Oregon Scientific TW339, TW339H User Manual
EN
2.4GHz Digital Cordless Telephone with Caller ID and
Indoor/Outdoor Temperature
Teléfono Inalámbrico Digital de 2,4GHz con Identificación
de llamada y lectura de la Temperatura interior/exterior
Model: TW339/TW339H
User Manual
Manual de Usuario
TW339 manual_Eng 6.p65 3/9/05, 4:21 PM1
EN
TW339 manual_Eng 6.p65 3/9/05, 4:21 PM2
EN
IMPORTANT SAFETY INSTRUCTIONS . . . 1
SAFETY TIPS . . . . . . . . . . . . . . . . . . . . . . 2
INTRODUCTION . . . . . . . . . . . . . . . . . . . 2
Key Features . . . . . . . . . . . . . . . . . . . . 2
Handset – Front View . . . . . . . . . . . . . . . 3
Base Charger – Front View . . . . . . . . . . . 3
Remote Sensor – Front View . . . . . . . . . . 3
Remote Sensor – Back View . . . . . . . . . . .4
GETTING STARTED . . . . . . . . . . . . . . . . . . 4
Choosing a Base Unit Location . . . . . . . . 4
Connecting the Base Unit . . . . . . . . . . . . 4
Remote Sensor Set-up . . . . . . . . . . . . . . 4
Changing the Remote Sensor Channel . . . 5
Battery Set-up . . . . . . . . . . . . . . . . . . . . 5
Charging Handset Batteries . . . . . . . . . . . 5
Temperature Unit . . . . . . . . . . . . . . . . . . 5
INITIAL PROGRAMMING . . . . . . . . . . . . . . . 6
Language Setting . . . . . . . . . . . . . . . . . . 6
Handset Name . . . . . . . . . . . . . . . . . . . 6
Dial Mode . . . . . . . . . . . . . . . . . . . . . . . 6
Flash Time . . . . . . . . . . . . . . . . . . . . . . 6
Key Lock . . . . . . . . . . . . . . . . . . . . . . . 6
Key Tone . . . . . . . . . . . . . . . . . . . . . . . 7
Handset Ring Tone . . . . . . . . . . . . . . . . 7
Handset Ring Volume Level . . . . . . . . . . 7
Earpiece Volume Level . . . . . . . . . . . . . . 7
Auto Answer On/Off . . . . . . . . . . . . . . . . 7
Clear Message Waiting . . . . . . . . . . . . . . 8
BASICS . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Stand-by Mode . . . . . . . . . . . . . . . . . . . 8
Receiving a Call . . . . . . . . . . . . . . . . . . 8
Making a Call . . . . . . . . . . . . . . . . . . . . 8
Correcting a Call . . . . . . . . . . . . . . . . . . 8
Redialing . . . . . . . . . . . . . . . . . . . . . . . 8
Returning Missed Calls . . . . . . . . . . . . . . 9
The Mute Key . . . . . . . . . . . . . . . . . . . . 9
Handset Locator . . . . . . . . . . . . . . . . . . 9
Low Battery Warning . . . . . . . . . . . . . . . 9
Voice Mail Indicator . . . . . . . . . . . . . . . . 9
TABLE OF CONTENTS
CALLER ID FEATURES . . . . . . . . . . . . . . . . .9
Caller ID with Call Waiting . . . . . . . . . . . . . 9
Caller ID List . . . . . . . . . . . . . . . . . . . . . . 10
Reviewing Your Caller ID List . . . . . . . . . . 10
Deleting Entries From Caller ID List . . . . . . 10
DIRECTORY . . . . . . . . . . . . . . . . . . . . . . . . .10
Storing a Name/Numbers in Your Directory ..11
Making Calls from Your Directory . . . . . . . .11
Deleting an Entry . . . . . . . . . . . . . . . . . . . 11
Changing a Stored Entry . . . . . . . . . . . . . . 12
Store Caller ID Entries in Your Directory . . .12
MULTI-HANDSET CONFIGURATION. . . . . . . . 12
To Register a New Handset . . . . . . . . . . . .12
Identifying a Handset on the Network . . . . 13
Intercom (Internal) Calls . . . . . . . . . . . . . . 13
Intercom Ring Tone . . . . . . . . . . . . . . . . . 13
