Oster IN2ITIVETM 6710 User Manual

IMPORTANT SAFEGUARDS

When using your blender, you should always follow basic safety precautions, including the following:

• Read all instructions before use.

• To protect against electrical hazards, do not immerse the cord, plug or motor base in water or other liquids.

• Always use the product on a clean, flat, hard, dry surface. There should be no material such as a tablecloth or plastic between the unit and surface.

• Avoid contact with moving parts.

• Keep hands and utensils out of jar while blending to reduce the risk of: – Severe personal injury – Damage to the blender

• If scraping is necessary, turn the power OFF and use a rubber spatula only.

• Do not use the appliance: – With a damaged cord or plug – After the unit fails to work correctly – After you drop or damage the product in any way

Return the product to your nearest Authorized Oster

Appliance Service Center

for a safety check, adjustment or repair.

• Triple blades are sharp. Handle them carefully.

• To reduce the risk of injury: – Do not leave the triple blades sitting out or exposed – Always completely assemble the blades to the jar before putting on the base

• Always put the lid on the jar before operating the blender.

• When blending hot liquids beware of steam. Remove the feeder cap from the lid to allow steam to escape.

• Do not use outdoors.

• Do not allow the cord to touch hot surfaces or hang over the edge of a table or counter.

• Unplug the blender when it is not in use, before taking off or putting on parts and before cleaning.

• Never leave the appliance unattended while it is running.

• You risk personal injury, fire or electric shock if you use attachments, jars or parts other than those recommended by Oster

• Supervise children closely when they use or are nearby appliances.

SAVE THESE INSTRUCTIONS

• This product is for household use only.

• The maximum rating marked on the product is based on the attachment that draws the greatest load. Other attachments may draw less power.

Power Cord Instructions

Please follow the instructions below to ensure the safe use of the power cord.

• This blender has a power cord storage area that allows you to adjust the length of the cord so that it is the appropriate length for your location. Try to position the blender near the power source to reduce the hazards associated with power cords (such as becoming entangled or tripping over a long power cord).

• For blenders purchased in the U.S. and Canada: this appliance has a polarized plug (one prong is wider than the other). To reduce the risk of electric shock, this plug will fit into a polarized outlet in only one direction. If you cannot completely insert the power plug into the power outlet, reverse the direction of the plug. If it still does not fit, contact a qualified electrician. Do not modify the plug in any way.

• Do not pull, twist or otherwise abuse the power cord.

• Do not wrap the power cord around the main body of the blender during or after use.

This symbol has been placed in specific areas of the User Guide portion of this book. Its purpose is to help you easily identify instructions that require your special attention.

iii

Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1

Learning about your Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Using your Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

When to Use a HELP Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

What are ERROR Messages? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Using the AUTOMATIC Recipe Programs (for Drinks or Food) . . . . . . . . . . . . .7

Using the AUTOMATIC Favorites Program . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Using the Ice Crush Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Using the AUTOMATIC Food Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Using the AUTOMATIC Drinks Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

Overriding the AUTOMATIC Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Using MANUALLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Using the Low and High Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

Using the Pulse Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

After Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Caring for your Product . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Checking the Triple Blades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Storing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21

Blending Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Liquids . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Using the Feeder Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

Hot Foods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Ingredients Quantity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23

Foods Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Recipes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Frozen Drinks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26

Milk Shakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28

Powder Drinks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29

Smoothies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30

Salsa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33

Soups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

Baby Food . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

Batter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Nuts/Crumbs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40

Accessory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Blend-N-GoTMCup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42

Two-year Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43

How to Obtain Warranty Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44

Table of contents

Welcome

Congratulations on your purchase of an Oster®Model 6710 In2itive™ Blender/Food Processor. Your product includes the following technology and features:

• An “In2itive” technology takes the guesswork out of blending, giving you the ability to make a variety of foods and drinks with consistent results every time.

•A user-friendly touchpad design walks you through the complete process, whether you use the pre-programmed AUTOMATIC LCD settings, the recipe section in the instructions or your own recipes.

•A triple set of blades optimizes programmed food and drink preparation.

•A dynamic breaking function stops the blades quickly once the cycle is complete, ensuring that the ingredients are not over processed.

•A 500-watt reversible motor keeps ingredients near the blades by spinning at low speeds as needed then gradually speeding up to the programmed level, ensuring optimum results from smooth to chunky.

