F565372
Operating Instructions
Air Conditioner
P
O
WE
R
TIM
E
R
Q
U
IET
P
OWER
FUL
CS-E18FKR CU-E18FKR
CS-E21FKR CU-E21FKR
ENGLISH Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
Manufactured by:
Panasonic HA Air-Conditioning (M) Sdn. Bhd.
Lot 2, Persiaran Tengku Ampuan, Section 21, Shah Alam Industrial Site,
40300 Shah Alam, Selangor, Malaysia.
© 2006 Panasonic HA Air-Conditioning (M) Sdn Bhd
(11969-T). All rights reserved. Unauthorized copying
and distribution is a violation of law.
Thank you for purchasing Panasonic Air Conditioner
During Installation
During Operation
During Installation
During Operation
■ Definition
To prevent personal injury,
injury to others, or property
damage, please observe
the following.
Incorrect operation due to
failure to follow instructions
may cause harm or damage,
the seriousness of which is
classifi ed as below:
Warning
This sign warns of death
or serious injury.
Caution
This sign warns of injury
or damage to property.
The instructions to be
followed are classifi ed by
the following symbols:
SAFETY PRECAUTIONS
Warning
During Installation
• Do not install, remove and reinstall the unit by yourself; improper installation will cause leakage, electric
shock or fi re. Please consult an authorized dealer or specialist for the installation work.
• This equipment must be earthed and installed with ELCB. It may cause electrical shock or fi re in case of
malfunction
During Operation
• Do not share the same power outlet with
other equipment.
• Do not modify power cords.
• Do not use extension cords.
• Do not operate with wet hands.
• Do not insert your fi ngers or other objects
into the indoor or outdoor unit.
• Do not attempt to repair the unit by
yourself.
• Do not use rechargeable (Ni-Cd) batteries.
• Do not allow infants and small children
to play with the remote control to prevent
them from accidentally swallowing the
batteries.
• Use the specifi ed supply cord.
• If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualifi ed persons in
order to avoid a hazard.
• Remove the batteries if the unit is not
going to be used for a long period of
time.
• New batteries of the same type must
be inserted following the polarity stated
to prevent malfunction of the remote
control.
• In case of emergency or abnormal
conditions (burning, unusual odour, etc),
turn off the power supply.
Caution
This symbol denotes
an action that is
PROHIBITED.
These symbols denote
actions that are
COMPULSORY.
During Installation
• Ensure that the drainage pipe is connected properly. Otherwise, leakage may occur.
• Do not install the unit in a potentially explosive atmosphere.
During Operation
• Do not wash the unit with water, benzene,
thinner or scouring powder.
• Do not use for other purposes such as
preservation of food.
• Do not use any combustible equipment in
front of the airfl ow outlet.
• Do not sit or place anything on the indoor
or outdoor unit.
• Do not expose directly to cold air for a
long period.
• Aerate the room regularly.
• After long periods of use, make sure the installation rack is not damaged.
• Switch off the power supply before
cleaning or servicing.
• Turn off the power supply if the unit is not
used for a long period of time.
• This air conditioner is equipped with a
built-in surge protective device.
However, in order to further protect your
air conditioner from being damaged by
abnormally strong lightning activity, you
may want to disconnect it from the power
supply. Do not touch the air conditioner
during lightning, it may cause electric
shock.
Table of Content
SAFETY PRECAUTIONS ...................................................................................................................... 2
REGULATORY INFORMATION ............................................................................................................ 3
PRODUCT OVERVIEW ........................................................................................................................ 4
AUTO, HEAT, COOL, DRY .................................................................................................................... 5
FAN SPEED, AIR SWING ..................................................................................................................... 6
POWERFUL, QUIET ............................................................................................................................. 7
TIMER ................................................................................................................................................... 8
CARE & CLEANING .............................................................................................................................. 9
2
REGULATORY INFORMATION
EEnvironmental Requirements
End-of-Life Disposal
The appliance is not intended for use by young children or the infi rm person without supervision.
Young children should be supervised to ensure that they do not play with the appliance.
■ Operation Condition
Use this air conditioner under the
following temperature range.
nvironmental Requirements
Battery Disposal
The batteries must be recycled or disposed of properly.
