PALM CONNECT USB KIT User Manual

Macintosh

Windows

Read This First

Getting Started

PalmConnect

USB Kit

English...................................................1

Deutsch ...............................................13

Français...............................................23

Español................................................33

Italiano ................................................43

Table of Contents

PalmConnect®USB Kit enables you to connect your Palm Computing®platform handheld to a USB port on a Macintosh or PC. The kit includes a USB to serial port adapter and a CD-ROM with USB drivers for both the Macintosh and PC and Palm™ Desktop software for Macintosh. Follow the installation instructions in this guide for best results.

System requirements

• Palm Computing platform handheld

• Apple Macintosh or compatible computer with a Power PC processor and USB port, running MacOS 8.5.1 or

• IBM-compatible 486 PC or higher with USB port, running Windows 98 and Palm Desktop 3.0 or later

Introduction

PalmConnect®USB software includes Palm™ Desktop software to help you organize your addresses, appointments, tasks, and notes. It also contains HotSync®Manager software that transfers data between your Macintosh and your handheld.

Turn on your Macintosh.

Install the Palm Desktop software. Note: If you have a previous version of Palm Desktop software installed, it is

important that you install this version from the CD-ROM. If you are using other organizer software instead of Palm Desktop software, you still need to complete this process to install HotSync Manager.

• Insert the PalmConnect USB CD-ROM into your CD-ROM drive, then double-click the Palm™ Desktop Installer icon.

• Follow the onscreen instructions. The installer prompts you to do the following:

– Enter a user name. (If you have already performed a HotSync operation,

select the same name.) – Select PalmConnect USB from the Port list. – Reboot your Macintosh when the installation is done.

Make the connection.

• Connect the USB to serial port adapter to your cradle connector (or HotSync Cable).

Macintosh installation instructions

Macintosh installation instructions (continued)

Note: The AC adapter is only required for Palm V™ organizer users.

• Connect the USB to serial port adapter to the USB port on your Macintosh.

Synchronize your data.

• Double-click the Palm™ Desktop icon in the Palm folder.

• Place your handheld in the cradle and press the HotSync®button.

Congratulations!

You have successfully completed this installation and performed your first HotSync operation using the USB port on your computer.

Macintosh troubleshooting tips

How can I update my Macintosh to the latest MacOS?

Go to the Apple web site http://www.apple.com. This web site contains instructions for updating to the latest release of the MacOS.

Why can’t I perform a HotSync®operation after I plug in my USB to serial port adapter?

The serial port settings need to be adjusted. To correct this problem, follow these steps:

1. Check the USB to serial port adapter connections.

2. Launch HotSync Manager.

3. Disable HotSync Manager.

4. Click the Serial Port Settings tab.

5. Under Local Setup, select PalmConnect USB from the Port list.

6. Click the HotSync Controls tab and select Enabled.

7. Try performing a HotSync operation.

Why does an error message appear when I remove the USB to serial port adapter and reboot my Macintosh?

HotSync Manager does not support all USB plug and play features. If you temporarily disconnect the USB to serial port adapter, the following error message appears: “HotSync Manager has been disabled because the USB cable is not plugged into your Macintosh. Please reconnect the cable to the USB port before enabling HotSync Manager.” To proceed, simply click OK in the message box. To prevent this error message from appearing during reboot, launch HotSync Manager, choose Setup, disable HotSync Manager, and then disconnect the USB to serial port cable. Future versions of HotSync Manager will eliminate this error message.

Note: For additional troubleshooting tips, see the readme file for Palm™ Desktop

software.

PC installation instructions

Turn on your computer.

Install the Palm™ Desktop software. Note: You must install the Palm™ Desktop software before you install the

PalmConnect®USB software. Even if you are using Microsoft Outlook or other organizer software instead of Palm Desktop software, you still need to complete this process to install HotSync®Manager.

Important! Make sure the PalmConnect USB to serial port adapter is NOT connected to your PC. Wait until you are instructed to connect it in step 4.

• If Palm Desktop 3.0 or later is already installed on your PC, skip to step 3.

