PROGRAMMING MANUAL
SMDC-16 Digital Control Communicator
and
SMPC-32 Personal Control
Page 2
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Table of ContentsTable of Contents
Main Menu Sub Menus Page #
1. System Times
2. Zone
Configuration
3. Receiver
4. System Options
5. Report Codes
6. PIN Numbers
7. Downloader
8. Schedules
9. Partitions
0.
Pager/Fax/Printer
1.1. Delay Times - 1.2. Cutoff Times - 1.3. Self Test - 1.4 Time Clock 6 - 9
2.1. Zone Config. - 2.2. Templates - 2.3. Cross Zones - 2.4. # Shunt Alms - 2.5. Shunt
Period - 2.6. # of Exp Bds. 2.7. Wireless
3.1. Receiver - 3.2. # Telco Lines - 3.3. Monitor Options - 3.4. # Dial Attempts - 3.5. Dial
Features - 3.6. Comm Fail Code - 3.7. TLM Options - 3.8. Rcvr Options - 3.9. Radio Options
4.1. Monitor Mode - 4.2. Walk Test - 4.3. System features - 4.4. System Messages - 4.5.
Emergency 4.6. Two Wire Smokes - 4.7. Force Arming - 4.8. PGM / INP Functions -
4.9. Temporal Fire
5.1 . Report Menu 1 - 5.2. Report Menu 2 - 5.3. Report Menu 3 38 - 43
6.1. Installer PIN - 6.2. Duress PIN - 6.3. Special PIN - 6.4. Open/Close Report Codes -
6.5 Review PIN 1
7.1. Telephone # - 7.2. # of Rings - 7.3. Caller ID - 7.4. - Download PIN - 7.5. Panel Access
ID
8.1. Types - 8.2. Window System - 8.3. Auto Arm 48 - 53
9.1. Types - 9.2. Zone Partition - 9.3. Keypad Assignment - 9.4. User Assignment 54 - 56
0.1. Pager Options 0.2 Fax Options - 0.3 Printer Options 57 - 58
10 - 20
21 - 27
28 - 37
44 - 46
47
Program Info Description Page #
Alphabet
Contact ID Info
Dictionary
Hexadecimal
Chart
INP Options
Introduction
Loop Type
Description
Monitor
Information
Output Options
PGM Output
Options
Program Map
Receiver Routing
Receiver Types
Report Codes
SIA Information
Zone Type
Description
UL Addendum
Quick reference chart
Quick reference chart - additional report code options
Quick reference chart
Quick reference chart
Quick reference chart
Introduction to programming
Quick reference chart
Quick reference chart - Functional information
Quick reference chart
Quick reference chart
Flow chart
Quick reference chart
Quick reference chart
Quick Reference chart of program locations and receiver routing
Quick reference chart - additional report code options
Quick reference chart
UL information
19
42
19
42
37
3
20
29
43
37
4-5
27
27
27
43
20
59
Page 3
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Introduction & Program HintsIntroduction & Program Hints
All programming for the OPTEX INC. SMDC may be accomplished through the SMPC-32 Personal Control Keypad or from the DOS –
SRPU Download Software. English language prompts guide the programmer through easy to follow menu options should you choose to
program via the SMPC keypads.
• Should your company wish to receive a copy of the SRPU software, please contact Tech Support at Optex Inc.- 800-966-7839.
Programming the OPTEX INC. SMDCProgramming the OPTEX INC. SMDC
• Installer Programming for the OPTEX INC. SMDC is made up of ten main menus, each containing various sub-menus that are
arranged by system functions to simplify the programming procedure. (See page 3 & 4 for an expanded view of the menu options).
• To access the OPTEX INC. SMDC Installer Program, press 0000 + PROGRAM, the LCD will change to ‘ENTER YOUR
COMPANY PIN’. At this time enter the factory installed code of 9999.
• Once the factory installed code has been entered, the top line of the LCD will display ‘ENTER RESPONSE’ and the bottom line of
the LCD will be scrolling the nine (9) main menus beginning with “1 SYSTEM TIMES,” “2 ZONE CONFIG,” and so on. To select
one of the nine main menu options, simply press the number that corresponds to the desired menu.
• Once inside one of these menus, the top line will display the name of the menu you are currently in and the bottom line will again
scroll the available options. To exit out of a given menu, press the CLEAR key. This will take you back to the previous menu option
each time the CLEAR key is pressed.
• To exit out of the Installer Program, press the CLEAR key when the top line is displaying “Enter Response.”
Programming TipProgramming Tip
• Next to each programming description in this manual you will notice that there are numbers next to each programming option. This
number is a quick reference as to which numbers to press at the keypad to access that programming memory location.
Example:
1.1.5. A C Fail Display
AC Fail Display
NO 0=NO 1=YES
Selections: Yes / No
Default: No
The first 1. denotes “System Times”
The second 1. denotes “Delay Times”
The 5. denotes “AC Fail Display”
Programming PromptsProgramming Prompts
• Each of the programming prompts contained in the Installer Program are explained in detail, indicates what the factory default
values are and the possible range of entries that can be programmed.
• Throughout the program, you will be prompted for either YES or NO type questions that must be responded to by either pressing
the 0 key followed by the ENTER key to disable the option or to press the 1 key followed by the ENTER key to enable this option.
(See Example 2)
Example: 2
2.1.2. Telephone Output
Z-1 TELEPHONE
YES 0=NO 1=YES
Selections: Yes / No
Default: No
• Other menus will prompt you for an entry, that after you have made your selection, will be pulsating on the LCD display which you
must press the ENTER key to lock in your selection to memory.
Page 4
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Installer Program MenuInstaller Program Menu
1. System Times
1. Delay Times
1. Pre-Alarm Delay
2. Entry Delay
3. Exit Delay
4. AC Fail Delay
5. AC Fail Display
2. Cutoff Times
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
8. Listen-In
3. Self Test
1. Daily
2. Weekly
3. Time of Day
4. Self Test Code
5. Abnormal Test Code
6. Telco Test Report
7. Radio Test Report
4. Real Time Clock
1. Time Clock
1. Set Date
2. Set Time
2. Set by User
3. Display for User
4. Daylight Saving
2. Zone Configuration
1. Zone Configure
(Set Zone Number)
pre-defined YES/NO
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zoning
1. Cross Pair 1
2. Cross Pair 2
3. Cross Zone Timer
4. Number of Shunt Alm
5. Shunt Period
3. Receivers
1. Select Receiver #
1. Receiver 1
1. Telephone #
2. Account Numbers
1 Account # 1-40
1. Zones 1-8
2. Zones 9-16
3. Zones 17-24
4. Zones 25-32
5. Zones 33-40
2. Account # 41-80
1. Zones 41-48
2. Zones 49-56
3. Zones 57-64
4. Zones 65-72
5. Zones 73-80
3. Part Acct #’s
1. Part 1
2. Part 2
3. Part 3
4. Part 4
5. Part 5
6. Part 6
7. Part 7
8. Part 8
4. Common Acct. #
3. Format
2. Receiver 2
1. Telephone #
2. Account #’s
1 Account # 1-40
2 Account # 41-80
(Same as Rcvr 1)
3. Part Account #’s
(Same as Rcvr 1)
4. Common Acct. #
3. Formats
2. # of Telco Lines
3. Tel. Monitor Options
1. Monitor Both Lines
2. Keypad Audible
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
4. Number of Dial Atts.
5. Dial Features
1. TouchTone/Rotary
2. Fallback on Rotary
3. Delay Before Dial
4. TLM fault time
5. Anti-Jam Time
6. Comm Fail Rpt Code
7. TLM Report Codes
1. TLM Fault
2. TLM Restore
8. Rcvr Report Options
1. Alarms
2. Open/Close
3. System
4. Partition #
1. Partition 1
2. Partition 2
4. System Options
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Monitor Mode
5. Auto Monitor on
Disarm
6. PIN Entry Required
7. Monitor Mode Outputs
1. Bell 1 Output
2. Bell 2 Output
3. Relay 1 Output
4. Relay 2 Output
5. PGM 1 Output
6. PGM 2 Output
7. PGM 3 Output
2. Walk Test Mode
1. Bell 1 Output
2. Bell 2 Output
3. Relay 1 Output
4. Relay 2 Output
5. PGM 1 Output
6. PGM 2 Output
7. PGM 3 Output
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
before Zone Process
8. PIN Entry Required
for Zone Scan
9. Thresh of Bad Codes
4. System Messages
1. Top Line Display
1. Group/Part 1 Display
2. Group/Part 2 Display
3. Group/Part 3 Display
4. Group/Part 4 Display
5. Group/Part 5 Display
6. Group/Part 6 Display
7. Group/Part 7 Display
8. Group/Part 8 Display
2. Disarmed Nml Msg
3. Disarmed Abnnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell Output 1
4. Bell Output 2
5. Relay Output 1
6. Relay Output 2
7. PGM Output 1
8. PGM Output 2
9. PGM Output 3
6. 2 Wire Smoke Loop
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset Time
5. Alarm Verify.
6. Outputs
1. Bell 1 Output
Page 5
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
6. Number of Exp. Bds
7. Wireless
3. Partition 3
2. Pulse Bell 1
1. System ID
2. WX Super Time
3. # of WX Xmtrs
4. Xmtrs Enabled
5. Supervised Xmtrs
6. Disable Remote
Installer ProgramMenuInstaller ProgramMenu
4. Partition 4
5. Partition 5
6. Partition 6
7. Partition 7
8. Partition 8
9. Radio Options
1. Radio attempts
2. Radio first
3. Radio account
3. Bell 2 Output
4. Pulse Bell 2
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
9. Temporal Fire
Page 6
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
5. Report Codes
1. Report Code Menu 1
6. PIN Numbers
8. Schedules
9. Partitions
1. AC Fail
2. AC Restore
3. Low Battery
4. Battery Restore
5. Box Tamper
6. Box Tamper Restore
7. Bell Fault Trouble
8. Bell Fault Restore
9. Duress
2. Report Code Menu 2
1. Bus Fault
2. Bus Restore
3. Bell Restore
4. Open Restore
5. Exit Error
6. Open Exception
7. Close Exception
8. Enter Install. Prog
9. Exit Install. Prog.
3. Report Code Menu 3
1. O/C Buffer Full
2. O/C Buffer Overflow
3. Unauthorized User
4. Aux. Power Fail
5. Aux. Power Restore
6. Ground Fault
7. Force Arm
8. On Premise Arm
1. Installer PIN
2. Duress PIN
3. Special PIN Feature
1. Special PIN #
2. Outputs
1. Relay 1
2. Relay 2
3. PGM 1
4. PGM 2
5. PGM 3
4. User Report Codes
1. All Open Code
2. All Close Code
3. User Open Code
4. User Close Code
5. PC Ringback
6. Bell Ringback
7. Bell Test
5. Review PIN 1
7. Downloader
1. Phone Number
2. Number of Rings
3. Caller ID Enable
4. Local Download PIN
5. Panel Access ID #
1. Types
1. Schedule 1
2. Schedule 2
3. Close w/Bypass
4. Close w/Alarm
5. User Set
6. Report Open/Close
2. Windows System
1. Schedule 1
1. Open/Close Window
1. Open Window
2. Close Window
2. Group Schedule 1.
1. Sunday
1. Open Time
2. Close Time
2. Monday
1. Open Time
2. Close Time
3. Tuesday
1. Open Time
2. Close Time
4. Wednesday
1. Open Time
2. Close Time
5. Thursday
1. Open Time
2. Close Time
6. Friday
1. Open Time
2. Close Time
7. Saturday
1. Open Time
2. Close Time
(Sched. for Grps 2 8 is prgmd the same).
2. Schedule 2 (same
as Schedule 1).
3. Holidays
4. Temporary Sched. 1
1. Select Group #
1. Select Date
2. Open Start
3. Close Start
5. Temporary Sched. 2
1. Select Group #
1. Select Date
2. Open Start
3. Close Start
3. Auto Arm
1. Enable Auto Arm
2. Auto Arm Code
3. Fail Auto Arm Code
4. Preclose Warn. Tone
1. Types
1. Keypad Partition
2. Group Arming
3. Total # of Groups
4. Common Group #
2. Zones Grp/Partition
(Select Part #)
1. Partition 1
1. Zones
2. Open Code
3. Close Code
(Prog Part. 2-8 in
same manner as 1)
3. Keypad Part. Assign.
1. Keypad 1 Part. #
2. Keypad 2 Part. #
3. Keypad 3 Part. #
4. Keypad 4 Part. #
5. Keypad 5 Part. #
6. Keypad 6 Part. #
7. Keypad 7 Part. #
8. Keypad 8 Part. #
4. User Part. Assign.
User# 1 Part 1
Part 2
Part 3
Part 4
Part 5
Part 6
Part 7
Part 8
User# 2- 99 same as
User# 1 assignment
0. Pager/Fax Printer
1. Pager Options
1. Pager Tel 1
2. Pager Tel 2
2. Pager Delay Time
3. Alarm Report
4. Open/Close Report
5. Open/Close Fail Rpt
6. System Report
2. Fax Options
1. Fax Phone Number
2. Modem Command
3. Fax Class 2.0
4. Fax Time
5. Fax Schedule
3. Printer Options
1. Printer Enabled
2. Logging Option
1. System Times1. System Times
The information in Section 1 has four sub menus: Delay Times, Cutoff Times, Self Test,
and Real Time Clock.
1. System Times
1. Delay Times
1. Pre-Alarm
2. Entry Delay
3. Exit Delay
4. AC Fail Delay
5. AC Fail Display
Page 7
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
1.1 Delay Times1.1 Delay Times
1.1.1 Pre-Alarm Delay
PREALARM DELAY
00 SECONDS
Select the amount of time for silent entry delay.
Note:Note: This value of time will add on to the total entry delay time.
ExampleExample: 15 sec. Pre Alarm Delay + 15 sec. Entry Delay = 30 sec. Ttl Entry Delay
(see 1.1.2-Entry Delay / 2.1.6-Zone Entry Delay).
1.1.2 Entry Delay
ENTRY Delay
00 SECONDS
Select the required entry delay.
Note:Note: (see 2.1.6-Entry Delay to customize the entry time by zone).
1.1.3 Exit Delay
EXIT DELAY
00 SECONDS
Select the required exit delay time.
Note:Note: This exit delay is common to all exit zones and cannot be customized by zone.
1.1.4 AC Fail Delay
AC FAIL DELAY
00 x 10 MINUTES
Select the amount of time the panel will wait before transmitting the AC Fail Report code
to the central station.
Note:Note: This delay is for communications only, not display.
(see 1.1.5-AC Fail Display / 5.1.1-AC Fail Report Code).
Selections: 0-255 sec.
Default: 0 seconds.
Selections: 0-255 sec.
Default: 45 seconds
Selections: 0-255 sec.
Default: 60 seconds.
Selections: 0-99 x 10 Minutes.(16.5 hrs. max)
Default: 360 minutes (6 hrs)
1.1.5 AC Fail Display
AC Fail Display
YES 0=NO 1=YES
Enable this option to allow the SMDC to display audibly and visually the AC Fail message
at all keypads.
Note: Note: A PIN is required to be entered to silence this warning indicator.
Note:Note: The AC Fail Display message will occur at all keypads approximately 10 seconds after
the AC fault has occurred.
1.2 Cutoff Times1.2 Cutoff Times
Cutoff times allow for the customizing of the trigger outputs. These outputs maybe used
for a variety of purposes. (see 2-Zone Config. / 3.3-Tel. Monitor / 4.5-Emergency/Duress
/ 4.6-Two Wire Smokes / Wiring diagram).
1.2.1 Bell 1 Cutoff
BELL 1 CUTOFF
10 MINUTES
Select the amount of time in minutes alarm output voltage will be present for Bell 1 output.
1.2.2 Bell 2 Cutoff
BELL 2 CUTOFF
10 MINUTES
Select the amount of time in minutes alarm output voltage will be present for Bell 2 output.
Selections: Yes / No
Default: Yes
Selections: 0-99 minutes.
Default: 10 minutes
Selections: 0-99 minutes.
Default: 10 minutes.
Page 8
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
1. System Times1. System Times
2. Set by User
1.2 Cutoff Times 1.2 Cutoff Times (continued)
1.2.3 Relay 1 Cutoff
RELAY 1 CUTOFF
10 MINUTES
Select the amount of time in minutes Relay 1 will remain energized.
1.2.4 Relay 2 Cutoff
RELAY 2 CUTOFF
10 MINUTES
Select the amount of time in minutes Relay 2 will remain energized.
1.2.5 PGM 1 Cutoff
PGM 1 CUTOFF
10 MINUTES
Select the amount of time in minutes PGM 1 will remain energized.
1.2.6 PGM 2 Cutoff
PGM 2 CUTOFF
10 MINUTES
Select the amount of time in minutes PGM 2 will remain energized.
1.2.7 PGM 3 Cutoff
PGM 3 CUTOFF
10 MINUTES
Select the amount of time in minutes PGM 3 will remain energized.
Selections: 0-99 minutes.
Default: 10 minutes.
Selections: 00-99 minutes.
Default: 10 minutes.
Selections: 00-99 minutes.
Default: 10 minutes.
Selections: 00-99 minutes
Default: 10 minutes
Selections: 00-99 minutes
Default: 10 minutes
1. System Times
1. Delay Times
1. Pre-Alarm
2. Entry Delay
3. Exit Delay
4. AC Fail Delay
5. AC Fail Display
2. Cutoff Times
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
8. Listen - In
3. Self Test
1. Daily
2. Weekly
3. Time of Day
4. Self Test Code
5. Abnormal test Code
6. Telco Test Report
7. Radio Test Report
4. Real Time Clock
1. Time Clock
1. Set Date
2. Set Time
1.2.8 Listen-In Cutoff
LISTEN IN CUTOFF
00 MINUTES
Select the amount of time in minutes Listen-In will remain energized.
(additional equip. required).
1.3 Self Test1.3 Self Test
Self Test reports can be used to periodically test the integrity of the communication link
between the SMDC and the central station. Test reports may be sent on a daily
or weekly basis.
1.3.1 Daily Self Test
DAILY TEST RPT
NO 0=NO 1=YES
Enable this option for the SMDC to transmit a self test report on a daily basis.
(see 1.3.4-Test Rpt Code / 1.3.5-Ab Test Rpt Code / 3.8.3-Rcvr Routing)
1.3.2 Weekly Self Test
WEEKLY TEST RPT
NO 0=NO 1=YES
Enable this option for the SMDC to transmit a self test report on a weekly basis.
1.3.2 Day of Week
DAY OF WEEK 0
NO 0=NO 1=YES
Select the day of the week for transmission of the self test code after weekly test has been enabled.
(see 1.3.4-Test Rpt Code / 1.3.5-Ab Test Rpt Code / 3.8.3-Rcvr Routing).
Selections: 00-99 minutes
Default: 00 minutes
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: 1-7
Default: 0
Page 9
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
1. System Times1. System Times
2. Set by User
1.3 Self Test (continued)1.3 Self Test (continued)
1.3.3 Time of Day for Self Test
TIME HH:MM
__:__ AM 1=PM
Select the time of day the Self Test report will be transmitted to the central station.
(see 1.3.4-Test Rpt Code / 1.3.5-Ab Test Rpt Code / 1.3.6-Telco / 3.8.3-Rcvr Routing).
1.3.4 Self Test Code
SELF TEST CODE
code NO
Select the Self Test report code that will be transmitted to the central station via
both digital and radio (requires additional radio hardware).
(see SIA-Contact ID-Hex charts on pg 42 & 43).
1.3.5 Abnormal Test Code
ABNORMAL CODE
code NO
Select the Abnormal Code that will be transmitted to the central station when a zone(s)
designated as a Fire Zone and/or the 2-wire smoke detector zone has gone into an alarm
condition that has not been restored to a normal condition once the Self Test Time arrives.
(see SIA-Contact ID-Hex charts on pg 42 & 43).
1.3.6 Report Self Test on Telco
TELCO REPORT
YES 0=NO 1=YES
Enable this option to transmit the Self Test report code via the telephone line(s).
