Oster TSSTTVXXLL Instruction Manual

Download

MODEL

TSSTTVXXLL-049

Instruction Manual

EXTRA LARGE CAPACITY TOASTER OVEN

READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE

TSSTTVXXLL-049_15EM1.indd 1 7/15/15 1:48 PM

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed including the following:

READ ALL INSTRUCTIONS, PRODUCT LABELS AND WARNINGS BEFORE USING THE TOASTER OVEN.

1. DO NOT touch hot surfaces . Always use oven mitts when handling hot materials and allow metal parts to cool before cleaning. Allow the unit to cool thoroughly before putting in or taking off parts. Always use the oven handles when moving the unit.

2. When the unit is not in use and before cleaning, unplug the oven from the wall outlet. Note: Make sure the oven is turned off before unplugging.

3. To protect against risk of electrical shock, do not immerse the appliance in water or any other liquids.

4. DO NOT operate this or any appliance with a frayed or damaged cord or plug or after the appliance malfunctions or is dropped or has been damaged in any manner. Take this appliance only to the nearest Authorized Service Center for examination, repair or adjustment.

5. DO NOT use attachments not recommended by the manufacturer; they may cause re, electric shock or personal injury.

6. DO NOT use outdoors or for commercial purposes.

7. DO NOT use this appliance for other than its intended use.

8. DO NOT let the cord dangle over the edge of a tabletop or countertop or touch hot surfaces.

9. DO NOT place the appliance near a hot gas or electric burner or in a heated oven.

10. Extreme caution should be used when using containers constructed of material other than metal or glass.

11. DO NOT store any items on top of the appliance when in operation. A re may occur

if the toaster oven is covered or touching ammable materials, including curtains,

draperies, walls, etc., when in operation.

12. When using the oven, pull the unit out a minimum of 15 cm (6 inches) away from walls on all sides. Remove cords from other products from behind the oven.

13. DO NOT store any materials, other than manufacturer’s recommended accessories, in this unit when not in use.

14. DO NOT place any ammable materials in oven, such as paper, cardboard, plastic or any materials that may catch re or melt.

15. DO NOT cover the oven with metal foil. This will cause overheating of the appliance.

TSSTTVXXLL-049_15EM1.indd 1 7/15/15 1:48 PM

16. The door or the outer surface may get hot when the appliance is operating.

17. Oversized foods or metal utensils must not be inserted in the appliance as they may

create a re or risk of electrical shock.

18. DO NOT clean with metal scouring pads. Pieces can break off the pad and touch electrical parts involving a risk of electrical shock.

19. When broiling, use extreme caution when removing tray or disposing of hot grease.

20. The door and the outer surface may get hot when appliance is used.

21. To turn this appliance off, return all controls to the off “O” position.

22. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.

23. Close supervision is necessary when any appliance is used by or near children, or incapacitated individuals.

24. The instructions shall state that appliances are not intended to be operated by means of an external timer or separate remote-control system.

25. This appliance is intended to be used in household and similar applications such as:

staff kitchen areas in shops, ofces and other working environments, farm houses,

motels and other residential type environments.

THIS UNIT IS FOR HOUSEHOLD USE ONLY.

SAVE THESE INSTRUCTIONS

SHORT POWER SUPPLY CORD INSTRUCTIONS

A short power-supply cord is provided to reduce the risk resulting from becoming entangled in or tripping over a longer cord. An extension cord may be used if care is exercised in its use. If an extension cord is used, the electrical rating of the cord must be at least as great as the electrical rating of the appliance. The extension cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over unintentionally.

TSSTTVXXLL-049_15EM1.indd 2 7/15/15 1:48 PM

DESCRIPTION OF THE APPLIANCE

1. Temperature Selector Knob

2. Function Selector Knob

3. Timer Selector Knob

4. Power Light

5. Two Rack Positions

6. Two Removable Wire Racks

7. Baking Tray

8. Broil Rack

9. Rotisserie-Spit

10. Spit Forks

11. Thumb Screws

12. Spit Mounting Brackets

13. Interior Light

14. Crumb Tray

15. Easy Clean Interior Walls

16. Glass Door

17. Rotisserie Handle

18. Grill/Baking Tray Handle

TSSTTVXXLL-049_15EM1.indd 3 7/15/15 1:48 PM

LEARNING ABOUT YOUR TOASTER OVEN

1. Temperature Selector Knob – Adjust the thermostat dial to the desired temperature

(See Figure 1).

