OVISLINK KVM-102 User Manual

SWITCH FOR 2 COMPUTERS ACCESS
KVM-102

OvisLink thanks you for the loyalty you have shown in our company, for sure the
performance and the quality of our devices will satisfy your demands.

Package content:

Before proceed with the installation procedure, please make sure you have
received all the next elements:

- KVM Switch

- All cables included

- Quick Installation Guide.

If any element is missing, please contact with your distributor.

Quick Installation Guide:
Operation:

1.First turn on the monitor followed by the KVM Switch, then the PC.

2.Make sure each PC is boot-up completely before switching the KVM Switch.

*To activate the scan mode (Auto status):

-Hot Key operation :

*To deactivate the scan mode (Manual status):

-Press on the keyboard:

*To select PC:

-Hot Key operation:

ENGLISH

1

Scroll

Lock

Scroll

Lock

ESC

Scroll

Lock

Scroll

Lock

ESC

LED:

After the computer is turned on, the front panel shows:

- PC1/PC2 LED : The LED will be lit for the PC which is selected or scanned.

- AUTO LED : It’s on manual mode when turn on the PC, so the LED will not
be lit.

Adjust the SCAN TIME:

1. 5 sec. in original design.

2. Press into the Auto Scan mode.

3. Press or to choice the scan rate.

SCAN

RATE

Num Lock

LED

Caps Lock

LED

Scroll Lock

LED

5 Sec. OFF OFF ON

10 Sec. ON OFF OFF

15 Sec. ON OFF ON

20 Sec. OFF ON OFF

25 Sec. OFF ON ON

30 Sec. ON ON OFF

Note: If the power wased turn off, the scan rate will back to the original
design- 5 seconds.

ENGLISH

2

Scroll

Lock

Scroll

Lock

+

-

SPECIFICATIONS

FUNCTION SPECIFICATION

Model ( PS/2 ) KVM-102

Description 2 PCs to 1 Use

Scan Rate “5 sec / 10 sec / 15 sec

20 sec / 25 sec / 30 sec”

PC side connector HD-15M x 2

MD-6M x 4

3.5 Ø phone jack x 2

Console side connector HD-15F x 1

MD-6F x 2

3.5 Ø phone jack x 1

Audio Support YES

TRANSMISION DISTANCE

PC side to Switch 5 Meter

Console side to Switch 3 Meter

CABLE Molding with 1.2M Coaxial cable

Vertical Frequency

43-250Hz

Max. Resolution 1920 x 1440

Video Bandwidth 250MHz

Horizontal Frequency

30-180KHz
