Panasonic AP8S71 Users Manual

Operating Instructions

Steam Convection Microwave Oven

Model: NN-CS597S

READ ALL INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN.

Para instrucciones en español, voltee el libro.

For assistance, please call: 1-800-211-PANA(7262) or send e-mail to: consumerproducts@panasonic.com or visit us at www.panasonic.com (U.S.A)

For assistance, please call: 787-750-4300 or visit us at www.panasonicpr.com (Puerto Rico)

F00038S70AP

iPress0707-0

Printed in China

IP1156_38S70AP_Eng_12_070705.indd 1IP1156_38S70AP_Eng_12_070705.indd 1 2007-7-5 10:54:262007-7-5 10:54:26

Table of Contents

Safety Information

Precaution .............................................................................................................................................1

Important Safety Instructions ..............................................................................................................2-4

Installation and Grounding Instructions ..............................................................................................5-6

Safety Precautions .......................................................................................................................... 7-10

Cookware and Container Guide .....................................................................................................11-12

Cookware and Container Chart ...........................................................................................................13

Speciﬁcations ......................................................................................................................................14

IP1156_38S70AP_Eng_12_070705.indd 2IP1156_38S70AP_Eng_12_070705.indd 2 2007-7-5 10:54:262007-7-5 10:54:26

Microwave Oven Safety

Your safety and the safety of others are very important.

We have provided important safety messages in this manual and on your appliance. Always read and obey all safety messages.

This is the safety alert symbol. It is used to alert you to potential hazards that can kill or hurt you and others. The safety messages will follow the safety alert symbol and either the word “DANGER”, “WARNING” or “CAUTION”. These words mean:

You can be killed or seriously injured if you don’t

DANGER

immediately follow instructions.

WARNING

CAUTION

The safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can happen if the instructions are not followed.

You can be killed or seriously injured if you don’t follow instructions.

You can be exposed to a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

PRECAUTIONS TO AVOID

POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE ENERGY

(a) Do not attempt to operate this oven with the door open since open-door operation can result

in harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

(b) Do not place any object between the oven front face and the door or allow soil or cleaner

residue to accumulate on sealing surfaces.

properly and that there is no damage to the: (1) door (bent), (2) hinges and latches (broken or loosened), (3) door seals and sealing surfaces. (d) The oven should not be adjusted or repaired by anyone except properly qualiﬁed service

personnel.

IP1156_38S70AP_Eng_12_070705.indd Sec2:1IP1156_38S70AP_Eng_12_070705.indd Sec2:1 2007-7-5 10:54:262007-7-5 10:54:26

Thank you for purchasing a Panasonic Microwave Oven.

Your microwave oven is a cooking appliance and you should use as much care as you use with a stove or any other cooking appliance. When using this electrical appliance, basic safety precautions should be followed, including the following:

IMPORTANT SAFETY INSTRUCTIONS

WARNING

persons, or exposure to excessive microwave energy:

1. Read all instructions before using this appliance.

2. Read and follow the speciﬁc “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY,” found on page 1.

3. This appliance must be grounded. Connect only to a properly grounded outlet. See “GROUNDING INSTRUCTIONS” found on page 5 and 6.

4. As with any cooking appliance, DO NOT leave oven unattended while in use.

5. Install or locate this appliance only in accordance with the installation instructions found on page 5.

6. DO NOT cover or block any openings on this appliance.

7. DO NOT store this appliance outdoors. DO NOT use this product near water— for example, near a kitchen sink, in a wet basement, or near a swimming pool or similar locations.

8. Use this appliance only for its intended use as described in this manual. DO NOT use corrosive chemicals, vapors, or non-food products in this appliance. This type of oven is speciﬁcally designed to heat, or cook food. It is not designed for industrial or laboratory use. The use of corrosive chemicals in heating or cleaning will damage the appliance and may result in radiation leaks.