2. Function Selector Knob – Adjust the dial to select cooking function (See Figure 2).

3. Timer Selector Knob – Adjust the dial to the desired cooking time (See Figure 3).

4. Power Light – Indicates that oven is plugged in and that the timer is set to begin warming.

5. Crumb Tray – Collects crumbs or fallen food particles. Pulls out for easy cleaning.

6. Glass Door – Lets you to see food while cooking.

7. Easy Clean Interior Walls – Allows for easy cleaning.

8. Baking Tray – Use for all your baking needs.

9. Two Wire Racks and Dual Rack Positions – For added cooking versatility.

10. Rotisserie Spit – Enables rotisserie style cooking.

11. Rotisserie Handle - For easy removal of Rotisserie Spit from the toaster oven.

12. Grill/Baking Tray Handle - For easy removal of baking tray/grill from the toaster oven.

13. Interior Light – Helps with monitoring food while cooking.

Figure 1 Figure 2 Figure 3

PREPARING TO USE YOUR TOASTER OVEN

FOR THE FIRST TIME

If you are using your toaster oven for the rst time, please be sure to:

• Remove any stickers from the surface of the oven.

• Open oven door and remove all printed documents and paper from inside the toaster oven.

• Clean the rack, tray, and tray with hot water, a small amount of dishwashing liquid and a

nonabrasive sponge or cleaning pad.

• DONOTIMMERSETHEBODYOFTHEUNITINWATER.

• Dry the unit thoroughly before using.

• Select a location for the toaster oven. The location should be in an open area on a at counter

where the plug will reach an outlet.

• Plug the toaster oven into the appropriate electrical outlet.

The heating elements are designed to work efciently and maintain a precise temperature.

You may not see the elements glowing, however they are working properly.

PLEASE NOTE – It is recommended that the toaster oven heat at 230°C for approximately 15 minutes to eliminate any manufacturing residue that may remain after shipping.

TSSTTVXXLL-049_15EM1.indd 4 7/15/15 1:48 PM

USING YOUR TOASTER OVEN

TO USE THE PRE-HEAT FUNCTION (SEE FIG. 4)

1. Select desired oven rack position. (See “Positioning Rack” Section)

2. Close the oven door.

3. Turn the Function selector knob to the PRE-HEAT “ ” position.

Both the top and bottom heating elements will operate.

4. Turn the temperature control knob “ ” to the desired temperature.

5. Set the timer knob “ ” to desired time. It is recommended to set

the timer for 5-8 minutes for the oven to pre-heat.

6. When pre-heating is completed, select the desired function and

follow the instructions below.

TOUSETHEBAKE/WARMFUNCTION(SEEFIG.5)

1. Select desired oven rack position. (See “Positioning Rack” Section)

2. Arrange food on one of the wire racks or in the baking tray.

3. Close the oven door.

4. Turn the Function knob to the BAKE/WARM “ ” position.

Only the bottom heating elements will operate. (The heating elements will cycle ON and OFF to maintain temperature.)

5. Turn the temperature control knob “ ” to the desired temperature.

6. Turn the timer knob “ ” to the desired time. The timer can be set

for up to 60 minutes and further to “Stay ON” mode for additional 60 minute increments as desired. The interior light turns on when timer is on. At the end of the cooking time, a bell signal sounds, and the oven turns off automatically.

7. When warming is completed, open door fully and remove food

carefully with oven mitt.

WARNING: Cooked food can be very hot, especially pastry llings.

Handle with care.

Figure 4

Figure 5

TSSTTVXXLL-049_15EM1.indd 5 7/15/15 1:48 PM

TO USE THE TURBO CONVECTION BAKE FUNCTION (SEE FIG. 6)

1. Select desired oven rack position. (See “Positioning Rack” Section)

2. Arrange food on one of the wire racks or in the baking pan.

3. Close the oven door.

4. Turn the Function knob to the TURBO CONVECTION BAKE

“ ” position. The top and bottom heating elements will operate and the turbo convection fans will be activated. (The heating elements will cycle ON and OFF to maintain temperature.)

5. Turn the temperature control knob “ ” to the desired temperature.

6. Turn the timer knob “ ” to the desired time. The timer can be set

7. When baking is completed, open door fully and remove food

carefully with oven mitt.

