XP
OPERATING INSTRUCTIONS
Personal Computer
Model No. CF-W2 Series
1
2
For first-time and basic operation, refer to the Operating
Instructions (this manual).
For more information on how
to use this computer, refer to
the onscreen Reference Manual.
Î page 8
For your technical support
office, refer to the Operating
Instructions.
Contents
Preparations
Read Me First ..............................................................
Usage Precautions/About Notations............................ 7
How to Use this Manual............................................... 8
Features....................................................................... 9
Names and Functions of Parts ................................. 10
Confirm the Status Using the LEDs .......................... 12
First-time Operation .................................................. 13
Page
Getting Started (Basic Operations)
Starting Up/Shutting Down ....................................... 19
Using the Touch Pad................................................. 21
Using the Fn key....................................................... 22
Expanding Memory................................................... 23
Setup Utility............................................................... 25
Useful Information
Usage / Handling / Maintenance............................... 32
Wireless LAN ............................................................ 34
Windows ................................................................... 35
Antivirus Measures / When Disposing of This Device ...
Use of Peripheral Devices / Internal Hard Disk......... 37
Using CD/DVD .......................................................... 38
3
Preparations
Getting Started
36
Useful Information
Troubleshooting
List of Error Codes.................................................... 39
How to Resolve the Problem .................................... 40
Dealing with Problems (Summary) ........................... 41
Information for Installed Applications........................ 48
Reinstalling Software ................................................ 49
Important Information
LIMITED USE LICENSE AGREEMENT ................... 54
Hard Disk Data Erase Utility ..................................... 55
Specifications............................................................ 57
LIMITED WARRANTY .............................................. 60
Index ............................................................. back cover
Troubleshooting
Important Information
Customer’s Record
Model No.*
1
Dealer’s Name
Serial No.
or
Code No.
Dealer’s Address
Date of Purchase
*1
For the Model No., insert the 12 digit number (for example, CF-W2DWADZBM) located on the bottom of the computer.
Introduction
Thank you for purchasing the Panasonic computer. Read this manual thoroughly for proper operation of your new computer.
Copyright
This manual is copyrighted by Matsushita Electric Industrial Co., Ltd. with all rights reserved. No part of this manual may be reproduced in any form without the prior written permission of Matsushita Electric Industrial Co., Ltd.
No patent liability is assumed with respect to the use of the information contained herein.
© 2004 Matsushita Electric Industrial Co., Ltd. All Rights Reserved.
Disclaimer
Computer specifications and manuals are subject to change without notice. Matsushita Electric Industrial Co., Ltd. assumes no liability for damage incurred directly or indirectly from errors, omissions or discrepancies between the computer and the manuals.
Trademarks
Microsoft, Windows and the Windows logo are registered trademarks of Microsoft Corporation of the United States and/or other
countries.
Intel, Pentium and PROSet are either registered trademarks or trademarks of Intel Corporation.
SD Logo is a trademark.
®
Adobe
other countries.
WinDVD™ is a trademark of InterVideo, Inc.
Panasonic is a registered trademark of Matsushita Electric Industrial Co., Ltd.
Names of products, brands, etc., appearing in this manual are trademarks or registered trademarks of their respective owner companies.
and Acrobat® are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or
2
Read Me First
Precautions
Usage
Avoid Extreme Heat and Cold
Do not store or use the computer in locations exposed to heat, direct sunlight, or
extreme cold.
Avoid moving the computer between
locations with large temperature difference.
Operation: 5 °C to 35 °C {41 °F to 95 °F}
Storage: -20 °C to 60 °C {-4 °F to 140 °F}
Avoid Direct Sunlight on the LCD Panel
The LCD panel should not be exposed to
direct sunlight or ultraviolet light.
Avoid Humidity, Liquids and Dust
Do not store or use the computer in locations exposed to high humidity, liquids
(including rain) or dust.
Prevent Shock
Avoid subjecting the computer to severe
vibrations or impact. Do not place the
computer inside a car trunk.
Avoid Radio Frequency Interference
Do not place the computer near a television or radio receiver.
Avoiding low-temperature burns
Avoid more than casual contact with any
heat producing area of the notebook
computer, AC adaptor, and any option or
accessory you use with it. Even low heat,
if warmer than body temperature, can
cause a burn, if the skin is exposed to the
heat source for a long enough period of
time.
*1
Handling
Avoid Magnetic Fields
Keep the computer away from magnets.
Data stored on the hard disk may be lost.
Avoid Stacking
Do not place heavy objects on top of the
computer.
Do Not Disassemble the Computer
Do not disassemble the computer using
methods other than those shown in this
manual.
This computer contains high-voltage
parts, contact with which may result in
electrical shock. Modification or incorrect
disassembly may result in fire.
Avoid Excessive Force on the Display
Do not apply excessive downward force
on the display.
Do not connect a telephone line, or a
network cable other than the one specified, into the LAN port
If the LAN port is connected to a network
such as the ones listed below, a fire or
electric shock may result.
• Networks other than 100BASE-TX or
10BASE-T
• Telephone lines
• Internal phone lines (on-premise
switches)
• Digital public phones
• Phone lines other than those listed
above
Preparations
Do not touch the computer and cable
when it starts thundering
Keep SD memory cards and MultiMedia
Cards (both sold separately) away from
infants and small children
Accidental swallowing will result in bodily
injury.
In the event of accidental swallowing, see
a doctor immediately.
*1
About low-temperature burns
Allowing one area of the skin to be in direct
contact with an object that is even slightly
warmer than body temperature for long
periods of time may result in a "low-temperature burn."
3
Read Me First
Preparations
Getting Started
If a malfunction occurs, immediately
unplug the AC cord and the battery pack
• Computer is damaged
• Foreign object inside computer
• Smoke emitted
• Unusual smell emitted
• Unusually hot
Continuing to use the computer while any
of the above conditions are present may
result in fire or electrical shock.
z If a malfunction occurs, immediately
turn the power off and unplug the AC
cord and the battery pack.
Do not do anything that may damage
the AC cord, the DC plug, or the AC
adaptor
Do not damage or modify the cord, place
it near hot tools, bend, twist, or pull it
forcefully, place heavy objects on it, or
bundle it tightly.
Continuing to use a damaged cord may
result in fire, short circuit, or electrical
shock.
Clean the DC plug of dust and other
debris regularly
If dust or other debris accumulates on the
plug, humidity, etc. may cause a defect in
the insulation, which may result in a fire.
z Pull the plug, and wipe it with a dry
cloth.
Pull the plug if the computer is not
being used for a long period of time.
Do not pull or insert the DC plug if
your hands are wet
May result in electrical shock.
Insert the AC plug completely
If the plug is not inserted completely, fire
due to overheating or electrical shock
may result.
z Do not use a damaged plug or loose
electrical socket.
Do not place metal objects or containers of liquid on top of the computer
z If water or other liquid spills, or if paper
clips, coins, or other metal objects get
inside the computer, fire or electrical
shock may result.
Do not place the computer on unstable
surfaces
If balance is lost, the computer may fall
over or drop, resulting in an injury.
Do not move the computer while the
DC plug is connected
The AC cord may be damaged, resulting
in fire or electrical shock.
z If the AC cord is damaged, remove the
DC plug immediately.
Hold the plug when unplugging the AC
cord
Pulling on the cord may damage the cord,
resulting in a fire or electrical shock.
Do not turn the volume up to loud
when using headphones
Listening at high volumes that overstimulate the ear for long periods of time may
result in loss of hearing.
Take a break of 10-15 minutes every
hour
Using the computer for long periods of
time may have detrimental health effects
on the eyes or hands.
Do not look into the DVD-ROM & CD-R/
RW drive
Looking directly at the internal laser light
source may result in damage to eyesight.
Do not use disks that are cracked or
deformed
Because the disks rotate at high speeds,
damaged disks may break apart causing
injury.
z Disks that are not round and disks that
have been repaired using adhesives
are similarly dangerous, and so should
not be used.
Do not cover the computer with a thick
cloth, such as a blanket
4
Precautions (Wireless LAN)
Keep the computer at least 22 cm
{8.7”} away from heart pacemaker
devices
Pacemaker operations may be affected by
radio waves.
Turn o f f
*1
inside of airplanes
Radio waves may obstruct the safe operations of the aircraft. Follow the instructions of the airline with regard to use on
airplanes.
Do not use near automatic doors, fire
alarms, and other automatic control
devices
Radio waves from this computer may
affect automatic control devices, resulting
in damage due to malfunctions.
Turn off
*1
in hospitals and other locations with electrical medical devices
(do not bring into operating rooms,
intensive care units, CCUs
*2
, etc.)
Radio waves from this computer may
affect electrical medical devices, resulting
in damage due to malfunctions.
Turn off
*1
in crowded areas, as persons
wearing heart pacemakers may be
nearby
Pacemaker operations may be affected by
radio waves.
Preparations
*1
If it is necessary to use the computer in
these types of environments, turn the wireless LAN off using the following procedure.
Note, however, that use of computers even
while the wireless LAN is off may be prohibited during takeoff and landings, and at
other times.
Double-click the icon or the icon on
the notification area, and click [Off].
*2
CCU: Coronary Care Unit
5
Read Me First
Precautions (Battery Pack)
z Care should be exercised with regard to the following
in order to avoid the possibility of overheating, fire or
damage.
Avoid Heat
Do not throw the battery pack into a fire or
expose it to excessive heat.
Keep Articles Away
Do not place the battery pack together
with articles such as necklaces or hairpins when carrying or storing.
Do Not Disassemble
Do not insert sharp objects into the battery
Preparations
Getting Started
pack, expose it to bumps or shocks,
deform, disassemble, or modify it.
Do Not Short
Do not short the positive (+) and negative
(-) contacts.
Avoid Extreme Heat, Cold and Direct
Sunlight
Do not charge, use or leave the battery
pack for extended periods where it will be
exposed to direct sunlight, in a hot place
(in a car on a sunny day, for example), or
in a cold place.
Do not charge the battery using the
methods other than indicated in this
manual
Do not use this computer with a battery pack other than the one specified
(the one included with the computer or
the specified battery pack sold seperately)
Do Not Use With Any Other Computer
The battery pack is rechargeable and was
intended for the specified computer. Do
not use it with a computer other than the
one for which it was designed.
Do Not Put into a Microwave
Do not put the battery pack into a microwave oven or a pressurized chamber.
Stop Using
Should the battery emit an abnormal
odor, become hot to the touch, become
discolored, change shape, or become in
any way different from normal, remove it
from the computer and stop using it.
z Do not touch the terminals on the battery pack. The
battery pack may no longer function properly if the
contacts are dirty or damaged.
z Do not expose the battery pack to water, or allow it to
become wet.
z If the battery pack will not be used for a long period of
time (a month or more), charge or discharge (use) the
battery pack until the remaining battery level becomes
30% to 40% and store it in a cool, dry place.
z This computer prevents overcharging of the battery by
recharging only when the remaining power is less than
approx. 95% of capacity.
z The battery pack is not charged when the computer is
first purchased. Be sure to charge it before using it for
the first time. When the AC adaptor is connected to
the computer, charging begins automatically.
z Should the battery leak and the fluid get into your eyes,
do not rub your eyes. Immediately flush your eyes with
clear water and see a doctor for medical treatment as
soon as possible.
NOTE
z The battery pack may become warm during
recharging or normal use. This is completely normal.
z Recharging will not commence outside of the
allowable temperature range (0 °C to 55 °C {32 °F
to 131 °F}). (Î "Chapter 2: Battery Power" in
onscreen Reference Manual) Once the allowable
range requirement is satisfied, charging begins
automatically. Note that the recharging time varies
based on the usage conditions. (Recharging takes
longer than usual when the temperature is 10 °C
{50 °F} or less.)
z If the temperature is low, the operating time is
shortened. Only use the computer within the
allowable temperature range.
z The battery pack is a consumable item. If the
amount of time the computer can be run off a particular battery pack becomes dramatically shorter
and repeated recharging does not restore its performance, the battery pack should be replaced
with a new one.
z When transporting a spare battery inside a pack-
age, briefcase, etc., it is recommended that it be
placed in a plastic bag so that its contacts are protected.
z Always power off the computer when it is not in
use. Leaving the computer on when the AC adaptor is not connected will exhaust the remaining battery capacity.
6
Usage Precautions / About Notations
Usage Precautions
Before using the drive:
z When using the drive for the first time, slide the open lever (A) on the left side of
the computer to open the disk cover after the computer has been powered on, and
if the protective sheet (B) is attached to the drive, remove it from the lens area.
z Do not expose the DVD-ROM & CD-R/RW drive to excessive smoke that may leave
a residue, e.g. oil smoke, or tobacco smoke. Doing so could shorten the life of the
drive lens.
When closing the disk cover:
z Press down near the power indicator (position of the arrow) to ensure that the
cover is locked.
About Notations
Notations Meanings
NOTE NOTE provides a useful fact or helpful information.
CAUTION CAUTION indicates a condition that may result in minor or a moderate degree of injury.
Enter
Fn+F5
[start] - [Run] This illustration tells you to click [start], then to click [Run]. For some applications, you
Î This symbol indicates related pages.
This illustration means pressing the
This illustration refers to pressing and holding the Fn key, then pressing the F5 key.
When using with the
and
Ctrl
reversed.
may need to double-click.
z Some of the illustrations in this manual may differ slightly in shape from the actual
items on your computer. This should make the explanation easier to understand
z If a user has logged on to Windows without the Administrator Authority, some func-
tions may not be executable, and some screens may not be displayed as shown in
this manual.
If this happens, log-on to Windows with the Administrator Authority to enable these
functions
Fn
and
Ctrl
Enter
functions interchanged (Î page 27), read with Fn
key.
Preparations
Getting Started
z In this manual, “Microsoft
“Windows XP”
z In this manual, the following software packages are described as follows:
• "WinDVD™ 5 (OEM Version)" as "WinDVD"
• "B's Recorder GOLD7 BASIC" as "B's Recorder"
• "B's CLiP 5" as "B's CLiP"
z Circular media such as DVD-ROM and CD-ROM is described as a "disk".
z Optional Products or Accessories
Confirm the latest information on optional products or accessories from other
sources
®
Windows® XP Professional” is indicated as “Windows” or
7
How to Use this Manual
Manual Types and Contents
Using the
hard copy
Using the
onscreen
manual
Operating Instructions
(This manual)
Reference Manual
(PDF format)
Important Tips
(PDF format)
Windows Help Windows Help explains operations and functions about Windows.
This manual explains startup methods and basic operations required
when using the computer for the first time.