End-of-Life Disposal
“Instructions for end-user” for air conditioners:
Information on Disposal in other countries outside the European Union
This symbol is only valid in the European Union. If you wish to discard this product, please contact
your installer, dealer or local authority and ask for the correct method of disposal.
Temperature (°C)
COOLING
HEATING
Temperature (°C)
COOLING
HEATING
*DBT: Dry bulb temperature
*WBT: Wet bulb temperature
Maximum 32 23
Minimum 16 11
Maximum 30 –
Minimum 16 –
Maximum 43 26
Minimum 16 11
Maximum 24 18
Minimum -5 -6
Indoor
*DBT *WBT
Outdoor
*DBT *WBT
ENGLISH
Note:
The illustrations in this manual
are for explanation purposes only and
may differ from the actual unit. It is
subjected to change without notice for
future improvement.
3
Indoor Unit
Outdoor Unit
■ About
SET
CL
SET
AUT
O
HEA
T
FAN
SPEED
AIR
SWING
COOL
DRY
TEMP
AIR SWIN
G
FAN
SPEED
QUIET
POWERF
UL
TIMER
ON
1
23
OFF
SET
CANCEL
MODE
OFF/ON
AC
RC
SET
CLOCK
CHECK
RESET
Remote Control
PRODUCT OVERVIEW
Remote Control Preparation
1. Pull out
the cover.
2. Insert AAA or R03
batteries.
3. Close the cover.
4. Press CLOCK.
TIMER
ON
123
OFF
CHECK
SET
CLOCK
SET
CANCEL
AC
RESET
5. Press to
set time.
RC
6. Press again.
• Timer operation will be based on
current time set.
• The batteries can be used for
approximately 1 year.
Remote Control Signal
• Make sure it is not obstructed.
• Maximum distances : 10m.
• Certain fluorescent lights may
interfere with signal transmission.
Please consult your nearest dealer.
Indoor Unit
Front panel
Air filter
Discharged air
Outdoor Unit
Air inlet (rear)
Air inlet (side)
Air intake
Supersonic air
purifying device
Auto OFF/ON
button
Receiver
Indicator
Airflow direction
louver
Air outlet
Auto OFF/ON Button
Action Mode
Press once. Automatic
Press and hold until
you hear one beep,
then release.
Press until you hear
one beep then release.
Press again until you
hear two beeps then
release.
• To turn off, press the AUTO OFF/
ON button again.
Troubleshooting
● In the event of an error, the unit will stop and the timer indicator will blink.
1. Press for 5 seconds.
Cooling
Heating
TIMER
ON
123
OFF
CHECK
SET
Remote Control
LCD display
Operation mode
Quiet operation
Powerful operation
Airflow direction
adjustment
Check
* For normal operation, the and reset buttons are not in use.
* Press reset to restore the remote control’s default setting.
2. Press until you hear beep
sound, then jot down the
error code.
3. Press for 5 seconds to quit
checking.
4. Turn the unit off and reveal the
error code to your nearest dealer.
CLOCK
SET
CANCEL
AC
RESET
RC
Transmitter
Off/On
Temperature setting
Fan speed selection
Timer setting
Clock setting
Notes:
• The unit may be operable (with 4 beeps)
on a limited basis, depending on the error.
4
AUTO, HEAT, COOL, DRY
2
1
3
FAN
SPEED
AIR
SWING
FAN SPEED
SET
CANCEL
AC
RC
RESET
MODE
1
Select the
desired
operation.
AUTO
HEAT
COOL
DRY
OFF/ON
MODE
QUIET
POWERFUL
TEMP
AIR SWING
TIMER
ON
123
OFF
SET
CHECK
CLOCK
OFF/ON
2
Start the
operation.
3
4%-0
Set the
temperature.
(16°C~30°C)
■ Operation Details
AUTO - Automatic Operation
• Unit selects the operation mode
according to temperature setting,
outdoor and room temperature.
• The power indicator blinks during
operation.
• Operation mode is reselected
every 30 minutes.
HEAT - Heating Operation
• In heating mode, it takes a while
for the unit to warm up. The
power indicator blinks during this
operation.
COOL - Cooling Operation
• Enjoy cool air at your desired
temperature.
