Panasonic TC-L47ET5 Service manual

Page 1

ORDER NO.MTNC120204CE

B32 Canada: B61

47 inch Class 1080p LCD HDTV

Model No. TC-L47ET5

LA35 Chassis
© Panasonic Corporation 2012. Unauthorized copying and distribution is a violation of law.
Page 2
TABLE OF CONTENTS
PAG E PAGE
1 Safety Precautions -----------------------------------------------3
1.1. General Guidelines ---------------------------------------- 3
2 Warning --------------------------------------------------------------4
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices ----------4
2.2. About lead free solder (PbF) ----------------------------5
3 Service Navigation------------------------------------------------6
3.1. PCB Layout --------------------------------------------------6
4 Specifications ------------------------------------------------------7 5 Technical Descriptions------------------------------------------8
5.1. Specification of KEY for DTCP-IP, WMDRM and Widevine------------------------------------------------8
6 Service Mode -------------------------------------------------------9
6.1. How to enter into Service Mode ------------------------ 9
6.2. SRV-TOOL------------------------------------------------- 10
6.3. Hotel mode------------------------------------------------- 11
6.4. Data Copy by SD Card --------------------------------- 12
7 Troubleshooting Guide---------------------------------------- 15
7.1. Check of the IIC bus lines ------------------------------ 15
7.2. Power LED Blinking timing chart --------------------- 16
7.3. LCD Panel test mode ----------------------------------- 16
8 Disassembly and Assembly Instructions --------------- 17
8.1. Disassembly Flow Chart for the Unit ---------------- 17
8.2. Disassembly Procedure for the Unit----------------- 17
9 Measurements and Adjustments -------------------------- 33
9.1. Voltage chart of P-board-------------------------------- 33
9.2. Voltage chart of A-board------------------------------- 33
10 Block Diagram --------------------------------------------------- 35
10.1. Main Block Diagram ------------------------------------- 35
10.2. Block (1/2) Diagram ------------------------------------- 36
10.3. Block (2/2) Diagram ------------------------------------- 37
11 Wiring Connection Diagram--------------------------------- 39
11.1. Caution statement.--------------------------------------- 39
11.2. Wiring 1 ----------------------------------------------------- 39
11.3. Wiring 2 ----------------------------------------------------- 40
12 Schematic Diagram 13 Printed Circuit Board 14 Exploded View
Page 3

1 Safety Precautions

1.1. General Guidelines

1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly installed.
3. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
4. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials.
5. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires have been broken or disconnected, do not attempt to repair or re-wire the units. Replace the entire wiring unit instead.
6. When conducting repairs and servicing, do not twist the Fasten connectors but plug them straight in or unplug them straight out.

1.1.1. Leakage Current Cold Check

1. Unplug the AC cord and connect a jumper between the two prongs on the plug.
2. Measure the resistance value, with an ohmmeter, between the jumpered AC plug and each exposed metallic cabinet part on the equipment such as screwheads, connectors, control shafts, etc. When the exposed metallic part has a return path to the chassis, the reading should be 100 Mohm and over. When the exposed metal does not have a return path to the chassis, the reading must be .

1.1.2. Leakage Current Hot Check (See Figure 1.)

1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a 1.5kohm, 10 watts resistor, in parallel with a
0.15μF capacitors, between each exposed metallic part on the set and a good earth ground such as a water pipe, as shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of the above measurements.
6. The potential at any point should not exceed 0.75 volts RMS. A leakage current tester (Simpson Model 229 or equivalent) may be used to make the hot checks, leakage current must not exceed 1/2 milliamp. In case a measurement is outside of the limits specified, there is a possibility of a shock hazard, and the equipment should be repaired and rechecked before it is returned to the customer.
Figure 1
Page 4

2 Warning

2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices

Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor [chip] components. The following techniques should be used to help reduce the incidence of component damage caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap, which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as [anti-static (ESD protected)] can generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise ham less motion such as the brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient to damage an ES device).
Page 5

2.2. About lead free solder (PbF)

Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol PbF stamped on the back of PCB.
Caution
• Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40 °C) higher. Please use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
• Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C). If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before applying Pb solder. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
• After applying PbF solder to double layered boards, please check the component side for excess solder which may flow onto the opposite side. (see figure below)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder. However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used.
's manufacture due to environmental conservation issues. For service and repair work, we'd
Page 6

3 Service Navigation

3.1. PCB Layout

Board Name Function A-Board Main K-Board Remote Receiver, LED, Cat's eye P-Board Power supply GK-Board Power switch, Control Button
Page 7

4 Specifications

Power Source AC 110-127 V, 60 Hz Power Consumption
Rated Power 128 W Standby Power 0.1 W
Display Panel
Panel System LCD panel (LED backlight) Screen size 47 inch class (47.0 inches measured diagonally) W × H × Diagonal 40.9 inch × 23.0 inch × 47.0 inch (1,040 mm × 585 mm × 1,193 mm)
Number of pixels 1,920 × 1,080 Speaker Output 20 W [10 W + 10 W] ( 10 % THD ) Channel Capability (Digital/Analog) VHF/ UHF: 2 - 69, CATV: 1 - 135 Operating Conditions Temperature: 32 °F - 95 °F (0 °C - 35°C)
Humidity: 20 % - 80 % RH (non-condensing)
Connection Terminals
VIDEO IN RCA PIN (VIDEO, AUDIO-L, AUDIO-R)
COMPONENT IN RCA PIN (Y, PB, PR, AUDIO-L, AUDIO-R)
HDMI IN 1/2/3/4 TYPE A Connector (supports [HDAVI Control 5] function)
USB 1/2 USB 2.0 Type A connector
PC IN D-SUB 15PIN (VGA, SVGA, XGA, WXGA, SXGA)
DIGITAL AUDIO OUT PCM / Dolby Digital, Fiber Optic
OTHERS SD CARD slot, ETHERNET (10BASE-T/100BASE-TX) Dimensions (W × H × D)
Including pedestal 43.6 inch × 28.1 inch × 10.6 inch (1,107 mm × 712 mm × 268 mm)
TV Set only 43.6 inch × 26.2 inch × 2.1 inch (1,107 mm × 666 mm × 52 mm) Mass
Including pedestal 45.2 lb. (20.5 kg) NET
TV Set only 37.5 lb. (17.0 kg) NET
Q Wireless LAN
Standard Compliance and
Frequency Range*
Access Mode Infrastructure mode Security WPA2-PSK (TKIP/AES)
1
*
The frequency and channel differ depending on the country.
2
802.11b/g/n CH1 ~ CH11 only use for North America and Canada.
*
Q 3D Eyewear
Lens type Circularly-polarized filter
Operating Conditions Temperature : 32 °F - 104 °F (0 °C - 40 °C) Materials Main body: Resin
Dimensions 5.87 inch × 1.74 inch × 6.74 inch (149.0 mm × 44.0 mm × 171.0 mm) (W × H × Overall length) Mass Approx. 0.64 oz (Approx. 18 g)
• Use Panasonic 3D Eyewear supporting passive 3D system technology.
1,*2
IEEE802.11n / IEEE802.11a:
5.150GHz - 5.850 GHz
IEEE802.11g / IEEE802.11b / IEEE802.11n:
2.400 GHz - 2.4835 GHz
WAP-PSK (TKIP/AES) WEP (64bit/128bit)
Lens section: Resin
Note
Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
Page 8

5 Technical Descriptions

5.1. Specification of KEY for DTCP-IP, WMDRM and Widevine

5.1.1. General information:

1. EEPROM (IC8902) for spare parts has the seed of KEY for each DTCP-IP for DLNA, WMDRM for Netflix and Widevine for CinemaNow.
2. The final KEY data will be generated by Peaks IC (IC8000) when SELF CHECK was done and are stored in both Peaks IC (IC8000) and EEPROM (IC8902).

5.1.2. Replacement of ICs:

When Peaks IC is replaced, EEPROM should be also replaced with new one the same time. When EEPROM is replaced, Peaks IC is not necessary to be replaced the same time. After the replacement of IC, SELF CHECK should be done to generate the final KEY data. How to SELF CHECK: While pressing [VOLUME ( - )] button on the main unit, press [MENU] button on the remote control for more than 3 seconds. TV will be forced to the factory shipment setting after this SELF CHECK.
Page 9

6 Service Mode

6.1. How to enter into Service Mode

6.1.1. Purpose

After exchange parts, check and adjust the contents of adjustment mode.
While pressing [VOLUME ( - )] button of the main unit, press [INFO] button of the remote control three times within 2 seconds.
Note:
Service Mode can not be entered when 3D signal input. Input 2D signal to enter Service Mode.

6.1.2. Key command

[1] button...Main items Selection in forward direction [2] button...Main items Selection in reverse direction [3] button...Sub items Selection in forward direction [4] button...Sub items Selection in reverse direction [VOL] button...Value of sub items change in forward direction ( + ), in reverse direction ( - )

6.1.3. How to exit

Switch off the power with the [POWER] button on the main unit or the [POWER] button on the remote control.

6.1.4. Contents of adjustment mode

• Value is shown as a hexadecimal number.
• Preset value differs depending on models.
• After entering the adjustment mode, take note of the value in each item before starting adjustment.
Main item Sub item Sample Data Remark
ADJUST CONTRAST 000
COLOR 50 TINT 00 SUB-BRT 800 BACKLGT 086 B-Y-G 40 R-Y-A 00 V COM 000
WB-ADJ R-GAIN 80
G-GAIN 6C B-GAIN 5E R-CENT 77 G-CENT 80 B-CENT 89
OPTION Boot SD Factory Preset.
STBY-SET 00 EMERGENCY ON CLK MODE 00 CLOCK 045 EDID-CLK HIGH
SRV-TOOL 00 See next.
Page 10

6.2. SRV-TOOL

6.2.1. How to access

1. Select [SRV-TOOL] in Service Mode.
2. Press [OK] button on the remote control.

6.2.2. Display of SOS History

SOS History (Number of LED blinking) indication. From left side; Last SOS, before Last, three occurrence before, 2nd occurrence after shipment, 1st occurrence after shipment. This indication except 2nd and 1st occurrence after shipment will be cleared by [Self-check indication and forced to factory shipment setting].

6.2.3. POWER ON TIME/COUNT

Note : To display TIME/COUNT menu, highlight position, then press MUTE for 3 sec. Time : Cumulative power on time, indicated hour : minute by decimal Count : Number of ON times by decimal Note : This indication will not be cleared by either of the self-checks or any other command.

6.2.4. Exit

1. Disconnect the AC cord from wall outlet.
10
Page 11

6.3. Hotel mode

1. Purpose Restrict a function for hotels.
2. Access command to the Hotel mode setup menu In order to display the Hotel mode setup menu: While pressing [VOLUME (-)] button of the main unit, press [INPUT] button of the remote control three times within 2 seconds.
Then, the Hotel mode setup menu is displayed.
3. To exit the Hotel mode setup menu Disconnect AC power cord from wall outlet.
4. Explain the Hotel mode setup menu
Item Function Mode Select hotel mode off/on Input Select input signal modes.
Set the input, when each time power is switched on. Selection:
-,RF,HDMI1,HDMI2,HDMI3,HDMI4, Comp./Video,PC
• OFF: give priority to a last memory.
Channel Select channel when input signal is RF.
Set the channel, each time power is switched on. Selection: Any channel number or [-]. [-] means the channel when turns off.
Volume Adjust the volume when each time power is
switched on. Range: 0 to 100
Vol. Max Adjust maximum volume.
Range: 0 to 100
OSD Ctrl Restrict the OSD.
Selection: Off/Pattern1
• Off: No restriction
• Pattern1: restriction
FP Ctrl Select front key conditions.
Selection: Off/Pattern1/All
• Off: altogether valid.
• Pattern1: only input key is valid.
• All: altogether invalid.
Pow Ctrl Select POWER-ON/OFF condition when AC
power cord is disconnected and then connected. Off: The same condition when AC power cord is disconnected. On: Forced power ON condition.
11
Page 12

6.4. Data Copy by SD Card

6.4.1. Purpose

(a) Board replacement (Copy the data when exchanging A-board):
When exchanging A-board, the data in original A-board can be copied to SD card and then copy to new A-board.
(b) Hotel (Copy the data when installing a number of units in hotel or any facility):
When installing a number of units in hotel or any facility, the data in master TV can be copied to SD card and then copy to other TVs.

