Sunrise Wake-up Clock
Model: WS902
USER MANUAL
EN
EN
INTRODUCTION
Sunrise Wake-up Clock
Model: WS902
USER MANUAL
CONTENTS
Contents....................................................................1
Introduction ............................................................. 2
Overview................................................................... 2
Front View.............................................................. 3
Bottom View........................................................... 3
LCD Display........................................................... 3
Getting Start.............................................................. 3
Replacing Lamp..................................................... 3
Connect to Power Source...................................... 3
Clock.......................................................................... 5
Manually Set Clock................................................ 5
Radio......................................................................... 5
Soothing Nature Sounds......................................... 5
Adjust Volume.........................................................5
Alarm......................................................................5
Alarm with Wake up Light...................................... 5
Sleep Timer ................................................................ 5
Reading Lamp.......................................................... 5
Play Music................................................................. 5
LCD Backlight........................................................... 5
Reset......................................................................... 5
Spectifications.......................................................... 5
Main Unit................................................................ 5
Troubleshooting...................................................... 5
Precaution................................................................ 5
EU-Declaration of Conformity ................................ 6
About Oregon Scientific .........................................6
1
2
2
2
2
2
2
2
3
3
3
3
3
3
3
4
4
4
4
4
4
4
4
5
6
6
6
1
EN
INTRODUCTION
Thank you for selecting the Oregon Scientific Sunrise
Wake-up Clock
Our body clock is often not in sync with the demands and
rhythm of modern life.
Our biological clock is affected by external cues, such as
sunlight. Light at dawn stimulates production of cortisol,
which gets the body ready to work and wake up. By
simulating dawn, Oregon Scientific’s Sunrise Wake-up Clock
(WS902) prepares the body to wake up by gradually
increasing brightness to the set level in the 20 minutes prior
to desired (set) alarm time.
Start your day better and feel energised to tackle the day.
Wake up as nature intended!
NOTE Please keep this manual handy as you use your
new product. It contains practical step-by-step instructions,
as well as technical specifications and warnings you should
know about.
IMPORTANT
This device does not reduce the hours
of sleep needed.
OVERVIE
FRONT VIEW
6
7
8
9
10
11
12
1. Lamp Holder
2. SNOOZE SENSOR: Motion sensor for snooze function
3. / : Adjust volume (only when radio / nature sound
is playing); change values of the setting
4. SLEEP: View remaining time; enable sleep function
with radio / nature sound / light; set sleep timer
5. RADIO TUNE : Enable auto-search for radio station;
adjust radio frequency marginally (by 0.05MHz)
6. NATURE SOUND: Toggle through selection (Crickets /
Brook / Ocean / Rain)
7. SET CLOCK: Enter clock settings
8. SET ALARM: View alarm status; enter alarm settings
9. / : Adjust brightness (only when LAMP function
has been activated)
10. LAMP: Turn on/off light
11. ALARM: Enable / disable alarm function
12. RADIO: Turn on / off radio
TM
1
2
3
4
5
BOTTOM VIEW
3
2
4
1 & 5
1. Battery compartment
2. WAKE UP LIGHT ON•OFF: Enable / disable light for
alarm sequence
3. DISPLAY BRIGHTNESS LOW•HIGH: Select LCD
display brightness LOW / HIGH
4. AUDIO LINE-IN: Socket for connecting to external
music storage device
5. RESET: Reset unit to default settings
LCD DISPLAY
1
2
3
4
5 6 7 8 9
1. AM/PM
2. Beep / Radio / Bird chirp alarm selected
3. Alarm with wake up light enabled
4. Batteries low / no battery
5. Alarm time
6. Radio Mode is ON and frequency is displayed
7. Volume is displayed
8. Sleep mode is ON and remaining time is displayed
9. Nature sound selected (1-4)
10. Sound from external source plugged into unit
11
10
GETTING STARTED
REPLACING LAMP
For first time use, take out provided light bulb and go
directly to step 2.
1. Unplug unit from wall socket and allow unit (bulb) to
cool for approx. 15 minutes.
CAUTION Always allow unit to cool for 15 minutes prior
to cleaning, storing, replacing parts as unit can be very
hot.
