Oregon Scientific OS6976 User Manual
os6976-en1.p65 5/6/2005, 10:32 AM1
900MHz Cordless Phone with
Kitch Companion
Model: OS6976
User Manual
Manual de Usuario
EN
900MHz Cordless Phone with Kitchen Companion
TABLE OF CONTENTS
Model: OS6976
User Manual
Important Safety Instruction ........................ 1
Introduction ...................................................3
Digital Security System ........................... 3
Before You Begin ........................................... 4
Parts Checklist .......................................... 4
Safety Precautions ................................... 4
Installation Guidelines .................................. 5
Telephone Jack Requirements ................ 5
Installing the Phone ......................................5
Wall Base Unit .......................................... 5
Connecting the Telephone Line ............... 6
Connecting the AC (Electrical) Power .....6
Installing the Handset Battery ................. 6
SPACEMAKER
Connecting the AC (Electrical) Power .....7
Charging the Handset Battery ................. 7
Under Cabinet Mounting .............................7
Tools Required ..........................................7
Mounting Hardware Packed
with Your Unit .......................................8
Before Mounting ...................................... 8
Mounting Procedure ................................ 9
Handset and Wall Base Unit Layout .......... 12
Spacemaker® Layout ................................ 12
Spacemaker® Setup ...................................13
Day/Time Setup ...................................... 13
Adjust the Day of the Week ................... 13
Adjust the Hour ...................................... 13
Adjust the Minute ...................................13
Check the Current Day/Time ................. 13
Ringer Setup .......................................... 14
System Setup ......................................... 14
Language ............................................... 14
Local Area Code ..................................... 14
®
Unit ...................................... 7
Tone/Pulse Dialing ..................................15
Display Contrast ..................................... 15
Answering System ON/OFF ................... 15
Setting the Rings to Answer ................. 16
Setting the Security Code for
Remote Access ................................... 16
Spacemaker® .........................................16
Default Settings ...................................... 17
Handset Setup ............................................. 17
Ringer Setup .......................................... 17
System Setup ......................................... 18
Language ............................................... 18
Local Area Code ..................................... 18
Tone /Pulse Dialing ................................ 19
Default Settings ...................................... 19
Handset Operation ................................ 19
Registration ............................................ 19
Receiving a Call ...................................... 20
Making a Call ......................................... 20
Line in Use ............................................. 20
3-Way Conferencing ............................... 20
Call Transfer ............................................ 20
Last Number Redial ................................ 20
Flash ........................................................ 21
In Use Indicator Light .............................21
Auto Standby ......................................... 21
Channel Button ...................................... 21
Temporary Tone ...................................... 21
Exit ...........................................................21
Finding the Handset ............................... 21
Ringer ...................................................... 22
Volume ................................................... 22
Call Timer ............................................... 22
Speakerphone Operation .......................... 22
Speakerphone Location ......................... 22
os6976-en1.p65 5/6/2005, 10:32 AM2
Speakerphone Guidelines .................... 22
Registration ............................................ 22
Receiving a Call ...................................... 23
Making a Call ......................................... 23
Line in Use ............................................. 23
3-Way Conferencing ............................... 23
Call Transfer ............................................ 23
Flash ........................................................ 23
Speaker Indicator Light ..........................24
Charge Indicator Light .......................... 24
Exit ...........................................................24
Display Backlight ................................... 24
Channel Button ...................................... 24
Speakerphone Volume .......................... 24
MIC Mute ................................................ 24
Call Timer ............................................... 25
Answering System Operation .................... 25
Voice Instructions ...................................25
Recording the Outgoing
Announcement ...................................25
Reviewing Announcement .................... 25
Messages Indicator ................................ 25
Screening Calls from the Charge .......... 25
Message Playback .................................. 26
Answering System Memory Full .......... 26
Erasing Messages .................................. 26