DRY - Soft Dry Operation
• Keeps your environment
dehumidifi ed by running a very
gentle cooling operation.
• During soft dry operation, the
indoor fan operates at low fan
speed.
■ Hint
• A temperature setting 1°C higher
in cooling operation or 2°C lower in
heating operation than the desired
temperature equates to a 10%
power saving.
ENGLISH
● Supersonic air purifying device operates automatically once
the unit is switched on.
POWERFUL
●
● Press
Troubleshooting
● Mist emerges from indoor unit. ► Condensation effect due to cooling process.
● Heating/Cooling operation does not work.
● Water fl owing sound during operations. ► Cause by refrigerant fl ow inside the unit.
● The power indicator blinks during the operation and
and
OFF/ON
the indoor fan is stopped.
QUIET
operations are available in all modes.
again to stop the operation.
► Ensure temperature is set correctly.
► Make sure windows and doors are closed.
► Make sure fi lters are cleaned and replaced.
► Make sure inlet and outlet vents are cleared.
► The unit is in defrost mode, and the melted frost is drained from the
outdoor unit.
5
■ Operations Details
FAN SPEED
• There are 5 fan speeds, as well as
automatic*.
* For automatic fan speed, the
speed of the indoor fan is
automatically adjusted according
to the operation.
FAN SPEED, AIR SWING
AIR SWING
• Keeps the room ventilated.
• There are 5 options for vertical/
horizontal airfl ow direction.
• Do not adjust the vertical and
horizontal louvers by hand.
• If automatic vertical airfl ow direction
has been set, the louvers swing up
and down automatically.
• For HEATING operation, the air
blows horizontally for a while, then
starts to blow downwards.
• If automatic horizontal airfl ow
direction has been set, the louvers
swing left and right automatically.
• For HEATING operation, the airfl ow
louvers start to swing left/right after
the temperature rises.
AIR SWING
Adjust the
airfl ow
direction
louver.
AUTO
HEAT
COOL
DRY
OFF/ON
MODE
QUIET
POWERFUL
TEMP
FAN SPEED
AIR SWING
TIMER
ON
123
OFF
SET
CHECK
CLOCK
CANCEL
AC
RESET
SET
FAN
SPEED
AIR
SWING
RC
FAN SPEED
Select fan
speed.
Troubleshooting
● The room has a peculiar odour. ► This may be a damp smell emitted by the wall, carpet, furniture or
● Indoor fan stops occasionally during automatic fan
speed setting.
● Indoor fan stops occasionally during heating
operation.
clothing.
► This helps to remove the surrounding odours.
► To avoid unintended cooling effect.
6
POWERFUL, QUIET
P
■ Operation Details
OWERFUL
QUIET
Enables
quiet
operation.
POWERFUL
AUTO
HEAT
COOL
DRY
OFF/ON
MODE
QUIET
POWERFUL
TEMP
FAN SPEED
AIR SWING
TIMER
ON
123
SET
FAN
SPEED
AIR
SWING
• To reach the desired set
temperature quickly.
QUIET
• To provide a quiet surrounding
■ Hint
• To reduce power consumption
during cooling operation, close the
curtains to prevent the sunlight and
heat from coming in.
ENGLISH
Enables
powerful
operation.
POWERFUL
●
and
QUIET
operations could not be activated at the
same time.
POWERFUL
●
and
QUIET
operations could be cancelled by pressing
the respective button again.
Troubleshooting
● Noisy during operation.
● Operation is delayed a few minutes after restart.
● Outdoor unit emits water/steam.
OFF
SET
CHECK
CLOCK
CANCEL
AC
RESET
RC
► The unit may have been installed at an incline, or the front panel is not
closed properly.
► The delay is a protection to the unit’s compressor.
► Condensation or evaporation occurs on pipes.
7
C
SET
1
2
3
■ Operation Details
C
• The timer allows you to turn the air
conditioner on or off automatically.
• The unit may start in preliminary
operation before the actual set time
when ON timer has been set.
• The set timer repeats daily once
set.
• If there is a power failure, you can
restore the previous setting (once
power is resumed) by pressing the
SET
button.
• If the timer is cancelled, press
to restore the previous setting.