WARNING: Cooked food can be very hot. Handle with care. Do not leave toaster oven unattended.

FAQS ABOUT CONVECTION BAKING

Figure 6

What is Convection?

Answer: In your Toaster Oven there is a built in fan that circulates the hot air in the oven chamber to cook the food better and give a browning effect to it.

How do I adjust the time for Convection?

Answer: On average, convection will shorten the cooking time by 30% but it varies by food. It is suggested to go with a shorter cooking time to start with and then add time if it is needed.

What are the best foods to use with Convection?

Answer: While a shorter cook time is often desirable, baked foods in particular benet from

convection cooking as the circulating air keeps oven temperature consistent throughout.

TO USE THE BROIL FUNCTION (SEE FIG. 7)

1. Select desired oven rack position. (See “Positioning Rack” Section)

2. Place broil rack in baking tray.

3. Arrange food on broiler rack.

4. Close the door to the rst notch, leaving approximately an 8 cm (3-inch)

gap at the top. This will ensure adequate airow during broiling.

5. Turn the Function knob to the BROIL “ ” position. Only the

top-heating element will operate. (The heating element will cycle ON and OFF to maintain temperature.)

6. Turn the temperature control knob “ ” to the desired temperature.

7. Turn the timer knob “ ” to the desired time. The timer can be set

to for up to 60 minutes and further to “Stay ON” mode for additional 60 minute increments as desired. The interior light turns on when timer is on. At the end of the cooking time, a bell signal sounds, and the oven turns off automatically.

8. Turn food over about halfway through the broiling time.

9. When broiling is completed, open door fully and remove food

carefully with oven mitt.

WARNING: Do not leave toaster oven unattended.

Figure 7

TSSTTVXXLL-049_15EM1.indd 6 7/15/15 1:48 PM

TO USE THE TOAST FUNCTION (SEE FIG. 8)

1. Select desired oven rack position. (See “Positioning Rack” Section)

NOTE: Different types of bread require different settings. Lighter

breads and wafes require a lighter setting. Darker breads, mufns, and English mufns require a darker setting.

2. Arrange food on the wire rack.

3. Turn the Function knob to the TOAST “ ” position. Both

the top and bottom heating elements will operate. (The heating elements will cycle ON and OFF to maintain temperature.)

4. Turn the temperature control knob to the TOAST “ ” setting.

5. Turn the timer knob “ ” to select the desired toast setting.

6. When toasting is completed, open door fully and remove food

carefully with oven grove.

WARNING: Cooked food can be very hot. Handle with care. Do not leave toaster oven unattended.

Figure 8

TO USE THE ROTISSERIE FUNCTION (SEE FIG. 9)

1. Place the chicken, turkey or other food you want to cook on the rotisserie

spit. Use the two spit forks to hold the food in place in the center of the

spit. Use the two spit screws to tighten the spit forks (see gure 1).

2. Use the spit holder tool to place the rotisserie spit on the spit

mounting brackets inside the oven.

3. After securely placing the rotisserie spit in place, remove spit

holder tool and close the oven door.

4. Turn the Function knob to the ROTISSERIE “ ” position.

Only the top-heating element will operate and the Rotisserie motor will be activated. (The heating element will cycle ON and OFF to maintain temperature.)

5. Turn the temperature control knob “ ” to the desired temperature.

6. Turn the timer knob “ ” to the desired time. The timer can be set

7. When cooking is completed, open door fully and use the spit

holder tool to remove food carefully.

8. Place tray on lowest rack when the rotisserie function is in use to prevent dripping of hot

uids and food into the oven for easier clean up.

Figure 9

WARNING: The rotisserie-spit, spit forks, screws and cooked food can be very hot.

Use the rotisserie handle to take out the rotisserie spit/forks. Handle with care. Do not

leave toaster oven unattended.

TSSTTVXXLL-049_15EM1.indd 7 7/15/15 1:48 PM

NOTE: Use the Rotisserie Handle to remove the Rotisserie spit from the toaster oven.

POSITIONING RACK

To accommodate a wide variety of foods, the oven has two rack positions. (See Figure 10)

Rack in the up position

Rack in the down position

Figure 10

Positioning of the rack will depend on the size of the food and desired browning. Before removing the rack allow the unit to cool.

PLEASE NOTE – For best toast and pizza results, position the rack in the upper rack position.

