Oregon RM983A User Manual
ENGLISH
Use the [ up ] and [ down ] buttonto activate / deactiv ate the alarm in the respective
Alarm Display Mode.
RADIO CONTROLLED
ALARM CLOCK WITH
THERMOMETER
MODEL : RM983A
USER MANUAL
A
B
C
E
F
Fig. 1
Set offset hour in 2nd time- zone Imposta l'ora di offset del 2º fuso orario
Règle la compensation du deuxième fuseau horaire. hora de compensación de 2a hora/zona horaria
Zeitzonenversatz einstellen Ajustar a diferença horária da 2a. zona de fuso horário
Fig. 4
Press & Hold 2 seconds Pulse y sostenga 2 segundos
Tenere premuto per 2 secondi 2 Sekunden lang drücken und festhalten
Appuyer dessus pendant 2 secondes.
Prima durante 2 segundos
D
G
H
Fig. 5
AA
Fig. 2a Fig. 2b
Strong, Forte, Stark, Buona, Fuerte, Forte
Weak, Faible, Schwach, Debole, Devil, Fraco
No Reception, Pas de réception, Kein Empfang,
Ricezione nulla, No Hay Recepcion, Sem sinal
Receiving, Recevant, Empfang,
Ricezione, Recibiendo, A receber
Fig. 3
Fig. 7
Fig. 8
Fig. 6
Language
Langues
Sprache
Lingue
Idiomas
Lingua
English
Anglais
Englisch
Inglese
Inglés
Inglês
German
Allemand
Deutsch
Tedesco
Alemán
Alemão
French
Français
Französisch
Francese
Francés
Francês
Italian
Italian
Italienisch
Italiano
Italiano
Italíano
Spanish
Espagnol
Spanisch
Spagnolo
Español
Espanhol
Day-of-the-week Affichage du jour Wochentaganzeige
Giorno della settimana
Monday
Lundi Mardi
Montag
Lunedí
Lunes Martes
Segunda Terça Quarta Quinta Sexta Sábado
Día de la semana Dia de Semana
Tuesday Wednesday Thursday
Mercredi
Dienstag Mittwoch
Martedí Mercoledí Glovedí Venerdí
Miércoles Jueves Viernes Sábado Domingo
Jeudi
Donnerstag
Friday
Vendredi
Freitag
Saturday
Samedi
Samstag Sonntag
Sabato
Fig. 5
Sunday
Dimanche
Domenica
Domingo
INTRODUCTION
Congratulations on your purchase of the RM983A Radio-controlled Clock with
thermometer.
Features of RM983A include:
- RF controlled Clock and Calendar
- Indoor temperature display
- Backlight for night viewing
- Dual Alarm (Single and Weekday Alarm) with Snooze function
MAIN FEATURE [FIG. 1]
A. SNOOZE BUTTON
-Press to turn on the backlight for 5 seconds
-Press to activate the 8-minute Snooze function when alarm goes off
B. CLOCK WINDOW
-Displays clock function
C. CALENDAR/ ALARM WINDOW
-Displays Calendar and Alarm functions
D. TEMPERATURE WINDOW
-Displays indoor temperature
E. ALARM BUTTON
-Press to toggle among Weekday Alarm, Single Alarm and Calendar mode
-Press and hold for 2 seconds to enter the alarm time setting mode when
the respective alarm mode is in display
F. MODE BUTTON
-Press to toggle among the following displays:
Clock with Second ➝ Clock with Weekday ➝ Clock with offset hour ➝ …
-Press and hold for 2 seconds to enter the clock setting mode
G. UP & DOWN BUTTONS
-Press to increase or decrease the value of a setting
-Press to activate or deactivate the alarm when the respective alarm time is
shown
H. BATTERY COMPARTMENT
-Uses 1 piece of UM-3 or "AA" battery
BATTERY INSTALLATION [Fig. 2a]
Remark: Replace with new battery when the low battery indicator [ ] is
displayed [Fig. 2b]
HOW TO USE THE BACKLIGHT
Press the SNOOZE button to turn on the backlight for 5 seconds.
ABOUT RADIO RECEPTION [FIG. 3]
RM983A is designed to synchronize its calendar clock automatically once it is
brought within range of the radio signal from the U.S. Atomic Clock.When the
unit is new and just out of the box, synchronization with the U.S. Atomic Clock
can take up to 72 hours.
When the unit is receiving signal, the Radio Reception symbol will start to blink.
Generally, complete reception takes around 2 to 10 minutes depending on the
strength of the radio signal.
To disable the reception of RF signal manually, press and hold the DOWN
button for 2 seconds until the Radio Reception symbol disappear.
To enable the reception again, press and hold the UP button f or 2 seconds. The
Radio Reception symbol will blink and the unit will search for RF signal
automatically.
Interference
Reception can be affected by a number of factors. For best reception, place the
device away from metal objects and electrical appliances. Other causes for signal
interference include electrical power transmission towers, steel reinforced
concrete construction, and/or metal siding.