The Reference Manual explains functions for you to make greater
use of the computer, such as how to add peripheral devices, how the
Setup Utility works, and other useful information.
Important Tips provides information on how to maximize use of the
battery pack, which is necessary for computing away from your home
or office.
How to Use the Onscreen Manual
The manual is saved in the computer's hard disk. To view the manual, start up the
computer after completing the settings for "First-time Operation" (Î page 13).
z When the manuals in PDF format (see above) are accessed for the first time, the
PreparationsGetting Started
License Agreement of the Acrobat Reader may be displayed. If it is displayed, after
reading the agreement, click [Accept].
z Refer to Acrobat Reader Help to use the Acrobat Reader.
How to access the Reference Manual
1 Click [start] then click [Reference Manual].
How to access the Important Tips
1 Double-click the icon on the desktop.
Important Tips can also be accessed from [start] - [All Programs] [Panasonic] - [On-Line Manuals] - [Important Tips].
How to access Windows Help
1 Click [start] - [Help and Support].
8
Features
Enjoy videos, music, data exchange, and other
functions easily with SD memory card!
Î “Chapter 4: SD Memory Card/MultiMedia Card” in onscreen Reference Manual
Enlarge the display of characters and icons on the
screen!
Î “Chapter 6: Icon Enlarger” in onscreen Reference Manual
*1
Some characters in the application software, homepages and HTML e-mails may not be
magnified.
*1
Set a password to prevent unauthorized use!
z Various password settings / using the SD memory card
Î “Chapter 2: Security Measures” and “Chapter 4: SD Memory Card Security Func-
tion” in onscreen Reference Manual
Effective in giving presentations!
z Also offers a standard external display connector
Î “Chapter 4: External Display” in onscreen Reference Manual
Preparations
Enjoy wireless broadband wireless LAN functions
(conforms to IEEE802.11b+g)!
Before using a wireless LAN, check the wireless LAN on. (Î page 34)
Various methods for connecting to the Internet!
z Use a telephone line, LAN, or wireless LAN.
Î “Chapter 5: Modem/LAN/Wireless LAN” in onscreen Reference Manual
Protect your computer from viruses!
z Use Internet Connection Firewall and other functions.
Î “Chapter 8: Protecting Your Computer from Viruses” in onscreen Reference Manual
Keep your computer in the most updated condition!
z Use Windows Update or other update functions.
Î “Chapter 8: To Update this Computer to its Latest Version” in onscreen Reference
Manual
Watch DVD videos! Write to CDs!
z WinDVD, B’s Recorder, B’s CLiP already installed.
z The drive construction (in which the disk cover opens from the top) makes it easy to
set disks even in tight places.
Î “Chapter 3: DVD-ROM & CD-R/RW Drive” in onscreen Reference Manual
Getting Started
9
Names and Functions of Parts
Names Functions/Reference
A Function Keys
B Keyboard —
C Touch Pad Î page 21
D Latch
E LEDs Î page 12
Power Switch
F
Press a key in combination with the
key. Î page 22
When the display is closed and the latch is locked, the computer goes into standby or
hibernation Mode. (Î “Chapter 2: Standby/Hibernation Functions” in onscreen Reference Manual)
z When the computer is in standby or hibernation mode, open the display to restart
operations.
Slide the switch for about one second to turn the power on. Î page 14
Fn
key to execute the function allocated to that
G Speaker
PreparationsGetting Started
z To adjust the volume:
z Speaker on/off: Fn+
Fn+F5
F4
/ Fn+
F6
H Display (Internal LCD) —
I Security Lock
Modem Port
J
LAN Port
K
SD Memory Card Indica-
L
tor
M SD Memory Card Slot Î “Chapter 4: SD Memory Card/MultiMedia Card” in onscreen Reference Manual
N PC Card Slot Î “Chapter 4: PC Cards” in onscreen Reference Manual
A Kensington cable can be connected.
For more information, read the manual that comes with cable.
Connect modem telephone cable.
Î “Chapter 5: Modem” in onscreen Reference Manual
Connect LAN cable.
Î “Chapter 5: LAN” in onscreen Reference Manual
Î page 12
10
Names Functions/Reference
Wireless LAN Antenna
A
(built-in)
DC-IN Jack
B
External Display Port Connect the external display cable.
C
USB Ports
D
Microphone Jack
E
Headphone Jack
F
G Open Lever
DVD-ROM & CD-R/RW
H
Drive
This computer has a built-in antenna for wireless LAN communications.
Î “Chapter 5: Wireless LAN” in onscreen Reference Manual
Connect the AC adaptor. Î page 14
Î “Chapter 4: External Display” in onscreen Reference Manual
Connect the USB cable.
Î “Chapter 4: USB Devices” in onscreen Reference Manual
Use only a monaural condenser microphone (miniature jack). Using an input source
other than a monaural condenser microphone may not allow audio to be input or may
damage the equipment.
Use this jack to connect headphones or amplifier-equipped speakers. Audio output
from the internal speaker is disabled when headphones or external speakers are connected.
Slide the lever to open the disk cover. This works only when the power is on.
When using the drive for the first time, slide the open lever to open the disk cover after
the computer has been powered on, and if the protective sheet is attached to the drive,
remove it from the lens area.
Î page 38, “Chapter 3: DVD-ROM & CD-R/RW Drive” in onscreen Reference Manual
Preperations
I Latch (left)
J Latch (right) This latch is locked automatically when inserting the battery pack properly.
K Battery Pack Î page 13, “Chapter 2: Battery Power” in onscreen Reference Manual
L RAM Module Slot Î page 23
M Emergency Hole Î page 38, “Chapter 3: DVD-ROM & CD-R/RW Drive” in onscreen Reference Manual
This latch is locked manually when inserting/removing the battery pack.
Î page 13
Getting Started
11
Confirm the Status Using the LEDs
Indicators Indicator Name/Status
Power indicator
z Not lit: Power off / Hibernation mode
z Green: Power on
z Blinking green: Standby mode
Battery pack indicator
z Not lit: Battery pack is not connected or no charging.
PreparationsGetting Started
z Orange: Charging in progress.
z Green: Fully charged.
z Red: The battery level is very low (the charge is approx. 9% or less).
z Blinking red: Battery pack or charging circuit may not be working properly.
z Blinking orange: Battery cannot be recharged temporarily (The internal temperature of the battery
pack is outside the acceptable temperature range for recharging.)
Caps Lock indicator
z This indicator lights green when the
capitalized.
NumLk indicator (Ten-key mode)
z This indicator lights green when the
will function as a ten-key numeric input.
When the green light is on, if the
keyboard, then those keys will operate as numeric keys.
The [Enter] key functions differently depending on the application.
To disable, press the
z When the NumLk indicator is on: the following functions will operate:
NumLk
Caps Lock
NumLk
Fn
key is pressed along with keys on certain other segments of the
key once more (the indicator will turn off).
key is pressed: Subsequent non-shifted input is
key is pressed: Part of the keyboard (see figure below)
12
ScrLk indicator (Scroll lock)
z This indicator lights green when the
depending on the application.
Hard disk drive indicator
z Lighted: This indicator lights when the hard disk drive is accessed.
DVD-ROM & CD-R/RW drive indicator
z Lighted: This indicator lights when the DVD-ROM & CD-R/RW drive is accessed.
SD memory card indicator
z Lighted: This indicator lights when the SD memory card or MultiMedia Card is accessed.
Fn+ScrLk
key are pressed: Scroll lock functions differently
First-time Operation
Explains operating procedures from the time of purchase to the start of first Windows
operations.
1 Confirm the inclusion of all parts.
Make sure the parts shown in the figure have been supplied. If any of these
items are missing or is not working properly, contact your technical support
office (Î page 60).
AC adaptor......... 1
Model No: CF-AA1623A
Product Recovery
DVD-ROM........... 1
AC Cord............. 1
Modem Telephone
Cable................... 1
Battery Pack........ 1
Model No: CF-VZSU27
Operating Instructions
(This book)................. 1
Supplementary Instructions
........................................ 1
®
Windows
Book.... 1
2 Read the LIMITED USE LICENSE AGREEMENT (Î page 54).
Be sure to read the LIMITED USE LICENSE AGREEMENT before breaking
the seal on the computer’s packaging.
3 Turn the computer over and insert the battery pack.
A Slide the left-side latch (A) to the unlock position ( ).
B Make sure the battery pack is facing the correct direction, slide it in the
direction of the arrow.
C Slide the left-side latch to the lock position ( ), and then check to ensure
that the battery pack is held firmly.
(Right-side latch is locked automatically.)
Preparations
CAUTION
z Confirm that the latch is properly locked. If it is not, the battery pack may come
off while you are carrying the computer.
z Do not touch the terminals on the battery pack and the computer. The battery
pack may no longer function properly if the contacts are dirty or damaged. Also,
the computer may not operate properly.
z Before using the battery pack, carefully read “Precautions (Battery Pack)”
(Î page 6).
13
First-time Operation
4 Open the display.
A Slide the latch (B) located at the front.
B Lift open the display.
z Do not open the display wider than necessary (135° or more), and do
not apply excessive pressure to the LCD. Also, do not hold the LCD
when opening or closing the display.
Preparations
Getting Started
5 Connect your computer to a power outlet.
z Be sure the AC adaptor is connected until completing the first-time use
operation.
z The battery pack will be charged automatically.
Charging Time: Approx. 4.5 hours (Varies depending on the usage conditions.)
z When using the computer for the first time, do not connect any peripheral
device except the battery pack and AC adaptor to the computer.
CAUTION
Handling the AC adaptor
z Do not subject the AC adaptor to any strong impact.
Using the AC adaptor after a strong impact such as being dropped may result in
electrocution, short circuit, or fire.
z Use only the specified AC adaptor with your computer. Using an AC adaptor
other than the one supplied might damage the battery and/or the computer.
z Problems such as sudden voltage drops may arise during periods of thunder
and lightning. Since this could adversely affect your computer, an uninterruptible power source (UPS) is highly recommended unless running from the battery
pack alone.
14
6 Turn your computer on.
z Slide the power switch and hold it for approximately one second until
the power indicator turns on before releasing it.
CAUTION
z Do not slide the power switch and hold it for more than four seconds; this will
cause the power to be turned off forcibly.
z Do not slide the power switch repeatedly.
z It takes some time before [Windows XP Professional Setup] is displayed. Do not
press any keys or touch the touch pad, and do not change the Setup Utility settings. If you do, Windows setup may not operate properly.
7 Setup Windows.
Moving the cursor or clicking buttons can be performed with the touch pad
(A) and left button (B).
z During operations, it may take some time before the next screen is dis-
played.
Wait, and do not press any keys, or touch the touch pad, etc.
A At [Welcome to the Windows XP Setup Wizard], click [Next].
B After reading the agreement, click [I accept this agreement], then click
[Next].
z If [I don’t accept this agreement] is selected, the Windows setup will be
aborted.
C Select settings for your region, then click [Next].
D Enter your name and then click [Next]. (You do not need to enter your
organization.)
E
Enter your computer name and administrator password and then click [Next].
z "Computer name" is for recognizing this computer when multiple com-
puters are connected via the network.
z Remember this password! This password may be needed to manage
the computer.
Preparations
F Enter the correct date, time and the time zone, then select [Next].
z Click or to set.
z If set properly, click [Next].
z After being set automatically, the computer will restart automatically,
and Windows will start.
z It may take some time before the computer restarts. Wait, and do not
press any keys, or touch the touch pad, etc.
G Enter your password set in step E and select .
z When inputting the password, confirm that character input is not set to
“Caps Lock” or “NumLk.” (Î page 12)
NOTE
z At the time of purchase, the wireless LAN is turned on. If you want to use the
computer with the wireless LAN turned off: Î page 34.
15
First-time Operation
8 Create "User Accounts" to recognize this computer's user.
z If you make mail settings, create password reset disks (Î page 18), or
conduct other related operations before creating the user account, you will
be unable to use mail history or settings. Create the user account at this
time.
A Click [start]
account].
*1
Immediately after Windows setup, the screen may show a display as though [start]
has been clicked (i.e., [All Programs] and other menus may be shown above
[start]).
B Enter a new name for the new account, then click [Next].
(For example: Matsushita)
*1
- [Control Panel] - [User Accounts] - [Create a new
Preparations
Getting Started
C Click [Create Account].
z When you create the first new account, you can only select [Computer
administrator].
Once a “Computer Administrator” account has been created, you can
create additional limited user accounts by operating step 8.
D Set the password.
z When sharing this computer with multiple users, we recommend set-
ting a password for your own account.
z When setting password, click the account for which you will set the
password, click [Create a password], and the password following the
onscreen instructions, and click [Create Password].
• Remember the password you have set.
[password hint] in case you forget your password. In addition, we recommend that you create a password reset disk beforehand (Î page
18).
Refer to “When administrator password is forgotten” (Î page 42) in
“Dealing with Problems (Summary).”
E Click [start] - [Turn Off Computer] - [Restart] to restart the computer.
F At the Welcome screen, click the created user (user icon) to log-on.
z If the password has been set, enter the password and click . You
cannot operate the computer until the proper password is entered.
Confirm that character input is not set to "Caps Lock" or "NumLk."
(Î page 12)
z Note also that only the added user account will be displayed in the Wel-
come screen. The account for the administrator created during Windows setup will not be displayed.
It is useful to input a hint in
16
NOTE
z If the characters or icons on the screen are too small and difficult to see:
A Click [start] - [All Programs] - [Panasonic].
B Click [Icon Enlarger], and click [Large Size] or [Extra Large Size], and click
[OK].
This will allow you to magnify the display of characters and icons on the screen.
z The [Icon Enlarger] can be set separately for each account.
9 Double-click the icon on the desktop, start up Win-
dows
After this, start up the application following the instructions on the screen.
z During this process, you will be required to agree to the license agree-
z If [I Decline] is selected or a window is closed without any decision being
z To have DVD video and MPEG files played back automatically on WinDVD
A. When starting up Windows
ting screens will be displayed.
After removing the check mark, select [Finish].
®
Media Players, and agree to the license agreement.
ment.
made in the license agreement, no icons on the desktop may be selected.
In this case, restart the computer.
(Î “Chapter 3: Watching DVD Video” in onscreen Reference Manual),
remove the check mark from [DVD Video] and [Movie file (mpeg)] on
screen A or B on the left.
®
Media Player for the first time, one of the set-
Preparations
B. After starting up Windows
[Tools] - [Options] - [File Types] is selected.
After removing the check mark, select [Apply].
z After completing the settings, select on the screen of the Windows
Media Player.