6.4.2. Preparation

Make pwd file as startup file for (a) or (b) in a empty SD card.
1. Insert a empty SD card to your PC.
2. Right-click a blank area in a SD card window, point to New, and then click text document. A new file is created by default (New Text Document.txt).
3. Right-click the new text document that you just created and select rename, and then change the name and extension of the file to the following file name for (a) or (b) and press ENTER.
File name:
(a) For Board replacement : boardreplace.pwd (b) For Hotel : hotel.pwd
Note:
Please make only one file to prevent the operation error.
No any other file should not be in SD card.
12
Page 13

6.4.3. Data copy from TV set to SD Card

1. Turn on the TV set.
2. Insert SD card with a startup file (pwd file) to SD slot. On-screen Display will be appeared according to the startup file automatically.
3. Input a following password for (a) or (b) by using remote control.
(a) For Board replacement : 2770
(b) For Hotel : 4850 Data will be copied from TV set to SD card. It takes around 2 to 6 minutes maximum for copying.
4. After the completion of copying to SD card, remove SD card from TV set.
5. Turn off the TV set.
Note:
Following new folder will be created in SD card for data from TV set.
(a) For Board replacement : user_setup (b) For Hotel : hotel
13
Page 14

6.4.4. Data copy from SD Card to TV set

1. Turn on the TV set.
2. Insert SD card with Data to SD slot. On-screen Display will be appeared according to the Data folder automatically.
3. Input a following password for (a) or (b) by using remote control.
(a) For Board replacement : 2771 (b) For Hotel : 4851
Data will be copied from SD card to TV set.
4. After the completion of copying to SD card, remove SD card from TV set.
(a) For Board replacement : Data will be deleted after copying (Limited one copy). (b) For Hotel : Data will not be deleted and can be used for other TVs.
5. Turn off the TV set.
Note:
1. Depending on the failure of boards, function of Data copy for board replacement does not work.
2. This function can be effective among the same model numbers.
14
Page 15

7 Troubleshooting Guide

Use the self-check function to test the unit.
1. Checking the IIC bus lines
2. Power LED Blinking timing

7.1. Check of the IIC bus lines

7.1.1. How to access

Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds. Self-check indication and forced to factory shipment setting: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [MENU] button on the remote
control for more than 3 seconds.

7.1.2. Exit

Disconnect the AC cord from wall outlet.

7.1.3. Screen display

7.1.4. Check Point

Confirm the following parts if NG was displayed.
DISPLAY Check Ref. No. Description Check Point PEAKS IC8000 PEAKS A-Board TUN TU6706 TUNER A-Board MEM1 IC8902 PEAKS EEPROM A-Board MEM2 IC8900 NAND FLASH A-Board FRC IC9100 FRC A-Board ID ID HDMI-SW IC4700 HDMI-SW A-Board WiFi IC8000,A20 WiFi A-Board/WiFi
15
Page 16

7.2. Power LED Blinking timing chart

1. Subject Information of LED Flashing timing chart.
2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit.
Blinking Times Contents Check point
1 BACK LIGHT SOS LCD PANEL
3 IROM BOOT PROGRAM SOS A-Board
7 SUB 3.3V SENSE SOS A-Board 8 SOS (T-CON power) A-Board 9 SOUND SOS A-Board
10 ZWEI/FRC SOS A-Board 12 BE SOS A-Board 13 EMERGENCY SOS A-Board 20 2nd BOOT PROGRAM SOS
(Watchdog timer over flow)
21 2nd BOOT PROGRAM SOS
(System error)
22 2nd BOOT PROGRAM SOS
(Main system bus freeze)
23 2nd BOOT PROGRAM SOS
(Accidental interrupt signal)
24 2nd BOOT PROGRAM SOS
(NAND Flash memory data transfer error shut down)
25 2nd BOOT PROGRAM SOS
(Unsupported NAND Flash memory)
P-Board
P-Board
Speaker
A-Board
A-Board
A-Board
A-Board
A-Board
A-Board

7.3. LCD Panel test mode

Purpose:
To find the possible failure point where in LCD Panel or Printed Circuit Board when the abnormal picture is displayed.
How to Enter:
While pressing [VOLUME ( - )] button of the main unit, press [OPTION] button of the remote control three times within 2 seconds.
How to Exit:
Disconnect AC plug from wall outlet.
How to confirm:
If the abnormal picture is displayed, go into LCD Panel test mode to display the several test patterns. And then, judge by the following method. Still abnormal picture is displayed: The cause must be in LCD Panel. Normal picture is displayed: The cause must be in A board.
Remarks:
The test pattern is created by the circuit in LCD Panel. In LCD Panel test mode, this test pattern is displayed unaffected by signal processing for RF or input signal. If the normal picture is displayed, LCD Panel must be okay and the cause of failure must be in A board.
16
Page 17

8 Disassembly and Assembly Instructions

8.1. Disassembly Flow Chart for the Unit

This is a disassembly chart. When assembling, perform this chart conversely.

8.2. Disassembly Procedure for the Unit

8.2.1. Pedestal

1. Lay down the unit so that the rear cover faces upward.
2. Remove the 4 screws.
3. Remove the pedestal.

8.2.2. WiFi dongle

1. Remove the 1 screw.
2. Remove the WiFi Dongle.
17
Page 18

8.2.3. Back cover

1. Remove the 18 screws (A).
2. Remove the 15 screws (B).
3. Remove the 4 M6 CAPs.
4. Remove the Back cover.

8.2.5. A-Board

1. Remove the 2 screws.
2. Remove the metal AV bracket bottom.

8.2.4. P-Board

1. Remove the 5 screws.
2. Disconnect the connectors (P2 and P4).
3. Remove the P-Board.
4. Remove the Barrier P PCB.
3. Remove the 1 screw.
4. Remove the metal AV bracket side.
5. Remove the 3 screws.
6. Disconnect the connectors (A02, A10, A12 ,A20 ,TC01A and TC02A).
7. Remove the A-Board.
18
Page 19
8. Remove the 4 screws.
9. Remove the metal CH frame L/R.

8.2.6. K-Board

1. Remove the 2 screws.
2. Remove the bottom cover.
8. Remove the K-Board.

8.2.7. GK-Board

1. Remove the 2 screws.
2. Remove the control panel.
3. Remove the 6 screws (C).
4. Remove the 2 screws (D).
5. Remove the bottom metal.
6. Remove the 4 locking tabs.
7. Disconnect the connector (K10).
3. Remove the 3 screws.
4. Disconnect the connector (GK4).
5. Remove the GK-Board and the key button.
19
Page 20

8.2.8. Speaker unit L/R

1. Remove the speaker unit L/R.
2. Remove the 4 screws.
3. Remove the 4 speaker brackets.

8.2.9. WiFi metal

1. Remove the 1 screw.
2. Remove the WiFi metal, the USB Cable and the USB cable bracket.

8.2.10. Vesa metal

1. Remove the 4 screws.
2. Remove the 4 vesa metals.

8.2.11. Cabinet and LCD panel

1. Remove the cabinet and the LCD panel.
20
Page 21

8.2.12. EMI processing

21
Page 22
2223242526272829303132
Page 23
Page 24
Page 25
Page 26
Page 27
Page 28
Page 29
Page 30
Page 31
Page 32
Page 33

9 Measurements and Adjustments

9.1. Voltage chart of P-board

VOLTAGE TEST POINT SPECIFICATION
5VS TP7412,7507 5.3V±0.1V 16V TP7508,7514 16.1V±0.6V 24V TP7512,7513 24V±1.2V

9.2. Voltage chart of A-board

VOLTAGE TEST POINT SPECIFICATION
PANEL12V TP4004/TP4005 11.45V - 12.55V
USB_5V TP5440 4.94V - 5.40V
SUB5V TP5420 4.95V - 5.65V SUB3.3V TP5400 3.17V - 3.43V SUB1.8V TP8700 1.7V - 1.9V SUB1.5V TP8101 1.435V - 1.585V SUB1.1V TP8100 1.10V - 1.22V FRC1.0V TP9300 0.95V - 1.05V FRC1.8V TP9301 1.71V - 1.89V
33
Page 34
34
Page 35

10 Block Diagram

(LED:9 TIMES)
(LED:7 TIMES)
(LED:1 TIME)
(LED:9 TIMES)
(LED:7 TIMES)
(LED:1 TIME)
(LED:9 TIMES)
(LED:7 TIMES)
(LED:1 TIME)
STB1.1V
P15V
R
DDR3
SUB_AI_3.3V
TC01A and TC02A
K
SUB5V
HDMI2
P16V
SUB1.8V
HDMI MUX
HDMI3.3V
WiFi
P2
HDMI3.3V
R/G/B/H/V
5VS
A20
P4
SUB3.3V SENSE
SLOT
TMDS DATA
REMOTE IN
STB5V
DIGITAL
A10
USB2
V/COMP
GK4
IECOUT
ASDOUT0
AUDIO
SUB1.5V
BL_PWM
SUB3.3V
PEAKS_EEPROM
USB1
HDMI RX
SUB1.5V
LCD PANEL
P15V
SUB5V
A
DCDC
REMOTE RECEIVER
STB1.2V
SUB3.3V
STB5V
L/R
AUDIO
L
BL_PWM
BL_ON
SUB1.1V
SD CARD DATA
SUB1.8V
DCDC
POWER LED(R)
STB3.3V
SUB_ON
SUB1.1V
USB I/F
USB2.0_IF
PNL12V
ARC OUT
POWER SW
PANEL_3D_ON
A02
FRC
DCDC
SPEAKER(R)
LVDS TX
SUB ON
STB3.3V
SD CARD
KEY1
SUB3.3V
ANALOG-ASIC
V/Y,PB,PR
ARC
SUB3.3V
SPI
POWER LED
IFD_OUT
USB5V
PANEL
TUNER
USB5V
HDMI4
TMDS DATA
LED/RM/CATS
KEY3
DCDC
SUB3.3V
GK
SWITCH
DCDC
BL_ON
POWER
LCD DRIVER
P
TMDS DATA
HDMI3
DCDC
C.A.T.S. SENSOR
STB3.3V
SD IF
LAN DATA
USB2.0_IF
DMD
OUT
MAIN
SUB3.3V
SUB_ON
BL_PWM
SIF_OUT
ETHERNET
K10
SUB_ON
DCDC
BL_ON
DDR
KEY1KEY1
TMDS DATA
LLC CONVERTER
P15V
REG
PANEL12V
Peaks LD4
DCDC
INPUT FILTER
ETHER PHY
JK7101
SUB5V
SPEAKER(L)
LED BACK LIGHT
KEY3
NAND IF
BL_SOS
NEUTRAL
BL_SOS
BL_SOS
AC CORD
A12
24V
NAND FLASH
STB5V
USB2.0_IF
PNL12V
16V
PC
PFC
SUB9V
AC DETECT
CONTROL PANEL KEY
KEY3(POWER ON)
LIVE
PANEL_3D_ON
HDMI1
USB5V
AMP
SUB3.3V
OVP DET
SUB1.5V
SOUND SOS
SUB1.1V
STB3.3V
SUB5V
C.A.T.S. SENSOR

10.1. Main Block Diagram

35
Page 36

10.2. Block (1/2) Diagram

COLDHOT
COLDHOT
POWER
P
D7102
RECTIFIER
CF7101,2
**
LF7103-5
LINE FILTER
F7101
2
1
JK7202
AC CORD
IC7201, T7201, Q7201
PFC
MAIN
A
IC7301, Q7301, Q7302
LLC CONVERTER
AC DETECT
PC7301
PC7302
PC7303
T7301
PHOTO COUPLER
PHOTO COUPLER
PHOTO COUPLER
D7408,9
D7401,2
COLDHOT
D7407
IC7401
ERROR DETCT
PA7406
P4
LCD PANEL
IC7502
PA7401
+24V
7
LED DRIVE
8
LCD DRIVER
+24V15+24V
91
STB6V
+6V
Q7402
BL_PWM
BL_ON
23
BL_SOS
KEY3
10 11
Q7403
KEY1
PA7402
KEY1
KEY3
BL_SOS
BL_ON
BL_PWM
GK4
2
3
GK
P2
5
3
2
1
7
8
KEY3(POWER ON)
9
10 4
11
13 10
SW
SW2851-2855
CONTROL PANEL KEY
SW2857
POWER SW
5.8VS
+16V
+16V
+16V
SUB_ON
KEY1
BL_SOS
BL_ON
BL_PWM
PNL12V
PANEL_3D_ON
P15V
5.8VS
PANEL12V
LVDS DATA
LVDS DATA
IC5300
+12V
P15V
PNL12V
D5300
D5301
PANEL_VCC_ON
FRC DCDC CTRL
SOS_SENSE
IC9300
PANEL_3D_ON
SUB_ON
KEY1
KEY3
BL_SOS
BL_ON
BL_PWM
LVDS TX CHB
LVDS TX CHA
DCDCEN
USB5V
PNL3.3V
IC5440
IC5420
IC5400
+3.3V
+5V
SUB5V
+5V
SUB3.3V
+3.3V
IC9351
D5179
D5187
PA5440
IC9302
FRC1.8V
IC9301
FRC1.0V
+1.8V
+1.0V
IC9250
DDR
IC9350
SPI
IIC0
IIC0
IC9100
FRC
IC9303
FRC2.5V
+5V
OVP
D5178
D5188
D5172
D5173
1
5.8VS
2
USB5V
3
SUB5V
4
SUB3.3V
5
6
P15V
7
A02
9
5
3
1
13
2
6
TC 01A
1
4
51
11
40
TC 02A
3
32
36
Page 37