NOTE: Use the Baking Tray Handle to remove the baking tray/grill from the toaster oven.

TSSTTVXXLL-049_15EM1.indd 8 7/15/15 1:48 PM

CLEANING YOUR TOASTER OVEN

Before cleaning your toaster oven, unplug it and allow it to cool. To clean, wipe with damp cloth. DONOTIMMERSEINWATER! Make sure to use only mild, soapy water. Abrasive cleaners, scrubbing brushes and chemical cleaners will damage the coating on this unit. Empty crumb tray frequently to avoid accumulation of crumbs. Toaster oven racks are dishwasher safe (top of dishwasher only).

STORING YOUR TOASTER OVEN

Allow the appliance to cool completely before storing. If storing the toaster oven for long periods of time, make certain that the toaster oven is clean and free of food particles. Store the toaster oven in a dry location such as on a table or countertop or cupboard shelf. Other than the recommended cleaning, no further user maintenance should be necessary.

HELPFUL TIPS/ TROUBLESHOOTING

PROBLEM

• Overcooked / undercooked foods.

• Burnt smell.

• Oven does not turn ON.

• Only one heating element is

heating up.

• Heating elements do not stay ON.

POTENTIAL CAUSE

• Incorrect temperature or time setting.

• Rack placement.

• Food build-up inside oven, on

heating elements or in crumb tray.

• Unit is unplugged.

• Timer was not turned

past 20 minute mark.

• Function setting selection

determines which heating element will operate.

• Heating elements will cycle ON and

OFF to maintain proper heat.

SOLUTION

• You may have to adjust the time and

temperature to the desired taste.

• Because your oven is smaller than

your regular oven, it will heat up faster and generally cook in shorter periods of time.

• Refer to “Positioning Rack” Section.

Rack may need to be adjusted to accommodate food type.

• Refer to “Cleaning Your Toaster

Oven” Section.

• Plug the toaster oven into

appropriate electrical outlet.

• Set timer knob and temperature

knob to the desired setting. Both must be turned on to operate the toaster oven.

• When toasting, make sure the oven

is not set to broil setting.

• Be certain that function is as

desired.

TSSTTVXXLL-049_15EM1.indd 9 7/15/15 1:48 PM

WARRANTY

Jarden Consumer Solutions of India Private Limited (hereinafter referred to as “JCS”) warrants that, for a period of two (2) years from the date of purchase of this product as evidenced in the cash memo (“Warranty Period”), this product will be free from defects in material and workmanship (the “Warranty”). Please preserve the warranty card and the cash memo of the product duly stamped and signed by the dealer, as this will be required for any claims under this Warranty.

• The rights and benets under this Warranty are additional to your statutory rights,

which are not affected by this Warranty.

• During the Warranty Period, JCS, at its sole choice, will either repair or replace this

product or any component of the product found to be defective free of cost through (the dealer from whom the product was purchased or through the service center listed

in the card – business people to conrm), provided that:

- JCS is promptly informed of the defect;

- The product has not been altered in any way or subjected to misuse or repair by the

person other than a person authorized by JCS;

- This Warranty, duly lled, stamped and signed by the dealer is made available.

• The Warranty provided herein is towards the original purchaser and is not

transferrable to any third party.

• Any repaired or replaced product will be warranted on these terms for the remaining

portion of the Warranty in the country where the product was purchased.

• Liability for consequential loss or damage is neither accepted nor is it implied.

• This Warranty is in lieu of all others expressed or implied and does not cover the following:

a. If product was use in any manner other than the intended use. b. If the product has not been used according to the instruction manual/user’s

manual, included with the product. c. If the defects are caused by improper use or reckless use. d. If the product was altered or repaired by anyone other than those authorized by JCS. e. If installation of the product is not done as per the printed instructions provided

along with the product.

f. If the defects are caused by re, ood, and other act of god.

g. If the defects are caused by use of incorrect current or voltage or faulty electric power supply. h. Normal wear and tear of parts and accessories resulting from regular use. i. Damage resulting from transportation, accidents, mishandling or negligence on the

part of the consumer. j. The following part/components:

- Broken glass or ceramic parts

- Light bulb

- Accessories k. If the product is put to industrial or commercial use.

• JCS will not be responsible for any delay in servicing due to non-availability of

any components or due to reasons beyond the control of JCS.

• Any failure of the product to perform any purpose other than the intended

purpose shall not be considered as a default under this warranty.