Selections: 12:00am - 11:59pm
Default: No time
Selections: 01-FF / Contact ID / SIA
Default: No report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: Yes / No
Default: Yes
1. System Times
1. Delay Times
1. Pre-Alarm
2. Entry Delay
3. Exit Delay
4. AC Fail Delay
5. AC Fail Display
2. Cutoff Times
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
8. Listen - In
3. Self Test
1. Daily
2. Weekly
3. Time of Day
4. Self Test Code
5. Abnormal test Code
6. Telco Test Report
7. Radio Test Report
4. Real Time Clock
1. Time Clock
1. Set Date
2. Set Time
1.3.7 Report Self Test on Radio
RADIO REPORT
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to transmit the Self Test report code via Varitech long range radio.
(additional hardware required).
Page 10
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
1. System Times1. System Times
2. Set by User
1.4 Real Time Clock1.4 Real Time Clock
1.4.1. Time Clock
Both the time and date may be programmed in the installer program.
Note Note see 4.3.6- Clock / 4.3.6-AC Clock).
Important:Important: The Time/Date must be entered for all timing functions to operate correctly.
1.4.1.1 Set Date
DATE
00/00/00
Enter the current date. (The SMDC is Y2K compliant).
1.4.1.2 Set Time
TIME HH:MM
__:__ AM 1=PM
Enter the current time. If the time being entered is “PM,” press the “1” key after
entering the time.
1.4.2 Set by User
SET BY USER
NO 0=NO 1=YES
Enable this option to allow for the user to set the date and time from the user program.
1.4.3 Display Time/Date for User
DISPLAY FOR USER
NO 0=NO 1=YES
This option will enable the date and time to display on the top line of all keypads during
the disarmed period.
NoteNote: Enabling this option will override the messages programmed for the System Prompts
(see 4.4-System Messages).
Selections: 12:00am - 11:59pm
Default: No date
Selections: 12:00am - 11:59pm
Default: No time
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: Yes
1. System Times
1. Delay Times
1. Pre-Alarm
2. Entry Delay
3. Exit Delay
4. AC Fail Delay
5. AC Fail Display
2. Cutoff Times
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
8. Listen - In
3. Self Test
1. Daily
2. Weekly
3. Time of Day
4. Self Test Code
5. Abnormal test Code
6. Telco Test Report
7. Radio Test Report
4. Real Time Clock
1. Time Clock
1. Set Date
2. Set Time
1.4.4 Daylight Savings Adjust
DAYLIGHT TIME
NO 0=NO 1=YES
Selections: 0=No 1=Yes
Default: No
Enable this option to allow the internal clock to automatically compensate for daylight savings time.
Page 11
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
2. Zone Configuration
The information contained in this section will determine how each of the zones connected to the alarm
panel will respond, what report codes are to be transmitted and if cross zoning will be a factor. There
are two methods a zone may be programmed. Zones may be programmed individually (Standard) or by
the use of Zone Templates (Pre-Defined). Zone Templates should be used to reduce programming time.
Example, If there are 25 Perimeter Instant zones connected to the system that share the same
characteristics, programming a Perimeter Instant zone template and then applying that
zone template to each zone saves you from answering 19 additional programming prompts for each zone.
Warning:Warning: Programming Zone Templates must be completed first should you decide to use templates.
2.1 Standard (Pre-Defined =2.1 Standard (Pre-Defined =
No)No)
PRE-DEFINED ?
NO
This option determines if the zone being programmed will have all the characteristics
programmed individually (Pre-Defined = No) or if you choose to use a Zone Template
(Pre-Defined = Yes). Go to menu 2.2 should you wish to select Zone Templates.
2.1.1 Zone Type
Z-## TYPE 2
(SCROLLING)
Select the appropriate Zone Type as required.
(see page 20 for a description of the available Zone Types and their characteristics).
2.1.2 Loop Type
Z-## TYPE 3
(SCROLLING)
Select the appropriate Loop Type as required.
(see page 20 for a description of the available Loop Types and their characteristics).
2.1.3 Report Codes
Zones are capable of transmitting Alarm, Trouble, Bypass, Cancel, and Restore report
codes. Select the report codes as required or if for an example, you do not wish to transmit
Restore codes, do not even go to that memory location, skip over it.
If you intend to use Ademco Contact ID or SIA format, any entry is acceptable other than 00.
(See Contact ID-SIA-Hex report code options on page 42 & 43 / 3.8 Receiver Routing Option).
2.1.3.1 Alarm
ALARM CODE
CODE NO
Select the alarm report code that will be transmitted to the central station.
(see Contact ID / SIA note in 2.1.3).
2.1.3.2 Trouble
TROUBLE CODE
CODE NO
Select the trouble report code that will be transmitted to the central station.
(see Contact ID / SIA note in 2.1.3).
2.1.3.3 Bypass
BYPASS CODE
CODE NO
Select the bypass report code that will be transmitted to the central station after the exit delay
has expired and the SMDC has been armed. (see Contact ID / SIA note in 2.1.3).
2.1.3.4 Cancel
CANCEL CODE
CODE NO
Select the Cancel report code that will be transmitted to the central station after an alarm
condition occurs and the system has been disarmed within two minutes of the alarm activation.
(see Contact ID / SIA note in 2.1.3).
Selections: Yes / No
Default: No
Selections: See Table 1: Zone Types
Default: Type 2
Selections: See Table 2: Loop Types
Default: Type 3
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
Page 12
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
2. Zone Configuration
2.1 Standard2.1 Standard (continued)
2.1.3.5 Restore
RESTORE CODE
CODE NO
Select the restore report code that will be transmitted to the central station after zone alarm
or zone trouble has reset to a normal condition. (see Contact ID / SIA note in 2.1.3).
2.1.4 Zone Name
Z-## ZONE NAME
ZONE #
Enter the appropriate name for each zone up to 16 characters including spaces.
(see page 19 for the alphabet, list of available characters and word library).
2.1.5 Loop Response
Z-## LOOP RESP
0005 X 50ms
Enter the amount of time necessary for the SMDC to react to an abnormal condition.
2.1.6 Entry Delay
Z-## ENTRY DELAY
45 SECONDS
Select the amount of entry delay time that will be custom to this entry zone.
(see 1.2-Entry Delay).
2.1.7 Zone Features
This section determines the individual characteristics each zone will have.
2.1.7.1 Silent Day / Audible Night
Z## SILENT DAY
NO 0=NO 1=YES
The SMDC will not energized either bell 1 or bell 2 outputs when the alarm system
is in a disarmed condition if enabled. However the PGMs and the relay outputs will change
state if programmed as an alarm output. The SMDC will activate the bell outputs when
this zone is activated during an armed period,
NoteNote: This option is to be used with 24 hour, Fire and Day zones only.
2.1.7.2 Telephone
Z## TELEPHONE
YES 0=NO 1=YES
Enable this option to allow all zone report to transmit codes via telephone to the central
station.
(see 2.1.3-Report Codes / 3.8-Receiver Routing).
2.1.7.3 Radio
Z## RADIO
NO 0=NO 1=YES
Enable this option to allow all zone report codes to transmit via Varitech long range radio
to the central station.
(See 2.1.3-Report Codes / 3.9-Radio Options).
2.1.7.4 Bypass Allowed
Z## BYPASS
YES 0=NO 1=YES
This option determines if this zone will be able to be bypassed by the user.
(see user manual for PIN authorization levels).
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: Up to 16 characters
Default: Zone #
Selections: 0001-9999 x 50 ms
Default: 0005 x 50 ms
Selections: 00-255 Seconds
Default: 45
Selections: Yes / No
Default: No
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
Selections: Yes / No
Default: Yes
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
Page 13
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
2. Zone Configuration
2.1 Standard2.1 Standard (continued)
2.1.7.5 Shunt Allowed
Z## SHUNT
NO 0=NO 1=YES
This option determines if this zone will automatically cease sending alarm report codes to
the central station after the programmed number of activation’s (2.4-# Shunt Alarms) and
time period (2.5-Shunt Period).
WarningWarning: The alarm outputs will continue to activate on each new alarm condition.
2.1.7.6 Display Armed
Z## DISP. ARMED
YES 0=NO 1=YES
This option determines if this zone description will be displayed on the keypad once the
SMDC senses an alarm activation during the armed period.
NoteNote: The zone description will not display if Group Arming is enabled.
2.1.7.7 Walk Test
Z## WALK TEST
YES 0=NO 1=YES
Enabled this option if this zone will be included in the Walk Test mode.
WarningWarning: Fire and 24 hour zones will activate an alarm condition in this mode.
(see User Manual).
2.1.7.8 Monitor Mode
Z## MONITOR
NO 0=NO 1=YES
Enabled this option if this zone will be included in the Monitor mode.
WarningWarning: Fire and 24 hour zones will activate an alarm condition in this mode.
(see User Manual).
2.1.7.9 Auto Walk at Arm
Z## AUTO-WALK
NO 0=NO 1=YES
Enabling this option will prompt the user that the SMDC has not detected a change
of state on this zone during the disarmed period.
Note: Note: This prompt will occur upon arming.
2.1.8 Zone Outputs
This section determines which output(s) the SMDC will activate when the specified
zone activates an alarm condition.
2.1.8.1 Bell 1
Z## BELL 1
YES 0=NO 1=YES
Enable this option for the SMDC to activate a steady output from Bell 1
when this zone initiates an alarm condition.
(see 1.2 Cutoff Times / wiring diagram).
2.1.8.2 Bell 1 Pulse
Z## BELL 1 PULSE
NO 0=NO 1=YES
Enable this option for the SMDC will activate a pulsed output from Bell 1
when this zone initiates an alarm condition.
(see 1.2 Cutoff Times / wiring diagram).
NoteNote: 2.1.8.1 Bell 1 output must be programmed as YES for this Pulse Bell option to function.
Selections: Yes / No
Default: No
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
Page 14
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
2. Zone Configuration
2.1 Standard 2.1 Standard (continued)
2.1.8.3 Bell 2
Z## BELL 2
YES 0=NO 1=YES
Enable this option for the SMDC to activate a steady output from Bell 2
when this zone initiates an alarm condition. (see 1.2 Cutoff Times / wiring diagram).
2.1.8.4 Bell 2 Pulse
Z## BELL 2 PULSE
NO 0=NO 1=YES
Enable this option for the SMDC will activate a pulsed output from Bell 2
when this zone initiates an alarm condition. (see 1.2 Cutoff Times / wiring diagram).
NoteNote: 2.1.8.3 Bell 2 output must be programmed as YES for this Pulse Bell option to function.
2.1.8.5 Relay 1
Z## RELAY 1
NO 0=NO 1=YES
Enable this option for the SMDC to activate Relay 1 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.1.8.6 Relay 2
Z## RELAY 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate Relay 2 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.1.8.7 PGM 1
Z## PGM 1
NO 0=NO 1=YES
Enable this option for the SMDC to activate PGM 1 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.1.8.8 PGM 2
Z## PGM 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate PGM 2 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.1.8.9 PGM 3
Z## PGM 3
NO 0=NO 1=YES
Enable this option for the SMDC to activate PGM 3 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.1.9 Alarm Verify
Z## ALARM VERIFY
NO 0=NO 1=YES
Enabling this option will help in the reduction of false alarms in that the SMDC will
recognize an alarm state on this zone and will then start a timer “window” of 60 seconds
and must recognize subsequent alarm activation from the same circuit within the
“window” before the panel will initiate an actual alarm condition.
NoteNote: This feature can’t be used for any UL Listed application.
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
Page 15
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
2. Zone Configuration
2.2. Zone Templates (Pre-Defined = Yes)2.2. Zone Templates (Pre-Defined = Yes)
There are nine Zone Templates available which corresponds to the individual zone types
(1 - 9). Select the Zone Type upon entering this menu that you wish to program.
2.2.1 Loop Response
TY-# LP RESP
0005x50ms
Enter the amount of time necessary for the SMDC to react to an abnormal condition.
2.2.2 Zone Features
This section determines the individual characteristics each zone will have.
2.2.2.1 Silent Day / Audible Night
TY# SILENT DAY
NO 0=NO 1=YES
The SMDC will not energized either bell 1 or bell 2 outputs when the alarm system
is in a disarmed condition if enabled. However the PGMs and the relay outputs will change
state if programmed as an alarm output. The SMDC will activate the bell outputs when
this zone is activated during an armed period.
Note: This option is to be used with 24 hour, Fire and Day zones only.
2.2.2.2 Telephone
TY# TELEPHONE
YES 0=NO 1=YES
Enable this option to allow all zones report codes to transmit via telephone to the central
station.
(see 2.1.3 Report Codes)
2.2.2.3 Radio
TY# RADIO
NO 0=NO 1=YES
Enable this option to allow all zone report codes to transmit via Varitech long range radio
to the central station.
(See 2.1.3-Report Codes / 3.9-Radio Options).
2.2.2.4 Bypass Allowed
TY# BYPASS
YES 0=NO 1=YES
This option determines if this zone will be able to be bypassed by the user.
(see user manual for PIN authorization levels).
2.2.2.5 Shunt Allowed
TY# SHUNT
YES 0=NO 1=YES
This option determines if this zone will automatically cease sending alarm report codes to
the central station after the programmed number of activation’s (2.4-# Shunt Alarms) and
time period (2.5-Shunt Period).
WarningWarning: The alarm outputs will continue to activate on each new alarm condition.
2.2.2.6 Display Armed
TY# DSP ARMED
YES 0=NO 1=YES
This option determines if this zone description will be displayed on the keypad once the
SMDC senses an alarm activation during the armed period.
NoteNote: The zone description will not display if Group Arming is enabled.
Selections: 0001-9999 x 50 ms
Default: 0005x50 ms
Selections: 0001-9999
Default: 0001x50 ms
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: Yes
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
Page 16
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
2. Zone Configuration
2.2 Zone Templates2.2 Zone Templates (continued)
2.2.2.7 Walk Test
TY# WALK TEST
NO 0=NO 1=YES
2.2.3 Zone Outputs2.2.3 Zone Outputs
Enabled this option if this zone will be included in the Walk Test mode.
WarningWarning: Fire and 24 hour zones will activate an alarm condition in this mode.
(see User Manual).
2.2.2.8 Monitor Mode
TY# MONITOR
YES 0=NO 1=YES
Enabled this option if this zone will be included in the Monitor mode.
WarningWarning: Fire and 24 hour zones will activate an alarm condition in this mode.
(see User Manual).
2.2.2.9 Auto Walk at Arm
TY# AUTO-WALK
NO 0=NO 1=YES
Enabling this option will prompt the user that the SMDC has not detected a change
of state on this zone during the disarmed period.
Note: This prompt will occur upon arming.
This section determines which output(s) the SMDC will activate when the specified
zone type initiates an alarm condition.
2.2.3.1 Bell 1
TY# BELL 1
NO 0=NO 1=YES
Enable this option for the SMDC to activate a steady output from Bell 1
when this zone initiates an alarm condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.2 Bell 1 Pulse
TY# BELL 1 PULSE
NO 0=NO 1=YES
Enable this option for the SMDC will activate a pulsed output from Bell 1
when this zone initiates an alarm condition.
(see 1.2 Cutoff Times / wiring diagram).
NoteNote: 2.1.8.1 Bell 1 output must be programmed as YES for this Pulse Bell option to function.
2.2.3.3 Bell 2
TY# BELL 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate a steady output from Bell 2
when this zone initiates an alarm condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.4 Bell 2 Pulse
TY# BELL 2 PULSE
NO 0=NO 1=YES
Enable this option for the SMDC will activate a pulsed output from Bell 2
when this zone initiates an alarm condition.
(see 1.2 Cutoff Times / wiring diagram).
NoteNote: 2.1.8.1 Bell 2 output must be programmed as YES for this Pulse Bell option to function.
Selections: Yes / No
Default: No
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
Page 17
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
2. Zone Configuration
2.2.3 Zone Outputs2.2.3 Zone Outputs
2.2.3.5 Relay 1
TY# RELAY 1
NO 0=NO 1=YES
2.3 Cross Zone Pairs2.3 Cross Zone Pairs
Enable this option for the SMDC to activate Relay 1 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.6 Relay 2
TY# RELAY 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate Relay 2 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.7 PGM 1
TY# PGM1
NO 0=NO 1=YES
Enable this option for the SMDC to activate PGM 1 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.8 PGM 2
TY# PGM 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate PGM 2 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
2.2.3.9 PGM 3
TY# PGM 3
NO 0=NO 1=YES
Enable this option for the SMDC to activate PGM 3 when this zone initiates an alarm
condition. (see 1.2 Cutoff Times / wiring diagram).
The use of Cross Zones Pairs will help in the reduction of false alarms in that the SMDC
must recognize the activation of two zones within a programmable time period before an
actual alarm condition will be generated by the SMDC. The SMDC allows for a
maximum of sets of Cross Zone pairs that both share a common time. Typical applications
may be two sets of outdoor photoelectric beams or two interior detectors.
2.3.1 Cross Zone Pair 1
2.3.1.1 Zone A
PAIR 1 / ZONE A
Zone 00
Select the applicable zone that will be used for Zone A of Cross Zone Pair 1.
2.3.1.2 Zone B
PAIR 1 / ZONE B
Zone 00
Select the applicable zone that will be used for Zone B of Cross Zone Pair 1.
2.3. 2 Cross Zone Pair 2
2.3.2.1 Zone A
PAIR 2 / ZONE A
Zone 00
Select the applicable zone that will be used for Zone A of Cross Zone Pair 2.
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: 1-80
Default: 00
Selections: 1-80
Default: 00
Selections: 1-80
Default: 00
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
Page 18
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
2. Zone Configuration
2.3 Cross Zone Pairs2.3 Cross Zone Pairs
(continued)
2.3.2.2 Zone B
2.4 Number of Shunt Alarms2.4 Number of Shunt Alarms
2.5 Shunt Period2.5 Shunt Period
2.6 Number of Expander Boards2.6 Number of Expander Boards
2.7 Wireless Options2.7 Wireless Options
PAIR 2 / ZONE B
Zone 00
Select the applicable zone that will be used for Zone B of Cross Zone Pair 2.
2.3.3 Cross Zone Timer
CROSS ZONE TIME
00 seconds
Select the time “window “ for both Cross Zone Pairings the SMDC must wait before
before creating an actual alarm condition.
# OF SHUNT ALM
00
Select the number of alarms that must occur before the SMDC will auto bypass the zone.
(see Shunt Allowed 2.1.7.5 / Shunt Period).
SHUNT PERIOD
00x10 MINUTES
Select the time period that will allow the SMDC to auto bypass this zone.
(see 2.1.7.5 Shunt Allowed / Number of Shunt Alarms).
# of EXP BDS
00
Select the total number of expander boards that will be installed.
Note:Note: The SMDC will not allow you to program or scan past the main sixteen zones
if the correct number of expander boards has not been enabled.
Note:Note: The SMDC will not allow arming if there has been a low battery trouble or a “fail to
check in” trouble (not respoding).
The SMDC-WX (wireless features) have not been investigated for use in
UL Listed Fire Applications or UL Listed Burglar Applications
2.7.1 System ID
SYSTEM ID
NO
Enter the unique operating code for the wireless receiver.
Note:Note: This option will allow you to set a SMDC so that it will not receive interference
from a neighboring SMDC wireless system.
(additional equipment required).
Selections: 1-80
Default: 00
Selections: 00-255 seconds
Default: 00 seconds
Selections: 00-99
Default: 00
Selections: 00x10 minutes
Default: 00 minutes
Selections: 0-8
Default: 0
Selections: 00 - 99
Default: No
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
Page 19
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
2. Zone Configuration
2.7 Wireless Options (continued)2.7 Wireless Options (continued)
2.7.2 WX Supervised Time
WX SUPER. TIME
00x1 hours
Select the regularity each of the installed wireless transmitters must send a “check in signal”
before a trouble condition will be initiated by the alarm panel.