10.3. Block (2/2) Diagram

(LED:1 TIME)
(LED:7 TIMES)
(LED:3 TIMES)
(LED:9 TIMES)
(LED:1 TIME)
(LED:7 TIMES)
(LED:3 TIMES)
(LED:9 TIMES)
USB I/F
USB0VBUS
+1.8V
+3.3V
CN8660
SD CARD
SD DATA
+1.1V
+5V
SD CARD I/F
VDDSD1.8V3.3V
+1.5V
JK8600A
ETHERNET
IC8600
ETHER PHY
SUB3.3V
LAN I/F
X8600
25MHz
DIGITAL AUDIO OUT
IC8000
DDR I/F
D3006
LD4
IEC_OUT
(LED:3 TIMES)
PANEL_VCC_ON
SOS
KEY1
JK4701A
HDMI2
ARC_OUT
DDC IIC2
TMDS DATA/CLOCK
Rx1
DDC1
ARC_OUT
BL_SOS
(LED:1 TIME)
PANEL_PWM
BL_ON
+5V
HDMI_CEC
HDMI_5V_DET1
SW_OFF_DET
STB_RST
JK4700A
HDMI1
TMDS DATA/
CLOCK
Rx2
3D_LED_ON
POWER_DET
+5V
DDC IIC0
DDC2
JK4702A
TMDS DATA/
HDMI_CEC
HDMI_5V_DET2
HDMI3
CLOCK
+5V
DDC IIC3
HDMI_5V_DET0
STB1.1V
HDMI_CEC
CEC
CEC PUL
STB3.3V
JK4703A
HDMI4
DDC IIC1
TMDS DATA/
CLOCK
+5V
HDMI_CEC
HDMI_5V_DET3
IC4700
DDC1_IIC
DDC3_IIC
RX1
RX2
CATS_EYE
HDMI MUX
POWER_LED_ON
RM_IN
SEL1
SEL2
FOR FACTORY USE
CN0100
IIC0 IIC1 STM_IIC SBO0/SBI0
IC8706
AVDDH3.3V
3.3V
IIC3
Rx0
DDC0
IIC1
HDMI_3.3V
IIC0
IIC3
DMD_ IIC0
SBI0 SBO0
NAND I/F
CPU BUS
+3.3V
IIC1
IC8902
PEAKS EEPROM
IIC0
IIC3
DMD_ IIC0
SBI0 SBO0
IC8900
NAND FLASH
SUB5V
SUB3.3V
SPEAKER_L
JK3001
COMPONENT/VIDEO
MAIN
MAIN
A
A
L
R
PB
Y/V
JK3005B
PC
PR
PC-R
PC-B
PC-G
PC-H
PC-V
ANTENNA/ CABLE IN
FE_XRST
AGC1/2
IFD1/2
SUB1.8V
SUB3.3V
DMC_IIC0
TU6706
TUNER
P15V
SPEAKER_R
4
A12
R(-)
15V
IFD1/2
AGC1/2
FE_XRST
RGB/YPbPr/CVBS/YC HS,VS
L/R
SUB3.3V_SENSE (LED:7 TIMES)
3
R(+)
IC4900
AUDIO AMP
SOS
SOUND SOS
(LED:9 TIMES)
PWM
PWM
JK8450
JK8451
USB2
2
1
L(-)
L(+)
USB1
IC8453
USB5V
USB I/F
USB1VBUS
LVDS I/F
IC8454
USB2VBUS
A20
WiFi
IC8457
SUB3.3V
1
5.8VS
2
USB5V
3
SUB5V
4
SUB3.3V
5
6
P15V
7
D5188
+1.8V
IC8100
IC8101
D5187
D5191
+1.1V
SUB1.5V
+1.5V
SUB1.1V
SUB1.8V
IC8702
IC8200
IC8201
DDR3
OVP
P_PWMA
BL_PWM
STBRST
SW_OFF_DET
SUB ON
OVP
DCDCEN
STB5V
PANEL_VCC_ON
SOS_SENSE
KEY1
BL_ON
P_PWMA
BL_SOS
ANALOG-ASIC
SUB5V
5VS
PWM_A_IN
PWM_A_OUT
STB_RESET
SW_OFF_DET
SUB ON
OVP DET
DCDC CTL
P15V
SW_OFF_DET
STB_RST
IC5000
LATCH
3D_LED_ON
SUB_AI_3.3V
STB1.1V
STB3.3V
R_LED_LED
REMOTE
AI_SENSOR
STB3.3V
REMOTE
R_LED_ON
AI_SENSOR
POWER LED/REMOTE RECEIVER/C.A.T.S. SENSOR
K
POWER LED
D2800B
A10
5
3
9
6
7
STB3.3V
R_LED_ON
REMOTE
AI_SENSOR
SUB3.3V
K10
3
1
7
4
5
REMOTE RECEIVER
RM2800
VCC
C.A.T.S. SENSOR
SN2800
GND
OUT
123
37
Page 38
38
Page 39

11 Wiring Connection Diagram

11.1. Caution statement.

Caution:
Please confirm that all flexible cables are assembled correctly. Also make sure that they are locked in the connectors. Verify by giving the flexible cables a very slight pull.

11.2. Wiring 1

39
Page 40

11.3. Wiring 2

40
Page 41

Model No. : TC-L47ET5 Schematic Diagram Note

S-1
Page 42

Model No. : TC-L47ET5 Replacement Parts List Note

S-2
Page 43

Model No. : TC-L47ET5 P-Board (1/2)

S-3
Page 44

Model No. : TC-L47ET5 P-Board (2/2)

S-4
Page 45

Model No. : TC-L47ET5 A-Board (1/9)

S-5
Page 46

Model No. : TC-L47ET5 A-Board (2/9)

S-6
Page 47

Model No. : TC-L47ET5 A-Board (3/9)

S-7
Page 48

Model No. : TC-L47ET5 A-Board (4/9)

S-8
Page 49

Model No. : TC-L47ET5 A-Board (5/9)

S-9
Page 50

Model No. : TC-L47ET5 A-Board (6/9)

S-10
Page 51

Model No. : TC-L47ET5 A-Board (7/9)

S-11
Page 52

Model No. : TC-L47ET5 A-Board (8/9)

S-12
Page 53

Model No. : TC-L47ET5 A-Board (9/9)

S-13
Page 54

Model No. : TC-L47ET5 GK-Board and K-Board

S-14
Page 55

Model No. : TC-L47ET5 P-Board (Foil Side)

S-15
Page 56

Model No. : TC-L47ET5 P-Board (Component Side)

S-16
Page 57

Model No. : TC-L47ET5 A-Board (Foil Side)

S-17
Page 58

Model No. : TC-L47ET5 A-Board (Component Side)

