Page 1
Operating Instructions
Model No. KX-TG7841
KX-TG7842
KX-TG7843
KX-TG7844
KX-TG7845
KX-TG365SK
KX-TG7871
KX-TG7872
KX-TG7873
KX-TG7874
KX-TG7875
KX-TG385SK
Link-to-Cell Cellular Convergence Solution
Model shown is KX-TG7841.
Before initial use, see “Getting Started”
on page 10.
Thank you for purchasing a Panasonic product.
Please read these operating instructions before using the unit and save them for
future reference.
Consulte “Guía Rápida Española”, página 80.
For assistance, visit our Web site: http://www.panasonic.com/help for customers
in the U.S.A. or Puerto Rico.
Please register your product: http://www.panasonic.com/prodreg
Page 2
Table of Contents
Introduction
Model composition .......................................3
Accessory information ..................................3
Important Information
For your safety .............................................6
Important safety instructions ........................7
For best performance ...................................7
Other information .........................................8
Specifications ...............................................9
Getting Started
Setting up ...................................................10
Intelligent eco mode ...................................12
Controls ......................................................12
Display/Indicators .......................................14
Initial settings .............................................16
Link to Cell
Link to cell feature ......................................17
Pairing a cellular phone ..
Link to cell settings .....................................18
............................17
Making/Answering Calls Using
the Handset
Making cellular calls ...................................21
Making landline calls ..................................21
Answering calls ..........................................22
Useful features during a call .......................22
Power back-up operation for
landline .......................................................25
Making/Answering Calls Using
the Base Unit
Making cellular calls ...................................28
Making landline calls ..................................28
Answering calls ..........................................29
Useful features during a call .......................29
Shared Phonebook
Shared phonebook .....................................32
Speed Dial
Speed dial ..................................................35
Programming
Programmable settings ..............................36
Special programming .................................44
Registering a unit .......................................47
2
Caller ID Service
Using Caller ID service ...............................
Caller list ....................................................49
Using Bluetooth Devices
Copying phonebook from a cellular phone
(phonebook transfer) ..................................52
Text message alert .....................................53
Using a Bluetooth wireless headset (optional)
for landline calls .........................................53
Answering System for Landline
Answering system for landline ...................56
Turning the answering system on/
off ...............................................................56
Greeting message ......................................56
Listening to messages using the base
unit .............................................................57
Listening to messages using the
handset ......................................................58
Advanced new message alerting
features ......................................................59
Remote operation .......................................60
Answering system settings .........................61
Voice Mail Service for Landline
Voice mail service for landline ....................63
Intercom/Locator
Intercom .....................................................65
Handset locator ..........................................65
Transferring calls, conference calls ............65
Useful Information
Wall mounting ............................................67
Error messages ..........................................68
Troubleshooting .........................................69
FCC and other information .........................77
Guía Rápida Española
Guía Rápida Española ...............................80
Appendix
Customer services .....................................90
Warranty (For United States and Puerto
Rico) ...........................................................91
Index
Index...........................................................93
48
Page 3
Introduction
Model composition
Series Model No.
KX-TG7841
s
eries
KX-TG7841
KX-TG7842 KX-TG7841 KX-TGA680 2
KX-TG7843 KX-TG7841 KX-TGA680 3
KX-TG7844 KX-TG7841 KX-TGA680 4
KX-TG7845 KX-TG7841 KX-TGA680 5
KX-TG365SK KX-TG7841 KX-TGA680 5
KX-TG7871
*2
eries
s
KX-TG7871
KX-TG7872 KX-TG7871 KX-TGA680 2
KX-TG7873 KX-TG7871 KX-TGA680 3
KX-TG7874 KX-TG7871 KX-TGA680 4
KX-TG7875 KX-TG7871 KX-TGA680 5
KX-TG385SK KX-TG7871 KX-TGA680 5
*1 Single handset models: Intercom calls can be made between handsets by purchasing and
r
egistering one or more optional handsets (page 5).
*2 The following features are provided for these models:
– USB charging (USB jack is on the left side of the base unit)
– Text message alert feature
Base unit Handset
Part No. Part No. Quantity
1
*
KX-TG7841 KX-TGA680 1
1
*
KX-TG7871 KX-TGA680 1
Accessory information
Supplied accessories
Supplied handset qty.
No.
Accessory item/
O
rder number
6
A
AC adaptor
B Telephone line cord/
QJA10075Z
P
C Desk stand/Wall mounting
daptor*7/PNKL1038Z1
a
D Rechargeable batteries/
H
HR-4DPA
E
Handset cover
PNYNTGA680BR
*
8
*
/
For assistance, please visit http://www.panasonic.com/help
1 unit
1
*
2 units
2
*
3 units
3
*
4 units
Accessory quantity
1 1 1 1 1
1 1 1 1 1
1 1 1 1 1
2 4 6 8 10
1 2 3 4 5
4
*
5 units
5
*
3
Page 4
Introduction
Supplied handset qty.
No.
Accessory item/
rder number
O
F Belt clip/PNKE1268Z1 1 2 3 3 3
G Charger/PNLC1040ZB – 1 2 3 4
*1 KX-TG7841/KX-TG7871
2 KX-TG7842/KX-TG7872
*
*3 KX-TG7843/KX-TG7873
*4 KX-TG7844/KX-TG7874
*5 KX-TG7845/KX-TG7875/KX-TG365SK/KX-TG385SK
*6 PNLV226Z: KX-TG7841/KX-TG7842/KX-TG7843/KX-TG7844/KX-TG7845/KX-TG365SK
PNLV234Z: KX-TG7871/KX-TG7872/KX-TG7873/KX-TG7874/KX-TG7875/KX-TG385SK
*7 The desk stand/wall mounting adaptor comes attached to the base unit.
*8 The handset cover comes attached to the handset.
A
PNLV226 PNLV234
E F G
1 unit*12 units*23 units*34 units*45 units
Accessory quantity
B C D
Additional/replacement accessories
lease contact your nearest Panasonic dealer for sales information (page 90).
P
Accessory item Order number
1
Rechargeable
b
atteries
HHR-4DPA
R To order, please call 1-800-332-5368 or visit
Battery type:
–
– 2 x AAA (R03) size for each handset
Headset KX-TCA60, KX-TCA93, KX-TCA400, KX-TCA430
T-adaptor KX-J66
Range extender
Key detector
KX-TGA405
KX-TGA20
*1 Replacement batteries may have a different capacity from that of the supplied batteries.
*
http://www.panasonic.com/batterystore
Nickel metal hydride (Ni-MH)
2
*
3
*
*5
4
For assistance, please visit http://www.panasonic.com/help
Page 5
Introduction
*2 By installing this unit, you can extend the range of your phone system to include areas
w
here reception was previously not available. This product can be purchased online. Please
visit our Web site: http://www.panasonic.com/RangeExtender
*3 By registering the key detector (4 max.) to a Panasonic Digital Cordless Phone and
attaching it to an easy-to-lose item in advance, you can locate and find the mislaid item to
which the key detector is attached. Please visit our Web site:
http://panasonic.net/pcc/products/telephone/p/tga20/
Expanding your phone system
Handset (optional): KX-TGA680
You can expand your phone system by
r
egistering optional handsets (6 max.) to a
single base unit.
R Optional handsets may be a different color
from that of the supplied handsets.
Bluetooth®
You can expand your phone system by pairing the following units to a single base unit.
Your Bluetooth cellular phone
(for cellular calls: page 17)
Your Bluetooth headset
(for a wireless hands-free conversation: page 53)
*1 Your cellular phone and headset must be Bluetooth wireless technology compatible. For
devices
1
*
: 2 max.
*
1
: 1 max.
m
ore details and the list of compatible cellular phones, please visit our Web site:
http://www.panasonic.com/link2cell
Trademarks
R T
he Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of
such marks by Panasonic Corporation is under license. All other trademarks identified herein
are the property of their respective owners.
For assistance, please visit http://www.panasonic.com/help
5
Page 6
Important Information
For your safety
T
o prevent severe injury and loss of life/
property, read this section carefully before
using the product to ensure proper and safe
operation of your product.
WARNING
Power connection
se only the power source marked on the
R U
product.
R Do not overload power outlets and
extension cords. This can result in the risk
of fire or electric shock.
R Completely insert the AC adaptor/power
plug into the power outlet. Failure to do so
may cause electric shock and/or excessive
heat resulting in a fire.
R Regularly remove any dust, etc. from the
AC adaptor/power plug by pulling it from
the power outlet, then wiping with a dry
cloth. Accumulated dust may cause an
insulation defect from moisture, etc.
resulting in a fire.
R Unplug the product from power outlets if it
emits smoke, an abnormal smell, or makes
an unusual noise. These conditions can
cause fire or electric shock. Confirm that
smoke has stopped emitting and contact
the Panasonic Call Center at
1-800-211-PANA (1-800-211-7262).
R Unplug from power outlets and never touch
the inside of the product if its casing has
been broken open.
R Never touch the plug with wet hands.
Danger of electric shock exists.
Installation
o prevent the risk of fire or electrical
R T
shock, do not expose the product to rain or
any type of moisture.
R Do not place or use this product near
automatically controlled devices such as
automatic doors and fire alarms. Radio
waves emitted from this product may cause
such devices to malfunction resulting in an
accident.
6
For assistance, please visit http://www.panasonic.com/help
R D
o not allow the AC adaptor or telephone
line cord to be excessively pulled, bent or
placed under heavy objects.
Operating safeguards
nplug the product from power outlets
R U
before cleaning. Do not use liquid or
aerosol cleaners.
R Do not disassemble the product.
R Do not spill liquids (detergents, cleansers,
etc.) onto the telephone line cord plug, or
allow it to become wet at all. This may
cause a fire. If the telephone line cord plug
becomes wet, immediately pull it from the
telephone wall jack, and do not use.
Medical
onsult the manufacturer of any personal
R C
medical devices, such as pacemakers or
hearing aids, to determine if they are
adequately shielded from external RF
(radio frequency) energy. (The product
operates in the frequency range of
1.92 GHz to 1.93 GHz, and the RF
transmission power is 115 mW (max.).)
R Do not use the product in health care
facilities if any regulations posted in the
area instruct you not to do so. Hospitals or
health care facilities may be using
equipment that could be sensitive to
external RF energy.
CAUTION
Installation and location
R N
ever install telephone wiring during an
electrical storm.
R Never install telephone line jacks in wet
locations unless the jack is specifically
designed for wet locations.
R Never touch uninsulated telephone wires or
terminals unless the telephone line has
been disconnected at the network interface.
R Use caution when installing or modifying
telephone lines.
R The AC adaptor is used as the main
disconnect device. Ensure that the AC
outlet is installed near the product and is
easily accessible.
R This product is unable to make calls when:
Page 7
– the handset batteries need recharging or
h
ave failed.
– there is a power failure.
Battery
e recommend using the batteries noted
R W
on page 4. USE ONLY rechargeable
Ni-MH batteries AAA (R03) size.
R Do not mix old and new batteries.
R Do not open or mutilate the batteries.
Released electrolyte from the batteries is
corrosive and may cause burns or injury to
the eyes or skin. The electrolyte is toxic and
may be harmful if swallowed.
R Exercise care when handling the batteries.
Do not allow conductive materials such as
rings, bracelets, or keys to touch the
batteries, otherwise a short circuit may
cause the batteries and/or the conductive
material to overheat and cause burns.
R Charge the batteries provided with or
identified for use with this product only, in
accordance with the instructions and
limitations specified in this manual.
R Only use a compatible base unit (or
charger) to charge the batteries. Do not
tamper with the base unit (or charger).
Failure to follow these instructions may
cause the batteries to swell or explode.
Attention:
A nickel metal hydride battery that is
r
ecyclable powers the product you have
purchased.
Please call 1-800-8-BATTERY
(1-800-822-8837) for information on how to
recycle this battery.
Important Information
Important safety
i
nstructions
When using your product, basic safety
precautions should always be followed to
reduce the risk of fire, electric shock, and
injury to persons, including the following:
1. Do not use this product near water for
example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet
basement or near a swimming pool.
2. Avoid using a telephone (other than a
cordless type) during an electrical storm.
There may be a remote risk of electric
shock from lightning.
3. Do not use the telephone to report a gas
leak in the vicinity of the leak.
4. Use only the power cord and batteries
indicated in this manual. Do not dispose of
batteries in a fire. They may explode.
Check with local codes for possible special
disposal instructions.
SAVE THESE INSTRUCTIONS
For best performance
Base unit location/avoiding noise
T
he base unit and other compatible Panasonic
units use radio waves to communicate with
each other.
R For maximum coverage and noise-free
communications, place your base unit:
– at a convenient, high, and central
location with no obstructions between
the handset and base unit in an indoor
environment.
– away from electronic appliances such as
TVs, radios, personal computers,
wireless devices, or other phones.
– facing away from radio frequency
transmitters, such as external antennas
of mobile phone cell stations. (Avoid
putting the base unit on a bay window or
near a window.)
R Coverage and voice quality depends on the
local environmental conditions.
For assistance, please visit http://www.panasonic.com/help
7
Page 8
Important Information
R I
f the reception for a base unit location is
not satisfactory, move the base unit to
another location for better reception.
Environment
eep the product away from electrical noise
R K
generating devices, such as fluorescent
lamps and motors.
R The product should be kept free from
excessive smoke, dust, high temperature,
and vibration.
R The product should not be exposed to
direct sunlight.
R Do not place heavy objects on top of the
product.
R When you leave the product unused for a
long period of time, unplug the product from
the power outlet.
R The product should be kept away from heat
sources such as heaters, kitchen stoves,
etc. It should not be placed in rooms where
the temperature is less than 0 °C (32 °F) or
greater than 40 °C (104 °F). Damp
basements should also be avoided.
R The maximum calling distance may be
shortened when the product is used in the
following places: Near obstacles such as
hills, tunnels, underground, near metal
objects such as wire fences, etc.
R Operating the product near electrical
appliances may cause interference. Move
away from the electrical appliances.
Routine care
ipe the outer surface of the product
R W
with a soft moist cloth.
R Do not use benzine, thinner, or any
abrasive powder.
Other information
C
AUTION: Risk of explosion if battery is
replaced by an incorrect type. Dispose of used
batteries according to the instructions.
Notice for product disposal, transfer,
r return
o
R This product can store your private/
confidential information. To protect your
privacy/confidentiality, we recommend that
you erase information such as phonebook
or caller list entries from the memory before
you dispose of, transfer, or return the
product.
Notice
ENERGY S
As an ENERGY STAR® Partner, Panasonic
has determined that this product meets the
ENERGY STAR guidelines for energy
efficiency. ENERGY STAR is a U.S.
registered mark.
TAR (for KX-TG7841 series)
8
For assistance, please visit http://www.panasonic.com/help
Page 9
Specifications
R S
tandard:
DECT 6.0 (Digital Enhanced
Cordless Telecommunications 6.0)
Bluetooth wireless technology 2.0
R Frequency range:
1.92 GHz to 1.93 GHz (DECT)
2.402 GHz to 2.48 GHz (Bluetooth)
R RF transmission power:
115 mW (max.)
R Power source:
120 V AC, 60 Hz
R Power consumption:
Base unit:
Standby: Approx. 1.2 W
Maximum: Approx. 4.5 W
Base unit:
Standby: Approx. 1.2 W
Maximum: Approx. 8.5 W
Charger:
Standby: Approx. 0.1 W
Maximum: Approx. 1.8 W
R USB Charger:
Output voltage: DC 5 V
Output current: 500 mA
R Operating conditions:
0 °C – 40 °C (32 °F – 104 °F), 20 % – 80 %
relative air humidity (dry)
*1 KX-TG7841 series: page 3
*2 KX-TG7871 series: page 3
Note:
R Design and specifications are subject to
change without notice.
R The illustrations in these instructions may
vary slightly from the actual product.
*1
*2
*2
Important Information
For assistance, please visit http://www.panasonic.com/help
9
Page 10
Correct
Incorrect
To power outlet
Press plug firmly.
Hook
“Click”
To single-line
telephone jack
(RJ11C)
DSL/ADSL filter*
“Click”
To power outlet
To single-line
telephone jack
(RJ11C)
DSL/ADSL filter*
“Click”
“Click”“Click”
To power outlet
Getting Started
Setting up
Connections
R I
f you do not connect the telephone line
cord and use only cellular lines, set the
cellular line only mode to use this unit more
conveniently (page 19).
n Base unit (KX-TG7841 series: page 3)
R Use only the supplied Panasonic AC
adaptor PNLV226.
n
Base unit (KX-TG7871 series: page 3)
R Use only the supplied Panasonic AC
adaptor PNLV234.
R The hook of the base unit is not designed to
hold the AC adaptor cord for the desk stand
or wall mounting use (page 67).
*DSL/ADSL filter (not supplied) is required if
ou have DSL/ADSL service.
y
n Charger
*DSL/ADSL filter (not supplied) is required if
you have DSL/ADSL service.
10
For assistance, please visit http://www.panasonic.com/help
Page 11
Rechargeable Ni-MH ONLY
Confirm “Charging” is displayed.
Getting Started
Battery installation
R USE ONLY Ni-MH batteries AAA (R03)
size.
R Do NOT use Alkaline/Manganese/Ni-Cd
batteries.
R Confirm correct polarities ( , ).
R W
hen the date and time setting is
displayed, see page 16.
Battery charging
C
harge for about 7 hours.
R When the batteries are fully charged,
“Fully charged” is displayed.
Note when setting up
Note for connections
he AC adaptor must remain connected at
R T
all times. (It is normal for the adaptor to feel
warm during use.)
R The AC adaptor should be connected to a
vertically oriented or floor-mounted AC
outlet. Do not connect the AC adaptor to a
ceiling-mounted AC outlet, as the weight of
the adaptor may cause it to become
disconnected.
Note for battery installation
se the supplied rechargeable batteries.
R U
For replacement, we recommend using the
Panasonic rechargeable batteries noted on
page 4, 7.
R Wipe the battery ends (
loth.
c
R Avoid touching the battery ends (
o
r the unit contacts.
Note for battery charging
R I
t is normal for the handset to feel warm
during charging.
R Clean the charge contacts of the handset,
base unit, and charger with a soft and dry
cloth once a month. Before cleaning the
unit, disconnect from power outlets and any
telephone line cords. Clean more often if
the unit is exposed to grease, dust, or high
humidity.
, ) with a dry
, )
For assistance, please visit http://www.panasonic.com/help
Battery level
Icon Battery level
High
Medium
Low
Needs charging.
Empty
11
Page 12
A A
B
B
D
C
H
I
J
K
G
L
A
E
F
Getting Started
Panasonic Ni-MH battery
erformance (supplied batteries)
p
Operation Operating time
In continuous use
Not in use (standby)
*1 If eco mode is on.
N
ote:
R Actual battery performance depends on
usage and ambient environment.
R Even after the batteries are fully charged,
the handset can be left on the base unit or
charger without any ill effect on the
batteries.
R The battery level may not be displayed
correctly after you replace the batteries. In
this case, place the handset on the base
unit or charger and let it charge for at least
7 hours.
10 hours max.
8 days max.
Intelligent eco mode
his feature automatically reduces handset
T
power consumption by suppressing handset
transmission power when the handset is close
to the base unit.
R When this feature is activated,
isplayed. However, during a cellular call,
d
is not displayed even though this
f
eature is activated.
R Eco mode is turned off when the clarity
booster is activated (page 23).
12
For assistance, please visit http://www.panasonic.com/help
Controls
1
*
1
*
is
Handset
Speaker
(TALK)
M N
Headset jack
Dial keypad (*: TONE)
MZN (SP-PHONE: Speakerphone)
Microphone
Receiver
Display
MOFFN
MFLASHNMCALL WAITN
Page 13
B
R
B
A
A
D
F
G
E
H
K
I
J
L
M
O
N
P
C
MN
OISE REDUCTIONN
Charge contacts
n C
ontrol type
S
oft keys
The handset features 2 soft keys. By
pressing a soft key, you can select the
feature shown directly above it on the
display. After a cellular phone is paired,
MCELLN is displayed.
N
avigator key
– MDN, MCN, MFN, or MEN: Scroll through
various lists and items.
(Volume: MDN
–
receiver or speaker volume while talking.
– MFN
– MEN REDIAL: View the redial list.
– MCN CID (Caller ID): View the caller list.
or MCN): Adjust the
: View the phonebook entry.
Base unit
Getting Started
USB jack
(
KX-TG7871 series: page 3)
Charge contacts
Speaker
Display
MH
OLDN
MR
EDIALN MPAUSEN
MF
LASHN MCALL WAITN
MZN (
SP-PHONE: Speakerphone)
SP-PHONE indicator
ME
RASEN
MA
NSWER ON/OFFN
ANSWER ON/OFF indicator
ML
OCATORN MINTERCOMN
MnN
(STOP) (EXIT)
M N
(PLAY)
Message indicator
ELL 1N
MC
CELL 1 indicator
ELL 2N
MC
CELL 2 indicator
Desk stand/Wall mounting adaptor
he adaptor is a removable
R T
attachment for desk stand or wall
mounting use (page 67).
Microphone
Dial keypad (*:
n Control type
Soft keys
he base unit features 3 soft keys. By
T
pressing a soft key, you can select the
feature shown directly above it on the
display.
Navigator key
MCN, M
– MDN,
various lists and items.
– VOL. (Volume: MDN or MCN): Adjust the
speaker volume while talking.
N/M N:
– M
during playback.
TONE)
N,
or MN: Scroll through
Repeat/skip messages
For assistance, please visit http://www.panasonic.com/help
13
Page 14
1
Getting Started
Charging the cellular phone by
USB
Available for:
X-TG7871 series (page 3)
K
By connecting a USB cable (not supplied) to
t
he cellular phone and the base unit, you can
charge a cellular phone. However, the cellular
phone cannot exchange data with the base
unit through a USB cable.
Belt clip
n
To attach n To remove
Display/Indicators
Handset display items
Item Meaning
Within base unit range
Item Meaning
Out of base unit range
The landline is in use.
R W
hen flashing:
The call is put on hold.
R When flashing rapidly: An
incoming call is now being
received.
A cellular line is in use.
hen flashing:
R W
The cellular call is put on
hold.
R When flashing rapidly:
A cellular call is being
received.
A cellular phone is
onnected.*1 Ready to make/
c
receive cellular calls.