Leaving a Memo .....................................26
Remote Access ...................................... 26
Caller ID (CID) ............................................. 27
Call Waiting Caller ID ............................. 27
Receiving and Storing Calls ................. 28
Reviewing CID Records .......................... 28
Transferring CID Records to Memory .. 28
Deleting the CID Record
Showing in the Display ......................29
Deleting All CID Records ....................... 29
Dialing a CID Number ............................ 29
Changing the CID Number Format ....... 29
Radio Operation ......................................... 30
AM Antenna ............................................30
FM Antenna ............................................ 30
Turning on the Radio ............................. 30
Band ........................................................ 30
Radio Volume......................................... 30
Changing Stations ..................................30
Storing Preset Stations .......................... 30
Using Preset Stations ............................. 30
Clock ........................................................ 30
Memory ........................................................ 31
Storing a Name and Number in
Memory ...............................................31
Changing a Stored Number ................. 31
Storing a Redial Number ....................... 31
Dialing a Stored Number .......................32
Inserting a Pause in the Dialing
Sequence ............................................ 32
Reviewing and Deleting Stored
Numbers ................................................ 32
Chain Dialing from Memory ................. 33
Programmable Timer ..................................33
Setting the Timer ................................... 33
Starting the Timer................................... 34
Stopping the Timer................................ 34
Pausing the Timer................................... 34
Using the Timer with Other Modes....... 34
TALK Mode............................................. 34
Changing the Battery..................................35
Display Messages........................................35
Handset Sound Signals ............................. 36
Headset and Belt Clip Operation .............. 36
Connecting an Optional
Headset to the Handset ...................... 36
Connecting the Belt Clip ....................... 37
Troubleshooting Tips ................................... 37
Caller ID ...................................................37
Telephone ............................................... 37
About Oregon Scientific .............................39
FCC Statement ............................................ 39
Consumer Information ............................... 40
Declaration of Conformity .......................... 42
EN
os6976-en1.p65 5/6/2005, 10:32 AM3
IMPORTANT SAFETY
EN
INSTRUCTIONS
Some of the following information may
not apply to your particular product;
however, when using Conference Phone
equipment, basic safety precautions
should always be followed to reduce the
risk of fire, electric shock and injury to
persons, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions
marked on the product.
3. Unplug this product from the wall
outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners. Use
a damp cloth for cleaning.
4. This product should not be used while
you are in a bathtub, shower or pool.
Immersion of the product in water
could cause an electrical shock.
5. Slots and openings in the cabinet back
or bottom are provided for ventilation,
to protect it from overheating. These
openings must not be blocked or
covered. The openings should never be
blocked by placing the product on the
bed, sofa, rug, or other similar surface.
This product should not be placed in a
built-in installation unless proper
ventilation is provided.
6. This product should be operated only
from the type of power source indicated on the marking label. If you are
not sure of the type of power supply
to your home, consult your dealer or
local power company.
7. Do not allow anything to rest on the
power cord. Do not locate this product
where the cord will be abused by
persons walking on it.
8. Do not overload wall outlets and
extension cords as this can result in the
risk of fire or electric shock.
9. Never push objects of any kind into this
product through cabinet slots as they
may touch dangerous voltage points
or short out parts that could result in a
risk of fire or electric shock. Never spill
liquid of any kind on the product.
10. To reduce the risk of electric shock, do
not disassemble this product, but take
it to a qualified serviceman when
service or repair work is required.
Opening or removing covers may expose you to dangerous voltages or
other risks. Incorrect reassembly can
cause electric shock when the tele
phone equipment is subsequently
used.
11. Do not expose the product to extreme
temperatures such as areas near a hot
radiator or stove or in a hot car.
12.Do not place lighted candles, cigarettes,
cigars, etc., on the telephone.
13.Never touch uninsulated telephone
wires or terminals unless the tele
phone line has been disconnected at
the net work interface.
14.Never install or modify telephone
wiring during a lightning storm.
15.Never install telephone jacks in wet
locations unless the jack is specifically
designed for wet locations.
16. Use caution when installing or modi-
fying telephone lines to prevent
electrical shock and/or fire.
