In the case of SD signals, pictures with a 4:3 aspect ratio are
enlarged horizontally, and displayed. This mode is suited to
displaying anamorphic pictures with a 16:9 aspect ratio.

Pictures with a 4:3 aspect ratio are displayed with their
original aspect ratio. Side panels are displayed at the left
and right edges of the screen.

The pictures with a 4:3 aspect ratio among the 16:9 aspect
ratio signals are displayed with their original aspect ratio.
The left and right edges of the pictures are masked with
side panels.

Letterbox pictures with a 16:9 aspect ratio are enlarged
vertically and horizontally so that their display fi lls the screen.
The top and bottom edges of the pictures are cut off.

Letterbox pictures with a 16:9 aspect ratio are enlarged
vertically and horizontally so that their display fi lls the screen.
The top and bottom edges as well as the left and right edges
of the pictures are cut off.

18

Digital Zoom

This displays an enlargement of the designated part of the displayed image.

Display the operation guide.

1

Press to access Digital Zoom.
The operation guide will be displayed.

During Digital Zoom, only the following buttons can be operated.

[Remote control]

Select the area of the image to be enlarged.

2

Press on the enlargement location to select.

Exit

1

POSITION /
ACTION button

The cursor will move.

Select the magnifi cation required for the enlarged display.

3

Each time this is pressed, the magnifi cation factor changes.
This is shown in the image being displayed.

× 1 × 2 × 3 × 4

Return to normal display (quit Digital Zoom).

4

Press to exit from the Digital Zoom.

Notes:

• When power goes OFF (including “Off Timer” operation), Digital Zoom terminates.

• The Digital Zoom function cannot be selected while in the following operation state:
When MULTI DISPLAY Setup is On (see page 34).
When Screensaver is running (see page 29)

• While Digital Zoom is in operation, “Adjusting Pos. / Size” cannot be used.

Exit

2

2

19

On-Screen Menu Displays

Remote Control Unit

Display the menu screen.

1

Select the item.

2


Normal

Normalise

Picture Mode
Backlight
Contrast
Brightness
Colour
Tint
Sharpness
White balance

Advanced settings

100

70
50
50
50
50

Normal

Normal

(Example: Picture menu)

Set.

3

Press to select.
(Example: Picture menu)

Select.

Adjust.

Press several times.
Each time the MENU button is pressed, the

menu screen will switch.

Normal Viewing Picture

Sound Pos. /Size Setup

Select.

Press.

Adjust.

Press.

Exit the menu.

4

Press.

Press to return to the
previous menu.

Press several times.

20

On-Screen Menu Displays

Overview

Note: Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input and menu setting.

Pos. /Size

Normal

Normalise

Auto Setup

H-Pos
H-Size
V-Pos
V-Size
Clock Phase
Dot Clock
1:1 Pixel Mode


Normal

Normalise

Picture Mode
Backlight
Contrast
Brightness
Colour
Tint
Sharpness
White balance

Advanced settings

Advanced settings

Normal

Normalise

Input level
Gamma
AGC
W/B High R
W/B High G
W/B High B
W/B Low R
W/B Low G
W/B Low B

Sound

Normal

Normalise

Sound Mode
Bass
Treble
Balance
Surround

0
0
0
0
0
0

Off

Page 22, 23

Normal

100

70
50
50
50
50

Normal

Page 24, 25

0

2.2
Off

50
50
50
50
50
50

Page 24, 25

Normal
0
0
0

Off

Setup

Signal

Screensaver

Input label
Wobbling
Component/RGB-in select

Power management
No signal power off

No activity power off

Standby save
ECO
OSD Language English(UK

MULTI DISPLAY Setup

Set up TIMER

PRESENT TIME Setup
Menu Display Duration
Menu Transparency

RGB

Enable

Enable

15 S

20

Page 27-40

MULTI DISPLAY Setup

MULTI DISPLAY Setup
Horizontal Scale
Vertical Scale
Bezel H Adjustment
Bezel V Adjustment
Location

10
10

Page 34, 35

Set up TIMER

PRESENT TIME MON 0 : 03

Program
Timer Function
Day
Power Mode
Time
Input

MON

Power On

0 : 00

VIDEO

Page 28

PRESENT TIME Setup

PRESENT TIME MON 99 : 99

Set
DAY
PRESENT TIME

MON

99 : 99

Page 27

On

Auto

Off
Off

[ AV ]

1/2

Off

Signal

3D Y/C Filter
Colour system
Cinema reality
Noise reduction

Page 37-40

On

On
Off

)

2/2Setup

Screensaver

Start

Mode

Input label

VIDEO
Component
PC
DVI
HDMI1
HDMI2

PRESENT TIME MON 0 : 02

Off

Page 29, 30

VIDEO

Component

PC

DVI
HDMI1
HDMI2

Page 32

Off

1
1

A1

1

Off

Page 26

21

Adjusting Pos. /Size

1

Press to display the Pos. /Size menu.

Press to select the menu to adjust.

2

Press to adjust the menu.

3

4

Note:

If a “Cue” or “Rew” signal from a VCR or DVD player is received, the picture position will shift up or down. This picture
position movement cannot be controlled by the Picture Pos./Size function.

Auto Setup

H-Pos/V-Pos, H-Size/V-Size, Dot Clock and Clock Phase are automatically adjusted when the RGB or
PC signal is received.
This setting only operates when a PC signal or RGB signal is input, and the aspect is “16:9”.

Using Remote Control

Press to exit from adjust mode.

Pos. /Size

Normalise

Auto Setup

H-Pos
H-Size
V-Pos
V-Size
Clock Phase
Dot Clock
1:1 Pixel Mode

Notes:

Unadjustable items are grayed
out.
Adjustable items differ depending
on the input signal and the display
mode.

Normal

0
0
0
0
0
0

Off

When on the remote control is pressed, “Auto Setup” will be executed.

When Auto Setup does not work, “Invalid” is displayed.

Notes:

• When digital RGB signal input, Dot Clock and Clock Phase cannot be made.

• Auto Setup may not work when a cropped or dark image is input. In such case, switch to a bright
image with borders and other objects are clearly shown, and then try auto setup again.

• Depending on the signal, out of alignment may occur after Auto Setup. Carry out fi ne tuning for the
position/size as required.

• If Auto Setup cannot set properly for vertical frequency 60Hz XGA signal (1024×768@60Hz and
1366×768@60Hz), pre-selecting the individual signal in “XGA Mode” (see page 38) may results in
correct Auto Setup.

• Auto Setup does not work well when a signal such as additional information is superimposed out of
valid image period or intervals between synchronizing and image signals are short.

• If Auto Setup cannot adjust correctly, select “Normalise” once and press ACTION ( ), then adjust
Pos. /Size manually.

• If the picture goes off screen in the horizontal direction as a result of performing Auto Setup, perform
Dot Clock adjustment.

22

Adjusting POS. /SIZE

H-Pos Adjust the horizontal position. V-Pos Adjust the vertical position.

H-Size Adjust the horizontal size. V-Size Adjust the vertical size.

Clock
Phase

Dot Clock (During Component, RGB and PC input signal)

Over scan Turn image over scan On/Off.

1:1 Pixel
Mode

(During Component, RGB and PC input signal)

Eliminate the fl ickering and distortion.