®
Media Player, the screen will be displayed when
®
This concludes the first-time use operation guidelines.
17
First-time Operation
Password Reset Function
When you have forgotten a Windows log-on password.
Windows XP has a function to reset a current password and to set a new password.
To use this function, you need to create a password reset disk beforehand following the
steps below.
Screen Display
Preparations
Getting Started
etc.
The screen displayed first when powering on the computer and logging on to Windows,
is called the “desktop.” (These screens and icons are only examples.)
z Icons on the desktop
When you double-click icons, the software application will run and the window will
open.
A Connect the USB floppy disk drive (optional: CF-VFDU03) to your com-
puter.
B Click [start] - [Control Panel] - [User Accounts].
C Click the account you have logged on, and click [Prevent a forgotten pass-
word] from [Related Tasks] menu.
Create a password reset disk following the onscreen instructions, and
store the password reset disk in a safe place.
z Only the log-on password for each account can be reset. The pass-
word set in the Setup Utility cannot be reset.
z [start] menu
When you click [start], the menu will be displayed.
Select the software application, etc. that you want to use from the menu, and click it.
z Notification area (see the bottom right on the screen)
Each of the icons has a separate role; for example, to set functions or confirm status.
(Use for screen settings)
(Turn wireless LAN on/off and use to set Wireless LAN connections)
(Use to make various touch pad settings)
(Use to make settings and confirm status for the Touch Pad utility)
(Set volume)
(Use to set LAN or wireless LAN connections)
(Use to make various B's CLiP settings)
z When disconnecting the AC adaptor, the icon will be displayed. (Use it for the
battery settings.)
z If the icon on the notification area being explained in this manual is hidden and not
displayed, click on the icon to display all icons.
z The notification area icons used in this manual are only examples. The actual dis-
play of the order and types of icons may differ depending on your computer environment (various function settings, devices connected, etc.).
18
Starting Up/Shutting Down
Starting Up
1 Open the display.
A Slide the latch (A) located at the front.
B Lift open the display.
z Do not open the display wider than necessary (135° or more), and do
not apply excessive pressure to the LCD. Also, do not hold the LCD
when opening or closing the display.
2 Turn your computer on.
Slide the power switch and hold it for approximately one second until the
power indicator turns on before releasing it.
z Do not slide the power switch and hold it for more than four seconds; this
will cause the power to be turned off forcibly.
z While booting, avoid the following until the hard disk drive indicator has
turned off.
• Connecting or disconnecting the AC adaptor.
• Touching the power switch.
• Performing any keyboard, touch pad, or external mouse operations.
• Closing the display.
z Do not slide the power switch repeatedly.
z Once the computer is powered off, you must wait at least ten seconds
before powering it on again.
3 Log-on to Windows.
After confirming that the hard disk drive indicator has turned off, click the
user (user's icon).
z Input the password, then click . Until the correct password is entered,
the computer will not operate.
Confirm that character input is not set to “Caps Lock” or “NumLK.”
(Î page 12)
z This operation may differ according to [Use the Welcome screen setting].
z When only one user has been created and no password has been set, the
screen for selecting the user will not be displayed (automatic log-on).
4 Select your application.
Run various software applications, etc. and operate them.
NOTE
z
The power saving function is factory set, so if there is no input from a key, the touch
pad or an external mouse (when one is connected) for a certain interval of time, the
power to the LCD and hard disk may be turned off. The LCD will resume operation
when the touch pad or an external mouse (when one is connected) is used or a key
is pressed.
The power to the LCD may be turned off even when an application software is
being installed. In this case, because it is conceivable that a selection dialog
box will be shown, do not press the
resume from this condition as doing so may trigger a selection, but instead,
press a key unrelated to the direct triggering of a selection, like the
In addition, when the computer is left alone, it automatically enters the standby
or hibernation mode. The computer will resume by sliding the power switch.
(ΓChapter 2: Standby/Hibernation Functions” in onscreen Reference Manual)
Space
key or the
Enter
key to attempt to
Ctrl
Getting Started
key.
19
Starting Up/Shutting Down
z When the CPU temperature rises, the computer may not power on to prevent
the CPU from overheating. Should this happen, allow the computer to cool
down then switch the power on again.
If the computer still does not power on, contact your technical support office.
(Î page 60)
If the screen on the left is displayed immediately after
you turn on the power...
A password has been set to ensure the computer's security.
*1
Enter your password
z When the correct password is input, the computer will start.
z When three incorrect password attempts or nothing is input for one minute, the com-
puter will power off.
*1
Supervisor Password or User Password set in the Setup Utility (not the Windows password).
and press the
Enter
Shutting Down (power off your computer)
1 Save important data and close each application.
key.
Getting Started
2 Display the shutdown screen.
Click [start] - [Turn Off Computer].
(Î page 35 “Change the Way Users log on or off”)
3 Click [Turn Off].
Your computer will power off automatically.
z Restarting your computer (without shutting down): click [Restart].
To shut down using the keyboard:
A Press the key, the U key, and select [Turn Off] with Î Í Ï Ð.
B Press the
CAUTION
z Do not do the following during the shutdown/restart procedure.
• Connecting or disconnecting the AC adaptor.
• Touching the power switch.
• Performing any keyboard, touch pad or external mouse operations.
• Closing the display.
NOTE
Enter
key.
20
z When the DC plug is not connected to the computer, disconnect the AC cord
from your AC wall outlet. About 1.5 W of power is consumed simply by having
the AC adaptor plugged into an electrical outlet.
When you leave the computer or interrupt your work...
If you use the “Standby” or “Hibernation” function, then when you turn on the power
next time, the application software and files you were using before will be displayed,
and you can restart the same operations. ( Î “Chapter 2: Standby/Hibernation Function” in onscreen Reference Manual)
Using the Touch Pad
Use the touch pad to move the cursor on the screen and perform computer operations.
A. Work Surface (touch pad)
B. Left Button
C. Right Button
Function Operation
Moving the Cursor
Tapping/Clicking
Double-Tapping/
Double-Clicking
Move the tip of your finger lightly over
the work surface.
tapping or clicking
z A right-click: Can only be performed by clicking the
right button.
double-tapping or double-clicking
Dragging
Two quick taps, but on the second tap leave your finger
down (applying pressure) and move it on the work surface.
or
While holding down the button, move your finger on the
work surface.
Scroll Trace a circle around the edge of touch pad. (Î “Chapter
2: Using the Touch Pad” in onscreen Reference Manual)
NOTE
z You can change the speed of the double-click or the operations of mouse but-
tons using [Mouse Properties] screen
• To display [Mouse Properties]:
Click [start] - [Control Panel] - [Printers and Other Hardware] - [Mouse].
z Sensitivity when touching the touch pad can be adjusted
(Î “Chapter 2: Using the Touch Pad” in onscreen Reference Manual)
z When an external mouse is connected and the cursor does not operate prop-
erly:
In the [Main] menu of the Setup Utility, set [Touch Pad] to [Disable]. When you
want to use the touch pad again, return the setting to [Enable]. (Î page 27)
z When using the touch pad, keep the following in mind.
• By design the touch pad is to be used with a finger tip only. Do not place any
object or press down forcefully with sharp-pointed objects, i.e. finger nails,
pencils, or pens on the work surface.
• Try to avoid having any harmful substances, such as oil, come in contact with
the touch pad. The cursor may not work properly in such cases.
Getting Started
21
Using the Fn key
If you press a key for a character or symbol contained in a key while
pressing the
tained in that key will be executed.
z Details of various functionsÎ “Chapter 2: Using the Fn key” in
onscreen Reference Manual
z When using with the
changed. (Î page 27)
Press the
(It is not possible to replace the markings on the keys, or the keys
themselves)
Fn
key, the function for the character or the symbol con-
Fn
key and the
Ctrl
key instead of the Fn key for the desired Fn function.
Key Functions
Ctrl
key functions inter-
Pop-up Window
(Displayed after logging on to
Windows)
Fn+F1
Fn+F2
Fn+F3
Fn+F4
Fn+F5
Fn+F6
Fn+F7
Getting Started
Fn+F9
Fn+F10
Fn+NumLk
Fn+Home
LCD brightness control
(
Fn+F1
Display change (When the external display is connected) —
Speaker on/off switch
Volume control
(
Fn+F5
Forcing the standby function —
Remaining capacity of the battery pack
Forcing the hibernation function —
The functions differ depending on the application software being used.
= down / Fn+F2 = up)
= down / Fn+F6 = up)
—
OFF
(MUTE)
ON
When the battery
pack is inserted in the
computer (example)
When the battery
pack is not inserted in
the computer
22
Expanding Memory
Depending on the computer, you can expand the RAM module (sold separately). The
increase in memory will improve the processing speed of Windows and other application software. (Effects may differ depending on your usage conditions.)
z Use recommended RAM module products. Do not use non-recommended RAM
modules. Non-recommended RAM modules may not operate properly, and may
cause damage to your computer. Refer to "Specifications" (Î page 57) for recommended RAM module specifications. Refer to various sources for recommended
RAM module.
z Matsushita Electric Industrial Co., Ltd. will bear no responsibility whatsoever for fail-
ures or damage caused by the use of non-recommended RAM modules, or by
incorrect installation or removal of such RAM modules. Before installing a RAM
module, confirm the product type and the correct installation method.
CAUTION
z RAM modules are extremely sensitive to static electricity. There are cases
where static electricity generated by the human body has adversely affected
such RAM modules. When inserting or removing a RAM module, do not touch
the terminals or internal components, insert objects other than the module, or
allow foreign particles to enter. Doing so has been known to cause damage, fire
or electric shock.
Inserting / Removing the RAM Module
Inserting
1 Power off your computer. (Î page 20)
z Do not shut down using the standby or hibernation function.
z Disconnect the AC adaptor.
2 Turn the computer over, remove the battery pack and the
screw (A), then c hold up the cover (B) and d pull it out.
z There is one screw on the cover. Do not confuse this with the cover with
two screws.
z Use the proper size screw driver to insure that the screw does not get
stripped.
3 Insert the RAM module.
A Check direction of a RAM module (C).
Hold the RAM module in the direction that the notch (E) of the RAM
module suits to the protrusion (D) of the slot.
B Place the RAM module lightly in parallel with a slot.
(The gold terminals (F) are visible)
Getting Started
23
Expanding Memory
C Insert the module parallel to the slot and press firmly until the gold termi-
nals are no longer visible.
z If the RAM module is difficult to insert, do not force it. Check once more
to ensure that the module is positioned correctly.
z The slot may be damaged if the following procedure is performed with-
out inserting the module firmly.
D Press the RAM module down until the right and left hooks (G) lock into
place.
z When pressing down the module, the right and left hooks will open
slightly and will return after locking.
z If the RAM module is difficult to press down, do not force it. Check once
more to ensure that the module is positioned correctly.
Getting Started
4 Put the cover back in place.
A Insert the cover at an angle, then fit it into place.
B Fasten the screw.
NOTE
z The memory size in [Information] menu of the Setup Utility (Î page 26) has
increased if the RAM module has been recognized.
If the RAM module is not recognized, power off the computer and insert it again.
Refer to the main memory in the specifications to check the memory size at the
time of shipment. (Î page 57)
Removing
After making the settings in step 1 to 2 of “Inserting,” remove the RAM module as follows.
A Gently open the left and right hooks (H).
The RAM module will be raised at an angle.
24
B Gently remove the RAM module from the slot.
C Put the cover back in place.
Refer to step 4 of “
Inserting.”
Setup Utility
The Setup Utility sets the computer's boot-up operating environment (i.e. passwords, startup drive). The following six
menu items are available:
[Information], [Main], [Advanced], [Security], [Boot], [Exit]
Running the Setup Utility
1 Turn on or restart the computer.
2 Press the
F2
key while [Panasonic] boot screen is displayed
soon after the computer begins the startup procedure.
When the password is set, the screen shown at left will be displayed. Enter
your password, and press the
When the Setup Utility is started with Supervisor Password
z You can modify all items of the Setup Utility
When the Setup Utility is started with User Password
z On the [Advanced] and the [Boot] menu:
• You can view the settings, but cannot change them
z On the [Security] menu:
• [Clear registered SD card], [Set Supervisor Password] and [Hard
Disk Lock] will not be displayed
• [Password on boot], [SD Startup], [SD Setting Method], [Setup Utility
Prompt], [Boot First Menu] and [User Password Protection] will be
displayed, but cannot be set
• The User Password can be changed only when [User Password Protection] has been set to [No Protection]. The User Password cannot
be deleted
z On the [Exit] menu:
• [Get Default Values] option will not be displayed
z The
F9
key does not work
Enter
key.
Getting Started
NOTE
z When [Password on boot] in the Setup Utility is set to [Disable]:
• The computer can be started up without entering a password
• When the Setup Utility is started:
The password becomes necessary. This alternative prevents the contents of
the Setup Utility from being changed
z If you fail to press the
up. In this case, let the computer fully boot up, and then perform a shutdown or
restart from Windows.
z To close the Setup Utility:
A Press the
B Select the exiting method from the [Exit] menu and press the
C Select [Yes] and then press the
Esc
key.
F2
key at the right moment, the Setup Utility will not start
Enter
Enter
key.
key.
25
Setup Utility
Key Operations
z
F1
To display the corresponding "help" file (Press the F1 key to return to the original
screen)
z
Esc
To display the [Exit] menu
zÏ
Ð
To move among the items (Use these keys when selecting the item)
zÍ
Î
To move among the menus (Use these keys when the [Information], [Main],
[Advanced], [Security], [Boot], or [Exit] menu is selected)
z
F5
Select previous item (Use this key when changing setting values)
z
F6
Select next item (Use this key when changing setting values)
z
Enter
To display sub-menu of each item (Use this key after selecting the item by using the
Ï
key or the Ð key)
z
F9
To set default settings (except the password, System Time and System Date)
z
F10
To save the settings and exit
Information Menu
Getting Started
Language: [English]
Model No.: CF-xxxxxxxxx
Serial No.: xxxxxxxxxx
CPU Type: xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
CPU Speed: x.x GHz
BIOS: Vx.xxLxx
Embedded Controller: Vx.xxLxx
System Memory: xxx MB
Primary Master: xx GB
Secondary Master: CD/DVD Drive
Parameters
(An underline indicates the factory default settings)
Language
z Select the language for displaying the Setup Utility
English
Japanese
26
Main Menu
System Time:
System Date:
Touch Pad: [Enable]
Fn/Ctrl Key: [Normal]
Display: [Simultaneous]
Display Expansion: [Enable]
CD/DVD Drive Speed: [High]
*1
Time is shown in 24-hr. style.