17. Unplug this product from the wall
outlet and refer servicing to qualified
service personnel under the following
conditions:
1
os6976-en1.p65 5/6/2005, 10:32 AM4
A. When the power supply cord or
plug is damaged or frayed.
B. If the product has been exposed to
rain or water.
C. If the product does not operate
normally by following the
operating instructions.
D. If the product’s cabinet has been
damaged.
E. If the product exhibits a distinct
change in performance.
18. Avoid using a telephone (other than a
cordless type) during an electrical
storm. There may be a remote risk of
electric shock from lightning.
19. Do not use the telephone to report a
gas leak in the vicinity of the leak.
20.Do not place this product on an
unstable cart, stand or table.
The product may fall, causing serious
damage to the product.
21. Plug the adaptor to a socket-outlet
which is near the equipment and is
easily accessible.
22. Risk of explosion if battery is
replaced by an incorrect type, use only
SANIK, 3SN-AA60-S-J1. Dispose
of used batteries according to the
instructions.
23. For servicing or replacement, you can
purchase a suitable headset through
service center or retailer shop (see in
www.oregonsicientic. com)
CAUTION
To reduce the risk of fire, use only
No. 26 AWG or larger
telecommunication line cord.
CAUTION
You must use a Class 2
power source that supplies
120V DC and delivers at
least 650mA. Its plug must
fit the phone’s DC IN 12V
jack. The supplied adapter meets
these specifications. Using an adapter
that does not meet these
specifications could damage the
phone or the adapter.
Always connect the AC adapter to the
phone before you connect it to AC
power. When you finish, disconnect
the adapter from AC power before you
disconnect from the phone.
SAVE THESE INSTRUCTION
EN
os6976-en1.p65 5/6/2005, 10:32 AM5
2
INTRODUCTION
EN
CAUTION: When using telephone equipment, there are basic safety instructions that
should always be followed. Refer to the IMPORTANT SAFETY INSTRUCTIONS provided
with this product and save them for future reference.
telephone company, to subscribers of Caller ID or similar caller identification services.
Your Caller ID phone enables you to:
To get the most from your new phone, we suggest that you take a few minutes right now to read
through this user’s guide.
IMPORTANT: In order to use all of the Caller ID features of this phone, you must subscribe to either
the standard Name/Number Caller ID Service or Call Waiting Caller ID Service. To know who is
calling while you are on the phone, you must subscribe to Call Waiting Caller ID Service.
IMPORTANT: Because cordless phones operate on electricity, you should have at least one phone in
your home that isn’t cordless, in case the power in your home goes out.
INSTALLATION NOTE: Some cordless telephones operate at frequencies that may cause
interference to nearby TVs, microwave ovens, and VCRs. To minimize or prevent such interference,
the base of the cordless telephone should not be placed near or on top of a TV, microwave ovens,
or VCR. If such interference continues, move the cordless telephone farther away from these
appliances.
Your Caller ID phone stores and displays specific information, provided by your local
• Identify callers before you answer the phone.
• View the time and date of each incoming call.
• Record up to 40 Caller ID messages sequentially.
• Know who called while you were away or on the phone.
DIGITAL SECURITY SYSTEM
Your cordless phone uses a digital security system to provide protection against false ringing,
unauthorized access, and charges to your phone line.
3
os6976-en1.p65 5/6/2005, 10:32 AM6
BEFORE YOU BEGIN
PARTS CHECKLIST
Make sure your package includes the items shown here.
In addition, your package also includes some mounting hardware, please refer to the Under
Cabinet Mounting section for details.