R When turned off:
A cellular phone is not
connected to the base
unit. (page 19)
– The cellular line is
s
elected for the ringer
setting.
– A cellular call is being
received on that line.
2
*
Eco mode is on.
Noise reduction is set.
(page 24)
Equalizer is set. (page 24)
Z Speakerphone is on.
page 21)
(
Ringer volume is off.
(page 22, 38)
Silent mode is on.
page 45)
(
Call sharing mode is off.
page 41)
(
Alarm is on. (page 44)
Handset number
Battery level
Blocked call (page 45)
(page 12)
3
*
14
For assistance, please visit http://www.panasonic.com/help
Page 15
Getting Started
Item Meaning
2
Clarity booster is on.
(page 23)
In use
Cell1 in
se
u
Cell2 in
se
u
Line in
se
u
*1 Corresponding cellular line(s) is(are)
i
ndicated next to the item.
*2 During a cellular call, the item is not
displayed even though the feature is
activated.
*3 Corresponding lines (1, 2: cellular line, L:
landline) are indicated next to the item. If
all lines are turned off, no line is indicated.
Answering system is being
sed by another handset or
u
the base unit.
Someone is using the
cellular line.
Someone is using the
landline.
*
Base unit display items
Item Meaning
1
*
In use
Cell1 in
se
u
Cell2 in
se
u
Line in
se
u
Ringer volume is off.
(page 29, 42)
Silent mode is on.
(
page 45)
Call sharing mode is off.
(
page 41)
Answering system is being
sed by a handset.
u
Someone is using the
cellular line.
Someone is using the
andline.
l
Item Meaning
“G
reeting only” is
selected as the caller’s
recording time. In this case,
the answering system
answers calls with a greeting
message and caller
messages are not recorded.
(page 62)
A Bluetooth headset is
connected to the base unit.
Ready to use it.
luetooth headset is in use.
A B
*1 Corresponding lines (1, 2: cellular line, L:
andline) are indicated next to the item. If
l
all lines are turned off, no line is indicated.
CELL 1/CELL 2 indicators on the
b
ase unit
The CELL 1/CELL 2 indicators show each
cellular line status.
Status Meaning
On A cellular phone is connected.
Flashing – The cellular line is in use.
Flashing
apidly
r
Light off – A cellular phone is not
R
eady to make/receive
cellular calls.
Phonebook entries are
–
being copied from a
cellular phone (page 52).
– The base unit is searching
for the paired cellular
phone.
– The base unit is pairing a
cellular phone.
– A cellular call is put on hold.
A cellular call is being
received.
aired to the base unit.
p
– A cellular phone is not
connected to the base unit
(page 19).
For assistance, please visit http://www.panasonic.com/help
15
Page 16
Getting Started
Initial settings
Direct command code:
n
Programmable settings can be accessed by
pressing MMENUN, #, and then the
corresponding code on the dial keypad
(page 36).
Example: Press MMENUN#101.
n Symbol meaning:
Example: MbN: “Off”
Press MCN or MDN to select the words in
quotations.
Date and time
I
mportant:
R When you install the batteries for the first
time, the handset may prompt you to set
date and time. First press MSELECTN, then
proceed to step 2.
Handset
ENUN#101
1 MM
2 Enter the current month, date, and year
by selecting 2 digits for each.
Example: July 15, 2013
07 15 13
3 MOKN
4 Enter the current hour and minute
(12-hour clock format) by selecting 2
digits for each.
Example: 9:30
09 30
5 *: Select “AM” or “PM”.
6 MSAVEN a MOFFN
Note:
R When English is selected as the display
language, 12-hour clock format is used.
When Spanish is selected, 24-hour clock
format is used.
R The date and time may be incorrect after a
power failure. In this case, set the date and
time again.
Display language
You can select either “English” or
“Español” as the display language. The
default setting is “English”.
Handset / Base unit
1 MMENUN#110
2 MbN: Select the desired setting. a
MSAVEN
3 Proceed with the operation for your unit.
Handset: MOFFN
Base unit: MEXITN
Voice guidance language
ou can select either “English” or
Y
“Español” as the voice guidance language
of the answering system. The default setting is
“English”.
Handset
ENUN#112
1 MM
2 MbN: Select the desired setting.
3 MSAVEN a MOFFN
Dialing mode
I
f you cannot make calls, change this setting
according to your telephone line service. The
default setting is “Tone”.
“Tone”: For tone dial service.
“Pulse”: For rotary/pulse dial service.
Handset
1 MM
ENUN#120
2 MbN: Select the desired setting.
3 MSAVEN a MOFFN
16
For assistance, please visit http://www.panasonic.com/help
Page 17
Link to cell feature
T
o use this feature, you must first pair and
connect your cellular phones to the base unit
(page 17).
Your cellular phones must have Bluetooth
wireless technology that is compatible with this
product.
This feature allows you to:
– make or answer cellular calls using your
home phone (handset or base unit) with
better reception.
– maximize the benefits of cellular services
(such as free night and weekend calls, or
cellular to cellular call plans) by utilizing
unused peak minutes with your home
phone.
– conserve the battery power of your cellular
phone while the unit is on a cellular call.
(We recommend charging your cellular
phone during the cellular call as your
cellular phone battery is being consumed.)
Important:
R You may pair a maximum of 2 cellular
phones and 1 headset. However, the base
unit allows only one Bluetooth to be active
at a time.
R Locate your cellular phone near the base
unit. If the cellular phone is too close to the
base unit during a cellular call, you may
hear noise. For best performance, we
recommend placing the cellular phone
between 0.6 m to 3 m (2 feet to 10 feet)
away from the base unit.
Link to Cell
fter the CELL 1 or CELL 2 indicator
R A
on the base unit starts flashing, the
rest of the procedure must be
completed within 5 minutes.
2 Your cellular phone:
While the CELL 1 or CELL 2 indicator is
flashing, follow the instructions of your
cellular phone to enter the pairing mode.
R Depending on your cellular phone, it
may ask you to enter the base unit PIN
(default: “0000”).
3 Handset:
Wait until a long beep sounds.
R It may take more than 10 seconds to
complete pairing.
R When the CELL 1 or CELL 2 indicator
lights up, the cellular phone is
connected to the base unit. You are
ready to make cellular calls.
4 MOFFN
Note:
R Make sure that your cellular phone is set to
connect to this product automatically. Refer
to your cellular phone’s operating
instructions.
R Make sure you cancel your cellular phone’s
current pairing if you want to pair it to the
other line (page 17).
R The default setting for the text message
alert feature is “On”, so when you pair your
cellular phone to the base unit, this feature
may be activated (page 53). (This
depends on the version and type of cellular
phone you are using.)
Pairing a cellular phone
mportant:
I
R For more details and the list of compatible
cellular phones, please visit our Web site:
http://www.panasonic.com/link2cell
R Before pairing a Bluetooth enabled cellular
phone to the base unit, make sure that no
other Bluetooth device such as a Bluetooth
headset is connected to your cellular phone.
1 Handset:
For CELL 1: MMENUN#6241
For CELL 2: MMENUN#6242
For assistance, please visit http://www.panasonic.com/help
Unpairing a cellular phone
You can cancel the pairing of a cellular phone
that is stored in the base unit.
Handset
1 For CELL 1: MMENUN#6111
For CELL 2: MMENUN#6112
2 MbN: “Yes” a MSELECTN
R When the cellular phone is unpaired,
the CELL 1 or CELL 2 indicator is
turned off.
3 MOFFN
17
Page 18
Link to Cell
Link to cell settings
Selecting which unit receives
c
ellular calls
You can select which unit rings and receives
calls for a cellular line. When “All” is
selected, all handsets and the base unit ring.
Handset
1 F
or CELL 1: MMENUN#6271
For CELL 2: MMENUN#6272
2 MbN: Select the desired handset or “All”.
a MSAVEN
3 MOFFN
Note:
R When you select a specific handset to
receive calls for a cellular line:
– other handsets cannot answer the calls.
– the base unit can answer the calls even
though it does not ring. However, you
can make the base unit ring by adjusting
the base unit ringer volume (page 38).
R When you change the setting to “All”, the
base unit ringer volume also returns to the
lowest level even if the ringer volume has
been changed.
R The units selected with this setting have the
text message alert feature (page 53)
applied to them. (KX-TG7871 series:
page 3)
Ring as cell mode
nce this feature is turned on, the handset
O
and base unit ring using the same ringer tone
as your cellular phone.
The following settings are available:
– “Off”: Turn this feature off to use the
ringer tones of the handset and base unit.
Caller information is announced depending
on the Talking Caller ID setting (page 40).
– “On (with Talking CID)” (default):
The handset and base unit use your cellular
phone’s ringer tone. Caller information is
announced even if the Talking Caller ID is
turned off.
– “O
n (without Talking CID)”: The
handset and base unit use your cellular
phone’s ringer tone. Caller information is
not announced even if the Talking Caller ID
is turned on.
Important:
R To use this feature, your cellular phone
must support Bluetooth in-band ringtone.
Refer to your cellular phone’s operating
instructions.
Handset
1 F
or CELL 1: MMENUN#6141
For CELL 2: MMENUN#6142
2 MbN: Select the desired setting.
3 MSAVEN a MOFFN
Note:
R The units use the preset ringer tones
(page 39) instead of your cellular phone’s
ringer tone when a cellular call is being
received if:
– your cellular phone is in silent mode
(depending on your cellular phone).
– the base unit is in use.
– 2 handsets are sharing a landline call.
R If your cellular phone is in silent mode with
“On (with Talking CID)” set, the unit
announces caller information even when
Talking Caller ID is turned off (page 40).
To use the handset ringer tone
i
nstead of your cellular phone’s
ringer tone
Select “Off” in step 2, “Ring as cell mode”,
page 18.
To change the handset ringer tone for a
cellular line, see page 38.
Auto connection to the cellular
p
hone
After pairing, your cellular phone is connected
to the base unit. If you move the cellular
phone out of base unit range, the cellular
phone is disconnected from the base unit.
This feature allows the base unit to try to
reconnect the cellular phone at regular
18
For assistance, please visit http://www.panasonic.com/help
Page 19
intervals when it returns within base unit
r
ange. You can set the interval. The default
setting is “1 min”.
Important:
R When you are using a cellular line or a
Bluetooth headset, the base unit loses its
connection from other Bluetooth devices
(cellular phone or headset). To
automatically resume the connection to
cellular phones, leave the auto connection
on.
R Some cellular phones lose connection after
usage, please check the specifications of
your cellular phone for more details.
Handset
1 MM
ENUN#632
2 MbN: Select the desired setting.
3 MSAVEN a MOFFN
Note:
R Some cellular phones may ask you if you
accept the connection requirement from the
base unit. In that case, select “Off” in step
2. Check the specifications of your cellular
phone.
Connecting/disconnecting the
ellular phone manually
c
If you will not be using the paired cellular
phone’s link to cell feature temporarily (for
example, you do not want the unit to ring
when your cellular line receives a call), you
can disconnect your cellular phone from the
base unit. If you want to use it again,
reconnect the cellular phone to the base unit.
Note:
R Even if a paired cellular phone was
disconnected from the base unit, if it is
brought within the base unit’s range during
the auto connection interval, it may
automatically connect to the base unit
(page 18).
R A disconnected cellular phone is not
“Unpair” from the base unit, so pairing it
to the base unit again is unnecessary.
Link to Cell
Handset
1 T
o connect/disconnect:
For CELL 1: MMENUN#6251
For CELL 2: MMENUN#6252
R A long beep sounds.
2 MOFFN
Cellular line only mode (If you do
ot use the landline)
n
If you do not use the landline, we recommend
setting the unit to the cellular line only mode.
Important:
R If you turn on the “Cell line only
mode”, disconnect the telephone line cord
from the base unit. Otherwise the “Cell
line only mode” cannot be activated.
Handset
ENUN#157
1 MM
2 To turn on:
MbN: “On” a MSELECTN a
MbN: “Yes” a MSELECTN
To turn off:
MbN: “Off” a MSELECTN
Note:
R Once you set this mode, you can use the
following buttons to make cellular calls:
– for the handset, press M
instead of MCELLN (page 21).
– for the base unit, press MZN instead of
the line button (MCELL 1N or MCELL 2N)
set for the cellular line selection
(page 20, 28).
R Once you set this mode, the following
features cannot be used:
– Landline features (page 43)
– Answering system (page 56)
Messages cannot be received.
– Voice mail features (page 63)
R After this mode is turned on or off, the base
unit reboots.
– Bluetooth connections from cellular
phones or headset are disconnected. If
the auto connection is turned on
(page 18), the cellular phones are
reconnected.
N or MZN
For assistance, please visit http://www.panasonic.com/help
19
Page 20
Link to Cell
– will be displayed on the handset
omentarily. The handset can be used
m
once
is displayed.
When you use the landline again
efore connecting the telephone line to the
B
base unit, select “Off” in step 2, “Cellular line
only mode (If you do not use the landline)”,
page 19.
Cellular line selection
his feature determines which cellular line is
T
selected to make cellular calls when:
– you press MCELLN on the handset.
– you press M
while the cellular line only mode is turned
on.
– you press MZN on the base unit while the
cellular line only mode is turned on.
The following settings are available:
– “Manual” (handset only: default): You can
select the desired cellular line when making
a call.
– “Cellular phone 1” (base unit default): CELL
1 is selected.
– “Cellular phone 2”: CELL 2 is selected.
Handset
1 F
or handset: MMENUN#634
For base unit: MMENUN#*634
N
or MZN on the handset
2 MbN: Select the desired setting.
3 MSAVEN a MOFFN
Base unit
1 MM
ENUN#634
2 MbN: Select the desired setting.
3 MSAVEN a MEXITN
7-digit phone number when making cellular
c
alls.
Handset
1 MM
ENUN#633
2 Enter the 3-digit area code.
R To correct a digit, press MCLEARN.
3 MSAVEN a MOFFN
Changing the Bluetooth PIN
(
Personal Identification Number)
The PIN is used to pair cellular phones to the
base unit. The default PIN is “0000”. To
prevent unauthorized access to this product,
we recommend that you change the PIN, and
keep it confidential.
Important:
R Please make note of your new PIN. The
unit does not reveal the PIN to you. If you
forget your PIN, see page 75.
Handset
1 MM
ENUN#619
R If the unit prompts you to enter the old
PIN (when the default has been
changed), enter the current 4-digit PIN.
2 Enter the new 4-digit PIN. a MOKN
3 Enter the new 4-digit PIN again. a
MSAVEN
4 MOFFN
Storing your area code (for
d
ialing only a 7-digit phone
number to make a local call)
You need to add your area code when making
cellular calls to a phone number in your area.
Once you store your area code, it is
automatically added to the beginning of the
20
For assistance, please visit http://www.panasonic.com/help
Page 21
Making/Answering Calls Using the Handset
Making cellular calls
I
mportant:
R Only 1 cellular line can be used at a time.
R Before making calls, confirm that the CELL
1 or CELL 2 indicator lights up (page 15).
1 Lift the handset and dial the phone
number.
R To correct a digit, press MCLEARN.
2 MCELLN
R The unit starts dialing when:
– only 1 cellular phone is paired.
– a specific line is set to make cellular
calls (page 20).
Go to step 4.
3 MbN: Select the desired cellular phone. a
MSELECTN
4 When you finish talking, press MOFFN or
place the handset on the base unit or
charger.
Note:
R To switch to the speaker, press MZN.
To switch back to the receiver, press MZN/
M
N.
Adjusting the receiver or speaker
v
olume
Press MDN or MCN repeatedly while talking.
Making a cellular call using the redial
l
ist
The last 5 phone numbers dialed are stored in
the redial list (each 48 digits max.).
1 MEN REDIAL
2 MbN: Select the desired phone number.
3 MCELLN
R The unit starts dialing when:
– only 1 cellular phone is paired.
– a specific line is set to make cellular
calls (page 20).
4 MbN: Select the desired cellular phone. a
MSELECTN
Erasing a number in the redial list
hen a cellular phone is paired:
n W
1 MEN REDIAL
2 MbN: Select the desired phone number.
a MMENUN
3 MbN: “Erase” a MSELECTN
4 MbN: “Yes” a MSELECTN
5 MOFFN
n When a cellular phone is not paired:
1 MEN REDIAL
2 MbN: Select the desired phone number.
a MERASEN
3 MbN: “Yes” a MSELECTN
4 MOFFN
Making landline calls
ift the handset and dial the phone
1 L
number.
R To correct a digit, press MCLEARN.
2 M
N
hen you finish talking, press MOFFN or
3 W
place the handset on the base unit or
charger.
Using the speakerphone
1 D
ial the phone number and press MZN.
R Speak alternately with the other party.
2 When you finish talking, press MOFFN.
Note:
R For best performance, use the
speakerphone in a quiet environment.
R To switch back to the receiver, press MZN/
M
N.
Making a call using the redial list
he last 5 phone numbers dialed are stored in
T
the redial list (each 48 digits max.).
1 MEN REDIAL
2 MbN: Select the desired phone number.
For assistance, please visit http://www.panasonic.com/help
21
Page 22
Making/Answering Calls Using the Handset
3 M N
Storing a number to the phonebook
hone numbers of up to 24 digits can be
P
stored in the phonebook.
n When a cellular phone is paired:
1 MEN REDIAL
2 MbN: Select the desired phone number.
a MMENUN
3 MbN: “Save” a MSELECTN
4 To store the name, continue from step
3, “Editing entries”, page 34.
n When a cellular phone is not paired:
1 MEN REDIAL
2 MbN: Select the desired phone number.
a MSAVEN
3 To store the name, continue from step
3, “Editing entries”, page 34.
Pause (for PBX/long distance service
sers)
u
A pause is sometimes required when making
calls using a PBX or long distance service.
When storing a calling card access number
and/or PIN in the phonebook, a pause is also
needed (page 34).
Example: If you need to dial the line access
number “9” when making outside calls with a
PBX:
1 9 a MDN (Pause)
2 Dial the phone number. a M
ote:
N
R A 3.5 second pause is inserted each time
MDN (Pause) is pressed.
N
Answering calls
ift the handset and press M
1 L
when the unit rings.
R To answer a cellular call, you can also
press MCELLN.
R You can also answer the call by
pressing any dial key from 0 to 9,
*, or #. (Any key answer feature)
22
For assistance, please visit http://www.panasonic.com/help
N
or MZN
hen you finish talking, press MOFFN or
2 W
place the handset on the base unit or
charger.
Auto talk
ou can answer calls simply by lifting the
Y
handset off the base unit or charger. You do
not need to press M
on, see page 41.
N. To turn this feature
Adjusting the handset ringer volume
hile the handset is ringing for an
n W
incoming call:
Press MDN or MCN repeatedly to select the
desired volume.
n Programming the volume beforehand:
1 To change the cellular line ringer
volume:
For CELL 1: MMENUN#6281
For CELL 2: MMENUN#6282
To change the landline ringer
volume:
MMENUN#160
2 MbN: Select the desired volume. a
MSAVEN
3 MOFFN
Temporary ringer off
hile the unit is ringing for a call, you can turn
W
the ringer off temporarily by pressing M
N.
Useful features during a
all
c
Hold
This feature allows you to put an outside call
on hold.
1 Press MMENUN during an outside call.
2 MbN: “Hold” a MSELECTN
3 To release hold on the cellular line:
Press MCELLN.
R Another handset user can take the call:
MCELLN*1 a MSELECTN
Page 23
Making/Answering Calls Using the Handset
*1 The call is taken when:
–
only 1 cellular phone is paired.
– a specific line is set to make
R The base unit user can take the call by
To release hold on the landline:
Press M
R A
R T
Note:
R If a call is kept on hold for more than 9
minutes, an alarm tone starts to sound.
After 1 additional minute on hold, the call is
disconnected.
R If another phone is connected to the same
line, you can also take the landline call by
lifting its handset.
cellular calls (page 20).
pressing MCELL 1N or MCELL 2N.
N.
nother handset user can take the call
by pressing M
he base unit user can take the call by
pressing MZN.
N.
Mute
hile mute is turned on, you can hear the
W
other party, but the other party cannot hear
you.
1 Press MMUTEN during conversation.
R MMUTEN flashes.
2 To return to the conversation, press
MMUTEN again.
Note:
R MMUTEN is a soft key visible on the display
during a call.
Flash for landline calls
LASHN allows you to use the special
MF
features of your host PBX such as transferring
an extension call, or accessing optional
telephone services.
Note:
R To change the flash time, see page 41.
For call waiting or Call Waiting
Caller ID service users
To use call waiting or Call Waiting Caller ID,
you must first subscribe with your service
provider/telephone company.
This feature allows you to receive calls while
you are already talking on the phone. If you
receive a call while on the phone, you will hear
a call waiting tone.
If you subscribe to both Caller ID and Call
Waiting with Caller ID services, the 2nd
caller’s information is displayed after you hear
the call waiting tone on the handset.
1 Press MCALL WAITN to answer the 2nd
call.
2 To switch between calls, press MCALL
WAITN.
Note:
R Please contact your service provider/
telephone company for details and
availability of this service in your area.
Temporary tone dialing for
l
andline calls (for rotary/pulse
service users)
You can temporarily switch the dialing mode
to tone when you need to access touch-tone
services (for example, answering services,
telephone banking services, etc.).
Press * (TONE) before entering access
numbers which require tone dialing.
Handset clarity booster
his feature can improve sound clarity when
T
the handset is used in an area where there
may be interference. During an outside call,
this feature is turned on automatically when
necessary.
R When this feature is turned on,
d
isplayed. However, during a cellular call,
is not displayed even though the
f
eature is activated.
is
For assistance, please visit http://www.panasonic.com/help
23
Page 24
Making/Answering Calls Using the Handset
Handset noise reduction
This feature allows you to hear the voice of
the person you are talking to clearly, by
reducing the surrounding noise coming from
the other party’s telephone.
Press MNOISE REDUCTIONN to turn on/off
while talking.
Note:
R When this feature is turned on, is
isplayed while talking.
d
R Depending on the environment where this
handset is being used, this feature may not
be effective.
R This feature is not available using the
speakerphone.
R When both the “Equalizer” setting and
noise reduction are activated,
hown on the display.
s
is
Handset equalizer
T
his feature clarifies the voice of the person
you are talking to, producing a more
natural-sounding voice that is easier to hear
and understand.
