Original Instruction Manual
Lawn Mower Model LM300
Manuel d’Instructions Original
Tondeuse à Gazon Modèle LM300
Manual de Instrucciones Original
Cortacésped Modelo LM300
Manual de Instruções Original
Cortacésped Modelo LM300
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
WARNING: Read and understand all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
This instruction manual contains translations of a manual drafted in English and are provided to assist those
who do not speak English as their first language. Being a technical writing, some terms may not have a like or
equivalent meaning as translated. Therefore, you should not rely on this translation, and should cross-reference
the English version, where relying on the translated instructions could result in harm to your person or property.
Français. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
AVERTISSEMENT : Prenez connaissance de tous les avertissements et consignes de sécurité.
L’inobservation de ces avertissements et consignes comporte des risques d’électrocution, d’incendie et/ou
de lésions graves. Rangez ces consignes et avertissements en lieu sûr afin de pouvoir les consulter
ultérieurement.
Ce manuel d’utilisation contient plusieurs traductions d’un document rédigé en anglais. Ces traductions visent
à aider les utilisateurs dont l’anglais n’est pas la langue maternelle. Comme il s’agit d’un document technique,
certains termes sont susceptibles de prendre une signification différente après traduction. Par conséquent,
vous ne devez pas vous fier aveuglément à cette traduction. Reportez-vous à la version anglaise si vous
percevez que le respect des consignes traduites pourrait occasionner des dommages matériels ou des lésions
corporelles.
Español. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
ADVERTENCIA: Lea y entienda todas las advertencias de seguridad e instrucciones.
El incumplimiento de las advertencias e instrucciones puede dar lugar a descargas eléctricas, incendios o
lesiones graves. Guarde todas las advertencias e instrucciones para referencia futura.
Este manual de instrucciones contiene traducciones de un manual redactado en inglés y se ofrece para ayudar
a aquellos que no hablan inglés como primer idioma. Al tratarse de un texto técnico, algunos términos pueden
no tener un significado similar o equivalente en la traducción. Por lo tanto, no debe confiar en esta traducción, y
debería ir consultando la versión inglesa en aquellos puntos donde la confianza en las instrucciones traducidas
pueda causar daños a su persona o a la propiedad.
Português . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
ADVERTÊNCIA: Leia e entenda todas as advertências e instruções de segurança. A falha em
seguir todas as advertências e instruções pode resultar em choque elétrico, incêndio e/ou lesão pessoal séria.
Preserve todas as advertências e instruções para consulta futura.
Este manual de instruções contém traduções de um manual escrito em inglês, e tem a finalidade de ajudar
quem não fala inglês como idioma nativo. Como se trata de escrita técnica, alguns termos podem não ter um
significado semelhante ou equivalente quando traduzidos. Portanto, não confie unicamente nesta tradução.
Consulte a versão em inglês quando confiar na tradução em português puder resultar em danos pessoais ou à
propriedade.
4
Lawn Mower Model LM300
Table of Contents
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
General Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Slope Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Children . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Battery Packs and Charging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Symbols and Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Product Identification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Battery Pack and Charger. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Warranty and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
© Blount, Inc. Pricing and specifications subject to change without notice. All rights reserved. Oregon® is a registered trademark of Blount,
Inc. in the United States and/or in other countries.
5
Lawn Mower Model LM300
Important Safety Instructions
Important Safety Instructions
SAFE PRACTICES FOR PEDESTRIANCONTROLLED MOWERS
WARNING: When using cordless lawn
mowers, basic safety precautions should always
be followed to reduce the risk of fire, electric
shock, and personal injury, including the following:
This cutting machine is capable of amputating
hands and feet and throwing objects. Failure to
observe the following safety instructions could
result in serious injury or death.
General Operation
Read, understand, and follow all instructions on
the machine and in the manual(s) before starting.
Prevent unintended starting. Ensure the switch is
in the off position before inserting battery pack.
Inserting the battery pack into machines that have
the switch on invites accidents.
Keep hands and feet away from cutting area. Keep
clear of the discharge opening at all times.
Only allow responsible adults who are familiar
with the instructions to operate this machine. This
tool is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge.
Maintain Lawn Mower With Care – Keep cutting
edges sharp and clean for best and safest
performance.
Follow instructions for lubricating and changing
accessories.
Keep handles dry, clean, and free from oil and
grease.
Objects struck by the lawn mower blade can
cause severe injuries to persons. Clear the area of
objects such as rocks, wire, toys, etc., which could
be thrown by the blade. Stay behind the handle
when the motor is running.
If lawn mower strikes a foreign object, follow
these steps:
• Stop lawn mower. Release the switch.
• Remove battery pack.
• Inspect for damage.
• Repair any damage before restarting and
operating the lawn mower.