Note: ( Radio Frequency appliances such as the Projection Alarm Clock
perform best when placed near a window . After receiving the initial signal,
updates are accomplished with greater ease. Even though there are areas
that may have more difficulty in receiving a signal, the Projection Alarm
Clock contains very accurate quartz movement and will retain precise time
even if a signal is missed on a rare occasion..)
HOW TO SET THE CLOCK AND CALENDAR
MANUALLY [Fig. 4] & [Fig. 5]
It is unlikely that you will want or need to manually set the Alarm Clock.
Should the need or desire to manually set the clock arise, please follow (Fig.
4) To set the calendar manually follow instructions in Fig. (5). The default
clock setting is 1st of January, 2001; 12:00pm (Pacific zone- time) with houroffset preset as -8 hours. Please note that upon successful reception of the
signal from the U.S. Atomic Clock, the time display will be adjusted to
Pacific zone-time automatically. You can set the offset-hour as follow in order
to display the other US time-zones:
- 7 — Mountain
- 6 — Central
- 5 — Eastern
Otherwise, you can change the offset-hour to display other zone-time outside
the U.S. (Fig 6).
HOW TO SET AND ACTIVATE THE ALARM
This unit is equipped with 2 alarms: Single Alarm [ ] and Weekday Alarm
[
]. For the Single Alarm, it will go off only once at the preset time. For the
Weekday Alarm, it will be enabled from Monday to Friday and disabled automatically during weekend (i.e., Saturday and Sunday).
To set and activate the alarm, see [FIG. 7]
Follow the same procedures to set and activate the Single and/or W eekday Alarm.
To deactivate the alarm, see [FIG. 8]
CRESCENDO ALARM AND SNOOZE FUNCTION
When the alarm goes off at the preset time, the backlight will be turned on for 8
seconds. The ALARM ON icon [
turned on.
The crescendo alarm function allows the alarm sound to start off gently with
step-up intensity. Without interruption, the alarm will go off for 2 minutes.
To stop the alarm, press ALARM or SNOOZE. If SNOOZE button is pressed,
the alarm sound will be turned off temporarily and the snooze function will be
activated. The alarm will go off again after approx. 8 minutes until other ke y is
pressed to turn off the alarm.
] flashing and the alarm sound will be
INDOOR TEMPERATURE DISPLAY
The indoor temperature is shown in degree Fahrenheit (˚F). RM983A is capable to measure temperature ranging from +32°F ( 0˚C ) to +122°F ( +50˚C ).
Display will show either "HHH" or "LLL" when the temperature measured is
out of range.
RESETTING THE UNIT
In case of malfunction or abnormal display, take out and re-install the batteries
again. All settings will be cleared and reset to their default values.
MAINTENANCE
When handled properly, this unit is engineered to give y ou years of satisfactory
service. Here are a few product care instructions:
1. Do not immer se the unit in w ater. If the unit comes in contact with water,
dry it immediately with a soft lint-free cloth.
2. Do not c lean the unit with abrasiv e or corrosi v e materials. Abrasive cleaning agents may scratch the plastic parts and corrode the electronic circuit.
3. Do not subject the unit to excessive: force, shock, dust, temperature, or
humidity. Such treatment may result in malfunction, a shorter electronic
life span, damaged batteries, or distorted parts.
4. Do not tamper with the unit’s internal components. Doing so will terminate the unit’s warranty and may cause damage. The unit contains no user serviceable parts.
5. Only use new batteries as specified in this instruction manual.
6. Read this instruction manual thoroughly before operating the unit.
SPECIFICATIONS
Operating Temperature :23°F to 122°F
Clock Functions
Radio Control : By Radio signal generated from the
Calendar : Weekday in English, German, French,
U.S. Atomic Clock
Italian and Spanish
Month / Day
Clock Time : 12 / 24 hour format
Accuracy : +/-0.5 second/day (when RF is disabled)
Hour Offset : +/- 9 hours
Temperature Measurement
Indoor Measurement : 32°F to 122°F
General Specification
Battery Type :
1 piece of UM3 or "AA" size 1.5V battery
Unit Dimension : 4.33x3.35x1.97 inches (H x W x D)
Unit Weight : 5.57 ounces (without battery)
CUSTOMER ASSIST ANCE
Should you require assistance regarding this product and its operation, please
contact our customer care department at 541-868-8205 or via email at
helpme@oscientific.com.
WARRANTY
This product is warranted to be free of manufacturing defects for a period of 90
days from date of retail purchase. Defective product should be directed to the
place of retail purchase for exchange. Should this not be possible, contact our
customer care department for assistance and a return material authorization. No
returns may be made without a return authorization. Please retain your retail
receipt as you may be asked to provide a copy of it for proof of date purchased.
This warranty does not cover product subjected to abuse, misuse, accidental
damage or tampering.
CAUTION
- The content of this manual is subject to change without further notice.
- Due to printing limitation, the displays shown in this manual may dif-
fer from the actual display.
- The contents of this manual may not be reproduced without the per-
mission of the manufacturer.
086-002278-05