S-18
Page 59

Model No. : TC-L47ET5 K-Board

S-19
Page 60

Model No. : TC-L47ET5 GK-Board

S-20
Page 61
Model No. : TC-L47ET5 Parts List
S-21
Safety
Ref.
No.
PCB TXN/A1SKUUS CIRCUIT BOARD A 1 (RTL) PAVCA
PCB TXN/K1SKUUS CIRCUIT BOARD K 1 (RTL) PAVCA
PCB TXN/P1SKUU CIRCUIT BOARD P 1 (RTL) PAVCA
PCB TXNGK1SLUU CIRCUIT BOARD GK 1 (RTL) PAVCA
A02 K1KY16BA0394 16P CONNECTOR 1 PAVCA
A10 K1KA10B00218 10P CONNECTOR 1
A12 K1KY04BA0387 4P CONNECTOR 1 PAVCA
A20 K1FY105E0017 CONNECTOR 1 PAVCA
C0900 F1G1H220A834 C 22PF, 50V 1 PAVCA
C0902 F1G1H220A834 C 22PF, 50V 1 PAVCA
C1958 F1G1E1030005 C 0.01UF 25V 1
C2000 F1G1A105A047 C 1UF 10V 1
C2014 F1K1E106A134 C 10UF, 25V 1
C2023 F1G1C104A077 C 0.1UF 16V 1
C2802 F1G1C1030008 C 0.01UF 16V 1
C2805 ECJ1XB1C104K C 0.1UF, Z, 16V 1
C2811 F1J1A106A087 C 10UF, 10V 1
C3084 F1H0J105A051 C 1UF, 6.3V 1 PAVCA
C3085 F1H0J105A051 C 1UF, 6.3V 1 PAVCA
C3086 F1H0J105A051 C 1UF, 6.3V 1 PAVCA
C3116 F1H0J105A051 C 1UF, 6.3V 1 PAVCA
C3117 F1H0J105A051 C 1UF, 6.3V 1 PAVCA
C3118 F1H0J105A051 C 1UF, 6.3V 1 PAVCA
C3159 F1H1A105A099 C 1UF, 10V 1 PAVCA
C3160 F1H1A105A099 C 1UF, 10V 1 PAVCA
C4702 F1H0J105A051 C 1UF, 6.3V 1 PAVCA
C4713 F1G1C104A077 C 0.1UF 16V 1
C4716 F1G1C104A077 C 0.1UF 16V 1
C4722 F1G1C104A077 C 0.1UF 16V 1
C4723 F1G1C104A077 C 0.1UF 16V 1
C4727 F1J1A106A087 C 10UF, 10V 1
C4900 F1K1V106A010 C 10UF, 25V 1 PAVCA
C4901 F1K1V106A010 C 10UF, 25V 1 PAVCA
C4903 F1G1C104A077 C 0.1UF 16V 1
C4904 F1G1C104A077 C 0.1UF 16V 1
C4905 F1G1C104A077 C 0.1UF 16V 1
C4906 F1G1C104A077 C 0.1UF 16V 1
C4907 F1K1V106A010 C 10UF, 25V 1 PAVCA
C4909 F1K1V106A010 C 10UF, 25V 1 PAVCA
C4921 F1J1E474A272 C 4.7UF, 25V 1 PAVCA
C4922 F1J1E474A272 C 4.7UF, 25V 1 PAVCA
C4923 F1J1E474A272 C 4.7UF, 25V 1 PAVCA
C4924 F1J1E474A272 C 4.7UF, 25V 1 PAVCA
C5000 F1G1A105A047 C 1UF 10V 1
C5002 F1G1A105A047 C 1UF 10V 1
C5004 F1G1A105A047 C 1UF 10V 1
C5006 F1J1E105A287 C 1UF, 25V 1 PAVCA
C5012 F1G1A105A047 C 1UF 10V 1
C5020 F1G1C104A077 C 0.1UF 16V 1
C5021 F1G1A105A047 C 1UF 10V 1
C5022 F1G1A105A047 C 1UF 10V 1
C5026 F1H1C105A145 C 1 uF 16 V 1
C5150 F1G1E1030005 C 0.01UF 25V 1
C5151 F1G1E1030005 C 0.01UF 25V 1
C5171 F1G1C1030008 C 0.01UF 16V 1
C5318 F1G1H332A730 C 3300PF, 50V 1 PAVCA
C5319 F1K1E106A134 C 10UF, 25V 1
C5320 F1K1E106A134 C 10UF, 25V 1
C5321 F1K1E106A134 C 10UF, 25V 1
Part No. Part Name & Description Q'ty Remarks
Page 62
Model No. : TC-L47ET5 Parts List
S-22
Safety
Ref.
No.
C5322 F1K1E106A134 C 10UF, 25V 1
C5323 F1K1E106A134 C 10UF, 25V 1
C5324 F1K1E106A134 C 10UF, 25V 1
C5325 F1G1H103A835 C 0.01UF, 50V 1 PAVCA
C5326 F1G1C183A116 C 0.018UF, 16V 1
C5328 F1G1H472A571 C 4700PF. 50V 1
C5400 F1K1V106A010 C 10UF, 25V 1 PAVCA
C5401 F1K1V106A010 C 10UF, 25V 1 PAVCA
C5402 F1G1C104A077 C 0.1UF 16V 1
C5403 F1J0J2260004 C 22 UF 6.3 V 1
C5404 F1J0J2260004 C 22 UF 6.3 V 1
C5407 F1G1E333A059 C 0.033UF, 25V 1 PAVCA
C5408 F1G1H222A830 C 2200PF, 50V 1 PAVCA
C5420 F1K1V106A010 C 10UF, 25V 1 PAVCA
C5421 F1K1V106A010 C 10UF, 25V 1 PAVCA
C5422 F1G1C104A077 C 0.1UF 16V 1
C5423 F1J0J2260004 C 22 UF 6.3 V 1
C5424 F1J0J2260004 C 22 UF 6.3 V 1
C5427 F1G1E333A059 C 0.033UF, 25V 1 PAVCA
C5428 F1G1H222A830 C 2200PF, 50V 1 PAVCA
C5440 F1K1V106A010 C 10UF, 25V 1 PAVCA
C5441 F1K1V106A010 C 10UF, 25V 1 PAVCA
C5442 F1G1C223A081 C 0.022UF, 16V 1
C5443 F1J0J2260004 C 22 UF 6.3 V 1
C5444 F1J0J2260004 C 22 UF 6.3 V 1
C5448 F1H1C105A145 C 1 uF 16 V 1
C5449 F1G1C104A077 C 0.1UF 16V 1
C5450 F1G1H100A833 C 10PF 50V 1 PAVCA
C6707 F1G1C104A077 C 0.1UF 16V 1
C6710 F1G1C104A077 C 0.1UF 16V 1
C6712 F1G1C104A077 C 0.1UF 16V 1
C6713 F1G1C104A077 C 0.1UF 16V 1
C6715 F1G1C104A077 C 0.1UF 16V 1
C6716 F1G1C104A077 C 0.1UF 16V 1
C6733 F1G1C104A077 C 0.1UF 16V 1
C6743 F1G1C104A077 C 0.1UF 16V 1
C6744 F1G1C104A077 C 0.1UF 16V 1
C6745 F1G1C104A077 C 0.1UF 16V 1
C6746 F1G1C104A077 C 0.1UF 16V 1
C6747 F1G1C104A077 C 0.1UF 16V 1
C6770 F1G1C104A077 C 0.1UF 16V 1
C6771 F1G1C104A077 C 0.1UF 16V 1
C6772 F1G1C104A077 C 0.1UF 16V 1
C6773 F1G1H220A834 C 22PF, 50V 1 PAVCA
C6774 F1G1H220A834 C 22PF, 50V 1 PAVCA
C7102 F1A2E471A007 C 470PF, 250V 1 PAVCA
C7103 F1A2E471A007 C 470PF, 250V 1 PAVCA
C7104 F0CAF224A124 C 0.22UF, 250V 1 PAVCA
C7105 F0CAF224A124 C 0.22UF, 250V 1 PAVCA
C7107 F1A2E471A007 C 470PF, 250V 1 PAVCA
C7201 F1J1H102A909 C 1000pF, 50V 1 PAVCA
C7202 F1J1H102A909 C 1000pF, 50V 1 PAVCA
C7203 F1J1H223A900 C 0.022UF, 50V 1 PAVCA
C7204 F1J1E224A272 C 2.2UF, 25V 1 PAVCA
C7206 F1J1E475A257 C 47UF, 25V 1 PAVCA
C7207 F1A3A221A060 C 220PF 1KV 1
C7209 ECWF2W105KAC C 1UF, 450V 1 PAVCA
C7213 F2A2W6800011 C 68UF 450V 1 PAVCA
C7214 F1J1H102A909 C 1000pF, 50V 1 PAVCA
C7302 F1J1H104A902 C 0.1UF, 50V 1 PAVCA
C7303 F1J1H104A902 C 0.1UF, 50V 1 PAVCA
C7304 F1A3A221A060 C 220PF 1KV 1
Part No. Part Name & Description Q'ty Remarks
Page 63
Model No. : TC-L47ET5 Parts List
S-23
Safety
Ref.
No.
C7305 F1J1H104A902 C 0.1UF, 50V 1 PAVCA
C7306 F1J1H104A902 C 0.1UF, 50V 1 PAVCA
C7307 F1J1H101A906 C 100PF, 50V 1 PAVCA
C7308 ECWH8223HAC C 0.022UF, Z, 800V 1 PAVCA
C7310 F2A1V3310067 C 150UF 35V 1 PAVCA
C7311 F1J1E105A287 C 1UF, 25V 1 PAVCA
C7312 F1J1H474A757 C 0.47UF, 50V 1
C7313 F1J1H102A909 C 1000pF, 50V 1 PAVCA
C7314 F1J1H101A906 C 100PF, 50V 1 PAVCA
C7315 F1A3A221A060 C 220PF 1KV 1
C7316 F1A3A221A060 C 220PF 1KV 1
C7416 F1J1C475A225 C 4.7UF, 10V 1 PAVCA
C7417 F1J1E105A287 C 1UF, 25V 1 PAVCA
C7418 F1J1H104A902 C 0.1UF, 50V 1 PAVCA
C7422 F2A1V6810039 C 680UF 35V 1 PAVCA
C7423 F2A1E6810033 E 680UF 25V 1 PAVCA
C7427 F1A3A471A060 C 470PF 1KV 1
C7428 F1A3A471A060 C 470PF 1KV 1
C7429 F1K1E106A134 C 10UF, 25V 1
C7514 F2A1C2220116 C 2200UF 16V 1 PAVCA
C7515 F1J1E105A287 C 1UF, 25V 1 PAVCA
C8002 F1J1A106A087 C 10UF, 10V 1
C8004 F1G1C104A077 C 0.1UF 16V 1
C8005 F1G1C104A077 C 0.1UF 16V 1
C8007 F1J1A106A087 C 10UF, 10V 1
C8014 F1J0G2260001 C 22 UF 4 V 1
C8017 F1G1C104A077 C 0.1UF 16V 1
C8019 F1G1C104A077 C 0.1UF 16V 1
C8020 F1G1C104A077 C 0.1UF 16V 1
C8022 F1G1C104A077 C 0.1UF 16V 1
C8023 F1G1C104A077 C 0.1UF 16V 1
C8024 F1G1C104A077 C 0.1UF 16V 1
C8025 F1G1A105A047 C 1UF 10V 1
C8031 F1J1A106A087 C 10UF, 10V 1
C8033 F1J1A106A087 C 10UF, 10V 1
C8034 F1J0G2260001 C 22 UF 4 V 1
C8035 F1G1C104A077 C 0.1UF 16V 1
C8036 F1G1A105A047 C 1UF 10V 1
C8038 F1J0G2260001 C 22 UF 4 V 1
C8039 F1J0G2260001 C 22 UF 4 V 1
C8100 F1G1C223A146 C 0.022UF, 16V 1 PAVCA
C8101 F1H1C105A145 C 1 uF 16 V 1
C8102 F1G1C104A077 C 0.1UF 16V 1
C8103 F1K1E106A134 C 10UF, 25V 1
C8105 F1J0G2260001 C 22 UF 4 V 1
C8106 F1J0G2260001 C 22 UF 4 V 1
C8108 ECJ1VB1E104K C 0.1 UF, 25V 1
C8110 F1G1C183A146 C 0.018UF, 16V 1 PAVCA
C8111 F1H1C105A145 C 1 uF 16 V 1
C8112 F1G1C104A077 C 0.1UF 16V 1
C8113 F1K1E106A134 C 10UF, 25V 1
C8115 F1J0G2260001 C 22 UF 4 V 1
C8116 F1J0G2260001 C 22 UF 4 V 1
C8118 ECJ1VB1E104K C 0.1 UF, 25V 1
C8203 F1G1C104A077 C 0.1UF 16V 1
C8204 F1G1C104A077 C 0.1UF 16V 1
C8205 F1G1C104A077 C 0.1UF 16V 1
C8206 F1G1C104A077 C 0.1UF 16V 1
C8207 F1J1A106A087 C 10UF, 10V 1
C8208 F1G1C104A077 C 0.1UF 16V 1
C8210 F1G1C104A077 C 0.1UF 16V 1
C8212 F1G1C104A077 C 0.1UF 16V 1
Part No. Part Name & Description Q'ty Remarks
Page 64
Model No. : TC-L47ET5 Parts List
S-24
Safety
Ref.
No.
C8215 F1G1C104A077 C 0.1UF 16V 1
C8216 F1J1A106A087 C 10UF, 10V 1
C8218 F1G1C104A077 C 0.1UF 16V 1
C8220 F1G1C104A077 C 0.1UF 16V 1
C8221 F1G1C104A077 C 0.1UF 16V 1
C8224 F1G1C104A077 C 0.1UF 16V 1
C8229 F1G1A105A047 C 1UF 10V 1
C8230 F1G1C104A077 C 0.1UF 16V 1
C8231 F1G1C104A077 C 0.1UF 16V 1
C8232 F1G1C104A077 C 0.1UF 16V 1
C8300 F1G1H9R0A831 C 9 PF, 50V 1 PAVCA
C8301 F1G1H9R0A831 C 9 PF, 50V 1 PAVCA
C8304 F1G1A105A047 C 1UF 10V 1
C8305 F1G1A105A047 C 1UF 10V 1
C8306 F1G1A105A047 C 1UF 10V 1
C8307 F1G1A105A047 C 1UF 10V 1
C8308 F1G1A105A047 C 1UF 10V 1
C8309 F1G1A105A047 C 1UF 10V 1
C8310 F1G1A105A047 C 1UF 10V 1
C8311 F1G1A105A047 C 1UF 10V 1
C8312 F1G1A105A047 C 1UF 10V 1
C8452 F1J1A106A087 C 10UF, 10V 1
C8453 F1G1C104A077 C 0.1UF 16V 1
C8454 EEEHB0J221UP E 220UF, 6.3V 1
C8455 F1J1A106A087 C 10UF, 10V 1
C8457 F1G1C104A077 C 0.1UF 16V 1
C8461 F1J1A106A087 C 10UF, 10V 1
C8463 F1G1C104A077 C 0.1UF 16V 1
C8465 EEEHB0J221UP E 220UF, 6.3V 1
C8467 F1J1A106A087 C 10UF, 10V 1
C8470 F1G1C104A077 C 0.1UF 16V 1
C8474 F1J1A106A087 C 10UF, 10V 1
C8475 F1G1C104A077 C 0.1UF 16V 1
C8477 F1J1A106A087 C 10UF, 10V 1
C8478 F1G1C104A077 C 0.1UF 16V 1
C8600 F1L3D1020008 C 1000PF 2000V 1
C8601 F1G1C1030008 C 0.01UF 16V 1
C8602 F1G1C1030008 C 0.01UF 16V 1
C8603 F1G1H8R0A831 C 8 PF, 50V 1 PAVCA
C8604 F1G1H8R0A831 C 8 PF, 50V 1 PAVCA
C8611 F1G1C104A077 C 0.1UF 16V 1
C8613 F1G1C104A077 C 0.1UF 16V 1
C8615 F1G1C104A077 C 0.1UF 16V 1
C8619 F1G1C104A077 C 0.1UF 16V 1
C8621 F1G1C104A077 C 0.1UF 16V 1
C8660 F1G1C104A077 C 0.1UF 16V 1
C8661 F1G1C104A077 C 0.1UF 16V 1
C8668 F1G1C104A077 C 0.1UF 16V 1
C8669 F1J1A106A087 C 10UF, 10V 1
C8670 F1J0G2260001 C 22 UF 4 V 1
C8671 F1G1H220A834 C 22PF, 50V 1 PAVCA
C8673 F1J1A106A087 C 10UF, 10V 1
C8675 F1G1A105A047 C 1UF 10V 1
C8677 F1J1A106A087 C 10UF, 10V 1
C8680 F1J1A106A087 C 10UF, 10V 1
C8714 F1J1A106A087 C 10UF, 10V 1
C8715 F1J1A106A087 C 10UF, 10V 1
C8764 F1J1A475A039 C 4.7UF, 10V 1
C8765 F1J1A475A039 C 4.7UF, 10V 1
C8850 F1G1E1030005 C 0.01UF 25V 1
C8900 F1G1C104A077 C 0.1UF 16V 1
C8901 F1G1C104A077 C 0.1UF 16V 1
Part No. Part Name & Description Q'ty Remarks
Page 65
Model No. : TC-L47ET5 Parts List
S-25
Safety
Ref.
No.
C8902 F1G1C104A077 C 0.1UF 16V 1
C9052 F1K1E106A134 C 10UF, 25V 1
C9053 F1H1H103B047 C 0.01UF, 50V 1 PAVCA
C9100 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9101 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9102 F1G1C104A077 C 0.1UF 16V 1
C9104 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9112 F1G1C104A077 C 0.1UF 16V 1