• Insert the Palm Desktop CD-ROM that came with your handheld and follow the onscreen instructions.

Note: The installer will prompt you to connect the cradle to the serial port on your

PC and choose a Com port. These steps are optional since the PalmConnect USB to serial port adapter and software use a USB port.

Insert the PalmConnect USB CD-ROM into the CD-ROM drive on your PC.

Make the connection.

• Connect the USB to serial port adapter to your cradle connector (or HotSync Cable).

• Connect the USB to serial port adapter to the USB port on your PC.

Note: The AC adapter is only

required for Palm V™ organizer users.

PC troubleshooting tips

The USB installer software didn’t launch after I connected the USB to serial port adapter; what do I do?

Some PC manufacturers do not enable the USB feature in the system BIOS. Consult your computer’s manual or contact the PC manufacturer to determine how to access the BIOS Setup software and enable the USB feature.

Do I need my Windows 98 CD-ROM during the installation process?

If you upgraded from Windows 95 to Windows 98 you may need the Windows 98 CD-ROM during the USB installation process.

Why is my PC hanging when I remove the USB to serial port adapter?

Most likely an older version of HotSync Manager is installed on your PC. To correct this problem, reinstall the PalmConnect®USB software. See the readme file for PalmConnect USB software for instructions.

Note: For additional troubleshooting tips, see the readme file for PalmConnect

USB software.

Install the PalmConnect®USB software.

After you connect the USB to serial port adapter, the installation software launches automatically. Simply follow the onscreen instructions. When prompted to provide the location of the USB driver, select your CD-ROM drive. (The drivers are located on the CD-ROM you inserted in step #3.)

Synchronize your data.

Place your handheld in the cradle and press the HotSync®button.

Congratulations!

You have successfully completed this installation and performed your first HotSync operation using the USB port on your computer.

PC installation instructions (continued)

Limited warranty

HARDWARE: Palm Computing, Inc., a subsidiary of 3Com Corporation (collectively “3Com”), warrants to the original end user (“Customer”) that this product will be free from defects in workmanship and materials, under normal use, for one year from the date of original purchase from 3Com or its authorized reseller. 3Com’s sole obligation under this express warranty shall be, at 3Com’s option and expense, to replace the product or part with a comparable product or part, repair the product or part, or if neither repair nor replacement is reasonably available, 3Com may, in its sole discretion, refund to Customer the purchase price paid for the product or part. Replacement products or parts may be new or reconditioned. 3Com warrants any replaced or repaired product or part, and any hardware upgrade to which Customer is entitled under an agreement between Customer and 3Com, for a period of ninety (90) days from shipment, or through the end of the original warranty, whichever is longer. All products or parts that are replaced become the property of 3Com.

Accessory products, as listed in the applicable 3Com catalogue, are not covered under this Limited Warranty except for the modem for the connected organizer, the cradles, cables, memory upgrades, and leather items sold under the 3Com

brand. 3Com shall not be responsible for Customer’s software, firmware, information, or memory data contained in, stored on, or integrated with any products returned to 3Com for repair, whether under warranty or not.

SOFTWARE: 3Com warrants to Customer that the Palm™ Desktop organizer software and Palm OS™ software licensed from it will perform in substantial conformance to their program specifications, for a period of ninety (90) days from the date of original purchase from 3Com or its authorized reseller. 3Com warrants the media containing software against failure during the warranty period. No updates are provided. 3Com does not provide any warranty for Adobe

Acrobat®Reader or any other third-party applications software that is licensed to Customer by the third party. 3Com’s sole obligation with respect to this express warranty shall be (at 3Com’s discretion) to refund the purchase price paid by Customer for any defective software product, or to replace any defective media with software which substantially conforms to applicable 3Com published specifications. 3Com makes no warranty or representation that its software products will meet Customer’s requirements or will work in combination with any hardware or applications software products provided by third parties, that the operation of the software products will be uninterrupted or error free, or that all defects in the software products will be corrected.