• In any event, if JCS becomes liable for damages incurred in connection with

these presents, then the liability of JCS will be limited to the amount equal to the sale invoice amount paid by you.

Waste electrical products should not be disposed off with household waste. Please recycle where facilities exist.

TSSTTVXXLL-049_15EM1.indd 10 7/15/15 1:48 PM

AUTHORIZED SERVICE CENTERS

Region State City Name Address Contact

Person

East

West Bengal Kolkata Jeeves

West Bengal Kolkata Southern Service 6/19A, Prince Anwarshah Road,

West Bengal Kolkata Baishanu Service

West Bengal Howrah Time n Service 37 & 38, Mohenath Lane,

West Bengal Hooghly DNP Enterprises 52, Sahaganj Main Road, PO.

West Bengal Barrackpore Balaji Enterprise 4/E/A Barasat Road,

West Bengal Siliguri S D Electronics Deys Lodge,138/69/57, Nazrul

West Bengal Asanol Yes Service Hutton Road, Near Mahal

Assam Guwahati Multi Track

Consumer Services Pvt Ltd

Care

Services

356, Jodhpur Park, Kolkata

- 700068

Poddar Nagar, Kolkata - 700068

55D, Adaya Nath Saha Road, Lake Town, Near Jaya Cinema, Kolkata - 700048

Salkia, Howrah - 711106

Sahaganj, Near Bandel Station, Hooghly - 712104

Barrackpore, Dist. North 24 Parganas, Near 15 No. Rail Gate, Barrackpore - 700122

Sarani, Ashrampara, Siliguri

- 734001

Banquet Marriage Hall, Asansol

- 713301

G S Road, Ground Floor, Bora Service Station, Ulubari, Guwahati - 781007

Someswar Basu

Subrata Manna (033) 24729651

Piyush Nandan (033) 40664210

Tapas Hazra (033) 65639720

Indrajit Bag (0) 9163668360

Pradip Kr Ghosh

Arup Dey (0353) 2526028

Sarfaraz Ahmed

Kallol Dutta (0361) 2457296

Contact No.

(033) 40012100

/ 65488822

(033) 25451224

(03228) 2280029

TSSTTVXXLL-049_15EM1.indd 11 7/15/15 1:48 PM

AUTHORIZED SERVICE CENTERS

Delhi Delhi Jeeves Consumer

Delhi Delhi S T Services M-131, 1st Floor, Guru

Haryana Gurgaon Jeeves Consumer

Haryana Faridabad Jeeves Consumer

Uttar Pradesh Noida Jeeves Consumer

Services Pvt Ltd.

North

Uttar Pradesh Lucknow Swastik Customer

Uttar Pradesh Kanpur Shubham

Uttar Pradesh Agra Sai Electronics 25/113, Gandhi Nagar, Agra

Haryana Ambala Telecare Old Hospital Road, Bara Thakur

Haryana Sonipat Saibaba Enterprises House No. 1510, Sector - 15,

Haryana Karnal Jeeves Consumer

Punjab Mohali Jeeves Consumer

Punjab Ludhiana Jeeves Consumer

Punjab Jallandhar Jeeves Consumer

Punjab Amritsar Keerat Electronics Naraingarh Bazar, Shaheed Bhagat

Himachal Shimla Suvidha Electronics Mehta Niwas, Ground Floor,

Himachal Mandi Kuldeep Electro

Rajasthan Jaipur Jeeves Consumer

Care

Electronics

Services Pvt Ltd.

Care

Services Pvt Ltd.

# E-10, Arya Samaj Road, School Road, Uttam Nagar, Delhi - 1100059

R-32, 2nd Floor, Vikas Marg, Shakarpur, Opp. Heera Sweets, Metro Pillar # 46 , Delhi 1100092

Harkrishan Nagar, Paschim Vihar, New Delhi - 110041

4/18 A, 1st Floor, Laxmi Garden, Behind Police Chowki, Khandsa Road, Gurgaon-122001

5H-49,1st Floor, NIT Faridabad

-121001

1st Floor, Above Punjab ATM, Sector-22, Chaura More Main Road, Near Oriental Bank of Commerce, Opp.Rajkiya Inter College, Noida, U.P - 201301

