Basic Owner’s Manual
Digital Camera
Model No. DMC-ZS20
DMC-ZS19
Before connecting, operating or adjusting this product,
please read the instructions completely.
More detailed instructions on the operation of
this camera are contained in “Owner’s Manual
for advanced features (PDF format)” in the
supplied disc. Install it on your PC to read it.
For USA and Puerto Rico assistance, please call: 1-800-211-PANA(7262) or,
contact us via the web at: http://www.panasonic.com/contactinfo
P
VQT4B72
M0112KZ0
Dear Customer,
Date of Purchase Dealer Phone No.
Dealer Purchased From Model No.
Dealer Address Serial No.
Thank you for choosing Panasonic!
You have purchased one of the most sophisticated and reliable products
on the market today. Used properly, we’re sure it will bring you and your
family years of enjoyment. Please take time to fill in the information below.
The serial number is on the tag located on the underside of your camera.
Be sure to retain this manual as your convenient camera information
source.
Please note that the actual controls and components, menu items, etc.
of your Digital Camera may look somewhat different from those shown in
the illustrations in this Owner’s Manual.
Carefully observe copyright laws.
• Recording of pre-recorded tapes or discs or other published or broadcast material
for purposes other than your own private use may infringe copyright laws. Even
for the purpose of private use, recording of certain material may be restricted.
A lithium ion battery that is recyclable powers
the product you have purchased. Please call
1-800-8-BATTERY for information on how to recycle
this battery.
2 VQT4B72 (ENG)
Information for Your Safety
WARNING:
To reduce the risk of fire, electric shock or product damage,
• Do not expose this unit to rain, moisture, dripping or splashing.
• Do not place objects filled with liquids, such as vases, on this
unit.
• Use only the recommended accessories.
• Do not remove covers.
• Do not repair this unit by yourself. Refer servicing to qualified
service personnel.
The socket outlet shall be installed near the equipment and shall be
easily accessible.
■
Product identification marking
Product Location
Digital camera Bottom
(ENG) VQT4B72 3
FCC Note:
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: To assure continued compliance, follow the attached
installation instructions and use only shielded interface
cables with ferrite core when connecting to computer or
peripheral devices.
Any changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
this equipment.
Declaration of Conformity
Trade Name: Panasonic
Model No.: DMC-ZS20 / DMC-ZS19
Responsible Party: Panasonic Corporation of
Support Contact: Panasonic Consumer
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
North America
One Panasonic Way,
Secaucus, NJ 07094
Marketing Company of
North America
1-800-211-PANA (7262)
DMC-ZS20
DMC-ZS19
4 VQT4B72 (ENG)
■
About the battery pack
CAUTION
Battery pack (Lithium ion battery pack)
• Use the specified unit to recharge the battery pack.
• Do not use the battery pack with equipment other than the specified unit.
• Do not get dirt, sand, liquids, or other foreign matter on the terminals.
• Do not touch the plug terminals (+ and −) with metal objects.
• Do not disassemble, remodel, heat or throw into fire.
If any electrolyte should come into contact with your hands or clothes,
wash it off thoroughly with water.
If any electrolyte should come into contact with your eyes, never rub
the eyes. Rinse eyes thoroughly with water, and then consult a doctor.
CAUTION
• Danger of explosion if battery is incorrectly replaced. Replace only
with the type recommended by the manufacturer.
• When disposing the batteries, please contact your local authorities or
dealer and ask for the correct method of disposal.
• Do not heat or expose to flame.
• Do not leave the battery(ies) in a car exposed to direct sunlight for a
long period of time with doors and windows closed.
Warning
Risk of fire, explosion and burns. Do not disassemble, heat above
60 °C (140 °F) or incinerate.
(ENG) VQT4B72 5
■
About the AC adaptor (supplied)
CAUTION!
To reduce the risk of fire, electric shock or product damage,
• Do not install or place this unit in a bookcase, built-in cabinet or in
another confined space. Ensure this unit is well ventilated.
AC adaptor
This AC adaptor operates on AC between 110V and 240V.
But
• In the U.S.A. and Canada, the AC adaptor must be connected to a
120V AC power supply only.
• When connecting to an AC supply outside of the U.S.A. or Canada,
use a plug adaptor to suit the AC outlet configuration.
6 VQT4B72 (ENG)
■
Cautions for Use
• Do not use any other USB connection cables except the supplied one.
• Always use a genuine Panasonic HDMI mini cable
(RP-CDHM15, RP-CDHM30: optional).
