Panasonic TC-43P15 User Manual

'■ i-W ■'•'■'•^^^' ^'■''''' '■■^"' ' ■ ' '■’ '■' '■ '' I■ '. •

i'i-.:,-.iv,:-.-. ''v. ■'.’i--

Panasonic

Projection Television

Operating Instructions

Model No.

TX-51P15 Series
TC-51P15 Series

TX-43P15 Series

TC-43P15 Series

This is a combined Operating Instruction

manual for all the above series of models.
Please read these instructions before

operating your set and retain them for
future reference.

TQBC0191-1

Dear Panasonic Customer

Welcome to the Panasonic family of customers. We hope that you will have many

years of enjoyment from your new colour television set.

To obtain maximum benefit from your set, please read these Instructions
before making any adjustments, and retain them for future reference.

Retain your purchase receipt also, and note down the Model Number and

Serial Number of your set in the space provided on the rear cover of these
Instructions.

t

Important information

(1) The long time (max. 2 hours) use of TV game on the set is not recommended since the signal from

TV game may be the cause of damage on picture projection tubes oh the set.

(2) Do not allow a still picture to be displayed for an extended period, as this can cause a permanent

after-image to remain on the Projection TV screen.

Exampies of still pictures include logos, video games, computer images, teletext and images

displayed in 16 : 9 mode.

If still picture cannot be avoided, reduce the brightness and contrast levels of the picture to minimize

any damage that might occur.

(3) In order to minimize any damage to the projection tubes, this set uses the PICTURE SHIFT

function (Refer to page 46) to change (shift) the entire picture approximately 4 mm every 30
minutes.

Table of Contents

Warnings and Cautions________________________________________4-5

Before Operating This Set______________________________________6-9

How to Use This Manual.............................................................................................................................................................................6

Quick Reference Guide for your TV Set........................................................................................................

Securing the casters...................................................................................................................................................................................7

Connecting the Aerial Cable to the RF In Terminal................................................................................................................................. 8

Safety Precaution........................................................................................................................................................................................8

Connecting the Plug to the wall Outlet......................................................................................................................................................9

How to Turn the Power On.........................................................................................................................................................................9

Battery installation......................................................................................................................................................................................9

............................................

7

Convergence Adjustment
Location of Controls
Connections

______________________________________________

________________________________________

___________________________________

10 - 11

12 - 14

15 - 17

Flow Chart of Main menu____________________________________18 - 19

Tuning Procedure__________________________________________20 - 31

Channel Selection..................................................................................................................................................................................... 20

Regional System Selection......................................................................................................................................................................22

Channel Allocation....................................................................................................................................................................................23

Automatic Tune..........................................................................................................................................................................................24

Manual Tune.............................................................................................................................................................................................. 26

Fine Tuning................................................................................................................................................................................................28

How to Cancel the Fine Tuning................................................................................................................................................................29

Programme Number Skip....................................................................................................................................................................... 30-

How to Cancel the Skip Function............................................................................................................................................................ 31

General Operation

How to switch the power ON or OFF / STANDBY mode

Programme Number Selection................................................................................................................................................................ 32

Direct Programme Number Selection..................................................................................................................................................... 32

Volume adjustment................................................................................................................................................................................... 32

TV / AV mode Selection / Display button / Game button / Sound Mute button / Recall button / Off Timer button

Sound System Selection..........................................................................................................................................................................34

Colour System Selection........................................................................................................................................................................ 35

_________________________________________

....................................................................................................................... 32

.........................

32 - 35

33

Advanced Remote Control Operation

PICTURE IN PICTURE Operation............................................................................................................................................................. 36

STROBE, CH SEARCH and STILL Operation......................................................................................................................................... 38

RAI and D.PNR Operation........................................................................................................................................................................39

Surround Operation..................................................................................................................................................................................40

Stereo Reception...................................................................................................................................................................................... 41

Main Menu Operation

Picture Menu Operation.......................................................................................................................................................................... 42

Sound Menu Operation.............................................................................................................................................................................43

Features Menu Operation.........................................................................................................................................................................44

Language Menu Operation.......................................................................................................................................................................47

Multi PIP Menu Operation....................................................................................................................................................................... 48

_______________________________________

Teletext Operation (For TX-51P15 series . TX-43P15 Series)

_________________________

_______

36 - 41

42 - 49

50 - 53

Operation of the VCR / LD / DVD ______________________________54 -- 55

Troubleshooting 56

Cleaning

_____________________________________________________

57

Specifications 58 - 59

'X

Warnings and Cautions

AWarnings

0

0

si,

/“

"Hi

Unplug the power cord in the
event of any malfunction
(screen goes blank, no sound,
odd sounds, smoke or unusual
odors coming from the unit).
Unplug the power cord if

foreign matter or water fails

into the unit, or if the unit is

dropped or the cabinet is

damaged.

DO NOT place any of the
following on the unit;
Flower vases, flower pots,
cups, small metal objects, or
cosmetics containers,
chemicals or water.

DO NOT insert foreign objects
(metal or easily flammable

objects).

0

0

DO NOT use this unit near
water. (Near a bath tub, etc.)

DO NOT use if the power cord
or power plug is damaged, or
if the plug does not fit tightly
into the socket.

DO NOT use at a voltage other
than indicated

ACautions

r

/ \ ii ' /

L_

____i____El_____

afterimages appear

L—

TAKE CARE NOT to damage
the power cord.

0

DO NOT touch the aerial cable
and this unit when there is
lightning. ^ '

Do not allow a still picture to be displayed for an extended period, as this can cause a permanent
after-image to remain on the Projection TV screen.
Examples of still pictures include logos, video games, computer images, teletext and images
displayed in 16 ; 9 mode.

J

0

DO NOT remove the rear
cover as live parts and High
Voltage components are
accessible when the rear
cover is removed.

DO NOT touch the power plug
if your hands are wet.

ÉÜ

Warnings and Cautions

ACautions

o

O

DO NOT place in humid or
dusty location, or areas
exposed to smoke or steam.
DO NOT place in direct
sunlight and other sources
of direct heat.

DO NOT stand, or place heavy
objects on the unit.
Particular care should be taken
by families with small children.

When inserting batteries,
ensure that the polarities
(positive and negative) are
correctly aligned, insert as
shown on remote control. If

inserted incorrectly, battery

fluid may leak, and fire, injury,

or damage to surrounding
components may result.

Adequate ventilation is
essential to prevent failure of
electrical components, we
recommend that a gap of at
least 10 cm (-4bi^) is left all
around this unit even when it
is placed inside a cabinet or
between shelves.

O

DO NOT place in an unstable
location

Place in a safe location.

/— s

Do not mix new and old
batteries. Use only the
specified batteries. Failure to
follow this precaution may
result in leakage of battery
fluid. Fire, injury, or damage
to surrounding components
may also result.

Turn the power “Off” before
connecting other electrical

equipment.

Before cleaning, unplug the
power plug from the socket.

Unplug the power plug from the
socket if you are not going to
use the unit for an extended
period.

To ensure continued excellent performance by this product, periodic cleaning is recommended. See page 57 for more

information.

DO NOT joint the unit.

Ask your sales outlet to install
the aerial.

Before Operating This Set

How to Use This Manual

1. Check the Model Number of your TV set; the Model Number is shown on the rear cover name plate on the set.
Use the table on the opposite page to confirm which features your particular Model is equipped with. This will

help you to known which sections of the manual apply to your set.

2. Check the Part Number on the rear of your Remote Control handpiece, and note the functions available, as

shown below.

TC-51P15G
TC-51P15H
TC-43P15G

TC-43P15H

TV/AV

o o o

© ® ®
® ® ®
® ® ®

© ® ©

D.PNn OtSEUCH STILL PIP

CD CD CD CD

P.M STtUSE OUWE PIP ACTION

vcn EPf OTB I BI OISO SSE IQ

a □ ® Q

WIU9U

OV7

-m

CD O CD O

VCRfLO/DVO

CED
[XI

~

m [>

□u

EglWt»l

M4 BMW

TX-51P15H
TX-51P15X
TX-43P15H
TX-43P15X

Stereo / Bilingual
Selection button

L

__

iSimti» TV /Av

o o o

© ® ®
© ® ®
© ® ®

(g) ® ©

D.P№ CHSEAROH STILL PtP

o o o o

P AI 5TB0BE CWAHOe PIPACnCK

CD CD C D CD

VCFVLD/DVD

r

► 1

m

4-i

wen iL Emva E№b C9ID E{S

CD a ® □

tuiuw ^ I

□ X\Iqd

<3 ® [>

—1—éP TIME

F.p. TBtr nevEAL fiTiB

CD CD a a

►H

[

ID

MalBWPI

m

CD m m

CD (HD H3)

Stereo / Bilingual
Selection button

TELETEXT Operation
button

Before Operating This Set

-'Ìi^''v '■ 'O'. nO-.I - -

Quick Reference Guide for your TV Set

Please check the model number of your set.
This Manual applies to several Models and there are slight differences among them.

Please check the table below to see what your TV is equipped with before you begin using these Operating Instructions.

Instructions are given for all functions, please disregard these which do not apply to your TV,

China ♦

*

*

*

*

*

*

Destination

Multi
Language

Hong Kong

Southeast Asia

Australia

NZ

Middle East *

English

Chinese

Arabic *

*

* «

_________________

AC 110-240 v

Power
Source

50 /60 Hz

AC 220-240 V

50/60 Hz

*

Securing the casters

To ensure safety, secure the casters in place using
the supplied stoppers.

This set is equipped with casters to enable it to be

easily moved. When positioning the set, place the
supplied stoppers under the casters to secure the
casters and prevent the set from moving.

To prevent the set from tipping forward, turn the two

casters on the front of the TV so they face fonward,
as shown in the picture.

