Oricom PMR1000R User Manual
Stay in touch for FREE with Oricom
User Guide
Oricom PMR1000R
High Powered 1 Watt
UHF Two-Way Radios
Read this manual
carefully before use.
Stay in touch for FREE with Oricom
Highly sophisticated: You can communicate when you are out and about enjoying sport
and leisure activities, whilst at work or out on a job site.
Long range: With a massive 1 watt of power you can expect up to 7km range
depending on terrain and environmental conditions. The range is longer when using the
duplex feature.
Free communication: No call costs.
No license required: Start using your Oricom PMR1000R radios straight away.
Highly compact: Lightweight and small, they easily fit in your pocket or bag, or clip
them on your belt with the clips included.
Smart features: Advanced features include 40 UHF channels, long in use time, range
extender in duplex mode, channel scan, hands-free with or without a headset and Roger
beep confirmation tone.
Channel scan: Lets you easily find your group’s channel by searching all possible channels.
12-month replacement warranty
Contact us
Contact us
Australia
Oricom International Pty Ltd
PO Box 5681
South Windsor NSW 2756
Australia
Customer support
Email: support@oricom.com.au
Web: www.oricom.com.au
Fax: (02) 4572 0939
Phone: 1300 889 785
22
Important information
1
Important information
Important safety information
• Do not use the radios in areas where there is a risk of explosion, such as fuel stores,
blasting areas, chemical stores or areas in which chemicals or other solids are
present in the air. Always follow all information signs. Areas at risk of explosion are not
always clearly marked however.
• Changing battery packs/batteries in areas at risk of explosion means a danger to life.
• These radios are not waterproof. Do not immerse in water.
• If the radio becomes wet, switch it off immediately and remove the battery pack or
batteries. Do not use the radio until it is completely dry.
• When transmitting, always hold the radio vertically and approximately 2.5 to 5 cm from
your mouth.
• When receiving, hold the radio at least 2.5 cm from your head.
• In order to avoid electromagnetic conflicts, switch the radios off if requested to do so
by an information sign.
• If you are not sure whether the use of radios is permitted (aeroplane, boats, hospitals,
etc.) ask a responsible person before using the radios.
• In the car, never place radios above an airbag, as loose objects are flung away in force
when the airbag is released and present a risk of injury.
• Excessive exposure to smoke, dust, vibrations, chemicals, moisture, heat or the direct
rays of the sun must be avoided.
Warranty information
Warranty information
This product is covered by a 12-month warranty against defective workmanship or
parts. The warranty does not extend to damage caused by misuse, negligence, water
ingress, battery leakage or lightning. This guarantee in no way affects your statutory
rights. Full details of the warranty are contained in the enclosed warranty card.
If you feel this product is not working correctly please consult the user guide and ensure
that you are using the product in accordance with the instructions.
For assistance with technical issues please consult our website for further information
or send us an email for a prompt response to your enquiry. In the unlikely event of a fault
developing, please contact us for assistance. If the product is then found to be faulty
you will be asked to return it directly to us with a copy of the purchase receipt.
21
Exposure to Radio Frequency (RF) energy
Safety and general information
Safety and general information
Exposure to Radio Frequency (RF) energy
Your radio contains both a receiver and transmitter. When it is turned on it receives and
transmits RF energy. Your Oricom unit is designed to comply with local
regulatory requirements concerning exposure of human beings to RF energy (Specific
Absorption Rate Data (SAR).
No user licence is required in Australia or New Zealand.
2
This unit complies with all relevant Australian and New Zealand approval requirements including radio
communications (Electromagnetic Radiation Human Exposure) standard 2003
.
N13134
20
Attaching the belt clips
Attaching the belt clips
Attaching the belt clips (2 included)
Each radio is supplied with a belt clip.
To attach, simply slide into place.
Removing the belt clip
To remove, release the clip with a
screwdriver and slide upwards as shown.
→
→
Clip
Your Oricom PMR1000R radio controls
Your Oricom PMR1000R radio controls
Menu button
Display
illumination
Volume and
menu settings
Headset
socket
On/off button
Indicator light
Charging
contacts
Channel search
and monitor
Volume and
menu settings
Push
to talk button
Call tone
button
Battery compartment
catch
3