1 Press MMENUN while talking.
2 MbN: “Equalizer” a MSELECTN
3 MbN: Select the desired setting.
4 Press MOKN to exit.
Note:
R When this feature is activated,
isplayed while talking.
d
R Depending on the condition and quality of
your telephone line, this feature may
emphasize existing line noise. If it becomes
difficult to hear, turn this feature off.
R This feature is not available while using the
speakerphone.
is
Call share
Y
ou can join an existing outside call.
n While another unit is on a cellular call:
1 To join the conversation, press
MCELLN.
R You can join the conversation when:
– only 1 cellular phone is paired.
24
For assistance, please visit http://www.panasonic.com/help
– a specific line is set to make
ellular calls (page 20).
c
2 MbN: Select the desired cellular phone.
a MSELECTN
n While another unit is on a landline call:
To join the conversation, press M
N
ote:
R A maximum of 3 parties (including 1 outside
party) can join a conversation using 2
extensions. (3-way conference)
R To prevent other users from joining your
conversations with outside callers, turn call
sharing mode off (page 41).
N.
Transferring a cellular call
etween the handset and a
b
cellular phone
Transferring a cellular call from the
h
andset to a cellular phone
1 Press MMENUN during a cellular call.
2 MbN: “Transfer to cell” a
MSELECTN
R The cellular call is transferred to the
cellular phone.
Note:
R Depending on your cellular phone type, you
may need to set the cellular phone to be
ready to talk before transferring. For
example, if your cellular phone has a top
cover, open it beforehand.
Transferring a cellular call from a
ellular phone to the handset
c
During a conversation using a cellular phone,
the call cannot be transferred to the handset
by the cellular phone. Perform the following
with the handset.
1 During a conversation using a cellular
phone, press MCELLN.
R The call is transferred to the handset
when:
– only 1 cellular phone is paired.
– a specific line is set to make cellular
calls (page 20).
Page 25
Making/Answering Calls Using the Handset
Select the desired cellular phone. a
2 MbN:
MSELECTN
R The call is transferred to the handset.
Using the other line during a
onversation
c
You can handle a cellular call and a landline
call at the same time. When another call is
being received during a conversation, the
interrupt tone sounds (page 39), and the 2nd
caller’s information is displayed if you
subscribe to Caller ID (page 48). You can
answer the 2nd call while holding the 1st call.
Making/answering a cellular call
during a conversation on the landline
1 Press MMENUN during a landline call.
2 MbN: “Hold” a MSELECTN
3 To make a 2nd call:
Dial the phone number. a MCELLN*1 a
MbN: Select the desired cellular phone. a
MSELECTN
*1 The unit starts dialing when:
– only 1 cellular phone is paired.
– a specific line is set to make
cellular calls (page 20).
To answer a 2nd call:
MCELLN
R To hold the 2nd call: MMENUN a MbN:
“Hold” a MSELECTN
4 To hang up the 2nd call and return to the
1st call (landline call), press MOFFN, then
press M N.
Making/answering a landline call
d
uring a conversation on a cellular line
1 Press MMENUN during a cellular call.
2 MbN: “Hold” a MSELECTN
3 To make a 2nd call:
Dial the phone number. a M
o answer a 2nd call:
T
M
N
R T
o hold the 2nd call: MMENUN a MbN:
“Hold” a MSELECTN
For assistance, please visit http://www.panasonic.com/help
N
o hang up the 2nd call and return to the
4 T
1st call (cellular call), press MOFFN, then
press MCELLN.
Power back-up operation
f
or landline
When a power failure occurs, the charged
handset temporarily supplies power to the
base unit (power back-up mode). This allows
you to make and receive landline calls using a
handset during a power failure. The base unit
will not perform any other functions. However,
some functions such as Caller ID and shared
phonebook are available only when using a
handset other than the handset supplying
power to the base unit. You can program
“Power failure” and the default setting is
“Auto” (page 41).
Important:
R If a handset is not placed on the base unit
when a power failure occurs, “Base no
power Press OFF” is displayed. After
pressing MOFFN on the handset, place it on
the base unit to start power back-up mode.
R Power back-up mode will not work if the
battery level of the power supplying
handset is
o not lift the power supplying handset
R D
from the base unit during power back-up
mode.
R Do not touch the handset’s charge contacts
during power back-up mode.
R If the battery level is low, the unit will not
work sufficiently during power back-up
mode. In addition, in case handset battery
power runs out, we recommend connecting
a corded-type telephone (without AC
adaptor) to the same telephone line or to
the same telephone line jack using a
Panasonic T-adaptor (page 4).
or .
25
Page 26
Making/Answering Calls Using the Handset
Panasonic Ni-MH battery
erformance (supplied batteries)
p
during power back-up mode
When the batteries are fully charged,
operating time of the handset in power
back-up mode varies depending on usage.
– Continuous use of the handset in power
back-up mode: 1.5 hours max.
– Continuous use of the handset other than a
handset in power back-up mode: 2 hours
max.
– Not in use in power back-up mode: 2 hours
max.
Note:
R Actual battery performance depends on
usage and ambient environment.
Making calls during a power
f
ailure
n When only 1 handset is registered:
1 Lift the handset and dial the phone
number.
2 Within 1 minute, place the handset on
the base unit.
R Wait until speakerphone is turned
on automatically and the call is
made.
3 When the other party answers the call,
keep the handset on the base unit and
talk using the speakerphone.
4 When you finish talking, press MOFFN.
Note:
R In step 2, if you do not place the handset on
the base unit within 1 minute, the power
back-up mode turns off. In this case, press
MOFFN on the handset and dial the phone
number. Then try again from step 2.
n When 2 or more handsets are registered:
You should leave one handset on the base
unit for supplying the power, and use
another handset for making calls. For the
operation, please see “Making landline
calls”, page 21.
Note:
R During a call with the handset placed on the
base unit (power back-up mode), the call
26
For assistance, please visit http://www.panasonic.com/help
may be disconnected if you touch the
h
andset. In such case, try to call back.
R The range of the base unit is limited during
a power failure. Please use the handset
close to the base unit.
Making a call using the redial list
n W
hen only 1 handset is registered:
1 Lift the handset.
2 MEN REDIAL
3 MbN: Select the desired phone number.
4 Within 1 minute, place the handset on
the base unit.
R Wait until speakerphone is turned
n When 2 or more handsets are registered:
You should leave one handset on the base
unit for supplying the power, and use
another handset for making calls. For the
operation, please see “Making a call using
the redial list”, page 21.
Making a call using the shared
honebook
p
There must be at least 2 handsets
registered to the base unit in order for the
shared phonebook feature to be used
during a power failure.
You should leave one handset on the base
unit for supplying the power, and use another
handset for making calls.
For the operation, please see “Finding and
calling from a phonebook entry”, page 33.
Answering calls during a power
ailure
f
n When only 1 handset is registered:
1 When the unit rings, keep the handset
on the base unit and press M
MZN.
R Speakerphone is turned on.
2 When you finish talking, press MOFFN.
on automatically and the call is
made.
or
N
Page 27
Making/Answering Calls Using the Handset
n W
hen 2 or more handsets are registered:
When the unit rings, use a handset which is
not supplying power to the base unit. For
the operation, please see “Answering calls”,
page 22.
R Do not use or lift the handset which is
placed on the base unit during power
back-up mode.
Note:
R During a call with the handset placed on the
base unit (power back-up mode), the call
may be disconnected if you touch the
handset. In such case, try to call back.
R The range of the base unit is limited during
a power failure. Please use the handset
close to the base unit.
For assistance, please visit http://www.panasonic.com/help
27
Page 28
Making/Answering Calls Using the Base Unit
hen you finish talking, press MZN.
4 W
Making cellular calls
1 D
ial the phone number.
2 Press MCELL 1N or MCELL 2N.
3 When the other party answers, speak into
the microphone.
R Speak alternately with the other party.
4 When you finish talking, press MZN.
Note:
R For best performance, use the
speakerphone in a quiet environment.
R While on a call, you can switch from the
base unit to the handset:
With the call sharing mode on (page 30),
press MCELLN on the handset. a MbN:
Select the desired cellular phone. a
MSELECTN a Press MZN on the base unit.
– When only 1 cellular phone is paired or
the line is set to make cellular calls
(page 20), press MCELLN on the
handset, then press MZN on the base
unit.
If the handset is on the base unit, simply lift
it.
Note:
R While on a call, you can switch from the
base unit to the handset:
– Press M
MZN on the base unit with the call
sharing mode on (page 30).
– If the handset is on the base unit, simply
lift it.
Making a call using the redial list
he last 10 phone numbers dialed are stored
T
in the redial list (each 48 digits max.).
1 MREDIALN
2 MbN: Select the desired phone number.
3 MZN
Erasing a number in the redial list
EDIALN
1 MR
2 MbN: Select the desired phone number.
a MERASEN
3 MbN: “Yes” a MSELECTN
4 MEXITN
Adjusting the speaker volume
Press MDN or MCN repeatedly while talking.
Making a cellular call using the redial
l
ist
The last 10 phone numbers dialed are stored
in the redial list (each 48 digits max.).
1 MREDIALN
2 MbN: Select the desired phone number.
3 Press MCELL 1N or MCELL 2N.
Pause (for PBX/long distance service
users)
A pause is sometimes required when making
calls using a PBX or long distance service.
When storing a calling card access number
and/or PIN in the phonebook, a pause is also
needed (page 34).
Example: If you need to dial the line access
number “9” when making outside calls with a
PBX:
1 9 a MPAUSEN
2 Dial the phone number. a MZN
Making landline calls
ial the phone number.
1 D
Note:
R A 3.5 second pause is inserted each time
MPAUSEN is pressed.
2 MZN
3 When the other party answers, speak into
the microphone.
on the handset, then press
N
28
For assistance, please visit http://www.panasonic.com/help
Page 29
Making/Answering Calls Using the Base Unit
Answering calls
W
hen a landline call is being received, the
SP-PHONE indicator flashes rapidly.
When a cellular call is being received, the
CELL 1 or CELL 2 indicator and SP-PHONE
indicator flash rapidly.
1 Press MZN when the unit rings.
R You can also answer the cellular call
by pressing MCELL 1N or MCELL 2N.
2 Speak into the microphone.
3 When you finish talking, press MZN.
Adjusting the base unit ringer volume
n While the base unit is ringing for an
incoming call:
Press MDN or MCN repeatedly to select the
desired volume.
n Programming the volume beforehand:
1 To change the cellular line ringer
volume:
For CELL 1: MMENUN#6281
For CELL 2: MMENUN#6282
To change the landline ringer
volume:
MMENUN#160
2 MbN: Select the desired volume.
3 MSAVEN a MEXITN
Useful features during a
c
all
Hold
his feature allows you to put an outside call
T
on hold.
1 Press MHOLDN during an outside call.
2 To release hold on the cellular line:
Press MCELL 1N or MCELL 2N.
R A handset user can take the call:
MCELLN*1 a MSELECTN
*1 The call is taken when:
– only 1 cellular phone is paired.
– a specific line is set to make
ellular calls (page 20).
c
To release hold on the landline:
Press MZN.
R A handset user can take the call by
pressing M
ote:
N
R While a landline call is on hold, the
SP-PHONE indicator flashes.
R If a call is kept on hold for more than 9
minutes, an alarm tone starts to sound.
After 1 additional minute on hold, the call is
disconnected.
R If another phone is connected to the same
line, you can also take the landline call by
lifting its handset.
N.
Mute
hile mute is turned on, you can hear the
W
other party, but the other party cannot hear
you.
1 Press MMUTEN during conversation.
R The SP-PHONE indicator on the base
unit flashes.
2 To return to the conversation, press
MMUTEN again.
Flash for landline calls
LASHN allows you to use the special
MF
features of your host PBX such as transferring
an extension call, or accessing optional
telephone services.
Note:
R To change the flash time, see page 41.
For call waiting or Call Waiting
C
aller ID service users
To use call waiting or Call Waiting Caller ID,
you must first subscribe with your service
provider/telephone company.
This feature allows you to receive calls while
you are already talking on the phone. If you
receive a call while on the phone, you will hear
a call waiting tone.
For assistance, please visit http://www.panasonic.com/help
29
Page 30
Making/Answering Calls Using the Base Unit
If you subscribe to both Caller ID and Call
W
aiting with Caller ID services, the 2nd
caller’s information is displayed after you hear
the call waiting tone on the base unit.
1 Press MCALL WAITN to answer the 2nd
call.
2 To switch between calls, press MCALL
WAITN.
Note:
R Please contact your service provider/
telephone company for details and
availability of this service in your area.
Temporary tone dialing for
l
andline calls (for rotary/pulse
service users)
You can temporarily switch the dialing mode
to tone when you need to access touch-tone
services (for example, answering services,
telephone banking services, etc.).
Press * (TONE) before entering access
numbers which require tone dialing.
Call share
ou can join an existing outside call.
Y
To select the line that is being used for the call:
– for a cellular line press MCELL 1N or MCELL
2N.
– for the landline press MZN.
Note:
R A maximum of 3 parties (including 1 outside
party) can join a conversation using 2
extensions. (3-way conference)
R To prevent other users from joining your
conversations with outside callers, turn call
sharing mode off (page 41).
Transferring a cellular call
between the base unit and a
cellular phone
Transferring a cellular call from the
ase unit to a cellular phone
b
During a cellular call, press and hold MCELL
1N or MCELL 2N until the SP-PHONE indicator
goes out.
R The cellular call is transferred to the cellular
phone.
Transferring a cellular call from a
ellular phone to the base unit
c
During a conversation using a cellular phone,
press MCELL 1N or MCELL 2N.
R The cellular call is transferred to the base
unit.
Using the other line during a
onversation
c
You can handle a cellular call and a landline
call at the same time. When another call is
being received during a conversation, the
interrupt tone sounds (page 42). You can
answer the 2nd call while holding the 1st call.
Making/answering a cellular call
during a conversation on the landline
1 Press MHOLDN during a landline call.
2 To make a 2nd call:
Dial the phone number. a Press MCELL
1N or MCELL 2N.
To answer a 2nd call:
Press MCELL 1N or MCELL 2N.
R To hold the 2nd call, press MHOLDN.
3 To hang up the 2nd call and return to the
1st call (landline call), press MZN 2 times.
30
Making/answering a landline call
uring a conversation on a cellular line
d
1 Press MHOLDN during a cellular call.
For assistance, please visit http://www.panasonic.com/help
Page 31
Making/Answering Calls Using the Base Unit
o make a 2nd call:
2 T
Dial the phone number. a MZN
To answer a 2nd call:
MZN
R To hold the 2nd call, press MHOLDN.
3 To hang up the 2nd call and return to the
1st call (cellular call), press MZN, then
press MCELL 1N or MCELL 2N.
For assistance, please visit http://www.panasonic.com/help
31
Page 32
Shared Phonebook
Shared phonebook
T
he shared phonebook allows you to make
calls without having to dial manually. The base
unit and any handset registered to the base
unit can use the shared phonebook. You can
add 3,000 names and phone numbers to the
shared phonebook, and assign each
phonebook entry to the desired group
(“Home”, “Cell 1”, “Cell 2”).
Important:
R Only 1 person can access the shared
phonebook at a time.
R Caller ID subscribers can use group ringer
tone features (page 49).
R You can copy phonebook entries from a
Bluetooth cellular phone to the unit’s
shared phonebook (page 52).
Adding entries
Handset
1 MFN
2 MbN: “Add new entry” a MSELECTN
3 Enter the party’s name (16 characters
max.). a MOKN
4 Enter the party’s phone number (24 digits
max.). a MOKN
5 MbN: Select the desired group. a
MSELECTN 2 times
R To add other entries, repeat from step
3.
6 MOFFN
Character table for entering names
W
hile entering characters, you can switch
between uppercase and lowercase by
pressing * (A®a).
Key Character
1 & ’ ( ) H ,
2 A B C 2
ENUN
a MM
– . / 1
a b c 2
Key Character
3 D E F 3
d e f 3
4 G H I 4
g h i 4
5 J K L 5
j k l 5
6 M N O 6
m n o 6
7 P Q R S 7
p q r s 7
8 T U V 8
t u v 8
9 W X Y Z 9
w x y z 9
0
# #
R To enter another character that is located
on the same dial key, first press MEN to
move the cursor to the next space.
R If you do not press any dial key within 5
seconds after entering a character, the
character is fixed and the cursor moves to
the next space.
R in the above table represents a single
space.
0
Erasing the character or number
P
ress MFN or MEN. a MCLEARN
R Press and hold MCLEARN to erase all
characters or numbers.
Groups
G
roups can help you find entries in the
phonebook quickly and easily. When adding
an entry to the phonebook, you can assign it
to one of 3 groups. You can search for
phonebook entries by group. The group ringer
tone feature is available for Caller ID
subscribers (page 49).
32
For assistance, please visit http://www.panasonic.com/help
Page 33
Finding and calling from a
phonebook entry
Scrolling through all entries
sing a cellular line:
n U
Handset
1 M
FN
2 MbN:
Select the desired entry.
3 MCELLN
R The unit starts dialing when:
– only 1 cellular phone is paired.
– a specific line is set to make cellular
calls (page 20).
4 MbN: Select the desired cellular phone. a
MSELECTN
Base unit
1 M
N
Select the desired entry.
2 MbN:
3 Press MCELL 1N or MCELL 2N.
n Using the landline:
Handset / Base unit
1 P
roceed with the operation for your unit.
Handset: MFN
Base unit: M N
2 MbN: Select the desired entry.
3 Proceed with the operation for your unit.
Handset: M
ase unit: MZN
B
Searching by first character
Handset / Base unit
N
1 Proceed with the operation for your unit.
Handset: MFN
Base unit: M N
ress the dial key (0 – 9 or #) which
2 P
contains the character you are searching
for (page 32).
R Press the same dial key repeatedly to
display the first entry corresponding to
each character located on that dial key.
Shared Phonebook
f there is no entry corresponding to
R I
the character you selected, the next
entry is displayed.
3 MbN: Scroll through the phonebook if
necessary.
4 To make a cellular/landline call, continue
from step 3 for handset or step 3 for base
unit, “Scrolling through all entries”,
page 33.
Searching by query
Y
ou can narrow down the search to enter the
first characters of a name.
Handset / Base unit
roceed with the operation for your unit.
1 P
Handset: MFN
B
ase unit: M
2 T
o search for the name, enter the first
characters (up to 4) in uppercase
(page 32).
R Characters cannot be entered in
lowercase.
R If there is no entry corresponding to
the characters you selected, the next
entry is displayed.
a *
N a *
3 MOKN
4 MbN: Scroll through the phonebook if
necessary.
5 To make a cellular/landline call, continue
from step 3 for handset or step 3 for base
unit, “Scrolling through all entries”,
page 33.
Searching by group
Handset / Base unit
1 P
roceed with the operation for your unit.
Handset: MFN
Base unit: M N
2 MGROUPN
3 MbN: Select the group you want to search.
a MSELECTN
R If you select “All” on the handset or
“All groups” on the base unit, the
unit ends the group search.
For assistance, please visit http://www.panasonic.com/help
33
Page 34
Shared Phonebook
Select the desired entry.
4 MbN:
5 To make a cellular/landline call, continue
from step 3 for handset or step 3 for base
unit, “Scrolling through all entries”,
page 33.
Editing entries
Handset
1 F
ind the desired entry (page 33).
2 MMENUN a MbN: “Edit” a MSELECTN
3 Edit the name if necessary (16 characters
max.; page 32). a MOKN
4 Edit the phone number if necessary (24
digits max.). a MOKN
5 MbN: Select the desired group (page 32).
a MSELECTN 2 times
6 MOFFN
Erasing entries
Erasing an entry
Handset
1 F
ind the desired entry (page 33).
2 MMENUN a MbN: “Erase” a MSELECTN
3 MbN: “Yes” a MSELECTN
4 MOFFN
Base unit
ind the desired entry (page 33).
1 F
2 MERASEN a MbN: “Yes” a MSELECTN
3 MEXITN
Erasing all entries in a group
Handset
1 MFN a MM
ENUN
2 MbN: “Erase all” a MSELECTN
3 MbN: Select the desired group. a
MSELECTN
4 MbN: “Yes” a MSELECTN
34
For assistance, please visit http://www.panasonic.com/help
“Yes” a MSELECTN
5 MbN:
6 MOFFN
Base unit
1 M N a ME
RASEN
2 MbN: Select the desired group. a
MSELECTN
3 MbN: “Yes” a MSELECTN
4 MbN: “Yes” a MSELECTN
Chain dial
T
his feature allows you to dial phone numbers
in the phonebook while you are on a call. This
feature can be used, for example, to dial a
calling card access number or bank account
PIN that you have stored in the phonebook,
without having to dial manually.
Handset / Base unit
1 P
roceed with the operation for your unit.
During an outside call:
Handset: MMENUN a MbN:
“Phonebook” a MSELECTN
Base unit: M
Select the desired entry.
2 MbN:
N
3 Press MCALLN to dial the number.
Note:
R When storing a calling card access number
and your PIN in the phonebook as one
phonebook entry, press MDN (Pause) to add
pauses after the number and PIN as
necessary (page 22).
R If you have rotary/pulse service, you need
to press * (TONE) before pressing
MMENUN on the handset or M
base unit in step 1 to change the dialing
mode temporarily to tone. When adding
entries to the phonebook, we recommend
adding * (TONE) to the beginning of
phone numbers you wish to chain dial
(page 32).
on the
N
Page 35
Speed Dial
Speed dial
Y
ou can assign 1 phone number to each of
the dial keys (1 to 9) on the handset.
Adding phone numbers to speed
d
ial keys
n By entering phone numbers:
1 Press and hold the desired speed dial
key (1 to 9). a MADDN
2 MbN: “Manual” a MSELECTN
3 Enter the party’s name (16 characters
max.). a MOKN
4 Enter the party’s phone number (24
digits max.). a MOKN
5 MSELECTN a MOFFN
n From the shared phonebook:
1 Press and hold the desired speed dial
key (1 to 9). a MADDN
2 MbN: “Phonebook” a MSELECTN
3 MbN: Select the desired entry.
4 MSAVEN a MOFFN
Note:
R If you edit a phonebook entry which is
assigned to a speed dial key, the edited
entry does not transfer to the speed dial
key.