2.7.3 Number of Wireless Transmitters
# OF WX XMTRS
00
This option will determine the number of wireless transmitters that will be installed.
2.7.4 Transmitters Enabled
XMTRS ENABLED 01
NNNNNNNNNNNNNNNN
You must enable the transmitter numbers that will be utilized.
Note:Note: The first wireless zone utilized will begin with zone 17 if there are no expander boards
(G-EX) installed.
Example:Example: The wireless zones will be 25 to 57 if the SMDC has one expander board
(G-EX) installed, even though all 8 zones on the expander board may not have be
utilized.
2.7.5 Supervised Transmitters
SUPERVISED 01
NNNNNNNNNNNNNNNN
Select the installed transmitters that will be supervised.
2.7.6 Disable Remote
DISABLE REMOTE
NO 0=NO 1=YES
Select if the wireless arm / disarm function will be available.
Selections: 00 - 99
Default: 04x1 hour
Selections: 00 - 32
Default: 00
Selections: 1= Yes 0= No
Default: NNNNNNNNNNNNNNNN
Selections: 1=Yes 0=No
Default: NNNNNNNNNNNNNNNN
Selections: Yes / No
Default: No
(Set Zone #)
1. Zone Config.
1. Zone Type
2. Loop Type
3. Report Codes
1. Alarm
2. Trouble
3. Bypass
4. Cancel
5. Restore
4. Zone Name
5. Loop Response
6. Entry Delay
7. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
8. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
9. Alarm Verify
2. Templates
(Set Zone Type)
1. Loop Response
2. Zone Features
1. Silent Day/
Audible Night
2. Telephone
3. Radio
4. Bypass Allowed
5. Shunt Allowed
6. Display Armed
7. Walk Test
8. Monitor Mode
9. Auto Walk at Arm
3. Zone Outputs
1. Bell 1
2. Bell 1 Pulse
3. Bell 2
4. Bell 2 Pulse
5. Relay 1
6. Relay 2
7. PGM 1
8. PGM 2
9. PGM 3
3. Cross Zone Pairs
1. Cross Zone Pair 1
1. Zone A
2. Zone B
2. Cross Zone Pair 2
1. Zone A
2. Zone B
3. Cross Zone Timer
4. # of Shunt Alarms
5. Shunt Period
Page 20
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
2. Zone Configuration2. Zone Configuration
Custom DictionaryCustom Dictionary
To select a word from this library, enter the number that corresponds to that word followed by pressing the MEMORY button on the keypad.
1 = AREA
2 = ATTIC
3 = BASEMENT
4 = BATHROOM
5 = BEDROOM
6 = BUTTON
7 = COMPUTER
8 = CORRIDOR
9 = DEN
10 = DETECTOR
11 = DINING
12 = DOOR
13 = DRAWER
14 = EAST
15 = ELEVATOR
16 = EMERGENCY
17 = ENTRANCE
18 = EXIT
19 = FAMILY
20 = FENCE
21 = FIRE
22 = FLOOR
23 = FRONT
24 = FURNACE
25 = GARAGE
26 = GATE
27 = HALL
28 = HATCH
29 = HEAT
30 = HOLDUP
31 = KITCHEN
32 = LIVING
33 = LOADING
34 = LOBBY
35 = MAIN
36 = MANAGER
37 = MASTER
38 = MEDICAL
39 = NORTH
40 = OFFICE
41 = OVERLOAD
42 = PANIC
43 = PATIO
44 = PORCH
45 = REAR
46 = ROOF
47 = ROOM
48 = SAFE
49. SCREEN
50. SHIPPING
51. SIDE
52. SKYLIGHT
53. SMOKE
54. SOUTH
55. STAIRS
56. STOCK
57. STORAGE
58. STUDY
59. TRANSOM
60. VAULT
61. WATER
62. WEST
63. WINDOW
AlphabetAlphabet
To create your own word from this chart, enter the number that corresponds to each letter followed by pressing the ENTER button on the keypad.
You may enable the letter(s) to pulsate by adding the value of 100 to your selection.
1 = A
2 = B
3 = C
4 = D
5 = E
6 = F
7 = G
8 = H
9 = I
10 = J
11 = K
12 = L
13 = M
14 = N
15 = O
16 = P
17 = Q
18 = R
19 = S
20 = T
21 = U
22 = V
23 = W
24 = X
25 = Y
26 = Z
27 = a
28 = b
29 = c
30 = d
31 = e
32 = f
33 = g
34 = h
35 = i
36 = j
37 = k
38 = l
39 = m
40 = n
41 = o
42 = p
43 = q
44 = r
45 = s
46 = t
47 = u
48 = v
49 = w
50 = x
51 = y
52 = z
53 = :
54 = ;
55 = <
56 = >
57 = =
58 = ?
59 = @
60 = 0
61 = 1
62 = 2
63 = 3
64 = 4
65 = 5
66 = 6
67 = 7
68 = 8
69 = 9
70 = !
71 = “
72 = #
73 = N/A
74 = $
75 = %
76 = &
77 = ‘
78 = (
79 = )
80 = *
81 = +
82 = ,
83 = 84 = .
85 = /
86 = [
87 = ]
88 =∧
89 = −
90 =
91 = à
92 = ß
93 = \
94 = {
95 = }
Page 21
2. Zone Configuration2. Zone Configuration
Zone Type DescriptionsZone Type Descriptions
Zone Type Description
1. Entry / Exit
2. Perimeter
Instant
3. Interior 1
4. Interior 2
5. Interior 3
6. 24 Hour
7. Fire
8. Day Zone 1) Disarmed - an activation creates an trouble condition.
9. Garage Door
* Note: The term follower is defined as the zone will be delayed on entry if the Exit door is sensed by the control panel first, should the follower zone be
sensed first by the control panel, the follower zone will create an alarm instantly.
1) Away mode - this zone is always delayed (entry / exit).
2) Stay mode - this zone is always delayed (entry / exit).
3) Instant mode - this zone is always delayed exit and always instant alarm on entry.
1) Away mode - this zone is always an instant alarm.
2) Stay mode - this zone is always an instant alarm.
3) Instant mode - this zone is always an instant alarm.
1) Away mode - this zone responds as a follower.*
2) Stay mode - this zone responds as a follower. *
3) Instant mode - this zone responds as an instant alarm if activated.
1) Away mode - this zone responds as a follower. *
2) Stay mode - this zone is always bypassed.
3) Instant mode - this zone is always bypassed.
1) Away mode - this zone is always delayed
2) Stay mode - this zone is always delayed
3) Instant mode - this zone is always bypassed
1) This zone type is used for devices that will create an alarm regardless of the armed state of the SMDC.
1) This type of zone may also be enable for Fire Supervisory after the YES has been programmed.
2) If YES is selected for Fire Supervisory, the keypad(s) will emit a steady tone on an alarm condition and display the zone
in alarm.
2) Armed - an activation creates an instant alarm condition.
1) This zone type allows the zone to be open when arming the SMDC.
2) When the zone restores, it is returned as an active entry delay zone.
3) The zone must restore to a secure condition prior to exit delay time expiring.
4) Should the zone fail to secure, an exit error code will be transmitted if so programmed.
5) An alarm will be generated if the zone is left open.
Loop Type DescriptionsLoop Type Descriptions
Loop Type 2.2K EOL Description
1. Normally Open
2. Normally Closed
3. Normally Open/
Normally Closed
4. Normally Open,
Trouble on Break
5. Normally Closed,
Trouble on Short
No 1) For devices that have a Normally Open relay output.
2) Open will occur on a short.
3) No trouble conditions will be generated.
No 1) For devices that have a Normally Closed relay output.
2) Open condition will occur on a break.
3) No trouble conditions will be generated.
Yes 1) For devices that have a Normally Open or Normally Closed relay output.
2) Open will occur on a short or a break.
3) No trouble conditions will be generated.
Yes 1) For devices which have a Normally Open relay output.
2) Open condition will occur on a short
3) Trouble condition will occur on a break
4) Armed - Trouble report code transmitted if programmed on all zone types.
5) Disarmed - Trouble report code transmitted if programmed on zone type 6 (24 hr)- 7 (fire) only.
Yes 1) For devices which have a Normally Closed relay output.
2) Open will occur on a break
3) Trouble condition will occur on a short.
4) Armed - Trouble report code transmitted if programmed on all zone types.
5) Disarmed - Trouble report code transmitted if programmed on zone type 6 (24 hr)- 7 (fire) only.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 22
3. Receivers3. Receivers
This section details the requirements necessary for the transmission of signals, format type,
telephone line monitor responses, account number(s), radio options, and receiver reporting
options. Program each of the options as necessary for the installation.
3.1 Select Receiver #3.1 Select Receiver #
SEL. RECEIVER
ExampleExample : Press 1 for receiver 1 - Enter - Clear
3.1.1 Receiver 1
Once Receiver 1 is chosen, the display will scroll the following three options:
1. Telephone 2. Account Numbers 3. Formats
3.1.1.1 Telephone Number
TELEPHONE NUMBER
Select up to 16 digits/characters for the telephone number and any required delays or
access codes. (see chart below).
Note: Note: Press the RESET key to clear the phone number presently displaying,
Selections: 0 through 9
Instant Key: 3 second dial pause (appears as a “:”)
Memory Key: 5 second dial tone detect (appears as a”;”)
Stay Key: # (pound)
Away Key: * (asterisk)
3.1.1.2. Account Numbers
This section allows you to assign unique account numbers to various “packs” of zones.
Each “pack” consists of 8 zones.
Note: Note: Always program Common Account Number if multiple account numbers are not needed
as this will write the account number to all locations.
This menu will scroll.:
(1) Account Z01-40
(2) Account Z41-80
(3) Account Groups
(4) Common Account Number (see note above).
3.1.1.2.1 Zone Account Numbers for Z 01-40
The bottom line will be scrolling the different sets of account numbers.
3.1.1.2.1.1 Zones 1-8
ACCOUNT Z01-08
0000
Select the account number to be transmitted for zones 1-8.
Selections: 1 or 2
Default: Blank
Selections: See below
Default: Blank
Selections: 0000 - FFFF
Default: 0000
3. Receivers
1. Select Receiver #
1. Receiver 1
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. Receiver 2
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. # of Telco Lines
3. Tel. Monitor Opt.
1. Monitor Both Lines
2. Keypad Audible
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
4. Number of Dial Att.
5. Dial Features
1. TouchTone/Rotary
2. Fallback on Rotary
3. Delay before
4. TLM fault time
5. Anti-Jam Time
6. Comm. Fail Code
7. TLM Report Codes
1. TLM Fault
2. TLM Restore
8. Rcvr Routing Options
1. Alarms
2. Open/Close
3. System
4. Partition #
1. Partition 1
2. Partition 2
3. Partition 3
4. Partition 4
5. Partition 5
6. Partition 6
7. Partition 7
3.1.1.2.1.2 Zones 9-16 Select the account number to be transmitted for zones 9-16.
3.1.1.2.1.3 Zones 17-24 Select the account number to be transmitted for zones 17-24.
3.1.1.2.1.4 Zones 25-32 Select the account number to be transmitted for zones 25-32.
3.1.1.2.1.5 Zones 33-40 Select the account number to be transmitted for zones 33-40.
.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 23
3. Receivers3. Receivers
7. 20PPS 3/1 Extended 14. Ademco Contact ID
3.1.1 Receiver 1(continued)3.1.1 Receiver 1(continued)
3.1.1.2.2 Zone Account Numbers for Z 41-80
The bottom line will be scrolling different sets of account numbers
3.1.1.2.2.1 Zones 41-48
ACCOUNT Z41-48
0000
Select the account number to be transmitted for zones 41-48.
3.1.1.2.2.2 Zones 49-56 Select the account number to be transmitted for zones 49-56.
3.1.1.2.2.3 Zones 57-64 Select the account number to be transmitted for zones 57-64.
3.1.1.2.2.4 Zones 65-72 Select the account number to be transmitted for zones 65-72.
3.1.1.2.2.5 Zones 73-80 Select the account number to be transmitted for zones 73-80.
3.1.1.2.3 Partition Account Numbers
This section allows you to assign unique account numbers to various groups.
Note:Note: These Partition numbers will only be transmitted in a Partitioned System.
NoteNote: Always program Common Account Number if multiple account numbers are not needed
as this will write the account number to all locations.
3.1.1.2.3.1 Partition 1
1 ACCOUNT GRP-1
0000
Select the account number to be transmitted for Partition 1.
3.1.1.2.3.2. Partition 2 - Select the account number to be transmitted for Partition 2
3.1.1.2.3.3. Partition 3 - Select the account number to be transmitted for Partition 3
3.1.1.2.3.4. Partition 4 - Select the account number to be transmitted for Partition 4
3.1.1.2.3.5. Partition 5 - Select the account number to be transmitted for Partition 5
3.1.1.2.3.6. Partition 6 - Select the account number to be transmitted for Partition 6
3.1.1.2.3.7. Partition 7 - Select the account number to be transmitted for Partition 7
3.1.1.2.3.8. Partition 8 - Select the account number to be transmitted for Partition 8
3.1.1.2.4 Common Account Number
1 COMMON ACCOUNT
0000
Select the account number to be transmitted for all Groups and all zones
WarningWarning: making an entry in this location will over-write the information to all account
number locations (partition and zone account numbers).
3.1.1.3 Format
RCVR# FORMAT
(scroll formats)
Select the transmission format will be for Receiver 1.
(see chart below and on page 27 for more detailed information).
Selections: 0000 - FFFF
Default: 0000
Selections: 0000 - FFFF
Default: 0000
Selections: 0000 - FFFF
Default: 0000
Selections: See Table 3 below
Default: 10PPS 3/1 Format
3. Receivers
1. Select Receiver #
1. Receiver 1
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. Receiver 2
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. # of Telco Lines
3. Tel. Monitor Opt.
1. Monitor Both Lines
2. Keypad Audible
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
4. Number of Dial Att.
5. Dial Features
1. TouchTone/Rotary
2. Fallback on Rotary
3. Delay before
4. TLM fault time
5. Anti-Jam Time
6. Comm. Fail Code
7. TLM Report Codes
1. TLM Fault
2. TLM Restore
8. Rcvr Routing Options
1. Alarms
2. Open/Close
3. System
4. Partition #
1. Partition 1
2. Partition 2
3. Partition 3
4. Partition 4
5. Partition 5
6. Partition 6
7. Partition 7
Transmission Format TypesTransmission Format Types
1. 10PPS 3/1 8. 20PPS 4/1
2. 10PPS 3/1 Extended 9. 20PPS 4/1 Extended
3. 10PPS 4/1 10. 20PPS 4/2
4. 10PPS 4/1 Extended 11. 40PPS with Parity
5. 10PPS 4/2 12. Varitech FSK 4/2
6. 20PPS 3/1 13. SIA Level 1
3.1.2 Receiver 2
The programming sequence for Receiver 2 is identical to Receiver 1. Program the
necessary information as required for Receiver 2.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 24
3. Receivers3. Receivers
3.2 Number of Telco Lines3.2 Number of Telco Lines
# of Telco Line
01
Enter the number of phone lines that will be connected to the SMDC. (see wiring diagram).
NoteNote: The panel will enunciate a telco fault should this option be enable for more lines
than are installed.
3.3 Telephone Monitor3.3 Telephone Monitor
OptionsOptions
The information in this section focuses on how the SMDC will respond should the
telephone line(s) be compromised.
3.3.1 Monitor Both Lines
MONITOR BOTH
NO 0=NO 1= YES
Enable this option to allow the SMDC to monitor the phone line current and voltage
of two phone lines.
3.3.2 Keypad Audible
KEYPAD AUDIBLE
NO 0=NO 1=YES
Enable this option to allow the SMDC to enunciate a trouble condition at all
SMPC-32 should the SMDC detect a trouble condition on the phone line(s).
3.3.3 Bell 1 Output
BELL 1 OUTPUT
NO 0=NO 1=YES
Enable this option to energize Bell 1 when the SMDC has detected a telco line fault
condition.
(see 1.2 Cutoff Times).
3.3.4 Bell 2 Output
BELL 2 OUTPUT
NO 0=NO 1=YES
Enable this option to energize Bell 2 when the SMDC has detected a telco line fault
condition.
(see 1.2 Cutoff Times).
3.3.5 Relay 1 Output
RELAY 1 OUTPUT
NO 0=NO 1=YES
Enable this option to energize Relay 1 when the SMDC has detected a telco line fault
condition.
(see 1.2 Cutoff Times).
Selections: 00 - 02
Default: 01
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
3. Receivers
1. Select Receiver #
1. Receiver 1
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. Receiver 2
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. # of Telco Lines
3. Tel. Monitor Opt.
1. Monitor Both Lines
2. Keypad Audible
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
4. Number of Dial Att.
5. Dial Features
1. TouchTone/Rotary
2. Fallback on Rotary
3. Delay before
4. TLM fault time
5. Anti-Jam Time
6. Comm. Fail Code
7. TLM Report Codes
1. TLM Fault
2. TLM Restore
8. Rcvr Routing Options
1. Alarms
2. Open/Close
3. System
4. Partition #
1. Partition 1
2. Partition 2
3. Partition 3
4. Partition 4
5. Partition 5
6. Partition 6
7. Partition 7
3.3.6 Relay 2 Output
RELAY 2 OUTPUT
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to energize Relay 2 when the SMDC has detected a telco line fault
condition.
(see 1.2 Cutoff Times).
3.3.7 PGM 1 Output
PGM-1 OUTPUT
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to energize PGM 1 when the SMDC has detected a telco line fault
condition.
(see 1.2 Cutoff Times).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 25
3. Receivers3. Receivers
3.3. Telephone Monitor Options3.3. Telephone Monitor Options (continued)
3.3.8 PGM 2 Output
PGM-2 OUTPUT
NO 0=NO 1=YES
Enable this option to energize PGM 2 when the SMDC has detected a telco line fault
condition.
(see 1.2 Cutoff Times).
3.3.9 PGM 3 Output
PGM-3 OUTPUT
NO 0=NO 1=YES
Enable this option to energize PGM 3 when the SMDC has detected a telco line fault
condition.
(see 1.2 Cutoff Times).
3.4 Number of Dial Attempts3.4 Number of Dial Attempts
NUMBER OF ATT
05
Select the number of dial attempts the SMDC will try to reach the central station.
Note:Note: This entry is applicable to both Receiver 1 and Receiver 2.
3.5 Dial Features3.5 Dial Features
This section determines the characteristics of the dialing features.
3.5.1 Touch Tone / Rotary
TOUCH TONE
NO 0=NO 1=YES
Select whether the SMDC will attempt to dial in a Touch Tone or Rotary format.
(see 3.5.2 Rotary Fallback).
3.5.2 Fallback on Rotary
ROTARY BACKUP
NO 0=NO 1=YES
You may select to have the SMDC “fallback” on rotary dialing should the signal
fail to reach the central station after the first Touch Tone attempt.
NoteNote: All dialing attempts after the first Touch tone attempt will be rotary.
3.5.3 Delay Before Dial
DIAL DELAY
00 seconds
Enter the appropriate amount of time to delay the communication of burglary alarm signals
to the central station to allow the user to abort the alarm transmission.
NoteNote: This entry does not effect Fire alarms, Keypad Emergency or Duress alarms.
Selections: Yes / No
Default: No
Selections: Yes /No
Default: No
Selections: 1-15
Default: 5
Selections: 1=TT, 0=Rotary
Default: TT
Selections: Yes / No
Default: No
Selections: 0-99 seconds
Default: 00 seconds
3. Receivers
1. Select Receiver #
1. Receiver 1
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. Receiver 2
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. # of Telco Lines
3. Tel. Monitor Opt.
1. Monitor Both Lines
2. Keypad Audible
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
4. Number of Dial Att.
5. Dial Features
1. TouchTone/Rotary
2. Fallback on Rotary
3. Delay before
4. TLM fault time
5. Anti-Jam Time
6. Comm. Fail Code
7. TLM Report Codes
1. TLM Fault
2. TLM Restore
8. Rcvr Routing Options
1. Alarms
2. Open/Close
3. System
4. Partition #
1. Partition 1
2. Partition 2
3. Partition 3
4. Partition 4
5. Partition 5
6. Partition 6
7. Partition 7
3.5.4 TLM Fault Time
TLM FAULT TIME
01 x 20 secs
Selections: 0-99
Default: 1 x 20 seconds
Enter the period of time the phone line must be faulted before the SMDC will panel
will generate a TLM fault condition.