C9113 F1G1C104A077 C 0.1UF 16V 1
C9114 F1G1C104A077 C 0.1UF 16V 1
C9116 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9117 F1G1C104A077 C 0.1UF 16V 1
C9118 F1G1C104A077 C 0.1UF 16V 1
C9119 F1H1A105A099 C 1UF, 10V 1 PAVCA
C9122 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9123 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9124 F1G1C104A077 C 0.1UF 16V 1
C9128 F1H1A105A099 C 1UF, 10V 1 PAVCA
C9131 F1G1C104A077 C 0.1UF 16V 1
C9133 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9134 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9135 F1G1C104A077 C 0.1UF 16V 1
C9136 F1G1C104A077 C 0.1UF 16V 1
C9138 F1H1A105A099 C 1UF, 10V 1 PAVCA
C9139 F1H1A105A099 C 1UF, 10V 1 PAVCA
C9140 F1G1C104A077 C 0.1UF 16V 1
C9142 F1G1C104A077 C 0.1UF 16V 1
C9145 F1G1C104A077 C 0.1UF 16V 1
C9146 F1G1C104A077 C 0.1UF 16V 1
C9148 F1J0G2260001 C 22 UF 4 V 1
C9151 F1G1C104A077 C 0.1UF 16V 1
C9152 F1G1C1030008 C 0.01UF 16V 1
C9155 F1J0G2260001 C 22 UF 4 V 1
C9156 F1J1A106A087 C 10UF, 10V 1
C9157 F1J0G2260001 C 22 UF 4 V 1
C9160 F1J1A106A087 C 10UF, 10V 1
C9162 F1G1C104A077 C 0.1UF 16V 1
C9163 F1G1H120A834 C 12PF, 50V 1 PAVCA
C9164 F1G1C104A077 C 0.1UF 16V 1
C9165 F1G1C104A077 C 0.1UF 16V 1
C9166 F1G1C104A077 C 0.1UF 16V 1
C9167 F1G1C104A077 C 0.1UF 16V 1
C9168 F1G1C104A077 C 0.1UF 16V 1
C9169 F1G1H120A834 C 12PF, 50V 1 PAVCA
C9170 F1J0G2260001 C 22 UF 4 V 1
C9171 F1J0G2260001 C 22 UF 4 V 1
C9172 F1J0G2260001 C 22 UF 4 V 1
C9173 F1J0G2260001 C 22 UF 4 V 1
C9174 F1J0G2260001 C 22 UF 4 V 1
C9182 F1J0G2260001 C 22 UF 4 V 1
C9183 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9184 F1G1C104A077 C 0.1UF 16V 1
C9250 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9251 F1G1A104A069 C 0.1UF 10V 1 PAVCA
C9252 F1G1A104A069 C 0.1UF 10V 1 PAVCA
C9253 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9254 F1J0G2260001 C 22 UF 4 V 1
C9255 F1G1A104A069 C 0.1UF 10V 1 PAVCA
C9256 F1G1A104A069 C 0.1UF 10V 1 PAVCA
C9259 F1G1A104A069 C 0.1UF 10V 1 PAVCA
C9260 F1G1A104A069 C 0.1UF 10V 1 PAVCA
C9261 F1G1A104A069 C 0.1UF 10V 1 PAVCA
Part No. Part Name & Description Q'ty Remarks
Page 66
Model No. : TC-L47ET5 Parts List
S-26
Safety
Ref.
No.
C9262 F1G1A104A069 C 0.1UF 10V 1 PAVCA
C9266 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9275 F1G1C104A077 C 0.1UF 16V 1
C9278 F1G1H471A830 C 470PF, 50V 1 PAVCA
C9279 F1G1A105A047 C 1UF 10V 1
C9280 F1G1A104A069 C 0.1UF 10V 1 PAVCA
C9303 F1H1C105A145 C 1 uF 16 V 1
C9304 F1G1C104A077 C 0.1UF 16V 1
C9306 F1H1C105A145 C 1 uF 16 V 1
C9307 F1G1C1030008 C 0.01UF 16V 1
C9309 F1G1C104A077 C 0.1UF 16V 1
C9310 ECJ1VB1E104K C 0.1 UF, 25V 1
C9311 F1G1C104A077 C 0.1UF 16V 1
C9312 ECJ1VB1E104K C 0.1 UF, 25V 1
C9313 F1K1E106A134 C 10UF, 25V 1
C9314 F1K1E106A134 C 10UF, 25V 1
C9315 F1K1E106A134 C 10UF, 25V 1
C9317 F1J0G2260001 C 22 UF 4 V 1
C9318 F1J0G2260001 C 22 UF 4 V 1
C9319 F1J0G2260001 C 22 UF 4 V 1
C9323 F1J1A106A087 C 10UF, 10V 1
C9329 F1H1A105A099 C 1UF, 10V 1 PAVCA
C9355 F1G1A1040006 C 0.1UF 10V 1
C9359 F1J1A106A087 C 10UF, 10V 1
C9362 F1H1A105A099 C 1UF, 10V 1 PAVCA
CF7101 D4CA94R0A001 THERMISTOR 1 PAVCA
CF7102 D4CA94R0A001 THERMISTOR 1 PAVCA
CN0100 K1KA14A00248 14P CONNECTOR 1
CN8660 K1NA12E00016 12P CONNECTOR 1
D2800B B3AAB0000379 DIODE 1
D3006 K7AAAY000014 PHOTO LINK 1 PAVCA
D3100 DZ2J140M0L ZENER DIODE 1
D3101 DZ2J140M0L ZENER DIODE 1
D3102 DZ2J140M0L ZENER DIODE 1
D3103 DZ2J140M0L ZENER DIODE 1
D3104 DZ2J140M0L ZENER DIODE 1
D3105 DZ2J140M0L ZENER DIODE 1
D4702 DA2J10100L DIODE 1
D4704 DB2J30900L DIODE 1 PAVCA
D4719 DA2J10100L DIODE 1
D4735 DA2J10100L DIODE 1
D4770 DA2J10100L DIODE 1
D4785 DB2J30900L DIODE 1 PAVCA
D5172 DZ2J220M0L TRANSISTOR 1
D5173 DA2J10100L DIODE 1
D5178 DZ2J068M0L ZENER DIODE 1
D5179 B0ADCK000001 DIODE 1
D5180 DZ2J033M0L ZENER DIODE 1
D5187 DZ2J047M0L ZENER DIODE 1
D5188 B0ADCK000001 DIODE 1
D5191 B0ADCK000001 DIODE 1
D5300 B0ADCK000001 DIODE 1
D5301 DA2J10100L DIODE 1
D7101 ERZV10Q621CD VARISTOR 1 PAVCA
D7102 B0EBNR000048 DIODE 1 PAVCA
D7104 B0EAKR000022 DIODE 1 PAVCA
D7105 B0EAKR000022 DIODE 1 PAVCA
D7211 B0JAME000091 DIODE 1
D7212 B0JAME000091 DIODE 1
Part No. Part Name & Description Q'ty Remarks
Page 67
Model No. : TC-L47ET5 Parts List
S-27
Safety
Ref.
No.
D7216 B0HASR000018 DIODE 1 PAVCA
D7217 B0BC02500002 ZENER DIODE 1
D7301 DZ2J039M0L ZENER DIODE 1
D7302 B0HAGQ000001 DIODE 1
D7303 DZ2J039M0L ZENER DIODE 1
D7304 B0HAGQ000001 DIODE 1
D7305 B0ADCK000001 DIODE 1
D7306 B0BC02500002 ZENER DIODE 1
D7307 B0BC02500002 ZENER DIODE 1
D7308 B0BC02500002 ZENER DIODE 1
D7309 B0JAME000091 DIODE 1
D7310 B0JAME000091 DIODE 1
D7311 B0BC02500002 ZENER DIODE 1
D7401 B0JBSK000024 DIODE 1 PAVCA
D7402 B0JBSK000024 DIODE 1 PAVCA
D7404 B0ADCK000001 DIODE 1
D7405 DA2J10100L DIODE 1
D7407 B0JCPE000038 DIODE 1
D7408 B0JDSG000010 DIODE 1 PAVCA
D7409 B0JDSG000010 DIODE 1 PAVCA
D8716 B0ECKM000053 DIODE 1
D8850 DB2J30900L DIODE 1 PAVCA
F7101 K5E502YY0001 FUSE 1 PAVCA
FL9056 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9057 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9058 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9059 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9060 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9061 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9068 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9069 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9070 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9071 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9072 J0ZZB0000147 NW_R(X4) 1 PAVCA
FL9073 J0ZZB0000147 NW_R(X4) 1 PAVCA
GK4 K1KA03BA0061 3P CONNECTOR 1
IC4700 C1AB00003469 IC 1
IC4900 C1AB00003871 IC 1 PAVCA
IC5000 AN34043AAVF IC 1
IC5300 C0DBAYY01281 IC 1 PAVCA
IC5400 C0DBAYY01299 IC 1 PAVCA
IC5420 C0DBAYY01299 IC 1 PAVCA
IC5440 C0DBAYY01283 IC 1 PAVCA
IC7201 C0DBBYY00050 IC 1 PAVCA
IC7301 C0DBAYY01329 IC 1 PAVCA
IC7401 C0DBZYY00531 IC 1 PAVCA
IC7502 C0DBGYY03054 IC 1 PAVCA
IC8000 MN2WS0250B IC 1 PAVCA
IC8100 C0DBAYY01283 IC 1 PAVCA
IC8101 C0DBAYY01285 IC 1 PAVCA
IC8200 C3ABUY000020 IC 1 PAVCA
IC8201 C3ABUY000020 IC 1 PAVCA
IC8453 C0DBZYY00541 IC 1 PAVCA
IC8454 C0DBZYY00541 IC 1 PAVCA
IC8457 C0DBZYY00541 IC 1 PAVCA
IC8600 C1CB00003736 IC 1 PAVCA
IC8660 C0DBEYY00102 IC 1 PAVCA
IC8702 C0DBEYY00102 IC 1 PAVCA
Part No. Part Name & Description Q'ty Remarks
Page 68
Model No. : TC-L47ET5 Parts List
S-28
Safety
Ref.
No.
IC8706 C0DBGYY01682 IC 1
IC8900 TVRS696ADS IC 1 PAVCA
IC8902 TVRS695S IC 1 PAVCA
IC9100 C1AB00003869 IC 1 PAVCA
IC9250 C3ABSY000090 IC 1 PAVCA
IC9300 C0EBK0000129 IC 1 PAVCA
IC9301 C0DBAYY01285 IC 1 PAVCA
IC9302 C0DBAYY01285 IC 1 PAVCA
IC9303 C0DBGFD00011 IC 1
IC9350 TVRS862S IC_SPI FLASH 1 PAVCA
IC9351 C0DBGYY00887 IC 1
J218 D0AF2R2JA112 C 2.2 OHM, J,1/2W 1 PAVCA
JK3001 K2HE2YYB0001 JACK 1 PAVCA
JK3005B K1FY315B0003 CONNECTOR 1 PAVCA
JK4700A K1FY119E0050 CONNECTOR 1 PAVCA
JK4701A K1FY119E0050 CONNECTOR 1 PAVCA
JK4702A K1FY119E0050 CONNECTOR 1 PAVCA
JK4703A K1FY119E0050 CONNECTOR 1 PAVCA
JK7202 K2AEYB000001 AC INLET 1 PAVCA
JK8450 K1FY104B0081 CONNECTOR 1 PAVCA
JK8451 K1FY104B0081 CONNECTOR 1 PAVCA
JK8600A K2LC1YYE0002 JACK 1 PAVCA
JS0050 D0GAR00J0005 M 0 OHM, 1/16W 1
JS0057 D0GAR00J0005 M 0 OHM, 1/16W 1
K10 K1KA07A00292 7P CONNECTOR 1
L3119 J0JYC0000156 FILTER 1 PAVCA
L3120 J0JYC0000156 FILTER 1 PAVCA
L4901 G1C150MA0533 INDUCTION COIL 1 PAVCA
L4902 G1C150MA0533 INDUCTION COIL 1 PAVCA
L4903 G1C150MA0533 INDUCTION COIL 1 PAVCA
L4904 G1C150MA0533 INDUCTION COIL 1 PAVCA
L5300 G1C220MA0445 INDUCTION COIL 1 PAVCA
L5400 G1C4R7ZA0311 INDUCTION COIL 1 PAVCA
L5420 G1C6R8MA0533 INDUCTION COIL 1 PAVCA
L5440 G1C3R3ZA0311 INDUCTION COIL 1 PAVCA
L6707 J0JGC0000020 CHIP INDUCTOR 1
L6711 J0JHC0000046 CHIP INDUCTOR 1
L6721 D0GAR00J0005 M 0 OHM, 1/16W 1
L7103 J0JKB0000034 FLAT CORE 1
L7201 J0JKB0000034 FLAT CORE 1
L7202 J0JKB0000034 FLAT CORE 1
L7203 J0JKB0000034 FLAT CORE 1
L7301 J0JKB0000034 FLAT CORE 1
L7401 J0JKB0000034 FLAT CORE 1
L7402 J0JKB0000034 FLAT CORE 1
L7403 EXCELSA39 BEAD CHOKE 1
L8001 J0JCC0000287 CHIP INDUCTOR 1
L8002 J0JYC0000464 FILTER 1 PAVCA
L8003 J0JKC0000021 CHIP INDUCTOR 1
L8004 J0JCC0000287 CHIP INDUCTOR 1
L8005 J0JYC0000464 FILTER 1 PAVCA
L8006 J0JYC0000464 FILTER 1 PAVCA
L8100 G1C1R5ZA0311 INDUCTION COIL 1 PAVCA
L8101 G1C2R2ZA0311 INDUCTION COIL 1 PAVCA
L8451 J0ZZB0000142 FILTER 1
L8453 J0ZZB0000142 FILTER 1
L8459 J0ZZB0000142 FILTER 1
Part No. Part Name & Description Q'ty Remarks
Page 69
Model No. : TC-L47ET5 Parts List
S-29
Safety
Ref.
No.
L8461 J0JHC0000045 CHIP INDUCTOR 1
L8462 J0JHC0000045 CHIP INDUCTOR 1
L8466 J0JYC0000464 FILTER 1 PAVCA
L8660 J0JBC0000115 CHIP INDUCTOR 1
L8662 J0JHC0000045 CHIP INDUCTOR 1
L8663 J0JYC0000014 FILTER 1
L8664 J0JYC0000014 FILTER 1
L9101 J0JYC0000464 FILTER 1 PAVCA
L9102 J0JYC0000464 FILTER 1 PAVCA
L9104 J0JYC0000464 FILTER 1 PAVCA
L9300 G1C2R2ZA0311 INDUCTION COIL 1 PAVCA
L9301 G1C2R2ZA0311 INDUCTION COIL 1 PAVCA
LF7103 G0B183G00006 CHOKE COIL 1 PAVCA
LF7104 G0B183G00006 CHOKE COIL 1 PAVCA
LF7105 G0B350HA0036 CHOKE COIL 1 PAVCA
P2 K1KY15BA0386 15P CONNECTOR 1 PAVCA
P4 K1KA12BA0062 12P CONNECTOR 1
PA7401 K5H502YA0063 FUSE 1
PA7402 K5H502YA0063 FUSE 1
PA7406 K5H502200003 FUSE 1 PAVCA
PC7301 B3PAA0000629 IC 1 PAVCA
PC7302 B3PAA0000629 IC 1 PAVCA
PC7303 B3PAA0000629 IC 1 PAVCA
Q2011 B1ABCE000015 TRANSISTOR 1
Q2013 B1ABCE000015 TRANSISTOR 1
Q4700 B1ABCF000231 TRANSISTOR 1
Q4702 B1ABCF000231 TRANSISTOR 1
Q4704 B1ABCF000231 TRANSISTOR 1
Q4709 B1ABCF000231 TRANSISTOR 1
Q7201 B1CERR000070 TRANSISTOR 1 PAVCA
Q7202 B1ADCE000022 TRANSISTOR 1