• MANUAL controls allow you to add additional time at the end of AUTOMATIC programs or allow you to operate the product MANUALLY for personal recipes.

•A Progress indicator lets you estimate how much more programmed time remains.

•A Pause/Resume button lets you stop to add additional ingredients, then resume at the same point to complete the AUTOMATIC program.

•A feeder cap lets you add ingredients without removing the jar lid.

1. Feeder Cap – Allows you to add ingredients during use.

2. Lid – Seals the blender jar.

3. Jar – Made from Polycarbonate, a virtually indestructible plastic. Has a maximum

capacity of 6 cups.

4. Sealing Ring – Seals the jar to the triple blade assembly.

5. Triple Blades – Creates a forward and reverse action when using the AUTOMATIC

programs.

6. Low Profile Base – Holds the jar securely in 6 positions. Contains a powerful,

reversible, variable speed motor. It uses programmed logic that takes the guesswork out of creating foods and drinks.

7. Control Panel – Contains all the necessary controls to operate your product.

Learning about your Product

MANUAL

SPEEDS

MANUAL

SPEEDS

Learning about your Product

MANUAL

SPEEDS

8. POWER Button – Turns the product On and Off.

9. LCD Screen – Displays user prompts for food or drink selections and recipes.

10. Pulse Button – Press and hold to Pulse. Release the button to Stop.

11. High Button – Use to MANUALLY increase speed.

12. START/STOP Button – Use to Start and Stop the product.

13. Low Button – Use to MANUALLY decrease speed.

14. Pause/Resume Button – Use to Pause and Resume the AUTOMATIC or MANUAL function.

15. Touchpad Buttons – Use to navigate through programmed menus and screens.

Control Panel

Using your Product

Welcome to the

Oster

New Technology

Blender

To skip tutorial

screens in the future

press this button

NEXT BACK

Before you use the product for the first time, separate the lid, feeder cap and blades from the jar. Wash in warm, soapy water. Rinse and dry well.

Assembly

1 Check to ensure the sealing ring is properly

seated on the ledge surrounding the triple blades.

2 Turn the jar upside down.

3 Turn the triple blades upside down and twist them

into the bottom of the jar. You can use the feeder cap as a tool to twist the blades securely in place.

Be sure the triple blades are locked securely to the jar before using.

4 Wrap the power cord around the cord storage

area on the base of the product until the cord is the length you desire.

Using your Product

Welcome to the

Oster

New Technology

Blender

To skip tutorial

screens in the future

press this button

NEXT BACK

5 Set the jar onto the base. 6 Plug the power cord into a standard household

120/127-volt, 60 Hz. AC outlet. You are now ready to start.

Set Up

1 Press the POWER button. All the lights blink on

briefly and you will hear a greeting sound as the Welcome screen appears. The POWER light stays on, meaning the product is ready to use. Each time you press one of the buttons, you will hear a tick sound.

If you do not have the jar or another attachment placed on the base, a screen will ask you to put one in place.

Next, Tutorial screens appear briefly explaining the different functions of the touchpad and MANUAL buttons. Follow the instructions on these screens.

2 Press the arrow button beside the blinking NEXT

to page through the tutorial screens.

3 To skip the Tutorial screens in the future, press

the button beside the arrow on the screen. If you want to view the tutorial every time you turn on the product, press the arrow button beside the blinking NEXT.

Cont’d. next page

Using your Product

To enter the MAIN MENU for AUTOMATIC programs, press the arrow button beside the blinking NEXT.

Make your selections at the MAIN MENU. To change the introduction screens, press the arrow button next to HELP.

When to Use a HELP Screen

HELP screens are useful to:

• Revisit Tutorial screens,

• Turn the Tutorial screens On or Off,

• Turn the audible button tick sounds, On or Off,

• Display your Favorites list first (vs. MAIN

MENU) when the product is turned On.

What are ERROR Messages?

These are programmed messages that appear when you press an unrecognized button, asking if you want to:

• End your program?

• Exit AUTO Programming and use MANUAL

controls?

Or stating that:

• Certain buttons work only for MANUAL speeds,

• Product is about to leave Pause mode and exit the

program,

• Product is shutting down.

When these messages appear, follow the instructions displayed on the screen.