Periodic striped pattern interference (noise) may occur when a striped pattern is displayed. If this happens,
adjust so that any such noise is minimized.

Confi gurable signals are as follows:
525i, 525p, 625i, 625p, 750/60p, 750/50p (Component Video, DVI, HDMI)

On Off

Notes:

• “Off” is effective during only “16:9” aspect mode.

• When “Off” is set, “H-Size” and “V-Size” cannot be adjusted.

Adjusts the display size when 1125i or 1125p signal is input.

Notes:

• “On” is effective during only “16:9” aspect mode.

• Select On when you would like to replay 1920 × 1080 input signal.

• Applicable input signal;
1125 (1080) / 50i · 60i · 24sF · 24p · 25p · 30p · 50p · 60p

• Select Off when fl ickering is shown around the image.

• H-Size and V-Size cannot be adjusted when On is selected.

Off On

Helpful Hint ( /

While the Pos. / Size display is active, if either the N button on the remote control is pressed at any time or the ACTION ( ) button is
pressed during “Normalise”, then all adjustment values (except “Clock Phase” and “Dot Clock”) are returned to the factory settings.

Normalise

Normalisation)

23

Picture Adjustments

1

Select to adjust each item.

2


Normalise

Picture Mode
Backlight
Contrast
Brightness
Colour
Tint
Sharpness
White balance

Advanced settings

Normal

Press to display the Picture menu.

Press to select the menu to adjust.

Select the desired level by looking at the picture behind the menu.

Note:

Menu that cannot be adjusted is grayout. Adjustable menu changes depending on signal, input
and menu setting.

Press “ ” or “ ” button to switch between modes.

100

70
50
50
50
50

Normal

Normal

Normal

Cinema

Normal

For viewing in standard (evening lighting)
environments.
This menu selects the normal levels of Brightness

Dynamic

and Contrast.

Dynamic

For viewing in brighter environments.
This menu selects higher than normal levels of
Brightness and Contrast.

Press to enter
Advanced settings .

Advanced settings
Enables fi ne picture adjustment at a professional
level (see next page).

Advanced settings

Normalise

Input level
Gamma
AGC
W/B High R
W/B High G
W/B High B
W/B Low R
W/B Low G
W/B Low B

Normal

0

2.2

Off
50
50
50
50
50
50

Cinema

Ideal for movies.

Note:

If you would like to change the picture and colour

of the selected Picture menu to something else,
adjust using the items in the Picture menu. (see
next page)

Press “ ” or “ ” button to switch between modes.

Normal Warm Cool

Helpful Hint ( /

Normalise

Normalisation)

While the “Picture” menu is displayed, if either the N button on the remote control is pressed at any time or the
ACTION ( ) button is pressed during “Normalise”, then all adjustment values are returned to the factory settings.

24

Picture Adjustments

Item Effect Adjustments

Backlight

Contrast

Darker

Less More

Brighter

Adjusts luminance of the back
light.

Selects the proper brightness
and density for the room.

Adjusts for easier viewing of

Brightness

Colour

Tint

Sharpness

Darker Brighter

Less More

Reddish Greenish

Less More

dark pictures such as night
scenes and black hair.

Adjusts colour saturation.

Adjusts for nice skin colour.

Adjusts picture sharpness.

Advanced settings

Item Effect Details

Notes:

• “Colour” setting can be adjusted for Video
input signal.

• You can change the level of each function
(Backlight, Contrast, Brightness, Colour, Tint,
Sharpness) for each Picture Mode.

• The setting details for normal, dynamic
and cinema respectively are memorized
separately for each input terminal.

• The “Tint” setting can be adjusted for NTSC
signal only during Video input signal.

• In Contrast, there is not a noticeable change
even when contrast is increased with a bright
picture or reduced with a dark picture.

Input level

Gamma

AGC

W/B High

R

W/B High

G

W/B High

B

W/B Low R

W/B Low G

W/B Low B

Less More

Down Up

Off On

Less More

Less More

Less More

Less More

Less More

Less More

Adjustment of parts which are extremely bright and hard to see.

S Curve 2.0 2.2 2.6

Increases the brightness of dark signal automatically.

Adjusts the white balance for light red areas.

Adjusts the white balance for light green areas.

Adjusts the white balance for light blue areas.

Adjusts the white balance for dark red areas.

Adjusts the white balance for dark green areas.

Adjusts the white balance for dark blue areas.

Notes:

• Carry out “W/B” adjustment as follows.

1.

Adjust the white balance of the bright sections using the “W/B High R”, “W/B High G” and “W/B High B” settings.

2. Adjust the white balance of the dark sections using the “W/B Low R”

, “W/B Low G”

and “W/B Low B” settings.

3. Repeat steps 1 and 2 to adjust.

Steps 1 and 2 affect each other’s settings, so repeat each step in turn to make the adjustment.

• The adjustment values are memorized separately for each input terminal.

• The adjustment range values should be used as an adjustment reference.

Helpful Hint ( /

Normalise

Normalisation)

On the remote control unit, while the “Advanced settings” menu is displayed, if either the N button is pressed at any time or
the ACTION ( ) button is pressed during “Normalise”, then all adjustment values are returned to the factory settings.

25

Sound Adjustment

1

Select to adjust each item.

2

3

Item Details

Sound Mode

Bass Adjusts low pitch sounds.

Treble Adjusts high pitch sounds.

Balance Adjusts left and right volumes.

Surround Select On or Off.

Note: Bass, Treble and Surround settings are memorized separately for each Sound Mode.

Press to display the Sound menu.

Press to select the menu to adjust.

Select the desired level by listening to the sound.

Press to exit from adjust mode.

Normal: Emits the original sound.
Dynamic: Accentuates sharp sound.
Clear: Attenuates human voice.

Sound

Normalise

Sound Mode
Bass
Treble
Balance
Surround

Normal

Normal
0
0
0

Off

Helpful Hint ( /

While the “Sound” menu is displayed, if either the N button on the remote control is pressed at any time or the
ACTION ( ) button is pressed during “Normalise”, then all adjustment values are returned to the factory settings.

Normalise

Normalisation)

26

PRESENT TIME Setup / Set up TIMER

The timer can switch the Display On or Off.

Before attempting Timer Set, confi rm the PRESENT TIME and adjust if necessary.
Then set POWER ON Time / POWER OFF Time.

1

Press to display the Setup menu.

Press to select Set up TIMER or PRESENT TIME Setup.

2

Press to display the Set up TIMER screen or
PRESENT TIME Setup screen.

PRESENT TIME Setup

1

Press to select DAY or PRESENT TIME.

Press to setup DAY or PRESENT TIME.

button: Forward
button: Back

Notes:

• Pressing “ ” or “ ” button once changes PRESENT TIME 1 minute.

• Pressing “ ” or “ ” button continuously changes PRESENT TIME by 15 minutes.

Press to select Set.

2

Press to store PRESENT TIME Setup.

Notes:

• Set cannot be selected unless PRESENT TIME is set.

• Unless setting the present time other than “99:99”, “DAY” and “PRESENT TIME”
can not be set.

