OWI AMP-HDTR62SVC Specifications

ARCHITECTS AND ENGINEERS

SPECIFICATIONS / TECHNICAL DATA

3 Source, 6", Integratable on a 2X2 Tile

with UL Listed Metal Backcan

GENERAL SPECIFICATIONS

MODEL NUMBER: 2X2AMP-HD2S61

ELECTRICAL AMPLIFIER:

Input voltage, nominal

(25 watts) 15 volts DC

Input current, operating (15VDC)

1.45 amperes peak

Input volt-amperes, peak (15VDC)

22 volt-amperes

Input voltage, maximum

16.5 volts, DC

Frequency Response,

EQ set to flat

20Hz to 20 kHz

Bass

±10dB@50Hz

Treble

±10dB@10kHz

THD + Noise

<1% at 13.5 watts, “A” weighted

S/N

>82 dB

Max Power Output (28V in)

40 watts

DC Power, Standby

1.4 watts

AC Power, Sleep Mode

1.4 watts

DC Power,

Short Circuit protected

Yes

Over current protected

Yes

Over voltage protected

Yes

Over temperature protected

Yes

Minimum Load Impedance

4.0 Ω (Two 8 Ω Speakers in parallel)

Minimum Input impedance, Priority in

10,000 Ω

Minimum Input impedance, RJ45 in

150,000 Ω

Minimum Input impedance, mini-jack

37,000 Ω

Min. Input Impedance, Mini-Jack:

2300 Ω

Woofer Size:

6.5 Inches

Weight of Amplifier/Speaker:

15 Lbs.

Height of Amplifier/Speaker:

4.5 Inches

Backcan:

UL Listed Enclosure (Included)

Tile Bridge:

2X2 Metal Tile (Included)

Warranty:

1 Year

**Mechanical “UL Rating” is dependent upon use of the Backcan and Tile Bridge.

Note: Maximum power requires the replacement of the 15 Volt supply with a
22 Volt supply and Energy Star and UL approvals no longer apply.

SELF POWERED
SPEAKER/AMPLIFIER
