PEG1104001CE
Version:1101
Service Manual
Super Quiet Ventilating Fan/Light Combination
WhisperSense
(North America Market)
TM
FV-08VQC5
FV-11VQC5
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individuals of potential
dangers in attempting to service a product. Products powered by electricity should be serviced or repaired
only by experienced professional technicians. Any attempt to service or repair the product or products dealt
with in this service information by anyone else could result in serious injury or death.
FV-08VQCL5
FV-11VQCL5
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are
marked by in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential
that these critical parts should be replaced with manufacturer's specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission of manufacture.
We suggest to handle such parts after the static electricity prevention.
It is forbidden to touch the PCB parts by bare hands during the repairing process.
CONTENTS
1 Specifications
2 Parts Identification
3 Wiring Diagram
4 Parts List
PAGE
1
2~5
6
7~10
Page 2
1.Specifications
FV-08VQC5
FV-11VQC5
FV-08VQCL5
FV-11VQCL5
1
Page 3
2. Parts Identification
FV-08VQC5
FV-11VQC5
4
7
D
8
6
5
B
Details Of Wiring Section
1
A
2
B
(2pcs)
A
B
A
28
C
(2pcs)
3
(3pcs)
C
(4pcs)
Cord Clip
B
11
Capacitor Box
10
C
(6pcs)
Section
(Motor Lead)
(Motor Lead)
(Motor Lead)
Red
White
White
30
(4pcs)
Black
(Motor Lead)
12
Motor Unit
9
29
White
(Cord)
Binder Tie
31
Black
(Cord)
Capacitor Box Section
G
(2pcs)
19
21
22
(2pcs)
Louver Assy Section
23
20
14
A
(3pcs)
Cord Clip
(3pcs)
C
(3pcs)
18
E
(2pcs)
13
F
C
(2pcs)
C
16
C
15
17
(4pcs)
24
25
Main PCB Section
H
26
C
27
52
2
Page 4
2. Parts Identification
32
(32)
33
34
44
46
41
42
43
47
FV-08VQC5
FV-11VQC5
40
45
35
36
LISTEN
A375682G8
8B68
US
FAN
C
37
mm
Inch
1
_
2
2
60
2
50
40
1
_
1
2
30
1
20
1
_
2
10
39
Main Labels
(Stuck On Frame Assy)
48
49
50
38
51
Main Packing Materials
3
Page 5
2. Parts Identification
FV-08VQCL5
FV-11VQCL5
4
7
D
8
56
5
6
B
Details Of Wiring Section
1
A
2
B
(2pcs)
A
B
A
32
C
(2pcs)
3
(3pcs)
C
(4pcs)
Cord Clip
B
11
Capacitor Box
10
C
(6pcs)
Section
(Motor Lead)
(Motor Lead)
(Motor Lead)
Red
White
White
34
(4pcs)
Black
(Motor Lead)
12
Motor Unit
9
33
White
(Cord)
Binder Tie
35
Black
(Cord)
Capacitor Box Section
20
22
24
25
26
27
Grille Assy Section
G
23
13
14
C
H
(4pcs)
30
28
21
A
(3pcs)
Cord Clip
(3pcs)
15
29
C
31
Main PCB Section
C
(3pcs)
19
(2pcs)
E
16
17
C
C
(2pcs)
18
F
4
Page 6
2. Parts Identification
36
(36)
37
38
48
50
FV-08VQCL5
FV-11VQCL5
45
46
47
51
44
49
39
40
LISTEN
A375682G8
8B68
US
FAN
C
41
mm
Inch
1
_
2
2
60
2
50
40
1
_
1
2
30
1
20
1
_
2
10
43
Main Labels
(Stuck On Frame Assy)
52
53
54
42
55
Main Packing Materials
5
Page 7
3. Wiring Diagram
FV-08VQC5
FV-11VQC5
FV-08VQCL5
FV-11VQCL5
6
Page 8
No. Part No. Part Name Q'ty Remark
1 FFV1600111S Frame Assembly 1
2 FFV0420027S Bracket Cover 1
3 FFV0800001S Casing Support 3
4 FFV0000120S Adapter Assembly 1
5 FFV0900052S Connector Plate 1
6 FFV0900049S Connector Assy V 1
7 FFV3402103S Earth Lead Wire Assy 1
8 FFV2800012S Junction Cover 1
9 FFV0760028S Capacitor Box 1
10 FFV3702214S Motor Assembly 1
(10) FFV3702215S Motor Assembly 1
11 FFV3730089S Motor Support 1
12 FFV0400103S Blade 1
13 FFV7020021S Nut 1
14 FFV0790077S Casing 1
15 FFV4300131S Orifice 1
16 FFV2220053S Humid Sensor Assembly 1 Not Include Humid Sensor Lead Wire
17 FFV5530065S Switch Assembly 1
18 FFV3420031S Grille Unit 1 Not Include Sensor Box Assy
19 FFV2520025S Insulation Plate 1
20 FFV5500028S Sensor Box Assembly 1
21 FFV5560036S Spring Stopper 1
22 FFV5560017S Spring 2
23 FFV2220051S Sensor Cover 1
24 FFV3740021S Main PCB Box 1
25 FFV3740022S Main PCB 1
26 FFV3700330S Motor Lead Wire 1
27 FFV3740023S Main PCB Cover 1
28 FFV3702241S Motor Unit 1
(28) FFV3702242S Motor Unit 1
29 FFV0750203S Capacitor 1
(29) FFV0750206S Capacitor 1
30 FFV0900024S Connector 4
31 FFV4620077S Power Lead Wire 1
32 FFV4020685S Name Plate 1