*

*

: Function available

\

i— —c

. . j- „J . i

Before Operating This Set

Connecting the Aerial Cable to the RF In Terminal

To obtain optimum quality picture and sound, an
Aerial, the correct cable (75 Ohm coaxial) and the
correct terminating plug are required.

If a communal Aerial system is used, you may require
the correct connection cable and plug between the
wall Aerial socket and your set.

Your local Television Service Centre or Dealer may

be able to assist you in obtaining the correct Aerial

system for your particular area and accessories

required.

Any matters regarding Aerial installation, upgrading

of existing systems or accessories required, and the

costs incurred, are the responsibility of you, the

Customer.

Safety Precaution

Please take safety precautions to prevent the uhit
form falling over.
The unit may fall over during earthquakes, or if some

one stands on or shakes the TV,

RF In Terminal-

75 Ohm Coaxial Cable

Coaxial aerial plug

i

iííí.

■m

'W-

■Wt

Fixing to a wall

Use a strong rope or a chain to
fasten the TV firmly to a strong
support such as a wall or a pillar.

V . ■ . .'l. ' I

Before Operating This Set

Connecting the Plug to the Wall Outlet

Note:

Main plug types vary between countries. The main plug shown at left
may therefore not be the type fitted to your set.
When connecting the main plug to the wall outlet, the power indicator
will light (Orange).

How to Turn the Power On

Push the Power switch on Television to turn the set on.

The Power Indicator will light.

Power-OFF
Stand-by 0
Power-ON

Note:

When in the Stand-by condition (Refer to page 32), it is possible to turn
the TV set on by pushing the “Power (Stand-by)” button any of the
“Direct Programme Number Selection” buttons (0 ~ 9) and Programme

Number Up and Down buttons on the TV set or Remote Control.

............

.............

..............

Orange
Red
Green

Battery Installation

__________________

1

Open the cover.

Apply slight downward
pressure while pulling
towards the bottom.

Do not use rechargeable (Ni-Cd) batteries.

They are different in shape and performance and may fail to ensure correct operation.

A

Battery cautions

The incorrect use of batteries can cause electrolyte leakage which will corrode the Remote Control or cause the

batteries to burst.

Old Batteries New Batteries

2

Batteries: Use two “R6 (AA)” size
batteries.

Insert the batteries ensuring correct polarity.
This is identifiable by the and symbols
on both the batteries and inside the battery
compartment.

Replace the cover.

Replace both batteries at the same time.

Don't mix battery types
(alkaline with carbon zinc, etc.)

Don't Recharge.

Convergence Adjustment

Convergence Adjustment mode

■in

< 3

®

Push the Position Left “<” or
Right “>" button to enter
CONVERGENCE ADJUSTMENT
mode.

'^mi

■ ■

Convergence Adjustment

Convergence Adjustment for GREEN, RED and BLUE

Use the Position Up V’ or Down “v” button to
align the horizontal green line with the vertical
centre marker.

Use the Position Left “<” or Right “>” button to
align the vertical green line with the horizontal
centre marker.

Push the “N” button to adjust the red mode.
(Stores green)

<10^

d]

\7

CONVERGENCE

N0(T:[Nj

CONVERGENCE

<|^E> GREEN

NEXTriN]

o

Morizontal centre marker

CONVERGENCE

<=i

i

NEXT:®

GREEN

red

© Vertical center

marker

Use the Position Up “a” or Down "v”, Left “<” or
Right “>” buttons to align the red line with the
green line, (Becomes a yellow line)

Push the “N" button to adjust the blue mode.
(Stores red)

Use the Position Up “a” or Down V’, Left “<” or
Right “>” buttons to align the blue line with the

yellow line. (Becomes a white line)

Push the “N" button to return to the normal
viewing. (Stores blue)

4 cs ^

¿2^

<\m\)

^ CEl ^

22

<1 ® [>

If you wish to view a video with a different colour
system (PAL / SECAM, NTSC), repeat the steps
above while displaying a picture.

11

Direct Programme Number Selection (page 32)

Recall (page 33)

Channel Search (page 38)

D.PNR (page 39)

Strobe (page 38)

P.AI (page 39)

VCR / LD / DVD Play (page 55)

VCR / LD / DVD Rewind / Review (page 55)

VCR / LD / DVD Power (page 55)

LD / DVD button (page 54)

VCR button (page 54)

Main Menu (page 18)

Normalization (page 42, 43)

Position button

Off Timer button (page 33)

Stereo / Bilingual Sound Selection (page 41)

*TC-51P15, TC-43P15 Series are not equipped ^

^ ^ / TEXT Selection (page 51)

TEXT Favourite Page Selection (page 51)

Time TEXT (page 52)

A

O

fl^kll Hlil lDi. i.M /iv/w 'i

I ■' . '■>i''^' » .i''' ' * i ' *' *'»» \ *». '* ***. i

Sound Mute (page 33)

TV / AV Mode Selection (page 33)

Programme Number Up and Down (page 32)

Volume Up and Down (page 32)
Two Digit Programme Number Selection (page 32)

Picture in Picture Selection (page 36)
Still (page 38)
PIP Action (page 37)
Main / Sub Picture Change (page 37)

VCR / LD / DVD Fast Forward / Cue (page 55)
VCR / LD / DVD Stop (page 55)
VCR Still Advance (VCR) (page 55)

DISC SIDE A Selection (LD / DVD)
VCR Record (VCR) (page 55)

OPEN

VCR / LD / DVD Pause / Still (page 55)

Programme Number Up and Down (VCR) (page 55)

TC-51P15, TC-43P15 Series are not equipped ^

TEXT Hold (page 51)
TEXT index (page 51)
TEXT Full / Top / Bottom Selection (page 51)
TEXT Reveal (page 51)
TEXT Colour-coded Button (page 51)

1-5

Location of Controls

Controls and Terminals on the TV

Display button (See page 33)

TV / AV Selection button (See page 33)

Preset button (See page 21)

yolume Up(+) / Down(-) button (See page 32)

o 6 o

OlSPWr TV/AV PRE - + V A SAME

1

Main headphone Jack (See page 17) —

Sub headphone Jack (See page 17)

Programme Number button (See page 32)

Game button (See page 33)

AV2 Input Terminals

14

t £

II

.

............

, ................ 'K..' ■ .. ■■ ■■■■,,.

How to connect the “AV1, 2, 3 or 4” Input Terminals

(Super-VHS VCR)

•000000

m
m

Audio \fidao

OU T I

OUT

I i I

Note:

(1) When AV1, AV2, AV3 or AV4 is selected, and that AV mode has no input picture signal, the Background Colour of

the TV screen will change. (This only occurs if the Blue-Back function is set to the ON condition: refer to page 45
for details.)

(2) When an S-Video cable is connected to the S-Video terminal, the Video input will be automatically switched off for

that AV mode.
(3) When a Monaural VCR is used, connect the Monaural Audio cable to the Audio “L” (Left) terminal.
(4) Similar connections are available at the AV1, AV2, AV3 and AV4 input terminals.

Select the desired AV input position by pushing the TV/AV button. (Refer to page 33)

(5) The AV4 audio input terminals serves as the audio input terminal for both the Video input and for the DVD Input.

15

Connections

Note:

(1) The AV4 audio signal is common for both AV4 and DVD input signal terminals.
(2) The DVD signal input terminal takes priority over the AV4 video signal input terminal.

How to connect the AV Monitor Output Terminals to other equipment.

The “Monitor Ouf Terminals output the same signals as main picture on the TV screen and sound from the speaker at
that time, e.g. TV programmes or signals from AV1, AV2, AV3 or AV4 input.

Recording Equipment

(VHS VCR)

Note:

{1) Never connect the same video recorder with both the VIDEO IN and MONITOR OUT terminals on this TV set, as

this could cause Incorrect operation.
(2) The monitor output emits the main picture norma! video and audio signals.
(3) Teletext display on screen will not be output at the MONITOR OUT terminals.
(4) Even if the television is in picture-in-picture condition, MONITOR OUT terminals output the same signals as main

picture on the screen and sound from speakers. Sub picture including strobe, still, channel search, etc. will not be

output at the MONITOR OUT terminals.
(5) DVD signal (Y, Pb, Pr) are not output at the MONITOR out terminals.

Connections

Connecting Headphones

Connect headphones as follows.

You can listen to sound from each of the headphones plugs as shown below.

Sub

Headphones

A

(Mono)

B

(Mono)

■ A

(Mono)

Monitor

Output

A

(Stereo)

A

(Stereo)

B

(Stereo)

Single picture/
Teletext

Picture in Picture

Picture in Picture/

CHANGE

Screen condition

Speaker

Sound

A

(Stereo)

A

B

B

H

A

(Stereo)

B

(Stereo)

Main

Headphones

A

(Stereo)

A

(Stereo)

B

(Stereo)

Main Headphones plug:

When a Main Headphones plug is inserted into the Headphones socket, ali speakers will be automatically disconnected;

only the Main Headphones will function.
Use Volume Up “+” or Down button to control volume level.

Sub Headphones plug:

For the sub Headphones volume control, refer to page 37.

1-7

A,i'-...

Flow Chart of Main menu

When the “MAIN MENU" button is pushed at the Main menu screen, the screen display will return to the normal
viewing condition.
When the “MAIN MENU” button is pushed at each menu screen {Picture, Sound, Features, Language, Preset, Multi

PIP), the screen display will return to the Main menu screen.