Editing an entry
ress and hold the desired speed dial key
1 P
(1 to 9). a MMENUN
2 MbN: “Edit” a MSELECTN
3 Edit the name if necessary (16 characters
max.; page 32). a MOKN
4 Edit the phone number if necessary (24
digits max.). a MOKN
5 MSELECTN a MOFFN
Erasing an entry
1 Press and hold the desired speed dial key
(1 to 9). a MMENUN
2 MbN: “Erase” a MSELECTN
3 MbN: “Yes” a MSELECTN
4 MOFFN
Viewing speed dial key
ssignments
a
You can see the speed dial key assignments
on the handset display.
Press and hold the desired speed dial key (1
to 9).
Making a call using a speed dial
k
ey
n Using a cellular line:
1 Press and hold the desired speed dial
key (1 to 9).
2 MCELLN
R The unit starts dialing when:
– only 1 cellular phone is paired.
– a specific line is set to make
cellular calls (page 20).
3 MbN: Select the desired cellular phone.
a MSELECTN
n Using the landline:
1 Press and hold the desired speed dial
key (1 to 9).
2 M
N
For assistance, please visit http://www.panasonic.com/help
35
Page 36
Programming
Programmable settings
Y
ou can customize the unit by programming the following features.
To access the features, there are 2 methods.
Handset / Base unit
crolling through the display menus
n S
1 MMENUN
2 Press MCN or MDN to select the desired main menu. a MSELECTN
3 Press MCN or MDN to select the desired item from the next sub-menus. a MSELECTN
4 Press MCN or MDN to select the desired setting. a MSAVEN
R This step may vary depending on the feature being programmed.
R To exit the operation, press MOFFN on the handset or MEXITN on the base unit.
n Using the direct command code
1 MMENUN a Enter the desired code.
Example: Press MMENUN#110.
For available code:
– Handset: see page 36.
– Base unit: see page 42.
2 Select the desired setting. a MSAVEN
R This step may vary depending on the feature being programmed.
R To exit the operation, press MOFFN on the handset or MEXITN on the base unit.
Note:
R In the following table, < > indicates the default settings.
R In the following table,
isplay menu order and sub-menu may vary depending on your model.
R D
Display menu tree and direct command code table
n Handset
Main menu: “P
Operation Code
Viewing the phonebook entry. #280 33
Main menu: “C
Operation Code
Viewing the caller list. #213 49
Main menu: “A
Sub-menu 1 Sub-menu 2 Settings Code
Play new msg.
sg.: message)
(m
36
indicates the reference page number.
honebook”
aller list”
nswering device”
– – #323 58
For assistance, please visit http://www.panasonic.com/help
Page 37
Programming
Sub-menu 1 Sub-menu 2 Settings Code
Play all msg.
1
Erase all msg.
Greeting
*
Record greeting
Check greeting
Pre-recorded
(Reset to pre-recorded
greeting)
New message
*1
a
lert
Outgoing call
– On/Off
Outgoing call
– N
Outgoing call
– R
Base unit beep
Settings
Ring count
Recording time
Remote code
Screen call
1
Answer on
Answer off
*
*
1
Main menu: “V.M. access”*3 (V.M.: Voice mail)
Operation Code
Listening to voice mail messages. #330 64
Main menu: “I
ntercom”
Operation Code
Paging the desired unit. #274 65
– – #324 58
– – #325 58
1
*
– #302 57
– #303 57
1
*
– #304 57
n 0: <Off> #338 59
1: O
–
otification to
ctivate
emote code
1
*
1: A
0: <Inactivate>
n 0: <Off> #339 59
1: O
2–7: 2
-7 rings
<4 rings>
0: Toll saver
*
1
1: 1
min
3: <3 min>
0: Greeting
*2
only
*1
<1
11> #306 60
n> 0: Off #310 56
1: <O
– – #327 56
– – #328 56
#211 61
#305 62
For assistance, please visit http://www.panasonic.com/help
37
Page 38
Programming
*4
*4
luetooth”
Connect
Disconnect
Ringer volume
– H
Ringer volume
– B
Ringer tone
Select unit to
ing
r
Ring as cell
limited)
(
Pair
Unpair
Add new device
Connect
Disconnect
Pair
Unpair
1
*
/
andset
ase unit
*1
*1
*1
0–6: Off–6 <6>
7, *8
0–6: Off–6 <1>
<Tone 2>
*1
*
<Tone 4>
1–6: Handset 1-6
G: <All>
1: <On (with
Talking CID)>
2: On (without
–
#6251
#6252
#6281
#6282
#G6
#G6
*5
*6
#6291
#6292
#6271
#6272
#6141
#6142
Talking CID)
0: Off
–
#6241
#6242
–
#6111
#6112
– – #618 52
4
*
*
1
/
*1
– #621 54
– #622 54
– #621 54
– #612 54
Main menu: “B
Sub-menu 1 Sub-menu 2 Settings Code
Link to cell
– 1
: Add new
device
(for CELL 1)
– 2: Add new
device
(for CELL 2)
Phonebook
ransfer
t
Headset
281
282
*5
19
*
6
5
*
22
*
6
*5
29
*6
*5
–
*
6
5
*
18
*
6
5
*
18
*
6
5
*
17
*
6
5
*
17
*
6
38
For assistance, please visit http://www.panasonic.com/help
Page 39
Programming
Sub-menu 1 Sub-menu 2 Settings Code
Settings
Auto connect
Cell area code
Cell line only
*1
ode
m
Cell line select
– H
andset
Cell line select
– B
ase unit
Set PIN
Main menu: “S
et date & time”
Sub-menu 1 Sub-menu 2 Settings Code
*
Date and time
1
Alarm
Time a
djustment
Main menu: “I
*1, *9
nitial setting”
Sub-menu 1 Sub-menu 2 Settings Code
Ringer setting
Ringer volume 0–6: Off–6 <6> #160 22
Ringer t
(Handset)
Interrupt tone
– H
andset
Interrupt tone
– B
ase unit
Silent mode
– O
n/Off
Silent mode
tart/End
– S
*1
1:
<1 min>
#632 18
2: 3 min
3: 5 min
4: 10 min
0: Off
*
1
– #633 20
1: On 0: <Off> #157 19
*4
ellphone 1
1: C
2: Cellphone 2
*4
#634 20
0: <Manual>
*4
<Cellphone 1>
*1
1
*
1:
2: Cellphone 2
<0
000> #619 20
#G6
*4
– – #101 16
– 1: O
nce
#720 44
2: Daily
0: <Off>
– 1:
<Caller ID auto>
#226 –
0: Manual
*7, *8, *10
<T
one
*11
*1, *11
one 1> #161 –
1: <On> 0: Off #201 25
<On> 0: Off #G201 30
1:
1: On 0: <Off> #238 44
<11:00 PM/06:00
#237 45
AM>
34
For assistance, please visit http://www.panasonic.com/help
39
Page 40
Programming
Sub-menu 1 Sub-menu 2 Settings Code
1
Set date & time
Date and time
Alarm
Time
djustment
a
Talking Caller ID Handset
Base unit
Handset name
Key detector
*12
etting
s
Change name
– 1: Add new
device
(for Detector1)
– 2: Add new
device
*13
Registration
(for Detector2)
– 3: Add new
device
(for Detector3)
– 4: Add new
device
Deregistration
(for Detector4)
1
Call block
*
First ring
Block w/o num
(Block calls without
phone number)
Speed dial
Voice mail Store VM
a
ccess#
(VM: Voice mail)
VM tone detect
LCD contrast
Display contrast)
(
*
Key tone
16
Caller ID edit
Caller ID number auto
(
edit)
*
1: O
– #101 16
nce
#720 44
2: Daily
0: <Off>
*
*1, *9
1
1: <Caller ID auto>
0: Manual
n> 0: Off #162 48
1: <O
1: O
n 0: <Off> #G162
#226 –
– – #104 45
1
*
Detector1
Detector2
Detector3
Detector4
14
*
14
*
*
14
#6561 –
#6562
#6563
#6564
– #6571 –
#6572
#6573
#6574
– #6581 –
#6582
#6583
#6584
– – #217 45
1
*
*
1, *2
1: <O
n> 0: Off #173 46
1: O
n 0: <Off> #240 46
– – #261 35
*1
*1
1: <O
– #331 63
n> 0: Off #332 63
– 1–6: Level 1–6 <3> #145 –
– 1: <O
– 1: <O
n> 0: Off #165 –
n> 0: Off #214 50
*15
*15
*15
*
*
*
*
*
*
15
15
15
15
15
15
40
For assistance, please visit http://www.panasonic.com/help
Page 41
Programming
Sub-menu 1 Sub-menu 2 Settings Code
17
Auto talk
Set tel line
*
Set dial mode
Set flash
t
Set l
*
Call sharing
1
Registration Register handset
Deregistration
Power failure
Change language Display
Voice prompt
ime
*1, *18
ine mode
– 1: O
*
1
1: P
2: <Tone>
0: 900 ms
1: <700 ms>
2: 600 ms
3: 400 ms
4: 300 ms
5: 250 ms
G: 200 ms
#: 160 ms
6: 110 ms
7: 100 ms
8: 90 ms
9: 80 ms
*1, *19
1: A 2
– 1: <O
2
*
– 1: <A
1: <E
2: Español
*
1
1: <E
2: Español
n 0: <Off> #200 22
ulse
#120 16
#121 23
: <B> #122 –
n> 0: Off #194 24,
– #130 47
– #131 47
uto> 0: Off #152 25
nglish>
nglish>
#110 16
#112 16
30
Main menu: “C
ustomer support”
Operation Code
Displaying customer support Web address. #680 –
Main menu: “K
ey detector”
*12
Sub-menu 1 Sub-menu 2 Settings Code
Search
Battery check
– – #655 –
– –
For assistance, please visit http://www.panasonic.com/help
41
Page 42
Programming
Base unit
n
“P
Main menu:
Operation Code
Viewing the phonebook entry. #280 33
Main menu: “C
Operation Code
Viewing the caller list. #213 49
Main menu: “A
Sub-menu 1 Sub-menu 2 Settings Code
Screen call
honebook”
aller list”
nswer device”
– <O
n> Off #310 56
Main menu: “B
luetooth”
Sub-menu 1 Sub-menu 2 Settings Code
Link to cell
– Cellular phone 1
– Cellular phone 2
22
*
Headset
Cell line
Ph.book setting
h.book:
(P
Phonebook)
Main menu: “I
*
Ringer volume
*4
*4
Text msg. alert
(msg.:message)
Connect*1/
Disconnect
International
Country code
National access
nitial setting”
Off–
6 <1>
#6281
#6282
21
*
<O
n> Off
#6101
#6102
*1
–
– #622 –
<C
ellphone 1>
*4
#634 20
– #117 52
– #118
– #119
20
Sub-menu 1 Sub-menu 2 Settings Code
Ringer setting
Talking CID
42
Ringer volume Off–
1, *11
Interrupt tone
*
Silent mode
n/Off
– O
Silent mode
tart/End
– S
– On
6 <1> #160 29
<O
n> Off #201 30
On <Off> #238 44
<11:00 PM/
#237 45
06:00 AM>
<Off> #162 48
For assistance, please visit http://www.panasonic.com/help
5
*
29
*
6
5
*
53
*
6
Page 43
Programming
Sub-menu 1 Sub-menu 2 Settings Code
1
Call block
*
LCD contrast
(
Display contrast)
Caller ID edit
Caller ID number auto
(
edit)
Change language
Display)
(
First ring
Block w/o num
(Block calls without phone
number)
– – #217 45
1
*
*
1, *2
<O
n> Off #173 46
On
<Off> #240 46
– Level 1–6 <3> #145 –
– <On> Off #214 50
– <E
nglish>
#110 16
Español
Main menu: “C
ust. Support”
Operation Code
Displaying customer support Web address. #680 –
*1 If you program these settings using one of the units, you do not need to program the same
i
tem using another unit.
*2 This menu is not displayed when scrolling through the display menus. It is only available in
direct command code.
*3 When the cellular line only mode is turned on, these menus are not displayed (page 19).
*4 After the Bluetooth device is paired, the device name is displayed.
*5 For CELL 1
*6 For CELL 2
*7 If you select one of the melody ringer tones, it will continue to play for several seconds even
if the caller has already hung up. You may either hear a dial tone or no one on the line when
you answer the call.
*8 The preset melodies in this product are used with permission of © 2009 Copyrights Vision
Inc.
*9 This feature allows the unit to automatically adjust the date and time each time caller
information including date and time is received.
To turn this feature on, select “Caller ID auto”. To turn this feature off, select
“Manual”. (Caller ID subscribers only)
To use this feature, set the date and time first (page 16).
*10 If you subscribe to a distinctive ring service (such as IDENTA-RING), select a tone (tone 1 to
3). If you select a melody, you cannot distinguish lines by their ringers.
*11 This tone lets you know when you receive an outside call while you are on another line or an
intercom call. If you select “On”, the tone sounds 2 times.
*12 This setting is available when you have the key detector (KX-TGA20). Read the installation
guide for more information on the key detector.
*13 For models with supplied key detectors, the display shows "1: Detector1".
*14 If you register 2 or more key detectors.
*15 If you have 2 or more key detectors.
*16 Turn this feature off if you prefer not to hear key tones while you are dialing or pressing any
keys, including confirmation tones and error tones.
For assistance, please visit http://www.panasonic.com/help
43
Page 44
Programming
*17 If you subscribe to a Caller ID service and want to view the caller’s information after lifting up
t
he handset to answer a call, turn off this feature.
*18 The flash time depends on your telephone exchange or host PBX. Contact your PBX
supplier if necessary. The setting should stay at “700 ms” unless pressing MFLASHN fails to
pick up the waiting call.
*19 Generally, the line mode setting should not be changed. This setting automatically maintains
receiver volume at the proper level depending on the current telephone line condition. Set
the line mode to “A” if telephone line condition is not good.
*20 This setting is available when a cellular phone is paired.
*21 KX-TG7871 series: page 3
*22 This setting is available when a headset is paired.
7 MS
Special programming
Alarm
n alarm sounds at the set time for 3 minutes
A
once or daily. Alarm can be set for each
handset.
Important:
R Set the date and time beforehand
(page 16).
Handset
ENUN#720
1 MM
2 MbN: Select the desired alarm option. a
MSELECTN
“O
ff” Turns alarm off. Go to
nce” An alarm sounds once at
“O
aily” An alarm sounds daily at
“D
3 E
nter the desired month and date. a
MOKN
4 Set the desired time.
5 *: Select “AM” or “PM”. a MOKN
6 MbN: Select the desired alarm tone. a
MSELECTN
R We recommend selecting a different
ringer tone from the one used for
outside calls.
step 7.
the set time.
the set time. Go to step 4.
ELECTN a MOFFN
R When the alarm is set,
ote:
N
R To stop the alarm, press MOFFN or place
the handset on the base unit or charger.
R When the handset is in use, the alarm will
not sound until the handset is in standby
mode.
Silent mode
ilent mode allows you to select a period of
S
time during which the handset and/or base
unit will not ring for outside calls. This feature
is useful for time periods when you do not
want to be disturbed, for example, while
sleeping. Silent mode can be set for each unit.
Important:
R Set the date and time beforehand
(page 16).
R If you have set the alarm, the alarm sounds
even if the silent mode is turned on.
Turning silent mode on/off
Handset
ENUN#238
1 MM
2 MbN: Select the desired setting. a
MSAVEN
R If you select “Off”, press MOFFN to
exit.
3 Enter the desired hour and minute you
wish to start this feature.
4 *: Select “AM” or “PM”. a MOKN
is displayed.
44
For assistance, please visit http://www.panasonic.com/help
Page 45
Programming
nter the desired hour and minute you
5 E
wish to end this feature.
6 *: Select “AM” or “PM”.
7 MSAVEN a MOFFN
R When the silent mode is set,
isplayed.
d
Base unit
ENUN#238
1 MM
is
2 MbN: Select the desired setting. a
MSAVEN
R If you select “Off”, press MEXITN to
exit.
3 Enter the desired hour and minute you
wish to start this feature.
4 MAM/PMN: Select “AM” or “PM”. a MOKN
5 Enter the desired hour and minute you
wish to end this feature.
6 MAM/PMN: Select “AM” or “PM”.
7 MSAVEN a MEXITN
R When the silent mode is set,
isplayed.
d
Changing the start and end time
Handset / Base unit
ENUN#237
1 MM
is
2 Continue from step 3 for handset or step
3 for base unit, “Turning silent mode on/
off”, page 44.
Changing the handset name
ach handset can be given a customized
E
name (“Bob”, “Kitchen”, etc.). This is useful
when you make intercom calls between
handsets. You can also select whether or not
the handset name is displayed in standby
mode. The default setting is “No”. If you select
“Yes” without entering any handset name,
“Handset 1” to “Handset 6” is displayed.
Handset
ENUN#104
1 MM
For assistance, please visit http://www.panasonic.com/help
nter the desired name (max. 10
2 E
characters; see the character table,
page 32).
R If not required, go to step 3.
3 MSAVEN
4 MbN: Select the desired setting. a
MSELECTN 2 times
5 MOFFN
Call block (Caller ID subscribers
only)
This feature allows the unit to reject calls when:
– the unit receives a call from a phone
number stored in the call block list as
unwanted (“Storing unwanted callers”,
page 45).
– the unit receives a call without phone
number (“Blocking incoming calls without
phone number”, page 46).
When a call is received, the unit rings for a
short time*1 while the caller is being identified.
If the phone number matches an entry in the
call block list, the unit emits no sound to the
caller, and disconnects the call.
*1 This is called first ring. If you do not want
the first ring to sound, turn this setting to
“Off” (page 46).
Important:
R When the unit receives a call from a
number that is stored in the call block list or
a call without a recognized phone number,
the call is logged in the caller list
(page 49) with after the call is
d
isconnected.
R You can program this setting using either
the base unit or one of the handsets.
Storing unwanted callers
ou can store up to 250 phone numbers in the
Y
call block list.
Important:
R We recommend storing 10 digits (including
an area code). If only 7 digits are stored, all
numbers that have the same last 7 digits
will be blocked.
n From the caller list:
45
Page 46
Programming
Handset
n W
hen a cellular phone is paired:
1 MCN CID
2 MbN: Select the entry to be blocked. a
MSELECTN
R To edit the number, press *
repeatedly until the phone number
is shown in the 10-digit format.
3 MSAVEN
4 MbN: “Call block” a MSELECTN
5 MbN: “Yes” a MSELECTN
6 Edit the phone number if necessary
(24 digits max.).
7 MSAVEN a MOFFN
n When a cellular phone is not paired:
1 MCN CID
2 MbN: Select the entry to be blocked.
R To edit the number: MMENUN a
MbN: “Edit” a MSELECTN
Press MEDITN repeatedly until the
phone number is shown in the
10-digit format. And then, press
MSAVEN. Go to step 5.
3 MMENUN
4 MbN: “Save CID” a MSELECTN
5 MbN: “Call block” a MSELECTN
6 MbN: “Yes” a MSELECTN
7 Edit the phone number if necessary
(24 digits max.).
8 MSAVEN a MOFFN
Base unit
1 MC
IDN
2 MbN: Select the entry to be blocked.
R To edit the number, press MEDITN
repeatedly until the phone number is
shown in the 10-digit format.
3 MSAVEN
4 MbN: “Call block” a MSELECTN
5 MbN: “Yes” a MSELECTN
6 Edit the phone number if necessary (24
digits max.).
46
For assistance, please visit http://www.panasonic.com/help
AVEN a MEXITN
7 MS
n By entering phone numbers:
Handset
ENUN#217
1 MM
2 MMENUN a MbN: “Add” a MSELECTN
3 Enter the phone number (24 digits max.).
R To erase a digit, press MCLEARN.
4 MSAVEN a MOFFN
Base unit
ENUN#217 a MADDN
1 MM
2 Enter the phone number (24 digits max.).
R To erase a digit, press MCLEARN.
3 MSAVEN a MEXITN
Blocking incoming calls without
hone number
p
You can reject a call when no phone number
is provided, such as a call just showing “Out
of area”.
Handset / Base unit
1 MM
ENUN#240
2 MbN: Select the desired setting. a
MSAVEN
3 Proceed with the operation for your unit.
Handset: MOFFN
Base unit: MEXITN
Note:
R When the unit receives a cellular call
without a phone number, the call may not
be rejected.
Setting the first ring for the call block
list
Handset / Base unit
If you do not want the first ring from a number
on the call block list to sound, turn the first ring
setting to “Off”. The default setting is “On”.
1 MMENUN#173
2 MbN: Select the desired setting. a
MSAVEN
Page 47
roceed with the operation for your unit.
3 P
Handset: MOFFN
Base unit: MEXITN
Viewing/editing/erasing call block
umbers
n
Handset
ENUN#217
1 MM
2 MbN: Select the desired entry.
R To exit, press MOFFN.
3 To edit a number:
MEDITN a Edit the phone number. a
MSAVEN a MOFFN
To erase a number:
MERASEN a MbN: “Yes” a MSELECTN
a MOFFN
Base unit
1 MMENUN#217
2 MbN: Select the desired entry.
R To exit, press MEXITN.
3 To edit a number:
MEDITN a Edit the phone number. a
MSAVEN a MEXITN
To erase a number:
MERASEN a MbN: “Yes” a MSELECTN
a MEXITN
Note for handset and base unit:
R When editing, press the desired dial key to
add, MCLEARN to erase.
R When viewing, “Block w/o num” is
displayed if the blocking incoming calls
without phone number feature is turned on.
To turn the feature off: MERASEN a MCN
a MSAVEN a MOFFN (Handset) or MEXITN
(Base unit)
Registering a unit
Operating additional units
Additional handsets
p to 6 handsets can be registered to the
U
base unit.
Programming
Important:
R S
ee page 5 for information on the available
model.
Registering a handset to the
ase unit
b
The supplied handset and base unit are
pre-registered. If for some reason the handset
is not registered to the base unit, re-register
the handset.
1 Handset:
MMENUN#130
2 Base unit:
Press and hold MLOCATORN for about 5
seconds until the registration tone sounds.
R If all registered handsets start ringing,
press MLOCATORN again to stop, then
repeat this step.
R The next step must be completed
within 90 seconds.
3 Handset:
Press MOKN, then wait until a long beep
sounds.
Note:
R While registering, “Base in
registering” is displayed on all
registered handsets.