YEAR 2000 WARRANTY: In addition to the Hardware Warranty and Software Warranty stated above, 3Com warrants that the following datedata sensitive Palm Computing

products, namely the Pilot 1000, Pilot 5000, PalmPilot™ Personal Edition, PalmPilot Professional Edition, Palm III™, Palm IIIx™, Palm V™, and Palm VII™ connected organizers, as well as all other 3Com products based on the Palm Computing platform software as of July 1, 1998 and later, including the companion desktop software for Microsoft®Windows®and MAC OS™ platforms, will continue performing properly with regard to such date-data on and after January 1, 2000, provided that all other products used by Customer in connection or combination with the Palm Computing product, including hardware, software, and firmware, accurately exchange date-data with the Palm Computing product. 3Com makes no certification regarding the Year 2000 status of any other Palm Computing products.

Any Palm Computing platform application supplied by 3Com that makes correct use of Palm Computing platform date and time functions will not have a problem transitioning to the year 2000. The date and time utilities for the Palm Computing platform use 32 bits to store seconds, starting at January 1, 1904. This approach allows the correct representation of dates through February 5, 2040. The Date Book software currently displays dates through December 31, 2031. Provided the product is still being sold by 3Com, 3Com will make software enhancements to remove these limitations well in advance of these dates.

If it appears that any Palm Computing product does not perform properly with regard to such date-data on and after January 1, 2000, and Customer notifies Palm Computing before the later of April 1, 2000, or ninety (90) days after original purchase of the product from 3Com or its authorized reseller, 3Com shall, at its option and expense, provide a software update which would effect the proper performance of the product, repair the product, deliver to Customer an equivalent product to replace the product, or, if none of the foregoing is feasible, refund to Customer the purchase price paid for the product.

Any software update or replaced or repaired Palm Computing product will carry a Year 2000 Limited Warranty for ninety (90) days after purchase or until April 1, 2000, whichever is later.

Customers using date and time utilities other than those supplied by Palm Computing should check with the developer to determine if the software will correctly handle all of the subtle issues of date and time conversion.

OBTAINING WARRANTY SERVICE: Customer must contact a Palm Computing, Inc. or 3Com Technical Support or Customer Service center within the applicable warranty period to obtain warranty service authorization. Dated proof of original purchase from 3Com or its authorized reseller will be required. 3Com is not responsible for Customer products or parts received without a warranty service authorization. In the United States, 3Com may ship a replacement product or part prior to receiving the original product or part (“advance exchange”). If advance exchange is not available, then the repaired product or part will be shipped as soon as reasonably possible, which will be no later than thirty (30) days after 3Com receives the original product or part. Repaired or replacement products will be shipped to Customer at 3Com’s expense. The repair and replacement process for products or parts in locations outside of the United States will vary depending on Customer’s location. Products or parts shipped by Customer to 3Com must be sent prepaid and packaged appropriately for safe shipment, and it is recommended that they be insured or sent by a method that provides for tracking of the package. When an advance exchange is provided and Customer fails to return the original product or part to 3Com within thirty (30) days from the date the warranty service authorization is issued, 3Com will charge Customer the then-current published catalogue price of such product or part.

WARRANTIES EXCLUSIVE:

IF THIS PRODUCT DOES NOT OPERATE AS WARRANTED ABOVE, CUSTOMER’S SOLE REMEDY FOR BREACH OF THAT WARRANTY SHALL BE REPLACEMENT OR REPAIR OF THE PRODUCT OR PART OR REFUND OF THE PURCHASE PRICE PAID, AT 3COM’S OPTION. TO THE FULL EXTENT ALLOWED BY LAW, THE FOREGOING WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER WARRANTIES, TERMS, OR CONDITIONS, EXPRESS OR IMPLIED, EITHER IN FACT OR BY OPERATION OF LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES, TERMS, OR CONDITIONS OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, SATISFACTORY QUALITY, CORRESPONDENCE WITH DESCRIPTION, AND NON-INFRINGEMENT, ALL OF WHICH ARE EXPRESSLY DISCLAIMED. 3COM NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF ITS PRODUCTS.