*2
Date is shown in order of Month/Day/Year.
*3
The
Tab
key can be used to move the cursor.
[xx:xx:xx]
[xx/xx/xxxx]
*1*3
*2*3
Parameters
(An underline indicates the factory default settings)
Touch Pad
z Select whether to use the touch pad ([Enable]) or not ([Dis-
able])
Fn/Ctrl Key
z Select whether to switch the
functions, and vice versa on the internal keyboard
z Do not attempt to replace the markings on the keys, or the
keys themselves
Display
z The display destination in cases where Windows is not run-
ning is set here
z If an external display is not connected, all information will
appear on the internal LCD even if [External Monitor] or
[Simultaneous] is selected.
After Windows starts up, the screen is displayed on the display destination set in the following menu
[start] - [Control Panel] - [Other Control Panel Options] [Intel(R) Extreme Graphics] - [Devices]
Display Expansion
z Select whether to have the display expanded when not
using the native screen resolution
CD/DVD Drive Speed
z Select whether to set the DVD-ROM & CD-R/RW drive
speed to fast ([High]) or slow ([Low])
Fn
functions with the
Ctrl
Disable
Enable
Normal
Replace
External Monitor
Internal LCD
Simultaneous
Disable
Enable
High
Low
Getting Started
27
Setup Utility
Advanced Menu
Modem: [Enable]
LAN: [Enable]
Boot up from LAN: [Enable]
Wireless LAN: [Enable]
Legacy USB Support: [Enable]
NOTE
z The [Advanced] menu cannot be changed when the Setup Utility is started up
with the User Password
Parameters
(An underline indicates the factory default settings)
Getting Started
Modem
z Select whether to use the internal modem function
([Enable]) or not ([Disable]) (This does not work for the
external modem)
LAN
z Select whether to use the internal LAN function ([Enable]) or
not ([Disable])
(This does not work for the external LAN card)
Boot up from LAN
z Select whether to use the function starting the computer
from a LAN server ([Enable]) or not ([Disable])
z This can be set only when [LAN] is set to [Enable]. (This
function works only for the internal LAN. This does not work
for an internal wireless LAN and external wireless LAN card)
Wireless LAN
z Select whether to use the internal wireless LAN function
([Enable]) or not ([Disable]) (This does not work for the
external wireless LAN card)
Legacy USB Support
z Select whether to use the function that makes the computer
recognize USB keyboard and USB floppy disk ([Enable]) or
not ([Disable]) before starting Windows
Disable
Enable
Disable
Enable
Disable
Enable
Disable
Enable
Disable
Enable
28
Security Menu
Password on boot: [Enable]
SD Startup:
SD Setting Method:
XClear registered SD card:
*1
*1
*1
XSet Supervisor Password:
Setup Utility Prompt: [Enable]
Boot First Menu: [Enable]
Hard Disk Lock: [Disable]
User Password Protection: [No Protection]
XSet User Password:
*1
This is displayed only when an SD memory card has been registered. (Î “Chapter 4: SD
Memory Card Security Function” in onscreen Reference Manual)
[Enable]
[Leave Set]
[Enter]
[Enter]
[Enter]
NOTE
z When the Setup Utility is started up with the User Password:
• [Clear registered SD card], [Set Supervisor Password] and [Hard Disk Lock]
will not be displayed
• [Password on boot], [SD Startup], [SD Setting Method], [Setup Utility Prompt],
[Boot First Menu] and [User Password Protection] will be displayed, but cannot
be set
• The User Password can be changed only when [User Password Protection]
has been set to [No Protection]. The User Password cannot be deleted
Parameters
(An underline indicates the factory default settings)
Getting Started
Password on boot
z Select whether you will need to input ([Enable]) or not ([Dis-
able]) the Supervisor Password or the User Password on
booting
SD Startup
z Select whether to use an SD memory card instead of enter-
ing the password on booting ([Enable]) or not ([Disable])
SD Setting Method
z Select whether to set an SD memory card to [Leave Set] or
[Set and Eject] when an SD memory card is used instead of
entering the password
z This can be set only if [SD Startup] has been set to [Enable]
Clear registered SD card
z Clear the registration from all registered SD memory cards
not to be used instead of entering the password on booting
Set Supervisor Password
z Set a Supervisor Password if you wish to prevent any unau-
thorized changes to the Setup Utility settings, also if you
require a password on boot, set [Password on boot] to
[Enable] after you set Supervisor Password
*2
[SD Startup] and [SD Setting Method] cannot be set if [Password on boot] is set to [Disable].
*2
*2
Disable
Enable
Disable
Enable
Leave Set
Set and Eject
To the sub-menu
To the sub-menu
29
Setup Utility
Setup Utility Prompt
z Select whether to display ([Enable]) or not to display ([Dis-
able]) the message “Press F2 for Setup/F12 for LAN” shown
on the bottom of the [Panasonic] boot screen that is displayed after starting this computer
Boot First Menu
z Select whether to display “Boot Menu” ([Enable]) or not
([Disable])
Hard Disk Lock
z Select whether enable ([Enable]) or disable ([Disable]) the
hard disk lock
z This function will not work without the Supervisor Password
being set
User Password Protection
z Select whether to permit changing the User Password ([Pro-
tected]) or not ([No Protection])
Set User Password
z Set User Password when more than one person will use this
computer, etc.
For example, when the system administrator sets Supervisor Password and User Password and lets other users know
only the User Password, other users cannot change some
of the settings in Setup Utility
z This function will not work without the Supervisor Password
being set
Disable
Enable
Disable
Enable
Disable
Enable
No Protection
Protected
To the sub-menu
Boot Menu
Getting Started
Set priorities (displayed in order from top to bottom) for devices that start up the operating system.
To move a device up by one in the order, select the device with the Ï
key, and then press the
To move a device down by one in the order, select the device with the Ï
key, and then press the
z Panasonic USB floppy disk drive (CF-VFDU03 (optional)) can be used for startup
(recommended)
Floppy Drive
Hard Disk Drive
CD/DVD Drive
*1
LAN
*1
This is not displayed when [LAN] or [Boot up from LAN] is set to [Disable] on the [Advanced]
menu.
F6
F5
key.
key.
key and the Ð
key and the Ð
NOTE
z The [Boot] menu cannot be changed when the Setup Utility is started up with
the User Password
z Boot Menu
The device for starting up the operating system can also be selected during
computer start-up. After the computer is turned on and the
at [Panasonic] boot screen, [Boot Menu] (the device selection screen) will
appear. When the [Boot] menu setting is changed, the selection screen display
Esc
key is pressed
30
Exit Menu
will also change. [Boot Menu] is displayed only when [Boot First Menu] in the
[Security] menu is set to [Enable]
Save Values & Exit
Exit Without Saving Changes
Get Default Values
Load Previous Values
Save Current Values
Battery Recalibration
*1
This item is not displayed when starting up the Setup Utility with the User Password.
*1
Parameters
Save Values & Exit Exit the Setup Utility and save your changes to
CMOS.
Exit Without Saving Changes Exit the Setup Utility without saving your
changes to CMOS.
Get Default Values Set the Setup Utility to the default settings.
Load Previous Values Load previous values from CMOS for all Setup
items.
Save Current Values Save your changes to CMOS.
Battery Recalibration To accurately display remaining battery capac-
ity, fully charge the battery pack, then fully discharge it. (Î “Chapter 2: Battery Power” in
onscreen Reference Manual)
Getting Started
31
Usage / Handling / Maintenance
Usage Environment
z Place the computer on a flat stable surface.
Do not place the computer to tip over. When the computer receives extremely strong
shock after disk may become inoperable.
z Operation: Temperature: 5°C to 35°C {41°F to 95°F}
Humidity: 30% to 80% RH (No condensation)
z Storage: Temperature: -20°C to 60°C {-4°F to 140°F}
Humidity: 30% to 90% RH (No condensation)
z Keep the computer clear of electromagnetic cards and objects that emit electromagnetic
waves.
• Do not place the computer near magnets, electromagnetic bracelets, or other magnetic fields.
• This computer uses a magnet in the position marked with a circle in the diagram
on the left. Do not place a magnetic card or other magnetic field in contact with
the computer.
Handling
Operation
Useful Information
When Carrying the computer, be sure to keep to the fol-
lowing:
z Turn off the computer.
z Remove all external devices, cables, PC Cards protruding from the computer (see
figure A), SD memory cards, and MultiMedia Cards before transporting the computer.
z Close the display, and ensure that the latch (Î page 10) is positioned correctly in
the slot.
Do not carry the computer by gripping the display or the cabinet around the display
(see figure B).
z Do not drop or hit the computer against solid objects.
z When taking an airplane
• Always carry your computer and disks, etc with you. Never check it in with luggage.
• Before using the computer inside an airplane, we recommend asking the airlines
regarding their policy on this issue.
z When transporting a spare battery pack (sold separately) inside a package, brief-
case, etc., it is recommended that it be placed in a plastic bag in order to protect its
contacts.
z If the computer is being carried in a soft bag when the battery pack has been
removed, be careful to avoid undue pressure on the body of the computer in a
crowded place, etc., as this may result in damage to the LCD.
We recommend the following:
z Preparing a spare battery pack (sold separately).
z Making backup copies on SD memory cards, etc. and if necessary, carrying them
with you.
Maintenance
32
z Care of the display / touch pad:
Wipe lightly with a gauze or other dry, soft cloth.
z When the touch pad or other area other than the screen becomes dirty: wet a soft
cloth with water or a diluted kitchen cleanser (neutral), wring the cloth out thoroughly, and wipe the dirty area gently. Using a detergent other than a neutral
kitchen cleanser (e.g., a weak alkali cleanser) may adversely affect painted surfaces.
CAUTION
z Do not use benzene, thinner, or rubbing alcohol. Doing so may adversely affect
the surface, e.g., discoloration. In addition, do not use commercially-available
household cleaners and cosmetics, as they may contain components harmful to
the surface.
z Do not directly add or spray water or detergent onto the computer. If liquid
enters the inside of the computer, it may cause it to work improperly or be damaged.
Operation
Useful Information
33
Wireless LAN
For instructions on settings for wireless LAN and cautions during use, click [start] [Reference Manual], and refer to “Chapter 5: Wireless LAN”.
About Turning on/off the Wireless LAN
z Before using a wireless LAN, turn it on using the following method (at the time of
purchase, the wireless LAN is set to [On]).
z Turn on/off the wireless LAN using Intel(R) PROSet client.
1 Double-click the icon / the icon (when the wireless
LAN is on) or the icon (when the wireless LAN is off) on
the notification area.
2 Select your wireless LAN adaptor and click [General].
3 Click [On] or [Off] for [Switch radio].
Operation
Useful Information
4 Click [OK].
• Do not click [Disable]*1 in [Network Connections].
*1
This is displayed by right-clicking [Wireless Network Connection] in [Network Connections].
Do not use the wireless LAN in airplanes, hospitals, or
in other locations where wireless LAN signals may
affect the operation of devices in the vicinity.
Abide by instructions regarding use in airplanes and hospitals.
This computer uses channels 1 through 11
Check the channel being used by the access point.
*2
In the case of wireless communications, the frequency band being used can be divided into
segments, so that different communications can be conducted on each band segment. A
"Channel" refers to the individual frequency bandwidth divisions.
*2
34
Windows
Windows
Depending on the settings in Windows installed applications, drivers, menus and other
displays may be inoperable. In this case, refer to the items below, and the applied items
from this manual, “Chapter 7: Dealing with Problems (Advanced)” in onscreen Reference Manual, Windows Help (Î page 8), and the software application and driver’s
operating instructions, etc.
Change the Way Users Log on or off
If the check mark is added for [Use the Welcome screen] or [Use Fast User Switching]
in [start] - [Control Panel] - [User Accounts] - [Change the way users log on or off], the
operation differs as follows.
Welcome screen settings
The operations when starting and exiting Windows differ as follows.
[Use the Welcome
screen] setting
When adding the
check mark (when
using)
With no check mark
(when not using)
• At the time of purchase, it is set with the check mark added (when using).
• When [Use when logging on to Windows] is set in [SD Card Setup] (Î “Chapter 4:
SD Memory Card Security Function” in the onscreen Reference Manual), the Welcome screen cannot be used.
Operation when starting Operation when exiting
The list of user names will be
displayed. Click the user name
with which you want to log-on.
Enter the user name and password, and click [OK].
Click [start] - [Turn Off
Computer] - [Turn Off].
Click [start] - [Shut Down] [Shut down] and click [OK].
Fast User Switching settings
When adding the check mark for this setting, you can change to another user without
logging on again when multiple users use the computer.
In the following case, Fast User Switching cannot be used.
z When the check mark is not added for [Use the Welcome screen]
z When joining the network domain
z When the [Use when logging on to Windows] is set in [SD Card Setup] (Î “Chapter
4: SD Memory Card Security Function” in the onscreen Reference Manual)
Operation
Useful Information
Depending on the software application, the computer may not work properly if this
function is used.
This manual explains the procedure for cases where the check mark is added.
z When switching to a different user with the Fast User Switching function, it may not
be possible to set the display settings. In this case, log-off all users, and retry the
operation.
35
Antivirus Measures/When Disposing of This Device
Antivirus Measures/Windows Updates
To improve the security of the computer, use the following measures.
z Use antivirus software (commercially available).
z Use Windows XP Internet Connection Firewall.
z Update Windows
If you can connect to the Internet, perform Windows Update. This can help protect
the computer against virus attacks.
Windows Update enables you to update Windows on your computer by applying the
latest patches and service packs for Windows.
z Get the newest information about viruses from the Website of Microsoft Corp. and
other software makers, etc.
For detailed information, refer to Reference Manual. (ΓChapter 8: Protecting Your
Computer from Viruses” and “Chapter 8: To Update this Compute to its Latest Version”
in onscreen Reference Manual)
When Disposing of This Device
When disposing of or transferring ownership of this device, erase all data on the hard
disk in order to prevent the theft of hard disk data. Even if you delete data or initialize
the hard disk through normal Windows commands, data can still be read using special
software. In order to erase all data, either have the data erased by a specialist (at a
charge) or use the hard disk data erase utility (included). (Note that this hard disk data
erase utility does not guarantee that data will be completely erased.)
Also, note that if you transfer ownership of this device without deleting commercial software that you have installed to the hard disk, you may be in violation of the licensing
agreement for that software.
