FScan
I FScan
FScan is a vertical near-field planar scanner system that is a perfect solution for antenna measurement applications where a phased array, high gain, or reflector antenna is under evaluation. The FScan system is suitable for small to medium antennas due to the slim cross section scanner structure that fits into small chambers and allows maximum travel.
+
Slim cross- section structure
SOLUTION FOR
• Phased Array Antenna Testing
• High Gain Antenna Testing
• Near-field Focused Antenna Testing
• Array Illumination Assessment
• Array Element Failure Analysis
Main features
Technology
Near-field/Planar
- Near-field/Spherical
- Near-field/Cylindrical
Measurement capabilities
Gain
Radiation pattern
Beamwidth
Cross polarization
Sidelobe levels
Element performance
Array illumination
Frequency bands
100 MHz to 110 GHz
Scan sizes
Standard systems ranging from 4 x 4 to 13 x 13 ft
(1.2 x 1.2 to 4 x 4 m)
Other sizes available upon request
Positioning equipment
Frame scanner with Z-roll probe mount
System configurations
Software
Measurement control, data acquisition and post processing
959 Spectrum (North America only) with NF/FF planar transform*
MiDAS with NF/FF planar transform
Equipment
Planar box scanner
Z-roll probe mount
AL-4164 positioner controller*
Scanner absorber treatment***
Rotary joint for roll axis*
RF cables*
Uninterruptible power supply
Vector network analyzer DUT stand
Add-ons
RF system upconverters/downconverters above 40 GHz
DUT positioner axes for upgrade to cylindrical or spherical NF*
Cylindrical and spherical software transform*
Portable absorber walls***
StarLine linear probe array
Shielded anechoic chamber***
Accessories
Data acquisition workstation
Near-field open-ended waveguides**
Standard gain horns**
High speed channel switching (OFR9800)*
Near-field broadband dual polarized probes with interchangeable
aperture**
Services
Installation
Warranty
Training
Post-warranty service plans****
MV-Cor™ correction table service******
 Included  Optional  Required
* See the ORBIT/FR product catalogs for more information ** See the MVG antenna catalog for more information *** See MVG-EMC Systems catalogs for more information **** See Orbit/FR service brochure for more information ***** See MV-Cor
TM
brochure for more information
107
2
System overview
Data Acquisition Workstation
I FScan
PIN Switch (optional)
VNA
OFR 9800 Switch Controller (optional)
AL-4164 Series Positioner Controller
The standard system is able to collect high resolution antenna planar near-field data using standard Vector Network Analyzers. The AL-4164 controller allows the simultaneous control of up to four (4) axes. Additional units can be added when upgrading to cylindrical and/or spherical.
The data acquisition workstation is equipped with either the 959 Spectrum or MiDAS software, for powerful data acquisition and analysis.
TM
The optional MV-Cor
correction table service allows
physical errors to be measured using a laser tracker system
PIN Switch (optional)
or other optical device. The data is entered into the positioner controller. Real-time corrections to the errors of up to 3 axes (X, Y and Z) are applied to the demanded positions for data acquisition.
Optional pre-test or real time switching via the OFR 9800 high speed switch controller enables the collection of multiple channel data. PIN switches can be added for dual probe as well as multiple channel DUT applications. An optional modular shielded anechoic chamber with absorbers sized to the appropriate frequency range and/or portable absorber walls are available for temporary or cost effective measurement set-up.
108
3
Standard system components
Positioning equipment
Wide range of available frame
scanner sizes for various scan geometries
Aluminum or steel construction
DUT upgrade for cylindrical or
spherical near-field measurements
A wide selection of optional
DUT positioners
Optional 18 GHz or 40 GHz
rotary joint for Z-Roll
ORBIT/FR positioning
equipment catalog
Absorbers and anechoic chambers
I FScan
FScan-13, steel construction