MAINI^N U

Push
Select
Symbol . Mark

On-Screen
Indication

□

SELECT RCCESS

SELECTO RCCESS

SELECT O RCCESS

Push
On-Screen

Indication
(example)

COLOUR
HTSC-TIHT
BRIGHT
COHTRfiST
5HRRPHES5

MENU

MENU

DYNRMIC
COLOUR

<33E

HTSC-TIHT

Sit 33

aaBSi

CONTRRST
SHARPNESS

MENU

DYNAMIC

@933

COLOUR
NTSC-TINT

^33

033

BRIGHT

3 CDNTRRS r

LD33 SHARPNESS

MENU OYHRKIC
®33 COLOUR
Sa33 NTSC-TINT
033 BRIGHT
flS3 CONTRAST

M¥bMs

43 TREBLE

BRLRHCE

SURROUND OFF

MENU OTNRtllC

^> 45 TREBLE
b.j3S BRLRHCE

SURROUND OFF

MENU DTHRHIC

0:40 BRSS

b.^32 BRLRHCE
SURROUND OFF

MENU DYHRHIC

0=40 BRSS

' 43 TREBLE

SURROUND OFF

MENU DYNAMIC

40 BRSS

45 TREBLE

?

j33 BALANCE

13X1

P. fli ON
C. TEMP STRNDRRD
CH COLOUR SET — —
OEHO^O. PHR

D. PNR
C. TEMP

CH COLOUR SET
DEHO/D. PHR

W

O. PHR

P. RI
Cl^OLOU^ET

OEHD/O, PNR

cr. PHR
P. fil
C, TEMP

OEMO/'D. PNR

D. PNR AUTO
P. RI ON
C. TEMP STANDARD
CH COLOUR SET — —

RU SKIP
CHILD LOCK OFF
PICTURE SHIFT ON

COHUERGEHCE

STRNDRRD

a

AUTO
ON

RUTO
ON

STRNDRRD

□ FFUCR/'ORME

>

BLUE BACK □ H
UCR/GRME

ItMJSiH

CHILD LOCK OFF
PICTURE SHIFT

COHUERGEHCE

▼

BLUE BRCK ON
UCR^GRHE
RU SKIP

IXIII ■■ III n

PICTURE SHIFT
COHUERGEHCE

▼

BLUE BRCK OH
UCR/GRHE
RU SKIP
CHILD LOCK

CDNUER^cV

▼

BLUE BRCK
UCR.^QRHE
RU SKIP
CHILD LOCK
PICTURE SHIFT

laiTEHainanaa

▼

OFF

ON

OFF

OH

OFF

ON
OFF

OFF
OH

Some default settings may be different for TX/TC-43P15
series and TX/TC-51P15 series.

1ft

BLUE BACK ON
RU SKIP

CHILD LOCK OFF
PICTURE SHIFT ON
COHUERGEHCE

Flow Chart of Main menu

Ш

io

f

ШШШЗ

SELECT О ACCESS

f

SELECT О ACCESS

TZ?

IS PRESET

CN le

CH SELECT PQS.
5YS3EUECT ftilR^N, I

MIHMUR L^^Hl

EOUNQ SYS S, SHH»
COLOUR SYS RUTO
FINE TUNS
SKZF OFF

IE PRESET

CH12

СИ SELECT POS.
8YS SELECT REIRAN. E.

JTO TUHE

SOUND SYS 5. SKH»
COLOUR SYS RUTO
FINE TUHE
SKIP OFF

CK SELECT POE,
SYS SELECT RSIRy-n. E.
RUTO TUNE
HflHURL TUH6

впммди

SELECT О ACCESS

\7

PIP
CH SEARCH

STROBE
STILL
CHANGE

PIP
PIP SIZE

Hire3E!ifin!

STROBE
STILL
CHANGE

PIP
PIP SIZE
CN SEARCH
Miaiiiia
STILL
CHANGE

e

PIP
PIP SIZE
CH SEARCH
STRBB^^^

CHAHG^^^

GH

OFF

OFF

OFF
LARGE

OFF

OFF

LARGE

OFF

OFF
LARGE

GGQQ

SELECT О ACCESS

\7

Ешашвв Есиа

LIST STORE
TEXT NODE LIST/FASr

DISPLAY CANCEL

TEXT NODE LIST-^FAST

DISPLAY CANCEL
LIST STORE

CH SELECT PQ8.

eVS SELECT niZA^»4, E.
RUTS TUHE
rtRHURL TUHB
SOUND SYS S, SnNi
COLOUR SYS RUTO
FINE TUNE

J

PIP
PIP SIZE
CH SEARCH
STROBE
STILL

lilifeliBIB

OFF
LARGE

OFF

Only for
TX-51P15 Series
TX-43P15 Series

[Tuning Procedure

J

Channel Selection

Select the most easily viewed channel selection method.

Example

Programme

Number

1
2
3
4

5
6
7
8
9

10

Channel

Display

2 2
4 4
6

8 8
10 10
12 12
14
16 16
18 18

20 20

Received

Channel

6

14

m
m

Mi

POSITION SELECT

When the Channel Selection is on PCS. (Position), and
Auto Tune is performed, the unit memories the channels
tuned in order from programme No.1.

Push the button 0 to view channel 2.
Push the button 0 to view channel 4.
Push the button 0 to view channel 6.

During position mode various reception channels can
be viewed.

Example

Programme

Number

on

10

20

DIRECT SELECT

Channel

Display

1
2
3
4

5
6
7
8
9

2

-

4 4

- -

6 6

-

8

-

10

20

Received

Channel

2

-

-

8

-

10

20

When the Channel Selection is on DIRECT, and Auto
Tune is performed, the unit memories the programme

number which is the same as the channel tuned.

This method allows you to select the desired channel

by pushing the channel display number directly on the
remote control to select the station. The channel display
numbers for the broadcast stations in each region are
listed on page 23.

Tuning Procedure

1,3 2

(TV set)

Before Regional System Selection and AUTO tuning, set the “CHANNEL SELECT” mode, as detailed
below.

PRE.

Push the “PRE." (PRESET)
button, setting the Preset
Menu to “CH SELECT’.

Select the “CH SELECT
(Channel Select)” Mode by
pushing the Volume Up V or
Down button.

1 PR ES E T

CH I

CH SELEC T P05.

SYS S E LE C T RS IR /H . E.
flUT O T UN E
tiPN U RL T U NE
SO UN D S YS 5 . SH H z
CO LO U R SY S R U TO
FIN E TU N E
SKI P OF F

1 PR ES E T

CH I

CH SELEC T POS.

SYS S E LE C T RS IR /N . E.
RU TO T U NE
NR NU R L TU N E
SO UN D S YS 5 . SM H x
CO LO U R SY S R U TO
FIN E TU N E
SKI P OFF

“CH SELECT" Condition

Setting range when the
“POS." (Position) has been
selected: Position 0-99
Setting range when the
“DIRECT has been selected;
Channel 0-125

The channel select indicator
will change as follows.

DIRECT^ POS.

PRE.

Push the “PRE.” (PRESET)
button 8 times.

This returns the set to the

normai viewing condition.

Tuning Procedure

Regional System Selection

1>3

OtSPlAY TV/AV PRE. - + V Д GAME

L

Г

(TV set)

Before AUTO tuning and MANUAL tuning, set the “SYSTEM SELECT” mode, as detailed below.

“SYS SELECr Condition.

The system select indicator
will change as follows.

4

CHINA

I

HK/UK

I I

ASIA / M.E. AMERICA

I

NZ / INA SPECL

I

AUS E.EUROPE

t

________

This returns the set to the

normal viewing condition.

PRE

PRE.

Push the "PRE.” (PRESET)

button twice, setting the Preset

Menu to “SYS SELECr.

Select the appropriate System
by pushing the Volume Up V’
or Down button.

Push the “PRE.” (PRESET)
button 7 times.

1 P RE S ET
CH 1
CH S EL EC T P O S.

■ SYS SELECT

RU TO T U NE
MR NU R L TU N E
SO UN D S YS
CO LO U R SY S
FIN E TU N E
SKI P

____________

1 P RE S ET

CH 1

CH S EL EC T P O S.

iSYS SELECT nSin /M. E.

RU TO T U NE
HR NU R L TU N E
SO UN D S YS
CO LO U R SY S
FIN E TU N E

-SU E _____________

nSIñ/M. E .

5. S N Hz

RU TO

OF F

5. S N Hz

RU TO

OF F

1

JAPAN

I

CATV

:

I

t

I

I

i
Í

■Wi

|y.
Ш-

ё:

Í:

System Select by Regiotial ’

SYSTEM SELE CT

CHINA

HK/UK
ASIA/M.E.
NZ/INA
AUS

E.EUROPE

SPECL

AMERICA

CATV

JAPAN

China
Hong Kong, United Kingdom
Malaysia, Singapore, Thailand, Asia countries, Kuwait Saudi Arabia, United Arab Emirates, Middle East countries, etc.
New Zealand, Indonesia, etc.
Australia
CIS, Poland, etc.

South Africa
U.S.A., Chile, Mexico, Panama, Pelu, Philippines, Taiwan, Venezuela, etc.
USA CATV

Japan

22

Region

Ш;

i

Tuning Procedure

Channel Allocation

CATV (USA CATV) channei numbers as recommended by the joint EIA/NCTA Engineering committee and

published as EIA INTERIM STANDARD N0.6-CABLE TELEVISION CHANNEL IDENTIFICATION PLAN-MAY

1983.

The receiving channels are as follows;

Tuning Procedure

Automatic Tune (Ctiaraiel Select and Regional System must already be se^ Refer Id pages 20 to 23)

1,6 2,4 3

(TV set)

This TV uses automatic tuning to determine whether or not a broadcast signal is being sent which
it can receive, and automatically prepares so that the channel selection can respond to both the
position select and direct select modes.

1

PRE.

Push the “PRE.” (PRESET)
button 3 times.

1

CH 1
CH S EL EC T P O S.
SVS S E LE C T RS IP /K . E .

nUT G TUNE

HR NU flL T U NE
SO UN D S YS 5 . 5M H z
CO LO U R SY S R U TO
FIN E TU N E
SKI P OF F

PR ES E T

Automatic Search “AUTO
TUNE” Condition.