R When you purchase an additional handset,
refer to the additional handset’s installation
manual for registration.
Deregistering a handset
handset can cancel its own registration to
A
the base unit, or other handsets registered to
the same base unit. This allows the handset to
end its wireless connection with the system.
1 MMENUN#131
R All handsets registered to the base unit
are displayed.
2 MbN: Select the handset you want to
cancel. a MSELECTN
3 MbN: “Yes” a MSELECTN
4 MOFFN
For assistance, please visit http://www.panasonic.com/help
47
Page 48
Caller ID Service
Using Caller ID service
I
mportant:
R This unit is Caller ID compatible. To use
Caller ID features, you must subscribe to a
Caller ID service. Contact your service
provider/telephone company for details.
Caller ID features
Handset / Base unit
hen an outside call is being received, the
W
caller information is displayed.
Caller information for the last 50 callers is
logged in the caller list from the most recent
call to the oldest.
R If the unit cannot receive caller information,
the following is displayed:
– “Out of area”: The caller dials from
an area which does not provide a Caller
ID service.
– “Private caller”*1 / “Private”*2:
The caller requests not to send caller
information.
– “Long distance”*1 / “Long
dist.”*2: The caller makes a long
distance call.
R If the unit is connected to a PBX system,
caller information may not be properly
received. Contact your PBX supplier.
*1 Handset
*2 Base unit
Missed calls
Handset / Base unit
f a call is not answered, the unit treats it as a
I
missed call. The display shows “Missed
call”.
Note:
R Even when there are unviewed missed
calls, “Missed call” disappears from the
standby display if the following operation is
performed by one of the units:
– A handset is replaced on the base unit
or charger.
– Pressing MOFFN on a handset.
– Pressing MEXITN on the base unit.
48
For assistance, please visit http://www.panasonic.com/help
Phonebook name display
hen caller information is received and it
W
matches a phone number stored in the
phonebook, the stored name in the
phonebook is displayed and logged in the
caller list.
Talking Caller ID
Handset / Base unit
T
his feature lets you know who is calling
without looking at the display.
To use this feature, you must:
– subscribe to a Caller ID service of your
service provider/telephone company.
– turn this feature on (page 40, 42).
When caller information is received, the
handsets and base unit announce the caller’s
name or phone number received from your
service provider/telephone company following
every ring.
The unit announces in English only.
R Name pronunciation may vary. This feature
may not pronounce all names correctly.
R Caller ID service has a limit of how many
characters can be displayed. If the caller’s
name is too long, the unit may not be able
to display or announce the entire name.
R The announcement is heard at the same
level as the ringer volume (page 22, 29, 39,
42).
R If you turn on the answering system and set
the number of rings “2 rings” (page
61), the unit does not announce the caller
information from the landline. If “Toll
saver” is selected and there is a new
message, the unit does not announce the
caller information from the landline.
R When you receive a call while on the
phone, the 2nd caller’s name is not
announced even if you subscribe to both
Caller ID and Call Waiting with Caller ID
services.
Phonebook name announcement
W
hen caller information is received and it
matches a phone number stored in the
phonebook, the stored name in the
phonebook is announced.
Page 49
Caller ID Service
Ringer ID for handset
You can select the desired ringer tone to a
group that each phonebook entry is assigned
(page 32). When a call is received from a
caller assigned to a group, the ringer tone you
selected for that group rings instead of the
called line’s ringer tone (page 18, 38, 39) after
caller information is displayed. If you select
“Current ringer” (default), the unit uses
the called line’s ringer tone you selected on
page 39 when calls from this group are
received.
Handset
1 MFN a MM
ENUN
2 MbN: “Group” a MSELECTN
3 MbN: Select the desired group. a
MSELECTN
4 MbN: Select the desired ringer tone. a
MSAVEN
5 MOFFN
Caller list
I
mportant:
R Only 1 person can access the caller list at a
time.
R Make sure the unit’s date and time setting
is correct (page 16).
Viewing the caller list and calling
b
ack
n Using a cellular line
Handset
1 MCN
CID
2 Press MCN to search from the most recent
call, or MDN to search from the oldest call.
3 To call back, press MSELECTN.
To exit, press MOFFN.
4 MCELLN
R The unit starts dialing when:
– only 1 cellular phone is paired.
– a specific line is set to make cellular
alls (page 20).
c
5 MbN: Select the desired cellular phone. a
MSELECTN
Base unit
1 MC
IDN
2 Press MCN to search from the most recent
call, or MDN to search from the oldest call.
3 To call back, press MCELL 1N or MCELL
2N.
To exit, press MEXITN.
n Using the landline
Handset / Base unit
1 P
roceed with the operation for your unit.
Handset: MCN CID
Base unit: MCIDN
2 Press MCN to search from the most recent
call, or MDN to search from the oldest call.
3 Proceed with the operation for your unit.
Handset:
– To call back, press M
–
To exit, press MOFFN.
Base unit:
– To call back, press MZN.
– To exit, press MEXITN.
Note for handset and base unit:
R If the entry has already been viewed or
answered, “
iewed or answered using another unit.
v
R In step 2 for handset or step 2 for base unit,
if
is displayed, not all of the information is
hown. To see the remaining information:
s
Handset:
Press MEN.
To return to the previous screen, press MFN.
Base unit:
Press MN.
To return to the previous screen, press
M
R or indicates the caller information
w
as received from the cellular line.
” is displayed, even if it was
N.
N.
For assistance, please visit http://www.panasonic.com/help
49
Page 50
Caller ID Service
Editing a caller’s phone number
before calling back
You can edit a phone number in the caller list
by removing its area code and/or the long
distance code “1”.
Handset
n W
hen a cellular phone is paired:
1 MCN CID
2 MbN: Select the desired entry.
3 Press MSELECTN, then press *
repeatedly until the phone number is
shown in the desired format.
A
Local phone number
E
xample: 321-5555
B
Area code – Local phone number
Example: 555-321-5555
C
1 – Area code – Local phone number
Example: 1-555-321-5555
4 U
sing a cellular line:
To make a cellular call, continue from
step 4, “Viewing the caller list and
calling back”, page 49.
Using the landline:
M
N
n W
hen a cellular phone is not paired:
1 MCN CID
2 MbN: Select the desired entry.
3 MMENUN a MbN: “Edit” a
MSELECTN
4 Press MEDITN repeatedly until the
phone number is shown in the desired
format.
A
Local phone number
xample: 321-5555
E
B
Area code – Local phone number
Example: 555-321-5555
C
1 – Area code – Local phone number
Example: 1-555-321-5555
5 M
N
Base unit
1 MC
IDN
2 MbN: Select the desired entry.
3 Press MEDITN repeatedly until the phone
number is shown in the desired format.
A
Local phone number
xample: 321-5555
E
B
Area code – Local phone number
Example: 555-321-5555
C
1 – Area code – Local phone number
Example: 1-555-321-5555
4 U
sing a cellular line:
To make a cellular call, continue from
step 3, “Viewing the caller list and calling
back”, page 49.
Using the landline:
MZN
Caller ID number auto edit feature
Handset / Base unit
nce you call back an edited number, the unit
O
which was used to call back remembers the
area code and format of the edited number.
The next time someone calls from the same
area code, caller information is customized by
the unit as follows:
– When the call is being received, the Caller
ID number is displayed in the same format
as the edited number.
– After the call has ended, the caller’s phone
number is displayed in the same format as
the edited number, when reviewed from the
caller list.
For example, you can use this feature to set
the unit to ignore the area code of callers in
your area, so that you can call these local
numbers using caller information without
dialing the area code.
To activate this feature, you must edit an entry
in the caller list, then call that number. After
that, phone numbers from that caller’s area
code are edited automatically.
This feature can be set for each unit (page 40,
43). The default setting is “On”.
50
For assistance, please visit http://www.panasonic.com/help
Page 51
Note:
R P
hone numbers from the 4 most recently
edited area codes are automatically edited.
Erasing selected caller
nformation
i
Handset / Base unit
1 Proceed with the operation for your unit.
Handset: MCN CID
Base unit: MCIDN
2 MbN: Select the desired entry.
3 MERASEN a MbN: “Yes” a MSELECTN
4 Proceed with the operation for your unit.
Handset: MOFFN
Base unit: MEXITN
Erasing all caller information
Handset / Base unit
roceed with the operation for your unit.
1 P
Handset: MCN CID
Base unit: MCIDN
2 MERASEN a MbN: “Yes” a MSELECTN
3 Handset: MOFFN
Storing caller information to the
p
honebook
Handset
n W
hen a cellular phone is paired:
1 MCN CID
2 MbN: Select the desired entry.
R To edit the number, press
MSELECTN, then press *
repeatedly until the phone number
is shown in the desired format.
3 MSAVEN
4 MbN: “Phonebook” a MSELECTN
5 Continue from step 3, “Editing entries”,
page 34.
Caller ID Service
n W
hen a cellular phone is not paired:
1 MCN CID
2 MbN: Select the desired entry.
R To edit the number: MMENUN a
MbN: “Edit” a MSELECTN
Press MEDITN repeatedly until the
phone number is shown in the
desired format. And then, press
MSAVEN. Go to step 5.
3 MMENUN
4 MbN: “Save CID” a MSELECTN
5 MbN: “Phonebook” a MSELECTN
6 Continue from step 3, “Editing entries”,
page 34.
Base unit
1 MC
IDN
2 MbN: Select the desired entry.
R To edit the number, press MEDITN
repeatedly until the phone number is
shown in the desired format.
3 MSAVEN
4 MbN: “Phonebook” a MSELECTN
5 MEXITN
Note for base unit:
R If you stored caller information to the
phonebook using the base unit, the entry is
automatically assigned to “Home”.
R If you want to edit the caller name, you can
do so using the handset (page 34).
For assistance, please visit http://www.panasonic.com/help
51
Page 52
Using Bluetooth Devices
Copying phonebook from a
c
ellular phone (phonebook
transfer)
You can copy phonebook entries from the
paired cellular phones or other cellular phones
(not paired) to the unit’s shared phonebook. A
cellular phone must be compatible with
Bluetooth wireless technology.
Important:
R If a copied entry has 2 or more phone
numbers, each phone number (6 max.) is
stored as a separate entry with the same
name.
R If a phonebook entry includes additional
data such as a picture, that entry may fail to
copy to the base unit.
R If your cellular phone includes international
call entries, set the conversion codes
before copying (page 52).
1 Handset:
MMENUN#618
2 Handset:
To copy from paired cellular phones:
MbN: Select the desired cellular phone. a
MSELECTN
R Copied items are stored to the group
(“Cell 1” or “Cell 2”) which the
cellular phone is paired to.
To copy from other cellular phones
(not paired):
MbN: “Other cell” a MSELECTN a
MbN: Select the group you want to copy to.
a MSELECTN
3 When “Use the cell to
transfer phone book” is displayed:
Go to step 4.
When “Select mode” menu is
displayed:
MbN: Select “Auto” or “Manual”. a
MSELECTN
“Auto”: Download all entries from the
cellular phone automatically. Go to step 5.
“Manual”: Copy entries you selected.
R “Select mode” menu is displayed
only when the cellular phone supports
PBAP (Phone Book Access Profile) for
luetooth connection.
B
4 Cellular phone:
Follow the instructions of your cellular
phone to copy phonebook entries.
R For other cellular phones (not paired),
you need to search for and select the
base unit. The base unit PIN (default:
“0000”) may be required.
R The entries being copied are displayed
on the handset.
5 Handset:
Wait until “Completed” is displayed.
R You can continue copying other entries
if necessary.
6 Handset: MOFFN
Note:
R Some copied entries may have characters
which do not exist in the character table
(page 32). These characters can be
displayed but cannot be entered when
editing an entry.
R The unit does not support some characters.
If a copied entry includes those characters,
they are replaced with other available
characters or “H”.
R If you receive a call while copying
phonebook entries, the copying procedure
stops. Try again after finishing the call.
Setting conversion codes
You must first set the following 3 dialing codes
in the base unit which you want to copy to
before transferring the phonebook from your
cellular phone (each 4 digits max.).
– “International”: An international prefix
used when you make an international call.
– “Country code”: Your country code for
international calls.
– “National access”: A trunk prefix; the
initial digit(s) to be dialed in a domestic call,
prior to the area code.
Base unit
ENUN
1 MM
2 To store “International”: #117
To store “Country code”: #118
52
For assistance, please visit http://www.panasonic.com/help
Page 53
To store “N
#119
ational access”:
3 Enter the desired number. a MSAVEN
4 MEXITN
Note:
R After you copy the entries, confirm that the
numbers were transferred correctly.
Text message alert
Available for:
X-TG7871 series (page 3)
K
This feature sets the handset and base unit to
otify the arrival of a new text message on a
n
cellular phone that is paired with the base unit.
This notification is displayed momentarily on
both the handset and the base unit, and
announced 2 times. The announcement is in
English only.
The default setting is “On”.
Important:
R To use the text message alert feature, you
need to pair your cellular phone to the base
unit (page 17).
R Your cellular phone must support Message
Access Profile (MAP) specification. We
recommend that you confirm if your cellular
phone supports MAP in advance.
R For more details and the list of compatible
cellular phones, please visit our Web site:
http://www.panasonic.com/link2cell
For those whose devices do not support
the Message Access Profile (MAP):
By installing the application “Text Message
Alert”, you can use the text message alert
feature. Please visit our Web site:
http://www.panasonic.net/pcc/support/tel/
Using Bluetooth Devices
Text message alert settings
Your cellular phone
T
o use this text message alert feature, you
may need to turn on the notification of
Bluetooth setting on your cellular phone.
Base unit
1 For CELL 1: MMENUN#6101
For CELL 2: MMENUN#6102
2 MbN: Select the desired setting.
3 MSAVEN a MEXITN
Note:
R If the text message alert feature does not
work, you must turn on notifications in the
Bluetooth settings of your cellular phone.
For instructions on how to do this, visit our
Web site:
http://www.panasonic.net/pcc/support/tel/
R The unit cannot display or announce that a
text message has been received during a
call.
R Text message alerts are not logged in the
caller list of your unit.
Using a Bluetooth wireless
eadset (optional) for
h
landline calls
By pairing a Bluetooth headset to the base
unit, you can have a hands-free conversation
wirelessly for landline calls.
Important:
R 1 headset can be paired to the base unit.
However, only one Bluetooth device
(cellular phone or headset) can be
connected to the base unit at a time.
R For best performance, we recommend
using a Bluetooth headset within 1 m
(3.3 feet) of the base unit. A headset can
communicate with the base unit within a
range of approximately 10 m (33 feet).
efer to your cellular phone operating
R R
instructions for information on how to install
applications.
For assistance, please visit http://www.panasonic.com/help
53
Page 54
Using Bluetooth Devices
Pairing a headset to the base unit
Important:
R Make sure that the Bluetooth headset is not
connected to any other Bluetooth device.
1 Your headset:
Set your headset to pairing mode.
R Refer to the headset operating
instructions.
2 Handset:
MMENUN#621
3 If your headset PIN is “0000”, go to
step 4.
If your headset PIN is other than
“0000”, press MCLEARN, then enter your
headset PIN.
R Typically, default PIN is “0000”. Refer
to the headset operating instructions.
4 Press MOKN, then wait until a long beep
sounds.
5 MOFFN
R When
nit, the headset is available for use.
u
Connecting/disconnecting a headset
f you cannot connect the headset and base
I
unit using the headset, you can connect using
the unit.
To use your headset with another Bluetooth
device such as a cellular phone, you may
need to disconnect it from the base unit.
Important:
R Make sure that the headset is turned on.
Handset / Base unit
o connect/disconnect:
1 T
MMENUN#622
R A long beep sounds.
is displayed on the base
2 Proceed with the operation for your unit.
Handset: MOFFN
Base unit: MEXITN
Unpairing a headset
Y
ou can cancel a pairing of the headset that is
stored to the base unit.
Handset
1 MM
ENUN#612
2 MbN: “Yes” a MSELECTN
R When the headset is unpaired, the
disappears from the base unit
isplay.
d
3 MOFFN
Operating a Bluetooth wireless
h
eadset using a landline
Important:
R Refer to your headset operating instructions
for headset operations.
Answering landline calls with your
eadset
h
To answer a landline call, turn on your
headset referring to your headset operating
instructions.
When you finish talking, turn off your headset
referring to your headset operating
instructions.
Note:
R If you cannot hang up the call using your
headset, press MZN on the base unit 2
times.
Switching between the base unit and
our headset
y
You can switch between the base unit and
your headset:
– during a landline call with the base unit
speakerphone.
– during an intercom call between the base
unit and handset.
– while listening to messages recorded on
the base unit answering system.
n To switch to your headset:
Press M
n To switch to the base unit:
Press MZN on the base unit.
on the base unit.
N
54
For assistance, please visit http://www.panasonic.com/help
Page 55
Call sharing between your headset
nd the handset
a
Important:
R To activate this feature, you should set call
sharing mode to on beforehand (page 41).
n While the handset is on a landline call:
To join the conversation with your headset,
turn on the headset referring to your
headset operating instructions.
n While your headset is on a landline call:
To join the conversation with the handset,
press M
N.
Adjusting your headset receiver
olume
v
Base unit
P
ress MDN or MCN repeatedly while using your
headset.
Using Bluetooth Devices
For assistance, please visit http://www.panasonic.com/help
55
Page 56
Answering System for Landline
Answering system for
l
andline
The answering system can answer and record
calls for you when you are unavailable to
answer the phone.
You can also set the unit to play a greeting
message but not to record caller messages by
selecting “Greeting only” as the recording
time setting (page 62).
Important:
R Only 1 person can access the answering
system (listen to messages, record a
greeting message, etc.) at a time.
R When callers leave messages, the unit
records the day and time of each message.
Make sure the date and time have been set
correctly (page 16).
R When the cellular line only mode is set
(page 19), the answering system cannot be
used and any messages are not received.
Memory capacity (including your
g
reeting message)
The total recording capacity is about 18
minutes. A maximum of 64 messages can be
recorded.
Note:
R When message memory becomes full:
– “Messages full” is shown on the
handset and base unit display.
– The ANSWER ON/OFF indicator on the
base unit flashes rapidly if the answering
system is turned on.
– If you use the pre-recorded greeting
message, the unit automatically switches
to another pre-recorded greeting
message asking callers to call again
later.
– If you recorded your own greeting
message, the same message is still
announced to callers even though their
messages are not recorded.
Turning the answering
s
ystem on/off
Base unit
Press MANSWER ON/OFFN to turn on/off the
answering system.
Handset
o turn on:
1 T
MMENUN#327
To turn off:
MMENUN#328
2 MOFFN
Note for base unit and handset:
R When the answering system is turned on,
the ANSWER ON/OFF indicator on the
base unit lights up.
Call screening
Handset / Base unit
W
hile a caller is leaving a message, you can
listen to the call through the unit’s speaker.
To adjust the speaker volume, press MDN or
MCN repeatedly.
You can answer the call by pressing M
the handset or MZN on the base unit.
Call screening can be set for each unit. The
default setting is “On”.
N
1 MMENUN#310
2 MbN: Select the desired setting. a
MSAVEN
3 Proceed with the operation for your unit.
Handset: MOFFN
Base unit: MEXITN
Greeting message
When the unit answers a call, a greeting
message is played to callers.
You can use either:
– your own greeting message
– a pre-recorded greeting message
on
56
For assistance, please visit http://www.panasonic.com/help
Page 57
Answering System for Landline
Recording your greeting message
Handset
1 MM
ENUN#302
2 MbN: “Yes” a MSELECTN
3 After a beep sounds, hold the handset
about 20 cm (8 inches) away and speak
clearly into the microphone (2 minutes
max.).
4 Press MSTOPN to stop recording.
5 MOFFN
Using a pre-recorded greeting
m
essage
The unit provides 2 pre-recorded greeting
messages:
– If you erase or do not record your own
greeting message, the unit plays a
pre-recorded greeting asking callers to
leave a message.
– If the message recording time (page 62)
is set to “Greeting only”, callers’
messages are not recorded and the unit
plays a different pre-recorded greeting
message asking callers to call again.
Resetting to a pre-recorded greeting
m
essage
If you want to use a pre-recorded greeting
message once you record your own greeting
message, you need to erase your own
greeting message.
Handset
1 MM
ENUN#304
2 MYESN a MOFFN
Playing back the greeting
m
essage
Handset
1 MM
ENUN#303
2 To exit, press MOFFN.
For assistance, please visit http://www.panasonic.com/help
Listening to messages
u
sing the base unit
When new messages have been recorded:
N
– M
on the base unit flashes.
– “New message” is displayed.
Press M
R If new messages have been recorded, the
R If there are no new messages, the base
Operating the answering system
uring playback
d
Key Operation
MDN
M
M
MP
MnN
ME
*1 If pressed within the first 5 seconds of a
Calling back (Caller ID
s
ubscribers only)
If caller information was received for the call,
you can call the caller back while listening to a
message.
Press MZN during playback.
R To edit the number before calling back,
R To call back using a cellular line, continue
(PLAY).
N
base unit plays back new messages.
unit plays back all messages.
or MCN Adjust the speaker
N
N Skip message
AUSEN Pause message
(STOP) Stop playback
RASEN Erase currently playing
m
essage, the previous message is
played.
press MEDITN repeatedly until the phone
number is shown in the desired format
(page 50).
from step 2, “Making cellular calls”, page 28.
volume
*
Repeat message
To resume playback,
press M
message
1
N.
57
Page 58
Answering System for Landline
Erasing all messages
Press MERASEN 2 times while the unit is not in
use.
Listening to messages
u
sing the handset
When new messages have been recorded,
“New message” is displayed.
1 To listen to new messages:
MMENUN#323
To listen to all messages:
MMENUN#324
2 When finished, press MOFFN.
Note:
R To switch to the receiver, press M
n step 1, the following soft key is also
R I
available to listen to new messages.
When a cellular phone is paired:
MMENUN a MPLAYN
When a cellular phone is not paired:
*1
MPLAYN
*1 If there are no new messages in the
answering system, MPLAYN is not
displayed.
*1
Operating the answering system
MMENUN a MbN: “Answering device” a
MSELECTN
Key Operation
MDN
or MCN Adjust the receiver/speaker
or MFN Repeat message (during
1
or MEN Skip message (during
2
3 Enter the “S
4 Play new messages
5 Play all messages
6 Play greeting message
76 Record greeting message
58
volume (during playback)
*1
playback)
playback)
ettings” menu
For assistance, please visit http://www.panasonic.com/help
N.