Be sure the area is clear of children and other
bystanders before operating. Stop machine if
anyone enters the area. The operator or user is
responsible for accidents or hazards occurring to
other people or their property.
Do not operate machine barefooted or while
wearing sandals. Always wear substantial
footwear.
Dress Properly – Do not wear loose clothing or
jewelry. They can be caught in moving parts. Use
of rubber gloves and footwear is recommended
when working outdoors. Wear long pants.
Always wear eye protection when operating
machine.
Always use face or dust mask if operation is dusty.
Never mow by pulling the mower towards you.
Disengage the switch lever to turn off the machine
and use extreme caution when stepping back
or pulling the machine towards you.. Always
look down and behind before and while moving
backward.
Always stand clear of the discharge zone when
operating the machine. Never direct discharged
material toward anyone. Avoid discharging
material against a wall or obstruction. Material
may ricochet back toward the operator.
Turn off the machine by disengaging the switch
lever when crossing gravel and other surfaces
other than grass.
Never pick up or carry the machine while the
motor is running.
6
Lawn Mower Model LM300
Important Safety Instructions
Always inspect all guards, shields and safety
devices prior to each use. Do not operate machine
without the entire grass catcher, discharge guard,
rear guard, or other safety protective devices in
place and working.
Do not tilt the machine when starting or switching
on the motor, except if the machine has to be
tilted for starting in long grass. In this case, do not
tilt it more than absolutely necessary and tilt only
the part which is away from the operator.
Always ensure that both hands are in the
operating position before returning the machine to
the ground.
Switch on the motor according to the instructions
with feet well away from rotating parts.
Never leave a running machine unattended.
Stop the motor, wait until the blade comes to a
complete stop and remove the battery before
cleaning the machine, removing grass catcher, or
unclogging the discharge guard.
Operate machine only in daylight or good artificial
light.
Do not operate machine while under the influence
of alcohol or drugs.
Do not use battery-operated lawn mower in rain.
Avoid Dangerous Environment –Don’t use lawn
mowers in damp or wet locations.
Never operate mower in wet grass. Wet grass may
cause the operator to slip. Always be sure of your
footing; walk, never run.
If the machine should start to vibrate abnormally,
stop the motor and check for the cause
immediately. Vibration is generally a warning of
trouble.
Use Right Appliance – Do not use lawn mower for
any job except that for which it is intended.
Don’t Force Lawn Mower – It will do the job better
and safer at the rate for which it was designed.
Don’t Overreach – Keep proper footing and
balance at all times.
Stay Alert – Watch what you are doing. Use
common sense. Do not operate lawn mower when
you are tired.
See manufacturer’s instructions for proper
operation and installation of accessories. Only
the accessories and attachments originally
provided with the lawn mower are approved by
the manufacturer.
Always store the lawn mower in a cool, dry
place and out of direct sunlight. Long exposure
to sunlight and UV rays can degrade plastics
overtime, potentially causing guards to fail.
Slope Operation
Slopes are a major factor related to slip and
fall accidents, which can result in severe injury.
Operation on all slopes requires extra caution. If
you feel uneasy on a slope, do not mow it.
Mow across the face of slopes; never up and
down. Exercise extreme caution when changing
direction on slopes.
Watch for holes, ruts, bumps, rocks, or other
hidden objects. Uneven terrain could cause a slip
and fall accident. Tall grass can hide obstacles.
Avoid mowing on wet grass or excessively steep
slopes (> °). Poor footing could cause a slip and
fall accident.
Exercise extreme caution when changing direction,
especially on slopes.
Do not mow near drop offs, ditches, or
embankments. You could lose your footing or
balance.
Children
Tragic accidents can occur if the operator is not
alert to the presence of children. Children are
often attracted to the machine and the mowing
activity. Never assume that children will remain
where you last saw them.
Remove the safety key whenever you leave or
store the machine. Store in a secure and lockedup place – out of reach of children.
Keep children out of the mowing area and under
the watchful care of a responsible adult other
than the operator.
Be alert and turn mower off if a child enters the
area.
7
Lawn Mower Model LM300
Important Safety Instructions
Never allow children to operate the machine.
Use extra care when approaching blind corners,
shrubs, trees, or other objects that may block your
view of a child.
Service
Always remove the battery pack before adjusting,
cleaning, repairing, or storing to prevent
unintended starting. Such preventative safety
measures reduce the risk of starting the lawn
mower accidentally.
Store Idle Lawn Mower Indoors – When not in use,
lawn mower should be stored in an indoor dry and
locked-up place – out of reach of children
Keep guards in place and in working order.
Keep blades sharp.
Use identical replacement blades only. Use of any
other accessory or attachment might increase the
risk of injury.
