Electric Indoor
Use and Care Instructions
Grills
plus recipes and tips for indoor
grilling with great outdoor flavor.
When using electrical appliances; basic safety precautions should always be followed, including the
following:
1.
2.
3.
READ ALL INSTRUCTiONS.
Do not touch hot surfaces. Use
handles.
To protect against electrical shock, do not immerse cord, plugs, power controller, or heat
element in water or other liquid.
4.
5.
Close supervision is necessary when any appliance is used by or near children.
Unplug from outlet when not in use and before cleaning. Allow to cool before putting on
or taking off parts.
6.
Do not operate any appliance with a damaged cord or plug or after the appliance
7.
8.
9.
malfunctions, or has been damaged in any manner.
Return appliance to the nearest
authorized service facility for examination, repair or adjustment.
The use of
accesory
attachments not
recommended by
the appliance manufacturer may
cause injuries.
Do not use outdoors.
Do not let cord hang aver edge of table or-counter, or touch hot surfaces
IO, Do not place on
Or
near a hot gas or electric burner, or in a heated oven.
11.
Extreme ‘caution must be used when moving an appliance containing hot-oil or other-
hot liquids.
12. Always attach plug’to appliance
first then
plug cord into wall outlet. To disconnect, first
remove plug from
wall
outlet, or, if using a
Variable
temperature
control,
turn control to “off”,
then remove plug from wall outlet.
13. Do not use appliance for other than its intended use.
Household
use only.
14. A grill that is plugged into an outlet should not be
left
unattended.
15. Fuels such as charcoal briquettes are not
to be
used with this appliance.
16. Do not cover grill with any metal, such as aluminium foil or pot cover, as this will cause
excessive heat build-up.
PLEASE NOTE: A short detachable power supply cord is provided to reduce the risk resulting from
becoming entangled in or tripping over a longer cord. Longer detachable power cords or extension
cords are available and may be used if care is exercised in their use. If a longer detachable power
supply cord is used: (1) the marked electrical rating of the cord set or extension cord should be at
least as great as the electrical rating of the appliance; (2) if the appliance is of the grounding type,
the extension cord should be a grounding type 3-wire cord; and (3) the longer cord should be
arranged so that it will not drape over the counter top or tabletop where it can be pulled on by
children or tripped over unintentionally.
GENERAL OPERATING INSTRUCTIONS: Your new Electric Indoor Grill is an indoor open air
broiler that, coupled with creative marinading and basting, brings great outdoor barbecue flavor
indoors. With its specially designed reflective drip pan and bowl, you get fat-free cooking, no mess,
virtually no smoke, easy clean-up and great taste in one great
product.This
grill is simple to use. In
less than five minutes it can be set up and ready to cook.
HOW TO ASSEMBLE YOUR NEW GRILL: Unpack the grill. Wash the
GRIFFOTM
porcelain
coated grid (or wire grate) before using for the first time to remove any factory oil. Set base on a
counter near an outlet. Set the aluminum drip pan next to the base. Inset-t the support rod into
holes on the sides of the drip pan.
0
Place heating element in the drip pan, resting the extended
portion on the support bar and slipping the element bracket into the notch cut in one side of the drip
pan as shown.
@
Tilting the opposite end of the drip pan, insert the bracket end into the window
on the side of the base and position drip pan in base. The drip pan and element will lock into place.
@
Plug the electric cord (or the variable temperature control) into the cooking element. @ Place
the
GRIFFOTM
porcelain coated grid (or wire grate) on top of the base and you’re ready to grill.