Key Operation
8 Turn answering system on
2
MPAUSEN
or
9
MSTOPN
0 Turn answering system off
*4
*5 Erase all messages
*6 Reset to a pre-recorded
*1 If pressed within the first 5 seconds of a
m
played.
*2 To resume playback:
MbN: “Playback” a MSELECTN
*3 You can also erase as follows:
MPAUSEN a MbN: “Erase” a
MSELECTN a MbN: “Yes” a MSELECTN
Pause message
Stop recording
Stop playback
3
*
Erase currently playing
m
essage
reeting message
g
essage, the previous message is
*
Calling back (Caller ID
s
ubscribers only)
If caller information is received for the call, you
can call the caller back while listening to a
message.
1 Press MPAUSEN during playback.
2 MbN: “Call back” a MSELECTN
Editing the number before calling back
1 Press MPAUSEN during playback.
2 MbN: “Edit & Call” a MSELECTN
3 Press MEDITN repeatedly until the phone
number is shown in the desired format
(page 50). a M N
o call back using a cellular line,
R T
continue from step 2, “Making cellular
calls”, page 21.
Erasing all messages
1 MM
ENUN#325
2 MbN: “Yes” a MSELECTN a MOFFN
Page 59
Answering System for Landline
Advanced new message
a
lerting features
Audible message alert
T
his feature allows the base unit to beep to
inform you of a new message arrival when
new messages are recorded. The base unit
beeps 2 times every minute until you listen to
the messages, if the “Base unit beep”
setting is turned on. The default setting is
“Off”.
Handset
1 MM
ENUN#339
2 MbN: Select the desired setting. a
MSAVEN a MOFFN
Note:
R When the silent mode is activated
(page 44), the base unit beeps will not
sound.
New message alert by a call
his feature allows the unit to make a call to
T
the pre-stored phone number and inform you
that a new message has been received by
announcement.
To use this feature, you must:
– store a phone number to which the unit
makes the call to.
– turn on the new message alert setting.
After you answer the new message alert call,
you can listen to messages from that call
(page 60).
Important:
R The unit makes a call to the pre-stored
phone number after the new message is
recorded:
– If the call is answered, the
announcement is repeated for about 1
minute.
– If nobody answers within 1 minute, the
unit will not retry the call.
Storing a phone number to which the
nit makes an alert call
u
Handset
rom the phonebook:
n F
1 MMENUN#338
2 MbN: “Notification to” a
MSELECTN a MADDN
3 MbN: “Phonebook” a MSELECTN
4 MbN: Select the desired phonebook
entry. a MSAVEN a MOFFN
n By entering a phone number:
1 MMENUN#338
2 MbN: “Notification to” a
MSELECTN a MADDN
3 MbN: “Manual” a MSELECTN
4 Enter the desired name (16 characters
max.; page 32). a MOKN
5 Enter the desired number (24 digits
max.). a MOKN a MSELECTN a
MOFFN
Turning on/off the new message alert
etting
s
Handset
ENUN#338
1 MM
2 MbN: “On/Off” a MSELECTN
3 MbN: Select the desired setting. a
MSAVEN a MOFFN
Editing the set phone number
Handset
1 MMENUN#338
2 MbN: “Notification to” a MSELECTN
3 MMENUN a MbN: “Edit” a MSELECTN
4 Edit the name if necessary (16 characters
max.; page 32). a MOKN
5 Edit the phone number if necessary (24
digits max.). a MOKN a MSELECTN a
MOFFN
For assistance, please visit http://www.panasonic.com/help
59
Page 60
Answering System for Landline
Erasing the set phone number
Handset
ENUN#338
1 MM
2 MbN: “Notification to” a MSELECTN
3 MMENUN a MbN: “Erase” a MSELECTN
4 MbN: “Yes” a MSELECTN a MOFFN
R The new message alert setting is
turned off.
Activating/inactivating the remote
ccess code to play messages
a
If you activate this feature, you must enter the
remote access code (page 60) to play the
new message from the new message alert
call. This is so that unauthorized parties
cannot listen to your messages. The default
setting is “Inactivate”.
– “Inactivate”: You can listen to the
message by pressing 4 to play new
messages (without entering the remote
access code).
– “Activate”: You must enter your remote
access code (page 60) and then press 4
to play new message.
Handset
1 MM
ENUN#338
2 MbN: “Remote code” a MSELECTN
3 MbN: Select the desired setting. a
MSAVEN a MOFFN
Listening to messages
fter you answer the new message alert, you
A
can listen to the messages as follows.
n When the remote access code is set to
“Inactivate”:
Press 4 to play the new message during
the announcement.
n When the remote access code is set to
“Activate”:
1 Enter the remote access code
(page 60) during the announcement.
2 Press 4 to play the new message.
Note:
R A
fter listening to new messages, you can
press #9 during the call to turn off the
new message alert by a call feature.
R Even if the unit makes a new message alert
call, the handset redial list does not show
the record. However, on the base unit redial
list it is shown as “Message alert”.
Remote operation
U
sing a touch-tone phone, you can call your
phone number from outside and access the
unit to listen to messages or change
answering system settings. The unit’s voice
guidance prompts you to press certain dial
keys to perform different operations.
Remote access code
A
3-digit remote access code must be entered
when operating the answering system
remotely. This code prevents unauthorized
parties from listening to your messages
remotely. The default setting is “111”.
Important:
R To prevent unauthorized access to this
product, we recommend that you regularly
change the remote code.
Handset
ENUN#306
1 MM
2 Enter the desired 3-digit remote access
code.
3 MSAVEN a MOFFN
Deactivating remote operation
ress * in step 2 on “Remote access code”,
P
page 60.
R The entered remote access code is deleted.
Using the answering system
emotely
r
1 Dial your landline phone number from a
touch-tone phone.
60
For assistance, please visit http://www.panasonic.com/help
Page 61
fter the greeting message starts, enter
2 A
your remote access code.
3 Follow the voice guidance prompts as
necessary or control the unit using
remote commands (page 61).
4 When finished, hang up.
Voice guidance
n W
hen the English voice guidance is
selected
During remote operation, the unit’s voice
guidance starts and prompts you to press
1 to perform a specific operation, or press
2 to listen to more available operations.
n When the Spanish voice guidance is
selected
To start the voice guidance, press 9. The
voice guidance announces the available
remote commands (page 61).
Note:
R If you do not press any dial keys within 10
seconds after a voice guidance prompt, the
unit disconnects your call.
Answering System for Landline
*1 If pressed within the first 5 seconds of a
m
essage, the previous message is
played.
*2 For English voice guidance only
*3 For Spanish voice guidance only
Turning on the answering system
r
emotely
If the answering system is off, you can turn it
on remotely.
1 Dial your phone number from a
touch-tone phone.
2 Let the phone ring 15 times.
R A long beep is heard.
3 Enter your remote access code within 10
seconds after the long beep.
R The greeting message is played back.
R You can either hang up, or enter your
remote access code again and begin
remote operation (page 60).
Answering system settings
Remote commands
Y
ou can press dial keys to access certain
answering system functions without waiting for
the voice guidance to prompt you.
Key Operation
1 Repeat message (during
2 Skip message (during playback)
4 Play new messages
5 Play all messages
9
0 Turn answering system off
*4 Erase currently playing message
*5 Erase all messages
*# End remote operation
*1
layback)
p
2
Stop playback
Start voice guidance
or hang up)
(
For assistance, please visit http://www.panasonic.com/help
*
*3
Number of rings before the unit
nswers a call
a
You can change the number of times the
phone rings “Ring count” before the unit
answers calls. You can select 2 to 7 rings, or
“Toll saver”.
The default setting is “4 rings”.
“Toll saver”: The unit’s answering system
answers at the end of the 2nd ring when new
messages have been recorded, or at the end
of the 5th ring when there are no new
messages. If you call your phone from outside
to listen to new messages (page 60), you
know that there are no new messages when
the phone rings for the 3rd time. You can then
hang up without being charged for the call.
Handset
ENUN#211
1 MM
2 MbN: Select the desired setting. a
MSAVEN a MOFFN
61
Page 62
Answering System for Landline
For voice mail service subscribers
f you subscribe to a flat-rate service package
I
that includes Caller ID, call waiting, voice mail,
and unlimited local/regional/long distance
calls, please note the following:
R To use the voice mail service provided by
your service provider/telephone company
rather than the unit’s answering system,
turn off the answering system (page 56).
R To use this unit’s answering system rather
than the voice mail service provided by
your service provider/telephone company,
please contact your service provider/
telephone company to deactivate your
voice mail service.
If your service provider/telephone company
cannot do this:
– Set this unit’s “Ring count” setting so
that this unit’s answering system
answers calls before the voice mail
service of your service provider/
telephone company does. It is necessary
to check the number of rings required to
activate the voice mail service provided
by your service provider/telephone
company before changing this setting.
– Change the number of rings of the voice
mail service so that the answering
system can answer the call first. To do
so, contact your service provider/
telephone company.
Caller’s recording time
ou can change the maximum message
Y
recording time allowed for each caller. The
default setting is “3 min”.
Handset
ENUN#305
1 MM
2 MbN: Select the desired setting. a
MSAVEN a MOFFN
Note:
R W
hen you select “Greeting only”:
– If you do not record your own message,
the unit will play the pre-recorded
greeting-only message asking callers to
call again later.
– If you use your own message, record the
greeting-only message asking callers to
call again later (page 57).
Selecting “G
You can select “Greeting only” which sets
the unit to announce a greeting message to
callers but not record messages.
Select “Greeting only” in step 2 on
“Caller’s recording time”, page 62.
62
reeting only”
For assistance, please visit http://www.panasonic.com/help
Page 63
Voice mail service for
1-222-333-4444
VM access
number
Pauses Password
PPPP 8888
l
andline
Voice mail is an automatic answering service
offered by your service provider/telephone
company. After you subscribe to this service,
your service provider/telephone company’s
voice mail system answers calls for you when
you are unavailable to answer the phone or
when your line is busy. Messages are
recorded by your service provider/telephone
company, not your telephone. Please contact
your service provider/telephone company for
details of this service.
Important:
R To use the voice mail service provided by
your service provider/telephone company
rather than the unit’s answering system,
turn off the answering system (page 56).
For details, see page 62.
Storing the voice mail (VM)
a
ccess number
In order to listen to your voice mail messages,
you must dial your service provider/telephone
company’s voice mail access number. Once
you have stored your voice mail access
number, you can dial it automatically
(page 64).
Handset
1 MM
2 Enter your access number (24 digits
Note:
R When storing your voice mail access
number and your mailbox password, press
MDN (Pause) to add pauses (page 22)
between the access number and the
password as necessary. Contact your
service provider/telephone company for the
required pause time.
Voice Mail Service for Landline
Example:
To erase the voice mail access
umber
n
Handset
1 MM
2 Press and hold MCLEARN until all digits
are erased. a MSAVEN a MOFFN
Voice mail (VM) tone detection
Handset / Base unit
Y
our service provider/telephone company
sends special signals (sometimes called
“voice mail tones” or “stutter tones”) to the unit
to let you know you have new voice mail
messages. If you hear a series of dial tones
followed by a continuous dial tone after you
press M
the base unit, you have new voice mail
messages. Soon after you hang up a call or
after the phone stops ringing, your unit checks
the phone line to see if new voice mail
messages have been recorded.
Turn this feature off when:
ENUN#331
max.). a MSAVEN a MOFFN
– You do not subscribe to voice mail service.
– Your service provider/telephone company
does not send voice mail tones.
– Your phone is connected to a PBX.
If you are not sure which setting is required,
contact your service provider/telephone
company.
Turning VM tone detection on/off
he default setting is “On”.
T
Handset
1 MM
2 MbN: Select the desired setting. a
MSAVEN a MOFFN
For assistance, please visit http://www.panasonic.com/help
ENUN#331
on the handset or press MZN on
N
ENUN#332
63
Page 64
Voice Mail Service for Landline
Listening to voice mail messages
The unit lets you know that you have new
voice mail messages in the following way:
– “New Voice Mail” is displayed if
message indication service is available.
Handset
1 MMENUN#330
R The speakerphone turns on.
2 Follow the pre-recorded instructions.
3 When finished, press MOFFN.
Note:
R In step 1, you can also press MVMN*1 to
listen to new voice messages.
*1 MVMN is displayed if a cellular phone is
not paired and there are new messages
in the voice mail.
Base unit
T
o listen to voice mail messages, you have to
dial your voice mail access number manually.
Note for handset and base unit:
R If the handset and base unit still indicate
there are new messages even after you
have listened to all new messages, turn it
off by pressing and holding # until the
handset or base unit beeps.
64
For assistance, please visit http://www.panasonic.com/help
Page 65
Intercom/Locator
Intercom
I
ntercom calls can be made:
– between handsets
– between a handset and the base unit
Note:
R When paging unit(s), the paged unit(s)
beeps for 1 minute.
R If you receive an outside call while talking
on the intercom, you hear 2 tones.
– To answer the call with the handset,
press MOFFN, then press M
To answer the call with the base unit,
–
press MZN 2 times.
Making an intercom call
Handset
ENUN a MbN: “Intercom” a
1 MM
MSELECTN
2 MbN: Select the desired unit. a MSELECTN
R To stop paging, press MOFFN.
3 When you finish talking, press MOFFN.
Note:
R In step 1, the following soft key is also
available to make an intercom call.
When a cellular phone is paired:
MMENUN a MINTN
When a cellular phone is not paired:
*1
MINTN
*1 If there is a new message in the voice
mail or answering system, MINTN is not
displayed.
Base unit
ress MINTERCOMN.
1 P
When 2 or more handsets are
registered:
– To page a specific handset, enter the
handset number.
– To page all handsets, press 0 or wait
for a few seconds.
R To stop paging, press MINTERCOMN.
*1
2 When you finish talking, press
MINTERCOMN.
N.
Answering an intercom call
Handset
1 P
ress M
to answer the page.
N
2 When you finish talking, press MOFFN.
Base unit
ress MINTERCOMN to answer the page.
1 P
2 When you finish talking, press
MINTERCOMN.
Handset locator
ou can locate a misplaced handset by
Y
paging it.
1 Base unit: Press MLOCATORN.
R All registered handsets beep for 1
minute.
2 To stop paging:
Base unit:
Press MLOCATORN.
Handset:
Press M
then press MOFFN.
N,
Transferring calls,
onference calls
c
Outside calls can be transferred or a
conference call with an outside party can be
made:
– between 2 handsets
– between a handset and the base unit
Handset
1 D
uring an outside call, press MMENUN to
put the call on hold.
2 MbN: “Intercom” a MSELECTN
3 MbN: Select the desired unit. a MSELECTN
4 Wait for the paged party to answer.
R If the paged party does not answer,
press M
call.
N
to return to the outside
For assistance, please visit http://www.panasonic.com/help
65
Page 66
Intercom/Locator
o complete the transfer:
5 T
Press MOFFN.
R The outside call is being routed to the
destination unit.
To establish a conference call:
MMENUN a MbN: “Conf.” a MSELECTN
R To leave the conference, press MOFFN.
The other 2 parties can continue the
conversation.
R To put the outside call on hold:
MMENUN a MbN: “Hold” a
MSELECTN
To resume the conference: MMENUN
a MbN: “Conf.” a MSELECTN
R To cancel the conference: MMENUN a
MbN: “Stop conference” a
MSELECTN
You can continue the conversation
with the outside caller.
Base unit
1 D
uring an outside call, press
MINTERCOMN.
When 2 or more handsets are
registered:
– To page a specific handset, enter the
handset number.
– To page all handsets, press 0 or wait
for a few seconds.
2 Wait for the paged party to answer.
R If paged party does not answer, press
MINTERCOMN to return to the outside
call.
3 To complete the transfer:
Press MZN.
R The outside call is being routed to the
handset.
To establish a conference call:
Press MCONFN.
R To leave the conference, press MZN.
The other 2 parties can continue the
conversation.
R To put the outside call on hold, press
MHOLDN. To resume the conference,
press MCONFN.
Base unit
P
ress MZN to answer the page.
Answering a transferred call
Handset
P
ress M
66
to answer the page.
N
For assistance, please visit http://www.panasonic.com/help
Page 67
Wall mounting
AAA
A
BB
BB
3
1
2
Hook
AA
AA
BB
BB
83 mm
(3
1
/4 inches)
or
102 mm
(4 inches)
2
1
Wall phone plate
102 mm
83 mm
(4 inches)
1
2
(3
1
/4 inches)
Screws
27.2 mm
(ޓinches)
1
/
16
T
he base unit can be mounted on a wall by
changing the wall mounting adaptor’s position.
Note:
R Make sure that the wall and the fixing
method are strong enough to support the
weight of the unit.
R Model shown is KX-TG7841 series.
Base unit
1 T
o remove the wall mounting adaptor,
push down the release levers (A).
Remove the adaptor (B).
Turn the adaptor so that the words
2 A
“UP WALL” are facing up.
B Tuck the telephone line cord inside the
wall mounting adaptor.
C Connect the AC adaptor cord and
telephone line cord.
Useful Information
nsert the lower tabs of the adaptor into
3 I
the unit’s bottom slots (A), then insert by
pushing down the levers of the adaptor
into the upper slots (B).
R The words “UP WALL” should be
facing up.
ount the unit on a wall then slide down
4 M
to secure in place.
For assistance, please visit http://www.panasonic.com/help
Charger
rive the screws (not supplied) into the wall.
D
67
Page 68
Useful Information
Error messages
Display message Cause/solution
Base no power
r
o
No link. Re-connect base
AC adaptor.
or
No link.
Busy
Call phone company for
our access #
y
Check tel line
Error!!
Failed
Invalid
Requires subscription to
aller ID.
C
68
For assistance, please visit http://www.panasonic.com/help
he handset has lost communication with the base
R T
unit. Move closer to the base unit and try again.
R Unplug the base unit’s AC adaptor to reset the unit.
Reconnect the adaptor and try again.
R The handset’s registration may have been canceled.
Re-register the handset (page 47).
R When “No link.” is displayed during a power
failure, place a handset on the base unit to supply
power to the base unit.
o cellular phone is paired to the base unit. Pair a
R N
cellular phone (page 17).
R The called unit is in use.
R Other units are in use and the system is busy. Try
again later.
R The handset you are using is too far from the base
unit. Move closer and try again.
R You have not stored the voice mail access number.
Store the number (page 63).
he supplied telephone line cord has not been
R T
connected yet or not connected properly. Check the
connections (page 10).
R If you do not connect the telephone line cord and use
only cellular lines, set the cellular line only mode
(page 19).
ecording was too short. Try again.
R R
R Someone is using a cellular line or headset. Try
again later.
R The phonebook copy is incomplete (page 52). The
cellular phone is disconnected from the base unit.
Make sure that other Bluetooth devices are not
connected to the cellular phone, and try again.
lthough the unit tried to connect to the cellular
R A
phone or headset, the connection has been failed.
– Someone is using a cellular line or headset. Try
again later.
– Make sure that the cellular phone or headset is
not connected to other Bluetooth devices.
here is no handset registered to the base unit
R T
matching the handset number you entered.
R The handset is not registered to the base unit.
Register the handset (page 47).
R You must subscribe to a Caller ID service. Once you
receive caller information after subscribing to a Caller
ID service, this message will not be displayed.
Page 69
Useful Information
Display message Cause/solution
Use rechargeable battery.
R A
wrong type of battery such as Alkaline or
Manganese was inserted. Use only the rechargeable
Ni-MH batteries noted on page 4, 7.
Troubleshooting
f you still have difficulties after following the instructions in this section, disconnect the base unit’s
I
AC adaptor, then reconnect the base unit’s AC adaptor. Remove the batteries from the handset,
and then insert the batteries into the handset again.
General use
Problem Cause/solution
The handset does not turn on
ven after installing charged
e
batteries.
The unit does not work. R M
I cannot pair a cellular phone to
he base unit.
t
R Place the handset on the base unit or charger to turn on
the handset.
ake sure the batteries are installed correctly (page 11).
R Fully charge the batteries (page 11).
R Check the connections (page 10).
R Unplug the base unit’s AC adaptor to reset the unit.
Reconnect the adaptor and try again.
R The handset has not been registered to the base unit.
Register the handset (page 47).
R Depending on the compatibility of the cellular phone, you
may not be able to pair it to the base unit. Confirm that
your cellular phone supports the hands-free profile (HFP)
specification.
R Confirm that the Bluetooth feature of your cellular phone
is turned on. You may need to turn this feature on
depending on your cellular phone.
R The Bluetooth technology on your cellular phone may not
be functioning normally. Turn off and on your cellular
phone.
R If your cellular phone is already connected to another
Bluetooth device such as a Bluetooth headset, turn it off
or disconnect it from your cellular phone.
R Some cellular phones may require you to enter the base
unit PIN to pairing. Confirm that you entered the correct
PIN.
For assistance, please visit http://www.panasonic.com/help
69
Page 70
Useful Information
Problem Cause/solution
I cannot connect a cellular
p
hone to the base unit.
I cannot hear a dial tone. R M
The base unit beeps. R N
Programmable settings
Problem Cause/solution
The display is in a language I
annot read.
c
I cannot register a handset to a
ase unit.
b
R Confirm that your cellular phone is turned on.
R Confirm that your cellular phone is within base unit range
(page 14).
R Depending on the state of the wireless environment, such
as the presence of any electrical interference, there may
be a delay even if the auto connection feature is turned
on. You can connect to the base unit manually (page 19).
R The cellular phone has not been paired to the base unit.
Pair the cellular phone (page 17).
ake sure that the CELL 1 or CELL 2 indicator lights up
(page 15).
R The base unit’s AC adaptor or telephone line cord is not
connected. Check the connections.
R Disconnect the base unit from the telephone line and
connect the line to a known working telephone. If the
working telephone operates properly, contact our service
personnel to have the unit repaired. If the working
telephone does not operate properly, contact your service
provider/telephone company.
ew messages have been recorded. Listen to the new
messages (page 57).
R Change the display language (page 16).
R The maximum number of handsets (6) is already
registered to the base unit. Cancel unused handset
registrations from the base unit (page 47).