Keep all nuts and bolts tight to be sure the
equipment is in safe working condition.
Never remove or tamper with safety devices.
Check their proper operation regularly. Never do
anything to interfere with the intended function
of a safety device or to reduce the protection
provided by a safety device.
Keep machine free of grass, leaves, or other debris
build up.
If you strike a foreign object, stop and inspect the
machine. Repair, if necessary, before starting.
Never make any adjustments or repairs with the
motor running.
Check grass catcher components and the
discharge guard frequently and replace with
manufacturer’s recommended parts, when
necessary.
Ensure that all replacement or service parts are
approved by the manufacturer.
Mower blades are sharp. Wrap the blade or wear
gloves, and use extra caution when servicing
them.
Be careful during adjustment of the machine
to prevent entrapment of the fingers between
moving blade and fixed parts of the machine
When servicing the blades be aware that, even
though the power source is switched off, the blade
can still be moved.
Maintain or replace safety and instruction labels,
as necessary.
Battery Packs and Charging
Do not charge battery pack in rain, or in wet
locations. Keep the battery charger away from rain
or moisture. Penetration of water in the battery
charger increases the risk of an electric shock.
Do not use battery-operated lawn mower in rain.
Remove or disconnect battery before servicing,
cleaning, or removing material from the lawn
mower.
Use lawn mower only with Oregon Series B
specifically designated battery packs BE,
BE, or BE. Use of any other battery packs
may create a risk of injury and fire.
Recharge only with the charger specified by the
manufacturer, Oregon C, C, or C. A
charger that is suitable for one type of battery
pack may create a risk of fire when used with
another battery pack.
Do not charge other batteries on the charger.
The battery charger is suitable only for charging
manufacturer specific and approved lithium
ion batteries within the listed voltage range.
Otherwise there is danger of fire and explosion.
Before each use, check the battery charger, cable
and plug. If damage is detected, do not use the
battery charger. Never open the battery charger
yourself. Have repairs performed only by a
qualified technician and only using original spare
parts. Damaged battery chargers, cables and
plugs increase the risk of an electric shock.
Keep the battery charger clean. Contamination can
lead to danger of an electric shock.
Occasionally clean the venting slots of the battery
using a soft, clean and dry brush.
8
Lawn Mower Model LM300
Important Safety Instructions
Do not dispose of the battery in a fire. The cell
may explode. Check with local codes for possible
special disposal instructions.
Do not open or mutilate the battery. Released
electrolyte is corrosive and may cause damage to
the eyes or skin. It may be toxic if swallowed.
Exercise care in handling batteries in order not
to short the battery with conducting materials
such as rings, bracelets, and keys. The battery or
conductor may overheat and cause burns
When battery pack is not in use, keep it away
from other metal objects like paper clips, coins,
keys, nails, screws, or other small metal objects
that can make a connection from one terminal to
another. Shorting the battery terminals together
may cause burns or a fire.
Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid
contacts eyes, additionally seek medical help.
Liquid ejected from the battery may cause
irritations or burns.
In case of damage and improper use of the
battery, vapors may be emitted. Ventilate the area
and seek medical help in case of complaints. The
vapors can irritate the respiratory system.
Do not use a battery pack or lawn mower that
is damaged or modified. Damaged or modified
batteries may exhibit unpredictable behavior
resulting in fire, explosion or risk of injury.
Do not expose a battery pack or lawn mower to
fire or excessive temperature such as continuous
intense sunlight or stored in a hot vehicle.
Exposure to fire or temperature above °C may
cause explosion. Store the battery only within a
temperature range between °C and °C.
Follow all charging instructions and do not charge
the battery pack or lawn mower outside of the
temperature range specified in the instructions.
Charging improperly or at temperatures outside
the specified range may damage the battery and
increase the risk of fire.
Do not operate the battery charger on easily
inflammable surfaces (e. g., paper, textiles, etc.) or
surroundings. The heating of the battery charger
during the charging process can pose a fire hazard.
Have servicing performed by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the product is
maintained.
Do not attempt to repair the lawn mower
or battery pack except as indicated in the
instructions for use and care.
Storage
Always store the lawn mower in a cool, dry
place and out of direct sunlight. Long exposure
to sunlight and UV rays can degrade plastics
overtime, potentially causing guards to fail.
Transport
The contained lithium-ion batteries are subject to
the Dangerous Goods Legislation requirements.
The user can transport the batteries by road
without further requirements.
When being transported by third parties (e.g.:
air transport or forwarding agency), special
requirements on packaging and labeling must
be observed. For preparation of the item being
shipped, consulting an expert for hazardous
material is required.
Ship batteries only when the housing is
undamaged.
Tape or mask off open contacts and pack up the
battery in such a manner that it cannot move
around in the packaging.