(see 3.7 TLM Report codes).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 26
3. Receivers3. Receivers
3.5 Dial Features3.5 Dial Features (continued)
3.5.5 Anti-Jam Time
ANTI JAM TIME
15 seconds
Select the amount of time required by your local telephone company to release the
line of an incoming call and produce dial tone for the next out going call.
Note:Note: Consult your phone company for the correct time as the amount of time varies
by phone company.
3.6 Comm Fail Report Code3.6 Comm Fail Report Code
COMM FAIL RPT
code NO
Select the Comm Fail report code that will be sent to the central station via the second
phone line or long range radio after the programmed number of dialing attempt on phone l
has been exhausted.
(see SIA-Contact ID-Hex charts pg 42 & 43).
3.7 TLM Report Codes3.7 TLM Report Codes
TLM (Telephone Line Monitor) Report Codes will be transmitted to the central station
on the remaining telephone line should a telephone line fault/restore condition occur for
approximately 30 seconds.
3.7.1 TLM Fault
TLM FAULT CODE
code NO
Select the TLM fault report code that will be transmitted to the central when telephone line
fault condition occurs. (see 3.5.4-TLM Fault Time).
(see SIA-Contact ID-Hex charts pg 42 & 43).
3.7.2 TLM Restore
TLM RESTORE CODE
code NO
Select the TLM restore report code that will be transmitted to the central when telephone line
fault condition has reset. (see 3.5.4-TLM Fault Time).
(see SIA-Contact ID-Hex charts pg 42 & 43).
3.8. Receiver Report Options3.8. Receiver Report Options
This section determines the destination of all reporting codes. Please note the following
chart for the selection for this options.
(see page 27 for additional information regarding routing).
Selections: Yes / No
Default: 15 seconds
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
3. Receivers
1. Select Receiver #
1. Receiver 1
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. Receiver 2
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. # of Telco Lines
3. Tel. Monitor Opt.
1. Monitor Both Lines
2. Keypad Audible
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
4. Number of Dial Att.
5. Dial Features
1. TouchTone/Rotary
2. Fallback on Rotary
3. Delay before
4. TLM fault time
5. Anti-Jam Time
6. Comm. Fail Code
7. TLM Report Codes
1. TLM Fault
2. TLM Restore
8. Rcvr Routing Options
1. Alarms
2. Open/Close
3. System
4. Partition #
1. Partition 1
2. Partition 2
3. Partition 3
4. Partition 4
5. Partition 5
6. Partition 6
7. Partition 7
1. Rcvr 1 only 6. Rcvr 2 + radio
2. Rcvr 2 only 7. Rcvr 2 back-up to 1 + radio
3. Rcvr 2 as a back-up for rcvr 1 8. Rcvr one and Rcvr two + radio
4. Both Rcvrs 9. Radio only
5. Rcvr 1 + radio
3.8.1 Alarms Codes
ALARM ROUTING =1
(Scrolling 1-4)
Selections: 1-4
Default: 1
Enter the number that correspond to the option that will determines how all the alarm
reporting codes will be transmitted to the central station.
Note:Note: You may only select receiver options 1 to 4 for alarms.
(see page 27 for additional information regarding routing).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 27
3. Receivers3. Receivers
3.8. Receiver Report Options3.8. Receiver Report Options
3.8.2 Open / Close Codes
OP/CL ROUTING =1
(Scrolling 1-9)
Enter the number that correspond to the option that will determines how all the Open/Close
reporting codes will be transmitted to the central station.
(see page 27 for additional information regarding routing).
3.8.3 System Codes
SYSTEM ROUTING =1
(Scrolling 1-9)
Enter the number that correspond to the option that will determines how all the System
reporting codes will be transmitted to the central station.
(see page 27 for additional information regarding routing).
3.8.4. Partition Routing Options
This section determines the destination of all reporting codes pertaining to each partition.
Please note the chart on the selection chart on the preceding page for this options.
Note:Note: this routing is applicable only in a Keypad Partitioned System.
SET PART NUMBER
PARTITION
Enter the partition number that you wish to program. Press ENTER, CLEAR.
3.8.4.1 Partition 1
PART -1 ROUTING =1
(Scrolling 1-9)
Enter the number that correspond to the option that will determines how the system
reporting codes will be transmitted to the central station.
(see page 27 for additional information regarding routing).
3.8.4.2 Partition 2 - Program in the same manner as Partition 1.
3.8.4.3 Partition 3 - Program in the same manner as Partition 1.
3.8.4.4 Partition 4 - Program in the same manner as Partition 1.
3.8.4.5 Partition 5 - Program in the same manner as Partition 1.
3.8.4.6 Partition 6 - Program in the same manner as Partition 1.
3.8.4.7 Partition 7 - Program in the same manner as Partition 1.
3.8.4.8 Partition 8 - Program in the same manner as Partition 1.
3.93.9 Radio OptionsRadio Options
This option determines the characteristics of the radio system.
(Additional hardware required)
Selections: 1-10 (10 = none)
Default: 1
Selections: 1-10 (10 = none)
Default: 1
Selections: 1-8
Default: Blank
Selections: 1-10 (10 = none)
Default: 1
3. Receivers
1. Select Receiver #
1. Receiver 1
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. Receiver 2
1. Telephone Number
2. Account #
1. Acct # Z01-Z40
2. Acct # Z41-Z80
3. Partition Acct
4. Common Account #
3. Formats
2. # of Telco Lines
3. Tel. Monitor Opt.
1. Monitor Both Lines
2. Keypad Audible
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
4. Number of Dial Att.
5. Dial Features
1. TouchTone/Rotary
2. Fallback on Rotary
3. Delay before
4. TLM fault time
5. Anti-Jam Time
6. Comm. Fail Code
7. TLM Report Codes
1. TLM Fault
2. TLM Restore
8. Rcvr Routing Options
1. Alarms
2. Open/Close
3. System
4. Partition #
1. Partition 1
2. Partition 2
3. Partition 3
4. Partition 4
5. Partition 5
6. Partition 6
7. Partition 7
3.9.1 Radio Attempt
RADIO ATTEMPTS
00
Select the number of radio attempts that will be made to transmit all signals to the central
station.
Note: Note: . The radio will not attempt further transmissions once the digital signal has been “kissed off”.
3.9.2 Radio First
RADIO FIRST
NO 0=NO 1=YES
Enable this option for the first radio signal to be transmitted to the central station prior to a digital
dialing attempt.
3.9.4 Radio Account Numbers
Do not program unless Optex Radio will be installed.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Selections: 00 - 10
Default: 00
Selections: Yes / No
Default: No
Page 28
3. Receivers3. Receivers
Receiver InformationReceiver Information
All central station receivers have different types of line cards that are capable of accepting or not accepting certain formats. Therefore it is recommended
that you contact the technical support group at your central station to determine the fastest and most reliable format available.
# Format Name Description
1 10PPS 3-1 10 pulses per second - 3 digit account number - 1 digit report code
2 10PPS 3-1 EXT 10 pulses per second - 3 digit account number - 1 digit report code w/ extended 2 digit
3 10PPS 4-1 10 pulses per second - 4 digit account number - 1 digit report code
4 10PPS 4-1 EXT 10 pulses per second - 4 digit account number - 1 digit report code w/ extended 2 digit
5 10PPS 4-2 10 pulses per second - 4 digit account number - 2 digit report code
6 20PPS 3-1 20 pulses per second - 3 digit account number - 1 digit report code
7 20PPS 3-1 EXT 20 pulses per second - 3 digit account number - 1 digit report code w/ extended 2 digit
8 20PPS 4-1 20 pulses per second - 4 digit account number - 1 digit report code
9 20PPS 4-1 EXT 20 pulses per second - 4 digit account number - 1 digit report code w/ extended 2 digit
10 20PPS 4-2 20 pulses per second - 4 digit account number - 2 digit report code
11 40PPS W/PARITY 40 pulses per second - 3 digit account number - 1 digit report code
12 VAR FSK 4-2 Tones (no pulses) - 4 digit account number - 2 digit report code
13 SIA LEVEL 1 Tone (no pulses) - 4 digit account number - zone type w/zone number in English
14 CONTACT ID Tone (no pulses) - 4 digit account number - zone type w/zone number in English
Accepted Receivers
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech- Ademco SK FBI
Varitech
Check w/central station
Check w/central station
Receiver Routing OptionsReceiver Routing Options
The chart below indicates all reporting options in alphabetical order and the individual receiver routing.
Report Codes Menu Rcvr
Routing
Report Codes Menu Rcvr
Routing
2-Wire Smk Alarm 4.6.1 3.8.1. Emergency Report 4.5.2 3.8.3.
2-Wire Smk Restore 4.6.3 3.8.1. Enter Install. Prog 5.2.8 3.8.3.
2-Wire Smk Trbl 4.6.2 3.8.1.
Abnormal Self Test 1.3.5 3.8.3.
Exit Error 5.2.5 3.8.2.
Exit Install. Prog. 5.2.9 3.8.3.
AC Fail 5.1.1 3.8.3. Force Arm 5.3.7 3.8.2.
AC Restore 5.1.2 3.8.3. Ground Fault 5.3.6 3.8.3.
Auto Arm Code 8.3.2 3.8.2.
Auto Arm Fail 8.3.3 3.8.2.
No Trip Code 2.8 3.8.3.
O/C Buffer Full 5.3.1 3.8.2.
Aux. Power Fail 5.3.4 3.8.3. O/C Buffer Over 5.3.2 3.8.2.
Aux. Power Restore 5.3.5 3.8.3. On Premise Arm 5.3.8 3.8.2.
Battery Low 5.1.3 3.8.3. Open Code (all) 6.4.1 3.8.2.
Battery Restore 5.1.4 3.8.3. Open Code (user) 6.4.3 3.8.2.
Bell Fault Restore 5.1.8 3.8.3. Open Exception 5.2.6 3.8.2.
Bell Fault Trouble 5.1.7 3.8.3. Open Restore 5.2.4 3.8.2.
Bell Restore 5.2.3 3.8.3.
Self Test 1.3.4 3.8.3.
Box Tamper 5.1.5 3.8.3. Special PIN 5.3.9 3.8.3.
Box Tamper Restore 5.1.6 3.8.3.
Bus Fault 5.2.1 3.8.3.
TLM Fault 3.7.1 3.8.3.
TLM Restore 3.7.2 3.8.3.
Bus Restore 5.2.2 3.8.3. Unauthorized User 5.3.3 3.8.3.
Close Code (all) 6.4.2 3.8.2.
Close Code (user) 6.4.4 3.8.2.
Close Exception 5.2.7 3.8.2.
Zone Alarm 2.3.1 3.8.1
Zone Bypass 2.3.3 3.8.1
Zone Cancel 2.3.4 3.8.1
Comm Fail 3.6 3.8.3. Zone Restore 2.3.5 3.8.1
Duress 5.1.9 3.8.3. Zone Trouble 2.3.2 3.8.1
Legend 3.8.1 = Alarm Codes / 3.8.2 = Open\Close Codes / 3.8.3 = System Codes
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 29
4. System Options4. System Options
4. System Options
4. INP-1 Function
4.1. Monitor Mode4.1. Monitor Mode
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
This section determines the various options that are available for Monitor Mode,
Walk Test, System Features, System Messages, Emergency, 2 Wire Smoke and
Force Arming capabilities. Within each of these sub-menus, select the necessary
options that are required for the installation.
Note:Note: see chart on page 29 for detailed operation.
4.1.1 Ack Required
ACKNOWLEDGE
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable to option if the outputs assigned to Monitor will be continuous or monetary
(monetary if Ack = no / continuous if Ack = yes)
4.1.2 Scroll Open Zones
SCROLL OPEN
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the non-secure zones will scroll on the keypad(s).
4.1.3 Scroll Bypass Zones
SCROLL BYPASS
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the keypads to scroll all bypassed zones while the SMDC
is in the Monitor mode. (see 2.7.4 Bypass Allowed).
4.1.4 Silent Monitor Mode
SILENT MODE
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for all of the installed keypads to be silent in the Monitor mode.
4.1.5 Auto Monitor on Disarm
MON ON DISARM
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to be automatically placed in the Monitor Mode
upon disarming.
Note:Note: This option will not function if an alarm condition has taken place during the
armed state.
4.1.6 PIN Entry Required
PIN REQUIRED
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option if the installation requires that an authorized user PIN be used to enter
the Monitor Mode.
NoteNote: This option should be set for yes if the keypad will be installed in a public access area.
4.1.7 Monitor Outputs
This sections determines which output(s) will activate when a zone is activated during
the Monitor Mode (see 2.7.8 Monitor).
4.1.7.1 Bell 1
BELL OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Bell 1 output when a Monitor Mode
zone is activated. (see 4.1.1 Ack Required).
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 30
4. System Options4. System Options
4. System Options
4. INP-1 Function
4.1. Monitor Mode4.1. Monitor Mode (continued)
4.1.7.2 Bell 2
BELL OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Bell 2 output when a Monitor Mode
zone is activated. (see 4.1.1 Ack Required).
4.1.7.3 Relay 1
RELAY OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Relay 1 output when a Monitor Mode
zone is activated. (see 4.1.1 Ack Required).
4.1.7.4 Relay 2
RELAY OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Relay 2 output when a Monitor Mode
zone is activated. (see 4.1.1 Ack Required).
4.1.7.5 PGM 1
PGM OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the PGM 1 output when a Monitor Mode
zone is activated. (see 4.1.1 Ack Required).
4.1.7.6 PGM 2
PGM OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the PGM 2 output when a Monitor Mode
zone is activated. (see 4.1.1 Ack Required).
4.1.7.7 PGM 3
PGM OUTPUT 3
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the PGM 3 output when a Monitor Mode
zone is activated. (see 4.1.1 Ack Required).
Monitor Mode OperationMonitor Mode Operation
Zone Type Prog’d Yes/No and Results KP Display
1. Entry Exit Yes = Monitor outputs only (no report) Yes
2. Perm. Instant Yes = Monitor outputs only (no report) Yes
3. Interior 1 Yes = Monitor outputs only (no report) Yes
4. Interior 2 Yes = Monitor outputs only (no report) Yes
5. Interior 3 Yes = Monitor outputs only (no report) Yes
6. 24 Hour Yes = Alarm Reported / alarm outputs activated Yes
7. Fire Yes = Alarm Reported / alarm outputs activated Yes
8. Day Zone Yes = Alarm Reported / alarm outputs activated Yes
9. Garage Yes = Monitor outputs only (no report) Yes
1. Entry Exit No = No Activation (no report) No
2. Perm. Instant No = No Activation (no report) No
3. Interior 1 No = No Activation (no report) No
4. Interior 2 No = No Activation (no report) No
5. Interior 3 No = No Activation (no report) No
6. 24 Hour No = Alarm Reported / alarm outputs activated No
7. Fire No = Alarm Reported / alarm outputs activated No
8. Day Zone No = Alarm Reported / alarm outputs activated No
9. Garage No = No Activation (no report) No
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 31
4. System Options4. System Options
4. System Options
4. INP-1 Function
4.2 Walk Test Mode4.2 Walk Test Mode
4.3 System Features4.3 System Features
This sections determines which output(s) will activate when a zone (programmed as a
Walk Test zone) is activated during a Walk Test. (See 2.7.7. Walk Test)
4.2.1 Bell 1
BELL OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Bell 1 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.2 Bell 2
BELL OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Bell 2 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.3 Relay 1
RELAY OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Relay 1 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.4 Relay 2
RELAY OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the Relay 2 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.5 PGM 1
PGM OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the PGM 1 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.6 PGM 2
PGM OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the PGM 2 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
4.2.7 PGM 3
PGM OUTPUT 3
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option for the SMDC to activate the PGM 3 output for 2 seconds (only)
when a zone is activated during a Walk Test. (see 2.7.7. Walk Test).
This section defines has the user may interact with the SMDC with history viewing
operation of the clock, power delays of the SMDC.
4.3.1 History View by User
HIST VIEW USER
YES 0=NO 1=YES
Selections: Yes / No
Default: Yes
Enable this option to allow the users to view all historical events that have occurred.
(see 0 Pager/Fax/Printer / users manual).
NoteNote: The SMDC control/communicator is able to log 512 total events.
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 32
4. System Options4. System Options
4. System Options
4. INP-1 Function
4.3. System Features4.3. System Features
(continued)
4.3.2 O/C View by User
OP/CL VIEW USER
YES 0=NO 1=YES
Enable this option to allow the users to view all opening and closing historical events that
have occurred. (see 0 Pager/Fax/Printer / users manual).
4.3.3 Silent Trouble
SILENT TRBL
NO 0=NO 1=YES
Enable this option for all SMPCs to be silent if a trouble condition occurs between the
hours of 9:00pm to 7:00am. Note: Not for Fire Alarm System Installations.
4.3.4 Not Used / Reserved for Future Use
Not Used / Reserved for
Future Use
4.3.5 50Hz / 60Hz
50 HZ
NO 0=NO 1=YES
Enable this option to allow the SMDC to operate on 60Hz or 50Hz
(see 1.4-Time Clock)
4.3.6 AC/Crystal Clock
CRYSTAL CLOCK
NO 0=NO 1=YES
Enable this option to allow the clock to operate on a crystal or AC cycles.
(see 1.4 Time Clock Options).
Note:Note: AC cycles will allow for a accurate clock operation.
4.3.7 Power Delay Time before Zone Processing
POWER UP DELAY
10 seconds
Enable this option to allow the SMDC to ignore the zone’s status upon the return
of AC and DC power.
Note: Note: This option is especially helpful when motion detectors or other powered devices
connected to the SMDC need a period of time to stabilize after power has restored to
the SMDC.
4.3.8 PIN Entry Required for Zone Scan
PIN FOR SCAN
YES 0=NO 1=YES
Enable this option to require an authorized user PIN to perform a zone scan.
(see User Manual for levels).
4.3.9. Threshold of Bad Codes
# OF BAD CODES
00
Enable this option to allow the SMDC to send an Unauthorized User report code to the
central station after the programmed number of consecutive unauthorized attempts to secure
a PIN has been entered at a keypad
(see 5.3.3 Unauthorized User report code).
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
Selections: 50Hz / 60Hz
Default: 60Hz
Selections: AC / Crystal
Default: AC
Selections: Blank, 01-99 seconds
Default: 10 seconds
Selections: Yes / No
Default: Yes
Selections: Blank, 1-99
Default: 00
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 33
4. System Options4. System Options
4. System Options
4. INP-1 Function
4.4. System Messages4.4. System Messages
4.5. Emergency4.5. Emergency
This section allows you to customize the text on the top and bottom line of the keypad during
normal and abnormal conditions. (see 1.4.3 Display Clock for User)
4.4.1 Top Line Display
Each of the eight available Groups / Partitions may have their own customized line of text
for the top line.
Note:Note: This text will be common to both Partitioning and Groups.
4.4. 1.1 Group / Partition 1
GRP-1 DISPLAY
GRP-1
Selections: Up to 16 characters
Default: GRP-#
Enter up to 16 characters as necessary for the top line of the keypad display.
(select words or letters from the chart on page 19).
4.4.1.2 Group / Partition 2 - Enter up to 16 characters as necessary.
4.4.1.3 Group / Partition 3 - Enter up to 16 characters as necessary.
4.4.1.4 Group / Partition 4 - Enter up to 16 characters as necessary.
4.4.1.5 Group / Partition 5 - Enter up to 16 characters as necessary.
4.4.1.6 Group / Partition 6 - Enter up to 16 characters as necessary.
4.4.1.7 Group / Partition 7 - Enter up to 16 characters as necessary.
4.4.1.8 Group / Partition 8 - Enter up to 16 characters as necessary.
4.4.2 Disarmed Normal Message
DIS NORM MSG
READY TO ARM
Selections: Up to 16 characters
Default: Ready To Arm
Enter up to 16 characters as necessary for the bottom line of the keypad display when
all zones are in a secured condition
(This text will be common to both Partitioning and Groups).