FORMATREDIAL CID/VOL
+
-
F
timer mem
M
TALK
C
K
A
C
L
A
L
B
DEF
ABC
3
2
p
a
g
e
Wall base unit
RINGER HI LO OFF
MIN HOUR DAY/TIMECHECK
press to check/hold to change
Spacemaker
answerer controls
l
e
nn
ha
c
mic
r
e
tim
message
delete
play
a
a
erase
memo
n
e
stop
cid
n
c
o
n
u
skip
+
L
K
A
T
speaker
C
K
A
L
C
L
A
B
c
h
a
r
g
+
CID
exit
tune/seek
VOL
-
-
c
i
m
review
flash
radio
e
radio
m
am•fm
e
t
format
u
presets
prog
on•off
radio controls
®
Unit Handset
GHI
PQRS
exit
1
4
7
delete program
CHAN FLASH
MNO
JKL
6
5
WXYZ
TUV
9
8
PAUSE0OPER*TONE
9
ringer
HI
LO
OFF
mic
EN
Handset battery
pack
Telephone
line cord
Adaptor
Belt Clip
SAFTEY PRECUATIONS
CAUTION: To reduce the risk of fire, do not place any heating or cooking product beneath
this unit.
• Never install telephone wiring during a lightning storm.
• Never install telephone jacks in wet locations unless the jack is specifically designed for wet
locations.
• Never touch non-insulated telephone wires or terminals, unless the telephone line has been
disconnected at the network interface.
• Use caution when installing or modifying telephone lines.
• Temporarily disconnect any equipment connected to the phone such as faxes, other phones, or
modems.
os6976-en1.p65 5/6/2005, 10:32 AM7
4
INSTALLATION GUIDELINES
EN
• Install the wall base unit into an electrical outlet that is near a telephone (modular) jack.
• The Spacemaker® is a cordless speakerphone with radio and answering machine. Before
mounting it under a cabinet, check if the cordless speakerphone and the radio work well at
the selected location first, also check the orientation of the power converter cord for the best
FM radio reception.
• Avoid sources of noise, such as a window by a busy street, and electrical noise, such as motors,
microwave ovens and fluorescent lighting.
• Avoid heat sources, such as heating air ducts, heating appliances, radiators, and direct sunlight.
• Avoid areas of excessive moisture or extremely low temperature.
• Avoid dusty locations.
• Avoid other cordless telephones or personal computers.
TELEPHONE JACK REQUIREMENTS
To use this phone, you need an RJ11C type modular telephone jack, which
might look like the one pictured here, installed in your home. If you don ’t
have a modular jack, call your local phone company to find out how to
get one installed.
Modular
telephone
line jack
INSTALLING THE PHONE
Choose the best location to install your wall base unit and Spacemaker® unit. Your wall base unit
should be plugged into an electrical outlet with a phone jack nearby, while your Spacemaker®
should be mounted under the counter, or you may place it on a level surface such as a desk or
table top.
WALL BASE UNIT
Wall plate
5
os6976-en1.p65 5/6/2005, 10:32 AM8
CONNECTING THE TELEPHONE LINE
1. Connect one end of the telephone line cord to the LINE jack on the bottom of the wall base unit.
2. Connect the other end of the telephone line cord to a telephone jack on the wall.
3. Raise the antenna on the base.
Connect to any other phone
page
CONNECTING THE AC (ELECTRICAL) POWER
1. Plug the wall base unit into an electrical outlet.
2. Make sure that its pins are inserted fully into the outlet and it is firmly installed. If not, choose
another electrical outlet to plug into.
INSTALLING THE HANDSET BATTERY
NOTE: The handset battery and battery compartment cover are packaged together.
PRIOR TO USE
CONNECT BATTERY AND
INSTALL COVER
PRESS DOWN
FIRMLY
CHARGE FOR 12 HOURS
BATTERY
BLACK WIRE
RED
WIRE
EN
1. Connect the battery cord into the jack inside the handset battery compartment and then insert
the battery pack.
NOTE: It is important to maintain the polarity (black and red wires) to the jack inside the
compartment as shown in the illustration. For this purpose and your convience the
battery plug and jack are keyed so they will only mate in one direction.
2. Close the battery compartment by pushing the cover up until it snaps into place.
os6976-en1.p65 5/6/2005, 10:32 AM9
6
CHARGE UNIT
EN
TIP: Before mounting the Spacemaker® under the counter, it is highly recommended to
check if the speakerphone and radio work well at the mounting location first.