SET
TIMER
1
Select ON or
OFF timer.
AUTO
HEAT
COOL
DRY
FAN
SPEED
AIR
SWING
2
2
■ Hints
• Press and hold the
approximately 5 seconds to set
either 12-hour (am/pm) or 24-hour
time indication.
• To dim the indicator display:
TIMER
ON
123
OFF
CHECK
SET
• To switch the temperature setting
to °C or °F, press and hold
for approximately 10 seconds.
CLOCK
SET
CANCEL
AC
RESET
RC
for
CLOCK
Press and hold for
5 seconds.
To cancel, press
again for
the
5 seconds.
CANCEL
Cancel the
selected timer.
OFF/ON
MODE
QUIET
POWERFUL
TEMP
FAN SPEED
AIR SWING
TIMER
ON
123
OFF
SET
CHECK
CLOCK
CANCEL
AC
RESET
SET
Set the
desired time.
3
Confi rm the
setting.
RC
● The timer is valid only when the clock is set correctly.
● You can set your preferred time for ON and OFF timers.
The unit will turn ON or OFF automatically.
● To cancel ON or OFF timer, press
press
Troubleshooting
● Timer indicator always on. ► The timer setting repeats daily once set.
● Remote control does not work. ► The batteries are inserted incorrectly or need replacing.
● The unit does not work. ► The circuit breaker is tripped or the timer is set incorrectly.
● Power indicator blinks before the unit is switched on. ► This is a preliminary step in preparation for the operation when the ON
#!.#%,
8
.
timer has been set.
/.
or
OFF
, then
Switch off the power supply
before cleaning
CARE & CLEANING
AIR FILTER
FRONT PANEL
SUPERSONIC AIR
PURIFYING DEVICE
INDOOR
UNIT
Switch off the power supply
before cleaning
FRONT PANEL
Raise and pull to remove.
Wash and dry.
AIR FILTER
Vacuum, wash and dry.
■ Washing Instructions
• Do not use benzene, thinner or
scouring powder.
• Use only soaps (
household detergent.
• Do not use water hotter than 40°C.
INDOOR UNIT
• Wipe the unit gently with a soft, dry
cloth.
AIR FILTER
• Air fi lters cleaning is needed every
two weeks.
• Replace any damaged fi lter.
Part no: CWD001137
CWD001138
pH7) or neutral
≃
ENGLISH
Remove
SUPERSONIC AIR
PURIFYING DEVICE
Remove
Remove
Vacuum the super
alleru-buster fi lter.
INDOOR
UNIT
Wipe gently.
SUPER ALLERU-BUSTER AND
DEODORIZING FILTERS
• It is recommended to vacuum the
fi lters every 6 months.
• For best perfomance, place the
deodorizing fi lter under direct
sunlight for at least six hours every
six months.
• Replace the fi lter every 3 years or
replace any damaged fi lters.
Part no: CZ-SAD13P
■ Hints
• Clean the fi lter regularly for best
performance and to reduce power
consumption.
• Please consult your nearest dealer
for seasonal inspection.
Vacuum, wash and
dry the frame.
■ For extended non-use
• Activate heating for 2~3 hours to thoroughly dry the unit.
• Turn off the power supply.
• Remove the remote control batteries.
Vacuum the deodorizing
fi lter and place under
direct sunlight.
9
SEASONAL INSPECTION AFTER EXTENDED NON-USE:
• Checking of remote control batteries.
• No obstruction at inlet and outlet vents.
• After 15 minutes of operation, it is normal to have the following temperature difference between inlet and outlet vents:
Cooling: ≥ 8°C
Heating: ≥ 14°C
10
NON SERVICEABLE CRITERIAS
TURN OFF POWER SUPPLY and CALL Authorized Distributor under the following conditions:
• Abnormal noise during operation • Circuit breaker switches off frequently
• Water/foreign particles have entered the Remote Control • Power cord becomes unnaturally warm
• Water leak from Indoor unit • Switches or buttons are not functioning properly
11
F565372
Matsushita Electric Industrial Co., Ltd.
Web Site: http://www.panasonic.co.jp/global/
Printed in Malaysia
OPSC0606-01
Loading...