(select words or letters from the chart on page 19).
4.4.3 Disarmed Abnormal Message
DIS. ABN MSG
SECURE TO ARM
Selections: Up to 16 characters
Default: Secure To Arm
Enter up to 16 characters as necessary for the bottom line of the keypad display when zone(s)
are open or shorted. (This text will be common to both Partitions and Grps).
(select words or letters from the chart on page 19).
This option determines the characteristics of the keypad Emergency buttons.
4.5.1 Emergency Enable
EMER. ENABLE
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable to option to allow the Select Emergency keys on the SMDC to operate.
Note:Note: the buttons must be pressed simultaneously
(see 4.5.2 Emergency Code - 4.5.3 Emergency outputs)
4.5.2 Emergency Report Code
EMER. RPT CODE
code NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Enter the report code that will be transmitted to the central station when the Emergency
keys are pressed.
(see SIA-Contact ID-Hex charts on pg 42 & 43).
4.5.3 Bell 1
BELL OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to activate Bell 1 output when the Emergency keys have been activated.
(see 2.2.1-Cutoff Times / 4.5.1-Emergency Enable).
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 34
4. System Options4. System Options
4. System Options
4. INP-1 Function
4.5. Emergency (continued)4.5. Emergency (continued)
4.6. Two Wire Smoke4.6. Two Wire Smoke
4.5.4 Bell 2
BELL OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to activate Bell 2 output when the Emergency keys have been activated.
(see 2.2.1-Cutoff Times / 4.5.1-Emergency Enable).
4.5.5 Relay 1
RELAY OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to activate Relay 1 output when the Emergency keys have been activated.
(see 2.2.1-Cutoff Times / 4.5.1-Emergency Enable).
4.5.6 Relay 2
RELAY OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to activate Relay 2 output when the Emergency keys have been activated.
(see 2.2.1-Cutoff Times / 4.5.1-Emergency Enable).
4.5.7 PGM 1
PGM OUTPUT 1
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to activate PGM 1 output when the Emergency keys have been activated.
(see 2.2.1-Cutoff Times / 4.5.1-Emergency Enable).
4.5.8 PGM 2
PGM OUTPUT 2
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to activate PGM 2 output when the Emergency keys have been activated.
(see 2.2.1-Cutoff Times / 4.5.1-Emergency Enable).
4.5.9 PGM 3
PGM OUTPUT 3
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to activate PGM 3 output when the Emergency keys have been activated.
(see 2.2.1-Cutoff Times / 4.5.1-Emergency Enable).
This section determines the characteristics of the 2 wire smoke detector The maximum
number of 2 wire smoke detectors connected to this loop may not exceed 10 for UL
installations. Please refer to the SMDC Hookup Diagram for the compatibility listing
of 2 wire smoke detectors.
4.6.1 Alarm Report Code
ALARM RPT CODE
code NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the report code that will be transmitted to the central station when an alarm condition
is sensed on the 2 wire smoke detector circuit. (see wiring diagram / 3.8.3-Rcvr Routing /
SIA-Contact ID-Hex charts on pg 42 & 43).
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 35
4. System Options4. System Options
4. System Options
4. INP-1 Function
4.6. Two Wire Smoke4.6. Two Wire Smoke
(continued)(continued)
4.6.2 Trouble Report Code
TRBL RPT CODE
code NO
Select the report code that will be transmitted to the central station when a trouble condition
is sensed on the 2 wire smoke detector circuit. (see wiring diagram / 3.8.3-Rcvr Routing).
(see SIA-Contact ID-Hex charts on pg 42 & 43).
4.6.3 Restore Report Code
RESTORE CODE
code NO
Select the report code that will be transmitted to the central station when a trouble condition
has restored from an alarm or trouble condition on the 2 wire smoke detector circuit.
(see wiring diagram / 3.8.3-Rcvr Routing).
(see SIA-Contact ID-Hex charts on pg 42 & 43).
4.6.4 Smoke Reset Time
SMOKE RES. TIME
15 seconds
Select the amount of time in seconds that is required by the manufacturer of the 2 wire
smoke detectors to perform a reset from an alarm condition.
Note: Note: consult the manual for the smoke detectors for the correct value of time for this
memory location.
4.6.5 Alarm Verification
ALARM VERIFY
NO 0=NO 1=YES
Enable this option to allow for the SMDC to drop power to the 2 wire smoke zone for
10 seconds (+ / - ) when an alarm condition is sensed. The SMDC will initiate a fire
alarm condition if the alarm condition is still present or if the circuit has secured and
another alarm condition is sensed within 60 seconds.
4.6.6 Outputs
Select the output(s) that will be active when the 2 wire smoke zone is in alarm condition.
(see 1.2 Cut Off Times)
4.6.6.1 Bell 1
BELL OUTPUT 1
YES 0=NO 1=YES
Enable this option for the SMDC to activate an output from Bell 1 when this circuit
initiates an alarm condition. (see 1.2 Cut Off Times).
4.6.6.2 Bell 1 Pulse
BELL 1 PULSE
YES 0=NO 1=YES
Enable this option for the SMDC to activate a pulsed output from Bell 1 when this
circuit initiates an alarm condition. (see 1.2 Cut Off Times).
NoteNote: Bell 1 output must be programmed as YES for this the Pulse Bell option to function.
4.6.6.3 Bell 2
BELL OUTPUT 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate an output from Bell 2 when this circuit
initiates an alarm condition. (see 1.2 Cut Off Times).
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-20 seconds
Default: 15 seconds
Selections: Yes / No
Default: No
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: Yes
Selections: Yes / No
Default: No
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 36
4. System Options4. System Options
4. System Options
4. INP-1 Function
4.6. Two Wire Smoke4.6. Two Wire Smoke
4.7. Force Arming Enabled4.7. Force Arming Enabled
4.8. PGM / INP Functions4.8. PGM / INP Functions
(continued)(continued)
4.6.6.4 Bell 2 Pulse
BELL 2 PULSE
NO 0=NO 1=YES
Enable this option for the SMDC to activate a pulsed output from Bell 2 when this
circuit initiates an alarm condition. (see 1.2 Cut Off Times).
NoteNote: Bell 2 output must be programmed as YES for this the Pulse Bell option to function.
4.6.6.5 Relay 1
RELAY OUTPUT 1
NO 0=NO 1=YES
Enable this option for the SMDC to activate an output from Relay 1 when this circuit
initiates an alarm condition. (see 1.2 Cut Off Times).
4.6.6.6 Relay 2
RELAY OUTPUT 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate an output from Relay 2 when this circuit
initiates an alarm condition. (see 1.2 Cut Off Times).
4.6.6.7 PGM 1
PGM OUTPUT 1
NO 0=NO 1=YES
Enable this option for the SMDC to activate an output from PGM 1 when this circuit
initiates an alarm condition. (see 1.2 Cut Off Times).
4.6.6.8 PGM 2
PGM OUTPUT 2
NO 0=NO 1=YES
Enable this option for the SMDC to activate an output from PGM 2 when this circuit
initiates an alarm condition. (see 1.2 Cut Off Times).
4.6.6.9 PGM 3
PGM OUTPUT 3
NO 0=NO 1=YES
Enable this option for the SMDC to activate an output from PGM 2 when this circuit
initiates an alarm condition. (see 1.2 Cut Off Times).
FORCE ARMING
NO 0=NO 1=YES
Enable this option to allow the user of the SMDC to Force Arm non secure zones.
There are two methods of FORCE ARMING:
1. Zones that are forced armed will be permanently bypassed until the SMDC has been
disarmed if the zone has been programmed as bypassable.
2. Zones that are forced armed will become part of the alarm system if they return to a
normal condition during the armed period if the zone has been programmed as not bypassable.
(see 2.1.7.4-Bypassed Allowed).
These programming menus allow the customizing of the PGM outputs, Aux Inputs and the
Radio terminals to perform various functions.
4.8.1 PGM 1 Functions
PGM-1 FUNCTION
NO
Select one of the options from the PGM list on page 37. (see wiring diagram).
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: 01- 40
Default: No
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 37
4. System Options4. System Options
4. System Options
4. INP-1 Function
4.8. PGM / INP Functions (continued)4.8. PGM / INP Functions (continued)
4.9. Temporal Fire
4.8.2 PGM 2 Functions
PGM-2 FUNCTION
NO
Selections: 01- 40
Default: No
Select one of the options from the PGM list on page 37. (see wiring diagram).
4.8.3 PGM 3 Functions
PGM-3 FUNCTION
NO
Selections: 01- 40
Default: No
Select one of the options from the PGM list on page 37. (see wiring diagram).
4.8.4 Auxiliary Input 1
INP-1 FUNCTION
NO
Selections: 00 - 10
Default: no
Select one of the options from the Input list on page 37. (see wiring diagram).
4.8.5 Auxiliary Input 2
INP-2 FUNCTION
NO
Selections: 00 - 10
Default: no
Select one of the options from the Input list on page 37. (see wiring diagram).
4.8.6 LED 1 Function
LED-1 FUNCTION
NO
Selections: 00 - 40
Default: no
Select one of the options from the PGM list on page 37 to allow LED 1 output to
operate as PGM output. (see wiring diagram).
4.8.7 LED 2 Function
LED-2 FUNCTION
NO
Selections: 00 - 40
Default: no
Select one of the options from the PGM list on page 37 to allow LED 2 output to
operate as PGM output. (see wiring diagram).
4.8.8 Radio Transmit Function
R-TX FUNCTION
NO
Selections: 00 - 40
Default: no
Select one of the options from the PGM list on page 37 to allow Radio TX output to
operate as PGM output. (see wiring diagram).
4.8.9 Radio Key Function
R-KEY FUNCTION
NO
Selections: 00 - 40
Default: no
Select one of the options from the PGM list on page 37 to allow Radio Key output to
operate as PGM output. (see wiring diagram).
TEMPORAL FIRE
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to allow for a unique output to be presented on the Fire bell voltage
circuit. The output cycle will be:
1/2 second on
1/2 second off
1/2 second on
1/2 second off
1/2 second on
2 1/2 second off
and will repeat the above cycle until the bell cutoff time has expired.
(see 1.2 Cut Off Times)
1. Monitor Mode
1. Ack Required
2. Scroll Open Zones
3. Scroll Bypass
4. Silent Mon. Mode
5. Auto Mon on Disarm
6. PIN Entry Required
7. Outputs
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
2. Walk Test Mode
1. Bell 1
2. Bell 2
3. Relay 1
4. Relay 2
5. PGM 1
6. PGM 2
7. PGM 3
3. System Features
1. Hist. View by User
2. O/C View by User
3. Silent Trouble
4. Not Used - Reserved
5. 50Hz/60Hz
6. AC/Crystal
7. Pwr Dly Time
8. PIN Require for Scan
9. Threshold Bad Codes
4. System Messages
1. Top Line Display
1. Grp/Part 1 Display
7-8. Group/Part Display
2. Disarmed Nml Msg
3. Disarmed Abnml Msg
5. Emergency
1. Emergency Enabled
2. Emergency Rpt
3. Bell 1 Output
4. Bell 2 Output
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
6. 2 Wire Smk
1. Alarm Report
2. Trouble Report
3. Smoke Restore
4. Smoke Reset
5. Alarm Verify
6. Outputs
1. Bell 1 Output
2. Bell 1 Pulse
3. Bell 2 Output
4. Bell 2 Pulse
5. Relay 1 Output
6. Relay 2 Output
7. PGM 1 Output
8. PGM 2 Output
9. PGM 3 Output
7. Force Arming Enabled
8. PGM / INP Functions
1. PGM 1 Function
2. PGM 2 Function
3. PGM 3 Function
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 38
4. System Options4. System Options
PGM Options PGM Options PGM OptionsPGM Options
Prog.
Selection
01 Partition 1 Arm/Disarm status
02 Partition 2 Arm/Disarm status
03 Partition 3 Arm/Disarm status
04 Partition 4 Arm/Disarm status
05 Partition 5 Arm/Disarm status
06 Partition 6 Arm/Disarm status
07 Partition 7 Arm/Disarm status
08 Partition 8 Arm/Disarm status
09 Communication Fail
10 Not Used - Reserved for Future Use
11 Entry/Exit Status Indicator for Partition 1
12 Entry/Exit Status Indicator for Partition 2
13 Entry/Exit Status Indicator for Partition 3
14 Entry/Exit Status Indicator for Partition 4
15 Entry/Exit Status Indicator for Partition 5
16 Entry/Exit Status Indicator for Partition 6
17 Entry/Exit Status Indicator for Partition 7
18 Entry/Exit Status Indicator for Partition 8
19 Not Used - Reserved for Future Use
20
Note:Note:
01 - 08 The voltage will be present when a partition (not group) is armed and will be removed when the partition is disarmed.
11 - 18 The voltage will be present for the period of time programmed for the entry / exit delay period. This voltage will be steady.
21 - 38 The voltage will be present at the end of the open window and will be removed at the end of the close window.
Ground Start (Note: See wiring diagram for
installation)
Function
Prog.
Selection
21 Timer Function for Partition 1 Schedule 1
22 Timer Function for Partition 2 Schedule 1
23 Timer Function for Partition 3 Schedule 1
24 Timer Function for Partition 4 Schedule 1
25 Timer Function for Partition 5 Schedule 1
26 Timer Function for Partition 6 Schedule 1
27 Timer Function for Partition 7 Schedule 1
28 Timer Function for Partition 8 Schedule 1
29 Follows Open / Close Exception
30 Follows TLM fault
31 Timer Function for Partition 1 Schedule 2
32 Timer Function for Partition 2 Schedule 2
33 Timer Function for Partition 3 Schedule 2
34 Timer Function for Partition 4 Schedule 2
35 Timer Function for Partition 5 Schedule 2
36 Timer Function for Partition 6 Schedule 2
37 Timer Function for Partition 7 Schedule 2
38 Timer Function for Partition 8 Schedule 2
39 Not Used - Reserved for Future Use
40
Cutoff Times change to a 10 second
multiplier. (except bells) with this entry
Function
Input Options
Prog.
Selection
00 Disabled
01 Allows for the selected PGM to be used for a momentary input for arming / disarming for partition 1
02 Allows for the selected PGM to be used for a momentary input for arming / disarming for partition 2
03 Allows for the selected PGM to be used for a momentary input for arming / disarming for partition 3
04 Allows for the selected PGM to be used for a momentary input for arming / disarming for partition 4
05 Allows for the selected PGM to be used for a momentary input for arming / disarming for partition 5
06 Allows for the selected PGM to be used for a momentary input for arming / disarming for partition 6
07 Allows for the selected PGM to be used for a momentary input for arming / disarming for partition 7
08 Allows for the selected PGM to be used for a momentary input for arming / disarming for partition 8
09* Allows for the selected PGM to be used for a momentary input for arm for a non partition SMDC
10* Allows for the selected PGM to be used for a momentary input for disarm for a non partition SMDC
11-99 Not used - reserved for future use
*NoteNote: The SMDC also has the provision for a monetary input for arming/disarming a non partition SMDC.
(see wiring diagram).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Function
38 of 59
Page 39
5. Report Codes5. Report Codes
This section addresses the report codes for all the ancillary functions. This menu
consists of three sub-menus: Report Code Menu 1, Report Code Menu 2, and
Report Code Menu 3.
(see the SIA-Contact ID-Hex information charts on page 42 & 43).
5.1. Report Code Menu 15.1. Report Code Menu 1
Program the appropriate report codes for the following options.
5.1.1 AC Fail
AC FAILURE
code: NO
Select the AC fail report code that will be transmitted to the central station when an AC Fail
condition occurs and the AC fail timer expires. (see 1.1.4- AC Fail Delay / 1.1.5 AC Display /
3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
5.1.2 AC Restore
AC RESTORE
code: NO
Select the AC Restore report code that will be transmitted to the central station when an
the AC power has been restored. (see Wiring diagram / 3.8.3-Rcvr Routing / SIA-
Contact ID-Hex chart on page 42 & 43).
5.1.3 Low Battery
LOW BATTERY
code: NO
Select the Low Battery report code that will be transmitted to the central station when
the voltage on the battery drops below 11.45 Vdc. (3.8.3-Rcvr Routing / SIA-Contact ID-Hex
chart on page 42 & 43).
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
5. Report codes
1. Report Code Menu 1
1. AC Fail
2. AC Restore
3. Low Battery
4. Battery Restore
5. Box Tamper
6. Box Tamper Restore
7. Bell Fault Trouble
8. Bell Fault Restore
9. Duress
2. Report Code Menu 2
1. Bus Fault
2. Bus Restore
3. Bell Restore
4. Open Restore
5. Exit Error
6. Open Exception
7. Close Exception
8. Enter Inst. Program
9. Exit Inst. Program
3. Report Code Menu 3
1. O/C Buffer Full
2. O/C Buffer Overflow
3. Unauthorized User
4. Aux Power Fail
5. Aux Power Restore
6. Ground Fault
5.1.4 Battery Restore
BATTERY RESTORE
code: NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the Low Battery report code that will be transmitted to the central station when
the voltage on the battery reaches 11.85 Vdc. (see Wiring diagram / 3.8.3-Rcvr Routing /
SIA-Contact ID-Hex chart on page 42 & 43).
5.1.5 Box Tamper
BOX TAMPER
code: NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the Box Tamper report code that will be transmitted to the central station.
(see Wiring diagram / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
5.1.6 Box Tamper Restore
BOX TAMPER REST.
code: NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the Box Tamper Restore report code that will be transmitted to the central station.
(see Wiring diagram / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
5.1.7 Bell Fault Trouble
BELL TROUBLE
code: NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the Bell Fault Trouble report code that will be transmitted to the central station
when the SMDC detects a trouble condition on the Bell 1 circuit.
(see Wiring diagram / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
39 of 59
Page 40
5. Report Codes5. Report Codes
5.1. Report Code Menu 1 (continued)5.1. Report Code Menu 1 (continued)
5.1.8 Bell Trouble Restore
BELL TRBL REST
code: NO
Select the Bell Trouble Restore report code that will be transmitted to the central station
when the SMDC detects a restore condition on Bell 1’s circuit. (see Wiring diagram /
3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
5.1.9 Duress
DURESS RPT CODE
code: NO
Select the Duress report code that will be transmitted to the central station when the Duress
PIN number is entered at any of the keypads. (see 3.8.3-Rcvr Routing / 6.2-PIN Numbers /
SIA-Contact ID-Hex chart on page 42 & 43).
5.2. Report Code Menu 25.2. Report Code Menu 2
Program the appropriate report codes for the following options.
5.2.1 Bus Fault
BUS FAULT
code: NO
Select the Bus Fault report code that will be transmitted to the central station when the
control panel has sensed a trouble condition on either the Omnet Bus (used for expansion
modules) or the Keypad Bus. (see Wiring diagram / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex
chart on page 42 & 43).
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
5. Report codes
1. Report Code Menu 1
1. AC Fail
2. AC Restore
3. Low Battery
4. Battery Restore
5. Box Tamper
6. Box Tamper Restore
7. Bell Fault Trouble
8. Bell Fault Restore
9. Duress
2. Report Code Menu 2
1. Bus Fault
2. Bus Restore
3. Bell Restore
4. Open Restore
5. Exit Error
6. Open Exception
7. Close Exception
8. Enter Inst. Program
9. Exit Inst. Program
3. Report Code Menu 3
1. O/C Buffer Full
2. O/C Buffer Overflow
3. Unauthorized User
4. Aux Power Fail
5. Aux Power Restore
6. Ground Fault
5.2.2 Bus Restore
BUS RESTORE
code: NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the Bus Restore report code that will be transmitted when the Omnet or Keypad
bus restores to a normal condition. (see Wiring diagram / 3.8.3-Rcvr Routing /
SIA-Contact ID-Hex chart on page 42 & 43).