V A

“ +

Push the Volume Up or
Down button.

After all stations are tuned,
the on-screen display will
automatically change from
“AUTO TUNE” to "SOUND
SYS” Position. Confirm the
sound condition of each
Programme Number by using
the Programme Number Up

“a" button.

If necessary, push the
Volume Up "+” or Down
button, to improve the Sound
quality.

AUTO TUNE

1 1 P RE S ET I

CH 1
CH S EL EC T
SYS S E LE C T
RU TO T U NE
HflN U R L T U NE

BOU ND SY B

CO LO U R SY S
FIN E TU N E
SKI P

1 1 P RE S ET 1

CH X
CH S EL EC T
SYS S E LE C T
RU TO T U NE
MR NU R L TU N E

SOU ND SYS

CO LO U R SY S
FIN E TU N E
SKI P

PO S.
R5I R/ M . E .

5. B H Hz H

RU TO

OF F

PO S.
fiSI R/ M. E .

5. S M H zH

RU TO

OF F

Search Start.

The best tuning position is
automatically memorized.

If the Sound is not clear or
no sound is produced on a
Programme Number, then
follow the next Step 4.

Note:

When sound volume is too
small to confirm, turn it up by

using the sound volume
button on the remote control.

The sound indicator will
change as follows.

4.5MHz <

6.5MHz ------------> 6.0MHz

----------

> 5.5MHz

t

t

24

Tuning Procedure

Use the Programme Number
Up “a” button to sequentially

check each station.

If necessary, repeat steps 3 to
4 for each Programme Number.

PRE.

After all stations are tuned,
push the “PRE.” (PRESET)

button 4 times.

This returns the set to the

normai viewing condition.
Programme Number
memory locations.

f'Helpful Hint

(1) To tune, push the Main Menu button and Position button on the Remote Control.

By following the display in the Preset Menu, setting can be formed using only the Remote Control.

(2) If a clear picture with correct coiours cannot be obtained when a Broadcast or AV signal is received, refer to the

"Colour System Selection” operation on page 35.

(3) After the Automatic tune is finished, push the Programme Number V’ button to confirm the tuning condition for

each Programme Number. If some Programme Numbers are unused, it is possible to skip such Programme
Numbers. Please refer to the Programme Number Skip operation on page 30.

(4) Repeated pushing of the “PRE.” (PRESET) button changes the Preset Menu as follows;

CH SELECT SYS SELECT ^ AUTO TUNE MANUAL TUNE SOUND SYS

(Page 21) (Page 22) (Page 24) (Page 26) (Page 34)

TV Mode^ SKIP^

(Normal viewing condition) (Page 30)

FINE TUNE

(Page 28)

■COLOUR SYS^

(Page 35)

oc

Tuning Procedure

Manual Tune (Channel Select and Regional System must already be s^; Refer to pages 20 to 23)

1,4,6 3,5 2

(TV set)

Ш:

V Л

- -» +

PRE.

Push the “PRE.” (PRESET)
button 4 times.

Push either the Programme
Number Up V’ or Down V’
button.

Push the Volume Up "+” or
Down button.

Volume “+”: Next higher

Channel

Volume : Next lower

Channel

1 1 P RE S ET I

CH 1
CH S EL EC T P O S.
SYS S E LE C T
flUT C T UN E

MRNURL TUNE

SO UN D S YS

CO LO U R SY S
PIN E TU N E
SKI P

[ г P R ES E T 1

CH 1
CH S EL EC T P O S.
SYS S E LE C T
RU TO T U NE

MRNURL TUNE

SO UN D S YS
CO LO U R SY S
FIN E TU N E
SKI P

MANUAL TUNE

1 a PR E S ET 1

CH a
CH S EL EC T P O S.
SYS S E LE C T
RU 'LO T U NE

MRMUflL TUNE

SO UN D S YS 5 . S NH z
CO LO U R SY S
FIN E TU N E

SKI P

RS IR XM . E.

1

5. 5 M Hz

RU TO

OF F

flSI fi/M . E.

1

5. S H Hz

RU TO

OF F

flSI fl/H . E.

1

RU TO

OF F

Manual Search “MANUAL

TUNE” Condition.

Select the desired Programme
Number.

Search Start.

The best tuning position is
automatically memorized.

OA

PRE

Push the “PRE.” (PRESET)
button.

Г1 PRESET1

CH a
CH S EL EC T POS.
SYS S E LE C T
RU TO T U NE
NR NU R L TU N E

IBDUND SYS

CO LO U R SY S
FIN E TU N E
SKI P

flSI fl/N . E.

5. S tlH z H

RU TO

OF F

“SOUND SYS” Condition.

Tuning Procedure

PRE.

f

Helpful Hint

If the sound is not clear or no
sound is produced on a
Programme Number Position,
push the Volume Up or
Down button.

Push the “PRE.” (PRESET)
button 4 times.

S P RE S ET 1
CH 2
CH S EL EC T POS.
SYS S E LE C T
RU TO T U NE
MR NU R L TU N E

jSOUND S YS

CO LO U R SY S
FIN E TU N E
SKI P

flSI fl/M . E.

5. S NHzH

RU TO

OF F

You may improve the

Sound quality.

The sound indicator will

change as follows.

4.5MHz <

----------

^ 5.5MHz

i . i

6.5MHz <

Note:

When sound volume is too
small to confirm, turn it up
by using the sound volume
button on the remote
control.

This returns the set to the
normal viewing condition.

----------

> 6.0MHz

(1) If a clear picture cannot be obtained even when a Broadcast or AV signal is received, refer to the “Colour System

Selection” operation on page 35.

(2) After the Manual tune is finished, push the Programme Number V’ button to confirm the tuning condition for each

Programme Numbers. If some Programme Numbers are unused, it is possible to skip such Programme Numbers.
Please refer to the Programme Number skip operation on page 30.

(3) When using a VCR without video and audio input/output terminals, it is convenient to connect the aerial cable as

indicated in the instruction manual of VCR and to set the designated channel to programme No. “0”. In that case,
perform manual tune after setting the colour system and sound system in advance. Further, in multi-system VCR,
it is more convenient to set the designated channel to several programme Numbers.

Tuning Procedure

Fine Tuning

2,4

l^-;;.vU...:i>:... .^■í'ÍÍvíi^Íifcl^iVjLÍi4'£¿.1¿£¡¿áá^

1_

DISPLAY TV/AV PRE.

- -- +

A

r

(TV set)

Under normal reception conditions this function is not required or necessary.
However, in areas of poor reception or constant interference, a slight adjustment of the tuning may
improve the picture and sound quality.

1

PRE.

Select the channel which you

want to improve, using the

Programme Number Up “a” or
Down V’ button.

Push the “PRE.” (PRESET)

button 7 times, setting the

Preset menu to “FINE TUNE”.

riPRESET 1

CH 2
CH S EL EC T
SYS S E LE C T
RU TO T U NE
MR NU R L TU N E
SO UN D S YS
CO LO U R SY S

IF INE TUNE*

{SK IP

PO S.
RS IR /M . E .

5. S M Hz
RU TO

OF F

Select the desired
Programme Number.

Fine Tune Condition.

28

PR E.

Push and hold the Volume Up
V’ or Down button until the
clear picture is received.

Push the “PRE.’
button twice.

(PRESET)

• s

CH E
CH S EL EC T P O S.
SYS S E LE C T fiS Ifi /H . E ,
RU TO T U NE
MR NU R L TU N E
SO UN D S YS 5 . 5M H r

»IC QL D UR S Y S RU T O

FINE TUNE

PR ES E T

SKIP

Fine Tune Start.

The AFC function is
deactivated.
The “■ ” symbol appears to
the left of the Programme

Number.

OF F

This returns the set to the

normal viewing condition.

í*'r;iÍ:'ii!UÍ,K:¿'.í ti!, .t-^ •:•. i.a.i.^^.ii¡¿Í!;:^.^:.;i: !iSv.-.^+.-;

Tuning Procedure

How to Cancel the Fine Tuning

(TV set)

Cancelling previously adjusted (manually) fine tuning, means re-activating the AFC (Automatic Frequency
Controi) Function, also know as AFT (Automatic Fine Tuning). Re-activating the Automatic Fine Tuning

means albaming the set to automatically tune to the optimum tuning position, for that programme Number.

1

Select the "AFC OFF”
Programme Number which you
want to return to Automatic
Frequency Control (cancel the
manual fine tuning).

“AFC OFF” Programme
Numbers are indicated to
you by the “■ ” symbol to
the left of the Programme
Numbers in the On-Screen
Display.

- - -I-

PRE

Push the “PRE.” (PRESET)
button 4 times, setting the

Preset menu to “MANUAL

TUNE”.

Push the Volume Up

Down button, briefly.

- a

CH 2
CH S EL EC T P OS .
SYS S E LE C T R S IR /M . E .
fiUT O T UN E

tlñNURL TUNE

SO UN D S YS 5 . 51 1H z
CO LO U R SY S R UT O
FIN E TU N E
SKI P OF F

PR ES E T

Manual Search Condition.

The best tuning position is

automatically memorized.

(In other words, manually

tune away from the

[ePRESET1

CH 2
CH S EL EC T POS .
SYS S E LE C T

RU TO T U NE

MRNUqL TUNE

SO UN D S YS
CO LO U R SY S
FIN E TU N E
SKI P

RS Ifl/ H. E.

5. 5 N Hz
RU TO

OF F

transmission, and then back
to .it.)

PRE.

Push the "PRE." (PRESET)
button 5 times.

This returns the set to the

normal viewing condition.

nn

Tuning Procedure

Programme Number Skip

(TV set)

It is possible to skip Programme Number on which no TV stations are tuned appearing on the screen.