Please also observe possibly more detailed
national regulations.
Disposal
Do not dispose of garden products, battery
chargers and batteries/rechargeable batteries into
household waste.
SAVE THESE INSTRUCTIONS
9
Lawn Mower Model LM300
Important Safety Instructions
Symbols and Labels
These symbols and labels appear on the lawn mower, battery, and charger.
SYMBOL NAME EXPLANATION
General Hazard
Safety Alert
The text that follows explains a danger, warning, or caution.
Read Instruction
Manual
The original instruction manual contains important safety and
operating information. Read and follow the instructions carefully.
Maintain Safety
Devices
Do not open or remove safety shields while the tool is running.
Keep Bystanders
Away
Do not mow when children or others are too close.
Look Behind While
Backing
Look down and behind first to avoid tripping when pulling back.
Steep Slope Hazard
Use extra caution on slopes. Do not mow slopes greater than 15
degrees.
Remove Safety Key
Switch off and remove safety key before adjusting, cleaning and
before adjusting. Cleaning leaving the product unattended for any
period.
Wear Eye
Protection
Wear eye protection when operating the machine.
Wear Hearing
Protection
Wear hearing protection when operating the machine.
Wear Hand
Protection
Wear gloves when operating the machine or touching the stopped
blades.
Wear Long Pants Wear long pants when operating the lawn mower.
Wear Foot
Protection
Wear appropriate closed-toe work boot when operating the lawn
mower.
Do Not Incinerate Do not dispose in flames.
Do Not Dispose
Do not throw in the household waste. Take to an authorized
recycler.
Do Not Expose To
Rain
Do not operate the charger in wet conditions.
Operating
Temperature
Only use the battery pack at a temperature between 32°F to 104°F
(0°C and 40°C).
Remove Battery Remove the battery before performing any maintenance.
10
Lawn Mower Model LM300
Product Identification
Product Identification
Upper handle assembly
Bolt
Cable clips
Washer
Lower handle
Grassbox cover
Safety Key
Left grassbox
Rotate block
Right grassbox
Grassbox handle
Discharge cover
Knob
1
2
3
13
4
5
8
6
7
7
7
7
9
10
11
12
11
Lawn Mower Model LM300
Assembly
Assembly
Intended Use
The garden product is intended for domestic lawn
mowing.
Assembly (Fig. A - B - C - D)
WARNING: Make sure the battery is
removed from the machine.
Fix the rotation-blocks () into the lower handle
() (Fig. A), then you can fix the lower handle
() and the machine together with the knobs ().
Fix the upper handle to the frame of the lower
handle (Fig. B) and then secure using the knobs
(), bolts (), and washer (). Hand tighten the
Knobs ().
Assemble the grass box by connecting the two
sides of the box (, ) ensuring that all of the
tabs located along the connecting edge of ()
are properly seated into the edge of (). You will
hear and audible click sound as each tab is properly
seated. Ensure the entire connecting seam between
() and () is properly connected (Fig. C).
Place the top of the grass box () on to the
formed piece of () and (). Ensure that all tabs
on the edge of () and () properly and securely
seat into the frame of (). You will hear and
audible click sound as each tab is properly seated
(Fig. C).
Place the grass box handle () into the proper
location on the top of the grass box (). Firmly
push the tabs on the handle into the grass box,
ensuring the handle is properly seated. You
will hear and audible click sound as each tab is
properly seated (Fig. C).
To attach the grass box to the machine, lift and
hold the discharge cover with one hand, and
with the opposite hand, slide the grass box onto
the rear of the machine, ensuring that the grass
box properly seats on the frame of the machine.
Release the spring loaded discharge cover,
allowing the cover to collapse over the opening
between the grass box and the machine (Fig. D).
Properly secure the cable to the handlebar frame
using the provided cable clips () (Fig. D).
Inserting and Removing the Battery
Pack (Fig. E - F - G)
WARNING: Ensure the safety key is turned
off before inserting or removing the battery
pack.
To insert the battery pack, push the button ()
on the machine battery cover () and lift the
cover () (Fig. E, F). Insert the battery pack into
the battery cover, ensuring the small rails on the
cover align with the rail slots on the battery pack.
Firmly push the battery pack into place, until you
hear an audible click sound. Close the battery
cover. You will hear an audible click when the
cover is properly closed (Fig. G).
To remove the battery pack, open the battery
cover. Lift the small button below the front of
the battery pack to release the battery pack. The
spring loaded button will release the battery pack,
allowing you to pull the battery pack out of the
machine. Close the cover to prevent accidental
damage to the machine.
Adjusting the Cutting Height (Fig. H)
Your lawn mower is equipped with a central height
adjustment system, offering height settings. The
setting are approximately in ( mm), / in
( mm), / in ( mm), / in ( mm),
/ in ( mm), and in ( mm). The actual
cutting height may vary slightly.