5.2.3 Bell Restore
BELL RESTORE
code: NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the Bell Restore report code that will be transmitted to the central station when after the
bell circuit has reset and the circuit that initiated the activation has been restored to a normal
condition. This code is common for both bell outputs. (see Wiring diagram / 3.8.3-Rcvr Routing /
SIA-Contact ID-Hex chart on page 42 & 43).
5.2.4 Open Restore
OPEN RESTORE
code: NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the Open Restore report code that will be transmitted to the central station when the control
panel has been disarmed after an alarm condition.
Note:Note: The circuit that caused the alarm condition must be in a secure condition before this report
will be transmitted.
(see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
5.2.5 Exit Error
EXIT ERROR
code: NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the Exit Error code that will be transmitted to the central station when an Entry/Exit
zone has been left open after the exit time has expired.
(see 1.2 Exit Delay Time / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
40 of 59
Page 41
5. Report Codes5. Report Codes
5.2. Report Code Menu 2 (continued)5.2. Report Code Menu 2 (continued)
5.2.6 Open Exception
OPEN EXCEPTION
code: NO
Select the Open Exception report code that will be transmitted to the central station when
the SMDC has not been disarmed by the end of the opening window.
(see 3.8.3-Rcvr Routing / 8-Schedules / SIA-Contact ID-Hex chart on page 42 & 43).
5.2.7 Close Exception
CLOSE EXCEPTION
code: NO
Select the Close Exception report code that will be transmitted to the central station when
the SMDC has not been armed by the end of the closing window. (see 3.8.3-Rcvr Routing /
8-Schedules / SIA-Contact ID-Hex chart on page 42 & 43).
5.2.8 Enter Installer Program
ENTER INST PROG
code: NO
Select the Enter Installer Program report code that will be transmitted to the central station
when the SMDC’s Installation program is accessed. (see 6.1-Installers PIN /
3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
5.2.9 Exit Installer Program
EXIT INST PROG
code: NO
Select the Exit Installer Program report code that will be transmitted to the central station
when the SMDC’s Installation program is exited. (see 6.1-Installers PIN /
3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
5. Report codes
1. Report Code Menu 1
1. AC Fail
2. AC Restore
3. Low Battery
4. Battery Restore
5. Box Tamper
6. Box Tamper Restore
7. Bell Fault Trouble
8. Bell Fault Restore
9. Duress
2. Report Code Menu 2
1. Bus Fault
2. Bus Restore
3. Bell Restore
4. Open Restore
5. Exit Error
6. Open Exception
7. Close Exception
8. Enter Inst. Program
9. Exit Inst. Program
3. Report Code Menu 3
1. O/C Buffer Full
2. O/C Buffer Overflow
3. Unauthorized User
4. Aux Power Fail
5. Aux Power Restore
6. Ground Fault
5.3. Report Code Menu 35.3. Report Code Menu 3
Program the appropriate report codes for the following options.
5.3.1 O/C Buffer Full
O/C BUFFER FULL
code: NO
Select the O/C Buffer Full report code that will be transmitted to the central station when the
Opening and Closing event buffer reaches 384 events. (see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex
chart on page 42 & 43).
5.3.2 O/C Buffer Overflow
O/C OVERFLOW
code: NO
Select the O/C Buffer Full report code that will be transmitted to the central station when the
Opening and Closing event buffer exceeds 512 events. (see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex
chart on page 42 & 43).
5.3.3 Unauthorized User
UNAUTH. USER
code: NO
Select the Unauthorized User report code that will be transmitted to the central station after a number
of consecutive unauthorized PIN numbers have been entered at a keypad
(see 4.9-Threshold of Bad Codes / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
41 of 59
Page 42
5. Report Codes5. Report Codes
5.3 Report Code Menu 3 (continued)5.3 Report Code Menu 3 (continued)
5.3.4 Aux. Power Fail
AUX. POWER FAIL
code: NO
Select the Aux. Power Fail report code that will be transmitted to central station when the
SMDC failure of Aux. power. (see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on
page 42 & 43).
5.3.5 Aux. Power Restore
AUX. POWER REST
code: NO
Select the Aux. Power Restore report code that will be transmitted to central station when the
Auxiliary Power is restored (see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on
page 42 & 43).
5.3.6 Ground Fault Code
GND FAULT CODE
code: NO
Select the Ground Fault Code report that will be transmitted to central station when a ground
is detected on any of the zone inputs or if the ground is removed from the SMDC.
(see wiring diagram / 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43).
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
5. Report codes
1. Report Code Menu 1
1. AC Fail
2. AC Restore
3. Low Battery
4. Battery Restore
5. Box Tamper
6. Box Tamper Restore
7. Bell Fault Trouble
8. Bell Fault Restore
9. Duress
2. Report Code Menu 2
1. Bus Fault
2. Bus Restore
3. Bell Restore
4. Open Restore
5. Exit Error
6. Open Exception
7. Close Exception
8. Enter Inst. Program
9. Exit Inst. Program
3. Report Code Menu 3
1. O/C Buffer Full
2. O/C Buffer Overflow
3. Unauthorized User
4. Aux Power Fail
5. Aux Power Restore
6. Ground Fault
5.3.7 Force Arm Code
FORCE ARM CODE
code: NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the Force Arm Code report code that will be transmitted to central station when a
PIN has been used to force arm/disarm the control panel.
(see 3.8.3-Rcvr Routing / 4.7-Force Arm Enabled / SIA-Contact ID-Hex chart on page 42 & 43 /
User Manual).
5.3.8 On Premise Report Code
ON PREM CODE
code NO
Selections: 01-FF / Contact ID / SIA
Default: No Report
Select the On Premise Report Code report code that will be transmitted to central station
when the SMDC has been armed in the Stay or Instant mode.
(see 3.8.3-Rcvr Routing / SIA-Contact ID-Hex chart on page 42 & 43 / User Manual).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
42 of 59
Page 43
5. Report Codes
Contact ID Reporting OptionsContact ID Reporting Options
Report
Function
24 Hour Burg. any zone 133 43
2-Wire Smk Alarm 4.6.1 111
2-Wire Smk Restore 4.6.3 111 * Force Arm 5.3.7 400 *
2-Wire Smk Trbl 4.6.2
Abnormal Self Test 1.3.5
AC Fail 5.1.1 301 * Interior Alarm any zone 132 42
AC Restore 5.1.2 301 * No Trip Code 2.8 102
Audible Panic any zone
Auto Arm Code 8.3.2
Auto Arm Fail 8.3.3
Aux. Power Fail 5.3.4 300 * Open Code (all) 6.4.1 401 *
Aux. Power Restore 5.3.5 300 * Open Code (user) 6.4.3 401 *
Battery Low 5.1.3 302 * Open Exception 5.2.6 453 *
Battery Restore 5.1.4 302 * Open Restore 5.2.4 400 *
Bell Fault Restore 5.1.8 321 *
Bell Fault Trouble 5.1.7 321 *
Bell Restore 5.2.3
Box Tamper zone or 5.1.5 137
Box Tamper Restore zone or 5.1.6
Bus Fault 5.2.1
Bus Restore 5.2.2 333 *
Close Code (all) 6.4.2
Close Code (user) 6.4.4
Close Exception 5.2.7
Comm Fail 3.6 350
Duress 5.1.9 121 47 Water flow any zone 113 4A
Day / Night any zone 135 45 Zone Alarm 2.3.1 130
Emerg (panic) Report 4.5.2 120
Enter Install. Prog 5.2.8 627 *
Exit Error 5.2.5 374 *
Exit Install. Prog. 5.2.9 628 *
* use any entry other than 00
Use the number on the above chart that is designated for a particular report function.
Menu Contact
ID Report
373 * Ground Fault 5.3.6 310 *
608 * Group Close 9.2.1. 402 *
123 49 O/C Buffer Full 5.3.1 622 *
403 * O/C Buffer Over 5.3.2 624 *
455 * On Premise Arm 5.3.8 441 *
000
137 *
333
401 Temp Sch Change TBA 631
401
454
Prog Report
Function
Fire Alarm any zone 110 *
* Fire Sup any zone 200 4B
Perimeter Alarm any zone 131 41
Perm Sch Change TBA 631
*
46 Silent Tamper (silent) any zone 122 48
*
*
*
* Unauthorized User 5.3.3 421 *
*
Self Test 1.3.4 602
Tamper Alarm any zone 137 46
Tamper Restore any zone 137
TLM Fault 3.7.1 351
TLM Restore 3.7.2 351
Zone Bypass 2.3.3 570
Zone Cancel 2.3.4 406
Zone Restore 2.3.5 130
Zone Trouble 2.3.2 370
Menu Contact
ID Report
Prog
*
*
*
*
*
*
*
*
*
*
*
*
Hexadecimal Chart
Hexadecimal Letter Keypad Button
A AWAY
B STAY
C INSTANT
D MEMORY
E PROGRAM
F MONITOR
Depress the appropriate keypad button for the desired hexadecimal character.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
43 of 59
Page 44
5. Report Codes
SIA Custom Reporting Program
Report
Function
24 Hour Burg. any zone BA *
2-Wire Smk Alarm 4.6.1 FA
2-Wire Smk Restore 4.6.3 FR * Group Close 9.2.1. CG *
2-Wire Smk Trbl 4.6.2
Abnormal Self Test 1.3.5
AC Fail 5.1.1 AT * Interior Alarm any zone BA *
AC Restore 5.1.2 AR * Medical any zone MA 4D
Audible Panic any zone
Auto Arm Code 8.3.2
Auto Arm Fail 8.3.3
Aux. Power Fail 5.3.4 YP * On Premise Arm 5.3.8 CL *
Aux. Power Restore 5.3.5 YQ * Open Code (all) 6.4.1 OP *
Battery Low 5.1.3 YT * Open Code (user) 6.4.3 OP *
Battery Restore 5.1.4 YR * Open Exception 5.2.6 OI *
Bell Fault Restore 5.1.8 YR * Open Restore 5.2.4 OR *
Bell Fault Trouble 5.1.7 YA *
Bell Restore 5.2.3
Box Tamper zone or 5.1.5 TA
Box Tamper Restore zone or 5.1.6
Bus Fault 5.2.1
Bus Restore 5.2.2 ER *
Close Code (all) 6.4.2
Close Code (user) 6.4.4
Close Exception 5.2.7
Comm Fail 3.6 YC
Duress 5.1.9 HA * TLM Restore 3.7.2 LR
Day / Night any zone BA *
Emergency Report 4.5.2 PA
Enter Install. Prog 5.2.8 LB *
Exit Error 5.2.5 EE *
Exit Install. Prog. 5.2.9 LS *
Fire Alarm any zone FA *
Force Arm 5.3.7 CF *
Freezer Alarm any zone ZA 5A
* use any entry other than 00 Use the number on the above chart that is designated for a particular report function.
Menu SIA
Report
FT * Heat alarm any zone KA 4B
RP * Hold Up any zone HA 48
PA * No Trip Code 2.8 UY *
CA * O/C Buffer Full 5.3.1 JL *
CI * O/C Buffer Over 5.3.2 JO *
UR
TR * Self Test 1.3.4 RP
ET
CL * Tamper Alarm any zone TA 54
CL
CI
Pro
g
* Ground Fault 5.3.6 UT *
*
* Perm Sch Change tba JS
* *
*
*
*
51
Report
Function
Gas Alarm any zone GA 46
Panic Alarm any zone PA 50
Perimeter Alarm any zone BA *
Sprinkler Alarm any zone SA 53
Tamper Restore any zone TR
Temp Sch Change tba JS
TLM Fault 3.7.1 LT
Unauthorized User 5.3.3 JA *
Water flow any zone WA 57
Zone Alarm 2.3.1 BA
Zone Bypass 2.3.3 BB
Zone Cancel 2.3.4 BC
Zone Restore 2.3.5 BR
Zone Trouble 2.3.2 BT
Menu SIA
Report
Prog
*
*
*
*
*
*
*
*
*
*
*
Outputs Options and Programming Locations
Prog.
Menu
2 Wire Smoke
AC Fail
Bell Ringback
Bell Test
Duress
Emergency
Monitor
PC Ringback
Special PIN
Telco Fault
Walk Test
Zone Alarm
Zone Trbl
4.6.
1.5
6.4.6
6.4.7.
6.2. & 4.5.3.
4.5
4.1
6.4.5.
6.3.2.
3.3.
4.2.
2.8.
2.2.
Prog = Programmable Y/N no = not available on = cannot be disabled
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Bell 1 Bell 2 Relay1Relay2PGM1PGM2PGM3Keypa
Prog. Prog. Prog. Prog. Prog. Prog. Prog. no
no no no no no no no Prog
no Prog. no no no no no no
no Prog. no no no no no no
Prog. Prog. Prog. Prog. Prog. Prog. Prog. no
Prog. Prog. Prog. Prog. Prog. Prog. Prog. no
Prog. Prog. Prog. Prog. Prog. Prog. Prog. Prog.
no no no no no no no Prog.
no no Prog. Prog. Prog. Prog. Prog. no
Prog. Prog. Prog. Prog. Prog. Prog. Prog. Prog.
Prog. Prog. Prog. Prog. Prog. Prog. Prog. on
Prog. Prog. Prog. Prog. Prog. Prog. Prog. no
no no no no no no no on
d
44 of 59
Page 45
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
6. PIN Numbers6. PIN Numbers
6. PIN Numbers
5.Review PIN 1
The information in menu 6 has five sub menus: Installers PIN, Duress PIN Special PIN,
User Reporting and Hide PIN.
6.1 Installer PIN6.1 Installer PIN
INSTALLER PIN
9999
Enter the necessary Installer PIN to gain access to the Installer Program. This PIN may be
changed to protect sensitive information contained within the Installer Program.
Extreme WarningExtreme Warning: The panel must returned to Optex Inc. if this entry is unknown
or is lost. Please contact Optex Inc. for further information.
6.2 Duress PIN6.2 Duress PIN
DURESS PIN
(BLANK)
Enter the Duress PIN. Press RESET to delete this PIN.
Note: Note: The SMDC has a single Duress PIN available.
(see 5.1.9-Duress Report Code / User Manual).
6.3 Special PIN Features6.3 Special PIN Features
The SMDC has five unique Special PIN that may be used for a variety of applications
Note:Note: The Special PIN cannot be used as an arm/disarm PIN and is a maximum of four digits only.
6.3.1. Special PIN
SPECIAL PIN
(BLANK)
Enter the appropriate 4 digit special PIN. Press RESET to delete this PIN.
(see 6.3.2-Outputs).
Selections: 0000 - 9999
Default: 9999
Selections: 0000 - 9999
Default: Blank
Selections: 0000 - 9999
Default: Blank
1. Installer PIN
2. Duress PIN
3. Special PIN Features
1. Special PIN Number
2. Outputs
1. Relay 1
2. Relay 2
3 PGM 1
4 PGM 2
5. PGM 3
4. User Report Codes
1. All Open Code
2. All Close Code
3. User Open Code
4. User Close Code
5. PC Ringback
6. Bell Ringback
7. Bell Test
6.3.2
Select the necessary outputs for this Special PIN to activate.
6.3.2.1 Relay 1
Enable this option to activate Relay 1 output for approximately five seconds when the
Special PIN is entered.
(see 6.3.1-Special PINs).
6.3.2.2 Relay 2
Enable this option to activate Relay 2 output for approximately five seconds when the
Special PIN is entered.
(see 6.3.1-Special PINs).
OUTPUTS
(SCROLLING
RELAY OUTPUT 1
NO 0=NO 1=YES
RELAY OUTPUT 2
NO 0=NO 1=YES
Selections: 1-7
Default: Scrolling
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Page 46
6. PIN Numbers6. PIN Numbers
6. PIN Numbers
5.Review PIN 1
6.3 Special PIN Features6.3 Special PIN Features
6.3.2.3 PGM 1
PGM 1 OUTPUT
NO 0=NO 1=YES
Enable this option to activate PGM 1 output for approximately five seconds when the
Special PIN is entered.
(ee 6.3.1-Special PINs).
6.3.2.4 PGM 2
PGM OUTPUT 2
NO 0=NO 1=YES
Enable this option to activate PGM 2 output for approximately five seconds when the
Special PIN is entered.
(see 6.3.1-Special PINs).
6.3.2.5 PGM 3
PGM 3 OUTPUT
NO 0=NO 1=YES
Enable this option to activate PGM 3 output for approximately five seconds when the
Special PIN is entered.
(see 6.3.1-Special PINs).
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
1. Installer PIN
2. Duress PIN
3. Special PIN Features
1. Special PIN Number
2. Outputs
1. Relay 1
2. Relay 2
3 PGM 1
4 PGM 2
5. PGM 3
4. User Report Codes
1. All Open Code
2. All Close Code
3. User Open Code
4. User Close Code
5. PC Ringback
6. Bell Ringback
7. Bell Test
6.4. User Report Codes6.4. User Report Codes
All Open and Close Codes
This option allows for the same report code to be transmitted for all users.
If you wish to transmit unique report codes for each user (open/close by user)
Do Not program this option go to 6.4.3 User Open code and 6.4.4 User Close code.
WARNING:WARNING: Entering a report code in the all open and all close codes menus will
over write what has been programmed in 6.4.3 User Open code and 6.4.4 User Close code.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 47
6. PIN Numbers6. PIN Numbers
6. PIN Numbers
6.4.1 All Open Code
ALL OPEN CODE
code NO
Select the Open report code that will be transmitted for all users on disarm.
(see SIA-Contact ID-Hex chart on page 42 & 43). Note: Note: Press RESET to clear all Open codes.
Extreme Warning: Extreme Warning: Pressing RESET will also clear 6.4.3 User Open codes.
6.4.2 All Close Code
ALL CLOSE CODE
code NO
Select the report code that will be transmitted for all users on arming.
(see SIA-Contact ID-Hex chart on page 42 & 43). Note: Note: Press RESET to clear all Close codes.
Extreme Warning: Extreme Warning: Pressing RESET will also clear 6.4.4 User Close codes.
6.4.3. to 4. User Open and Close Report Codes6.4.3. to 4. User Open and Close Report Codes
User Open and Close Report codes allow for the transmission of a unique report code for
each user that will be arming and disarming the SMDC.
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
1. Installer PIN
2. Duress PIN
3. Special PIN Features
1. Special PIN Number
2. Outputs
1. Relay 1
2. Relay 2
3 PGM 1
4 PGM 2
5. PGM 3
4. User Report Codes
1. All Open Code
2. All Close Code
3. User Open Code
4. User Close Code
5. PC Ringback
6. Bell Ringback
7. Bell Test
The above display will be shown on the LCD after either 6.4.3 (User Open Code) or 6.4.4
(User Close Code) has been selected. Enter the user number that you wish to program (example:
User 1, press 1) followed by the ENTER key and CLEAR. Enter the two digit report code that
you wish to transmit for this user. Once your entry has been made press the CLEAR key to
return to the SET USER NUMBER prompt and continue in the same fashion until all the
desired users have been assigned a report code. (see SIA-Contact ID-Hex chart on page 42 & 43).
6.4.3. User Open Code
Select the User Open report code that will be transmitted to the central station.
6.4.4 User Close Code
Select the User Close report code that will be transmitted to the central station.
6.4.5 PC Ringback
Enable this option to energized an audible two second tone from all keypads once the
open and close report code has been received at the central station.
6.4.6 Bell Ringback
Enable this option to energized an audible two second tone from bell 2 (only)
once the open and close report code has been received at the central station. (see wiring diagram).
6.4.7 Bell Test
Enable this option to allow the SMDC to produce a two second output on bell 2 (only)
once the PIN has been entered and the arming mode has been selected. (see wiring diagram).
