Orion 19RCM, 17RCM User Manual

Installation and User’s Guide

ECONOMY SERIES LCD MONITOR

TFT-LCD MONITOR

(SECURITY)

Installation and User’s Guide

http://www.orionimages.com

All contents of this document may change without prior notice, and actual product appearance may differ
from that depicted herein

p

http://www.orionimages.com

Installation and User’s Guide

Warning Statem ents

* Follow this safety instruction to us e the monitor properly and prevent th e damages.

* This safety instruction has “ Warning” and “ Caution” as below.

WARNING:

CAUTION:

If the user does not follow this instruction,
it may cause the serious damage to the user.

If the user does not follow this instruction, it may cause the slight
damage to the user or cause some damages to the monitor.

* Keep this user’s guide book for later use.

Never remove the back over and touch
the inside of the monitor. If you need a
service, please contact the service center.

Keep away the monitor from the
direct sunlight and a heating appliance.

Never push objects of any kind into this
product as they may result in a risk of fire
or electric shock.

Connect the power code to the wall
outlet tightly. If the power code or plug are
defective and the wall outlet is not tight,

lease do not use them.

2

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg2

http://www.orionimages.com

Installation and User’s Guide

Warning Statem ents

Do not install this monitor on the outside
and near water. If may cause damage to
the product, electric shock and fire.

For cleaning do not use liquid cleaners.
Never touch the power plug with wet­hands.

When lightning and thundering, unplug
the monitor from the wall outlet and never
touch it.

Unplug this product from the wall outlet,
when It does not operate for a long time.

When smoking and noising from the
monitor, unplug the product from the wall
outlet and contact a service center.

How to fix

1. Do not open this product as it contains high voltage inside.

2. It may create an electric shock.

3. It the user disassembles and remove the back cover, it does not make sure

4. To make up for the damages and do a service and exchange the monitor..

3

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg3

http://www.orionimages.com

Install this monitor some distance
From the wall and do not install unless
Proper ventilation is provided.

The openings must not be blocked by
curtain, rug or other similar surface.

Before carrying the monitor, tum it off
and Unplug the signal cables and the
power code From the wall outlet.

Install this monitor about 50cm far from
the eyes and an angle of 0~15 degrees
below eyes. Too close installation may
cause having weak sight.

For cleaning, unplug the monitor from
the Wall outlet. Do net use the liquid
cloth. Use the soft cloth.

Cautions

Place this product on a stable place.
If not, it may fall, causing serious
Damages to the monitor and people.

When carrying this monitor, be careful
not to damage the panel and drop it
It may cause some trouble.

Take the power plug out from the wall
outlet. Do not pull the cable. It may
snap the inner wires and cause
overheating and fire.

Do not press the LCD panel with hands
or the sharpened material hardly.

Do not use the chemical liquid for
cleaning. It may cause fading and
breakage.

Installation and User’s Guide

4

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg4

http://www.orionimages.com

Installation and User’s Guide

1. INSTALLATION

1.1 Parts

1.2 How to install ............................................................................................................

2. FEATURES

2.1 Display Mode

2.2 Specification (17INCH) ...............................................................................................

2.3 Specification (19INCH) ...............................................................................................

3. OSD SETTING

3.1 OSD Menu(PC Mode)

3.2 OSD Menu(VIDEO/CVBS Mode)

4. INFORMATION TO THE USER

5. TROUBLESHOOTIN G

6. LIMITED LIFETIME WARRANTY

……....................................................................................................................

…..................................................................................................................

.................................................................................................................

TABLE OF CONTENTS

.................................................................................................................

…….……..............................................................................................

................................................................................................

..........................................................................

......................................................................................

.....................................................................................................

...................................................................................

6
6
7

8
8

9
9

10
10

11-15

16
17
16

5

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg5

http://www.orionimages.com

Installation and User’s Guide

1.1 Parts

INSTALLATION

6

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg6

sta

http://www.orionimages.com

1.2 How to In

* Warning:

ll

Tilting more than 10 degrees to the front or 30 degrees to the back
may cause collapse of the product.

Installation and User’s Guide

INSTALLATION

7

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg7

http://www.orionimages.com

Installation and User’s Guide

2.1 Display Mode

FEATURES

8

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg8

http://www.orionimages.com

Installation and User’s Guide

2.2 Specification (17INCH)

2.2 Specification (19INCH)

FEATURES

9

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg9

http://www.orionimages.com

3.1 OSD MENU (PC MODE)

OSD (On Screen Display) Setting

Installation and User’s Guide

10

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg10

http://www.orionimages.com

Installation and User’s Guide


Contrast:

Brightness:

Sharpness:

Color Adjust:

Color Temp:

Clock:
Phase:

OSD (On Screen Display) Setting

The Contrast feature adjusts the Black level. Choices range from 0
to 100. Default is 60.

The Brightness feature adjusts the brightness of the backlight.
Choices range from 0 to 100. Default is 50.