2. Turn the unit around to view back of the product
(UNLOCK COVER tab facing you)
3. Using left thumb, press and hold UNLOCK COVER
tab.
2
UNLOCK COVER
EN
4. While continuously pressing on UNLOCK COVER
tab, place right hand around the side of the product.
Push in the side of the cover (area above tab and hook)
and lift up to release cover.
(Left handed individuals can use right thumb and left
hand if more comfortable).
5. Unscrew old light bulb.
6. Screw in new light bulb.
7. Holding cover, with the top part at a slight angle away
from you, align the 2 front plastic tabs to the allotted
space.
8. Tilt cover down and towards you until lamp cover
clicks back into place.
NOTE This unit uses 60 W light bulbs. The built-in
protection feature will automatically shut down the unit
when the temperature inside the lamp cover is too high.
Remove the power plug from the socket, and only plug in
again after unit has cooled down sufficiently.
IMPORTANT Please allow this unit to cool until the
temperature inside is within a safe range.
CONNECT TO POWER SOURCE
Memory backup:
1. Remove the battery compartment cover.
2. Insert the batteries (2xAAA), matching the polarities.
3. Replace the battery compartment cover.
NOTE Batteries should not be exposed to excessive
heat such as sunshine or fire.
Before selecting a location to place the unit, consider the
following:
• Ensure there is approximately 15 cm between unit and
closest object, such as walls or other objects.
• Ensure there is at least 40 cm space above the top of
the unit for ventilation purposes.
• Ensure distance between unit location and wall socket
is not longer than the power cord itself.
Batteries serve as a back-up power supply. To fully utilize
all features, plug into wall socket.
To completely disconnect from power, the unit should be
disconnected from the wall socket.
NOTE The main unit should not be exposed to wet
conditions. No objects filled with liquid, such as vases,
should be placed on the main unit.
CLOCK
MANUALLY SET CLOCK
1. Press SET CLOCK to enter setting mode.
2. Press + or - to change the settings or press and hold
+ / – to rapidly change the settings.
3. Press SET CLOCK to confirm and move to next
setting.
The settings order is: 12/24 hr format, time.
RADIO
To activate / deactivate radio:
• Press RADIO to turn radio on / off.
To set radio station:
1. Press RADIO to turn radio on.
2. Press and hold RADIO TUNE to auto search or
press RADIO TUNE to manually select frequency.
For your convenience, the volume and radio frequency will
be stored in memory for the next time radio is turned on.
SOOTHING NATURE SOUNDS
NOTE Deactivate radio first. RADIO OFF will be
displayed on screen.
To activate / deactivate soothing sounds:
1. Press NATURE SOUND to play sounds.
2. Press NATURE SOUND repeatedly to select desired
sound (1-4) or to turn sound off.
ADJUST VOLUME
To adjust volume:
• Press + / – when radio or nature sound is turned on.
TIP Press and hold + / – to rapidly adjust volume.
ALARM
To set the alarm:
1. Press SET ALARM to enter setting mode.
2. Press + / - to change the settings or press and hold +
/ – to rapidly change the settings.
3. Press SET ALARM to confirm and move to next
setting.
4. Repeat steps 2-3 for all setting options.
The settings order is: time, alarm sound (select from beep
/ radio / bird sound).
NOTE If radio alarm is selected, radio will play for 60
minutes at set alarm time at maximum volume level.
If bird sound alarm is selected, bird sound will gradually
increase in volume to maximum and play for 2 minutes at
set alarm time .
To activate / deactivate alarm:
• Press ALARM.
-:- - indicates alarm function has been disabled.
To silence the alarm:
• Wave your hand up to 8 cm (3 inches) in front of the
SNOOZE SENSOR to silence it for 8 minutes ( / /
/ will continue flashing to indicate snooze function has
been activated)
3
EN
ALARM WITH WAKE UP LIGHT
To activate / deactivate wake up light:
• Slide WAKE UP LIGHT switch to ON / OFF.
When wake up light has been activated, will be displayed
next to ALARM on the LCD screen.