SET USER NUMBER
(BLANK)
US# OPEN CODE
code: NO
US# CLOSE CODE
code: NO
PC RINGBACK
NO 0=NO 1=YES
BELL RINGBACK
NO 0=NO 1=YES
BELL TEST
NO 0=NO 1=YES
Selections: 1-80
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
6.5. Review PIN 16.5. Review PIN 1
USER 1 PIN
1234
This option allows you to review user 1 PIN. (No programming allowed).
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Selections: No programming
Default: 1234
Page 48
7. C.S. Downloading7. C.S. Downloading
This section determines the parameters necessary for off/on-site programming using the
SRPU (Super Remote Programming Utility) software. Contact Tech Support at
Optex Inc. to obtain a copy of the SRPU software.
7.1 Phone Number7.1 Phone Number
PHONE NUMBER
(BLANK)
Enter the telephone number the SMDC will need dial in order to connect with
the computer modem that has the SRPU software loaded on it.
Note:Note: To delete this telephone number press RESET.
Dialer Chart
Selections: = 0 through 9
Instant Key = 3 second dial pause (appears as a “:”)
Memory Key = 5 second dial tone detect (appears as a “;”)
Stay Key = # (pound)
Away Key = * (asterisk)
7.2 Number of Rings7.2 Number of Rings
NUMBER OF RINGS
08
Enter the number of rings the SMDC will wait before automatically answering
the call placed by the computer with the SRPU software. If at the subscriber site another
device is connected to the same phone line (i.e.: an answering machine) that answers the call
prior to the ring count being reached, the SMDC will still listen for the lead in tone from the
SRPU software, and if the control panel recognizes the proper frequency, it will seize the
phone line from the devices that initially answered the call and begin communication. The
SMDC is able to communicate with the SRPU on either phone line connected to the panel
at the subscriber’s premise.
Selections: Up to 16 characters
Default: Blank
Selections: 0 - 15
Default: 08 (0 = disabled)
7. Downloader
1. Phone Number
2. Number of Rings
3. Caller ID Enable
4. Local Download PIN
5. Panel Access ID
7.3 Caller ID Enable7.3 Caller ID Enable
CALLER ID
NO O=NO 1=YES
Enable this option should the phone line connected to the SMDC have Caller ID service.
Note:Note: Caller ID service can in some instances can cause interfere with the operation of the
panel if the option is not enabled.
7.4 Local Download PIN7.4 Local Download PIN
LOCAL PIN
(BLANK)
Enable this option to allow for the Local Download PIN to initiate a remote programming
session from the keypad.
Note:Note: By entering this PIN number and then pressing the PROGRAM key enables the panel
to dial the phone number programmed in 7.1. To delete this number press RESET.
7.5 Panel Access ID7.5 Panel Access ID
PANEL ACCESS #
0000
Enable this option to allow the SRPU software to connect with the SMDC to determine if the
SMDC Access ID matches the SRPU Access ID. Programming is allowed once a match is
confirmed. The session will be terminated immediately if a match is not confirmed.
NoteNote: FFFF (monitor 4 times) will delete the Access ID number and download access will be denied.
Selections: Yes / No
Default: No
Selections: Blank, 0000 - 9999
Default: Blank
Selections: 0000 - 9999
Default: 0000
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 49
8. Schedules8. Schedules
Auto Arming Time
This section defines various schedules that are available with the SMDC.
• Schedules 1 and 2 are used to suppress the transmission of Opening and Closing reports
to the central station.
• This is achieved by:
1. Defining the periods of the Opening and Closing windows (in minutes).
2. Defining the Open Start and Close Start Time for each day of the week and for each of
the eight groups.
• Also available is the ability for the SMDC to automatically arm the control panel
at the end of the specified Closing window for Schedule One (only).
• Shown below is an example of how an Opening and Closing Schedule might be set up.
Opening Window
6:00AM 9:00AM 4:30PM 6:30PM
• Opening Reports that are generated between the hours of 6:00am and 9:00am will not be
transmitted to the central station.
• An open exception will be transmitted at 9:01am if the SMDC is not disarmed.
• Closing reports that are generated between the hours of 4:30pm and 6:30pm will not be
transmitted to the central station.
• An close exception will be transmitted at 6:31pm if the SMDC is not armed.
• Any Opening and Closing reports generated outside of the given window
will transmit to the central station.
Note:Note: Enable option 8.1.6-Report Open/Close signals if daily opening and closing report
codes are necessary.
8.1. Types8.1. Types
This menu consists of six sub menus that determine if the schedules will be functional (enable Schedule 1
& 2) and if the SMDC will be forced to transmit Open and Close signals due to irregular arming and
disarming.
8.1.1 Schedule 1
SCHEDULE 1
NO 0=NO 1=YES
Enable this option to turn on Schedule 1. This schedule pertains to the automatic arming of
the control panel and the suppression of open/close reporting. This schedule
was designed to be used by the primary personnel.
ExampleExample: normal business hours.
8.1.2 Schedule 2
SCHEDULE 2
NO 0=NO 1=YES
Enable this option to turn on Schedule 2. This schedule pertains only to the suppression of
open/close reporting. This schedule was designed to be used by the secondary personnel.
ExampleExample: abnormal hours (cleaning crew).
Closing Window
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
8. Schedules
1. Types
1. Schedule 1
2. Schedule 2
3. Close w/Bypass
4. Close w/Alarm
5. User Set
6. Report Open/Close
2. Windows System
1. Schedule 1
1. Open/Close Window
1. Open Window
2. Close Window
2. Select Group #
(1 - 8)
1. Sunday
1. Open Time
2. Close Time
2. Monday
1. Open Time
2. Close Time
3. Tuesday
1. Open Time
2. Close Time
4. Wednesday
1. Open Time
2. Close Time
5. Thursday
1. Open Time
2. Close Time
6. Friday
1. Open Time
2. Close Time
7. Saturday
1. Open Time
2. Close Time
Groups 2-8 Daily
Sched. Prog same
2. Schedule 2
(Prog same as Schd 1)
3. Holidays
4. Temporary Sched. 1
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
5. Temporary Sched. 2
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
8.1.3 Close with Bypass
CLOSE W/BYPASS
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Enable this option to force the SMDC to transmit the closing report code if a zone
is bypassed and the SMDC is being armed within the prescribed closing window.
NoteNote: Bypass report will be transmitted (if programmed) at the time of arming.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 50
8. Schedules8. Schedules
8.1 Types (continued)8.1 Types (continued)
8.1.4 Close with Alarm
CLOSE W/ALARM
NO 0=NO 1=YES
Enable this option to force the SMDC to transmit the closing report code if an alarm
condition has taken place during the disarmed period and the SMDC is being
armed within the prescribed closing window.
8.1.5 User Set
USER SET
NO 0=NO 1=YES
Enable this option to allow the user the ability to modify Schedule 1& 2, Temp Schedules
and Holidays from the user program. (see User program).
8.1.6 Report Open/Close
REPORT O/C
NO 0=NO 1=YES
Enable this option to force the SMDC to report the opening and closing
signals during the window schedule time. (see 6.4-User Report Codes).
8.2 Window System8.2 Window System
8.2.1 Schedule 1
This area of the program will allow you to program the unique characteristics of each schedule.
8.2.1.1 Open/Close Window
Select either Open window or Close window.
NoteNote: These windows do not pertain to Schedule 2.
WarningWarning: Do not overlap the Opening and Closing Windows.
8.2.1.1.1 Open Window
OPEN WINDOW
01 x 10 minutes
Enter the amount of time in minutes the user will be able to:
1) Suppress the opening code from being transmitted to the central station.
Note: Note: You must have a value of time programmed in this option for Schedule 1 to operate.
8.2.1.1.2 Close Window
CLOSE WINDOW
01 x 10 minutes
Enter the amount of time in minutes that at the end of this window the SMDC will:
1) suppress the closing code from being transmitted to the central station.
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: 1-99 minutes
Default: 01 x 10 minutes
Selections: 1-99 minutes
Default: 01 x 10 minutes
8. Schedules
1. Types
1. Schedule 1
2. Schedule 2
3. Close w/Bypass
4. Close w/Alarm
5. User Set
6. Report Open/Close
2. Windows System
1. Schedule 1
1. Open/Close Window
1. Open Window
2. Close Window
2. Select Group #
(1 - 8)
1. Sunday
1. Open Time
2. Close Time
2. Monday
1. Open Time
2. Close Time
3. Tuesday
1. Open Time
2. Close Time
4. Wednesday
1. Open Time
2. Close Time
5. Thursday
1. Open Time
2. Close Time
6. Friday
1. Open Time
2. Close Time
7. Saturday
1. Open Time
2. Close Time
Groups 2-8 Daily
Sched. Prog same
2. Schedule 2
(Prog same as Schd 1)
3. Holidays
4. Temporary Sched. 1
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
5. Temporary Sched. 2
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
Note: Note: You must have a value of time programmed in this option for Schedule 1 to operate.
8.2.1.2 Group/Partitions 1 Daily Schedule
Each day of the week may be programmed to have a unique Opening and Closing start time.
The following display will prompt you for a Group/Partition number.
SET GROUP NUMBER
(BLANK)
Selections: 1-8
Default: BLANK
Select the Group/Partition number (1-8) you wish to program, press ENTER, then CLEAR.
After CLEAR has been pressed, the days of the week (1-7) will be scrolling. Select the
the day that you wish to program by pressing the corresponding number.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 51
8. Schedules8. Schedules
8.2 Window System 8.2 Window System (continued)
8.2.1.2.1.1 Sunday Group/Partition 1.
8.2.1.2.1.1.1 Open Time
G-# OPN TIME SUN
__:__ AM 1=PM
Select the time of day the Open time is to begin.
Note:Note: To delete the time press Reset.
8.2.1.2.1.1.2 Close Time
G-# CLS TIME SUN
__:__ AM 1=PM
Select the time of day the Close time is to begin.
Note:Note: To delete the time press Reset.
8.2.1.2.1.2 Monday Group/Partition 1 - Program same as Sunday.
8.2.1.2.1.3 Tuesday Group/Partition 1 - Program same as Sunday.
8.2.1.2.1.4 Wednesday Group/Partition 1 - Program same as Sunday.
8.2.1.2.1.5 Thursday Group/Partition 1 - Program same as Sunday.
8.2.1.2.1.6 Friday Group/Partition 1 - Program same as Sunday.
8.2.1.2.1.7 Saturday Group/Partition 1 - Program same as Sunday.
After you have completed the programming for Schedule 1-Group/Partition 1,
proceed to program the remaining Schedule 1 for Groups/Partitions 2-8 as needed.
8.2.2 Schedule 2
Schedule 2 also will allow the SMDC to suppress the transmission of Opening and
Closing reports to the central station in the same fashion as Schedule 1 with the exception that
Schedule 2 does not have Open and Close windows associated to it.
Instead the alarm panel bases the limitation of communicating open and close report codes
to the central station on whether the opening and/or closing event occurs between the Open
and Close start times programmed.
Note:Note: Enable option 8.1.6-Report Open/Close signals if daily opening and closing report
codes are necessary.
8.2.2.1
The following display will prompt you for a Group/Partition number.
SET GROUP NUMBER
(BLANK)
Select the Group/Partition number (1-8) you wish to program, press ENTER, then CLEAR.
After CLEAR has been pressed, the days of the week (1-7) will be scrolling. Select the
the day that you wish to program by pressing the corresponding number.
Selections: 12:00am - 11:59pm
Default: No
Selections: 12:00am - 11:59pm
Default: No
Selections: 1-8
Default: BLANK
8. Schedules
1. Types
1. Schedule 1
2. Schedule 2
3. Close w/Bypass
4. Close w/Alarm
5. User Set
6. Report Open/Close
2. Windows System
1. Schedule 1
1. Open/Close Window
1. Open Window
2. Close Window
2. Select Group #
(1 - 8)
1. Sunday
1. Open Time
2. Close Time
2. Monday
1. Open Time
2. Close Time
3. Tuesday
1. Open Time
2. Close Time
4. Wednesday
1. Open Time
2. Close Time
5. Thursday
1. Open Time
2. Close Time
6. Friday
1. Open Time
2. Close Time
7. Saturday
1. Open Time
2. Close Time
Groups 2-8 Daily
Sched. Prog same
2. Schedule 2
(Prog same as Schd 1)
3. Holidays
4. Temporary Sched. 1
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
5. Temporary Sched. 2
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
The example screen below is shown as Sunday-Group/Partition 1.
8.2.2.1.1 Sunday Group/Partition 1
8.2.2.1.1.1 Open Time
G-# OPN TIME SUN
__ :__ AM 1=PM
Selections: 12:00am - 11:59pm
Default: No
Select the time of day the Open time is to begin.
Note:Note: To delete the time press Reset.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 52
8. Schedules8. Schedules
8.2 Window System8.2 Window System
8.2.2 Schedule 28.2.2 Schedule 2 (continued)
8.2.2.1.1.1.2 Close Time
G-# CLS TIME SUN
__:__ AM 1=PM
Select the time of day the Close time is to begin.
Note:Note: To delete the time press Reset.
8.2.2.1.2 Monday Group/Partition 1 - Program the same as Sunday
8.2.2.1.3 Tuesday Group/Partition 1 - Program the same as Sunday
8.2.2.1.4 Wednesday Group/Partition 1 - Program the same as Sunday
8.2.2.1.5 Thursday Group/Partition 1 - Program the same as Sunday
8.2.2.1.6 Friday Group/Partition 1 - Program the same as Sunday
8.2.2.1.7 Saturday Group/Partition 1 - Program the same as Sunday
After you have completed the programming for Schedule 2 - Group/Partition 1,
proceed to program the remaining Schedule 2 for Groups/Partitions 2-8 as needed.
8.2.3. Holidays
Close and Open Exception codes (if programmed) will not be transmitted to the central
station on days that are designated as Holidays. Holidays are also considered irregular
opening and closings. Therefore this option allows for the transmission of the Open and
Close report code should there be arm/disarm activity on day(s) designated as holidays
during the prescribed open and close windows.
8.2.3.1 Add Holiday
8.2.3.1.1 Date
DATE
00/00/00
Select the date that the holiday will occur.
8.2.3.1.2 Number of Days
NUMBER OF DAYS
00
Select the number of days for the above holiday.
8.2.3.2 Delete Holiday
8.2.3.2.1 Date
DATE
00/00/00
Select the day the holiday will end.
Selections: 12:00am - 11:59pm
Default: No
Selections: MM/DD/YY
Default: No Date
Selections: 00-99
Default: No Date
Selections: MM/DD/YY
Default: No Date
8. Schedules
1. Types
1. Schedule 1
2. Schedule 2
3. Close w/Bypass
4. Close w/Alarm
5. User Set
6. Report Open/Close
2. Windows System
1. Schedule 1
1. Open/Close Window
1. Open Window
2. Close Window
2. Select Group #
(1 - 8)
1. Sunday
1. Open Time
2. Close Time
2. Monday
1. Open Time
2. Close Time
3. Tuesday
1. Open Time
2. Close Time
4. Wednesday
1. Open Time
2. Close Time
5. Thursday
1. Open Time
2. Close Time
6. Friday
1. Open Time
2. Close Time
7. Saturday
1. Open Time
2. Close Time
Groups 2-8 Daily
Sched. Prog same
2. Schedule 2
(Prog same as Schd 1)
3. Holidays
4. Temporary Sched. 1
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
5. Temporary Sched. 2
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
8.2.3.2.2 Number of Days
NUMBER OF DAYS
00
Selections: 00-99
Default: No Date
Select the number of days of the holiday
8.2.3.3. View Holiday
This option is for viewing purposes only and therefore no programming is allowed.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 53
8. Schedules8. Schedules
8.2 Window System 8.2 Window System (continued)
8.2.4 Temporary Schedule 1
Temporary Schedules allow the user to set up a temporary schedule which will override
Schedule 1 and 2 for the day that is specified. This is useful for days which have not been
programmed for regular open and close times in Schedule 1 and/or Schedule 2.
Group/Partition 1 is used for the example.
8.2.4.1 Group/Partition 1
The following display will prompt you for a Group/Partition number.
SET GROUP NUMBER
(BLANK)
Once you have selected the Group/Partition number (1-8), press ENTER, then CLEAR.
After CLEAR has been pressed, the following screen will be display.
8.2.4.1.1 Select Date
1 SELECT DATE
__/__/__
Select the date when Temporary Schedule 1 will be active.
8.2.4.1.2 Open Start Time
1 OPEN START
__:__ AM 1=PM
Select the Open Start time for Temporary Schedule 1.
8.2.4.1.3 Close Start Time
1 CLOSE START
__:__ AM 1=PM
Select the Close Start time for Temporary Schedule 1.
After you have completed the programming for Temporary Schedule 1-Group/Partition 1,
proceed to program the remaining Temporary Schedule 1 for Groups/Partitions 2-8 as needed.
8.2.5 Temporary Schedule 2
Temporary Schedules allow the user to set up a temporary schedule which will override
Schedule 1 and 2 for the day that is specified. This is useful for days which have not been
programmed for regular open and close times in Schedule 1 and/or Schedule 2.
Group/Partition 1 is used for the example.
8.2.5.1 Group/Partition 1
The following display will prompt you for a Group/Partition number.
SET GROUP NUMBER
(BLANK)
Once you have selected the Group/Partition number (1-8), press ENTER, then CLEAR.
After CLEAR has been pressed, the following screen will be display.
Selections: 1-8
Default: BLANK
Selections: MM/DD/YY
Default: No Date
Selections
Default: No Time
Selections
Default: No Time
Selections: 1-8
Default: BLANK
8. Schedules
1. Types
1. Schedule 1
2. Schedule 2
3. Close w/Bypass
4. Close w/Alarm
5. User Set
6. Report Open/Close
2. Windows System
1. Schedule 1
1. Open/Close Window
1. Open Window
2. Close Window
2. Select Group #
(1 - 8)
1. Sunday
1. Open Time
2. Close Time
2. Monday
1. Open Time
2. Close Time
3. Tuesday
1. Open Time
2. Close Time
4. Wednesday
1. Open Time
2. Close Time
5. Thursday
1. Open Time
2. Close Time
6. Friday
1. Open Time
2. Close Time
7. Saturday
1. Open Time
2. Close Time
Groups 2-8 Daily
Sched. Prog same
2. Schedule 2
(Prog same as Schd 1)
3. Holidays
4. Temporary Sched. 1
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
5. Temporary Sched. 2
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
8.2.5.1.1 Select Date
1 SELECT DATE
__/__/__
Selections: MM/DD/YY
Default: No Date
Select the date when Temporary Schedule 2 will be active.
8.2.5.1.2 Open Start Time
1 OPEN START
__:__ AM 1=PM
Selections
Default: No Time
Select the Open Start time for Temporary Schedule 1.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 54
8. Schedules8. Schedules
8.2 Window System 8.2 Window System (continued)
8.2.5 Temporary Schedule 2 (continued)
8.2.5.1.3 Close Start Time
1 CLOSE START
__:__ AM 1=PM
Select the Close Start time for Temporary Schedule 2.
After you have completed the programming for Temporary Schedule 2-Group/Partition 1,
proceed to program the remaining Temporary Schedule 2 for Groups/Partitions 2-8 as needed.
8.3 Auto Arm8.3 Auto Arm
Auto arm will allow for the SMDC to arm itself automatically should the user
inadvertently vacate the premises without entering his or hers PIN. All zones must be in a
secure condition for the panel to successfully perform an auto arm.
Note:Note: The Auto Arm feature follows the prescribed times set forth in schedule one only for a
Group or Non-Group system.
Note: Note: The Auto Arm feature follows the prescribed times set forth in schedules 1-8 only for a
Keypad Partitioned system.
(see 8.1.1-Schedule 1 Enabled / 8.2.1-Schedule System).
8.3.1 Auto Arm On
AUTO ARM ON
NO 0=NO 1=YES
Enable this option for the Auto Arm function to operate.
Note:Note: Auto arm will not perform if zone(s) are not secure.
8.3.2 Auto Arm Code
AUTO ARM CODE
code NO
Select the Auto Arm report code that will be transmitted to the central station if the
SMDC has successfully performed an auto arm.