Operation
Useful Information
36
Use of Peripheral Devices/Internal Hard Disk
When Using Peripheral Devices
Pay strict attention to the following points to avoid damage to the computer, peripheral
devices, cables, etc.
Also, in addition to following this manual and the onscreen Reference Manual, carefully
read the instruction manuals for the peripheral devices being used.
z Use only peripheral devices that conform to the computer’s specifications.
z Connect the devices properly, paying close attention to the condition and position of
the connectors.
z If a connection cannot be made easily, do not apply undue force; check once more
to confirm the condition and position of the connector (alignment of pins, etc.).
z If the connector has holding screws, fasten the screws firmly.
z Do not carry the computer with cables attached, and do not pull on the cables force-
fully.
Internal Hard Disk
To Protect Data
Keep the following.
z Do not expose your computer to shock.
Use care when handling your computer, shock may damage your hard disk or make
your software applications and data unusable.
z Do not power off your computer while software applications are running or
hard disk drive indicator is on.
Properly shut Windows down from the [start] menu to avoid problems. (Î page 20)
z Do not place the Computer close to objects that emit electromagnetic waves
(magnets, electromagnetic bracelets, etc.).
The data saved on the hard disk may be erased.
z Important data saved on the hard disk should be saved regularly (e.g., in case
of failures, unexpected data updates, erasure, etc.)
Regular backups are recommended as a means of minimizing damages in the
event of trouble.
z Use the security function for all important data.
(Î “Chapter 2: Security Measures” and “Chapter 4: SD Memory Card Security
Function” in onscreen Reference Manual)
When Changing Hard Disk Partitions
z During reinstallation, you can divide the hard disk space into two partitions by exe-
cuting: [Make two partitions, for the operating system and data, and reinstall Windows to the operating system partition].
Operation
Useful Information
Confirm the minimum partition size required for the OS by checking the screen during the reinstallation.
If you want to create three or more partitions, after creating an OS partition and a
data partition during the reinstallation, start up Windows, erase the second partition
once using [Disk Management], and then create the partitions in the open space.
37
Using CD/DVD
About opening or closing the disk cover/cleaning the
drive lens
z When the computer is on, be sure to use the open lever on the left side of the com-
puter or perform the ejecting operation through Windows.
When using the following software application, you cannot open the cover using the
open lever
• When using B’s Recorder or B’s CLiP, refer to “Chapter 3: Writing to CDs” in
z To remove a disk when the disk cover cannot be opened or when the computer is
powered off, insert a pointed object (e.g., the bent-out tip of a paper clip, or the tip of
a ballpoint pen) into the emergency hole (A), and move in the direction of the arrow
z Be careful not to do any of the following when the disk cover is open:
• Do not close the display.
• Never insert foreign objects such as paper clips into the DVD-ROM & CD-R/RW
z The disk cover can be opened up to an angle of 70 degrees. Do not force the cover
open any further.
If a hand or other object touches the disk cover and accidentally opens it wider than
70 degrees, pull it forward slowly until the stopper holds the cover in its proper position
z Do not leave the disk cover in the open position or touch the lens.
Over time, dust may build up on the lens, or on a disk. This may result in a read or
write malfunction
z Insert the disk securely. If the disk cover is closed without inserting the disk securely,
it may become damaged.
z Do not access the drive until after the disk cover is closed and the DVD-ROM & CD-
R/RW drive status indicator is off
Operation
z We recommend cleaning the drive lens (B) with an air puffer used for camera lenses
(Do not use any spray lens cleaning products)
onscreen Reference Manual
Be sure to close the display only after confirming the disk cover is closed. If the
disk cover is open, the LCD may become damaged
drive.
This could cause it to malfunction
Useful Information
While the DVD-ROM & CD-R/RW drive is being
accessed
z Do not open the DVD-ROM & CD-R/RW drive or move the computer while the DVD-
ROM & CD-R/RW drive is being accessed
Doing so could cause the disk to shift position, which may damage the disk, or
cause the DVD-ROM & CD-R/RW drive to malfunction.
After running an application involving access to a disk, do not open the DVD-ROM &
CD-R/RW drive until after the application has been closed
z Do not apply excessive force on the disk cover
z Do not shock the computer by removing or inserting cables and cards, etc. This may
result in a read or write malfunction
About recognition of media
z It may take about 30 - 40 seconds for an image recorded to a rewritable media to be
played back
38
List of Error Codes
When turning on the computer, if one of the following error codes or messages is displayed, follow the instructions
shown below.
If the problem persists, or if the error code or message displayed is not shown here, contact your technical support
office (Î page 60).
Error Code/Message Action
0211: Keyboard error z If an external keyboard or mouse is connected, disconnect these devices.
0251: System CMOS checksum
bad - Default configuration used
0271: Check date and time settings
0280: Previous boot incomplete Default configuration used
Press <F1> to resume, <F2> to
Setup
Operating System not found The OS is not properly installed on the floppy disk or the hard disk that you are
An error has occurred in the memory that stores the Setup Utility settings. This
error occurs when the memory content is changed through some inadvertent
operation by a program or other function.
z Run the Setup Utility and load the default values, then change the settings to
the appropriate values as needed. (Î page 25)
z If the problem persists, the internal clock battery may need to be replaced.
Contact your technical support office.
The date and time setting are incorrect.
z Set the date and time correctly in the [Main] menu of the Setup Utility.
(Î page 27)
z If the problem persists, the internal clock battery may need to be replaced.
Contact your technical support office.
Startup has failed repeatedly, so the Setup Utility settings have been returned to
their default values, and the computer has been booted.
z Run the Setup Utility and load the default values, then change the settings to
the appropriate values as needed. (Î page 25)
z Write down the error details and press the
firm the settings, and change the settings to the appropriate values as
needed. (Î page 25)
trying to boot from.
z If the computer cannot be booted from the floppy disk, check the floppy disk
drive to ensure that the disk is in fact bootable, and change it to another if not.
z If the computer cannot be booted from the hard disk, confirm whether the hard
disk is properly recognized in the [Information] menu of the Setup Utility.
(Î page 26)
• If the hard disk is recognized (“xx GB” is displayed), perform the reinstallation procedure.
• If the hard disk is not recognized (“none” is displayed), contact your
technical support office.
z If a device is connected to the USB port, disconnect the device, or run the
Setup Utility and set [Legacy USB Support] in the [Advanced] menu to [Disable]. (Î page 28)
F2
key to run the Setup Utility. Con-
Troubleshooting
39
How to Resolve the Problem
When the operation does not start or work properly, check the following items.
1 Does the computer power on?
Ye s
• Click [start] - [Reference Manual], and refer to
onscreen Reference Manual.
View troubleshooting methods and other information not included in this manual.
• If you cannot resolve the problem: refer to step 2.
2 Does the software application run?
Ye s No
Refer to this section when the keyboard or touch
pad do not operate, or when the screen is not dis-
• Refer to “Dealing with Problems (Summary)” in
this manual. (Î page 41)
No
played
• Refer to each software application’s help section.
• For Windows, click [start] - [Help and Support]
and refer to Windows Help.
• If you cannot resolve the problem: refer to step 3.
• Regarding the pre-installed software on this com-
puter (Î page 59), ask the makers of the software applications. (Î page 48)
3 Do the connected peripherals work properly?
Ye s
Refer to this section even if the peripheral device is
not connected.
• Contact the peripheral device makers.
Refer to the manual included with the peripheral
device for contact information.
No
T
If you cannot resolve these problems: Refer to your technical support office (Î page 60)
Troubleshooting
40
Dealing with Problems (Summary)
If you encounter a problem, try the following methods.
z Windows Setup: Î below
z Starting up: Î below
z Enter Password: Î page 42
z Display: Î page 43
z Setup Utility: Î page 44
z Shutting Down: Î page 44
z Standby/Hibernation Functions: Î page 44
z Battery Indicator: Î page 45
z Onscreen Reference Manual: Î page 45
z Disk Operations: Î page 45
z Reinstalling B’s Recorder/B’s CLiP: Î page 45
z SD Card Setup (SD Memory Card security function): Î page 45
z Fast User Switching Function: Î page 46
z Wireless LAN: Î page 46
z Expanding Memory: Î page 46
z Other Problems: Î page 46
You can use the PC Information Viewer to check the computer’s usage status. (Î page
47)
Windows Setup
During Windows setup, the process
does not move to the next screen
z Sometimes it takes time to move to the next screen. Also, it may take two to
three minutes while the computer moves to the next screen from the [Date
and time settings] screen, and then restarts automatically. Wait, and do not
press any keys, or touch the touch pad, etc. (Î page 15)
Starting Up
The power indicator or battery indicator is not lit
The computer does not operate
when a USB device is connected
[Enter Password] is displayed z Enter your Supervisor Password or User Password. If you have forgotten
POST Startup Error(s) are displayed Î page 39
Windows startup, or an operation is
extremely slow
The date and time are incorrect z You can set the date and time using the following menu:
z Check the cable connection for the AC adaptor
z Check to see if a fully charged battery is properly inserted
z Remove the battery pack and disconnect the AC adaptor. Then reconnect
them
z The computer may not operate when certain USB devices are connected.
Disconnect the USB device, or set [Legacy USB Support] to [Disable] in
[Advanced] menu of the Setup Utility (Î page 28)
your password, contact your technical support office (Î page 60)
z Press the F9 key in the Setup Utility (Î page 25). This will restore the
Setup Utility’s settings to their default values (except for the password, System Date and System Time). The Setup Utility must be run once again for
you to input the appropriate operating environment settings. (The processing speed depends on the application software used, so this operation may
not cause the processing speed to increase)
z If operations slow down during streaming playback, try changing the num-
ber of colors of the display
z If you install resident software after purchasing this computer, disable the
resident software
[start] - [Control Panel] - [Date, Time, Language, and Regional Options] [Date and Time]
z If you continue to experience problems, the internal battery maintaining the
clock may need to be replaced. Contact your technical support office
(Î page 60)
z When the computer is connected to a LAN, confirm the date and time of the
server
z This computer will not correctly recognize the date and time starting from
the year 2100 A.D.
Troubleshooting
41
Dealing with Problems (Summary)
Starting Up
When resuming from the standby or
hibernation mode, [Enter Password]
does not appear even if a password
has been set in the Setup Utility
When the administrator password is
forgotten
When “Remove disks or other
media. Press any key to restart” (or
a similar message) is displayed
When the previous items are not the
cause
z Even when a password has been set in the [Security] menu of the Setup
Utility, [Enter Password] does not appear when the computer resumes from
the standby or hibernation mode. Use the Windows password as follows:
A Click the account to change in [start] - [Control Panel] - [User
Accounts] and set the password.
B Add the check mark for [Prompt for password when computer
resumes from standby] in [Control Panel] - [Performance and
Maintenance] - [Power Options] - [Advanced].
z If you have created a password reset disk (Î page 18), a message is dis-
played when you fail to correctly enter the password. Follow the message’s
instructions and set the password again by using the password reset disk.
If you have not created a password reset disk, after reinstalling setup Windows and then set the password again
z This means a floppy disk that dose not contain system startup information
has been left in the floppy disk drive. Remove the floppy disk, and press any
key
z This message may appear when certain USB devices are connected.
Remove the USB device, or set [Legacy USB Support] in the [Advanced]
menu of the Setup Utility to [Disable]
z If the message still appears even after trying the above measures, this may
be an indication that some type of hard disk failure has occurred. Contact
your technical support office
z Press the F9 key in the Setup Utility. This will restore the Setup Utility’s
settings to their default values (except the password settings)
z Try removing all peripheral devices
z Check a disk error using the following procedure:
A Display [Local Disk (C:) Properties].
Click [start] - [My Computer], right-click [Local Disk(C:)] and click
[Properties].
B Click [Tools] - [Check Now].
C Click [Start] after selecting required items in [Check disk options].
z At startup, hold down the
*1
pears
is displayed. Start the computer in Safe Mode, and confirm the details of
the error
*1
When [Password on boot] is set to [Enable], [Enter Password] appears after the
[Panasonic] boot screen disappears. Hold down the
password and pressing the
, and release your finger when the Windows Advanced Option Menu
F8
key when [Panasonic] boot screen disap-
F8
key soon after inputting the
Enter
key.
Enter Password
Even after entering the password,
[Enter password] is displayed again
Troubleshooting
42
z The computer may be in “ten-key” mode
If lights up, press the
input (Î page 12)
z The computer may be in Caps Lock mode
If lights up, press the
and then input (Î page 12)
NumLk
Caps Lock
key to disable the ten-key mode, and then
key to disable the Caps Lock mode,
Display
No display after powering on z When the external display is not visible
• Check your cable connection to the external display
• Confirm that your display is powered on
• Check the settings for your external display
z The display destination may be set to the external display.
Try changing the display destination by pressing the
If you want to switch the display destination repeatedly by pressing the
F3
key, make sure that the display destination has switched completely
each time before pressing the
z Press the
The power has not been turned off,
but after a certain period of time,
there is no display
When the battery pack is used, the
screen is darker than when the AC
adaptor is connected
An afterimage appears (e.g., the key
green, red, and blue dots remain on
the display) or there are dots not displaying the correct colors
The screen becomes disordered z Changing the number of colors or resolution of the display may affect the
The external display no longer
shows the correct image
When you want to display the fonts
or icons in a larger size
During simultaneous display, if one
of the screens malfunctions
z Has the computer been set to the power-saving mode?
To resume operation of your computer when the display’s power is off (for
energy conservation purposes), press any key unrelated to the direct triggering of a selection, like the
z To save power, your computer may have automatically entered the standby
mode (the power indicator blinks green) or hibernation mode (the power
indicator turns off). If so, slide the power switch
z Press the Fn+F2 key and adjust the brightness. Note, however, that when
the brightness is increased, the battery running time will become shorter.
Brightness can be set to separate levels for when the AC adaptor is connected and when it is disconnected
z If an image is displayed for a prolonged period of time, an afterimage may
appear. This is not a malfunction. The afterimage will disappear when a
different screen is displayed
z High-precision and advanced technologies are used in the production of
color liquid crystal displays (color LCDs). Therefore, if 0.002% or less of the
picture’s elements either fail to light or remain constantly lit (that means that
more than 99.998% of the elements are functioning properly), this is not
considered a defect
screen. Restart the computer
z When an external display, not compatible with the power-saving mode, is
connected to the computer. The display may not function correctly when the
computer enters the power-saving mode. Turn off the power to the external
display
z Change the size of the icons, etc. using "Icon Enlarger"
z You can also change the settings as follows (for more details, refer to the
Windows Help)
z Try changing the display by pressing the Fn + F3 key
z If you continue to experience problems, try changing the display destination
as follows:
z When [Command Prompt] is set to “Full Screen” by pressing the
Enter
dow display is restored by pressing the
exhibited on both displays
Fn+F2
A Click [start] - [Control Panel] - [Appearance and Themes] - [Dis-
play] - [Appearance].