Optional portable absorber wall
or anechoic chamber
Anechoic chambers with
integrated design, production, installation and testing services
AEMI absorber catalog
Measurement probes
Open-ended waveguides
or dual-polarized open-ended waveguides
MVG antenna catalog
FScan in a shielded anechoic chamber
109
43
I FScan
System specifications*
SYSTEMS FSCAN-4 FSCAN-5 FSCAN-7 FSCAN-9 FSCAN-11 FSCAN-13
Frequency Range 0.5-40 GHz 0.5-40 GHz 0.5-40 GHz 0.5-40 GHz 0.5-40 GHz 0.5-40 GHz baseline* baseline* baseline* baseline* baseline* baseline*
Antenna Gain 0.3 dBi rms typical 0.3 dBi rms typical 0.3 dBi rms typical 0.3 dBi rms typical 0.3 dBi rms typical 0.3 dBi rms typical
Sidelobe Accuracy 1.0 dB rms typical 1.0 dB rms typical 1.0 dB rms typical 1.0 dB rms typical 1.0 dB rms typical 1.0 dB rms typical @ -30 dB (relative to peak) (relative to peak) (relative to peak) (relative to peak) (relative to peak) (relative to peak)
Boresight Error 0.05° typical 0.05° typical 0.05° typical 0.05° typical 0.05° typical 0.05° typical
Pattern Range +/- 70° to +/-80° +/- 70° to +/-80° +/- 70° to +/-80° +/- 70° to +/-80° +/- 70° to +/-80° +/- 70° to +/-80° from boresight from boresight from boresight from boresight from boresight from boresight typical** typical** typical** typical** typical** typical**
Accuracy X (RMS) 0.005 in 0.005 in 0.006 in 0.007 in 0.007 in 0.007 in
0.13 mm 0.13 mm 0.15 mm 0.18 mm 0.18 mm 0.18 mm
Accuracy Y (RMS) 0.005 in 0.005 in 0.005 in 0.006 in 0.006 in 0.007 in
0.13 mm 0.13 mm 0.13 mm 0.15 mm 0.15 mm 0.18 mm
Planarity (RMS) 0.005 in 0.006 in 0.005 in 0.006 in 0.006 in 0.007 in
0.13 mm 0.15 mm 0.13 mm 0.15 mm 0.15 mm 0.18 mm
Repeatability X (RMS) 0.001 in 0.001 in 0.001 in 0.001 in 0.001 in 0.001 in
0.025 mm 0.025 mm 0.025 mm 0.025 mm 0.025 mm 0.025 mm
Repeatability Y (RMS) 0.001 in 0.001 in 0.001 in 0.001 in 0.001 in 0.001 in
0.025 mm 0.025 mm 0.025 mm 0.025 mm 0.025 mm 0.025 mm
Z-Roll Axis ZR-50*** ZR-50*** ZR-50*** ZR-50*** ZR-50*** ZR-50***
* Up to 110 GHz with MV-CorTM accuracy improvement ** Depending on DUT size and probe-DUT separation *** See ORBIT/FR Z-Roll Units specication table
Mechanical characteristics*
SYSTEMS FSCAN-4 FSCAN-5 FSCAN-7 FSCAN-9 FSCAN-11 FSCAN-13
SCANNER SUBSYSTEM
Model Number AL-4951-1-4-4-V AL-4951-1-5-5-V AL-4952-1-7-7-V AL-4952-1-9-9-V AL-4952-1-11-11-V AL-4952-1-13-13-V
Scanner Construction Aluminum Aluminum Aluminum Aluminum Steel Steel
Scan Travel X 4 ft 5.5 ft 7 ft 9 ft 11 ft 13 ft
1.22 m 1.68 m 2.14 m 2.74 m 3.35 m 3.96 m
Scan Travel Y 4 ft 5.5 ft 7 ft 9 ft 11 ft 13 ft
1.22 m 1.68 m 2.14 m 2.74 m 3.35 m 3.96 m
Scan Travel X (with Z-roll) 3.2 ft 4.9 ft 6.5 ft 8.2 ft 10 ft 12 ft 1 m 1.5 m 2 m 2.5 m 3 m 3.65 m
Scan Travel Y (with Z-roll) 3.6 ft 5.1 ft 6.6 ft 8.6 ft 10.6 ft 12.2 ft
1.12 m 1.58 m 2.04 m 2.64 m 3.25 m 3.73 m
Payload 50 lbs 50 lbs 50 lbs 50 lbs 50 lbs 50 lbs 23 kg 23 kg 23 kg 23 kg 23 kg 23 kg
Bending Moment 100 ft-lbs 100 ft-lbs 100 ft-lbs 100 ft-lbs 100 ft-lbs 100 ft-lbs 14 kg-m 14 kg-m 14 kg-m 14 kg-m 14 kg-m 14 kg-m
Speed (X & Y) 5 in/sec 5 in/sec 5 in/sec 5 in/sec 5 in/sec 5 in/sec 127 mm/sec 127 mm/sec 127 mm/sec 127 mm/sec 127 mm/sec 127 mm/sec
Motor Drive Power (X & Y) 1/8 hp 1/8 hp 1/8 hp 1/8 hp 1/8 hp 1/8 hp
Height 72.3 in 100.4 in 128.3 in 141.7 in 172.4 in 196.5 in 1,836 mm 2,550 mm 3,260 mm 3,736 mm 4,380 mm 4,990 mm
Width 72.3 in 94.5 in 121.5 in 141.2 in 165.1 in 189.1 in 1,836 mm 2,400 mm 3,086 mm 3,586 mm 4,194 mm 4,803 mm
Depth 29.5 in 29.5 in 29.5 in 29.5 in 39.4 in 39.4 in 750 mm 750 mm 750 mm 750 mm 1,000 mm 1,000 mm
Anechoic Treatment AEP-4* AEP-4* AEP-6* AEP-6* AEP-6* AEP-6*
* Absorber treatment according to the desired frequency range - See the MVG-EMC Systems catalogs for more information
110
5
Typical measurement performance
I FScan
Far-field 3D polar plot
Far-field 2D polar plot
Far-field cartesian plot
Near-field cartesian plot
Near-field data 3D plot
Product specications and descriptions in this datasheet are subject to change without notice.
Actual products may differ in appearance from images shown.
Copyright MVG 2014
