Palm ROAE Users Manual

User Guide

Intellectual property notices

© 2010 Palm, Inc., a subsidiary of Hewlett-Packard Company. Palm, XXX, Synergy, Touchstone, webOS, and the Palm and XXX logos are among the trademarks or registered trademarks owned by or licensed to Palm, Inc. Microsoft and Outlook are trademarks of the Microsoft group of companies. Exchange ActiveSync Enabled. Facebook Facebook, Inc. Google and Google Maps are trademarks of Google, Inc. Amazon, Amazon MP3, and the Amazon MP3 logo are trademarks of Amazon.com, Inc. or its affiliates. Quickoffice is a registered trademark of Quickoffice, Inc. All other brand and product names are or may be trademarks of their respective owners.

Disclaimer and limitation of liability

Palm, Inc. and its suppliers assume no responsibility for any damage or loss resulting from the use of this guide. Palm, Inc. and its suppliers assume no responsibility for any loss or claims by third parties that may arise through the use of this software. Palm, Inc. and its suppliers assume no responsibility for any damage or loss caused by deletion of data as a result of malfunction, dead battery, or repairs. Be sure to make backup copies of all important data on other media to protect against data loss.

Patent pending. This product also is licensed under United States patent 6,058,304.

Use of this device requires providing a valid email address, mobile phone number, and related information for account setup and activation. A data plan is also required. An unlimited usage data plan is strongly recommended or additional data charges may apply.

Open Source License information

You can view the Open Source License terms on your phone. Tap the center of the gesture area and then tap the Launcher icon. Swipe left until the PDF View icon appears. Tap PDF View and then tap Open Source Information.pdf.

is a registered trademark of

As part of Palm’s corporate commitment to be a good steward of the environment, we strive to use environmentally friendly materials, reduce waste, and develop the highest standards in electronics recycling.

v. 1.0

You can also view the file on your computer. Connect your phone to your computer with the

USB cable. On your phone, tap USB Drive. On your computer, locate and double-click the

removable drive named for your phone. To locate the drive, do the following for your operating system:

• Windows Vista/Windows 7: Open Computer.

• Windows XP: Open My Computer.

• Mac: Open Finder.

• Linux (Ubuntu): The drive is displayed on the desktop.

• Other Linux distribution: The location of the drive may vary by system.

After you open the drive, double-click the file Open Source Information.pdf.

Recycling and disposal

This symbol indicates that Palm products should be recycled and not be disposed of in unsorted municipal waste. Palm products should be sent to a facility that properly recycles electrical and electronic equipment. For information on environmental programs visit palm.com/environment or recyclewirelessphones.com/.

Chapter 1 Basics

6 Get to know your phone 9Set up your phone 9 Turn the phone on/off 10 Open applications 11 Work with applications 12 Enter and save information 13 Use the menus 14 View and respond to notifications 15 Find info on your phone

Chapter 2 Phone

18 Make calls 19 Receive calls 19 Use voicemail 19 What can I do during a call? 20 Set up and use a Bluetooth

Chapter 3 Email and other messages

22 Email 23 Messaging

hands-free device

Chapter 5 Photos, videos, and music

32 Camera 32 Photos 33 Videos 33 Music

Chapter 6 Web and wireless connections

36 Wi-Fi 36 Web 36 Bluetooth

wireless technology

Chapter 7 Documents

38 PDF View

Chapter 8 Preferences

40 Screen & Lock 40 Sounds & Ringtones

Chapter 9 Learn More

Chapter 4 Contacts, Calendar, and other personal

information

28 Contacts 30 Calendar

44 While using your phone

Regulatory and Safety Information

Index

Contents 3

4Contents

Basics

You’re about to discover the many things about your

XXX™ phone that will help you better manage

Palm your life and have fun, too. As you become more familiar with your phone, you’ll want to personalize the settings and add applications to make it uniquely yours.