The function is only effective when selecting Programme Numbers by pushing the Programme Number

up or Down button either on the TV set or the Remote control.

5

2 3

(T\

PR E.

Repeat Steps 2 and 3 for the
remaining Programme
Numbers for which the Skip

function is desired.

After the Skip Operation is
completed, push the “PRE.”

(PRESET) button (once).

This returns the set to the
normal viewing mode.

i.4¿vi^ :i.-.v, ,;>'i ■.

Tuning Procedure

How to Cancel the Skip Function

1,5 3

^ DISPLAY TV/AV PRE. - ^ + V A SAME

(TV set)

r

PR E

Push the “PRE.” (PRESET)
button 8 times, setting the
Preset Menu to “SKIP”.

Select a skipped Programme

Number, by pushing the
Programme Number Up V’ or
Down “v” button.

Push the Volume Up "+" or
Down button.

2 PR ES E T
CH 12
CH S EL EC T P O S.
SYS S E LE C T flS Ifl /M . E .
flUT D T UN E
MR NU R L TU N E
SO UN D S YS 5 . 5M H z
CO LO U R SY S R U TO
FIN E TU N E

2 PR ES E T
CH 12
CH S EL EC T P O S.
SYS S E LE C T flS Ifl /M . E .
RU TO T U NE
HR NU R L TU N E
SO UN D S YS S . SH H z
CO LO U R SY S R U TO
FIN E TU N E

2 PR ES E T

CH 12
CH S EL EC T P O S.
SYS S E LE C T fiS Ifl /M . E .
RU TO T U NE
MR NU R L TU N E
SO UN D S YS 5 . SM H z
CO LO U R SY S R U TO
FIN E TU N E

Channel Skip Condition

The displayed “ON” condition

changes to “OFF".

2 3

PR E.

Repeat Steps 2 and 3, if you

wish to cancel the skip
function on any other

Programme Number.

After the Skip Cancel
Operation is completed, push
the “PRE.” (PRESET) button

(once).

This returns the set to the
normal viewing condition.

OH

General Operation

6 5

о о о

DBPLAV TV/AV РПЕ, ” ^ + V Д GAME

oo 6

1

(TV set)

. '■Я'..'3 V LmiVL'cl

How to switch the power ON or OFF /
STANDBY mode.

The TV set must first be switched on at the
wail outlet and at the Power Switch. (Refer
to page 9)

Push this button to turn the TV set ON, from
STANDBY mode.
Push it again to turn the TV set OFF,
STANDBY mode.

Note:

It is also possible to turn the TV set on
STANDBY by pushing the “Direct Programme
Number Selection” buttons (0-9) and the
“Programme Number Up or Down” button,
either on the set or on the Remote Control.

Programme Number Selection

Push the Programme Number Up “a” or
Down

V’

button to select the next higher or

lower Programme number.

10

® © ®

OD

>

V J

+ '

1^

ма(5ИГЯ

® ® ®
® ® ©

DMA Ш SEARCH STILi.

О О О

PAt $ТЮвЕ OWNOE PIPACTtON

О О О О

VCFVLD^DVD

ca

a

(■)

VCR ILD/Ovg [а>н:як[5]

□ □ ® □

a

СШ

<

TVTOCT index НОШ

aw

(Й)

CD ^ ШВ

пые

reff REVEAL rrr/B

□ (Hi dni 13

□ о о a

—2

Direct Programme Number Selection

(CH SELECT = POS.)

You can select the numbers directly by
pushing “Number 0-9” button and the two digit
Numbers by pushing “Two Digit” and
“Programme Number” buttons.

Programme Number 8
Programme Number 12

............

..........

(J)
© . (D . ®

Direct Programme Number Selection
(CH SELECT = DIRECT)

You can select the number directly by pushing
the corresponding programme number

button.

Programme Number 8
Programme Number 36

Programme Number 124... © . @ . ©

...........

.........

® / ® . ®
, (?)

Note:

When the Skip setting for Programme
Number 100 through 125 is on, the channel
selection time will be shortened, and thus you
can not input three digits at a time.

Volume adjustment

Push the Volume Up “+” or Down button

to increase or decrease the sound volume

level.

^ 12 VOLUME

-50

General Operation

DISPUY

TV/AV mode Selection

Push the ‘TV/AV” button to select TV,
AV1, AV2, AV3, AV4 input signal
modes sequentially.

Display button

When the Display button is pressed,

the Panasonic Logo is displayed.
Push the Display button a second time
to the normal viewing condition.

Note:

(1) When this button is pushed,

Picture and Sound menus
change to Picture (DYNAMIC)
and Sound (DYNAMIC).

(2) When this button is pushed during

Game mode, Picture and Sound
menus change to Picture (GAME)
and Sound (DYNAMIC).

Recall button

Push the “Recall” button to display
the current system status.
Push again to cancel.

■4

<D

mso

Programme Number (Refer to page 20)

o

Audio Mode (Refer to page 41)

o

Sound Menu (Refer to page 43)

o

Picture Menu (Refer to page 42)

o

Off Timer (Refer to page 33)

0

Off Timer button

The TV set may be preset to switch
to stand-by after a fixed period.

By pushing “Off-Timer” button, you

can select the preset time; either “30”,

“60", “90” minutes or AUTO mode.

GAME

Game button

Push this button to change to the AV2
input signal and enter Game mode.
The picture and sound changes to a
suitable mode for video games.

10

Note:

When you push this button during

stand-by mode, the TV will turn on
automatically and Picture and Sound
changes to a suitable mode for video
games.

8

Sound Mute button

Push this button to mute the sound
completely.

The “Mute” symbol will appear.

(Colour change to red)

Push the button once again to restore
the previous sound level, and cancel
the mute.

a30~-> E]60 ^E]90 -

■Bo^

Setting Off-Timer to AUTO mode.

If the set is not switched off when the

TV station stops broadcasting, it will

automatically go to Stand-by mode
after 5 minutes.

Note:

Off-Timer setting will not operate in
AUTO mode when the Television set

is in AV mode.

►BAUTO

J

oo

...........

, ‘-I \

General Operation

Sound System Selection (Different region use differing systems)

1,3 2

L

DISPLAY TV/AV PRE. - ^ +

A game

r

(TV set)

This function is used only in the TV mode, and is not applicable in AV mode when the sound is not clear or

no sound is produced on a Programme Number.

1

PR E

Push the “PRE.” (PRESET)
button 5 times.

Push the Volume Up or
Down button repeatedly
until the optimum sound is

obtained.

s

CH s
CH S EL EC T P O S.
SYS S E LE C T fíSlñ/'H. E
RU TO T U NE
HP HU R L TU N E

SOUND SYS 5. SMHi

CO LO U R SY S R U TO
FIN E TU N E
SKI P OF F

I 2 PR E SE T I

CH 2
CH S EL EC T POS .
SYS S E LE C T
RU TD T U NE
HR NU R L TU N E

ISDUND SYS

CO LO U R SY S
FIN E TU N E

SKI P

PR ES E T

RS Ifi/ H. E.

5.

RU TO

OF F

Sound System Condition.

The sound system will change

as shown.

4.5MHz -e

---------

> 5.5MHz

t i

6.5MHz <

Note:

These are different sound
broadcast transmission
systems applicable to differing
countries.

----------

> 6.0MHz

PR E.

Push the "PRE.” (PRESET)
button 4 times.

This returns the set to the
normal viewing condition.

The selected Sound System is
automatically memorised.

ili

General Operation

Colour System Selection (Different region use differing systems)

1,3 2

L

DISPLAY TV/AV PRE. - + V A GAME

(TV set)

If a clear picture with current colours cannot be obtained when a Broadcast or AV signai is received.

PRE.

Push the “PRE.” (PRESET)
button 6 times. (In AV mode it
is only necessary to push the
“PRE.” (PRESET) button
once.)

Push the Volume Up or
Down button repeatedly
until the optimum image is
produced.

|12 P RE S ET I

CH 12
CH S EL EC T
SYS S E LE C T
flUT D T UN E
MP IN UR L T UN E
SO UN D S YS

COL OUR SYS

FIN E TU N E
SKI P

12 PR E SE T
CH 12
CH S EL EC T P O S.
SYS S E LE C T flS Ifl /M . E .
RU TO T U NE
NR HU R L TU N E
SO UN D S YS 5 . StiHz

PQ S.

RS IR /H. E .

5. 5 M Hz

OF F

(miBiH iJfei mal Ifcá ii

FIN E TU N E

SKI P______________OFF

______

Colour System Condition.

The colour system will change
as shown.

AUTO PAL’^^ SECAM

t i

NTSC3.58 ^ NTSC4.43

Note:

PAL, SECAM and NTSC 3.58

are different colour signal

broadcast transmission
systems applicable to differing

countries NTSC 4.43 is a trick

playback mode used in special
VCR’s to playback NTSC
recorded video tapes through
PAL television equipment.

PRE.

Push the “PRE.” (PRESET)

button 3 times.
(In the AV mode, push the
“PRE.” (PRESET) button
once.)

This returns the set to the
normal viewing condition.

The selected Colour System is
automatically memorised.

or

Advanced Remote Control Operation

PICTURE IN PICTURE Operation

1 ^PIP' The TV broadcast signals and the external

signals can be viewed simultaneously.
By pushing the PIP button to view the
following PIP conditions.

PIP condition is as shown below

{Normal mode) (Picture in Picture mode)

■Sub Picture

input mode

■Sub Picture

Note:

(1) The DVD (Y, Pb, Pr) signal does not display a Sub-

Picture.

(2) When the set is in PIP mode, the left and right picture

are processed by two different circuits.

Therefore there may be a minor difference in clarity

between the Pictures.