Recipes Favorites/Ice Crush Food Drinks

HELP

Drink Recipes Food Recipes

Frozen drinks Milk Shakes Powdered drinks Smoothies

The next screen is the

Main Menu for

Automatic programs.

NEXT BA

Cranberry-Orange Morning Mocha Very Berry

MORE BA

Using your Product

Recipes Favorites/Ice Crush Food Drinks

HELP

Drink Recipes Food Recipes

Frozen drinks Milk Shakes Powdered drinks Smoothies

Cranberry-Orange Morning Mocha Very Berry

MORE BA

Using the AUTOMATIC Recipe Programs (for Drinks or Food)

1 From the MAIN MENU, press the arrow button

next to Recipes.

2 Select from the programmed Drink recipes or

Food recipes.

3 Select a recipe category.

4 Select a specific recipe.

Cont’d. next page

Using your Product

Add the ingredients exactly as shown on the screen.

6 Press the arrow button beside the flashing NEXT

for additional screens of ingredients or to advance to the Press Start screen.

At the Press Start screen, the light on the START/STOP button blinks, indicating that the product is ready to begin processing. Arrow buttons beside MAIN MENU and BACK returns you to the MAIN MENU if you want to start over, or to the previous screen.

7 Make sure the lid and feeder cap are on and

press the START/STOP button to start. The light on the button stays on and the Progress indicator bar represents the time left in the program.

When complete, the product stops AUTOMATICALLY, you will hear a series of tones, and ENJOY! shows on the screen. For additional controls, see Overriding the AUTOMATIC Programming on page 13–14.

If the jar is ever removed from the base while the product is running, the motor will stop as quickly as possible and error tones will sound.

Favorites/Ice Crush Smoothies Frozen Margarita Salsas

INGREDIENTS 1 cup Orange juice 1/2 cup vanilla fat free yogurt 1 cup frozen mixed berries

NEXT BACK

Add the ingredients

Make sure the lid is on

and press

MAIN MENU

BACK

START

Using your Product

Using the AUTOMATIC Favorites Program

1 From the MAIN MENU, press the arrow button

next to Favorites/Ice Crush. Favorites are shortcuts to the last three items you processed.

Favorites may include recipe selections. The Favorites screen can be set as the default start up screen by pressing HELP at the MAIN MENU.

2 Select a Favorite.

The light on the START/STOP button blinks. Add the ingredients or follow the recipe and make sure the lid and feeder cap are on. Arrow buttons beside MAIN MENU and BACK returns you to the MAIN MENU or to the previous screen.

3 Press the START/STOP button to start. The light

on the button stays on. The Progress indicator bar monitors the status.

When complete, the product stops AUTOMATICALLY, you will hear a series of tones, and ENJOY! shows on the screen. For additional controls, see Overriding the AUTOMATIC Programming on pages 13–14.

Using your Product

Using the AUTOMATIC Food Program

1 From the MAIN MENU, press the arrow button

beside Food.

2 Select a food category. The arrow button beside

MORE takes you to additional food categories.

The light on the START/STOP button blinks.

3 Choose a recipe from the recipe section of this

manual or use one of your own.

4 Add the ingredients to your liking and make sure

the lid and feeder cap are on. Arrow buttons beside MAIN MENU and BACK returns you to the MAIN MENU or to the previous screen.

5 Press the START/STOP button to start. The light

on the button stays on. The Progress indicator bar monitors the status.

When complete, the product stops AUTOMATICALLY, you will hear a series of tones, and ENJOY! shows on the screen. For additional controls, see Overriding the AUTOMATIC Programming on pages 13–14.

Using your Product

Using the AUTOMATIC Drinks Program

1 From the MAIN MENU, press the arrow button

beside Drinks.

2 Select a drink category.

The light on the START/STOP button blinks.

3 Choose a recipe from the recipe section of this

manual or use one of your own.

4 Add the ingredients to your liking and make sure

the lid and feeder cap are on. Arrow buttons beside MAIN MENU and BACK returns you to the MAIN MENU or to the previous screen.

Progress

to finish your recipe, or to cancel

RESUME

Press

STOP

Frozen drinks Milk Shakes Powdered drinks Smoothies

Recipes Favorites/Ice Crush Food Drinks

MAIN MENU BACK

Add the ingredients

Make sure the lid is on

and press

START

+ 36 hidden pages