• The settings of “DAY” and “PRESENT TIME” are reset when leaving the display
turned off for about 7 days for the following reasons:

Pressing switch of the unit to turn off the display.
Disconnecting the AC cord.
Interruption of power supply.

MULTI DISPLAY Setup

Set up TIMER

PRESENT TIME Setup
Menu Display Duration
Menu Transparency

PRESENT TIME Setup

PRESENT TIME MON 99 : 99

Set
DAY
PRESENT TIME

2/2Setup

15 S

20

MON

99 : 99

27

PRESENT TIME Setup / Setup TIMER

Set up TIMER

Set the program for turning the power On/Off and select the input signal at the specifi ed time. Up to 20 programs can be set.

[Setting Example]

Program 1, Every Monday, 12:00, Power On, Input: VIDEO

Set up TIMER

PRESENT TIME MON 0 : 03

Program
Timer Function
Day
Power Mode
Time
Input

1

On

MON

Power On

12 : 00
VIDEO

select

1

adjust

2

Set the program number.

1

To execute the program, set to “On”.

2

The program is disabled when “Off” is set.

Set the day.

3

The program is executed every day when “Everyday” is set.

Set the power On/Off.

4

Set the time.

5

Pressing “ ” or “ ” button once changes “Time” 1 minute.
Pressing “ ” or “ ” button continuously changes “Time” by
15 minutes.

Set the input.

6

Notes:

• This function cannot be set unless “PRESENT TIME Setup” is set.

• If more than one programs are set for the same time, only the program with the smallest program number is enabled.

28

Screensaver (For preventing image retention)

Do not display a still picture, especially in 4:3 mode, for any length of time.
If the display must remain on, a Screensaver should be used.
When the screen saver is operating, the following 5 patterns are displayed full screen for 5 seconds each.

Black→Dark Gray→Gray→Light Gray→White

1

2

Mode selection

3

Start setting

4

Press to display the Setup menu.

Press to select Screensaver.

Press to display Screensaver screen.

Off

Press to select Mode.

Press to select each
mode items.

Interval

Time Designation : Operates when Start Time and Finish Time

Standby after SCR Saver

On : Operates when Start is selected and the

When the Mode is set to On, press to select Start.

Setup

Signal

Screensaver

Input label
Wobbling
Component/RGB-in select

Power management
No signal power off

No activity power off

Standby save
ECO
OSD Language English(UK)

Screensaver

PRESENT TIME MON 0 : 02

Start

Mode

1/2

Off

RGB

On

Enable

Enable

On
Off

Off

: Operates when Periodic Time and Operating

Time are setup and those times arrive.

are setup and those times arrive.

: Operates while Screensaver duration, and

display enters standby mode.

ACTION ( ) button is pressed.

Press to start Screensaver.
The menu screen will disappear and the Screensaver will be activated. To stop the

Screensaver under On, press the R button or any buttons on the main unit.

Note: When the display is turned off, the Scrensaver will be deactivated.

29

Screensaver (For preventing image retention)

Setup of Screensaver Time

After selecting Time Designation, Interval or Standby after SCR Saver, the relevant Time Setup will become available
for selection and the Operating Time may be set. (Time cannot be set when “Mode” is “On” or “Off”.)

Press to select Start Time / Finish Time
(When Time Designation is selected).
Press to select Periodic Time / Operating Time
(When Interval is selected).
Press to select Screensaver duration
(When Standby after SCR Saver is selected).
Press to setup.
button: Forward

button: Back

Notes:

• Pressing “ ” or “ ” button once changes the Time 1 minute.
[However, switching occurs every 15 minutes when Periodic Time is selected.]

• Pressing “ ” or “ ” button continuously changes the Time by 15 minutes.

• “Screensaver duration” of the “Standby after SCR Saver” can be set from 0:00 to
23:59. When this is set to “0:00”, “ Standby after SCR Saver” will not be activated.

Note: Timer function will not work unless “PRESENT TIME” is set.

Wobbling

Screensaver

Screensaver

Screensaver

PRESENT TIME MON 15 : 00

Start
Mode
Start Time
Finish Time

PRESENT TIME MON 15 : 00

Start
Mode
Periodic Time
Operating Time

PRESENT TIME MON 15 : 00

Start
Mode
Screensaver duration

Standby after SCR Saver

Time Designation

6 : 15

12 : 30

Interval

12 : 00

3 : 00

6 : 15

Automatically shifts the display image (therefore unnoticeable to the eye) to prevent image retention of sharper contour
of image.

1

2

3

Notes:

Press to display the Setup menu.

Press to select “Wobbling”.

Press to select “On” or “Off”.
On: Shifts the position of the display image on a fi xed time

interval.

Press to exit from adjust mode.

Setup

Signal

Screensaver

Input label
Wobbling
Component/RGB-in select

Power management
No signal power off

No activity power off

Standby save
ECO
OSD Language English(UK)

Off

RGB

On

Enable

Enable

On
Off

1/2

• If “MULTI DISPLAY Setup” is set to “On”, this function does not operate.

• When this function is operating, part of the screen may appear to be missing.

30

Reduces power consumption

• Power management: When this function is set to On, it operates under the following conditions to turn the
power on or off automatically.

→ Power is turned off (standby); the power indicator lights up orange.
When pictures are subsequently detected:
→ Power is turned on; the power indicator lights up green.
Notes:

• This function operates only during input from PC IN or DVI-D IN terminal.

• This function is effective when “Sync” is set to “Auto” and during normal viewing (one

• No signal power off: Equipment power supply is turned Off when there is no signal.

When this is set to “Enable”, the power supply of the unit goes Off 10 minutes after

Note:
This function is effective during normal viewing (one picture screen).

• No activity power off: When this function is set to “Enable”, the power is turned off (standby) automatically

Starting from 3 minutes before the turn off, the remaining time will be displayed.

When no pictures are detected for 30 or so seconds during input from PC IN or
DVI-D IN terminal:

picture screen).

the input signals stop.

when there is no operation of the Display for 4 hours.

Press any key to abort.

No activity power off

3min

When the power is turned off due to this function, a message “Last turn off due to

’No activity power off’.” is displayed next time the power is turned on.

Note:
During the screensaver is running, this function is disabled.

• Standby save: When this function is set to “On”, serial communication is disabled during standby
mode, reducing the power consumption during standby.

To perform serial communication while in standby, set this function to “Off(SERIAL)”.

However, the standby power consumption is greater than when it is set to “On”.

Note:
The factory setting is “On”.

• ECO: This function adjusts the brightness of the backlight to reduce power consumption.
Off: This function does not operate.
On: Backlight brightness is reduced.
Sensor: The backlight brightness is automatically adjusted according to the viewing
environment.

Note:
When this function is set to “On” or “Sensor”, the “Backlight” setting in the Picture

menu is disabled.

1

2

Press to select the menu to adjust.

Press to select “On (Enable)” or “Off (Disable)”.

On (Enable) Off (Disable)

Setup

Signal

Screensaver

Input label
Wobbling
Component/RGB-in select

Power management
No signal power off

No activity power off

Standby save
ECO
OSD Language English(UK

Off

RGB

On

Enable

Enable

On
Off

1/2

)

3

Press to exit from Setup.

31

Customizing the Input labels

This function can change the label of the Input signal to be displayed. (see page 15)

Setup

1/2

1

Press to display the Setup menu.