Part numbers: RP-CDHM15 (1.5 m) (4.9 feet), RP-CDHM30 (3.0 m) (9.8 feet)
• Always use a genuine Panasonic AV cable (DMW-AVC1: optional).
Keep this unit as far away as possible from electromagnetic equipment (such
as microwave ovens, TVs, video games etc.).
• If you use this unit on top of or near a TV, the pictures and/or sound on this unit
may be disrupted by electromagnetic wave radiation.
• Do not use this unit near cell phones because doing so may result in noise
adversely affecting the pictures and/or sound.
• Recorded data may be damaged, or pictures may be distorted, by strong
magnetic fields created by speakers or large motors.
• Electromagnetic wave radiation generated by microprocessors may adversely
affect this unit, disturbing the pictures and/or sound.
• If this unit is adversely affected by electromagnetic equipment and stops
functioning properly, turn this unit off and remove the battery or disconnect AC
adaptor (supplied). Then reinsert the battery or reconnect AC adaptor and turn
this unit on.
Do not use this unit near radio transmitters or high-voltage lines.
• If you record near radio transmitters or high-voltage lines, the recorded pictures
and/or sound may be adversely affected.
For information about the software used for this product, press [MENU/SET] and
select [Setup] to display [Version Disp.] before pressing [MENU/SET] again.
This product is licensed under the AVC patent portfolio license for the personal
and non-commercial use of a consumer to (i) encode video in compliance with
the AVC Standard (“AVC Video”) and/or (ii) decode AVC Video that was encoded
by a consumer engaged in a personal and non-commercial activity and/or was
obtained from a video provider licensed to provide AVC Video. No license is
granted or shall be implied for any other use. Additional information may be
obtained from MPEG LA, LLC.
See http://www.mpegla.com.
(ENG) VQT4B72 7
Contents
Information for Your Safety .......3
Before use ...................................9
Standard accessories ..............10
Names and Functions of
Main Parts .................................11
Touch operations ......................12
Inserting and removing the
card (optional)/the battery .......13
Charging the battery ................14
Setting the clock .......................15
Setting the menu ......................17
Taking pictures .........................18
Taking motion pictures ............19
Viewing your pictures
[Normal Play] ............................20
Deleting pictures ......................20
When operation or other information is more or less the same between models,
●
DMC-ZS20 is used as examples for the instructions provided in this manual.
The operations, procedures, or functions that differ among models are indicated
●
separately, together with the relevant model number.
(Example)
DMC-ZS20
DMC-ZS19
GPS and map functions
DMC-ZS20
Reading the Owner’s Manual
(PDF format) ..............................25
Installing supplied software ....26
Specifications ...........................27
Digital Camera Accessory
System .......................................30
Digital Camera Accessory
Order Form ................................31
Limited Warranty
(ONLY FOR U.S.A. AND
PUERTO RICO) .........................32
....................................21
8 VQT4B72 (ENG)
Before use
■
Camera handling
Keep the camera away from excessive vibration, force, or pressure.
●
The camera is not dust resistant, splash resistant, or waterproof.
●
Avoid using the camera in places with excessive dust or sand, or
where water can come into contact with the camera.
■
Condensation (When the lens or the LCD monitor is fogged up)
Condensation may occur when the camera is exposed to sudden
●
changes of temperature or humidity. Avoid these conditions, which
may make the lens or LCD monitor dirty, cause mold, or damage the
camera.
If condensation does occur, turn off the camera and wait about two
●
hours before using it. Once the camera adjusts to the surrounding
temperature, the fogging will clear naturally.
(ENG) VQT4B72 9
Standard accessories
Check that all the accessories are supplied before using the camera. Part
numbers are as of January 2012.
Battery pack
DMW-BCG10PP
• Charge the battery
before use.
Battery pack is indicated as
battery pack or battery in the
text.
AC adaptor
VSK0768
Hand strap
VFC4297
USB connection
cable
K1HY08YY0025
• SD Memory Card, SDHC Memory Card and SDXC Memory Card are
indicated as card in the text.
• Memory cards are optional. You can record or play back pictures on the
built-in memory when you are not using a card.
• For information about optional accessories, refer to the “Digital Camera
Accessory System”.
• If any accessories are lost, customers should contact Panasonic’s parts
department at 1 800 833-9626 for further information about obtaining
replacement parts.
• Please dispose of all packaging appropriately.
• Keep small parts in a safe place out of the reach of children.
• The illustrations and screens in this manual may differ from the actual
product.
DMC-ZS20
DVD
VFF0974
• Software:
Use it to install the software
on your PC.
• Map data
• Owner’s Manual for
advanced features
DVD is indicated as disc in
the text.