3COM SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT OR MALFUNCTION IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED ATTEMPTS TO OPEN, REPAIR, OR MODIFY THE PRODUCT, OR ANY OTHER CAUSE BEYOND THE RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OTHER HAZARDS, OR ACTS OF GOD. THIS WARRANTY DOES NOT COVER PHYSICAL DAMAGE TO THE SURFACE OF THE PRODUCT, INCLUDING CRACKS OR SCRATCHES ON THE LCD TOUCHSCREEN OR OUTSIDE CASING. THIS WARRANTY DOES NOT APPLY WHEN THE MALFUNCTION RESULTS FROM THE USE OF THIS PRODUCT IN CONJUNCTION WITH ACCESSORIES, OTHER PRODUCTS, OR ANCILLARY OR PERIPHERAL EQUIPMENT AND 3COM DETERMINES THAT THERE IS NO FAULT WITH THE PRODUCT ITSELF. THIS WARRANTY DOES NOT APPLY TO ANY MALFUNCTION OR FAILURE OF THE PRODUCT OR PART DUE TO ANY COMMUNICATION SERVICE CUSTOMER MAY SUBSCRIBE TO OR USE WITH THE PRODUCT.

LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW, 3COM ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY,

WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE

DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATA, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE, OR INTERRUPTION OF THIS PRODUCT, EVEN IF 3COM OR ITS AUTHORIZED RESELLER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, AND LIMITS ITS LIABILITY TO REPLACEMENT, REPAIR, OR REFUND OF THE PURCHASE PRICE PAID, AT 3COM’S OPTION. THIS DISCLAIMER OF LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.

DISCLAIMER: Some countries, states, or provinces do not allow the exclusion or limitation of implied warranties or the limitation of incidental or consequential damages for certain products supplied to consumers, or the limitation of liability for personal injury, so the above limitations and exclusions may be limited in their application to you. When the implied warranties are not allowed to be excluded in their entirety, they will be limited to the duration of the applicable written warranty. This warranty gives you specific legal rights which may vary depending on local law.

GOVERNING LAW: This Limited Warranty shall be governed by the laws of the State of California, U.S.A. excluding its conflicts of laws principles and excluding the United Nations Convention on Contracts for the International Sale of Goods.

Palm Computing, Inc., a subsidiary of 3Com Corporation 5400 Bayfront Plaza PO Box 58007 Santa Clara, California 95052-8007 United States of America (408) 326-5000 May 20, 1999

YOU SHOULD CAREFULLY READ THE FOLLOWING TERMS AND CONDITIONS BEFORE USING THIS PRODUCT. IT CONTAINS SOFTWARE, THE USE OF WHICH IS LICENSED BY PALM COMPUTING, INC., A SUBSIDIARY OF 3COM CORPORATION (COLLECTIVELY, “3COM”), TO ITS CUSTOMERS FOR THEIR USE ONLY AS SET FORTH BELOW. IF YOU DO NOT AGREE TO THE TERMS AND CONDITIONS OF THIS AGREEMENT, DO NOT USE THE SOFTWARE. USING ANY PART OF THE SOFTWARE INDICATES THAT YOU ACCEPT THESE TERMS.

LICENSE: 3Com grants you a nonexclusive license to use the accompanying software program(s) (the “Software”) subject to the terms and

restrictions set forth in this License Agreement. You are not permitted to lease or rent (except under separate mutually agreeable terms set forth in writing), distribute or sublicense the Software or to use the Software in a time-sharing arrangement or in any other unauthorized manner. Further, no license is granted to you in the human readable code of the Software (source code). Except as provided below, this License Agreement does not grant you any rights to patents, copyrights, trade secrets, trademarks, or any other rights in respect to the Software.