Press to select Input label.

2

Press to display the Input label screen.

Press to select image input.

3

Component/RGB-in select

Power management
No signal power off

No activity power off

Standby save
ECO
OSD Language English(UK)

Press to change input label.

Input label

Image input Input label
[VIDEO] VIDEO / DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB / (Skip)
[Component]* Component / DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB / (Skip)
[PC] PC / DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB / (Skip)
[DVI] DVI / DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB / (Skip)
[HDMI1] HDMI1 / DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB / (Skip)
[HDMI2] HDMI2 / DVD1 / DVD2 / DVD3 / Blu-ray1 / Blu-ray2 / Blu-ray3 / CATV / VCR / STB / (Skip)

Screensaver

Input label

Wobbling

VIDEO
Component
PC
DVI
HDMI1
HDMI2

Signal

Off

RGB

On

Enable

Enable

On
Off

VIDEO

Component

PC

DVI
HDMI1
HDMI2

(Skip): The INPUT button press will skip its input.

* “Component” may be displayed as “RGB” depending on the setting of “Component/RGB-in select”. (see page 36)

32

Selecting the On-Screen Menu Language

1

2

Press to display the Setup menu.

Press to select the OSD Language.

Press to select your preferred language.

Selectable languages

English (UK)

Deutsch

Français

Italiano

Español

English (US)

......(Chinese)

.......(Japanese)

Setup

Signal

Screensaver

Input label
Wobbling
Component/RGB-in select

Power management
No signal power off

No activity power off

Standby save
ECO
OSD Language English(UK)

1/2

Off

RGB

On

Enable

Enable

On
Off

Русский.......(Russian)

Customizing the On-Screen Menu Display

Set the display time and background transparency of the on-screen menu display.

1

2

3

Press to display the Setup menu.

Press to select “Menu Display Duration”.

Press to adjust the display duration.

Press to select “Menu Transparency”.

Press to adjust the transparency.

MULTI DISPLAY Setup

Set up TIMER

PRESENT TIME Setup
Menu Display Duration
Menu Transparency

2/2 Setup

15 S

20

4

Press to exit from adjust mode.

33

Setup for MULTI DISPLAY

By lining up the Displays in groups, for example, as illustrated below, an enlarged picture may be displayed across
all screens.
For this mode of operation, each display has to be set up with a Display number to determine its location.

(Example)

group of 16 (4 × 4)group of 4 (2 × 2) group of 9 (3 × 3) group of 25 (5 × 5)

How to Setup MULTI DISPLAY

1

Press to display the Setup menu.

Press to select the MULTI DISPLAY Setup.

2

Press to display the “MULTI DISPLAY Setup” menu.

Press to select the MULTI DISPLAY Setup.

3

Press to select “On” or “Off”.

Item Details

MULTI DISPLAY Setup Select “On” or “Off”.

Horizontal Scale Select “1”, “2”, “3”, “4”, “5”.

Vertical Scale Select “1”, “2”, “3”, “4”, “5”.

Areas of the image that are hidden by the joint sections are adjusted both horizontally and
vertically (0~100).

To show joints between displays. To hide joints between displays.

MULTI DISPLAY Setup

Set up TIMER

PRESENT TIME Setup
Menu Display Duration
Menu Transparency

MULTI DISPLAY Setup

MULTI DISPLAY Setup
Horizontal Scale
Vertical Scale
Bezel H Adjustment
Bezel V Adjustment
Location

2/2Setup

15 S

20

Off

1

1
10
10

A1

Bezel H Adjustment
Bezel V Adjustment

34

Suitable for still image display. Suitable for moving image display.

Setting value: 0 Setting value: 100

Item Details

Select the required arrangement number. (A1-E5 : Refer to the following)

Display Number locations for each arrangement.

(Examples)

( 2 × 1) ( 2 × 3 ) ( 4 × 4 )( 4 × 2 ) ( 5 × 5 )

Location

Setup for MULTI DISPLAY

A1 A2 A3 A4 A5

B1 B2 B3 B4 B5

C1 C2 C3 C4 C5

D1 D2 D3 D4 D5

E1 E2 E3 E4 E5

4

Press to exit from Setup.

35

Setup for Input Signals

Component / RGB-in select

Select to match the signals from the source connected to the COMPONENT/RGB IN terminal.
Y, PB, PR signals “Component”
RGB signals “RGB”

1

Press to display the Setup menu.

Press to select the “Component / RGB-in select”.

2

Press to select the desired input signal.

Component RGB

3

Note:

Make setting of the selected input terminal (COMPONENT/RGB IN).

Press to exit from adjust mode.

Setup

Signal

Screensaver

Input label

Wobbling

Component/RGB-in select

Power management
No signal power off

No activity power off

Standby save
ECO
OSD Language English(UK)

1/2

Off

RGB

On

Enable

Enable

On
Off

36

Setup for Input Signals

Signal menu

Note:

“Signal” setup menu displays a different setting condition for each input signal.

Setup

1/2

1

2

3

4

Press to display the Setup menu.

Press to select the “Signal”.

Press to display the Signal menu.

Press to select the menu to adjust.

Press to adjust the menu.

Press to exit from adjust mode.

Signal

Screensaver

Input label

Wobbling

Component/RGB-in select

Power management
No signal power off

No activity power off

Standby save
ECO
OSD Language English(UK

Press ACTION ( ) button

For Video For RGB

Signal

3D Y/C Filter
Colour system
Cinema reality
Noise reduction

On

Auto

Off
Off

[ AV ]

Signal

Sync
Cinema reality
XGA Mode
Noise reduction

H-Freq.

V-Freq.

Signal Format

For Component For Digital

Signal

Cinema reality
XGA Mode
Noise reduction

H-Freq.

V-Freq.

Signal Format

[

Component

1024

kHz

63.98

Hz

60.02
1280×1024/60

]

Signal

Off

×

768

Off

Cinema reality
Noise reduction

H-Freq.

V-Fr eq. H z

Dot Clock Freq.

Signal Format 1280×1024/60

Enable

Enable

1024

kHz

63.98

Hz

60.02
1280×1024/60

kHz

63.98

60.02
MHz

108.0

Off

RGB

On

On
Off

Auto

Off

Off

Off
Off

[

×

768

[

Digital

)

RGB

]

]

3D Y/C Filter

Select “Signal” from the “Setup” menu during Video (S Video) input signal. (“Signal [AV]” menu is displayed.)

Press to select the “3D Y/C Filter”

Press to set On / Off.

3D Y/C Filter

On

37

Setup for Input Signals

y

Colour system

Select Signal from the “Setup” menu during Video input signal. (“Signal [AV]” menu is displayed.)

Press to select the “Colour system”.

Press to select each functions.

Signal

3D Y/C Filter
Colour system
Cinema reality
Noise reduction

On

Auto

Off
Off

[

]

AV

If the picture image becomes unstable:

With the system set on Auto, under conditions of low level or noisy input signals the image may in rare cases
become unstable. Should this occur, set the system to match the format of the input signal.

Colour system: Set the colour system to match the input signal. When “Auto” is set, Colour system will be

automatically selected from NTSC/PAL/SECAM/NTSC 4.43/PAL M/PAL N.
To display PAL60 signal, select “Auto”.