Call Togging . . . . . . . . . . . . . . . . . . . . . . 13
3-Way Conference Call . . . . . . . . . . . . . . 13
Call Waiting . . . . . . . . . . . . . . . . . . . . . . 14
Transfer Calls Between Handsets . . . . . . . 14
Call Back . . . . . . . . . . . . . . . . . . . . . . . . 14
TEMPERATURE MONITORING . . . . . . . . . . . . 14
Indoor Temperature . . . . . . . . . . . . . . . . . 14
Outdoor Temperature . . . . . . . . . . . . . . . . 15
Sensor Search . . . . . . . . . . . . . . . . . . . . . 15
Change Remote Control . . . . . . . . . . . . . . 15
CHANGING THE HANDSET BATTERY . . . . . . . 15
Replacing the Battery . . . . . . . . . . . . . . . . 15
RECYCLING NICKEL-METAL HYDRIDE
BATTERIES . . . . . . . . . . . . . . . . . . . . . . . . . 16
HEADSET JACK AND BELT CLIP . . . . . . . . . . 16
Belt Clip . . . . . . . . . . . . . . . . . . . . . . . . . 16
POWER FAILURE . . . . . . . . . . . . . . . . . . . . 16
LCD SCREEN MESSAGES . . . . . . . . . . . . . . 16
Light Signals . . . . . . . . . . . . . . . . . . . . . . 17
Sound Signals . . . . . . . . . . . . . . . . . . . . . 17
TROUBLESHOOTING . . . . . . . . . . . . . . . . . .17
Telephone . . . . . . . . . . . . . . . . . . . . . . . . 17
Multi-handset Use . . . . . . . . . . . . . . . . . . 18
Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . 18
Remote Sensor . . . . . . . . . . . . . . . . . . . . 18
Causes of Poor Reception . . . . . . . . . . . . 18
MAINTENANCE AND CARE . . . . . . . . . . . . . . 19
MAXIMIZING BATTERY PERFORMANCE . . . . . 19
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . .19
ABOUT OREGON SCIENTIFIC . . . . . . . . . . . 20
FCC STATEMENT . . . . . . . . . . . . . . . . . . . . . 20
CONSUMER INFORMATION . . . . . . . . . . . . . 21
DECLARATION OF CONFORMITY . . . . . . . 22
2.4GHz Digital Cordless Telephone
with Caller ID and Indoor/Outdoor
Temperature
Model: TW339/TW339H
USER MANUAL
TW339 manual_Eng 6.p65 3/9/05, 4:21 PM3
EN
IMPORTANT SAFETY INSTRUCTIONS
1
Some of the following information may not apply
to your particular product; however, when using
conference phone equipment, basic safety
precautions should always be followed to reduce
the risk of fire, electric shock and injury to
persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked
on the product.
3. Unplug this product from the wall outlet
before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for
cleaning.
4. This product should not be used while you are
in a bathtub, shower or pool. Immersion of
the product in water could cause an electrical
shock.
5. Slots and openings in the cabinet back or
bottom are provided for ventilation, to protect
it from overheating. These openings must not
be blocked or covered. The openings should
never be blocked by placing the product on a
bed, sofa, rug, or other similar surface.
This product should not be placed in a built-in
installation unless proper ventilation is
provided.
6. This product should be operated only from
the type of power source indicated on the
marking label. If you are not sure of the type
of power supply to your home, consult your
dealer or local power company.
7. Do not allow anything to rest on the power
cord.Do not locate this product where the
cord will be abused by persons walking on it.
8. Do not overload wall outlets and extension
cords as this can result in the risk of fire or
electric shock.