Battery recharge
Problem Cause/solution
attery charge is low. Fully charge the batteries (page 11).
The handset beeps and/or
flashes.
I fully charged the batteries, but
–
still flashes,
– is displayed, or
–
the operating time seems to
be shorter.
70
For assistance, please visit http://www.panasonic.com/help
R B
R C
lean the battery ends (
ith a dry cloth and charge again.
w
R It is time to replace the batteries (page 11).
, ) and the charge contacts
Page 71
Making/answering calls, intercom
Problem Cause/solution
R T
is displayed.
Noise is heard, sound cuts in
nd out.
a
The handset or base unit does
ot ring.
n
I cannot make local calls with
he handset or base unit using
t
a cellular line.
I cannot make or answer
ellular calls with the handset
c
or base unit.
I can make and answer cellular
alls but cannot hear a sound.
c
I cannot switch cellular calls
rom the unit to the cellular
f
phone.
he handset is too far from the base unit. Move closer.
R The base unit’s AC adaptor is not properly connected.
Reconnect AC adaptor to the base unit.
R The handset is not registered to the base unit. Register it
(page 47).
R You are using the handset or base unit in an area with
high electrical interference. Re-position the base unit and
use the handset away from sources of interference.
R Move closer to the base unit.
R If you use a DSL/ADSL service, we recommend
connecting a DSL/ADSL filter between the base unit and
the telephone line jack. Contact your DSL/ADSL provider
for details.
R The ringer volume for landline is turned off. Adjust the
ringer volume (page 39, 42).
R The ringer volume for cellular line is turned off. Adjust the
ringer volume (page 38, 42).
R When one handset is selected to ring for cellular calls,
other units do not ring. To change the selection, see
page 20.
R Silent mode is turned on. Turn it off (page 44).
R You need to add your area code when making cellular
calls. Store your area code in order to automatically add it
to the beginning of the 7-digit phone number when
making cellular calls (page 20).
R Depending on the cellular phone’s compatibility, you may
not be able to make or answer cellular calls even if the
cellular phone is connected to the base unit.
R Make sure that the CELL 1 or CELL 2 indicator lights up
and the cellular phone is connected to the base unit
(page 19).
R If someone is talking on a cellular call or using the
headset, you cannot use the cellular feature. There can
be only one active Bluetooth connection at a time.
R The cellular phone is being used separately from your
system.
R The Bluetooth technology on your cellular phone may not
be functioning normally. Turn off and on your cellular
phone.
R Disconnect and reconnect the base unit AC adaptor and
try again.
R Your cellular phone may not support this feature. Refer to
the operating instructions of your cellular phone.
Useful Information
For assistance, please visit http://www.panasonic.com/help
71
Page 72
Useful Information
Problem Cause/solution
I cannot make a call using the
l
andline.
I cannot make long distance
alls.
c
Caller ID/Talking Caller ID
Problem Cause/solution
Caller information is not
isplayed.
d
Caller information is displayed
r announced late.
o
Caller information is not
nnounced.
a
R The dialing mode may be set incorrectly. Change the
setting (page 16).
R The cellular line only mode is turned on. Turn it off
(page 19).
R Make sure that you have long distance service.
R You must subscribe to Caller ID service. Contact your
service provider/telephone company for details.
R If your unit is connected to any additional telephone
equipment such as a Caller ID box or cordless telephone
line jack, plug the unit directly into the wall jack.
R If you use a DSL/ADSL service, we recommend
connecting a DSL/ADSL filter between the base unit and
the telephone line jack. Contact your DSL/ADSL provider
for details.
R The name display service for landline calls may not be
available in some areas. Contact your service provider/
telephone company for details.
R Other telephone equipment may be interfering with this
unit. Disconnect the other equipment and try again.
R Depending on your service provider/telephone company,
the unit may display or announce the caller’s information
at the 2nd ring or later.
R Move closer to the base unit.
R The ringer volume for landline is turned off. Adjust the
ringer volume (page 39, 42).
R The ringer volume for cellular line is turned off. Adjust the
ringer volume (page 38, 42).
R When one handset is selected to ring for cellular calls,
other units do not announce caller information. To change
the selection, see page 18.
R The Talking Caller ID feature is turned off. Turn it on
(page 40, 42).
R The ring as cell mode is set to “On (without Talking
CID)”. To change the mode, see page 18.
R The number of rings for the answering system is set to “2
rings” or “Toll saver”. Select a different setting
(page 61).
R Your unit does not announce caller information if
– the base unit or 2 or more handsets are on a call.
– a headset is in use.
72
For assistance, please visit http://www.panasonic.com/help
Page 73
Problem Cause/solution
The caller list/incoming phone
n
umbers are not edited
automatically.
I cannot dial the phone number
dited in the caller list.
e
Time on the unit has shifted. R I
The 2nd caller’s information is
ot displayed during an outside
n
call.
R The Caller ID number auto edit feature is turned off. Turn
it on and try again (page 40, 43).
R You need to call back the edited number to activate Caller
ID number auto edit.
R The phone number you dialed might have been edited
incorrectly (for example, the long distance “1” or the area
code is missing). Edit the phone number with another
pattern (page 50).
ncorrect time information from incoming Caller ID
changes the time. Set the time adjustment to
“Manual” (off) (page 40).
R In order to use Caller ID, call waiting, or Call Waiting
Caller ID (CWID), you must first contact your service
provider/telephone company and subscribe to the desired
service.
After subscribing, you may need to contact your service
provider/telephone company again to activate this specific
service, even if you already subscribed to both Caller ID
and Call Waiting with Caller ID services (CWID).
Using Bluetooth devices
Problem Cause/solution
I cannot copy phonebook
ntries from a cellular phone.
e
I cannot have a conversation
sing the headset.
u
Noise is heard during a call on
he headset.
t
R Confirm that the cellular phone supports Bluetooth
wireless technology.
R Confirm that the cellular phone supports the Phone Book
Access Profile (PBAP) or Object Push Profile (OPP)
specification.
R If the cellular phone is already connected to another
Bluetooth device such as a Bluetooth headset, turn it off
or disconnect it from the cellular phone.
R Someone is using a cellular line or headset. Try again
later.
R Turn the cellular phone off, then turn it on and try again.
R If an entry is already stored in the unit’s shared
phonebook, the entry cannot be copied even by selecting
another group.
R Your Bluetooth headset is not paired. Pair it (page 54).
R Turn your headset off, then turn it on and try again.
R A Bluetooth headset can communicate with the base unit
within a range of approximately 10 m (33 feet). The
connection may be subject to interference from
obstructions such as walls or electronic devices. Move
closer to the base unit.
Useful Information
For assistance, please visit http://www.panasonic.com/help
73
Page 74
Useful Information
Problem Cause/solution
I cannot connect my headset to
t
he base unit.
Some headset enhanced
eatures are not available.
f
An error tone is heard when I
ry to program the Bluetooth
t
feature.
Text message alert is not
nnounced.
a
R Confirm that your headset is turned on.
R If your headset is already connected to another Bluetooth
device such as your cellular phone, disconnect the
headset from your cellular phone, then perform the
connecting procedure from the base unit.
R If someone is using a cellular line, you cannot connect the
headset. There can be only one active Bluetooth
connection at a time.
R The headset has not been paired to the base unit. Pair
the headset (page 54).
R The base unit does not support enhanced features such
as Last number redial or Call reject.
R The Bluetooth feature cannot be accessed immediately
after connecting the AC adaptor to the base unit. Wait a
few seconds and try again.
R The headset has not connected to the base unit yet, even
though you performed the connecting procedure setting.
Wait a few seconds and try again.
R The text message alert announcement depends on the
“Ring as cell (limited)” setting (page 18) and the
“Talking Caller ID” setting (page 40, 42).
To make the unit announce text message alerts, there are
2 methods available, depending on whether or not you
want the unit to emit the same ring as the cellular phone
when a call is being received on the cellular phone.
– If you prefer the same ring as the cellular phone, select
“On (with Talking CID)” of the “Ring as
cell (limited)” setting.
– If you prefer the same ring as the unit, select “Off” of
the “Ring as cell (limited)” setting, and select
“On” of the “Talking Caller ID” setting on the
handset and base unit.
74
For assistance, please visit http://www.panasonic.com/help
Page 75
Answering system
Problem Cause/solution
The unit does not record new
m
essages.
I cannot operate the answering
ystem remotely.
s
The unit does not emit the
pecified number of rings.
s
R The answering system is turned off. Turn it on (page 56).
R The answering system does not answer or record calls
from cellular lines.
R The message memory is full. Erase unnecessary
messages (page 57).
R The recording time is set to “Greeting only”. Change
the setting (page 62).
R If you subscribe to a voice mail service, messages are
recorded by your service provider/telephone company,
not your telephone. Change the unit’s number of rings
setting or contact your service provider/telephone
company (page 62).
R The answering system will not answer incoming calls
while:
– the base unit or 2 or more handsets are on a cellular
call or an intercom call.
– a headset is in use.
Caller information is recorded in the caller list.
R The remote access code is not set. Set the remote
access code (page 60).
R You are entering the wrong remote access code. If you
have forgotten your remote access code, enter the
remote access code setting to check your current code
(page 60).
R The answering system is turned off. Turn it on (page 61).
R You cannot operate the answering system when calling a
cellular phone paired to the base unit.
R If the first ring is turned off, the number of rings decreases
by 1 from the specified number of rings.
Useful Information
Bluetooth PIN
Problem Cause/solution
I cannot remember the PIN. R C
hange the PIN using the following method.
1 MMENUN#619
2 *7000
3 Enter the new 4-digit PIN. a MOKN
4 Enter the new 4-digit PIN again. a MSAVEN a MOFFN
For assistance, please visit http://www.panasonic.com/help
75
Page 76
Useful Information
Liquid damage
Problem Cause/solution
Liquid or other form of moisture
h
as entered the handset/base
unit.
Caution:
R T
o avoid permanent damage, do not use a microwave oven to speed up the drying process.
R Disconnect the AC adaptor and telephone line cord from
the base unit. Remove the batteries from the handset and
leave to dry for at least 3 days. After the handset/base
unit are completely dry, reconnect the AC adaptor and
telephone line cord. Insert the batteries and charge fully
before use. If the unit does not work properly, contact an
authorized service center.
76
For assistance, please visit http://www.panasonic.com/help
Page 77
FCC and other information
This equipment complies with Part 68 of the
FCC rules and the requirements adopted by
the ACTA. On the bottom of this equipment
is a label that contains, among other
information, a product identifier in the
format US:ACJ----------.
If requested, this number must be provided
to the telephone company.
L Registration No.............(found on the
bottom of the unit)
L Ringer Equivalence No. (REN).......0.1B
A plug and jack used to connect this
equipment to the premises wiring and
telephone network must comply with the
applicable FCC Part 68 rules and
requirements adopted by the ACTA. A
compliant telephone cord and modular plug
is provided with the product. It is designed
to be connected to a compatible modular
jack that is also compliant.
The REN is used to determine the number
of devices that may be connected to a
telephone line. Excessive RENs on a
telephone line may result in the devices not
ringing in response to an incoming call. In
most but not all areas, the sum of RENs
should not exceed five (5.0). To be certain
of the number of devices that may be
connected to a line, as determined by the
total RENs, contact the local telephone
company. For products approved after July
23, 2001, the REN for the product is part of
the product identifier that has the format
US:AAAEQ##TXXXX. The digits
represented by ## are the REN without a
decimal point (e.g., 03 is a REN of 0.3).
If this equipment causes harm to the
telephone network, the telephone company
will notify you in advance that temporary
discontinuance of service may be required.
But if advance notice isn't practical, the
telephone company will notify the customer
as soon as possible. Also, you will be
advised of your right to file a complaint with
the FCC if you believe it is necessary.
The telephone company may make changes
in its facilities, equipment, operations or
procedures that could affect the operation of
the equipment. If this happens the
telephone company will provide advance
notice in order for you to make necessary
modifications to maintain uninterrupted
service.
If trouble is experienced with this
equipment, for repair or warranty
information, please contact a Factory
Service Center or other Authorized Servicer.
If the equipment is causing harm to the
telephone network, the telephone company
may request that you disconnect the
equipment until the problem is resolved.
Connection to party line service is subject to
state tariffs. Contact the state public utility
commission, public service commission or
corporation commission for information.
If your home has specially wired alarm
equipment connected to the telephone line,
ensure the installation of this equipment
does not disable your alarm equipment. If
you have questions about what will disable
alarm equipment, consult your telephone
company or a qualified installer.
This equipment is hearing aid compatible as
defined by the FCC in 47 CFR Section
68.316.
When you hold the phone to your ear, noise
might be heard in your Hearing Aid. Some
Hearing Aids are not adequately shielded
from external RF (radio frequency) energy. If
noise occurs, use an optional headset
accessory or the speakerphone option (if
applicable) when using this phone. Consult
with your audiologist or Hearing Aid
Useful Information
For assistance, please visit http://www.panasonic.com/help
77
Page 78
manufacturer about the availability of
Hearing Aids which provide adequate
shielding to RF energy commonly emitted
by digital devices.
WHEN PROGRAMMING EMERGENCY
NUMBERS AND(OR) MAKING TEST
CALLS TO EMERGENCY NUMBERS:
1) Remain on the line and briefly explain to
the dispatcher the reason for the call.
2) Perform such activities in the off-peak
hours, such as early morning or late
evenings.
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
Privacy of communications may not be
ensured when using this phone.
CAUTION:
Any changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate this device.
NOTE:
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and, if not installed
and used in accordance with the
instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
– Reorient or relocate the receiving
antenna.
– Increase the separation between the
equipment and receiver.
– Connect the equipment into an outlet on a
circuit different from that to which the
receiver is connected.
– Consult the dealer or an experienced
radio/TV technician for help.
Some cordless telephones operate at
frequencies that may cause interference to
nearby TVs and VCRs. To minimize or
prevent such interference, the base of the
cordless telephone should not be placed
near or on top of a TV or VCR. If
interference is experienced, move the
cordless telephone further away from the TV
or VCR. This will often reduce or eliminate
interference.
FCC RF Exposure Warning:
L This product complies with FCC radiation
exposure limits set forth for an
uncontrolled environment.
L To comply with FCC RF exposure
requirements, the base unit must be
installed and operated 20 cm (8 inches)
or more between the product and all
person’s body (excluding extremities of
hands, wrist and feet).
L This product may not be collocated or
operated in conjunction with any other
antenna or transmitter.
L The handset may be carried and operated
with only the specific provided belt-clip.
Other non-tested belt-clips or similar
body-worn accessories may not comply
and must be avoided.
Notice:
L FCC ID can be found inside the battery
compartment or on the bottom of the
units.
Useful Information
78
For assistance, please visit http://www.panasonic.com/help
Page 79
Compliance with TIA-1083 standard:
Telephone handsets identified with this logo
have reduced noise and interference when
used with T-Coil equipped hearing aids and
cochlear implants.
T
Compatible with
Hearing Aid T-Coil
TIA-1083
Useful Information
For assistance, please visit http://www.panasonic.com/help
79
Page 80
Conexiones
L
Use solo el adaptador de corriente Panasonic PNLV226 incluido.
*Se requiere un filtro DSL/ADSL (no incluido) si tiene servicio de DSL/ADSL.
L
Use solo el adaptador de corriente Panasonic PNLV234 incluido.
*Se requiere un filtro DSL/ADSL (no incluido) si tiene servicio de DSL/ADSL.
Unidad base para la serie KX-TG7841
Correcto Incorrecto
Gancho
Oprima firmemente
el contacto.
“Clic”
“Clic”
A la toma de
teléfono de línea
única (RJ11C)
A la toma
de corriente
Filtro DSL/ADSL*
Unidad base para la serie KX-TG7871
A la toma
de corriente
A la toma de
teléfono de línea
única (RJ11C)
Filtro DSL/ADSL*
“Clic”
“Clic”“Clic”
Cargador
A la toma de corriente
Guía Rápida Española
Guía Rápida Española
80
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
Page 81
Instalación de la batería/Carga de las baterías
Cargue aproximadamente durante 7 horas.
Nota:
L
UTILICE SOLO baterías de Ni-MH tamaño AAA (R03).
L
NO utilice baterías Alcalinas, de Manganeso o de Ni-Cd.
L
Compruebe que las polaridades son las correctas (S,T).
Sugerencias de operación
Teclas de función
La unidad incluye teclas de función. Al oprimir una tecla de función, puede seleccionar la función que
aparece directamente encima de ella en la pantalla. Preste atención a la pantalla para ver qué funciones
están asignadas a las teclas de función durante la operación.
Tecla n avegadora
Auricular:
−
{^},{V},{<}
, o
{>}
: Navegue por diversas listas y elementos.
−
?
(Volumen:
{^}
o
{V}
): Ajuste el volumen del receptor o el altavoz mientras habla.
−{<}C
: Ver la entrada del directorio telefónico.
−{>
}
REDIAL (Remarcación): Vea la lista de remarcación.
−
{V}
CID (identificador de llamadas): Vea la lista de personas que llamaron.
Unidad base:
−
{^},{V},{7}
o {8}: Navegue por diversas listas y elementos.
−
VOL. (Volumen:
{^}
o
{V}
): Ajuste el volumen del altavoz mientras habla.
−{7
}/{8}
: Repetir u omitir mensajes durante la reproducción.
SOLO baterías Ni-MH recargables
Confirme que aparezca
“Cargando”.
{V}
{^}
Subir volumen
Bajar volumen
{<}{>}
{V}
{^}
Subir volumen
Bajar volumen
{7}{8}
Auricular
Unidad base
Guía Rápida Española
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
81
Page 82
Cambio de idioma (predeterminado: “
English
”)
Cuando instale las baterías por primera vez, es posible que aparezca “Date and time Press SELECT”.
Oprima
{
OFF} para salir.
Idioma de la pantalla (Auricular/Unidad base)
1
{
MENU}(11)s{r}:“Español”s{GUARDA
}
2
Continúe operando su unidad.
Auricular:{OFF
}
Unidad base:{EXIT
}
Idioma de la guía de voz (Auricular)
{
MENU}(
112s{r}:“
Español”s{GUARDA}s{OFF
}
Fecha y hora (Auricular)
1
{
MENU}(1)
1
2
Introduzca el día, mes y año actuales. s{OK}
3
Introduzca la hora y minuto actuales (formato de reloj de 24 horas).
4
{
GUARDA}s{OFF
}
Cómo grabar el mensaje de saludo del contestador de llamadas para
la línea terrestre (Auricular)
Si utiliza un mensaje de saludo pregrabado, no es necesario que grabe su propio mensaje de saludo.
1
{
MENU}(3)2s{r}:“Sí”s{SELEC.
}
2
Después de que suene un pitido, sostenga el auricular a una distancia aproximada de 20 cm (8
pulgadas) y hable con claridad en el micrófono (máx. de 2 minutos).
3
Oprima {ALTO} para dejar de grabar. s{
OFF
}
Enlace a celular
Puede usar la unidad para hacer o contestar llamadas usando una línea de teléfono celular. Sus teléfonos
celulares deben tener tecnología inalámbrica Bluetooth
®
que sea compatible con este producto. Para
obtener más detalles, visite nuestro sitio web: http://www.panasonic.com/link2cell
L
Coloque su teléfono celular cerca de la unidad base. Si su teléfono celular está demasiado cerca de la
unidad base durante la llamada celular, es posible que escuche ruido. Para un mejor funcionamiento, le
recomendamos que coloque su teléfono celular de 0.6 m a 3 m (2 pies a 10 pies) de la unidad base.
Marcas registradas
L
La marca denominativa y los logotipos de Bluetooth® son propiedad de Bluetooth SIG, Inc. y cualquier
uso de dichas marcas por parte de Panasonic Corporation se hace bajo licencia. Todas las demás
marcas comerciales que se identifican en el presente pertenecen a sus respectivos propietarios.
Línea celular
Proveedor de servicio
del teléfono celular
Guía Rápida Española
82
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
Page 83
Cómo emparejar un teléfono celular con Bluetooth
1
Auricular:
Para CELL 1: {MENU}(
6241
Para CELL 2: {MENU}(
6242
L
Después de que el indicador de CELL 1 o CELL 2 comienza a parpadear en la unidad base, el resto
del procedimiento debe completarse en menos de 5 minutos.
2
Su teléfono celular:
Mientras el indicador de CELL 1 o CELL 2 está parpadeando, siga las instrucciones de su teléfono
celular para entrar al modo de emparejamiento.
L
Dependiendo de su teléfono celular, es posible que le pida que introduzca el NIP de la unidad base
(predeterminado:
“
0000”).
3
Auricular:
Espere a que se emita un pitido largo.
L
Es posible que tarde más de 10 segundos en completar el emparejamiento.
L
Cuando el indicador de CELL 1 o CELL 2 se ilumina, esto significa que el teléfono celular está
conectado a la unidad base. Ya está listo para hacer llamadas regulares de celular.
4
{
OFF
}
Nota:
L
Asegúrese de que su teléfono celular está configurado para conectarse a este producto
automáticamente. Consulte las instrucciones de operación de su teléfono celular.
Unidad base: Indicadores CELL 1/CELL 2
odacifingiSodatsE
Encendido Un teléfono celular está conectado. Listo para hacer o recibir llamadas
celulares.
Parpadeando
−
La línea del celular se está usando.
−
Las entradas del directorio telefónico se están copiando desde un
teléfono celular.
−
La unidad base está buscando el teléfono celular emparejado.
−
Una llamada de celular se pone en espera.
Parpadea rápidamente Se está recibiendo una llamada de celular.
Luz apagada
−
No hay un teléfono celular emparejado con la unidad base.
−
No hay un teléfono celular conectado a la unidad base.
Auricular: enlace a elementos de la pantalla del celular
t
Se está usando una línea de celular.
L
Cuando parpadea: la llamada celular se pone en espera.
L
Cuando parpadea rápidamente: se está recibiendo una llamada celular.
Un teléfono celular está conectado.*1 Listo para hacer o recibir llamadas celulares.
L
Cuando está apagado: no hay un teléfono celular conectado a la unidad base.
*1 La línea o líneas celulares correspondientes se indican enseguida del elemento.
uv
Está recibiendo una llamada de celular en esa línea.