NOTE Light will fade-in (gradually increase in brightness
to maximum) 20 minutes prior to set alarm time. Light Will
stay on (even after SNOOZE has been activated) after
set alarm time for 60 minutes.
SLEEP TIMER
To adjust sleep timer setting:
1. Turn on desired option:
OPTION PRESS:
Radio RADIO
Light LAMP
Nature sound NATURE SOUND
2. Press SLEEP to activate.
3. Press SLEEP repeatedly to change the sleep timer
setting (120, 90, 60, 30, 15, 0 min).
After 5 seconds of inaction, the timer will automatically be
confirmed and set.
TIP Press SLEEP again to change sleep timer (120, 90,
60, 30, 15, 0 min).
NOTE Ensure radio or sound and/or light has been
selected to activate sleep timer.
NOTE If light option has been chosen for sleep timer, light
will fade out.
READING LAMP
To turn on / off light:
• Press LAMP.
To adjust level of brightness:
• Press / to increase or decrease brightness.
TIP Press and hold / to rapidly change level of
brightness (1-20).
For your convenience, the level of brightness will be
stored in memory for the next time reading lamp is turned
on.
NOTE Do not look directly at the light.
PLAYING MUSIC
Using a cable, plug one end to your music storage device
and one end to AUDIO LINE-IN located at the back of unit.
When cable has been successfully connected, will
be displayed on the LCD screen and sound will emit from
speakers.
LCD BACKLIGHT
To adjust brightness:
• Slide DISPLAY BRIGHTNESS switch to LOW / HIGH.
RESET
1. Remove and reinsert the batteries.
2. Press RESET to return to the default settings.
SPECIFICATIONS
TYPE
MAIN UNIT
L x W x H
Weight 386 g (13.6 oz) without battery
FM
Power
NOTE
• Connection type of the switch: ε
• Range of lamp load: (Lamp) 20W - 60W
• The apparatus shall not be exposed to dripping or
splashing.
• To be completely disconnect the power input, the
mains plug of apparatus shall be disconnected from
the mains.
• The mains plug of apparatus should not be
obstructed OR should be easily accessed during
intended use.
• No naked flame sources such as lighted candles
should be placed on the apparatus.
DESCRIPTION
257 x 199 x 140 mm
(10.12 x 7.84 x 5.51 in)
87.5 to 108 MHz
Input: AC 230V 50Hz
(EU version)
Input: AC 100-120V 50/60Hz
(US/Canada/Japan version)
2 x UM-4 (AAA) 1.5V batteries
(for backup)
4
EN
5
TROUBLESHOOTING
The below table lists out some of the problems you could encounter. If you are unable to solve the problem, contact the
Customer Care Centre in your country. Contact us via www2.oregonscientific.com/service/support.asp
Problem Possible cause Solution / Remarks
The unit does not
work
Power supply? Ensure plug has been properly inserted into the wall socket
Ensure there is no power failure. Check by connecting
another appliance to the wall socket
The unit does not
work
When setting
functions, the unit
does not respond
The light does not
work
Lamp does not turn
on again immediately
after it has been
switched off
No sound when the
alarm goes on
The radio is
defective / produces
a crackling sound
Alarm did not activate
today, but it did
yesterday
The light wakes me
too early / late
Normal use This is normal as the light bulb generates heat. However,
Normal use Press RESET at the base of the unit or remove and reinsert
Light intensity is too low? Press to increase light intensity
Alarm function disabled? Ensure alarm time is displayed on LCD screen. Press
Light bulb is defective? Replace the light bulb.
Light bulb not properly
screwed in?
Normal operations Allow 3 seconds for the lamp to dim. Please wait until the
Alarm function disabled? Ensure alarm time is displayed on LCD screen. If -:- - is
Radio is defective? If radio has been selected for alarm mode, check that radio
Positioning of external
antenna?
Broadcast signal is weak? Press RADIO TUNE to search for the correct signal.
Alarm function disabled? Ensure alarm time is displayed on LCD screen. If -:- - is
Power failure? Perhaps there was a power failure which lasted longer than
Location of unit is not
suitable?
ensure there is enough ventilation and vents are not
covered as this can pose a fire hazard.
plug into wall socket. The appliance will then be reset to
factory default settings.