A-1/3, SEC-H Aliganj, Near Kendriya Bhawan, Lucknow

- 226020

192,Manohar Nagar Barra -3 , Opp Deepshika Guest House, Kanpur - 208027

- 282 003

Dwara, Opp. Polytechnic, Ambala City - 134003

Sonipat - 131001

Shop # 50, Ground Floor, Mayapuri, Rajiv Gandhi Marg/ Near Raj Palace, Meeraghati Chowk, Karnal - 132001

# SCF-4, Basement, The High Land Society, NAV, Baltana, Zirakhpur, Mohali-140603

Shop # 18B, Dhyan Singh Commercial Complex, Opp. Bus Stand, Ludhiana - 141001

EH-31, Laddowali Road, Opposite Gurudwara, Jalandhar

- 144001

Singh Road, Chheharta, Amritsar

- 143 001

Near Himfead Building, B C S, New Shimla - 171009

Neear FCI Godown, Kehanwal Road, Ram Nagar, Mandi 175001

A-79,Subash Nagar Shopping Centre, Jaipur - 302016

Md Khalid Pervez (011) 45785915

Manjeet Singh (011) 47754764

Vipin Yadav (011) 32958438

Karamvir Fogaat (0124) 4073434

Manoj Kumar Panwar

Devender Singh (0120) 4162644

Uma Shankar Mishra

Suman Gupta (0512) 2283394

Ajay Singhal / Sunil

Devinder Sharma (0171)

Pramod Sharma (0130) 6411206

Neeraj Sharma (0184) 4022201

Shiv Dhanda (0176) 2652574

Gurbeer Singh (0161) 2444002

Ashok Kumar (0181) 2221707

Sukhdeep / Mantreet Singh

Rajesh Kumar (0) 9816457886

Kuldeep Singh (01905) 222140

Vipendra Singh (0141) 4035102

/ 45586987

(0129) 4163003

(0522) 3298003 / 4102581 / 4102582

/ 2602029

(0562) 3297005

25567369

(0183) 2450095

/ 329574

TSSTTVXXLL-049_15EM1.indd 12 7/15/15 1:48 PM

AUTHORIZED SERVICE CENTERS

Maharashtra Mumbai S P Services Shop No. 10, Abdul Sattar

Maharashtra Mumbai Jeeves Consumer

Maharashtra Pune Jeeves Consumer

Maharashtra Nagpur Technic Services Khare Building, Hanuman Lane,

Maharashtra Chandrapur Suvidha Electronics No. 1, Devt Appartment, Church

Services Pvt Ltd.

West

Maharashtra Kolhapur Sikir Mobiles 1492 C Ward, Laxmipuri, Opp.

Maharashtra Aurangabad Emperor Services S-5,Manik Arcade Kalda Corner,

Maharashtra Nashik Harsha Electronics 3, Talak Complex, Rachna

Goa Salcete Jolly Enterprises Shop # G-2, 78/A Nuvem

Gujarat Ahmedabad Jeeves Consumer

Gujarat Baroda Uday Refrigeration G/3 Nandanvan Comples, Atma

Gujarat Surat Sadgurudev Shop No. L/6, Shankutal

Gujarat Rajkot PC Systems 4-Sardar Nagar (West),Tagore

Madhya Pradesh

Indore Cool Home

Bhopal Jeeves Consumer

Services Pvt Ltd.

Refrigeration

Services Pvt Ltd.

Compound, Fitwala Road, Opp. Satguru Darshan Bldg., Near Railway Station, Elphinston Road (West), Mumbai - 400013

Plot No 27/5, Pawani Chowk, Opp Mulund Darshan Building, Mulund Colony, Mulund (W), Mumbai - 400082

Shop No.1-1A, Ground oor,

Kirti Co-Op Housing Society, Ramachandra Extn Lane, Near Movie Time, Evershine Nagar, Malad(W), Mumbai-400064

No. 337, Sai Leela, 1st Floor, Datt Wadi, Mhasoba Chowk, Pune - 411030

Sitabuildi, Nagpur - 440 012

Road, Hanuman Nagartukum, Chandrapur - 442401

TATA Brand Stores, Kolhapur

- 416001

Opp Chowbey Hospital, Chetna Nagar, Aurangabad -31005

Vidyalaya Road, Sharanpur Roda, Nashik - 422002

Enclave, Along NH-17 Highway, Belloy Nuvem, Salcete - 403604

No. 37, Om Tower, Near Star Bazar, Jodhpur Cross Road, Satellite, Ahmedabad - 380015