9. When cleaning surfaces of the door and oven that come together on closing the door, use only mild, non-abrasive soaps or detergents applied with a sponge or soft cloth.

10. DO NOT allow children to use this appliance, unless closely supervised by an adult. DO NOT assume that because a child has mastered one cooking skill he/she can cook everything.

11. DO NOT operate this appliance if it has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped.

12. DO NOT immerse cord or plug in water.

13. Keep cord away from heated surfaces.

14. DO NOT let cord hang over edge of a table or counter.

15. This appliance should be serviced only by qualiﬁed service personnel. Contact the nearest authorized service center for examination, repair or adjustment.

16. Some products such as whole eggs with or without shell, narrow neck bottles and sealed containers — for example, closed glass jars — may explode and should not be heated in this oven.

17. To reduce the risk of ﬁre in the oven cavity:

(a) DO NOT overcook food. Carefully attend appliance when paper, plastic, or other combustible

materials are placed inside the oven to facilitate cooking. (b) Remove wire twist-ties from paper or plastic bags before placing bag in oven. (c) If material inside the oven ignites, keep oven door closed, turn oven off, and

disconnect the power cord, or shut off power at the fuse or circuit breaker panel. (d) DO NOT use the cavity for storage purposes. DO NOT leave paper products, cooking

utensils or food in the cavity when not in use.

18. Superheated Liquids Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point

without showing evidence (or signs) of boiling. Visible bubbling is not always present when the container is removed from the microwave oven. THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS INSERTED INTO THE LIQUID.

— To reduce the risk of burns, electric shock, ﬁre, injury to

IP1156_38S70AP_Eng_12_070705.indd Sec1:2IP1156_38S70AP_Eng_12_070705.indd Sec1:2 2007-7-5 10:54:272007-7-5 10:54:27

IMPORTANT SAFETY INSTRUCTIONS

To reduce the risk of injury to persons:

(a) STIR THE LIQUID BOTH BEFORE AND HALFWAY THROUGH HEATING IT. (b) DO NOT heat water and oil, or fats together. The ﬁlm of oil will trap steam, and may

cause a violent eruption.

(c) DO NOT use straight-sided containers with narrow necks. (d) After heating, allow the container to stand in the microwave oven for a short time before

removing the container.

19. DO NOT cook directly on the glass tray. It can crack, cause injury or damage to the oven.

(continued)

WARNING

TO AVOID THE RISK OF SHOCK: DO NOT remove outer panel from oven. Repairs must be done only by a

qualiﬁed service person.

TO REDUCE THE RISK OF EXPOSURE TO MICROWAVE ENERGY: DO NOT tamper with, or make any adjustments or repairs to Door,

Control Panel Frame, Safety Interlock Switches, or any other part of oven, microwave leakage may result.

TO AVOID THE RISK OF FIRE:

1. DO NOT operate the oven empty. The microwave energy will reﬂect continuously throughout the oven causing overheating and damage, if food or water is not present to absorb energy.

2. DO NOT store ﬂammable materials next to, on top of, or in the oven.

3. DO NOT dry clothes, newspapers or other materials in the oven, or use newspaper or paper bags for cooking.

4. DO NOT hit or strike Control Panel. Damage to controls may occur.

5. DO NOT use recycled paper products unless the paper product is labeled as safe for microwave oven use.

Recycled paper products may contain impurities which may cause sparking.

TO AVOID THE RISK OF SCALDING: POT HOLDERS should always be used when removing items from the oven. Heat is transferred from

the HOT food to the cooking container and from the container to the Glass Tray. The Glass Tray can also be very HOT after removing the cooking container from the oven.

SAVE THESE INSTRUCTIONS

For proper use of your oven, read remaining safety cautions and operating instructions.

IP1156_38S70AP_Eng_12_070705.indd Sec1:3IP1156_38S70AP_Eng_12_070705.indd Sec1:3 2007-7-5 10:54:272007-7-5 10:54:27