The Sharpness feature adjusts the clearness of the image.
Choices range from 0 to 4. Default is 2.

The Color Adjust feature adjusts the Red, Green, and Blue when
Color Temp. Item is set to ‘User’.
Choices are 0 to 255. Default is 128.

The Color Temp. feature sets the baseline color reference for the
monitor. Choices are 9300K (cooler), 6500K(warmer) and USER.
Default is USER.

The Clock feature adjusts the horizontal image size.
Use the Clock Phase feature when noise remains on the screen

after operating the Auto adjustment of OSD menu item.

11

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg11

http://www.orionimages.com

Position

OSD Menu

OSD (On Screen Display) Setting

Installation and User’s Guide

H. Position

The H. Position feature adjusts t he
image position horizontally.

V. Position

The V. Position feature adjusts the image
position vertically.

OSD H. Position

The OSD H. Position feature adjusts the
horizontal position of the OSD window.

OSD V. Position

The OSD V. Position feature adjusts the
vertical position of the OSD window.
Choices are 0 to 200. Default is 100.

Translucent

The Translucent feature adjust the
transparency of the OSD window.
Choices are 0 to 7. Default is 2.

OSD Timer

The OSD Timer feature sets how long
the OSD menu stays on the screen.
Choices are 5 to 60. Default is 10.

12

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg12

http://www.orionimages.com

Language

Miscellaneous

Installation and User’s Guide

OSD (On Screen Display) Setting

Language

The Language feature sets which
language will be used to display the OSD
menu and your entries. Choices are
English, French, Dutch, Spanish,
Italian and 한국어.
Default is English.

Input

The Signal Source feature selects the
input signal source. Choices are
ANALOG, VIDEO and S-VIDEO

Reset

The Reset feature initializes memory
stored in the user mode.

Volume (option)

The Volume feature adjusts the speaker
volume. Choices are 0 to 100. Default is 50.

Mute (option)

The Sound feature turns the speakers on or
off. Choices are ON and OFF.
Default is OFF.

.

13

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg13

http://www.orionimages.com

3.2 OSD MENU (VIDEO / CVBS MODE)

+ OSD menu, Misc. and Sound menu items are same as in the VGA Mode.

OSD (On Screen Display) Setting

Installation and User’s Guide

14

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg14

http://www.orionimages.com

Video

Contrast:

Brightness:

Sharpness:

Tint:

Color:

Under Scan:

* OSD menu, Misc. and Sound menu items are same as in the VGA Mode.

OSD (On Screen Display) Setting

The Contrast feature adjusts the Black level. Choices range from 0
to 100. Default is 60.

The Brightness feature adjusts the brightness of the backlight.
Choices range from 0 to 100. Default is 50.

The Sharpness feature adjusts the clearness of the image.
Choices range from 0 to 4. Default is 2.

The Hue feature changes the RGB (red, green, blue) colors that you see.
You can change blue objects to appear as green, or purple obnects.
Choices range from 0 to 100. Default is 50.

The Saturation feature adjusts the saturation, which is color intensity.
Choices range from 0 to 100. Default is 50.

The Screen feature turns the size on or off. Choices are ON and OFF.
Default is OFF.

Installation and User’s Guide

15

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg15

http://www.orionimages.com

This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one more
of the following measures:

z Reorient or relocate the receiving antenna.
z Increase the separation between the equipment and receiver.
z Connect the equipment into an outlet on a circuit different from that to which

the receiver is connected.

z Consult the dealer or an experienced radio / TV technician for help.

WARNING:

The manufacturer is not responsible for any Radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate
the equipment."

Installation and User’s Guide

INFORMATION TO THE USER

16

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg16

http://www.orionimages.com

Installation and User’s Guide

* When the following troubles are occurred, follow the trouble shooting. Before contacting a

service center.

TROUBLESHOOTING

Troubleshooting Troubleshooting Tip

1. Make sure if the power supply is connected property

The screen doesn’t show up

The screen is too light or to dark

The screen size is not fit for the PC
signal

The screen color shows strange in
the PC signal

2. Turn on the power.

3. Select the input signal right for the connected port.

Control the BRIGHTNESS

Press the AUTO key among keys in the front.
(It is used only in the PC signal)

In the FUNCTION menu of OSD menu, perform the AUTO­ADJUST.

17

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg17

http://www.orionimages.com

Installation and User’s Guide

2Year Limited Warranty

All Orion Images products carry a limited warranty from ship date against defects in materials
and workmanship. Orion Images is not liable for improper installation that results in damage to
mounts, adapters, display equipment or personal injury.

Contact Orion Images

In the event of missing and/or damage equipment, or technical questions, the
following information can help in the completion of the installation.

Address: 7300 Bolsa Avenue, Westminster, CA 92683
Tel: [phone] / Fax: [phone]
Email: [e-mail]
Website: http://www.orionimages.com

18

7300 Bolsa Avenue, Westminster CA 92683 / Tel: [phone] / Fax: [phone]

pg18