Enlace a celular
]
1
2
Guía Rápida Española
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
83
Page 84
Cómo conectar o desconectar el teléfono celular
Conexión automática al teléfono celular
La unidad se conecta al teléfono celular a intervalos regulares si se pierde la conexión. Consulte las
instrucciones de operación para cambiar el intervalo (predeterminado:
“
1 min”).
L
Cuando está usando una línea celular o un audífono con Bluetooth, la unidad base pierde la conexión de
otros dispositivos con Bluetooth (teléfono celular o audífono). Para restablecer la conexión a los
teléfonos celulares automáticamente, deje encendida la conexión automática.
Cómo conectar o desconectar manualmente el teléfono celular (Auricular)
Si no va a utilizar el vínculo del teléfono celular apareado a la función del celular temporalmente (por
ejemplo, si no desea que la unidad timbre cuando su línea de celular reciba una llamada), puede
desconectar su teléfono celular de la unidad base. Si desea usarlo de nuevo, reconecte el teléfono celular
a la unidad base.
L
Aunque haya desconectado un teléfono celular apareado de la unidad base, si lo coloca dentro del
alcance de la unidad base durante el intervalo de conexión automática, es posible que se conecte
automáticamente a la unidad base.
L
Los teléfonos celulares desconectados no se “Des. Enlazar” de la unidad base, así que no es
necesario aparearlos de nuevo con ella.
1
Para conectarlo o desconectarlo:
Para CELL 1: {MENU}(
6251
(suena un pitido largo).
Para CELL 2:
{
MENU}(
6252
(suena un pitido largo).
2
{
OFF
}
Modo exclusivo para la línea celular (si no utiliza la línea terrestre) (Auricular)
Si no utiliza la línea terrestre, configure el modo exclusivo para la línea celular para usar esta unidad en
forma más conveniente.
1
{
MENU}(
157
2
Para encenderlo:
{r}:“
Encendido”s{SELEC.}s{r}:“Sí”s{SELEC.
}
Para apagarlo:
{r}:“
Apagado”s{SELEC.
}
Operaciones básicas
Cómo hacer y contestar llamadas (Auricular)
Para hacer llamadas de celular
1
Marque el número telefónico. s{
CEL.
}
L
Cuando el modo exclusivo para la línea celular está configurado,
también puede oprimir
{C}/{s}
en lugar de {CEL.}.
L
Cuando solo hay 1 teléfono celular emparejado, la unidad
comienza a marcar.
2
Cuando hay 2 teléfonos celulares emparejados:
{r}
: Seleccione el teléfono celular deseado. s{
SELEC.
}
Para hacer llamadas por la
línea terrestre
Marque el número telefónico. s{C}/{s}
Para contestar llamadas
{C}/{s}
Para colgar
{
OFF
}
Enlace a celular
Guía Rápida Española
84
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
Page 85
Cómo hacer y contestar llamadas (Auricular)
Para ajustar el volumen del
receptor o del altavoz
Oprima
{^}
o
{V}
repetidamente mientras habla.
Cómo hacer una llamada
usando la lista de remarcación
1
{>}
REDIAL s{r}
: Seleccione el número telefónico deseado.
2
Para hacer una llamada celular:
Cuando solo hay 1 teléfono celular emparejado: {CEL.
}
o
Cuando hay 2 teléfonos celulares emparejados:
{
CEL.}s{r}: Seleccione el teléfono celular deseado.
s
{
SELEC.
}
Para hacer una llamada terrestre:
{C}
Cómo hacer y contestar llamadas (Unidad base)
Para hacer llamadas de celular Marque el número telefónico. s{
CELL 1}/{CELL 2
}
L
Cuando el modo exclusivo para la línea celular está configurado,
también puede oprimir
{s}
en lugar de {CELL 1}/{CELL 2}.
Para hacer llamadas por la
línea terrestre
Marque el número telefónico. s{s}
Para contestar llamadas
{s}
Para colgar
{s}
Para ajustar el volumen del
altavoz
Oprima
{^}
o
{V}
repetidamente mientras habla.
Cómo hacer una llamada
usando la lista de remarcación
1
{
REDIAL}s{r}: Seleccione el número telefónico deseado.
2
Para hacer una llamada celular:{CELL 1}/{CELL 2
}
Para hacer una llamada terrestre:
{s}
Para ajustar el volumen del timbre (Auricular)
Para ajustar el volumen del
timbre del auricular (línea de
celular)
1
Para CELL 1:{MENU}(
6281
Para CELL 2:{MENU}(
6282
2
{r}
: Seleccione el volumen deseado. s{
GUARDA}s{OFF
}
Para ajustar el volumen del
timbre del auricular (línea
terrestre)
1
{
MENU}(16)
2
{r}
: Seleccione el volumen deseado. s{
GUARDA}s{OFF
}
Para ajustar el volumen del timbre (Unidad base)
Para ajustar el volumen del
timbre de la unidad base (línea
celular)
1
Para CELL 1:{MENU}(
6281
Para CELL 2:{MENU}(
6282
2
{r}
: Seleccione el volumen deseado. s{
GUARDA}s{EXIT
}
Para ajustar el volumen del
timbre de la unidad base (línea
terrestre)
1
{
MENU}(16)
2
{r}
: Seleccione el volumen deseado. s{
GUARDA}s{EXIT
}
Operaciones básicas
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
Guía Rápida Española
85
Page 86
Directorio telefónico compartido (Auricular)
Para añadir entradas
1
{<}Cs{MENU
}
2
{r}:“
Agregar Ent. Nueva”s{SELEC.
}
3
Introduzca el nombre de la persona (máx. 16 caracteres). s{OK}
4
Introduzca el número telefónico de la persona (máx. 24 dígitos).
s
{OK}
5
{r}
: Seleccione el grupo deseado. s{
SELEC.} 2 veces
s
{
OFF
}
Para hacer llamadas
1
{<}Cs{r}: Seleccione la entrada deseada.
2
Para hacer una llamada celular:
Cuando solo 1 teléfono celular está emparejado: {CEL.
}
o
Cuando 2 teléfonos celulares están emparejados:
{
CEL.}s{r}: Seleccione el teléfono celular deseado.
s
{
SELEC.
}
Para hacer una llamada terrestre:
{C}
Directorio telefónico compartido (Unidad base)
Para hacer llamadas
1
{C}s{r}
: Seleccione la entrada deseada.
2
Para hacer una llamada celular: {CELL 1}/{CELL 2
}
Para hacer una llamada terrestre:
{s}
Contestador de llamadas de la línea terrestre (Unidad base)
Contestador encendido/
apagado
Oprima {ANSWER ON/OFF} para encender y apagar el contestador
de llamadas.
Para escuchar mensajes
{6}
(PLAY)
Contestador de llamadas de la línea terrestre (Auricular)
Para escuchar mensajes
Para escuchar mensajes nuevos:
{
MENU}(
323
Para escuchar todos los mensajes:
{
MENU}(
324
Operaciones básicas
Guía Rápida Española
86
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
Page 87
Cómo usar dispositivos Bluetooth
Copiado de entradas del directorio telefónico desde un teléfono celular con Bluetooth (transferencia
del directorio telefónico)
Puede copiar entradas del directorio telefónico desde los teléfonos celulares emparejados o desde otros
teléfonos celulares (no emparejados) al directorio telefónico compartido de la unidad.
1
Auricular: {MENU}(
618
2
Auricular:
Para copiar desde teléfonos celulares emparejados:
{r}
: Seleccione el teléfono celular deseado. s{
SELEC.
}
L
Los elementos copiados se almacenan en el grupo (“Cel. 1” o “Cel. 2”) en el que está emparejado
el teléfono celular.
Para copiar desde otros teléfonos celulares (no emparejados):
{r}:“
Otro celular”s{SELEC.}s{r}: Seleccione el grupo al que desea copiar. s{
SELEC.
}
3
Cuando se muestre “
Transf. datos del directorio del celular”: Vaya al paso 4.
Cuando aparezca el menú “
Selec. modo
”:
{r}
: Seleccione “Auto” o “Manual”.s{
SELEC.
}
“
Auto”: Descargue todas las entradas del teléfono celular automáticamente. Vaya al paso 5.
“
Manual”: Copie las entradas que seleccionó.
L
El menú “Selec. modo” aparece solo cuando el teléfono celular soporta PBAP (Perfil de Acceso a
Directorio Telefónico) para la conexión Bluetooth.
4
Teléfono celular:
Siga las instrucciones de su teléfono celular para copiar las entradas del directorio telefónico.
L
Para otros teléfonos celulares (no emparejados), necesita buscar y seleccionar la unidad base. Es
posible que requiera el NIP (predeterminado:
“
0000”) de la unidad base.
L
Las entradas que se están copiando aparecen en el auricular.
5
Auricular:
Espere a que aparezca “Completo”.s{
OFF
}
Guía Rápida Española
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
87
Page 88
Cómo usar un audífono Bluetooth (opcional) para llamadas por la línea terrestre
Al emparejar un audífono Bluetooth con la unidad base, podrá tener conversaciones inalámbricas a manos
libres para llamadas terrestres.
L
La conexión del audífono con Bluetooth no está disponible mientras alguien se encuentra usando la línea
celular.
Cómo emparejar un audífono con la unidad base
1
Su audífono:
Configure su audífono en modo de emparejamiento.
L
Consulte las instrucciones de operación de su audífono.
2
Auricular:
{
MENU}(
621
3
Si el NIP de su audífono es “
0000”, vaya al paso 4.
Si el NIP de su audífono es diferente a “
0000”, pulse {BORRA} y después introduzca el NIP de su
audífono.
L
Por lo general, el NIP predeterminado es “0000”. Consulte las instrucciones de operación del
audífono.
4
Oprima {OK}, y después espere a que se emita un pitido largo. s{
OFF
}
L
Cuando aparezca en la unidad base, el audífono estará listo para usarse.
Cómo operar un audífono inalámbrico con Bluetooth usando una línea terrestre
Consulte las instrucciones de operación de su audífono para ver cómo funciona.
N
Cómo contestar llamadas de la línea terrestre con su audífono
Para contestar una llamada de línea terrestre, encienda su audífono. Para ello, consulte las instrucciones
de operación de su audífono.
Cuando termine de hablar, apague su audífono. Para ello, consulte las instrucciones de operación de su
audífono.
L
Si no puede colgar la llamada usando su auricular, oprima
{s}
2 veces en la unidad base.
N
Cómo cambiar entre la unidad base y su audífono
Puede cambiar entre la unidad base y su audífono:
−
durante una llamada por una línea terrestre con el altavoz de la unidad base.
−
durante una llamada de intercomunicador entre la unidad base y el auricular.
−
mientras escucha los mensajes grabados en el contestador de llamadas de la unidad base.
N
Para cambiar a su audífono:
Oprima
{W}
en la unidad base.
N
Para cambiar a la unidad base:
Oprima
{s}
en la unidad base.
Cómo usar dispositivos Bluetooth
Aparee usando el auricular.
Emparejamiento
Guía Rápida Española
88
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
Page 89
Preguntas frecuentes
Pregunta Causa y solución
¿Por qué aparece _?
L
El auricular está demasiado lejos de la unidad base. Acérquelo.
L
El adaptador para corriente de la unidad base no está conectado
correctamente. Conecte de nuevo el adaptador para corriente a la unidad
base.
L
El auricular no está registrado en la unidad base. Regístrelo.
1
Auricular:{MENU}(13)
2
Unidad base:
Oprima y mantenga oprimido {LOCATOR} durante
aproximadamente 5 segundos hasta que suene el tono de registro.
3
Auricular:
Oprima {OK}, y después espere hasta que suene un
pitido largo.
¿Por qué no es posible
emparejar un teléfono celular
con la unidad base?
L
Dependiendo de la compatibilidad del teléfono celular, es posible que no
pueda emparejarlo con la unidad base. Para obtener más información, visite
http://www.panasonic.com/link2cell
L
Confirme que la función de Bluetooth de su teléfono celular esté encendida.
Es posible que necesite encender esta función dependiendo de su teléfono
celular.
¿Por qué no se escucha el
tono de marcación? (línea
celular)
L
Asegúrese de que la luz indicadora de CELL 1 o CELL 2 se ilumine y de
que el teléfono celular esté conectado a la unidad base.
L
El teléfono celular no se ha emparejado con la unidad base. Empareje el
teléfono celular.
¿Cómo se incrementa el nivel
de volumen del auricular?
L
Oprima la tecla de volumen
{^}
repetidamente mientras habla.
¿Por qué hay ruido o se corta
la conversación?
L
Trate de reubicar la unidad base de forma que se minimice la distancia al
auricular.
L
Si ocurre el mismo problema aunque el auricular se encuentre enseguida
de la unidad base, llame a servicio a clientes de Panasonic al
1-800-211-PANA (1-800-211-7262).
¿Es posible añadir otro
auricular accesorio a mi
unidad base?
L
Sí, puede añadir hasta 6 auriculares (incluyendo los que se venden con
su unidad base) a una sola unidad base.
L
Para adquirir auriculares accesorios adicionales (KX-TGA680), visite
http://www.pstc.panasonic.com
o llame al 1-800-332-5368. Los usuarios TTY (usuarios con
impedimentos auditivos o del habla) pueden llamar al 1-866-605-1277.
¿Es posible mantener
cargando las baterías todo el
tiempo?
L
Puede dejar el auricular en la unidad base o el cargador en cualquier
momento. Esto no daña las baterías.
¿Cómo se contestan las
llamadas en espera (segunda
llamada)?
L
Oprima {CALL WAIT} cuando escuche el tono de llamada en espera.
Para obtener más información acerca del registro, visite
http://www.panasonic.com/RegisterYourHandset
(solo inglés)
Para obtener ayuda, visite http://www.panasonic.com/help (solo en inglés)
Guía Rápida Española
89
Page 90
Customer Services Directory (United States and Puerto Rico)
Obtain Product Information and Operating Assistance; locate your nearest
Dealer or Service Center; purchase Parts and Accessories; or make Customer
Service and Literature requests by visiting our Web Site at:
http://www.panasonic.com/help
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at: 1-800-211-PANA (1-800-211-7262),
Monday - Friday 9 am to 9 pm; Saturday - Sunday 10 am to 7 pm, EST.
TTY users (hearing or speech impaired users) can call 1-877-833-8855.
TTY users (hearing or speech impaired users) can call 1-866-605-1277.
Purchase Parts, Accessories and Instruction Books online for all
Panasonic Products by visiting our Web Site at:
http://www.pstc.panasonic.com
or, send your request by E-mail to:
npcparts@us.panasonic.com
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)
(Monday - Friday 9 am to 9 pm, EST.)
Panasonic Service and Technology Company
20421 84th Avenue South, Kent, WA 98032
(We Accept Visa, MasterCard, Discover Card, American Express, and
Personal Checks.)
Accessory Purchases (United States and Puerto Rico)
Appendix
Customer services
90
For assistance, please visit http://www.panasonic.com/help
Page 91
Warranty (For United States and Puerto Rico)
PANASONIC CORPORATION OF NORTH AMERICA
One Panasonic Way, Secaucus, New Jersey 07094
Limited Warranty Coverage
If your product does not work properly because of a defect in materials or workmanship,
Panasonic Corporation of North America (referred to as “the warrantor”) will, for the length
of the period indicated on the chart below, which starts with the date of original purchase
(“Limited Warranty period”), at its option either (a) repair your product with new or
refurbished parts, or (b) replace it with a new or a refurbished product. The decision to
repair or replace will be made by the warrantor.
Parts Labor
One (1) Year One (1) Year
During the “Labor” Limited Warranty period there will be no charge for labor. During the
“Parts” Limited Warranty period, there will be no charge for parts. You must mail-in your
product prepaid during the Limited Warranty period. This Limited Warranty excludes both
parts and labor for batteries, antennas, and cosmetic parts (cabinet). This Limited Warranty
only applies to products purchased and serviced in the United States or Puerto Rico. This
Limited Warranty is extended only to the original purchaser and only covers products
purchased as new.
For assistance in the continental United States and Puerto Rico in obtaining repairs please
ship the product prepaid to:
Panasonic Exchange Center,
4900 George McVay Drive, Suite B Door #12, McAllen, TX 78503
panacare@us.panasonic.com
Online Repair Request
To submit a new repair and for quick repair status visit our web site at
http://www.panasonic.com/help
When shipping the unit carefully pack in a padded shipping carton, include all
accessories, and send it prepaid. Include a letter detailing the complaint, a return
address and provide a day time phone number where you can be reached. P.O. Boxes
are not acceptable. Keep the tracking number for your records. A copy of valid registered
receipt is required under the 1 year parts and labor Limited Warranty.
For Limited Warranty service for headsets if a headset is included with this
product please follow instructions above.
IF REPAIR IS NEEDED DURING THE LIMITED WARRANTY PERIOD THE
PURCHASER WILL BE REQUIRED TO FURNISH A SALES
RECEIPT/PROOF OF PURCHASE INDICATING DATE OF PURCHASE,
AMOUNT PAID AND PLACE OF PURCHASE. CUSTOMER WILL BE
CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH
PROOF OF PURCHASE.
Panasonic Telephone Products
Limited Warranty
Ship-In Service
For assistance, please visit http://www.panasonic.com/help
Appendix
91
Page 92
Limited Warranty Limits And Exclusions
This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship,
and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty
ALSO DOES NOT COVER damages which occurred in shipment, or failures which are
caused by products not supplied by the warrantor, or failures which result from accidents,
misuse, abuse, neglect, bug infestation, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, power line surge, lightning damage, modification, introduction of sand,
humidity or liquids, commercial use such as hotel, office, restaurant, or other business or
rental use of the product, or service by anyone other than a Factory Service Center or
other Authorized Servicer, or damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED
WARRANTY COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR
ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY. (As examples, this
excludes damages for lost time, lost calls or messages, cost of having someone remove or
re-install an installed unit if applicable, travel to and from the servicer. The items listed are
not exclusive, but are for illustration only.) ALL EXPRESS AND IMPLIED WARRANTIES,
INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED TO THE
PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, or limitations on how long an implied warranty lasts, so the exclusions may not
apply to you.
This Limited Warranty gives you specific legal rights and you may also have other rights
which vary from state to state. If a problem with this product develops during or after the
Limited Warranty period, you may contact your dealer or Service Center. If the problem is
not handled to your satisfaction, then write to the warrantor’s Consumer Affairs
Department at the addresses listed for the warrantor.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY,
ARE YOUR RESPONSIBILITY.
L Carefully pack your unit, preferably in the original carton.
L Attach a letter, detailing the symptom.
L Send the unit to Panasonic Exchange Center, prepaid and adequately insured.
L Do not send your unit to Panasonic Corporation of North America listed on the back
cover or to executive or regional sales offices. These locations do not repair consumer
products.
When you ship the product
Appendix
92
For assistance, please visit http://www.panasonic.com/help
Page 93
Index
# 3
-way conference: 24, 30
A Additional handset: 47
Alarm: 44
Answering calls: 22, 29
Answering system
Call screening: 56
Erasing messages: 57, 58, 61
Greeting message: 56
Greeting only: 62
Listening to messages: 57, 58, 60
New message alerting: 59
Number of rings: 61
Recording time: 62
Remote access code: 60
Remote operation: 60
Ring count: 61
Toll saver: 61
Turning on/off: 56
Auto talk: 22, 41
B Battery: 11
Belt clip: 14
Bluetooth wireless technology
Cellular phone (Link to cell): 17
Headset: 53
Phonebook transfer: 52
Booster (Clarity booster): 23
C Call block: 45
First ring: 46
Call share: 24, 30, 41
Call waiting: 23, 29
Call Waiting Caller ID: 23
Caller ID number auto edit: 40, 43, 50
Caller ID service: 48
Caller list: 49
Caller list edit: 50
Cellular calls: 21, 28
Cellular phone
Pairing: 17
Unpairing: 17
Chain dial: 34
CID (Caller ID): 49
Conference calls: 65
Control type: 13
Customer support: 41, 43
D Date and time: 16
Dialing mode: 16
Direct command code: 36
Display
C
ontrast: 40, 43
Language: 16
E Eco mode: 12
Equalizer: 24
Error messages: 68
F Flash: 23, 29, 41
G Groups: 32, 49
H Handset
Deregistration: 47
Locator: 65
Name: 45
Registration: 47
Hold: 22, 29
I Intercom: 65
K Key detector: 40, 41
Key tone: 40
L Landline calls: 21, 28
Line mode: 41
Link to cell
Area code: 20
Auto connection: 18
Cellular line only mode: 19
Cellular line selection: 20
Connection: 19
Ring as cell mode: 18
Select unit to ring: 18
Text message alert: 53
M Making calls: 21, 28
Missed calls: 48
Mute: 23, 29
N Noise reduction: 24
P Pause: 22, 28
Phonebook: 32
PIN: 20
Power failure (power back-up
operation): 25
R Redialing: 21, 28
Ringer ID: 49
Ringer tone: 38, 39, 49
Rotary/pulse service: 23
S Silent mode: 44
Speed dial: 35
SP-PHONE (Speakerphone): 21
T Talking Caller ID: 48
Temporary tone dialing: 23, 30
Time adjustment: 40
Transferring calls: 65
Troubleshooting: 69
TTY: 90
Index
93
Page 94
Index
U U
SB charging: 14
V VM (Voice mail): 63
Voice guidance language: 16
Voice mail: 62, 63
Volume
Receiver: 21
Ringer (Base unit): 29, 38, 42
Ringer (Handset): 22, 38, 39
Speaker: 21, 28
W Wall mounting: 67
94
Page 95
Notes
95
Page 96
1 Reconnect AC adaptor to the base unit.
2 Check if telephone line cord is connected.
3 Use rechargeable Ni-MH batteries.
(Alkaline/Manganese/Ni-Cd batteries CANNOT be used.)
4 Read troubleshooting page in the Operating Instructions.
If your product is not working properly. . .
IMPORTANT!
Visit our Web site: http://www.panasonic.com/help
L
FAQ and troubleshooting hints are available.
For your future reference
Attach your purchase receipt here.
One Panasonic Way, Secaucus, New Jersey 07094
W
e recommend keeping a record of the following information to assist with any repair under
warranty.
Serial No. Date of purchase
(found on the bottom of the base unit)
Name and address of dealer
© Panasonic System Networks Co., Ltd. 2012
Printed in China
PNQX5764ZA TT1212MG1122 (E)
*PNQX5764ZA*
*PNQX5764ZA*
Loading...