DMC-ZS19
CD-ROM
VFF0999
• Software:
Use it to install the software
on your PC.
• Owner’s Manual for
advanced features
CD-ROM is indicated as disc
in the text.
10 VQT4B72 (ENG)
Names and Functions of Main Parts
Camera ON/OFF switch
Shutter button
Mode dial
Flash
Self-timer indicator/AF Assist Lamp
Lens barrel
Lens
Zoom lever
DMC-ZS20
GPS status indicator
[EXPOSURE] button
DMC-ZS20
[MAP] button
LCD monitor
Cursor buttons
[DISP.] button
[Q.MENU]/[
/ ] (Delete/Cancel)
button
We recommend using the
supplied hand strap to
avoid dropping the camera.
DMC-ZS20
Built-in GPS antenna
Microphone
Speaker
Motion picture button
REC/PLAY switch
[HDMI] socket
[AV OUT/DIGITAL]
socket
[MENU/SET] button
Charging lamp
Tripod receptacle
• Ensure that the tripod is stable.
Card/Battery door
Release lever
(ENG) VQT4B72 11
Touch operations
This camera’s touch screen senses pressure that is applied to the screen.
Touch
To “touch” is to press the touch screen and then pull
the finger back again.
Touching is used to select icons or pictures, among other
actions.
• Touch an icon near its center. If multiple icons are touched
simultaneously, the camera may not operate normally.
Drag
To “drag” is to touch and slide your finger across the
touch screen surface.
Dragging (sliding your finger across the screen) is used
to scroll the pictures or change the range of the pictures
displayed.
If the type of sheet made to protect LCD screens that are available in
●
the market is to be used, observe the precautions that are contained
with the sheet. (Some types of protective sheets may impair the
screen’s appearance and ease of operation.)
If the camera is used with a protective sheet available on the market
●
attached to its screen or if the screen is not very responsive, touch the
screen with a little more pressure.
If your hand is pressed against the touch screen when holding the
●
camera, the touch screen will not work properly.
Do not press on the LCD monitor with hard pointed tips, such as ball
●
point pens.
Do not press the touch screen with your fingernails.
●
Clean the LCD monitor with a soft, dry cloth if there are fingerprints or
●
other kinds of dirt on it.
12 VQT4B72 (ENG)
Inserting and removing the card (optional)/ the battery
To charge the battery, insert it into the camera.
Set the camera ON/OFF switch
to OFF and slide the release
lever ( ) to [OPEN] before
opening the card/battery door
Insert the battery and card,
making sure that their
orientation is correct
• Battery:
• Card: Insert all the way firmly until it
Insert all the way firmly until a
locking sound is heard, and check
that it is locked by lever ( ).
clicks.
Close the card/battery door
Slide the release lever to the [LOCK]
position.
■
To remove
• To remove battery:
Move lever in direction of arrow.
Lever
• To remove card:
Push the card until it clicks,
then pull the card out.
[OPEN] [LOCK]
Do not touch the
terminals on the
back of the card.
Always use genuine Panasonic batteries (DMW-BCG10PP).
●
If you use other batteries, we cannot guarantee the quality of this
●
product.
Keep the Memory Card out of reach of children to prevent swallowing.
●
We recommend using a Panasonic Memory card.
●
(ENG) VQT4B72 13
Charging the battery
• The battery is not charged when the camera is shipped. Charge
the battery before use.
• Charge the battery with the AC adaptor (supplied) indoors (10 °C
to 30 °C (50 °F to 86 °F)).
• Always use the dedicated AC adaptor (supplied), USB connection
cable (supplied), and battery.
• To charge the battery, insert it into the camera.
• Make sure that the camera is turned off.
Connect the AC adaptor ( ) (supplied) and the
camera using the USB connection cable ( )
(supplied), and plug the AC adaptor ( ) (supplied)
into the electrical outlet
To the electrical outlet
Do not use any other USB connection cables except the supplied one.
●
Doing so may cause malfunction of the camera.
Do not use any other AC adaptors except the supplied one.
●
■
Charging lamp ( )
On: Charging in progress (approx. 260 min. if fully depleted)
Off: Charging stops
■
About batteries that you can use with this unit
The battery that can be used with this unit is DMW-BCG10PP.
14 VQT4B72 (ENG)
Setting the clock
The clock is not set when the camera is shipped.
Set REC/PLAY switch to before turning the camera on.
Turn the camera on ( )
Press [MENU/SET] ( )
Press to select the items
(year, month, day, hour, minute,
display order or time display
format), and press to set
Press [MENU/SET] to set
Confirm the setting and press [MENU/SET]
• To return to the previous screen, press [ / ].