9. Never push objects of any kind into this
product through the cabinet slots as they
may touch dangerous voltage points or short
out parts that could result in a risk of fire or
electric shock. Never spill liquid of any
kind on the product.
10. To reduce the risk of electric shock, do not
disassemble this product, but take it to a
qualified serviceman when service or repair
work is required. Opening or removing covers
may expose you to dangerous voltages or
other risks. Incorrect reassembly can cause
electric shock when the telephone equipment
is subsequently used.
11. Do not expose the product to extreme
temperatures such as areas near a hot radiator,
or stove, or in a hot car.
12. Do not place lighted candles, cigarettes, cigars,
etc., on the telephone.
13. Never touch uninsulated telephone wires or
terminals unless the telephone line has been
disconnected at the network interface.
14. Never install or modify telephone wiring during
a lightning storm.
15. Never install telephone jacks in wet locations
unless the jack is specifically designed for wet
locations.
16. Use caution when installing or modifying telephone lines to prevent electrical shock and / or
fire.
17. Unplug this product from the wall outlet and
refer servicing to qualified service personnel
under the following conditions:
• When the power supply cord or plug is
damaged or frayed.
• If the product has been exposed to rain or
water.
• If the product does not operate normally by
following the operating instructions.
• If the product’s cabinet has been damaged.
• If the product exhibits a distinct change in
performance.
18. Avoid using a telephone (other than a cordless
type) during an electrical storm. There may be a
remote risk of electric shock from lightning.
19. Do not use the telephone to report a gas leak in
the vicinity of the leak.
20. Do not place this product on an unstable cart,
stand or table. The product may fall, causing
serious damage to the product.
21. Plug the adaptor to a socket-outlet which is near
the equipment and is easily accessible.
22. Risk of explosion if battery is replaced by
an incorrect type, use only SANIK, 3SNAAA75H-S-J1F. Dispose of used batteries
TW339 manual_Eng 6.p65 3/9/05, 4:21 PM4
EN
2
SAFETY TIPS
INTRODUCTION
This product is designed to give you years of
service if handled properly. Observe the following
guidelines:
• Clean the unit with a damp cloth and mild
detergent. Avoid dropping the unit or placing it in
a high-traffic location.
• Never immerse the unit in water. This can cause
electrical shock and damage the unit.
• Do not subject the Base Unit to extreme force,
shock, or fluctuations in humidity.
• Do not tamper with the internal components.
• Do not mix new and old batteries or batteries of
different types.
• Remove the batteries if storing this product for
a long period of time.
• Do not scratch the LCD display.
• Do not make any changes or modifications to
this product. Unauthorized changes may void
your right to use this product.
• The technical specifications for this product and
the contents of the user manual are subject to
change without notice.
CAUTION
To reduce the risk of fire, use only No. 26 AWG
or larger telecommunication line cord.
CAUTION
You must use a Class 2 power source
that provide in package. Its plug must
fit the phone’s DC IN 9V jack. The
supplied adapter meets these specifications.
Using an adapter that does not meet these
specifications could damage the phone or the
adapter. Always connect the AC adapter to the
phone before you connect it to AC power.
When you finish, disconnect the adapter from
AC power before you disconnect from the
phone.
SAVE THESE INSTRUCTIONS
Congratulations on your purchase of this Oregon
Scientific telephone. Your 2.4GHz digital cordless
telephone is a high-quality home communications
product with many advanced features.
It is carefully designed and produced by a world
leader of consumer electronic equipment. With
proper maintenance and care, your new telephone
will provide you with years of enjoyment and
service.
KEY FEATURES
Your 2.4GHz Digital Cordless Telephone With
Caller ID and Indoor/Outdoor Temperature
features:
Superior Range - The use of the 2.4GHz
frequency band for signal transmission means
greater communication range for you, compared
to conventional 46–49MHz cordless telephones.
Ultra-low Noise - High frequency communication
will significantly reduce unwanted noise levels.