To adjust the cutting height of the machine,
position the lever (Fig. H) to the desired height
position. The numbers indicated on the body of
the machine (, , , , , ) indicates the
approximate cutting height of the machine in that
position. The lower the number, the shorter the
grass will be cut.
Always perform a small test by cutting the
grass at higher settings and adjusting down to
determine your desired cutting height.
12
Lawn Mower Model LM300
Assembly
Using the Safety Key (Fig. I)
The safety key is an important safety device
on the machine. The motor and blades of the
machine can only be started when the safety key
is inserted and rotated to the ON position. Only
insert the safety key when you intend to start the
machine and turn the blades.
To insert the safety key, push the safety key into
the socket, by aligning the small tab on the key to
the slot in the socket (Fig. I).
To turn the machine to the "ON" position rotate
the key clockwise so the small indicator arrow on
the key points to the "I".
To turn the machine to the "OFF" position, and to
remove the key, rotate the key counterclockwise
so the small indicator arrow on the key points to
the "O". You may remove the key.
The motor can be started only when the safety
key is fitted.
Replacing or Sharpening the
Cutting Blade (Fig. L)
WARNING: Always remove the battery
and the safety key when performing any
maintenance.
The cutting blade is designed to be a replacement
item and may need sharpening from time to time.
Sharpen when dull. Replace when damaged.
Contact your dealer or the manufacturer for proper
instructions.
Operation (Fig. J)
First, make sure you are in the proper cutting
area. Ensure the cutting area is free of bystanders
and foreign objects. Inspect the machine for any
possible damage or unsafe conditions.
Ensure the cutting height of the machine is at your
desired height.
Ensure the safety is in the "ON" position (Fig. I).
Press and hold the safety button (), squeeze the
switch lever () towards the handlebar (Fig. J).
When the unit starts, release the safety button
(). Maintain squeezing the switch lever with two
hands during use.
Releasing the switch lever will disengage power
to the unit. The blades may continue to rotate for
a period of time after power is disengaged.
Stopping the Machine
Release the switch lever () (Fig. J). Releasing
the switch lever will disengage power to the unit.
The blades may continue to rotate for a period of
time after power is disengaged.
13
Lawn Mower Model LM300
Battery Pack and Charger
Battery Pack and Charger
WARNING: To reduce the risk of shock, do
not charge the battery pack in the rain.
Battery Pack LED Charge-Level Indicator
The lithium ion battery pack is equipped with an
LED charge-level indicator. To test the charge
level of the battery pack, press the indicator
button on the battery pack’s face.
No lights: recharge.
One steady green light:
less than charged.
Charge battery pack before use.
Two steady green lights:
– charged.
Three steady green lights:
– charged.
Four steady green lights:
– charged.
Connecting the Charger
If the charger includes a separate power cord,
connect the charger cord to the charger and to the
proper electrical outlet.
Only use the cord set that was supplied with
the charger. At first use, verify that the plug type
matches the receptacle.
Charger LED Charge-State Indicator
The battery charger is equipped with an LED
charge-state indicator that indicates the state of
charging as well as conditions that may delay or
prevent charging.
Note: Until a battery pack is inserted, no lights will
be visible.
Blinking orange light: a fault condition
exists. There are several potential causes.
See “Troubleshooting” in this manual.
Steady orange light: the battery pack
temperature is beyond the acceptable
range (°F/°C to °F /°C). Allow
the battery pack to reach the acceptable
temperature range before charging. The
pack may be left on the charger as the
temperature adjusts. Charging will begin
when the proper temperature is reached.
Blinking green light: battery pack is
charging.
Steady green light: battery pack is ready
for use.
Charging the Battery
WARNING: Failure to follow proper
charging procedures may cause excessive
voltage, excessive current flow, loss of
control during charging, leakage of hazardous
chemicals, heat generation, bursting or fire.
Follow these charging instructions.
With the charger cord connected to the charger
and plugged into a electrical outlet, align the
grooves on the battery with the rails on the
charger and slide the battery pack onto the
charger until fully seated.
For more information, please refer to your
battery and charger manuals.
INDICATOR LIGHTS
INDICATOR BUTTON
14
Lawn Mower Model LM300
Troubleshooting
Troubleshooting
Use this table to see possible solutions for possible problems with the lawn mower. If these suggestions
do not solve the problem, see “Warranty and Service”.
SYMPTOM POSSIBLE CAUSE RECOMMENDED ACTIONS
Tool fails to operate
Possible clogging
Remove battery, remove safety key.
Clear obstructions.
Check underneath the garden product and clear out as
necessary (always wear gardening gloves).