Auto SECAM NTSC PAL M PAL N

PAL

NTSC 4.43

Cinema reality

Cinema reality:

When on, the display attempts to reproduce a more natural interpretation of sources such as movie pictures, which
are recorded at 24 frames per second. If the picture is not stable, turn the setting to off.

Note:

When On, this setting only affects the following signal input:

• NTSC / PAL signal input during Video input signal.

• 525i (480i), 625i (575i), 1125 (1080) / 60i signal input during Component input signal.

Press to select Cinema reality.

Cinema reality

Off

Press to set On / Off.

XGA Mode

This menu is displayed when the input signal is analog (Component/PC). This menu sets two types of XGA signals
with 60Hz vertical frequency having different aspect ratios and sampling rates (1,024 × 768 @ 60Hz and
1,366 × 768 @ 60Hz).
When a 1,280 x 768 @ 60Hz input signal is automatically detected, the image is processed as a 1,280 x 768 @
60Hz XGA input signal irrespective of this setting.

Press to select “XGA Mode”.

XGA Mode

Press to select “1024×768”, “1366×768”.

Note:

After making this setting, be sure to make each adjustment (such as “Auto Setup”) on the “Pos. /Size” menu as
necessary. (see page 22)

1024 × 768

38

Noise reduction

Setup for Input Signals

Press to select “Noise reduction”.

Press to select “Off”, “Auto”, “Min”, “Mid”, “Max”.
Auto: Noise reduction will be automatically selected from “Min”,

“Mid” or “Max”.

Note:

Noise reduction can be adjusted while a Video or Component signal is being applied.

Sync

This function operates only during input from PC IN terminal.
Select Signal from the “Setup” menu during Component input signal.

Press to select the “Sync”.

Press to adjust.

Noise reduction

Signal

Sync
Cinema reality
XGA Mode

Off

Auto

1024

Off

×

[

768

RGB

]

Confi rm that the input is set to RGB input (this setting is valid only for RGB input signal).

Auto:

The H and V sync or synchronized signal is automatically selected. If both input, it is selected the H and V sync.
However, the synchronized signal that is input fi rst is selected.

on G: Uses a synchronized signal on the Video G signal, which is input from the G connector.

Note:

Accepts only RGB signals from COMPONENT/RGB IN terminal with “Sync on G”

39

Setup for Input Signals

Input signal display

Displays the frequency and the type of the current input signal.

This display is valid only for Component / RGB / PC and Digital input signal.
Display range:

Horizontal 30 - 110 kHz
Vertical 48 - 120 Hz

H-Freq.

V-Freq.

Signal Format

kHz

63.98

Hz

60.02
1280×1024/60

The dot clock frequency is displayed during digital signal input.

Note:

The automatically detected signal format may be displayed differently than the
actual input signal.

H-Freq.

V-Freq. Hz

Dot Clock Freq.

Signal Format 1280×1024/60

63.98

60.02

108.0

kHz

MHz

40

Options Adjustments

1

2

3

4

5

Press to display the Setup menu.

Press to select “OSD Language”.

Press for more than 3 seconds.

Press to select “Options”.

Press to display the Options menu.

Press to select your preferred menu.

Press to adjust the menu.

Press to exit from Options menu.

Options

Shipping

Options

On screen display
Initial input
Failover input
Initial VOL level
Maximum VOL level
Input lock
Button lock
Remocon User level

Options

Off-timer function

Initial Power Mode

Power On Screen Delay

Clock Display

Power On Message (No activity power off)

Winter Mode
Power Switch Lock

On
Off
Off

Off00

Off

Off

Off

Off

Enable

Normal

Off

Off

On

Off

Off

Normalisation

When both main unit buttons and remote control are disabled due to the “Button lock” or “Remocon User level”
adjustments, set all the values “Off” so that all the buttons are enabled again.

Press the button on main unit together with button on the remote control and hold for more than 5 seconds.

The “Shipping” menu is displayed and the lock is released when it disappears.

1/2

2/2

Item Adjustments

On screen display

Initial input

Failover input

Initial VOL level

Maximum VOL level

On: Displays all the following on screen.

• Power on display

• Input signal switch display

• No signal display

• Mute and the remaining time of off-timer after

was pressed.

Off: Hides all the items above from view.
Adjusts the input signal when the unit is turned on.

Off

VIDEO Component/RGB PC DVI HDMI1 HDMI2 Off

Notes:

• Only the adjusted signal is displayed. (see page 15)

• This menu is available only when “Input lock” is “Off”.
When there is no signal, the specifi ed input signal is automatically switched to.

Off

VIDEO Component/RGB PC DVI HDMI1 HDMI2 Off

Notes:

•

When other than “Off” is set, “Input lock” will be grayed out and cannot be set.

• When “Input lock” is set to other than “Off”, this setting will be grayed out and cannot be set.

Press button to adjust the volume when the unit is turned on.

Off

On

Off: Sets normal volume.
On: Sets your preferred volume.
Notes:

•

When “Maximum VOL level” is “On”, the volume can only be adjusted between 0 and your maximum range.

• You can hear the changed volume regardless of your volume setting before opening the options menu
if you adjust the volume when “Initial VOL level” is “On” and cursor is on the menu.

Press

Off

button to adjust the maximum volume.

On

Off: Sets auto maximum volume.
On: Sets your preferred maximum volume.
Notes:

• If the “Maximum VOL level” is set lower than the “Initial VOL level”, the “Initial VOL level” automatically
becomes the same as the “Maximum VOL level”.

• The volume display can go up to 100 regardless of the settings.

• You can hear the changed volume regardless of your volume setting before opening the options menu
if you adjust the volume when “Maximum VOL level” is “On” and cursor is on the menu.

41

Options Adjustments

Item Adjustments

Locks the input switch operation.

VIDEO Component/RGB PC DVI HDMI1 HDMI2 Off

Off

Input lock

Button lock

Remocon User level

Off-timer function

Initial Power Mode

Power On Screen

Delay

Notes:

• Only the adjusted signal is displayed (see page 15).

• Input switch can be used when this is set to “Off”.

Off
Off: All the buttons on main unit can be used.

MENU&ENTER: Locks

On: Locks all the button on main unit.

Sets Button lock with the unit buttons in the following procedure.

Off: Press
MENU&ENTER: Press four times→Press four times→Press four times→Press
On: Press four times→Press four times→Press four times→Press

Off User1 User2 User3
Off: You can use all of the buttons on the remote control.
User1: You can only use

User2: You can only use
User3:

Locks all the buttons on remote control.

Enable: Enables the “Off-timer function”.
Disable: Disables the “Off-timer function”.
Note: When “Disable” is set, the Off-timer is cancelled.

Normal

Sets the power mode of the unit for when the power recovers from failure or after plugging off and in again.

Normal: Power returns in as the same state as before the power interruption.
Standby
On: Power returns in power On. (Power Indicator : green)
Note: When using multiple displays, “Standby” is preferred to be set in order to reduce a power load.

Off

You can set the power-on delay time of the displays to reduce the power load, when you press
turn on the multiple displays that are set together, for example, on MULTI DISPLAY system.
Set each display’s setting individually.