CONNECTING THE AC (ELECTRICAL) POWER
Plug the AC power converter into an electrical outlet and the DC connector into the back of the
Spacemaker®.
CAUTION: Use only the Oregon Scientific power converter that came with this
unit. Using other power converters may damage the unit.
CHARGING THE HANDSET BATTERY
RINGER HI LO OFF
MIN HOUR DAY/TIMECHECK
press to check/hold to change
+
L
K
A
T
CID
speaker
exit
VOL
C
-
K
A
L
C
L
A
B
c
i
m
c
h
a
r
g
e
m
e
t
u
+
tune/seek
-
review
flash
radio
radio
am•fm
format
presets
prog
on•off
radio controls
answerer controls
l
e
n
n
a
h
c
mic
timer
message
delete
play
a
a
erase
memo
n
e
stop
cid
n
c
o
n
skip
u
1. Place the handset into the cradle.
2. The charge indicator on the Spacemaker® turns on to indicate the handset battery is charging.
3. Allow the handset to charge for 12 hours prior to first use. If you don’t properly charge the
handset, battery performance is compromised.
UNDER CABINET MOUNTING
TOOLS REQUIRED
• Drill and 1/4” drill bit • Ruler or tape measure
• Nail or awl • Scissors
• Screwdriver-phillips • Countersink (optional)
• Masking tape • Safety glasses
7
os6976-en1.p65 5/6/2005, 10:32 AM10
MOUNTING HARDWARE PACKED WITH YOUR UNIT
4 –1/4” Spacers 4 – Washers
4 –1/2” Spacers 4 – Cord hooks
4 – 1” Spacers
4 – 2” Phillips head screws
CUTOUTONSOLID BLACK LINE.
CORTESOBRELALÕNEAS”LIDA NEGRA.
SEE INSTRUCTION BOOK:
Be sure to select the correct height provided
spacers to position this unit at the proper distance
below the front edge of your cabinet. This will
provide access to the handset. Handset will be
slightly below the bottom of your cabinet when
LÌneasdeguÌaparaserdobladas
enlapartesobresalientedelos gabinetes.
FoldGuidelinesfor
Cabinetwithoverhang.
Model26976A
properly installed.
Sinohay una parte sobresaliente
lapartedelantera de la Plantilla
debeserigual con el borde
delanterodelCabinete.
Ifnooverhang
CUTOUTONSOLID BLACK LINE.
Frontedgeof Templateshould
beevenwith front edge of Cabinet.
CORTESOBRELALÕNEAS”LIDA NEGRA.
FRONT
CUTOUTONSOLID BLACK LINE.
FRENTE
CORTESOBRELALÕNEAS”LIDA NEGRA.
CUTOUTONSOLID BLACK LINE.
CORTESOBRELALÕNEAS”LIDA NEGRA.
PrintedinChina
1 – Mounting template
BEFORE MOUNTING
CAUTION: To reduce the risk of fire, do not place any heating or cooking product
beneath this unit.
• Select a location to mount the Spacemaker®
• Make sure that there is an electrical outlet nearby
• Follow the section of Installing the Phone and Telephone Operation to check if the phone works
well at the selected location
• Follow the section of Radio Operation to check if the radio works well at the selected location
• Disconnect the AC power supply to the Spacemaker®
when mounting.
Empty the contents of the cabinet under which the unit is to be mounted and thoroughly clean the
underside to remove any greasy residue. We recommend the unit be mounted at the front edge of
the cabinet.
EN
IMPORTANT: For secure mounting, the screws must go into the unit to a depth of at least 3/8". If the
overall length from the bottom of the cabinet shelf to the bottom of the overhang is more than 5/8",
you will need to use a wood shim. The shim can be located between the cabinet shelf bottom and
the spacers. Make sure the wood is at least as thick as the excess over 5/8". If a shim is necessary,
longer screws (available at most local hardware stores) are required.
os6976-en1.p65 5/6/2005, 10:32 AM11
8
Cut out the template on the line indicated. The template size and screw hole positions are identical
to the top of the unit.