VijSj^'^EvCil'Fiiiiiii^iiiiliiitVjilLiyLI'/i'j-'iZ’dV■-■ -1 • ■ ''i-Z-^”‘^'■'~^.■l-.'i..-ii■■'■■■ ■

Advanced Remote Control Operation

PiP ACTION

PIP ACTION

PIP ACTION

Sub picture Direct Programme
(Channel) Number Selection

Push the “PIP ACTION" button and
Direct programme Number Selection
button to select the programme number
during the Sub Picture input mode
indication is blinking.

Sub picture Programme Number
Selection

Push the "PIP ACTION” button and
Programme Number Up “a" or Down V”
button to select the next higher or lower

programme number.

Sub picture TV/AV mode
Selection

Push the “PIP ACTION" button, and TV/

AV button to select TV, AV1, AV2, AV3,
AV4 input signal mode seguentlally.

0

CHANGE

TV mode

CHANGE

^ Push the “CHANGE” button to swap from

Main picture to sub picture and vice
versa.

AV mode AV mode

7 Position buttons (Only for PIP

<d ® [ >

By pushing each “Position" button, you
can select the 9 positions of the Sub
Picture on the screen.

TV mode

PIP ACTION

Sub Headphones Volume
adjustment

Push the “PIP ACTION” button, and
volume Up “+” or Down button to
increase or decrease the sub
Headphones volume level.

Note;

The volume for the main picture on sub
picture can be adjusted separately.

Note:

By pushing the Normal “N” button while
the picture in picture mode is activated,
the Sub Picture position will move to the

bottom Right comer.

Advanced Remote Control Operation

STROBE , CH SEARCH and STILL Operation

STROBE

Push the “STROBE” button to display the sub
picture with a strobe effect.
When the “STROBE” is on, push the “STROBE”
button again to turn off the strobe, or push the
“STILL” button to freeze the strobe image.
Push the “STILL” button again to restart the strobe
effect.

PIP Size is Small

PIP Size is Large

OH SEARCH

STILL

CH (Channel) SEARCH

By pushing this button, it is possible to search
through all tuned programme numbers.
Push the desired programme number.

Channel Search

Number

STILL mode
PIP mode is OFF:

Push the Still button and the Main picture as a
still frame.

■STILL

PIP mode is ON:

Push the Still button to display the Sub picture

as a still frame.

OQ

STILL


Advanced Remote Control Operation

RAI and D.PNR Operation

P-AI (Picture-Artificial Intelligence)

The P-AI continuously detects fine difference in
the picture signal, with great precision, and

including the picture brightness, black level and
contrast. This function automatically adjusts the
picture to the best quality for the scene, and
reproduces images that provide a sense of
depth.

DPNR

D.PNR

This Picture Noise Reduction System is designed
to reduce picture noise during poor quality

reception conditions.

The D.PNR mode will change as shown.

r>OFF—STRONG

AUTO’^

WEAK—I

oo

Advanced Remote Control Operation

Surround Operation

SURROUND

Surround button

The benefits of surround sound are enormous. You

can be completely enveloped in sound; just as if you
were at a concert halt or cinema.

The surround effect can be obtained without the use

of external surround speakers.

On screen display during surround mode.

Type of broadcast

MONO (including
STEREO switched to
MONO by you) and
BILINGUAL

STEREO

On-screen display

MONO SURROUND

I

SURROUND OFF

STEREO SURROUND

I

SURROUND OFF

Select the AV mode
(AV1, AV2, AV3 and
AV4)

/►STEREO SURROUND

I

MONO SURROUND

SURROUND OFF

_______

Note:

If the stereo signal is poor or the receiving conditions
are not optimum or if STEREO: MONO automatic
switching occurs, it is recommended that “STEREO”
switch to MONO (Refer to page 41) be used. If problems
or unusual sudden effects are encountered in any of
the surround modes, it is recommended that
“SURROUND OFP be selected.

)

Advanced Remote Control Operation

Stereo Reception

When you receive the stereo/bilingual sound system,
sound output modes can be selected by pushing the
stereo/bilingual sound selection button.

SUPHMS TV/AV

o o

o

© © ©
© © ®
© © ©

© ©

aPNS «SEARCH sTiu PIP

o o o o

P.AI STROBE CHANSE f>IP ACTION

o o o o

I i [toll (f?D (F^

o o o o

Note:

(1) The “A2 (German)” stereo/bilingual TV

sound transmission system is used in the

following countries; Australia, Malaysia,

Thailand, Indonesia, etc.
The “NICAM” stereo TV sound transmission

system is used in the following countries;
New Zealand, Singapore, Hong Kong and
China.

(2) If the stereo signal is poor or the receiving

conditions are not optimum of if STEREO:

MONO automatic switching occurs, it is
recommended you switch from STEREO to

MONO.

When the broadcasting mode changes to
“STEREO” or “MONO” after you have

selected “MONO" mode, change over to
“STEREO” mode will be made
automatically.

0

VCfVlD/DVD

Audio Signal

STEREO
MAIN!
SUBH
MONO

Type of broadcast

Regular broadcast

(Standard Audio)

Regular

IS
<
o

z

'c'

O
9

cd
E

(U

NICAM MONOI

NICAM STEREO

NICAM DUAL MONO

(MAINI/SUBÌ)

Regular broadcast

(Standard Audio)

BILINGUAL or DUAL

MONO: MAIN!/

SUBÌ

STEREO

+

(MAINI)

Mode Indicator

CD

I

n

V

Mode Indicator

No Indicator

I V

CO V

I — I

^ ■■ m i

No Indicator

I — I

CO — V

Note:

(1) Even when the contents of the receiving signal

undergo changes, selection mode is kept intact.

(2) When the receiving conditions dereriorate, listening

will be easier if the mode is set to the "MONO”
position, using the stereo/bilingual sound selection
button.

(3) “DUAL”, also known as "DUAL MONO” or as

“BILINGUAL” is not currently transmitted in some
countries.

M -i

Main Menu Operation

Picture Menu Operation

9

w,

SELECT RCCES!

Picture Menu

DYNAMIC

STANDARD

SOFT

GAME

m

V io •

9 № V i O " @
apa Hina aaig

S3S COLOUR
n*a3a NTSC-TINT

■S'ja BRIGHT
□163 CONTRAST

0)3a SHARPNESS

Function

For viewing in brighter environments.

This menu selects a higher than normal

level of Contrast.
For viewing in normal (evening lighting)

environments.

This menu selects the normal levels of

Brightness and Contrast.
For viewing in a dark room.

This menu selects reduced levels of
Brightness and Contrast.

For playing TV GAME. *

MAIN MENU

a

1. Push the “Main Menu” button.

2. Select the “PICTURE” menu by pushing
the Position Left "<” or Right “>” button

and Access the “Picture” menu by
pushing the Position Up ‘V or Down “v”
button.

3. Choose the option and adjust by pushing
the Position Up “a” or Down “v ” button,

and by setting with the Position Left “<”
or Right “>” button.

1. You can change the level of each Function

{COLOUR, NTSC-TINT, BRIGHT,
CONTRAST, SHARPNESS) for each Picture
Menu.

2. Picture Menu mode will be memorized for

each TV, AV1, AV2, AV3 and AV4 mode.

Note

# Do not allow a still picture to be displayed for an

extended period, as this can cause a permanent
after-image to remain on the Projection TV
screen.
Examples of still pictures Include logos, video
games, computer images, teletext and images
displayed in 16 ; 9 mode.

Item

COLOUR

NTSC-TINT

BRIGHT

CONTRAST

SHARPNESS

Effect

<] D>

<l

<1 0

DuKtr BrioMtr

<1 D>

Indicator

n «CONTRAST

m sjsHA iwH eM

Note:

(1) When the to Multi PIP mode and Picture-in-

Picture mode, the main and sub pictures are
both adjusted simultaneously.

(2) Even if the TV is not set to “NTSC” mode,

“NTSC-TINT’ will be displayed and level
adjustment would be possible. But it would
not function.

(3) When the TEXT mode, COLOUR, NTSC-

TINT and SHARPNESS will not displayed.

f'Helpful Hint ([ElNormalization)

By pushing the Normal “N” button on the Remote Control while the Picture Menu is displayed, the selected Menu wiil be changed to

the Normal mode.

Normalization will not occur if the Menu is not displayed when the “N" button is pushed.

The Normal mode is the factory preset condition. Returning to this original condition is called “Normalization”.

Main Menu Operation

Sound Menu Operation

: V (0 * B

EÉnni

SELECT ACCESS

Sound Menu

DYNAMIC

STANDARD For Normal use.

V lo ■

EltlIÜM

SELECT O ftCCE

Amplifies the Low and High frequencies

and outputs
optimum sound.

For music programmes for example.

mtfjMENU

□

^ ^ lo ÿ B

MENU DYNRMIC

9=40 BASS

$ 45 TREBLE

bsjSE BALANCE
SURROUND STEREO

Function

1. Push the “Main Menu” button.

Z. Select the “Sound” menu by pushing the

Position Left “<” or Right “>” button and

Access the “Sound" menu by pushing the
Position Up “a” or Down “v" button.

3. Choose the option and adjust by pushing
the Position Up “a” or Down “v” button,
and by setting with the Position Left "<"
or Right “>" button.

1 - You can change the level of each Function

(BASS, TREBLE) for each Sound Menu.

2. Sound Menu mode will be memorized for each

TV, AV1. AV2, AV3 and AV4 mode.

AUTO

Item

BASS

TREBLE

BALANCE

Sound and Music signals are altered and

the best sound is automatically adjusted:

sound (e. g. News and Human voice, etc.)
is adjusted so as to be easy to hear and
music is adjusted to give background
impression.

Effect

0 ^

LM» Uon

Indicator

^ TREB LE

< 1

^

UttSP. FUtfUSP.