Battery not fully charged Charge battery.
Battery not inserted
(properly)
Properly insert battery.
Grass too long
Increase height of cut and tilt garden product to reduce
starting load.
Motor protector has
activated
Allow motor to cool and increase height of cut.
Battery too hot/cold Allow to cool/warm.
Safety key not inserted
correctly/fully
Insert safety key correctly.
There is a short delay in
the motor starting after
engaging the safety
button switch
Hold safety button for 1 – 3 seconds before engaging
switch lever to start motor.
Motor starts and
stops immediately
Battery not fully charged Charge battery.
Isolator key not inserted
correctly/fully
Insert safety key correctly.
Battery not inserted
(properly)
Properly insert battery.
Battery too hot/cold Allow to cool/warm.
Tool functions
intermittently
Internal wiring of garden
product damaged
Contact service agent.
Motor protector has
activated
Allow motor to cool and increase height of cut.
Garden product
leaves ragged
finish and/or Motor
labours
Height of cut too low Increase height of cut.
Cutting blade dull Replace the blade or sharpen the blade.
Possible clogging
Remove battery, remove safety key.
Check underneath the garden product and clear out as
necessary (always wear gardening gloves).
Blade fitted upside down
Remove battery, remove safety key.
Refit blade correctly.
15
Lawn Mower Model LM300
Troubleshooting
SYMPTOM POSSIBLE CAUSE RECOMMENDED ACTIONS
Area of cut (battery
duration) not large
enough
Height of cut too low Increase height of cut and walk slower.
Grass too high Increase height of cut and walk slower.
Grass wet or damp Wait until grass is dry and walk slower.
Grass is dense
Increase height of cut, walk slower and cut more
frequently.
Cutting blade not
rotating while
garden product
switched on
Cutting blade obstructed
Remove battery, remove safety key.
Clear obstruction (always wear gardening gloves).
Blade nut/bolt loose
Remove battery, remove safety key.
Tighten blade nut/bolt (15 Nm).
Excessive
vibrations/noise
Blade nut/bolt loose
Remove battery, remove safety key.
Tighten blade nut/bolt (15 Nm).
No charging
procedure possible
Battery contacts
contaminated
Clean the battery contacts by inserting and removing
the battery several times or replace the battery.
The battery is defective,
due to a disconnection in
the battery
Replace the battery.
The charge
control LEDs and
respectively, do
not light up after
inserting the mains
plug into the socket
Mains plug of battery
charger not plugged in
(properly)
Insert mains plug (fully) into the socket outlet.
Socket outlet, mains
cable or battery charger
defective
Check the mains voltage and, if necessary, have the
battery charger checked by an authorized customer
service station for power tools.
16
Lawn Mower Model LM300
Specifications
Specifications
BATTERY RECHARGEABLE LAWN MOWER LM300
Blade width 1.3 ft (40 cm)
Height of cut in (mm) 1 in (25 mm) – 3 in (75 mm)
Grassbox, capacity 50 L
Weight with battery 36 lbs (16.3 kg)
Serial number
Refer to label on the machine
(under discharge cover)
BATTERY OREGON BRAND 40V B SERIES BATTERY PACK
Battery pack rated voltage As indicated on the battery pack label
Battery pack capacity As indicated on the battery label
Charging period (battery discharged) Depends on battery capacity and charger output.
Lawn area per battery charge
Depends on battery pack capacity; approximately
4000 ft2 with a 4.0 Ah battery pack
Sound power level: acoustical energy emitted by
the source
LwA.d: 96 dB(A)
Sound pressure level: what the operator hears
Lpa.d: 84 dB(A), Kpa: 3 dB(A)
3,5 m/s², K=1,5 m/s²
Hand/arm vibration avhw < 2.5 m/s2 k= 1,5m/s
2
17
Lawn Mower Model LM300
Warranty and Service
Warranty and Service
Warranty
Blount, Inc. warrants all registered Oregon®
Cordless Tools and Chargers for a period of three
() years and all registered Oregon® Cordless
Battery packs for two () years from original date
of purchase. Registered Oregon® Cordless Tools,
Battery Packs and Chargers are warranted for
two () years if used for commercial purchases.
This limited warranty applies to Oregon® Cordless
Tools System manufactured products. During
the warranty period, Blount will replace or, at
its option, repair for the original purchaser only,
free of charge, any product or part which is found
upon examination by Blount to be defective in
material and/or workmanship. The purchaser
shall be responsible for all transportation charges
and any cost of removing any part submitted for
replacement under this warranty.
To register your product, visit the “support”
section of OregonCordless.com.
Service and Support Information
Visit us on the web at OregonCordless.com
for service center information, or contact our
customer service department at .. for
assistance, additional technical advice, repair, or
replacement parts.