DMC-ZS20
Go to step .
DMC-ZS19
The clock setting procedure is completed with step .
Press to select [Yes] and press [MENU/SET]
if automatically correcting time of day using the
GPS function
• To manually set date and time →select [No].
• When you select automatic time adjustment using the GPS
function, [GPS Setting] is set to [ON].
(ENG) VQT4B72 15
Setting the clock
When [Please set the home area] is displayed,
press [MENU/SET]
Press to set your home area
and press [MENU/SET]
The current time and home area are set.
■
To change the time setting
Select [Clock Set] from [Rec] or [Setup] menu, perform and .
16 VQT4B72 (ENG)
Setting the menu
Refer to the following procedures to operate the menus.
Example: Setting [AF Mode] from to in the [Program AE] Mode
Press [MENU/SET] to display the menu
Switching to the [Rec] menu
Use cursor button to select [Rec] and
press [MENU/SET].
• The menu type can also be selected by
touch operations.
Press to select [AF Mode]
and then press [MENU/SET]
• Depending on the item, its setting may not
appear or it may be displayed in a different
way.
Press to select and then
press [MENU/SET] to set
Press [ / ] several times to
close the menu
(ENG) VQT4B72 17
Taking pictures
Turn the camera on ( )
Slide the REC/PLAY switch ( )
to
Set to the desired recording mode
( )
■
Recording mode
Take pictures with automatic settings.
The subjects are recorded using your own settings.
The shutter speed is automatically determined by the aperture value you
set.
The aperture value is automatically determined by the shutter speed you
set.
The exposure is adjusted by the aperture value and the shutter speed
that are manually adjusted.
Use this mode to take pictures with previously registered setting.
Record 3D still pictures.
Take pictures according to the scene.
Take pictures while confirming the picture effect.
Take a picture
Shutter button
Press halfway
(press lightly and focus)
18 VQT4B72 (ENG)
Press fully
(press the button
all the way to record)
Taking motion pictures
Recording mode:
You can record motion pictures with audio (stereo). Zoom can also be
used during recording.
Slide the REC/PLAY switch ( )
to
Press the motion picture button ( )
to start recording
Press the motion picture button ( )
again to end recording
Remaining recording time (approx.)
Elapsed recording time
We recommend you use a battery with sufficient battery power when
●
recording motion pictures.
Immediately release the motion picture button after pressing it all the
●
way.
You can continuously record a motion picture in [MP4] for up to
●
29 minutes 59 seconds or approx. 4 GB. In this case, you can
continuously record a motion picture in [FHD] for up to approx.
27 minutes 12 seconds.
If [Rec Quality] of [AVCHD] motion pictures is set to [GPH]
●
[PSH], [GFS]
picture for up to 29 minutes 59 seconds.
If the surrounding temperature is high, or a motion picture is
●
recorded continuously, is displayed and recording may be
stopped halfway through to protect the camera. (Only when [Rec
Quality] is set to [GPH]
You can record a motion picture to the built-in memory only in [MP4]
●
using the [VGA] setting.
DMC-ZS20
or [FSH], you can continuously record a motion
DMC-ZS20
DMC-ZS19
, [PSH], [GFS]
DMC-ZS20
DMC-ZS20
or [FSH])
(ENG) VQT4B72 19
,
Viewing your pictures
[Normal Play]
Slide the REC/PLAY switch ( )
to
Drag your finger
across the screen,
and select the
picture to be played
back
To play back a motion picture, touch or press after selecting a
●
picture.
You can print pictures by connecting a camera to your computer or
●
printer, or by giving an SD card to a shop assistant at a photo shop.
Deleting pictures
Deleted pictures cannot be recovered.
Press [ / ] ( ) to delete the
displayed picture
Press to select [Yes] and then
press [MENU/SET] ( )
20 VQT4B72 (ENG)
GPS and map functions
Before using the camera, be sure to read “License Agreement for Place
Name and Map Data” (Owner’s Manual for advanced features).
This camera can record the location information of a place where a
picture was taken on the pictures. The camera can also automatically
adjust the time or display a place where a picture was taken on a map
during playback.
Your Panasonic Lumix digital still camera is GPS-equipped which can
automatically record the precise location coordinates of where the photo
was taken. The specific physical address of this location can easily be
derived from this information.
If you upload such “geotagged” photos to the Internet, a social networking
site or any other electronic media, the precise location of where the photo
was taken will remain embedded in the photo and can be viewed by
others.