The Software is licensed to be used on any personal computer and/or any 3Com product, provided that the Software is used only in connection with 3Com products. With respect to the Desktop Software, you may reproduce and provide one (1) copy of such Software for each personal computer or 3Com product on which such Software is used as permitted hereunder. With respect to the Device Software, you may use such Software only on one (1) 3Com product. Otherwise, the Software and supporting documentation may be copied only as essential for backup or archive purposes in support of your use of the Software as permitted hereunder. You must reproduce and include all copyright notices and any other proprietary rights notices appearing on the Software on any copies that you make.

Notwithstanding any other provision of this License Agreement, this License Agreement shall not be deemed to apply to the Adobe

Acrobat®Reader software or any other applications software licensed to you by third parties that is included on the same media as 3Com’s Software (“Other Software”) if the Other Software provides that the use of the Other Software is subject to the terms and conditions of the third party’s license agreement.

NO ASSIGNMENT; NO REVERSE ENGINEERING: You may transfer the Software and this License Agreement to another party if the other party agrees in writing to accept the terms and conditions of this License Agreement. If you transfer the Software, you must at the same time either transfer all copies of the Software as well as the supporting documentation to the same party or destroy any such materials not transferred. Except as set forth above, you may not transfer or assign the Software or your rights under this License Agreement.

Modification, reverse engineering, reverse compiling, or disassembly of the Software is expressly prohibited. However, if you are a European Community (“EC”) resident, information necessary to achieve interoperability of the Software with other programs within the meaning of the EC Directive on the Legal Protection of Computer Programs is available to you from 3Com upon written request.

EXPORT RESTRICTIONS: You agree that you will not export or re-export the Software or accompanying documentation (or any copies thereof) or any products utilizing the Software or such documentation in violation of any applicable laws or regulations of the United States or the country in which you obtained them.

The software covered by this agreement may contain strong data encryption code which cannot be exported outside of the U.S. or Canada. You agree that you will not export/reexport, either physically or electronically, the encryption software or accompanying documentation without obtaining written authorization from the U.S. Department of Commerce.

TRADE SECRETS; TITLE: You acknowledge and agree that the structure, sequence and organization of the Software are the valuable trade secrets of 3Com and its suppliers. You agree to hold such trade secrets in confidence. You further acknowledge and agree that ownership of, and title to, the Software and all subsequent copies thereof regardless of the form or media are held by 3Com and its suppliers.

UNITED STATES GOVERNMENT LEGEND: The Software is commercial in nature and developed solely at private expense. The Software is delivered as “Commercial Computer Software” as defined in DFARS 252.227-7014 (June 1995) or as a commercial item as defined in FAR

2.101(a) and as such is provided with only such rights as are provided in this License Agreement, which is 3Com’s standard commercial license for the Software. Technical data is provided with limited rights only as provided in DFAR 252.227-7015 (Nov. 1995) or FAR 52.227-14 (June

1987), whichever is applicable.

TERM AND TERMINATION: This License Agreement is effective until terminated. You may terminate it at any time by destroying the Software and documentation together with all copies and merged portions in any form. It will also terminate immediately if you fail to comply with any term or condition of this License Agreement. Upon such termination you agree to destroy the Software and documentation, together with all copies and merged portions in any form.

3Com end user software license agreement

GOVERNING LAW: This License Agreement shall be governed by the laws of the State of California as such laws are applied to agreements

entered into and to be performed entirely within California between California residents and by the laws of the United States. You agree that the United Nations Convention on Contracts for the International Sale of Goods (1980) is hereby excluded in its entirety from application to this License Agreement.

LIMITED WARRANTY; LIMITATION OF LIABILITY: All warranties and limitations of liability applicable to the Software are as stated on the Limited Warranty Card or in the product manual accompanying the Software. Such warranties and limitations of liability are incorporated herein in their entirety by this reference.

SEVERABILITY: In the event any provision of this License Agreement is found to be invalid, illegal or unenforceable, the validity, legality and enforceability of any of the remaining provisions shall not in any way be affected or impaired and a valid, legal and enforceable provision of similar intent and economic impact shall be substituted therefor.

ENTIRE AGREEMENT: This License Agreement sets forth the entire understanding and agreement between you and 3Com, supersedes all prior agreements, whether written or oral, with respect to the Software, and may be amended only in a writing signed by both parties.