B Select the font size in [Font size] and click [Effects]. Then add the
check mark for [Use large icons] to increase the icon size.
C Click [OK], then click [OK].
A Click [start] - [Control Panel], from the [See Also] area click
[Other Control Panel Options], then click [Intel(R) Extreme
Graphics] - [Devices].
B Click the display destination. Then click [OK].
key, the screen is shown on only one of the displays. When the win-
key and adjust the brightness
Fn+F3
Ctrl
key again
key
Alt
+
Enter
Fn+F3
key, the screen is
key.
Alt
+
Fn
+
Troubleshooting
43
Dealing with Problems (Summary)
Display
When a video such as an MPEG file
and a DVD video is being played
®
with WinDVD or Windows
Player, the display destination cannot be switched using the
key
The notification area icons on the
bottom right of the screen are hidden
and cannot be seen
Media
Fn
+ F3
z The display destination cannot be switched while a video such as an MPEG
file or a DVD video are playing. Stop playing the video before switching the
display destination
z Click the icon on the notification area to display the hidden icons
z If you want all icons to be displayed constantly, right-click on the taskbar,
click on [Properties], and remove the check mark from [Notification area] [Hide inactive icons]
Setup Utility
[Enter Password] is displayed z Enter the Supervisor Password or User Password. If you have forgotten it, a
fee will be charged for repairs. Contact your technical support office
(Î page 60)
z The [Advanced] and [Boot] menu
can not be registered
z Some items in [Security] menu
can not be registered
z
F9
does not work
z Restart the Setup Utility with the Supervisor Password
Shutting Down
Windows cannot be shut down or
restarted
z If a USB device is connected, try remove it
z Is the connection to the ISP provider set properly?
If the setting are incorrect, Windows may not shut down, or may not start
up. For details of communication settings, refer to the ISP provider’s manual
z Is the LAN or wireless LAN set properly?
If settings are incorrect, Windows may not shut down, or may not start up.
Check with your provider or with your system administrator about LAN and
wireless LAN settings
Standby/Hibernation Function
Unable to enter standby or hibernation mode
Unable to automatically enter
standby or hibernation mode
Troubleshooting
The computer does not resume z Did you disconnect the AC adaptor or the battery pack while the computer
z If a USB device is connected to the computer, the standby or hibernation
function may not work properly. Simply remove the USB device. If the problem persists, restart the computer
z It may take a minute or two to enter standby or hibernation mode
z The computer may not enter standby mode properly and seems to be fro-
zen while the computer is communicating via the modem. If this happens,
slide the power switch for four seconds or more to forcibly turn your computer off
z If there is a disk in the DVD-ROM & CD-R/RW drive that has been formatted
using B’s CLiP, the computer will not enter standby or hibernation mode.
Remove the disk
z If a peripheral is connected to the computer, disconnect the device
z When the internal LCD is closed, the computer may not enter standby or
hibernation mode. In order to activate standby or hibernation automatically
while using the computer with the internal LCD closed, set [Touch Pad] to
[Disable] in the [Main] menu of the Setup Utility
z If there is a disk in the DVD-ROM & CD-R/RW drive that has been formatted
using B’s CLiP, the computer will not enter standby or hibernation mode.
Remove the disk
was in standby mode? If the computer's power supply is disconnected while
the computer is in standby mode all unsaved data will be lost
z Did you slide the power switch and hold it for four seconds or more? If so,
the power will be turned off forcibly. In this case, all unsaved data will be lost
44
Battery Indicator
The red indicator is lit z The battery level is very low (the charge is approx. 9% or less).
z Connect the AC adaptor. You can use the computer when the indicator light
is orange. If you do not have an AC adaptor, save your data and power off
your computer. After replacing the battery pack with a fully charged one,
turn your computer on again
The red indicator blinks z Quickly save your data and power off your computer. Disconnect the AC
adaptor and remove the battery pack, then connect them again. If the problem persists, contact your technical support office (Î page 60). The battery pack or charging circuit may be defective
The orange indicator blinks z Battery cannot be recharged temporarily because the internal temperature
of the battery pack is beyond the acceptable temperature range for recharging. Once the allowable range requirement is satisfied, charging begins
automatically. Your computer can be used normally in this state
Onscreen Reference Manual
The Reference Manual is not displayed
z Has Acrobat Reader been uninstalled?
If Acrobat Reader has been uninstalled, run
[c:\util\reader\acroreader51_enu_full.exe] in [start] - [Run] to reinstall the
program. When installing the program, do not change the installation destination folder. If the destination folder is changed, the Reference Manual
cannot be opened from the [start] menu
Disk Operations
If the DVD-ROM & CD-R/RW drive
vibrates excessively or is noisy
Cannot eject disk z Is the computer powered on?
Cannot play back TV programs
recorded on a commercial DVD
recorder
z Is the disk bent or labeled?
z
Check to see if the disk is inserted correctly, and it is in good condition. If the
disk is good and inserted correctly, set [CD/DVD Drive Speed] to [Low] in the
Setup Utility
z When writing to a disk using B's Recorder, you can minimize vibration while
writing by setting the writing speed at [8x] or less
Open lever works only when the computer is powered on.
To remove a disk when the computer is powered off, insert a pointed object
(e.g., the bent-out tip of a paper clip, or the tip of a pencil or ballpoint pen)
into the emergency hole, and then move it (Î page 38)
z In the following cases, finalize the recording on the DVD recorder:
• If the program was recorded in DVD-R/RW in video mode
• If the program was recorded in DVD-RW in VR mode
(Î
page 27
)
Reinstalling B’s Recorder/B’s CLiP
When reinstalling, you will be asked
for a serial number
z Input the following serial number.
B’s Recorder:
B’s CLiP:
SD Card Setup (SD Memory Card security function)
Cannot log-on to Windows with the
SD memory card
z Windows log-on user name and password are not set in the SD memory
card correctly
Enter the Windows user name and password without using the SD memory
card
After logging on to Windows, set the same user name and the password on
the SD memory card and Windows, using one of the following operations:
• Change the setting for the SD memory card [SD Card Setup]
• Change the setting for Windows [Control Panel] (Î “Chapter 2: Security
Measures” in onscreen Reference Manual)
Troubleshooting
45
Dealing with Problems (Summary)
Fast User Switching Function
Some applications may not work
properly
Wireless LAN
Wireless LAN cannot be used
Access point is not detected
Expanding Memory
You do not know the available RAM
module
Cannot tell whether the RAM module
has been correctly installed
The RAM module has not been recognized
z When switching to a different user with the Fast User Switching function,
the following problems may occur:
• Some applications may not work properly
• Key combination with the
• It may not be possible to set the settings of the display
• The wireless LAN cannot be used
• The B’s CLiP icon will no longer be shown on the notification area and B’s
CLiP cannot be used
In this case, log-off all users without using Fast User Switching function,
and try the operation once more. If the problem persists, restart the computer.
z When the wireless LAN function is turned off, turn it on using Intel(R)
PROSet.
(Î page 34)
z Even if the wireless LAN function is turned on, when access point is not dis-
played in [Available Networks] from [Intel(R) PROSet] - [Networks] - [Scan],
click [Refresh].
z For detailed information, refer to “Networking: Wireelss LAN” of “Chapter 7:
Dealing with Problems (Advanced)” in onscreen Reference Manual
Î page 57
z You can check whether the RAM module is recognized using the [Informa-
tion] menu in the Setup Utility. (Î page 26)
If the RAM module is not recognized, turn the computer off and reinsert.
z Make sure the RAM module has been properly inserted
z Use the RAM module that supports the recommended specifications
(Î page 23)
Fn
key may not work
Other Problems
No response z Press the
z Is there an input screen (e.g., password input screen at startup) hidden
z After shutting down by sliding the power switch for more than four seconds,
Cannot operate Fn keys (Î page
22)
Troubleshooting
z In the [Main] menu of the Setup Utility, is [Fn/Ctrl Key] set to [Replace]?
Ctrl+Shift+Esc
ware application that is not responding
behind another window? Use the
being displayed
slide the power switch to power on and open the application again. If the
program no longer works normally, delete the program using the following
menu. Then reinstall the program
[start] - [Control Panel] - [Add or Remove Programs]
(Î page 27)
Return the setting to [Normal], or press the
if you want to leave the setting in [Replace]
key to open Task Manager and close the soft-
Alt+Tab
key to check for other windows
Ctrl
key instead of the Fn key
46
Check the Computer’s Usage Status
You can use the PC Information Viewer to check the computer’s usage status, and use
this information when calling your technical support office for advice. (If you have not
logged on to Windows with the Administrator Authority, some information will be displayed as [Not Found].)
Running PC Information Viewer
A Click [start] - [All Programs] - [Panasonic] - [PC Information Viewer] -
[PC Information Viewer].
Click on the items to display detailed information for each item.
z The [PC Information Viewer] screen is always displayed on the top of
every other screen
Save information to a file
Displayed information can be saved on a text file (.txt).
A Run the PC Information Viewer and display the information you wish to
save.
B Click [Save].
z To save the item that is displayed.
Click [Save only the information displayed] and click [OK].
Some of the hidden information on the screen, which cannot be shown
without scrolling the screen, will be saved, too
z To save all items.
Click [Save all the information] and click [OK]
C Select the folder, input the file name, then click [Save].
Save a copy of the screen to a file
You can save a copy of the screen currently being displayed to a file in bitmap format
(.bmp).
A Display the screen you want to save.
B Press the
C When a message “The copy of the screen was saved...” is displayed, click
[OK].
[pcinfo.bmp] file will be saved in [My Documents] folder. If [pcinfo.bmp] file
already exists, it will ne overwritten. (If [pcinfo.bmp] file is set as a “Read-only”
of “Hidden” file, the new file cannot be saved.)
z
To display the extension of the file, click [Tools] - [Folder Options] - [View]
from Explorer, and remove the check mark for [Hide extensions for known
file types] under the [Advanced settings] section
NOTE
z You can also save a copy of the screen to a file using the following procedure:
Click [start] - [All Programs] - [Panasonic] - [PC Information Viewer] - [Screen
Copy]
z At the time of purchase, the computer is set so that a copy of the screen can be
saved to a file by pressing the
using the following procedure:
A Click [start] - [All Programs] - [Panasonic] - [PC Information Viewer].
B Right-click [Screen Copy], then click [Properties] - [Shortcut].
C Move the cursor to [Shortcut key], and press the key to be used for the
shortcut, and then click [OK].
z Colors are saved in 256 colors
z When using an Extended Desktop:
A copy of the screen displayed on the primary device will be saved.
Ctrl+Alt+F8
key.
Ctrl+Alt+F8
key. This setting can be changed
Troubleshooting
47
Information for Installed Applications
If the application software included with this computer does not operate properly, first
carefully read “Dealing with Problems” in this manual, and onscreen Reference Manual
as well as the help files for the application software.
If you can connect to the Internet, refer to “Frequently Asked Questions” and other support information available on the relevant homepage for the manufacturer of the application software.
If you cannot find any hints or methods there to resolve your problem, forward your
question to the address shown below.
When forwarding an inquiry, include information on your computer’s usage conditions.
z B’s Recorder / B's CLiP
B.H.A.
• URL:
http://www.bhacorp.com/
http://www.bha.co.jp/ (In Japanese)
• E-mail addresses:
U.S./Canada/Australia (English, French): BHAxpsupport@bhacorp.com
Europe (English, German, French): eurosupport@bhacorp.com
Asia (Chinese): asiasupport@bhacorp.com
Getting Started
z WinDVD
InterVideo, Inc.
• URL:
http://www.intervideo.com/
• E-mail address:
support@intervideo.com
z Other pre-installed software
Contact the Panasonic technical support office as listed in the “LIMITED WARRANTY” in this manual.
Confirm the contact information for the Panasonic technical support office using the
following procedure:
A Click [start], right-click on [My Computer], and click on [Properties].
B Click on [Support Information].
Troubleshooting
48
Reinstalling Software
When reinstallation procedure is performed, the contents of the hard disk will be erased. Be sure to back up any critical data on your hard disk to another media or to an external hard disk before running the reinstallation procedure.
The reinstallation procedure will return the computer to its original condition.
If you have created partitions for data, the data may be erased or become corrupt as a result of the reinstallation procedure.
What is “Reinstallation”?
Reinstallation refers to formatting the hard disk, and reinstalling Windows.
When is “Reinstallation” necessary?
z When Windows does not start up, or when Windows operation is unstable and can-
not be recovered.
z When using the hard disk with two partitions.
Before Reinstallation
Preparing
z You will need the Product Recovery DVD-ROM (included).
Confirm the following
z Remove all peripherals and SD memory cards/MultiMedia Cards. Especially, when
a USB floppy disk drive or a USB CD/DVD drive is connected, the reinstallation
does not operate properly. Remove them.
z Even if reinstallation is executed, the number of times that the DVD video region
code can be set will not be returned to the state set at the time of factory shipment.
Reinstallation Procedure
Change the settings in the Setup Utility
Use the Product Recovery DVD-ROM to execute reinstallation. (About 20 minutes)
Return the Setup Utility settings to their default values.
Setup Windows.
Change the settings in the Setup Utility. (Only when necessary)
If you can connect to the Internet, after the Internet Connection Firewall setting is
enabled (Î page 36), perform Windows Update.
(Î “Chapter 8: To Update this Computer to its Latest Version” in onscreen Reference
Manual)
Troubleshooting
49
Reinstalling Software
Reinstalling
1 Connect the AC adaptor.
2 Change the settings in the Setup Utility.
Make the following settings.
z Return settings to the status at the time of shipment.
z Change settings to enable startup from DVD-ROM & CD-R/RW drive.
If you change the status of the computer from that at the time of purchase, we
recommend that you make a note of the settings that are changed.
A Turn on the computer, and press the
screen is displayed.
The Setup Utility will start up.
z If the password has been set, enter the Supervisor Password, and
press the
Enter
key.
F2
key while [Panasonic] boot
B Press the
At the confirmation message, select [Yes] and press the
C Select the [Boot] menu, then select [CD/DVD Drive] and press the
until [CD/DVD Drive] is at the top of the [Boot] menu.
D Place the Product Recovery DVD-ROM into the DVD-ROM & CD-R/RW
drive.
E Press the
At the confirmation message, select [Yes] and press the
F9
F10
key.
key.