Therefore, when taking digital still photos, care should be taken in
determining whether you wish to have the GPS feature enabled or
disabled.
DMC-ZS20
(ENG) VQT4B72 21
GPS and map functions
DMC-ZS20
Using the GPS function to execute positioning
Press [MENU/SET] ( )
Use cursor button to select
[GPS] menu and press
[MENU/SET]
Use cursor button to select
[GPS Setting] and press
[MENU/SET]
Use cursor button to select [ON] and press
[MENU/SET]
• A message appears on the screen. After confirming the message,
press [MENU/SET].
■
When [GPS Setting] is [ON], the GPS function works even if the
camera’s power is off.
• Electromagnetic waves from the camera can affect instruments and
meters. During takeoff and landing of airplanes or in other restricted
areas, set [GPS Setting] to [OFF] or set [Airplane Mode] to [ON], and
then turn off the camera.
• When [GPS Setting] is [ON] and [Airplane Mode] is [OFF], power will
drain from the battery even if the camera is turned OFF.
22 VQT4B72 (ENG)
■
●
Positioning will take time in environments where it is difficult to
receive the signals from the GPS satellites. For details, refer to
“Using the GPS function to record the location of a picture” (Owner’s
Manual for advanced features).
●
Even if GPS reception is good, it will take approx. 2 to 3 minutes
to successfully execute positioning under the following conditions;
when positioning is executed for the first time, or when positioning is
executed after the camera is turned off with the [GPS Setting] set to
[OFF] or [Airplane Mode] set to [ON], and then turned on again.
Displaying the status and result of positioning
The icons that indicate the status and result of positioning will
appear on the LCD monitor. When the camera successfully executes
positioning, it records the current location and displays the place name
information on the screen.
GPS reception icon
Positioning
executed
successfully
Place name
information
The same number of icons as the
number of the GPS satellites (from
which radio signals are successfully
received) stop flashing and light (blue).
If the three bars of the GPS reception
icon do not light and the icon turns
off, it means that positioning was
unsuccessful.
Positioning result icons
(Time elapsed after successful positioning)
(minute)
: No positioning information has been
acquired.
(ENG) VQT4B72 23
GPS and map functions
DMC-ZS20
Confirming the place where you took a picture using a map
You can display a map showing the location where a picture was taken or
your current location.
If you copy the map data stored on the supplied DVD to a memory
●
card, you can display more detailed maps. For details, refer to “Using
the map data on the DVD (supplied)” (Owner’s Manual for advanced
features).
Display the pictures in playback
mode
• The is displayed during playback for
pictures that are recorded with location
and place name information.
Press [MAP] button ( )
A map of the place where you
took the picture will appear.
Touch the +/- button to enlarge or reduce the map
size.
(You can also enlarge or reduce the map size
using the zoom lever.)
Map scale level
(The levels that can be displayed vary depending on the region)
• You can drag the screen or press the cursor button to operate the
display location of a map.
• When you press the [ / ] button, it will return to the previous
display.
24 VQT4B72 (ENG)
Reading the Owner’s Manual
More detailed instructions on the operation of this camera are contained
in “Owner’s Manual for advanced features (PDF format)” in the supplied
disc. Install it on your PC to read it.
To read the supplied DVD, use a DVD drive with single-sided dual layer
recording support.
■
For Windows
DMC-ZS20
(PDF format)
Turn the PC on and insert the disc containing the
Owner’s Manual (supplied)
Click the “Owner’s Manual”
Select the desired language
and then click “Owner’s
Manual” to install
To return to the install menu.
Double-click the “Owner’s
Manual” shortcut icon on the
desktop
■
When the Owner’s Manual (PDF format) will not open
You will need Adobe Acrobat Reader 5.0 or later, or Adobe Reader 7.0
or later to browse or print the Owner’s Manual (PDF format).
Insert the disc containing the Owner’s Manual (supplied), click and
then follow the messages on the screen to install.
Compatible OS: Windows XP SP3 / Windows Vista SP2 / Windows 7
• You can download and install a version of Adobe Reader that you can
use with your OS from the following Website.
http://get.adobe.com/reader/otherversions/
(ENG) VQT4B72 25
Installing supplied software
This software allows you to acquire pictures to the PC, and also
categorize these acquired pictures by their recording date or the model
name of the camera used.
• Before inserting the disc, close all running applications.
Check the environment of your PC
Operating environment of PHOTOfunSTUDIO 8.1 PE
OS
CPU
Display
RAM
Free hard disk space 450 MB or more for installing software
• Refer to the Operating Instructions of “PHOTOfunSTUDIO” (PDF)
for further information about the operating environment.