But first, take the few easy steps in this chapter to set up your phone and get it running. Then learn about the key features that make moving around on your phone and accessing your information easy: gestures, menus, search, notifications, and more.

In this chapter

6Get to know your phone 9 Set up your phone 9 Turn the phone on/off 10 Open applications 11 Work with applications 12 Enter and save information 13 Use the menus 14 View and respond to notifications 15 Find info on your phone

Chapter 1 : Basics 5

Get to know your phone

Slide out the keyboard

• Hold the phone as shown below and gently push up.

Front view

6Chapter1:Basics

1 Earpiece 2 Touchscreen: Tap and make other gestures directly on the screen. 3 Vo lu me 4 Gesture area: Make the back gesture and begin other gestures here. 5 Microphone 6 Keyboard: See Use the keyboard. 7 Charger/microUSB connector 8 Connector cap

TIP Be careful not to scratch, crush, or apply too much pressure on the

touchscreen. Do not store your phone in a place where other items might damage it. Do not use harsh chemicals, cleaning solvents, or aerosols to clean the phone or its accessories.

Keyboard

To u c h s c r e e n

1 Application name: Displays the name of the currently open application. Drag down over

the app name to open the application menu.

2 Launcher: See Open an application in the Launcher. 3 Scroll arrow: Swipe up or down to see icons that are on the page but hidden. 4 Quick Launch: See Open an application in Quick Launch. 5 Connection icons: Show the status of wireless service connections and battery strength .

Drag down over the icons to open the connection menu.

6 Page indicators: Show how many Launcher pages are to the right or the left of the

currently displayed page. Swipe left or right on the screen to see other pages.

7 Notification icons: Show missed calls, new voicemail and email messages, and more. Tap

the bottom of the screen to view notification details.

1 Option: Press to enter numbers, punctuation, and symbols that appear above the letters on

the keys (see Enter alternate keyboard characters), or to move the cursor.

2 Shift: See Enter uppercase letters. 3 Space 4 Backspace 5 Enter: Press to enter a line return (for example, in a memo or in an email message you are

composing) or to accept information you entered in a field.

6 Sym: Press to enter symbols and accented characters that don't appear on the keys.

Chapter 1 : Basics 7

Back view

The back cover of your XXX phone is compatible with the TouchstoneTM charging dock (sold separately).

To p v ie w

1 Power: Press to wake up or turn off the screen. Press and hold to turn wireless services on

and off, replace the battery, or turn your device completely on and off. Turn your device completely off before you remove the battery.

2 Ringer switch: Slide to turn the ringer and notification sounds on or off. (Red means off.)

The ringer switch does not affect music or video playback sounds.

3 3.5mm headset jack.

Bottom view

1 Camera flash 2 Camera lens 3 Speaker

8Chapter1:Basics

* Back cover release

Set up your phone

Verify your profile

After you finish setup, look for an email on your computer at the address you used for your Palm profile. If you don’t see the confirmation email in your Inbox, check your spam mail folder in your desktop email program. Click the link in the email to do the following:

• Verif y you r Pal m prof i le.

• Follow a link to learn about getting data like contacts and appointments

onto your phone from your desktop organizer software.

Tu r n t h e p h o n e o n /o f f

Your XXX phone’s screen can be turned on and off separately from its wireless services (which are the Phone app, Wi-Fi app, and Bluetooth organizer features of your device (Calendar, Contacts, Tasks, Memos, and so on) without turning on the phone and other wireless features. Also, when the screen is turned off, the phone can be on and ready for you to receive phone calls or messages.

app). This means you can wake up the screen to use just the

To turn the screen on, do one of the following:

• Press power . Drag up to unlock the screen.

* Power

• Slide out the keyboard.

TIP You can also unlock the screen by dragging up from the gesture area across

the onscreen lock icon.

To turn the screen off, press power .

