Orion 220GX User Manual
Specifications and Main Features
- Models: GS-1000, GS-100, 4100gx, 2150gx, 220gx, 240gx, 280gx
- Sensitivity of Voltage Input: 10 - 16 volts
- Delivered Impedance: 4 - 16 Ohm
- Damping Factor: over 500
- Damping Factor: over 500
- Slew Rate: 30V/microsecond
- Voltage Requirements: 10V - 16 voltage
- Stereo Separation: Unspecified
- Dimensions: Vary by model
- Varies by model (e.g., 220gx: 20 WRMS per channel, 4100gx: 100 WRMS per channel)
- Power Supply: +15 volts
- Consumption of Current: 50 mA @ No Excitation; 200 mA @ Maximum Output (depends on model)
- Current up to 500 mA
- 30 - 30,000 Hz Frequency Response
- Ratio of Signal to Noise: More than 110 decibels
- Distortion: Conventional 0.006 percent
- Turn On Current: 50 mA
- Retroflexion Rate: 70 mV
Frequently Asked Questions
Q: Please state the output wattage on the ORION 240gx amplifer?
A: Each channel outputs 40 watts RMS and it operates at 4 ohms.
Q: Are the ORION amplifiers capable of being bridged for enhanced performance?
A: There exists the possibility of bridging the 220gx, 240gx, and the 280gx models using the ORION Bridging Module 400 BDG for enhanced power output.
Q: What is the required speaker impedance?
A: The optimal range of speaker impedance for the ORION amplifiers is between 4 to 16 ohms.
Q: Is there a guarantee period for the ORION products?
A: ORION products come with a 2 year guarantee period which protects against material and workmanship defects.
Q: At what gauge should I wire the speakers?
A: For moderate power speakers, a minimum of 16 AWG is recommended to ensure connectivity.