Insert the disc with the supplied software
When you insert the supplied disc, the install menu will start.
Click on the [Applications] on the install menu
Click on the [Recommended Installation]
• Proceed with installation according to messages appearing on the
screen.
The software compatible with your PC will be installed.
●
– PHOTOfunSTUDIO (Windows XP/Vista/7)
– LoiLoScope 30-day full-trial version (Windows XP/Vista/7)
(This will only install a shortcut to the trial version download site.)
– LUMIX Map Tool (Windows XP/Vista/7, Mac OS X)
PHOTOfunSTUDIO is not compatible with Mac.
●
Windows XP (32 bit) SP3
Windows Vista (32 bit) SP2
Windows 7 (32 bit/64 bit) and SP1
Windows XP Pentium III 500 MHz or higher
Windows Vista 800 MHz or higher
Windows 7 1 GHz or higher
1024 × 768 pixels or more
(1920 × 1080 pixels or more recommended)
Windows XP
Windows Vista
Windows 7
512 MB or more
1 GB or more (32 bit)
2 GB or more (64 bit)
DMC-ZS20
26 VQT4B72 (ENG)
Specifications
Digital Camera: Information for your safety
Power Source DC 5.1 V
Power
Consumption
Camera effective
pixels
Image sensor 1/2.33” MOS sensor,
Lens
[NANO SURFACE
COATING]
Image Stabilizer Optical method
Focus range
P / A / S / M 50 cm (1.6 feet) (Wide) / 2 m (6.6 feet) (Tele) to
Macro /
Intelligent
Auto /
Motion picture
Scene Mode There may be difference in above settings.
Shutter system Electronic shutter + Mechanical shutter
Minimum
Illumination
Shutter speed 15 seconds to 1/2000th of a second
Exposure (AE) Program AE (P) / Aperture-priority AE (A) /
Metering Mode [Multi Metering] / [Center Weighted] / [Spot]
When recording: 1.4 W
When playing back: 1.1 W
14,100,000 pixels
total pixel number 15,300,000 pixels
Primary color filter
Optical 20 x zoom
f=4.3 mm to 86.0 mm
(35 mm film camera equivalent: 24 mm to 480 mm) /
F3.3 (Max. W) to F6.4 (Max. T)
3 cm (0.098 feet) (Wide) / 1 m (3.3 feet) (Tele) to
(5 × to 7 × is 2 m (6.6 feet) to )
Approx. 10 lx (when i-Low light is used, the shutter
speed is 1/30th of a second)
Shutter-priority AE (S) / Manual exposure (M)
(ENG) VQT4B72 27
Specifications
LCD monitor 3.0” TFT LCD (4:3) (Approx. 460,800 dots)
(field of view ratio about 100%) / Touch screen
Microphone Stereo
Speaker Monaural
Recording media Built-in Memory
DMC-ZS20
DMC-ZS19
(Approx. 12 MB)
(Approx. 70 MB)
SD Memory Card / SDHC Memory Card /
SDXC Memory Card
Recording file
format
Still picture JPEG (based on Design rule for Camera File
system, based on Exif 2.3 standard /
DPOF corresponding) / MPO
Motion pictures
Audio
compression
AVCHD / MP4 / QuickTime Motion JPEG
AVCHD: Dolby Digital (2 ch)
MP4: AAC (2 ch)
format
Interface
Digital USB 2.0 (High Speed)
Analog video NTSC Composite
Audio Audio line output (Monaural)
Terminal HDMI: MiniHDMI TypeC
AV OUT/DIGITAL: Dedicated jack (8 pin)
Dimensions
Approx. 104.9 mm (W) x 58.9 mm (H) x 28.2 mm (D)
[4.13” (W) x 2.32” (H) x 1.11” (D)]
(excluding the projection part)
Mass (Weight)
DMC-ZS20
With card and battery: Approx. 206 (0.454 lb)
Excluding card and battery: Approx. 184 (0.406 lb)
DMC-ZS19
With card and battery: Approx. 202 (0.445 lb)
Excluding card and battery: Approx. 180 (0.397 lb)
28 VQT4B72 (ENG)
Operating
0 °C to 40 °C (32 °F to 104 °F)
temperature
Operating
10%RH to 80%RH
humidity
Language select [ENGLISH] / [ESPAÑOL]
AC adaptor
(Panasonic VSK0768): Information for your safety
Input ~ 110 V to 240 V, 50/60 Hz, 0.2 A
Output
Battery pack (lithium-ion)
(Panasonic DMW-BCG10PP): Information for your safety
Voltage / capacity
5 V, 800 mA
3.6 V / 895 mAh
(ENG) VQT4B72 29
Digital Camera Accessory System
Description Accessory#
Battery Pack DMW-BCG10
AV Cable DMW-AVC1
HDMI mini cable RP-CDHM15, RP-CDHM30
Marine Case DMW-MCTZ30
Class 10 64 GB SDXC Memory Card
Class 10 32 GB SDHC Memory Card
Class 10 16 GB SDHC Memory Card
Class 10 8 GB SDHC Memory Card
Class 10 4 GB SDHC Memory Card
Class 4 16 GB SDHC Memory Card
Class 4 8 GB SDHC Memory Card
Class 4 4 GB SDHC Memory Card
Class 4 2 GB SD Memory Card
Product numbers are correct as of January 2012. These may be
●
subject to change.