Palm Computing, Inc., a subsidiary of 3Com Corporation 5400 Bayfront Plaza PO Box 58007 Santa Clara, California 95052-8007 United States of America (408) 326-5000 September 3, 1998

FCC Statement

This device complies with part 15 of the FCC rules. Operation is subject to the condition that this device may not cause harmful interference.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC

rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

■

Reorient or relocate the receiving antenna.

■

Increase the separation between the equipment and receiver.

■

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

■

Consult the dealer or an experienced radio/TV technician for help.

The use of shielded I/O cables is required when connecting this equipment to any and all optional peripheral or host devices. Failure to do so may violate FCC rules.

Caution: Changes or modifications not covered in this manual must be approved in writing by the manufacturer’s Regulatory Engineering

Department. Changes or modifications made without written approval may void the user’s authority to operate this equipment.

Palm Computing, Inc., a subsidiary of 3Com Corporation 5400 Bayfront Plaza PO Box 58007 Santa Clara, California 95052-8007 United States of America (408) 326-5000

PalmConnect®USB Kit 3C90201U

Tested to Comply

With FCC Standards

FOR HOME OR OFFICE USE

Canadian RFI Statement

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur le matériel brouilleur du Canada.

Canadian ICES-003 Statement

This Class B digital apparatus meets all of the requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numerique de la classe B respecte toutes les exigences du Reglement sur le materiel brouilleur du Canada.

CE Compliance Statement

This product was tested by Palm Computing, Inc., a subsidiary of 3Com Corporation and found to comply with all the requirements of the EMC Directive 89/336/EEC as amended.

Statement of Conformity

Statement Of Conformity to the Voluntary Control Council for Interference from Information Technology Equipment (VCCI) Class B ITE for Regular Members.

This is a Class B product based on the standard of the Voluntary Control Council for Interference from Information Technology Equipment (VCCI). If this is used near a radio or television receiver in a domestic environment, it may cause radio interference. Install and use the equipment according to the instruction manual.

Copyright © 1999 3COM Corporation or its subsidiaries. All rights reserved. 3Com, the 3Com logo, HotSync, Palm Computing, and PalmConnect are registered trademarks, and the HotSync logo, Palm, the Palm Computing Platform logo, and Palm V are trademarks of Palm Computing, Inc., 3Com Corporation or its subsidiaries. Other product and brand names may be trademarks or registered trademarks of their respective owners.

Mit dem PalmConnect®USB-Zubehör können Sie Ihr Handheld-Gerät für die Palm Computing®-Plattform in den USB-Anschluß eines Macintosh oder PCs einstecken. Im Zubehör enthalten ist ein Anschlußadapter (USB/seriell) und eine CD-ROM mit USB-Treibern für den Macintosh und den PC sowie der Palm™ Desktop-Software für den Macintosh. Zur Erzielung optimaler Ergebnisse folgen Sie bitte den Installationsanweisungen in diesem Handbuch.

Systemanforderungen

• Handheld-Gerät für die Palm Computing-Plattform

• Apple Macintosh oder kompatibler Computer mit Power PC-Prozessor und USB-Anschluß, auf dem MacOS 8.5.1 ausgeführt wird oder

• IBM-kompatibler 486er PC oder höher, mit USB-Anschluß, auf dem Windows 98 und Palm Desktop 3.0 oder höher ausgeführt wird

Einleitung

Die PalmConnect®USB-Software enthält die Palm™ Desktop-Software, mit deren Hilfe Sie Adressen, Termine, Aufgaben und Notizen verwalten können. Im Lieferumfang befindet sich außerdem die HotSync®Manager-Software, mit der Daten zwischen Ihrem Macintosh und Ihrem Handheld-Gerät übertragen werden.

Schalten Sie Ihren Macintosh ein.