For safety, use only genuine factory replacement
parts on the power tool. Our service center is
staffed with trained personnel to efficiently
provide support and assistance with adjustment,
repair, or replacement of all Oregon® Cordless
Tool System products.
18
Tondeuse à gazon LM300
18
Table des matières
Consignes de sécurité importantes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Fonctionnement général . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Fonctionnement en pente . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Enfants . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Batterie et charge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Stockage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Transport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Mise au rebut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Symboles et étiquettes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Identification du produit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Montage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Batterie et chargeur . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Dépistage des pannes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Caractéristiques techniques . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Garantie et service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Figures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
© Blount, Inc. Les prix et les caractéristiques techniques peuvent être modifiés sans avis préalable. Tous droits réservés. Oregon® est une
marque déposée de Blount, Inc. aux États-Unis et/ou dans d'autres pays.
19
Consignes de sécurité importantes
Tondeuse à gazon LM300
19
Consignes de sécurité importantes
RÈGLES DE SÉCURITÉ POUR LES TONDEUSES À
GAZON POUSSÉES
AVERTISSEMENT : si vous utilisez des
tondeuses sans fil, respectez toujours les consignes
de sécurité basiques suivantes afin de réduire le
risque d'incendie, d'électrocution et de blessure.
Cette machine tranchante est capable d'amputer les
mains et les pieds et de projeter des objets. Le nonrespect des consignes de sécurité suivantes peut
entraîner des blessures graves ou la mort.
Fonctionnement général
Lisez, assimilez et respectez toutes les consignes
indiquées sur la machine et dans le(s) manuel(s)
avant de l'utiliser.
Avant d'insérer la batterie, vérifiez que le
commutateur est en position d'arrêt afin d'empêcher
tout démarrage accidentel. Insérer une batterie dans
une machine dont le commutateur est en position de
marche peut provoquer des accidents.
Tenez toujours vos mains et pieds à bonne distance
de la zone de coupe. Restez toujours à l'écart de
l'orifice d'éjection.
Seuls des adultes responsables connaissant bien les
consignes peuvent utiliser cette machine. Cet outil
n'est pas destiné à être utilisé par des personnes (y
compris des enfants) ayant des capacités physiques,
sensorielles ou mentales réduites ou manquant
d'expérience et de connaissances.
Entretenez soigneusement la tondeuse. Maintenez la
lame bien affutée et propre pour une performance de
meilleure qualité et plus sûre.
Respectez les consignes de lubrification et de
remplacement des accessoires.
Gardez les poignées sèches et propres, sans huile ni
graisse.
Les objets heurtés par la lame de la tondeuse
peuvent provoquer des blessures graves. Par
conséquent, retirez de la zone tous les objets tels
que les pierres, câbles, jouets, etc. pouvant être
heurtés par la lame. Restez derrière la poignée
lorsque le moteur fonctionne.
Si la tondeuse heurte un corps étranger, procédez
comme suit :
• Arrêtez la tondeuse. Relâchez le commutateur.
• Retirez la batterie.
• Vérifiez si des dommages ont été causés.
• Si c'est le cas, réparez-les avant de redémarrer
la tondeuse.
Assurez-vous qu'il n'y a aucun enfant ni aucune
personne présents dans la zone avant de faire
fonctionner la machine. Arrêtez-la si quelqu'un
pénètre dans la zone. L'opérateur ou l'utilisateur est
responsable des accidents ou mises en danger de
tiers ou de ses propriétés.
N'utilisez pas la machine si vous êtes pieds nus ou
portez des chaussures ouvertes. Portez toujours des
chaussures solides.
Portez une tenue appropriée. Ne portez pas de bijoux
ou de vêtements amples, car ils pourraient être
happés par des composants mobiles. L'utilisation
de gants en caoutchouc et de chaussures est
recommandée lorsque vous travaillez en extérieur.
Portez un pantalon long.
Portez toujours des lunettes de protection lorsque
vous utilisez la machine.
Portez toujours un masque de protection ou antipoussière si vous travaillez dans un environnement
poussiéreux.
Ne tondez jamais en tirant la machine vers vous.
Relâchez le levier de contact pour arrêter la machine
et soyez très prudent lorsque vous reculez ou tirez
la machine vers vous. Regardez toujours par terre et
derrière vous avant et pendant que vous reculez.
Éloignez-vous toujours de la zone d'éjection lorsque
vous utilisez la machine. N'orientez jamais le
matériau éjecté vers une personne. Évitez également
de l'éjecter contre un mur ou un obstacle, car le
matériau pourrait ricocher et heurter l'opérateur.
Arrêtez la machine en relâchant le levier de contact
lorsque vous traversez des surfaces gravillonnées ou
non gazonnées.