Accessories and/or model numbers may vary between countries.
●
Consult your local dealer.
RP-SDU64GE1K
RP-SDU32GU1K
RP-SDU16GU1K
RP-SDU08GU1K
RP-SDU04GU1K
RP-SDL16GU1K
RP-SDL08GU1K
RP-SDL04GU1K
RP-SDL02GU1K
30 VQT4B72 (ENG)
Digital Camera Accessory Order Form
Please photocopy this form when placing an order.
1. Digital Camera Model #
2. Items Ordered
Accessory # Description Price Each Quantity Total Price
Shipping & Handling
$6.95
Subtotal
Your State & Local Sales Tax
Total
3. Method of payment (check one)
American Express
VISA Credit Card #
MasterCard Expiration Date
Discover Customer Signature
(Please do not send cash)
4. Shipping information (UPS delivery requires complete street address)
Ship To:
Mr.
Mrs.
Ms.
First Last
Street Address
City
TO OBTAIN ANY OF OUR DIGITAL CAMERA ACCESSORIES YOU CAN DO ANY OF
VISIT YOUR LOCAL PANASONIC DEALER
CALL PANASONIC’S ACCESSORY ORDER LINE AT 1-800-332-5368
MAIL THIS ORDER TO: PANASONIC NATIONAL PARTS CENTER
State Zip
THE FOLLOWING:
OR
[6 AM-6 PM M-F, PACIFIC TIME]
20421 84th Ave S., Kent, WA 98032
OR
Phone#:
Day ( )
Night ( )
(ENG) VQT4B72 31
Limited Warranty (ONLY FOR U.S.A. AND PUERTO RICO)
Panasonic Consumer Marketing Company of North America,
Division of Panasonic Corporation of North America
One Panasonic Way, Secaucus, New Jersey 07094
Panasonic Digital Still Camera Products
Limited Warranty
Limited Warranty Coverage (For USA and Puerto Rico Only)
If your product does not work properly because of a defect in materials or
workmanship, Panasonic Consumer Marketing Company of North America (referred
to as “the warrantor”) will, for the length of the period indicated on the chart below,
which starts with the date of original purchase (“warranty period”), at its option
either (a) repair your product with new or refurbished parts, (b) replace it with a new
or a refurbished equivalent value product, or (c) refund your purchase price. The
decision to repair, replace or refund will be made by the warrantor.
Product or Part Name Parts Labor
Digital Still Camera 1 year 1 year
SD Memory Cards, Rechargeable
Battery Pack (defective exchange)
During the “Labor” warranty period there will be no charge for labor. During the
“Parts” warranty period, there will be no charge for parts. This Limited Warranty
excludes both parts and labor for non-rechargeable batteries, antennas, and
cosmetic parts (cabinet). This warranty only applies to products purchased and
serviced in the United States or Puerto Rico. This warranty is extended only to the
original purchaser of a new product which was not sold “as is”.
90 days Not Applicable
32 VQT4B72 (ENG)
Mail-In Service
For assistance in the U.S.A. and Puerto Rico in obtaining repairs, please ship the
product prepaid to:
Panasonic Exchange Center
4900 George McVay Drive
Suite B
McAllen, TX 78503
panacare@us.panasonic.com
When shipping the unit, carefully pack, include all supplied accessories listed in
the Owner’s Manual, and send it prepaid, adequately insured and packed well in a
carton box. When shipping Lithium Ion batteries please visit our Web Site at
www.panasonic.com/BatteryHandling as Panasonic is committed to providing
the most up to date information. Include a letter detailing the complaint, a return
address and provide a daytime phone number where you can be reached. A valid
registered receipt is required under the Limited Warranty.
IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD, THE PURCHASER
WILL BE REQUIRED TO FURNISH A SALES RECEIPT/PROOF OF PURCHASE
INDICATING DATE OF PURCHASE, AMOUNT PAID AND PLACE OF
PURCHASE. CUSTOMER WILL BE CHARGED FOR THE REPAIR OF ANY UNIT
RECEIVED WITHOUT SUCH PROOF OF PURCHASE.
Limited Warranty Limits And Exclusions
This warranty ONLY COVERS failures due to defects in materials or workmanship,
and DOES NOT COVER normal wear and tear or cosmetic damage. The warranty
ALSO DOES NOT COVER damages which occurred in shipment, or failures which
are caused by products not supplied by the warrantor, or failures which result from
accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty
installation, set-up adjustments, misadjustment of consumer controls, improper
maintenance, power line surge, lightning damage, modification, introduction of
sand, humidity or liquids, commercial use such as hotel, office, restaurant, or other
business or rental use of the product, or service by anyone other than a Factory
Service Center or other Authorized Servicer, or damage that is attributable to acts
of God.
(ENG) VQT4B72 33
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER
“LIMITED WARRANTY COVERAGE”.
THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL
DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT
OF ANY BREACH OF THIS WARRANTY.
(As examples, this excludes damages for lost time, travel to and from the servicer,
loss of or damage to media or images, data or other memory or recorded content.
The items listed are not exclusive, but for illustration only.)
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY
OF MERCHANTABILITY, ARE LIMITED TO THE PERIOD OF THE LIMITED
WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential
damages, or limitations on how long an implied warranty lasts, so the exclusions
may not apply to you.
This warranty gives you specific legal rights and you may also have other rights
which vary from state to state. If a problem with this product develops during or after
the warranty period, you may contact your dealer or Service Center. If the problem
is not handled to your satisfaction, then write to the warrantor’s Consumer Affairs
Department at the addresses listed for the warrantor.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED
WARRANTY, ARE YOUR RESPONSIBILITY.
34 VQT4B72 (ENG)
Customer Services Directory (United States and Puerto Rico)
Obtain Product Information and Operating Assistance; locate your nearest
Dealer or Service Center; purchase Parts and Accessories; or make
Customer Service and Literature requests by visiting our Web Site at:
http://www.panasonic.com/help
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at:
1-800-211-PANA (7262)
Monday-Friday 9am-9pm, Saturday-Sunday 10am-7pm EST
For hearing or speech impaired TTY users, TTY: 1-877-833-8855
Accessory Purchases (United States and Puerto Rico)
Purchase Parts, Accessories and Instruction Books online for all Panasonic
Products by visiting our Web Site at:
http://www.pstc.panasonic.com
Or, send your request by E-mail to:
npcparts@us.panasonic.com
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only)
(Monday-Friday 9am-9pm EST)
Panasonic National Parts Center
20421 84th Ave S., Kent, WA 98032
(We accept Visa, MasterCard, Discover Card, American Express)
For hearing or speech impaired TTY users, TTY: 1-866-605-1277
As of January 2012
(ENG) VQT4B72 35
-If you see this symbol-
Information on Disposal in other Countries outside
the European Union
This symbol is only valid in the European Union. If you
wish to discard this product, please contact your local
authorities or dealer and ask for the correct method of
disposal.
• HDMI, the HDMI Logo, and High-Definition
Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC in the United
States and other countries.
• HDAVI Control™ is a trademark of Panasonic
Corporation.
•
VIERA Link™ is a trademark of Panasonic Corporation.
• EZ Sync™ is a trademark of Panasonic Corporation.
• “AVCHD Progressive”, “AVCHD”, the “AVCHD
Progressive” Logo and the “AVCHD” Logo are
trademarks of Panasonic Corporation and Sony
Corporation.
•
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
• SDXC Logo is a trademark of SD-3C, LLC.
• QuickTime and the QuickTime logo are trademarks
or registered trademarks of Apple Inc., used under
license therefrom.
• Windows and Windows Vista are either registered
trademarks or trademarks of Microsoft Corporation
in the United States and/or other countries.
• Mac and Mac OS are trademarks of Apple Inc.,
registered in the U.S. and other countries.
• This product uses “DynaFont” from DynaComware
Corporation. DynaFont is a registered trademark of
DynaComware Taiwan Inc.
• Other names, company names, and product names
printed in these instructions are trademarks or
registered trademarks of the companies concerned.
Panasonic Consumer Marketing Company of North America,
Division of Panasonic Corporation of North America
One Panasonic Way, Secaucus, NJ 07094
© Panasonic Corporation 2012
Printed in Japan
Loading...