Q7301 B1CFRR000018 TRANSISTOR 1 PAVCA
Q7302 B1CFRR000018 TRANSISTOR 1 PAVCA
Q7303 B1ADCE000022 TRANSISTOR 1
Q7401 B1ABCF000231 TRANSISTOR 1
Q7402 B1CHRE000005 TRANSISTOR 1
Q7403 B1CHRE000005 TRANSISTOR 1
Q9350 B1ADCE000022 TRANSISTOR 1
Q9351 B1ABCF000231 TRANSISTOR 1
R0900 D0GA220JA023 M22 OHM, J.1/16 W 1
R0901 D0GA220JA023 M22 OHM, J.1/16 W 1
R0904 D0GA473JA023 M 47KOHM, J,1/16W 1
R0905 D0GA101JA023 M 100 OHM, J,1/16W 1
R0906 D0GA101JA023 M 100 OHM, J,1/16W 1
R0907 D0GA101JA023 M 100 OHM, J,1/16W 1
R0910 D0GA332JA023 M 3.3KOHM, J,1/16W 1
R0911 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0912 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0913 D0GA332JA023 M 3.3KOHM, J,1/16W 1
R0914 D0GA101JA023 M 100 OHM, J,1/16W 1
R0916 D0GA220JA023 M22 OHM, J.1/16 W 1
R0917 D0GA220JA023 M22 OHM, J.1/16 W 1
R0918 D0GA220JA023 M22 OHM, J.1/16 W 1
R0919 D0GA220JA023 M22 OHM, J.1/16 W 1
R0932 D0GA220JA023 M22 OHM, J.1/16 W 1
R0933 D0GA220JA023 M22 OHM, J.1/16 W 1
Part No. Part Name & Description Q'ty Remarks
Page 70
Model No. : TC-L47ET5 Parts List
S-30
Safety
Ref.
No.
R0938 D0GAR00J0005 M 0 OHM, 1/16W 1
R0940 D0GAR00J0005 M 0 OHM, 1/16W 1
R0946 D0GAR00J0005 M 0 OHM, 1/16W 1
R0948 D0GAR00J0005 M 0 OHM, 1/16W 1
R0951 D0GA101JA023 M 100 OHM, J,1/16W 1
R0952 D0GA102JA023 M1KOHM, J.1/16 W 1
R0954 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0955 D0GA272JA023 M 2.7KOHM, J.1/16W 1
R0956 D0GA332JA023 M 3.3KOHM, J,1/16W 1
R0957 D0GA332JA023 M 3.3KOHM, J,1/16W 1
R1951 D0GA680JA023 M 68 OHM, J,1/16W 1
R1953 D0GA103JA023 M10KOHM, J.1/16 W 1
R2000 D0GA433JA023 M 43KOHM,J,1/16W 1 PAVCA
R2003 D0GAR00J0005 M 0 OHM, 1/16W 1
R2008 D0GA473JA023 M 47KOHM, J,1/16W 1
R2013 D0GA101JA023 M 100 OHM, J,1/16W 1
R2014 D0GA101JA023 M 100 OHM, J,1/16W 1
R2016 D0GA122JA023 M 1.2KOHM, J,1/16W 1
R2034 D0GAR00J0005 M 0 OHM, 1/16W 1
R2051 D0GA101JA023 M 100 OHM, J,1/16W 1
R2053 D0GA473JA023 M 47KOHM, J,1/16W 1
R2054 D0GA104JA023 M100KOHM, J.1/16 W 1
R2055 D0GA103JA023 M10KOHM, J.1/16 W 1
R2060 D0GA473JA023 M 47KOHM, J,1/16W 1
R2061 D0GA223JA023 M 22K OHM J 1/16W 1
R2062 D0GA101JA023 M 100 OHM, J,1/16W 1
R2066 D0GAR00J0005 M 0 OHM, 1/16W 1
R2803 D0GAR00J0005 M 0 OHM, 1/16W 1
R2805 D1BA1201A014 M 1.2 KOHM,F.1/16 W 1
R2806 D0GA470JA023 M 47 OHM, J,1/16W 1
R2807 D0GAR00J0005 M 0 OHM, 1/16W 1
R2852 D1BD1911A066 M 1.91KOHM,J.1/8 W 1 PAVCA
R2853 D1BD3091A066 M 3.09KOHM,J.1/8 W 1 PAVCA
R2854 D1BD6041A066 M 6.04KOHM,J.1/8 W 1 PAVCA
R2855 D1BD1692A066 M 16.9KOHM,F.1/8W 1 PAVCA
R3101 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R3102 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R3103 D0GD750JA052 M 75 OHM,J,1/8W 1
R3104 D0GD750JA052 M 75 OHM,J,1/8W 1
R3105 D0GD750JA052 M 75 OHM,J,1/8W 1
R3118 D0GA473JA023 M 47KOHM, J,1/16W 1
R3119 D0GA473JA023 M 47KOHM, J,1/16W 1
R3120 D0GA473JA023 M 47KOHM, J,1/16W 1
R3121 D1BB1403A106 M 140KOHM,J.1/10W 1 PAVCA
R3122 D0GA473JA023 M 47KOHM, J,1/16W 1
R3123 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R3127 D0GA220JA023 M22 OHM, J.1/16 W 1
R3157 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R3181 D0GD750JA052 M 75 OHM,J,1/8W 1
R3182 D0GD750JA052 M 75 OHM,J,1/8W 1
R3183 D0GD750JA052 M 75 OHM,J,1/8W 1
R3184 D0GA333JA023 M 33KOHM,J,1/16W 1
R3185 D0GA333JA023 M 33KOHM,J,1/16W 1
R3189 D1BB1403A106 M 140KOHM,J.1/10W 1 PAVCA
R3201 D0GA101JA023 M 100 OHM, J,1/16W 1
R3871 D0GAR00J0005 M 0 OHM, 1/16W 1
R3966 D0GA473JA023 M 47KOHM, J,1/16W 1
R4702 D0GA103JA023 M10KOHM, J.1/16 W 1
R4708 D0GA103JA023 M10KOHM, J.1/16 W 1
R4709 D0GA103JA023 M10KOHM, J.1/16 W 1
R4710 D0GA473JA023 M 47KOHM, J,1/16W 1
R4711 D0GA102JA023 M1KOHM, J.1/16 W 1
Part No. Part Name & Description Q'ty Remarks
Page 71
Model No. : TC-L47ET5 Parts List
S-31
Safety
Ref.
No.
R4712 D0GA473JA023 M 47KOHM, J,1/16W 1
R4715 D0GA103JA023 M10KOHM, J.1/16 W 1
R4721 D0GA103JA023 M10KOHM, J.1/16 W 1
R4722 D0GA103JA023 M10KOHM, J.1/16 W 1
R4723 D0GA473JA023 M 47KOHM, J,1/16W 1
R4724 D0GA102JA023 M1KOHM, J.1/16 W 1
R4725 D0GA473JA023 M 47KOHM, J,1/16W 1
R4728 D0GA103JA023 M10KOHM, J.1/16 W 1
R4732 D0GA103JA023 M10KOHM, J.1/16 W 1
R4734 D0GA103JA023 M10KOHM, J.1/16 W 1
R4735 D0GA103JA023 M10KOHM, J.1/16 W 1
R4736 D0GA473JA023 M 47KOHM, J,1/16W 1
R4737 D0GA102JA023 M1KOHM, J.1/16 W 1
R4738 D0GA473JA023 M 47KOHM, J,1/16W 1
R4739 D0GA220JA023 M22 OHM, J.1/16 W 1
R4744 D0GA680JA023 M 68 OHM, J,1/16W 1
R4745 D0GA680JA023 M 68 OHM, J,1/16W 1
R4746 D0GA680JA023 M 68 OHM, J,1/16W 1
R4747 D0GA680JA023 M 68 OHM, J,1/16W 1
R4748 D0GA680JA023 M 68 OHM, J,1/16W 1
R4749 D0GA680JA023 M 68 OHM, J,1/16W 1
R4750 D0GA680JA023 M 68 OHM, J,1/16W 1
R4751 D0GA680JA023 M 68 OHM, J,1/16W 1
R4752 D1BA1600A023 M 160 OHM,F.1/16 W 1 PAVCA
R4753 D1BA82R0A014 M 82 OHM,F.1/16 W 1 PAVCA
R4763 D0GA473JA023 M 47KOHM, J,1/16W 1
R4764 D0GA473JA023 M 47KOHM, J,1/16W 1
R4765 D0GA473JA023 M 47KOHM, J,1/16W 1
R4766 D0GA473JA023 M 47KOHM, J,1/16W 1
R4767 D0GA392JA023 M 3.9KOHM, J,1/16W 1
R4770 D0GA473JA023 M 47KOHM, J,1/16W 1
R4771 D0GA152JA023 M 1.5KOHM, J,0.063W 1
R4772 D0GA152JA023 M 1.5KOHM, J,0.063W 1
R4774 D0GA473JA023 M 47KOHM, J,1/16W 1
R4775 D0GA473JA023 M 47KOHM, J,1/16W 1
R4776 D0GA680JA023 M 68 OHM, J,1/16W 1
R4777 D0GA680JA023 M 68 OHM, J,1/16W 1
R4780 D0GA121JA023 M 120 OHM, J,1/16W 1
R4788 D0GA103JA023 M10KOHM, J.1/16 W 1
R4794 D0GA103JA023 M10KOHM, J.1/16 W 1
R4795 D0GA103JA023 M10KOHM, J.1/16 W 1
R4796 D0GA473JA023 M 47KOHM, J,1/16W 1
R4797 D0GA102JA023 M1KOHM, J.1/16 W 1
R4798 D0GA473JA023 M 47KOHM, J,1/16W 1
R4799 D0GA273JA023 M 27K OHM J ,1/16W 1
R4900 D0GFR00J0005 M 0 OHM,J,1/3W 1
R4901 D1HY1014A022 NETWORK RESISTER 1 PAVCA
R4906 D0GA822JA023 M8.2KOHM, J,1/16W 1 PAVCA
R4907 D0GA102JA023 M1KOHM, J.1/16 W 1
R4908 D0GA102JA023 M1KOHM, J.1/16 W 1
R4913 D0GAR00J0005 M 0 OHM, 1/16W 1
R4914 D0GAR00J0005 M 0 OHM, 1/16W 1
R4955 D0GA103JA023 M10KOHM, J.1/16 W 1
R4956 D0GA102JA023 M1KOHM, J.1/16 W 1
R4981 D0GA103JA023 M10KOHM, J.1/16 W 1
R5002 D0GA683JA023 M 68KOHM, J,1/16W 1
R5003 D0GA103JA023 M10KOHM, J.1/16 W 1
R5006 D0GA223JA023 M 22K OHM J 1/16W 1
R5007 D0GA223JA023 M 22K OHM J 1/16W 1
R5009 D1BA5602A023 M 56KOHM,F. 1/16 W 1 PAVCA
R5012 D1BA2202A023 M 22KOHM,F. 1/16 W 1 PAVCA
R5030 D0GA103JA023 M10KOHM, J.1/16 W 1
Part No. Part Name & Description Q'ty Remarks
Page 72
Model No. : TC-L47ET5 Parts List
S-32
Safety
Ref.
No.
R5100 D0GA101JA023 M 100 OHM, J,1/16W 1
R5104 D0GA103JA023 M10KOHM, J.1/16 W 1
R5152 D0GA222JA023 M 2.2KOHM, J,1/16W 1
R5175 D0GA680JA023 M 68 OHM, J,1/16W 1
R5181 D0GA103JA023 M10KOHM, J.1/16 W 1
R5312 D0GD100JA059 M 10 OHM,J,1/4W 1
R5315 D1BA1402A023 M 14KOHM,F. 1/16 W 1 PAVCA
R5316 D1BA1001A023 M 1 KOHM,F.1/16 W 1 PAVCA
R5317 D0GA103JA023 M10KOHM, J.1/16 W 1
R5318 D1BA1001A023 M 1 KOHM,F.1/16 W 1 PAVCA
R5321 D0GA473JA023 M 47KOHM, J,1/16W 1
R5322 D0GA473JA023 M 47KOHM, J,1/16W 1
R5400 D0GAR00J0005 M 0 OHM, 1/16W 1
R5401 D1BA2202A023 M 22KOHM,F. 1/16 W 1 PAVCA
R5402 D0GB911ZA037 M 910 OHM,J,1/10W 1 PAVCA
R5403 D1BB2871A106 M 2.87 KOHM,F.1/10 W 1 PAVCA
R5420 D0GAR00J0005 M 0 OHM, 1/16W 1
R5421 D1BA3302A023 M 33KOHM,F. 1/16 W 1 PAVCA
R5422 D0GB911ZA037 M 910 OHM,J,1/10W 1 PAVCA
R5423 D1BB4871A106 M 4.87 KOHM,F.1/10 W 1 PAVCA
R5441 D0GAR00J0005 M 0 OHM, 1/16W 1
R5442 D1BB1301A195 M 1.3KOHM,J.1/10W 1 PAVCA
R5443 D1BB7501A195 M 7.5 KOHM,F.1/10 W 1 PAVCA
R6726 D0GA681JA023 M680 OHM, J,1/16W 1
R6727 D0GA681JA023 M680 OHM, J,1/16W 1
R6731 D0GA103JA023 M10KOHM, J.1/16 W 1
R6732 D0GA103JA023 M10KOHM, J.1/16 W 1
R7101 D0GF105JA048 M 1M OHM. 1/4W 1 PAVCA
R7102 D0GF105JA048 M 1M OHM. 1/4W 1 PAVCA
R7103 D0GF105JA048 M 1M OHM. 1/4W 1 PAVCA
R7104 D0B1106JA033 M 10MOHM J 1W 1
R7201 ERX1SJR22 M0.22 OHM, J, 1W 1
R7202 ERX1SJR22 M0.22 OHM, J, 1W 1
R7203 D0GD104JA052 M 100KOHM,J,1/8W 1
R7204 D0GD101JA059 M 100 OHM,J,1/4W 1
R7205 D0GD101JA052 M 100 OHM,J,1/8W 1
R7206 D0GD220JA059 M 22 OHM,J,1/4W 1
R7207 D0GD104JA052 M 100KOHM,J,1/8W 1
R7208 ERX1SJR22 M0.22 OHM, J, 1W 1
R7212 D0GD103JA052 M 10KOHM,J,1/8W 1
R7219 D0GD513JA052 M 51KOHM,J,1/8W 1 PAVCA
R7220 D0GD223JA052 M 22KOHM,J,1/8W 1
R7224 D1BD8203A066 M 820KOHM,F.1/8W 1 PAVCA
R7225 ERJ8ENF1504V M 150KOHM, 1/8W 1 PAVCA
R7226 ERJ8ENF1504V M 150KOHM, 1/8W 1 PAVCA
R7227 ERJ8ENF1504V M 150KOHM, 1/8W 1 PAVCA
R7228 ERJ8ENF1504V M 150KOHM, 1/8W 1 PAVCA
R7229 D1BD2003A066 M 200KOHM.F.1/8W 1 PAVCA
R7230 D1BD4422A066 M 44.2KOHM,F.1/8W 1 PAVCA
R7231 D1BD4303A066 M 430KOHM,F.1/8W 1 PAVCA
R7232 D1BD3603A066 M 360KOHM,F.1/8W 1 PAVCA
R7234 D1BD8203A066 M 820KOHM,F.1/8W 1 PAVCA
R7302 D0GD101JA059 M 100 OHM,J,1/4W 1
R7303 D0GD101JA059 M 100 OHM,J,1/4W 1
R7304 D0AF2R2JA112 C 2.2 OHM, J,1/2W 1 PAVCA
R7305 D0AF151JA112 C 150 OHM, J,1/2W 1 PAVCA
R7306 D0GD222JA052 M 2.2KOHM,J,1/8W 1
R7307 D0GD561JA052 M 560 OHM,J,1/8W 1
R7308 D0GD561JA052 M 560 OHM,J,1/8W 1
R7312 D0AF222JA112 C 2.2KOHM, J,1/2W 1 PAVCA
R7314 D0GD104JA052 M 100KOHM,J,1/8W 1
R7315 D0GD222JA052 M 2.2KOHM,J,1/8W 1
Part No. Part Name & Description Q'ty Remarks
Page 73
Model No. : TC-L47ET5 Parts List
S-33
Safety
Ref.
No.
R7317 D0GD223JA052 M 22KOHM,J,1/8W 1
R7318 D0GD473JA052 M 47KOHM,J,1/8W 1
R7319 D0GD473JA052 M 47KOHM,J,1/8W 1
R7320 D0GD473JA052 M 47KOHM,J,1/8W 1
R7321 D0GD100JA059 M 10 OHM,J,1/4W 1
R7322 D0GD100JA059 M 10 OHM,J,1/4W 1
R7323 D0GD223JA052 M 22KOHM,J,1/8W 1
R7324 D0GD223JA052 M 22KOHM,J,1/8W 1
R7401 D0GD102JA052 M 1.0KOHM,J,1/8W 1
R7402 D0GD102JA052 M 1.0KOHM,J,1/8W 1
R7403 D0GD472JA052 M 4.7KOHM,J,1/8W 1
R7404 D0GD103JA052 M 10KOHM,J,1/8W 1
R7405 D0GD222JA052 M 2.2KOHM,J,1/8W 1
R7406 D1BD3321A066 M 3.32KOHM,F.1/8W 1 PAVCA
R7407 D0GD102JA052 M 1.0KOHM,J,1/8W 1
R7408 D1BD1822A066 M 18.2KOHM,F.1/8W 1 PAVCA
R7409 D0GD473JA052 M 47KOHM,J,1/8W 1