Installieren Sie die Palm Desktop-Software. Hinweis: Sie müssen unbedingt diese Version der Palm Desktop-Software von der

CD installieren, auch wenn Sie bereits eine frühere Version der Software installiert haben. Wenn Sie statt der Palm Desktop-Software eine andere Organizer-Software verwenden, muß der folgende Vorgang trotzdem durchgeführt werden, um den HotSync Manager zu installieren.

• Legen Sie die PalmConnect USB CD-ROM in Ihr CD-ROM-Laufwerk ein, und doppelklicken Sie anschließend auf das Symbol des Palm™ Desktop-Aktualisierungsprogramms.

• Befolgen Sie die Anweisungen auf dem Bildschirm. Das Aktualisierungsprogramm fordert Sie zu den folgenden Eingaben auf:

– Eingabe eines Benutzernamens. (Wurde bereits ein HotSync-Vorgang

durchgeführt, können Sie denselben Namen verwenden.) – Wahl von „PalmConnect USB“ in der Liste der Anschlüsse. – Neustart des Macintosh nach abgeschlossener Installation.

Stellen Sie eine Verbindung her.

• Verbinden Sie den Anschlußadapter (USB/seriell) mit der Docking-Station (oder dem HotSync-Kabel).

Installationsanweisungen für den Macintosh

Synchronisieren Sie Ihre Daten.

• Doppelklicken Sie auf das Symbol „Palm™ Desktop“ im Palm-Ordner.

• Setzen Sie Ihr Handheld-Gerät in die Docking-Station ein, und drücken Sie auf die HotSync®-Taste.

Herzlichen Glückwunsch!

Sie haben die Installation erfolgreich abgeschlossen und den ersten HotSync-Vorgang über einen USB-Anschluß auf dem Computer durchgeführt.

• Verbinden Sie den Anschlußadapter (USB/seriell) mit dem USB-Anschluß Ihres Macintosh.

Installationsanweisungen für den Macintosh

(Fortsetzung)

Hinweis: Der AC-Adapter wird nur für den Palm V™ Organizer benötigt.

Tips für die Fehlerbehebung auf dem Macintosh

Wie aktualisiere ich meinen Macintosh mit der neuesten MacOS?

Gehen Sie zur Apple Website unter http://www.apple.com. Hier finden Sie Hinweise zur Aktualisierung mit der neuesten MacOS-Version.

Warum kann ich nach dem Einstecken meines Anschlußadapters (USB/seriell) keinen HotSync®-Vorgang durchführen?

Die Einstellungen des seriellen Anschlusses müssen geändert werden. Führen Sie dazu die folgenden Schritte aus:

1. Überprüfen Sie die Verbindungen des Anschlußadapters.

2. Starten Sie den HotSync Manager.

3. Deaktivieren Sie den HotSync Manager.

4. Klicken Sie auf die Registerkarte „Serial Port Settings“.

5. Wählen Sie in „Local Setup“ „PalmConnect USB“ in der Liste der Anschlüsse.

6. Klicken Sie auf die Registerkarte „HotSync Controls“, und wählen Sie „Enabled“.

7. Versuchen Sie, einen HotSync-Vorgang durchzuführen.

Warum erhalte ich eine Fehlermeldung, wenn ich den Anschlußadapter entferne und den Macintosh neu starte?

Der HotSync Manager unterstützt nicht alle USB-Plug & Play-Funktionen. Ist die Verbindung zum Anschlußadapter zeitweise unterbrochen, erhalten Sie folgende Fehlermeldung: „HotSync Manager has been disabled because the USB cable is not plugged into your Macintosh. Please reconnect the cable to the USB port before enabling HotSync Manager.“ Klicken Sie zum Fortfahren auf „OK“. Um zu verhindern, daß diese Meldung während des Neustarts erneut angezeigt wird, starten Sie HotSync Manager, wählen Sie „Setup“, deaktivieren Sie HotSync Manager, und ziehen Sie anschließend das Adapterkabel heraus. In künftigen HotSync Manager-Versionen erscheint diese Fehlermeldung nicht mehr.

Hinweis: Weitere Tips zur Fehlerbehebung finden Sie in der Readme-Datei der

Palm™ Desktop-Software.