(see 8.3.3-Auto Arm Fail Code / SIA-Contact ID-Hex chart on page 42 & 43).
8.3.3 Auto Arm Fail Code
AUTO FAIL CODE
code NO
Select the Auto Arm Fail report code that will be transmitted to the central station if the
SMDC has not successfully performed an auto arm.
(see 8.3.2-Auto Arm Code / SIA-Contact ID-Hex chart on page 42 & 43).
8.3.4 Pre Close Warning
PRE-CLOSE WARNING
NO 0=NO 1=YES
Enable this option to allow the SMPCs to emit a tone 10 minutes prior to the end of
the close window for Schedule 1 only.
Selections
Default: No Time
Selections: Yes / No
Default: No
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: Yes / No
Default: No
8. Schedules
1. Types
1. Schedule 1
2. Schedule 2
3. Close w/Bypass
4. Close w/Alarm
5. User Set
6. Report Open/Close
2. Windows System
1. Schedule 1
1. Open/Close Window
1. Open Window
2. Close Window
2. Select Group #
(1 - 8)
1. Sunday
1. Open Time
2. Close Time
2. Monday
1. Open Time
2. Close Time
3. Tuesday
1. Open Time
2. Close Time
4. Wednesday
1. Open Time
2. Close Time
5. Thursday
1. Open Time
2. Close Time
6. Friday
1. Open Time
2. Close Time
7. Saturday
1. Open Time
2. Close Time
Groups 2-8 Daily
Sched. Prog same
2. Schedule 2
(Prog same as Schd 1)
3. Holidays
4. Temporary Sched. 1
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
5. Temporary Sched. 2
1. Select Group #
(1 - 8)
1. Select Date
2. Open Start
3. Close Start
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 55
9. Partitions / Groups9. Partitions / Groups
9. Partitions
Partitions/Groups allows for two distinct modes of operation that cannot be intermixed.
This features allows you to customize the SMDC to fit all your installation needs. It is
imperative that this section be fully understood to be of use to you and your customer.
It is recommended that you read this section carefully and if you have any questions to
call our technical support before programming.
Keypad PartitioningKeypad Partitioning
Programming
◊ In this mode you assign zones to partitions (see 9.2-Zone Assignment).
◊ You are then allowed to assign one or more keypads to each of the Partitions (see 9.3-
Assignment Keypad).
◊ You must then assign the user to the partition(s) from the installers program.
(see 9.4-User Assignment).
◊ You may have separate auto arming schedules
Operation
• The user is allowed to control more than one partition but the user must perform the
command from the keypad assigned to the partition.
• The user can only view the alarm activity and history that has occurred in his partition
from the keypad(s) assigned to his partition.
• This type of program would normally be used if you had a need for multiple alarm panels
using a single control panel.
Group ArmingGroup Arming
Programming
◊ In this mode you must assign zones to Groups (see 9.2-Zone Assignment).
◊ All keypads must be assigned to Group/Partition one (see 9.3-Keypad Assignment).
◊ User PINs are then assigned to groups (see User Program).
◊ You can have only one auto arm time.
Operation
• In this mode the subscriber may arm/disarm any group from any keypad.
• User can view the alarm activity and history for the entire alarm panel from any
installed keypad.
• This type of program would be used when you had a need for a single alarm system
with multiple areas and the user needed the ability to control multiple areas from a
single keypad.
1. Types
1. Keypad Partition
2. Group Arming
3. Total # of Groups
4. Common Partition #
2. Zones Partition
1. Partition 1
1.Zone Assignment
2.Open Code
3.Close Code
2. Partition 2
1.Zone Assignment
2.Open Code
3.Close Code
3. Partition 3
1.Zone Assignment
2.Open Code
3.Close Code
4. Partition 4
1.Zone Assignment
2.Open Code
3.Close Code
5. Partition 5
1.Zone Assignment
2.Open Code
3.Close Code
6. Partition 6
1.Zone Assignment
2.Open Code
3.Close Code
7. Partition 7
1.Zone Assignment
2.Open Code
3.Close Code
8. Partition 8
1.Zone Assignment
2.Open Code
3.Close Code
3. Keypad Part. Assign.
1. Keypad 1 Part. #
2. Keypad 2 Part. #
3. Keypad 3 Part. #
4. Keypad 4 Part. #
5. Keypad 5 Part. #
6. Keypad 6 Part. #
Note:Note: If neither of the above mentioned applications fit your installation, call tech
support or do not perform any programming in this section
9.1 Types9.1 Types
You may select either Keypad Partition or Group Arming.
Note:Note: You cannot select both.
9.1.1 Keypad Partition
KEYPAD PART
NO 0=NO 1=YES
Enable this option to allow the SMDC to use the method described above.
9.1.2 Group Arming
GROUP ARMING
NO 0=NO 1=YES
Enable this option to allow the SMDC to use the method described above.
9.1.3 Total # of Groups
NUMBER OF GRPS
01
Enter the total number of groups or partitions that will be needed.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Selections: Yes / No
Default: No
Selections: Yes / No
Default: No
Selections: 1 - 8
Default: 1
Page 56
9. Partitions / Groups9. Partitions / Groups
9. Partitions
9.1. Types (continued)9.1. Types (continued)
1. Types
1. Keypad Partition
2. Group Arming
3. Total # of Groups
4. Common Partition #
9.1.4. Common Group #
COMMON GRP #
00
A typical application for a Common Group to be used is where multiple groups
share a common entrance area. When the last user arms his group, the Common Group
will begin it’s exit delay time automatically. Conversely, when all groups are armed
(including the Common Group), the first user to disarm their group will also disarm the
Common Group.
Note: Note: The Common Group may be used only if Group Arming is enabled. This will not work
with Partitioning.
9.2. Zones Groups / Partition9.2. Zones Groups / Partition
This programming menu is common to both a Partition system or Group Arm system.
9.2.1 Select Group / Partition #
SELECT GROUP #
00
Select the group number that is to be programmed, press ENTER and then press CLEAR.
9.2.1.1 Group / Partition 1 Zones
G-1 SEL ZONE ##
yyyyyyyyyyyyyyyy
• Group number 1 will have the first 16 zones automatically assigned as the default.
• Please note the bottom line has 16 Y’s which represent YES that all sixteen zones
are assigned to partition number 1.
• Partitions 2 - 8 will have all zones defaulted as N’s (NO)
• Please note the upper right hand corner of the LCD will be displaying which zone
number the cursor is on.
• To advance to the next zone press either 1 which equals yes or 0 which equals no. The
cursor will automatically advance to the next zone and the zone number display will
also advance automatically to the next zone.
• To move the cursor without changing the program, you may press the Walk key
to move to the left or Monitor key to move to the right
9.2.1.2 Partition 1 Open Code
OPEN CODE
code NO
Enter the appropriate Open report code for this partition.
Note:Note: The SMDC will send User Open codes plus Partition Open codes if so programmed.
Warning: Warning: This code does not transmit if Group arm is selected.
(see 6.4-Open-Close Report Codes / SIA-Contact ID-Hex chart on page 42 & 43).
Selections: Yes / No
Default: 00
Selections: 1 - 8
Default: 00
Selections: Yes / No
Default: Yes
Selections: 01-FF / Contact ID / SIA
Default: No Report
2. Zones Partition
1. Partition 1
1.Zone Assignment
2.Open Code
3.Close Code
2. Partition 2
1.Zone Assignment
2.Open Code
3.Close Code
3. Partition 3
1.Zone Assignment
2.Open Code
3.Close Code
4. Partition 4
1.Zone Assignment
2.Open Code
3.Close Code
5. Partition 5
1.Zone Assignment
2.Open Code
3.Close Code
6. Partition 6
1.Zone Assignment
2.Open Code
3.Close Code
7. Partition 7
1.Zone Assignment
2.Open Code
3.Close Code
8. Partition 8
1.Zone Assignment
2.Open Code
3.Close Code
3. Keypad Part. Assign.
1. Keypad 1 Part. #
2. Keypad 2 Part. #
3. Keypad 3 Part. #
4. Keypad 4 Part. #
5. Keypad 5 Part. #
6. Keypad 6 Part. #
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 57
9. Partitions / Groups9. Partitions / Groups
9. Partitions
9.2. Zones Groups / Partition (continued)9.2. Zones Groups / Partition (continued)
1. Types
1. Keypad Partition
2. Group Arming
3. Total # of Groups
4. Common Partition #
9.2.1.3 Partition 1 Close Code
OPEN CODE
code NO
Enter the appropriate Close report code for this partition.
Note:Note: The SMDC will send User Close codes plus Partition Close codes if so
programmed.
Warning: Warning: This code does not transmit if Group arm is selected.
(see 6.4-Open-Close Report Codes / SIA-Contact ID-Hex chart on page 42 & 43).
Program the remaining partitions with the unique characteristics for each in the same
fashion as the above example for partition one.
9.2.2. Partition 2 - Zones Assignment + Open & Close Report Codes
9.2.3. Partition 3 - Zones Assignment + Open & Close Report Codes
9.2.4. Partition 4 - Zones Assignment + Open & Close Report Codes
9.2.5. Partition 5 - Zones Assignment + Open & Close Report Codes
9.2.6. Partition 6 - Zones Assignment + Open & Close Report Codes
9.2.7. Partition 7 - Zones Assignment + Open & Close Report Codes
9.2.8. Partition 8 - Zones Assignment + Open & Close Report Codes
9.3. Keypad Partition9.3. Keypad Partition
AssignmentAssignment
Assign the installed keypad numbers to the appropriate partition.
NoteNote: Keypad numbers 1-2-3-4 are defaulted as assigned to partition one.
Note: Note: A keypad canot be assigned to more than one partition.
9.3. 1 Keypad 1 Partition #
KEYPAD 1 PART
01
Select which partition keypad 1 will be assigned to.
9.3.2 Keypad 2 Partition # Select which partition keypad 2 will be assigned to.
9.3.3 Keypad 3 Partition # Select which partition keypad 3 will be assigned to.
9.3.4 Keypad 4 Partition # Select which partition keypad 4 will be assigned to.
9.3.5 Keypad 5 Partition # Select which partition keypad 5 will be assigned to.
9.3.6 Keypad 6 Partition # Select which partition keypad 6 will be assigned to.
9.3.7 Keypad 7 Partition # Select which partition keypad 7 will be assigned to.
9.3.8 Keypad 8 Partition # Select which partition keypad 8 will be assigned to.
Selections: 01-FF / Contact ID / SIA
Default: No Report
Selections: 1 - 8
Default: 1
2. Zones Partition
1. Partition 1
1.Zone Assignment
2.Open Code
3.Close Code
2. Partition 2
1.Zone Assignment
2.Open Code
3.Close Code
3. Partition 3
1.Zone Assignment
2.Open Code
3.Close Code
4. Partition 4
1.Zone Assignment
2.Open Code
3.Close Code
5. Partition 5
1.Zone Assignment
2.Open Code
3.Close Code
6. Partition 6
1.Zone Assignment
2.Open Code
3.Close Code
7. Partition 7
1.Zone Assignment
2.Open Code
3.Close Code
8. Partition 8
1.Zone Assignment
2.Open Code
3.Close Code
3. Keypad Part. Assign.
1. Keypad 1 Part. #
2. Keypad 2 Part. #
3. Keypad 3 Part. #
4. Keypad 4 Part. #
5. Keypad 5 Part. #
6. Keypad 6 Part. #
9.4. Users Assignment (Partitioning only)9.4. Users Assignment (Partitioning only)
In this section users are assigned any partition from 1-8. More than one partition may be
assigned to any user. For Keypad Partition system, partitions may only be assigned to user
from installer menu whereas in a Group Arm system, groups may only be assigned from
User’s program.
U-1 SELECT G-01
Y N N N N N N N
This option will allow for the assignment of Partitions to the individual user PINs. Press the
number that corresponds to the Group number.
ExampleExample: group numbers 2-3-5-7 - Press 2-3-5-7.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Selections: 1-2-3-4-5-6-7-8
Default: Y N N N N N N N
Page 58
0. Pager / Fax / Printer - Options0. Pager / Fax / Printer - Options
These options allow you to customize the SMDC to send various report codes to a
pager service, call and print history reports to an on site or remote fax machine and also
print history reports to an on site serial printer.
Notes: External modem required for fax option.
The SMDC-INT-P/F (fax and printer) options are not for Commercial Fire Applications
0.1 Pager Options0.1 Pager Options
0.1.1 Pager Telephone 1
PAGER TELEPHONE 1
(BLANK)
Enter the telephone number for the first pager service to be dialed.
(see Dialer Chart below).
0.1.1 Pager Telephone 2
PAGER TELEPHONE 2
(BLANK)
Enter the telephone number for the second pager service to be dialed.
(see Dialer Chart below).
Dialer Chart
Selections = 0 through 9
Instant Key = 3 second dial pause (appears as a “:”)
Memory Key = 5 second dial tone detect (appears as a “;”)
Stay Key = # (pound)
Away Key = * (asterisk)
Selections: 0-9 : ; # *
Default: Blank
Selections: 0-9 : ; # *
Default: Blank
0. Pager-Fax-Printer
1. Pager Options
1. Telephone Number 1
2. Telephone Number 2
3. Pager Delay
4. Alarm Report
5. Open/Close Report
6. Open/Close Fail Rpt
7. System Report
2. Fax Options
1. Fax phone Number
2. Modem Command
3. Fax Class 2.0
4. Fax Time
5. Fax Schedule
1. Daily
2. Weekly
3. Monthly
3. Printer Options
1. All Events
0.1.3 Pager Delay
PAGER DELAY
0-0 seconds
Selections: 0 - 9 seconds
Default: 0-0
Select the amount of “wait” time before the SMDC will transmit the report code after
the connection has been made to the pager by the paging service. The first entry in this location
will be for telephone number one and the second entry will be telephone number two.
Note:Note: It is recommended to contact the paging service for the correct amount of time or
send a few test transmissions to ensure the correct amount of time has been entered.
0.1.4 Alarm Reports
ALARM REPORTS
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Select this option to allow the Alarm reporting codes to be sent to the paging service after
the digital communication signal has been kissed off at the central station.
Zone Alarm-Trouble-Bypass-Cancel-Restore codes will be transmitted.
0.1.5 Open / Close Report
OPEN/CLOSE REPORT
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Select this option to allow the Open and Close reporting codes to be sent to the paging
service after the digital communication signal has been kissed off at the central station.
0.1.6 Open / Close Fail Report
O/C FAIL REPORT
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Select this option to allow the Open and Close Fail reporting codes to be sent to the
paging service after the digital communication signal has been kissed off at the central station.
0.1.7 System Report
SYSTEM REPORT
NO 0=NO 1=YES
Selections: Yes / No
Default: No
Select this option to allow the System report codes to be sent to the paging service
after the digital communication signal has been kissed off at the central station.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 59
0. Pager - Fax - Printer Options0. Pager - Fax - Printer Options
0.2 Fax Options0.2 Fax Options
This selection details the programming options for the transmission of the history
buffer to a fax machine. The volume of history transmitted will depend on the usage
of this option. The first history event that will be sent to the fax will be the first
event after the last event sent previously. Note: External modem required for fax option.
0.2.1 Fax Telephone Number
FAX TELEPHONE #
00000000000000000
Select up to 16 digits/characters for the telephone and any required delays or
access codes. (see dialer chart below).
Dialer Chart
Selections: = 0 through 9
Instant Key = 3 second dial pause (appears as a “:”)
Memory Key = 5 second dial tone detect (appears as a “;”)
Stay Key = # (pound)*
Away Key = * (asterisk)
0.2.2 Modem Command
MODEM COMMAND
(BLANK)
Select up to 16 digits/characters for the modem command (initialization string)
using numeric and the alphabet table on page 19.
Selections: 0-9 : ; # *
Default: 00000000000000000
Selections:
Default: Blank
0. Pager-Fax-Printer
1. Pager Options
1. Telephone Number 1
2. Telephone Number 2
3. Pager Delay
4. Alarm Report
5. Open/Close Report
6. Open/Close Fail Rpt
7. System Report
2. Fax Options
1. Fax phone Number
2. Modem Command
3. Fax Class 2.0
4. Fax Time
5. Fax Schedule
1. Daily
2. Weekly
3. Monthly
3. Printer Options
1. All Events
0.2.3 Fax Class 2.0
FAX CLASS 2.0
NO 0=NO 1=YES
Select the modem class by entering either:
Yes = class 2.0 / No = class 2
Note:Note: consult your modem manual to determine the class.
0.2.4 Fax Time
TIME HH:MM
__:__ AM 1=PM
Select the time of day the SMDC will transmit the entire history buffer to the
fax machine. (see 0.2.5-Fax Schedule).
0.2.5 Fax Schedule
FAX SCHEDULE 0
(SCROLLING)
Select the regularity the alarm panel will transmit the history to the fax machine.
Your options are: 1. Daily.
2. Weekly (Sunday only).
3. Monthly (1
0.3 Printer Options0.3 Printer Options
0.3.1 Printer Enabled
PRINTER ENABLED
NO 0=NO 1=YES
This options determines if the alarm panel will be transmitting the events to the on site printer.
Selections: Yes / No
Default: No
Selections: 12:00am - 11:59pm
Default: 12:00am 1=pm
Selections: 01-03
Default: 0
st
day of month).
Selections: Yes / No
Default: No
0.3.2 Logging Options
LOGGING OPTIONS 0
(SCROLLING)
Selections: 01-03
Default: 0
This options determines the type of events the alarm panel will be transmitting to the on site printer.
Your options are: 01. All occurrences.
02. Alarm occurrences.
03. Open and Close occurrences.
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 60
U.L. Information Addendum
• The exit delay time shall not exceed 60 seconds. (section 1.1.3)
• The entry delay time shall not exceed 45 seconds. (section 1.1.2)
• The sounder cutoff time shall not be less than 4 minutes. (section 1.2)
• The AC power failure report time shall not be more than 360 minutes. (section 1.1.4)
• The delay before Dial time shall be 0 seconds. (section 3.5.4)
• “Normally Open” loop type is only suitable for Grade B, Household Burglary. (section 2.1.1)
• “Normally Closed” loop type is only suitable for Grade B, Household Burglary. (section 2.1.1)
• “Normally Open/Normally Closed” loop type is only suitable for Grade A, Household Burglary and Commercial
Burglary. (section 2.1.1)
• The dial attempts shall not be less than 5 and more than 10. (section 3.4)
• If fire alarm verification feature is used, the “Fire Alarm Verify” feature shall be enabled. (section 4.6.5)
• The ‘alarm verify’ noted in 2.1.9 should not be used in any UL listed application. (section 2.1.9)
• DACT and BELL shall be tested every 24 hours for Commercial Fire. (section 1.3 & 6.4.7)
• For Fire bell to Ring in Temporal Pattern, the following settings must be entered:
1. Zone Type must be set to Fire Zone (section 2.1.1).
2. Bell 1 must be set to Yes (section 2.8.1).
3. Bell 1 Pulse must be set to Yes (section 2.8.2).
4. Temporal Fire must be set to Yes (section 4.9).
• The SMDC-WX (wireless features) has not been investigated for use in UL Listed Fire Applications
or UL Listed Burglar Applications. (section 2.7)
Optex Inc. - 1845 W 205th St. - Torrance, Ca. 90501 - 800-966-7839 SMDC-16 Program Manual 3440-0252 A4
Page 61
Filename: 252_A4.DOC
Directory: C:\WINDOWS\Desktop\SMDC PDF\Prg Man
Template: C:\Program Files\Microsoft Office\Templates\Normal.dot
Title:
Subject:
Author: Unknown
Keywords:
Comments:
Creation Date: 01/25/00 15:16
Change Number: 30
Last Saved On: 01/26/00 09:56
Last Saved By: Joshua
Total Editing Time: 94 Minutes
Last Printed On: 01/26/00 10:50
As of Last Complete Printing
Number of Pages: 60
Number of Words: 19,722 (approx.)
Number of Characters: 112,420 (approx.)
Loading...