To save power, the screen dims automatically after a period of inactivity, then turns off. You can be on a call when the screen dims and turns off—this does not affect the call. To brighten the screen after it dims, tap the screen.

Turn the screen on/off

Turn the screen on and leave the wireless services turned off when you want to use only the organizer features, for example, when you’re on a plane and you must turn off all wireless services, but you want to look at your calendar.

TIP You can set how long the screen stays on during a period of inactivity).

Turn wireless services off (airplane mode)

Airplane mode turns off your phone as well as the Bluetooth® wireless technology and Wi-Fi features. Use airplane mode when you are on a plane or anywhere else you need to turn off all wireless services. You can’t browse the web, but you can still use apps like Calendar, Contacts, Photos, Music, Doc View, and PDF View.

Chapter 1 : Basics 9

Do one of the following:

Open an application in the Launcher

• Tap the upper-right corner of any screen to open the connection menu.

Ta p Turn on Airplane Mode.

• Press and hold power and tap Airplane Mode.

When your phone is in airplane mode, the airplane mode icon appears at the top of every screen, and Airplane Mode appears in the upper-left corner of the screen in the Launcher, Card view, and Phone. Your phone is not connected to any mobile network.

TIP When your phone is in airplane mode, you can turn the Wi-Fi and Bluetooth

features on individually. To turn your phone back on, you must turn airplane mode off.

Turn wireless services on

When you turn on your phone, it automatically connects to your mobile network so that you can make and receive phone calls and use other wireless services (if supported by the local network).

If airplane mode is turned on, you need to turn it off before you can connect to your mobile network. Tap the upper-right corner of any screen to open the connection menu. Tap Tu rn o ff A ir pl a n e M od e .

The Launcher displays all your applications. The Launcher includes multiple pages, which you can organize to group apps the way you want.

1 If you’re in an app, tap the center of the gesture area to display Card

view.

2 In Card View, tap .

TIP You can also open the Launcher by flicking up twice from the gesture area to

the screen. If you are in Card view, just flick up once to open the Launcher

3 To find the app you want, swipe up or down to see all the icons on a

page. To see other pages, swipe right or left on the screen, or tap the arrows in the upper-left and upper-right corner of the screen.

4 Tap the application icon.

To close the Launcher, do one of the following:

• Tap the center of the gesture area.

• Tap .

• Make the up gesture: Flick up from the gesture area to the screen.

When you are inside a coverage area, the bars of the signal-strength icon are filled in according to the strength of the signal. If you're outside a coverage area, the bars in the signal-strength icon appear dimmed with an X.

Open applications

You can have as many applications open at one time as you like, limited only by the amount of memory available on your phone at the time.

10 Chapter 1 : Basics

Open an application in Quick Launch

Quick Launch is the bar of five icons you can access from any app. Quick Launch always appears at the bottom of Card view.

You can customize Quick Launch to contain the icons for apps you use most often. To open an application from Quick Launch, just tap the icon.

Quick Launch can display no more than five icons. By default it displays, from left to right, Phone, Contacts, Email, Calendar, and the Launcher. You can change the order of icons (except the Launcher icon) in Quick Launch, or swap in whatever applications you like.

NOTE If you have a notification or the dashboard is open, you need to dismiss

them to access Quick Launch.

Work with applications

Make the following gesture to display Quick Launch and open one of its applications.

1 Drag up slowly from the gesture area to the screen.

NOTE Don’t confuse this “drag up” with the up gesture, which is a flick up from

the gesture area to the screen that displays Card view.

2 Move your finger to the application icon. When you see the app name

appear, lift your finger. The application opens.

Go up one level in an app (back gesture)

The back gesture takes you up one level from a detailed level to a more general view of the application you're working in. For example, when you finish reading an email message, make the back gesture to close the message and return to your list of messages. Or when you finish writing a memo, make the back gesture to close and save the memo and return to the display of all your memos. When you make the back gesture in an application and that's the only screen of that app that's open, you minimize the app and go back to Card view.