Off: The display will be turned on at the same time as
1 to 30 (sec.)

Notes:

• During this function is working, the power indicator is blinking green.

•

: Power returns in standby mode. (Power Indicator : red/orange)

1 2 3.... 30

This function also works when the power recovers from failure or after plugging off and in again the power cord.

On MENU&ENTER

and buttons on main unit.

four times→Press four times→Press four times→Press

, , , , buttons on the remote control.

button on the remote control.

On Standby

to

is pressed.

: Set the power-on delay time (second).

After pressing , the display will be powered on with time delay depending on this setting.

Clock Display

Power On Message

(No activity power

off)

Winter Mode

Power Switch Lock

Off: Not display the clock.
On: Display the clock.

The clock is displayed at the lower left of the screen when

Note: When “PRESENT TIME Setup” is not set, the clock is not displayed even

10:00

Whether to show/hide No activity power off Precautions at the time of power ON is set.

On: The warning precautions are shown at the time of power ON.
Off: The warning precautions are not shown at the time of power ON.
Note: This setting is enabled only if “No activity power off” is “Enable” (see page 31).

Set this function to maintain the image quality when the product is used in a low temperature
environment of 39 °F/4 °C or lower.

Off: Normal standby operation
On: Image is muted at standby and backlight is turned on when the inside temperature of the display

is 32 °F/0 °C or lower to prevent decreasing the temperature. Backlight is turned off when the
inside temperature is 50 °F/10 °C or higher.

When this function is set to “On”, the following message appears at standby.

if “Clock Display” is “On”. (see page 27)

button is pressed.

Winter mode is active.

Notes:

• Do not unplug the power cable while using the product with this function “On”.

• When this function is set to “On”, the power consumption at standby is approx. 100 W.

• Turn this function “Off” to use this product in an environment of 39 °F/4 °C or higher.

Sets the lock setting for the display Power switch.

On: Power switch operation is disabled.
Off: Power switch operation is enabled.

42

Troubleshooting

Before you call for service, determine the symptoms and make a few simple checks as shown below.

Symptoms

Picture Sound

Electrical Appliances

Interference Noisy Sound

Normal Picture No Sound

No Picture No Sound

No Picture Normal Sound

No Colour Normal Sound

No remote control operations can be performed. Check whether the batteries have discharged completely and, if they have not,

A cracking sound is sometimes heard from the unit.

The top or bottom of the picture on the screen is cut
off when I use the zoom function.
Areas at the top and bottom of the screen where
the image is missing appear when I use the zoom
function.
I can hear sounds coming from inside the unit. When the power is turned on, a sound of the display panel being driven may be

Parts of the unit become hot. Even when the temperature of parts of the front, top and rear panels has risen,

Power automatically turns off unexpectedly. Check the settings of “Power management”, “No signal power off” and “No

This LCD Display uses special image processing. Hence a slight time lag may occur between image and audio, depending on the type
of input signal. However, this is not a malfunction.

Cars / Motorcycles
Fluorescent light
Volume
(Check whether the mute function has been activated on the remote control.)

Not plugged into AC outlet
Not switched on
Picture and Brightness/Volume setting
(Check by pressing the power switch or stand-by button on the remote control.)
If a signal with a non-applicable colour system format, or frequency is input, only
the input terminal indication is displayed.

Colour controls set at minimum level
(see page 24, 25)
Colour system (see page 38)

whether they were inserted properly.
Check whether the remote control sensor is exposed to an outdoor light or a
strong fl uorescent light.
Check whether the remote control designed specifi cally for use with the unit is
being used. (The unit cannot be operated by any other remote control.)
If there is nothing wrong with the picture or sound, this is the sound of the cabinet
undergoing very slight contractions in response to changes in the room temperature.
There are no adverse effects on the performance or other aspects.
Adjust the position of the picture on the screen.

When using a video software program (such as a cinema size program) with a
screen wider than one in the 16:9 mode, blank areas separate from the images
are formed at the top and bottom of the screen.

heard: This is normal and not indicative of malfunctioning.

these temperature rises will not pose any problems in terms of performance or
quality.

activity power off” in the Setup menu. Any of them may be set to “On (Enable)”.
(see page 31)

Checks

LCD Display panel

Symptoms Check

The screen darkens slightly
when bright pictures with minimal
movements are shown.

It takes a while for the picture
to appear.

The edges of the images fl icker.

There may be red spots, blue
spots, green spots and black
spots on the screen.

Image retention appears

Whirring sounds can be heard
from the display unit.

The screen will darken slightly when photos, still images of a computer or other pictures with minimal
movements are shown for an extended period. This is done to reduce image retention on the screen
and the shortening of the screen’s service life: It is normal and not indicative of malfunctioning.

The unit digitally processes the various signals in order to reproduce esthetically pleasing images. As
such, it sometimes takes a few moments for the picture to appear when the power has been turned
on, when the input has been switched.

Due to the characteristics of the system used to drive the panel, the edges may appear to fl icker in
the fast-moving parts of the images: This is normal and not indicative of malfunctioning.

This is a characteristic of liquid crystal panels and is not a problem. The liquid crystal panel is built
with very high precision technology giving you fi ne picture details. Occasionally, a few non-active
pixels may appear on the screen as fi xed points of red, blue, green, or black. Please note this does
not affect the performance of your LCD.

Image retention may occur. If you display a still picture for an extended period, the image might remain
on the screen. However, it will disappear after a while. This is not considered as malfunction.

The display unit is fi tted with a cooling fan to dissipate heat generated during normal use. The whirring
sound is caused by rotation of the fan and is not a malfunction.

43

Applicable Input Signals

PC signals

Signal name

1 640x400@70Hz 31.46 70.07 * (25.17) * (25.17) * (25.17)
2 640x400@85Hz 37.86 85.08 * (31.5) * (31.5) * (31.5)
3 640x480@60Hz 31.43 59.88 * (25.15) * (25.15) * (25.15)
4 640x480@60Hz 31.47 59.94 * (25.18) * (25.18) * (25.18) *
5 640x480@67Hz 35.00 66.67 * (30.24) * (30.24) * (30.24)
6 640x480@72Hz 37.86 72.81 * (31.5) * (31.5) * (31.5)
7 640x480@75Hz 37.50 75.00 * (31.5) * (31.5) * (31.5)
8 640x480@85Hz 43.27 85.01 * (36.0) * (36.0) * (36.0)