Jyoti Ashram Road, Behind Citizen Society, Ellora Park, Baroda

Complex, Beside Sangvi Tower, Near Gujarat Gas Circle, Adajan Patia, Surat - 395009

Road, Near Astron Circle, Rajkot-360001

LG-70, Trade Centre, 18, South Tukogunj, Indore- 452 001

Ward no 47, Goyal Vihar,

Ground oor, Flat no-G-1, 31-C,

Zone-2, MP Nagar, Bhopal

Palsingh Panyari (022) 24326726

Ramesh Yadav (022) 65288597

Murali Joshi (022) 65278590

Saket Dubey (020) 24321679

Dilip Panda (0712) 2550076

Subash Deashkar (07172) 258966

Sukir Bakare (0) 9372555011

Mr. Willy Bento Colaco

Pravin Patil (0) 9422254240

John Gonzanalves

Girish Parmar (079) 40080485

Shailesh (0265) 6590948

Manoj Rana (0261) 6540417

Manoj Gohil (0281) 2480479

Husain Anjum (0731) 4076404

Ram Ashish Prasad

/ 24312623

/ 256453

(0240) 2350606

(0832)2791800

(0755) 4059310

TSSTTVXXLL-049_15EM1.indd 13 7/15/15 1:48 PM

AUTHORIZED SERVICE CENTERS

Tamil Nadu Chennai Jeeves Consumer

Tamil Nadu Chennai G C Services Old No. 12, New No. 37, 1st

Tamil Nadu Coimbatore V K Engineering 108-A/92, West Ponnurangam

Pondicherry Pondicherry Bestronics 49, Saint Theresa Street,

Andhra Pradesh

South

Karnataka Bangalore Jeeves Consumer

Karnataka Mangalore Jeeves Consumer

Karnataka Mysore Jeeves Consumer

Hyderabad Jeeves Consumer

Vijaywada Jeeves Consumer

Services Pvt Ltd.

New No.3,Old No.1-A, Sripuram,2nd Lane,Royapetah, Chennai-600014

Floor, Sattanna Naichen Street, Nehru Timber Market, Choolai, Chennai - 600112

Road, Ground Floor (Near Telephone Exchange), R.S.Puram, Coimbatore - 641002

Pondicherry - 605001

Flat No. 205, Karan Centre, Opp. IBP Petrol Pump and Karan Hotel, Park Lane, S.D.Road, Near Paradise Circle, Secunderabad - 500003

Door No.25-10-10A,G.S.Raju Road,Gandhi Nagar, Near Gymkhana Road, Vijayawada

- 520003

No. 126, 1st Floor, 8th Main J.P.Nagar, 3rd Phase, Bangalore

- 560078

First Floor, Khan Bldg, 7 & 8th Cross, Jakkasandra Extension, Bangalore - 560032

1st Floor, Quadra compound, Bejai,kapikad, Kavoor Road, Mangalore -575004

No.1095, 1st Floor, C&D Block, Lalithadri Road, Kuvempunagar, Mysore - 570023

Dinesh Kumar 044-

Naval R (044)

Selvadurai (0422)

B Jayashankar (0)

Kumararajan (040)

Rahamatullah Gouse Khan

Ramesh Kumar (080)

Surulivel (080)

Divakar Shetty (0824)

Venkatesh.S.Kulkarni (0821)

42632371

26690084 / 42822868

2541172

9443728020

64591168

(0866) 6591168

41209331

25520424

2213699

4191094

TSSTTVXXLL-049_15EM1.indd 14 7/15/15 1:48 PM

by Jarden Consumer Solutions of India Private Limited, Unit B-204, Universal Business Park, Off Saki Vihar

Road, Chandivali Farm Road, Andheri (E) Mumbai 400 072, India. 2 Year Limited Warranty - see inside for

details. Sunbeam Products, Inc. and Jarden Consumer Solutions of India Private Limited are subsidiaries of

Jarden Corporation (NYSE: JAH).

1-800-102-6300

www.oster.in

WARRANTY CARD

Model No. :

Date of Purchase :

Dealer’s Stamp :

Printed in PRC

TSSTTVXXLL-049_15EM1.indd 15 7/15/15 1:48 PM

TSSTTVXXLL-049_15EM1

P.N. 184427

GCDS-OST41296-BB

Oster TSSTTVXXLL Instruction Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