To make the back gesture, swipe right to left anywhere in the gesture area.

Display all open applications (Card view)

Card view displays open applications as small cards so that you can easily scroll through them and drag them to change their order.

When an application fills the screen and you want to go to Card view, do one of the following:

• Tap the center of the gesture area.

• Make the up gesture: Flick up from the gesture area to the screen.

Open an application Universal Search

1 Tap the center of the gesture area to open Card view.

2 Begin typing the name of the application or one of its keywords.

3 When the application icon appears in the search results, tap it.

Move among open applications

1 In Card view, swipe left or right on the screen to see other open apps.

Chapter 1 : Basics 11

2 Tap a card to maximize the application.

TIP You can also maximize the center card in Card view by flicking down from the

screen to the gesture area.

TIP You can set a preference to move among open apps without first going to

Card view.

Close an application

4 Backspace 5 Enter: Press to enter a line return (for example, in a memo or in an email message you are

composing) or to accept information you entered in a field.

6 Sym: See Enter characters from the symbols table.

Enter uppercase letters

By default, the first letter of each sentence or field is capitalized and the remaining text you enter is lowercase. To enter other uppercase letters, do one of the following:

• In Card view, throw the card off the top of the screen.

Enter and save information

Use the keyboard

• Press Shift and press the letter key. The Shift symbol appears. You

don’t need to hold down Shift while you press the letter key.

• Turn on Caps Lock: Press Shift twice. The Caps Lock symbol

appears.

• Turn off Caps Lock: Press .

Enter alternate keyboard characters

Numbers, punctuation, and symbols appear above the letters on the keys. To enter these characters, do one of the following:

• Press Option and press the key for the character. The alternate

character symbol appears. You don’t need to hold down Option while pressing the second key.

• Enter a series of alternate characters: Press Option twice to turn on

Option Lock. The Option Lock symbol appears.

• Turn off Option Lock: Press Option .

Enter passwords

1 Option: Press to enter numbers, punctuation, and symbols that appear above the letters on

the keys (see Enter alternate keyboard characters), or to move the cursor.

2 Shift: See Enter uppercase letters. 3 Space

12 Chapter 1 : Basics

You can see each character of a password only as you enter it, so be careful. Be sure Caps Lock and Option lock are off unless you need them. For information on how to enter characters, see Enter uppercase letters and

Enter alternate keyboard characters.

Enter characters from the symbols table

Select items in a list

You can enter symbols and accented characters that don't appear on the keys by using the symbols table. See Symbols and accented characters for a list of the available symbols and accented characters.

1 Press Sym to display the symbols table.

2 Narrow the list by pressing the key that corresponds to the character

you want. For example, to enter an é, press e. See the table below for a list of corresponding characters.

TIP The symbols and accented characters are grouped according to their

similarity to the corresponding key. In some cases, the symbol is related to the alternate character on the key, not the letter. For example, to type a € or other currency symbol, press Sym + h. Why? Because the alternate character on the H key is $.

TIP If you press the wrong key, press Backspace to return to the full list of

symbols and accented characters. You can then press another key.

3 Scroll to find the character you want.

4 Tap the character to insert it.

Lists enable you to select from a range of options. Lists are different from menus, which give you access to additional features.

Lists are hidden until you tap the currently displayed option for that list.

1 Tap the currently displayed option to open the list. For example, when

creating a new event in Calendar, tap 15 minutes before to display the list of reminder options.

2 Tap the list item you want.

Save information

• On most screens, your information is saved automatically. Just make the

back gesture to close the screen, and your info is saved at the same time.

• Your info is also saved if you minimize an app screen to a card and throw

the card off the top of the screen to close the app.

• On screens with a Done button, tap Done to save your information.

Use the menus

Enter information in a field

You can enter information in a field by typing or by pasting previously copied information. The auto-correct feature works with all text fields.