9 720x400@70Hz 31.47 70.08 * (28.32) * (28.32) * (28.32)
10 800x600@55Hz 34.50 55.38 * (35.33) * (35.33) * (35.33)
11 800x600@56Hz 35.16 56.25 * (36.0) * (36.0) * (36.0)
12 800x600@60Hz 37.88 60.32 * (40.0) * (40.0) * (40.0) *
13 800x600@60Hz 38.00 60.51 * (40.13) * (40.13) * (40.13)
14 800x600@72Hz 48.08 72.19 * (50.0) * (50.0) * (50.0)
15 800x600@75Hz 46.88 75.00 * (49.5) * (49.5) * (49.5)
16 800x600@85Hz 53.67 85.06 * (56.25) * (56.25) * (56.25)
17 852x480@60Hz 31.47 59.94 * (33.54) * (33.54) * (34.24)
18 1,024x768@50Hz 39.55 50.00 * (51.89) * (51.89) * (51.89)
19 1,024x768@60Hz 48.36 60.00 * (65.0) * (65.0) * (65.0) *
20 1,024x768@60Hz 48.50 60.02 * (64.99) * (64.99) * (65.18)
21 1,024x768@70Hz 56.48 70.07 * (75.0) * (75.0) * (75.0)
22 1,024x768@75Hz 60.24 74.93 * (80.0) * (80.0) * (80.0)
23 1,024x768@75Hz 60.02 75.03 * (78.75) * (78.75) * (78.75)
24 1,024x768@75Hz 61.01 75.70 * (80.05) * (80.05) * (81.0)
25 1,024x768@85Hz 68.68 85.00 * (94.5) * (94.5) * (94.5)
26 1,024x768@120Hz 97.55 119.99 * (115.5) * (115.5)
27 1,066x600@60Hz 37.64 59.94 * (53.0) * (53.0) * (53.0)
28 1,152x864@60Hz 53.70 60.00 * (81.62) * (81.62) * (81.62)
29 1,152x864@75Hz 67.50 75.00 * (108.0) * (108.0) * (108.0)
30 1,152x900@65Hz 61.20 65.20 * (92.0) * (92.0) * (92.0)
31 1,152x900@66Hz 61.85 66.00 * (94.5) * (94.5) * (94.5)
32 1,152x900@75Hz 71.40 75.60 * (105.1) * (105.1) * (105.1)
33 1,280x768@60Hz 47.78 59.87 * (79.50) * (79.50) * (79.50)
34 1,280x800@50Hz 41.20 50.00 * (68.55) * (68.55) * (68.55)
35 1,280x960@60Hz 60.00 60.00 * (108.0) * (108.0) * (108.0)
36 1,280x960@85Hz 85.94 85.00 * (148.5) * (148.5) * (148.5)
37 1,280x1,024@50Hz 52.70 50.00 * (89.38) * (89.38) * (89.38)
38 1,280x1,024@60Hz 63.34 59.98 * (108.18) * (108.18) * (108.18)
39 1,280x1,024@60Hz 63.90 60.00 * (107.35) * (107.35) * (107.35)
40 1,280x1,024@60Hz 63.37 60.01 * (107.5) * (107.5) * (107.5)
41 1,280x1,024@60Hz 63.74 60.02 * (108.1) * (108.1) * (108.1)
42 1,280x1,024@60Hz 63.98 60.02 * (108.0) * (108.0) * (108.0) *
43 1,280x1,024@60Hz 63.79 60.18 * (108.19) * (108.19) * (108.19)
44 1,280x1,024@66Hz 70.66 66.47 * (119.84) * (119.84) * (119.84)
45 1,280x1,024@75Hz 79.98 75.02 * (135.0) * (135.0) * (135.0)
46 1,280x1,024@76Hz 81.13 76.11 * (135.0) * (135.0) * (135.0)
47 1,280x1,024@85Hz 91.15 85.02 * (157.5) * (157.5)
48 1,360x768@60Hz 47.71 60.02 * (85.5) * (85.5) * (85.5)
49 1,366x768@50Hz 39.55 50.00 * (69.92) * (69.92) * (69.92)
50 1,366x768@60Hz 48.36 60.00 * (86.71) * (86.71) * (87.44)
51 1,400x1,050@60Hz 65.12 59.91 * (121.38) * (121.38) * (122.43)
52 1,400x1,050@60Hz 65.32 59.98 * (121.75) * (121.75) * (121.75)
53 1,400x1,050@60Hz 65.35 60.12 * (121.81) * (121.81) * (121.85)
54 1,400x1,050@75Hz 82.28 74.87 * (156.0) * (156.0) * (156.0)
55 1,600x1,200@60Hz 75.00 60.00 * (162.0) * (162.0) * (162.0)
56 1,920x1,080@60Hz 67.50 60.00 * (148.5) * (148.5) * (148.5)
57 1,920x1,200@60Hz 74.04 59.95 * (154.0) * (154.0)
58 Macintosh13" (640x480) 35.00 66.67 * (30.24) * (30.24) * (30.24)
59 MacintoshLC13" (640x480) 34.97 66.60 * (31.33) * (31.33) * (31.33)
60 Macintosh16" (832x624) 49.72 74.55 * (57.28) * (57.28) * (57.28)
61 Macintosh19" (1,024x768) 60.24 75.08 * (80.0) * (80.0) * (80.0)
62 Macintosh21" (1,152x870) 68.68 75.06 * (100.0) * (100.0) * (100.0)
63 Macintosh II (1,280x1,024) 80.00 75.00 * (134.4) * (134.4) * (135.2)

Horizontal

frequency (kHz)

Vertical

frequency (Hz)

RGB IN

(Dot clock (MHz))

(Dot clock (MHz))

*Mark: Applicable input signal

PC IN

DVI-D IN

(Dot clock (MHz))

HDMI1
HDMI2

44

Applicable Input Signals

Component signals

Signal name

1 525(480)/60i 15.73 59.94 * (13.5) * (27.0) *
2 525(480)/60p 31.47 59.94 * (27.0) * (27.0) *
3 625(575)/50i 15.63 50.00 * (13.5)
4 625(576)/50i 15.63 50.00 * (27.0)
5 625(575)/50p 31.25 50.00 * (27.0) *
6 625(576)/50p 31.25 50.00 * (27.0) *
7 750(720)/60p 45.00 60.00 * (74.25) * (74.25) *
8 750(720)/50p 37.50 50.00 * (74.25) * (74.25) *

9 1,125(1,080)/60p 67.50 60.00 * (148.5)
10 1,125(1,080)/60i 33.75 60.00 * (74.25)
11 1,125(1,080)/50p 56.25 50.00 * (148.5)
12 1,125(1,080)/50i 28.13 50.00 * (74.25)
13

1,125(1,080)/24sF
14 1,125(1,080)/30p 33.75 30.00 * (74.25)
15 1,125(1,080)/25p 28.13 25.00 * (74.25)
16 1,125(1,080)/24p 27.00 24.00 * (74.25)

∗1:

Based on SMPTE 274M standard.

Horizontal

frequency (kHz)

27.00 48.00 * (74.25)∗2

Vertical

frequency (Hz)

∗2:

Based on SMPTE RP211 standard.

COMPONENT IN
(Dot clock (MHz))

Mark: Applicable input signal

*

DVI-D IN

(Dot clock (MHz))

∗1 * (148.5) *
∗1 * (74.25) *
∗1 * (148.5) *
∗1 * (74.25)

∗1 * (74.25) *
∗1 * (74.25) *
∗1 * (74.25) *

Video signals (VIDEO)

Signal name

1 NTSC 15.73 59.94
2 PAL 15.63 50.00
3 PAL60 15.73 59.94
4 SECAM 15.63 50.00
5 NTSC 4.43 15.73 59.94
6 PAL N 15.63 50.00
7 PAL M 15.73 59.94

Horizontal Vertical

frequency(kHz) frequency(Hz)

HDMI1
HDMI2

*

*

45

Shipping condition

This function allows you to reset the unit to the factory setting.

1

2

3

4

Press to display the Setup menu.