Note:

(1) When set to Multi PIP mode and Picture-in-

Picture mode, the main sound is adjusted .

(2) When SOUND AUTO mode is selected in

Sound Menu Operation, BASS and TREBLE
can not be adjusted.

f Helpful Hint ([^Normalization)

By pushing the Normal “N” button on the Remote Control while the Sound Menu is displayed, the selected Menu will be changed to

the Normal mode.

Normalization will not occur if the Menu is not displayed when the “N" button is pushed.

The Normal mode is the factory preset condition. Returning to this original condition is called “Normalization".

AO

Main Menu Operation

Features Menu Operation

MAW MENU

№ V i s t

SELECT PCCE5E

I) № Q to y B

M № Q lo f B

SELECT it>RCCES5

Id. PNR

P. fli
C. TEHP
CH COLOUR

pEHQ/D. PNR

I .

__________

D.PNR (Picture Noise Reduction) mode

This Picture Noise Reduction System is designed
to reduce picture noise during poor quality

reception conditions.

P.AI mode

The P.AI continuously detects fine differences in
the picture signal, with great precision, and

including the picture brightness, black level and
contrast.
This function Automatically adjusts the picture to
the best quaiity for the scene, and reproduces

images that provide a sense of depth.

a

STANDARD

SET — —

1. Push the “Main Menu” button.

2. Select the “FEATURES” menu by pushing

3. Choose the option and adjust by pushing

strong!

OFF

g » Q |j0 * B

ID. PNR

P. fli OFF
C. TEMP STANDARD
CH COLOUR SET — —

pEHO/D. PNR

I ^

i » is to 7 ■

D. PNR
C. TEMP STRNDARO

CH COLOUR SET
DEMO/D. PNR

the Position Left “<” or Right “>” button
and Access the “Features” menu by
pushing the Position Up “a” or Down “v”
button.

the Position Up “a" or Down “v" button,
and by setting with the Position Lett “<”
or Right “>” button.

5TR0NGÌ

I

STRONG

C.TEMP (Colour Temperature) mode

The C.TEMP (Colour Temperature = classifying
white light) will change as follows.

STANDARD <- COOL

WARM

CH COLOUR SET mode

Colour density varying between broadcast
channels can be adjusted to three levels for each

reception channel.

IWT Tb

D. PNR
P, fli

CH COLOUR SET
DEMO/D. PNR

STRONG

OFF

STRHORRD

g № Q |0 f B

D. PNR nUTO
P. flI ON
C. TEMP STflHOBRD

OEMO/D. PNR

Main Menu Operation

DEMO / D.PNR mode

You can check the D.PNR effect on the left and

right sides of the screen.

BLUE BACK mode

When no picture signai is received, or the signai
is weak, the screen reverts to a blue background
colour and the Sound is muted.
Disable this Feature to continue watching very
weak signais.

Note:

If BLUE BACK mode is set on while a VCR signal
is being viewed, selecting CUE or REVIEW may

cause the screen to revert to the blue background

colour. Disable this Feature to view correctly.

.y

ffl TETi

D. PNR
P. fil
C. TEMP
CH COLOUR SET

f

g № Q lo " @

BLUE BRCK

UCR/CRHE

BU CKI P

CHILD LOCK OFF
PICTURE SHIFT OK
CONVERGENCE

STRONG

OFF

STRNDRRD

io^

OFF

D.PNR

m

Blue if no input picture
signal or input signal is
weak

VCR/GAME mode

Reproduction of irregular signals, such ascertain
TV games and rental video tapes, may be
improved.

Note

slTBiW"

BLUE BACK OH

lULR/GfiME

flU SKIP
CHILD LOCK
PICTURE SHIFT
CONUERGENCE

■ ■

OFF

OFF
ON

Do not allow a still picture to be displayed for an extended period, as this can cause a permanent after-image to
remain on the Projection TV screen.
Examples of still pictures include logos, video games, computer images, teletext and images displayed in 16 : 9
mode.

Main Menu Operation

AV Skip mode

When the AV Skip mode is set on, this step is
skipped at the time of seiection with the TV/AV

button.

CHILD LOCK mode
(No indication in TEXT input mode)

if the Chiid-Lock function is set ON, picture and

sound of the TV/AV mode being viewed wiii
disappear.

PICTURE SHIFT

For use as a screen saver, the following displays
change position (shift) every 30 minutes by several
millimetres;

• Standard on-screen status indicators (all current
system settings can be displayed using the Recall
button).

• Input screen during Game mode.

S № u

BLUE BRCK QH
UCR/GRHE

mu

CHILD LOCK
PICTURE SHIFT
CQNUERGENCE

S R Q lo

BLUE BRCK
UCR/GRME OFF
RU SKIP

CHILD LOCK

PICTURE SHIFT

CDNUERGEHCE

i

f m

i » Q lo 7 i

BLUE BRCK ON
UCR/'GinME OFF
flU SKIP
CHILD LOCK OFF

PICTURE SHIFT DN

CQNUERGENCE

s

OFF
OFF

ON

ON

□ ffB

ON

CONVERGENCE ADJUSTMENT

(See page 10)

W R Q lo

BLUE BRCK ON
UCR/GRNE OFF
RU SKIP
CHILD LOCK OFF
PICTURE SHIFT ON

■C OHU ERG ENC EH

▼

"

i

i X^'^'I'jr.iriJi-i ;¿i; iLi. ,1 j /i!,. c.

Main Menu Operation

Language Menu Operation

^ № VI f e

LRNGUPIGE

m\i

SELECT O RCCE55

Mwpu

D

1. Push the “Main Menu” button.

2. Select the “Language” menu by
pushing the Position Left “<” or Right
“>” button.

3. Push the Position Up “a” or Down “v”
button. The on-screen language
display will change.

Main Menu Operation

Multi PIP Menu Operation

PIP mode

Select the PIP mode.

1. Push the "Main Menu” button.

2. Select the “Multi PIP" menu by pushing the

Position Left “<" or Right “>" button and

Access the "Multi PIP" menu by pushing
the Position Up “a” or Down “v" button.

3. Choose the option and adjust by pushing
the Position Up “a ” or Down “v” button, and

by setting with the Position Left “<” or
Right V button.

OFF;Normal mode ON: Picture in Picture

PIP SIZE mode

This feature allows the user to change the sub

picture size in PIP mode.

SMALL........1/16 size of the main picture

LARGE

.......

1/9 size of the main picture

—

^

1 1

When the PIP size mode is
SMALL:

When the PIP size mode Is

LARGE:

Main Menu Operation

CH (Channel) SEARCH mode

When the CH SEARCH mode is ON, it is possible
to search through all tuned programme numbers,
Push the desired programme numbers.

STROBE mode

When the STROBE mode is ON, to display the
sub-picture with a strobe effect.

When the PIP Size Mode is
Small:

When the PIP SIZE Mode is

Large:

When the PIP SIZE Mode is

Small;

When the PIP SIZE Mode is

Large:

STILL mode

TV mode -AV mode AV mode TV mode

Aa

Teletext Operation

( For TX-51P15, TX-43P15 series )

• Teletext features may vary depending on the Broadcasting
Companies and is only availabie if the channel selected is
transmitting Teletext.

• When In teletext mode, the volume may still be altered to the
desired listening level.

What is LIST mode?

In LIST mode, four different coloured page numbers are situated

at the bottom of the screen. Each of these numbers can be altered
and stored in the TV's memory.

What is FASTEXT?

!n FASTEXT mode, four differently coloured subjects are situated
at the bottom of the display. To access more information about
one of these subjects, push the appropriately coloured button.

This facility enables fast access to information of the subjects

shown.

What are the advantages?

• Page selection at the touch of a Colour-coded button.

• Easy to use step-by-step selection of the topics subject.

• Reduction of waiting time.

• Page status line at bottom of screen so you always know which

button will take you to the desired information.

8

3

5

Teletext Operation

TV/TEXT

TV/Teletext mode

By pushing the ‘TV/TEXT” button, to

change the TV/Teletext mode as
follows.

TV

Teletext

Page Selection

Pages can be selected in two ways:

a) Push the Up/Down button to

increase or decrease the page
number by one.

b) By entering the page number,

using 0‘9 on the remote control.

Full/Top/Bottom

Push to expand the Top half of the
page.
Push again to expand the Bottom half.
Push again to return to normal (FULL)
size.

8

F.P.

Favourite Page (F.P.)

Stores a favourite page in memory for
instant recall. To store such a page, the
TV must be in LIST mode, push the Light

BLUE button, select the page number,

then push List Store. The page number

is now stored.
Push F.P. to recall this page.

Index

Push INDEX to return to the main index
page.

(±1

Light

cb Gb cb

Red Green Yellow Blue

Hold

Push to hold the current page.
Push again to cancel the hold.

Reveal

Push to reveal hidden words e.g.quiz
page answers.
Push again to hide.

Colour-Coded buttons

In FASTEXT mode these correspond
to the differently coloured subjects.

In LIST mode they correspond to the

differently coloured page numbers.

p 4

Teletext Operation

Sub Coded Page Access

The TEXT menu will be displayed in TEXT mode. When teletext

information exceeds more than one page, it may take some time for

the automatic changing of the sub pages to reach the sub page you

require. It is possible to enter your required sub page and continue

Panasonic

SURROUND TV/AV

o o o

® © ®

watching the normal programme until the correct sub page is found.
Select the required page number using buttons 0-9.

TIME

TEXT

Push the TIME TEXT button.