Ne soulevez et ne portez jamais la machine lorsque
son moteur tourne.
Inspectez toujours tous les carénages, protections
et dispositifs de sécurité avant chaque utilisation.
Ne faites pas fonctionner la machine si le collecteur
d'herbe, la protection de l'éjection, la protection
arrière ou d'autres dispositifs de sécurité ne sont pas
intégralement installés et opérationnels.
20
Consignes de sécurité importantes
Tondeuse à gazon LM300
20
Ne soulevez pas la machine lorsque vous démarrez
le moteur, sauf si la machine doit être soulevée pour
pouvoir démarrer dans l'herbe haute. Dans ce cas,
ne la soulevez pas plus que ce qui est absolument
nécessaire et soulevez uniquement la partie éloignée
de l'opérateur.
Assurez-vous toujours que les deux mains sont en
position opérationnelle avant de reposer la machine
au sol.
Démarrez le moteur selon les instructions, en
éloignant vos pieds des pièces rotatives.
Ne laissez jamais une machine en marche sans
surveillance.
Arrêtez le moteur, attendez que la lame se soit
complètement arrêtée et retirez la batterie avant de
nettoyer la machine, de retirer le collecteur d'herbe
ou de désobstruer la protection de l'éjection.
Utilisez la machine uniquement de jour ou dans de
bonnes conditions d'éclairage artificiel.
N'utilisez pas la machine si vous êtes sous l'influence
de l'alcool ou de la drogue.
N'utilisez pas une tondeuse fonctionnant sur batterie
sous la pluie.
Évitez les environnements dangereux. N'utilisez pas
la tondeuse dans un endroit humide ou mouillé.
N'utilisez jamais la tondeuse dans de l'herbe
mouillée, car l'opérateur pourrait glisser. Gardez
toujours un bon équilibre ; marchez et ne courez
jamais.
Si la machine commence à vibrer anormalement,
arrêtez le moteur et cherchez immédiatement la
cause du problème. Les vibrations sont généralement
le signe d'un problème.
Choisissez le matériel adapté. N'utilisez pas la
tondeuse pour une tâche pour laquelle elle n'est pas
conçue.
Ne forcez pas sur la tondeuse. Elle accomplira
parfaitement sa tâche en toute sécurité à la vitesse
pour laquelle elle a été conçue.
Ne prenez pas de risques. Veillez en toutes
circonstances à prendre appui sur vos deux pieds et à
maintenir votre corps en équilibre.
Restez vigilant. Concentrez-vous sur votre travail et
faites preuve de bon sens. N'utilisez pas la tondeuse
si vous êtes fatigué.
Consultez les consignes du fabricant relatives au bon
fonctionnement et à l'installation des accessoires.
Seuls les accessoires d'origine (fournis avec la
tondeuse) sont approuvés par le fabricant.
Stockez toujours la tondeuse dans un endroit frais
et sec, à l'abri de la lumière directe du soleil. Une
exposition prolongée aux rayons du soleil et aux UV
peut abîmer le plastique et réduire la performance
des protections.
Fonctionnement en pente
Les pentes constituent la principale cause des
glissades et chutes qui peuvent entraîner des
blessures graves.
L'utilisation de la tondeuse dans une pente, quelle
qu'elle soit, nécessite la plus grande prudence. Si
vous n'êtes pas à l'aise sur une pente, ne la tondez
pas.
Passez la tondeuse perpendiculairement à la pente,
jamais de haut en bas. Soyez extrêmement prudent
lorsque vous changez de direction sur une pente.
Faites attention aux trous, ornières, bosses, pierres
ou autres objets cachés. Un terrain irrégulier peut
provoquer une chute ou une glissade. Les herbes
hautes peuvent masquer des obstacles.
Évitez de tondre de l'herbe humide ou des pentes
excessivement raides (> °). Un mauvais équilibre
pourrait causer une glissade ou une chute.
Soyez extrêmement prudent lorsque vous changez de
direction, en particulier sur une pente.
Ne tondez pas à proximité de ravins, de fossés ou de
berges. Vous pourriez perdre l'équilibre.
Enfants
Des accidents tragiques peuvent se produire si
l'opérateur ne porte pas attention à la présence
d'enfants. Ces derniers sont souvent attirés par la
machine et la tonte. Ne supposez jamais qu'un enfant
va rester à l'endroit où vous l'avez vu pour la dernière
fois.
Retirez la clé de sécurité chaque fois que vous vous
éloignez de la machine ou que vous la remisez.
Stockez-la dans un lieu sûr et fermé, hors de portée
des enfants.
Veillez à ce que les enfants restent à l'écart de la
zone de tonte et soient surveillés par un adulte
responsable autre que l'opérateur.
Loading...