Press to select “OSD Language”.

Press for more than 3 seconds.

Press to select “Shipping”.

Press to display the Shipping menu.

Press to select “YES”.

Setup

Signal

Screensaver

Input label
Wobbling
Component/RGB-in select

Power management
No signal power off

No activity power off

Standby save
ECO
OSD Language English(UK)

Options

Shipping

Shipping

YES NO

1/2

Off

RGB

On

Enable

Enable

On
Off

Press to confi rm.

5

Wait for 10 seconds.

6

Press the power switch ( ) on main unit to turn the power off.
* If the power switch is locked, please disconnect the AC cord plug from the wall outlet.

[from the unit]

1 Press the MENU button till the Setup menu is displayed.
2 Press the Volume Up“+” or Down“–” button to select “OSD Language”.
3 Press and hold the ENTER button till the Shipping menu is displayed.
4 Press the Volume Up“+” or Down“–” button to select “YES”.
5 Press the ENTER button and wait for 10 sec.
6 Press the power switch ( ) on main unit to turn the power off.

* If the power switch is locked, please disconnect the AC cord plug from the wall outlet.

46

Specifi cations

TH-42LFP30W TH-47LFP30W

For USA, Canada

and Mexico

Power Source 110 - 127 V AC,

50/60 Hz

Power Consumption

Power on 250 W 240 W 300 W 290 W

Stand-by condition

(Winter Mode: Off)

Stand-by condition

(Winter Mode: On)

Power off condition 0.1 W 0.2 W 0.1 W 0.2 W

LCD Display panel 42-inch IPS panel, 16:9 aspect ratio 47-inch IPS panel, 16:9 aspect ratio
Screen size 36.6” (W) × 20.5” (H) × 42.0” (diagonal) /

(No.of pixels) 2,073,600 (1,920 (W) × 1,080 (H))

Operating condition

Temperature 32 °F - 104 °F / 0 °C - 40 °C (during Winter Mode: -4 °F - 104 °F / -20 °C - 40 °C)

Applicable signals

Colour System NTSC, PAL, PAL60, SECAM, NTSC 4.43, PAL M, PAL N

Scanning format 525 (480) / 60i · 60p, 625 (575) / 50i · 50p, 750 (720) / 60p · 50p, 1125 (1080) / 60i · 60p · 50i ·

PC signals VGA, SVGA, XGA, SXGA

Connection terminals

AV IN VIDEO

AUDIO L-R

HDMI 1/2 TYPE A Connector

COMPONENT/RGB IN

G/Y

B/P

B/CB

R/PR/CR

AUDIO L-R

DVI-D IN

AUDIO

PC IN

AUDIO

SERIAL External Control Terminal

EXT SP 8 Ω, 10 W [5 W + 5 W] (10 % THD)

Dimensions (W × H × D) 41.3” × 25.3” × 6.3” /

Mass (weight) approx. 83.8 lbs / 38.0 kg approx. 99.2 lbs / 45.0 kg

Save off 0.2 W,

Save on 0.1 W

Backlight Off 40 W
Backlight On 80 W

930 mm (W) × 523 mm (H) × 1,067 mm

[5,760 × 1,080 dots]

50p · 24p · 25p · 30p · 24sF

BNC
RCA Pin jack × 2

BNC
BNC
BNC
RCA Pin jack × 2

DVI-D 24 Pin
Content Protection
Stereo mini jack (M3) × 1

High-Density Mini D-sub 15 Pin

Stereo mini jack (M3) × 1

D-sub 9 Pin RS-232C compatible

1,049 mm × 642 mm × 158 mm

For Europe and Asia For USA, Canada

and Mexico

220 - 240 V AC,

50/60 Hz

Save off 0.3 W,

Save on 0.2 W

Backlight Off 40 W
Backlight On 80 W

(diagonal)

UXGA ···· (compressed)

Horizontal scanning frequency 30 - 110 kHz

Vertical scanning frequency 48 - 120 Hz

110 - 127 V AC,

50/60 Hz

Save off 0.2 W,

Save on 0.1 W

Backlight Off 40 W

Backlight On 100 W

40.9” (W) × 23.0” (H) × 46.9” (diagonal) /

1,039 mm (W) × 584 mm (H) × 1,192 mm

2,073,600 (1,920 (W) × 1,080 (H))

1.0 Vp-p (75 Ω)

0.5 Vrms

with sync 1.0 Vp-p (75 Ω)

0.7 Vp-p (75 Ω)

0.7 Vp-p (75 Ω)

0.5 Vrms
Compliance with DVI Revision 1.0

Compatible with HDCP 1.1

0.5 Vrms, Shared with PC IN
G with sync 1.0 Vp-p (75 Ω)

G without sync 0.7 Vp-p (75 Ω)
B: 0.7 Vp-p (75 Ω)
R: 0.7 Vp-p (75 Ω)
HD/VD: 1.0 - 5.0 Vp-p (high impedance)

0.5 Vrms, Shared with DVI-D IN

For Europe and Asia

220 - 240 V AC,

50/60 Hz

Save off 0.3 W,

Save on 0.2 W

Backlight Off 40 W

Backlight On 100 W

(diagonal)

[5,760 × 1,080 dots]

45.8” × 27.8” × 6.3” /

1,162 mm × 706 mm × 158 mm

Notes:

• Design and specifi cations are subject to change without notice. Mass and dimensions shown are approximate.

• This equipment complies with the EMC standards listed below.
EN55022, EN55024, EN61000-3-2, EN61000-3-3.

47

Information for Users on Collection and Disposal of Old Equipment and used Batteries

These symbols on the products, packaging, and/or accompanying documents mean that used
electrical and electronic products and batteries should not be mixed with general household waste.
For proper treatment, recovery and recycling of old products and used batteries, please take them to
applicable collection points, in accordance with your national legislation and the Directives
2002/96/EC and 2006/66/EC.
By disposing of these products and batteries correctly, you will help to save valuable resources and
prevent any potential negative effects on human health and the environment which could otherwise
arise from inappropriate waste handling.
For more information about collection and recycling of old products and batteries, please contact your
local municipality, your waste disposal service or the point of sale where you purchased the items.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national
legislation.

For business users in the European Union

If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for
further information.

[Information on Disposal in other Countries outside the European Union]

These symbols are only valid in the European Union. If you wish to discard these items, please
contact your local authorities or dealer and ask for the correct method of disposal.

Note for the battery symbol (bottom two symbol examples):

This symbol might be used in combination with a chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical involved.

USA only: This product has a fl uorescent lamp that contains mercury.
Disposal may be regulated in your community due to environmental
considerations. For disposal or recycling information, please visit
Panasonic website: http://www.panasonic.com/environmental or call
1-888-769-0149.

Customer’s Record

The model number and serial number of this product can be found on its rear panel. You should note this serial
number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of your
purchase to aid in identifi cation in the event of theft or loss, and for Warranty Service purposes.

Model Number Serial Number

Pursuant to the directive 2004/108/EC, article 9(2)
Panasonic Testing Centre
Panasonic Service Europe, a division of Panasonic Marketing Europe GmbH
Winsbergring 15, 22525 Hamburg, F.R. Germany

Web Site : http://panasonic.net

© Panasonic Corporation 2011