® ® ®
® ® ®

V

R

@ ® 0

O. PNR CH SEARCH STILL PIP

O O CD CD

P. AI STROBE CHANaE PIP ACTION

O CD CD O

VCR/LD/DVD

VCR iLD/DVOl [TlDiscsirerBl

a □ (B a

a ZD

0 ™ 0

TV/TEXT INDEX

CEW

fiTnl

□ (UD

TIME

TEXT HE\^AL FVT7B

CD jm

1-

3

O CD CD

(jp ®

I5XIPI m

(A]

Md IHK IH

HOLD

*1

HD d2)

CD

Enter desired sub page number.

To select page 6 enter 0, 0, 0 and 6.

Push the TIME TEXT button.

Teletext Operation

TEXT Menu

B f'fi V lo t

SELECT ACCESS

"WiTV

liigaEl

LIST STCF!

TEXT HOOE!

DISPLAY CANCEL

Push the Position Left “<”
screen will display the pad

News Flash

When a news flash page

update is received, it will

Update

Push Position Left “<” or

the page number will be

Operation

MAIN MENU

a

iD f ■ g

LIST/FflST

Dr Right “>” button to view the TV picture while searching for a Teletext page. When found, the

e number at the top left.

las been selected, push Position Left “<” or Right ">” button to view the TV picture, when an

t)e displayed on screen.

Flight “>" button to see the update of information on certain pages. When an update is received,
c isplayed at the top left of the screen.

1. Push the “TV/TEXT button on the Remote

Control to select the TEXT mode.

2. Push the “Main Menu” button.

3. Select the “TEXT” menu by pushing the
Position Left “<” or Right ">" button and

Access the “TEXT” menu by pushing the

Position Up “a” or Down “v” button.

4. Choose the option and adjust by pushing the
Position Up “a” or Down “v” buttons, and by
setting with the Position Left “<” or Right “>”
buttons.

LIST STORE

In LIST mode the four
buttons and enter the nevj/
Push and hold List store,

TEXT MODE

Push to change from FA
In FASTEXT mode four
coloured button to access

psi

ge numbers can be altered for channel position. To do this, push one of the colour coded

page number.

the page number will change colour.

S TEXT mode to LIST mode and vice versa.

differently coloured subjects are displayed at the bottom of the page. Push the appropriate

more information about one of these subjects.

Operation of the VCR / LD / DVD

Manufacturer setting

Remote Control Operation is possible for the VCR’s, LD’s and DVD’s
of the various manufacturers.
After completion of setting, execute the various operations after pushing
the VCR or the LD/DVD button.

1

VCR

Push the button of the unit to be set {VCR or
LD / DVD).

While pushing the VCR / LD / DVD Power

button, push the manufacturer code setting
(enter the two digit code), and push the VCR /
LD / DVD Stop button.

VCR

Manufacturer
Panasonic/

National ORION

AIWA

FUJITSU 20 SANYO
HITACHI 25,26,27

JVC 30,31,32

MITSUBISHI 35,36 TOSHIBA

LD

Manufacturer
Panasonic

KENWOOD
PHILIPS
PIONEER

Code

10,11,12,13
15,16

Code

10,11,12,13
15,16
20
25

Manufacturer Code
NEC

PHILIPS

SHARP
SONY

Manufacturer Code

SAMSUNG
SHARP
SONY

40,41,42,43
45,46

50
55,56.57,58
60,61
65,66,67
70,71

30
35
40,41,42,43

DVD

Manufacturer Code

Panasonic

70

NOTE:

After setting, execute operation confirmation.

If there is no operation, set a different code.

f Helpful Hint

(1) The respective VCR / LD / DVD manufacturer code is cancelled

when battery has been exchanged.

Please set it again.

(2) Depending on the model, operation of VCR’s, LD’s or DVD’s of

the manufacturers listed above may not be possible.
(3) In some cases, new products may not be operative.
(4) It will not operate with other than the above manufactures.

Si

Execute the various operations after pushing the VCR or LD / DVD

button.

5

6

7

8

Button

m

◄◄

&

►►

Function

VCR

Rew (Rewind) /
Review Button

VCR Power Button

Stop Button

Still Advance
Button

Play Button

FF (Fast Forward) /
Cue Button

LD/DVD

Rew (Rewind) /
Review Button

LD / DVD Power
Button

Stop Button

DISC SIDE A
Selection Button

Play Button

FF (Fast Forward) /

Cue Button

8

□D

I5KTP1 iXH

(A)

|<M rSklPI

Rec (Record)
Button

Pause / Still Button

Programme
Number Up and
Down Button

DISC SIDE B
Selection Button

Pause / Still Button

Programme Skip
Button

Cleaning

To ensure continued excellent performance by this product, periodic cleaning is recommended.

0

0

The unit contains many plastic
parts. For this reason DO NOT
use benzine, thinner or other
chemicals to clean the unit.

DO NOT bring into contact with
insecticide or other volatile
substances.
DO NOT allow the unit to come
into contact for extended periods
with rubber or vinyl products.

Dust will accumulate on the
picture screen. Please wipe
with the supplied soft cloth from
time to time. If you use a

chemically treated cloth, please
be careful to follow the
instructions that corne with the
cloth.

Remove dirt and soiling by

wiping with a light cloth.

Even if the unit is heavily soiled,
do not apply cleaner directly to
the unit. Soak a cloth in a

solution of neutral cleanser

thinned with water. Then wring

out the cloth, wipe the unit

clean, and finish by wiping with

a dry cloth.

Do not use any type of

cleansers on the picture screen.

Specifications

Power Source

Power Consumption

Receiving System

TX-51P15X
TX-43P15X

AC Auto 110-240 V, 50/60 Hz

193 W
Stand-by condition 0.4 W

21 Systems

1
2
3
4

5

6
7

8
9
10
11
12

13

14 SECAM 1
15

16
17
18
19
20
21

PALB, G, H
PALI
PAL D, K
SECAM B, G
SECAM D. K
SECAM K1
NTSC M (NTSC 3.58/4.5 MHz)

NTSC 4.43/5.5 MHz
NTSC 4.43/6.0 MHz
NTSC 4.43/6.5 MHz
NTSC 3.58/5.5 MHz
NTSC 3.58/6.0 MHz
NTSC 3.58/6.5 MHz

PAL 60 Hz/5.5 MHz

PAL 60 Hz/6.0 MHz

PAL 60 Hz/6.5 MHz
SECAM 60 Hz/5.5 MHz
SECAM 60 Hz/6.0 MHz
SECAM 60 Hz/6.5 MHz

NTSC 50 Hz/4.5 MHz

TC-51P15G, TC-51P15H
TX-51P15H, TC-43P15G

TC-43P15H, TX-43P15H
AC 220-240 V, 50 / 60 Hz

188 W
Stand-by condition 0.4 W

Function

Reception of broadcast transmis-

sions and Playback from Video

Cassette Tape Recorders

Playback from Special VCR's

Playback from Special Disc
Players and Special VCR's

Receiving Channels

Receiving Stereo System

Regular TV

VHP BAND

2-12 (PAL/SECAM B,K1)
0- 12 (PAL B AUST.1

1- 9 (PALBN.Z) .
1-12 (PAL/SECAM D)
1- 12 (NTSC M Japan)
2- 13 (NTSC M U.S.A)

CATV

S1-S20 (OSCAR)
1-125 (U.S.A CATV)
C13-C49 (JAPAN)
S21-S41 (HYPER)
Z1-Z37 (CHINA)

5A, 9A (AUST.)

NICAM I , NICAM B/G, NICAM D, A2 (German)

UHF BAND

21-69 (PALG, H, I/SECAM G, K, K1)

28-69 (PAL B AUST)
13-57 (PAL aK)
13- 62 (NTSC M Japan)
14- 69 (NTSC M U.S.A)

Specifications

Tuning System

Audio Output

Headphones
Aeriai Impedance

Video/Audio Terminals

Frequency synthesizer
Auto Search Tuning

TX-51 PI5H, TX-51 PI5X, TC-51P15H
TX-43P15H. TX-43P15X, TC-43P15H

26W[13W+13W] (MAX)

24W[12W+12 W] (10%THD)

3.5 mm Plug x 2

75 n Unbalanced coaxial

AV1,2, 3, 4 S-Videotn

Monitor Out Video Out

AVI IN (Rear) : S-Video, Video, Audio L/R terminals
AV2 IN (Front) : S-Video, Video, Audio L/R terminals
AV3 IN (Rear) : Video, Audio L/R terminals
AV4 IN (Rear) : Video or Y / Pb/ Ph, Audio L/R terminals

POS (Position) : 100 Position
DIRECT : 125 Position

TC-51 PI 5G
TC-43P15G

26W[13W + 13W] (MAX)

22W[11W+ 11W] (7%THD)

DVD (Y/Pb/Pr)

Video In 1 Vp-p. 75 a

Audio in Approx. 0.5 V 47 KO

Audio Out Approx. 0.5 V 1 KO

Y;1 Vp-p, 75 ti
C:0.3 Vp-p, 75 O

1 Vp-p, 75 n

Accessories Supplied Remote control Transmitter TNQE194 .....TX-51 PI 5H, TX-51 P15X

TX-43P15H.TX-43P15X

Dimensions

(WxDxH)

Weight (Ma^):

; .'.v.j.;' ... . . .

Note: ij

Design and

■viv

TNQE196

R6 (AA) Battery x 2

75 n coaxial aerial plug

TC / TX-51 P15 Series TO / TX-43P15 Series

1095 mm x 500 mm x 1371 mm 933 mm x 500 mm x 1261 mm

TX-51P15H, TX-51P15X, TC-51P15H: 61 kg (Net)
TC-51 P15G: 62 kg (Net)
TX-43P15H, TX-43P15X, TC-43P15H: 53 kg (Net)
TC-43P15G: 54 kg (Net)

5ns are subject to change without notice. Weight and Dimensions shown are approximate.

.....TC-51P15H.TC-51P15G

TC-43P15H,TC-43P15G

m:-'

iii