Channel Auto Scan - Your new telephone uses
one of the channels in the 2.4GHz frequency
band. It automatically selects a clear channel
every time you receive or place a call.
COMPANDER PLUS Noise Reduction - This
fourth generation noise reduction technology
filters out even more background noise to give
you clear communication.
Other features of this product include:
• Caller ID memory that holds up to 30 numbers.
• Electronic telephone book that holds up to 70
numbers.
• Recognition of up to 4 additional handsets for
making handset-to-handset calls (intercom) and
3-way calls. Two handsets are shipped with this
product. Additional handsets are sold separately.
• Microphone mute function.
• Adjustable ring tones, volume levels, language
display, handset IDs and low-battery / out-ofrange warning signals.
• Rechargeable batteries and up to 7-hours of
continuous talk time.
• Indoor and outdoor temperature display (Celsius
or Fahrenheit).
according to the instructions.
23. For servicing or replacement, you can purchase
a suitable headset through service center or
retailer shop (see in www. oregonscientic.com).
TW339 manual_Eng 6.p65 3/9/05, 4:21 PM5
EN
3
• Wireless, splash-proof remote sensor.
• Register up to 2 additional remote sensors for
displaying individual room or outdoor tempera
ture information.
IMPORTANT: To use all of the features of this
telephone, you must subscribe to either the
standard Name/Number Caller ID Service or
Caller ID with Call Waiting Service from your local
telephone company.
The following items should be included in the
TW339/TW339H package:
• Base unit
• Handset cradle (for TW339H)
• 1 handsets (2 handsets for TW339H)
• 1 AC adaptor (2 AC adaptors - Base: PI-41-
735US, Handset charger: A10920(T) for
TW339H)
• 1 belt clip (2 belt clips for TW339H)
• Telephone line cord
• Handset batteries
• Battery order sheet
• Remote sensor
• Sensor table stand
• Sensor wall mount
• Sensor batteries
• User manual
NOTE: You need an RJ11 type modular phone
jack. If you do not have a modular jack, call your
local phone company to find out how to get one
installed.
NOTE : Please keep this manual handy as you
use your new product. It contains practical stepby-step instruction, as well as technical specifications and warnings you should know.
HANDSET - FRONT VIEW
BASE CHARGER - FRONT VIEW
1. TEMP button
2. LCD display
3. °C / °F hole (on bottom of base)
4. PAGE button
5. CHARGE/IN USE indicator
REMOTE SENSOR - FRONT VIEW
1. LCD (temperature) display
2. LED indicator
1. MENU/OK key
2. key
3. TALK key
4. TONE key
5. REDIAL/PAUSE key
6. Earpiece
7. LCD screen
8. key
9. C/MUTE key
10.INT key
11. NUMBER keys
12.FLASH/DEL key
13.Microphone
14.Headset jack
TW339 manual_Eng 6.p65 3/9/05, 4:21 PM6
EN
4
REMOTE SENSOR - BACK VIEW
1. RESET button
2. °C / °F switch
3. Channel selection switch
4. Battery compartment
GETTING STARTED
Some cordless telephones operate at frequencies
that may cause interference to nearby TVs,
microwave ovens and VCRs. To minimize or
prevent such interference, the base of the
cordless telephone should not be placed near or
on top of a TV, microwave oven or VCR. If such
interference continues, move the cordless
telephone farther away from these appliances.
Certain other communication devices may also
use the 2.4GHz frequency for communication
and, if not set properly, these devices may
interfere with your new telephone.
Typical devices that may use the 2.4GH
frequency include wireless audio/video senders,
wireless computer networks and multi-handset
cordless telephone systems.
CHOOSING BASE UNIT LOCATION
When selecting a location for your base unit
(which records and displays the indoor temperature), please observe the following guidelines:
• Choose a location that provides easy access
to a 120-volt AC power source.
• Choose a location that will allow the telephone
cable to reach a telephone jack. (You can use
an extension cable if necessary).