To accept the information you entered, do one of the following:

• Tap outside the field.

• Press Enter . If a screen contains multiple fields, pressing Enter accepts

the information you just entered and moves the cursor to the next field.

• When you are done entering information on the screen containing the

field, make the back gesture to accept the information and back out of the screen.

Most applications have an application menu hidden in the upper-left corner, which provides access to additional features. There is also a connection menu hidden in the upper-right corner, which provides access to wireless services.

Some applications have additional menus. For example, in Photos, tap an open picture and tap to display a menu of tasks you can do with the picture (see Photos).

To get the most out of your phone, it’s a good idea to familiarize yourself with the additional features available through the menus in various applications.

Chapter 1 : Basics 13

Open the application menu

The application menu contains items for the application you are working in, such as Cut and Copy, Preferences, Help, and other application-specific menu items. Help is available on the app menu of every application.

1 In an app, do one of the following:

• Drag down from the upper-left corner of the phone (above the

screen) onto the screen.

• Tap the application name in the upper-left corner of the screen.

2 Tap a menu item to open it. If a menu item displays a right-pointing

arrow , tap the item to display the submenu for that item—for example, tap the Edit menu item to open a submenu containing Cut, Copy, and Paste items. If you see a downward-pointing arrow at the bottom of the menu, scroll down to see additional menu items.

mode)). If you see a downward-pointing arrow at the bottom of

the menu, scroll down to see additional menu items.

3 To close the menu without selecting an item, repeat one of the options

in step 1.

View and respond to notifications

Respond to a notification

Notifications show up at the bottom of the screen to notify you of new voicemail and messages, upcoming appointments, missed calls, application updates, and more. By default, if a notification arrives when the screen is off, the gesture area light pulses. You can turn this feature off.

3 To close the menu without selecting an item, repeat one of the options

in step 1.

Open the connection menu

The connection menu lets you manage wireless services—the phone, Bluetooth

1 Do one of the following:

2 Tap a menu item to turn that wireless feature on or to display a list of

wireless technology, and Wi-Fi.

DID YOU KNOW? The connection menu also displays the current day and date

and the battery charge level.

• Drag down from the upper-right corner of the phone (above the

screen) onto the screen.

• Tap the upper-right corner of the screen.

menu items for that feature (see Turn wireless services off (airplane

Do one of the following:

• Tap the notification to act on it.

• For some types of notifications, throw the notification off the side of the

screen to dismiss it.

View all your notifications

For most types of notifications, if you do not tap a notification after a few seconds, it becomes an icon in the lower-right portion of the screen.

1 Tap anywhere on the bottom of the screen to display your

notifications.

2 Tap a notification to act on it. If the notification has a number next to it,

the number indicates how many items are included in the notification—how many voicemail or email messages you have, and so on.

Some notifications enable you to perform multiple actions. For example, on a calendar notification, tap the calendar icon to open Calendar in Day view

14 Chapter 1 : Basics

with the event displayed, or tap the event name to open the event details screen.

Find info on your phone

You can search for contacts and applications on your phone.

1 Open Card view or the Launcher.

2 Begin typing the search term. As you type, your phone displays the

following items whose name matches the characters you entered. As you continue typing, the search results narrow.

• Applications, including apps you have downloaded from App

Catalog

• Contacts

3 Do one of the following:

• To open an application: Tap the application.

• To look up or get in touch with someone: Tap a contact name to

open the person’s contact information. Tap a phone number to dial it, an email address to send a message, and so on.

• To search your company's Global Address List (GAL) for a contact:

Ta p Global Address Lookup.

Chapter 1 : Basics 15

16 Chapter 1 : Basics

Phone

Yo u r Pa l m® XXX™ phone enables you to effectively manage multiple calls. You can answer a second call, swap between calls, and set up a three-way conference call. You can also work with other applications while on a call. Your Palm helps you to do all these tasks with ease.

XXX™ phone