(32) FFV4020686S Name Plate 1
33 FFV1320001S ESP Mark 1
34 FFV0810010S Warning Label 1
35 FFV2260003S UL Mark 1
36 FFV2260002S HVI Mark 1
37 FFV6730045S Warning Label 1
38 FFV5720015S Scale Tape 1
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
4. Parts List
FV-08VQC5
FV-11VQC5
7
Page 9
No. Part No. Part Name Q'ty Remark
39 FFV6730050S Wiring Label 1
40 FFV5710023S
Suspension Bracket Ⅰ
1
41 FFV5710024S
Suspension Bracket Ⅱ
1
42 FFV5710018S
Suspension Bracket Ⅳ
1
43 FFV5710019S
Suspension Bracket Ⅲ
1
44 FFV2540120S Installation Instruction 1 English,For CA Market/USA Market
45 FFV2540121S Installation Instruction 1 French,For USA Market
(45) FFV2540122S Installation Instruction 1 Spanish,For CA Market
46 FFV0010200S Accessory A 1
47 FFV4710210S Grille Case Assembly 1
48 FFV4710322S Right Pad 1
49 FFV4710323S Left Pad 1
50 FFV4710330S Sensor Pad 1
51 FFV9000983S Packing Case Assy 1
(51) FFV9000984S Packing Case Assy 1
52 FFV2220054S Humid Sensor Lead Wire 1
A FFV7000065S Bind Screw 6
B FFV7000108S Truss Tap Screw 5
C FFV7000089S Truss Tap Screw 20
D FFV7000168S Screw Assembly 1 Include Spring Washer&P.R Washer
E FFV7000195S Pan Tap Screw 2
F FFV7000074S Truss Tap Screw 1
G FFV7000140S Pan Tap Screw 2
H FFV7000145S Truss Tap Screw 4
!
!
4. Parts List
FV-08VQC5
FV-11VQC5
8
Page 10
No. Part No. Part Name Q'ty Remark
1 FFV1600111S Frame Assembly 1
2 FFV0420027S Bracket Cover 1
3 FFV0800001S Casing Support 3
4 FFV0000121S Adapter Assembly 1
5 FFV0900048S Connector Plate 1
6 FFV0900049S Connector Assy V 1
7 FFV3402103S Earth Lead Wire Assy 1
8 FFV2800012S Junction Cover 1
9 FFV0760028S Capacitor Box 1
10 FFV3702217S Motor Assembly 1
(10) FFV3702215S Motor Assembly 1
11 FFV3730086S Motor Support 1
12 FFV0400103S Blade 1
13 FFV7020021S Nut 1
14 FFV0790077S Casing 1
15 FFV2220054S Humid Sensor Lead Wire 1
16 FFV2220053S Humid Sensor Assembly 1 Not Include Humid Sensor Lead Wire
17 FFV5530065S Switch Assembly 1
18 FFV3470003S Ballast Assembly 1
19 FFV3420033S Grille Unit 1 Not Include Sensor Box Assy
20 FFV3420025S Light Cover Assembly 1
21 FFV3420026S Lamp Holder Section 1
22 FFV3420027S Fluorescent Lamp 1
23 FFV3420005S Night Lamp 1
24 FFV5500028S Sensor Box Assembly 1
25 FFV3420030S Grille Section 1 Include Sensor Cover&Lamp Cover
26 FFV2220051S Sensor Cover 1
27 FFV3420029S Lamp Cover 1
28 FFV3740021S Main PCB Box 1
29 FFV3740022S Main PCB 1
30 FFV3700330S Motor Lead Wire 1
31 FFV3740023S Main PCB Cover 1
32 FFV3702243S Motor Unit 1
(32) FFV3702244S Motor Unit 1
33 FFV0750203S Capacitor 1
(33) FFV0750204S Capacitor 1
34 FFV0900024S Connector 4
35 FFV4620077S Power Lead Wire 1
36 FFV4020687S Name Plate 1
(36) FFV4020688S Name Plate 1
37 FFV1320001S ESP Mark 1
38 FFV0810010S Warning Label 1
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
!
4. Parts List
FV-08VQCL5
FV-11VQCL5
9
Page 11
No. Part No. Part Name Q'ty Remark
39 FFV2260003S UL Mark 1
40 FFV2260002S HVI Mark 1
41 FFV6730045S Warning Label 1
42 FFV5720015S Scale Tape 1
43 FFV6730051S Wiring Label 1
44 FFV5710023S
Suspension Bracket Ⅰ
1
45 FFV5710024S
Suspension Bracket Ⅱ
1
46 FFV5710018S
Suspension Bracket Ⅳ
1
47 FFV5710019S
Suspension Bracket Ⅲ
1
48 FFV2540123S Installation Instruction 1 English,For CA Market/USA Market
49 FFV2540124S Installation Instruction 1 French,For USA Market
(49) FFV2540125S Installation Instruction 1 Spanish,For CA Market
50 FFV0010200S Accessory A 1
51 FFV4710210S Grille Case Assembly 1
52 FFV4710322S Right Pad 1
53 FFV4710323S Left Pad 1
54 FFV4710330S Sensor Pad 1
55 FFV9000985S Packing Case Assy 1
(55) FFV9000986S Packing Case Assy 1
56 FFV0900039S Connector Assy L 1
A FFV7000065S Bind Screw 6
B FFV7000108S Truss Tap Screw 5
C FFV7000089S Truss Tap Screw 20
D FFV7000168S Screw Assembly 1 Include Spring Washer&P.R Washer
E FFV7000195S Pan Tap Screw 2
F FFV7000074S Truss Tap Screw 1
G FFV7000079S Pan Tap Screw 1
H FFV7000145S Truss Tap Screw 4
!
!
4. Parts List
FV-08VQCL5
FV-11VQCL5
10