R7410 D0GD153JA052 M 15KOHM,J,1/8W 1
R7411 D0GD104JA052 M 100KOHM,J,1/8W 1
R7412 D0GD153JA052 M 15KOHM,J,1/8W 1
R7416 D0GD103JA052 M 10KOHM,J,1/8W 1
R7417 D0GD103JA052 M 10KOHM,J,1/8W 1
R7420 D0GD473JA052 M 47KOHM,J,1/8W 1
R7421 D0GD224JA052 M 220KOHM,J,1/8W 1
R8008 D0GA331JA023 M 330 OHM, J,1/16W 1
R8009 D0GA1R1JA023 M 1.1OHM, J,1/16W 1 PAVCA
R8100 D1BB2001A197 M 2 KOHM,F.1/10 W 1 PAVCA
R8101 D1BB1051A087 M 1.05 KOHM,F.1/10 W 1 PAVCA
R8111 D1BB2001A197 M 2 KOHM,F.1/10 W 1 PAVCA
R8112 D1BB1961A087 M 1.96 KOHM,F.1/10 W 1 PAVCA
R8200 D1BA2400A023 M 240 OHM,F.1/16 W 1 PAVCA
R8203 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8204 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8205 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8206 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8207 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8208 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8217 D0GA221JA023 M220 OHM, J.1/16 W 1
R8218 D0GA221JA023 M220 OHM, J.1/16 W 1
R8219 D1BA2400A023 M 240 OHM,F.1/16 W 1 PAVCA
R8220 D1BA2400A023 M 240 OHM,F.1/16 W 1 PAVCA
R8221 D0GA103JA023 M10KOHM, J.1/16 W 1
R8230 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8231 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8232 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8233 D1BA2700A023 M 270 OHM,F.1/16 W 1 PAVCA
R8234 D0GA470JA023 M 47 OHM, J,1/16W 1
R8235 D0GA470JA023 M 47 OHM, J,1/16W 1
R8236 D0GA470JA023 M 47 OHM, J,1/16W 1
R8237 D0GA470JA023 M 47 OHM, J,1/16W 1
R8238 D0GA220JA023 M22 OHM, J.1/16 W 1
R8240 D1HY2208A012 NETWORK RESISTER 1 PAVCA
R8241 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R8242 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R8243 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R8300 D0GA471JA023 M 470OHM, J,1/16W 1
R8301 D1BA6201A023 M 6.2 KOHM,F.1/16 W 1 PAVCA
R8302 D0GA360JA023 M 36 OHM, J,1/16W 1
R8303 D0GA360JA023 M 36 OHM, J,1/16W 1
R8304 D0GA360JA023 M 36 OHM, J,1/16W 1
R8305 D0GA360JA023 M 36 OHM, J,1/16W 1
R8450 D0GA103JA023 M10KOHM, J.1/16 W 1
Part No. Part Name & Description Q'ty Remarks
Page 74
Model No. : TC-L47ET5 Parts List
S-34
Safety
Ref.
No.
R8451 D0GA103JA023 M10KOHM, J.1/16 W 1
R8453 D1BA3742A014 M 37.4KOHM,F. 1/16 W 1 PAVCA
R8454 D0GA103JA023 M10KOHM, J.1/16 W 1
R8455 D0GA103JA023 M10KOHM, J.1/16 W 1
R8457 D1BA3742A014 M 37.4KOHM,F. 1/16 W 1 PAVCA
R8458 D1BA3742A014 M 37.4KOHM,F. 1/16 W 1 PAVCA
R8469 D0GA103JA023 M10KOHM, J.1/16 W 1
R8470 D0GA103JA023 M10KOHM, J.1/16 W 1
R8498 D0GAR00J0005 M 0 OHM, 1/16W 1
R8500 D0GAR00J0005 M 0 OHM, 1/16W 1
R8501 D0GAR00J0005 M 0 OHM, 1/16W 1
R8512 D0GAR00J0005 M 0 OHM, 1/16W 1
R8514 D0GAR00J0005 M 0 OHM, 1/16W 1
R8519 D0GAR00J0005 M 0 OHM, 1/16W 1
R8520 D0GAR00J0005 M 0 OHM, 1/16W 1
R8521 D0GAR00J0005 M 0 OHM, 1/16W 1
R8601 D1BA75R0A023 M 75.0 OHM,F.1/16 W 1 PAVCA
R8602 D1BA75R0A023 M 75.0 OHM,F.1/16 W 1 PAVCA
R8603 D1BA75R0A023 M 75.0 OHM,F.1/16 W 1 PAVCA
R8604 D1BA75R0A023 M 75.0 OHM,F.1/16 W 1 PAVCA
R8611 D1BA2491A023 M 2.49KOHM,F,1/16W 1 PAVCA
R8612 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R8613 D0GA680JA023 M 68 OHM, J,1/16W 1
R8614 D0GA680JA023 M 68 OHM, J,1/16W 1
R8616 D0GA680JA023 M 68 OHM, J,1/16W 1
R8617 D0GA680JA023 M 68 OHM, J,1/16W 1
R8620 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R8622 D0GA680JA023 M 68 OHM, J,1/16W 1
R8623 D0GA680JA023 M 68 OHM, J,1/16W 1
R8624 D0GA680JA023 M 68 OHM, J,1/16W 1
R8625 D0GA152JA023 M 1.5KOHM, J,0.063W 1
R8626 D0GA680JA023 M 68 OHM, J,1/16W 1
R8627 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R8629 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R8630 D0GA680JA023 M 68 OHM, J,1/16W 1
R8631 D0GA680JA023 M 68 OHM, J,1/16W 1
R8634 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R8635 D0GA680JA023 M 68 OHM, J,1/16W 1
R8636 D0GA680JA023 M 68 OHM, J,1/16W 1
R8660 D0GA560JA023 M 56 OHM, J,1/16W 1
R8661 D0GA560JA023 M 56 OHM, J,1/16W 1
R8662 D0GA560JA023 M 56 OHM, J,1/16W 1
R8663 D0GA560JA023 M 56 OHM, J,1/16W 1
R8664 D0GA560JA023 M 56 OHM, J,1/16W 1
R8665 D0GA560JA023 M 56 OHM, J,1/16W 1
R8666 D1HY1038A012 NETWORK RESISTER 1 PAVCA
R8667 D1HY5604A012 NETWORK RESISTER 1 PAVCA
R8668 D1HY5604A012 NETWORK RESISTER 1 PAVCA
R8669 D0GA220JA023 M22 OHM, J.1/16 W 1
R8673 D1BB1200A055 M 120 OHM,J.1/10W 1 PAVCA
R8674 D1BB2000A055 M 200 OHM,J.1/10W 1
R8755 D0GA104JA023 M100KOHM, J.1/16 W 1
R8797 D1BA1200A023 M 120 OHM,F.1/16 W 1 PAVCA
R8798 D1BA56R0A023 M 56 OHM,F.1/16 W 1 PAVCA
R8800 D0GA103JA023 M10KOHM, J.1/16 W 1
R8801 D0GA103JA023 M10KOHM, J.1/16 W 1
R8802 D0GA103JA023 M10KOHM, J.1/16 W 1
R8803 D0GA103JA023 M10KOHM, J.1/16 W 1
R8817 D0GA103JA023 M10KOHM, J.1/16 W 1
R8821 D0GA103JA023 M10KOHM, J.1/16 W 1
R8829 D0GA103JA023 M10KOHM, J.1/16 W 1
R8850 D0GA331JA023 M 330 OHM, J,1/16W 1
Part No. Part Name & Description Q'ty Remarks
Page 75
Model No. : TC-L47ET5 Parts List
S-35
Safety
Ref.
No.
R8851 D1BB7151A106 M 7.15 KOHM,F.1/10 W 1 PAVCA
R8852 D0GA102JA023 M1KOHM, J.1/16 W 1
R8853 D0GA182JA023 M 1.8KOHM, J,0.063W 1
R8854 D0GA102JA023 M1KOHM, J.1/16 W 1
R8858 D0GA473JA023 M 47KOHM, J,1/16W 1
R8859 D0GA103JA023 M10KOHM, J.1/16 W 1
R8870 D0GA473JA023 M 47KOHM, J,1/16W 1
R8871 D0GA473JA023 M 47KOHM, J,1/16W 1
R8872 D0GA473JA023 M 47KOHM, J,1/16W 1
R8873 D0GA473JA023 M 47KOHM, J,1/16W 1
R8874 D0GA473JA023 M 47KOHM, J,1/16W 1
R8875 D0GA473JA023 M 47KOHM, J,1/16W 1
R8876 D0GA473JA023 M 47KOHM, J,1/16W 1
R8877 D0GA473JA023 M 47KOHM, J,1/16W 1
R8883 D0GA103JA023 M10KOHM, J.1/16 W 1
R8885 D0GA473JA023 M 47KOHM, J,1/16W 1
R8887 D0GA473JA023 M 47KOHM, J,1/16W 1
R8902 D0GA473JA023 M 47KOHM, J,1/16W 1
R8904 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R8909 D0GA222JA023 M 2.2KOHM, J,1/16W 1
R8910 D0GA103JA023 M10KOHM, J.1/16 W 1
R8911 EXB2HV121JV NW_R(x8) 1
R9004 D0GA101JA023 M 100 OHM, J,1/16W 1
R9005 D0GA101JA023 M 100 OHM, J,1/16W 1
R9006 D0GA101JA023 M 100 OHM, J,1/16W 1
R9007 D0GA101JA023 M 100 OHM, J,1/16W 1
R9008 D0GA101JA023 M 100 OHM, J,1/16W 1
R9009 D0GA101JA023 M 100 OHM, J,1/16W 1
R9010 D0GA101JA023 M 100 OHM, J,1/16W 1
R9011 D0GA101JA023 M 100 OHM, J,1/16W 1
R9012 D0GA101JA023 M 100 OHM, J,1/16W 1
R9013 D0GA101JA023 M 100 OHM, J,1/16W 1
R9014 D0GA101JA023 M 100 OHM, J,1/16W 1
R9015 D0GA101JA023 M 100 OHM, J,1/16W 1
R9074 D0GAR00J0005 M 0 OHM, 1/16W 1
R9100 D1BA2400A023 M 240 OHM,F.1/16 W 1 PAVCA
R9104 D0GA103JA023 M10KOHM, J.1/16 W 1
R9110 D0GA182JA023 M 1.8KOHM, J,0.063W 1
R9112 D0GA182JA023 M 1.8KOHM, J,0.063W 1
R9115 D0GA221JA023 M220 OHM, J.1/16 W 1
R9121 D0GD100JA052 M 10 OHM,J,1/8W 1
R9122 D0GD100JA052 M 10 OHM,J,1/8W 1
R9123 D0GD100JA052 M 10 OHM,J,1/8W 1
R9124 D0GD100JA052 M 10 OHM,J,1/8W 1
R9125 D0GD100JA052 M 10 OHM,J,1/8W 1
R9129 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R9250 D1BA1001A023 M 1 KOHM,F.1/16 W 1 PAVCA
R9251 D1BA1001A023 M 1 KOHM,F.1/16 W 1 PAVCA
R9252 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9253 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9254 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9255 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9256 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9257 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9258 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9259 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9260 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9261 D0GA220JA023 M22 OHM, J.1/16 W 1
R9262 D0GA220JA023 M22 OHM, J.1/16 W 1
R9263 D0GA220JA023 M22 OHM, J.1/16 W 1
R9264 D0GA220JA023 M22 OHM, J.1/16 W 1
R9265 D0GA220JA023 M22 OHM, J.1/16 W 1
Part No. Part Name & Description Q'ty Remarks
Page 76
Model No. : TC-L47ET5 Parts List
S-36
Safety
Ref.
No.
R9266 D0GA220JA023 M22 OHM, J.1/16 W 1
R9267 D0GA220JA023 M22 OHM, J.1/16 W 1
R9268 D0GA220JA023 M22 OHM, J.1/16 W 1
R9269 D0GA220JA023 M22 OHM, J.1/16 W 1
R9270 D1BA49R9A023 M 49.9 OHM,J.1/16 W 1 PAVCA
R9271 D1BA49R9A023 M 49.9 OHM,J.1/16 W 1 PAVCA
R9300 D1BA2202A023 M 22KOHM,F. 1/16 W 1 PAVCA
R9301 D1BA2202A023 M 22KOHM,F. 1/16 W 1 PAVCA
R9302 D0GA223JA023 M 22K OHM J 1/16W 1
R9307 D1BB2001A197 M 2 KOHM,F.1/10 W 1 PAVCA
R9309 D1BB2001A197 M 2 KOHM,F.1/10 W 1 PAVCA
R9311 D1BB6800A087 M 680 OHM,J.1/10W 1 PAVCA
R9312 D1BB2801A087 M 2.8 KOHM,F.1/10 W 1 PAVCA
R9350 D0GA222JA023 M 2.2KOHM, J,1/16W 1
R9351 D1HY2204A012 NETWORK RESISTER 1 PAVCA
R9352 D0GA333JA023 M 33KOHM,J,1/16W 1
R9353 D0GA102JA023 M1KOHM, J.1/16 W 1
R9354 D0GA103JA023 M10KOHM, J.1/16 W 1
R9356 D0GA473JA023 M 47KOHM, J,1/16W 1
R9357 D0GA472JA023 M 4.7KOHM, J,1/16W 1
R9359 D0GA103JA023 M10KOHM, J.1/16 W 1
R9360 D0GA103JA023 M10KOHM, J.1/16 W 1
R9361 D0GA102JA023 M1KOHM, J.1/16 W 1
R9363 D0GA151JA023 M 150 OHM, J,1/16W 1
R9364 D0GA151JA023 M 150 OHM, J,1/16W 1
R9365 D0GA151JA023 M 150 OHM, J,1/16W 1
R9371 D0GA103JA023 M10KOHM, J.1/16 W 1
R9372 D0GA103JA023 M10KOHM, J.1/16 W 1
RM2800 PNJ4815M01TV REMOTE SENSOR 1
SN2800 B3JB00000116 IC 1
SW2851 EVQ11G05R SWITCH 1
SW2852 EVQ11G05R SWITCH 1
SW2853 EVQ11G05R SWITCH 1
SW2854 EVQ11G05R SWITCH 1
SW2855 EVQ11G05R SWITCH 1
SW2857 EVQ11G05R SWITCH 1
T7201 G4DYA0000366 SWITCHING TRANS 1 PAVCA
T7301 G4DYA0000372 SWITCHING TRANS 1 PAVCA
T8600 G5BYC0000040 TRANS 1 PAVCA
TC01A K1MY51BA0526 51P CONNECTOR 1 PAVCA
TC02A K1MY41BA0526 41P CONNECTOR 1 PAVCA
TU6706 J3ACAAB00007 TUNER 1 PAVCA
X8300 H0J245500110 CRYSTAL 1
X8600 H0J250500120 CRYSTAL 1 PAVCA
X9100 H0J270500166 CRYSTAL 1 PAVCA
ZA0050 K4AD01D00008 TERMINAL 1
ZA0052 K4AD01D00008 TERMINAL 1
ZA7101 K4AD01A00003 TERMINAL 1 PAVCA
ZA7103 K4AD01A00003 TERMINAL 1 PAVCA
Part No. Part Name & Description Q'ty Remarks
Page 77