Enter
Enter
key.
key.
F6
key
Troubleshooting
50
The Setup Utility will close, and the computer will restart.
3 Use the Product Recovery DVD-ROM to execute
reinstallation.
A Press the 1 key to execute [1. [Recovery]].
(All of the screens below are only examples).
z The provision to perform the reinstallation will be displayed.
B If you agree, press the
If you do not agree, press the
z If you press the
z If you press the
1
key.
2
key.
1
key the menu will be displayed.
2
key the reinstallation will be complete.
C Make a selection from the menu.
z To return the computer to its status at the time of purchase
Press the
z To divide the hard disk into two partitions (for OS and data)
Press the
Enter the basic partition size (GB) for the operating system installation
and press the
• You can cancel this operation by pressing the
• The data partition size is the remainder after subtracting the basic
partition size. (Data partition: 1 GB or more)
Maximum settable size differs depending on the model.
z To reinstall Windows in the original partition without changing the parti-
tion configuration
Press the
• The first partition size must be 6 GB or more of the hard disk size.
Reinstallation cannot be performed with a small partition size.
1
2
3
key.
key.
key.
Enter
key.
0
key.
Troubleshooting
51
Reinstalling Software
D At the confirmation message, press the Y key.
The operation of reinstallation for the hard disk starts automatically. (The
operations take about 20 minutes.)
z Do not interrupt the reinstallation procedure before completion, for
example by turning off the computer or pressing the
key, as this may prevent Windows from starting up, or may cause data
to be lost so that the reinstallation procedure cannot be executed.
E The message "[Recovery] is complete" will be displayed. Remove the
Product Recovery DVD-ROM, and press any key to shut down the computer.
Ctrl+ Alt+ Del
4 Return the Setup Utility settings to their default values.
Return the Setup Utility to its settings at the time of shipment to ensure
proper setup of Windows.
A Turn on the computer, and press the
screen is displayed.
The Setup Utility will start up.
If the password has been set, enter the Supervisor Password, and press
the
Enter
B Press the
At the confirmation message, select [Yes] and press the
C Press the
At the confirmation message, select [Yes] and press the
The Setup Utility will close, and the computer will restart.
key.
F9
F10
key.
key.
F2
key while [Panasonic] boot
Enter
Enter
key.
key.
Troubleshooting
52
5 Setup Windows. (Î page 15)
6 Run the Setup Utility and change the settings where neces-
sary.
(The Setup Utility settings will return to their default values. Even the security
settings with the exception of the password(s), date and time will return to
their default values.)
7 If you can connect to the Internet, after the Internet Connec-
tion Firewall setting is enabled (Î page 36), perform Windows Update. (Î “Chapter 8: To Update this Computer to its Latest
Version” in onscreen Reference Manual)
Changing the drive letter
You can change the drive letter for the DVD-ROM & CD-R/RW drive or hard disk drive
by the following steps.
z Drive letters can only be changed when two or more partitions have been created
on the hard disk drive. The name of the C: drive cannot be changed.
z We recommend that you make these changes before installing applications.
A Click [start] - [Control Panel] - [Performance and Maintenance] - [Admin-
istrative Tools], and double click [Computer Management].
B Click [Disk Management] from [Storage].
C Right click on the partition of the hard disk or the name of the DVD-ROM &
CD-R/RW drive and click [Change Drive Letter and Paths...].
D Click [Change].
E Click [Assign the following drive letter] and select the new drive letter, and
then click [OK].
F At the confirmation message, click [Yes].
Troubleshooting
53
LIMITED USE LICENSE AGREEMENT
THE SOFTWARE PROGRAM(S) (“PROGRAMS”) FURNISHED WITH THIS PANASONIC® PRODUCT (“PRODUCT”)
ARE LICENSED ONLY TO THE END-USER (“YOU”), AND MAY BE USED BY YOU ONLY IN ACCORDANCE WITH
THE LICENSE TERMS DESCRIBED BELOW. YOUR USE OF THE PROGRAMS SHALL BE CONCLUSIVELY
DEEMED TO CONSTITUTE YOUR ACCEPTANCE OF THE TERMS OF THIS LICENSE.
Matsushita Electric Industrial Co., Ltd. (“MEI”) has developed or otherwise obtained the Programs and hereby licenses
their use to you. You assume sole responsibility for the selection of the Product (including the associated Programs) to
achieve your intended results, and for the installation, use and results obtained therefrom.
LICENSE
A. MEI hereby grants you a personal, non-transferable and non-exclusive right and license to use the Pro-
grams in accordance with the terms and conditions stated in this Agreement. You acknowledge that you are
receiving only a LIMITED LICENSE TO USE the Programs and related documentation and that you shall
obtain no title, ownership nor any other rights in or to the Programs and related documentation nor in or to
the algorithms, concepts, designs and ideas represented by or incorporated in the Programs and related
documentation, all of which title, ownership and rights shall remain with MEI or its suppliers.
B. You may use the Programs only on the single Product which was accompanied by the Programs.
C. You and your employees and agents are required to protect the confidentiality of the Programs. You may not
distribute or otherwise make the Programs or related documentation available to any third party, by time-
sharing or otherwise, without the prior written consent of MEI.
D. You may not copy or reproduce, or permit to be copied or reproduced, the Programs or related documenta-
tion for any purpose, except that you may make one (1) copy of the Programs for backup purposes only in
support of your use of the Programs on the single Product which was accompanied by the Programs. You
shall not modify, or attempt to modify, the Programs.
E. You may transfer the Programs and license them to another party only in connection with your transfer of the
single Product which was accompanied by the Programs to such other party. At the time of such a transfer,
you must also transfer all copies, whether in printed or machine readable form, of every Program, and the
related documentation, to the same party or destroy any such copies not so transferred.
F. You may not remove any copyright, trademark or other notice or product identification from the Programs
and you must reproduce and include any such notice or product identification on any copy of any Program.
YOU MAY NOT REVERSE ASSEMBLE, REVERSE COMPILE, OR MECHANICALLY OR ELECTRONICALLY TRACE
THE PROGRAMS, OR ANY COPY THEREOF, IN WHOLE OR IN PART.
YOU MAY NOT USE, COPY, MODIFY, ALTER, OR TRANSFER THE PROGRAMS OR ANY COPY THEREOF, IN
WHOLE OR IN PART, EXCEPT AS EXPRESSLY PROVIDED IN THE LICENSE.
IF YOU TRANSFER POSSESSION OF ANY COPY OF ANY PROGRAM TO ANOTHER PARTY, EXCEPT AS PERMITTED IN PARAGRAPH E ABOVE, YOUR LICENSE IS AUTOMATICALLY TERMINATED.
TERM
This license is effective only for so long as you own or lease the Product, unless earlier terminated. You may terminate
this license at any time by destroying, at your expense, the Programs and related documentation together with all copies thereof in any form. This license will also terminate effective immediately upon occurrence of the conditions therefor
set forth elsewhere in this Agreement, or if you fail to comply with any term or condition contained herein. Upon any
such termination, you agree to destroy, at your expense, the Programs and related documentation together with all copies thereof in any form.
YOU ACKNOWLEDGE THAT YOU HAVE READ THIS AGREEMENT, UNDERSTAND IT AND AGREE TO BE BOUND
BY ITS TERMS AND CONDITIONS. YOU FURTHER AGREE THAT IT IS THE COMPLETE AND EXCLUSIVE STATEMENT OF THE AGREEMENT BETWEEN US, WHICH SUPERSEDES ANY PROPOSAL OR PRIOR AGREEMENT,
ORAL OR WRITTEN, AND ANY OTHER COMMUNICATIONS BETWEEN US, RELATING TO THE SUBJECT MATTER OF THIS AGREEMENT.
About Intel
The enclosed software products and documentation were developed at private expense, and are provided with
“RESTRICTED RIGHTS.” Use, duplication or disclosure by the government is subject to restrictions as set forth in
FAR 52.227-14 and DFARS 252.227-7013 et. seq. or its successor. The use of this product by the government con-
Important Information
stitutes acknowledgment of Intel's proprietary rights in the product.
®
software products
54
Hard Disk Data Erase Utility
This computer is equipped with a utility for erasing hard disk data.
When disposing of or transferring ownership of this device, erase all data on the hard disk in order to prevent the theft of
hard disk data following the steps below.
The hard disk data erase utility erases data using an overwriting method, but there is a possibility that due to malfunctions or other operational errors, data may not be completely erased. There are also specialized devices that may be
able to read data that has been erased using this method. If you need to erase highly confidential data, we recommend that you contact a company that specializes in this process. Matsushita Electric Industrial Co., Ltd. will bear no
responsibility for losses or damages suffered as a result of the use of this utility.
Before Erasing Data
Preparing
z You will need the Product Recovery DVD-ROM (included).
Confirm the followings
z Be sure the AC adaptor is connected until the procedure is completed.
z This utility can only be used for internal hard disk. It cannot be used to erase data
from external hard disks.
z This utility cannot erase data from damaged disk.
z This utility cannot erase data for specific partitions.
z After executing this utility, the computer cannot be booted from the hard disk.
Completely Erasing Data
A Turn the computer on, and press the
screen is displayed.
The Setup Utility will start up.
If the password has been set, enter the Supervisor Password, and press
the
word.
B Select the [Boot] menu, then select [CD/DVD Drive] and press the
until [CD/DVD Drive] is at the top of the [Boot] menu.
C Place the Product Recovery DVD-ROM into the DVD-ROM & CD-R/RW
drive.
D Press the
At the confirmation message, select [Yes] and press the
The Setup Utility will close, and the computer will restart.
If [Enter Password] is displayed during the following procedure, enter the
Supervisor Password or User Password.
E When the message "Select a number" is displayed, press the
perform "2. [Erase HDD]."
(You can cancel this operation by pressing the
The confirmation message will be displayed.
Enter
F2
key while [Panasonic] boot
key. The [Boot] menu cannot be changed with User Pass-
F10
key.
0
Enter
key.)
key.
2
key and
F6
key
Important Information
55
Hard Disk Data Erase Utility
F Press the Y key.
Hard Disk Data Erase Utility will start.
(All of the screens below are only examples.)
G When [<<<Start menu>>>] is displayed, press the
H The approximate time required for erasing data will be displayed.
Press the
I At the confirmation message, press the
Space
key.
Enter
key.
Enter
key.
Important Information
56
The operation of erasing the hard disk starts.
z If necessary, the “hard disk data erase” operation can be cancelled
after it has begun by pressing the
If the operation is cancelled before being completed, a part of data will
not be erased.
J The message "Hard disk data has been deleted" will be displayed.
Remove the Product Recovery DVD-ROM, and press any key to shut
down the computer.
z If a problem occurred during the operation, an error message will be
displayed.
Ctrl+C
key.
Specifications
z Main Specifications
CF-W2DWADZBM
Model No.
CF-W2DWAEZBM
CF-W2DWAFZBM
CF-W2DWAGZBM
CPU/
Secondary cache memory
Chip Set
Main Memory
Video Memory
Hard Disk Drive
Intel® Pentium® M Processor 1.1 GHz ULV (FSB: 400 MHz)/
*
1
1MB
On-Die Level 2 (L2) Cache
Intel® 855 GM chip set
*
256 MB
(768 MB
UMA (64 MB
Approx. 40 GB
1
, DDR SDRAM
*
1
Max.)
*
1
Max.)
*3
*2
DVD-ROM & CD-R/RW Drive Buffer underrun error prevention function: Supported
*6
Continuous Data Transfer Speed
Playback
Continuous Data Transfer Speed
Recording
*4*5
*4*5
zDVD-RAM
/
zDVD-RW: 4X speed (Max.) zDVD-ROM*8: 8X speed (Max.) zCD-ROM*8: 24X speed
(Max.) zCD-R
zCD-R write
/
speed zHigh-Speed CD-RW write
CD-RW write
: 2X speed (4.7 GB*3)/1X speed (2.6 GB*3) zDVD -R*7: 4X speed (Max.)
*8
: 24X speed (Max.) zCD-RW*8: 24X speed (Max.)
*
9
: 4X speed, 8X speed, 8-16X speed, 8-24X speed zCD-RW write: 4X
*10*
11
: 8X speed, 10X speed, 8-16X speed
DVD-ROM (Single Layer, Dual Layer), DVD-R
*
Compatible Disk and Compatible For-
*
5
/Playback
mats
(Ver.1.1 4.7 GB, 9.4 GB)
*
3
, CD-Audio, CD-ROM (XA compatible), CD-R, Photo CD (multiple session com-
GB)
3
, DVD-RAM
patible), VideoCD, CD-EXTRA, CD-RW, CD-TEXT
Compatible Disks and Compatible For-
*
5
/Recording
mats
Display Method
Internal LCD Display
CD-R, CD-RW
12.1 XGA type (TFT) (1024
65,536/16,777,216 colors (1024
*
10
CF-W2DWBDZBM
CF-W2DWBEZBM
CF-W2DWBFZBM
CF-W2DWBGZBM
*
1
512 MB
(256-MB
, DDR SDRAM
*
1
RAM module
has been added to the
RAM module slot. 768
*
1
Max.)
MB
*
10
: 4X speed, 8X speed,10X speed zUltra-Speed
*
7
*
6
(1.4 GB, 2.8 GB, 2.6 GB, 5.2 GB, 4.7 GB, 9.4
× 768 dots)
*
× 768 dots)
12
(1.4 GB, 3.95 GB, 4.7 GB)
CF-W2DWGDZBM
CF-W2DWGEZBM
CF-W2DWGFZBM
CF-W2DWGGZBM
*
768 MB
(512-MB
1
, DDR SDRAM
*
1
RAM module
has been added to the
RAM module slot.)
*
3
, DVD-RW
*
External Display
13
Simultaneous Display on LCD + Exter-
*
nal Display
13
65,536/16,777,216 colors (800 × 600 dots/1024 × 768 dots/1280 × 1024 dots/1600 ×
1200 dots)
65,536/16,777,216 colors (800 × 600 dots, 1024 × 768 dots)
Wireless LAN Built in (Î page 59)
*
14
LAN
Modem
IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX
*
Data: 56 kbps (V.92 & K56flex)
15
FAX: 14.4 kbps
Sound WAVE and MIDI playback, Monaural Speaker (built in)
Card Slots
PC Card Slot × 1: (One Type I or Type II, Allowable current 3.3 V: 400 mA, 5 V: 400 mA)
*
SD Memory Card Slot
16
× 1
172-pin, 2.5 V, Micro DIMM, DDR SDRAM, PC2100 Compliant
To add the RAM module,
RAM Module Slot
remove the 256-MB
*
1
RAM
module currently in the
*
RAM module slot.
