POLERMO Projection Clock

with Motion Alert

Model: RMR939PA / MSR939A

USER MANUAL

POLERMO Projection Clock

with Motion Alert

Model: RMR939PA / MSR939A

USER MANUAL

CONTENTS

Introduction .............................................................. 2

Product Overview .................................................... 3

Front View .............................................................. 3

Back View .............................................................. 5

LCD Display ...........................................................6

Remote Motion Sensor (MSR939A) - Front View ..8

Remote Motion Sensor (MSR939A) - Back View .. 9

Safety and Care ...................................................... 10

Safety Precautions ............................................... 10

Caring for this Product ......................................... 10

Getting Started ....................................................... 10

Package Contents ............................................... 10

Batteries ............................................................... 11

AC Adaptor .......................................................... 12

About Atomic Clock Reception ............................ 12

Turning the Atomic Clock Signal ON / OFF ......... 13

Clock / Calendar ..................................................... 13

Clock / Calendar Display ..................................... 13

Setting the Clock / Calendar ................................ 14

Backlight ................................................................. 14

Temperature............................................................ 14

Alarm ....................................................................... 15

Alarm Display ...................................................... 15

Setting the Alarm(s) ............................................. 15

Activating / Deactivating the Alarm(s) ..................15

Alarm Sound ........................................................ 15

Snooze / Turning the Alarm OFF ......................... 15

Motion Alarm .......................................................... 16

Motion Alarm Setting Display ............................... 16

Setting the Motion Alarm...................................... 16

Turning the Motion Alarm OFF ............................ 17

Sleep Timer .............................................................17

Projection Unit ....................................................... 18

Motion Sensor (MSR939A) .................................... 18

Setup Sensor ....................................................... 18

Wake-Up Vibration Alarm - VR101A (Optional) .... 19

Resetting the Clock ............................................... 19

Warnings .................................................................20

Troubleshooting .....................................................20

Technical Specifications ....................................... 21

RMR939PA English R5 9/21/04, 2:40 PM1

Notices .................................................................... 23

Statement of Responsibility ................................. 23

About Oregon Scientific ........................................ 23

FCC Statement ....................................................... 24

Declaration of Conformity .................................... 24

INTRODUCTION

Thank you for selecting the Oregon Scientific

POLERMO Projection Clock with Motion Alert. This

device is designed to give you many years of reliable service, including the following conveniences:

• US Atomic Calendar Clock

• Optional Wireless Vibration Alarm with 8-Minute Snooze Function (Wake-Up Vibrating Alarm VR101A can be purchased separately)

• Sleep Function with 6 Soothing Sounds

• 5 Alarm Melodies with 2 Volume Levels

• 2-Minute Dual Alarm with 8-Minute Snooze Function

• Time / Alarm Status Projection Unit

• Security Alarm / Motion Sensor Unit

• Indoor Temperature Display

• Day of the Week in 1 of 5 Languages

• Time Zone Hour Offset Function

• Backlight for Clock

Keep this manual handy as you use your new product. It contains practical step-by-step instructions, as well as technical specifications and warnings you should know.

RMR939PA English R5 9/21/04, 2:40 PM2

PRODUCT OVERVIEW

FRONT VIEW

1 2

4 5

RMR939PA English R5 9/21/04, 2:40 PM3

1. SOUND / SLEEP button

• Press to turn the soothing sound ON.

• Press to wrap around the sleep timer setting as follows: 0 0

• Press and hold for 2 seconds to choose 1 of

6 soothing sounds.

2. SNOOZE / LIGHT button

• Press to activate the 8-minute snooze function.

• Press and hold for 2 seconds to turn snooze OFF and reset the alarm for the next day.

• Press to activate the backlight and projection for 5 seconds.

120 90 60 30 15

minutes.

3. LCD display

4. CLOCK ALARM button

• Press to toggle between alarm 1 and alarm 2 ON / OFF.

• Press and hold for 2 seconds to enter the Alarm Time Setting Mode.

5. MOTION ALARM button

• Press to enter the Motion Alarm Mode; press again to toggle between motion alarm ON / OFF.

• Press and hold for 2 seconds to enter:

- Motion Sensor Code.

- Motion Alarm Setting Mode for motion alarm period and alarm type.

6. Projector

Projects time and alarm status.

7. CLOCK button

• Press to toggle between the following display modes:

- Clock with seconds and calendar.

- Clock with weekday and calendar.

- Clock with time zone hour offset and calendar.

• Press and hold for 2 seconds to enter the Clock Setting Mode - US time zone hour offset, 12- / 24-hour format, hour, minute, year, MM / DD or DD / MM format, month, day and day of the week language.

UP /

DOWN button

• Press to increase or decrease a setting.

• Press and hold for 2 seconds to activate or deactivate atomic clock.

• Press to increase or decrease the soothing sound volume.

RMR939PA English R5 9/21/04, 2:40 PM4

BACK VIEW

2 3 4

1. Projector FOCUS knob

• Twist to focus the projected image.

2. Projector IMAGE ROTATION knob

• Twist to get the best viewing angle of the projected

image.

3. PROJECTION ON switch

• Slide to ON for continuous image projection when the AC power is connected.

4. Projector 180° ROTATION button

• Press to rotate the image upside down.

5. 6V AC / DC Power Socket

6. Battery Compartment (cover on)

• Uses 4 x UM-3 / AA 1.5V batteries.

7. RESET hole

• Insert a thin blunt instrument to return all values to the default settings.

8. °C / °F switch

• Press to select between °C / °F display format.

RMR939PA English R5 9/21/04, 2:40 PM5

LCD DISPLAY

1 2

3 4

5 6

RMR939PA English R5 9/21/04, 2:40 PM6

• Appears when the sleep function is activated.

2. Battery Low icon

1. SOUND

12 13

14 15

17 18 19

• Appears when the clock batteries are low or, no batteries are installed and only the AC adaptor is connected.

3. Time

• HH / MM, 12- / 24-Hour, AM / PM.

4. ZONE

• Appears when you are in the Time and Zone Hour

Offset display.

5. Channel 1 / 2

• Ch.1 or Ch.2 will appear when the related motion sensor is activated.

6. Motion Alarm ON icon

7. Calendar

• DD / MM / YY or MM / DD / YY.

8. Temperature

• °C / °F.

9. Atomic Clock Signal Reception icon

• Shows the strength of the reception signal.

10. MIN

• Appears when the sleep function is activated.

11. Time Zone Hour Offset / Day of the Week

• Offsets the atomic clock time setting when you are in a different time zone (+ / -23 hours).

• Name of day available in 1 of 5 languages.

12. START

• Start time for the motion sensor to be activated.

13. Alarm 1

• Indicator to show this is alarm 1.

14. Alarm 1 / 2 Time

• Shows alarm times / AM or PM.

15. Melody Alarm icon

• Shows when the clock alarm is set.

16. Vibration Alarm icon (Wake-Up Vibration Alarm - optional item)

• Appears on the display when the vibrating alarm

has been set.

17. Alarm 2

• Indicator to show this is alarm 2.

18. STOP

• Stop time for the motion sensor.

19. Motion Alarm Settings icon

RMR939PA English R5 9/21/04, 2:40 PM7