ALARM to enable.
Unscrew and screw in the light bulb again.
lamp reaches the preset intensity level
displayed, press ALARM to enable.
works. Press RADIO after you disable the alarm or press
ALARM.
Change position of external antenna if necessary.
displayed, press ALARM to enable.
the capacity of the back up system? The display will show
an incorrect time and alarm will be 00:00. Do settings
again.
It is recommended that the unit is not placed too far and not
lower than your head while in a sleeping position. Make
sure the light is not blocked by bed, duvet or pillow.
Snooze does not
work
LCD backlight is too
weak to see
There is no sound
after plugging to an
external source
Distance? Wave your hand in front of the SNOOZE SENSOR at a
distance range of approx. 1cm to 8cm (0.5 to 3 in).
Display brightness? Slide DISPLAY BRIGHTNESS to HIGH.
External device? Make sure external device is playing.
Connection? Make sure cable is firmly connected with the external
device and the unit.
EN
PRECAUTIONS
• Do not subject the unit to excessive force, shock, dust,
temperature or humidity.
• Do not cover the ventilation holes with any items such as
newspapers, curtains etc.
• Remove dust regularly with a dry cloth. Accumulated
dust poses a potential fire hazard.
• Do not immerse the unit in water. If you spill liquid over it,
dry it immediately with a soft, lint-free cloth.
• Do not clean the unit with abrasive or corrosive materials.
• Do not tamper with the unit’s internal components. This
invalidates the warranty.
• Only use fresh batteries. Do not mix new and old batteries.
• Images shown in this manual may differ from the actual
display.
• When disposing of this product, ensure it is collected
separately for special treatment.
• Placement of this product on certain types of wood may
result in damage to its finish for which Oregon Scientific will
not be responsible. Consult the furniture manufacturer's
care instructions for information.
• The contents of this manual may not be reproduced
without the permission of the manufacturer.
• Do not dispose old batteries as unsorted municipal waste.
Collection of such waste separately for special treatment is
necessary.
• Please note that some units are equipped with a battery
safety strip. Remove the strip from the battery compartment
before first use.
NOTE The technical specifications for this product and
the contents of the user manual are subject to change
without notice.
NOTE If the external flexible cable or cord of this luminair
is damaged, it shall be exclusively replaced by manufacturer or his service agent or a similar qualified person in
order to avoid hazard.
NOTE For indoor use only.
EU-DECLARATION OF CONFORMITY
Visit our website (www.oregonscientific.com) to learn
more about Oregon Scientific products. If you're in the
US and would like to contact our Customer Care
department directly, please visit:
www2.oregonscientific.com/service/support.asp
For international inquiries, please visit:
www2.oregonscientific.com/about/international.asp
All EC countries, Switzerland
COUNTRIES RTTE APPROVAL COMPLIED
and Norway
CH
N
ABOUT OREGON SCIENTIFIC
Hereby, Oregon Scientific, declares that this Sunrise
Wake-Up Clock (Model: WS902) is in compliance with
EMC directive 2004/108/EC. A copy of the signed and
dated Declaration of Conformity is available on request via
our Oregon Scientific Customer Service.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2)
This device must accept any interference received,
including interference that may cause undesired
operation.
WARNING Changes or modifications not expressly
approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE This equipment has been tested and found to
comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio / TV
technician for help.
MANUALLY SET CLOCK
ALARM
The following information is not to be used as contact for
support or sales. Please call our customer service
number (listed on our website at
www.oregonscientific.com), or on the warranty card for
this product) for all inquiries instead.
We
Name: Oregon Scientific, Inc.
Address: 19861 SW 95th Ave.,Tualatin,
Oregon 97062 USA
declare that the product
Product No.: WS902
Product Name: Sunrise Wake-Up Clock
Manufacturer: iPM Concepts Limited
Address: Block C, 9/F, Kaiser Estate,
Phase 1, 41 Man Yue St.,
Hung Hom, Kowloon, Hong Kong
is in conformity with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: 1) This device
may not cause harmful interference. 2) This device must
accept any interference received, including interference
that may cause undesired operation.
6
Loading...