• Place the base unit as high as possible to get
a better radio frequency range with the
handset. You may need to try several
locations – such as upstairs, or near a firstfloor landing – to find the best range. Solid
structures, such as walls and doors, may
reduce the signal strength.
• Do not place the base unit near a sink, bathtub
or shower.
• Do not place the base unit near large metal
objects or electronic appliances that may
cause radio interference. Some of these
include: mirrors, filing cabinets, electric
stoves, washing machines, microwave ovens,
televisions, fluorescent lights or other
telephones.
• Do not place the unit near heat sources, such
as radiators or air ducts, or in a place subject
to direct sunlight.
CONNECTING THE BASE UNIT
To connect the base unit:
1. Plug the AC adaptor into the power jack on
the back of the base, and then plug the
other end into an electrical outlet.
2. Plug the telephone line cord into the
telephone line jack on the back of the base
unit, and then plug the other end into a
modular phone jack.
NOTE: The adaptor is shipped with the product.
Please check the label on the adaptor to make
sure you are using the right one.
NOTE: You need a RJ11 modular phone jack. If
you do not have a modular jack, call your local
phone company to find out how to get one
installed.
REMOTE SENSOR SETUP
This product measures the outdoor temperature
and then transmits the information to the base
unit. It can be used with up to 2 other remote
sensors to transmit data back to the base unit.
Additional remote sensors that measure temperature are sold separately.
NOTE: If you are using more than one remote
sensor, be sure to select a different channel for
TW339 manual_Eng 6.p65 3/9/05, 4:21 PM7
EN
5
each sensor.
To setup your remote sensor:
1. Place the remote sensor as close as
possible to the base unit.
2. Remove the battery compartment cover by
using a Philips screwdriver to loosen the
screws, and then insert the batteries. (Be
sure to match polarities as shown).
3. Assign channel numbers 1, 2, or 3. If you
are using more than one remote sensor,
select a different channel number for each
sensor.
4. Select the temperature measurement units
°C or °F (Celsius or Fahrenheit).
5. Press the RESET button with the point of a
blunt object (such as a ball point pen).
6. Replace the battery compartment cover.
Secure.
7. Position the remote sensor using either the
stand (included) or the recess hole on the
back of the sensor.
8. Connect the adaptor to the base unit, press
and hold TEMP on the base until the CH icon
blinks. (It will take 3 minutes for the base to
search for available remote sensors even if
you only have one sensor).
9. Once the batteries are in place, the sensor
will transmit signals every 40 seconds.
NOTE: The readings shown on the base unit
depend on which remote sensor (1, 2 or 3) is
selected.
CHANGING THE REMOTE SENSOR
CHANNEL
To change the channel on your remote sensor,
select a different channel number and then press
RESET on the sensor.
To install the battery in
your handset:
1. Open the battery
compartment cover
located at the back
of the handset.
2. Plug the battery
connector into the
socket.
3. Replace the battery
compartment cover
by sliding it in the
direction shown by the
arrow in the diagram to
the right. The cover
clicks into place when
it is secured.
BATTERY SETUP
CHARGING HANDSET BATTERIES
You must charge the handset batteries for 15
continuous hours the first time you use them.
When the icon appears empty and “CHARGE
BATTERY” shows on the LCD screen, or if you
hear a warning beep during a call, please:
• End the call as soon as possible.
• Charge the handset by putting it back on the
base cradle with the keypad facing outwards.
(The blue CHARGE LED on the base unit
steadily lights to indicate that the handset is
charging).
NOTE: It is normal for the handset and base to
get warm when the handset is charging on the
base.
TEMPERATURE UNIT
The temperature display switch is located on the
bottom of the base unit. Use the tip of a pointed
object (such as an unfolded paperclip) to switch
between Celsius and Fahrenheit. The unit of
measurement should match the unit you selected
for the remote sensor.
NOTE: When the outdoor temperature reaches 40
1.
2.
3.