Model No. : TC-L47ET5 Exploded View

S-37
Page 78
Model No. : TC-L47ET5 Parts List
S-38
Safety
Ref.
No.
1 10030-0066000 BATTERY COVER 1 PAVCA
2 K2CB2YY00071 AC CORD 1 PAVCA
3 K2KYYYY00199 AV CABLE 1 PAVCA
4 L0EYAA000006 SPEAKER UNIT L 1
5 L0EYAA000007 SPEAKER UNIT R 1
6 L5EDDYY00367 LCD PANEL 1 PAVCA
7 N2QAYB000703 REMOTE CONTROLLER 1 PAVCA
8 N5HBZ0000064 WIFI DONGLE 1 PAVCA
9 TBL5ZX0270 PEDESTAL ASS'Y 1 PAVCA
10 TBL5ZX03031 ASSY, STAND ACC 1 PAVCA
11 TBX5ZA00601 KEY_BUTTON 1
12 TKK5ZL50051 USB_CABLE_BRACKET 1 PAVCA
13 TKKL5521 M6_CAP 4
14 TKP5ZA13801 BOTTOM COVER 1
15 TKX5ZA02501 SPEAKER_BRACKET 4
16 TKZ5ZF50035 METAL_AV_BRACKET_SIDE 1 PAVCA
17 TKZ5ZF50071 METAL_AV_BRACKET_BTM 1 PAVCA
18 TKZ5ZX5005-2 VESA METAL 4 PAVCA
19 TKZ5ZX50271 BOTTOM_METAL 1
20 TXFKK5Z0003 LED PANEL ASSY 1 PAVCA
33 TXFKP0112SER LED BRACKET ASSY 1 PAVCA
21 TXFKU0712SER REAR COVER 1 PAVCA
22 TXFKY01SKUU CABINET ASSY 1 PAVCA
31 XSS5+15FNK SCREW (SUP-BRA) 4
32 XYN4+F25FJK SCREW 4
Part No. Part Name & Description Q'ty Remarks
K1HY05YY0022 USB CABLE 1 PAVCA
N5ZZ00000261 3D GLASSES 4
TEWB625 GASKET(8x10x20) 1
TEWB763 GASKET(12x10x20) 1 PAVCA
TEWB772 GASKET(5x10x10) 3
TEWF091 AL/PET TAPE 15x80 2
THEC1509 SCREW(BC15) 15
THEJ024 SCREW (BOTTOM_METAL2) 2
THEJ036J SCREW(BTM6/VESA4/A10/P5) 25
THTD030J SCREW(BC18/BTM_COVER2/DUNGLE1) 21
TMK2AX234 BARRIER_P_PCB 1 PAVCA
TMK2AX250 SHADING SHEET 2 PAVCA
TMK2AX251 SHADING PLATE 4 PAVCA
TMKK486 HEAT RUBBER 2
TMKK487 A-THERMAL CONDUCTIVE SHEET(PEAKS) 1 PAVCA
TMKK488 A-THERMAL CONDUCTIVE SHEET(DDR) 2 PAVCA
TMME268 CLAMPER 2
TMME289 CLAMPER 1
TMME399 SPACER(P_PCB) 7
TMME415 SPACER FPR A-HEAT SINK 3 PAVCA
TQB2AA0636 INSTRUCTION BOOK 1 PAVCA
TQEF144 BAG 1
TSCFF0030005 LVDS FFC (51PIN) 1 PAVCA
TSCFF0030006 LVDS FFC (41PIN) 1 PAVCA
TXJ/P4SKUU LEAD (P4-LD/GK4) 1 PAVCA
TXJA12SKUU SPEAKER LEAD (A12-SP) 1 PAVCA
XTV3+10JFJ SCREW 7
XTW3+8TFJ SCREW 2
XYN3+C6FJ SCREW 2
XYN3+C6FJ SCREW 1
XYN3+C8FJ SCREW 1
Loading...