EN
3/8” Minimum
MOUNTING PROCEDURE
1. If your cabinet does not have an overhang:
a) Position the template in the desired location on the underside of the cabinet, flush with the
front edge of the cabinet.
b) Tape the template in place and go to step 2.
Front edge of cabinet
If your cabinet has an overhang:
a) Measure the thickness of the overhang.
b) Fold the front of the template downward along the printed guideline closest to the thickness
of your cabinet.
c) Tape folded-down portion to backside of the overhang, and tape the template to the cabinet
underside.
Measure the
thickness of
cabinet overhang
9
os6976-en1.p65 5/6/2005, 10:32 AM12
Mounting template
Fold template on
dotted line
NOTE: If your cabinet has glue blocks or other obstructions, cut out corresponding areas
on the template to clear them. Do not cut out or cut through the screw holes in the
template.
CAUTION: We recommend safety glasses be worn while drilling screw holes to
prevent the possibility of eye injury.
2. Drill four 1/4" diameter holes through the underside of the cabinet.
TIP: On wooden cabinets you may want to mark and start the drill holes with a nail or an
awl. Be sure to hold the drill very firmly against the cabinet.
Use masking tape above the hole locations on the inside of the cabinet shelf to reduce
splintering. If installing the unit under a wood cabinet, you may want to countersink the drilled
hole from the INSIDE of the cabinet. This will eliminate the use of washers and allow the screw
head to be flush with the floor of your cabinet. If you cannot countersink the holes, use the
supplied washers.
3. Remove the template and drill shavings from inside and underneath the cabinet.
4. If your cabinet does NOT have an overhang, go to Step 5.
If your cabinet HAS an overhang, select the spacer or combination of spacers, that is equal to
the length of the overhang, plus 5/8". The added 5/8" is to insure adequate space to remove the
handset.
EN
Length of
overhang
plus 5/8”
5/8
Clearance required for
handset access
Unit as correctly
positioned
os6976-en1.p65 5/6/2005, 10:32 AM13
Cabinet
overhang
Washer
Cabinet bottom
Spacers
3/8” Minimum
2-1/16”
Maximum
Select screws that meet
minimum but do not exceed
maximum length
10
5. Insert screws from the INSIDE of the cabinet. If you did not countersink the drilled holes,
EN
position the washers, flat side down, and place the screws in the holes.
If your cabinet does not have an overhang, go to Step 7.
6. Hold the screw heads down while you push the selected spacers onto the screws under the
cabinet. Be sure to push spacers until they are firmly against the cabinet bottom and/or fully
nested (if more than one is used).
7. Align the unit under the screws. Hold the screw holes on the top of the unit against the
mounting screws and partially tighten the screws.
TIP: Do not fully tighten until all 4 screws are installed.
8. Extend the cord towards an electrical outlet and secure by using the cord hooks to hold the
cord out of the way. For a more attractive appearance, place the cord hooks at the back edge
of the cabinet (on or next to wall) directly over the electrical outlet to be used.
To attach cord hooks peel off the adhesive on the back of the hooks and attach to a clean, dry
surface on the underside of the cabinet or back wall.
11
os6976-en1.p65 5/6/2005, 10:32 AM14
answerer controls
channel
mic
r
e
m
message
i
t
delete
play
a
a
erase
memo
stop
n
e
cid
n
c
o
skip
n
u
+
+
L
K
A
T
MIN HOUR DAY/TIMECHECK
RINGER HI LO OFF
CID
speaker
exit
tune/seek
VOL
press to check/hold to change
-
C
-
K
A
L
C
L
A
B
c
i
m
review
c
flash
h
radio
a
r
g
e
radio
m
am•fm
e
format
u
t
presets
prog
on•off
radio controls
Cord
hooks
Loading...