18
*
12
*
17
*
512-MB
1
RAM module has
been added to the RAM
module slot.
Important Information
57
Specifications
z Main Specifications
USB Ports
Interface
External Display Port: Mini Dsub 15-pin female / Microphone Jack: Miniature jack, 3.5
DIA / Headphone Jack: Miniature jack, 3.5 DIA
Keyboard/Pointing Device 85 keys/Touch Pad
Power AC adaptor or Battery pack
AC Adaptor
*
20
Input: 100 V - 240 V AC, 50 Hz/60 Hz
Output: 16 V DC, 2.5 A
Battery Pack Li-ion 7.4 V, 6.6 Ah
*
Operating Time
Charging Time
Power Consumption
Physical Dimensions (W × H × D)
21
*
24
*
25
Approx. 4 hours - 7.5 hours
Approx. 4.5 hours
Approx. 35 W
268 mm
protrusion) {10.6 "
Weight Approx. 1300 g {2.87 lb.}
Operation
Environment
Storage
*1
1 MB = 1,048,576 bytes
*2
A segment of the main memory is allotted automatically depending on the computer’s operating status. The size of the Video
Temperature
Humidity 30% to 80% RH (No condensation)
Temperature
Humidity 30% to 90% RH (No condensation)
5°C to 35°C {41°F to 95°F}
-20
°C to 60°C {-4°F to 140°F}
Memory cannot be set by the user.
*3
1 GB = 1,000,000,000 bytes. Operating system or some application software will report as fewer GB.
*4
Data transfer speeds indicate values measured by Matsushita Electric Industrial Co., Ltd.
*5
Performance of CD-R, CD-RW, DVD-RAM, DVD-R, and DVD-RW cannot be guaranteed depending on writing status and recording format. Also, some data cannot be played back depending on the disk, settings, and environment being used.
*6
In the case of DVD-RAM, only non-cartridge disks or removable cartridge disks can be used.
*7
DVD-R is compatible with 4.7 GB (for General) playback. DVD-R (for Authoring) playback is compatible with disks recorded using
Disk-at-Once recording.
*8
If an unbalanced disk (e.g., a disk with which the balance has been displaced from the center) is inserted, the speed may become
slower if there are large vibrations while the disk is rotating.
*9
Depending on the disk, the writing speed may become slower.
*10
To rewrite at 8-16X speed, a disc that accommodates Ultra-Speed is required (does not support 4X speed). Also, to rewrite at 810X speed, a disc that accommodates High-Speed is required.
*11
Does not support 24X speed rewriting.
*12
A 16,777,216 color display is achieved by using the dithering function.
*13
Display may be impossible using some connected external displays.
*14
Some devices cannot be used depending on the port type.
*15
The settings for the K56flex modem need to be changed according to the AT command.
*16
The transfer rate using the SD memory card slot on this computer is 2 MB per second (this is a theoretical value, and differs from
actual speeds). The transfer rate is 2 MB per second even if you use an SD memory card that supports high-speed transfer rates.
Does not guarantee connection/operation of all SD devices. Does not support SD I/O.
*17
A PC2700-compliant RAM module added to this computer, operates at the same speed as a PC2100-compliant RAM module.
*18
For the RAM module’s model number, refer to your technical support office. (Î page 60)
*19
Does not guarantee operation of all USB-compatible peripherals.
*20
<Only for North America>
The AC adaptor is compatible with power sources up to 240 V AC adaptor. This computer is supplied with a 125 V AC compatible AC cord.
*21
Varies depending on the usage conditions, CPU speed, etc.
*22
Measured using BatteryMark™ Version 4.0.1 (LCD brightness: Maximum - Minimum)
*23
Measured using MobileMark™ 2002 (LCD brightness: 60 cd/m2)
*24
Varies depending on the usage conditions, CPU speed, etc.
It may take a long time to charge a fully charged battery.
*25
Important Information
Approx. 1.5 W when the battery pack is fully charged (or not being charged) and the computer is off.
*26
Rated power consumption.
× 2（USB2.0 × 2）
*
26
× 27.5 mm (at the front)/41.5 mm (at the rear) × 209.2 mm (excluding
*
19
/ Modem Port（RJ-11）/ LAN Port（RJ-45）
*
22
(Approx. 5.5 hours
*
23
)
/ Approx. 40 W (maximum when recharging in the ON state)
× 1.1 " / 1.7 " × 8.3 "}
*
14
/
58
z Main Specifications
*
1
OS
Microsoft® Windows® XP Professional with Service Pack 2
Microsoft® Internet Explorer 6 Service Pack 2 / DirectX 9.0 c /
®
Windows® Media Player 9 / Microsoft® Windows® Movie Maker 2.1
®
Acrobat® Reader, Intel® PROSet, SD-MovieStage, SD Utility, Icon Enlarger, Touch Pad
Pre-installed Software
Microsoft
Adobe
Utility, DMI Viewer, PC Information Viewer, WinDVD™5 (OEM Version), B’s Recorder GOLD7
*
2
BASIC, B’s CLiP 5
Setup Utility, Hard Disk Data Erase Utility
*1
Operations of this computer are not guaranteed except for the pre-installed OS.
*2
Preinstalled B’s CLiP does not support CD-R.
*3
The Product Recovery DVD-ROM is required.
, Hotkey Settings
*
3
z Wireless LAN
*
4
Data Transfer Speeds
IEEE802.11b: 11 Mbps/5.5 Mbps/2 Mbps/1 Mbps (automatic switching)
IEEE802.11g: 54 Mbps/48 Mbps/36 Mbps/24 Mbps/18 Mbps/12 Mbps/9 Mbps/6 Mbps (automatic
*
4
switching
)
Conformance Standards IEEE802.11b/IEEE802.11g (wireless LAN standard protocol)
Forwarding Methods
Effective Distances
OFDM, DS-SS
About 50 m unobstructed (during communications with access point)
*
5
Wireless Channels Used Channels 1-11
RF Frequency Bands All 2.4 GHz bands (2.4 GHz - 2.4835 GHz)
*4
These are speeds specified in IEEE802.11b+g standards. Actual speeds may differ.
*5
Effective distances differ depending on surrounding conditions such as radio wave environment, obstructions, and setting environment, and on usage conditions such as application software and OS.
Important Information
59
LIMITED WARRANTY
PANASONIC PERSONAL COMPUTER AND PERIPHERALS LIMITED WARRANTY
Panasonic Computer Solutions Company (referred to as “Panasonic”) will repair this product (other than software, which is covered
by a separate warranty) with new or rebuilt parts, free of charge in the U.S.A. for three (3) years from the date of original purchase in
the event of a defect in materials or workmanship. This warranty includes the AC adaptor but excludes the batteries and all other
options and accessories which are covered for a period of one (1) year from the date of purchase.
This warranty is extended solely to the original purchaser. A purchase receipt or other proof of date of original purchase will be
required before warranty performance is rendered.
This warranty only covers failures due to defects in materials or workmanship which occur during normal use. It does not cover damage which occurs in shipment or failures which are caused by products not supplied by Panasonic, or failures which result from alteration, accident, misuse, introduction of liquid or other foreign matter into the unit, abuse, neglect, installation, maladjustment of
consumer controls, improper maintenance, modification or service by anyone other than a Factory Service Center or authorized
Panasonic Service Dealer, or damage that is attributable to acts of God.
Limits and Exclusions:
There are no other express warranties except as listed below.
PANASONIC SHALL NOT BE LIABLE FOR LOSS OF DATA OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS WARRANTY. ALL EXPRESS AND
IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE. Some states do not allow the exclusion or
limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above limitations or
exclusions may not apply to you.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state. If a problem
with your product develops during or after the warranty period, you may contact our representatives shown below.
In U.S.A In Japan
z For General Inquiry in English:
DIAL TOLL FREE: (888) 270-5615
Monday-Friday (excluding US holidays)
9:00a.m.-5:30p.m. (CST)
z For Technical Support in English:
DIAL TOLL FREE: (800) LAPTOP5 (527-8675)
365 days/24hours
(888) 715-5155 (in Japanese)
Monday-Friday (excluding US holidays, Dec.24, Dec.25,
z For General Inquiry in English:
1-888-270-5615 (chargeable call)
Monday-Friday (excluding US holidays)
9:00a.m.-5:30p.m. (CST)
z For Technical Support in English:
1-800-527-8675 (chargeable call)
365 days/24hours
DIAL TOLL FREE: 0120-873029 (in Japanese)
365 days/9:00 a.m.-8:00p.m. (Japan Time)
Dec.30, Dec.31, the day before Thanksgiving Day and
the day following Thanksgiving Day)
10:00a.m.-7:00p.m. (EST)
If the problem is not handled to your satisfaction, then write to the Consumer Affairs Division at the address indicated below.
SOFTWARE LIMITED WARRANTY
Panasonic Computer Solutions Company (referred to as “Panasonic”) warrants to you only that the disk(s) or other media on which
the Programs are furnished will be free from defects in materials and workmanship under normal use for a period of sixty (60) days
from the date of delivery thereof to you, as evidenced by your purchase receipt.
This is the only warranty Panasonic makes to you. Panasonic does not warrant that the functions contained in the Programs will meet
your requirements or that the operation of the Programs will be uninterrupted or error free.
Panasonic’s entire liability, and your exclusive remedy under this warranty shall be limited to the replacement, in the United States, of
any defective disk or other media which is returned to Panasonic’s Authorized Service Center, together with a copy of the purchase
receipt, within the aforesaid warranty period.
Anything in the foregoing to the contrary notwithstanding, Panasonic shall have no obligation for any defects in the disk(s) or other
media on which the Programs are furnished resulting from your storage thereof, or for defects that have been caused by operation of
the disk(s) or other media otherwise than on the Product or in environmental conditions other than those specified by Panasonic by
alteration, accident, misuse, abuse, neglect, mishandling, misapplication, installation, maladjustment of consumer controls, improper
maintenance, modification of damage that is attributable to acts of God. In addition, Panasonic shall have no obligation for any
Important Information
defects in the disk(s) or other media if you have modified, or attempted to modify any Program.
60
DURATION OF IMPLIED WARRANTIES, IF ANY, IS LIMITED TO SIXTY (60) DAYS.
PANASONIC ASSUMES NO RISK OF AND SHALL NOT IN ANY CASE BE LIABLE FOR ANY DAMAGES, INCLUDING, WITHOUT
LIMITATION, ANY SPECIAL, INCIDENTAL, CONSEQUENTIAL, OR PUNITIVE DAMAGES ARISING FROM BREACH OF WARRANTY OR CONTRACT, NEGLIGENCE OR ANY OTHER LEGAL THEORY, INCLUDING, WITHOUT LIMITATION LOSS OF
GOODWILL, PROFITS OR REVENUE, LOSS OF USE OF THE PROGRAMS OR PRODUCTS OR ANY ASSOCIATED EQUIPMENT, COST OF CAPITAL, COST OF ANY SUBSTITUTE EQUIPMENT, FACILITIES, SERVICES, DOWNTIME COSTS, OR
CLAIMS OF ANY PARTY DEALING WITH YOU FOR SUCH DAMAGES.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on how long an implied
warranty lasts, so the above limitations or exclusions may not apply to you.
This limited warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
This Limited Warranty will be governed by the laws the State of New York, without regard to its conflict-of-laws rules.
* * *
To obtain service or technical assistance within the continental U.S.A. and Alaska.
In U.S.A In Japan
z For General Inquiry in English:
DIAL TOLL FREE: (888) 270-5615
Monday-Friday (excluding US holidays)
9:00a.m.-5:30p.m. (CST)
z For Technical Support in English:
DIAL TOLL FREE: (800) LAPTOP5 (527-8675)
365 days/24hours
(888) 715-5155 (in Japanese)
Monday-Friday (excluding US holidays, Dec.24, Dec.25,
z For General Inquiry in English:
1-888-270-5615 (chargeable call)
Monday-Friday (excluding US holidays)
9:00a.m.-5:30p.m. (CST)
z For Technical Support in English:
1-800-527-8675 (chargeable call)
365 days/24hours
DIAL TOLL FREE: 0120-873029 (in Japanese)
365 days/9:00 a.m.-8:00p.m. (Japan Time)
Dec.30, Dec.31, the day before Thanksgiving Day and
the day following Thanksgiving Day)
10:00a.m.-7:00p.m. (EST)
Correspondence requesting product information should be sent to:
Panasonic Computer Solutions Company
50 Meadowlands Parkway, Panazip 2F-5, Secaucus, NJ 07094
Important Information
61
Memo
Important Information
62
Important Information
63
Index
Also, refer to onscreen Reference Manual. Some explanations that are not described in this manual may be described
in onscreen Reference Manual. (Î page 8)
A
Antivirus Measures .......... 36
B
Battery Pack Indicator...... 12
Dealing with Problems
.................................... 45
C
Caps Lock ........................ 12
Clicking ............................ 21
D
Disk Operations (Dealing with
Problems) ........................ 45
Display
Dealing with Problems
.................................... 43
Display Change ........... 22
LCD Brightness Control
.................................... 22
Double-Clicking ................ 21
Double-Tapping ............... 21
Dragging .......................... 21
DVD-ROM & CD-R/RW Drive
Indicator ........................... 12
Usage Precautions ........ 7
E
Emergency Hole .............. 38
Enter Password (Dealing with
Problems) ........................ 42
F
Fast User Switching Function
(Dealing with Problems) .. 46
H
Hard Disk Drive Indicator . 12
Hibernation Function (Deal-
ing with Problems) ............ 44
I
Important Tips .................... 8
M
Maintenance .................... 32
N
Notification Area .............. 18
NumLk ............................. 12
P
PC Information Viewer ..... 47
Peripheral Devices .......... 37
Popup Window ................ 22
Power Indicator ................ 12
R
RAM Module (Dealing with
Problems) ........................ 46
Reference Manual ............. 8
Dealing with Problems
.................................... 45
Reinstalling B’s Recorder/B’s
CLiP ................................. 45
Right-Click ....................... 21
S
ScrLk Indicator .................12
Scroll ................................21
SD Card Setup (Dealing with
Problems) .........................45
SD Memory Card Indicator
......................................... 12
Setup Utility ...................... 25
Speaker On/Off Switch .....22
Standby Function (Dealing
with Problems)...................44
Starting Up (Dealing with
Problems) .........................41
T
Tapping ............................21
V
Volume Control .................22
W
Windows Update ..............36
